Acer Altos G330 MK2 User Guide

Acer Altos

G330 Mk2 Series

User’s Guide

Copyright © 2007 Acer Incorporated
All Rights Reserved.

Acer Altos G330 Mk2 Series
User’s Guide

Changes may be made periodically to the information in this publication without obligation
to notify any person of such revision or changes. Such changes will be incorporated in new
editions of this manual or supplementary documents and publications. This company makes
no representations or warranties, either expressed or implied, with respect to the contents
hereof and specifically disclaims the implied warranties of merchantability or fitness for a
particular purpose.

Record the model number, serial number, purchase date, and place of purchase information in
the space provided below. The serial number and model number are recorded on the label
affixed to the unit. All correspondence concerning the unit should include these information.

No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronic, mechanical, photocopy, recording, or otherwise,
without the prior written permission of Acer Incorporated.

Acer Altos G330 Mk2 Series

Model Name : G330 Mk2

Part Number: MU.R3100.001

Purchase Date:

Place of Purchase:

Acer and the Acer logo are registered trademarks of Acer Inc. Other company’s product
names or trademarks are used herein for identification purposes only and belong to their
respective companies.

Notices

FCC declaration of conformity

This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.

The following local manufacturer/importer is responsible for this declaration:

iii

Product:
Model number:
Name of responsible party:
Address of responsible party:

Contact person:
Phone number:
Fax number:

Server
G330 Mk2
Acer America Corporation
333 West San Carlos St., San Jose,

CA 95110, U. S. A.
Acer Representative
1-254-298-4000
1-254-298-4147

FCC notice

Class A devices do not have an FCC logo or FCC IDE on the label. Class B devices
have an FCC logo or FCC IDE on the label. Once the class of the device is
determined, refer to the following corresponding statement.

Class A equipment

This device has been tested and found to comply with the limits for a Class A
digital device pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy, and if not installed
and used in accordance with the instructions, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference, in which case the user will be required to
correct the interference at personal expense.

iv

However, there is no guarantee that interference will not occur in a particular
installation. If this device does cause harmful interference to radio or television
reception, which can be determined by turning the device off and on, the user
is encouraged to try to correct the interference by one or more of the following
measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the device and receiver

• Connect the device into an outlet on a circuit different from that to which
the receiver is connected

• Consult the dealer or an experienced radio/television technician for help

Notice: Shielded cables

All connections to other computing devices must be made using shielded cables
to maintain compliance with FCC regulations.

Notice: Peripheral devices

Only peripherals (input/output devices, terminals, printers, etc.) certified to
comply with the Class A limits may be attached to this equipment. Operation
with noncertified peripherals is likely to result in interference to radio and TV
reception.

Caution: Changes or modifications not expressly approved by the
manufacturer could void the user’s authority, which is granted by
the Federal Communications Commission, to operate this server.

Use conditions

This part complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.

Notice: Canadian users

This Class A digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.

Remarque à l'intention des utilisateurs canadiens

Cet appareil numérique de la classe A est conforme a la norme NMB-003 du
Canada.

Laser compliance statement

The CD or DVD drive used with this computer is a laser product. The CD or DVD
drive's classification label (shown below) is located on the drive.

CLASS 1 LASER PRODUCT
CAUTION: INVISIBLE LASER RADIATION WHEN OPEN. AVOID EXPOSURE TO
BEAM.

APPAREIL A LASER DE CLASSE 1 PRODUIT
LASERATTENTION: RADIATION DU FAISCEAU LASER INVISIBLE EN CAS
D'OUVERTURE. EVITTER TOUTE EXPOSITION AUX RAYONS.

LUOKAN 1 LASERLAITE LASER KLASSE 1
VORSICHT: UNSICHTBARE LASERSTRAHLUNG, WENN ABDECKUNG GEÖFFNET
NICHT DEM STRAHLL AUSSETZEN.

PRODUCTO LÁSER DE LA CLASE I
ADVERTENCIA: RADIACIÓN LÁSER INVISIBLE AL SER ABIERTO. EVITE
EXPONERSE A LOS RAYOS.

ADVARSEL: LASERSTRÅLING VEDÅBNING SE IKKE IND I STRÅLEN.

VARO: LAVATTAESSA OLET ALTTINA LASERSÅTEILYLLE.

VARNING: LASERSTRÅLNING NÅR DENNA DEL ÅR ÖPPNAD ÅLÅ TUIJOTA

SÅTEESEENSTIRRA EJ IN I STRÅLEN.

VARNING: LASERSTRÅLNING NAR DENNA DEL ÅR ÖPPNADSTIRRA EJ IN I
STRÅLEN.

ADVARSEL: LASERSTRÅLING NAR DEKSEL ÅPNESSTIRR IKKE INN I STRÅLEN.

v

Macrovision copyright protection notice

"U.S Patent Nos. 4,631,603; 4,819,098; 4,907,093; 5,315,448; and 6,516,132."

This product incorporates copyright protection technology that is protected by
U.S. patents and other intellectual property rights. Use of this copyright
protection technology must be authorized by Macrovision, and is intended for
home and other limited viewing uses only unless otherwise authorized by
Macrovision. Reverse engineering or disassembly is prohibited.

vi

CE Declaration of conformity

We,

Acer Computer (Shanghai) Limited

3F, No. 168 Xizang Medium Road, Huangpu District,
Shanghai, China

Contact Person: Mr. Easy Lai
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]

Hereby declare that:

Product:
Trade name:
Model number:
SKU number:

Is compliant with the essential requirements and other relevant provisions of
the following EC directives, and that all the necessary steps have been taken
and are in force to assure that production units of the same product will
continue to comply with these requirements.

• EMC Directive 2004/108/EC, amended by conformity with the
following harmonized standards:

• EN55022:1998 + A1:2000 + A2:2003, AS/NZS CISPR22:2002, Class B

• EN55024:1998 + A1:2001 + A2:2003

• EN61000-3-2:2000 + A2:2005, Class D

• EN61000-3-3:1995 + A1:2001

• Low Voltage Directive 2006/95/EC as attested by conformity with
the following harmonized standard:

• EN60950-1:2001 + A11:2004

• RoHS Directive 2002/95/EC on the Restriction of the Use of certain
Hazardous Substances in Electrical and Electronic Equipment

Director, Acer Computer (Shanghai) Limited

Server
Acer
G330 Mk2
G330 Mk2xx ("x" = 0~9, a~z, A~Z or blank)

Declaration of conformity for EU countries

Hereby, Acer, declares that this PC series is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC.

Russian regulatory certification compliance

vii

viii

Information for your safety and comfort

Safety instructions

Read these instructions carefully. Keep this document for future reference.
Follow all warnings and instructions marked on the product.

Turning the product off before cleaning

Unplug this product from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp cloth for cleaning.

CAUTION for plug as disconnecting device

Observe the following guidelines when connecting and disconnecting power to
the power supply unit:

• Install the power supply unit before connecting the power cord to the AC
power outlet.

• Unplug the power cord before removing the power supply unit from the
server.

• If the system has multiple sources of power, disconnect power from the
system by unplugging all power cords from the power supplies.

CAUTION for accessibility

Be sure that the power outlet you plug the power cord into is easily accessible
and located as close to the equipment operator as possible. When you need to
disconnect power to the equipment, be sure to unplug the power cord from the
electrical outlet.

The product is not suitable for use with visual display work place devices
according to §2 of the German Ordinance for Work with Visual Display Units.

Usage warnings

• Do not use this product near water. Never spill liquid of any kind onto or
into the product.

• Do not place this product on an unstable cart, stand or table. If the product
falls, it could be seriously damaged.

• Slots and openings are provided for ventilation to ensure reliable
operation of the product and to protect it from overheating. These
openings must not be blocked or covered. The openings should never be

blocked by placing the product on a bed, sofa, rug or other similar surface.
This product should never be placed near or over a radiator or heat
register, or in a built-in installation unless proper ventilation is provided.

• Never push objects of any kind into this product through cabinet slots as
they may touch dangerous voltage points or short-out parts that could
result in a fire or electric shock.

• To avoid damage of internal components and to prevent battery leakage,
do not place the product on a vibrating surface.

• Never use it under sporting, exercising, or any vibrating environment
which will probably cause unexpected short current or damage rotor
devices, hard drives, optical drives, and even exposure risk from lithium
battery pack.

Using electrical power

• This product should be operated from the type of power indicated on the
marking label. If you are not sure of the type of power available, consult
your dealer or local power company.

• Do not allow anything to rest on the power cord. Do not locate this
product where people will walk on the cord.

• If an extension cord is used with this product, make sure that the total
ampere rating of the equipment plugged into the extension cord does not
exceed the extension cord ampere rating. Also, make sure that the total
rating of all products plugged into the wall outlet does not exceed the fuse
rating.

• Do not overload a power outlet, strip or receptacle by plugging in too
many devices. The overall system load must not exceed 80% of the branch
circuit rating. If power strips are used, the load should not exceed 80% of
the power strip's input rating.

• This product's power supply is equipped with a three-wire grounded plug.
The plug only fits in a grounded power outlet. Make sure the power outlet
is properly grounded before inserting the power supply plug. Do not insert
the plug into a non-grounded power outlet. Contact your electrician for
details.

ix

Warning! The grounding pin is a safety feature. Using a
power outlet that is not properly grounded may result in
electric shock and/or injury.

Note: The grounding pin also provides good protection from

unexpected noise produced by other nearby electrical devices that
may interfere with the performance of this product.

x

• Use the product only with the supplied power supply cord set. If you need
to replace the power cord set, make sure that the new power cord meets
the following requirements: detachable type, UL listed/CSA certified, type
SPT-2, rated 7 A 125 V minimum, VDE approved or its equivalent, 4.6
meters (15 feet) maximum length.

Safe listening

Follow these instructions, suggested by hearing experts, to protect your
hearing.

• Gradually increase the volume until you can hear it clearly and comfortably
and without distortion.

• After setting the volume level, do not increase it after your ears adjust.

• Limit the amount of time listening to music at high volume.

• Avoid turning up the volume to block out noisy surroundings.

• Turn the volume down if you can't hear people speaking near you.

Product servicing

Do not attempt to service this product yourself, as opening or removing covers
may expose you to dangerous voltage points or other risks. Refer all servicing to
qualified service personnel.

Unplug this product from the wall outlet and refer servicing to qualified service
personnel when:

• the power cord or plug is damaged, cut or frayed

• liquid was spilled into the product

• the product was exposed to rain or water

• the product has been dropped or the case has been damaged

• the product exhibits a distinct change in performance, indicating a need
for service

• the product does not operate normally after following the operating
instructions

Note: Adjust only those controls that are covered by the
operating instructions, since improper adjustment of other
controls may result in damage and will often require extensive
work by a qualified technician to restore the product to normal
condition.

CAUTION: Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by
the manufacturer. Dispose of used batteries according to the
manufacturer's instructions.

Disposal instructions

Do not throw this electronic device into the trash when discarding. To minimize
pollution and ensure utmost protection of the global environment, please
recycle. For more information on the Waste from Electrical and Electronics
Equipment (WEEE) regulations, visit
http://global.acer.com/about/sustainability.htm.

xi

xii

Tips and information for comfortable use

Computer users may complain of eyestrain and headaches after prolonged use.
Users are also at risk of physical injury after long hours of working in front of a
computer. Long work periods, bad posture, poor work habits, stress, inadequate
working conditions, personal health and other factors greatly increase the risk
of physical injury.

Incorrect computer usage may lead to carpal tunnel syndrome, tendonitis,
tenosynovitis or other musculoskeletal disorders. The following symptoms may
appear in the hands, wrists, arms, shoulders, neck or back:

• numbness, or a burning or tingling sensation

• aching, soreness or tenderness

• pain, swelling or throbbing

• stiffness or tightness

• coldness or weakness

If you have these symptoms, or any other recurring or persistent discomfort
and/or pain related to computer use, consult a physician immediately and
inform your company's health and safety department.

The following sections provide tips for more comfortable computer use.

Finding your comfort zone

Find your comfort zone by adjusting the viewing angle of the monitor, using a
footrest, or raising your sitting height to achieve maximum comfort. Observe
the following tips:

• Refrain from staying too long in one fixed posture.

• Avoid slouching forward and/or leaning backward.

• Stand up and walk around regularly to remove the strain on your leg
muscles.

• Take short rests to relax your neck and shoulders.

• Avoid tensing your muscles or shrugging your shoulders.

• Install the external display, keyboard and mouse properly and within
comfortable reach.

• If you view your monitor more than your documents, place the display at
the center of your desk to minimize neck strain.

xiii

Taking care of your vision

Long viewing hours, wearing incorrect glasses or contact lenses, glare, excessive
room lighting, poorly focused screens, very small typefaces and low-contrast
displays could stress your eyes. The following items provide suggestions on how
to reduce eyestrain.

•Eyes

• Rest your eyes frequently.

• Give your eyes regular breaks by looking away from the monitor and
focusing on a distant point.

• Blink frequently to keep your eyes from drying out.

•Display

• Keep your display clean.

• Keep your head at a higher level than the top edge of the display so
your eyes point downward when looking at the middle of the display.

• Adjust the display brightness and/or contrast to a comfortable level
for enhanced text readability and graphics clarity.

• Eliminate glare and reflections by:
– placing your display in such a way that the side faces the window or

any light source
– minimizing room light by using drapes, shades or blinds
– using a task light
– changing the display's viewing angle
– using a glare-reduction filter
– using a display visor, such as a piece of cardboard extended from

the display's top front edge

• Avoid adjusting your display to an awkward viewing angle.

• Avoid looking at bright light sources, such as open windows, for
extended periods of time.

Important: The product is not suitable for use with visual
display work place devices according to §2 of the German
Ordinance for Work with Visual Display Units.

xiv

Developing good work habits

Develop the following work habits to make your computer use more relaxing
and productive:

• Take short breaks regularly and often.

• Perform some stretching exercises.

• Breathe fresh air as often as possible.

• Exercise regularly and maintain a healthy body.

Warning! We do not recommend using the computer on a
couch or bed. If this is unavoidable, work for only short
periods, take breaks regularly, and do some stretching
exercises.

1 System tour 1

System specifications 3

Performance 3
Mechanical 6

External and internal structure 7

Front panel 7
Rear panel 8
Internal components 9

System boards 10

Mainboard 10
Backplane board 12

BMC module 13
System jumpers 14
System LED indicators 15

Front panel LED indicators 15

Hot-plug HDD LED indicators 16

LAN port LED indicators 17

2 System setup 19

Setting up the system 21

Pre-installation requirements 21
Connecting peripherals 22
Turning on the system 23

Power-on problems 24
Turning off the system 25

Contents

3 System upgrade 27

Installation precautions 29

ESD precautions 29

Pre-installation instructions 30

Post-installation instructions 30
Opening the server 31

Removing the side panel 31

Removing the front bezels 32
Configuring a 5-25 inch storage device 33
Configuring a hard drive 35
Upgrading the processor 39
Upgrading the system memory 44
Installing an expansion card 48
Installing the BMC module 51
Installing the TPM module 52

4 System BIOS 53

BIOS overview 55
Entering BIOS setup 56

BIOS setup primary menus 56

BIOS setup navigation keys 57
Main menu 58
Advanced menu 59

Advanced Processor Options 60

Memory Configuration 62

Advanced Chipset Control 63

PCI Configuration 64

I/O Device Configuration 65

IDE Configuration 66

I/O Channel 0/Secondary Master/Slave 67

Floppy Configuration 69

Boot Configuration 70
Security menu 72

Setting a system password 73

Changing a system password 74

Removing a system password 74
Server menu 75

System Management 76

Console Redirection 77

Event Log Configuration 79
Boot menu 80
Exit menu 81

5 System

troubleshooting 83

Pre-troubleshooting procedure 85

Resetting the system 85
Initial system startup problems 86
Initial troubleshooting checklist 87
Hardware diagnostic testing 88

Checking the boot-up status 88

Verifying the condition of the storage devices 89

Confirming loading of the operating system 89
Component troubleshooting 90

Appendix A: Server management tools 95

Server management overview 97

RAID configuration utilities 98

Onboard SATA RAID Configuration Utility 98

LSI MegaRAID SAS 8708ELP RAID Configuration Utility101

LSI MegaRAID SAS 8204ELP RAID Configuration Utility102

Index 105

1 System tour

The Acer Altos G330 Mk2 server is a single

processor system featuring the latest in

computing technology. It hosts a range of

powerful and flexible features designed to

meet the needs of various network

environments. From simple networking

functions to computing-intensive applications,

the Altos G330 Mk2 delivers.

System specifications

This section lists down the impressive computing features of the
Altos G330 Mk2 system.

Performance

Processor

•Single Intel® LGA775 processor socket supporting the following
processor models:

• Quad-Core Intel Xeon processor 3200 series

• Dual-Core Intel Xeon processor 3000 series

• Intel® Core™2 Quad processor

• Intel® Core™2 Duo processor

• Intel® Pentium® Dual-Core processor

• Intel® Celeron® processor

• 512 KB, 1 MB, 2 MB, 4 MB or 2x4 MB L2 cache

• 1333, 1066, and 800 MHz front side bus (FSB) speed

• Supports the following Intel technologies:

• Intel Quad-Core Architecture

• Intel Dual-Core Architecture

• Intel Extended Memory 64 Technology (EM64T)

• Intel Enhance Intel SpeedStep Technology (EIST)

• Intel Virtualization Technology (VT)

1

3

Chipset

• North bridge - Intel 3200 Memory Controller Hub (MCH)

• South bridge - Intel 82801IR I/O Controller Hub (ICH9R)

1

Support for dual core, quad core configuration, Hyper-Threading Technology
and EM64T may vary depending on processor type specifications.

4

1 System tour

Memory

• Four DIMM slots supporting DDR2 800 unbuffered ECC modules

• Maximum memory capacity of 8 GB

• Supports 512 MB, 1 GB, and 2 GB capacity modules

• Supports dual-channel interleave operation

2

PCI interface

• Five PCI bus slots with four separate bus segments

• One PCI Express x16 slot with x8 throughput (PCI-E 1 slot)

• One PCI Express x8 slot with x4 throughput (PCI-E 2 slot)

• One PCI Express x4 slot with x1 throughput (PCI-E 3 slot)

• Two 32-bit/33 MHz/3.3V PCI slots (PCI 4 and PCI 5 slots)

Video controller

• Embedded XGI Z9s chipset

• 16 MB DDR SDRAM

SATA II controller

• Integrated in the Intel ICH9R chipset

• Data transfer rate of up to 3.0 Gb/s

• Supports six onboard SATA ports

• Onboard SATA RAID support

• RAID 0,1 and 10 support

Networking

• One Gigabit Ethernet LAN port (RJ-45)

• Broadcom BCM 5721 Gigabit Ethernet Controller

Baseboard Management Controller (optional)

• Baseboard Management Controller (BMC) module (optional)

• Intelligent Platform Management Interface (IPMI) 2.0 compliant

2

Dual-channel memory mode requires that only memory modules of the same
type, banking, stacking technology, and manufacturer be installed in the
Altos G330 Mk2 server.

Media storage

• Three 5.25-inch device bays

• Optical disc drive (ODD) installed in the topmost bay

(DVD-ROM or combo drive)

• Two 5.25-inch bays support installation of optional DAT and

AIT tape drives

• One hard disk drive (HDD) cage bay supports the following
options:

• Hot-swap 3 or easy-swap HDD cages

• Up to four SAS or SATA II drives

• Media storage options

• One 3.5-inch floppy disk drive (FDD) bay for optional FDD
installation

I/O ports

5

• Two front USB 2.0 ports

• PS/2 keyboard port

• PS/2 mouse port

• Serial port

• Monitor port

• Two rear USB 2.0 ports

• One Gigabit LAN port
(RJ-45)

Power supply and ventilation

• 350-watts ATX 12V PFC power supply with auto switching function

• Support for the following cooling components:

• One rear system fan

• One processor heat sink-fan (HSF) assembly

• Optional HDD fan for systems using at least two hard drives
are installed in adjacent HDD bays.

3

The hot-swap HDD configuration is only available when the optional hot-plug
backplane board is installed in the HDD cage.

6

1 System tour

Hardware monitoring and server management

• Hardware monitoring for voltage, temperature, and fan speed
detection integrated in the ITE 8718 chip

• Status LED indicators for constant monitoring of basic system
operations

• Acer Server Management (ASM) monitors potential problem spots
in the network environment

• Trusted Platform Module (TPM) 1.2 support

Operating system

• Microsoft Windows Server 2003 x64 Edition

• Microsoft Windows Server 2003

•Red Hat® Enterprise Linux® 5.0 EM64T

•Red Hat

•SUSE

•SUSE

®

Enterprise Linux® 5.0

Linux® Enterprise Server 10.0 EM64T

Linux® Enterprise Server 10.0

Mechanical

•Chassis

• Tool-less chassis design for easy hardware access

• Tower orientation

•Dimensions
– Height: 424.6 mm (16.72 in)

– Depth: 479.7 mm (18.89 in)
– Width: 185.9 mm (7.32 in)

• Mainboard

• Dimensions (length x width): 304.8 x 243.8 mm (12 x 9.6 in)

• Form factor: Advanced Technology Extended (ATX)

External and internal structure

Front panel

Mk2

7

No. Component No. Component

1 ODD mechanical eject hole 9 HDD activity indicator

2 ODD activity indicator 10 Status/fault indicator

3 Optical disc drive 11 HDD bay bezel

4 ODD eject button 12 Security keylock

5 5.25-inch drive bays 13 FDD eject button

6 USB 2.0 ports 14 FDD activity indicator

7 Power button 15 Floppy disk drive (optional)

8 Power indicator

If you intend to install an optional floppy disk drive, refer to the

Note:

documentation that came with the new drive for instructions.

8

Rear panel

No. Icon Component

1 Side panel release latch

2 Expansion slot covers

1 System tour

3 Gigabit LAN port

4 Monitor port

5Serial port

6 USB 2.0 ports

7 PS/2 keyboard port

8 PS/2 mouse port

9 Power cable socket

Internal components

No. Component

1 Release sliders for the 5.25-inch device bays

2 Release slider for the FDD bay

3 HDD cage

9

4 HDD fan

5 Hot-plug HDD backplane board

6 Mainboard

7 Processor heat sink-fan

8 System fan

9 Power supply unit

Notes:

• The HDD fan is an optional item. Use of it is only required when the
system is using at least two hard drives are installed in adjacent HDD bays.

• The hot-plug backplane board is an optional item.

• Contact your local Acer representive for information on how to purchase
these hardware options.

10

System boards

Mainboard

1 System tour

37

36

35

34

33

16

32

31

30

26

28

29

27

24

25

22

23

17

19

18

20

21

No. Component No. Component

11

1 TOP: PS/2 Mouse Port

Bottom: PS/2 Keyboard Port

2 USB2.0 Port 21 SATA port 5

3 Serial Port 22 TPM module connector

4 Monitor Port 23 Front panel LED connector

5 Gigabit LAN port 24 Serial port connector (COM 2)

6 Processor socket 25 USB connector 1

7 Processor HSF connector 26 USB connector 2

8 DIMM A1 27 Chassis intrusion connector

9 DIMM A2 28 IPMB_1 connector

10 DIMM B1 29 IPMB_2 connector

11 DIMM B2 30 BMC Module slot

12 FDD connector 31 PCI 5 slot (32-bit/33 MHz/3.3 V)

13 2x12 ATX power connector 32 PCI 4 slot (32-bit/33 MHz/3.3 V)

14 HDD fan connector 33 PCI-E 3 slot PCI Express x4

20 SATA port 4

(with x1 throughput)

15 I2C connector 34 PCI-E 2 slot PCI Express x8

(with x4 throughput)

16 SATA port 0 35 PCI-E 1 slot PCI Express x16

(with x8 throughput)

17 SATA port 1 36 Rear system fan connector

18 SATA port 2 37 2x4 ATX power connector

19 SATA port 3

12

1 System tour

Backplane board

The backplane board attached to the rear of the hot-plug HDD cage is
what differentiate it from the easy-swap HDD cage model.

5

No. Component

1 HDD access LED control jumpers

Close 2-3 – HDD LED control via pin 11 (default)

2 HDD power cable connectors

3 HDD data cable connector (SFF-8484)

4 SAS Backplane Management cable connector

5HDD connectors

BMC module

The optional BMC module is the meeting point between the server
hardware and the system management software. In conjunction with
the mainboard hardware monitor, it allows system administrators to
manage the system remotely over a network.

No. Code Description

1 SODIMM_1 BMC module mainboard connector

13

2 U3 SDRAM (Synchronous Dynamic Random Access Memory)

3 U1 H85/216x BMC chipset

Note: Altos G330 Mk2 does not support ARMC/3.

14

System jumpers

1 System tour

No. Jumper Setting

1 Clear CMOS 1-2 – Normal operation setting

2-3 – The CMOS RAM contents will be cleared
on the next reset.

2 BIOS recovery 1-2 – Normal operation setting

2-3 – BIOS recovery setting

Note: The default setting for normal operation is 1-2 for all
system jumpers.

15

System LED indicators

This section discusses the different status LED indicators located on the:

• Front panel

• Hot-plug HDD carrier

• LAN port

Knowing what each LED indicator signifies can aid in problem
diagnosis and troubleshooting.

Front panel LED indicators

The LED indicators (green) mounted on the front panel allow the
constant monitoring of the system’s power status and drive activity.

Mk2

No. Indicator Status Description

1 ODD activity Blinking There is an ongoing ODD activity.

16

No. Indicator Status Description

2 Power On The system is powered on.

Blinking The system is in ACPI sleep mode.

3 HDD activity Blinking There is an ongoing HDD activity.

1

4

Status/fault

Solid green System is in normal mode.

1 System tour

Solid
amber

5 FDD activity Blinking There is an ongoing FDD activity.

1 The status/fault LED indicator is only enabled when the optional BMC module is installed

on the mainboard. To purchase this option, contact your local Acer representative.

Critical system threshold breach
Access the Setup utility and view
the system event log for details.

Hot-plug HDD LED indicators

A drive activity LED indicator is mounted on the hot-plug HDD carrier.
The table below lists the possible drive states.

Status Green Amber Description

HDD access Blinking — Ongoing hot-plug HDD activity

HDD failure — On Hot-plug HDD failure

HDD rebuild Flashing green/amber HDD is rebuilding data.

17

LAN port LED indicators

The Gigabit LAN port located on the rear panel has two LED indicators
that show its status.

No. Indicator Status Description

1Network

speed

2Network

connection

Solid yellow GbE link network access

Solid green 100 Mbps link network access

Off 10 Mbps link network access

Solid green Active network link

Blinking green Ongoing network data activity

Off Off-line network

18

1 System tour

2 System setup

This chapter gives you instructions on how to
prepare the system for operation. Procedures for
connecting peripherals are also explained.

Setting up the system

Pre-installation requirements

Selecting a site

Before unpacking and installing the system, select a suitable site for
the system for maximum efficiency. Consider the following factors
when choosing a site for the system:

• Near a grounded power outlet

• Clean and dust-free

• Stable surface free from vibration

• Well-ventilated and away from sources of heat

• Secluded from electromagnetic fields produced by electrical
devices such as air conditioners, radio and TV transmitters, etc.

Checking the package contents

Check the following items from the package:

• Acer Altos G330 Mk2 system

• Acer Altos G330 Mk2 System DVD

• Acer Altos G330 Mk2 accessory box

• System keys (attached to the security keylock)

21

If any of the above items are damaged or missing, contact your dealer
immediately.

Save the boxes and packing materials for future use.

22

2 System setup

Connecting peripherals

The color-coded I/O ports on the rear panel support a variety of
compatible peripherals.

Note: Consult the operating system manual for information on
how to configure the network setup.

Caution: Do not route the power cord where it will be walked on
or pinched by items placed against it. The server is designed to be
electrically grounded (earthed). To ensure proper operation, plug
the power cord into a properly grounded AC outlet only.

23

Turning on the system

After making sure that you have properly set up the system, applied
power, and connected all the necessary peripherals, you can now
power on the system.

To turn on the system, press the power button on the front panel.

The system starts up and displays a welcome message on the monitor.
After that, a series of power-on self-test (POST) messages appears. The
POST messages indicate if the system is running well or not.

Note: If the system does not turn on or boot after pressing the
power button, go to the next section for the possible causes of the
boot failure.

Aside from the POST messages, you can determine if the system is in
good condition by checking if the following occurred.

• The power status indicator on the front panel lights up green.

• The Num Lock, Caps Lock, and Scroll Lock indicators on the
keyboard light up.

24

2 System setup

Power-on problems

If the system fails to boot after you have applied power, check the
following factors that might have caused the boot failure.

• The external power cord may be loosely connected.
Check the power cord connection from the power outlet to the

power cord socket on the rear panel. Make sure that the cord is
properly connected to the power outlet and to the power cord
socket.

• No power comes from the grounded power outlet.
Have an electrician check your power outlet.

• Loose or improperly connected internal power cables.
Check the internal cable connections. If you are not confident to

perform this step, ask a qualified technician to assist you.

Warning! Make sure all power cords are disconnected from
the electrical outlet before performing this task.

Note: If you have gone through the preceding actions and the

system still fails to boot, ask your dealer or a qualified technician
for assistance.

25

Turning off the system

There are two ways to turn off the server—via software or via
hardware. The software procedure below applies to a system running
on a Windows OS. For other OS shutdown procedures, refer to the
related user documentation.

To turn off the system via software:

1 Press Ctrl+Alt+Delete on the attached keyboard or click Start on

the Windows taskbar.
2 Select Shut Down.
3 Select Shut down from the drop-down menu, then click OK.

To turn off the system via hardware:

If you cannot shut down the server via software, press the power
button for at least four seconds. Quickly pressing the button may put
the server in a Suspend mode only.

26

2 System setup

3 System upgrade

This chapter discusses the precautionary
measures and installation procedures you
need to know when upgrading the system.

Installation precautions

Before you install any server component, it is recommended that you
read the following sections first. These sections contain important ESD
precautions along with pre-installation and post-installation
procedures.

ESD precautions

Electrostatic discharge (ESD) can damage static-sensitive hardware
components, such as the processor, disk drives, and the system boards.
Always observe the following precautions before you install a server
component:

• Do not remove a component from its protective packaging until
you are ready to install it.

• Do not touch the component pins, leads, or circuitry.

• Components with a Printed Circuit Board (PCB) assembly should
always be laid with the assembly-side down.

• Wear a wrist grounding strap and attach it to a metal part of the
server before handling components. If a wrist strap is not
available, maintain contact with the server throughout any
procedure requiring ESD protection.

• Avoid moving around unnecessarily to minimize your body’s ESD.

• Keep the work area free of nonconductive materials, such as
ordinary plastic assembly aids and foam packing.

29

30

3 System upgrade

Pre-installation instructions

Perform the steps below before you open the server or before you
remove or replace any component.

Warning! Failure to properly turn off the server before you
start perform any hardware configuration may cause
serious damage and bodily harm. Do not attempt the
procedures described in the following sections unless you
are a qualified service technician.

1 Back up all important system and data files before performing any

hardware configuration.
2 Turn off the server and all connected peripherals.
3 Unplug all power cables from their outlets.
4 Disconnect all telecommunication cables from their ports.
5 Place the server on a flat, stable surface.
6 Open the server according to the instructions on page 31.
7 Follow the ESD precautions described in the previous section when

handling a server component.

Post-installation instructions

Perform the steps below after installing a server component.
1 See to it that all components are installed according to the

described step-by-step instructions.
2 Reinstall any expansion board(s), peripheral(s), bracket(s) and

system cable(s) that have previously been removed.
3 Reinstall the side panel and the front bezels.
4 Reconnect the power, peripheral, and telecommunication cables.
5 Turn on the system.

Opening the server

Caution: Before you proceed, make sure that you have turned
off the system and all peripherals connected to it. Read the

"Pre-installation instructions" section page 30.

You need to open the server before you can install upgrade
components. The front bezels and (left) side panel are removable to
allow access to the server’s internal components. Refer to the
following sections for instructions.

Removing the side panel

1 Perform the pre-installation instructions described on page 30.
2 Open the HDD bay bezel.

(1) If necessary, insert the key into the lock and turn it

counterclockwise until it points to the unlock icon.

(2) Open the lower bezel to a 90° angle.

31

3 Remove the side panel.

(1) Loosen the two screws located on the rear edge of the

side panel.

(2) Move the side panel release latch all the way down to

unfasten the panel from the chassis.

32

(3) Slide the side panel toward the rear of the chassis to detach it.

3 System upgrade

Removing the front bezels

1 Remove the side panel.
2 Remove the front bezels.

There are two front bezels protecting the 5.25-inch drive bays and
the HDD bay. Remove the top bezel first.

(1) Release the top bezel retention tabs from the chassis interior.
(2) Pull the top bezel away from the chassis.
(3) Pull the lower bezel upward to release its retention tabs from

the chassis.

(4) Pull the lower bezel away from the chassis.

33

Configuring a 5-25 inch storage device

The three 5.25-inch device bays support a variety of storage devices for
additional storage capacity and scalability. Go to page 5 for a list of
supported storage devices.

By default, the system ships with a DVD-ROM drive installed on the
topmost device bay. You can choose to replace this default drive, or
you can install a new storage device.

To install an optional storage device:

1 Perform the pre-installation instructions described on page 30.
2 If you intend to replace the DVD drive, go to the next step.

If you intend to install a new storage device, go to step 4.
3 Remove the default DVD drive.

(1) Disconnect the power and IDE cables from rear of the default

DVD drive.

(2) Move and hold the DVD drive release slider to the unlock

position .

(3) Pull the drive out of the device bay.

Proceed to step 5 for instructions on how to install a new
storage device.

34

3 System upgrade

4 Use a flat-blade screwdriver to pry the dummy bezel off the device

bay where you intend to install the new storage device.
Keep this dummy bezel for future reinstallation.

5 Install the new 5.25-inch storage device.

(1) Move and hold the DVD drive release slider of the unlock

position .
(2) Slide the new 5.25-inch drive into the drive bay.
(3) Move the release slider into the lock position .
(4) Connect the power and data cables of the new storage device.

6 Observe the post-installation instructions described on page 30.

35

Configuring a hard drive

The Altos G330 Mk2 HDD cage bay accommodates both hot-plug and
easy-swap HDD cage models. The main difference between these two
cage models is the presence of a backplane board on the rear side of
the hot-plug HDD cage. Both cage models support up to four SATA II or
SAS hard disk drives. Users have the option to purchase extra hard disks
to provide the system with additional storage capacity and scalability.

Hard drive configuration reminders

• A dummy HDD carrier occupies a vacant HDD bay. Users need to
purchase a blank HDD carrier to install additional hard drive(s).

• If you intend to install a SAS hard drive model, install the SAS or
SAS RAID card option first.

• If you intend to install at least two hard drives in adjacent HDD
bays, an HDD fan is required to maintain proper system cooling.

Contact your local Acer representative for more information on how to
purchase these optional items.

To remove a hot-plug hard drive:

1 If necessary, unlock the front bezel, then pull it open.
2 Remove the hot-plug hard drive from its bay.

(1) Press the hard disk carrier button to release the ejector lever.
(2) Use the ejector lever to pull the drive out of the cage.

Make sure to support the drive when pulling it out of the
cage.

36

3 System upgrade

To remove an easy-swap hard drive:

1 Remove the side panel from the chassis.

Go to page 31 for instructions.

2 Disconnect the data and power cables from their HDD connectors.

The figure below shows the cable connections for a SAS HDD
connected to an optional SAS/SAS RAID expansion card. Easy-swap
HDD configuration also supports SATA HDDs connected to the
onboard SATA connectors.

3 Press the hard disk carrier button to release the ejector lever.
4 Use the ejector lever to pull the drive out of the cage.

Make sure to support the drive when pulling it out of the cage.

5 Observe the post-installation instructions described on page 30.

To install a hot-plug hard drive:

1 If necessary, unlock the HDD bay bezel, then pull it open.
2 Pull out the dummy HDD carrier from the cage.

3 Prepare the new blank HDD carrier for installation.

(1) Remove the four screws that secures the blank frame.

You will use these screws to secure the hard disk later.

(2) Detach the plastic frame from the HDD carrier.

37

38

3 System upgrade

4 Align the new hard disk with the HDD carrier, then secure it with

the four screws you removed in step 3-1.

5 Install the new hard drive into the cage.

(1) Slide the drive into the cage with the ejector lever still

extended.

(2) Make sure that the drive is properly inserted before pushing

the lever back until it clicks into place.

To install an easy-swap hard drive:

1 Remove the side panel from the chassis.

Go to page 31 for instructions.
2 Observe steps 2 through 5 of the previous section.
3 Connect the data and power cables to their HDD connectors.
4 Observe the post-installation instructions described on page 30.

39

Upgrading the processor

Altos G330 Mk2 has one LGA775 processor socket that supports a
variety of Intel processor models. Refer to page 3 to for a list of these
supported processor options.

This section explains the procedures for removing and installing the
processor and heat sink-fan.

Processor configuration precautions

• Handle the processor and the HSF assembly carefully. Damage to
either may prevent the system from functioning properly.

• Do not touch the pins on either the processor or the processor
socket; they are very sensitive and are easily damaged.

• Do not force the processor into the socket. When properly
aligned, the processor will easily fit into place.

• Be sure that the server has the most recent ROM version. Failure
to flash the ROM before installing a new processor can cause
system failure.

To upgrade the processor:

1 Perform the pre-installation instructions described on page 30.
2 Lay the server on its side (components showing).
3 If necessary, remove any accessory boards or cables that prevent

access to the HSF.

40

3 System upgrade

4 Remove the HSF from the chassis.

The figure below shows the HSF type available for the Altos G330
Mk2 system.

(1) Disconnect the processor HSF cable from its mainboard

connector.
(2) Loosen the four HSF mounting pins.
(3) Twist the HSF sightly to break the thermal grease bond loose.

Once the thermal grease bond is broken, lift the HSF away

from the mainboard.

(4) Lay down the HSF in an upright position—with the thermal

patch facing upward. Do not let the thermal patch touch the

work surface.

5 Use an alcohol pad to wipe off the thermal grease from both the

HSF assembly and the processor socket retention plate.

6 Remove the default processor.

Warning! The processor becomes very hot when the
system is on. Allow it to cool off first before handling.

(1) Press down on the socket lever while pulling it towards the

center of the mainboard to disengage it from the socket hook.
(2) Fully open the load lever.
(3) Press the rear tab with your finger tip to bring the front end

of the retention plate up slightly.
(4) Open the plate to expose the socket body.
(5) Grasp the processor by its edges and lift it out of its socket.

41

7 Store the old processor inside an anti-static bag.
8 Remove the new processor from its box, handling it by the edges.
9 Remove the protective shipping cover from the new processor.

42

3 System upgrade

10 Install the new processor.

(1) Hold the processor by its edges, then insert it in the socket.

Make sure that the alignment tabs on the socket fit the two
notches located on the edge of the processor. The pins are
keyed in such a way that you cannot install the processor in

the wrong orientation without bending the pins.
(2) Close the retention plate.
(3) Press down on the socket lever while pushing it towards the

center of the processor socket to engage it under the socket

hook.

11 Apply a thin layer of an Acer-approved thermal interface material

to the processor base and the bottom side of the HSF.
Make sure that only a very thin layer is applied so that both

contact surfaces are still visible.

12 Reinstall the HSF assembly.

The figure below shows the HSF type available for the Altos G330
Mk2 system.

(1) Align then insert the HSF on top of the retention plate.
(2) Tighten the four mounting pins a few threads in, observing a

diagonally opposite pattern, then tighten them completely to
secure the heat sink to the processor base.

(3) Reconnect the HSF cable to its mainboard connector.

43

13 Observe the post-installation instructions described on page 30.

44

3 System upgrade

Upgrading the system memory

This section explains the procedures for removing and installing a
memory module.

Altos G330 Mk2 has four DDR2-800 DIMM slots. Each slot supports
512 MB, 1 GB or 2 GB memory modules. The maximum memory
capacity is 8 GB.

System memory interface

Altos G330 Mk2 has four DIMM slots divided into two memory
channels.

• Channel A - DIMM A1 and DIMM A2

• Channel B - DIMM B1 and DIMM B2

System memory configuration guidelines

• To ensure data integrity, use only Acer-approved DDR2 800
unbuffered ECC modules in 512 MB, 1 GB, or 2 GB capacities.

• Use identical modules—same type, banking, stacking technology,
and manufacturer.

• The minimum memory configuration is one DIMM, installed in the
DIMM A1 slot (the slot closest to the processor socket).

• The system does not support a three-DIMM memory configuration.

45

• DIMMs on channel A (DIMM A1 and A2) are paired with DIMMs on
channel B (DIMM B1 and B2) to enable two-way interleaving.
When only two DIMMs are being used, the population order must
be DIMM A1 and DIMM B1 to ensure dual-channel operating
mode.

• For best performance and dual-channel interleave operation,
DIMM modules must be installed or removed in matched pairs,
following the slot sequence: DIMM A1 and B1 first, then DIMM A2
and B2.

• Observe the population sequence illustrated in the table below
when installing a memory module.

Memory channel DIMM slot Population order

A DIMM A1 1

A DIMM A2 3

B DIMM B1 2

B DIMM B2 4

• The table below lists the supported memory installation based on
the memory interleave configuration.

Interleave
mode

Single
channel

Channel A Channel B

DIMM A1 DIMM A2 DIMM B1 DIMM B2

512 MB 512 MB

1 GB 1 GB

2 GB 2 GB

Tot al
memory

46

3 System upgrade

Interleave
mode

Dual
channel

Channel A Channel B

DIMM A1 DIMM A2 DIMM B1 DIMM B2

512 MB 512 MB 1 GB

1 GB 1 GB 2 GB

2 GB 2 GB 4 GB

512 MB 512 MB 512 MB 512 MB 2 GB

1 GB 1 GB 1 GB 1 GB 4 GB

2 GB 2 GB 2 GB 2 GB 8 GB

Tot al
memory

To remove a memory module:

1 Perform the pre-installation instructions described on page 30.
2 Lay the server on its side (components showing).
3 If necessary, remove any cables that prevent access to the DIMM

slots.
4 Locate the memory module you intend to remove.
5 Remove the memory module.

(1) Press the retaining clips on both sides of the slot outward to

release the DIMM.

(2) Hold the DIMM by its edges, then gently pull it upward to

remove it.

6 Store the removed memory module inside an anti-static bag.
7 If you intend to install a new memory module, proceed to the next

section for related procedure, otherwise observe the

post-installation instructions described on page 30.

To install memory module:

1 Perform steps 1 through 3 of the previous section.
2 Select an empty DIMM slot.
3 If necessary, open the holding clips of the selected DIMM slot.
4 Remove the new memory module from its protective packaging,

handling it by the edges.

5 Install the new memory module.

(1) Align the module so that the notch on the slot fits the keyed

edge of the module, then press the module at both ends until
the retaining clips snap into place.

If you insert a module but it does not fit easily into the slot,
you have inserted it incorrectly. Reverse the orientation of the
module and insert it again.

(2) Make sure to firmly press the retaining clips inward to lock the

module in place.
If the holding clips do not close, the module is not properly

inserted.

47

6 Observe the post-installation instructions described on page 30.

The system automatically detects the amount of memory installed.
Run the BIOS setup utility to view the new value for total system
memory.

48

3 System upgrade

Installing an expansion card

This section explains how to install an expansion card.

Altos G330 Mk2 has five PCI bus slots, namely:

• One PCI Express x16 slot with x8 throughput (PCI-E 1 slot)

• One PCI Express x8 slot with x4 throughput (PCI-E 2 slot)

• One PCI Express x4 slot with x1 throughput (PCI-E 3 slot)

• Two 32-bit/33 MHz/3.3V PCI bus slots (PCI 4, PCI5 slots)

1 slot

3 slot

2 slot

4

5

To install an expansion card:

1 Perform the pre-installation instructions described on page 30.
2 If necessary, remove any cables that prevent access to the

expansion slots.
3 Locate an empty expansion slot that is compatible with the

specification of the card you intend to install.
4 Install the expansion card.

(1) Pull the card bracket latch slightly upward.

(2) Detach the card bracket latch from the chassis.

(3) Pull out the slot cover opposite the selected expansion slot.

Store it for future reassembly.

Caution: Do not discard the slot cover. If the expansion card is
removed in the future, the slot cover must be reinstalled to
maintain proper system cooling.

5 Remove the expansion card from its protective packaging,

handling it by the edges.

6 Install the new expansion card.

(1) Insert the card into the selected slot.

Make sure that the card is properly seated.

(2) Insert the lower end of the card bracket latch to its chassis

notch.

(3) Secure the card bracket latch tab to the chassis.

49

50

3 System upgrade

7 Connect the necessary cables to the expansion card as required.
8 Observe the post-installation instructions described on page 30.

When you turn on the system, the BIOS setup automatically

detects and assigns resources to the new device (applicable only to

Plug-and-Play expansion cards).

51

Installing the BMC module

The optional BMC module allows system administrators to manage the
Altos G330 Mk2 system remotely over a network.

To install the BMC module:

1 Perform the pre-installation instructions described on page 30.
2 Locate the IPMI_1 slot. If necessary, remove any boards or cables

that prevent access to it.
3 If necessary, open the holding clips of the IPMI_1 slot.
4 Remove the BMC module from its protective packaging, handling

it by the edges.
5 Install the BMC module.

(1) Align the module so that the notch on the IPMI_1 slot fits the

keyed edge of the module, then press the module at both
ends to seat it fully into the slot.

When the module is properly installed, the holding clips will
automatically lock in place.

(2) Secure the module with the one screw.

6 Observe the post-installation instructions described on page 30.

52

3 System upgrade

Installing the TPM module

The optional TPM module allows system administrators to enhance the
security of Altos G330 Mk2 system.

To install the TPM module:

1 Perform the pre-installation instructions described on page 30.
2 Locate the TPM module connector. If necessary, remove any boards

or cables that prevent access to it.

3 Remove the TPM module from its protective packaging, handling

it by the edges.

4 Install the TPM module.

(1) Insert the TPM module into the TPM module connector.

5 Observe the post-installation instructions described on page 30.

4 System BIOS

This chapter gives information about the
system BIOS and discusses how to configure
the system by changing the settings of the
BIOS parameters.

55

BIOS overview

BIOS setup is a hardware configuration program built into the system's
Basic Input/Output System (BIOS). Since most systems are already
properly configured and optimized, there is no need to run this utility.
You will need to run this utility under the following conditions.

• When changing the system configuration settings

• When redefining the communication ports to prevent any conflicts

• When modifying the power management configuration

• When changing the password or making other changes to the

security setup

• When a configuration error is detected by the system and you are

prompted ("Run Setup" message) to make changes to the BIOS

setup

Note: If you repeatedly receive Run Setup messages, the battery
may be bad. In this case, the system cannot retain configuration
values in CMOS. Ask a qualified technician for assistance.

BIOS setup loads the configuration values in a battery-backed
nonvolatile memory called CMOS RAM. This memory area is not part
of the system RAM which allows configuration data to be retained
when power is turned off.

Before you run the PhoenixBIOS Setup Utility, make sure that you have
saved all open files. The system reboots immediately after you close
the Setup.

Note: PhoenixBIOS Setup Utility will be simply referred to as

"Setup" or "Setup utility" in this guide.

The screenshots used in this guide display default system values.
These values may not be the same those found in your system.

56

4 System BIOS

Entering BIOS setup

1 Turn on the server and the monitor.

If the server is already turned on, close all open applications, then
restart the server.

2 During POST, press F2.

If you fail to press F2 before POST is completed, you will need to
restart the server.

The Setup Main menu will be displayed showing the Setup’s menu
bar. Use the left and right arrow keys to move between selections
on the menu bar.

BIOS setup primary menus

The tabs on the Setup menu bar correspond to the six primary BIOS
Setup menus, namely:

•Main

•Advanced

•Security

• Server

•Boot

• Exit

In the descriptive table following each of the menu screenshots,
settings in boldface are the default and suggested settings.

57

BIOS setup navigation keys

Use the following keys to move around the Setup utility.

• Left and Right arrow keys – Move between selections on the

menu bar.

• Up and Down arrow keys – Move the cursor to the field you

want.

• PgUp and PgDn keys – Move the cursor to the previous and next

page of a multiple page menu.

•Home – Move the cursor to the first page of a multiple page

menu.

•End – Move the cursor to the last page of a multiple page menu.

• + and - keys – Select a value for the currently selected field (only if

it is user-configurable). Press these keys repeatedly to display each

possible entry, or the Enter key to choose from a pop-up menu.

Note: Grayed-out fields are not user-configurable.

• Enter key – Display a submenu screen.

Note: Availability of submenu screen is indicated by a (>).

•Esc – If you press this key:

• On one of the primary menu screens, the Exit menu displays.

• On a submenu screen, the previous screen displays.

• When you are making selections from a pop-up menu, closes
the pop-up without making a selection.

• F1 – Display the BIOS setup General Help panel.

•F9 – Press to load default system values.

• F10 – Save changes made the Setup and close the utility.

58

Main menu

Parameter Description

4 System BIOS

System Time Set the system time following the hour-minute-second

System Date Set the date following the weekday-month-day-year

BIOS Version Version number of the BIOS setup utility

BIOS Date Date when the BIOS setup utility was created

Processor
CPU Type
CPU Speed
CPU Count

Total Memory
Size

format.

format.

Technical specifications for the installed processor

Total size of system memory detected during POST

Advanced menu

The Advanced menu display submenu options for configuring the
function of various hardware components. Select a submenu item,
then press Enter to access the related submenu screen.

59

60

4 System BIOS

Advanced Processor Options

Parameter Description Option

CPU Type Processor model name

CPU Speed The processor speed is the speed at which a

FSB Speed Front side bus frequency

Processor CPUID Processor ID number

Processor L2
Cache

C1 Enhanced
Mode

microprocessor executes instructions. Clock
speeds are expressed in megahertz (MHz),
with 1 MHz being equal to 1 million cycles
per second. The faster the clock, the more
instructions the CPU can execute per
second.

Processor second-level cache size detected during POST
Note: This field is not shown on the above screenshot.

Select whether to enable the C1 Enhanced
mode for the processor. If enabled, all
logical processors in a physical processor
will run in a C1 state.

Enabled

Disabled

Parameter Description Option

61

Intel
Virtualization
Technology

Execute Disable
Bit

Intel EIST
Support

Processor
Multicore

Trusted
Execution
Technology

Hardware
Prefetcher

Select whether to enable the Intel
Virtualization Technology function. VT
allows a single platform to run multiple
operating systems in independent
partitions.

Select whether to enable the Intel Execute
Disable Bit (XD) function. The XD function
allows the processor to divide the system
memory into areas for storage of processor
instructions or for storage of data. When a
malicious worm attempts to insert code in
the buffer, the processor disables code
execution, preventing damage or worm
propagation.

Enable/Disable Enhanced Intel SpeedStep
Technology.

Enable/Disable processor multicore Enabled

Enable/Disable Trusted Execution
Technology

Select whether to enable the speculative
prefetch unit of the processor.

Enabled

Disabled

Enabled

Disabled

Enabled

Disabled

Disabled

Enabled

Disabled

Enabled

Disabled

Adjacent Cache
Line Prefetch

When enabled, cache lines are fetched in
pairs. When disabled, only the required
cache line is fetched.

Enabled

Disabled

62

Memory Configuration

4 System BIOS

Parameter Description Option

System Memory Total size of system memory detected during POST

Extended
Memory

DIMM Group A1,
A2, B1, B2 Status

Memory Retest Select whether to delete the historical

Total size of extended memory detected during POST

The size of memory installed on each of the FBD slots.

Yes
memory data log. System memory will
be retested on the next boot-up.

No

Advanced Chipset Control

Parameter Description Option

63

Wake On LAN/
PME

Wake On Ring Select whether to wake up the system

Wake On RTC
Alarm

Select whether to wake up the system
when a LAN or PME event is detected.

when an incoming call is detected on
the modem.

Select whether to wake up the system
when an RTC alarm is detected.

Enabled

Disabled

Enabled

Disabled

Enabled

Disabled

64

4 System BIOS

PCI Configuration

Parameter Description Option

PCI Slot 1 - 5
Option ROM

Onboard LAN
Control

LAN Option
ROM Scan

Onboard VGA
Control

When enabled, this setting will initialize
the device expansion ROM for the related
PCI slot.

Enable or Disable the onboard LAN Device
by setting item to the desired value

Select whether to enable the selected
onboard LAN device. When enabled,
device expansion ROM will be initialized.

Enable or Disable the onboard VGA by
setting item to the desired value

Enabled

Disabled

Enabled

Disabled

Enabled

Disabled

Enabled

Disabled

I/O Device Configuration

Parameter Description Option

65

Serial Port A/B When enabled allows you to configure

the serial port settings.
When set to Auto allows the server’s

BIOS or OS to select a configuration.
When set to Disabled, displays no

configuration for the serial port.

Base I/O address Base I/O address and IRQ setting for the

selected serial port

PS/2 Mouse Enable this parameter if you intend to

use a mouse or trackball with a PS/2
interface.

USB Controller Enables or disables the onboard USB

controller.

Enabled

Disabled
Auto

3F8/IRQ4

2F8/IRQ3
3E8/IRQ4
2E8/IRQ3

Enabled

Disabled

Enabled

Disabled

66

Parameter Description Option

4 System BIOS

Legacy USB
Support

Enables or disables support for legacy
USB devices.

Enabled

Disabled

IDE Configuration

The IDE Configuration submenu lets you define the parameter settings
related to the system hard drive(s).

Parameter Description Option

Serial ATA Select whether to enable support for

Native Mode
Operation

SATA RAID
Enable

SATA AHCI
Enable

SATA devices.

Select the native mode for the SATA
function.

Enable/Disable SATA RAID function. Enabled

Set this item to enable SATA AHCI
function for WinXP-SP1+IAA driver
supports AHCI mode.

Enabled

Disabled

Auto

Serial ATA

Disabled

Enabled

Disabled

I/O Channel 0/Secondary Master/Slave

Parameter Description Option

Type Selects the drive type. Auto

None
CD-ROM
ATAPI Removable
IDE Removable
User

67

Total Sectors Total number of sectors available in the selected hard drive.

Maximum
Capacity

Multi-Sector
Transfers

LBA Mode
Control

Maximum capacity of the selected hard drive.

Set the multi-Sector transfer mode. 16 Sectors

Disabled
2 Sectors
4 Sectors
8 Sectors

Selects the hard disk drive translation
method. For drivers with more than
504 MB, LBA mode is necessary.

Enabled

Disabled

68

Parameter Description Option

4 System BIOS

32-bit I/O Enables or disables the 32-bit data

transfer function

Transfer
Mode

Ultra DMA
Mode

Select a transfer mode to enhance hard
disk performance.

Selects DMA (Direct Memory Access)
mode.

Disabled

Enabled

Fast PIO 4

Standard
Fast PIO 1
Fast PIO 2
Fast PIO 3
FPIO 3/DMA 1
FPIO 4/DMA 2

Mode 6

Disabled
Mode 0
Mode 1
Mode 2
Mode 3
Mode 4
Mode 5

Floppy Configuration

The Floppy Configuration submenu displays the type of floppy disk
drive installed in the server.

69

70

4 System BIOS

Boot Configuration

Parameter Description Option

Boot-time
Diagnostic
Screen

Multiprocessor
Specification

POST Error
Pause

After Power
Failure

Choose whether to display the boot-time
diagnostic screen during POST.

Select the multiprocessor (MP) specification
revision level.

Note: Some operating system will require a

1.1 setting for compatibility reasons.

Select whether to pause POST when a
boot-up error is detected.

Defines the power state to resume to after a
system shutdown that is due to an
interruption in AC power.

When set to Last State, the system will
return to the active power state prior to
shutdown.

When set to Stay Off, the system remains
off after power shutdown.

When set to Power On, the system will be
turned on from a power failure.

Disabled

Enabled

1.4

1.1

Enabled

Disabled

Last State

Stay Off

Power On

Parameter Description Option

71

NumLock Select the NumLock behavior during

boot-up.

Security Mode
for PWR/RST
button

Enable/Disable Security mode for PWR
button and RST button

On

Off

Enabled

Disabled

72

4 System BIOS

Security menu

The Security menu allows you to safeguard and protect the system
from unauthorized use by setting up access passwords.

There are three types of passwords that you can set:

• Supervisor password
Entering this password will allow the user to access and change all

settings in the Setup Utility.

• User password
Entering this password will restrict a user’s access to the Setup

menus. To enable or disable this field, a supervisor password must
first be set. A user can only access and modify the System Time,
System Date, and Set User Password fields.

• Power-on password
When the Password on Boot field is enabled, a password will be

required to boot up the server. To enable or disable this field, a
supervisor password must first be set.

Parameter Description Option

73

Supervisor
Password Is

User Password Is This parameter indicates whether a user

Set Supervisor
Password

Set User
Password

Password On
Boot

TPM Support Enable/Disable Trusted Platform Module

This parameter indicates whether a
supervisor password has been assigned.

password has been assigned.

Press Enter to configure the supervisor password.

Press Enter to configure the user password.

Select Enabled to activate security check
during POST.

support

Clear
Enabled

Clear
Enabled

Disabled

Enabled

Disabled

Enabled

Setting a system password

1 Use the up/down keys to select a password parameter (Set

Supervisor Password or Set User Password), then press Enter.
A password box will appear.

2 Type a password then press Enter.

The password may consist of up to six alphanumeric characters
(A-Z, a-z, 0-9).

3 Retype the password to verify the first entry then press Enter

again.
4 Press F10.
5 Select Yes to save the new password and close the Setup Utility.

74

4 System BIOS

Changing a system password

1 Use the up/down keys to select a password parameter (Set

Supervisor Password or Set User Password), then press Enter.
2 Type the original password then press Enter.
3 Type a new password then press Enter.
4 Retype the password to verify the first entry then press Enter

again.
5 Press F10.
6 Select Yes to save the modified password and close the Setup

Utility.

Removing a system password

1 Use the up/down keys to select a password parameter (Set

Supervisor Password or Set User Password), then press Enter.
2 Enter the current password then press Enter.
3 Press Enter twice without entering anything in the new and

confirm password fields.

After doing this, the system automatically sets the related

password parameter to Clear.

Server menu

Parameter Description

System Management Displays basic system ID information, as well as

BIOS and BMC firmware versions.
Press Enter to access the related submenu.

75

Console Redirection Displays console redirection-related settings.

Press Enter to access the related submenu.

Event Log Configuration Displays DMI event log-related settings.

Press Enter to access the related submenu.

76

4 System BIOS

System Management

The System Management submenu is a simple display page for basic
system ID information, as well as BIOS and BMC firmware versions.

Items on this window are non-configurable.

Parameter Description

Clear Case Open Status Press Enter to select whether to clear case open

status

Console Redirection

Parameter Description Option

77

COM Port
Address

Baud Rate Select the baud rate for console

Select whether to enable console
redirection.

Console redirection enables users to
manage the system from a remote
location.

redirection.

Onboard COM A
Onboard COM B

Disabled

300
1200
2400
9600

19.2K

38.4K

57.6K

115.2K

78

Parameter Description Option

4 System BIOS

Console
Typ e

Flow
Control

Continue
C.R. After
POST

Select a terminal type to be used for
console redirection.

Assign control for the console redirection
flow.

Select whether to enable console
redirection after POST.

VT100,
VT100 8bit

PC-ANSI 7bit

VT100+
VT-UTF8

None
XON/OFF

CTS/RTS

On

Off

Event Log Configuration

Parameter Description Option

79

Clear All Event
Logs

Log POST Sys.
Event

Press Enter then select whether to clear all entries in
the system event log.

Select whether to enable the BIOS event
log to be integrated in the system event
log.

Disabled

Enabled

80

4 System BIOS

Boot menu

The Boot menu allows you to set the drive priority during system
boot-up. BIOS setup will display an error message if the drive(s)
specified is not bootable.

By default, the server searches for boot devices in the following order:
1 Floppy disk drive
2 Optical disc drive
3 Hard drive

81

Exit menu

The Exit menu displays the various options to quit from the BIOS setup.
Highlight any of the exit options then press Enter.

Parameter Description

Exit Saving
Changes

Exit Discarding
Changes

Load Setup
Defaults

Discard
Changes

Save Changes Saves changes made in the BIOS setup.

Saves changes made and close the BIOS setup.

Discards changes made and close the BIOS setup.

Loads the default settings for all BIOS setup parameters.
Setup Defaults are quite demanding in terms of
resources consumption. If you are using low-speed
memory chips or other kinds of low-performance
components and you choose to load these settings, the
system might not function properly.

Discards all changes made in the BIOS setup.

82

4 System BIOS
