Distributed by:
Atlantic Horizon International, Inc.
New York, New York
Model No. AH2058
USA Patent 6,039,746
USA Patent 5,534,003
www.ActiveForever.com
www.ActiveForever.com
INSTRUCTION GUIDE
T HE E ASY W AY TO R EMOVE
www.ActiveForever.com
U NWANTED H AIR
C ONTENTS
➤ Introduction 3
➤ The Magic behind e-PEN 4
➤ Hands Free Conductive Gel Pads 4
➤ Hair Growth Cycles 4
➤ Hair Removal Diagrams 5
➤ Effective use of e-PEN 5
➤ Product Key 6
➤ Important Pre -Treatment Notes 7
➤ How to use e-PEN 8
➤ Applications 9-12
➤ Your Questions Answered 12-13
➤ Technical Data 14
T HE Verseo
C ONTAINS:
➤ 1 Control Unit (ePEN wand)
➤ 2 x AA (MN 1500)
Alkaline Batteries
➤ Conductive Gel
➤ Cotton Buds/Q Tips
➤ Tweezers
➤ 1 x 3 Fold Soft Pouch
➤ 1 x Pad Set:
3 Rectangular Pad
2 Round Pad
1 Upper Lip
1 x Lead with 3 Pad
connectors
T HE V ERSEO E-PEN
www.ActiveForever.com
P ERMANENT H AIR R EMOVAL S YSTEM
At last the painless solution for permanent hair removal, (needle free).*
This unique product has many advanced features, which include skin-sensor, automatic
timer/buzzer, and LED indicator lights. Front of hand-held unit has an adjustable head
to ensure comfortable position when using cotton bud/Q tip treatment on face - ideal
for treating unwanted facial hair including eyebrows and upper lip.
Larger treatment areas simply plug in the set of Conductive Gel Pads provided. This
allows you hands free treatment of the upper lip, legs, arms, under arms and bikini line.
Ver seo e-PEN allows many hairs to be treated simultaneously. All types of hair
The
can be effectively removed forever.
As this amazing technology
is needle free. There is no
pain, scarring or pitting
associated with needle
electrolysis.
* Clinical trials carried out by a
leading, approved clinical research
laboratory confirmed that 39% of
hairs were removed permanently
over a 90 day period. Subjects were
administered 14 treatments of 20
second duration - total treatment
time of 5 minutes.
3
T HE M AGIC B EHIND E- PEN
www.ActiveForever.com
Apply conductive gel provided to treatment area. Insert cotton bud/Q tip into gold
cotton bud/Q tip holder. (If using double-ended cotton bud/Q tip, cut in half). Dip cotton
bud/Q tip into gel and apply to treatment area. Small pulses of completely safe electrical
energy pass through the gel on to the cotton bud/Q tip. When the cotton bud/Q tip is
applied to the treatment area, this energy passes through to the hair follicle. The water
and salt solution are then chemically changed to sodium hydroxide, which slowly
destroys the hair root and papilla. This allows for the painless and permanent removal
of the hair.
H ANDS F REE C ONDUCTIVE G EL P ADS
The pads work the same way as above. The self-adhesive pads also contain conductive
gel, ready for treatment. Simply apply the self-adhesive pads which are connected to
the main unit via a lead, slide the function button to
sit back and relax - The
NB: Read Page 8 - “How to use your e-PEN.”
Verseo e-PEN will do the rest.
FACE PAD or BODY PAD, then
H AIR G ROWTH C YCLES
To understand how hairs grow and how you can remove them permanently, there are
three things you need to know. First, a person has more than 500 of these follicles per
square inch. Each of these follicles are capable of growing a hair at any time. However,
less than 20% of them grow at the same time.
Second, the hair follicles grow in cycles. Since not all grow at the same time, there are
periods of rest for the follicles. During this rest period, the hair may remain in the follicle
for a long time or it may fall out. The follicle actually shrinks during the rest period and
the dermal papilla cells are separated from the bottom of the follicle. When the rest
period is over, the follicle grows down to meet the dermal papilla again, and the cells
start making another hair. This cycling of each follicle goes on for a lifetime.
For many of the hairs that are typically treated by permanent methods, the period of
active growth may only last for 2 weeks after you see the hair. As you will learn, it is vital
to treat these hairs within this 2 week period while they are still growing.
Third, it takes 8-12 weeks for a hair to grow from the base of the follicle to the surface
of the skin so you can see it. What this means is that even if you just tweeze a hair out,
you have to wait 8-12 weeks for the hair to grow again. Many people think if they tweeze
4
Hair Shaft
www.ActiveForever.com
Outer Skin Surface
or wax all the hairs from an area of
skin one day, and see hairs in the same
area the next week, that these are the
same hairs that have regrown. You
now know that this is impossible. The
hairs you see a week later in the same
area are from different hair follicles.
Follicle -
The elongated
casing that
encloses root
Remember needle electrolysis works
exactly on the same principle as
PEN PERMANENT HAIR REMOVAL
SYSTEM.
However, The Verseo e-
PEN PERMANENT HAIR REMOVAL
SYSTEM is needle free without the
pain, pitting and scarring that are the
common side effects of needle
electrolysis. Can be used safely and
Artery -
carries blood to
papilla
Dermal Papilla -
(Hair Root Cells)
contains cells
which generate hair
growth
effectively on all skin types.
E FFECTIVE U SE OF E-PEN
To effectively stop hair growth permanently, you must treat the hair in its growth cycle,
when the Dermal Papilla cells in the hair root are in their active phase. During the rest
period in the hair growth cycle, the Dermal Papilla cells retreat below the follicle so cannot
be treated.
When you first remove a hair or hairs,
you do not know which hairs are in
growth cycle or rest period. Only
when hairs re-appear are you sure
you can treat them permanently. You
have around 2 weeks of growth cycle
once a hair has appeared, to apply
effective treatment.
The process of Permanent hair
removal is not therefore instant.
You will need some patience, but will
be rewarded by less and less hairs reappearing after each treatment.
This diagram shows the electric pulse going all the way into the hair follicle
through the conductive gel, changing the chemical structure of the water
and salt solution to sodium hydroxide in the follicle.As a result the hair root
is destroyed allowing painless removal of the hair.
e-
5
3 - Fold Soft
www.ActiveForever.com
Pouch
E-Pen Pad Lead
P RODUCT K EY
E-Pen Control Unit
Conductive Gel
Conductive Pad
Set
Tweezers
Cotton Buds
Cotton Bud
Removable Q-Tip Holder
Green LED Indicator Light
Red LED Indicator Light
Gold Activator Button
E-Pen Pad Lead
6
I MPORTANT
www.ActiveForever.com
P RE-TREATMENT N OTES FOR THE E-PEN
P ERMANENT H AIR R EMOVAL S YSTEM
For successful treatment, please carry out the following:-
Facial Hair Remove all make up using your normal cleanser. The area to be
•
treated must be thoroughly clean, dry and non-greasy.
Body Hair Thoroughly cleanse the treatment area as above. You should cut
•
long hairs as short as possible with scissors or a razor before applying the
conductive gel treatment pad.
Please do not do the following:-
• DO NOT
• DO NOT use perfume or perfumed products prior to use
DO NOT use on open abrasions, inflamed skin or sunburnt areas
•
DO NOT use on hairs growing from moles at any time
•
DO NOT use on delicate areas such as eyelids, inner ear or nasal hair
•
DO NOT use during pregnancy or during first few days of menstruation
•
DO NOT use near varicose veins
•
DO NOT use the e-PEN without the conductive gel when using the
•
DO NOT exceed recommended treatment times
•
Do not use if you have any heart condition or use a heart pacemaker
e-PEN cotton bud/Q tips. Pads have their own conductive gel.
C ONDUCTIVE P ADS &CORD
The Verseo e-PEN has one main cord which plugs into the back of the unit. The
cord divides into 3 separate cap ends:
White Cap: Plugs into moustache or rectangular pad (active) i.e. treatment area.
Green Cap: Plugs into circular pad (non active)
White Cap: This is a spare lead to be used should you wish to treat two areas
Extra pads can be bought from Atlantic Horizon using the order form on page 15.
simultaneously i.e. leg area or under arm.
7
H OW TO U SE Y OUR E-PEN
www.ActiveForever.com
P ERMANENT H AIR R EMOVAL S YSTEM
F ACE T REATMENT
• Thoroughly clean treatment area as described on Pre-treatment (Page 7).
• Cut the cotton bud/Q tip in half and insert. The cotton bud/Q tip should sit against gold
ring with stem fully inserted.
•
Dip cotton bud/Q tip into the conductive gel making sure that gel also covers the gold
cotton bud/Q tip holder at the front of the control unit. Cotton bud should NOT now
fall out. This ensures that the cotton cotton bud/Q tip is fully conductive.
(See diagram 1)
• Hold e-PEN the following way (see diagram 2).
• Slide the switch to the
(Check red power light is on to confirm battery is working).
• When touching the treatment area, green
conductive light
must light up, if not put more conductive gel
onto cotton bud/Q tip and gold cotton bud/Q tip
holder.
PROBE position.
• PROBE
• OFF
• FACE PAD
• BODY PAD
• The Gold cotton bud/Q tip holder can be easily
removed for cleaning (see diagram opposite).
Simply insert nail between plastic and gold tip
holder, and pull out. Rinse in warm water to
remove surplus gel.
T REATMENT OF F INE F ACIAL H AIRS
Apply cotton bud/Q tip to treatment area, press activator gold button to commence 20
second treatment time. Touch gel with the cotton bud/Q tip. Green conductivity LED light
will come on. If you do not touch the gel continuously - the green conductivity light will go
out.
e-PEN automatically resets itself when good contact is made. The automatic timer
buzzes when the 20-second treatment time is finished and resets itself for the next
treatment. Once the gold button is released the conductivity stops. Repeat the process for
the next treatment area. Remove the treated hair with
Maximum Use: DO NOT EXCEED one 20 second treatment per day in one treatment area
- 2cm diameter. Maximum of 3 treatments per week in one treatment area.
e-PEN Tweezers provided.
8
Diagram 1
www.ActiveForever.com
Diagram 2
Upper lip and Face
Note: The diagrams on this page show one way to hold e-PEN. You may find it easier to hold like
a pen, still using finger on the button.
Bikini LineBreastsEyebrows
T REATMENT OF S INGLE H AIRS
W ITH e-PEN C OTTON BUD
Thoroughly clean area as before, cut only long hairs in the treatment area as short as possible. Dip cotton
bud/Q tip into gel so that both cotton bud/Q tip and gold cotton bud/Q tip holder are covered in gel (see
diagram 1). Apply
LED lights up to show conductivity. Keep activator button pressed until buzzer sounds and green LED
light goes out. GENTLY PULL hairs out with tweezers provided.
Maximum Use: DO NOT EXCEED one treatment per day in one treatment area - 2cm diameter.
Maximum of 3 treatments per week in one treatment area.
e-PEN to treatment area (as diagram 2), press gold activator button with finger, green
T REATMENT T IME P ATCH M ODE
FACE PAD MODE: Treatment time - 6 minutes (2.5 minutes on 1 minute rest, 2.5 minutes on).
BODY PAD MODE: Treatment time - 11 minutes (5 minutes on 1 minute rest, .5 minutes on).
continued ☞
9
NB: If skin becomes pink during first treatment, this is quite normal and will disappear
www.ActiveForever.com
after 30 minutes. repeat the treatment the following day. Successful treatment is
cumulative - the more you use the product, the better the results. DO NOT, however
exceed the maximum recommended use.
Facial Upper LIP (FACE PAD Mode)
➤ Thoroughly clean treatment area as before.
➤ Slide switch mode to OFF position.
➤ Insert lead into jack socket at
the end of
➤ Carefully apply upper lip pad
so that it adheres to the skin.
➤ Place the second circular pad on
either upper arm.
➤ Carefully push the white lead clip onto
the button on the upper lip pad.
➤ Carefully push the green lead cap onto the circular pad.
➤ Slide the pad button to the FACE PAD position.
➤ The red power light illuminates to show power on. The green
conductivity light illuminates to show good conductivity.
One beep sounds, the first stage of 5 minute treatment begins.
➤ After 2.5 minutes the green LED light will flash to indicate 1 minute rest period.
➤ After 1 minute, the green LED light remains on and one beep sounds to
indicate 2nd stage of treatment (2.5 minutes).
➤ Three beeps will sound to indicate end of treatment and green LED light will go out.
Slide mode switch to
➤ Remove hairs with e-PEN tweezers or if you prefer
your own tweezers.
➤ Carefully replace conductive pads onto the silicon backing sheet,
in order to preserve self-adhesive for next treatment.
Maximum Use: DO NOT EXCEED one treatment per day in one treatment area using
face pad. Maximum of 3 treatments per week in one treatment area.
e-PEN.
• PROBE
• OFF
• FACE PAD
• BODY PAD
T IP: Slight tingling sensation? This can be
reduced with thorough cleansing of treatment area.
• PROBE
• OFF
• FACE PAD
• BODY PAD
OFF.
• PROBE
• OFF
• FACE PAD
• BODY PAD
10
B ODY AND L EGS (BODY PAD Mode)
www.ActiveForever.com
➤ Slide mode switch to the OFF position.
➤ Thoroughly clean the treatment area.
➤ Cut any long hairs short.
➤ Place the rectangular shaped pad onto treatment area.
➤ Push white lead clip onto rectangular pad button.
➤ Place circular conductivity pad near the rectangular pad.
➤ Push on the green lead clip.
NB: Only the rectangular pad will give treatment. There are 2 white lead clips so you
can use 2 rectangular pads at the same time. See replacement pads section on
• PROBE
• OFF
• FACE PAD
• BODY PAD
page 7.
➤ Slide mode switch to BODY PAD position.
➤ Make sure the red power light comes on.
➤ The 10 minute treatment time begins. Repeat the process again
• PROBE
• OFF
• FACE PAD
• BODY PAD
so that complete treatment is 20 minutes.
NB: If skin becomes pink during first treatment, this is quite normal. Repeat the
ten minutes treatment the following day. Successful treatment is cumulative - the
more you use, the better the results. DO NOT however, exceed maximum
recommended use.
➤ Sit down and relax - read a book or watch TV.
➤ The green LED light comes on. After 5 minutes a beep will sound to indicate first
part of treatment is finished and the green LED light will flash to indicate 1 minute
rest period.
➤ Do not remove pads
➤ A beep will sound to indicate the start of the second stage of treatment (5 minutes).
➤ Three beeps indicate end of complete treatment and green LED light goes out.
➤ Slide mode switch to OFF.
➤ Carefully remove pads and stick them onto special silicon
plastic sheet provided.
➤ Remove hairs with e-PEN tweezers, or your own tweezers
• PROBE
• OFF
• FACE PAD
• BODY PAD
if you prefer.
➤ Repeat treatments until hair is permanently removed.
11
U NDER A RMS AND B IKINI L INE (BODY PAD Mode)
www.ActiveForever.com
Repeat as for legs.
The rectangular pad is to be located on the
treatment area. Clip on the white cap. The
circular pad is to be located close to the
rectangular pad. Clip on the green
cap. Remove hair with
or use your own tweezers.
Place the pads back onto
the silicon plastic sheet
provided.
Maximum Use: DO NOT EXCEED one treatment per day in one treatment area using
body pads. Maximum of 3 treatments per week in one treatment area.
e-PEN
• PROBE
• OFF
• FACE PAD
• BODY PAD
Y OUR Q UESTIONS A NSWERED
Will I achieve permanent hair removal?
In a word YES! Provided you thoroughly clean the treatment area with cleansing lotion
or alcohol-free soap wash and carefully follow the instructions given. Be patient, hair
grows in 8-12 week cycles. After 60 days with regular treatment, you will see positive
results.
Is the Verseo e-PEN as good as needle electrolysis?
Better, because it can treat many hairs at once. It is therefore faster. It is painless
because E-PEN is non-invasive. There are no side effects such as pitting or scarring
caused by needle electrolysis. It is easier because anyone can use it. Needle electrolysis
works but requires a fully qualified professional beautician to administer the treatment.
The Verseo e-PEN is the safe and painless way to permanent hair removal.
I have dark skin - Can I use it?
You may use e-PEN on any skin type, black, brown, yellow or white. It does not scar
black skin which needle electrolysis can.
12
Is The Verseo e-PEN really painless?
www.ActiveForever.com
Yes. All you feel is a slight tingling sensation when you use it on your face. Apply more
gel to reduce this. Metal teeth fillings sometimes react to the treatment and you may
experience a slight metallic taste which only lasts for a short time. This is quite normal.
Occasionally your skin will turn pink around the treatment area. This again is normal and
will disappear in a short time.
The red light will not go on?
This normally indicates the 2 x AA (MN 1500) alkaline batteries need replacing.
The green conductivity light will not go on?
Poor conductivity maybe due to treatment area not being clean, or insufficient gel. Make
sure your finger is damp when touching the gold probe button when touching the hair -
this helps conductivity. Make sure the cotton bud/Q tip is thoroughly damp and pushed
firmly into the control unit so that the cotton touches the gold metal ring.
Check the red power light is on, if not the batteries need replacing.
What causes excessive hair growth?
A number of conditions. Hormonal changes, stress, menopause, puberty, medication or
hereditary conditions. These can all influence hair growth.
After treatment
If the skin is spotty, try a non-greasy antiseptic cream.
After treatment make up
Simply follow your normal beauty and make up routines after treatment.
13
G ENERAL I NFORMATION
www.ActiveForever.com
The conductive and adhesive pads should last for up to 8 treatments. To order more
pads or gel, please fill in the order form opposite or telephone on 562-948-1114.
e-PEN ‘wand’ can be cleaned using a damp cloth or sponge. Do not immerse in
The
water.
Use 2 x AA (MN 1500) alkaline batteries only. If the red LED light won’t come on this
generally means the batteries need replacing.
T ECHNICAL D ATA
Model No: AH2058
Input Voltage: 2 x AA alkaline batteries
Oscillation Frequency: 0.7Ma maximum
Output Voltage: 23 volts maximum
Complies to: EN50081 - 1 1992
Conforms to: EMC Regulations
(Electro-Magnetic Compatibility Directive 89/336 EEC)
If the unit is damaged, please call our hotline: 562-948-1114 for return authorization
code. Do not tamper with wires or attempt to open control unit.
The Verseo e-PEN is guaranteed for one year against original factory faults in
material and workmanship. If repairs are necessary as a result of accident or misuse this
is not included in our guarantee.
Important: This undertaking is in addition to consumer’s statutory rights and does not
affect those rights in any way.
The Verseo e-PEN is manufactured under license in China to the exclusive USA
design of
is protected by two US Patents).
R EPAIRS &SERVICES
G UARANTEE
ATLANTIC HORIZON INTERNATIONAL, INC., New York, New York (This product
14
Loading...
