502 D
Cooker hood
Operating and Installation Instructions
OKO SYSTEM
2
MADE IN GERMANY
Printed on recycled paper.
AEG – putting words into action.
Contents
Electrical connections.......................................................... 4
Safety warnings for electricians .............................................. 4
Appliances with 2 wires .......................................................... 5
Safety warnings for kitchen unit installer ................................6
General details........................................................................7
Extractor version ..................................................................... 7
Filter Version ........................................................................... 8
Description of the appliance................................................ 9
Technical details ................................................................... 9
Fixing the hood ..................................................................... 10
Safeting warnings for user .................................................... 11
Hood operation .....................................................................12
Care and maintenance........................................................13
Metal grease filter ................................................................ 13
Charcoal filter........................................................................14
Replacing the lamps ............................................................. 15
Cleaning................................................................................15
Special accessories............................................................16
What to do if ........................................................................ 16
Service and spare parts ..................................................... 17
Customer Care .................................................................... 17
Guarantee conditions ......................................................... 18
3
Electrical connections
Safety
warnings for
electrician
It must be ensured that the voltage and current indicated on the
rating plate agree with the voltage of the user to electricity supply.
If the appliance has been equipped with a mains lead with a
moulded-on type plug, the following regulations must be comply
with:
The plug moulded on to the lead incorporates a fuse. For replacement, use a 5 amp BS1362 fuse. Only ASTA approved or certified
fuses should be used. If the fuse cover/carrier is lost, a replacement cover/carrie must be obtained from an electrical goods
retailer. If the socket outlets are not suitable for the plug fitted to
the appliance, then the plug must be cut off and destroyed for
safety reasons, and an appropriate plug be fitted.
When wiring the plug ensure that all strands of wire are securely
retained in each terminal. Do not forget to tighten the mains lead
clamp on the plug.
Electrical connections
230 V - using fixed power supply line with plug.
240 V - using fixed power supply line (Great Britain).
Fuse rating 13 amps
(The unit should only be connected up by an authorized electrician).
See rating plate for further information.
It is recommended that the socket for the plug is sited above the
cooker hood or above the overhead cabinet.
This has 2 advantages:
1) The socket is not visible.
2) The appliance can easily be unplugged when necessary.
If a fixed connection is required the cooker hood should be
connected by an electrical installer registered with a competent
electricity company. An isolating device is to be provided on the
fixed wiring side. Switches with a contact opening of more than
3mm apply as isolating devices.
These include-automatic cut-out switches, fuses and contactors
(VDE 0730, s. 7, Part1).
4
Electrical connection for the UK
The appliance must be connected to fixed wiring with a double
pole switched fused spur outlet with or without pilot lamp.
We strongly recommend the appliance to be connected only by a
qualified electrician who is a member of the NICEIC who will comply with the IEE and any local regulations.
NOTE:
The terminology “DOUBLE POLE” means that both the live
and the neutral supplies are switched and disconnected at
the same time.
The terminations labelled SUPPLY are for the connection for the
internal house wiring and the terminations labelled LOAD are for
the appliance.
IMPORTANT
The wires of the mains lead supplied with this appliance are
coloured in accordance with the following code:
Blue-Neutral
Brown-Live
As the colours of the flexible cord of this appliance may not
correspond with the coloured markings identifying the terminals in the plug, proceed as follows: The wire which is
coloured brown must be connected to the terminal which is
marked with the letter L or coloured red.
The wire which is coloured blue must be connected to the
terminal which is marked with the letter N or coloured black.
Appliances
with 2 wires
FUSE
BLUE
(NEUTRAL)
SUPPLY
N
ON
N
LOAD
SUPPLY
DP 13A, 250V
BROWN
(LIVE)
L
LOAD
L
5
Safety
warnings for
kitchen unit
installer
When the unit is used in its extractor version, a sufficiently large
ventilation hole must be provided, with dimensions that are
approximately the same as the outlet hole.
The air outlet must not be connected to chimney flues or combustion gas ducts. The air outlet must under no circumstances be
connected to ventilation ducts for rooms in which fuel-burning
appliances are installed.
It is advisable to apply for authorization from the relevant controlling authority when connecting the outlet to an unused chimney
flue or combustion gas duct.
The air outlet installation must comply with the regulations laid
down by the relevant authorities.
National and regional building regulations impose a number of
restrictions on using hoods and fuel-burning appliances connected to a chimney, such as coal or oil room-heaters and gas
fires, in the same room.
The local decree on fuel-burning systems specifies a maximum
depression of 0.04 mbar in such rooms.
Hoods can only be used safely with appliances connected to a
chimney if the room and/or flat (air/environment combination) is
ventilated from outside using a suitable ventilation hole approximately 500-600 cm2 large to avoid the possibility of negative
pressure being created during operation of the hood.
If you have any doubts, contact the relevant controlling authority
or building inspector’s office.
Since the rule for rooms with out fuel burning appliances is “air
inlet should be same size as extractor outlet hole”, an aperture of
500-600 cm2, which is to say a larger hole, could reduce the
performance of the extractor hood.
If the hood is used in its filtering version (carbon filter), it will
operate simply and safely in the above conditions without the
need for any of the aforementioned measures.
When the hood is used in its extractor function, the following rules
must be followed to obtain optimal operation:
— short and straight outlet hose
— minimum number of bends in the outlet hose
— Install hoses with an acute angle, always following a gentle
curve only
— hose as large as possible (100 mm Ø).
Failure to observe these basic rules will drastically reduce the
performance and increase the noise levels of the extractor hood.
6
When used as an extractor unit, the hood must be fitted with a
100mm diameter hose.
If the fumes must be forced out through the wall, you must obtain
a MKZ sizable wall exhaust pipe (with external exhaust and air
intake), E-Nr.- 610 899 004 (Ø 120 mm) which is one of our
optional parts.
When installing the hood, make sure you respect the following minimum distance from the top edge of the cooking hob/
ring surfaces:
electric cookers 650 mm
gas cookers 700 mm
coal and oil cookers 900 mm min.
General details
The hood is supplied as a ducted version, but may also be used
in recirculation mode by inserting a charcoal filter (Special accessories).
The air is ducted out through a pipe which is connected to the
outlet hole A (fig. 1) by means of a coupling flange B.
To connect the hood to a wall box, you use hoses and wall boxes
as offered on the AEG price list as optional extras.
B
A
1
Extractor
version
7
Description of the appliance
1) Light switch
2) Motor switch
3) Work surface lamp
4) Grid
3
4
Technical details
2
1
Model 502 D
Net weight: 5 kg
Height 145 mm
Width 520 mm
Depth 285 mm
Absorbed power: 160W
Motor: 1 x 120 W
Lighting: 1 x 40 Watt
Lengt of the cable: 110 cm
Fan powers (speed), speed in compliance with DIN 44971
Speed: 1 2 3
Extractor version: 126 m
Filter version: 110 m
Flange: 100 mm Ø
3
/h 149 m3/h 185 m3/h
3
/h 133 m3/h 170 m3/h
9
Fixing
the hood
After having adjusted the hood for the version required, it may be
installed.
This appliance is designed for fitting in a cabinet or some other
support.
The opening to be made on the bottom of the wall-hung cabinet
must correspond with the measurements shown in fig. 4
(495 X 260 mm).
To fix the hood proceed as follows:
a) remove the grid.
b) Fit the hood into the opening.
c) Secure the unit to the cabinet by screwing up screws through
holes C (fig. 4).
d) Replace the grid.
C
C
4
10
The hood is fitted with one variable speed motor.
The most effective use of the hood is obtained by switching it on
a few minutes before you start cooking and leaving it on a for
approximately 5-15 minutes after having finished, thus ensuring
that all that cooking odours are eliminated.
Never leave a cooking hob or ring on without a pot or pan on
top of it, to avoid the possibility of excess heat damaging the
unit. Gas, oil or coal cooker flames in particular should never
be left uncovered.
Special care should be taken when using deep fat fryers
since the oil in them can overheat and burst into flames.
The risk of fat catching fire is increased when using dirty oil.
It is extremely important to note that overheating can cause
a fire.
Never carry out any flambé cooking under the hood.
Always disconnect the unit from the power supply before
carrying out any work on the hood, including replacing the
light bulb (take the cartridge fuse out of the fuse holder or switch
off the automatic circuit breaker).
It is very important to clean the hood and the grease filters at
the recommended intervals. Failure to do so could cause
grease deposits to build up, causing a fire hazard.
Safety warnings for user
11
Hood Operation
Controls
The hood is fitted with a variable speed motor. The most effective
use of the hood is obtained by switching it on a few minutes before
you start cooking and leaving it on a for approximately 15 minutes
after you have finished, thus ensuring all cooking odours are
eliminated. The control switches are located on the unit’s front
panel: the light switch (A) switches the hood lamp on and off;
the motor switch (B) switches the cooking smoke and vapour
extractor motor on and off, enabling you to select one of the three
different speeds.
B
A
12
Care and Maintenance
Before performing any maintenance operation, disconnect the
hood from the electricity.
The hood has a metal grease filter.
To clean the filter, proceed as follows:
Open the grill by turning knob A (fig. 2).
A
2
Pull the two plastic stops B as shown by the arrows (fig. 5) and
remove the metal filter.
B
A
B
Metal
grease filter
5
You should take out the metal filter every four weeks and wash it
either in the dishwashing machine or by hand.
Clean the internal housing only with warm washing-up water —
do not use any harsh cleaners, brushes, or abrasive.
Soak metal filter cassette for about one hour in hot water with a greaseloosening cleaner, then rinse off thoroughly with hot water. Repeat the
process if necessary.
Place metal filter cassette in dishwasher. Select most powerful washing
program and highest temperature, at least 65° C. Repeat the process.
Re-fit the cassette when it is dry.
When washing the metal grease filter in the dishwasher a slight discoloration
of the filter can occur.
Re-fit the cassette when it is dry.
Hand-washing
Dishwashing
machine
13
Always turn off the electricity before replacing lamps!
1) Remove the grid (Fig. 2) in order to check the lamps and
replace them if necessary.
Replacing
the lamps
A
2
2) Unscrew the lamps that do not work and replace them with
40W max lamps (E14).
If the light does not function, check that the lamps are properly
screwed before contacting a customers’ service centre.
Warning: always disconnect the hood from the mains power
supply before cleaning it.
Never insert pointed objects in the motor’s protective grille.
Wash the outside surfaces using a mild detergent solution.
Never use caustic detergents or abrasive brushes or powders.
Only ever clean the switch panel and filter grille using a damp
cloth and mild detergents.
It is extremely important to clean the unit and change the
filters at the recommended intervals. Failure to do so will
cause grease deposits to build up that could constitute a fire
hazard.
A
Cleaning
Attention
Failure to observe the rules for cleaning the appliance and
changing and cleaning the filters may cause fire. Therefore,
properly observing these instructions is highly recommended.
15
Special accessories
See AEG price-list for wallbox and hose accessories.
KF-Plus charcoal filter E-Nr. 942 118 620
What to do if
If your appliance fails to work properly please carry out the
following checks.
Symptom Solution
The cooker hood will not start... Check that:
The hood is connected to
the electricity supply.
Check that the fan speed
control is set to 1, 2 or 3.
The cooker hood is not working Chec k that:
effectively.. The fan speed is set high
enough for the task.
The grease filters are
clean.
The kitchen is adequately
vented to allow the entry of
fresh air.
If set up for recirculation,
check that the charcoal
filter is still effective.
If set up for extraction,
check that the ducting and
outlets are not blocked.
The cooker hood has The safety cut-out device
switched off during operation... has been tripped.
Turn off the hob and then
wait for the device to reset.
If the hood has been
installed below the heights
indicated in the installation
instructions the motor will
cut-out frequently which
will damage the hood.
If after all these checks, the problem persists, contact your local
Service
Force Centre, quoting the model and serial number.
Please note that it will be necessary to provide proof of
purchase for any in-guarantee service calls.
In-guarantee customers should ensure that the above checks
have been made as the engineer will make a charge if the fault
16
is not a mechanical or electrical breakdown.
Service and spare parts
In the event of your appliance requiring service, or if you
wish to purchase spare parts, contact your local AEG
Service Force Centre by telephoning
08705 929 929
Your call will be automatically routed to the Service Centre
covering your post code area.
For the address of your local Service Force Centre and
further information about Service Force, please visit the
website at www.serviceforce.co.uk
Please ensure that you have read the section „What to do
if....“ as the engineer will make a charge if the fault is not a
mechanical or electrical breakdown even the appliance is
under warranty.
Please note that proof of purchase is required for inguarantee service calls.
Help us to help you
Please determine your type of enquiry before writing or
telephoning.
When you contact us we need to know:
• Your name
• Address and post code
• Telephone number
• Clear and concise details of the fault
• Name and model of the appliance*
• E number*
* This information can be found on the rating plate, which
can be seen when the grease filters are removed.
Customer Care
For general enquiries concerning your AEG appliances, or
for further
information on AEG products, please contact our Customer
Care
Department at the address below or visit our website at
www.aeg.co.uk
Customer Care Department
AEG Domestic Appliances
55-77 High Street
Slough
Berkshire
SL1 1DZ
Tel.: 08705 350 350*
* calls to this number may be recorded for training
purposes.
17
Guarantee conditions
Guarantee Conditions
AEG offer the following guarantee to the first purchaser of this
appliance.
1. The guarantee is valid for 12 months commencing when the
appliance is handed over to the first retail purchaser, which
must be verified by purchase invoice or similar
documentation.The guarantee does not cover commercial
use.
2. The guarantee covers all parts or components which fail
due to faulty workmanship or faulty materials. The
guarantee does not cover appliances where defects or poor
performance are due to misuse, accidental damage,
neglect, faulty installation, unauthorised modification or
attempted repair, commercial use or failure to observe
requirements and recommendations set out in the
instruction book.This guarantee does not cover such parts
as light bulbs, removable glass-ware or plastic.
3. Should guarantee repairs be necessary the purchaser must
inform the nearest customer service office (manufacturer`s
service or authorised agent). AEG reserves the right to
stipulate the place of the repair (i.e.the customer`s home,
place of installation or AEG workshop).
4. The guarantee or free replacement includes both labour and
materials.
5. Repairs carried out under guarantee do not extend the
guarantee
period for the appliance. Parts removed during guarantee
repairs become the property of AEG.
6. The purchaser`s statutory rights are not affected by this
guarantee.
European Guarantee
If you should move to another country within Europe then your
guarantee moves with you to your new home subject to the
following qualifications:
- The guarantee starts from the date you first purchased your
product.
- The guarantee is for the same period and to the same
extent for labour and parts as exist in the new country of
use for this brand or range of products.
- This guarantee relates to you an cannot be transferred to
another user.
- Your new home is within the European Community (EC) or
European Free Trade Area.
- The product is installed and used in accordance with our
instructions and is only used domestically, i.e. a normal
household.
- The product is installed taking into account regulations in
your new country.
18
Before you move please contact your nearest Customer Care
Centre, listed below, to give them details of your new home.They
will then ensure that the local Service Organisation is aware of
your move and able to look after you and your appliances.
France Senlis +33 (0) 3 44 62 29 29
Germany Nürnberg +49 (0) 800 234 7378
Italy Pordenone +39 (0) 800 117 511
Sweden Stockholm +46 (0) 8 672 5360
UK Slough +44 (0) 1753 219899
19
AEG Hausgeräte GmbH
Postfach 1036
D-90327 Nürnberg
http://www.aeg.hausgeraete.de
© Copyright by AEG
LI1ZDA Ed. 05/02
documentation manual, user maintenance, brochure, user reference, pdf manual
This file has been downloaded from:
User Manual and User Guide for many equipments like mobile phones, photo cameras, monther board, monitors, software, tv, dvd, and othes..
Manual users, user manuals, user guide manual, owners manual, instruction manual, manual owner, manual owner's, manual guide,
manual operation, operating manual, user's manual, operating instructions, manual operators, manual operator, manual product,
Loading...
