DashDrive Air AV200
Quick Guide
01 English
06 Français
11 Italiano
16 Deutsch
21 Español
26 Português
31 рускi
36
41
46
DashDrive Air AV200 Quick Guide
1. AV200 Introduction
Battery level indicator
(Green/ Orange) Data access LED (Green)
Wireless On/Off indicator (Blue)
Battery charge LED (Red)
SD Slot
Power On / Off Switch:
On: Enable Wi-Fi mode Off: Charging & USB Card Reader Mode
USB Slot
Mini-USB
LAN connector
RJ-45
Reset
P1
2. Default Settings
IP address |
10.10.1.1 |
Subnet mask |
255.255.255.0 |
Username |
OFF |
Password |
OFF |
Operation Mode |
Gateway |
IP(DHCP) |
Server Mode |
SSID |
DashDrive Air |
Channel |
Auto |
Security |
OFF |
|
|
3.Charging
i.To charge the embedded battery, connect the cable to the AV200’s mini-USB port and to your PC/Notebook or USB wall adapter.
ii.When charging is done, the red LED indicator will turn off.
4.How to configure access point for first time
(The following screenshot is from an iOS mobile device)
i.Connect a RJ45 Ethernet cable to the AV200, power on the AV200 and wait about 35 seconds.
ii.Open your mobile device’s wireless network settings, select the wireless access point DashDrive Air_XXXXXX, and click connect.
iii.Determine the mobile device to connect to the AV200, and start the web browser.
iv.Enter: http://10.10.1.1/ in URL-address.
v.Click “Settings” at the upper-right corner and then click “Gateway”.
P2
vi.Refer to the following screen and click “Next”.
vii. LAN Interface Setup
This stage is to set up the parameters for local area network connected to the AV200. To use the storage function of AV200, it is not necessary to update the IP address and subnet mask. Please click “Next” directly.
viii. WAN Interface Setup
Select PPPoE for ADSL on WAN interface. Set the User Name and Password, then click “Next”. If there is no network for connecting WAN Port of AV200, keep it in “DHCP Client” and click “Next” directly to
skip it.
P3
ix.Wireless Basic Settings for different SSID. If you don’t want to change, just click “Next“directly.
x.Wireless Security Setting
Turning on the AV200 security will prevent any unauthorized access to the wireless network and storage device. After updating it, click “Finished” and wait around 20 seconds to access your New SSID.
5.How to transfer files with the AV200
i.Open your mobile device’s wireless network settings, select the wireless access point DashDriverAir_XXXXXX, and click connect.
ii.Plug the USB Flash drive or SD card into the AV200 and turn on. Wait about 35 seconds, until the Blue LED starts flashing.
iii.For iOS users: Go to the Apple Store, and download the free DashDrive Air application. After installation is complete, use this application to transfer files.
P4
iv.For users of other operating systems:
Open the web browser, and input the DashDrive Air IP address (factory default is http://10.10.1.1/)
Click DashDrive Air to browse and download files from the USB flash drive or memory card.
To upload files from your device to a USB Flash drive or memory card, use the upload function shown at the bottom of the page.
For repeater mode and more detailed information, please visit the ADATA website www.adata-group.com
P5
DashDrive Air AV200 Mode de L’emploi
1.Présentation AV200
LED PWR Alimentation |
|
(Vert/ Orange) |
LED Accès (Vert) |
|
LED Wi-Fi(Bleu)
Statut de la batterie en LED (Rouge)
Fente
Interrupteur d'alimentation à glissière :
ON: Activer le mode Wi-Fi OFF: Mode de charge et lecteur de carte SD
ou clé USB Fente USB
Fente Mini-USB
WAN RJ-45
Réinitialiser
P6
2. Paramètres par défaut
Adresse IP |
10.10.1.1 |
Masque de sous-réseau |
255.255.255.0 |
Nom d'utilisateur |
Désactivé |
Mot de passe |
Désactivé |
Mode d'utilisation |
Passerelle |
IP(DHCP) |
Mode Serveur |
SSID |
DashDrive Air |
Canal |
Auto |
Sécurité |
Désactivé |
3.Comment démarrer le lecteur et charger
i.Pour charger la batterie intégrée, connectez le câble au port mini-USB sur AV200 et à votre PC/ordinateur portable ou adaptateur mural USB.
ii.Lorsque la charge est terminée, la LED rouge s'éteint.
4.Comment configurer un point d'accès pour la première fois(La capture d’ écran ci-dessous vient d’un appareil iOS mobile)
i.Connectez un câble Ethernet RJ45 au AV200, allumez le lecteur WiFi et attendez pendant 35 secondes.
ii.Ouvrez les paramètres de wifi sur votre appareil mobile, selectionnez le point d’accès « DashDrive Air_XXXXXX », puis cliquez sur la connexion.
iii.Déterminez l'appareil mobile de se connecter à l'AV200, et démarrez le navigateur Web.
iv.Entrez: http://10.10.1.1/ dans l'adresse URL.
v.Cliquez sur “Settings”
(Paramètres) à l'angle supérieur |
|
droit, puis cliquez sur “Gateway” |
|
(Passerelle). |
P7 |
|
vi. Reportez-vous à |
|
|
ix. Paramètres de base |
|
l'écran suivant et |
|
|
sans fil pour |
|
cliquez sur “Next” |
|
|
différents SSID. Si |
|
(Suivant). |
|
|
vous ne voulez pas |
|
|
|
|
changer, il suffit de |
|
vii.Configuration de |
|
|
cliquer directement |
|
l'interface LAN |
|
|
sur “Next” (Suivant). |
|
Cette étape consiste à |
|
|
|
|
configurer les |
|
|
|
|
paramètres pour le |
|
|
|
|
réseau local connecté |
|
|
|
|
au AV200. Pour |
|
|
|
|
utiliser la fonction de |
|
|
|
|
stockage du AV200, |
|
|
|
|
vous n'avez pas |
|
|
|
|
besoin de mettre à |
|
|
x. Paramètre de |
|
jour les adresses IP et |
|
|
sécurité sans fil |
|
le masque de |
|
|
Le fait d'activer la |
|
sous-réseau. Cliquez |
|
|
sécurité du AV200 |
|
directement sur |
|
|
empêche tout accès |
|
|
|
non autorisé au |
|
|
“Next” (Suivant). |
|
|
|
|
|
|
réseau sans fil et au |
|
|
|
|
|
|
|
viii. Configuration de |
|
|
périphérique de |
|
|
|
stockage. Après sa |
|
|
l'interface WAN |
|
|
|
|
|
|
mise à jour, cliquez |
|
|
Sélectionnez PPPoE |
|
|
|
|
|
|
sur “Finished”. |
|
|
pour l'ADSL sur |
|
|
(Terminé) et attendez |
|
l'interface WAN. Le |
|
|
environ 20 secondes |
|
|
|
pour accéder à votre |
|
|
nom d'utilisateur et |
|
|
|
|
|
|
nouveau SSID. |
|
|
le mot de passe |
|
|
|
|
|
|
|
|
|
doivent être définis, |
|
|
|
|
|
|
5. Comment transférer des fichiers avec le AV200 |
|
|
puis cliquez sur |
|
|
|
|
"Suivant". S'il n'y a |
|
|
i. Ouvrez les paramètres de wifi sur votre appareil mobile, |
|
pas de réseau pour |
|
|
|
|
|
|
selectionnez le point d’accès « DashDrive Air_XXXXXX », puis |
|
|
connecter le port |
|
|
|
|
|
|
cliquez sur la connexion. |
|
|
WAN du AV200, |
|
|
|
|
|
|
ii. Inserez la clé USB ou la carte SD au AV200, allumez le pendant |
|
|
laissez-le dans |
|
|
|
|
|
|
35 secondes jusqu'à ce que le voyant bleu commence à clignoter. |
|
|
"Client DHCP" et |
|
|
iii. Pour les utilisateurs iOS: Allez à l'Apple Store et téléchargez |
|
cliquez sur “Next” |
|
|
l'application de DashDrive Air sans frais. Une fois l'installation |
|
(Suivant)directement |
|
|
terminée, utilisez cette application pour transférer des fichiers. |
|
|
|
|
|
|
pour l'ignorer. |
P8 |
|
P9 |
|
|
|
|
||
|
|
|
|
|
iv.Pour les utilisateurs d’ autres opérateurs:
Ouvrez le navigateur Web et entrez l'adresse IP DashDrive Air (http://10.10.1.1/ par défaut).
Cliquez DashDrive Air pour naviguer, puis téléchargez des fichiers à partir de la clé USB ou la carte SD.
Pour télécharger des fichiers de votre appareil à la clé USB ou la carte SD, utilisez la fonction de « upload » indiquant en bas de la page.
Pour le mode Répéteur et des informations plus détaillées,Visitez le site Web de ADATA www.adata-group.com
P10
DashDrive Air AV200 Guida introduttiva
1. Introduzione all'AV200
LED PWR
(verde/arancione) LED di accesso (verde)
LED Wi-Fi(blu)
LED carica batteria (rosso)
SD
Selettore ON/OFF:
ON: modalità Wi-Fi attivata OFF: caricamento e modalità lettore di schede USB
USB
Mini-USB
WAN RJ-45
Ripristina
P11
2. Impostazioni predefinite
Indirizzo IP |
10.10.1.1 |
Subnet mask |
255.255.255.0 |
Nome utente |
OFF |
Password |
OFF |
Modalità operativa |
Gateway |
IP(DHCP) |
Server Mode |
SSID |
DashDrive Air |
Canale |
Auto |
Sicurezza |
OFF |
3.Come avviare il lettore e ricaricare
i.Per ricaricare la batteria incorporata, collegare il cavo alla porta mini-USB del AV200 e al proprio PC/notebook o all'adattatore USB da parete.
ii.Quando il caricamento è stato completato, l'indicatore LED rosso si spegne.
4.Come configurare l'access point per la prima volta
(la seguente schermata è per un dispositivo mobile con sistema operativo iOS)
i.Collegare il cavo Ethernet RJ45 al AV200, accendere il AV200 e attendere circa 35 secondi.
ii.Aprire le impostazioni di rete wireless del proprio dispositivo mobile, selezionare l’access point wireless DaskDrive Air_XXXXXX, e cliccare su Connetti.
iii.Scegliere il dispositivo mobile da collegare all’AV200 e inizializzare il browser.
iv.Immettere: http://10.10.1.1/ nella barra dell'indirizzo.
v.Fare clic su “Settings” (impostazioni) nell'angolo superiore destro e scegliere “Gateway”.
P12
vi.Fare riferimento alla schermata seguente e fare clic su “Next” (avanti).
vii.Configurazione dell'interfaccia LAN
In questa fase si configurano i parametri della rete locale LAN connessa al AV200. Per utilizzare la funzione di archiviazione del AV200, non è necessario aggiornare l'indirizzo IP e la subnet mask. Fare clic su “Next” (avanti) direttamente.
viii.Configurazione dell'interfaccia WAN
Selezionare PPPoE for ADSL per l'interfaccia WAN. È necessario impostare il nome utente e la password, quindi fare clic su “Next”(avanti). Se non è presente alcuna rete per la connessione della porta WAN del AV200, impostare “DHCP Client” e fare clic su “Next” (avanti) direttamente per saltare il passaggio.
P13
ix.Configurazione wireless di base per un SSID differente. Se non si desidera effettuare questa modifica, è sufficiente scegliere direttamente “Next“ (avanti).
x.Configurazione della sicurezza wireless
Attivando la sicurezza del AV200 si eviterà l'accesso non autorizzato alla rete wireless e al dispositivo di archiviazione. Dopo aver effettuato l'aggiornamento, fare clic su “Finished” (completato) e attendere circa 20 secondi per accedere al nuovo SSID.
5.Trasferimento file con l’AV200
i.Aprire le impostazioni di rete wireless del proprio dispositivo mobile, selezionare access point wireless DashDriveAir_XXXXXX, e cliccare su connect.
ii.Collegare la chiavetta di memoria USB oppure la scheda SD nell’AV200 e accenderlo. Attendere circa 35 secondi, fino a quando il led blu inizia a lampeggiare.
iii.Per gli utenti iOS: scaricare gratuitamente l’applicazione DashDrive Air. Dopo che l’installazione e’ completa e’ possibile trasferire file.
P14
iv.Per utenti con altri sistemi operativi
il browser web e inserire l’indirizzo IP del DashDrive Air (per default http://10.10.1.1/) Cliccare su DashDrive Air to visualizzre e scaricare file dalla memoria USB o dalla scheda di memoria.
Per caricare file dal proprio dispositivo alla memoria USB o alla scheda di memoria, si utilizzi la funzione di upload mostrata a fondo pagina.
Per configurare la modalità Ripetitore e per informazioni più dettagliate,visitare il sito Web di ADATA all'indirizzo www.adata-group.com
P15
