Product type Desktop computer
Product category D
Manufacturer name, address
Acer Italy s.r.l,
Via Lepetit, 40, 20020 Lainate (MI) Italy
Product model number Veriton N4630
Year of manufacture 2014
E
TEC
allowance with capability
adjustments when discrete graphics cards
are disabled (from 1 July 2014)
265 kWh/year
E
TEC
allowance with capability
adjustments when discrete graphics cards
are enabled (from 1 July 2014)
Not Appliable
E
TEC
allowance with capability
adjustments when discrete graphics cards
are disabled (from 1 January 2016)
204 kWh/year
E
TEC
allowance with capability
adjustments when discrete graphics cards
are enabled (from 1 January 2016)
Not Appliable
Whether all discrete graphics card are
enabled during the test
Yes
Whether switchable graphics mode with
UMA is driving the display during the test
No
E
TEC
of highest power-demanding
configuration
48.68 kWh/year
Idle state power demand 12.936 Watt
Sleep mode power demand 0.872 Watt
Sleep mode with WOL enabled power
demand
0.909 Watt
Off mode power demand 0.618 Watt
Off mode with WOL enabled power
demand
0.657 Watt
Maximum power demand Not applicable
Internal power supply (IPS) efficiency at
10 %, 20 %, 50 % and 100 % of rated
output power
Output Load 100% , Efficiency 88.53%
Output Load 50% , Efficiency 86.43%
Output Load 20% , Efficiency 87.73%
Output Load 10% , Efficiency 85.01%
External power supply's (EPS) average
active efficiency
Not applicable
Noise levels (the declared A-weighted
sound power level, L
WAd
) of idle mode
3.65 B
Technical Documentation of (EU) No 617/2013
Noise levels (the declared A-weighted
sound power level, L
WAd
) of "HDD random
seek" mode
3.66 B
Minimum number of loading cycles that
the batteries can withstand
Not applicable
Configuration of memory 8 GB
Configuration of internal storage 2 piece
Configuration of discrete television tuner 0 piece
Configuration of discrete audio card 0 piece
Configuration of discrete graphics cards 0 piece
Configuration of discrete graphics cards
category
Not applicable
The battery in this product cannot be
easily replaced by users themselves
Not applicable
For products with an integrated display,
the total content of mercury is
Not applicable
Measurement methodology for E
TEC
COMMISSION REGULATION (EU) No
617/2013 of 26 June 2013 implementing
Directive 2009/125/EC of the European
Parliament and of the Council with regard
to ecodesign requirements for computers
and computer servers:
ANNEX II Ecodesign requirements and
timetable:
1.1.1. E
TEC
formula.
Measurement methodology for idle mode
EN 62623:2013 — Desktop and notebook
computers — Measurement of energy
consumption:
5.2. Test setup;
5.3.5. Measuring short idle mode;
5.7. True RMS watt meter specification;
5.8. True RMS watt meter accuracy;
Annex E.2 (informative) ENERGY STAR
®
V5 compliant testing methodology.
Measurement methodology for sleep
mode
EN 62623:2013 — Desktop and notebook
computers — Measurement of energy
consumption:
5.2. Test setup;
5.3.3. Measuring sleep mode;
5.4. Test conditions;
5.7. True RMS watt meter specification;
5.8. True RMS watt meter accuracy.
Measurement methodology for off mode
EN 62623:2013 — Desktop and notebook
computers — Measurement of energy
consumption:
5.2. Test setup;
5.3.2. Measuring off mode;
5.4. Test conditions;
5.7. True RMS watt meter specification;
5.8. True RMS watt meter accuracy.
Measurement methodology for IPS
efficiency
Not applicable
Measurement methodology for EPS
efficiency
EN 50563:2011 External a.c.—d.c. and
a.c.—a.c. power supplies —
Determination of no-load power and
average efficiency of active modes.
Measurement methodology for noise level
ECMA-109 2nd edition (December 1987)
Declared Noise Emission Values of
Computer and Business Equipment:
4. Determination of the declared noise
emission values.
ECMA-74 11th edition (December 2010)
Measurement of Airborne Noise emitted
by Information Technology and
Telecommunications Equipment:
5. Installation and operating instructions;
6. Method for determination of sound
power levels of equipment in
reverberation test rooms;
7. Method for determination of sound
power levels of equipment under
essentially free-field conditions over a
reflecting plane;
Annex C.15 Equipment category:
personal computers and workstations.
Measurement methodology for battery
loading cycles
Not applicable
Sequence of steps for achieving a stable
condition with respect to power demand
EN 62623:2013 — Desktop and notebook
computers — Measurement of energy
consumption:
5.2. Test setup;
5.3.2. Measuring off mode;
5.3.3. Measuring sleep mode;
5.3.5. Measuring short idle mode.
Description of how sleep mode was
selected or programmed
EN 62623:2013 — Desktop and notebook
computers — Measurement of energy
consumption:
5.2. Test setup;
5.3.3. Measuring sleep mode.
Description of how off mode was selected
or programmed
EN 62623:2013 — Desktop and notebook
computers — Measurement of energy
consumption:
5.2. Test setup;
5.3.2. Measuring off mode.
Sequence of events required to reach the
mode where the equipment automatically
changes to sleep mode
ENERGY STAR® Program Requirements
Product Specification for Computers,
Eligibility Criteria Version 6.0, Rev. Oct2013:
1.D.4 Sleep Mode.
Sequence of events required to reach the
mode where the equipment automatically
changes to off mode
Not applicable
The length of time after a period of user
inactivity in which the computer
automatically reaches a power mode that
has a lower power demand requirement
than sleep mode
30 minutes
The length of time before the display
sleep mode is set to activate after user
inactivity
10 minutes
User information on the energy-saving
potential of power management
functionality
http://www.energystar.gov/index.cfm?c=p
ower_mgt.pr_power_mgt_users
User information on how to enable the
power management functionality
http://www.energystar.gov/index.cfm?c=p
ower_mgt.pr_power_mgt_users
Test parameter for ambient temperature 25 ℃
Test parameter for test voltage 230 V
Test parameter for frequency 50 Hz
Test parameter for total harmonic
distortion of the electricity supply system
3 %
Test parameter for information and
documentation on the instrumentation,
set-up and circuits used for electrical
testing
Digital Power Meter- Yokogawa WT210
Programmable AC Soure- Chroma 61603
