System Tour

Features

Below is a brief summary of the computer’s many feature:
NOTE: The features listed in this section is for your reference only. The exact configuration of the system

depends on the model purchased.

Operating System

• Microsoft Windows 7 Home Premium 64bit

• Microsoft Windows 7 Home Premium 32bit

• Microsoft Window 7 Home Basic 64bit

• Microsoft Windows 7 Home Basic 32bit

• Microsoft Windows 7 Starter 32bit

• Microsoft Windows 7 Professional 32bit

• Microsoft Windows XP Professional 32bit

• Free DOS

• Linpus XWindows 9.5

• Lipus Linux cons

Chapter 1

Processor

• Socket Type: AMD Socket AM3

• Socket Quantity: 1

• Processor Type:

• Support AM3 6-core Thuban CPU (140W)

Chipset

• NB: RS880P

• SB: AMD SB810

PCB

• 4 Layer uATX form factor 9.6in X 9.6in (24.38cm X 24.38cm)

Memory subsystem

• Socket Type: DDR III Un-buffered DIMM connector

• Socket Quantity: 4

• 2 channels, 2 DIMMs per channel.

• Different colors for DIMM 0 and DIMM 1

• 1GB/2GB/4GB DDR3 1.5V 1333/1066 Un-buffered Non-ECC DIMM support

• 1 GB to 16GB Max memory support

• Design Criteria:

• Must meet Intel Lynnfield and Clarkdale Chipset platform design guide

• Support 1.5V DIMM

Chapter 1 1

• Dual channel should be enabled always when plug-in 2 same memory size DDRIII memory

module

Hard disk drive

• Support up to two SATA ports

• 3.5"

• Capacity and models are listed on AVLC

Optical disk drive

• Support one SATA 5.25" standard ODD

• Support DVD-ROM, DVD-SuperMulti, BD-combo, BD-rewrite

• Maximum ODD depth to 185mm with bezel

• Models are listed on AVLC

Graphics card

• No mechanical retriction to support for double slot, full length graphics cards in the single PCIe X16 slot

Vedio

• AMD RS880P on die graphic solution

• Meet Microsoft Vista Premium graphic requirement

• 1 HDMI port and 1 D-sub port for Consumer model

• 1 D-sub port and 1 DVI-D port for Commercial model

• Need to measure VGA follow Acer SOP

Audio

• Chip : HD audio codec ALC662-VC HD codec 5.1

• Connectors support:

• Rear 3 jack follow HD audio definition (ALC662-VC)

• Audio jacks color coding: should meet Microsoft Windows Logo Program Device Requirements:

Audio-0002

• 1 S/PDIF-out header (1*4)

• 1 front panel audio header (2*5)

• 1 internal speaker header (2*4)

• Add HD de-pop CKT

Serial ATA controller

• Slot Type: SATA connector

• Six SATA ports:

• 4 for HDD

• 2 for ODD

• Storage Type support:

• 1.HDD : Support RAID 0/1/5/10

• 2.Blue Ray ODD

• 3.AHCI mode supported for internal SATA port

2 Chapter 1

LAN

• Controller: Realtek 8111E Gigabit Ethernet controller

• RJ-45 Back panel port with Link/Activity LEDs

USB ports

• Ports Quantity: 14 (should reserve more header for front DB)

• 6 ports for rear port

• On-board: 4 2*5 headers

4 ports for front daughter board
2 ports for internal card reader
2 ports for Daughter board (Aspire M5400/M3400 only)

• Connector Pin: standard Intel FPIO pin definition

Extension slot

• Support one PCIe x 16 slot

• Support two PCIe x 1 slots

• Support one PCI slot

Rear I/O connectors

• 1 PS/2 Keyboard port

• 1 PS/2 Mouse port

• 1 HDMI port (need certification) for consumer models

• 1 D-sub port

• 1 DVI-D port for commercial models

• 6 USB ports

• 1 RJ45 LAN port

• 1 Com port for commercial models

• 5.1 channel phone jack (3 audio jacks)

On-board connectors

• 1 AM3 CPU socket

• 4 DDR3 memory sockets

• 1 PCI Express x16 slot

• 2 PCI Express x1 slot

• 1 PCI slots

• 6 SATA2 connectors

• 4 2x5-pin Intel FPIO specification USB pin connectors (follow Intel FPIO Standard Specifica ti on)

• 1 2x5-pin Intel FPIO spec Microphone In/ Headphone Out pin connector

• 1 1x4 S/PDIF out header (for ALC662 SKU)

• 1 3-pin CPU fan connector (co-lay with 4-pin CPU fan connector)

• 1 3-pin system fan connector with linear circuit

• 1 24-pin + 4-pin ATX interface PS3/PS2 SPS connector

• 1 2x7-pin front panel I/O header

• 1 Jumper for clear CMOS

• 1 on board buzzer

Chapter 1 3

• 2 reserved 2-pin GPIO connector

System BIOS

• Size: 8Mbit

• AMI Kernel with Acer skin/copyright

Power supply

• 300W/500W in stable mode (Acer Assign System Power Unit)

• Support 82+ PSU for EnergyStar 5.0 complaint

• Design for RS880P+SB810 series chipset compatible system

• Voltage design should be covered +5V, +3.3V, +12V, +5VSB, -12V (attention to 12V output capability)

• Demand for both PFC/Non-PFC solutions (two different quotations are needed)

• PS2 style

4 Chapter 1

Block Diagram

Chapter 1 5

System Components

This section is a virtual tour of the system’s interior and exterior components.

Front Panel

1

2

3

4

9
8
7

6

5

No. Component

1 USB 2.0 ports
2Acer logo
3 Optical drive button
4 Optical drive button (Removable HDD bay for AM551 bezel)
5 Removable HDD bay
6 Power button
7 16 in 1 Card Reader
8 Headphone/Speaker-out/line-out jack
9 Microphone-in jack

6 Chapter 1

Rear Panel

1

14

2
3

13

12

4

5

6

11

10

9

7
8

No. Component

1 Power connector
2 PS2 keyboard port
3 HDMI port
4VGA port
5 USB 2.0 ports
6Mic-in
7 Line-out
8 Expansion slot (graphics card and TV tuner card and Mode card)
9 Line-in
10 USB 2.0 ports
11 LAN connector
12 System FAN
13 PS2 mouse port
14 Fan aperture

Chapter 1 7

Hardware Specifications and Configurations

Processor

Item Specification

Processor Type Support AM3 6-core Thuban CPU (140W)
Socket Type AMD Socket AM3
Minimum operating speed 0 MHz (If Stop CPU Clock in Sleep State in BIOS Setup is set to Enabled.)

BIOS

Item Specification

BIOS code programer AMI Kernel with Acer skin
BIOS version P01-A0
BIOS ROM type SPI ROM
BIOS ROM size 8Mb
Support protocol SMBIOS(DMI)2.4/DMI2.0
Device Boot Support Support BBS spec

1st priority: HDD
2nd priority: CD-ROM
3th priority: LAN

4th priority: USB device
Support to LS-120 drive YES
Support to BIOS boot block feature YES

IOS Hotkey List

Hotkey Function Description

Del Enter BIOS Setup Utility Press while the system is booting to enter BIOS Setup Utility.

Main Board Major Chips

Item Specification

North Bridge RS880P
South Bridge SB810
Audio controller ALC662-VC
LAN controller Realtek 8111E Gigabit Ethernet controller
HDD controller RS880P

8 Chapter 1

Memory Combinations

Slot Memory Total Memory

Slot 1 1MB,2GB,4GB 1G ~4GB
Slot 2 1MB,2GB,4GB 1G ~4GB
Slot 3 1MB,2GB,4GB 1G ~4GB
Slot 4 1MB,2GB,4GB 1G ~4GB
Maximum System Memory Supported 1G~16GB

System Memory

Item Specification

Memory slot number 4 slot
Support Memory size per socket 1GB/2GB/4GB
Support memory type DDRIII
Support memory interface DDRIII 1066/1333MHz
Support memory voltage 1.5V
Support memory module package 240-pin DDRIII
Support to parity check feature Yes
Support to error correction code (ECC) feature No
Memory module combinations You can install memory modules in any combination as long as

they match the above specifications.

Audio Interface

Item Specification

Audio controller ALC662-VC
Audio channel codec 5.1
Audio function control Enable/disable by BIOS Setup
Mono or stereo Stereo
Compatibility Support host audio controller from the Intel ICH series chipset, and also from

any other HDA compatible audio controller. With EAX/Direct Sound 3D/I3DL2/
A3D compatibility, and excellent software utilities like environment sound
emulation, multiple bands of software equalizer and dynamic range control,
optional Dolby, Digital Live, DTS CONNECT, and Dolby Home Theater
programs, provides an excellent home entertainment package and game

experience for PC users.
Sampling rate 192 KHz (max.)
Microphone/Headphone jack Supported

Chapter 1 9

SATA Interface

Item Specification

SATA controller RS880P
Number of SATA channel SATA X 6
Support mode RAID/AHCI/IDE mode option

USB Port

Item Specification

Universal HCI USB 2.0/1.1
USB Class Support legacy keyboard for legacy mode
USB Connectors Quantity 6 back real ports

4 ports for front daughter board
4 ports reserved

Environmental Requirements

Item Specification

Temperature
Operating +5°C ~ +35°C
Non-operating -20 ~ +60°C (Storage package)
Humidity
Operating 15% to 80% RH
Non-operating 10% to 90% RH
Vibration
Operating (unpacked) 5 ~ 500 Hz: 2.20g RMS random, 10 minutes per axis in all 3 axes.

5 ~500 Hz: 1.09g RMS random, 1 hour per axis in all 3 axes.

Power Management

Devices S1 S3 S4 S5

Power ButtonVVVV
USB Keyboard/Mouse V V N/A N/A
PME Disabled Disabled Disabled Disabled
RCT Disabled Disabled Disabled Disabled
WOR Disabled Disabled Disabled Disabled

• Devices wake up from S3 should be less than.

• Devices wake up from S5 should be less than 10 seconds.

10 Chapter 1

Power Management Function(ACPI support function)

Device Standby Mode

• Independent power management timer for hard disk drive devices(0-15 minutes,time step=1minute).

• Hard Disk drive goes into Standby mode(for ATA standard interface).

• Disable V-sync to control the VESA DPMS monitor.

• Resume method:device activated (keyboard for DOS, keyboard &mouse for Windows.

• Resume recovery time 3-5sec

Global Standby Mode

• Global power management timer(2-120minutes,time step=10minute).

• Hard disk drive goes into Standby mode(for A TA standard interface).

• Disable H-sync and V-sync signals to control the VESA DPMS monitor.

• Resume method: Resume to original state by pushing external switch Button,modem ring in,keyboard

an mouse for APM mode.

• Resume recovery time :7-10sec

Suspend Mode

• Independent power management timer(2-120minutes,time step=10minute)o r pushing extern switch

button.

• CPU goes into SMM

• CPU asserts STPCLK# and goes into the Stop Grant State.

• LED on panel turns amber colour.

• Hard disk drive goes into SLEEP mode (for ATA standard interface).

• Disable H-sync and V-sync signals to control the VESA DPMS monitor.

• Ultra I/O and VGA chip go into power saving mode.

• Resume method: Resume to original state by pushing external switch Button,modem ring in,keyboard

an mouse for APM mode

• Return to original state by pushing external switch button,modem ring in and USB keyboard for ACPI

mode.

ACPI

• ACPI specification 1.0b

• S0,S1,S2 and S5 sleep state support.

• On board device power management support.

• On board device configuration support.

Chapter 1 11

Chapter 2

System Utilities

CMOS Setup Utility

CMOS setup is a hardware configuration program built into the system ROM, called the complementary metal­oxide semiconductor (CMOS) Setup Utility. Since most systems are already properly configured and
optimized, there is no need to run this utility. You will need to run this utility under the following conditions.

• When changing the system configuration settings

• When redefining the communication ports to prevent any conflicts

• When modifying the power management configuration

• When changing the password or making other changes to the security setup

• When a configuration error is detected by the system and you are prompted ("Run Setup"

message) to make changes to the CMOS setup

NOTE: If you repeatedly receive Run Setup messages, the battery may be bad. In this case, the system

cannot retain configuration values in CMOS. Ask a qualified technician for assistance.

CMOS setup loads the configuration values in a battery-backed nonvolatile memory called CMOS RAM. This
memory area is not part of the system RAM which allows configuration data to be retained when power is
turned off.

Before you run the CMOS Setup Utility, make sure that you have saved all open files. The system reboots
immediately after you close the Setup.

NOTE: CMOS Setup Utility will be simply referred to as “BIOS”, "Setup", or "Setup utility" in this guide.

The screenshots used in this guide display default system values. These values may not be the same
those found in your system.

Chapter 2 12

Entering CMOS setup

1. Turn on the server and the monitor.
If the server is already turned on, close all open applications, then restart the server.

2. During POST, press Delete.
If you fail to press Delete before POST is completed, you will need to restart the server.
The Setup Main menu will be displayed showing the Setup’s menu bar. Use the left and right arrow keys

to move between selections on the menu bar.

Navigating Through the Setup Utility

Use the following keys to move around the Setup utility.

• Left and Right arrow keys – Move between selections on the menu bar.

• Up and Down arrow keys – Move the cursor to the field you want.

• PgUp and PgDn keys – Move the cursor to the previous and next page of a multiple page menu.

• Home – Move the cursor to the first page of a multiple page menu.

• End – Move the cursor to the last page of a multiple page menu.

• + and - keys – Select a value for the currently selected field (only if it is user-confi g u r ab l e ). Press

these keys repeatedly to display each possible entry, or the Enter key to choose from a pop-up
menu.

NOTE: Grayed-out fields are not user-configurable.

• Enter key – Display a submenu screen.

NOTE: Availability of submenu screen is indicated by a (>).

• Esc – If you press this key:

• On one of the primary menu screens, the Exit menu displays.

• On a submenu screen, the previous screen displays.

• When you are making selections from a pop-up menu, closes the pop-up without making a

selection.

• F1 – Display the General Help panel.

• F6 – Press to load optimized default system values.

• F7 – Press to load fail-safe default system values.

• F10 – Save changes made the Setup and close the utility.

13 Chapter 2

Setup Utility Menus

The Setup Main menu includes the following main setup categories.

Parameter Description

Product Information This page shows the relevant information of the main board
Standard CMOS Features This setup page includes all the items in standard compatible BIOS
Advanced BIOS Features This setup page includes all the items of Award special enhanced features
Advanced Chipset Features This setup page includes all advanced chipset features
Integrated Peripherals This setup page includes all onboard peripherals
Power Management Setup This setup page includes all the items of Green function features
PC Health Status This setup page is the System auto detect Temperature, voltage, and fan speed
Frequency/Voltage Control This setup page is the System Frequency setup
BIOS Security Features Change, set or disable password. It allows you to limit access to the System
Load Default Setting Load Default Setting indicates the value of the system parameters which the system would be

in best performance configuration
Save & Exit Setup Save CMOS value settings to CMOS and exit setup
Exit Without Saving Abandon all CMOS value changes and exit setup

In the descriptive table following each of the menu screenshots, settin gs in boldface are the default and
suggested settings.

Chapter 2 14

Product Information

The Product Information menu displays basic information about the system. These entries are for your
reference only and are not user-configurable.

Parameter Description

Processor Type Type of CPU installed on the system.
Processor Speed Speed of the CPU installed on the system.
System Memory Total size of system memory installed on the system.
Product Name Product name of the system.
System Serial Number Serial number of the system.
System BIOS Version Version number of the BIOS setup utility.
BIOS Release Date Date when the BIOS setup utility was released
Asset Tag Number Asset tag number of this system.

15 Chapter 2

Standard CMOS Features

Parameter Description Option

System Date Set the date following the weekday-month-day-year format.
System Time Set the system time following the hour-minute-second format.
Halt On Determines whether the system will stop for an error during the POST. All, But Keyboard

No Errors
All Errors

Chapter 2 16

Advanced BIOS Feature

Parameter Description Option

Quick Boot Allows you to decrease the time it takes to boot the computer by shortening

or skipping certain standard booting process.

Quiet Boot When enabled, the BIOS splash screen displays during startup.

When disabled, the diagnostic screen displays during startup.

1st/2nd/3rd/4th Boot Device Specifies the boot order from the available devices. Hard Disk

Hard Disk Drive Priority Press Enter to access the Hard Disk Drive Priority submenu and specify the boot device

priority sequence from available hard drives.

Optical Disk Drives Priority Press Enter to access the Optical Disk Drive Priority submenu and specify the boot device

priority sequence from available CD/DVD drives.

Removable Device Priority Press Enter to access the Removable Device Priority submenu and specify the boot device

priority sequence from available removable drives.

Bootup Num-Lock Selects power on state for Num Lock. On

USB Beep Message Enables or disables BIOS to display error beeps or messages during USB

device enumeration.

Enabled

Disabled

Enabled

Disabled

CD^DVD
Removable

Device
LAN

Off

Disabled

Enabled

17 Chapter 2

Advanced Chipset Features

Parameter Description Option

AMD Cool’n’ Quiet When enabled, this feature allows the OS to reduce power consumption.

When disabled, the system operates at maximum CPU speed.

AMD-V Enables or disables the Virtualization Technology (VT) availability. If

enabled, a virtual machine manager (VMM) can utilize the additional
hardware virtualization capabilities provided by this technology.

Note: A full reset is required to change the setting.

ASF Enables or disables ASF Enabled

Primary Video Select a Video memory size Auto
UMA Frame buffer Size Select a Frame buffe size Auto
Surround view Enables or disables Surrande view Enabled

Enabled

Disabled

Enabled

Disabled

Disabled

Disabled

Chapter 2 18

Integrated Peripherals

Parameter Description Option

Onboard SATA Controller Enables or disables the onboard SATA controller. Enabled

Disabled

Onboard SATA Mode Select an operating mode for the onboard SATA. RAID

Native IDE

Onboard USB Controller Enables or disables the onboard USB controller. Enabled

Disabled

Legacy USB Support Enables or disables support for legacy USB devices. Enabled

Disabled

USB Storage Emulation Enables or disables support for legacy USB devices. Enabled

Disabled

Onboard Graphics Controller Enables or disables the onboard USB controller. Enabled

Disabled
Onboard Graphics Mode select a mode of the onboard graphics UMA
Onboard Audio Controller Enables or disables the onboard audio controller. Enabled

Disabled
Onboard LAN Controller Enables or disables the onboard LAN controller. Enabled

Disabled
Onboard LAN Option ROM Enables or disables the load of embedded option ROM for

onboard network controller.

Onboard Floppy Controller Enables or disables the onboard Floppy controller. Enabled

Serial Port1 Address select a port base on address 3F8/IRQ4
Serial Port1 Mode select the mode Normal
Serial Port2 Address select a port base on address 2F8/IRQ3
Serial Port2 Mode select the mode Normal
Parallel Port Address select a port base on address 378
Parallel Port Mode select the mode Normal

Enabled

Disabled

Disabled

19 Chapter 2

Power Management Setup

Parameter Description Option

ACPI Suspend Mode Select an ACPI state. S3 (STR)

S1 (POS)

Deep power off mode Select the Deep power off Mode Enabled

Disabled

Power On by RTC Alarm Enables or Disables to wake up the system by RTC Alarm Function Enabled

Disabled

Power On by PCIE Devices Enables or disables to wake up the system from a power saving mode

through an event on PCI Express device.

Power On by PCI Devices Enables or disables to wake up the system from a power saving mode

through an event on PCI device.

Power On by Modem Ring Enables or disables to wake up the system from a power saving mode

Wake Up by PS/2 KB/
Mouse

Wake Up by USB KB/
Mouse

Restore On AC Power Loss Enables or disables the system to reboot after a power failure or

through Modem Ring.
Enables or disables to wake up the system from a power saving mode

using a PS2 keyboard or mouse.
If enabled, press any key or click the mouse will wake system from S1/

S3 state.

interrupt occurs.

Enabled

Disabled

Enabled

Disabled

Enabled

Disabled

Enabled

Disabled

Enabled

Disabled

Power Off

Power On

Last State

Chapter 2 20

PC Health Status

Parameter Description Option

system Shutdown
Temperature

CPU Shutdown Temperature Select the system Shutdown Temperature Enabled

Smart FAN Enables or disables the smart system fan control function. Enabled

Select the system Shutdown Temperature Enabled

Disabled

Disabled

Disabled

21 Chapter 2

Frequency/Voltage Control

Parameter Description Option

Spread Spectrum Enables or disables the reduction of the mainboard’s EMI.

Note: Remember to disable the Spread Spectrum feature if you are
overclocking. A slight jitter can introduce a temporary boost in clock
speed causing the overclocked processor to lock up.

Enabled

Disabled

Chapter 2 22

BIOS Security Features

Parameter Description

Supervisor Password Indicates the status of the supervisor password.
User Password Indicates the status of the user password.
Change Supervisor

Password

Supervisor password prevents unauthorized access to the BIOS Setup Utility.
Press Enter to change the Supervisor password.

Setting a supervisor password

1. Use the up/down arrow keys to select Change Supervisor Password menu then press Enter.
A password box will appear.

2. Type a password then press Enter.
The password may consist up to six alphanumeric characters (A-Z, a-z, 0-9)

3. Retype the password to verify the first entry then press Enter again.

4. Press F10.

5. Select Yes to save the new password and close the Setup Utility.

Changing the supervisor password

1. Use the up/down arrow keys to select Change Supervisor Password menu then press Enter.

2. Type the original password then press Enter.

3. Type a new password then press Enter.

4. Retype the password to verify the first entry then press Enter again.

5. Press F10.

6. Select Yes to save the new password and close the Setup Utility.

Removing a supervisor password

1. Use the up/down arrow keys to select Change Supervisor Password menu then press Enter.

2. Enter the current password then press Enter.

3. Press Enter twice without entering anything in the password fields.

23 Chapter 2

Load Default Settings

The Load Default Settings menu allows you to load the default settings for all BIOS setup parameters. Setup
defaults are quite demanding in terms of resources consumption. If you are using low-speed memory chips or
other kinds of low-performance components and you choose to load these settings, the system might not
function properly.

Chapter 2 24

Save & Exit Setup

The Save & Exit Setup menu allows you to save changes made and close the Setup Utility.

25 Chapter 2

Exit Without Saving

The Exit Without Saving menu allows you to discard changes made and close the Setup Utility.

Chapter 2 26

Chapter 3

System Disassembly

This chapter contains step-by-step procedures on how to disassemble the desktop computer for maintenance
and troubleshooting.

Disassembly Requirements

To disassemble the computer, you need the following tools:

• Wrist grounding strap and conductive mat for preventing electrostatic discharge

• Flat-blade screwdriver

• Philips screwdriver

• Hex screwdriver

• Plastic flat-blade screwdriver

• Plastic tweezers

NOTE: The screws for the different components vary in size. During the disassembly process, group the

screws with the corresponding components to avoid mismatch when putting back the components.

Chapter 3 27

Pre-disassembly Procedure

Before proceeding with the disassembly procedure, perform the steps listed below:

1. Turn off the system and all the peripherals connected to it.

2. Unplug the power cord from the power outlets.

3. Unplug the power cord from the system.

4. Unplug all peripheral cables from the system.

5. Place the system unit on a flat, stable surface.

28 Chapter 3

Removing the Side Panel

1. Remove the two screws located on the rear edge of the side panel.

2. Slide the side panel toward the back of the chassis until the tabs on the cover disengage with the slots on

the chassis.

3. Lift the side panel away from the server and put it aside for reinstallation later.

Chapter 3 29

Removing the Heat Sink Fan Assembly

WARNING:The heat sink becomes very hot when the system is on. NEVER touch the heat sink with any metal

or with your hands.

1. Disconnect the fan cable from the mainboard.

2. Use a long-nosed screwdriver to loosen the four screws on the heat sink, in the order as shown below.

30 Chapter 3

3. Lift the heat sink fan assembly away from the mainboard.

4. Use an alcohol pad to wipe off the thermal grease from both the heat sink and the processor.

Chapter 3 31

Removing the Processor

IMPORTANT:Before removing a processor from the mainboa rd, make sure to create a backup file of all

important data.

WARNING:The processor becomes very hot when the system is on. Allow it to cool off first before handling.

1. Release the load lever.

2. Lift the load lever and load plate to the fully open.

3. Pull out the processor from the socket.

IMPORTANT: If you are going to install a new processor, note the arrow on the corner to make sure the

processor is properly oriented over the socket.

32 Chapter 3

Removing the Memory Modules

IMPORTANT:Before removing any DIMM from the memory board, make sure to create a backup file of all

important data.

1. Press the holding clips on both sides of the DIMM slot outward to release the DIMM(1,2).

2. Gently pull the DIMM upward to pull it away from the M/B(3).

3

1

2

Chapter 3 33

Removing the VGA Card

1. Release the Slot cover lock.

2. Remove the screw from chassis.

3. Disconnect the power cables from the VGA card.

4. One finger Press the clip and the same time Gently pull the card to remove it from the mainboard.

34 Chapter 3

Removing the Mode Card

1. Gently pull the Mode card to remove it from the mainboard.

Chapter 3 35

Removing the Front Bezel

1. Remove the side panel. Refer to the previous section for instructions.

2. Disconnect the LED cable.

3. Release the front bezel from the chassis interior.

4. Pull the bezel away from the chassis.

36 Chapter 3

Removing Rear USB Board

1. Remove USB cable

2. Release the screw of rear usb.

3. Remove the rear usb board.

Chapter 3 37

Removing the Hard Disk Drive

1. Disconnect the data and power cables from the rear of the optical drive and the mainbo ard.

2. Remove the HDD bracket

a. Remove the screw that secures the HDD bracket to the ODD bracket.

b. Lift the bracket up and turn it over.

38 Chapter 3

3. Remove the HDD module

a. Remove the eight screws secure the HDD module to the HDD bracket.

b. Slide the HDD out of the bracket.

Chapter 3 39

Removing the Optical Drive

1. Disconnect the data and power cables from the rear of the optical drive.

2. Remove screw from the optical drive.

3. Pull the drive out of the drive.

40 Chapter 3

Removing Cables

1. Remove power switch and LED cables from slot of M/B

2. Remove HDD Data and ODD Data cables from slot of M/B.

3. Remove USB1/2/3 cable from M/B.

4. Remove FIO cable and Audio cable from M/B

Chapter 3 41

Removing the removable HDD bay

1. Remove the HDD rail

2. Remove the screws that secure the HDD bay.

3. Remove the HDD bay.

42 Chapter 3

Removing the Power Supply

1. Disconnect the 24-pin and 4-pin power supply cables from the mainboard.

2. Remove the four screw that secures the power supply to the chassis.

Chapter 3 43

3. Lift the power supply module out of the chassis.

44 Chapter 3

Removing the Mainboard

1. Remove the eight screws that secure the mainboard to the chassis.

2

7

6

8

3

6

4

1

Note:Circuit boards >10 cm² has been highlighted with the yellow rectangle as above image shows.

Please detach the Circuit boards and follow local regulations for disposal.

2. Lift the board from the chassis.

Chapter 3 45

3. Punching in IO Shield then you can remove it.

4. Remove the RTC battery.

Note:RTC battery has been highlighted with the yellow circle as above image shows.Please detach the

RTC battery and follow local regulations for disposal.

46 Chapter 3

System Troubleshooting

This chapter provides instructions on how to troubleshoot system hardware problems.

Hardware Diagnostic Procedure

IMPORTANT:The diagnostic tests described in this chapte r are only intended to test Acer products. Non-

Acerproducts, prototype cards, or modified options can give false errors and invalid
systemresponses.

1. Obtain the failing symptoms in as much detail as possible.

2. Verify the symptoms by attempting to recreate the failure by running the diagnostic tests or repeating

thesame operation.

3. Refer to “Power System check” and “Beep Codes” to determine which corrective action to perform.

Chapter 4

Chapter 4 47

System Check Procedures

Power System Check

If the system will power on, skip this section. Refer to System External Inspection.
If the system will not power on, do the following:

• Check if the power cable is properly connected to the system and AC source.

• Check if the voltage selector switchis set to the correct voltage setting.

System External Inspection

1. Inspect the LED indicators on the front panel, which can indicate the malfunction.

2. Make sure that air flow is not blocked.

3. Make sure nothing in the system is making contact that could short out power.

4. If the problem is not evident, continue with System Internal Inspection.

System Internal Inspection

1. Turn off the system and all the peripherals connected to it.

2. Unplug the power cord from the power outlets.

3. Unplug the power cord from the system.

4. Unplug all peripheral cables from the system.

5. Place the system unit on a flat, stable surface.

6. Remove the system covers.For instructions on removing system covers, refer to “System Disassembly”.

7. Verify that components are properly seated.

8. Verify that all cable connectors inside the system are firmly and correctly attached to their appropriate

connectors.

9. Verify that all components are Acer-qualified and supported.

10. Replace the system covers.

11. Power on the system.

12. If the problem with the system is not evident, you can try viewing the POST messages and BIOS event

logs during the system startup.

48 Chapter 4

Beep Codes

Beep codes are used by the BIOS to indicate a serious or fatal error to the end user. Beep codes are used
when an error occurs before the system video has been initialized. Beep codes will be generated by the
system board speaker, commonly referred to as the PC speaker.

AMIBIOS displays the checkpoints in the bottom right corner of the screen during POST. This display method
is limited, since it only displays checkpoints that occur after the video card has been activated.

Not all computers using AMIBIOS enable this feature. In most cases, a checkpoint card is the best tool for
viewing AMIBIOS checkpoints.

Beep Symptom Cause and Description

One short beep System is ready.

System is OK.
Continuous one long beep Memory not installed or memory error.
One long beep and two short beeps then

repeat.

One long beep then two short beep BIOS damaged.

Two short beeps CMOS damaged.

VGA not installed or VGA error.

Graphics card error/not installed, graphics card memory

error or graphics card BIOS checksum error.

BIOS is damaged, BIOS POST jumps to Boot Block to

execute the default procedures.

CMOS checksum error or CMOS battery loss occurs.

Chapter 4 49

Checkpoints

A checkpoint is either a byte or word value output to I/O port 80h.The BIOS outputs checkpoints throughout
bootblock and Power-On Self Test (POST) to indicate the task the system is currently executing. Checkpoint
sare very useful in aiding software developers or technicians in debugging problems that occur during the pre­boot process.

Viewing BIOS checkpoints

Viewing all checkpoints generated by the BIOS requires acheckpoint card, also referred to as a POST card or
POST diagnostic card. These are ISA or PCI add-in cards that show the value of I/O port 80h on a LED
display. Checkpoints may appear on the bottom right corner of the screen during POST. This display method
islimited, since it only displays checkpoints thatoccur after the video card has been activated.

Bootblock Initialization Code Checkpoints

The Bootblock initialization code sets up the chipset,memory, and other components before system memory is
available. The following table describes the type of checkpoints that may occur during the bootblock
initialization portion of the BIOS.

NOTE: Please note that checkpoints may differ between different platforms based on system

configuration.Checkpoints may change due to vendor requirements,system chipset or option ROMs
from add-in PCI devices.

Checkpoint Description

Before D0 If boot block debugger is enabled, CPU cache-as-RAM functi onality is enabled at this point.

Stack will be enabled from this point.

D0 Early Boot Strap Processor (BSP) initialization like microcode update, frequency and other

CPU critical initialization. Early chipset initialization is done.

D1 Early super I/O initialization is done including RTC and keyboard controller. Serial port is

enabled at this point if needed for debugging. NMI is disabled. Perform keyboard controller
BAT test. Save power-on CPUID value in scratch CMOS. Go to flat mode with 4GB limit and

GA20 enabled.
D2 Verify the boot block checksum. System will hang here if checksum is bad.
D3 Disable CACHE before memory detection. Execute full memo ry sizing module. If memory

sizing module not executed, start memory refresh and do memory sizing in Boot block code.

Do additional chipset initialization. Re-enable CACHE. Verify that flat mode is enabled.
D4 Test base 512KB memory. Adjust policies and cache first 8MB. Set stack.
D5 Bootblock code is copied from ROM to lower system memory and control is given to it. BIOS

now executes out of RAM. Copies compressed boot block code to memory in right

segments. Copies BIOS from ROM to RAM for faster access. Performs main BIOS

checksum and updates recovery status accordingly.
D6 Both key sequence and OEM specific method is checked to determine if BIOSrecovery is

forced. Main BIOS checksum is tested. If BIOS recovery is necessary,control flows to

checkpoint E0. See Bootblock Recovery Code Checkpoints sectionfor more information.
D7 Restore CPUID value back into register. The Bootblock-Runtime interface module is moved

to system memory and control is given to it. Determine whether to execute serial flash.
D8 The Runtime module is uncompressed into memory. CPUID information is stored in memory .
D9 Store the Uncompressed pointer for future use in PMM. Copying Main BIOS into memory.

Leaves all RAM below 1MB Read-Write including E000 and F000 shadow areas but closing

SMRAM.

50 Chapter 4

Checkpoint Description

DA Restore CPUID value back into register. Give control to BIOS POST (ExecutePOSTKernel).

See POST Code Checkpoints section of document for more information.
DC System is waking from ACPI S3 state.
E1-E8 EC-

EE

OEM memory detection/configuration error. This range is reserved for chipset vendors &

system manufacturers. The error associated with this value may be different from one

platform to the next.

Chapter 4 51

Bootblock Recovery Code Checkpoints

The Bootblock recovery code gets control when the BIOS determines that a BIOS recovery needs to occur
because the user has forced the update or the BIOS checksum is corrupt. The following table describes the
type of checkpoints that may occur during the Bootblock recovery portion of the BIOS.

NOTE: Checkpoints may differ between different platforms based on system configuration. Checkpoints

maychange due to vendor requirements, system chipset or option ROMs from add-in PCI devices.

Checkpoint Description

E0 Initialize the floppy controller in the super I/O. Some interrupt vectors are initialized. DMA

controller is initialized. 8259 interrupt controller is initialized. L1 cache is enabled.
E9 Set up floppy controller and data. Attempt to read from floppy.
EA Enable ATAPI hardware. Attempt to read from ARMD and ATAPI CDROM.
EB Disable ATAPI hardware. Jump back to checkpoint E9.
EF Read error occurred on media. Jump back to checkpoint EB.
F0 Search for pre-defined recovery file name in root directory.
F1 Recovery file not found.
F2 Start reading FAT table and analyze FAT to find the clusters occupied by the recovery file.
F3 Start reading the recovery file cluster by cluster.
F5 Disable L1 cache.
FA Check the validity of the recovery file configuration to the current configuration of the flash

part.
FB Make flash write enabled through chipset and OEM specific method. Detect proper flash

part. Verify that the found flash part size equals the recovery file size.
F4 The recovery file size does not equal the found flash part size.
FC Erase the flash part
FD Program the flash part.
FF The flash has been updated successfully. Make flash write disabled. Disable ATAPI

hardware. Restore CPUID value back into register. Give control to F000 ROM at

F000:FFF0h.

52 Chapter 4

BIOS Recovery

1. Copy the target BIOS rom file to a USB disk. Rename the target BIOS to “amiboot.rom”.Plug the USB disk
to computer that you want to recovery the system BIOS.

2. Power on the system, BIOS recovery will be done. Wait for about 3 minutes the system will reboot
automatically after flash update completed successfully.

3. Press “Del” Key to enter BIOS Setup.

4. Choose “ Load Default Settings ” and press “ Enter ” key.

4-1.Choose “ OK ” and press “Enter ” key.

5. Choose “Save & Exit Setup ” and press “Enter” key.

5-1.Choose “ OK ” and press “Enter ” key.

6. AMIBIOS Recovery is finished.

Chapter 4 53

Jumper and Connector Information

M/B Placement

Chapter 5

Chapter 5 54

No Label Description No Label Description

1 CPU Socket AM3 938 socket for

CPU

3 CPU_FAN CPU fan power

header

5 MB_ID1~2 GPIO connector 6 PWR1 M/B main power

7 SATA1~6 SATA data transfe

connector

9 F_USB2~4 Card reader USB

headers
11 SYS_FAN SYS fan header 12 SPI SPI header
?13 HBIOS_WP BIOS write protect

header
15 SPDIF_OUT SPDIF out header 16 F_AUDIO Front panel audio

17 PCI1 PCI socket 18 PCIE_1X1 PCIE_1x1 socket
19 PCIE_1X PCIE_1x socket 20 PCI-E1_16X PCIE_x16socket

2 PWR2 CPU Power

connector

4 DIMM CONN,DIMM,DDRIII,

1.5V,Blu,1mm,G/
F,G,DIP-240

connector

8 F_PANEL Front panel switch/

LED

10 F_USB1 Front panel USB

headers

14 CLR_CMOS Clear CMOS jumpers

header

55 Chapter 5

Jumper Setting

The section explains how to set jumper for correct configuration of the mainboard.

Setting Jumper

Use the motherboard jumpers to set system configuration options. Jumpers with more Than one pin are
numbered. When setting the jumpers, ensure that the jumper caps are Placed on the correct pins.

Internal header pin definition

Jumper/Header Name Function Definition

CPU FAN HEADER 1: SENSE

2: POWER

CPU_FAN (3 PIN)

Header_1X3

CPU_FAN

1
2
3

3: GND

SYS_FAN (3 PIN)

CLR_CMOS (3 PIN)

SYS FAN HEADER

Yellow is symb ol, Red is Pin 1 of symbol.
CLEAR CMOS HEADER

1: SENSE
2: POWER
3: GND

1-2:CLEAR_CMOS
(1:Ground, 2:RTC_RSTJ)

2-3:NORMAL
(3:VCC_RTC)

Yellow is symb ol, Red is Pin 1 of symbol.

Chapter 5 56

Jumper/Header Name Function Definition

OBR

F_USB1, F_USB2, F_USB3,

F_USB4

System Recover HEADER

Yellow is symb ol, Red is Pin 1 of symbol.
FRONT USB HEADER (2X5)

Yellow is symb ol, Red is Pin 1 of symbol.

1:SYS_RECOVER
2: GND

1. VCC5

2. VCC5

3. D1-

4. D0-

5. D1+

6. D0+

7. GND

8. GND

9. KEY

10. GND

FRONT PANEL AUDIO HEADER (2X5)

F_AUDIO

Yellow is symb ol, Red is Pin 1 of symbol.

57 Chapter 5

1: A_MIC2_L
2: GND_AUDIO
3: A_MIC2_R
4: FP_AUD_DETECT
5: A_LINE2_R
6: A_MIC2_JD
7: GND_AUDIO
8: KEY
9: A_LINE2_L
10: A_LINE2_JD

Jumper/Header Name Function Definition

F_1394

F_PANEL

FRONT 1394 HEADER

Yellow is symb ol, Red is Pin 1 of symbol.
Front panel header

1. 1394_TPA0P_C

2. 1394_TPA0N_C

3. GND

4. GND

5. 1394_TPB0P_C

6. 1394_TPB0N_C

7. 1394_POW_CON_A

8. 1394_POW_CON_A

9. KEY

10. GND

1: HDD+ (PU 5V_S0)
2: PWRLED_PN2(PU

5V_S5)
3: HDD_LED
4: PWRLED_PN4(PU

5V_S5)
5: GND
6: PANSWHJ_C
7: SYS_RSTJ
8: GND
9: FP_9(PU 5V_S0)
10: KEY
11: NC
12: FP_LANLED
13: NC
14: LAN_LED

Yellow is symb ol, Red is Pin 1 of symbol.

TPM TPM Header 1: LCLK 2: GND

3: LFRAMEn
4: KEY 5: LRESETn
6: NC 7: LAD3
8: LAD2
9: VDD(3.3V)
10: LAD1 11: LAD0
12: GND 13: NC
14: NC 15: NC
16: SERIRQ
17: GND
18: CLKRUNin
19: LPCPDn
20: NC

Chapter 5 58

Jumper/Header Name Function Definition

LPT

Printer Header

Yellow is symb ol, Red is Pin 1 of symbol.

1: STRBJ
2: AFDJ
3: PRP_D0
4: PRERRJ
5:PRP_D1
6: INITJ
7: PRP_D2
8: SLINJ
9: PRP_D3
10: GND
11: PRP_D4
12: GND
13: PRP_D5
14: GND
15: PRP_D6
16: GND
17: PRP_D7
18: GND
19: PACKJ
20: GND
21: PBUSY
22: GND
23: PE
24: GND
25: PSLCT
26:NC

SPEAKER

Audio internal speaker header

Yellow is symb ol, Red is Pin 1 of symbol.

1: MONO_L
2: GND
3: MONO_R
4: KEY
5: GND
6: GND
7: VCC3
8: VCC5

59 Chapter 5

Jumper/Header Name Function Definition

1: VCC (5V_SYS)
2: KEY
3: A_SPDIF_OUT1

SPDIF_OUT, SPDIF_OUT1

4: GND

Yellow is symb ol, Red is Pin 1 of symbol.

1. JDCD2J

2. JSIN2

3. JSOUT2

1 2
3
5
7 8
9

COM2

COM2

4
6

X

Header_2X 5_K10

@Commercial

4. JDTR2J

5. GND

6. JDSR2J

7. JRTS2J

8. JCTS2J

9. JRI2J

10. KEY

Yellow is symb ol, Red is Pin 1 of symbol.

Chapter 5 60

USB CONNECTORS (Stacked)(Black)

USB_X4

Pin Signal Name

"1 1,21,31,41" VCC_USB1
12 USBP3N_R
13 USBP3P_R
14 Ground
22 USBP2N_R
23 USBP2P_R
24 Ground
32 USBP5N_R
33 USBP5P_R
34 Ground
42 USBP4N_R
43 USBP4P_R
44 Ground
"45,46,47,48,

49,50"

Ground

61 Chapter 5

11.2.2LAN-USB_X2

"1, 5" VCC_USB0 (5V)
2 USBP7N_R
3 USBP6N_R
"4, 8" GND
6 USBP6N_R
7 USBP6P_R
"23,24,25,26,

27,28,29,30"
9 AVDD18
10 MDI0+
11 MDI0­12 MDI1+
13 MDI1­14 MDI2+
15 MDI2­16 MDI3+
17 MDI3­18 GND
19 ACT_LED
20 LAN_LINK_LED
21 100_LED
22 1G_LED

Pin Signal Name

Ground

NOTE: Pins 9-18 for RJ-45 LAN Jack pin definition, 19-22 for LAN LED defi n i ti o n

Chapter 5 62

Audio Back Panel Connectors

AUDIO1A (MIC)

Pin Signal Name

1 GND_AUDIO
2 A_MIC1_L
3 A_MIC1_JD
4 GND_AUDIO
5 A_MIC1_R

AUDIO1B (Line in)

Pin Signal Name

31 GND_AUDIO
32 A_LOUT_L
33 A_LOUT_JD
34 GND_AUDIO
35 A_LOUT_R

AUDIO1C (Line out)

Pin Signal Name

21 GND_AUDIO
22 A_LINE1_L
23 A_LINE1_JD
24 GND_AUDIO
25 A_LINE1_R

IDE / SATA

40-pin (2x20) IDE Headers

1 IDERST 2 Ground
3PIDE_D7 4PIDE_D8
5 PIDE_D 6 6 PIDE_D 9
7 PIDE_D 5 8 PIDE_D 10
9 PIDE_D 4 10 PIDE_D 11
11 PIDE_D 3 12 PIDE_D 12
13 PIDE_D 2 14 PIDE_D 13
15 PIDE_D 1 16 PIDE_D 14
17 PIDE_D 0 18 PIDE_D 15
19 Ground 20 Key
21 PIDE_DREQ 22 Ground
23 PIDE_IOWJ 24 Ground
25 PIDE_IORJ 26 Ground
27 PIDE_RDY 28 Ground
29 PIDE_PACKJ 30 Ground
31 PIDE_IRQ 32 N/C

Pin Signal Name Pin Signal Name

63 Chapter 5

Pin Signal Name Pin Signal Name

33 PIDE_A1 34 PD_DMA66
35 PIDE_A0 36 PIDE_A2
37 PIDE_CS1J 38 PIDE_CS3J
39 PATA_LEDJ 40 Ground

1x7-pin SATA Headers

Pin Signal Name

1GND
2SATA_TX0+_
3 SATA_TX0-_C
4GND
5SATA_RX0-_C
6SATA_RX0+_C
7GND
8 KEY
9 KEY

VGA

HDMI

Pin Signal Name

1R
2G
3B
4ID0
5GND
6GND
7GND
8GND
9 NC (5V_VGA)
10 GND
11 ID1
12 SDA
13 HSYNC
14 VSYNC
15 SCL

Pin Signal Name

1 HDMI_TXDP2_C
2GND

Chapter 5 64

Pin Signal Name

3 HDMI_TXDN2_C
4 HDMI_TXDP1_C
5GND
6 HDMI_TXDN1_C
7 HDMI_TXDP0_C
8GND
9 HDMI_TXDN0_C
10 HDMI_TXCP_C
11 GND
12 HDMI_TXCN_C
13 NC
14 NC
15 HDMI_DDCCLK_C
16 HDMI_DDCDATA_C
17 GND
18 5V_HDMI_C
19 HP_DET_C
20 GND
21 GND

DVI-D

PS2

Pin Signal Name Pin Signal Name

1 DVI_TXDN2_C 13 NC
2 DVI_TXDP2_C 14 5V_HDMI_C
3GND 15GND
4NC 16HP_DET_C
5 NC 17 DVI_TXDN0_C
6 HDMI_DDCCLK_C 18 DVI_TXDP0_C
7 HDMI_DDCDATA_C 19 GND
8NC 20NC
9 DVI_TXDN1_C 21 NC
10 DVI_TXDP1_C 22 GND
11 GND 23 DVI_TXCP_C
12 NC 24 DVI_TXCN_C

Pin Signal Name Pin Signal Name

1 KB_DA 10 KBVCC (5V_DUAL)
2NC 11MS_CK
3GND 12NC
4 KBVCC (5V_DUAL) 13 GND
5 KB_CK 14 GND
6NC 15GND

65 Chapter 5

COM

Pin Signal Name Pin Signal Name

7MS_DA 16GND
8NC 17GND
9GND

Pin Signal Name

1 JDCD1J
2JSIN1
3JSOUT1
4JDTR1J
5,10,1 1 GND
6 JDSR1J
7JRTS1J
8JCTS1J
9JRI1J

Chapter 5 66

Chapter 6

FRU (Field Replaceable Unit) List

This chapter offers the FRU (Field Replaceable Unit) list in global configuration of the Aspire M5400(G)
desktop computer. Refer to this chapter whenever ordering the parts to repair or for RMA (Return Merchandise
Authorization).

NOTES:

• When ordering FRU parts, check the most up-to-date information available on your regional web

or channel. For whatever reasons a part number is changed, it will NOT be noted on the printed
Service Guide. For Acer authorized service providers, your Acer office may have a different part
number code from those given in the FRU list of this printed Service Guide. You MUST use the
local FRU list provided by your regional Acer office to order FRU parts for service.

• To scrap or to return the defective parts, follow the local government ordinance or regulations on

how to dispose it properly, or follow the rules set by your regional Acer office on how to return it.

• This document will be updated as more information about the FRU list becomes available.

chapter 6 67

Aspire M5400(G) Exploded Diagram(AM551 ASSY)

NOTE: This section will be updated when more information becomes available.

ITEM NAME Q’TY ITEM NAME Q’TY

1 CHASSIS ASM 1 5 FRONT BEZEL 1
2 TOP-COVER 1 6 HDD COVER 1
3ODD 17SIDE COVER 1
4 REMOVABLE HDD CARRIER 2 8 POWER 1

68 Chapter 6

Aspire M5400(G) Exploded Diagram(AM550 ASSY)

NOTE: This section will be updated when more information becomes available.

ITEM NAME Q’TY ITEM NAME Q’TY

1 CHASSIS ASM 1 5 FRONT BEZEL 1
2 TOP-COVER 1 6 HDD COVER 1
3ODD 17SIDE COVER 1
4 REMOVABLE HDD CARRIER 2 8 POWER 1

Chapter 6 69

Aspire M5400(G) FRU List

Category Part Number Acer P/N

MB Kit

Mainboard FRS880F consumer MB.SE109.001
Mainboard FRS880F consumer Support 140W CPU MB.SE109.003

IO Shielding

Rear I/O Shielding for MB TBD

Chassis

Micro-Tower chassis HM090H for AM550 HS.13100.117
Micro-Tower chassis HM090K for AM551 HS.13100.124

Bezel

CPU Cooler

System Fan

CPU

Aspire Bezel AM550 PZ.11900.175
Aspire Bezel AM551 PZ.11900.182

Fan Cooler K8_M2 FXC PKP482 Fan8025 HI.12900.026
Fan Cooler K8_M2 AVC Z7UB008 AVC fan7015 HI.12900.001
Cooler AMD AVC Z8UH408002 (for 125W/140W) HI.12900.021

System Fan KDE 1209/GP 92*92*25 (Rohs) HI.S150F.002

AMD Phenom II 965 KC.PM202.965
AMD Phenom II 955 KC.PM202.955
AMD Phenom II B95 KC.PH202.B95
AMD Phenom II 740 KC.PH202.740
AMD Phenom II 720 KC.PH202.720
AMD Phenom II B75 KC.PH202.B75

70 Chapter 6

Memory

Category Part Number Acer P/N

AMD Phenom II 555 KC.PH202.555
AMD Phenom II 550 KC.PM202.550
AMD Phenom II B55 KC.PH202.B55
AMD Athlon II x4 640 KC.AM202.640
AMD Athlon II x4 635 KC.AM202.635
AMD Athlon II x4 605e KC.AE202.605
AMD Athlon II x3 445 KC.AM202.445
AMD Athlon II x3 440 KC.AM202.440
AMD Athlon II x2 255 KC.AT202.255
AMD Athlon II x2 250 KC.AT202.250
AMD Athlon II x2 B24 KC.AT202.B24
AMD Athlon II 160u KC.AU202.160
SEMPRON 140 KC.SMP02.140

DDRIII 1333MHz 1GB KN.1GB0H.015
DDRIII 1333MHz 1GB TBD
DDRIII 1333MHz 1GB KN.1GB0B.030
DDRIII 1333MHz 1GB KN.1GB0B.036
DDRIII 1333MHz 1GB TBD
DDRIII 1333MHz 1GB KN.1GB01.031
DDRIII 1333MHz 1GB KN.1GB07.002
DDRIII 1333MHz 1GB KN.1GB0C.008
DDRIII 1333MHz 1GB KN.1GB0F.005
DDRIII 1333MHz 2GB KN.2GB0H.009
DDRIII 1333MHz 2GB KN.2GB03.018
DDRIII 1333MHz 2GB KN.2GB0B.014
DDRIII 1333MHz 2GB KN.2GB0B.024
DDRIII 1333MHz 2GB TBD
DDRIII 1333MHz 2GB KN.2GB01.025
DDRIII 1333MHz 2GB KN.2GB07.002
DDRIII 1333MHz 2GB KN.2GB0C.005
DDRIII 1333MHz 2GB KN.2GB0F.004
DDRIII 1333MHz 4GB TBD
DDRIII 1333MHz 4GB TBD
DDRIII 1333MHz 4GB TBD
DDRIII 1333MHz 4GB TBD

Chapter 6 71

HDD

Category Part Number Acer P/N

HDD HGST 3.5" 7200rpm 160GB HDT721016SLA380
Saturn SATA II LF F/W:31B

HDD HGST 3.5" 7200rpm 160GB Jupiter KH.16007.027
HDD HGST 3.5" 7200rpm 320GB HDT721032SLA380

Saturn SATA II LF F/W:31B
HDD HGST 3.5" 7200rpm 320GB Jupiter KH.32007.011
HDD HGST 3.5" 7200rpm 500GB Jupiter KH.50007.012
HDD HGST 3.5" 7200rpm 640GB Satum SATA II LF KH.64007.001
HDD HGST 3.5" 7200rpm 640GB Jupiter KH.64007.002
HDD HGST 3.5" 7200rpm 1000GB HDT721010SLA360

Saturn SATA II 16MB LF F/W:31B
HDD HGST 3.5" 7200rpm 1000GB Jupiter KH.01K07.003
HDD SEAGATE 3.5" 7200rpm 160G KH.16001.041
HDD SEAGATE 3.5" 7200rpm 320G KH.32001.015
HDD SEAGATE 3.5" 7200rpm 500G KH.50001.012
HDD SEAGATE 3.5" 7200rpm 640G KH.64001.002
HDD SEAGATE 3.5" 7200rpm 1000G KH.01K01.007
HDD SEAGATE 3.5" 7200rpm 1500G KH.15K01.002

KH.16007.023

KH.32007.006

KH.01K07.002

ODD

HDD WD 3.5" 7200rpm 160G KH.16008.025
HDD WD 3.5" 7200rpm 320G KH.32008.016
HDD WD 3.5" 7200rpm 500G KH.50008.014
HDD WD 3.5" 7200rpm 640G KH.64008.003
HDD WD 3.5" 7200rpm 750G KH.75008.005
HDD WD 3.5" 7200rpm 1000G KH.01K08.004
HDD WD 3.5" 5400rpm 1000G KH.01K08.005
HDD WD 3.5" 5400rpm 1000G KH.01K08.008
HDD WD 3.5" 5400rpm 1500G KH.15K08.001
HDD WD 3.5" 5400rpm 2000G KH.02K08.001

ODD HLDS DVD-ROM HH 16X DH20N LF+HF Black Bezel
SATA w/Win7

ODD PLDS DVD-ROM HH DL 16X DH-16D5SH LF+HF
Black Bezel SATA w/Win7

ODD TSST DVD-ROM w/Win7 KV.01601.001
ODD HLDS Super-Multi DRIVE HH 16X GH41N Black Bezel

SATA HF + Win 7

KV.0160D.016

KV.0160F.002

KU.0160D.049

ODD PLDS Super-Multi DRIVE HH 16X DH-16AASH Black
Bezel SATA HF+Win7

KU.0160F.009

72 Chapter 6

Category Part Number Acer P/N

ODD TSST Super-Multi with LF KU.01601.007

VGA

ODD PLDS BD ROM HH DL 4X DH-4O3S LF Standard
Bezel SATA

ODD HLDS BD COMBO HH 6X CH-20N (H/F) Black Bezel
SATA w/ WIN7

ODD PLDS BD COMBO HH 6X DH-6E2S Black Bezel SA TA
w/ Win 7

ODD HLDS BD RW HH 6X BH30N Black Bezel SATA HF
+Win7

ODD HLDS BD RW HH 6X BH20F Black Bezel SATA (Win7
FW)

288-1N143-010AC NV GT340 1GB DDR5 DVI+HDMI+VGA
ATX (HYNIX)

288-1N143-110AC GEFORCE GT340 1GB GDDR5
SAMSUNG (128BITS) VGA DVI HDMI ATX BRACKET
ROHS

288-30N58-010AC NV GT330 2GB DDR2 DVI+HDMI+VGA
ATX (SAMSUNG)

288-30N58-110AC NV GT330 2GB DDR2 DVI+HDMI+VGA
ATX (HYNIX)

288-5N118-010AC NV GT320 1GB sDDR3 DVI+HDMI+VGA
ATX (SAMSUNG)

KV.0040F.002

KO.0060D.005

KO.0060F.002

KU.0060D.004

KU.0060D.005

VG.PCPT3.401

VG.PCPT3.402

VG.PCPT3.301

VG.PCPT3.302

VG.PCPT3.201

288-5N118-110AC NV GT320 1GB sDDR3 DVI+HDMI+VGA
ATX (HYNIX)

288-6N118-010AC GEFORCE GT320 1GB DDR3
SAMSUNG (128BITS) VGA DVI HDMI ATX BRACKET
ROHS WITH CU COOLER

288-1N141-A00AC NV 315 512MB sDDR3 DVI+HDMI ATX
(SAMSUNG)

288-1N141-000AC NV 315 512MB sDDR3 DVI+HDMI+VGA
ATX (SAMSUNG)

288-1N141-000AC NV 315 512MB sDDR3 DVI+HDMI+VGA
ATX (HYNIX)

288-40N44-020AC GEFORCE 310 512MB DDR2
SAMSUNG (64BITS) VGA DVI HDMI ATX BRACKET ROHS

288-40N44-120AC GEFORCE 310 512MB DDR2 HYNIX
(64BITS) VGA DVI HDMI ATX BRACKET ROHS

HD5750 1GB GDDR 5 (128BITS) HYNIX DVI DVI HDMI DP
W/ATX BKT ROHS

288-1E160-000AC HD5750 1GB GDDR 5 (128BITS)
SAMSUNG DVI HDMI VGA W/ATX BKT ROHS

288-2E142-100AC HD5570 1GB DDR3 (128BITS) Hynix DVI
HDMI VGA W/ATX BKT ROHS

288-2E142-100AC HD5570 1GB DDR3 (128BITS) Samsung
DVI HDMI VGA W/ATX BKT ROHS

VG.PCPT3.202

VG.PCPT3.221

VG .PCPT3.153

VG.PCPT3.151

VG.PCPT3.152

VG.PCPT3.101

VG.PCPT3.102

VG .APC57.501

VG.APC57.502

VG.APC55.702

VG.APC55.701

Chapter 6 73

Category Part Number Acer P/N

ATI HD4650 1GB DSUB/HDMI/DVI ATX VG.APC46.501

TV-Tuner

Card Reader

288-1E127-010AC HD5450 512MB SDDR 3 (64BITS)
SAMSUNG DUAL DVI PASSIVE W/ATX BKT ROHS

288-1E127-110AC HD5450 512MB SDDR 3 (64BITS)
HYNIX DUAL DVI PASSIVE W/ATX BKT ROHS

288-1E145-A01AC HD5450 512MB SDDR 3 (64BITS)
SAMSUNG DVI HDMI W/LP BKT ROHS

288-1E145-001AC HD5450 512MB SDDR 3 (64BITS)
SAMSUNG DVI HDMI VGA W/ATX BKT ROHS

288-1E145-101AC HD5450 512MB SDDR 3 (64BITS)
HYNIX DVI HDMI VGA W/ATX BKT ROHS

AMD RADEON HD5450 512MB (64BIT) DDR3 DVI HDMI
VGA ATX BRACKET ROHS

Avermedia H751-A TV Tuner Card PCIe Hybrid ATSC, S/W
Encoder

Avermedia H751-D TV Tuner Card PCIe Hybrid DVB-T, S/W
Encoder

16-in-1 CR Reealtek RTS-5181, 720mm USB cable for 2010 M5CR.10400.116

16-in-1 CR RI236 UT330-LK, 720mm USB cable for 2010 M5 CR.10400.115

VG.APC54.5P1

VG.APC54.5P2

VG.APC54.511

VG.APC54.501

VG.APC54.502

VG.ECS54.501

TU.10500.045

TU.10500.048

Modem

D-1156I#/A7A, Modem PCI card, LSI Universal Modem (PCI)
56K V.92 - Pinball (P40)

WLAN

WN7600R, WLAN PCI-Ex1 card 802.11 b/g/n 1T x 2R, Ralink
1T x 2R, RT2790+RT2720

WN7601R, Ralink RT3090, 802.11b/g/n 1x1 WLAN PCI-E x1
card

FX.10100.004

NI.10200.008

NI.10200.037

74 Chapter 6

Power Supply

Mouse

Category Part Number Acer P/N

Non-PFC 250W (30L) EuP PY.25009.014
Non-PFC 250W (30L) EuP PY.25008.031
PFC 250W (30L) EuP PY.25009.015
PFC 250W (30L) EuP PY.25008.032
Non-PFC 300W (30L) EuP PY.3000B.015
Non-PFC 300W (30L) EuP PY.30008.028
FR 300W (30L) 82+ EuP PY.30009.019
FR 300W (30L) 82+ EuP PY.30008.029
FR 500W (30L) 82+ EuP PY.50008.004
FR 500W (30L) 82+ EuP PY.5000B.003

Acer 0810 Project PS2 Optical mouse MS.11200.013
Logitech 0810_USB Optical mouse USB M-UAY-ACR2 MS.11200.014
Lite-On PS2 optical mouse PS2 SM-9620 MS.11200.017
Lite-On USB optical USB SM-9625 MS.11200.018

Speaker

Remote control

Lite-on Optical mouse USB SM-9625S with new color AC­MT-018

Chicony RF2.4G mouse RF2.4G MG-0766 MS.11200.015
Chicony 2.4G Dangle Receiver external receiver RV.11000.010

Neosonica Speaker Acer logo /LF /0810 / 9M-20A200-000 SP.10600.011
Neosonica Speaker USB with new color AC-MT-018 SP.10600.027

Philips Remote Controller RC2604307/01BG for EMEA ;pair
with RV.11000.007

Philips Vista receiver OVU71 RV.11000.007
Philips Remote Controller RC2604301/01B MSFT code

EMEA;pair with OVU430008
Philips Remote Controller RC2604302/01B MSFT code

US;pair with OVU430008
Philips Win7 OVU430008 with IR blaster RV.11000.023

MS.11200.048

RT.11300.021

RT.11300.023

RT.11300.022

SMK Transceiver Win7 RXX6000-4111E with IR Blaster RV.11000.024
SMK Remote Controller US RRS9003-3406E SMK Quatro

Pulse;with Battery Pack

RT.11300.025

Chapter 6 75

Category Part Number Acer P/N

Keyboard

SMK Remote Controller Japan RRS9003-3407EC Quatro
Pulse

Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black
US w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black
Traditional Chinese w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black
Simplified Chinese w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black
US International w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black
Arabic/English w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black
Thailand w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Spanish w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Portuguese w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Canadian French w/o Aspire logo

RT.11300.026

KB.RF403.061

KB.RF403.062

KB.RF403.063

KB.RF403.064

KB.RF403.065

KB.RF403.066

KB.RF403.067

KB.RF403.068

KB.RF403.069

Keyboard CHICONY KG-0766 RF2.4 Standard 107KS Black
Brazilian Portuguese w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
German w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Italian w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
French w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Swedish w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
UK w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Dutch w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Swiss/G w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Belgium w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Icelandic w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Norwegian w/o Aspire logo

KB.RF403.070

KB.RF403.072

KB.RF403.073

KB.RF403.074

KB.RF403.075

KB.RF403.076

KB.RF403.077

KB.RF403.078

KB.RF403.079

KB.RF403.080

KB.RF403.081

Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black
Hebrew w/o Aspire logo

KB.RF403.082

76 Chapter 6

Category Part Number Acer P/N

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Polish w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Slovenian w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Slovak w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black
Russian w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Hungarian w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black
Greek w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Danish w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black
Czech w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Romanian w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Turkish w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Spanish Latin w/o Aspire logo

KB.RF403.083

KB.RF403.084

KB.RF403.085

KB.RF403.086

KB.RF403.087

KB.RF403.088

KB.RF403.089

KB.RF403.090

KB.RF403.091

KB.RF403.092

KB.RF403.093

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Turkish-Q w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Nordic w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Czech/Slovak

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
English/Canadian French w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Arabic/French w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Kazakh w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black
Turkmen w/o Aspire logo

Keyboard CHICONY KG-0766 RF2.4 Standard 109KS
Japanese with J1 layout

Keyboard CHICONY KB-0759 PS/2 Standard 104KS Black
US w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 104KS Black
Traditional Chinese w/o eKey

KB.RF403.094

KB.RF403.095

KB.RF403.285

KB.RF403.288

KB.RF403.521

KB.RF403.522

KB.RF403.523

KB.RF403.283

KB.PS203.284

KB.PS203.285

Keyboard CHICONY KB-0759 PS/2 Standard 104KS Black
Simplified Chinese w/o eKey

KB.PS203.286

Chapter 6 77

Category Part Number Acer P/N

Keyboard CHICONY KB-0759 PS/2 Standard 104KS Black
US International w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 104KS Black
Arabic/English w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 104KS Black
Thailand w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 105KS Black
Spanish w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 105KS Black
Portuguese w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 105KS Black
Canadian French w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 107KS Black
Brazilian Portuguese w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 105KS Black
German w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 105KS Black
Italian w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 105KS Black
French w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 105KS Black
Swedish w/o eKey

KB.PS203.287

KB.PS203.288

KB.PS203.289

KB.PS203.290

KB.PS203.291

KB.PS203.292

KB.PS203.293

KB.PS203.295

KB.PS203.296

KB.PS203.297

KB.PS203.298

Keyboard CHICONY KB-0759 PS/2 Standard 105KS Black
UK w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 105KS Black
Dutch w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 105KS Black
Swiss/G w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 105KS Black
Belgium w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 105KS Black
Icelandic w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 105KS Black
Norwegian w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 104KS Black
Hebrew w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 105KS Black
Polish w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 105KS Black
Slovenian w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 105KS Black
Slovak w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 104KS Black
Russian w/o eKey

KB.PS203.299

KB.PS203.300

KB.PS203.301

KB.PS203.302

KB.PS203.303

KB.PS203.304

KB.PS203.305

KB.PS203.306

KB.PS203.307

KB.PS203.308

KB.PS203.309

Keyboard CHICONY KB-0759 PS/2 Standard 105KS Black
Hungarian w/o eKey

KB.PS203.310

78 Chapter 6

Category Part Number Acer P/N

Keyboard CHICONY KB-0759 PS/2 Standard 104KS Black
Greek w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 105KS Black
Danish w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 104KS Black
Czech w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 105KS Black
Romanian w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 105KS Black
Turkish w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 105KS Black
Spanish Latin w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 105KS Black
Turkish-Q w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 105KS Black
Arabic/French w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 104KS Black
Kazakh w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 104KS Black
Turkmen w/o eKey

Keyboard CHICONY KB-0759 PS/2 Standard 105KS Black
Nordic w/o eKey

KB.PS203.311

KB.PS203.312

KB.PS203.313

KB.PS203.314

KB.PS203.315

KB.PS203.316

KB.PS203.317

KB.PS203.318

KB.PS203.319

KB.PS203.320

KB.PS203.321

Keyboard CHICONY KB-0759 PS/2 Standard 104KS Black
Simplified Chinese w/o eKey , w/i farmer PC label

Keyboard CHICONY KB-0759 PS/2 Standard 104KS Black
US w/o eKey , w/i farmer PC label

Keyboard CHICONY KB-0759 PS/2 Standard 105KS Black
English/Canadian French

Keyboard CHICONY KB-0759 PS/2 Standard 105KS Black
Czech/Slovak

Keyboard CHICONY KB-0759 PS/2 Standard 109KS Black
Japanese with J1 layout

Keyboard LITE-ON SK-9620 PS/2 Standard 104KS Black US
w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 104KS Black
Traditional Chinese w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 104KS Black
Simplified Chinese w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 104KS Black US
International w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 104KS Black
Arabic/English w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 104KS Black
Thailand w/o eKey

KB.PS203.322

KB.PS203.323

KB.PS203.328

KB.PS203.331

KB.PS203.330

KB.PS20B.069

KB.PS20B.070

KB.PS20B.071

KB.PS20B.072

KB.PS20B.073

KB.PS20B.074

Keyboard LITE-ON SK-9620 PS/2 Standard 105KS Black
Spanish w/o eKey

KB.PS20B.075

Chapter 6 79

Category Part Number Acer P/N

Keyboard LITE-ON SK-9620 PS/2 Standard 105KS Black
Portuguese w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 105KS Black
Canadian French w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 107KS Black
Brazilian Portuguese w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 105KS Black
German w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 105KS Black
Italian w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 105KS Black
French w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 105KS Black
Swedish w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 105KS Black UK
w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 105KS Black
Dutch w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 105KS Black
Swiss/G w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 105KS Black
Belgium w/o eKey

KB.PS20B.076

KB.PS20B.077

KB.PS20B.078

KB.PS20B.080

KB.PS20B.081

KB.PS20B.082

KB.PS20B.083

KB.PS20B.084

KB.PS20B.085

KB.PS20B.086

KB.PS20B.087

Keyboard LITE-ON SK-9620 PS/2 Standard 105KS Black
Icelandic w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 105KS Black
Norwegian w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 104KS Black
Hebrew w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 105KS Black
Polish w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 105KS Black
Slovenian w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 105KS Black
Slovak w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 104KS Black
Russian w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 105KS Black
Hungarian w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 104KS Black
Greek w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 105KS Black
Danish w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 104KS Black
Czech w/o eKey

KB.PS20B.088

KB.PS20B.089

KB.PS20B.090

KB.PS20B.091

KB.PS20B.092

KB.PS20B.093

KB.PS20B.094

KB.PS20B.095

KB.PS20B.096

KB.PS20B.097

KB.PS20B.098

Keyboard LITE-ON SK-9620 PS/2 Standard 105KS Black
Romanian w/o eKey

KB.PS20B.099

80 Chapter 6

Category Part Number Acer P/N

Keyboard LITE-ON SK-9620 PS/2 Standard 105KS Black
Turkish w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 105KS Black
Spanish Latin w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 105KS Black
Turkish-Q w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 105KS Black
Arabic/French w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 104KS Black
Kazakh w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 104KS Black
Turkmen w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 105KS Black
Nordic w/o eKey

Keyboard LITE-ON SK9620 PS/2 Standard 104KS Black
Thailand with 2.5m cable

Keyboard LITE-ON SK9620 PS/2 Standard 105KS Black
English/Canadian French

Keyboard LITE-ON SK-9620 PS/2 Standard 105KS Black
Czech/Slovak w/o eKey

Keyboard LITE-ON SK-9620 PS/2 Standard 109KS
Japanese with J1 layout

KB.PS20B.100

KB.PS20B.101

KB.PS20B.102

KB.PS20B.103

KB.PS20B.104

KB.PS20B.105

KB.PS20B.106

KB.PS20B.108

KB.PS20B.109

KB.PS20B.107

KB.PS20B.110

Keyboard CHICONY KU-0760 USB Standard 104KS Black
US w/o eKey

Keyboard CHICONY KU-0760 USB Standard 104KS Black
Traditional Chinese w/o eKey

Keyboard CHICONY KU-0760 USB Standard 104KS Black
Simplified Chinese w/o eKey

Keyboard CHICONY KU-0760 USB Standard 104KS Black
US International w/o eKey

Keyboard CHICONY KU-0760 USB Standard 104KS Black
Arabic/English w/o eKey

Keyboard CHICONY KU-0760 USB Standard 104KS Black
Thailand w/o eKey

Keyboard CHICONY KU-0760 USB Standard 105KS Black
Spanish w/o eKey

Keyboard CHICONY KU-0760 USB Standard 105KS Black
Portuguese w/o eKey

Keyboard CHICONY KU-0760 USB Standard 105KS Black
Canadian French w/o eKey

Keyboard CHICONY KU-0760 USB Standard 107KS Black
Brazilian Portuguese w/o eKey

Keyboard CHICONY KU-0760 USB Standard 109KS Black
Japanese w/o eKey

KB.USB03.192

KB.USB03.193

KB.USB03.194

KB.USB03.195

KB.USB03.196

KB.USB03.197

KB.USB03.198

KB.USB03.199

KB.USB03.200

KB.USB03.201

KB.USB03.202

Keyboard CHICONY KU-0760 USB Standard 105KS Black
German w/o eKey

KB.USB03.203

Chapter 6 81

Category Part Number Acer P/N

Keyboard CHICONY KU-0760 USB Standard 105KS Black
Italian w/o eKey

Keyboard CHICONY KU-0760 USB Standard 105KS Black
French w/o eKey

Keyboard CHICONY KU-0760 USB Standard 105KS Black
Swedish w/o eKey

Keyboard CHICONY KU-0760 USB Standard 105KS Black
UK w/o eKey

Keyboard CHICONY KU-0760 USB Standard 105KS Black
Dutch w/o eKey

Keyboard CHICONY KU-0760 USB Standard 105KS Black
Swiss/G w/o eKey

Keyboard CHICONY KU-0760 USB Standard 105KS Black
Belgium w/o eKey

Keyboard CHICONY KU-0760 USB Standard 105KS Black
Icelandic w/o eKey

Keyboard CHICONY KU-0760 USB Standard 105KS Black
Norwegian w/o eKey

Keyboard CHICONY KU-0760 USB Standard 104KS Black
Hebrew w/o eKey

Keyboard CHICONY KU-0760 USB Standard 105KS Black
Polish w/o eKey

KB.USB03.204

KB.USB03.205

KB.USB03.206

KB.USB03.207

KB.USB03.208

KB.USB03.209

KB.USB03.210

KB.USB03.211

KB.USB03.212

KB.USB03.213

KB.USB03.214

Keyboard CHICONY KU-0760 USB Standard 105KS Black
Slovenian w/o eKey

Keyboard CHICONY KU-0760 USB Standard 105KS Black
Slovak w/o eKey

Keyboard CHICONY KU-0760 USB Standard 104KS Black
Russian w/o eKey

Keyboard CHICONY KU-0760 USB Standard 105KS Black
Hungarian w/o eKey

Keyboard CHICONY KU-0760 USB Standard 104KS Black
Greek w/o eKey

Keyboard CHICONY KU-0760 USB Standard 105KS Black
Danish w/o eKey

Keyboard CHICONY KU-0760 USB Standard 104KS Black
Czech w/o eKey

Keyboard CHICONY KU-0760 USB Standard 105KS Black
Romanian w/o eKey

Keyboard CHICONY KU-0760 USB Standard 105KS Black
Turkish w/o eKey

Keyboard CHICONY KU-0760 USB Standard 105KS Black
Spanish Latin w/o eKey

Keyboard CHICONY KU-0760 USB Standard 105KS Black
Turkish-Q w/o eKey

KB.USB03.215

KB.USB03.216

KB.USB03.217

KB.USB03.218

KB.USB03.219

KB.USB03.220

KB.USB03.221

KB.USB03.222

KB.USB03.223

KB.USB03.224

KB.USB03.225

Keyboard CHICONY KU-0760 USB Standard 105KS Black
Arabic/French w/o eKey

KB.USB03.226

82 Chapter 6

Category Part Number Acer P/N

Keyboard CHICONY KU-0760 USB Standard 104KS Black
Kazakh w/o eKey

Keyboard CHICONY KU-0760 USB Standard 104KS Black
Turkmen w/o eKey

Keyboard CHICONY KU-0760 USB Standard 105KS Black
Nordic w/o eKey

Keyboard CHICONY KU-0760 USB Standard 104KS Black
Simplified Chinese w/o eKey; w/i farmer PC label

Keyboard CHICONY KU-0760 USB Standard 104KS Black
US w/o eKey; w/i farmer PC label

Keyboard CHICONY KU-0760 USB Standard 105KS Black
English/Canadian French

Keyboard CHICONY KU-0760 USB Standard 105KS Black
Czech/Slovak

Keyboard CHICONY KU-0760 USB Standard 109KS
Japanese with J1 layout

Keyboard LITE-ON SK-9625 USB Standard 104KS Black US
w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 104KS Black
Traditional Chinese w/o eKey

KB.USB03.227

KB.USB03.228

KB.USB03.229

KB.USB03.230

KB.USB03.232

KB.USB03.246

KB.USB03.311

KB.USB03.309

KB.USB0B.158

KB.USB0B.159

Keyboard LITE-ON SK-9625 USB Standard 104KS Black
Simplified Chinese w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 104KS Black US
International w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 104KS Black
Arabic/English w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 104KS Black
Thailand w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 105KS Black
Spanish w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 105KS Black
Portuguese w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 105KS Black
Canadian French w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 107KS Black
Brazilian Portuguese w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 109KS Black
Japanese w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 105KS Black
German w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 105KS Black
Italian w/o eKey

KB.USB0B.160

KB.USB0B.161

KB.USB0B.162

KB.USB0B.163

KB.USB0B.164

KB.USB0B.165

KB.USB0B.166

KB.USB0B.167

KB.USB0B.168

KB.USB0B.169

KB.USB0B.170

Keyboard LITE-ON SK-9625 USB Standard 105KS Black
French w/o eKey

KB.USB0B.171

Chapter 6 83

Category Part Number Acer P/N

Keyboard LITE-ON SK-9625 USB Standard 105KS Black
Swedish w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 105KS Black UK
w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 105KS Black
Dutch w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 105KS Black
Swiss/G w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 105KS Black
Belgium w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 105KS Black
Icelandic w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 105KS Black
Norwegian w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 104KS Black
Hebrew w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 105KS Black
Polish w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 105KS Black
Slovenian w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 105KS Black
Slovak w/o eKey

KB.USB0B.172

KB.USB0B.173

KB.USB0B.174

KB.USB0B.175

KB.USB0B.176

KB.USB0B.177

KB.USB0B.178

KB.USB0B.179

KB.USB0B.180

KB.USB0B.181

KB.USB0B.182

Keyboard LITE-ON SK-9625 USB Standard 104KS Black
Russian w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 105KS Black
Hungarian w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 104KS Black
Greek w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 105KS Black
Danish w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 104KS Black
Czech w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 105KS Black
Romanian w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 105KS Black
Turkish w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 105KS Black
Spanish Latin w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 105KS Black
Turkish-Q w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 105KS Black
Arabic/French w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 104KS Black
Kazakh w/o eKey

KB.USB0B.183

KB.USB0B.184

KB.USB0B.185

KB.USB0B.186

KB.USB0B.187

KB.USB0B.188

KB.USB0B.189

KB.USB0B.190

KB.USB0B.191

KB.USB0B.192

KB.USB0B.193

Keyboard LITE-ON SK-9625 USB Standard 104KS Black
Turkmen w/o eKey

KB.USB0B.194

84 Chapter 6

Category Part Number Acer P/N

Keyboard LITE-ON SK-9625 USB Standard 105KS Black
Nordic w/o eKey

Keyboard LITE-ON SK-9625 USB Standard 105KS Black
Czech/Slovak w/o ekey

Keyboard LITE-ON SK-9625 USB Standard 105KS Black
English/Canadian French

Keyboard LITE-ON SK-9625 USB Standard 105KS Black
Macedonian

Keyboard LITE-ON SK-9625 USB Standard 109KS
Japanese with J1 layout

Keyboard LITE-ON SK-9625S USB Standard 104KS Black
US with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 104KS Black
Simplified Chinese with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 104KS Black
Traditional Chinese with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 104KS Black
US International with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 104KS Black
Arabic/English with new color AC-MT-018

KB.USB0B.195

KB.USB0B.196

KB.USB0B.198

KB.USB0B.202

KB.USB0B.199

KB.USB0B.082

KB.USB0B.083

KB.USB0B.084

KB.USB0B.085

KB.USB0B.086

Keyboard LITE-ON SK-9625S USB Standard 104KS Black
Thailand with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 105KS Black
Spanish with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 105KS Black
Portuguese with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 105KS Black
Canadian French with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 107KS Black
Brazilian Portuguese with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 105KS Black
German with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 105KS Black
Italian with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 105KS Black
French with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 105KS Black
Swedish with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 105KS Black
UK with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 105KS Black
Dutch with new color AC-MT-018

KB.USB0B.087

KB.USB0B.088

KB.USB0B.089

KB.USB0B.090

KB.USB0B.091

KB.USB0B.093

KB.USB0B.094

KB.USB0B.095

KB.USB0B.096

KB.USB0B.097

KB.USB0B.098

Keyboard LITE-ON SK-9625S USB Standard 105KS Black
Swiss/G with new color AC-MT-018

KB.USB0B.099

Chapter 6 85

Category Part Number Acer P/N

Keyboard LITE-ON SK-9625S USB Standard 105KS Black
Belgium with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 105KS Black
Icelandic with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 105KS Black
Norwegian with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 104KS Black
Hebrew with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 105KS Black
Polish with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 105KS Black
Slovenian with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 105KS Black
Slovak with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 104KS Black
Russian with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 105KS Black
Hungarian with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 104KS Black
Greek with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 105KS Black
Danish with new color AC-MT-018

KB.USB0B.100

KB.USB0B.101

KB.USB0B.102

KB.USB0B.103

KB.USB0B.104

KB.USB0B.105

KB.USB0B.106

KB.USB0B.107

KB.USB0B.108

KB.USB0B.109

KB.USB0B.110

Keyboard LITE-ON SK-9625S USB Standard 104KS Black
Czech with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 105KS Black
Romanian with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 105KS Black
Turkish with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 105KS Black
Spanish Latin with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 105KS Black
Turkish-Q with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 105KS Black
Arabic/French with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 104KS Black
Kazakh with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 104KS Black
Turkmen with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 105KS Black
Nordic with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 105KS English/
Canadian French with new color AC-MT-018

Keyboard LITE-ON SK-9625S USB Standard 105KS Black
Czech/Slovak with new color AC-MT-018

KB.USB0B.111

KB.USB0B.112

KB.USB0B.113

KB.USB0B.114

KB.USB0B.115

KB.USB0B.116

KB.USB0B.117

KB.USB0B.118

KB.USB0B.119

KB.USB0B.201

KB.USB0B.197

Keyboard LITE-ON SK-9625S USB Standard 109KS
Japanese with J1 layout & new color AC-MT-018

KB.USB0B.200

86 Chapter 6

Category Part Number Acer P/N

Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black
US with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black
Traditional Chinese with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black
Simplified Chinese with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black
US International with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black
Arabic/English with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black
Thailand with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Spanish with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Portuguese with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Canadian French with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 107KS Black
Brazilian Portuguese with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
German with new silver color

KB.RF403.135

KB.RF403.136

KB.RF403.137

KB.RF403.138

KB.RF403.139

KB.RF403.140

KB.RF403.141

KB.RF403.142

KB.RF403.143

KB.RF403.144

KB.RF403.146

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Italian with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
French with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Swedish with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
UK with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Dutch with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Swiss/G with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Belgium with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Icelandic with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Norwegian with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black
Hebrew with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Polish with new silver color

KB.RF403.147

KB.RF403.148

KB.RF403.149

KB.RF403.150

KB.RF403.151

KB.RF403.152

KB.RF403.153

KB.RF403.154

KB.RF403.155

KB.RF403.156

KB.RF403.157

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Slovenian with new silver color

KB.RF403.158

Chapter 6 87

Category Part Number Acer P/N

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Slovak with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black
Russian with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Hungarian with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black
Greek with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Danish with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black
Czech with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Romanian with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Turkish with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Spanish Latin with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Turkish-Q with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Arabic/French with new silver color

KB.RF403.159

KB.RF403.160

KB.RF403.161

KB.RF403.162

KB.RF403.163

KB.RF403.164

KB.RF403.165

KB.RF403.166

KB.RF403.167

KB.RF403.168

KB.RF403.169

Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black
Kazakh with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black
Turkmen with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black
Nordic with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard English/
Canadian French with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 105KS
Czech/Slovak with new silver color

Keyboard CHICONY KG-0766 RF2.4 Standard 109KS
Japanese with J1 layout & silver color

KB.RF403.170

KB.RF403.171

KB.RF403.172

KB.RF403.289

KB.RF403.526

KB.RF403.284

88 Chapter 6
