Advantech TPC-1571H, TPC-1271H, TPC-1071H User Manual

User Manual

TPC-1071H/1271H/
1571H

Touch Panel Computer

®

With Intel
Processor

Atom™ Dual Core

Copyright

Part No. 2003157101 Edition 2

Printed in Taiwan January 2012

The documentation and the software included with this product are copyrighted 2011
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How­ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe­ments of the rights of third parties, which may result from its use.

Acknowledgements

Intel and Pentium are trademarks of Intel Corporation.

Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.

This Manual Covers the Following Models:

 TPC-1071H
 TPC-1271H
 TPC-1571H

TPC-1071H/1271H/1571H User Manual ii

Product Warranty (2 years)

Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur­chase.

This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.

Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec­tive, it will be repaired or replaced at no charge during the warranty period. For out­of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.

If you think you have a defective product, follow these steps:

1. Collect all the information about the problem encountered. (For example, CPU

speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.

2. Call your dealer and describe the problem. Please have your manual, product,

and any helpful information readily available.

3. If your product is diagnosed as defective, obtain an RMA (return merchandize

authorization) number from your dealer. This allows us to process your return
more quickly.

4. Carefully pack the defective product, a fully-completed Repair and Replacement

Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.

5. Write the RMA number visibly on the outside of the package and ship it prepaid

to your dealer.

iii TPC-1071H/1271H/1571H User Manual

Declaration of Conformity

CE

This product has passed the CE test for environmental specifications when shielded
cables are used for external wiring. We recommend the use of shielded cables. This
kind of cable is available from Advantech. Please contact your local supplier for
ordering information.

FCC Class A

Note: This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Opera­tion of this equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own expense.

Technical Support and Assistance

1. Visit the Advantech web site at http://support.advantech.com where you can find

the latest information about the product.

2. Contact your distributor, sales representative, or Advantech's customer service

center for technical support if you need additional assistance. Please have the
following information ready before you call:

– Product name and serial number
– Description of your peripheral attachments
– Description of your software (operating system, version, application software,

etc.)

– A complete description of the problem
– The exact wording of any error messages

3. This product is intended to be supplied by a listed power supply complying with

UL60950-1; rated from 10-29 V

, minimum 6.8 A to 2.4 A.

DC

TPC-1071H/1271H/1571H User Manual iv

Safety Instructions

1. Read these safety instructions carefully.

2. Keep this User Manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning. Use a damp

cloth. Do not use liquid or spray detergents for cleaning.

4. For plug-in equipment, the power outlet socket must be located near the equip-

ment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a reliable surface during installation. Dropping it or letting

it fall may cause damage.

7. The openings on the enclosure are for air convection. Protect the equipment

from overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting the

equipment to the power outlet.

9. Position the power cord so that people cannot step on it. Do not place anything

over the power cord.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the power source

to avoid damage by transient overvoltage.

12. Never pour any liquid into an opening. This may cause fire or electrical shock.

13. Never open the equipment. For safety reasons, the equipment should be

opened only by qualified service personnel.

14. If one of the following situations arises, get the equipment checked by service

personnel:

The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well, or you cannot get it to work according to

the user's manual.

The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.

15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE

STORAGE TEMPERATURE MAY GO BELOW -20° C (-4° F) OR ABOVE 60° C
(140° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT.

16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY

REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.

The sound pressure level at the operator's position according to IEC 704-1:1982 is
no more than 70 dB (A).

DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.

Caution! Danger of explosion if battery is incorrectly replaced. Replace only with

the same or equivalent type recommended by the manufacturer. Dis­pose of used batteries according to the manufacturer's instructions.

v TPC-1071H/1271H/1571H User Manual

TPC-1071H/1271H/1571H User Manual vi

Contents

Chapter 1 General Information ............................1

1.1 Introduction ............................................................................................... 2

1.2 Packing List............................................................................................... 2

1.2.1 TPC-1071H and 1271H ................................................................ 2

1.2.2 TPC-1571H ................................................................................... 2

1.3 Specifications ............................................................................................ 3

1.3.1 System Kernel............................................................................... 3

1.3.2 I/O Ports........................................................................................ 3

1.3.3 Safety and Environment................................................................ 3

1.4 LCD Specifications.................................................................................... 4

1.5 Touchscreen Specifications ...................................................................... 4

1.6 Power ........................................................................................................ 4

1.7 I/O Ports Arrangement .............................................................................. 5

Figure 1.1 TPC-1071H/1271H - I/O Port Arrangement

(Antenna is optional. Use P/N:1750000318 to order). 5

Figure 1.2 TPC-1571H - I/O Port Arrangement

(Antenna is optional. Use P/N:1750000318 to order). 5

1.8 Panel Mounting ......................................................................................... 6

Figure 1.3 Panel Mounting........................................................... 6

Figure 1.4 Front and Rear Images............................................... 6

1.9 Dimensions and Cutout............................................................................. 7

1.9.1 TPC-1071H ................................................................................... 7

Figure 1.5 TPC-1071H Dimensions............................................. 7

1.9.2 TPC-1271H ................................................................................... 8

Figure 1.6 TPC-1271H Dimensions............................................. 8

1.9.3 TPC-1571H ................................................................................... 9

Figure 1.7 TPC-1571H Dimensions............................................. 9

Chapter 2 System Setup.....................................11

2.1 System Setup.......................................................................................... 12

Figure 2.1 Unpack the Package ................................................ 12

Figure 2.2 Install CompactFlash Memory Card ......................... 13

Figure 2.3 Power Connector and Power Lines .......................... 13

Figure 2.4 Power Receptor & Switch Pin Assignment ............... 14

2.1.1 Installing the Drivers ................................................................... 14

Chapter 3 Features in Windows XP Embedded15

3.1 Features in Windows XP Embedded ...................................................... 16

3.2 EWF ........................................................................................................ 16

3.3 HORM ..................................................................................................... 16

Appendix A Jumper & Dip Switch Setting List and

DIO Pin Assignment and Wiring17

A.1 Jumper and DIP Switch Settings............................................................. 18

A.1.1 Jumper and Switch Locations ..................................................... 18

Figure A.1 Jumper and Switch Locations................................... 18

A.2 Jumper Settings ...................................................................................... 19

A.2.1 JP1 LCD Power Select ............................................................... 19

vii TPC-1071H/1271H/1571H User Manual

A.2.2 JP2 CMOS Clear Select ............................................................. 19

A.3 DIP Switch Settings ................................................................................ 20

A.3.1 SW1 TS Type Setting ................................................................. 20

A.3.2 SW2 LCD Controlled Function.................................................... 20

A.3.3 SW3 FPGA ................................................................................. 20

A.3.4 SW4 LCD Resolution Select....................................................... 21

A.3.5 SW5 & SW6 Termination Resistor Selection.............................. 21

A.4 DIO Board Pin Assignment and Wiring ................................................... 22

A.4.1 DIO PIN Assignment................................................................... 22

A.4.2 Isolated Digital Input -- Dry Contact............................................ 22

A.4.3 Isolated Digital Input -- Wet Contact ........................................... 23

A.4.4 Isolated Digital Output ................................................................ 23

TPC-1071H/1271H/1571H User Manual viii

Chapter 1

1 General Information

1.1 Introduction

The TPC-1071H/1271H/1571H Touch Panel Computers are state-of-the-art Human
Machine Interfaces featuring 10"/ 12"/ 15" displays with Intel Atom processors 400
and 500 Series with Intel 82801HM I/O Controller and the following key features:

 Fanless

By using a low-power processor, the system does not have to rely on fans,
which often are unreliable and causes dust to circulate inside the equipment.

 Compact Expansion

With its PCI-E/mini PCI-E slot, it provides the easiest way to expand TPC's func­tionality.

 Multiple OS

In addition to the OS support of Windows XP, Advantech offers platform support
for WES7 and Windows XP embedded. The optional Windows CE operating
system, specifically for Industrial Touch Panel Computers is also available.

 Automation IO Control Module

8 x DI/DO design with isolation and Fieldbus control for automation monitoring/
control application.

 Various Mounting Options

TPC-1071H/1271H/1571H allows a variety of mounting systems e.g. panel
mount. It has been verified and is recommended to work with vertical mounting
systems.

 RTC Battery Backup

RTC backup ensures real time data management in case of accidental power
failure.

1.2 Packing List

1.2.1 TPC-1071H and 1271H

 8 x Panel Mount Clamps
 8 x Panel Mount Screws
 1 x 3 Pin Power Connector
 1 x Power Indication Sticker
 1 x Wire for Chassis Ground
 1 x TPC Driver DVD
 1 x Registration and Warranty Card
 1 x Simplified Chinese Manual
 2 x 10-pin plug-in block for DI/O port

1.2.2 TPC-1571H

 10 x Panel Mount Clamps
 10 x Panel Mount Screws
 1 x 3 Pin Power Connector
 1 x Power Indication Sticker
 1 x Wire for Chassis Ground
 1 x TPC Driver DVD
 1 x Registration and Warranty Card
 1 x Simplified Chinese Manual
 2 x 10-pin plug-in block for DI/O port

TPC-1071H/1271H/1571H User Manual 2
