AcuRite 06021 Instruction Manual

Display for 3-in-1 Weather Sensor

Package Contents

1. Display

2. Power Adapter

3. Instruction Manual

Instruction Manual

model 06021

This product requires an AcuRite 3-in-1 Weather Sensor

(sold separately) to be operational.

PRODUCT MUST BE REGISTERED

IMPORTANT

PRODUCT REGISTRATION

Register online to receive 1 year warranty protection

TO RECEIVE WARRANTY SERVICE

www.AcuRite.com

Questions? Contact Customer Support at

[phone] or visit www.AcuRite.com.

SAVE THIS MANUAL FOR FUTURE REFERENCE.

Features & Benets

AUTO DIM

23 22

1
2

3
4

5

6
7

8
9

10
11

12

Learning...

FRONT OF DISPLAY

1. Current Outdoor Temperature

Arrow icon indicates the direction the
temperature is trending.

2. Seasonal Information

Heat Index calculation displays when
temperature is 80°F (27°C) or higher.
Dew Point calculation displays when
temperature is 79°F (26°C) or below
Wind chill calculation displays when
temperature is 40°F (4°C) or lower.

3. Current Wind Speed

4. Average Wind Speed

Based on all wind speed readings
from the past 2 minutes.

5. 12 to 24 Hour Weather Forecast

Self-Calibrating Forecasting pulls data
from your sensor to generate your
personal forecast.

6. Storm Indicator

Indicates when barometric pressure drops.

7. Humidity Level Indicator

Indicates a high or low indoor humidity

21

20

19

18

17
16

15
14

13

level.

8. Current Indoor Temperature

Arrow icon indicates the direction the
temperature is trending.

9. TODAY Icon

Indicates today’s high/low records

are displayed.

10. Moon Phase

11. ALL-TIME Icon

Indicates all-time records are displayed.

12. Button

For momentary backlight and dimmer
settings.

13. AUTO DIM Indicator

Indicates display is in auto-dimming
brightness mode (page 5).

14. Intelli-Time® Clock

Automatically updates itself for Daylight
Saving Time.

15. Date

16. Display Low Battery Indicator

17. Current Indoor Humidity

Arrow icon indicates the direction
the humidity is trending.

18. Learning Mode Icon

Disappears after weather forecast
self-calibration is complete.

19. Barometric Pressure

Arrow icon indicates the direction the
pressure is trending.

20. Peak Wind Speed

Highest speed from past 60 minutes.

21. Sensor Low Battery Indicator

22. Current Outdoor Humidity

Arrow icon indicates the direction
the humidity is trending.

23. Outdoor Sensor Signal Strength

2

Features & Benets

1

2

3

4

10

9

5

6

BACK OF DISPLAY

1. Button

For setup preferences.

2. Button

ox

For setup preferences.

3. Button

For setup preferences.

4. Button

Press to access all-time high and low
records.

5. Intelli-Time® Battery Compartment

8

7

6. Plug-in for Power Adapter

7. Power Adapter

8. Backup Battery Compartment

9. Reset Button

Full reset to factory defaults.

10. A-B-C Switch

ID code that must match sensor’s A-B-C
switch to ensure units synchronize.

11. Battery Compartment Cover

(not shown)

3

SETUP

Display Setup

Set the A-B-C Switch

1

Locate the A-B-C switch inside

•

the battery compartment. Set
the A-B-C switch to A, B or C.
You must select the same letter
choices for both the display and
the sensor in order for the units
to synchronize.

Install or Replace Backup

2

Batteries (optional)

•

1. Remove the battery
compartment cover.

2. Insert 3 x AAA alkaline
batteries into the battery
compartment, as shown.

Follow the polarity (+/–)

diagram in the battery
compartment.

3. Replace the battery cover.

Plug in Power Adapter

3

For the best performance, plug

•

in the power adapter as the main
power source for this product.

A-B-C Switch

1

Set to match sensor

A B C

Install Backup Batteries (optional)

2

3 AAA batteries

Plug in Power Adapter

3

PLEASE DISPOSE OF OLD OR DEFECTIVE BATTERIES IN AN ENVIRONMENTALLY SAFE
WAY AND IN ACCORDANCE WITH YOUR LOCAL LAWS AND REGULATIONS.

used for an extended period of time. Follow the polarity (+/-) diagram in the battery compartment. Promptly remove dead batteries from the device. Dispose of used
batteries properly. Only batteries of the same or equivalent type as recommended are to be used. DO NOT incinerate used batteries. DO NOT dispose of batteries in fire,
as batteries may explode or leak. DO NOT mix old and new batteries or types of batteries (alkaline/standard). DO NOT use rechargeable batteries. DO NOT recharge
non-rechargeable batteries. DO NOT short-circuit the supply terminals.

BATTERY SAFETY: Clean the battery contacts and also those of the device prior to battery installation. Remove batteries from equipment that will not be

IMPORTANT: Batteries are
a backup power source to
preserve records in the event of
a power outage. Power adapter

is recommended as the primary
power source to enjoy the full
functionality of this product.
