User Manual
APAX-5000 Series
I/O Modules
APAX-5000 I/O Series User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2014
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. However, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringements of the rights of third parties, which may result from its use.
Acknowledgements
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defective, it will be repaired or replaced at no charge during the warranty period. For outof-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.
Part No. 2003H01300 Edition 1.26
Printed in Taiwan September 2015
iii APAX-5000 I/O Series User Manual
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications when shielded
cables are used for external wiring. We recommend the use of shielded cables. This
kind of cable is available from Advantech. Please contact your local supplier for
ordering information.
FCC Class A
Note: This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own expense.
FM
This equipment has passed the FM certification. According to the National Fire Protection Association, work sites are classified into different classes, divisions and
groups, based on hazard considerations. This equipment is compliant with the specifications of Class I, Division 2, Groups A, B, C and D indoor hazards.
Technical Support and Assistance
1. Visit the Advantech web site at www .advante ch.com/support where you can find
the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
– Product name and serial number
– Description of your peripheral attachments
– Description of your software (OS, version, application software, etc.)
– A complete description of the problem
– The exact wording of any error messages
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the products from
damage.
To avoid electrical shock, always disconnect the power from your PC chassis
before you work on it. Don't touch any components on the CPU card or other
cards while the PC is on.
Disconnect power before making any configuration changes. The sudden rush of
power as you connect a jumper or install a card may damage sensitive electronic
components.
APAX-5000 I/O Series User Manual iv
Safety Instructions
1. Install the system only in area with restricted access.
2. Read these safety instructions carefully.
3. Keep this User Manual for later reference.
4. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
5. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
6. Keep this equipment away from humidity.
7. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
8. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
9. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
10. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
11. All cautions and warnings on the equipment should be noted.
12. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
13. Never pour any liquid into an opening. This may cause fire or electrical shock.
14. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
15. If one of the following situations arises, get the equipment checked by service
personnel:
16. The power cord or plug is damaged.
17. Liquid has penetrated into the equipment.
18. The equipment has been exposed to moisture.
19. The equipment does not work well, or you cannot get it to work accordin g to th e
user's manual.
20. The equipment has been dropped and damaged.
21. The equipment has obvious signs of breakage.
22. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERA TURE MAY GO BELOW -20° C (-4° F) OR ABOVE 60° C
(140° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT.
23. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.
24. The sound pressure level at the operator's position according to IEC 704-1:1982
is no more than 70 dB (A).
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.
v APAX-5000 I/O Series User Manual
Chapter 1 Overview...............................................1
1.1 Introduction ...............................................................................................2
Table 1.1: Supported I/O Module List................................... ... ... . 2
1.2 I/O Wiring .................................................................................................. 3
1.3 Removing the I/O Terminal .......................................................................4
1.4 Labeling the Terminal................................................................................5
1.5 Jumper Settings ........................................................................................6
1.6 ID Switch Setting.......................................................................... ... ... .......7
1.7 Mechanical Assembly and Power Connection....................................... 10
1.7.1 Wiring Power Input to the Backplane..........................................10
1.7.2 Using the APAX-5343E Power Supply Module...........................14
1.8 Decommission and Disposal................................................................... 17
1.9 Mounting .................................................................................................18
1.9.1 DIN-rail Mounting........................................................................18
1.9.2 Wall (Panel) Mounting................................................................. 20
Chapter 2 Analog Input/Output Modules ..........25
2.1 Analog Input Modules ............................................................................. 26
2.1.1 APAX-5013 8-ch RTD Module.................................................... 26
Figure 2.1 APAX-5013 Module Front View................................26
Figure 2.2 Wiring for APAX-5013 .............................................. 27
2.1.2 APAX-5017 12-ch Analog Input Module.....................................28
Figure 2.3 APAX-5017 Module Front View................................28
Figure 2.4 Wiring for APAX-5017 .............................................. 28
2.1.3 APAX-5017H 12-ch High Speed Analog Input Module............... 30
Figure 2.5 APAX-5017H Module Front View ............................. 30
Figure 2.6 Wiring for APAX-5017H............................................31
2.1.4 APAX-5018 12-ch Thermocouple Input Module ......................... 32
Figure 2.7 APAX-5018 Module Front View................................32
Figure 2.8 Wiring for APAX-5018 .............................................. 33
2.1.5 APAX-5017PE 12-ch Analog Input Module for P&E Applications...
36
Figure 2.9 APAX-5017PE Module Front View...........................36
Figure 2.10Wiring for APAX-5017PE..........................................36
2.2 Analog Output Modules.................. .... ... ................................................ .. 39
2.2.1 APAX-5028 8-ch Analog Output Module .................................... 39
Figure 2.11APAX-5028 Module Frontal View.............................39
Figure 2.12Wiring for APAX-5028 .............................................. 40
2.2.2 APAX-5028 Specifications.......................................................... 40
Chapter 3 Digital Input/Output Modules ...........41
3.1 Digital Input/Output Modules...................................................................42
3.1.1 APAX-5040 24-ch Digital Input Module ......................................42
Figure 3.1 APAX-5040 Module Front View................................42
Figure 3.2 Wiring for APAX-5040 .............................................. 42
3.1.2 APAX-5045 24-ch Digital Input/Output Module...........................44
Figure 3.3 APAX-5045 Module Frontal View............................. 44
Figure 3.4 Wiring for APAX-5045 .............................................. 45
3.1.3 APAX-5046 24-ch Digital Output Module.................................... 47
Figure 3.5 APAX-5046 Module Front View................................47
Figure 3.6 Wiring for APAX-5046 .............................................. 47
3.1.4 APAX-5040PE 24-ch Digital Input Module for P&E Applications 49
Figure 3.7 APAX-5040PE Module Front View...........................49
Figure 3.8 Wiring for APAX-5040PE..........................................50
3.1.5 APAX-5046SO 20-ch Digital Output Module .............................. 51
APAX-5000 I/O Series User Manual vi
Figure 3.9 APAX-5046SO Module Front View .......................... 51
Figure 3.10Wiring for APAX-5046SO......................................... 51
3.2 Relay Output Modules ................................................... ......................... 53
3.2.1 APAX-5060 12-ch Relay Output Module.................................... 53
Figure 3.11APAX-5060 Module Frontal View............................. 53
Figure 3.12Wiring for APAX-5060 .............................................. 54
3.2.2 APAX-5060PE 12-ch Relay Output Module for P&E Applications..
56
Figure 3.13APAX-5060PE Module Frontal View........................ 56
Figure 3.14Wiring for APAX-5060PE ......................................... 56
3.3 Counter Modules..................................................................................... 59
3.3.1 APAX-5080 Counter/Frequency and DIO Module...................... 59
Figure 3.15APAX-5080 Module Front View................................ 59
Figure 3.16Wiring for APAX-5080 .............................................. 60
Figure 3.17Pulse/DIR, No Reload, Count Once......................... 64
Figure 3.18Pulse/DIR, With Reload, Count Once ............. ....... .. 64
Figure 3.19Pulse/DIR, With Reload, Count Repetitively ............ 65
Figure 3.20Up/Down, No Reload, Count Once .......................... 66
Figure 3.21Up/Down, With Reload, Count Once............... .... ... .. 67
Figure 3.22Up/Down, With Reload, Count Once............... .... ... .. 68
Figure 3.23Up, No Reload, Count Once..................................... 69
Figure 3.24Up, With Reload, Count Once.................................. 69
Figure 3.25Up, With Reload, Count Repetitively........................ 70
Figure 3.26Frequency .................... ... ... .... ... ... ... .... ... ... ... ... .... ... .. 70
Figure 3.27A/B Phase 1X, No Reload, Count Once................... 71
Figure 3.28A/B Phase 1X, With Reload, Count Once ................ 72
Figure 3.29A/B Phase 1X, With Reload, Count Repetitively ...... 73
Figure 3.30A/B Phase 2X, No Reload, Count Once................... 74
Figure 3.31A/B Phase 2X, With Reload, Count Once ................ 75
Figure 3.32A/B Phase 2X , With Reload , Count Repetitively .... 76
Figure 3.33A/B Phase 4X, No Reload, Count Once................... 77
Figure 3.34A/B Phase 4X, With Reload, Count Once ................ 78
Figure 3.35A/B Phase 4X, With Reload, Count Repetitively ...... 79
Figure 3.36Pulse/DIR, With Reload, Count Once, DI Gate Disable
80
Figure 3.37Pulse/DIR, With Reload, Count Repetitively, DI Gate
Disable ..................................................................... 81
Figure 3.38Pulse/DIR, With Reload, Count Once, DI Gate Enable,
High level, Not Retriggerable ................................... 82
Figure 3.39Pulse/DIR , With Reload , Count Repetitively, DI Gate
Enable, High level, Not Retriggerable...................... 83
Figure 3.40Pulse/DIR, With Reload, Count Repetitively, DI Gate
Enable, High level, Not Retriggerable...................... 84
Figure 3.41Pulse/DIR, With Reload , Count Repetitively, DI Gate
Enable, High level, Retriggerable............................. 85
Figure 3.42Pulse/DIR, With Reload, Count Repetitively, DI Gate
Enable, Low level, Retriggerable............................ .. 86
Figure 3.43Pulse/DIR , With Reload , Count Repetitively, DI Gate
Enable, Low level, Not Retriggerable........ ... ... .... ..... 87
Figure 3.44Pulse/DIR, With Reload, Count Once, DI Gate Enable,
Low level, Retriggerable........................................... 88
Figure 3.45Pulse/DIR , With Reload , Count Repetitively, DI Gate
Enable, Low level, Retriggerable............................ .. 89
Figure 3.46Pulse/DIR, With Reload, Count Once, DI Gate Enable,
Rising Edge, Not Retriggerable................................ 90
Figure 3.47Pulse/DIR, With Reload, Count Repetitively, DI Gate
Enable, Rising Edge, Not Retriggerable................... 91
Figure 3.48Pulse/DIR , With Reload , Count Once, DI Gate Enable,
Rising Edge, Retriggerable ...................................... 92
Figure 3.49Pulse/DIR , With Reload , Count Repetitively, DI Gate
vii APAX-5000 I/O Series User Manual
Enable, Rising Edge, Retriggerable ......................... 93
Figure 3.50Pulse/DIR, With Reload, Count Once, DI Gate Enable,
Falling Edge, Not Retriggerable ............................... 94
Figure 3.51Pulse/DIR , With Reload , Count Repetitively, DI Gate
Enable, Falling Edge, Not Retriggerable.................. 95
Figure 3.52Pulse/DIR, With Reload, Count Once, DI Gate Enable,
Falling Edge, Retriggerable...................................... 96
Figure 3.53Pulse/DIR, With Reload, Count Repetitively, DI Gate
Enable, Falling Edge, Retriggerable......................... 97
Figure 3.54Pulse/DIR, With Reload, Count Once, DI Gate Enable,
Rising Edge Start...................................................... 98
Figure 3.55Pulse/DIR, With Reload, Count Repetitively, DI Gate
Enable, Rising Edge Start ........................................ 99
Figure 3.56Pulse/DIR, With Reload, Count Once, DI Gate Enable,
Falling Edge Start................................................... 100
Figure 3.57Pulse/DIR , With Reload, Count Repetitively, DI Gate
Enable, Rising Edge Start ...................................... 101
3.4 Communication Modules.......................................................................102
3.4.1 APAX-5090P 4-port RS-232/422/485 Communication Module 102
Figure 3.58APAX-5090P Module Front View ........................... 102
Figure 3.59APAX-5090P Function Block Diagram ...................102
Table 3.1: Configuration Settings .. .... ... ... ... ... .... ... ... ... .... ... ... ... 103
3.4.2 APAX-5095P 2-Port CAN bus communication Module............. 104
Figure 3.60APAX-5095P Module Front View ........................... 104
Figure 3.61APAX-5095P Function Block Diagram ...................104
Figure 3.62APAX-5095P PIN Assignment................................105
Figure 3.63APAX-5095P PIN Definitions..................................105
Table 3.2: ............................................................. ... ... .... .........106
Table 3.3: Configuration Settings .. .... ... ... ... ... .... ... ... ... .... ... ... ... 106
3.4.3 APAX-5490 4-port RS-232/422/485 Communication Module... 106
Figure 3.64APAX-5490 Module Front View and connection exam-
ple........................................................................... 106
Chapter 4 Backplane Modules.........................109
4.1 APAX-5002/5002L 2-slot Backplane Module........................................110
4.2 APAX-5001 1-slot Backplane Module...................................................111
4.3 APAX-5004L 4-slot Backplane Module.... .............................................111
Chapter 5 Power Supply Modules ...................113
5.1 APAX-5343E Power Supply for Expansion Modules............................114
5.2 APAX-5350 24V DC/DC Power Filter for P&E Applications.................. 115
Chapter 6 Error Handling and Diagnostics.....117
6.1 Error Handling and Diagnostics ............................................................118
APAX-5000 I/O Series User Manual viii
Chapter 1
1 Overview
APAX-5000 I/O Series User Manual 2
1.1 Introduction
This manual will discuss the specifications, functions and application wiring of the
AP AX-5000 series of I/O modules. Advantec h provides different APAX-5000 I/O modules for various applications. The following table outlines Advantech's supported I/O
modules.
Table 1.1: Supported I/O Module List
Module Name Specifications
Analog I/O APAX-5013 8-ch RTD Module
APAX-5017 12-ch Analog Input Module
APAX-5018 12-ch Thermocouple Input Module
APAX-5017H 12-ch High Speed Analog Input Module
APAX-5028 8-ch Analog Output Module
Digital I/O APAX-5040 24-ch Digital Input Module
APAX-5045 24-ch Digital Input/Output Module
APAX-5046 24-ch Digital Output Module
Relay Output APAX-5060 12-ch Relay Output Module
Counter APAX-5080 Counter/Frequency and DIO module
Communication APAX-5090P 4-port RS-232/422/485 Communication Module
Communication APAX-5095P 2-port CAN bus Communication Module
3 APAX-5000 I/O Series User Manual
Chapter 1 Overview
1.2 I/O Wiring
AP AX-5000 I/O modules leverage detachable clamp type terminal blocks. Comp aring
with traditional screw type terminal blocks, clamp type terminal blocks can save up to
75% wiring time and provide better reliability for shock and vibration. Follow the procedures below for wiring your APAX-5000 I/O module.
1. Insert the screw driver into the left hole of the terminal.
2. Insert the wiring into the right hole of the terminal.
Note! Please use # 14 AWG ~ 28 AWG wire for terminal block.
APAX-5000 I/O Series User Manual 4
1.3 Removing the I/O Terminal
APAX-5000 I/O modules provide detachable terminal blocks that are convenient
when wiring needs to be changed, because the terminal block can removed and the
module doesn't need to be. Refer to the figures below to remove the terminal block.
Warning! APAX-5000 I/O modules can be categorized into four categories: AI,
AO, DI and DO. If you insert a terminal block into a module which has a
different function, it might damage the modules (for example, inserting a
DO terminal block on DI module). In order to prevent this, APAX-5000
modules color the terminal block and label on the front side. Remember
to match the terminal block with the module as below.
Function Color
Analog Input Green
Analog Output Blue
Digital Input Yellow
Digital Output Red
5 APAX-5000 I/O Series User Manual
Chapter 1 Overview
1.4 Labeling the Terminal
Advantech provides write-on labels for each APAX-5000 I/O module. This write-on
label has two sides, one with the model name, specifications and a wiring diagram,
while the other side allows users to write information in by themselves. Refer to the
figures below for the write-on label details.
APAX-5000 I/O Series User Manual 6
1.5 Jumper Settings
Some I/O modules need to be configured manually through the onboard jumpers.
This section will show you how to adjust the jumper settings.
1. Pull out the write-on label and you can see the location of the jumper.
2. You can use the screw driver to adjust the jumper setting.
3. Once the jumper setting is done, slide the write-on label back to its position.
7 APAX-5000 I/O Series User Manual
Chapter 1 Overview
1.6 ID Switch Setting
The controller identifies each APAX-5000 I/O module through the ID number. Therefore, you need to set ID number for each I/O module by the rotary ID switch on the
front side. Rotate that ID switch and point the hole on the central axis to corresponding ID number ("0" ~ "F"). Refer to figures below for the location of the rotary ID
switch and how to set the ID number by the rotary ID switch.
Note! APAX supports locate functionality. It means the selected APAX I/O mod-
ule will flash its LED to let you identify through Apax/Adam utility. Refer to
related APAX controller or coupler software manual for how to operate it.
APAX-5000 I/O Series User Manual 8
From the figures above, you can choose ID number 0 ~ 15 from the rotary ID switch
("0" ~ "F"). Therefore, the maximum number for analog module in one system is 16.
For digital modules, there is another ID switch on the PCB that it can double the
available ID number. Thus, the maximum number for digital module in one system is
32.
You can distinguish if the ID number is doubled by the front LED. When the LED color
is green, only 0 ~ 15 ID number is used (0 ~ 15 according to the rotary ID switch).
Once the LED color is orange, the ID number is doubled (16~31 according to the
rotary ID switch). Refer to figure below for its location and how to configure it.
9 APAX-5000 I/O Series User Manual
Chapter 1 Overview
DIP Switch Setting ID LED Color
16 ~ 31 according to the rotary ID swich Orange
0 ~ 15 according to the rotary ID swich Green
Warning! Avoid two modules with the same ID number in the same system, or you
cannot see the module in the software utility. The LED on the front side
will flash four times if two or more modules have the same ID number in
one system. If this happens, simply change the ID number for these
conflicted modules and all of them can be found in utility again.
APAX-5000 I/O Series User Manual 10
1.7 Mechanical Assembly and Power Connection
1.7.1 Wiring Power Input to the Backplane
There are two ways that APAX-5000 I/O mdoules can be powered. One is to connect
the DC power supply wire directly to the power connector on the backplane. Another
way is using APAX-5343E power supply module.
When you wire the power supply to the backplane, the power is transferred between
backplanes, and provides to all APAX-5000 I/O modules inserted on the backplanes.
Refer to figures below for how to wiring the power to the backplane, and how to
assembly APAX-5000 I/O modules with backplanes:
1. Connect the power supply wire to the power connectors on the 2-slot APAX-
5002 backplane module.
2. Insert one APAX-5000 I/O module on that APAX-5002 backplane module.
Warning! If you use APAX-5000 digital modules in the same system, use different
power supplies for the system and the the digital channels on the modules to ensure isolation protection between digital channels and system.
11 APAX-5000 I/O Series User Manual
Chapter 1 Overview
3. Lock that APAX-5000 I/O module to the APAX-5002 backplane by pulling down
the module locks.
4. Insert another APAX-5000 I/O module on the same APAX-5002 backplane. Use
tongue-and-groove slots to move the module.
5. Lock that APAX-5000 I/O module to the APAX-5002 backplane by pulling down
the module locks.
APAX-5000 I/O Series User Manual 12
6. If you need more than one APAX-5000 I/O module, stack another APAX-5002
backplane to the original APAX-5002 backplane.
7. Lock the stacked APAX-5002 backplane to the original APAX-5002 backplane
by the backplane locks.
Warning! When you assembly different backplanes together, remember to turn off
the power connected to the backplane. If not, the backplanes may be
damaged. Turn on the power again after you complete the assembly for
all backplanes.
Note! If you want to provide more power to the system, you can connect
another power supply wire to the power connections on the second
APAX-5002 backplane. (The wiring procedure is the same as step 1)
13 APAX-5000 I/O Series User Manual
Chapter 1 Overview
8. Insert another APAX-5000 I/O module on the second APAX-5002 backplane.
9. Lock that APAX-5000 I/O module to the second APAX-5002 backplane by pull
down the module locks, similar as step 5.
10. If needed, repeat step 8 ~ 9 to have another APAX-5000 I/O module on the
same APAX-5002 backplane.
If you need more APAX-5000 I/O module, repeat Step 6 ~ Step 10 until all necessary
APAX-5000 I/O modules are inserted on the backplanes.
When the total number of APAX-5520 and APAX-5000 I/O modules is odd, you can
use 1-slot APAX-5001 backplane module as the last backplane in the system.
APAX-5000 I/O Series User Manual 14
1.7.2 Using the APAX-5343E Power Supply Module
APAX-5000 I/O modules can also be powered by the APAX-5343E power supply
module, connected to the left side of the whole system. The power can be transferred
to APAX-5000 I/O modules though the backplanes.
1. Follow the procedure described in Section 1.7.1 to assembly APAX-5000 I/O
modules into one complete system. The only difference is that you don't need to
connect the power supply wiring to the power connectors on the backplane
(step 1 in Section 1.7.1).
2. Pull up the module locks on the upper case of one APAX-5343E. Then you can
separate the upper case of APAX-5343E from its backplane.
Note! Refer to Chapter 5 for APAX-5343E specifications.
15 APAX-5000 I/O Series User Manual
Chapter 1 Overview
APAX-5000 I/O Series User Manual 16
3. Stack the b ackplane of APAX-5343E to the left side of the first APAX-5002 back-
plane in the system.
4. Lock the stacked AP AX-5343E backplane with the AP AX-5002 backplane by the
backplane locks on the APAX-5002 backplane.
5. Insert the upper case of APAX-5343E back to its backplane. Use tongue-and-
groove slots to move the upper case.
17 APAX-5000 I/O Series User Manual
Chapter 1 Overview
6. Lock the upper case of APAX-5343E to its backplane by pulling down the mod-
ule locks on the upper case. Connect AC power code to the power connectors
on the upper case of APAX-5343E. Then the whole system is powered-on.
1.8 Decommission and Disposal
APAX-5000 I/O modules support hot-swap functionality. It means the I/O module can
be removed from the backplane or inserted on the backplane when the complete system is power-on. This can significantly help to make it more convenient for system
maintenance. Changing one module won't affect operation of other modules. The
hot-swap functionality is implemented by the module locks. Refer to figure below for
how to dismantle APAX-5000 I/O modules:
1. Pull up the two module locks on side of APAX-5000 I/O modules first. This
action disconnects the power between the I/O module and backplane.
Note! If you only want to remove one module , the procedure is similar. (Pull
up the module locks and then remove the module without shutting down
the power)
APAX-5000 I/O Series User Manual 18
2. Detach APAX-5000 I/O module from the backplane.
Repeat Step 1 ~ Step 2 for all the APAX-5000 I/O modules you want to remove.
It is the similar when you insert APAX-5000 I/O modules back to the backplane. First,
insert APAX-5000 I/O module to backplane. Then, pull down the two module locks to
lock on the backplane, and APAX-5000 I/O module will be power-on and can be
used.
The device must be fully dismantled in order to dispose of it. Electronic part s must be
disposed of in accordance with national electronics scrap regulations.
1.9 Mounting
1.9.1 DIN-rail Mounting
AP AX-5000 I/O mo dule can be mounted through backplane to the f ollowing DIN rails:
35 x 7.5 mm or 35 x 15 mm. Below are the procedures for the DIN rails mounting.
1. Pull down the DIN rail lock at the back of APAX-5002 backplane.
19 APAX-5000 I/O Series User Manual
Chapter 1 Overview
2. Attach the APAX-5002 backplane on the DIN rail.
3. Repeat Step 1 ~ Step 2 until necessary APAX-5002 backplanes are all attached
on the DIN rail.
4. Move all backplanes to stack them together. Then slide the backplane locks on
the backplanes to fasten all backplanes. (Similar to Step 6 and 7 in section
1.7.1)
5. Slide the DIN rail lock of all backplanes into the position, to fix all backplanes to
the DIN rail.
6. Insert all necessary AP AX-500 0 I/O modules to the backplane s. (Similar to Step
2, Step 4 and Step 8 in section 1.7.1)
7. Slide the module lock of those APAX-5000 I/O modules into the position, to fix
these modules to related backplanes. (Similar to Step 3, Step 5 and Step 9 in
section 1.7.1)
Note! When the total number of APAX-5520 and APAX-5000 I/O modules is
odd, you can use APAX-5001 (1-slot backplane) as the last backplane in
the system. And the procedure to attach APAX-5001 on the DIN rail is
similar as APAX-5002.
APAX-5000 I/O Series User Manual 20
1.9.2 Wall (Panel) Mounting
Mount the APAX-5000 I/O module to a wall (panel) through backplane using two
screws per module. Use M4 or #8 panhead screws. Refer to figure below for the
dimensional template:
Below are the procedures for the wall (panel) mounting:
1. Pull down the DIN-rail lock at the back of the first APAX-5002 backplane.
21 APAX-5000 I/O Series User Manual
Chapter 1 Overview
2. Hang the APAX-5002 backplane onto the screw on the wall (panel). The screw
for APAX-5002 to hang should be special-designed. We have provided it in
accessory. (Diameter: 9 mm, length: 16 mm, height of head: 2.7 mm)
3. Mount the first APAX-5002 backplane to the wall (panel) using two standard M4
or #8 panhead screws. We also provide the two scre ws in accessory. (Diameter:
7 mm, length: 8 mm, height of head: 2.6 mm)
APAX-5000 I/O Series User Manual 22
4. Stack Another APAX-5002 backplane to original backplane. Lock the two back-
planes together.
5. Mount the second APAX-5002 backplane to the wall (panel) using two standard
M4 or #8 panhead screws.
23 APAX-5000 I/O Series User Manual
Chapter 1 Overview
6. Repeat Step 4 ~ Step 5 until all necessary APAX-5002 backplane are screwed
on the wall (panel).
7. Insert all necessary AP AX-500 0 I/O modules to the backplane s. (Similar to Step
2, Step 4 and Step 8 in section 1.7.1)
8. Lock AP AX-5520 and all necessary APAX-5000 I/O module to the backplane by
pull down the buckle. (Similar to Step 3, Step 5 and Step 9 in section 1.7.1)
Note! When the total number of APAX-5000 I/O modules is odd, you can use
APAX-5001 (1-slot backplane) as the last backplane in the system. The
procedure to attach APAX-5001 on the wall is similar as APAX-5002.
Warning! In order to have better ventilation remember to align the APAX-5000 I/O
modules as follows:
APAX-5000 I/O Series User Manual 24
We suggest remaining enough clearance space from enclosure walls and adjacent
equipments. Allow 50 mm (2 in.) of space on all sides, as shown below. This provide
ventilation and makes assembly more easily.
Chapter 2
2 Analog Input/Output
Modules
APAX-5000 I/O User Manual 26
2.1 Analog Input Modules
Analog input modules use an A/D converter to convert sensor voltage, current, thermocouple or RTD signals into digital data. The analog input modules protect your
equipment from ground loops and power surges by providing opto-isolation of the A/
D input and transformer based isolation up to 2,500 VDC.
2.1.1 APAX-5013 8-ch RTD Module
The APAX-5013 is a 16-bit, 8-channel RTD input module that features programmable input
ranges on all channels. This module is an extremely cost-effective solution for industrial measurement and monitoring applications. Its opto-isolated inputs provide 2,500 VDC of isolation
between the analog input and t he module, protect ing the module and peripherals from d amage due to high input line voltage.
Figure 2.1 APAX-5013 Module Front View
27 APAX-5000 I/O User Manual
Chapter 2 Analog Input
/
Output Modules
Application Wiring
Figure 2.2 Wiring for APAX-5013
APAX-5013
Technical Specifications
Channels: 8
Input Impedance: >10 M
Input T ype: Pt-100, Pt-200 , Pt-500, Pt-100 0, Balco, Ni 518 R TD (2-wire and 3-wire)
Temperature Range: Pt-100,Pt-200,Pt-500,Pt-1000: -120~130C, -200~850C
– Supports IEC 60751 ITS90 (0.03851// C) and JIS C 1604 (0.03916 // C)
– Balco 500: -30 ~ 120 C
– Ni 518: -80 ~ 100 C, 0 ~ 100 C
Configure Different Range for Each Channel: Yes
Resolution: 16-bit
Accuracy: ±0.1 % of FSR (at 25 C)
Sampling Rate: 50 Hz filter: 8 sample/second (total)
60 Hz filter: 10 sample/second (total)
CMR @ 50/60 Hz: 90 dBs
NMR @ 50/60 Hz: 60 dBs
Noise Suppression for Frequency: 50/60 Hz
Span Drift: 15 ppm/ C
Input Characteristic Curve: According to IEC 61131-2
Wire Burnout Detection: All RTD type
Protection
Isolation: 2,500 VDC (Between channels and backplane)
Environment
Operating Temperature: -10 ~ 60 C (when mounted vertically)
Storage Temperature: -40 ~ 70 C
Relative Humidity: 5 ~ 95% (non-condensing)
General
Dimensions (W x H x D): 30 x 139 x 100 mm
Weight: 170 g
Power Consumption: 2.5 W @ 24 VDC (typical)
APAX-5000 I/O User Manual 28
2.1.2 APAX-5017 12-ch Analog Input Module
The APAX-5017 is a 16-bit, 12-channel analog differential input module that provides
programmable input ranges on all channels, and different channels can be
configured using different ranges. It accepts voltage and current inputs. Adjust the
switch (refer to Section 1.5) to define each channel as voltage or current input. Refer
to the figure below to see how to define the input type by the jumper. Besides, you
can use software (APAX utility) to configure range type for each channel. This
module is an extremely cost-effective solution for industrial measurement and
monitoring applications. The module provides 2500 VDC optical isolation between
channels and backplane bus. If any high voltage or current damage the channels, the
whole system (backplanes, other modules, and control unit) won't be affected
because it is already isolated.
Figure 2.3 APAX-5017 Module Front View
Figure 2.4 Wiring for APAX-5017
29 APAX-5000 I/O User Manual
Chapter 2 Analog Input
/
Output Modules
Technical Specifications of APAX-5017
Channels: 12 (Differential)
Input Impedance: >10 M (Voltage), 120 (Current)
Input Type: V, mV, mA
Voltage/Current Range:
±150mV,±500mV,±1V,±5V,±10V,±20mA,0~20mA,4~20 mA
Configure Different Range for Each Channel: Yes
Accuracy: ±0.1% or better (Voltage), ±0.2% or better (Current) at 25 C
Resolution:
Sampling Rate: 12 samples/second (total)
CMR @ 50/60 Hz: 90 dB
NMR @ 50/60 Hz: 67 dB
Noise Suppression for Frequency: 50/60 Hz
Span Drift: ±30 ppm/ C
Zero Drift: ±6 V/ C
Input Characteristic Curve: According to IEC 61131-2
Common Mode Voltage: up to 200 VDC
Wire Burnout Detection: Only for 4 ~ 20 mA range
Note! To keep measurement accuracy please short the channels that
are not in use.
Note! You can use the jumpers to configure each analog input channel type
(voltage or current). Refer to Section 1.5 for the location of the jumpers.
There are a total of 12 jumpers and each is specific for one channel.
Voltage
Range Resolution
±150 mV 16 bit
±500 mV 16 bit
±1 V 16 bit
±5 V 16 bit
±10 V 16 bit
Current
Range Resolution
±20 mA 15 bit
0 ~ 20 mA 14 bit
4 ~ 20 mA 14 bit
Note! Please base on 16 bit to convert your raw data to engineer unit in the
current mode.
APAX-5000 I/O User Manual 30
Protection
Isolation: 2,500 VDC (Between channels and backplane bus)
Over Voltage Protection: ±35 VDC
Environment
Operating Temperature: -10 ~ 60 C (when mounted vertically)
Storage Temperature: -40 ~ 70 C
Relative Humidity: 5 ~ 95% (non-condensing)
General
Dimensions (W x H x D): 30 x 139 x 100 mm
Weight: 170 g
Power Consumption: 4 W @ 24 VDC (typical)
2.1.3 APAX-5017H 12-ch High Speed Analog Input Module
APAX-5017H is an 12-ch analog differential input module that provides programmable input ranges on each channel. Its sampling rate depends on the data format
received: up to 1000 sample/second (per channel). The module provides 2500 VDC
optical isolation between channels and backplane bus. If any high voltage or current
damage the channels, the whole system (backplanes, other modules, and control
unit) won't be affected because it is already isolated.
Figure 2.5 APAX-5017H Module Front View
Note! There is no built-in filter on APAX-5017H, so please try to use it in an
environment with less noise.
31 APAX-5000 I/O User Manual
Chapter 2 Analog Input
/
Output Modules
Application Wiring
Figure 2.6 Wiring for APAX-5017H
APAX-5017H Specifications
Channels: 12
Input Impedance: 2M (Voltage), 120 (Current)
Input Type: V, mV, mA
Input Range: 0 ~ 500 mV, ±10 V, 0 ~ 10 V, 0 ~ 20 mA, 4 ~ 20 mA
Configure Different Range for Each Channel: Yes
Accuracy: ±0.1% or better (voltage), ±0.2% or better (current) at 25C
Resolution: 12-bit
Sampling Rate: 1,000 sample/second (per channel)
Span Drift: ±25 ppm/C
Zero Drift: ±6 V/C
Input Characteristic Curve: According to IEC 61131-2
Wire Burnout Detection: Only for 4 ~ 20 mA range
Protection
Over Voltage Protection: ±35 VDC
Isolation: 2,500 VDC (Between channels and backplane bus)
Environment
Operating Temperature: -10 ~ 60C (when mounted vertically)
Storage Temperature: -40 ~ 70C
Relative Humidity: 5 ~ 95% (non-condensing)
Note! You can use the jumpers to configure each analog input channel type
(voltage or current). Refer to Section 1.5 for the location of the jumpers.
There are a total of 12 jumpers and each is specific for one channel.
Note! The voltage between any two pins must not exceed 15 V
APAX-5000 I/O User Manual 32
General
Dimensions (W x H x D): 30 x 139 x 100 mm
Weight: 175 g
Power Consumption: 3.5 W @ 24 VDC (typical)
2.1.4 APAX-5018 12-ch Thermocouple Input Module
The APAX-5018 is a 16-bit, 12-channel thermocouple input module that features programmable input ranges on all channels. It accepts millivolt inputs (±50 mV, ±100 mV,
±500 mV), voltage inputs (±1 V, ±2.5 V), current input (±20 mA, 0~20mA, 4~20mA)
and thermocouple input (T ype J, K, T, R, S, E, B). An external CJC on the plug-in terminal is designed for accurate temperature measurement. The module provides
2500 VDC optical isolation between channels and backplane bus. If any high voltage
or current damage the channels, the whole system (backplanes, other modules, and
control unit) won't be affected because it is already isolated.
Figure 2.7 APAX-5018 Module Front View
Warning! There is no built-in filter on APAX-5017H module, so it is not very suit-
able to use it in a very noisy environment.
33 APAX-5000 I/O User Manual
Chapter 2 Analog Input
/
Output Modules
Application Wiring
Figure 2.8 Wiring for APAX-5018
APAX-5018 Specifications
Channels: 12 (Differential)
Input Type: V, mV, mA, Thermocouple
Voltage/Current Range:
±50mV, ±100mV, ±500mV, ±1V, ±2.5V, ±20mA, 0~20mA, 4~20 mA
Voltage and Current Accuracy: ±0.1% or better (Voltage), ±0.2% or better
(Current) at 25 C
Temperature Range and Accuracy:
Note! You can use the jumpers to configure each analog input channel type
(voltage/thermocouple or current). Refer to Section 1.5 for the location
of the jumpers. There are a total of 12 jumpers and each is specific for
one channel.
Type Range Accuracy
Type J -210 ~ -150 ° C ±2.5 ° C
-150 ~ 1200 ° C ±2 ° C
Type K -230 ~ -150 ° C ±4 ° C
-150 ~ 1372 ° C ±2.5° C
Type T -230 ~ -150 ° C ±2° C
-150 ~ 400 ° C ±1.5 ° C
Type E -230 ~ -150 ° C ±2.5 ° C
-150 ~ 1000 ° C ±2 ° C
Type R 0 ~ 100 ° C ±2.5° C
100 ~ 1768 ° C ±2 ° C
Type S 0 ~ 100 ° C ±2.5 ° C
100 ~ 1768 ° C ±2 ° C
Type B 200 ~ 400 ° C ±4 ° C
400 ~ 1820 ° C ±3 ° C
APAX-5000 I/O User Manual 34
Configure Different Range for Each Channel: Yes
Resolution:
Sampling Rate: 12 samples/second (total)
CMR @ 50/60 Hz: 90 dB
NMR @ 50/60 Hz: 67 dB
Noise Suppression for Frequency: Hardware Filter (50/60 Hz)
Span Drift: ±25 ppm/ C
Zero Drift: ±6 V/ C
Thermocouple Wire Burn-out Detection: Yes
(When the loop resistance > 1K, it will detect as wire burn-out)
Input Characteristic Curve: According to IEC 61131-2
Common Mode Voltage: up to 200 VDC
Wire Burnout Detection: For 4 ~ 20 mA range and all thermocouple type
Protection
Isolation: 2,500 VDC (Between channels and backplane bus)
Note! This accuracy information only relates to the operating error, not includ-
ing cold connection CJC error. The CJC error can be eliminated by performing CJC compensation.
Voltage
Range Resolution
±50 mV 16 bit
±100 mV 16 bit
±250 mV 16 bit
±500 mV 16 bit
±1 V 16 bit
±2.5 V 16 bit
Current
Range Resolution
±20 mA 15 bit
0 ~ 20 mA 14 bit
4 ~ 20 mA 14 bit
Thermocouple
Range Resolution
Type J 14 bit
Type K 14 bit
Type T 15 bit
Type E 15 bit
Type R 14 bit
Type S 14 bit
Type B 14 bit
35 APAX-5000 I/O User Manual
Chapter 2 Analog Input
/
Output Modules
Environment
Operating Temperature: -10 ~ 60 C (when mounted vertically)
Storage Temperature: -40 ~ 70 C
Relative Humidity: 5 ~ 95% (non-condensing)
General
Dimensions (W x H x D): 30 x 139 x 100 mm
Weight: 170 g
Power Consumption: 3.5 W @ 24 VDC (typical)
APAX-5000 I/O User Manual 36
2.1.5 APAX-5017PE 12-ch Analog Input Module for P&E
Applications
The APAX-5017PE is a 16-bit, 12-channel analog differential input module that
provides programmable input ranges on all channels, and different channels can be
configured using different ranges. It accepts voltage and current inputs. You can use
software (APAX utility) to configure range type for each channel. This module is an
IEC-61850-3 compliant I/O modules, and suitable for measurement and monitoring
for power and energy related application. The highly anti-electromagnetic interference make it more robust and reliable to survive in the hush environment.The
module also provides 2500 VDC optical isolation between channels and backplane
bus. If any high voltage or current damage the channels, the whole system
(backplanes, other modules, and control unit) won't be affected because it is already
isolated.
Figure 2.9 APAX-5017PE Module Front View
Figure 2.10 Wiring for APAX-5017PE
APAX-50
17PE
37 APAX-5000 I/O User Manual
Chapter 2 Analog Input
/
Output Modules
Technical Specifications of APAX-5017PE
Channels: 12 (Differential)
Input Impedance: >10 M (Voltage)
Input Type: V, mV, mA (for current mode, 120 resistors is required to be
connected in parallel)
Voltage/Current Range:
±150mV,±500mV,±1V,±5V,±10V,±20mA,0~20mA,4~20 mA
Configure Different Range for Each Channel: Yes
Accuracy: ±0.1% or better (Voltage), ±0.2% or better (Current) at 25 C
Resolution:
Sampling Rate: 12 samples/second (total)
CMR @ 50/60 Hz: 90 dB
NMR @ 50/60 Hz: 67 dB
Noise Suppression for Frequency: 50/60 Hz
Span Drift: ±30 ppm/ C
Zero Drift: ±6 V/ C
Input Characteristic Curve: According to IEC 61131-2
Common Mode Voltage: up to 200 VDC
Wire Burnout Detection: Only for 4 ~ 20 mA range
Protection
Isolation: 2,500 VDC (Between channels and backplane bus)
Over Voltage Protection: ±35 VDC
Note! To keep measurement accuracy please short the channels that
are not in use.
Voltage
Range Resolution
±150 mV 16 bit
±500 mV 16 bit
±1 V 16 bit
±5 V 16 bit
±10 V 16 bit
Current
Range Resolution
±20 mA 15 bit
0 ~ 20 mA 14 bit
4 ~ 20 mA 14 bit
APAX-5000 I/O User Manual 38
Environment
Operating Temperature: -20 ~ 70C (when mounted vertically)
Storage Temperature: -40 ~ 85C
Relative Humidity: 5 ~ 95% (non-condensing)
General
Dimensions (W x H x D): 30 x 139 x 100 mm
Weight: 170 g
Power Consumption: 2 W @ 5 VDC (typical)
39 APAX-5000 I/O User Manual
Chapter 2 Analog Input
/
Output Modules
2.2 Analog Output Modules
2.2.1 APAX-5028 8-ch Analog Output Module
The APAX-5028 is a 8-channel analog output module. It uses the D/A converter controlled by the system module to convert the digital data into output signals. You can
specify slew rates and start up currents through the configuration software. For each
channel, voltage and current can be used by connecting to different terminal. The
module provides 2500 VDC optical isolation between channels and backplane bus. If
any high voltage or current damage the channels, the whole system (backplanes,
other modules, and control unit) won't be affected because it is already isolated.
Figure 2.11 APAX-5028 Module Frontal View
Note! The slew rate is defined as the slope indicated the ascending or
descending rate per second of the analog output from the present to the
required.
APAX-5000 I/O User Manual 40
Application Wiring
Figure 2.12 Wiring for APAX-5028
2.2.2 APAX-5028 Specifications
Channels: 8
Output T yp e: V, mA
Output Range: ±2.5 V , ±5 V, ±10 V, 0~2.5 V, 0~5 V, 0~10 V, 0~20 mA, 4~20 mA
Configure Different Range for Each Channel: Yes
Resolution: 14-bit
Accuracy: ±0.1% of FSR at 25 C
Settling Time: About 50 s to 0.01%
Output Latency: 500 s
Slew Rate: 0.7 VDC/s (per channel)
Span Drift: ±60 ppm/ C
Zero Drift: ±250 V/ C
Load: Voltage: 1000 (minimum), Current: 0 ~ 500
Protection
Isolation: 2,500 VDC (Between channels and backplane bus)
Short Circuit Protection
Fail Safe Protection*
* When I/O module lose its communication with controller or coupler, the output channel will generate a pre-defined value
Environment
Operating Temperature: -10 ~ 60 C (when mounted vertically)
Storage Temperature: -40 ~ 70 C
Relative Humidity: 5 ~ 95% (non-condensing)
General
Dimensions (W x H x D): 30 x 139 x 100 mm
Weight: 175 g
Power Consumption: 3.5 W @ 24 VDC (typical)
Note! The common terminals are physically connected together and to the
backplane power supply ground.
Chapter 3
3 Digital Input/Output
Modules
APAX-5000 I/O Series User Manual 42
3.1 Digital Input/Output Modules
3.1.1 APAX-5040 24-ch Digital Input Module
The APAX-5040 features 24 digital input (sink/source) channels. The APAX-5040
module's digital input channels can accept a 2-wiring input from a DC voltage source,
to determine the state of limits, standard switches or proximity switches. The digital
input channels offer LED to indicate digital status. The module provides 2500 VDC
optical isolation between channels and backplane bus. If any high voltage or current
damage the channels, the whole system (backplanes, other modules, and control
unit) won't be affected because it is already isolated.
Figure 3.1 APAX-5040 Module Front View
Application Wiring
Figure 3.2 Wiring for APAX-5040
Warning! Please use different power supply modules for digital channels and sys-
tem to ensure isolation effect.
43 APAX-5000 I/O Series User Manual
Chapter 3 Digital Input
/
Output Modules
APAX-5040 Specifications
Digital Input
Channels: 24
Points per Common: 12
Type: Sink/Source (Wet Contact)
Input Voltage Rated Value: 24 VDC
– For "0" signal: -5 ~ 5 VDC
– For "1" signal: 15 ~ 30 VDC and -15 ~ -30 VDC
Input Impedance: 5.4 k
Typical Input Current: 4.4 mA (At signal "1")
Maximum Input Current: 7.3 mA
Input Filter: 3 ms
Input Characteristic Curve: According to IEC 61131-2, type 1
Protection
Isolation: 2,500 VDC (Between channels and backplane bus)
Over Voltage Protection: ±70 VDC
Environment
Operating Temperature: -10 ~ 60 C (when mounted vertically)
Storage Temperature: -40 ~ 70 C
Relative Humidity: 5 ~ 95% (non-condensing)
General
Dimensions (W x H x D): 30 x 139 x 100 mm
Weight: 160 g
Power Consumption: 2 W @ 24 VDC (typical)
Status Display: LED per channel
– On: Logic level “1”
– Off: Logic level “0”
APAX-5000 I/O Series User Manual 44
3.1.2 APAX-5045 24-ch Digital Input/Output Module
The APAX-5045 features 12 digital input (sink/source) and 12 digital output (sink)
channels. The APAX-5045 module's digital input channels can accept a 2-wiring
input from a DC voltage source, to determine the state of limits, standard switches or
proximity switches. The APAX-5045 module's digital output channels can generate
discrete signal to external devices and change its output value to control the
devices. The digital output channels offer short-circuit protection and LED to indicate
digital status. The module provides 2500 VDC optical isolation between chan nels and
backplane bus. If any high voltage or current damage the channels, the whole system (backplanes, other modules, and control unit) won't be affected because it is
already isolated.
Figure 3.3 APAX-5045 Module Frontal View
Warning! Please use different power supply modules for digital channels and sys-
tem to ensure isolation effect.
45 APAX-5000 I/O Series User Manual
Chapter 3 Digital Input
/
Output Modules
Application Wiring
Figure 3.4 Wiring for APAX-5045
APAX-5045 Specifications
Digital Input
Channels: 12
Points per Common: 12
Type: Sink/Source (Wet Contact)
Input Voltage Rated Value: 24 VDC
– For "0" signal: -5 ~ 5 VDC
– For "1" signal: 15 ~ 30 VDC and -15 ~ -30 VDC
Input Impedance: 5.4 k
Input Current: typical 4.4 mA (At signal "1")
Input Filter: 3 ms
Input Characteristic Curve: According to IEC 61131-2, type 1
Warning! When you connect DO channel with inductive load, we suggest adding
one diode in the circuit to protect the APAX-5045 module. (Refer to figure below)
APAX-5000 I/O Series User Manual 46
Digital Output
Channels: 12
Type: Sink
Voltage Range: 8 ~ 35 VDC
Rated Output Current at signal "1": 0.5 A (per channel)
Permitted Output Current (at signal "1"): max. 0.75 A
Output Current at signal "0" (leakage current): 0.1 mA
Lamp Load: max. 5W
On-State Voltage Drop: 0.15 V at 0.5 A
Switch Rate:
– For resistive load: max. 300 Hz
– For inductive load: max. 20 Hz
– For lamp load: max. 200 Hz (Using 5W lamp and tested under 50 , 24 V)
Protection
Isolation: 2,500 VDC (Between channels and backplane bus)
Over Voltage Protection: ±70 VDC (for DI channel)
Short Circuit Protection (For DO channel)
Thermal Shutdown Protection (For DO channel)
Fail Safe Protection*
* When I/O module lose its communication with controller or coupler, the output channel will generate a pre-defined value
Environment
Operating Temperature: -10 ~ 60 C (when mounted vertically)
Storage Temperature: -40 ~ 70 C
Relative Humidity: 5 ~ 95% (non-condensing)
General
Dimensions (W x H x D): 30 x 139 x 100 mm
Weight: 165 g
Power Consumption: 2.5 W @ 24 VDC (typical)
Status Display: LED per channel
– On: Logic level “1”
– Off: Logic level “0”
47 APAX-5000 I/O Series User Manual
Chapter 3 Digital Input
/
Output Modules
3.1.3 APAX-5046 24-ch Digital Output Module
The APAX-5046 features 24 digital output (sink) channels. The digital output channels offer short-circuit protection and LED to indicate digital status. The module provides 2500 VDC optical isolation between channels and backplane bus. If any high
voltage or current damage the channels, the whole system (backplanes, other modules, and control unit) won't be affected because it is already isolated.
Figure 3.5 APAX-5046 Module Front View
Application Wiring
Figure 3.6 Wiring for APAX-5046
Warning! Please use different power supply modules for digital channels and sys-
tem to ensure isolation effect.
Warning! When you connect DO channel with inductive load, we suggest adding
one diode in the circuit to protect the APAX-5046 module. (Refer to figure below)
APAX-5000 I/O Series User Manual 48
APAX-5046 Specifications
Digital Output
Channels: 24
Type: Sink
Voltage Range: 8 ~ 35 VDC
Rated Output Current at signal "1": 0.5 A (per channel)
Permitted Output Current (at signal "1"): max. 0.75 A
Output Current at signal "0" (leakage current): 0.1 mA
Lamp Load: max. 5W
On-State Voltage Drop: 0.15 V at 0.5 A
Switch Rate:
– For resistive load: max. 300 Hz
– For inductive load: max. 20 Hz
– For lamp load: max. 200 Hz (Using 5W lamp and testing under 24 V)
Protection
Isolation: 2,500 VDC (Between channels and backplane bus)
Short Circuit Protection
Thermal Shutdown Protection
Fail Safe Protection*
* When I/O module lose its communication with controller or coupler, the output channel will generate a pre-defined value
Environment
Operating Temperature: -10 ~ 60C (when mounted vertically)
Storage Temperature: -40 ~ 70 C
Relative Humidity: 5 ~ 95% (non-condensing)
General
Dimensions (W x H x D): 30 x 139 x 100 mm
Weight: 165 g
Power Consumption: 2.5 W @ 24 VDC (typical)
Status Display: LED per channel
– On: Logic level “1”
– Off: Logic level “0”
49 APAX-5000 I/O Series User Manual
Chapter 3 Digital Input
/
Output Modules
3.1.4 APAX-5040PE 24-ch Digit al Input Module for P&E Applications
The APAX-5040PE features 24 digital input (sink/source) channels. The APAX5040PE module's digital input channels can accept a 2-wiring input from a DC voltage source, to determine the state of limits, standard switches or proximity switches.
The digital input channels offer LED to indicate digital status. This module is an IEC61850-3 compliant I/O modules, and suitable for power and energy related application. The highly anti-electromagnetic interference make it more robust and reliable to
survive in the hush environment.The module provides 2500 VDC optical isolation
between channels and backplane bus. If any high voltage or current damage the
channels, the whole system (backplanes, other modules, and control unit) won't be
affected because it is already isolated.
Figure 3.7 APAX-5040PE Module Front View
Warning! Please use different power supply modules for digital channels and sys-
tem to ensure isolation effect.
APAX-50
40PE
APAX-5000 I/O Series User Manual 50
Application Wiring
Figure 3.8 Wiring for APAX-5040PE
APAX-5040 Specifications
Digital Input
Channels: 24
Points per Common: 12
Type: Sink/Source (Wet Contact)
Input Voltage Rated Value: 24 VDC
– For "0" signal: -5 ~ 5 VDC
– For "1" signal: 15 ~ 30 VDC and -15 ~ -30 VDC
Input Impedance: 5.4 k
Typical Input Current: 4.4 mA (At signal "1")
Maximum Input Current: 7.3 mA
Input Filter: 3 ms
Input Characteristic Curve: According to IEC 61131-2, type 1
Protection
Isolation: 2,500 VDC (Between channels and backplane bus)
Over Voltage Protection: ±70 VDC
Environment
Operating Temperature: -20 ~ 75C (when mounted vertically)
Storage Temperature: -40 ~ 85C
Relative Humidity: 5 ~ 95% (non-condensing)
General
Dimensions (W x H x D): 30 x 139 x 100 mm
Weight: 160 g
Power Consumption: 2 W @ 24 VDC (typical)
Status Display: LED per channel
– On: Logic level “1”
– Off: Logic level “0”
51 APAX-5000 I/O Series User Manual
Chapter 3 Digital Input
/
Output Modules
3.1.5 APAX-5046SO 20-ch Digital Output Module
The APAX-5046SO features 20 digital output (source) channels. The digital output
channels offer short-circuit protection and LED to indicate digital status. The module
provides 2500 VDC optical isolation between channels and backplane bus. If any
high voltage or current damage the channels, the whole system (backplanes, other
modules, and control unit) won't be affected because it is already isolated.
The APAX-5046SO supports two independent power sources with different voltage
levels. For example, one can be 24VDC while the other is 12VDC.
Figure 3.9 APAX-5046SO Module Front View
Figure 3.10 Wiring for APAX-5046SO
Warning! Please use different power supply modules for digital channels and sys-
tem to ensure isolation effect.
VCC2
VCC2
GND1
GND2
VCC1
VCC1
APAX-5046SO
R
DO
VCC2
VCC2
19
0RR
R
GND
DO
DO
VCC1
VCC1
9
1
DO
GND102
DC
V24
24 V
DC
APAX-5000 I/O Series User Manual 52
APAX-5046SO Specifications
Digital Output
Channels: 20
Type: Source
Voltage Range: 10 ~ 35 V
DC
Rated Output Current at signal “1”: 1A (per channel)
Permitted Output Current (at signal “1”): max. 1.2A
Output Current at signal “0” (leakage current): 0.1 mA
Lamp Load: max. 10 W
On-State Voltage Drop: 0.15 V at 0.5 A
Switch Rate:
– For resistive load: max. 300 Hz
– For inductive load: max. 20 Hz
– For lamp load: max. 200 Hz (Using 5W lamp and testing under 24 V)
Protection
Isolation: 2,500 V
DC
(Between channels and backplane bus)
Short Circuit Protection
Thermal Shutdown Protection
Fail Safe Protection*
* When I/O module lose its communication with controller or coupler, the output channel will generate a pre-defined value
Environment
Operating Temperature: -10 ~ 60
o
C (when mounted vertically)
Storage Temperature: -40 ~ 70
o
C
Relative Humidity: 5 ~ 95% (non-condensing)
General
Dimensions (W x H x D): 30 x 139 x 100 mm
Weight: 165 g
Power Consumption: 2.5 W @ 24 V
DC
(typical)
Status Display: LED per channel
– On: Logic level “1”
– Off: Logic level “0”
53 APAX-5000 I/O Series User Manual
Chapter 3 Digital Input
/
Output Modules
3.2 Relay Output Modules
3.2.1 APAX-5060 12-ch Relay Output Module
The APAX-5060 relay output module provides 12 relay channels of Form A. Switches
can be used to control the relays. The digital output channels offer short-circuit protection and LED to indicate digital status. The module provides 2500 VDC optical isolation
between channels and backplane bus. If any high voltage or current damage the channels, the whole system (backplanes, other modules, and control unit) won't be affected
because it is already isolated.
Figure 3.11 APAX-5060 Module Frontal View
APAX-5000 I/O Series User Manual 54
Application Wiring
Figure 3.12 Wiring for APAX-5060
Warning! When you connect DO channel with inductive load, we suggest adding
one diode in the circuit to protect the APAX-5060 module. (Refer to figure below)
55 APAX-5000 I/O Series User Manual
Chapter 3 Digital Input
/
Output Modules
APAX-5060 Specifications
Relay Output
Channels: 12
Relay Type: Form A (SPST)
Switching Capacity and Lifetime of the Contact (For Resistive Load)
– VDE: 30,000 operations (5 A @ 250 VAC, 10 operations/minute at 8 C)
70,000 operations (5 A @ 30 VDC, 10 operations/ minute at 85 C)
– UL: 60,000 operations (5 A @ 250 VAC)
100,000 operations (5 A @ 30 VDC)
– Mechanism: 20,000,000 operations (no load, 300 operations/minute)
Breakdown Voltage: 500 VAC (50/60 Hz)
Contact Resistance: 30 m (maximum)
Insulation Resistance: 1 G (minimum) at 500 VDC
Operating Time: 10 ms maximum at rated voltage (excluding bounce time)
Release Time: 5 ms maximum at rated voltage (excluding bounce time)
Protection
Isolation: 2,500 VDC (Between channels and backplane bus)
Fail Safe Protection*
* When I/O module lose its communication with controller or coupler, the output channel will generate a pre-defined value
Environment
Operating Temperature: -10 ~ 60 C (when mounted vertically)
Storage Temperature: -40 ~ 70 C
Relative Humidity: 5 ~ 95% (non-condensing)
General
Dimensions (W x H x D): 30 x 139 x 100 mm
Weight: 195 g
Power Consumption: 2 W @ 24 VDC (typical)
Status Display: LED per channel
– On: Logic level “1”
– Off: Logic level “0”
APAX-5000 I/O Series User Manual 56
3.2.2 APAX-5060PE 12-ch Relay Output Module for P&E
Applications
The AP AX-5060PE relay output module provides 12 relay channels of Form A. Switches
can be used to control the relays. The digital output channels offer short-circuit protection and LED to indicate digital status.This module is an IEC-61850-3 compliant I/O
modules, and suitable for power and energy related application. The highly anti-electromagnetic interference make it more robust and reliable to survive in the hush environment. The module provides 2500 VDC optical isolation between channels and
backplane bus. If any high voltage or current damage the channels, the whole system
(backplanes, other modules, and control unit) won't be affected because it is already isolated.
Figure 3.13 APAX-5060PE Module Frontal View
Application Wiring
Figure 3.14 Wiring for APAX-5060PE
60PE
APAX-50
57 APAX-5000 I/O Series User Manual
Chapter 3 Digital Input
/
Output Modules
APAX-5060PE Specifications
Relay Output
Channels: 12
Relay Type: Form A (SPST)
Switching Capacity and Lifetime of the Contact (For Resistive Load)
– VDE: 30,000 operations (5 A @ 250 VAC, 10 operations/minute at 8 C)
70,000 operations (5 A @ 30 VDC, 10 operations/ minute at 85 C)
– UL: 60,000 operations (5 A @ 250 VAC)
100,000 operations (5 A @ 30 VDC)
– Mechanism: 20,000,000 operations (no load, 300 operations/minute)
Breakdown Voltage: 500 VAC (50/60 Hz)
Contact Resistance: 30 m (maximum)
Insulation Resistance: 1 G (minimum) at 500 VDC
Operating Time: 10 ms maximum at rated voltage (excluding bounce time)
Release Time: 5 ms maximum at rated voltage (excluding bounce time)
Protection
Isolation: 2,500 VDC (Between channels and backplane bus)
Fail Safe Protection*
* When I/O module lose its communication with controller or coupler, the output channel will generate a pre-defined value
Environment
Operating Temperature: -20 ~ 70C (when mounted vertically)
Storage Temperature: -40 ~ 85C
Relative Humidity: 5 ~ 95% (non-condensing)
General
Warning! When you connect DO channel with inductive load, we suggest adding
one diode in the circuit to protect the APAX-5060PE module. (Refer to
figure below)
APAX-5000 I/O Series User Manual 58
Dimensions (W x H x D): 30 x 139 x 100 mm
Weight: 195 g
Power Consumption: 2 W @ 24 VDC (typical)
Status Display: LED per channel
– On: Logic level “1”
– Off: Logic level “0”
59 APAX-5000 I/O Series User Manual
Chapter 3 Digital Input
/
Output Modules
3.3 Counter Modules
3.3.1 APAX-5080 Counter/Frequency and DIO Module
The APAX-5080 features counter/frequency and DIO functions. For the digital input
function, the APAX-5080 supports 4 isolated digital input and Gate function. For digital output function, the APAX-5080 supports 4 general isolated digital outp ut and specific alarm function with counter. For counter/frequency function, the APAX-5080 can
support many modes of counter input type such as A/B phase and CW/CCW types.
And the frequency input range can support from 0.1Hz to 1MHz. Here is the APAX5080 module view and application wiring below.
Figure 3.15 APAX-5080 Module Front View
GND
DO3
DO2
DO1
C1A-
C2A+
C2A-
C1B+
C1B-
C1A+
C0B-
C0B+
C0A-
C0A+
DI2
DO0
COM
DI3
DI1
DI0
C3A+
C3A-
C3B+
C3B-
C2B-
C2B+
APAX-50
80
APAX-5000 I/O Series User Manual 60
Application Wiring
Figure 3.16 Wiring for APAX-5080
Warning! Please use different power supply modules for digital channels and sys-
tem to ensure isolation effect.
61 APAX-5000 I/O Series User Manual
Chapter 3 Digital Input
/
Output Modules
APAX-5080 Function Block
APAX-5000 I/O Series User Manual 62
APAX-5080 Specifications
Digital Input
Channels: 4
Input Voltage
– For “0” Signal: 0 ~ 3 VDC
– For “1” Signal: 10 ~ 30 VDC
Input Current: 5~15 mA (For Signal “1”, typical)
Minimum Pulse Width: 500 ns (Max. Input Frequency)
Digital Output
Channels: 4
Voltage Range: 8 ~ 35 VDC
Output Current at Signal “1”
– Rated: 0.5 A
– Permitted: 0.75 A (max.)
Output Current at Signal “0”10A
– (Leakage Current)
Output Delay at Resistive Load
– From logic level “0” to “1”100 s (max.)
– From logic level “1” to “0”200 s (max.)
Counter Input
Modes: Pulse and Direction, Up/Down, Up Pulse, A/B phase and Frequency
Channels: 4 (Pulse and Direction, Up/Down, and A/B phase mode)
– 8 (Up Pulse and Frequency mode)
Counting Range: 32-bit + 1-bit overflow/underflow
Minimum Pulse Width: 500 ns
Input Frequency (max.): 1 MHz
Input Voltage
– For “0” Signal0 ~ 3 VDC
– For “1” Signal10 ~ 30 VDC
Input Current: 5~15 mA (For Signal “1”, typical)
Digital Noise Filter: 1~65000 s (programmable)
Protection
Isolation: 2500 VDC (Between channels and backplane bus)
Over Voltage Protection: 50 VDC (all channels)
– 110 VDC (single channel) (for DI and Counter Input channels)
Short Circuit Protection: Yes (for DO channels)
Environment
Operating Temperature: -10 ~ 70° C (14 ~ 158° F)
Storing Temperature: -25 ~ 85° C (-13 ~ 185° F)
Storing Humidity: 5 ~ 95% RH (non-condensing)
63 APAX-5000 I/O Series User Manual
Chapter 3 Digital Input
/
Output Modules
General
Dimensions (W x H x D): 30 x 139 x 100 mm
Weight: 165 g
Power Consumption: 2.5 W @ 24 VDC (typical)
Status Display: LED per channel
– On: Logic level “1”
– Off: Logic level “0”
APAX-5080 Counter Mode No Gate No Alarm
There are so many counter modes in APAX-5080 and below will use counter0 as an
example to explain every counter mode operation principle.
Below are the definitions of counter mode.
Pulse/DIR: Ch0_A provides the counting function, one pulse, one count, and
Ch0_B provides the clockwise and counter clockwise function.
Up/Down: CH0_A provides the counter up function, one pulse one up count,
and CH0_A provides the counter down function, one pulse one down count.
UP: CH0_A provides the counter up function, one pulse one up count.
A/B Phase 1X: counter mode A/B Phase x 1--If the signal “A” leads “B” by a ris-
ing or falling edge, then the number of steps will be added by one, and vice
versa.
A/B Phase 2X: counter mode A/B Phase x 2
A/B Phase 4X: counter mode A/B Phase x 4
With Reload: When the counter0 value is overflow , the value will be reset to the
initial value.
No Reload: If the counter0 value is overflow, the value will be 0. If the counter0
value is overflow, the value will be the max value.
Count Once: It means if the counter0 is overflow, it won’t count again.
Count Repetitively: when counter value is overflow or underflow , it will reset to
the default value and continuous to count.
Frequency: CH0_A provides the frequency function from 0.1Hz~1MHz.
Pulse/DIR, No Reload, Count Once
Figure 3.3 shows pulse/direction mode, Ch0_A provides the counting function, one
pulse, one count. Ch0_B provides the clockwise and counter clockwise function.
When the counter0 is enabled, the couner0 starts to count. If the counter value is
overflow or underflow, it will show the minimum (0x00) or maximum (0xFFFFFFFF)
value and not count continuously.
0x33 0x34 0x35
Up Down
0x34 0x33 0x32
……… 0x00 0 xFFFFFFFF
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Underflow
APAX-5000 I/O Series User Manual 64
Figure 3.17 Pulse/DIR, No Reload, Count Once
Pulse/DIR, With Reload, Count Once
Figure 3.4 shows pulse/direction mode, Ch0_A provides the counting function, one
pulse, one count. Ch0_B provides the clockwise and counter clockwise function.
When the counter0 is enabled, the couner0 starts to count. If the counter value is
overflow or underflow, it will reset to the defined value (e.g. 0x33) but won’t keep
counting.
Figure 3.18 Pulse/DIR, With Reload, Count Once
0x33 0x32 0x31
UpDown
0x32 0x33 0x34
……… 0xF..F 0x00
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Overflow
0x33 0x34 0x35
Up Down
0x34 0x33 0x32
……… 0x00 0x33
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Underflow
0x33 0x32 0x31
UpDown
0x32 0x33 0x34
……… 0xF..F 0x33
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Overflow
65 APAX-5000 I/O Series User Manual
Chapter 3 Digital Input
/
Output Modules
Pulse/DIR, With Reload, Count Repetitively
Figure 3.5 shows pulse/direction mode, Ch0_A provides the counting function, one
pulse, one count. Ch0_B provides the clockwise and counter clockwise function.
When the counter0 is enabled, the couner0 starts to count. If the counter value is
overflow or underflow, it will reset to the defined value (e.g. 0x33) and keep counting
repetitively.
Figure 3.19 Pulse/DIR, With Reload, Count Repetitively
0x33 0x34 0x33
Up Down
……… 0x00
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Underflow
0x33 0x32 ……… 0x00 0x33
0x33 0x32 0x33
Up
Down
……… 0xF..F
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Overflow
0x33 0x34 ……… 0xF..F 0x33
APAX-5000 I/O Series User Manual 66
Up/Down, No Reload, Count Once
Figure 3.6 shows up/down mode, Ch0_A provides the counting up function, one
pulse, one up count. Ch0_B provides the counting down function, one pulse, one
down count. When the counter0 is enabled, the couner0 starts to count. If the counter
value is overflow or underflow, it will show the minimum (0x00) or maximum
(0xFFFFFFFF) value and not count continuously.
Figure 3.20 Up/Down, No Reload, Count Once
0x33 0x34 0x35 0x36 0x35 0x34 ……… 0x00 0xFFFFFFFF
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Underflow
0x33 0x32 0x31 0x30 0x31 0x32 ……… 0xF..F 0x00
Ch0_A
Ch0_B
Counter
0
Value
Counter0
Enable
Counter0
Overflow
67 APAX-5000 I/O Series User Manual
Chapter 3 Digital Input
/
Output Modules
Up/Down, With Reload, Count Once
Figure 3.7 shows up/down mode, Ch0_A provides the counting up function, one
pulse, one up count. Ch0_B provides the counting down function, one pulse, one
down count. When the counter0 is enabled, the couner0 starts to count. If the counter
value is overflow or underflow, it will reset to the defined value (e.g. 0x33) but won’t
keep counting.
Figure 3.21 Up/Down, With Reload, Count Once
0x33 0x34 0x35 0x36 0x35 0x34 ……… 0x00 0x33
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Underflow
0x33 0x32 0x31 0x30 0x31 0x32 ……… 0xF..F 0x33
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Overflow
APAX-5000 I/O Series User Manual 68
Up/Down, With Reload, Count Repetitively
Figure 3.8 shows up/down mode, Ch0_A provides the counting up function, one
pulse, one up count. Ch0_B provides the counting down function, one pulse, one
down count. When the counter0 is enabled, the couner0 starts to count. If the counter
value is overflow or underflow, it will reset to the defined value (e.g. 0x33) and keep
counting repetitively.
Figure 3.22 Up/Down, With Reload, Count Once
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
0x33 0x34 0x33 ……… 0x00 0x33 0x32 ……… 0x00 0x33
Counter0
Underflow
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
0x33 0x32 0x33 ……… 0xF..F 0x33 0x34 ……… 0xF..F 0x33
Counter0
Overflow
69 APAX-5000 I/O Series User Manual
Chapter 3 Digital Input
/
Output Modules
Up, No Reload, Count Once
Figure 3.9 shows counter up mode, Ch0_A provides the counting up function, one
pulse, one up count. When the counter0 is enabled, the couner0 starts to count. If the
counter value is overflow or underflow, it will show the minimum (0x00) or maximum
(0xFFFFFFFF) value and not count continuously.
Figure 3.23 Up, No Reload, Count Once
Up, With Reload, Count Once
Figure 3.10 shows counter up mode, Ch0_A provides the counting up function, one
pulse, one up count. When the counter0 is enabled, the couner0 starts to count. If the
counter value is overflow or underflow , it will reset to the d efined value (e.g . 0x33) but
won’t keep counting.
Figure 3.24 Up, With Reload, Count Once
0x33 0x34 0x35 0x36 0x37 0x38 ……… 0xF..F 0x00
Ch0_A
Counter0
Value
Counter0
Enable
Counter0
Overflow
0x33 0x34 0x35 0x36 0x37 0x38 ……… 0xF..F 0x00
Ch0_B
Counter1
Value
Counter1
Enable
Counter1
Overflow
0x33 0x34 0x35 0x36 0x37 0x38 ……… 0xF..F 0x33
Ch0_A
Counter0
Value
Counter0
Enable
Counter0
Overflow
0x33 0x34 0x35 0x36 0x37 0x38 ……… 0xF..F 0x33
Ch0_B
Counter1
Value
Counter1
Enable
Counter1
Overflow
APAX-5000 I/O Series User Manual 70
Up, With Reload, Count Repetitively
Figure 3.11 shows up/down mode, Ch0_A provides the counting up function, one
pulse, one up count. Ch0_B provides the counting down function, one pulse, one
down count. When the counter0 is enabled, the couner0 starts to count. If the counter
value is overflow or underflow, it will reset to the defined value (e.g. 0x33) and keep
counting repetitively.
Figure 3.25 Up, With Reload, Count Repetitively
Frequency
Figure 3.12 shows the frequency function. Every counter channel can measure the
frequency of assigned time window and the range is from 0.1Hz~1MHz.
Figure 3.26 Frequency
Ch0_A
Counter0
Value
Counter0
Enable
Counter0
Overflow
0x33 0x34 0x35 ……… 0xF..F 0x33 0x34 ……… 0xF..F 0x33
Ch0_B
Counter1
Value
Counter1
Enable
Counter1
Overflow
0x33 0x34 0x35 ……… 0xF..F 0x33 0x34 ……… 0xF..F 0x33
Ch0_A
Counter0
Value
Counter0
Enable
0x33
Pulse Number in one acquisition time window
Ch0_B
Counter1
Value
Counter1
Enable
0x33
Puls e Number i n one a c qu is i t i on t i me w i ndow
71 APAX-5000 I/O Series User Manual
Chapter 3 Digital Input
/
Output Modules
A/B Phase 1X, No Reload, Count Once
Figure 3.13 shows A/B Phase 1X mode, Ch0_A and Ch0_B provide the counting
function. When the counter0 is enabled, the couner0 starts to count. If the counter
value is overflow or underflow, it will show the minimum (0x00) or maximum
(0xFFFFFFFF) value and not count continuously.
Figure 3.27 A/B Phase 1X, No Reload, Count Once
0x33 0x34 0x35 0x34 0x33 0x32 ……… 0 x00 0xFFFFFFFF
Ch0_A
Ch0_B
Counter 0
Value
Counter 0
Enable
Counter0
Underflow
0x33 0x32 0x31 0 x32 0x 33 0x3 4 ……… 0xF..F 0x00
Ch0_A
Ch0_B
Counter 0
Value
Counter 0
Enable
Counter0
Overflow
APAX-5000 I/O Series User Manual 72
A/B Phase 1X, With Reload, Count Once
Figure 3.14 shows A/B Phase 1X mode, Ch0_A and Ch0_B provide the counting
function. When the counter0 is enabled, the couner0 starts to count. If the counter
value is overflow or underflow, it will reset to the defined value (e.g. 0x33) but won’t
keep counting.
Figure 3.28 A/B Phase 1X, With Reload, Count Once
0x33 0x34 0x35 0x34 0x33 0x32 ……… 0x00 0x33
Ch0_A
Ch0_B
Counter 0
Value
Counter 0
Enable
Counter0
Underflow
0x33 0x32 0x31 0x32 0x33 0x34 ……… 0xF..F 0x33
Ch0_A
Ch0_B
Counter 0
Value
Counter 0
Enable
Counter0
Overflow
73 APAX-5000 I/O Series User Manual
Chapter 3 Digital Input
/
Output Modules
A/B Phase 1X, With Reload, Count Repetitively
Figure 3.15 shows A/B Phase 1X mode, Ch0_A and Ch0_B provide the counting
function. When the counter0 is enabled, the couner0 starts to count. If the counter
value is overflow or underflow, it will reset to the defined value (e.g. 0x33) and keep
counting repetitively.
Figure 3.29 A/B Phase 1X, With Reload, Count Repetitively
0x33 0x32 0x33 ……… 0xF..F
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Overflow
0x33 0x34 ……… 0xF..F 0x33
0x33 0x34 0x33 ……… 0x00
Ch0_B
Ch0_A
Counter 0
Value
Counter 0
Enable
Counter0
Underflow
0x33 0x32 ……… 0x00 0x33
APAX-5000 I/O Series User Manual 74
A/B Phase 2X, No Reload, Count Once
Figure 3.16 shows A/B Phase 2X mode, Ch0_A and Ch0_B provide the counting
function. When the counter0 is enabled, the couner0 starts to count. If the counter
value is overflow or underflow, it will reset to the defined value (e.g. 0x33) but won’t
keep counting.
Figure 3.30 A/B Phase 2X, No Reload, Count Once
0x33 0x32 0x31 0x32 0x33 0x34 ……… 0xF..F 0x00
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Overflow
0x33 0x34 0x35 0x34 0x33 ……… 0x00 0xFFFFFFFF
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Underflow
75 APAX-5000 I/O Series User Manual
Chapter 3 Digital Input
/
Output Modules
A/B Phase 2X, With Reload, Count Once
Figure 3.17 shows A/B Phase 2X mode, Ch0_A and Ch0_B provide the counting
function. When the counter0 is enabled, the couner0 starts to count. If the counter
value is overflow or underflow, it will reset to the defined value (e.g. 0x33) and keep
counting repetitively.
Figure 3.31 A/B Phase 2X, With Reload, Count Once
0x33 0x32 0x31 0x32 0x33 0x34 ……… 0xF..F 0x33
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Overflow
0x33 0x34 0x35 0x34 0x33 ……… 0x00 0x33
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Underflow
APAX-5000 I/O Series User Manual 76
A/B Phase 2X, With Reload, Count Repetitively
Figure 3.18 shows A/B Phase 2X mode, Ch0_A and Ch0_B provide the counting
function. When the counter0 is enabled, the couner0 starts to count. If the counter
value is overflow or underflow, it will reset to the defined value (e.g. 0x33) and keep
counting repetitively.
Figure 3.32 A/B Phase 2X , With Reload , Count Repetitively
0x33 0x34 0x35 0x34
Ch0_B
Ch0_A
Counter0
Value
Counter0
Enable
Counter0
Underflow
0x00 0x33 ……… 0x00 0x 33……… 0x32
0x33 0x32 0x 33
Ch0_B
Ch0_A
Counter0
Value
Counter0
Enable
Counter0
Overflow
0xF..F 0x33 ……… 0xF..F 0x 33……… 0x340x31 0x32
77 APAX-5000 I/O Series User Manual
Chapter 3 Digital Input
/
Output Modules
A/B Phase 4X, No Reload, Count Once
Figure 3.19 shows A/B Phase 4X mode, Ch0_A and Ch0_B provide the counting
function. When the counter0 is enabled, the couner0 starts to count. If the counter
value is overflow or underflow, it will reset to the defined value (e.g. 0x33) but won’t
keep counting.
Figure 3.33 A/B Phase 4X, No Reload, Count Once
0x33
0x00
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
0x32 0x31 0x30 0x2F 0x30 0x31 0x32 0x33 0x34 0x35
……
0xF..F
Counter0
Overflow
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
0x33
0xFFFFFFFF
0x34 0x35 0x36 0x37 0x36 0x35 0x34 0x33 0x32 0x31
……
0x00
Counter0
Underflow
APAX-5000 I/O Series User Manual 78
A/B Phase 4X, With Reload, Count Once
Figure 3.20 shows A/B Phase 4X mode, Ch0_A and Ch0_B provide the counting
function. When the counter0 is enabled, the couner0 starts to count. If the counter
value is overflow or underflow, it will reset to the defined value (e.g. 0x33) and keep
counting repetitively.
Figure 3.34 A/B Phase 4X, With Reload, Count Once
0x33
0x33
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
0x32 0x31 0x30 0x2F 0x30 0x31 0x32 0x33 0x34 0x35
……
0xF..F
Counter0
Overflow
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
0x33
0x33
0x34 0x35 0x36 0x37 0x36 0x35 0x34 0x33 0x32 0x31
……
0x00
Counter0
Underflow
79 APAX-5000 I/O Series User Manual
Chapter 3 Digital Input
/
Output Modules
A/B Phase 4X, With Reload, Count Repetitively
Figure 3.21 shows A/B Phase 2X mode, Ch0_A and Ch0_B provide the counting
function. When the counter0 is enabled, the couner0 starts to count. If the counter
value is overflow or underflow, it will reset to the defined value (e.g. 0x33) and keep
counting repetitively.
Figure 3.35 A/B Phase 4X, With Reload, Count Repetitively
DI Gate Function No Alarm
DI Gate Disable : Whatever the DI value is, the counter still continuously counts
DI Gate Enable : If the DI value is set to high, the counter can count. Otherwise,
the counter will be stopped counting.
Not Retriggerable : It means DI0 only can trigger the counter to count once.
Retriggerable : It means DI0 can trigger the counter to count anytime.
High level : the DI0 trigger level
Low level : the DI0 trigger level
Rising Edge : the DI0 trigger edge
Falling Edge : the DI0 trigger edge
Rising Edge Start : When DI0 status changes from low to high, the counter will
start to count. After start, whatever the DI0 status, the counter still counts until
the counter0 is disabled.
Falling Edge Start : When DI0 st atus changes from high to low, the counter will
start to count. After start, whatever the DI0 status, the counter still counts until
the counter0 is disabled.
Ch0_B
Ch0_A
Counter0
Value
Counter0
Enable
Counter0
Overflow
0x33 0x32 0x31 0x30 0x2F 0x30 0x31 0x32 ………… 0xF..F 0x34 0x3 50x33 …………0x36 0x340xF..F 0x3 3 0x35
Ch0_B
Ch0_A
Counter0
Value
Counter0
Enable
Counter0
Underflow
0x33 0x34 0x35 0x36 0x37 0x36 0x35 0x34
…………
0x00 0x32 0x310x33
…………
0x30 0x320x00 0x33
APAX-5000 I/O Series User Manual 80
Pulse/DIR, With Reload, Count Once, DI Gate Disable
Figure 3.22 shows pulse/direction mode, Ch0_A provides the counting function, one
pulse, one count. Ch0_B provides the clockwise and counter clockwise function.
When the counter0 is enabled, the couner0 starts to count. If the counter value is
overflow or underflow, it will show the minimum (0x00) or maximum (0xFFFFFFFF)
value and not count continuously. Whatever the DI value is, the counter still continuously counts.
Figure 3.36 Pulse/DIR, With Reload, Count Once, DI Gate Disable
0x33 0x34 0x35
Up Down
0x34 0x33 0x32
……… 0x00 0x33
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Underflow
DI0
0x33 0x32 0x31
UpDown
0x32 0x33 0x34
……… 0xF..F 0x33
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Overflow
DI0
81 APAX-5000 I/O Series User Manual
Chapter 3 Digital Input
/
Output Modules
Pulse/DIR, With Reload, Count Repetitively, DI Gate Disable
Figure 3.23 shows pulse/direction mode, Ch0_A provides the counting function, one
pulse, one count. Ch0_B provides the clockwise and counter clockwise function.
When the counter0 is enabled, the couner0 starts to count. If the counter value is
overflow or underflow, it will reset to the defined value (e.g. 0x33) but won’t keep
counting. Whatever the DI value is, the counter still continuously counts.
Figure 3.37 Pulse/DIR, With Reload, Count Repetitively, DI Gate Disable
0x33 0x34 0x33
Up Down
……… 0x00
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Underflow
0x33 0x32 ……… 0x00 0x33
DI0
0x33 0x32 0x33
Up
Down
……… 0xF..F
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Overflow
0x33 0x34 ……… 0xF..F 0x33
DI0
APAX-5000 I/O Series User Manual 82
Pulse/DIR, With Reload, Count Once, DI Gate Enable, High level, Not Retriggerable
Figure 3.24 shows pulse/direction mode, Ch0_A provides the counting function, one
pulse, one count. Ch0_B provides the clockwise and counter clockwise function.
When the counter0 is enabled, the couner0 starts to count. If the counter value is
overflow or underflow, it will reset to the defined value (e.g. 0x33) but won’t keep
counting. If the DI0 value is high level, the counter0 will starts to count but cannot
retriggered. Otherwise, the counter0 will stop counting.
Figure 3.38 Pulse/DIR, With Reload, Count Once, DI Gate Enable, High level,
Not Retriggerable
0x33 0x32 0x31
UpDown
0x32 0x33 0x34
……… 0xF0 0xF1
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Overflow
DI0
0x33 0x34 0x35
Up Down
0x34 0x33 0x32
……… 0x11 0x10
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Underflow
DI0
83 APAX-5000 I/O Series User Manual
Chapter 3 Digital Input
/
Output Modules
Pulse/DIR, With Reload, Count Repetitively, DI Gate Enable, High level, Not
Retriggerable
Figure 3.25 shows pulse/direction mode, Ch0_A provides the counting function, one
pulse, one count. Ch0_B provides the clockwise and counter clockwise function.
When the counter0 is enabled, the couner0 starts to count. If the counter value is
overflow or underflow, t will reset to the defined value (e.g. 0x33) but won’t keep
counting. If the DI0 value is high level, the counter0 will starts to count but cannot
retriggered. Otherwise, the counter0 will stop counting.
Figure 3.39 Pulse/DIR , With Reload , Count Repetitively, DI Gate Enable, High
level, Not Retriggerable
0x33 0x32 0x33
Up
Down
……… 0xF..F
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Overflow
0x33 0x34 0x35 0x36
DI0
0x33 0x34 0x33
Up Down
……… 0x00
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Underflow
0x33 0x32 0x31 0x30
DI0
APAX-5000 I/O Series User Manual 84
Pulse/DIR, With Reload , Count Once, DI Gate Enable, High level, Retriggerable
Figure 3.26 shows pulse/direction mode, Ch0_A provides the counting function, one
pulse, one count. Ch0_B provides the clockwise and counter clockwise function.
When the counter0 is enabled, the couner0 starts to count. If the counter value is
overflow or underflow, it will reset to the defined value (e.g. 0x33) and keep counting
repetitively.. If the DI0 value is high level, the counter0 will starts to count and can be
retriggered. Otherwise, the counter0 will stop counting.
Figure 3.40 Pulse/DIR, With Reload, Count Repetitively, DI Gate Enable, High
level, Not Retriggerable
0x33 0x34 0x35
Up Down
0x34
0x33
……… 0x00 0x33
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Underflow
DI0
0x33 0x32 0x31
UpDown
0x32
0x33
……… 0xF..F 0x33
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Overflow
DI0
85 APAX-5000 I/O Series User Manual
Chapter 3 Digital Input
/
Output Modules
Pulse/DIR, With Reload, Count Repetitively, DI Gate Enable, High level, Retriggerable
Figure 3.27 shows pulse/direction mode, Ch0_A provides the counting function, one
pulse, one count. Ch0_B provides the clockwise and counter clockwise function.
When the counter0 is enabled, the couner0 starts to count. If the counter value is
overflow or underflow, it will reset to the defined value (e.g. 0x33) and keep counting
repetitively. If the DI0 value is high level, the counter0 will starts to count and can be
retriggered. Otherwise, the counter0 will stop counting.
Figure 3.41 Pulse/DIR, With Reload , Count Repetitively, DI Gate Enable, High
level, Retriggerable
0x33 0x34
0x33
Up Down
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Underflow
DI0
0x32
......
0x00 0x33 0x32 0x31 0x30
0x33 0x32
0x33
UpDown
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Overflow
DI0
0x34
......
0xF..F 0x33 0x34 0x35 0x36
APAX-5000 I/O Series User Manual 86
Pulse/DIR, With Reload, Count Once, DI Gate Enable, Low level, Not Retriggerable
Figure 3.28 shows pulse/direction mode, Ch0_A provides the counting function, one
pulse, one count. Ch0_B provides the clockwise and counter clockwise function.
When the counter0 is enabled, the couner0 starts to count. If the counter value is
overflow or underflow, it will reset to the defined value (e.g. 0x33) but won’t keep
counting. If the DI0 value is low level, the counter0 will starts to count but cannot
retriggered. Otherwise, the counter0 will stop counting.
Figure 3.42 Pulse/DIR, With Reload, Count Repetitively, DI Gate Enable, Low
level, Retriggerable
0x33 0x32 0x31
UpDown
0x32 0x33 0x34
………
0xF0 0xF1
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Overflow
DI0
0x33 0x34 0x35
Up Down
0x34 0x33 0x32
………
0x11 0x10
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Underflow
DI0
87 APAX-5000 I/O Series User Manual
Chapter 3 Digital Input
/
Output Modules
Pulse/DIR, With Reload, Count Repetitively, DI Gate Enable, Low level, Not
Retriggerable
Figure 3.29 shows pulse/direction mode, Ch0_A provides the counting function, one
pulse, one count. Ch0_B provides the clockwise and counter clockwise function.
When the counter0 is enabled, the couner0 starts to count. If the counter value is
overflow or underflow, t will reset to the defined value (e.g. 0x33) but won’t keep
counting. If the DI0 value is low level, the counter0 will start to count but cannot be
retriggered. Otherwise, the counter0 will stop counting.
Figure 3.43 Pulse/DIR , With Reload , Count Repetitively, DI Gate Enable, Low
level, Not Retriggerable
0x33 0x32 0x33
Up
Down
………
0xF..F
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Overflow
0x33 0x34 0x35 0x36
DI0
0x33 0x34 0x33
Up Down
……… 0x00
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Underflow
0x33 0x32 0x31 0x30
DI0
APAX-5000 I/O Series User Manual 88
Pulse/DIR, With Reload, Count Once, DI Gate Enable, Low level, Retriggerable
Figure 3.29 shows pulse/direction mode, Ch0_A provides the counting function, one
pulse, one count. Ch0_B provides the clockwise and counter clockwise function.
When the counter0 is enabled, the couner0 starts to count. If the counter value is
overflow or underflow, it will reset to the defined value (e.g. 0x33) and keep counting
repetitively. If the DI0 value is low level, the counter0 will starts to count and can be
retriggered. Otherwise, the counter0 will stop counting.
Figure 3.44 Pulse/DIR, With Reload, Count Once, DI Gate Enable, Low level,
Retriggerable
0x33 0x34 0x35
Up Down
0x34
0x33
……… 0x00 0x33
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Underflow
DI0
0x33 0x32 0x31
UpDown
0x32
0x33
……… 0xF..F 0x33
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Overflow
DI0
89 APAX-5000 I/O Series User Manual
Chapter 3 Digital Input
/
Output Modules
Pulse/DIR, With Reload, Count Repetitively, DI Gate Enable, Low level, Retriggerable
Figure 3.30 shows pulse/direction mode, Ch0_A provides the counting function, one
pulse, one count. Ch0_B provides the clockwise and counter clockwise function.
When the counter0 is enabled, the couner0 starts to count. If the counter value is
overflow or underflow, it will reset to the defined value (e.g. 0x33) and keep counting
repetitively. If the DI0 value is low level, the counter0 will starts to count and can be
retriggered. Otherwise, the counter0 will stop counting.
Figure 3.45 Pulse/DIR , With Reload , Count Repetitively, DI Gate Enable, Low
level, Retriggerable
0x33 0x34
0x33
Up Down
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Underflow
DI0
0x32
......
0x00 0x33 0x32 0x31 0x30
0x33 0x32
0x33
UpDown
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Overflow
DI0
0x34
......
0xF..F 0x33 0x34 0x35 0x36
APAX-5000 I/O Series User Manual 90
Pulse/DIR, With Reload, Count Once, DI Gate Enable, Rising Edge, Not Retriggerable
Figure 3.31 shows pulse/direction mode, Ch0_A provides the counting function, one
pulse, one count. Ch0_B provides the clockwise and counter clockwise function.
When the counter0 is enabled, the couner0 starts to count. If the counter value is
overflow or underflow, it will reset to the defined value (e.g. 0x33) but won’t keep
counting. If the DI0 status is rising edge, the counter0 will starts to count but cannot
retriggered. Otherwise, the counter0 will stop counting.
Figure 3.46 Pulse/DIR, With Reload, Count Once, DI Gate Enable, Rising Edge,
Not Retriggerable
0x33 0x32 0x31
UpDown
0x32 0x33 0x34
……… 0xF0 0xF1
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Overflow
DI0
0x33 0x34 0x35
Up Down
0x34 0x33 0x32
……… 0x11 0x10
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Underflow
DI0
91 APAX-5000 I/O Series User Manual
Chapter 3 Digital Input
/
Output Modules
Pulse/DIR, With Reload, Count Repetitively, DI Gate Enable, Rising Edge, Not
Retriggerable
Figure 3.32 shows pulse/direction mode, Ch0_A provides the counting function, one
pulse, one count. Ch0_B provides the clockwise and counter clockwise function.
When the counter0 is enabled, the couner0 starts to count. If the counter value is
overflow or underflow, t will reset to the defined value (e.g. 0x33) but won’t keep
counting. If the DI0 status is rising edge, the counter0 will start to count but canno t be
retriggered. Otherwise, the counter0 will stop counting.
Figure 3.47 Pulse/DIR, With Reload, Count Repetitively, DI Gate Enable, Rising
Edge, Not Retriggerable
0x33 0x32 0x33
Up
Down
……… 0xF..F
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Overflow
0x33 0x34 0x35 0x36
DI0
0x33 0x34 0x33
Up Down
……… 0x00
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Underflow
0x33 0x32 0x31 0x30
DI0
APAX-5000 I/O Series User Manual 92
Pulse/DIR, With Reload, Count Once, DI Gate Enable, Rising Edge, Retriggerable
Figure 3.33 shows pulse/direction mode, Ch0_A provides the counting function, one
pulse, one count. Ch0_B provides the clockwise and counter clockwise function.
When the counter0 is enabled, the couner0 starts to count. If the counter value is
overflow or underflow, it will reset to the defined value (e.g. 0x33) and keep counting
repetitively. If the DI0 status is rising edge, the counter0 will starts to count and can
be retriggered. Otherwise, the counter0 will stop counting.
Figure 3.48 Pulse/DIR , With Reload , Count Once, DI Gate Enable, Rising Edge,
Retriggerable
0x33 0x34 0x35
Up Down
0x34
0x33
……… 0x00 0x33
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Underflow
DI0
0x33 0x32 0x31
UpDown
0x32
0x33
……… 0xF..F 0x33
Ch0_A
Ch0_B
Counter0
Value
Counter0
Enable
Counter0
Overflow
DI0
