Adesso E10 User Manual

www.adesso.com

TM

iMouse E10

2.4GHz RF Wireless Vertical Ergonomic Mouse

40

120 mm

30

76 mm

With 2.4 GHz Radio Frequency technology, the Adesso
iMouse E10 can provide you with wireless convenience and

TM

the freedom of a smooth connection without tangled cables
for up to a 30-foot range.

The special ergonomic vertical design with a soft rubber grip
offers a unique and comfortable user experience. Three
convenient buttons on the side allow intuitive control for faster
back and forward browsing navigation. Plus there are three
levels of DPI (1000/1500/2000) available.

An On/Off switch helps to conserve battery power, and an
indicator light lets you know when it is time to replace your
batteries. iMouse E10 comes with a mini USB receiver that

TM

connects automatically without any hassle.

2.4 GHz RF Wireless Technology with On/Off Switch

This mouse works at any angle with a range of up to 30 ft.
with no wires to get tangled. The On/Off switch helps
conserve battery power plus the low battery indicator helps
you know when it is time to change batteries.

Ergonomic Vertical Design

The vertical design provides better support for your forearm
minimizing wrist pain that can come from twisting.

Adjustable DPI Switch and Back/Forward Buttons

Switch DPI easily from 1000 to 2000, and access to back/
forward navigation shortcut without driver.

Plug-and-Play

Simply plug the mini USB receiver into a USB port and you
will be up and running. No drivers required, works with
Windows or Mac OS.

20

76 mm

2.4GHz RF Wireless
Technology

Vertical Ergonomic

Specifications:

Tracking Method
Connectivity
Range
DPI Resolution
Buttons

Hand Orientation
Power
Dimensions
Weight

Requirements:

Operating System

Connectivity Interface

Includes:

Adesso iMouse E10

TM

USB Wireless Receiver
AAA Batteries
Quick Start Guide

Shipping Information:

Item UPC Code

TM

iMouse E10 783750006132

63 mm

20

63 mm

1600800

Design

Adjustable
DPI Switch

Optical Sensor

2.4 GHz RF Wireless Technology
30 ft. (10m)
3 Levels (1000/1500/2000)
6 Buttons (Left & Right Click, Back & Forward,
DPI Switch, Scroll Wheel and Middle Button)
Right
AAA Batteries

3.0” x 4.7“ x 2.5” (75 x 120 x 63mm)

0.3 lb. (113g)

Windows
Mac

® 8 / 7 / Vista / XP / 2000

® OS X 10.4 & above

USB Port for Wireless Receiver

Package Dimensions

7.9” x 4.0” x 2.2”

Package Weight

0.5 lb.

76 mm

Back/Forward

Buttons

Qty/Carton

10/40

Windows 8

Compatible
