Mini-ITX
AIMB-250 Series
Intel® Pentium® M / Celeron® M Mini ITX Motherboard
User’s Manual
st
Ed – January 2007
1
AIMB-250 Series
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
Notice
This guide is designed for experienced users to setup the system within the shortest time.
For detailed information, please always refer to the electronic user's manual.
Copyright Notice
Copyright © 2006 Advantech Corp., ALL RIGHTS RESERVED.
No part of this document may be reproduced, copied, translated, or transmitted in any form
or by any means, electronic or mechanical, for any purpose, without the prior written
permission of the original manufacturer.
Trademark Acknowledgement
Brand and product names are trademarks or registered trademarks of their respective
owners.
2 AIMB-250 Series User’s Manual
User’s Manual
Disclaimer
Advantech Corp. reserves the right to make changes, without notice, to any product,
including circuits and/or software described or contained in this manual in order to improve
design and/or performance. Advantech Corp. assumes no responsibility or liability for the
use of the described product(s), conveys no license or title under any patent, copyright, or
masks work rights to these products, and makes no representations or warranties that
these products are free from patent, copyright, or mask work right infringement, unless
otherwise specified. Applications that are described in this manual are for illustration
purposes only. Advantech Corp. makes no representation or warranty that such application
will be suitable for the specified use without further testing or modification.
Life Support Policy
ADVANTECH CORP. PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN
LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE PRIOR WRITTEN APPROVAL
OF ADVANTECH CORP.
As used herein:
1. Life support devices or systems are devices or systems which, (a) are intended for
surgical implant into body, or (b) support or sustain life and whose failure to perform,
when properly used in accordance with instructions for use provided in the labeling, can
be reasonably expected to result in significant injury to the user.
2. A critical component is any component of a life support device or system whose failure
to perform can be reasonably expected to cause the failure of the life support device or
system, or to affect its safety or effectiveness.
A Message to the Customer
Advantech Customer Services
Each and every Advantech product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Advantech device is destined for the laboratory or the
factory floor, you can be assured that your product will provide the reliability and ease of
operation for which the name Advantech has come to be known.
Your satisfaction is our primary concern. Here is a guide to Advantech customer services.
To ensure you get the full benefit of our services, please follow the instructions below
carefully.
AIMB-250 User’s Manual
3
AIMB-250 Series
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
If you still cannot find the answer, gather all the information or questions that apply to your
problem, and with the product close at hand, call your dealer. Our dealers are well trained
and ready to give you the support you need to get the most from your Advantech products.
In fact, most problems reported are minor and are able to be easily solved over the phone.
In addition, free technical support is available from Advantech engineers every business
day. We are always ready to give advice on application requirements or specific information
on the installation and operation of any of our products. Please do not hesitate to call or
e-mail us.
Headquarters
Advantech Corp.
No.1, Alley 20, Lane 26, Rueiguang Road,
Neihu District, Taipei 114,
Taiwan
Tel : +886-2-2792-7818
Fax : +886-2-2794-7306
http://www.Advantech.com.tw
4 AIMB-250 Series User’s Manual
User’s Manual
Product Warranty
Advantech warrants to you, the original purchaser, that each of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been subject
to misuse, abuse, accident or improper installation. Advantech assumes no liability under
the terms of this warranty as a consequence of such events. Because of Advantech high
quality-control standards and rigorous testing, most of our customers never need to use our
repair service. If any of Advantech products is defective, it will be repaired or replaced at no
charge during the warranty period. For out-of-warranty repairs, you will be billed according
to the cost of replacement materials, service time, and freight. Please consult your dealer
for more details. If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU type and
speed, Advantech products model name, hardware & BIOS revision number, other
hardware and software used, etc.) Note anything abnormal and list any on-screen
messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your manual, product, and any
helpful information available.
3. If your product is diagnosed as defective, obtain an RMA (return material authorization)
number from your dealer. This allows us to process your good return more quickly.
4. Carefully pack the defective product, a complete Repair and Replacement Order Card
and a photocopy proof of purchase date (such as your sales receipt) in a shippable
container. A product returned without proof of the purchase date is not eligible for
warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid to your
dealer.
AIMB-250 User’s Manual
5
AIMB-250 Series
Contents
1. Getting Started..........................................................................................................10
1.1 Safety Precautions ..................................................................................................10
1.2 Packing List.............................................................................................................10
1.3 Document Amendment History ...............................................................................11
1.4 Manual Objectives...................................................................................................12
1.5 System Specifications .............................................................................................13
1.6 Architecture Overview .............................................................................................16
1.6.1 Block Diagram................................................................................................................................16
1.6.2 Intel 855GME and ICH4 ................................................................................................................. 17
1.6.3 Intel 855GME and ICH4 ................................................................................................................. 19
1.6.4 DRAM Interface (Intel 855GME) .................................................................................................... 20
1.6.5 DRAM Interface (Intel 855GME) .................................................................................................... 20
1.6.6 PCI Interface .................................................................................................................................. 20
1.6.7 IDE Interface (Bus Master Capability and Synchronous DMA Mode ) .......................................... 21
1.6.8 USB 2.0 .......................................................................................................................................... 21
1.6.9 VIA VT1616 Audio Codec .............................................................................................................. 21
1.6.10 Chrontel CH7009A TV/DVI Transmitter..................................................................................... 22
1.6.11 Ethernet...................................................................................................................................... 23
1.6.12 Winbond W83627HF.................................................................................................................. 24
1.6.13 Compact Flash Interface............................................................................................................ 24
2. Hardware Configuration...........................................................................................25
2.1 Product Overview....................................................................................................26
2.2 Installation Procedure .............................................................................................27
2.2.1 Processor Installation..................................................................................................................... 27
2.2.2 Main Memory.................................................................................................................................. 29
2.3 Jumper and Connector List .....................................................................................31
2.4 Setting Jumpers & Connectors ...............................................................................34
2.4.1 Clear CMOS (JBAT1)..................................................................................................................... 34
2.4.2 COM1 Pin 9 Signal Select (JP1) .................................................................................................... 34
2.4.3 COM1 RS-232/422/485 Select (JP2, JP3)..................................................................................... 35
2.4.4 4/5/8-wire Touch Screen Select (SW1, optional)........................................................................... 36
2.4.5 ATX Power Connector (ATXPWR1)............................................................................................... 36
2.4.6 CPU Fan Connector (C_FAN1)......................................................................................................37
2.4.7 Parallel Port Connector & VGA Connector (CN1).......................................................................... 38
2.4.8 Serial Port 1 Connector in RS-232 Mode (CN1) ............................................................................ 39
2.4.9 Serial Port 1 Connector in RS-422 Mode (CN1) ............................................................................ 40
6 AIMB-250 Series User’s Manual
User’s Manual
2.4.10 Serial Port 1 Connector in RS-485 Mode (CN1)........................................................................ 41
2.4.11 Audio Connector (CN2).............................................................................................................. 42
2.4.12 RJ-45 Ethernet / USB 0 & 1, 4 & 5 Connectors (CN3, CN4) ..................................................... 42
2.4.13 4/5/8-Wire Touch Screen Connector (CN5, optional)................................................................ 42
2.4.14 Floppy Connector (FLP1)........................................................................................................... 43
2.4.15 Primary IDE Connector (IDE_1)................................................................................................. 45
2.4.16 Secondary IDE Connector (IDE_2)............................................................................................ 46
2.4.17 LCD Inverter Connector (JBKL1)............................................................................................... 48
2.4.18 CD-ROM Audio Input Connector (JCD1)................................................................................... 49
2.4.19 Serial Port 2 Connector (JCOM1).............................................................................................. 49
2.4.20 Serial Port 3/4 Connector (JCOM2, JCOM3)............................................................................. 50
2.4.21 Digital Input / Output Connector (JDIO1)................................................................................... 51
2.4.22 Front Panel Connector (JFP1)................................................................................................... 52
2.4.23 IrDA Connector (JIR1) ............................................................................................................... 53
2.4.24 LVDS Connector (JLVDS1) ....................................................................................................... 54
2.4.25 Miscellaneous Setting Connector (JMISC1) .............................................................................. 55
2.4.26 TMDS DVI Connector (JTMDS1)............................................................................................... 56
2.4.27 TV Out Connector (JTV1) .......................................................................................................... 57
2.4.28 USB Connector 2 & 3 (JUSB1).................................................................................................. 58
2.4.29 USB Connector 4 & 5 (JUSB2).................................................................................................. 58
2.4.30 PS/2 Keyboard & Mouse Connector (KB_MS1) ........................................................................ 59
2.4.31 System Fan Connector 1 & 2 (S_FAN1, S_FAN2).................................................................... 59
3 BIOS Setup................................................................................................................60
3.1 Starting Setup .........................................................................................................61
3.2 Using Setup ............................................................................................................62
3.3 Getting Help ............................................................................................................63
3.4 In Case of Problems................................................................................................63
3.5 Main Menu ..............................................................................................................64
3.5.1 Standard CMOS Features.............................................................................................................. 65
3.5.2 Advanced BIOS Features .............................................................................................................. 67
3.5.3 Advanced Chipset Features........................................................................................................... 70
3.5.4 Integrated Peripherals.................................................................................................................... 73
3.5.5 Power Management Setup............................................................................................................. 77
3.5.6 PnP / PCI Configuration ................................................................................................................. 79
3.5.7 PC Health Status............................................................................................................................ 80
3.5.8 Frequency / Voltage Control .......................................................................................................... 81
3.5.9 Load Fail-Safe Defaults.................................................................................................................. 82
3.5.10 Load Optimized Defaults............................................................................................................ 82
3.5.11 Set Supervisor / User Password................................................................................................ 83
3.5.12 Save & Exit Setup ...................................................................................................................... 84
AIMB-250 User’s Manual
7
AIMB-250 Series
3.5.13 Exit Without Save....................................................................................................................... 85
4 Drivers Installation ...................................................................................................86
4.1 Install Driver ............................................................................................................87
5 Mechanical Drawing.................................................................................................88
Appendix A: AWARD BIOS POST Messages ................................................................90
Overview............................................................................................................................91
Post Beep ..........................................................................................................................91
Error Messages .................................................................................................................91
1. CMOS BATTERY HAS FAILED .........................................................................................................91
2. CMOS CHECKSUM ERROR .............................................................................................................91
3. DISK BOOT FAILURE, INSERT SYSTEM DISK AND PRESS ENTER ............................................ 91
4. DISKETTE DRIVES OR TYPES MISMATCH ERROR - RUN SETUP.............................................. 91
5. DISPLAY SWITCH IS SET INCORRECTLY...................................................................................... 92
6. DISPLAY TYPE HAS CHANGED SINCE LAST BOOT ..................................................................... 92
7. EISA Configuration Checksum Error PLEASE RUN EISA CONFIGURATION UTILITY................... 92
8. EISA Configuration Is Not Complete PLEASE RUN EISA CONFIGURATION UTILITY................... 92
9. ERROR ENCOUNTERED INITIALIZING HARD DRIVE.................................................................... 92
10. ERROR INITIALIZING HARD DISK CONTROLLER ..................................................................... 92
11. FLOPPY DISK CNTRLR ERROR OR NO CNTRLR PRESENT ................................................... 92
12. Invalid EISA Configuration PLEASE RUN EISA CONFIGURATION UTILITY .............................. 93
13. KEYBOARD ERROR OR NO KEYBOARD PRESENT ................................................................. 93
14. Memory Address Error at ... ........................................................................................................... 93
15. Memory parity Error at ................................................................................................................... 93
16. MEMORY SIZE HAS CHANGED SINCE LAST BOOT ................................................................. 93
17. Memory Verify Error at ... ............................................................................................................... 93
18. OFFENDING ADDRESS NOT FOUND ......................................................................................... 93
19. OFFENDING SEGMENT: ..............................................................................................................93
20. PRESS A KEY TO REBOOT ......................................................................................................... 94
21. PRESS F1 TO DISABLE NMI, F2 TO REBOOT ........................................................................... 94
22. RAM PARITY ERROR - CHECKING FOR SEGMENT ... ............................................................. 94
23. Should Be Empty But EISA Board Found PLEASE RUN EISA CONFIGURATION UTILITY....... 94
24. Should Have EISA Board But Not Found PLEASE RUN EISA CONFIGURATION UTILITY ....... 94
25. Slot Not Empty ............................................................................................................................... 94
26. SYSTEM HALTED, (CTRL-ALT-DEL) TO REBOOT ... ................................................................. 94
27. Wrong Board In Slot PLEASE RUN EISA CONFIGURATION UTILITY........................................ 95
28. FLOPPY DISK(S) fail (80) → Unable to reset floppy subsystem................................................... 95
29. FLOPPY DISK(S) fail (40) → Floppy Type dismatch..................................................................... 95
30. Hard Disk(s) fail (80) → HDD reset failed.................................................................................... 95
31. Hard Disk(s) fail (40) → HDD controller diagnostics failed.......................................................... 95
32. Hard Disk(s) fail (20) → HDD initialization error.......................................................................... 95
8 AIMB-250 Series User’s Manual
User’s Manual
33. Hard Disk(s) fail (10) → Unable to recalibrate fixed disk............................................................. 95
34. Hard Disk(s) fail (08) → Sector Verify failed................................................................................ 95
35. Keyboard is locked out - Unlock the key. ....................................................................................... 95
36. Keyboard error or no keyboard present. ........................................................................................ 95
37. Manufacturing POST loop.............................................................................................................. 95
38. BIOS ROM checksum error - System halted. ................................................................................ 95
39. Memory test fail. ............................................................................................................................. 95
40. POST Codes .................................................................................................................................. 96
AIMB-250 User’s Manual
9
AIMB-250 Series
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
Before you begin installing your single board, please make sure that the
following materials have been shipped:
z 1 x AIMB-250 Intel Socket 478/479 Pentium® M/Celeron® M Mini ITX
Main Board (Onboard Intel® Celeron® M 600 MHz with 0K L2 Cache or
Intel® Processor at 800 MHz
z 1 x CD-ROM or DVD-ROM contains the followings:
User’s Manual (this manual in PDF file)
Intel INF driver
Ethernet driver and utilities
VGA drivers and utilities
Audio drivers and utilities
z 1 x IDE HDD cable (40-pin, pitch 2.54mm)
z 1 x IDE HDD cable (44-pin, pitch 2.0mm)
z 1 x FDD cable (34-pin, pitch 2.54mm)
z 3 x Serial port cable with 1 DB9P(M) (10-pin, pitch 2.54mm)
z Startup manual
z 1 x I/O bracket
z 1 x Pentium® M CPU cooler
10 AIMB-250 Series User’s Manual
1.3 Document Amendment History
Revision Date Comment
1st Jan. 2007 Initial release
User’s Manual
AIMB-250 User’s Manual
11
AIMB-250 Series
1.4 Manual Objectives
This manual describes in detail the Advantech Technology AIMB-250 series Single Board.
We have tried to include as much information as possible but we have not duplicated
information that is provided in the standard IBM Technical References, unless it proved to
be necessary to aid in the understanding of this board.
We strongly recommend that you study this manual carefully before attempting to interface
with AIMB-250 series or change the standard configurations. Whilst all the necessary
information is available in this manual we would recommend that unless you are confident,
you contact your supplier for guidance.
Please be aware that it is possible to create configurations within the CMOS RAM that
make booting impossible. If this should happen, clear the CMOS settings, (see the
description of the Jumper Settings for details).
If you have any suggestions or find any errors concerning this manual and want to inform
us of these, please contact our Customer Service department with the relevant details.
12 AIMB-250 Series User’s Manual
1.5 System Specifications
System
User’s Manual
Model
CPU
FSB
BIOS
System Chipset
I/O Chip
System Memory
SSD
Watchdog Timer
H/W Status Monitor
Expansion
I/O
MIO
AIMB-250F-00B1
Supports Intel® µFC-PGA 478 / µFC-BGA 479 Pentium® M / Celeron® M up to 1.8
GHz with 0.13µ and 90nm process technology
400 MHz
Award 512 KB Flash BIOS
®
855GME GMCH/ICH4
Intel
Winbond W83627HF-AW
One 184-pin DIMM socket supports up to 1 GB DDR 266/333 SDRAM
One CompactFlash Type I/II socket
Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
Monitoring system temperature, voltage, and cooling fan status. Auto throttling
control when CPU overheats.
One PCI slot (PCI Rev. 2.2 compliant), one Mini PCI slot
4 x EIDE (Ultra DMA 100), 2 x FDD , 1 x LPT, 1 x RS-232, 1x RS-232/422/485, 1x
K/B, 1 x Mouse
IrDA
USB
DIO
115k bps, IrDA 1.0 compliant
6 USB 2.0 ports
16-bit General Purpose I/O for DI and DO
AIMB-250 User’s Manual
13
AIMB-250 Series
Display
Model
Chipset
Display Memory
Resolution
Dual Display
LVDS
DVI
TV-Out
Built-in Touch Screen (Optional)
Chipset
Touch Screen Interface
Audio
Chipset Intel® ICH4
AC97 Codec
Intel® 855GME GMCH integrated Extreme Graphics 2 controller
®
DVMT 2.1 supports up to 64 MB video memory
Intel
CRT mode: 1600 x 1200 @ 32 bpp (85 Hz)
LCD/Simultaneous mode: 1600 x 1200 @ 32 bpp (85 Hz)
CRT + LVDS, or DVI/TV-out + LVDS or CRT + DVI
Dual-channel 18/36-bit LVDS
Chrontel CH7009A DVI transmitter up to 135M pixels/second
Chrontel CH7009A TV encoder supports both NTSC/PAL
Supports both S-Video and composite video
PenMount DMC9000
With 9-pin 2 mm box header (can be selected with 4/5/8-wire connector)
VIA VT1616 supports 5.1 CH Audio
AIMB-250
Audio Interface Mic in, Line in, CD Audio in, Line out
Ethernet
LAN1
LAN2
Ethernet Interface
Realtek RTL8110S Gigabit LAN
N/A
1000Base-T Gigabit Ethernet compatible: Realtek RTL8110S
14 AIMB-250 Series User’s Manual
Mechanical & Environmental
User’s Manual
Model
Power Requirement
Power Type
Operation Temperature
Operating Humidity
Size ( L x W )
Weight
AIMB-250
+5 V @ 4.45 A, +12 V @ 0.05 A, +3.3 V @ 5.27 A, 5 Vsb @ 0.38 A
(with Intel Celeron 1 GHz, 1 GB SDRAM)
AT/ATX
0~60o C (32~140 o F)
0%~90% relative humidity, non-condensing
6.69" x 6.69" (170 mm x 170 mm)
0.88 lbs (0.4 Kg)
AIMB-250 User’s Manual
15
AIMB-250 Series
1.6 Architecture Overview
1.6.1 Block Diagram
The following block diagram shows the architecture and main components of AIMB-250
The following sections provide detail information about the functions provided onboard.
16 AIMB-250 Series User’s Manual
User’s Manual
1.6.2 Intel 855GME and ICH4
The Intel 855GME GMCH components provide the processor interface, DDR SDRAM
interface, display interface, and Hub interface. The Intel 855GME also has an option for
AGP external graphics port, in addition to integrated graphics support for added board
flexibility options.
The Intel 855GM GMCH is in a 732-pin Micro-FCBGA package and contains the following
functionality listed below:
• AGTL+ host bus supporting 32-bit host addressing with Enhanced Intel SpeedStep
technology support
• Supports a single channel of DDR SDRAM memory
• System memory supports DDR200/266 MHz (SSTL_2) DDR SDRAM
• Integrated graphics capabilities: Display Core frequency at 133 MHz or 200 MHz
• Render Core frequency at 100 MHz ,133 MHz, and 200 MHz
• Provides supports four display ports: one progressive scan analog monitor, dual
channel LVDS interface and two DVO port.
The Intel EE GMCH is in a 732-pin Micro-FCBGA package and contains all features listed
above and the additional functionality list below:
• Display Core frequency at 133 MHz, 200 MHz, or 250 MHz
• Render Core frequency at 100 MHz ,133 MHz, 166 MHz, 200 MHz, or 250 MHz
• System memory supports 200/266/333- MHz (SSTL_2) DDR SDRAM.
• Enhanced Power Management Graphics features
The GMCH IGD provides a highly integrated graphics accelerator delivering high
performance 2D, 3D, and video capabilities. With its interfaces to UMA using a DVMT
configuration, an analog display, a LVDS port, and two digital display ports (e.g. flat panel),
the GMCH can provide a complete graphics solution.
The GMCH also provides 2D hardware acceleration for block transfers of data (BLTs). The
BLT engine provides the ability to copy a source block of data to a destination and perform
raster operations (e.g., ROP1, ROP2, and ROP3) on the data using a pattern, and/or
another destination. Performing these common tasks in hardware reduces CPU load, and
thus improves performance. High bandwidth access to data is provided through the system
memory interface. The GMCH uses Tiling architecture to increase system memory
efficiency and thus maximize effective rendering bandwidth. The Intel 855GME GMCH
improves 3D performance and quality with 3D Zone rendering technology. The Intel
855GME GMCH also supports Video Mixer rendering and Bi-Cubic filtering.
AIMB-250 User’s Manual
17
AIMB-250 Series
The Intel 855GME GMCH has four display ports, one analog and three digital. With these
interfaces, the GMCH can provide support for a progressive scan analog monitor, a
dedicated dual channel LVDS LCD panel, and two DVO devices. Each port can transmit
data according to one or more protocols. The data that is sent out the display port is
selected from one of the two possible sources, Pipe A or Pipe B.
The Intel 855GME GMCH have an integrated dual channel LFP Transmitter interface to
support LVDS LCD panel resolutions up to UXGA The display pipe provides panel
up-scaling to fit a smaller source image onto a specific native panel size, as well as
provides panning and centering support. The LVDS port is only supported on Pipe B. The
LVDS port can only be driven by Pipe B, either independently or simultaneously with the
Analog Display port. Spread Spectrum Clocking is supported: center and down spread
support of 0.5%, 1%, and 2.5% utilizing an external SSC clock.
The DVO B/C interface is compliant with the DVI Specification 1.0. When combined with a
DVI compliant external device (e.g. TMDS Flat Panel Transmitter, TV-out encoder, etc.),
the GMCH provides a high-speed interface to a digital or analog display (e.g. flat panel, TV
monitor, etc.). The DVO ports are connected to an external display device. Examples of this
are TV-out encoders, external DACs, LVDS transmitters, and TMDS transmitters. Each
display port has control signals that may be used to control, configure and/or determine the
capabilities of an external device. The GMCH provides two DVO ports that are each
capable of driving a 165-MHz pixel clock at the DVO B or DVO C interface. When DVO B
and DVO C are combined into a single DVO port, then an effective pixel rate of 330 MHz
can be achieved. The DVO B/C ports can be driven by Pipe A or Pipe
B. If driven on Pipe B, then the LVDS port must be disabled.
The ICH4 is a highly integrated multifunctional I/O Controller Hub that provides the
interface to the PCI Bus and integrates many of functions needed in today’s PC platform.
The GMCH and ICH4 communicate over a dedicated hub interface. The ICH4 functions
and capabilities include:
• PCI Rev. 2.2 compliant with support for 33MHz PCI operations
• Supports up to 6 Request/Grant pairs (PCI slots)
• Power management logic support
• Enhanced DMA controller, interrupt controller, and timer functions
• Integrated IDE controller; Ultra ATA/100/66/33
• USB host interface; 3 host controllers and supports 6 USB ports; includes a EHCI
high-speed 2.0 USB controller
18 AIMB-250 Series User’s Manual
User’s Manual
• Integrated LAN controller
• System Management Bus (SMBus) compatible with most IC devices; ICH4 has both
bus master and slave capability
• AC ’97 2.3 compliant link for audio and telephony codecs; up to 6 channels
• Low Pin Count (LPC) interface
• FWH Interface (FWH Flash BIOS support)
• Alert on LAN* (AOL and AOL2)
1.6.3 Intel 855GME and ICH4
The Intel 855GME GMCH component provides the processor interface, DDR SDRAM
interface, display interface, and Hub Interface in an Intel 855GME chipset platform. The
Intel 855GME GMCH is optimized for the Mobile Intel Pentium 4 Processor-M, Mobile Intel
Celeron processor and Intel Celeron M processor. It supports a single channel of DDR
SDRAM memory. Intel 855GME Chipset contains advanced power management logic. The
Intel 855GME Chipset platform supports the fourth generation mobile I/O Controller Hub to
provide the features required by a mobile platform.
The Intel 855GME GMCH is in a 732-pin Micro-FCBGA package and contains the following
functionality:
• Supports single Intel processor configurations at 400-MHz or 3 GB/s
• 1.2-1.30-V AGTL+ host bus supporting 32-bit host bus addressing with Enhanced
Intel SpeedStep® technology (Intel Celeron M processor and Intel Celeron
Processor do not support Enhanced Intel SpeedStep Technology).
• System Memory supports 200/266-MHz (SSTL_2) DDR DRAM Up to 1 GB (with
256-Mb technology and two SO-DIMMs) of PC1600/2100 DDR SDRAM without
ECC
• Integrated graphics capabilities, including 3D rendering acceleration and 2D
hardware acceleration
• Integrated 350-MHz, 24-bit RAMDAC with pixel resolution up to 1600x1200 at 85-Hz
and up to 1920x1440 @ 60 Hz
• One Dedicated Dual Channel LFP LVDS interface with frequency range of 25 MHz
to 112 MHz (single channel/dual channel) for support up to SXGA+ (1400x1050 @
60 Hz) panel resolutions with maximum pixel depth of 18-bpp
• Integrated PWM (Pulse Width Modulation) interface for LFP backlight inverter
control for panel brightness
• One 165-MHz, 12-bit, DVO interface for TV-out encoder and DVI (LVDS transmitter
and TMDS transmitter) support I2C and DDC channels supported
• Dual Pipe Independent Display with Tri-view support through LFP, DVO, and CRT
• Deeper Sleep state support
AIMB-250 User’s Manual
19
AIMB-250 Series
• Distributed arbitration for highly concurrent operation
• Three USB host controllers provide high performance peripherals with 480 Mbps of
bandwidth, while enabling support for up to six USB 2.0 ports. This results in a
significant increase over previous integrated 1-4 port hubs at 12 Mbps
• The latest AC ’97 implementation delivers 20-bit audio for enhanced sound quality
and full surround sound capability. Integrated audio solutions continue to enjoy
success as a very cost-effective, yet high-performance solution
• LAN Connect Interface (LCI) provides flexible network solutions such as 10/100
Mbps Ethernet and 10/100 Mbps Ethernet with LAN manageability
• Dual Ultra ATA/100 controllers, coupled with the Intel® Application Accelerator – a
performance software package – support faster IDE transfers to storage devices
• Intel Application Accelerator software provides additional performance over native
ATA drivers by improving I/O transfer rates and enabling faster O/S load time,
resulting in accelerated boot times
• Communication and Network Riser (CNR) offers flexibility in system configuration
with a baseline feature set that can be upgraded with an audio card, modem card, or
network card
1.6.4 DRAM Interface (Intel 855GME)
The 855GME GMCH system memory controller directly supports the following:
• One channel of PC1600/2100/2700 DDR SDRAM memory
• DDR SDRAM devices with densities of 128-Mb, 256-Mb, and 512-Mb technology
• Up to 1 GB (512-Mb technology) SDRAM
1.6.5 DRAM Interface (Intel 855GME)
The 855GME GMCH system memory controller directly supports the following:
• One channel of PC1600/2100 DDR SDRAM memory
• DDR SDRAM devices with densities of 128-Mb, 256-Mb, and 512-Mb technology
• Variable page sizes of 2-kB, 4-kB, 8-kB, and 16-kB. Page size is individually selected
for every row and a maximum of 16 pages may be opened simultaneously
1.6.6 PCI Interface
The ICH4 PCI interface provides a 33 MHz, Rev. 2.2 compliant implementation. All PCI
signals are 5V tolerant, except PME#. The ICH2 integrates a PCI arbiter that supports up to
six external PCI bus masters in addition to the internal ICH4 requests.
20 AIMB-250 Series User’s Manual
User’s Manual
1.6.7 IDE Interface (Bus Master Capability and Synchronous DMA Mode )
The fast IDE interface supports up to four IDE devices providing an interface for IDE hard
disks and ATAPI devices. Each IDE device can have independent timings. The IDE
interface supports PIO IDE transfers up to 16 Mbytes/sec and Ultra ATA transfers up 100
Mbytes/sec. It does not consume any ISA DMA resources. The IDE interface integrates
16x32-bit buffers for optimal transfers.
The ICH4’s IDE system contains two independent IDE signal channels. They can be
electrically isolated independently. They can be configured to the standard primary and
secondary channels (four devices). There are integrated series resistors on the data and
control lines.
Access to these controllers is provided by two standard IDC 40-pin connectors.
1.6.8 USB 2.0
The ICH4 contains an Enhanced Host Controller Interface (EHCI) compliant host controller
that supports USB high-speed signaling. High-speed USB 2.0 allows data transfers up to
480Mb/s which is 40 times faster than full-speed USB. The ICH4 also contains three
Universal Host Controller Interface (UHCI) controllers that support USB full-speed and
low-speed signaling.
The ICH4 supports 6 USB 2.0 ports. All six USB ports are high-speed, full-speed, and
low-speed capable. ICH4’s port-routing logic determines whether a USB port is controlled
by one of the UHCI controllers or by the EHCI controller.
1.6.9 VIA VT1616 Audio Codec
VIA Technologies’ VT1616TM 18-bit audio codec conforms to the AC’97 2.2 specifications.
The VT1616 integrates Sample Rate Converters on all channels and can be adjusted in
1Hz increments. There is a provision in hardware for down-mixing the 6 channels into
stereo when only two end points are available. The analog mixer circuitry integrates a
stereo enhancement to provide a pleasing 3D surround sound effect for stereo media. This
codec is designed with aggressive power management to achieve low power consumption.
When used with a 3.3V analog supply, power consumption is further reduced. The primary
applications for this part are desktop and portable personal computers multimedia
subsystems.
AIMB-250 User’s Manual
21
AIMB-250 Series
1.6.10 Chrontel CH7009A TV/DVI Transmitter
The Chrontel CH7009A is a display controller device which accepts a digital graphics input
signal, and encodes and transmits data through a DVI (DFP can also be supported) or TV
output (analog composite, s-video or RGB). The device accepts data over one 12-bit wide
variable voltage data port which supports five different data formats including RGB and
YCrCb.
The DVI processor includes a low jitter PLL for generation of the high frequency serialized
clock, and all circuitries are required to encode, serialize and transmit data. The CH7009
comes in versions able to drive a DVI display at a pixel rate of up to 165MHz, supporting
UXGA resolution displays. No scaling of input data is performed on the data output to the
DVI device.
The TV-Out processor performs non-interlace to interlace conversion with scaling and
flicker filters, and encode the data into any of the NTSC or PAL video standards. The
scaling and flicker filter is adaptive and programmable to enable superior text display.
Eight graphics resolutions are supported up to 1024 by 768 with full vertical and horizontal
underscan capability in all modes. A high accuracy low jitter phase locked loop is
integrated to create outstanding video quality. Support is provided for MacrovisionTM and
RGB bypass mode which enables driving a VGA CRT with the input data.
22 AIMB-250 Series User’s Manual
User’s Manual
1.6.11 Ethernet
1.6.11.1 Realtek RTL8110S Gigabit Ethernet Controller
The Realtek RTL8110SB(L) LOM Gigabit Ethernet controllers (RTL8110SB (128 QFP) &
RTL8110SBL (128 LQFP)) combine a triple-speed IEEE 802.3 compliant Media Access
Controller (MAC) with a triple-speed Ethernet transceiver, 32-bit PCI bus controller, and
embedded memory. With state-of-the-art DSP technology and mixed-mode signal
technology, they offer high-speed transmission over CAT 5 UTP cable or CAT 3 UTP
(10Mbps only) cable. Functions such as Crossover Detection & Auto-Correction, polarity
correction, adaptive equalization, cross-talk cancellation, echo cancellation, timing recovery,
and error correction are implemented to provide robust transmission and reception
capability at high speeds.
The devices support the PCI v2.3 bus interface for host communications with power
management and are compliant with the IEEE 802.3 specification for 10/100Mbps Ethernet
and the IEEE 802.3ab specification for 1000Mbps Ethernet. They also support an auxiliary
power auto-detect function, and will auto-configure related bits of the PCI power
management registers in PCI configuration space.
They support the Advanced Configuration Power management Interface (ACPI)--power
management for modern operating systems that are capable of Operating System-directed
Power Management (OSPM)--to achieve the most efficient power management possible.
PCI Message Signaled Interrupt (MSI) is also supported.
In addition to the ACPI feature, the RTL8110SB(L) support remote wake-up (including AMD
Magic Packet, Re-LinkOk, and Microsoft® Wake-up frame) in both ACPI and APM
(Advanced Power Management) environments. The LWAKE pin provides four different
output signals including active high, active low, positive pulse, and negative pulse. The
versatility of the LWAKE pin provides motherboards with Wake-On-LAN (WOL)
functionality. To support WOL from a deep power down state (e.g. D3cold, i.e. main power
is off and only auxiliary exists), the auxiliary power source must be able to provide the
needed power for the RTL8110SB(L).
The RTL8110SB(L) is fully compliant with Microsoft® NDIS5 (IP, TCP, UDP) Checksum
and Segmentation Task-offload features, and supports IEEE 802 IP Layer 2 priority
encoding and 802.1Q Virtual bridged Local Area Network (VLAN). The above features
contribute to lowering CPU utilization, especially benefiting performance when in operation
on a network server. Also, the devices boost their PCI performance by supporting PCI
Memory Read Line & Memory Read Multiple when transmitting, and Memory Write and
Invalidate when receiving. To better qualify for server use, the RTL8110SB(L) support the
PCI Dual Address Cycle (DAC) command when the assigned buffers reside at a physical
memory address higher than 4 Gigabytes.
AIMB-250 User’s Manual
23
AIMB-250 Series
1.6.12 Winbond W83627HF
The Winbond W83627F/HF is made to fully comply with Microsoft PC98 and PC99
Hardware Design Guide. Moreover, W83627F/HF is made to meet the specification of
PC98/PC99’s requirement in the power management: ACPI and DPM (Device Power
Management). Super I/O chip provides features as the following:
• Meet LPC Spec. 1.0
• Support LDRQ# (LPC DMA), SERIRQ (serial IRQ)
• Include all features of Winbond I/O W83977TF and W83977EF
• Integrate Hardware Monitor functions
• Compliant with Microsoft PC98/PC99 Hardware Design Guide.
• Support DPM (Device Power Management), ACPI
• Programmable configuration settings
• Single 24 or 48 MHz clock input
1.6.13 Compact Flash Interface
A Compact Flash type II connector is connected to the secondary IDE controller. The
Compact Flash storage card is IDE compatible. It is an ideal replacement for standard IDE
hard drives. The solid-state design offers no seek errors even under extreme shock and
vibration conditions. The Compact Flash storage card is extremely small and highly suitable
for rugged environments, thus providing an excellent solution for mobile applications with
space limitations. It is fully compatible with all consumer applications designed for data
storage PC card, PDA, and Smart Cellular Phones, allowing simple use for the end user.
The Compact Flash storage card is O/S independent, thus offering an optimal solution for
embedded systems operating in non-standard computing environments. The Compact
Flash storage card is IDE compatible and offers various capacities.
24 AIMB-250 Series User’s Manual
User’s Manual
2. Hardware
Configuration
AIMB-250 User’s Manual
25
AIMB-250 Series
2.1 Product Overview
26 AIMB-250 Series User’s Manual
User’s Manual
2.2 Installation Procedure
This chapter explains you the instructions of how to setup your system.
1. Turn off the power supply.
2. Insert the DIMM module (be careful with the orientation).
3. Insert all external cables for hard disk, floppy, keyboard, mouse, USB etc. except for flat
panel. A CRT monitor must be connected in order to change CMOS settings to support
flat panel.
4. Connect power supply to the board via the ATXPWR.
5. Turn on the power.
6. Enter the BIOS setup by pressing the delete key during boot up. Use the “LOAD BIOS
DEFAULTS” feature. The Integrated Peripheral Setup and the Standard CMOS Setup
Window must be entered and configured correctly to match the particular system
configuration.
7. If TFT panel display is to be utilized, make sure the panel voltage is correctly set before
connecting the display cable and turning on the power.
2.2.1 Processor Installation
2.2.1.1 Installing Pentium M CPU
• The processor socket comes with a screw to secure the processor, please unlock the
screw first.
• Position the CPU above the socket and the gold triangular mark on the CPU must
align with pin 1 of the CPU socket. Then Insert the CPU gently seated in place.
• Turn the screw to the lock position.
Unlock
Pin 1 of the
socket
Lock
Gold
triangular
mark
Note: Do not force the CPU into the socket. It may bend the pins and damage the
CPU.
AIMB-250 User’s Manual
27
AIMB-250 Series
y
2.2.1.2 Installing the Fan and Heat Sink
• Insert the copper studs to the screw holes around the CPU socket from the top
through the rear side of the board with screw nuts fastened.
• Match and place the CPU fan and heat sink assembly on the top of the CPU and
copper studs. Tighten the screws into the copper studs through washers and the
screw holes around the heat sink.
• Place the CPU Fan Connector.
CPU Fan & heat
sink assembl
Screws
Copper Stud
Screw nut
(Rear side)
CPU fan
connector
Note: Make sure the CPU fan and heat sink assembly and the CPU top surface
are in total contact to avoid CPU overheating problem that would cause the
system to hang or unstable
2.2.1.3 Removing CPU
• Disconnect the CPU fan connector.
• Remove the CPU fan and heat sink assembly first.
• Unfasten the copper studs from the board.
• Unlock the Pentium M processor.
• Carefully lift up the existing CPU to remove it from the socket.
• Follow the steps of installing a CPU to change to another one.
28 AIMB-250 Series User’s Manual
User’s Manual
2.2.2 Main Memory
AIMB-250 provides one 184-pin DIMM socket to support DDR SDRAM. The total maximum
memory size is 1GB.
DIMM1
Make sure to unplug the power supply before adding or removing DIMMs or
other system components. Failure to do so may cause severe damage to
both the board and the components.
AIMB-250 User’s Manual
29
AIMB-250 Series
• Locate the DIMM slot on the board.
• Hold two edges of the DIMM module carefully. Keep away of touching its connectors.
• Align the notch key on the module with the rib on the slot.
• Firmly press the modules into the slot automatically snaps into the mounting notch. Do
not force the DIMM module in with extra force as the DIMM module only fit in one
direction.
• To remove the DIMM modules, push the two ejector tabs on the slot outward
simultaneously, and then pull out the DIMM module.
Note: (1) Please do not change any DDR SDRAM parameter in BIOS setup to
increase your system’s performance without acquiring technical
information in advance.
(2) Static electricity can damage the electronic components of the computer
or optional boards. Before starting these procedures, ensure that you
are discharged of static electricity by touching a grounded metal object
briefly.
30 AIMB-250 Series User’s Manual
User’s Manual
2.3 Jumper and Connector List
You can configure your board to match the needs of your application by setting jumpers. A
jumper is the simplest kind of electric switch.
It consists of two metal pins and a small metal clip (often protected by a plastic cover) that
slides over the pins to connect them. To “close” a jumper you connect the pins with the clip.
To “open” a jumper you remove the clip. Sometimes a jumper will have three pins, labeled 1,
2, and 3. In this case, you would connect either two pins.
The jumper settings are schematically depicted in this manual as follows:
A pair of needle-nose pliers may be helpful when working with jumpers.
Connectors on the board are linked to external devices such as hard disk drives, a
keyboard, or floppy drives. In addition, the board has a number of jumpers that allow you to
configure your system to suit your application.
If you have any doubts about the best hardware configuration for your application, contact
your local distributor or sales representative before you make any changes.
The following tables list the function of each of the board's jumpers and connectors.
Jumpers
Label Function Note
JBAT1
JP1
JP2, JP3
SW1
SW2
Clear CMOS 3 x 1 header, pitch 2.54mm
COM1 pin 9 signal select 3 x 2 header, pitch 2.0mm
COM1 RS-232/422/485 select 3 x 2 header, pitch 2.0mm
4 x 3 header, pitch 2.0mm
4/5/8-wire touch screen select (optional) Switch
Reserved Switch
AIMB-250 User’s Manual
31
AIMB-250 Series
Connectors
Label Function Note
ATXPWR1
C_FAN1
CF1
CN1
CN2
CN4
CN5
DIMM1
FLP1
IDE_1
IDE_2
JBKL1
JCD1
ATX Power connector ATX power connector
CPU fan connector 3 x 1 wafer, pitch 2.54mm
CF card connector
Parallel port connector
Serial port 1 connector
VGA connector
Audio connector Phone Jack X 3
RJ-45 Ethernet / USB 0 & 1 connector
4/5/8-wire touch screen connector (option) 9 x 1 wafer, pitch 2.0mm
184-pin DDR SDRAM DIMM socket
Floppy connector 17 x 2 header, pitch 2.54mm
Primary IDE connector
Secondary IDE connector
LCD inverter connector
CD-ROM audio input connector 4 x 1 wafer, pitch 2.0mm
D-sub 25-pin, female
D-sub 9-pin, male
D-sub 15-pin, female
20 x 2 header, pitch 2.54mm
22 x 2 header, pitch 2.0mm
5 x 1 wafer, pitch 2.0mm
JCOM1
JCOM2
JCOM3
JDIO1
JFP1
JIR1
JLVDS1
JMISC1
JTMDS1
JTV1
JUSB1
JUSB2
Serial port 2 connector 5 x 2 header, pitch 2.54mm
Serial port 3 connector 5 x 2 header, pitch 2.54mm
Serial port 4 connector 5 x 2 header, pitch 2.54mm
Digital input/output connector 10 x 2 header, pitch 2.54mm
Front panel connector 8 x 2 header, pitch 2.54mm
IrDA connector 5 x 1 header, pitch 2.54mm
LVDS connector HIROSE DF13-40DP-1.25V
Miscellaneous setting connector 5 x 2 header, pitch 2.54mm
TMDS connector HIROSE DF13-20DP-1.25V
TV out connector 3 x 2 header, pitch 2.54mm
USB connector 2 & 3 5 x 2 header, pitch 2.54mm
USB connector 4 & 5 5 x 2 header, pitch 2.54mm
32 AIMB-250 Series User’s Manual
Connectors
Label Function Note
User’s Manual
KB_MS1
MPCI1
PCI1
S_FAN1,S_FAN2
PS/2 Keyboard & mouse connector 6-pin Mini-DIN x 2
Mini PCI slot
PCI slot
System fan connector 1 & 2
3 x 1 wafer, pitch 2.54mm
AIMB-250 User’s Manual
33
AIMB-250 Series
2.4 Setting Jumpers & Connectors
2.4.1 Clear CMOS (JBAT1)
* Default
Protect*
Clear CMOS
2.4.2 COM1 Pin 9 Signal Select (JP1)
* Default
Ring*
+5V
+12V
34 AIMB-250 Series User’s Manual
2.4.3 COM1 RS-232/422/485 Select (JP2, JP3)
User’s Manual
(JP2)
RS-232*
(JP3)
RS-232*
RS-422
RS-422
RS-485
RS-485
* Default
AIMB-250 User’s Manual
35
AIMB-250 Series
2.4.4 4/5/8-wire Touch Screen Select (SW1, optional)
Wire BIT1 BIT2
* 4, 8 OFF ON
* Default
2.4.5 ATX Power Connector (ATXPWR1)
5 ON OFF
36 AIMB-250 Series User’s Manual
Signal PIN PIN Signal
+12V 10 20 +5V
VCCSB 9 19 +5V
PWROK 8 18 -5V
GND 7 17 GND
+5V 6 16 GND
GND 5 15 GND
+5V 4 14 PS_ON
GND 3 13 GND
+3.3V 2 12 -12V
+3.3V 1 11 +3.3V
2.4.6 CPU Fan Connector (C_FAN1)
User’s Manual
Signal PIN
TAC 3
+12V 2
GND 1
2.4.6.1 Signal Description – CPU Fan Connector (C_FAN1)
Signal Signal Description
TAC Fan speed monitor
AIMB-250 User’s Manual
37
AIMB-250 Series
2.4.7 Parallel Port Connector & VGA Connector (CN1)
Port Description
COM
Parallel
VGA
COM
Connects a parallel printer, a
scanner, or other devices.
For pointing devices or other
serial devices
VGA
Signal PIN Signal
6 GND
RED 1 11 NC
7 GND
GREEN 2 12 DAT
8 GND
BLUE 3 13 HSYNC
9 VCC
NC 4 14 VSYNC
10 GND
GND 5 15 DCK
2.4.7.1 Signal Description – VGA Connector (CN1)
Signal Signal Description
HSYNC CRT horizontal synchronisation output.
VSYNC CRT vertical synchronisation output.
DCK
DAT
RED
GREEN
BLUE
Display Data Channel Clock. Used as clock signal to/from monitors with DDC
interface.
Display Data Channel Data. Used as data signal to/from monitors with DDC
interface.
Analog output carrying the red colour signal to the CRT. For 75 Ω cable
impedance.
Analog output carrying the green colour signal to the CRT. For 75 Ω cable
impedance.
Analog output carrying the blue colour signal to the CRT. For 75 Ω cable
impedance.
38 AIMB-250 Series User’s Manual
2.4.8 Serial Port 1 Connector in RS-232 Mode (CN1)
User’s Manual
Signal PIN PIN Signal
DCD 1 2 RxD
TxD 3 4 DTR
GND 5 6 DSR
RTS 7 8 CTS
RI/+5V/+12V 9 10 NC
2.4.8.1 Signal Description – Serial Port 1 Connector in RS-232 Mode (CN1)
Signal Signal Description
Serial output. This signal sends serial data to the communication link. The signal is
TxD
RxD Serial input. This signal receives serial data from the communication link.
DTR
set to a marking state on hardware reset when the transmitter is empty or when
loop mode operation is initiated.
Data Terminal Ready. This signal indicates to the modem or data set that the
on-board UART is ready to establish a communication link.
DSR
RTS
CTS
DCD
RI
Data Set Ready. This signal indicates that the modem or data set is ready to
establish a communication link.
Request To Send. This signal indicates to the modem or data set that the on-board
UART is ready to exchange data.
Clear To Send. This signal indicates that the modem or data set is ready to
exchange data.
Data Carrier Detect. This signal indicates that the modem or data set has detected
the data carrier.
Ring Indicator. This signal indicates that the modem has received a telephone
ringing signal.
AIMB-250 User’s Manual
39
AIMB-250 Series
2.4.9 Serial Port 1 Connector in RS-422 Mode (CN1)
Signal PIN PIN Signal
TxD- 1 2 RxD+
TxD+ 3 4 RxD-
GND 5 6 NC
NC 7 8 NC
NC 9 10 NC
2.4.9.1 Signal Description – Serial Port 1 Connector in RS-422 Mode (CN1)
Signal Signal Description
Serial output. This differential signal pair sends serial data to the communication
TxD+/-
RxD+/-
link. Data is transferred from Serial Port 2 Transmit Buffer Register to the
communication link, if the RTS register of the Serial Port 2 is set to LOW.
Serial input. This differential signal pair receives serial data from the
communication link. Received data is available in Serial Port 2 Receiver Buffer
Register.
40 AIMB-250 Series User’s Manual
2.4.10 Serial Port 1 Connector in RS-485 Mode (CN1)
Signal PIN PIN Signal
DATA- 1 2 NC
User’s Manual
DATA+ 3 4 NC
GND 5 6 NC
NC 7 8 NC
NC 9 10 NC
2.4.10.1 Signal Description – Serial Port 1 Connector in RS-485 Mode (CN1)
Signal Signal Description
This differential signal pair sends and receives serial data to the communication
DATA+/-
link. The mode of this differential signal pair is controlled through the RTS
register of Serial Port 2. Set the RTS register of the Serial Port 2 to LOW for
transmitting, HIGH for receiving.
Do not select a mode different from the one used by the connected peripheral,
as this may damage CPU board and/or peripheral.
The transmitter drivers in the port are short circuit protected by a thermal
protection circuit. The circuit disables the drivers when the die temperature
reaches 150 °C.
RS-422 mode is typically used in point to point communication. Data and
control signal pairs should be terminated in the receiver end with a resistor
matching the cable impedance (typical 100-120 Ω). The resistors could be
placed in the connector housing.
RS-485 mode is typically used in multi drop applications, where more than 2
units are communicating. The data and control signal pairs should be
terminated in each end of the communication line with a resistor matching the
cable impedance (typical 100-120 Ω). Stubs to substations should be
avoided.
AIMB-250 User’s Manual
41
AIMB-250 Series
2.4.11 Audio Connector (CN2)
Audio-In
Audio-Out
Port Description
Connects a tape player or
Audio-In
other audio sources.
Connects a headphone or a
Audio-Out
speaker.
Microphone
Microphone Connects a microphone.
2.4.12 RJ-45 Ethernet / USB 0 & 1, 4 & 5 Connectors (CN3, CN4)
Port Description
Allows connection to a Local
RJ-45
CN4
USB 2.0
Area Network (LAN) through
a network hub.
For connecting USB port 0,
1 (CN4), 4, 5 (CN3)
2.4.13 4/5/8-Wire Touch Screen Connector (CN5, optional)
PIN 4-Wire 5-Wire 8-Wire
1 NA NA Right Sense
2 NA NA Left Sense
3 NA NA Bottom Sense
4 NA Sense Top Sense
5 Right LR Right Excite
6 Left LL Left Excite
7 Bottom UR Bottom Excite
8 Top UL Top Excite
9 GND GND GND
42 AIMB-250 Series User’s Manual
2.4.14 Floppy Connector (FLP1)
User’s Manual
Signal PIN PIN Signal
GND 1 2 REDWC
GND 3 4 NC
GND 5 6 NC
GND 7 8 INDEX
GND 9 10 MOTSA
GND 11 12 DRVSB
GND 13 14 DRVSA
GND 15 16 MOTEB
GND 17 18 DIR
GND 19 20 STEP
GND 21 22 WDATA
GND 23 24 WGATE
GND 25 26 TK00
GND 27 28 WPT
GND 29 30 RDATA
GND 31 32 SIDE1
GND 33 34 DSKCHG
AIMB-250 User’s Manual
43
AIMB-250 Series
2.4.14.1 Signal Description – Floppy Connector (FLP)
Signal Signal Description
RDATA The read data input signal from the FDD.
WDATA
WGATE Write enable. An open drain output.
MOATSA
MOTEB
DRVSA
DRVSB
SIDE1 This output signal selects side of the disk in the selected drive.
DIR
STEP
Write data. This logic low open drain writes pre-compensation serial data to the
selected FDD. An open drain output.
Motor A On. When set to 0, this pin enables disk drive 0. This is an open drain
output.
Motor B On. When set to 0, this pin enables disk drive 1. This is an open drain
output.
Drive Select A. When set to 0, this pin enables disk drive A. This is an open drain
output.
Drive Select B. When set to 0, this pin enables disk drive B. This is an open drain
output.
Direction of the head step motor. An open drain output
Logic 1 = outward motion
Logic 0 = inward motion
Step output pulses. This active low open drain output produces a pulse to move
the head to another track.
REDWC
TK00
INDEX
WPT
DSKCHG
This output indicates whether a low drive density (250/300kbps at low level) or a
high drive density (500/1000kbps at high level) has been selected.
Track 0. This Schmitt-triggered input from the disk drive is active low when the
head is positioned over the outermost track.
This Schmitt-triggered input from the disk drive is active low when the head is
positioned over the beginning of a track marked by an index hole.
Write protected. This active low Schmitt input from the disk drive indicates that the
diskette is write-protected.
Diskette change. This signal is active low at power on and whenever the diskette is
removed.
44 AIMB-250 Series User’s Manual
2.4.15 Primary IDE Connector (IDE_1)
User’s Manual
Signal PIN PIN Signal
RESET# 1 2 GND
PDD7 3 4 PDD8
PDD6 5 6 PDD9
PDD5 7 8 PDD10
PDD4 9 10 PDD11
PDD3 11 12 PDD12
PDD2 13 14 PDD13
PDD1 15 16 PDD14
PDD0 17 18 PDD15
GND 19 20 NC
PDREQ 21 22 GND
PDIOW# 23 24 GND
PDIOR# 25 26 GND
PIORDY 27 28 GND
PDDACK# 29 30 GND
IRQ14 31 32 NC
PDA1 33 34 PATADET
PDA0 35 36 PDA2
PDCS1# 37 38 PDCS3#
IDEACTP# 39 40 GND
AIMB-250 User’s Manual
45
AIMB-250 Series
2.4.16 Secondary IDE Connector (IDE_2)
Signal PIN PIN Signal
RESET# 1 2 GND
SDD7 3 4 SDD8
SDD6 5 6 SDD9
SDD5 7 8 SDD10
SDD4 9 10 SDD11
SDD3 11 12 SDD12
SDD2 13 14 SDD13
SDD1 15 16 SDD14
SDD0 17 18 SDD15
GND 19 20 NC
SDREQ 21 22 GND
SDIOW# 23 24 GND
SDIOR# 25 26 GND
SIORDY 27 28 GND
SDDACK# 29 30 GND
IRQ15 31 32 NC
SDA1 33 34 SATADET
SDA0 35 36 SDA2
SDCS1# 37 38 SDCS3#
IDEACTP# 39 40 GND
+5V 41 42 +5V
GND 43 44 NC
Due to IDE compatibility issue, do not use CF and IDE device on secondary IDE channel at
the same time.
46 AIMB-250 Series User’s Manual
User’s Manual
2.4.16.1 Signal Description – Primary / Secondary IDE Connector (IDE_1, IDE_2)
The IDE interface supports PIO modes 0 to 4 and Bus Master IDE. Data transfer rates up to
100 MB/Sec is possible.
Signal Signal Description
DA [2:0]
DCS1#, DCS3#
D [15:0] IDE Data Lines. D [15:0] transfers data to/from the IDE devices.
IOR#
IOW#
IORDY
RESET# IDE Reset. This signal resets all the devices that are attached to the IDE interface.
IRQ14 Interrupt line from hard disk. Connected directly to PC-AT bus.
DREQ
DACK#
IDE Address Bits. These address bits are used to access a register or data port in
a device on the IDE bus.
IDE Chip Selects. The chip select signals are used to select the command block
registers in an IDE device. DCS1# selects the primary hard disk.
IDE I/O Read. Signal is asserted on read accesses to the corresponding IDE port
addresses.
IDE I/O Write. Each signal is asserted on write accesses to corresponding the IDE
port addresses.
When deasserted, these signals extend the transfer cycle of any host register
access when the device is not ready to respond to the data transfer request.
The DREQ is used to request a DMA transfer from the South Bridge. The direction
of the transfers is determined by the IOR#/IOW# signals.
DMA Acknowledge. The DACK# acknowledges the DREQ request to initiate DMA
transfers.
DACT#
PATADET,
SATADET
Signal from hard disk indicating hard disk activity. The signal level depends on the
hard disk type, normally active low. The signal is routed directly to the LED1.
Primary/Secondary IDE detected.
AIMB-250 User’s Manual
47
AIMB-250 Series
2.4.17 LCD Inverter Connector (JBKL1)
Note:
For inverters with adjustable Backlight function, it is possible to control the
LCD brightness through the VR signal controlled by JMISC. Please see the
JMISC section for detailed circuitry information.
Signal PIN
+12V 1
GND 2
ENBKL 3
VR 4
+5V 5
2.4.17.1 Signal Description – LCD Inverter Connector (JBKL1)
Signal Signal Description
VR Vadj = 0.75V ~ 4.25V (Recommended: 4.7KΩ, >1/16W)
ENBKL LCD backlight ON/OFF control signal
48 AIMB-250 Series User’s Manual
2.4.18 CD-ROM Audio Input Connector (JCD1)
User’s Manual
Signal PIN
CD_L 1
GND 2
GND 3
CD_R 4
2.4.18.1 Signal Description – CD-ROM Audio Input Connector (JCD1)
Signal Signal Description
CD_R Right CD-IN signal
CD_L Left CD-IN signal
2.4.19 Serial Port 2 Connector (JCOM1)
Signal PIN PIN Signal
DCD 1 2 RxD
TxD 3 4 DTR
GND 5 6 DSR
RTS 7 8 CTS
RI 9 10 NC
AIMB-250 User’s Manual
49
AIMB-250 Series
2.4.20 Serial Port 3/4 Connector (JCOM2, JCOM3)
Signal PIN PIN Signal
DCD 1 2 RxD
TxD 3 4 DTR
GND 5 6 DSR
RTS 7 8 CTS
RI 9 10 NC
2.4.20.1 Signal Description – Serial Port 2/3/4 Connector (JCOM1, JCOM2, JCOM3)
Signal Signal Description
Serial output. This signal sends serial data to the communication link. The signal is
TxD
RxD Serial input. This signal receives serial data from the communication link.
DTR
DSR
RTS
CTS
set to a marking state on hardware reset when the transmitter is empty or when
loop mode operation is initiated.
Data Terminal Ready. This signal indicates to the modem or data set that the
on-board UART is ready to establish a communication link.
Data Set Ready. This signal indicates that the modem or data set is ready to
establish a communication link.
Request To Send. This signal indicates to the modem or data set that the on-board
UART is ready to exchange data.
Clear To Send. This signal indicates that the modem or data set is ready to
exchange data.
DCD
RI
Data Carrier Detect. This signal indicates that the modem or data set has detected
the data carrier.
Ring Indicator. This signal indicates that the modem has received a telephone
ringing signal.
50 AIMB-250 Series User’s Manual
2.4.21 Digital Input / Output Connector (JDIO1)
Signal PIN PIN Signal
DIO0 1 2 DIO10
DIO1 3 4 DIO11
DIO2 5 6 DIO12
DIO3 7 8 DIO13
DIO4 9 10 DIO14
DIO5 11 12 DIO15
DIO6 13 14 DIO16
User’s Manual
DIO7 15 16 DIO17
SMB_CLK_S 17 18 SMB_DATA_S
GND 19 20 +5V
2.4.21.1 Signal Description – Digital Input / Output Connector (JDIO1)
Signal Signal Description
DI [0:17] Digital Input/Output Data Bit 0 to Bit 17
SMB_CLK Data input for I2C input, 5V tolerant
SMB_DATA Data input for I2C serial input, 5V tolerant
AIMB-250 User’s Manual
51
AIMB-250 Series
2.4.22 Front Panel Connector (JFP1)
Signal PIN PIN Signal
RESET
GND
HDD_LED+
HDD_LED-
VCCSB
PWR_BUT
SUS_BUT
GND
1 2
3 4
5 6
7 8
9 10
11 12
13 14
15 16
SYS_LED+
SYS_LED-
PWR_LED+
PWR_LED-
SUS_LED+
SUS_LED-
SPK+
SPK-
y
2.4.22.1 Signal Description – Front Panel Connecter (JFP1)
PIN No. Description
1, 3 Reset SW
2, 4 System LED
5, 7 HDD LED
6, 8 Power-On LED
9, 11 Power SW
10, 12 Suspend LED
13, 15 Suspend SW
14, 16 Speaker
System LED will be on as long as power supply is connected.
52 AIMB-250 Series User’s Manual
2.4.23 IrDA Connector (JIR1)
User’s Manual
Signal PIN
+5V 1
NC 2
IRRX 3
GND 4
IRTX 5
2.4.23.1 Signal Description – IrDA Connecter (JIR1)
Signal Signal Description
IRRX Infrared Receiver input
IRTX Infrared Transmitter output
AIMB-250 User’s Manual
53
AIMB-250 Series
2.4.24 LVDS Connector (JLVDS1)
Signal PIN PIN Signal
+5V 2 1 +3.3V
+5V 4 3 +3.3V
I2C_DAT 6 5 I2C_CLK
GND 8 7 GND
Txout0 10 9 Txout1
Txout0# 12 11 Txout1#
GND 14 13 GND
Txout2 16 15 Txout3
Txout2# 18 17 Txout3#
GND 20 19 GND
E_Txout0 22 21 E_Txout1
E_Txout0# 24 23 E_Txout1#
GND 26 25 GND
E_Txout2 28 27 E_Txout3
E_Txout2# 30 29 E_Txout3#
GND 32 31 GND
Txclk 34 33 E_Txclk
Txclk# 36 35 E_Txclk#
GND 38 37 GND
+12V 40 39 +12V
2.4.24.1 Signal Description – LVDS Connector (JLVDS1)
Signal Signal Description
I2C interface for panel parameter EEPROM. This EERPOM is mounted on the
I2C_DAT, I2C_CLK
LVDS receiver. The data in the EEPROM allows the EXT module to automatically
set the proper timing parameters for a specific LCD panel.
54 AIMB-250 Series User’s Manual
2.4.25 Miscellaneous Setting Connector (JMISC1)
Signal PIN PIN Signal
CASEOPEN# 1 2 VTIN3
GND 3 4 THRMDN
+5V 5 6 +5V
User’s Manual
VR 7 8 #MASTER
GND 9 10 GND
2.4.25.1 Signal Description – Miscellaneous Setting Connecter (JMISC1)
PIN No. Description
1, 3 Case open detection
LCD brightness setting
5, 7, 9
JMISC1
5
7
9
Variation Resistor (Recommended: 4.7KΩ, >1/16W)
2, 4 Thermal detection
6, 8, 10 CF Master/Slave setting 8-10 short (default: Master)
VCC
JBKL1 pin 4
AIMB-250 User’s Manual
55
AIMB-250 Series
2.4.26 TMDS DVI Connector (JTMDS1)
Signal PIN PIN Signal
+5V 2 1 TDC0#
GND 4 3 TDC0
NC 6 5 NC
NC 8 7 NC
HPDET 10 9 TDC1#
TMDSDATA 12 11 TDC1
TMDSDCLK 14 13 NC
GND 16 15 NC
TLC# 18 17 TDC2#
TLC 20 19 TDC2
2.4.26.1 Signal Description – TMDS Connecter (JTMDS1)
Signal Type Signal Description
TDC0, TDC0# O
TDC1, TDC1# O
TDC2, TDC2# O
HPDET I
DVI Data Channel 0 Outputs: These pins provide the DVI differential
outputs for data channel 0 (blue).
DVI Data Channel 1 Outputs: These pins provide the DVI differential
outputs for data channel 1 (green).
DVI Data Channel 2 Outputs: These pins provide the DVI differential
outputs for data channel 2 (red).
Hot Plug Detect (internal pull-down): This input pin determines
whether the DVI is connected to a DVI monitor. When terminated,
the monitor is required to apply a voltage greater than 2.4 volts.
Changes on the status of this pin will be relayed to the graphics
controller via the P-OUT/TLDET* or GPIO (1)/TLDET* pin pulling low.
DVO I2C Data: This signal is used as the I2C_DATA for a digital
TMDSDATA I/O
TMDSDCLK I/O
TLC, TLC# O
display (i.e. TV-Out Encoder, TMDS transmitter). This signal is
tri-stated during a hard reset.
DVI DDC Clock: This signal is used as the DDC clock for a digital
display connector (i.e. primary digital monitor). This signal is tri-stated
during a hard reset.
DVI Clock Outputs: These pins provide the differential clock outputs
for the DVI interface corresponding to data on TDC (0:2) outputs.
56 AIMB-250 Series User’s Manual
2.4.27 TV Out Connector (JTV1)
User’s Manual
Signal PIN PIN Signal
TVCVB 1 2 GND
TVYFCC2 3 4 TVCFCC2
GND 5 6 GND
2.4.27.1 Signal Description – TV Out Connecter (JTV1)
Signal Signal Description
Luma / Green Output. This pin outputs a selectable video signal. The output is
TVYFCC2
TVCFCC2
TVCVB
designed to drive a 75 ohm doubly terminated load. The output can be selected to
be S-video luminance or green.
Chroma / Green Output. This pin outputs a selectable video signal. The output is
designed to drive a 75 ohm doubly terminated load. The output can be selected to
be S-video chrominance or red
Composite Video / Blue Output. Chroma / Green Output. This pin outputs a
selectable video signal. The output is designed to drive a 75 ohm doubly
terminated load. The output can be selected to be composite video or blue.
AIMB-250 User’s Manual
57
AIMB-250 Series
2.4.28 USB Connector 2 & 3 (JUSB1)
Signal PIN PIN Signal
+5V 1 2 GND
D2- 3 4 GND
D2+ 5 6 D3+
2.4.29 USB Connector 4 & 5 (JUSB2)
GND 7 8 D3-
GND 9 10 +5V
Signal PIN PIN Signal
+5V 1 2 GND
D4- 3 4 GND
D4+ 5 6 D5+
GND 7 8 D5-
GND 9 10 +5V
2.4.29.1 Signal Description – USB Connecter 2, 3, 4 & 5 (JUSB1, JUSB2)
Signal Signal Description
D2+/D2-
D3+/D3-
D4+/D4-
D5+/D5-
Differential bi-directional data signal for USB channel 2. Clock is transmitted along
with the data using NRZI encoding. The signalling bit rate is up to 12 Mbs.
Differential bi-directional data signal for USB channel 3. Clock is transmitted along
with the data using NRZI encoding. The signalling bit rate is up to 12 Mbs.
Differential bi-directional data signal for USB channel 4. Clock is transmitted along
with the data using NRZI encoding. The signalling bit rate is up to 12 Mbs.
Differential bi-directional data signal for USB channel 5. Clock is transmitted along
with the data using NRZI encoding. The signalling bit rate is up to 12 Mbs.
58 AIMB-250 Series User’s Manual
2.4.30 PS/2 Keyboard & Mouse Connector (KB_MS1)
Mouse
Port Description
Mouse PS/2 Mouse connector
User’s Manual
Keyboard
Keyboard PS/2 Keyboard connector
2.4.31 System Fan Connector 1 & 2 (S_FAN1, S_FAN2)
Signal PIN
TAC 3
+12V 2
GND 1
S_FAN1
S_FAN2
2.4.31.1 Signal Description – System Fan Connector (S_FAN1, S_FAN2)
Signal Signal Description
TAC Fan speed monitor
AIMB-250 User’s Manual
59
AIMB-250 Series
3 BIOS Setup
60 AIMB-250 Series User’s Manual
User’s Manual
3.1 Starting Setup
The AwardBIOS™ is immediately activated when you first power on the computer. The
BIOS reads the system information contained in the CMOS and begins the process of
checking out the system and configuring it. When it finishes, the BIOS will seek an
operating system on one of the disks and then launch and turn control over to the operating
system.
While the BIOS is in control, the Setup program can be activated in one of two ways:
By pressing <Del> immediately after switching the system on, or
By pressing the <Del> key when the following message appears briefly at the bottom of the
screen during the POST (Power On Self Test).
Press DEL to enter SETUP
If the message disappears before you respond and you still wish to enter Setup, restart the
system to try again by turning it OFF then ON or pressing the "RESET" button on the
system case. You may also restart by simultaneously pressing <Ctrl>, <Alt>, and <Delete>
keys. If you do not press the keys at the correct time and the system does not boot, an error
message will be displayed and you will again be asked to.
Press F1 to Continue, DEL to enter SETUP
AIMB-250 User’s Manual
61
AIMB-250 Series
3.2 Using Setup
In general, you use the arrow keys to highlight items, press <Enter> to select, use the
PageUp and PageDown keys to change entries, press <F1> for help and press <Esc> to
quit. The following table provides more detail about how to navigate in the Setup program
using the keyboard.
Button Description
↑
↓
←
→
Esc key
PgUp key Increase the numeric value or make changes
PgDn key Decrease the numeric value or make changes
+ key Increase the numeric value or make changes
- key Decrease the numeric value or make changes
Move to previous item
Move to next item
Move to the item in the left hand
Move to the item in the right hand
Main Menu -- Quit and not save changes into CMOS
Status Page Setup Menu and Option Page Setup Menu -- Exit current page and
return to Main Menu
F1 key General help, only for Status Page Setup Menu and Option Page Setup Menu
(Shift) F2 key
F3 key Calendar, only for Status Page Setup Menu
F4 key Reserved
F5 key Restore the previous CMOS value from CMOS, only for Option Page Setup Menu
F6 key
F7 key Load the default
F8 key Reserved
F9 key Reserved
F10 key Save all the CMOS changes, only for Main Menu
Change color from total 16 colors. F2 to select color forward, (Shift) F2 to select
color backward
Load the default CMOS value from BIOS default table, only for Option Page Setup
Menu
• Navigating Through The Menu Bar
Use the left and right arrow keys to choose the menu you want to be in.
Note: Some of the navigation keys differ from one screen to another.
62 AIMB-250 Series User’s Manual
User’s Manual
• To Display a Sub Menu
Use the arrow keys to move the cursor to the sub menu you want. Then press
<Enter>. A “¾” pointer marks all sub menus.
3.3 Getting Help
Press F1 to pop up a small help window that describes the appropriate keys to use and the
possible selections for the highlighted item. To exit the Help Window press <Esc> or the F1
key again.
3.4 In Case of Problems
If, after making and saving system changes with Setup, you discover that your computer no
longer is able to boot, the AwardBIOS™ supports an override to the CMOS settings which
resets your system to its defaults.
The best advice is to only alter settings which you thoroughly understand. To this end, we
strongly recommend that you avoid making any changes to the chipset defaults. These
defaults have been carefully chosen by both Award and your systems manufacturer to
provide the absolute maximum performance and reliability. Even a seemingly small change
to the chipset setup has the potential for causing you to use the override.
AIMB-250 User’s Manual
63
AIMB-250 Series
3.5 Main Menu
Once you enter the AwardBIOS™ CMOS Setup Utility, the Main Menu will appear on the
screen. The Main Menu allows you to select from several setup functions and two exit
choices. Use the arrow keys to select among the items and press <Enter> to accept and
enter the sub-menu.
Note that a brief description of each highlighted selection appears at the bottom of the
screen.
Note: The BIOS setup screens shown in this chapter are for reference purposes
only, and may not exactly match what you see on your screen.
Visit the Advantech website (www.Advantech.com.tw) to download the
latest product and BIOS information.
64 AIMB-250 Series User’s Manual
User’s Manual
3.5.1 Standard CMOS Features
The items in Standard CMOS Setup Menu are divided into few categories. Each category
includes no, one or more than one setup items. Use the arrow keys to highlight the item and
then use the <PgUp> or <PgDn> keys to select the value you want in each item.
3.5.1.1 Main Menu Selection
This reference table shows the selections that you may make on the Main Menu.
Item Options Description
Time HH : MM : SS Set the system time
IDE Primary Master
IDE Primary Slave
IDE Secondary Master
IDE Secondary Slave
Drive A
Drive B
Video
Halt On
Boot Display
Options are in 3.5.1.2
None
360K, 5.25 in
1.2M, 5.25 in
720K, 3.5 in
1.44M, 3.5 in
2.88M, 3.5 in
EGA/VGA
CGA 40
CGA 80
MONO
All Errors
No Errors
All, but Keyboard
All, but Diskette
All, but Disk/Key
CRT
LFP (LVDS)
CRT+LFP(LVDS)
EFP(PANEL-LINK)
TV
CRT+EFP
Press <Enter> to enter the sub menu of
detailed options
Select the type of floppy disk drive installed in
your system
Select the default video device
Select the situation in which you want the BIOS
to stop the POST process and notify you
Select Display Device that the screen will be
shown
AIMB-250 User’s Manual
65
AIMB-250 Series
Item Options Description
Panel Type
TV Standard
Video Connector
TV Format
Automatic, Composite
NTSC_M_J, NTSC_433,
PAL_60, SECAM_L,
SECAM_L1, SECAM_B,
SECAM_D, SECAM_G,
SECAM_H, SECAM_K,
3.5.1.2 IDE Adapter Setup
640 x 480 18
800 x 600 18
1024 x 768 18
1280 x 1024 24/2
1400 x 1050 24
1600 x 1200 24
1280 x 768 24
1680 x 1050 24
1920 x 1200 24
1024 x 768 24
1024 x 768 18/2
1024 x 768 24/2
1280 x 800 18
1280 x 600 18
Off, NTSC
PAL, SECAM
Component, Both
Auto, NTSC_M,
NTSC_N, PAL_B,
PAL_G, PAL_D,
PAL_H, PAL_I,
PAL_M, PAL_N,
SECAM_K1
Select Panel Resolution that will be displayed
depending on the LCD Panel (LFP)
Select the output mode of TV Standard
Select the type of Video display connector
This item allows you to select different TV
signal format when the TV Standard item is not
off.
The IDE adapters control the hard disk drive. Use a separate sub menu to configure each
hard disk drive. The below table will shows the IDE primary master sub menu.
Item Options Description
Press Enter to auto-detect the HDD on
IDE HDD Auto-detection Press Enter
IDE Primary Master
IDE Primary Slave,
IDE Secondary Master,
IDE Secondary Slave
Access Mode
The following options are selectable only if the ‘IDE Channel …’ item is set to ‘Manual’
Cylinder
Head
Precomp
Landing zone
Sector
None
Auto
Manual
CHS, LBA
Large, Auto
Min = 0
Max = 65535
Min = 0
Max = 255
Min = 0
Max = 65535
Min = 0
Max = 65535
Min = 0
Max = 255
this channel. If detection is successful,
it fills the remaining fields on this
menu.
Selecting ‘manual’ lets you set the
remaining fields on this screen.
Selects the type of fixed disk. "User
Type" will let you select the number of
cylinders, heads, etc. Note:
PRECOMP=65535 means NONE !
Choose the access mode for this hard
disk
Set the number of cylinders for this
hard disk.
Set the number of read/write heads
**** Warning: Setting a value of 65535
means no hard disk
****
Number of sectors per track
66 AIMB-250 Series User’s Manual
User’s Manual
3.5.2 Advanced BIOS Features
This section allows you to configure your system for basic operation. You have the
opportunity to select the system’s default speed, boot-up sequence, keyboard operation,
shadowing and security.
3.5.2.1 CPU Feature
This item allows you to setup the CPU thermal management function.
Item Options Description
Thermal Management
TM2 Bus VID 0.700 ~ 1.708
Execute Disable Bit Enabled, Disabled
Thermal Monitor 1
Thermal Monitor 2
3.5.2.2 Virus Warning
Allows you to choose the VIRUS Warning feature for IDE Hard Disk boot sector protection.
If this function is enabled and someone attempt to write data into this area, BIOS will show
a warning message on screen and alarm beep.
Item Description
Enabled
Disabled
Activates automatically when the system boots up causing a warning message to
appear when anything attempts to access the boot sector or hard disk partition table.
No warning message will appear when anything attempts to access the boot sector or
hard disk partition table.
3.5.2.3 CPU L1 & L2 & L3 Cache
The item allows you to speed up memory access. However, it depends on CPU design.
Item Description
Enabled Enable cache
Disabled Disable cache
3.5.2.4 Quick Power On Self Test
This category speeds up Power On Self Test (POST) after you power up the computer. If it
is set to Enable, BIOS will shorten or skip some check items during POST.
Item Description
Enabled Enable quick POST
Disabled Normal POST
AIMB-250 User’s Manual
67
AIMB-250 Series
3.5.2.5 First/Second/Third/Other Boot Device
The BIOS attempts to load the operating system from the devices in the sequence selected
in these items.
Item Description
Floppy Floppy Device
LS120 LS120 Device
HDD-0~4 Hard Disk Device 0, 1, 2, 3, 4
SCSI SCSI Device
CDROM CDROM Device
ZIP100 ZIP-100 Device
USB-FDD USB Floppy Device
USB-ZIP USB ZIP Device
USB-CDROM
USB-HDD
LAN Network Device
Disabled Disabled any boot device
USB CDROM Device
USB Hard Disk Device
3.5.2.6 Swap Floppy Drive
While system has two floppy drivers installed, this item will be affected. This function is to
assign physical drive B to logical drive A.
Item Description
Enabled Assign physical drive B to logical drive A
Disabled No change
3.5.2.7 Book Up Floppy Seek
Seeks disk drives during boot up. Disabling seeds boot up.
Item Description
Enabled Enable Floppy Seek
Disabled Disable Floppy Seek
3.5.2.8 Boot Up NumLock Status
Select power on state for NumLock.
Item Description
Enabled Enable NumLock
Disabled Disable NumLock
3.5.2.9 Gate A20 Option
Select if chipset or keyboard controller should control Gate A20.
Item Description
Normal A pin in the keyboard controller controls Gate A20
Fast Lets chipset control Gate A20
3.5.2.10 Typematic Rate Setting
Key strokes repeat at a rate determined by the keyboard controller. When enabled, the
typematic rate and typematic delay can be selected.
Item Description
Enabled Enable typematic rate/delay setting
Disabled Disable typematic rate/delay setting
3.5.2.11 Security Option
Select whether the password is required every time the system boots or only when you
enter setup.
68 AIMB-250 Series User’s Manual
User’s Manual
Item Description
System
Setup
The system will not boot and access to Setup will be denied if the correct password is
not entered at the prompt.
The system will boot, but access to Setup will be denied if the correct password is not
entered at the prompt.
Note: To disable security, select PASSWORD SETTING at Main Menu and then
you will be asked to enter password. Do not type anything and just press
<Enter>, it will disable security. Once the security is disabled, the system
will boot and you can enter Setup freely.
3.5.2.12 APIC Mode
The BIOS supports versions 1.4 of the Intel multiprocessor specification. When enabled,
The MPS Version 1.4 Control for OS can be activated.
The choice: Enabled/Disabled.
3.5.2.13 MPS Version Control For OS
This feature is only applicable to multiprocessor board as it specifies the version of the
Multi-Processor Specification (MPS) that the board will use.
The choice: 1.4, 1.1.
3.5.2.14 OS Select for DRAM > 64MB
Select the operating system that is running with greater than 64MB of RAM on the system.
Item Description
Non-OS2 Disable OS for over 64 MB DRAM
OS2 Enable OS for over 64 MB DRAM
3.5.2.15 Report No FDD For WIN95
The original Windows95 requires the presence of a floppy. Unless the BIOS tells it to
disregard the absence of the drive, it will generate an error message. For other operating
systems as Win98 etc this field is without relevance.
Item Description
No Don’t generate error message
Yes Generate error message
3.5.2.16 Full Screen LOGO Show
This item allows to enabled/disabled the full screen logo during BIOS boot up process.
Item Description
Enabled Full Screen Logo show is enabled
Disabled Full Screen Logo show is disabled
3.5.2.17 Logo (EPA) Show
This item allows you enabled/disabled the small EPA logo show on screen at the POST
step.
Item Description
Enabled EPA Logo show is enabled
Disabled EPA Logo show is disabled
AIMB-250 User’s Manual
69
AIMB-250 Series
3.5.3 Advanced Chipset Features
This section allows you to configure the system based on the specific features of the
installed chipset. This chipset manages bus speeds and access to system memory
resources, such as DRAM and the external cache. It also coordinates communications
between the conventional ISA bus and the PCI bus. It must be stated that these items
should never need to be altered. The default settings have been chosen because they
provide the best operating conditions for your system. The only time you might consider
making any changes would be if you discovered that data was being lost while using your
system.
The first chipset settings deal with CPU access to dynamic random access memory
(DRAM). The default timings have been carefully chosen and should only be altered if data
is being lost. Such a scenario might well occur if your system had mixed speed DRAM
chips installed so that greater delays may be required to preserve the integrity of the data
held in the slower memory chips.
3.5.3.1 DRAM Timing Selectable
This item allows you to select the DRAM timing value by SPD data or Manual by yourself.
The choices: Manual, By SPD.
3.5.3.2 CAS Latency Time
This item controls the time delay (in clock cycles - CLKs) that passes before the SDRAM
starts to carry out a read command after receiving it. This also determines the number of
CLKs for the completion of the first part of a burst transfer. In other words, the lower the
latency, the faster the transaction.
The choices: 2, 2.5.
3.5.3.3 Active to Precharge Delay
This item is the minimum delay time between Active and Precharge
The choices: 5, 6, 7.
70 AIMB-250 Series User’s Manual
User’s Manual
3.5.3.4 DRAM RAS# to CAS# Delay
This option allows you to insert a delay between the RAS (Row Address Strobe) and CAS
(Column Address Strobe) signals. This delay occurs when the SDRAM is written to, read
from or refreshed. Naturally, reducing the delay improves the performance of the SDRAM
while increasing it reduces performance.
The choices: 2, 3.
3.5.3.5 DRAM RAS# Precharge
This option sets the number of cycles required for the RAS to accumulate its charge before
the SDRAM refreshes. Reducing the precharge time to 2 improves SDRAM performance
but if the precharge time of 2 is insufficient for the installed SDRAM, the SDRAM may not
be refreshed properly and it may fail to retain data
So, for better SDRAM performance, set the SDRAM RAS Precharge Time to 2 but
increase it to 3 if you face system stability issues after reducing the precharge time.
The choices: 2, 3.
3.5.3.6 DRAM Data Integrity Mode
Select ECC if your memory module supports it. The memory controller will detect and
correct single-bit soft memory errors. The memory controller will also be able to detect
double-bit errors though it will not be able to correct them. This provides increased data
integrity and system stability.
The choices: Non-ECC, ECC.
3.5.3.7 MGM Core Frequency
This field sets the frequency of the DRAM memory installed.
The choices: Auto Max 266MHz, 400/266/133/200 MHz, 400/200/100/200 MHz,
400/200/100/133 MHz, 400/266/133/267 MHz, 533/266/133/200 MHz,
533/266/133/266 MHz, 400/333/166/250 MHz, Auto Max 400/333 MHz,
Auto Max 533/333 MHz.
3.5.3.8 System BIOS Cacheable
This feature is only valid when the system BIOS is shadowed. It enables or disables the
caching of the system BIOS ROM at F0000h-FFFFFh via the L2 cache. This greatly
speeds up accesses to the system BIOS. However, this does not translate into better
system performance because the OS does not need to access the system BIOS much.
The choices: Disabled, Enabled.
3.5.3.9 Video BIOS Cacheable
This feature is only valid when the video BIOS is shadowed. It enables or disables the
caching of the video BIOS ROM at C0000h-C7FFFh via the L2 cache. This greatly speeds
up accesses to the video BIOS. However, this does not translate into better system
performance because the OS bypasses the BIOS using the graphics driver to access the
video card's hardware directly.
The Choice: Enabled, Disabled.
AIMB-250 User’s Manual
71
AIMB-250 Series
3.5.3.10 Memory Hole At 15M-16M
Enabling this feature reserves 15MB to 16MB memory address space to ISA expansion
cards that specifically require this setting. This makes the memory from 15MB and up
unavailable to the system. Expansion cards can only access memory up to 16MB.
The choice: Enable, Disable.
3.5.3.11 Delayed Transaction
This feature is used to meet the latency of PCI cycles to and from the ISA bus. The ISA bus
is much, much slower than the PCI bus. Thus, PCI cycles to and from the ISA bus take a
longer time to complete and this slows the PCI bus down.
However, enabling Delayed Transaction enables the chipset's embedded 32-bit posted
write buffer to support delayed transaction cycles. This means that transactions to and from
the ISA bus are buffered and the PCI bus can be freed to perform other transactions while
the ISA transaction is underway.
This option should be enabled for better performance and to meet PCI 2.1 specifications.
Disable it only if your PCI cards cannot work properly or if you are using an ISA card that is
not PCI 2.1 compliant.
The Choice: Enabled, Disabled.
3.5.3.12 Delay Prior to Thermal
When you system temperature higher, you can set the DRAM access time slowdown
between on 4 min – 32 min delay.
The choice: 4 Min, 8 Min, 16 Min, and 32 Min.
3.5.3.13 AGP Aperture Size (MB)
Select the size of Accelerated Graphics Port (AGP) aperture. The aperture is a portion of
the PCI memory address range dedicated for graphics memory address space. Host cycles
that hit the aperture range are forwarded to the AGP without any translation.
The Choice: 4, 8, 16, 32, 64, 128, 256.
3.5.3.14 Init Display First
This item allows you to decide to active whether PCI Slot or Onboard/AGP first.
The choice: PCI Slot, Onboard/AGP.
3.5.3.15 On-Chip VGA
This item is enabled as the onboard VGA is used.
The Choices: Enabled, Disabled.
3.5.3.16 On-Chip Frame Buffer Size
This item is to select the amount of system memory that will be utilized as internal graphics
device memory
The choices: 1MB, 4MB, 8MB, 16MB, 32MB.
72 AIMB-250 Series User’s Manual
3.5.4 Integrated Peripherals
Use this menu to specify your settings for integrated peripherals.
3.5.4.1 OnChip IDE Device
User’s Manual
The chipset contains a PCI IDE interface with support for two IDE channels. Select Enabled
to activate the primary IDE interface. Select Disabled to deactivate this interface.
AIMB-250 User’s Manual
73
AIMB-250 Series
Item Options Description
On-Chip Primary PCI IDE
On-Chip Secondary PCI IDE
IDE Primary Master PIO
IDE Primary Slave PIO
IDE Secondary Master PIO
IDE Secondary Slave PIO
IDE Primary Master UDMA
IDE Primary Slave UDMA
IDE Secondary Master UDMA
IDE Secondary Slave UDMA
3.5.4.2 Onboard Device
Enabled
Disabled
Auto
Mode 0
Mode 1
Mode 2
Mode 3
Mode 4
Auto
Disabled
The chipset contains a PCI IDE interface with
support for two IDE channels. Select Enabled to
activate the primary/secondary IDE interface.
Select Disabled to deactivate this interface.
The IDE PIO (Programmed Input/Output) fields
let you set a PIO mode (0-4) for each of the four
IDE devices that the onboard IDE interface
supports. Modes 0 through 4 provide
successively increased performance. In Auto
mode, the system automatically determines the
best mode for each device.
Ultra DMA implementation is possible only if
your IDE hard drive supports it and the
operating environment includes a DMA driver
(Windows 95 OSR2 or a third-party IDE bus
master driver). If the hard drive and the system
software both support Ultra DMA, select Auto to
enable BIOS support.
Item Options Description
USB Controller
USB 2.0 Controller
USB Keyboard Support
USB Mouse Support
AC97 Audio
Disabled
Disabled
Disabled
Disabled
Disabled
74 AIMB-250 Series User’s Manual
Enabled
Enabled
Enabled
Enabled
Auto
This item allows you to set the USB Controller.
This item allows you to set the USB 2.0
Controller.
This item allows you to set the system’s USB
keyboard to Enabled/Disabled.
This item allows you to set the system’s USB
Mouse to Enabled/Disabled.
This item allows you to decide to Auto/disable
the Codec chip to support AC97 Audio.
3.5.4.3 Super IO Device
User’s Manual
AIMB-250 User’s Manual
75
AIMB-250 Series
Item Options Description
Select Enabled if your system has a floppy disk
Onboard FDC Controller
Onboard Serial Port 1
Onboard Serial Port 2
Onboard Parallel Port
Parallel Port Mode
EPP Mode Select EPP1.9, EPP1.7 Select EPP port type 1.7 or 1.9.
ECP Mode Use DMA 1, 3 Select a DMA channel for the port.
PWRON After PWR-Fail
Onboard Serial Port 3
Onboard Serial Port 4
Serial Port 3 Use IRQ
Serial Port 4 Use IRQ
Serial Port 3 Mode
Enabled
Disabled
Disable, 3F8/IRQ4
2F8/IRQ3, 3E8/IRQ4
2E8/IRQ3, AUTO
Disabled, 378/IRQ7
278/IRQ5, 3BC/IRQ7
SPP, EPP
ECP, Normal
ECP+EPP
Off, On
Former-Sts
Disable, 3F8
2F8, 3E8,
2E8
IRQ3, IRQ4, IRQ5
IRQ9, IRQ10, IRQ11
Normal
IRDA
controller (FDC) installed on the system board
and you wish to use it. If you are not going to
use FDC or the system has no floppy drive,
select Disabled in this field.
Select an address and corresponding interrupt
for the first and second serial ports.
Select a matching address and interrupt for the
physical parallel (printer) port.
Select an operating mode for the onboard
parallel port. Select Compatible or Extended
unless you are certain both your hardware and
software support EPP or ECP mode.
This item is to set whether to run Ac Loss Auto
Restart or off
Select an IRQ address for the third and forth
serial Ports.
Select an IRQ for the third and forth serial
ports.
Select an IO address for the third serial ports
3.5.4.4 Watch Dog Timer
This option will determine watch dog timer.
The choices: Disabled, 10, 20, 30, 40 Sec. 1, 2, 4 Min.
76 AIMB-250 Series User’s Manual
User’s Manual
3.5.5 Power Management Setup
The Power Management Setup allows you to configure you system to most effectively save
energy while operating in a manner consistent with your own style of computer use.
3.5.5.1 ACPI Function
This item allows you to enable/disable the ACPI function.
The choices: Enable, Disable.
3.5.5.2 ACPI Suspend Type
This item will set which ACPI suspend type will be used.
The choice: S1(POS), S3(STR).S1&S3.
3.5.5.3 Power Management
This category allows you to select the type (or degree) of power saving and is directly
related to the following modes:
Item Description
Min. Power Saving
Max. Power Saving
User Defined
Minimum power management,
HDD Power Down = 15 Min,
Maximum power management,
HDD Power Down =1 Min,
Allows you to set each mode individually. When not disabled, each of the
ranges are from 1 min. to 1 hr. except for HDD Power Down which ranges
from 1 min. to 15 min. and disable.
3.5.5.4 Video Off Method
This determines the manner in which the monitor is blanked.
The choices: Blank Screen, V/H SYNC+Blank, DPMS.
3.5.5.5 Video Off In Suspend
This determines the manner in which the monitor is blanked.
The choice: No, Yes.
3.5.5.6 Suspend Type
This function allows to select Suspend type.
The choices: Stop Grant, PwrOn Suspend.
AIMB-250 User’s Manual
77
AIMB-250 Series
3.5.5.7 MODEM Use IRQ
This determines the IRQ in which the MODEM can use.
The choices: NA, 3, 4, 5, 7, 9, 10, 11.
3.5.5.8 Soft-Off by PWR-BTTN
Pressing the power button for more than 4 seconds forces the system to enter the Soft-Off
state when the system has “hung”.(Only could working on ATX Power supply)
The choices: Delay 4 Sec, Instant-Off.
3.5.5.9 Wake Up by PCI Card
This will enable the system to wake up through PCI Card peripheral.
The choices: Enable, Disabled.
3.5.5.10 Power On By Ring
This determines whether the system boot up if there’s an incoming call from the Modem.
The choices: Enable, Disabled.
3.5.5.11 Resume By Alarm
This function is for setting date and time for your computer to boot up.
The choices: Enabled, Disabled.
3.5.5.12 Primary/Secondary IDE 0/1, FDD,COM,LPT PORT, PCI PIRQ[A-D]#
Reload Global Timer events are I/O events whose occurrence can prevent the system from
entering a power saving mode or can awake the system from such a mode. In effect ,the
system remain alert for anything which occurs to a device which is configured as
Enabled ,even when the system is in a power down mode.
The choices: Enabled, Disabled.
78 AIMB-250 Series User’s Manual
User’s Manual
3.5.6 PnP / PCI Configuration
This section describes configuring the PCI bus system. PCI, or Personal Computer
Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed
the CPU itself uses when communicating with its own special components. This section
covers some very technical items and it is strongly recommended that only experienced
users should make any changes to the default settings.
3.5.6.1 Reset Configuration Data
Normally, you leave this field Disabled. Select Enabled to reset Extended System
Configuration Data (ESCD) when you exit Setup if you have installed a new add-on and the
system reconfiguration has caused such a serious conflict that the operating system cannot
boot.
The choices: Enabled, Disabled.
3.5.6.2 Resources Controlled By
The Award Plug and Play BIOS has the capacity to automatically configure all of the boot
and Plug and Play compatible devices. However, this capability means absolutely nothing
unless you are using a Plug and Play operating system such as Windows®95. If you set
this field to “manual” choose specific resources by going into each of the sub menu that
follows this field (a sub menu is preceded by a “¾”).
The choices: Auto(ESCD), Manual.
3.5.6.3 PCI / VGA Palette Snoop
Leave this field at Disabled.
The choices: Enabled, Disabled.
AIMB-250 User’s Manual
79
AIMB-250 Series
3.5.7 PC Health Status
This section shows the status of your CPU, Fan & System.
3.5.7.1 Case Open Warning
This item allows to enable the case open warning function.
The choices: Enabled, Disabled.
80 AIMB-250 Series User’s Manual
3.5.8 Frequency / Voltage Control
This menu specifies your setting for frequency/voltage control.
3.5.8.1 Auto Detect PCI Clk
User’s Manual
This item allows you to enable/disable auto detect PCI Clock.
The choices: Enable, Disable.
3.5.8.2 Spread Spectrum
This item is to adjust extreme values of the pulse for EMI test.
The choices: Enable, Disable.
3.5.8.3 CPU Host / 3V66 / PCI Clock
These options allow you to set CPU Host/3V66/PCI clock into various types of frequencies.
The choices: Default, 100/66/33MHz, 105/70/35MHz, 109/73/36MHz, 114/76/38MHz,
117/78/39MHz, 127/85/42MHz, 130/87/43MHz, 133/67/33MHz,
137/69/34MHz, 141/71/35MHz, 145/73/36MHz, 150/75/38MHz,
155/78/39MHz, 160/80/40MHz.
AIMB-250 User’s Manual
81
AIMB-250 Series
3.5.9 Load Fail-Safe Defaults
Use this menu to load the BIOS default values for the minimal/stable performance for your
system to operate.
Press <Y> to load the BIOS default values for the most stable, minimal-performance
system operations.
3.5.10 Load Optimized Defaults
Use this menu to load the BIOS default values that are factory settings for optimal
performance system operations. While Award has designed the custom BIOS to maximize
performance, the factory has the right to change these defaults to meet their needs.
Press <Y> to load the default values setting for optimal performance system operations.
82 AIMB-250 Series User’s Manual
3.5.11 Set Supervisor / User Password
You can set either supervisor or user password, or both of them.
Supervisor Password: able to enter/change the options of setup menus.
User’s Manual
User Password: able to enter but no right to change the options of setup menus.
Type the password, up to eight characters in length, and press <Enter>. The password
typed now will clear any previously entered password from CMOS memory. You will be
asked to confirm the password. Type the password again and press <Enter>. You may also
press <Esc> to abort the selection and not enter a password. To disable a password, just
press <Enter> when you are prompted to enter the password. A message will confirm the
password will be disabled. Once the password is disabled, the system will boot and you can
enter Setup freely.
AIMB-250 User’s Manual
83
AIMB-250 Series
PASSWORD DISABLED.
When a password has been enabled, you will be prompted to enter it every time you try to
enter Setup. This prevents an unauthorized person from changing any part of your system
configuration. Additionally, when a password is enabled, you can also require the BIOS to
request a password every time your system is rebooted. This would prevent unauthorized
use of your computer. You determine when the password is required within the BIOS
Features Setup Menu and its Security option (see Section 3). If the Security option is set to
“System”, the password will be required both at boot and at entry to Setup. If set to “Setup”,
prompting only occurs when trying to enter Setup
3.5.12 Save & Exit Setup
Save CMOS value changes to CMOS and exit setup.
Enter <Y> to store the selection made in the menus in CMOS, a special section in memory
that stays on after turning the system off. The BIOS configures the system according to the
Setup selection stored in CMOS when boot the computer next time.
The system is restarted after saving the values.
84 AIMB-250 Series User’s Manual
User’s Manual
3.5.13 Exit Without Save
Abandon all CMOS value changes and exit setup, and the system is restarted after exiting.
AIMB-250 User’s Manual
85
AIMB-250 Series
4 Drivers Installation
Note: Installation procedures and screen shots in this section are
for your reference and may not be exactly the same as
shown on your screen.
86 AIMB-250 Series User’s Manual
4.1 Install Driver
Step 1
Insert the Supporting CD-ROM to CD-ROM drive,
and it should show the index page of Advantech’s
products automatically.
User’s Manual
Step 2. Click AIMB-250
Step 3. Click on the driver you wan to install
AIMB-250 User’s Manual
87
AIMB-250 Series
5 Mechanical
Drawing
88 AIMB-250 Series User’s Manual
User’s Manual
Unit: mm
AIMB-250 User’s Manual
89
AIMB-250 Series
Appendix A:
AWARD BIOS POST
Messages
90 AIMB-250 Series User’s Manual
User’s Manual
Overview
During the Power On Self-Test (POST), if the BIOS detects an error requiring you to do
something to fix, it will either sound a beep code or display a message.
If a message is displayed, it will be accompanied by:
PRESS F1 TO CONTINUE, CTRL-ALT-ESC OR DEL TO ENTER SETUP
Post Beep
Currently there are two kinds of beep codes in BIOS. This code indicates that a video error
has occurred and the BIOS cannot initialize the video screen to display any additional
information. This beep code consists of a single long beep followed by two short beeps.
The other code indicates that your DRAM error has occurred. This beep code consists of a
single long beep repeatedly.
Error Messages
One or more of the following messages may be displayed if the BIOS detects an error
during the POST. This list includes messages for both the ISA and the EISA BIOS.
1. CMOS BATTERY HAS FAILED
CMOS battery is no longer functional. It should be replaced.
2. CMOS CHECKSUM ERROR
Checksum of CMOS is incorrect. This can indicate that CMOS has become corrupt. This
error may have been caused by a weak battery. Check the battery and replace if
necessary.
3. DISK BOOT FAILURE, INSERT SYSTEM DISK AND PRESS ENTER
No boot device was found. This could mean that either a boot drive was not detected or the
drive does not contain proper system boot files. Insert a system disk into Drive A: and
press <Enter>. If you assumed the system would boot from the hard drive, make sure the
controller is inserted correctly and all cables are properly attached. Also be sure the disk
is formatted as a boot device. Then reboot the system.
4. DISKETTE DRIVES OR TYPES MISMATCH ERROR - RUN SETUP
Type of diskette drive installed in the system is different from the CMOS definition. Run
Setup to reconfigure the drive type correctly.
AIMB-250 User’s Manual
91
AIMB-250 Series
5. DISPLAY SWITCH IS SET INCORRECTLY
Display switch on the motherboard can be set to either monochrome or color. This indicates
the switch is set to a different setting than indicated in Setup. Determine which setting is
correct, and then either turn off the system and change the jumper, or enter Setup and
change the VIDEO selection.
6. DISPLAY TYPE HAS CHANGED SINCE LAST BOOT
Since last powering off the system, the display adapter has been changed. You must
configure the system for the new display type.
7. EISA Configuration Checksum Error
PLEASE RUN EISA CONFIGURATION UTILITY
The EISA non-volatile RAM checksum is incorrect or cannot correctly read the EISA slot.
This can indicate either the EISA non-volatile memory has become corrupt or the slot has
been configured incorrectly. Also be sure the card is installed firmly in the slot.
8. EISA Configuration Is Not Complete
PLEASE RUN EISA CONFIGURATION UTILITY
The slot configuration information stored in the EISA non-volatile memory is incomplete.
Note: When either of these errors appears, the system will boot in ISA mode,
which allows you to run the EISA Configuration Utility.
9. ERROR ENCOUNTERED INITIALIZING HARD DRIVE
Hard drive cannot be initialized. Be sure the adapter is installed correctly and all cables are
correctly and firmly attached. Also be sure the correct hard drive type is selected in Setup.
10. ERROR INITIALIZING HARD DISK CONTROLLER
Cannot initialize controller. Make sure the cord is correctly and firmly installed in the bus.
Be sure the correct hard drive type is selected in Setup. Also check to see if any jumper
needs to be set correctly on the hard drive.
11. FLOPPY DISK CNTRLR ERROR OR NO CNTRLR PRESENT
Cannot find or initialize the floppy drive controller. Make sure the controller is installed
correctly and firmly. If there are no floppy drives installed, be sure the Diskette Drive
selection in Setup is set to NONE.
92 AIMB-250 Series User’s Manual
User’s Manual
12. Invalid EISA Configuration
PLEASE RUN EISA CONFIGURATION UTILITY
The non-volatile memory containing EISA configuration information was programmed
incorrectly or has become corrupt. Re-run EISA configuration utility to correctly program the
memory.
Note: When either of these errors appears, the system will boot in ISA mode,
which allows you to run the EISA Configuration Utility.
13. KEYBOARD ERROR OR NO KEYBOARD PRESENT
Cannot initialize the keyboard. Make sure the keyboard is attached correctly and no keys
are being pressed during the boot.
If you are purposely configuring the system without a keyboard, set the error halt condition
in Setup to HALT ON ALL, BUT KEYBOARD. This will cause the BIOS to ignore the
missing keyboard and continue the boot.
14. Memory Address Error at ...
Indicates a memory address error at a specific location. You can use this location along
with the memory map for your system to find and replace the bad memory chips.
15. Memory parity Error at ...
Indicates a memory parity error at a specific location. You can use this location along with
the memory map for your system to find and replace the bad memory chips.
16. MEMORY SIZE HAS CHANGED SINCE LAST BOOT
Memory has been added or removed since the last boot. In EISA mode use Configuration
Utility to reconfigure the memory configuration. In ISA mode enter Setup and enter the new
memory size in the memory fields.
17. Memory Verify Error at ...
Indicates an error verifying a value already written to memory. Use the location along with
your system's memory map to locate the bad chip.
18. OFFENDING ADDRESS NOT FOUND
This message is used in conjunction with the I/O CHANNEL CHECK and RAM PARITY
ERROR messages when the segment that has caused the problem cannot be isolated.
19. OFFENDING SEGMENT:
This message is used in conjunction with the I/O CHANNEL CHECK and RAM PARITY
ERROR messages when the segment that has caused the problem has been isolated.
AIMB-250 User’s Manual
93
AIMB-250 Series
20. PRESS A KEY TO REBOOT
This will be displayed at the bottom screen when an error occurs that requires you to reboot.
Press any key and the system will reboot.
21. PRESS F1 TO DISABLE NMI, F2 TO REBOOT
When BIOS detects a Non-maskable Interrupt condition during boot, this will allow you to
disable the NMI and continue to boot, or you can reboot the system with the NMI enabled.
22. RAM PARITY ERROR - CHECKING FOR SEGMENT ...
Indicates a parity error in Random Access Memory.
23. Should Be Empty But EISA Board Found
PLEASE RUN EISA CONFIGURATION UTILITY
A valid board ID was found in a slot that was configured as having no board ID.
Note: When either of these errors appears, the system will boot in ISA mode,
which allows you to run the EISA Configuration Utility.
24. Should Have EISA Board But Not Found
PLEASE RUN EISA CONFIGURATION UTILITY
The board installed is not responding to the ID request, or no board ID has been found in
the indicated slot.
Note: When either of these errors appears, the system will boot in ISA mode,
which allows you to run the EISA Configuration Utility.
25. Slot Not Empty
Indicates that a slot designated as empty by the EISA Configuration Utility actually contains
a board.
Note: When either of these errors appears, the system will boot in ISA mode,
which allows you to run the EISA Configuration Utility.
26. SYSTEM HALTED, (CTRL-ALT-DEL) TO REBOOT ...
Indicates the present boot attempt has been aborted and the system must be rebooted.
Press and hold down the CTRL and ALT keys and press DEL.
94 AIMB-250 Series User’s Manual
User’s Manual
27. Wrong Board In Slot
PLEASE RUN EISA CONFIGURATION UTILITY
The board ID does not match the ID stored in the EISA non-volatile memory.
Note: When either of these errors appears, the system will boot in ISA mode,
which allows you to run the EISA Configuration Utility.
28. FLOPPY DISK(S) fail (80) → Unable to reset floppy subsystem.
29. FLOPPY DISK(S) fail (40) → Floppy Type dismatch.
30. Hard Disk(s) fail (80) → HDD reset failed.
31. Hard Disk(s) fail (40) → HDD controller diagnostics failed.
32. Hard Disk(s) fail (20) → HDD initialization error.
33. Hard Disk(s) fail (10) → Unable to recalibrate fixed disk.
34. Hard Disk(s) fail (08) → Sector Verify failed.
35. Keyboard is locked out - Unlock the key.
BIOS detect the keyboard is locked. P17 of keyboard controller is pulled low.
36. Keyboard error or no keyboard present.
Cannot initialize the keyboard. Make sure the keyboard is attached correctly and no keys
are being pressed during the boot.
37. Manufacturing POST loop.
System will repeat POST procedure infinitely while the P15 of keyboard controller is pull
low. This is also used for M/B burn in test.
38. BIOS ROM checksum error - System halted.
The checksum of ROM address F0000H-FFFFFH is bad.
39. Memory test fail.
BIOS reports the memory test fail if the onboard memory is tested error.
AIMB-250 User’s Manual
95
AIMB-250 Series
40. POST Codes
Please take reference to Phoenix-Award website for the latest post codes.
http://www.phoenix.com/en/Customer+Services/BIOS/AwardBIOS/Award+Error+Codes.ht
m
40.1 Normal POST Code
Note: EISA POST codes are typically output to port address 300h. ISA POST codes are output to
port address 80h.
Code (hex) Name Description
C0 Turn Off Chipset and
CPU test
C1 Memory Presence First block memory detect OEM Specific-Test to size on-board
C2 Early Memory
Initialization
C3 Extend Memory DRAM
select
OEM Specific-Cache control cache
Processor Status (1FLAGS) Verification. Tests the following
processor status flags: Carry, zero, sign, overflow, the BIOS sets
each flag, verifies They are set, then turns each flag off and
verifies it is off.
Read/Write/Verify all CPU registers except SS, SP, and BP with
data pattern FF and 00. RAM must be periodically refreshed to
keep the memory from decaying. This function ensures that the
memory refresh function is working properly.
memory. Early chip set initialization Memory presence test OEM
chip set routines clear low 64K of memory Test first 64K memory.
OEM Specific- Board Initialization
OEM Specific- Turn on extended memory Initialization
Cyrix CPU initialization, Cache initialization
C4 Special Display
Handling
C5 Early Shadow OEM specific- Early shadow enable for fast boot
C6 Cache presence test External cache size detection
CF CMOS Check CMOS checkup
B0 Spurious If interrupt occurs in protected mode.
B1 Unclaimed NMI If unmasked NMI occurs, display Press F1 to disable NMI, F2
BF Program Chip Set To program chipset from defaults values
E1-EF Setup Pages E1- Page 1, E2 - Page 2, etc.
1 Force load Default to
chipset
2 Reserved
OEM Specific- Display/Video Switch handling so that switch
handling display switch errors never occurs
reboot.
Chipset defaults program
96 AIMB-250 Series User’s Manual
User’s Manual
Code (hex) Name Description
3 Early Superio Init Early Initialized the super IO
4 Reserved
5 Blank video Reset Video controller
6 Reserved
7 Init KBC Keyboard controller init
8 KB test Test the Keyboard
9 Reserved
A Mouse Init Initialized the mouse
B Onboard Audio init Onboard audio controller initialize if exist
C Reserved
D Reserved
E CheckSum Check Check the intergraty of the ROM, BIOS and message
F Reserved
10 Auto detec EEPROM Check Flash type and copy flash write/erase routines to 0F000h
segments
11 Reserved
12 Cmos Check Check Cmos Circuitry and reset CMOS
13 Reserved
14 Chipset Default load Program the chipset registers with CMOS values
15 Reserved
16 Clock Init Init onboard clock generator
17 Reserved
18 Identify the CPU Check the CPU ID and init L1/L2 cache
19 Reserved
1A Reserved
1B Setup Interrupt Vector
Table
1C Reserved
1D Early PM Init First step initialize if single CPU onboard
Initialize first 120 interrupt vectors with SPURIOUS_INT_HDLR
and initialize INT 00h-1Fh according to INT_TBL
1E Reserved
1F Re-initial KB Re-init KB
20 Reserved
21 HPM init If support HPM, HPM get initialized here
22 Reserved
23 Test CMOS Interface
and battery Status
24 Reserved
Verifies CMOS is working correctly, detects bad battery. If failed,
load CMOS defaults and load into chipset
AIMB-250 User’s Manual
97
AIMB-250 Series
Code (hex) Name Description
25 Reserved
26 Reserved
27 KBC final Init Final Initial KBC and setup BIOS data area
28 Reserved
29 Initialize Video Interface Read CMOS location 14h to find out type of video in use. Detect
and Initialize Video Adapter.
2A Reserved
2B Reserved
2C Reserved
2D Video memory test Test video memory, write sign-on message to screen. Setup
shadow RAM - Enable shadow according to Setup.
2E Reserved
2F Reserved
30 Reserved
31 Reserved
32 Reserved
33 PS2 Mouse setup Setup PS2 Mouse and reset KB
34 Reserved
35 Test DMA Controller 0 Test DMA Controller 0
36 Reserved
37 Test DMA Controller 1 Test DMA Controller 1
38 Reserved
39 Test DMA Page
Registers
3A Reserved
3B Reserved
3C Test Timer Counter 2 Test 8254 Timer 0 Counter 2.
3D Reserved
3E Test 8259-1 Mask Bits Verify 8259 Channel 1 masked interrupts by alternately turning off
Test DMA Page Registers.
and on the interrupt lines.
3F Reserved
40 Test 8259-2 Mask Bits Verify 8259 Channel 2 masked interrupts by alternately turning off
and on the interrupt lines.
41 Reserved
42 Reserved
98 AIMB-250 Series User’s Manual
Code (hex) Name Description
User’s Manual
43 Test Stuck 8259's
Interrupt Bits
Test 8259 Interrupt
Functionality
44 Reserved
45 Reserved
46 Reserved
47 Set EISA Mode If EISA non-volatile memory checksum is good, execute EISA
48 Reserved
49 Size Base and
Extended Memory
4A Reserved
4B Reserved
4C Reserved
4D Reserved
Turn off interrupts then verify no interrupt mask register is on.
Force an interrupt and verify the interrupt occurred.
initialization. If not, execute ISA tests an clear EISA mode flag.
Size base memory from 256K to 640K and extended memory
above 1MB.
4E Test Base and
Extended Memory
4F Reserved
50 USB init Initialize USB controller
51 Reserved
52 Memory Test Test all memory of memory above 1MB using Virtual 8086 mode,
53 Reserved
54 Reserved
55 CPU display Detect CPU speed and display CPU vendor specific version
56 Reserved
57 PnP Init Display PnP logo and PnP early init
58 Reserved
Test base memory from 256K to 640K and extended memory
above 1MB using various patterns.
NOTE: This test is skipped in EISA mode and can be skipped
with ESC key in ISA mode.
page mode and clear the memory
string and turn on all necessary CPU features
59 Setup Virus Protect Setup virus protect according to Setup
5A Reserved
5B Awdflash Load If required, will auto load Awdflash.exe in POST
5C Reserved
5D Onboard I/O Init Initializing onboard superIO
AIMB-250 User’s Manual
99
AIMB-250 Series
Code (hex) Name Description
5E Reserved
5F Reserved
60 Setup enable Display setup message and enable setup functions
61 Reserved
62 Reserved
63 Initialize & Install
Mouse
64 Reserved
65 PS2 Mouse special Special treatment to PS2 Mouse port
66 Reserved
67 ACPI init ACPI sub-system initializing
68 Reserved
69 Setup Cache Controller Initialize cache controller.
6A Reserved
6B Setup Entering Enter setup check and auto- configuration check up
6C Reserved
6D Initialize Floppy Drive &
Controller
6E Reserved
6F FDD install Install FDD and setup BIOS data area parameters
70 Reserved
Detect if mouse is present, initialize mouse, install interrupt
vectors.
Initialize floppy disk drive controller and any drives.
71 Reserved
72 Reserved
73 Initialize Hard Drive &
Controller
74 Reserved
75 Install HDD IDE device detection and install
76 Reserved
77 Detect & Initialize
Serial/Parallel Port
78 Reserved
79 Reserved
7A Detect & Initialize Math
Coprocessor
7B Reserved
7C HDD Check for Write
protection
Initialize hard drive controller and any drives.
Initialize any serial and parallel ports (also game port).
Initialize math coprocessor.
HDD check out
100 AIMB-250 Series User’s Manual
