Acer LCD Monitor
User Guide
Copyright © 2015. Acer Incorporated.
All Rights Reserved.
Acer LCD Monitor User Guide
Original Issue: 4/2015
English
Changes may be made periodically to the information in this publication without obligation to notify
any person of such revisions or changes. Such changes will be incorporated in new editions of this
manual or supplementary documents and publications. This company makes no representations or
warranties, either expressed or implied, with respect to the contents hereof and specifically disclaims
the implied warranties of merchantability or fitness for a particular purpose.
Record the model number, serial number, purchase date and place of purchase information in the
space provided below. The serial number and model number are recorded on the label affixed to
your computer. All correspondence concerning your unit should include the serial number, model
number and purchase information.
No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any
form or by any means, electronically, mechanically, by photocopy, recording or otherwise, without
the prior written permission of Acer Incorporated.
Acer LCD Monitor User Guide
Model number: __________________________________
Serial number: ___________________________________
Date of purchase: ________________________________
Place of purchase: ________________________________
Acer and the Acer logo are registered trademarks of Acer Incorporated. Other companies’ product
names or trademarks are used herein for identification purposes only and belong to their respective
companies.
Information for your safety and
comfort
Safety instructions
Read these instructions carefully. Keep this document for future reference. Follow all
warnings and instructions marked on the product.
Special notes on LCD monitors
The following are normal with the LCD monitor and do not indicate a problem.
• Due to the nature of the fluorescent light, the screen may flicker during initial
use. Turn off the power switch and then turn it on again to make sure the flicker
disappears.
• You may find slightly uneven brightness on the screen depending on the desktop
pattern you use.
• The LCD screen has 99.99% or more effective pixels. It may include blemishes of
0.01% or less such as a missing pixel or pixel lit all the time.
• Due to the nature of the LCD screen, an afterimage of the previous screen may
remain after switching the image, when the same image is displayed for hours. In this
case, the screen is recovered slowly by changing the image or turning off the power
switch for a few hours.
English
Cleaning your monitor
Please carefully follow these guidelines when cleaning the monitor:
• Always unplug the monitor before cleaning.
• Use a soft cloth to wipe the screen and cabinet front and sides.
iii
Accessibility
Be sure that the power outlet you plug the power cord into is easily accessible and
located as close to the equipment operator as possible. When you need to disconnect
power from the equipment, be sure to unplug the power cord from the electrical outlet.
English
Safe listening
To protect your hearing, follow these instructions.
• Gradually increase the volume until you can hear it clearly and comfortably and
without distortion.
• After setting the volume level, do not increase it after your ears have adjusted.
• Limit the amount of time listening to music at high volume.
• Avoid turning up the volume to block out noisy surroundings.
• Turn the volume down if you can’t hear people speaking near you.
Warnings
• Do not use this product near water.
• Do not place this product on an unstable cart, stand or table. If the product falls, it
could be seriously damaged.
• Slots and openings are provided for ventilation to ensure reliable operation of the
product and to protect it from overheating. These openings must not be blocked
or covered. The openings should never be blocked by placing the product on a bed,
sofa, rug or other similar surface. This product should never be placed near or over
a radiator or heat register, or in a built-in installation unless proper ventilation is
provided.
• Never push objects of any kind into this product through cabinet slots as they may
touch dangerous voltage points or short-out parts that could result in a fire or
electric shock. Never spill liquid of any kind onto or into the product.
• To avoid damage of internal components and to prevent battery leakage, do not
place the product on a vibrating surface.
• Never use it under sporting, exercising, or any vibrating environment which will
probably cause unexpected short current or damage internal devices.
• The adapter is only used for this monitor, do not be used for other purposes.
• Your device uses one of the following power supplies:
Manufacture: DELTA:ADP-135KB-T(19V/135W)
Using electrical power
• This product should be operated from the type of power indicated on the marking
label. If you are not sure of the type of power available, consult your dealer or local
power company.
• Do not allow anything to rest on the power cord. Do not locate this product where
iv
people will walk on the cord.
• If an extension cord is used with this product, make sure that the total ampere rating
of the equipment plugged into the extension cord does not exceed the extension
cord ampere rating. Also, make sure that the total rating of all products plugged into
the wall outlet does not exceed the fuse rating.
• Do not overload a power outlet, strip or receptacle by plugging in too many devices.
The overall system load must not exceed 80% of the branch circuit rating. If power
strips are used, the load should not exceed 80% of the power strip’s input rating.
• This product’s power cord is equipped with a three-wire grounded plug. The
plug only fits in a grounded power outlet. Make sure the power outlet is properly
grounded before inserting the power cord plug. Do not insert the plug into a nongrounded power outlet. Contact your electrician for details.
Warning! The grounding pin is a safety feature. Using a power
outlet that is not properly grounded may result in electric
shock and/or injury.
Note: The grounding pin also provides good protection from
unexpected noise produced by other nearby electrical devices that
may interfere with the performance of this product.
• Use the product only with the supplied power supply cord set. If you need to
replace the power cord set, make sure that the new power cord meets the following
requirements: detachable type, UL listed/CSA certified, type SPT-2, rated 7 A 125 V
minimum, VDE approved or its equivalent, 4.6 meters (15 feet) maximum length.
English
Product servicing
Do not attempt to service this product yourself, as opening or removing covers may
expose you to dangerous voltage points or other risks. Refer all servicing to qualified
service personnel.
Unplug this product from the wall outlet and refer servicing to qualified service
personnel when:
• the power cord or plug is damaged, cut or frayed
• liquid was spilled into the product
• the product was exposed to rain or water
• the product has been dropped or the case has been damaged
• the product exhibits a distinct change in performance, indicating a need for service
• the product does not operate normally after following the operating instructions
v
Note: Adjust only those controls that are covered by the operating
instructions, since improper adjustment of other controls may result in damage
and will often require extensive work by a qualified technician to restore the
product to normal condition.
English
Potentially explosive environments
Switch off your device in any area with a potentially explosive atmosphere and obey all
signs and instructions. Potentially explosive atmospheres include areas where you would
normally be advised to turn off your vehicle engine. Sparks in such areas could cause
an explosion or fire resulting in bodily injury or even death. Switch off the device near
gas pumps at service stations. Observe restrictions on the use of radio equipment in fuel
depots, storage and distribution areas; chemical plants; or where blasting operations are
in progress. Areas with a potentially explosive atmosphere are often, but not always,
marked. They include below deck on boats, chemical transfer or storage facilities,
vehicles using liquefied petroleum gas (such as propane or butane), and areas where the
air contains chemicals or particles such as grain, dust or metal powders.
Additional safety information
Your device and its enhancements may contain small parts. Keep them out of the reach
of small children.
IT Equipment Recycling Information
Acer is strongly committed to environmental protection and views recycling, in the form
of salvaging and disposal of used equipment, as one of the company’s top priorities in
minimizing the burden placed on the environment.
We at Acer are very conscious of the environmental effects of our business and strive to
identify and provide the best working procedures to reduce the environmental impact
of our products.
For more information and help when recycling, please go to this website:
http://www.acer-group.com/public/Sustainability/sustainability01.htm
Visit www.acer-group.com for further information on the features and benefits of our
other products.
Disposal instructions
Do not throw this electronic device into the trash when discarding. To minimize
pollution and ensure utmost protection of the global environment, please recycle.
For more information on the Waste from Electrical and Electronics Equipment
(WEEE) regulations, visit http://www.acer-group.com/public/Sustainability/
sustainability01.htm
vi
LCD pixel statement
The LCD unit is produced with high-precision manufacturing techniques. Nevertheless,
some pixels may occasionally misfire or appear as black or red dots. This has no effect on
the recorded image and does not constitute a malfunction.
This product has been shipped enabled for power management:
• Activate display’s Sleep mode within 15 minutes of user inactivity.
• Activate computer’s Sleep mode within 30 minutes of user inactivity.
• Wake the computer from Sleep mode by pushing the power button.
Tips and information for comfortable use
Computer users may complain of eyestrain and headaches after prolonged use. Users are
also at risk of physical injury after long hours of working in front of a computer. Long
work periods, bad posture, poor work habits, stress, inadequate working conditions,
personal health and other factors greatly increase the risk of physical injury.
Incorrect computer usage may lead to carpal tunnel syndrome, tendonitis, tenosynovitis
or other musculoskeletal disorders. The following symptoms may appear in the hands,
wrists, arms, shoulders, neck or back:
• numbness, or a burning or tingling sensation
• aching, soreness or tenderness
• pain, swelling or throbbing
• stiffness or tightness
• coldness or weakness
English
If you have these symptoms, or any other recurring or persistent discomfort and/or pain
related to computer use, consult a physician immediately and inform your company’s
health and safety department.
The following section provides tips for more comfortable computer use.
Finding your comfort zone
Find your comfort zone by adjusting the viewing angle of the monitor, using a footrest,
or raising your sitting height to achieve maximum comfort. Observe the following tips:
• refrain from staying too long in one fixed posture
• avoid slouching forward and/or leaning backward
vii
• stand up and walk around regularly to remove the strain on your leg muscles
Taking care of your vision
Long viewing hours, wearing incorrect glasses or contact lenses, glare, excessive room lighting,
poorly focused screens, very small typefaces and low-contrast displays could stress your eyes. The
following sections provide suggestions on how to reduce eyestrain.
English
Eyes
• Rest your eyes frequently.
• Give your eyes regular breaks by looking away from the monitor and focusing on a istant point.
• Blink frequently to keep your eyes from drying out.
Display
• Keep your display clean.
• Keep your head at a higher level than the top edge of the display so your eyes point
downward when looking at the middle of the display.
• Adjust the display brightness and/or contrast to a comfortable level for enhanced
text readability and graphics clarity.
• Eliminate glare and reflections by:
• placing your display in such a way that the side faces the window or any light
source
• minimizing room light by using drapes, shades or blinds
• using a task light
• changing the display’s viewing angle
• using a glare-reduction filter
• using a display visor, such as a piece of cardboard extended from the display’s top
front edge
• Avoid adjusting your display to an awkward viewing angle.
• Avoid looking at bright light sources, such as open windows, for extended periods of
time.
Developing good work habits
Develop the following work habits to make your computer use more relaxing and
productive:
• Take short breaks regularly and often.
• Perform some stretching exercises.
• Breathe fresh air as often as possible.
• Exercise regularly and maintain a healthy body.
viii
X34
X34 xxxxxx;
English
Apr.10,2015
ix
English
Acer America Corporation
333 West San Carlos St., San Jose
Suite 1500
CA 95110, U. S. A.
Tel : 254-298-4000
Fax : 254-298-4147
www.acer.com
Federal Communications Commission
Declaration of Conformity
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
The following local Manufacturer /Importer is responsible for this declaration:
Product: LCD Monitor
Model Number: ;
SKU Number: ; xxxxxx
(“x” = 0~9, a ~ z, or A ~ Z)
Name of Responsible Party: Acer America Corporation
Address of Responsible Party:
333 West San Carlos St.
Suite 1500
San Jose, CA 95110
U. S. A.
Contact Person: Acer Representative
Phone No.: 254-298-4000
Fax No.: 254-298-4147
x
Information for your safety and comfort iii
Safety instructions iii
Special notes on LCD monitors iii
Cleaning your monitor iii
Accessibility iv
Safe listening iv
Warnings iv
Using electrical power iv
Product servicing v
Potentially explosive environments vi
Additional safety information vi
IT Equipment Recycling Information vi
Disposal instructions vi
LCD pixel statement vii
Tips and information for comfortable use vii
Finding your comfort zone vii
Taking care of your vision viii
Developing good work habits viii
Declaration of Conformity ix
Federal Communications Commission Declaration of
Conformity x
Unpacking 1
Attaching the base (for selected models) 2
Screen position adjustment 3
Connecting the adapter and AC Power cord 3
Power saving 3
Display Data Channel (DDC) 4
Connector pin assignment 4
19-pin color display signal cable
20-pin color display signal cable
English
Contents
4
4
Standard timing table 6
Installation 7
Users controls 8
Panel controls 8
Using the Shortcut Menu
The Function page
10
12
Troubleshooting 18
HDMI/DP Mode (Optional) 18
Unpacking
Please check that the following items are present when you unpack the box, and save
the packing materials in case you need to ship or transport the monitor in the future.
LCD monitor Quick start guide
Pre dator X34
Quick Guide
DP Cable
(Optional)
USB cable
(Optional)
HDMI cable
(Optional)
Wall mount BKT
AC Adapter
AC Power cord
English
1
SCREEN POSITION ADJUSTMENTSCREEN POSITION ADJUSTMENT
SCREEN POSITION ADJUSTMENTSCREEN POSITION ADJUSTMENT
SCREEN POSITION ADJUSTMENT
In oder to optimize the best viewing position, you can adjust the height/tilt
of the monitor.
English
•
•
•
After pressing the top of the monitor
He ight Adjustment
gh t Adjustm ent
He ight Adjustment
He ight AdjustmentHe ight Adjustment
He i
then you can adjust the height of the monitor.
1
2
mm
130
•
•
•
Please see the illustration below for an example of the tilt range.
Only at the highest point can 35 degrees of recline be offered for the angle of elevation.
2
Til tTil t
Tilt
tliT tliT
o
o
5
35
Connecting the adapter and AC Power cord
• Check first to make sure that the power cord you use is the correct type required for
your area.
• The monitor has a universal power supply that allows operation in either 100/120 V
AC or 220/240 V AC voltage area. No user-adjustment is required.
• Plug one end of the AC power cord to the Adapter, and plug the other end into an
AC outlet.
• For units using 120 V AC:
Use a UL-listed cord set, type SVT wire and plug rated 10 A/125 V.
• For units using 220/240 V AC:
Use a cord set consisting of H05VV-F cord and plug rated 10 A/250 V. The cord set
should have the appropriate safety approvals for the country in which the equipment
will be installed.
Power saving
The monitor will be driven into Power Saving” mode by the control signal
the display controller, as indicated by the amber-color power LED.
from
English
State
LED
Light
ONBlue
Power
Saving
Mode
Amber
The power saving states will be kept until a control signal has been detected
or the
keyboard or mouse is activated. The recovery time from Active OFF
state back to ON state is around 3 seconds.
3
Display Data Channel (DDC)
To make installation easier, so long as your system supports the DDC protocol, the
monitor is able to plug-and-play. The DDC is a communication protocol through which
the monitor automatically informs the host system about its capabilities; for example,
supported resolutions and corresponding timing. The monitor supports the DDC2B
standard.
English
20-pin color display signal cable
PIN No. Description PIN No. Description
1 ML_Lane 0+ 2 GND
3 ML_Lane 0- 4 ML_Lane 1+
5 GND 6 ML_Lane 1-
7 ML_Lane 2+ 8 GND
9 ML_Lane 2- 10 ML_Lane 3+
11 GND 12 ML_Lane 3-
13 CONFIG1 14 CONFIG2
15 AUX CH+ 16 GND
17 AUX CH- 18 Hot Plug
19 Return 20 DP_PWR
4
19-pin color display signal cable
1113151719 97531
26481014 121618
PIN No. Description PIN No. Description
1 TMDS Data2+ 2 TMDS Data2 Shield
3 TMDS Data2- 4 TMDS Data1+
5 TMDS Data1 Shield 6 TMDS Data1-
7 TMDS Data0+ 8 TMDS Data0 Shield
9 TMDS Data0- 10 TMDS Clock+
11 TMDS Clock Shield 12 TMDS Clock-
13 CEC 14 Reserved (N.C. on device)
15 SCL 16 SDA
17 DDC/CEC Ground 18 +5V Power
19 Hot Plug Detect
English
English
5
Standard timing table
MODE Resolution Remark
1 640x480 60Hz
2 720x480 60Hz
English
3 1280x720 60Hz
4 720x576 50Hz
5 1280x720 50Hz
6 1920x1080 60Hz
7 3440x1440 50Hz
8 3440x1440* 60Hz Deafault
9 3440x1440* 75Hz OverClock
10 3440x1440* 80Hz OverClock
11 3440x1440* 85Hz OverClock
12 3440x1440* 90Hz OverClock
13 3440x1440* 95Hz OverClock
14 3440x1440* 100Hz OverClock
*DisplayPort only .
6
English
Installation
DP
USB
1. Turn off your computer and unplug your computer's power cord.
2. Connect the signal cable to the HDMI (optional) and /or DP (optional)
input socket of the monitor, and the HDMI (optional) and /or DP (optional)
output socket of the graphics card on the computer. Then
tighten the thumbscrews on the signal cable connector.
3. Connect the USB Cable(Optional)
Connect the USB 3.0 cable to port for fast charge.
Connect the USB 3.0 cable to port.
4. Insert the monitor power cable into the power port at the back of the monitor.
5. Connect the power adapter and power cord to the monitor, then to a properly grounded
AC outlet.
7
English
Users controls
1234567
Input
External controls
1&2 Power button Turns the monitor on/off.Blue indicates power on. Amber indicates
3 Function key
/
4 Function key
/
5 Function key
/
6 Function key
/
7 Function key
/
standby/ power saving mode.
a. Press to view
the Function Menu.
b. When the
move to the next function.
a. Press to view
function.
b. When the
move to the previous function.
a. Press to view
adjustment function.
b. When the
selection in the OSD.
a. Press to view Function Menu.Press again to activate the Overdrive
function and set it to either Normal or Extreme mode.
b. When the OSD menu is active, this button will act as the exit key
(exit OSD menu).
a. When the
control
b. When the
mode.
Main page
Function Menu
Main page
Function Menu
Main page
Function Menu
Main page
Function Menu
.Press again to enter next function in
is active, press this key selected or
.Press again to enter Input select
is active, press this button selected or
.Press again to enter Volume
is active, this button will enter a
is active,Press to trigger the Game mode
is active, press to select scenario
8
-------------------------------------------------------------------------------------------------
G-SYNC (DP only):
3440x1440@60Hz:
G-SYNC requires an NVIDIA GeForce GTX650Ti BOOST GPU or higher. For more
information, visit the nVidia® website: http://www.nvidia.com/page/home.html
3440x1440@100Hz:
G-SYNC requires an NVIDIA GeForce GTX960 BOOST GPU or higher. For more
information,visit the nVidia® website:http://www.nvidia.com/page/home.html
------------------------------------------------------------------------------------------------DTS Sound:
For DTS patents, see http://patents.dts.com. Manufactured under license
from DTS Licensing Limited. DTS, the Symbol, & DTS and the Symbol
Inc. © DTS, Inc. All Rights Reserved.
together are registered trademarks, and DTS Sound is a trademark of DTS,
-------------------------------------------------------------------------------------------------
English
9
English
Using the Shortcut Menu
-------------------------------------------------------------------------------------------------------------
Note: The following content is for general reference only. Actual product specications
may vary.
The OSD (onscreen display) can be used to adjust the settings of your LCD monitor. Press
the MENU key to open the OSD. You can use the OSD to adjust the picture quality, OSD
position and general settings. For advanced settings, please refer to following page:
Main page
Game mode 1. OD (overdrive) options
2. Volume
3. Input selection
4. Function menu
10
English
Turn Game mode on or off
e7
Open the Game mode control and turn Game mode on or off using the arrows (OFF/
ON),andselectwhichuser-denedproletouse(pleaseseetheOSDsectionformore
information).
Adjusting the OD setting
Open the OD control and select your preferred OD setting using the arrows. When you are
done, use
OD
to go back one level.
Off
Normal
Extreme
Adjusting the volume
Open the Volume control and set the Volume using the arrows. When you are done, use
to go back one level.
Volum
Selecting the input
Open the Input control and select HDMI or DP. When you are done, use
one level.
HDMI DP
1
to go back
113
English
The Function page
Acer eColor Management
Brightness
Contrast
Blue Light
Dark boost
Adaptive Contrast
Off
Off
Off
50
27
Open the Function page to adjust the Picture, Color, OSD and Setting functions, settings
which you want using the arrows. You can also view your monitor’s system information from
this page. When you are done, use
1. Press the MENU key to open the OSD.
2. Usingthe▲/▼keys,selectPicturefromtheOSD.Thennavigatetothepictureelement
you wish to adjust.
3. Usethe◄/►keystoadjusttheslidingscales.
4. The Picture menu can be used to adjust the Acer eColor, Brightness, Contrast, Blue
Light, Dark boost and Adaptive contrast.
5. Brightness: Adjust the brightness from 0 to 100.
-----------------------------------------------------------------------------------------------------------
Note: Adjusts the balance between light and dark shades.
6. Contrast: Adjust the contrast from 0 to 100.
-----------------------------------------------------------------------------------------------------------
Note: Sets the degree of difference between light and dark areas.
7. Blue Light: Filters out blue light to protect your eyes by adjusting how much blue light is
shown -- 80%, 70%, 60%, or 50%.
-----------------------------------------------------------------------------------------------------------
Note: Higher values allow more blue light through. For the best protection select
a lower value.
to go back one level.
12
English
8. Dark boost: This boosts the amplitude of the dark color levels of the display– blacks will
be less black. The higher the level, the higher the boost.
9. Adaptive Contrast: This method usually increases the global contrast of many images,
especially when the usable data of the image is represented by close contrast values.
This allows for areas of lower local contrast to gain a higher contrast.
The method is useful in images with backgrounds and foregrounds that are both bright
or both dark. In particular, the method can lead to better views of bone structure in x-ray
images, and to better detail in photographs that are over or under-exposed.
13
English
Color
Color
Gamma
Colour Temp
Saturation
6-axis color
Warm
2.2
100
1. Press the MENU key to open the OSD.
2. Usingthe▲/▼keys,selectColorfromtheOSD.Thennavigatetothepictureelement
you wish to adjust.
3. Usethe◄/►keystoselectthesetting.
4. Gamma mode allows you to adjust the luminance tone.The default value is 2.2 (standard
value for Windows).
5. Color temperature: Default is warm. You can choose Cool, Warm,Normal,Bluelight or
User.
6. Saturation: Color brightness can be changed by 0~200 adjustment.
7. 6-axis color: Chroma of red, green, blue, cyan, yellow and magenta can be
independently adjusted from 0~155, changing the color quality of the image.
14
English
OSD
OSD
Language
OSD Timeout
Refresh rate num
Transparency
Game mode
Aim point
Off
Off
English
Off
120
1. Press the MENU key to open the OSD.
2. Usingthe▲/▼keys,selectOSDfromtheOSD.Thennavigatetothesettingyouwish
to change.
3. Usethe◄/►keystoadjustanyslidingscales.
4. Language: Set the OSD menu language.
5. OSD timeout: Adjust the delay before turning off the OSD menu.
6. Refresh rate num: Display the panel’s current refresh rate on the screen.
7. Transparency: Select the transparency when using gaming mode. The transparency
can be 0% (OFF), 20%, 40%, 60%, or 80%.
8. Gamemode:Therearethreeuser-denedprolesavailable.Whenyouhavedecided
what settings suit you, save them and system will be able to recall the settings in the
future when you turn on gaming mode and press 1, 2 or 3.
9. Aim point: Show an Aim point on the screen for shooting games.
15
English
Setting
Setting
Input
DTS
OD
Ambient Light
Wide Mode
Over Clock
Reset
Power-off
USB charge
Off
Aspect
Deep Sleep
Normal
HDMI
On
1. The Setting menu can be used to select the screen menu language and other important
settings, including input and OD level.
2. Press the MENU key to open the OSD.
3. Usingthe▲/▼keys,selectSettingfromtheOSD.Thennavigatetothesettingyou
wish to adjust.
4. Usethe◄/►keystoselectthesetting.
5. Input: Select the source from DP In, HDMI.
6. DTS: Turn DTS Sound On or Off. Your monitor is equipped with two 7W speakers on
therear.DTSSoundisstratiedandcreatesaremarkablesonicow.
7. OD: Select Off, Normal, or Extreme.
8. Ambient light: Adjust the lighting effects, color, and style.
9. Wide mode: You can select which screen aspect you are using. The options are Aspect
and 1:1.
10. OverClock: X34 can be overclocked (at the end user’s risk) to a higher refresh rate
thanadvertisedbythepanelspecication.Thisfunctionsthatallowsthisbehavior
* After rebooting, use the NVIDIA Control Panel to set the maximum refresh rate.
If nothing is displayed, disconnect the DisplayPort™ cable and use the monitor’s
onscreen display to select a default refresh rate.
11. Deep Sleep : You can select sleep mode on or off, when HDMI or DP source input.
On (default mode): Monitor enter into sleep mode 12minutes after no HDMI or DP
source input.
Off : Monitor don’t enter into sleep mode while no HDMI or DP source input
12. Reset: Resets the custom color settings to the factory defaults.
13. Power-off USB charge: Turn On or Off.
16
English
Product information
Information
Resolution
Max Refresh Rate
Mode
Normal
1920x1080
60 Hz
1. Press the MENU key to open the OSD.
2. Usingthe▲/▼keys,selectInformationtoviewthebasicinformationforyourmonitor
and current input.
17
Troubleshooting
Before sending your LCD monitor for servicing, please check the troubleshooting list
below to see if you can self-diagnose the problem.
HDMI/DP Mode (Optional)
English
Problem LED status Remedy
8
1
999999
Loading...
