SPECIAL NOTES ON LCD MONITORS

The following symptoms are normal with LCD monitor and do not indicate a problem.

NOTES

y Due to the nature of the fluorescent light, the screen may flicker during initial use. Turn off the

Power Switch and then turn it on again to make sure the flicker disappears.

y You may find slightly uneven brightness on the screen depending on the desktop pattern you

use.

y The LCD screen has effective pixels of 99.99% or more. It may include blemishes of 0.01% or less

such as a missing pixel or a pixel lit all of the time.

y Due to the nature of the LCD screen, an afterimage of the previous screen may remain after

switching the image, when the same image is displayed for hours. In this case, the screen is
recovered slowly by changing the image or turning off the Power Switch for hours.

EN-1

X193HQL

INFORMATION FOR YOUR SAFETY AND COMFORT

Safety instructions

Read these instructions carefully. Keep this document for future reference. Follow all warnings and
instructions marked on the product.

CAUTION for accessibility

Be sure that the power outlet you plug the power cord into is easily accessible and located as close to
the equipment operator as possible. When you need to disconnect power to the equipment, be sure to
unplug the power cord from the electrical outlet.

Warnings

y Do not use this product near water.
y Do not place this product on an unstable cart, stand or table. If the product falls, it could be

seriously damaged.

y Slots and openings are provided for ventilation to ensure reliable operation of the product and

to protect it from overheating. These openings must not be blocked or covered. The openings
should never be blocked by placing the product on a bed, sofa, rug or other similar surface. This
product should never be placed near or over a radiator or heat register, or in a built-in
installation unless proper ventilation is provided.

y Never push objects of any kind into this product through cabinet slots as they may touch

dangerous voltage points or short-out parts that could result in a fire or electric shock. Never
spill liquid of any kind onto or into the product.

y To avoid damage of internal components and to prevent battery leakage, do not place the

product on a vibrating surface.

y Never use it under sporting, exercising, or any vibrating environment which will probably cause

unexpected short current or damage rotor devices, HDD, Optical drive, and even exposure risk
from lithium battery pack.

Safe listening

Follow these instructions, suggested by hearing experts, to protect your hearing.

y Gradually increase the volume until you can hear it clearly and comfortably and without

distortion.

y After setting the volume level, do not increase it after your ears adjust.
y Limit the amount of time listening to music at high volume.
y Avoid turning up the volume to block out noisy surroundings.
y Turn the volume down if you can’t hear people speaking near you.

EN-2

X193HQL

Product servicing

Do not attempt to service this product yourself, as opening or removing covers may expose you to
dangerous voltage points or other risks. Refer all servicing to qualified service personnel.
Unplug this product from the wall outlet and refer servicing to qualified service personnel when:

y the power cord or plug is damaged, cut or frayed liquid was spilled into the product
y the product was exposed to rain or water
y the product has been dropped or the case has been damaged
y the product exhibits a distinct change in performance, indicating a need for service
y the product does not operate normally after following the operating instructions

LCD Pixel Statement

The LCD unit is produced with high-precision manufacturing techniques. Nevertheless, some pixels
may occasionally misfire or appear as black or red dots. This has no effect on the recorded image and
does not constitute a malfunction.

Note: Adjust only those controls that are covered by the operating instructions, since
improper adjustment of other controls may result in damage and will often require
extensive work by a qualified technician to restore the product to normal condition.

Tips and information for comfortable use

Computer users may complain of eyestrain and headaches after prolonged use. Users are also at risk of
physical injury after long hours of working in front of a computer. Long work periods, bad posture,
poor work habits, stress, inadequate working conditions, personal health and other factors greatly
increase the risk of physical injury.
Incorrect computer usage may lead to carpal tunnel syndrome, tendonitis, tenosynovitis or other
musculoskeletal disorders. The following symptoms may appear in the hands, wrists, arms, shoulders,
neck or back:

y numbness, or a burning or tingling sensation
y aching, soreness or tenderness
y pain, swelling or throbbing
y stiffness or tightness
y coldness or weakness

If you have these symptoms, or any other recurring or persistent discomfort and/or pain related to
computer use, consult a physician immediately and inform your company’s health and safety
department.
The following section provides tips for more comfortable computer use.

Finding your comfort zone

Find your comfort zone by adjusting the viewing angle of the monitor, using a footrest, or raising your
sitting height to achieve maximum comfort. Observe the following tips:

y refrain from staying too long in one fixed posture
y avoid slouching forward and/or leaning backward
y stand up and walk around regularly to remove the strain on your leg muscles

y take short rests to relax your neck and shoulders
y avoid tensing your muscles or shrugging your shoulders

y install the external display, keyboard and mouse properly and within comfort able reach
y if you view your monitor more than your documents, place the display at the center of your desk

to minimize neck strain

EN-3

X193HQL

Taking care of your vision

Long viewing hours, wearing incorrect glasses or contact lenses, glare, excessive room lighting, poorly
focused screens, very small typefaces and low-contrast displays could stress your eyes.
sections provide suggestions on how to reduce eyestrain.
Eyes

y Rest your eyes frequently.
y Give your eyes regular breaks by looking away from the monitor and focusing on a distant

point.

y Blink frequently to keep your eyes from drying out.

Display

y Keep your display clean.
y Keep your head at a higher level than the top edge of the display so your eyes point

downward when looking at the middle of the display.

y Adjust the display brightness and/or contrast to a comfortable level for enhanced text

readability and graphics clarity.

y Eliminate glare and reflections by:

 placing your display in such a way that the side faces the window or any light source

 minimizing room light by using drapes, shades or blinds

 using a task light

 changing the display’s viewing angle

 using a glare-reduction filter

 using a display visor, such as a piece of cardboard extended from the display’s top front

edge

y Avoid adjusting your display to an awkward viewing angle.
y Avoid looking at bright light sources, such as open windows, for extended periods of time.

The following

Developing good work habits

Develop the following work habits to make your computer use more relaxing and productive:

y Take short breaks regularly and often.
y Perform some stretching exercises.
y Breathe fresh air as often as possible.
y Exercise regularly and maintain a healthy body.

Warning! We do not recommend using the product on a couch or bed. If this is
unavoidable, work for only short periods, take breaks regularly, and do some stretching
exercises.
For more information and help in recycling, please visit the following websites: Worldwide:

http://www.acer-group.com/public/Sustainability/sustainability01.htm
http://www.acer-group.com/public/Sustainability/sustainability04.htm

EN-4

X193HQL

UNPACKING

Please check the following items are present when you unpack the box, and save the packing materials
in case you will need to ship or transport the monitor in future.

LCD Monitor

15-pin D-Sub Cable DVI Cable

(Only Dual-Input Model)

User Manual Quick Start Guide Audio Cable

AC Power Cord

(Optional)

EN-5

ATTACHING / REMOVING THE BASE

X193HQL

Install:
Align the release button on the bottom of the
monitor with the corresponding slots on the
bottom of the base.

Remove:
Depress the release button as indicated first
before removing the base and follow the arrow
direction to remove it.

SCREEN POSITION ADJUSTMENT

In order to optimize the best viewing position, you can adjust the tilt of the monitor by using both of
your hands to hold the edges of the monitor as shown in the figure below.
The monitor can be adjusted to 15 degrees up or 5 degrees down as indicated by arrow below.

EN-6
