Activeforever Pocket Talker Ultra System User Manual
Pocketalker
®
Ultra
Personal Amplifier • Model PKT D1
Pocketalker®Ultra
Personal Amplifier • Model PKT D1
©2006, Williams Sound Corp. MCAT
033C 1
NOTE: SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE!
Description:
The Pocketalker Ultra amplifies sound clearly and easily for better understanding. 100 hours of battery life ensures long-lasting performance. Each Pocketalker Ultra includes a plug-in sensitive microphone; and for the TV listener: a TV listening extension cord. Use the Pocketalker Ultra with a variety of available earphones and headphones of your choice, or, a neckloop and a telecoil-equipped
hearing aid. With the optional Telelink adapter, listeners can use the Pocketalker Ultra to amplify
telephone calls to a comfortable listening level.
Applications:
• 1-on-1 Conversations • TV Listening • Listening in the Car • Small Groups and much more
Dimensions: 3.38"L x 2.23"W x .88" THK. (85.8mm x 56.6mm x 22.3 mm)
(Not including belt clip or microphone assembly)
Weight: 2.5 oz. (70.9 grams) (with batteries and microphone)
Color/material: Silver gray, ABS/Polycarbonate molded plastic case.
Battery Type: Two 1.5V (AAA size) alkaline
Battery Life: 100 hours (typical usage)
Low Battery Indicator: Red light on top panel flashes.
Microphone: Omnidirectional, electret microphone assembled in housing
with foam wind screen and 3.5mm mono plug.
Tone Control: External rotary control knob to allow user to optimize hearing.
Volume Control: External rotary control knob with power ON-OFF switch.
Microphone Jack: 3.5 mm, mono, gold plated mini plug.
Headphone Jack: 3.5 mm, mono, nickel plated mini plug.
Accessories included: Belt clip: Allows the user to wear the unit on a belt.
Lanyard: Allows the user to wear around the neck.
TV listening extension cord: extends the microphone to 12 ft.
Options: Unit comes packaged with one of the Williams Sound options:
Mini earphone, single (EAR 013)
Dual mini earbud (EAR 014)
Wide range earphone; single (EAR 008)
Lightweight headphone (HED 021)
Wide range headphone (HED 026)
Induction neck loop (NKL 001)
Approvals: CE, RoHS, WEEE
Warranty: 5 years, parts and labor (90 days on accessories)
Electrical Specifications (1k Hz ref.): Power output: 50 mW (max) into 16 ohms
AGC: Limits maximum output level
Distortion: 2% THD (max)
Frequency Response: Tone at high position: 11dB boost at 5kHz, 8dB cut at 400 Hz.
Tone at mid position: 0dB boost at 5kHz, 4dB cut at 400Hz.
Tone at low position: 3dB cut at 5kHz, 4dB boost at 400 Hz.
PKT D1 Personal Amplifier:
PKT D1 Top
Mic
Jack
(3.5mm)
Earphone
Jack
Power
On/Off
Indicator
Belt Clip
TM
Pocketalker
PKT D1 Front
Lanyard
Connection
Tone
Control
Plug-in
Mic
Volume
Control
www.ActiveForever.com
Pocketalker
®
Ultra
Personal Amplifier • Model PKT D1
Pocketalker®Ultra
Personal Amplifier • Model PKT D1
©2006, Williams Sound Corp. MCAT
033C 2
Test Tone High Tone Mid Tone Low
SSPL90 121.4 dB 120.6 dB 120.1 dB
HF Ave (SSPL90) 119.3 dB 118.9 dB 118.4 dB
HF Ave full on gain (50 dB) 39.3 dB 36.5 dB 32.3 dB
Reftest gain 39.5 dB 36.7 dB 32.3 dB
Test Tone High Tone Mid Tone Low
SSPL90 121.8 dB 122.0 dB 122.5 dB
HF Ave (SSPL90) 120.9 dB 120.5 dB 119.3 dB
HF Ave full on gain (50 dB) 41.9 dB 38.9 dB 33.9 dB
Ref test gain 42.2 dB 39.1 dB 34.0 dB
Test Tone High Tone Mid Tone Low
SSPL90 120.9 dB 120.7 dB 120.9 dB
HF Ave (SSPL90) 116.7 dB 116.5 dB 116.2 dB
HF Ave full on gain (50 dB) 37.3 dB 34.8 dB 30.8 dB
Ref test gain 37.6 dB 35.0 dB 30.9 dB
Test Tone High Tone Mid Tone Low
SSPL90 123.5 dB 123.5 dB 123.5 dB
HF Ave (SSPL90) 117.8 dB 117.7 dB 117.5 dB
HF Ave full on gain (50 dB) 38.6 dB 36.5 dB 32.7 dB
Ref test gain 39.4 dB 37.1 dB 33.1 dB
Note: The Pocketalker®Ultra is not sold, advertised or intended for use as a personal hearing aid. Williams Sound recommends that any individual experiencing hearing loss be examined by a physician/audiologist to determine the cause
before using this device.
Acoustic Specifications: Typical values (ANSI S3.22-1987)
Lightweight headphone, HED 021: (with 6cc coupler)
Wide range headphone, HED 026: (with 6cc coupler)
Wide range earphone, EAR 008: (with 6cc coupler)
Mini earphone single, EAR 013: (with 2cc coupler)
Test Tone High Tone Mid Tone Low
SSPL90 120.8 dB 120.9 dB 121.1 dB
HF Ave (SSPL90) 109.1 dB 109.0 dB 108.9 dB
HF Ave full on gain (50 dB) 30.3 dB 28.4 dB 25.3 dB
Ref test gain 31.0 dB 28.7 dB 24.8 dB
Dual mini earphone, EAR 014: (with 2cc coupler)
NOTE: SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE!
www.ActiveForever.com
