Acer 4750 Schematics

5

JV50-CP Block Diagram

D D

Clock Generator

ICS9LRS3197AKLFT

DDRIII

3

800/1066/1333

DDRIII
800/1066/1333

Slot 0

Slot 1

20

21

4

DDRIII Channel A

DDRIII Channel B

Intel CPU

Arrandale
Clarksfield

4~10

3

PCI EXPRESS GRAPHIC

X16

2

Project code: 91.4GD01.001
PCB P/N : 48.4GD01.0SB
REVISION : SB 09285

ATI

Madison
or Park

62~66

VRAM

sDDR3 1Gb*8

67~70

1

CPU DC/DC

ISL62882

INPUTS

DCBATOUT

OUTPUTS

VCC_CORE

SYSTEM DC/DC

TPS51123

INPUTS

DCBATOUT

OUTPUTS

5V_S5
3D3V_S5

SYSTEM DC/DC

47,48

49

TPS51117

DMIx4

Mini-Card 1

WLAN

37

PCIE+USB 2.0

INTEL

PCH

Mini-Card 2

C C

RJ45
CONN

31

WLAN or 3G

Giga LAN

BCM57780

37

PCIE

30

INT MIC

HD AUDIO

MIC IN

LINE IN

CODEC

ALC272

32

AZALIA

14 USB 2.0/1.1 ports

(10/100/1000Mb)ETHERNET

High Definition Audio

6 SATA ports
8 PCIE ports

ACPI 1.1
LPC I/F

PCI/PCI BRIDGE

FDIx8

PCH RGB CRT

PCH LVDS 1CH

PCH Digital Display

USB 2.0

RGB CRT

Switch

22

WEBCAM

BLUETOOTH

USB x 4

Card Reader

AU6433

Touch Panel

Finger Print

LVDS 1CH

Switch

22

Digital Display

Switch

25

CRT

24

LCD

HDMI

23

25

36

WXGA+

23

28

29

SD/MMC

36

23

43

MS/MS Pro/xD

LINE OUT&SPDIF

B B

SATA HDD

26

SATA

2CH SPEAKER

RJ11

A A

5

OP AMP

APA2031

MODEM

MDC CARD

33

35

FAN

Flash ROM

4

128KB

SPI

41

Thermal
Sensor

G787

NPCE781B

39

LPC Bus

KBC

Touch
PAD

43

11~19

3

40

Int.
KB

40

SPI

LPC debug

40

PCB STACKUP

TOP

GND

S

S

GND

BOTTOM

SATA ODD

Flash ROM

4MB

27

41

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
A3

A3

A3
Date: Sheet of

Date: Sheet of

2

Date: Sheet of

Block Diagram

Block Diagram

Block Diagram

JV50-CP

JV50-CP

JV50-CP

INPUTS

DCBATOUT

SYSTEM DC/DC

INPUTS

DCBATOUT

SYSTEM DC/DC

INPUTS

DCBATOUT

INPUTS

3D3V_S0

INPUTS

1D5V_S3

SYSTEM DC/DC

INPUTS

DCBATOUT

SYSTEM DC/DC

INPUTS

DCBATOUT

CHARGER

ISL88731A

INPUTS

DCBATOUT

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

1

OUTPUTS

1D5V_S3

TPS51117

OUTPUTS

1D05V_S0

TPS51117

OUTPUTS

1D05V_VTT

RT9025

OUTPUTS

1D8V_S0

G2997

OUTPUTS

0D75_S0

ISL62881

OUTPUTS

VCC_GFXCORE

TPS51117

OUTPUTS

+VGA_CORE

OUTPUTS

1 57Thursday, August 27, 2009

1 57Thursday, August 27, 2009

1 57Thursday, August 27, 2009

BT+

50

50

51

50

52

54

55

53

SA

SA

SA

A

B

C

D

E

Processor StrappingPCH Strapping

Name Schematics Notes

SPKR

4 4

3 3

INIT3_3V#
GNT3#/

GPIO55

INTVRMEN

GNT0#,
GNT1#

GNT2#/
GPIO53

GPIO33

SPI_MOSI

NV_ALE

NC_CLE
HAD_DOCK_EN#

/GPIO[33]
HDA_SDO

HDA_SYNC
GPIO15
GPIO8
GPIO27

Reboot option at power-up

Internal weak Pull-down.

Default Mode:

Connect to Vcc3_3 with 8.2-kΩ

No Reboot Mode with TCO Disabled:

- 10-kΩ weak pull-up resistor.
Weak internal pull-down. Do not pull high.

Internal pull-up.

Default Mode:

(Connect to ground with 4.7-kΩ weak

Low (0) = Top Block Swap Mode

pull-down resistor).

High (1) = Integrated VRM is enabled
Low (0) = Integrated VRM is disabled

Left both GNT0# and GNT1# floating. No pull up

Default (SPI):

required.
Connect GNT1# to ground with 1-kΩ pull-down

Boot from PCI:

resistor. Leave GNT0# Floating.
Connect both GNT0# and GNT1# to ground with 1-kΩ

Boot from LPC:

pull-down resistor.

Default - Internal pull-up.

= Configures DMI for ESI compatible operation (for servers

Low (0)

only. Not for mobile/desktops).

Do not pull low.

Default:

Connect to ground with 1-kΩ

Disable ME in Manufacturing Mode:

pull-down resistor.

Connect to Vcc3_3 with 8.2-kΩ weak pull-up resistor.

Enable iTPM:

Left floating, no pull-down required.

Disable iTPM:

Connect to Vcc3_3 with 8.2-kΩ weak pull-up

Enable Danbury:

resistor.
Connect to ground with 4.7-kΩ weak pull-down

Disable Danbury:

resistor.
Weak internal pull-up. Do not pull low.

Flash Descriptor Security will be overridden.

Low (0):

Flash Descriptor Security will be in effect.

High (1) :

Weak internal pull-down. Do not pull high.
Weak internal pull-down. Do not pull high.
Weak internal pull-down. Do not pull high.
Weak internal pull-up. Do not pull low.

Default = Do not connect (floating)

High(1) = Enables the internal VccVRM to have a clean supply for
analog rails. No need to use on-board filter circuit.
Low (0) = Disables the VccVRM. Need to use on-board filter
circuits for analog rails.

Pin Name

CFG[4]

CFG[3]

CFG[0]

CFG[7]

Strap Description Configuration (Default value for each bit is

DisplayPort
Presence

PCI-Express Static
Lane Reversal

PCI-Express
Configuration
Select

Reserved ­Temporarily used
for early
Clarksfield
samples.

1 unless specified otherwise)

Disabled - No Physical Display Port attached to

1:Embedded

Embedded DisplayPort.
Enabled - An external Display Port device is

0:

connected to the Embedded Display Port.
Normal Operation.

1:

Lane Numbers Reversed 15 -> 0, 14 -> 1, ...

0:

Single PCI-Express Graphics

1:

Bifurcation enabled

0:

-

Clarksfield (only for early samples pre-ES1)

Connect to GND with 3.01K Ohm/5% resistor
Only temporary for early CFD samples

Note:

(rPGA/BGA) [For details please refer to the WW33
MoW and sighting report].
For a common motherboard design (for AUB and CFD),
the pull-down resistor should be used. Does not
impact AUB functionality.

Default
Value

1

1

1

0

2 2

USB Table

PCIE Routing

LANE1
LANE2

LAN
MiniCard1

Pair

MiniCard2LANE3

1 1

Device

0

USB3
USB2

1

USB4

2
3

MINICARD1

4 WECAM

Touch Panel

5

NC

6
7

NC

89NC

USB1(HS)

10

Finger Print

11

Blue Tooth

1213MINIC2

Cardreader

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
A3

A3

A3
Date: Sheet of

Date: Sheet of

Date: Sheet of

Table of Content

Table of Content

Table of Content

JV50-CP

JV50-CP

JV50-CP

Taipei Hsien 221, Taiwan, R.O.C.

2 57Tuesday, August 18, 2009

2 57Tuesday, August 18, 2009

2 57Tuesday, August 18, 2009

SA

SA

SA

A

3D3V_S0

4 4

R276

R276

0R3J-0-U-GP

0R3J-0-U-GP

1 2

B

C387

C387

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

3D3V_CK505

12

C371

C371

SC1U10V2ZY-GP

SC1U10V2ZY-GP

1D5V_S0

12

C375

C375

C

1D5V_S0_CLKGEN

R268

R268

1 2

Do Not Stuff

Do Not Stuff

0R3J-0-U-GP

0R3J-0-U-GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

1 2

R267

R267

DY

DY

1D5V_S0_CLKGEN

1D5V_S0_CLKGEN

3D3V_CK505_IO

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

C380

C380

12

C382

C382

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

12

C372

C372

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

12

C379

C379

12

12

C383

C383

C378

C378

SC1U10V2ZY-GP

SC1U10V2ZY-GP

D

1D05V_S0

R280

R280

1 2

0R3J-0-U-GP

0R3J-0-U-GP

R281

R281

Do Not Stuff

C390

C390

12

Do Not Stuff

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

1 2

DY

DY

3D3V_S0

E

SA 0622 EMI

VGA_XIN1_L

VGA_XIN1 63
OSC_SPREAD 63

CLK_ICH14 12

12

C373

C373

Do Not Stuff

Do Not Stuff

OSC_SPREAD_L

3D3V_S0

PCH_SMBDATA

PCH_SMBCLK

1

5

VDDREF_3_3

GNDCPU

12

15

VDD_27MHZ

VDDDOT96MHZ_3_3

GNDDOT96MHZ

GNDSRC

2

18

VDDSRC_IO

VDDCPU_IO

27MHZ_NONSS

27MHZ_SS

CPU_STOP#

CLKPWRGD/PD#_3_3

REF_3L/FSLC_3_3

SDATA_3_3

SCLK_3_3

GND27MHZ8GNDSATA

9

X1
X2

VGA_XIN1_L

6

OSC_SPREAD_L

7

CPU_STOP#

16

CLK_EN

25

FSC

30

GEN_XTAL_IN

28

GEN_XTAL_OUT

27
31

32

DY

DY

4

R269 10KR2J-3-GPR269 10KR2J-3-GP

1 2

R260 33R2J-2-GPR260 33R2J-2-GP

1 2

RNT1

RNT1

1

Do Not Stuff

Do Not Stuff

23

PCH_SMBDATA 12,20,21

PCH_SMBCLK 12,20,21

DY

DY

17

24

U19

U19

DREFCLK#12

DREFCLK12

CLKIN_DMI#12

CLKIN_DMI12

CLK_PCIE_SATA#12

3 3

CLK_PCIE_SATA12

CLK_CPU_BCLK#12

CLK_CPU_BCLK12

SRN0J-10-GP-U

SRN0J-10-GP-U

SRN0J-10-GP-U

SRN0J-10-GP-U
SRN0J-10-GP-U

SRN0J-10-GP-U

SRN0J-10-GP-U

SRN0J-10-GP-U

RN34

RN34

RN38

RN38

RN37

RN37

RN39

RN39

4

4

4

4

DREFCLK_R

23

CLKIN_DMI#_R

1

CLKIN_DMI_R

23

CLK_PCIE_SATA#_R

1

CLK_PCIE_SATA_R

23

CLK_CPU_BCLK#_R

23

CLK_CPU_BCLK_R

1

DREFCLK#_R

1

4

DOT96C_LPR

3

DOT96T_LPR

14

SRCC1_LPR

13

SRCT1_LPR

11

SATAC_LPR

10

SATAT_LPR

22

CPUC0_LPR

23

CPUT0_LPR

19

CPUC1_LPR

20

CPUT1_LPR

SLG8SP585VTR-GP

SLG8SP585VTR-GP

71.08585.003

71.08585.003

2ND = 71.08585.003

2ND = 71.08585.003

29

VDDSRC_3_3

VDDCPU_3_3

GNDREF

GND

21

26

33

1 2

EC41 Do Not Stuff

EC41 Do Not Stuff

1 2

DY

DY

EC40 Do Not Stuff

EC40 Do Not Stuff

DY

DY

DY

DY

1 2

ECT6 Do Not Stuff

ECT6 Do Not Stuff

DY

DY

1 2

ECT5 Do Not Stuff

ECT5 Do Not Stuff

SA 0629 RF

3D3V_S0

2 2

C376

C376

SC10P50V2JN-4GP

SC10P50V2JN-4GP

1 2

1 2

C377

C377

SC10P50V2JN-4GP

SC10P50V2JN-4GP

12

X4

X4
X-14D31818M-37GP

X-14D31818M-37GP

82.30005.901

82.30005.901

GEN_XTAL_OUT_R

1 2

0R2J-2-GP

0R2J-2-GP

R266

R266

GEN_XTAL_IN

12

R265

R265
Do Not Stuff

Do Not Stuff

DY

DY

GEN_XTAL_OUT

SB 0813

1 1

A

B

1D05V_VTT

DY

DY

1 2

1 2

R262

R262
Do Not Stuff

Do Not Stuff

R263

R263
2K2R2J-2-GP

2K2R2J-2-GP

FSC 0 1

SPEED

FSC

133MHz

(Default)

C

100MHz

CLK_EN

2N7002-12-GP

2N7002-12-GP

D

Q18

Q18

10KR2J-3-GP

10KR2J-3-GP
R275

R275

1 2

S D

G

VR_CLKEN# 47

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
A3

A3

A3
Date: Sheet of

Date: Sheet of

Date: Sheet of

Clock Generator

Clock Generator

Clock Generator

JV50-CP

JV50-CP

JV50-CP

Taipei Hsien 221, Taiwan, R.O.C.

3 57Thursday, September 03, 2009

3 57Thursday, September 03, 2009

3 57Thursday, September 03, 2009

E

SA

SA

SA

5

D D

DMI_TXN013
DMI_TXN113
DMI_TXN213
DMI_TXN313

DMI_TXP013
DMI_TXP113
DMI_TXP213
DMI_TXP313

DMI_RXN013
DMI_RXN113
DMI_RXN213
DMI_RXN313

DMI_RXP013
DMI_RXP113
DMI_RXP213
DMI_RXP313

FDI_TXN013
FDI_TXN113
FDI_TXN213

RN74

RN74

4

SRN1KJ-7-GP

SRN1KJ-7-GP

DIS_ONLY

DIS_ONLY

RN81

RN81

4

SRN1KJ-7-GP

SRN1KJ-7-GP

DIS_ONLY

DIS_ONLY

FDI_TXN313
FDI_TXN413
FDI_TXN513
FDI_TXN613
FDI_TXN713

FDI_TXP013
FDI_TXP113
FDI_TXP213
FDI_TXP313
FDI_TXP413
FDI_TXP513
FDI_TXP613
FDI_TXP713

FDI_FSYNC013
FDI_FSYNC113

FDI_INT13
FDI_LSYNC013

FDI_LSYNC113

FDI_FSYNC1

1

FDI_LSYNC1

23

FDI_LSYNC0

1

FDI_FSYNC0

23

C C

B B

For Graphics Disable , Pull-down to
GND via 1-k ± 5% resistor

SB 0820

4

DIS_ONLY

DIS_ONLY

12

R660

R660
1KR2J-1-GP

1KR2J-1-GP

CPU1A

CPU1A

A24

DMI_RX0#

C23

DMI_RX1#

B22

DMI_RX2#

A21

DMI_RX3#

B24

DMI_RX0

D23

DMI_RX1

B23

DMI_RX2

A22

DMI_RX3

D24

DMI_TX0#

G24

DMI_TX1#

F23

DMI_TX2#

H23

DMI_TX3#

D25

DMI_TX0

F24

DMI_TX1

E23

DMI_TX2

G23

DMI_TX3

E22

FDI_TX0#

D21

FDI_TX1#

D19

FDI_TX2#

D18

FDI_TX3#

G21

FDI_TX4#

E19

FDI_TX5#

F21

FDI_TX6#

G18

FDI_TX7#

D22

FDI_TX0

C21

FDI_TX1

D20

FDI_TX2

C18

FDI_TX3

G22

FDI_TX4

E20

FDI_TX5

F20

FDI_TX6

G19

FDI_TX7

F17

FDI_FSYNC0

E17

FDI_FSYNC1

C17

FDI_INT

F18

FDI_LSYNC0

D17

FDI_LSYNC1

CATHERINE#2177

CATHERINE#2177

62.10055.321

62.10055.321

2ND = 62.10055.321

2ND = 62.10055.321

3

1 OF 9

1 OF 9

PEG_ICOMPI

PEG_ICOMPO

PEG_RCOMPO

PEG_RBIAS

PEG_RX0#
PEG_RX1#
PEG_RX2#

DMI

DMI

PEG_RX3#
PEG_RX4#
PEG_RX5#

PCI EXPRESS -- GRAPHICS

PCI EXPRESS -- GRAPHICS

PEG_RX6#
PEG_RX7#
PEG_RX8#

PEG_RX9#
PEG_RX10#
PEG_RX11#
PEG_RX12#
PEG_RX13#
PEG_RX14#
PEG_RX15#

PEG_RX0
PEG_RX1
PEG_RX2
PEG_RX3
PEG_RX4
PEG_RX5

Intel(R) FDI

Intel(R) FDI

PEG_RX6
PEG_RX7
PEG_RX8

PEG_RX9
PEG_RX10
PEG_RX11
PEG_RX12
PEG_RX13
PEG_RX14
PEG_RX15

PEG_TX0#
PEG_TX1#
PEG_TX2#
PEG_TX3#
PEG_TX4#
PEG_TX5#
PEG_TX6#
PEG_TX7#
PEG_TX8#
PEG_TX9#

PEG_TX10#
PEG_TX11#
PEG_TX12#
PEG_TX13#
PEG_TX14#
PEG_TX15#

PEG_TX0
PEG_TX1
PEG_TX2
PEG_TX3
PEG_TX4
PEG_TX5
PEG_TX6
PEG_TX7
PEG_TX8

PEG_TX9
PEG_TX10
PEG_TX11
PEG_TX12
PEG_TX13
PEG_TX14
PEG_TX15

AUBURNDALE

AUBURNDALE

PEG_IRCOMP_R

B26
A26
B27

EXP_RBIAS

A25

PEG_RXN15

K35

PEG_RXN14

J34

PEG_RXN13

J33

PEG_RXN12

G35

PEG_RXN11

G32

PEG_RXN10

F34

PEG_RXN9

F31

PEG_RXN8

D35

PEG_RXN7

E33

PEG_RXN6

C33

PEG_RXN5

D32

PEG_RXN4

B32

PEG_RXN3

C31

PEG_RXN2

B28

PEG_RXN1

B30

PEG_RXN0

A31

PEG_RXP15

J35

PEG_RXP14

H34

PEG_RXP13

H33

PEG_RXP12

F35

PEG_RXP11

G33

PEG_RXP10

E34

PEG_RXP9

F32

PEG_RXP8

D34

PEG_RXP7

F33

PEG_RXP6

B33

PEG_RXP5

D31

PEG_RXP4

A32

PEG_RXP3

C30

PEG_RXP2

A28

PEG_RXP1

B29

PEG_RXP0

A30

PEG_TXN15_L PEG_TXN15

L33

PEG_TXN14_L PEG_TXN14

M35

PEG_TXN13_L PEG_TXN13

M33

PEG_TXN12_L PEG_TXN12

M30

PEG_TXN11_L PEG_TXN11

L31

PEG_TXN10_L PEG_TXN10

K32

PEG_TXN9_L PEG_TXN9

M29

PEG_TXN8_L PEG_TXN8

J31

PEG_TXN7_L PEG_TXN7

K29

PEG_TXN6_L PEG_TXN6

H30

PEG_TXN5_L PEG_TXN5

H29

PEG_TXN4_L PEG_TXN4

F29

PEG_TXN3_L PEG_TXN3

E28

PEG_TXN2_L PEG_TXN2

D29

PEG_TXN1_L PEG_TXN1

D27

PEG_TXN0_L PEG_TXN0

C26

PEG_TXP15_L PEG_TXP15

L34

PEG_TXP14_L PEG_TXP14

M34

PEG_TXP13_L PEG_TXP13

M32

PEG_TXP12_L PEG_TXP12

L30

PEG_TXP11_L PEG_TXP11

M31

PEG_TXP10_L PEG_TXP10

K31

PEG_TXP9_L PEG_TXP9

M28

PEG_TXP8_L PEG_TXP8

H31

PEG_TXP7_L PEG_TXP7

K28

PEG_TXP6_L PEG_TXP6

G30

PEG_TXP5_L PEG_TXP5

G29

PEG_TXP4_L PEG_TXP4

F28

PEG_TXP3_L PEG_TXP3

E27

PEG_TXP2_L PEG_TXP2

D28

PEG_TXP1_L PEG_TXP1

C27

PEG_TXP0_L PEG_TXP0

C25

1 2

1 2

DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS
DIS

DIS

R465

R465

R477

R477

1 2
1 2
1 2
1 2
1 2
1 2
1 2
1 2
1 2
1 2
1 2
1 2
1 2
1 2
1 2
1 2

1 2
1 2
1 2
1 2
1 2
1 2
1 2
1 2
1 2
1 2
1 2
1 2
1 2
1 2
1 2
1 2

2

49D9R2F-GP

49D9R2F-GP

750R2F-GP

750R2F-GP

PEG_RXN[15..0] 62

PEG_RXP[15..0] 62

C151 SCD1U10V2KX-5GP

C151 SCD1U10V2KX-5GP
C148 SCD1U10V2KX-5GP

C148 SCD1U10V2KX-5GP
C147 SCD1U10V2KX-5GP

C147 SCD1U10V2KX-5GP
C154 SCD1U10V2KX-5GP

C154 SCD1U10V2KX-5GP
C153 SCD1U10V2KX-5GP

C153 SCD1U10V2KX-5GP
C156 SCD1U10V2KX-5GP

C156 SCD1U10V2KX-5GP
C158 SCD1U10V2KX-5GP

C158 SCD1U10V2KX-5GP
C160 SCD1U10V2KX-5GP

C160 SCD1U10V2KX-5GP
C162 SCD1U10V2KX-5GP

C162 SCD1U10V2KX-5GP
C164 SCD1U10V2KX-5GP

C164 SCD1U10V2KX-5GP
C173 SCD1U10V2KX-5GP

C173 SCD1U10V2KX-5GP
C182 SCD1U10V2KX-5GP

C182 SCD1U10V2KX-5GP
C206 SCD1U10V2KX-5GP

C206 SCD1U10V2KX-5GP
C198 SCD1U10V2KX-5GP

C198 SCD1U10V2KX-5GP
C218 SCD1U10V2KX-5GP

C218 SCD1U10V2KX-5GP
C225 SCD1U10V2KX-5GP

C225 SCD1U10V2KX-5GP
C150 SCD1U10V2KX-5GP

C150 SCD1U10V2KX-5GP
C149 SCD1U10V2KX-5GP

C149 SCD1U10V2KX-5GP
C146 SCD1U10V2KX-5GP

C146 SCD1U10V2KX-5GP
C155 SCD1U10V2KX-5GP

C155 SCD1U10V2KX-5GP
C152 SCD1U10V2KX-5GP

C152 SCD1U10V2KX-5GP
C157 SCD1U10V2KX-5GP

C157 SCD1U10V2KX-5GP
C159 SCD1U10V2KX-5GP

C159 SCD1U10V2KX-5GP
C161 SCD1U10V2KX-5GP

C161 SCD1U10V2KX-5GP
C163 SCD1U10V2KX-5GP

C163 SCD1U10V2KX-5GP
C165 SCD1U10V2KX-5GP

C165 SCD1U10V2KX-5GP
C178 SCD1U10V2KX-5GP

C178 SCD1U10V2KX-5GP
C191 SCD1U10V2KX-5GP

C191 SCD1U10V2KX-5GP
C211 SCD1U10V2KX-5GP

C211 SCD1U10V2KX-5GP
C203 SCD1U10V2KX-5GP

C203 SCD1U10V2KX-5GP
C216 SCD1U10V2KX-5GP

C216 SCD1U10V2KX-5GP
C229 SCD1U10V2KX-5GP

C229 SCD1U10V2KX-5GP

1

PEG_TXN[15..0] 62

PEG_TXP[15..0] 62

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

A A

ENG DIS MADSION SAMSUNG

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
A3

A3

A3
Date: Sheet of

Date: Sheet of

Date: Sheet of

CPU (1/7)

CPU (1/7)

CPU (1/7)

JV50-CP

JV50-CP

JV50-CP

Taipei Hsien 221, Taiwan, R.O.C.

4 57Thursday, September 03, 2009

4 57Thursday, September 03, 2009

4 57Thursday, September 03, 2009

SA

SA

SA

5

4

3

2

1

1D05V_VTT

1 2

R151 49D9R2F-GPR151 49D9R2F-GP

1 2

R112 68R2-GPR112 68R2-GP

H_CATERR#
PROCHOT#

D D

H_PECI16

H_PROCHOT#47

PM_THRMTRIP-A#16,45

H_PM_SYNC13

R154 0R2J-2-GPR154 0R2J-2-GP

C C

H_PWRGD16,45,59

PM_DRAM_PWRGD13

H_VTTPW RGD51

PLT_RST#15,30,36,37,40,41,59,62

1 2

1 2

R120 20R2F-GPR120 20R2F-GP

1 2

R115 20R2F-GPR115 20R2F-GP

1 2

R142 49D9R2F-GPR142 49D9R2F-GP

1 2

R110 49D9R2F-GPR110 49D9R2F-GP

TP44Do Not Stuff TP44Do Not Stuff

R116 Do Not Stuff

R116 Do Not Stuff

1 2

DY

DY

TP43Do Not Stuff TP43Do Not Stuff

1

R153 0R2J-2-GPR153 0R2J-2-GP

1 2

1 2

R158 0R2J-2-GPR158 0R2J-2-GP

TP42Do Not Stuff TP42Do Not Stuff

1

R144

R144

1 2

1K5R2F-2-GP

1K5R2F-2-GP

H_COMP3
H_COMP2
H_COMP1
H_COMP0

SKTOCC#_R

1

H_CATERR#

PROCHOT#

H_CPURST#

VCCPWRGOOD_1

VCCPWRGOOD_0

DRAMPW ROK

H_PWRGD_XDP

PLT_RST#_R

12

R146

R146
750R2F-GP

750R2F-GP

CPU1B

CPU1B

AT23

COMP3

AT24

COMP2

G16

COMP1

AT26

COMP0

AH24

SKTOCC#

AK14

CATERR#

AT15

PECI

AN26

PROCHOT#

AK15

THERMTRIP#

AP26

RESET_OBS#

AL15

PM_SYNC

AN14

VCCPWRGOOD_1

AN27

VCCPWRGOOD_0

AK13

SM_DRAMPWROK

AM15

VTTPWRGOOD

AM26

TAPPWRGOOD

AL14

RSTIN#

CATHERINE#2177

CATHERINE#2177

62.10055.321

62.10055.321

2ND = 62.10055.321

2ND = 62.10055.321

MISC

MISC

CLOCKS

CLOCKS

AUBURNDALE

AUBURNDALE

THERMAL PWR MANAGEMENT

THERMAL PWR MANAGEMENT

DDR3

MISC

DDR3

MISC

JTAG & BPM

JTAG & BPM

2 OF 9

2 OF 9

BCLK

BCLK#

BCLK_ITP

BCLK_ITP#

PEG_CLK

PEG_CLK#

DPLL_REF_SSCLK

DPLL_REF_SSCLK#

SM_DRAMRST#

SM_RCOMP0
SM_RCOMP1
SM_RCOMP2

PM_EXT_TS0#
PM_EXT_TS1#

PRDY#
PREQ#

TCK
TMS

TRST#

TDO

TDI_M

TDO_M

DBR#

BPM0#
BPM1#
BPM2#
BPM3#
BPM4#
BPM5#
BPM6#
BPM7#

BCLK_CPU_P

A16

BCLK_CPU_N

B16
AR30

AT30

PEG_CLK_R

E16

PEG_CLK#_R

D16

DPLL_REF_SSCLK

A18

DPLL_REF_SSCLK#

A17

F6
AL1

AM1
AN1

AN15
AP15

AT28
AP27

AN28
AP28
AT27

AT29

TDI

AR27
AR29
AP29

AN25

AJ22
AK22
AK24
AJ24
AJ25
AH22
AK23
AH23

SM_RCOMP_0
SM_RCOMP_1
SM_RCOMP_2

XDP_PRDY#
XDP_PREQ#

XDP_TCLK
XDP_TMS
XDP_TRST#

XDP_TDI
XDP_TDO
XDP_TDI_M
XDP_TDO_M

XDP_DBRESET#

SM_DRAMRST# 16

1

BCLK_CPU_P 16
BCLK_CPU_N 16

PEG_CLK_R 12
PEG_CLK#_R 12

DPLL_REF_SSCLK 12
DPLL_REF_SSCLK# 12

RN22

RN22
SRN10KJ-5-GP

SRN10KJ-5-GP

1
2 3

TP41 Do Not StuffTP41 Do Not Stuff

SB 0814

4

1D05V_VTT

DPLL_REF_SSCLK
DPLL_REF_SSCLK#

SB 0818

SM_RCOMP_0
SM_RCOMP_1
SM_RCOMP_2

PM_EXTTS#0_R 20
PM_EXTTS#1_R 21

SRN0J-10-GP-U

SRN0J-10-GP-U

1 2

R202 100R2F-L1-GP-UR202 100R2F-L1-GP-U

1 2

R197 24D9R2F-L-GPR197 24D9R2F-L-GP

1 2

R199 130R2F-1-GPR199 130R2F-1-GP

RN75

RN75

1

4

2 3

R859

PM_DRAM_PWRGD

B B

1D5V_S0_DDR 1D5V_S0_DDR

12

R155

R155
1K1R2F-GP

12

1K1R2F-GP

R152

R152
3KR2F-GP

3KR2F-GP

NON-S3

NON-S3

DRAMPW ROK

NON-S3

NON-S3

A A

1D5V_S0_PWRGD45,52

R859

1 2

Do Not Stuff

Do Not Stuff

S3

S3

PM_DRAM_PWRGD

1
2
3

Do Not Stuff

Do Not Stuff

PM_DRAM_PWRGD_1

U86

U86

B

VCC

S3

S3

A

Y

GND

Do Not Stuff

Do Not Stuff

12

R782

R782
Do Not Stuff

Do Not Stuff

DY

DY

R781

R781
Do Not Stuff

Do Not Stuff

S3

S3

1 2

3D3V_S5

5

PM_DRAM_PWRGD_1

4

SB 0814

XDP_TMS
XDP_TDI
XDP_PREQ#
XDP_TDO

XDP_TCLK

XDP_TRST#

1 2

DY

DY

R98 Do Not Stuff

R98 Do Not Stuff

1 2

DY

DY

R97 Do Not Stuff

R97 Do Not Stuff

1 2

DY

DY

R96 Do Not Stuff

R96 Do Not Stuff

1 2

R101 51R2J-2-GPR101 51R2J-2-GP

1 2

DY

DY

R118 Do Not Stuff

R118 Do Not Stuff

1 2

R106 51R2J-2-GPR106 51R2J-2-GP

1D05V_VTT

CPU JTAG

XDP_TDO_M

XDP_TDI_M

12

R100

R100
0R2J-2-GP

0R2J-2-GP

3D3V_S0

XDP_DBRESET#

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
A3

A3

A3
Date: Sheet of

Date: Sheet of

Date: Sheet of

1 2

R121 1KR2J-1-GPR121 1KR2J-1-GP

CPU (2/7)

CPU (2/7)

CPU (2/7)

JV50-CP

JV50-CP

JV50-CP

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

5 57Thursday, September 03, 2009

5 57Thursday, September 03, 2009

5 57Thursday, September 03, 2009

SA

SA

SA

5

CPU1C

CPU1C

3 OF 9

3 OF 9

4

3

CPU1D

CPU1D

2

4 OF 9

4 OF 9

1

AA6

SA_CK0

M_A_DQ[63..0]20

D D

C C

B B

M_A_BS020
M_A_BS120
M_A_BS220

M_A_CAS#20
M_A_RAS#20
M_A_WE#20

M_A_DQ0
M_A_DQ1
M_A_DQ2
M_A_DQ3
M_A_DQ4
M_A_DQ5
M_A_DQ6
M_A_DQ7
M_A_DQ8
M_A_DQ9
M_A_DQ10
M_A_DQ11
M_A_DQ12
M_A_DQ13
M_A_DQ14
M_A_DQ15
M_A_DQ16
M_A_DQ17
M_A_DQ18
M_A_DQ19
M_A_DQ20
M_A_DQ21
M_A_DQ22
M_A_DQ23
M_A_DQ24
M_A_DQ25
M_A_DQ26
M_A_DQ27
M_A_DQ28
M_A_DQ29
M_A_DQ30
M_A_DQ31
M_A_DQ32
M_A_DQ33
M_A_DQ34
M_A_DQ35
M_A_DQ36
M_A_DQ37
M_A_DQ38
M_A_DQ39
M_A_DQ40
M_A_DQ41
M_A_DQ42
M_A_DQ43
M_A_DQ44
M_A_DQ45
M_A_DQ46
M_A_DQ47
M_A_DQ48
M_A_DQ49
M_A_DQ50
M_A_DQ51
M_A_DQ52
M_A_DQ53
M_A_DQ54
M_A_DQ55
M_A_DQ56
M_A_DQ57
M_A_DQ58
M_A_DQ59
M_A_DQ60
M_A_DQ61
M_A_DQ62
M_A_DQ63

A10

C10

B10

D10

E10

F10

H10

G10

AH5
AF5
AK6
AK7
AF6
AG5

AJ7
AJ6

AJ10

AJ9

AL10

AK12

AK8

AL7

AK11

AL8

AN8
AM10
AR11

AL11

AM9

AN9

AT11

AP12
AM12
AN12
AM13

AT14

AT12

AL13
AR14

AP14

AC3
AB2

AE1
AB3
AE9

SA_DQ0
SA_DQ1

C7

SA_DQ2

A7

SA_DQ3
SA_DQ4
SA_DQ5
SA_DQ6

A8

SA_DQ7

D8

SA_DQ8
SA_DQ9

E6

SA_DQ10

F7

SA_DQ11

E9

SA_DQ12

B7

SA_DQ13

E7

SA_DQ14

C6

SA_DQ15
SA_DQ16

G8

SA_DQ17

K7

SA_DQ18

J8

SA_DQ19

G7

SA_DQ20
SA_DQ21

J7

SA_DQ22

J10

SA_DQ23

L7

SA_DQ24

M6

SA_DQ25

M8

SA_DQ26

L9

SA_DQ27

L6

SA_DQ28

K8

SA_DQ29

N8

SA_DQ30

P9

SA_DQ31
SA_DQ32
SA_DQ33
SA_DQ34
SA_DQ35
SA_DQ36
SA_DQ37
SA_DQ38
SA_DQ39
SA_DQ40
SA_DQ41
SA_DQ42
SA_DQ43
SA_DQ44
SA_DQ45
SA_DQ46
SA_DQ47
SA_DQ48
SA_DQ49
SA_DQ50
SA_DQ51
SA_DQ52
SA_DQ53
SA_DQ54
SA_DQ55
SA_DQ56
SA_DQ57
SA_DQ58
SA_DQ59
SA_DQ60
SA_DQ61
SA_DQ62
SA_DQ63

SA_BS0
SA_BS1

U7

SA_BS2

SA_CAS#
SA_RAS#
SA_WE#

AUBURNDALE

AUBURNDALE

DDR SYSTEM MEMORY A

DDR SYSTEM MEMORY A

SA_CK0#
SA_CKE0

SA_CK1
SA_CK1#
SA_CKE1

SA_CS0#
SA_CS1#

SA_ODT0
SA_ODT1

SA_DM0

SA_DM1

SA_DM2

SA_DM3

SA_DM4

SA_DM5

SA_DM6

SA_DM7

SA_DQS0#
SA_DQS1#
SA_DQS2#
SA_DQS3#
SA_DQS4#
SA_DQS5#
SA_DQS6#
SA_DQS7#

SA_DQS0
SA_DQS1
SA_DQS2
SA_DQS3
SA_DQS4
SA_DQS5
SA_DQS6
SA_DQS7

SA_MA0

SA_MA1

SA_MA2

SA_MA3

SA_MA4

SA_MA5

SA_MA6

SA_MA7

SA_MA8

SA_MA9

SA_MA10
SA_MA11
SA_MA12
SA_MA13
SA_MA14
SA_MA15

AA7
P7

Y6
Y5
P6

AE2
AE8

AD8
AF9

B9
D7
H7
M7
AG6
AM7
AN10
AN13

C9
F8
J9
N9
AH7
AK9
AP11
AT13

C8
F9
H9
M9
AH8
AK10
AN11
AR13

Y3
W1
AA8
AA3
V1
AA9
V8
T1
Y9
U6
AD4
T2
U3
AG8
T3
V9

M_A_DM0
M_A_DM1
M_A_DM2
M_A_DM3
M_A_DM4
M_A_DM5
M_A_DM6
M_A_DM7

M_A_DQS#0M_A_DQS#0
M_A_DQS#1
M_A_DQS#2
M_A_DQS#3
M_A_DQS#4
M_A_DQS#5
M_A_DQS#6
M_A_DQS#7

M_A_DQS0
M_A_DQS1
M_A_DQS2
M_A_DQS3
M_A_DQS4
M_A_DQS5
M_A_DQS6
M_A_DQS7

M_A_A0
M_A_A1
M_A_A2
M_A_A3
M_A_A4
M_A_A5
M_A_A6
M_A_A7
M_A_A8
M_A_A9
M_A_A10
M_A_A11
M_A_A12
M_A_A13
M_A_A14
M_A_A15

M_CLK_DDR0 20
M_CLK_DDR#0 20
M_CKE0 20

M_CLK_DDR1 20
M_CLK_DDR#1 20
M_CKE1 20

M_CS#0 20
M_CS#1 20

M_ODT0 20
M_ODT1 20

M_A_DM[7..0] 20

M_A_DQS#[7..0] 20

M_A_DQS[7..0] 20

M_A_A[15..0] 20

M_B_DQ[63..0]21

M_B_BS021
M_B_BS121
M_B_BS221

M_B_CAS#21
M_B_RAS#21
M_B_WE#21

M_B_DQ0
M_B_DQ1
M_B_DQ2
M_B_DQ3
M_B_DQ4
M_B_DQ5
M_B_DQ6
M_B_DQ7
M_B_DQ8
M_B_DQ9
M_B_DQ10
M_B_DQ11
M_B_DQ12
M_B_DQ13
M_B_DQ14
M_B_DQ15
M_B_DQ16
M_B_DQ17
M_B_DQ18
M_B_DQ19
M_B_DQ20
M_B_DQ21
M_B_DQ22
M_B_DQ23
M_B_DQ24
M_B_DQ25
M_B_DQ26
M_B_DQ27
M_B_DQ28
M_B_DQ29
M_B_DQ30
M_B_DQ31
M_B_DQ32
M_B_DQ33
M_B_DQ34
M_B_DQ35
M_B_DQ36
M_B_DQ37
M_B_DQ38
M_B_DQ39
M_B_DQ40
M_B_DQ41
M_B_DQ42
M_B_DQ43
M_B_DQ44
M_B_DQ45
M_B_DQ46
M_B_DQ47
M_B_DQ48
M_B_DQ49
M_B_DQ50
M_B_DQ51
M_B_DQ52
M_B_DQ53
M_B_DQ54
M_B_DQ55
M_B_DQ56
M_B_DQ57
M_B_DQ58
M_B_DQ59
M_B_DQ60
M_B_DQ61
M_B_DQ62
M_B_DQ63

AF3
AG1

AK1
AG4
AG3

AH4
AK3

AK4
AM6
AN2

AK5

AK2
AM4
AM3

AP3
AN5

AT4
AN6
AN4
AN3

AT5

AT6
AN7

AP6

AP8

AT9

AT7

AP9

AR10

AT10

AB1

AC5

AC6

B5

SB_DQ0

A5

SB_DQ1

C3

SB_DQ2

B3

SB_DQ3

E4

SB_DQ4

A6

SB_DQ5

A4

SB_DQ6

C4

SB_DQ7

D1

SB_DQ8

D2

SB_DQ9

F2

SB_DQ10

F1

SB_DQ11

C2

SB_DQ12

F5

SB_DQ13

F3

SB_DQ14

G4

SB_DQ15

H6

SB_DQ16

G2

SB_DQ17

J6

SB_DQ18

J3

SB_DQ19

G1

SB_DQ20

G5

SB_DQ21

J2

SB_DQ22

J1

SB_DQ23

J5

SB_DQ24

K2

SB_DQ25

L3

SB_DQ26

M1

SB_DQ27

K5

SB_DQ28

K4

SB_DQ29

M4

SB_DQ30

N5

SB_DQ31
SB_DQ32
SB_DQ33

AJ3

SB_DQ34
SB_DQ35
SB_DQ36
SB_DQ37

AJ4

SB_DQ38
SB_DQ39
SB_DQ40
SB_DQ41
SB_DQ42
SB_DQ43
SB_DQ44
SB_DQ45
SB_DQ46
SB_DQ47
SB_DQ48
SB_DQ49
SB_DQ50
SB_DQ51
SB_DQ52
SB_DQ53
SB_DQ54
SB_DQ55
SB_DQ56
SB_DQ57
SB_DQ58
SB_DQ59
SB_DQ60
SB_DQ61
SB_DQ62
SB_DQ63

SB_BS0

W5

SB_BS1

R7

SB_BS2

SB_CAS#

Y7

SB_RAS#
SB_WE#

AUBURNDALE

AUBURNDALE

DDR SYSTEM MEMORY - B

DDR SYSTEM MEMORY - B

SB_CK0
SB_CK0#
SB_CKE0

SB_CK1
SB_CK1#
SB_CKE1

SB_CS0#
SB_CS1#

SB_ODT0
SB_ODT1

SB_DM0

SB_DM1

SB_DM2

SB_DM3

SB_DM4

SB_DM5

SB_DM6

SB_DM7

SB_DQS0#
SB_DQS1#
SB_DQS2#
SB_DQS3#
SB_DQS4#
SB_DQS5#
SB_DQS6#
SB_DQS7#

SB_DQS0
SB_DQS1
SB_DQS2
SB_DQS3
SB_DQS4
SB_DQS5
SB_DQS6
SB_DQS7

SB_MA0

SB_MA1

SB_MA2

SB_MA3

SB_MA4

SB_MA5

SB_MA6

SB_MA7

SB_MA8

SB_MA9

SB_MA10
SB_MA11
SB_MA12
SB_MA13
SB_MA14
SB_MA15

W8
W9
M3

V7
V6
M2

AB8
AD6

AC7
AD1

D4
E1
H3
K1
AH1
AL2
AR4
AT8

D5
F4
J4
L4
AH2
AL4
AR5
AR8

C5
E3
H4
M5
AG2
AL5
AP5
AR7

U5
V2
T5
V3
R1
T8
R2
R6
R4
R5
AB5
P3
R3
AF7
P5
N1

M_B_DM0
M_B_DM1
M_B_DM2
M_B_DM3
M_B_DM4
M_B_DM5
M_B_DM6
M_B_DM7

M_B_DQS#0
M_B_DQS#1
M_B_DQS#2
M_B_DQS#3
M_B_DQS#4
M_B_DQS#5
M_B_DQS#6
M_B_DQS#7

M_B_DQS0
M_B_DQS1
M_B_DQS2
M_B_DQS3
M_B_DQS4
M_B_DQS5
M_B_DQS6
M_B_DQS7

M_B_A0
M_B_A1
M_B_A2
M_B_A3
M_B_A4
M_B_A5
M_B_A6
M_B_A7
M_B_A8

M_B_A9
M_B_A10
M_B_A11
M_B_A12
M_B_A13
M_B_A14
M_B_A15

M_CLK_DDR2 21
M_CLK_DDR#2 21
M_CKE2 21

M_CLK_DDR3 21
M_CLK_DDR#3 21
M_CKE3 21

M_CS#2 21
M_CS#3 21

M_ODT2 21
M_ODT3 21

M_B_DM[7..0] 21

M_B_DQS#[7..0] 21

M_B_DQS[7..0] 21

M_B_A[15..0] 21

CATHERINE#2177

CATHERINE#2177

CATHERINE#2177

A A

5

2ND = 62.10055.321

2ND = 62.10055.321

62.10055.321

62.10055.321

4

3

CATHERINE#2177

2ND = 62.10055.321

2ND = 62.10055.321

62.10055.321

62.10055.321

2

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
A3

A3

A3
Date: Sheet of

Date: Sheet of

Date: Sheet of

CPU (3/7)

CPU (3/7)

CPU (3/7)

JV50-CP

JV50-CP

JV50-CP

Taipei Hsien 221, Taiwan, R.O.C.

6 57Thursday, September 03, 2009

6 57Thursday, September 03, 2009

6 57Thursday, September 03, 2009

1

SA

SA

SA

5

4

CPU1F

CPU1F

6 OF 9

6 OF 9

3

2

1

VCC_CORE

PROCESSOR CORE POWER

VCC_CORE

D D

C244

C244

C241

C241

C136

C136

C555

C553

C553

12

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

C548

C548

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

C549

C549

12

SC10U6D3V3MX-GP

C C

B B

A A

SC10U6D3V3MX-GP

C115

C115

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

C247

C247

C125

C125

12

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

C243

C243

C554

C554

12

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

C189

C189

C126

C126

12

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

5

C555

C240

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

C248

C248

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

C246

C246

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

C116

C116

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

C240

12

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

C547

C547

C114

C114

12

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

C135

C135

C245

C245

12

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

C242

C242

C239

C239

12

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

52A

4

AG35

VCC

AG34

VCC

AG33

VCC

AG32

VCC

AG31

VCC

AG30

VCC

AG29

VCC

AG28

VCC

AG27

VCC

AG26

VCC

AF35

VCC

AF34

VCC

AF33

VCC

AF32

VCC

AF31

VCC

AF30

VCC

AF29

VCC

AF28

VCC

AF27

VCC

AF26

VCC

AD35

VCC

AD34

VCC

AD33

VCC

AD32

VCC

AD31

VCC

AD30

VCC

AD29

VCC

AD28

VCC

AD27

VCC

AD26

VCC

AC35

VCC

AC34

VCC

AC33

VCC

AC32

VCC

AC31

VCC

AC30

VCC

AC29

VCC

AC28

VCC

AC27

VCC

AC26

VCC

AA35

VCC

AA34

VCC

AA33

VCC

AA32

VCC

AA31

VCC

AA30

VCC

AA29

VCC

AA28

VCC

AA27

VCC

AA26

VCC

Y35

VCC

Y34

VCC

Y33

VCC

Y32

VCC

Y31

VCC

Y30

VCC

Y29

VCC

Y28

VCC

Y27

VCC

Y26

VCC

V35

VCC

V34

VCC

V33

VCC

V32

VCC

V31

VCC

V30

VCC

V29

VCC

V28

VCC

V27

VCC

V26

VCC

U35

VCC

U34

VCC

U33

VCC

U32

VCC

U31

VCC

U30

VCC

U29

VCC

U28

VCC

U27

VCC

U26

VCC

R35

VCC

R34

VCC

R33

VCC

R32

VCC

R31

VCC

R30

VCC

R29

VCC

R28

VCC

R27

VCC

R26

VCC

P35

VCC

P34

VCC

P33

VCC

P32

VCC

P31

VCC

P30

VCC

P29

VCC

P28

VCC

P27

VCC

P26

VCC

CATHERINE#2177

CATHERINE#2177

62.10055.321

62.10055.321

2ND = 62.10055.321

2ND = 62.10055.321

POWER

POWER

AUBURNDALE

AUBURNDALE

CPU CORE SUPPLY

CPU CORE SUPPLY

SENSE LINES

SENSE LINES

1.1V RAIL POWER

1.1V RAIL POWER

PROC_DPRSLPVR

CPU VIDS

CPU VIDS

VSS_SENSE_VTT

VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0

VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0
VTT0

PSI#

VID0
VID1
VID2
VID3
VID4
VID5
VID6

VTT_SELECT

ISENSE

VCC_SENSE
VSS_SENSE

VTT_SENSE

AH14
AH12
AH11
AH10
J14
J13
H14
H12
G14
G13
G12
G11
F14
F13
F12
F11
E14
E12
D14
D13
D12
D11
C14
C13
C12
C11
B14
B12
A14
A13
A12
A11

AF10
AE10
AC10
AB10
Y10
W10
U10
T10
J12
J11
J16
J15

AN33

H_VID0

AK35

H_VID1

AK33

H_VID2

AK34

H_VID3

AL35

H_VID4

AL33

H_VID5

AM33

H_VID6

AM35
AM34

H_VTTVID1

G15

Clarksfield H_VTTVID1 = Low, VTT = 1.1V
Arrandale H_VTTVID1 = High, VTT = 1.05V

AN35

AJ34
AJ35

B15

TP_VSS_SENSE_VTT

A15

3

C281

C281

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

1

C272

C272

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

C601

C601

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

PSI# 47
H_VID[6..0] 47

PM_DPRSLPVR 47

TP45 Do Not StuffTP45 Do Not Stuff

IMVP_IMON 47

1

TP46 Do Not StuffTP46 Do Not Stuff

12

12

VTT_SENSE 51

C280

C280

+VTT_43
+VTT_44

C287

C287

12

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

C602

C602

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

VCC_CORE

C279

C279

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

RN23

RN23

1
2 3

SRN0J-10-GP-U

SRN0J-10-GP-U

12

R78

R78
100R2F-L1-GP-U

100R2F-L1-GP-U

12

R77

R77
100R2F-L1-GP-U

100R2F-L1-GP-U

2

C278

C278

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

12

1D05V_VTT

4

C282

C282

1D05V_VTT

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

The decoupling capacitors, filter
recommendations and sense resistors on the
CPU/PCH Rails are specific to the CRB
Implementation. Customers need to follow the
recommendations in the Calpella Platform
Design Guide.

1D05V_VTT

Please note that the VTT Rail
Values are Auburndale
VTT=1.05V; Clarksfield
VTT=1.1V

VCC_SENSE 47
VSS_SENSE 47

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom
Date: Sheet of

Date: Sheet of

Date: Sheet of

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

CPU (4/7)

CPU (4/7)

CPU (4/7)

JV50-CP

JV50-CP

JV50-CP

1

SA

SA

7 57Thursday, September 03, 2009

7 57Thursday, September 03, 2009

7 57Thursday, September 03, 2009

SA

5

4

3

2

1

VCC_GFXCORE

D D

C250

C250

C251

C251

C254

C254

C267

C267

Do Not Stuff

Do Not Stuff

UMA_PX

UMA_PX

VCC_GFXCORE

R662

R661

R661
0R3J-0-U-GP

0R3J-0-U-GP

DIS_ONLY

C C

DIS_ONLY

1 2

R662
0R3J-0-U-GP

0R3J-0-U-GP

DIS_ONLY

DIS_ONLY

1 2

R663

R663
0R3J-0-U-GP

0R3J-0-U-GP

DIS_ONLY

DIS_ONLY

1 2

12

12

Do Not Stuff

Do Not Stuff

UMA_PX

UMA_PX

1 2

Do Not Stuff

Do Not Stuff

R664

R664
0R3J-0-U-GP

0R3J-0-U-GP

DIS_ONLY

DIS_ONLY

12

UMA_PX

UMA_PX

12

Do Not Stuff

Do Not Stuff

UMA_PX

UMA_PX

SB 0812

Please note that the VTT Rail
Values are Auburndale
VTT=1.05V; Clarksfield
VTT=1.1V

SA 0626

TC19

B B

TC19

1D05V_VTT

12

Do Not Stuff

Do Not Stuff

DY

DY

1D05V_VTT

18A

12

C237

C237

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

C586

C586

12

12

C253

C253

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

C263

C263

C249

C249

12

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

C232

C232

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

CPU1G

CPU1G

AT21

VAXG1

AT19

VAXG2

AT18

VAXG3

AT16

VAXG4

AR21

VAXG5

AR19

VAXG6

AR18

VAXG7

AR16

VAXG8

AP21

VAXG9

AP19

VAXG10

AP18

VAXG11

AP16

VAXG12

AN21

VAXG13

AN19

VAXG14

AN18

VAXG15

AN16

VAXG16

AM21

VAXG17

AM19

VAXG18

AM18

VAXG19

AM16

VAXG20

AL21

VAXG21

AL19

VAXG22

AL18

VAXG23

AL16

VAXG24

AK21

VAXG25

AK19

VAXG26

AK18

VAXG27

AK16

VAXG28

AJ21

VAXG29

AJ19

VAXG30

AJ18

VAXG31

AJ16

VAXG32

AH21

VAXG33

AH19

VAXG34

AH18

VAXG35

AH16

VAXG36

J24

VTT1

J23

VTT1

H25

VTT1

K26

VTT1

J27

VTT1

J26

VTT1

J25

VTT1

H27

VTT1

G28

VTT1

G27

VTT1

G26

VTT1

F26

VTT1

E26

VTT1

E25

VTT1

CATHERINE#2177

CATHERINE#2177

2ND = 62.10055.321

2ND = 62.10055.321

62.10055.321

62.10055.321

SENSE

SENSE

AUBURNDALE

AUBURNDALE

GRAPHICS

GRAPHICS

GRAPHICS VIDs

GRAPHICS VIDs

FDI PEG & DMI

FDI PEG & DMI

POWER

POWER

VAXG_SENSE

VSSAXG_SENSE

LINES

LINES

GFX_VR_EN

GFX_DPRSLPVR

DDR3 - 1.5V RAILS

DDR3 - 1.5V RAILS

1.1V1.8V

1.1V1.8V

7 OF 9

7 OF 9

GFX_VID0
GFX_VID1
GFX_VID2
GFX_VID3
GFX_VID4
GFX_VID5
GFX_VID6

GFX_IMON

VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ
VDDQ

VTT1
VTT1
VTT1
VTT1

VTT1
VTT1
VTT1
VTT1
VTT1
VTT1

VTT1
VTT1
VTT1

AR22
AT22

AM22
AP22
AN22
AP23
AM23
AP24
AN24

AR25
AT25
AM24

AJ1
AF1
AE7
AE4
AC1
AB7
AB4
Y1
W7
W4
U1
T7
T4
P1
N7
N4
L1
H1

P10
N10
L10
K10

J22
J20
J18
H21
H20
H19

L26
L27
M26

GFX_VID0
GFX_VID1
GFX_VID2
GFX_VID3
GFX_VID4
GFX_VID5
GFX_VID6

1 2

12

R162

R162

1KR2J-1-GP

1KR2J-1-GP

DIS_ONLY

DIS_ONLY

12

C306

C306

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

C276

C276

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

C255

C255

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

C236

C236

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

VCC_AXG_SENSE 54
VSS_AXG_SENSE 54

GFX_VR_EN 54
GFX_DPRSLPVR 54
GFX_IMON 54

12

C314

C314

C296

C296

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

C603

C603

12

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

C593

C593

12

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

+V1.8S_VCCSFR

12

12

C226

C226

C233

C233

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

SC4D7U6D3V3KX-GP

SC4D7U6D3V3KX-GP

SB 0811

12

C316

C316

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

1D05V_VTT

1D05V_VTT

0.6A

C235

C235

12

GFX_VID[6..0] 54

6A

C346

C346

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

C234

C234

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

12

C347

C347

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

12

C344

C344

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

1 2

R132

R132
0R3J-0-U-GP

0R3J-0-U-GP

12

PM_SLP_S3_CTL13,20

NON-S3

NON-S3

C345

C345

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

1D8V_S0

R785

R785

1 2

1D5V_S3

R784

R784

0R3J-0-U-GP

1 2

NON-S3

NON-S3

0R3J-0-U-GP

0R3J-0-U-GP

0R3J-0-U-GP

1 2

NON-S3

NON-S3

S3

S3

S3

S3

G

R783

R783

0R3J-0-U-GP

0R3J-0-U-GP

12

S D

R786

R786

0R3J-0-U-GP

0R3J-0-U-GP

1 2

NON-S3

NON-S3

1D5V_S0_DDR

R858

R858
Do Not Stuff

Do Not Stuff

PM_SLP_S3_CTL_D

Q52

Q52

Do Not Stuff

Do Not Stuff

Do Not Stuff

Do Not Stuff

2nd = 84.27002.N31

2nd = 84.27002.N31

SB 0814

A A

5

4

3

2

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
A3

A3

A3
Date: Sheet of

Date: Sheet of

Date: Sheet of

CPU (5/7)

CPU (5/7)

CPU (5/7)

JV50-CP

JV50-CP

JV50-CP

Taipei Hsien 221, Taiwan, R.O.C.

8 57Thursday, September 03, 2009

8 57Thursday, September 03, 2009

8 57Thursday, September 03, 2009

1

SA

SA

SA

5

CPU1H

CPU1H

AT20

VSS

AT17

VSS

AR31

VSS

AR28

VSS

AR26

VSS

AR24

VSS

D D

C C

B B

AR23
AR20
AR17
AR15
AR12

AR9
AR6

AR3
AP20
AP17
AP13
AP10

AP7

AP4

AP2
AN34
AN31
AN23
AN20
AN17
AM29
AM27
AM25
AM20
AM17
AM14
AM11

AM8

AM5

AM2

AL34
AL31
AL23
AL20
AL17
AL12

AK29
AK27
AK25
AK20
AK17

AJ31
AJ23
AJ20
AJ17
AJ14
AJ11

AH35
AH34
AH33
AH32
AH31
AH30
AH29
AH28
AH27
AH26
AH20
AH17
AH13

AH9

AH6

AH3
AG10

AF8
AF4
AF2

AE35

AL9
AL6
AL3

AJ8
AJ5
AJ2

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

4

VSS

VSS

3

8 OF 9

8 OF 9

AE34

VSS

AE33

VSS

AE32

VSS

AE31

VSS

AE30

VSS

AE29

VSS

AE28

VSS

AE27

VSS

AE26

VSS

AE6

VSS

AD10

AUBURNDALE

AUBURNDALE

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

AC8
AC4
AC2
AB35
AB34
AB33
AB32
AB31
AB30
AB29
AB28
AB27
AB26
AB6
AA10
Y8
Y4
Y2
W35
W34
W33
W32
W31
W30
W29
W28
W27
W26
W6
V10
U8
U4
U2
T35
T34
T33
T32
T31
T30
T29
T28
T27
T26
T6
R10
P8
P4
P2
N35
N34
N33
N32
N31
N30
N29
N28
N27
N26
N6
M10
L35
L32
L29
L8
L5
L2
K34
K33
K30

H35
H32
H28
H26
H24
H22
H18
H15
H13
H11

G34
G31
G20

F30
F27
F25
F22
F19
F16
E35
E32
E29
E24
E21
E18
E13
E11

D33
D30
D26

C34
C32
C29
C28
C24
C22
C20
C19
C16
B31
B25
B21
B18
B17
B13
B11

A29
A27
A23

K27

J32
J30
J21
J19

CPU1I

CPU1I

VSS

K9

VSS

K6

VSS

K3

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

H8

VSS

H5

VSS

H2

VSS
VSS
VSS
VSS

G9

VSS

G6

VSS

G3

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

E8

VSS

E5

VSS

E2

VSS
VSS
VSS
VSS

D9

VSS

D6

VSS

D3

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

B8

VSS

B6

VSS

B4

VSS
VSS
VSS
VSS

A9

VSS

NCTF TEST PIN:

NCTF TEST PIN:

VSS

VSS

A35,AT1,AT35,B1,A3,A33,A34,AP1,AP35,

AR1,AR35,AT2,AT3,AT33,AT34,B35,C1,C35

A35,AT1,AT35,B1,A3,A33,A34,AP1,AP35,

AR1,AR35,AT2,AT3,AT33,AT34,B35,C1,C35

2

AUBURNDALE

AUBURNDALE

RSVD_NCTF#AT33
RSVD_NCTF#AT34
RSVD_NCTF#AP35
RSVD_NCTF#AR35

9 OF 9

9 OF 9

VSS_NCTF#AR34

VSS_NCTF#B34

VSS_NCTF#B2

VSS_NCTF#B1
VSS_NCTF#A35
VSS_NCTF#AT1

VSS_NCTF#AT35

RSVD_NCTF#AT3
RSVD_NCTF#AR1
RSVD_NCTF#AP1
RSVD_NCTF#AT2

RSVD_NCTF#C1
RSVD_NCTF#A3

RSVD_NCTF#C35

RSVD_NCTF#B35

RSVD_NCTF#A34

RSVD_NCTF#A33

AR34
B34
B2

B1
A35
AT1
AT35
AT33
AT34
AP35
AR35
AT3
AR1
AP1
AT2
C1
A3
C35
B35
A34
A33

TP_MCP_VSS_NCTF6
TP_MCP_VSS_NCTF1
TP_MCP_VSS_NCTF2
TP_MCP_VSS_NCTF7

1
1
1
1

1

TP55 Do Not StuffTP55 Do Not Stuff
TP24 Do Not StuffTP24 Do Not Stuff
TP56 Do Not StuffTP56 Do Not Stuff
TP23 Do Not StuffTP23 Do Not Stuff

CATHERINE#2177

CATHERINE#2177

2ND = 62.10055.321

2ND = 62.10055.321

62.10055.321

62.10055.321

A A

5

4

3

CATHERINE#2177

CATHERINE#2177

2ND = 62.10055.321

2ND = 62.10055.321

62.10055.321

62.10055.321

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
A3

A3

A3
Date: Sheet of

Date: Sheet of

2

Date: Sheet of

CPU (6/7)

CPU (6/7)

CPU (6/7)

JV50-CP

JV50-CP

JV50-CP

Taipei Hsien 221, Taiwan, R.O.C.

9 57Wednesday, August 26, 2009

9 57Wednesday, August 26, 2009

9 57Wednesday, August 26, 2009

1

SA

SA

SA

5

CPU1E

AP25

AL25
AL24
AL22
AJ33

AG9
M27

G25
G17

H17

E31
E30

L28
J17

CPU1E

RSVD#AP25
RSVD#AL25
RSVD#AL24
RSVD#AL22
RSVD#AJ33
RSVD#AG9
RSVD#M27
RSVD#L28
SA_DIMM_VREF#
SB_DIMM_VREF#
RSVD#G25
RSVD#G17
RSVD#E31
RSVD#E30

D D

SO-DIMM VREFDQ (M3) Circuit
for Clarksfield Processor

DY

DY

RN28

M_VREF_DQ_DIMM020
M_VREF_DQ_DIMM121

SB 0817

RN28

1
2 3

Do Not Stuff

Do Not Stuff

4

H_RSVD9_R
H_RSVD10_R

4

5 OF 9

5 OF 9

AJ13
AJ12

AH25
AK26

AL26
AR2

AJ26
AJ27

AUBURNDALE

AUBURNDALE

RSVD#AJ13
RSVD#AJ12

RSVD#AH25
RSVD#AK26

RSVD#AL26

RSVD_NCTF#AR2

RSVD#AJ26
RSVD#AJ27

3

CFG0

DY

DY

12

R74

R74
Do Not Stuff

Do Not Stuff

2

1

PCI-Express Configuration Select

CFG0

1:Single PEG
0:Bifurcation enabled

SA 0623

CFG3

12

R76

R76
3KR2F-GP

3KR2F-GP

CFG3 - PCI-Express Static Lane Reversal

CFG3

1 :Normal Operation
0 :Lane Numbers Reversed
15 -> 0, 14 -> 1, ...

RESERVED

RESERVED

RSVD#AL28

RSVD#AL29
RSVD#AP30
RSVD#AP32

RSVD#AL27
RSVD#AT31
RSVD#AT32
RSVD#AP33
RSVD#AR33

RSVD#AR32

RSVD_TP#E15

RSVD_TP#F15

RSVD#AJ15
RSVD#AH15

RSVD_TP#AA5
RSVD_TP#AA4

RSVD_TP#R8
RSVD_TP#AD3
RSVD_TP#AD2
RSVD_TP#AA2
RSVD_TP#AA1

RSVD_TP#R9

RSVD_TP#AG7

RSVD_TP#AE3

RSVD_TP#V4

RSVD_TP#V5

RSVD_TP#N2
RSVD_TP#AD5
RSVD_TP#AD7

RSVD_TP#W3
RSVD_TP#W2

RSVD_TP#N3
RSVD_TP#AE5
RSVD_TP#AD9

CFG0

AM30

CFG1

1

TP38Do Not Stuff TP38Do Not Stuff

RN17

RN17

TP29Do Not Stuff TP29Do Not Stuff

TP32Do Not Stuff TP32Do Not Stuff
TP34Do Not Stuff TP34Do Not Stuff

TP30Do Not Stuff TP30Do Not Stuff
TP33Do Not Stuff TP33Do Not Stuff
TP39Do Not Stuff TP39Do Not Stuff
TP40Do Not Stuff TP40Do Not Stuff
TP31Do Not Stuff TP31Do Not Stuff
TP28Do Not Stuff TP28Do Not Stuff
TP27Do Not Stuff TP27Do Not Stuff
TP36Do Not Stuff TP36Do Not Stuff
TP37Do Not Stuff TP37Do Not Stuff
TP35Do Not Stuff TP35Do Not Stuff

4

C C

1
2 3

SRN0J-10-GP-U

SRN0J-10-GP-U

B B

A A

5

CFG2

1

CFG3
CFG4
CFG5

1

CFG6

1

CFG7
CFG8

1

CFG9

1

CFG10

1

CFG11

1

CFG12

1

CFG13

1

CFG14

1

CFG15

1

CFG16

1

CFG17

1

H_RSVD17_R
H_RSVD18_R

CFG0

AM28

CFG1

AP31

CFG2

AL32

CFG3

AL30

CFG4

AM31

CFG5

AN29

CFG6

AM32

CFG7

AK32

CFG8

AK31

CFG9

AK28

CFG10

AJ28

CFG11

AN30

CFG12

AN32

CFG13

AJ32

CFG14

AJ29

CFG15

AJ30

CFG16

AK30

CFG17

H16

RSVD_TP#H16

B19

RSVD#B19

A19

RSVD#A19

A20

RSVD#A20

B20

RSVD#B20

U9

RSVD#U9

T9

RSVD#T9

AC9

RSVD#AC9

AB9

RSVD#AB9

J29

RSVD#J29

J28

RSVD#J28

CATHERINE#2177

CATHERINE#2177

2ND = 62.10055.321

2ND = 62.10055.321

62.10055.321

62.10055.321

4

KEY
RSVD#D15
RSVD#C15

VSS

AL28
AL29
AP30
AP32
AL27
AT31
AT32
AP33
AR33

AR32

E15
F15
A2
D15
C15
AJ15
AH15

AA5
AA4
R8
AD3
AD2
AA2
AA1
R9
AG7
AE3

V4
V5
N2
AD5
AD7
W3
W2
N3
AE5
AD9

AP34

RN20

SRN0J-10-GP-U

SRN0J-10-GP-U

1 2

RN20

1
2 3

RSVD64_R
RSVD65_R

VSS (AP34) can be left NC is
CRB implementation; EDS/DG
recommendation to GND.

RSVD_VSS

R73

R73
0R2J-2-GP

0R2J-2-GP

CFG4

CFG7

4

3

DY

DY

DY

DY

12

12

R119

R119
Do Not Stuff

Do Not Stuff

R75

R75
Do Not Stuff

Do Not Stuff

2

CFG4 - Display Port Presence

CFG4

CFG7 Clarksfield (only for early samples pre-ES1) -

1:Disabled; No Physical Display Port
attached to Embedded Display Port
0:Enabled; An external Display Port
device is connected to the Embedded
Display Port

CFG7(Reserved) - Temporarily used for early
Clarksfield samples.

Connect to GND with 3.01K Ohm/5% resistor.
Note: Only temporary for early CFD sample

(rPGA/BGA) [For details please refer to the
WW33 MoW and sighting report].
For a common M/B design (for AUB and CFD),
the pull-down resistor shouble be used. Does
not impact AUB functionality.

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
A3

A3

A3
Date: Sheet of

Date: Sheet of

Date: Sheet of

CPU (7/7)

CPU (7/7)

CPU (7/7)

JV50-CP

JV50-CP

JV50-CP

Taipei Hsien 221, Taiwan, R.O.C.

10 57Thursday, September 03, 2009

10 57Thursday, September 03, 2009

10 57Thursday, September 03, 2009

1

SA

SA

SA

5

1 2

ECT3 Do Not Stuff

ECT3 Do Not Stuff

DY

DY

1 2

ECT4 Do Not Stuff

ECT4 Do Not Stuff

DY

DY

1 2

ECT7 Do Not Stuff

ECT7 Do Not Stuff

DY

DY

1 2

ECT8 Do Not Stuff

ECT8 Do Not Stuff

DY

DY

RTC_AUX_S5

ACZ_RST#
ACZ_SYNC

ACZ_BIT_CLK

ACZ_SDATAOUT

ICH_RTCX1

1 2

R212

R212
10MR2J-L-GP

10MR2J-L-GP

X3

X3

1

D D

C357

C357

SC7P50V2DN-2GP

SC7P50V2DN-2GP

ACZ_RST#_AUDIO32
ACZ_SYNC_AUDIO32
ACZ_BITCLK_AUDIO32
ACZ_SDATAOUT_AUDIO32

C C

4

12

XTAL-32D768KHZ-6-GP

XTAL-32D768KHZ-6-GP

82.30001.B21

82.30001.B21

ACZ_RST#_MDC35
ACZ_SYNC_MDC35
ACZ_BTCLK_MDC35
ACZ_SDATAOUT_MDC35

23

ICH_RTCX2

C362

C362

12

ACZ_RST#
ACZ_SYNC
ACZ_BIT_CLK

SC7P50V2DN-2GP

SC7P50V2DN-2GP

ACZ_SDATAOUT

R185 10R2J-2-GPR185 10R2J-2-GP
R192 10R2J-2-GPR192 10R2J-2-GP
R518 10R2J-2-GPR518 10R2J-2-GP
R529 10R2J-2-GPR529 10R2J-2-GP

R181 33R2J-2-GPR181 33R2J-2-GP
R188 33R2J-2-GPR188 33R2J-2-GP

R517 10R2J-2-GPR517 10R2J-2-GP

R523 33R2J-2-GPR523 33R2J-2-GP

12
12
12
12

12
12
12
12

SB 0825

NO REBOOT STRAP

3D3V_S0

1 2

DY

DY

R557 Do Not Stuff

R557 Do Not Stuff

No Reboot Strap R23

HDA_SPKR

SA 0709

B B

PCH_JTAG_TMS

PCH_JTAG_TDO

PCH_JTAG_TDI

PCH_JTAG_RST#

PCH_JTAG_TMS

PCH_JTAG_TDO

A A

PCH_JTAG_TDI

PCH_JTAG_RST#

PCH_JTAG_TCK

R250 Do Not Stuff

R250 Do Not Stuff

R251 Do Not Stuff

R251 Do Not Stuff

R563 51R2F-2-GPR563 51R2F-2-GP

When unused all JTAG pins may be NC

ACZ_SPKR

Low = Default
High = No Reboot

R249

R249

1 2

200R2J-L1-GP

200R2J-L1-GP
R560

R560

1 2

200R2J-L1-GP

200R2J-L1-GP
R561

R561

1 2

200R2J-L1-GP

200R2J-L1-GP

1 2

DY

DY

R248

R248

1 2

100R2J-2-GP

100R2J-2-GP

R559

R559

1 2

100R2J-2-GP

100R2J-2-GP

R562

R562

1 2

100R2J-2-GP

100R2J-2-GP

1 2

DY

DY

1 2

5

3D3V_S5

SPI_CS0#, SPI_MISO, SPI_MOSI, SPI_CLK:
No series resistor required if routing length is 1.5"-6.5"

SPI_MOSI

Enable iTPM: Connect to Vcc3_3 with

8.2-kΩ weak pull-up resistor.
Disable iTPM: Left floating, no

pull-down required

3D3V_S0

1 2

R553 Do Not Stuff

R553 Do Not Stuff

RN29

RN29

2 3
1

SRN20KJ-GP-U

SRN20KJ-GP-U

SA 0629 RF

PCH_SPI_CLK41
PCH_SPI_CS#041

PCH_SPI_MOSI41

SPI_MOSO_R41

DY

DY

4

4

4

C351

C351

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

ME_UNLOCK#40

SPI_MOSI_R

12

ACZ_SDATAIN032
ACZ_SDATAIN135

12

C334

C334

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

21

G25

G25
Do Not Stuff

Do Not Stuff

ACZ_SPKR32

TP52Do Not Stuff TP52Do Not Stuff

R172 0R2J-2-GPR172 0R2J-2-GP

1 2

PCH_SPI_CLK
PCH_SPI_CS#0

PCH_SPI_MOSI

3

RTC_AUX_S5

1 2

R536

R536
1MR2J-1-GP

1MR2J-1-GP

1 2

R545

R545
330KR2F-L-GP

330KR2F-L-GP

SRTCRST# new signal Pin

1

1 2

R179 Do Not Stuff

R179 Do Not Stuff

DY

DY

R555 15R2J-GPR555 15R2J-GP

1 2

R565 15R2J-GPR565 15R2J-GP

1 2

R554 15R2J-GPR554 15R2J-GP

1 2

RTC_AUX_S5 RTC_BAT

1 2

R193 0R3J-0-U-GPR193 0R3J-0-U-GP

12

C337

C337
SC1U10V2ZY-GP

SC1U10V2ZY-GP

SM_INTRUDER#

ICH_INTVRMEN

ICH_RTCX1
ICH_RTCX2

ICH_RTCRST#

SRTCRST#
SM_INTRUDER#
ICH_INTVRMEN

ACZ_BIT_CLK
ACZ_SYNC

ACZ_RST#

HDA_SDIN2

ACZ_SDATAOUT

HDA_DOCK_EN#

PCH_JTAG_TCK
PCH_JTAG_TMS
PCH_JTAG_TDI
PCH_JTAG_TDO
PCH_JTAG_RST#

SPI_CLK_R

SPI_CS#0_R

SPI_MOSI_R

SPI_MOSO_R

RTC_PW R_L

3

INTVRMEN- Integrated SUS

1.1V VRM Enable
High - Enable internal VRs

PCH1A

PCH1A

B13

RTCX1

D13

RTCX2

C14

RTCRST#

D17

SRTCRST#

A16

INTRUDER#

A14

INTVRMEN

A30

HDA_BCLK

D29

HDA_SYNC

P1

SPKR

C30

HDA_RST#

G30

HDA_SDIN0

F30

HDA_SDIN1

E32

HDA_SDIN2

F32

HDA_SDIN3

B29

HDA_SDO

H32

HDA_DOCK_EN#/GPIO33

J30

HDA_DOCK_RST#/GPIO13

M3

JTAG_TCK

K3

JTAG_TMS

K1

JTAG_TDI

J2

JTAG_TDO

J4

TRST#

BA2

SPI_CLK

AV3

SPI_CS0#

AY3

SPI_CS1#

AY1

SPI_MOSI

AV1

SPI_MISO

IBEXPEAK-M-GP-NF

IBEXPEAK-M-GP-NF

3D3V_AUX_S5

D5

D5

2

3

1

BAS40-05W-GP

BAS40-05W-GP

83.00040.M81

83.00040.M81

2nd = 83.00040.M81

2nd = 83.00040.M81

RTC_PW R

RTCIHDA

RTCIHDA

SPI JTAG

SPI JTAG

1 2

R201

R201
1KR2J-1-GP

1KR2J-1-GP

FWH0/LAD0
FWH1/LAD1
FWH2/LAD2
FWH3/LAD3

FWH4/LFRAME#

LDRQ1#/GPIO23

LPC

LPC

SATA0RXN
SATA0RXP
SATA0TXN
SATA0TXP

SATA1RXN
SATA1RXP
SATA1TXN
SATA1TXP

SATA2RXN
SATA2RXP
SATA2TXN
SATA2TXP

SATA3RXN
SATA3RXP
SATA3TXN
SATA3TXP

SATA4RXN
SATA4RXP
SATA4TXN

SATA

SATA

SATA4TXP
SATA5RXN

SATA5RXP
SATA5TXN
SATA5TXP

SATAICOMPO

SATAICOMPI

SATALED#

SATA0GP/GPIO21
SATA1GP/GPIO19

2

1 OF 10

1 OF 10

D33
B33
C32
A32

C34
A34

LDRQ0#

F34
AB9

SERIRQ

AK7
AK6
AK11
AK9

AH6
AH5
AH9
AH8

AF11
AF9
AF7
AF6

AH3
AH1
AF3
AF1

AD9
AD8
AD6
AD5

AD3
AD1
AB3
AB1

AF16
AF15

T3

Y9
V1

RTC1

RTC1

1

PWR

2

GND

NP1

NP1

NP2

NP2

BAT-330DG02PSS0300CE-GP

BAT-330DG02PSS0300CE-GP

62.70001.041

62.70001.041

2

integrated VccSus1_05,VccSus1_5,VccCL1_5

INTVRMEN

High=Enable Low=Disable

integrated VccLan1_05VccCL1_05

LAN100_SLP

PCH_GPIO23
INT_SERIRQ

SATAICOMP

SATA_LED#

SATA_DET#0_R
SATA_DET#1_R

High=Enable Low=Disable

LPC_LAD0 40,41
LPC_LAD1 40,41
LPC_LAD2 40,41
LPC_LAD3 40,41

LPC_LFRAME# 40,41

1

TP53 Do Not StuffTP53 Do Not Stuff

INT_SERIRQ 40

SATA_RXN0 26
SATA_RXP0 26
SATA_TXN0 26
SATA_TXP0 26

SATA_RXN4 27
SATA_RXP4 27
SATA_TXN4 27
SATA_TXP4 27

1D05V_S0

1 2

R205

R205
37D4R2F-GP

37D4R2F-GP

SATA_LED# 44

RN33

RN33

SATA_DET#0_R
SATA_LED#
SATA_DET#1_R
INT_SERIRQ

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
A3

A3

A3
Date: Sheet of

Date: Sheet of

Date: Sheet of

6
7
8

SRN10KJ-7GP

SRN10KJ-7GP

PCH (1/9)

PCH (1/9)

PCH (1/9)

JV50-CP

JV50-CP

JV50-CP

1

HDD

ODD

3D3V_S0

45
3
2
1

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

11 57Thursday, September 03, 2009

11 57Thursday, September 03, 2009

11 57Thursday, September 03, 2009

1

SA

SA

SA

5

LAN

D D

MINICARD1

MINICARD2

C C

CLK_PCIE_MINI1#37
CLK_PCIE_MINI137

MINI1_CLKREQ#37

CLK_PCIE_MINI2#37

CLK_PCIE_MINI237

MIN2_CLKREQ#37

CLK_PCIE_LAN#30
CLK_PCIE_LAN30

B B

A A

LAN_CLKREQ#30

PCIECLKRQ{0,3,4,5,6,7}# should
have a 10K pull-up to +3VALW.

PCIECLKRQ{1,2} should have a
10K pull-up to +1.05VS (But CRB is
pull-up to +3VS).

R219

R219
Do Not Stuff

Do Not Stuff

DY

DY

1 2

PCIE_CLK_RQ3# PEG_B_CLKRQ#

R220

R220
10KR2J-3-GP

10KR2J-3-GP

1 2

PCIE_RXN130
PCIE_RXP130
PCIE_TXN130
PCIE_TXP130

PCIE_RXN237
PCIE_RXP237
PCIE_TXN237
PCIE_TXP237

PCIE_RXN337

PCIE_RXP337
PCIE_TXN337
PCIE_TXP337

SRN0J-10-GP-U

SRN0J-10-GP-U

R227 Do Not Stuff

R227 Do Not Stuff

SRN0J-10-GP-U

SRN0J-10-GP-U

R258 Do Not Stuff

R258 Do Not Stuff

SRN0J-10-GP-U

SRN0J-10-GP-U

R224 Do Not Stuff

R224 Do Not Stuff

3D3V_S03D3V_S5

R235

R235
Do Not Stuff

Do Not Stuff

DY

DY

1 2

PCIE_CLK_RQ1#

12

R242

R242
10KR2J-3-GP

10KR2J-3-GP

5

PCIE_RXN1
PCIE_RXP1

PCIE_RXN2
PCIE_RXP2

C308 SCD1U10V2KX-5GPC308 SCD1U10V2KX-5GP
C309 SCD1U10V2KX-5GPC309 SCD1U10V2KX-5GP

RN26

RN26

1
2 3

1 2

DY

DY

RN24

RN24

1
2 3

1 2

DY

DY

RN19

RN19

1
2 3

1 2

DY

DY

3D3V_S0

R259

R259
Do Not Stuff

Do Not Stuff

DY

DY

1 2

PCIE_CLK_RQ2#

12

R257

R257
10KR2J-3-GP

10KR2J-3-GP

TXN1

C326SCD1U10V2KX-5GP C326SCD1U10V2KX-5GP

12

TXP1

C328SCD1U10V2KX-5GP C328SCD1U10V2KX-5GP

12

TXN2

C315SCD1U10V2KX-5GP C315SCD1U10V2KX-5GP

12

TXP2

C320SCD1U10V2KX-5GP C320SCD1U10V2KX-5GP

12

TXN3

12

TXP3

12

PCIE_CLK_RQ0# PEG_CLKREQ#

CLK_PCH_SRC1_N

4

CLK_PCH_SRC1_P
PCIE_CLK_RQ1#

CLK_PCH_SRC2_N

4

CLK_PCH_SRC2_P
PCIE_CLK_RQ2#

CLK_PCH_SRC0_N

4

CLK_PCH_SRC0_P
PCIE_CLK_RQ3#

PCIE_CLK_RQ4#

PCIE_CLK_RQ5#

PEG_B_CLKRQ#

4

PCH1B

PCH1B

BG30

PERN1

BJ30

PERP1

BF29

PETN1

BH29

PETP1

AW30

PERN2

BA30

PERP2

BC30

PETN2

BD30

PETP2

AU30

PERN3

AT30

PERP3

AU32

PETN3

AV32

PETP3

BA32

PERN4

BB32

PERP4

BD32

PETN4

BE32

PETP4

BF33

PERN5

BH33

PERP5

BG32

PETN5

BJ32

PETP5

BA34

PERN6

AW34

PERP6

BC34

PETN6

BD34

PETP6

AT34

PERN7

AU34

PERP7

AU36

PETN7

AV36

PETP7

BG34

PERN8

BJ34

PERP8

BG36

PETN8

BJ36

PETP8

AK48

CLKOUT_PCIE0N

AK47

CLKOUT_PCIE0P

P9

PCIECLKRQ0#/GPIO73

AM43

CLKOUT_PCIE1N

AM45

CLKOUT_PCIE1P

U4

PCIECLKRQ1#/GPIO18

AM47

CLKOUT_PCIE2N

AM48

CLKOUT_PCIE2P

N4

PCIECLKRQ2#/GPIO20

AH42

CLKOUT_PCIE3N

AH41

CLKOUT_PCIE3P

A8

PCIECLKRQ3#/GPIO25

AM51

CLKOUT_PCIE4N

AM53

CLKOUT_PCIE4P

M9

PCIECLKRQ4#/GPIO26

AJ50

CLKOUT_PCIE5N

AJ52

CLKOUT_PCIE5P

H6

PCIECLKRQ5#/GPIO44

AK53

CLKOUT_PEG_B_N

AK51

CLKOUT_PEG_B_P

P13

PEG_B_CLKRQ#/GPIO56

IBEXPEAK-M-GP-NF

IBEXPEAK-M-GP-NF

4

3D3V_S5

SMBus

SMBus

PCI-E*

PCI-E*

Link

Link

Controller

Controller

PEG_A_CLKRQ#/GPIO47

PEG

PEG

CLKOUT_DP_N/CLKOUT_BCLK1_N
CLKOUT_DP_P/CLKOUT_BCLK1_P

From CLK BUFFER

From CLK BUFFER

CLKIN_SATA_N/CKSSCD_N

CLKIN_SATA_P/CKSSCD_P

Clock Flex

Clock Flex

RN60

RN60

1
2
3
4 5

SRN10KJ-7GP

SRN10KJ-7GP

8
7
6

2 OF 10

2 OF 10

SMBALERT#/GPIO11

SMBCLK

SMBDATA

SML0ALERT#/GPIO60

SML0CLK

SML0DATA

SML1ALERT#/GPIO74

SML1CLK/GPIO58

SML1DATA/GPIO75

CL_CLK1
CL_DATA1
CL_RST1#

CLKOUT_PEG_A_N
CLKOUT_PEG_A_P

CLKOUT_DMI_N
CLKOUT_DMI_P

CLKIN_DMI_N

CLKIN_DMI_P

CLKIN_BCLK_N

CLKIN_BCLK_P

CLKIN_DOT_96N

CLKIN_DOT_96P

REFCLK14IN

CLKIN_PCILOOPBACK

XTAL25_IN

XTAL25_OUT

XCLK_RCOMP

CLKOUTFLEX0/GPIO64

CLKOUTFLEX1/GPIO65

CLKOUTFLEX2/GPIO66

CLKOUTFLEX3/GPIO67

PCIE_CLK_RQ4#
PCIE_CLK_RQ5#

B9
H14
C8

J14
C6
G8

M14
E10
G12

T13
T11
T9

H1

AD43
AD45

AN4
AN2

AT1
AT3

AW24
BA24

AP3
AP1

F18
E18

AH13
AH12

P41

J42

AH51
AH53

AF38

T45

P43

T42

N50

SB 0812

3

PCH_GPIO11

PCH_GPIO60
SML0_CLK
SML0_DATA

PCH_GPIO74
KBC_SCL1
KBC_SDA1

CL_CLK
CL_DATA
CL_RST#

PEG_CLKREQ#PEG_CLKREQ#

CLK_PCH_PEGA_N
CLK_PCH_PEGA_P

CLK_EXP_N
CLK_EXP_P

CLKOUT_DP_N
CLKOUT_DP_P

CLKIN_DMI#
CLKIN_DMI

CLK_CPU_BCLK#
CLK_CPU_BCLK

DREFCLK#
DREFCLK

CLK_PCIE_SATA#
CLK_PCIE_SATA

CLK_ICH14

CLK_PCI_FB

XTAL25_IN
XTAL25_OUT

XCLK_RCOMP

CLK48

3

PCH_GPIO11 16

SMB_CLK 37
SMB_DATA 37

PCH_GPIO60 16

1

TP58 Do Not StuffTP58 Do Not Stuff

1

TP60 Do Not StuffTP60 Do Not Stuff

1

TP62 Do Not StuffTP62 Do Not Stuff

1 2

DY

DY

R556 Do Not Stuff

R556 Do Not Stuff

DIS

DIS

2 3
1

4

4

DY

DY

CLKIN_DMI# 3
CLKIN_DMI 3

CLK_CPU_BCLK# 3
CLK_CPU_BCLK 3

DREFCLK# 3
DREFCLK 3

CLK_PCIE_SATA# 3
CLK_PCIE_SATA 3

CLK_ICH14 3

CLK_PCI_FB 15

1 2

R163 90D9R2F-1-GPR163 90D9R2F-1-GP

1 2

R13933R2J-2-GP R13933R2J-2-GP

DY

DY

RN18

RN18

4

SRN0J-10-GP-U

SRN0J-10-GP-U

1

SRN0J-10-GP-U

SRN0J-10-GP-U

23

RN63

RN63

1

RN64

RN64

23

Do Not Stuff

Do Not Stuff

12

C266

C266

Do Not Stuff

Do Not Stuff

KBC_SCL1 40
KBC_SDA1 40

PEX_CLKREQ 63

CLK48_Cardreader 36

2

PCH_SMBDATA3,20,21

CLK_PCIE_PEG# 62
CLK_PCIE_PEG 62

PEG_CLK#_R 5
PEG_CLK_R 5

DPLL_REF_SSCLK# 5
DPLL_REF_SSCLK 5

PCH_GPIO1216

1D05V_S0

2

1

678

123

SML0_CLK

SML0_DATA KBC_SCL1

3D3V_S5 3D3V_S0

678

RN32

RN32
SRN2K2J-2-GP

SRN2K2J-2-GP

123

SMB_CLK

PCIE_CLK_RQ0#
PCH_GPIO74

PCH_GPIO12

R596

R596
Do Not Stuff

Do Not Stuff

UMA_PX

UMA_PX

1 2

1 2

Do Not Stuff

Do Not Stuff

4 5

84.2N702.A3F

84.2N702.A3F

2N7002KDW-GP

2N7002KDW-GP

1
2
3 4

1
2
3
4 5

SRN10KJ-7GP

SRN10KJ-7GP

Do Not Stuff

Do Not Stuff

Do Not Stuff

Do Not Stuff

2nd = 82.30020.791

2nd = 82.30020.791

XTAL25_OUT_R

UMA_PX

UMA_PX

R381

R381

Q35

Q35

R246

R246

1 2

10KR2J-3-GP

10KR2J-3-GP

RN59

RN59

XTAL25_IN

XTAL25_IN

PCH (2/9)

PCH (2/9)

PCH (2/9)

JV50-CP

JV50-CP

JV50-CP

SMB_CLK
SMB_DATA

XTAL25_OUT

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
A3

A3

A3
Date: Sheet of

Date: Sheet of

Date: Sheet of

3D3V_S0

SMB_DATA

6
5

3D3V_S5

8
7
6

1 2

R488 0R2J-2-GP

R488 0R2J-2-GP

DIS_ONLY

DIS_ONLY

X5

X5

12

UMA_PX

UMA_PX

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

1

3D3V_S5

RN58

RN58
SRN2K2J-2-GP

SRN2K2J-2-GP

4 5

KBC_SDA1

PCH_SMBCLK 3,20,21

C598

C598
Do Not Stuff

Do Not Stuff

UMA_PX

UMA_PX

C594

C594
Do Not Stuff

Do Not Stuff

UMA_PX

UMA_PX

12 57Thursday, September 03, 2009

12 57Thursday, September 03, 2009

12 57Thursday, September 03, 2009

12

12

SB 0812

SA

SA

SA

5

D D

1D05V_S0

1 2

R520 49D9R2F-GPR520 49D9R2F-GP

C C

B B

RSMRST#_KBC40

A A

PM_PWROK45
CORE_PW RGD45,47

3

BAT54-5-GP

BAT54-5-GP

5

R208 Do Not Stuff

R208 Do Not Stuff

1 2
1 2

R213 0R2J-2-GPR213 0R2J-2-GP

1 2

R210 10KR2J-3-GPR210 10KR2J-3-GP

ALL_PW RGD45,47,49,50,51,52

PM_DRAM_PWRGD5

SUS_PW R_DN_ACK40

PM_PWRBTN#40,59

AC_PRESENT40

3D3V_S5

D22

D22

1

2

83.BAT54.D81

83.BAT54.D81

2ND = 83.BAT54.D81

2ND = 83.BAT54.D81

DY

DY

12

R534

R534
10KR2J-3-GP

10KR2J-3-GP

12

R535

R535

100KR2J-1-GP

100KR2J-1-GP

ALL_PW RGD

PM_DRAM_PWRGD

1 2

R566 0R2J-2-GPR566 0R2J-2-GP

1 2

R568 0R2J-2-GPR568 0R2J-2-GP

1 2

R567 0R2J-2-GPR567 0R2J-2-GP

PM_RSMRST#

4

DMI_RXN04
DMI_RXN14
DMI_RXN24
DMI_RXN34

DMI_RXP04
DMI_RXP14
DMI_RXP24
DMI_RXP34

DMI_TXN04
DMI_TXN14
DMI_TXN24
DMI_TXN34

DMI_TXP04
DMI_TXP14
DMI_TXP24
DMI_TXP34

DMI_IRCOMP_R

PM_PWROK_1

1 2

R211 0R2J-2-GPR211 0R2J-2-GP

1 2

DY

DY

R215 Do Not Stuff

R215 Do Not Stuff

1 2

R550 10KR2J-3-GPR550 10KR2J-3-GP

SUS_PW R_DN_ACK_R

4

3D3V_S0

12

R222

R222
10KR2J-3-GP

10KR2J-3-GP

PM_SYSRST#_R

LAN_RST#1

PM_RSMRST#

PM_PWRBTN#_R

AC_PRESENT_R

PCH_GPIO72

PM_RI#

PM_CLKRUN#

ME_PWROK

PCH1C

PCH1C

BC24

DMI0RXN

BJ22

DMI1RXN

AW20

DMI2RXN

BJ20

DMI3RXN

BD24

DMI0RXP

BG22

DMI1RXP

BA20

DMI2RXP

BG20

DMI3RXP

BE22

DMI0TXN

BF21

DMI1TXN

BD20

DMI2TXN

BE18

DMI3TXN

BD22

DMI0TXP

BH21

DMI1TXP

BC20

DMI2TXP

BD18

DMI3TXP

BH25

DMI_ZCOMP

BF25

DMI_IRCOMP

T6

SYS_RESET#

M6

SYS_PWROK

B17

PWROK

K5

MEPWROK

A10

LAN_RST#

D9

DRAMPWROK

C16

RSMRST#

M1

SUS_PWR_DN_ACK/GPIO30

P5

PWRBTN#

P7

ACPRESENT/GPIO31

A6

BATLOW#/GPIO72

F14

RI#

IBEXPEAK-M-GP-NF

IBEXPEAK-M-GP-NF

1 2

R558

R558
8K2R2J-3-GP

8K2R2J-3-GP

3

DMI

DMI

System Power Management

System Power Management

3

3 OF 10

3 OF 10

FDI_RXN0
FDI_RXN1
FDI_RXN2
FDI_RXN3
FDI_RXN4
FDI_RXN5
FDI_RXN6
FDI_RXN7

FDI_RXP0
FDI_RXP1
FDI_RXP2
FDI_RXP3
FDI_RXP4
FDI_RXP5
FDI_RXP6
FDI_RXP7

FDI_INT

FDI_FSYNC0

FDI

FDI

FDI_FSYNC1
FDI_LSYNC0
FDI_LSYNC1

WAKE#

CLKRUN#/GPIO32

SUS_STAT#/GPIO61

SUSCLK/GPIO62

SLP_S5#/GPIO63

SLP_S4#

SLP_S3#

SLP_M#

TP23

PMSYNCH

SLP_LAN#/GPIO29

PM_RI#
SUS_PW R_DN_ACK_R
AC_PRESENT_R
PM_PWRBTN#_R

PCH_GPIO72

PCIE_WAKE#

BA18
BH17
BD16
BJ16
BA16
BE14
BA14
BC12

BB18
BF17
BC16
BG16
AW16
BD14
BB14
BD12

BJ14
BF13
BH13
BJ12
BG14

J12

Y1

P8

F3

E4

H7

P12

K8

N2

BJ10

F6

PCIE_WAKE#

PM_CLKRUN#

PM_SUS_STAT#

PM_SUS_CLK

PM_SLP_S5#

PM_SLP_S4#_R

PM_SLP_S3#_R

PM_SLP_M#_R

PM_SLP_DSW#

H_PM_SYNC

PM_SLP_LAN#

1
2
3
4 5

SRN10KJ-7GP

SRN10KJ-7GP

1 2

R552 8K2R2J-3-GPR552 8K2R2J-3-GP

1 2

R247 1KR2J-1-GPR247 1KR2J-1-GP

RN35

RN35

1

1

1

1

1

8
7
6

2

FDI_TXN0 4
FDI_TXN1 4
FDI_TXN2 4
FDI_TXN3 4
FDI_TXN4 4
FDI_TXN5 4
FDI_TXN6 4
FDI_TXN7 4

FDI_TXP0 4
FDI_TXP1 4
FDI_TXP2 4
FDI_TXP3 4
FDI_TXP4 4
FDI_TXP5 4
FDI_TXP6 4
FDI_TXP7 4

FDI_INT 4
FDI_FSYNC0 4
FDI_FSYNC1 4
FDI_LSYNC0 4
FDI_LSYNC1 4

PCIE_WAKE# 30,37

PM_CLKRUN# 40

TP63 Do Not StuffTP63 Do Not Stuff

TP69 Do Not StuffTP69 Do Not Stuff

TP68 Do Not StuffTP68 Do Not Stuff

1 2

R241 0R2J-2-GPR241 0R2J-2-GP

1 2

R207 0R2J-2-GPR207 0R2J-2-GP

1 2

R551 0R2J-2-GPR551 0R2J-2-GP

TP70 Do Not StuffTP70 Do Not Stuff

TP66 Do Not StuffTP66 Do Not Stuff

3D3V_S5

3D3V_S53D3V_S0

SB 0814

2

1

PM_SLP_S4# 40,50,52

PM_SLP_S3# 40,45,50,51,52,54

PM_SLP_M# 40

H_PM_SYNC 5

3D3V_S5

12

R787

R787

S3

S3

Do Not Stuff

Do Not Stuff

PM_SLP_S3_CTL 8,20

S3

S3

Q53

Q53

Do Not Stuff

PM_SLP_S3#

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
A3

A3

A3
Date: Sheet of

Date: Sheet of

Date: Sheet of

PCH (3/9)

PCH (3/9)

PCH (3/9)

JV50-CP

JV50-CP

JV50-CP

Do Not Stuff

G

Do Not Stuff

Do Not Stuff

2nd = 84.27002.N31

2nd = 84.27002.N31

S D

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

13 57Thursday, September 03, 2009

13 57Thursday, September 03, 2009

13 57Thursday, September 03, 2009

1

SA

SA

SA

5

D D

C C

3D3V_S0

1
2 3

Do Not Stuff

Do Not Stuff

Do Not Stuff

Do Not Stuff

8
7
6

Do Not Stuff

Do Not Stuff

UMA_PX

UMA_PX

RN25

RN25

UMA_PX

UMA_PX

R165

R165

12

UMA_PX

UMA_PX

R160

R160

1 2

Do Not Stuff

Do Not Stuff

UMA_PX

UMA_PX

RN50

RN50

1
2
3
45

LCTL_CLK CLK_DDC_EDID

4

LCTL_DATA

LIBG

LVDS_VREF

PCH_BLUE

PCH_GREEN

PCH_RED

SB 0811

B B

4

PCH_BL_ON22

PCH_LCDVDD_ON23

CLK_DDC_EDID22
DAT_DDC_EDID22

PCH_TXACLK-22
PCH_TXACLK+22

PCH_TXAOUT0-22
PCH_TXAOUT1-22
PCH_TXAOUT2-22

PCH_TXAOUT0+22
PCH_TXAOUT1+22
PCH_TXAOUT2+22

PCH_BLUE22
PCH_GREEN22
PCH_RED22

PCH_DDCCLK24
PCH_DDCDATA24

PCH_HSYNC24
PCH_VSYNC24

L_BKLTCTL23

TP50Do Not Stuff TP50Do Not Stuff

1 2

R149

R149
1KR2D-1-GP

1KR2D-1-GP

1K 0.5% ohm

DAT_DDC_EDID

LCTL_CLK
LCTL_DATA

LIBG
L_LVBG

1

LVDS_VREF

CRT_IREF

PCH1D

PCH1D

T48

L_BKLTEN

T47

L_VDD_EN

Y48

L_BKLTCTL

AB48

L_DDC_CLK

Y45

L_DDC_DATA

AB46

L_CTRL_CLK

V48

L_CTRL_DATA

AP39

LVD_IBG

AP41

LVD_VBG

AT43

LVD_VREFH

AT42

LVD_VREFL

AV53

LVDSA_CLK#

AV51

LVDSA_CLK

BB47

LVDSA_DATA#0

BA52

LVDSA_DATA#1

AY48

LVDSA_DATA#2

AV47

LVDSA_DATA#3

BB48

LVDSA_DATA0

BA50

LVDSA_DATA1

AY49

LVDSA_DATA2

AV48

LVDSA_DATA3

AP48

LVDSB_CLK#

AP47

LVDSB_CLK

AY53

LVDSB_DATA#0

AT49

LVDSB_DATA#1

AU52

LVDSB_DATA#2

AT53

LVDSB_DATA#3

AY51

LVDSB_DATA0

AT48

LVDSB_DATA1

AU50

LVDSB_DATA2

AT51

LVDSB_DATA3

AA52

CRT_BLUE

AB53

CRT_GREEN

AD53

CRT_RED

V51

CRT_DDC_CLK

V53

CRT_DDC_DATA

Y53

CRT_HSYNC

Y51

CRT_VSYNC

AD48

DAC_IREF

AB51

CRT_IRTN

IBEXPEAK-M-GP-NF

IBEXPEAK-M-GP-NF

3

4 OF 10

4 OF 10

DDPB_0N
DDPB_0P
DDPB_1N
DDPB_1P
DDPB_2N
DDPB_2P
DDPB_3N
DDPB_3P

DDPC_0N
DDPC_0P
DDPC_1N
DDPC_1P
DDPC_2N
DDPC_2P
DDPC_3N
DDPC_3P

DDPD_0N
DDPD_0P
DDPD_1N
DDPD_1P
DDPD_2N
DDPD_2P
DDPD_3N
DDPD_3P

BJ46
BG46

BJ48
BG48

BF45
BH45

T51
T53

BG44
BJ44
AU38

PCH_HDMI_DATA2-_L

BD42

PCH_HDMI_DATA2+_L

BC42

PCH_HDMI_DATA1-_L

BJ42

PCH_HDMI_DATA1+_L

BG42

PCH_HDMI_DATA0-_L

BB40

PCH_HDMI_DATA0+_L

BA40

PCH_HDMI_CLK-_L

AW38

PCH_HDMI_CLK+_L

BA38

Y49
AB49

BE44
BD44
AV40

BE40
BD40
BF41
BH41
BD38
BC38
BB36
BA36

U50
U52

BC46
BD46
AT38

BJ40
BG40
BJ38
BG38
BF37
BH37
BE36
BD36

SDVO_TVCLKINN
SDVO_TVCLKINP

SDVO_STALLN
SDVO_STALLP

SDVO_INTN
SDVO_INTP

SDVO_CTRLCLK

SDVO_CTRLDATA

DDPB_AUXN
DDPB_AUXP

DDPB_HPD

LVDS

LVDS

DDPC_CTRLCLK

DDPC_CTRLDATA

DDPC_AUXN
DDPC_AUXP

DDPC_HPD

Digital Display Interface

Digital Display Interface

DDPD_CTRLCLK

DDPD_CTRLDATA

DDPD_AUXN
DDPD_AUXP

DDPD_HPD

CRT

CRT

2

PCH_HDMI_CLK 25
PCH_HDMI_DATA 25

PCH_HDMI_DETECT 25

1 2

C277 Do Not Stuff

C277 Do Not Stuff

1 2

UMA_PX

UMA_PX

C273 Do Not Stuff

C273 Do Not Stuff

1 2

UMA_PX

UMA_PX

C285 Do Not Stuff

C285 Do Not Stuff

1 2

UMA_PX

UMA_PX

C283 Do Not Stuff

C283 Do Not Stuff

1 2

UMA_PX

UMA_PX

C294 Do Not Stuff

C294 Do Not Stuff

1 2

UMA_PX

UMA_PX

C291 Do Not Stuff

C291 Do Not Stuff

1 2

UMA_PX

UMA_PX

C297 Do Not Stuff

C297 Do Not Stuff

1 2

UMA_PX

UMA_PX

C303 Do Not Stuff

C303 Do Not Stuff

UMA_PX

UMA_PX

SB 0811

PCH_HDMI_DATA2- 25
PCH_HDMI_DATA2+ 25
PCH_HDMI_DATA1- 25
PCH_HDMI_DATA1+ 25
PCH_HDMI_DATA0- 25
PCH_HDMI_DATA0+ 25
PCH_HDMI_CLK- 25
PCH_HDMI_CLK+ 25

1

A A

5

4

3

2

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
A3

A3

A3
Date: Sheet of

Date: Sheet of

Date: Sheet of

PCH (4/9)

PCH (4/9)

PCH (4/9)

JV50-CP

JV50-CP

JV50-CP

Taipei Hsien 221, Taiwan, R.O.C.

14 57Thursday, September 03, 2009

14 57Thursday, September 03, 2009

14 57Thursday, September 03, 2009

1

SA

SA

SA

5

4

3

2

1

15 57Thursday, September 03, 2009

15 57Thursday, September 03, 2009

15 57Thursday, September 03, 2009

+V_NVRAM_VCCQ

12

R236

R236
Do Not Stuff

Do Not Stuff

DY

DY

+V_NVRAM_VCCQ

12

R237

R237
Do Not Stuff

Do Not Stuff

DY

DY

SA

SA

SA

5 OF 10

PCH1E

PCH1E

H40

RN21

PCI_PLOCK#

PCI_DEVSEL#

PCI_IRDY#
INT_PIRQG#

3D3V_S0

D D

3D3V_S0

1 2

R141 8K2R2J-3-GPR141 8K2R2J-3-GP

1 2

R137 8K2R2J-3-GPR137 8K2R2J-3-GP

1 2

R138 8K2R2J-3-GPR138 8K2R2J-3-GP

3D3V_S0

1 2

R140 8K2R2J-3-GPR140 8K2R2J-3-GP

1 2

R147 8K2R2J-3-GPR147 8K2R2J-3-GP

1 2

R143 8K2R2J-3-GPR143 8K2R2J-3-GP

1 2

R145 8K2R2J-3-GPR145 8K2R2J-3-GP

3D3V_S0

C C

PCI_GNT0#
PCI_GNT1#

RN27

RN27

1
2
3
4 5

SRN8K2J-4-GP

SRN8K2J-4-GP

1 2

R157 Do Not Stuff

R157 Do Not Stuff

1 2

R156 Do Not Stuff

R156 Do Not Stuff

1
2
3
4
5 6

8
7
6

DY

DY
DY

DY

RN21

SRN8K2J-2-GP-U

SRN8K2J-2-GP-U

PCI_REQ1#
INT_PIRQB#
PCI_REQ3#

INT_PIRQH#
PCI_PERR#
PCI_REQ0#
INT_PIRQF#

INT_PIRQC#
INT_PIRQE#
INT_PIRQA#
PCI_SERR#

10
9
8
7

3D3V_S0

PCI_TRDY#
PCI_FRAME#
INT_PIRQD#
PCI_STOP#

USE SPI

These pins are left as NC,
because the function is disable.

3D3V_S0

INT_PIRQA#

DY

DY

R495

R495
Do Not Stuff

Do Not Stuff

1 2

dGPU_SELECT#22,23,24

dGPU_PW M_SELECT#23

dGPU_SELECT#

INT_PIRQB#
INT_PIRQC#
INT_PIRQD#

PCI_REQ0#
PCI_REQ1#

PCI_REQ3#
PCI_GNT0#

PCI_GNT1#

dGPU_PW M_SELECT#

PCI_GNT3#
INT_PIRQE#

INT_PIRQF#
INT_PIRQG#
INT_PIRQH#

BOOT BIOS Strap

1

CLK_PCI_SIO_R
CLK_PCI_FB_R
CLK_PCI_KBC_R
CLK_PCI_3
CLK_PCI_4

12

R253

R253
Do Not Stuff

Do Not Stuff

DY

DY

PCI_SERR#
PCI_PERR#

PCI_IRDY#
PCI_DEVSEL#

PCI_FRAME#
PCI_PLOCK#
PCI_STOP#

PCI_TRDY#
ICH_PME#
PCI_PLTRST#

PCI_GNT#1 BOOT BIOS LocationPCI_GNT#0

0 0 LPC(Default)

01 Reserved

B B

A A

0 1

11

PCI_PLTRST#

5

PCI
SPI

1 2
1 2
1 2

3D3V_S5

PLT_RST#

TP64Do Not Stuff TP64Do Not Stuff

1
1

C369

C369

12

Do Not Stuff

Do Not Stuff

DY

DY

4

SB 0810

PCLK_FW H41
CLK_PCI_FB12
CLK_PCI_KBC40

1
2
3

Do Not Stuff

Do Not Stuff

1 2

R252 0R2J-2-GPR252 0R2J-2-GP

R492 22R2J-2-GPR492 22R2J-2-GP
R493 22R2J-2-GPR493 22R2J-2-GP
R159 47R2J-2-GPR159 47R2J-2-GP

TP47Do Not Stuff TP47Do Not Stuff
TP48Do Not Stuff TP48Do Not Stuff

U17

U17

B
A
GND

5

VCC

4

Y

DY

DY

AD0

N34

AD1

C44

AD2

A38

AD3

C36

AD4

J34

AD5

A40

AD6

D45

AD7

E36

AD8

H48

AD9

E40

AD10

C40

AD11

M48

AD12

M45

AD13

F53

AD14

M40

AD15

M43

AD16

J36

AD17

K48

AD18

F40

AD19

C42

AD20

K46

AD21

M51

AD22

J52

AD23

K51

AD24

L34

AD25

F42

AD26

J40

AD27

G46

AD28

F44

AD29

M47

AD30

H36

AD31

J50

C/BE0#

G42

C/BE1#

H47

C/BE2#

G34

C/BE3#

G38

PIRQA#

H51

PIRQB#

B37

PIRQC#

A44

PIRQD#

F51

REQ0#

A46

REQ1#/GPIO50

B45

REQ2#/GPIO52

M53

REQ3#/GPIO54

F48

GNT0#

K45

GNT1#/GPIO51

F36

GNT2#/GPIO53

H53

GNT3#/GPIO55

B41

PIRQE#/GPIO2

K53

PIRQF#/GPIO3

A36

PIRQG#/GPIO4

A48

PIRQH#/GPIO5

K6

PCIRST#

E44

SERR#

E50

PERR#

A42

IRDY#

H44

PAR

F46

DEVSEL#

C46

FRAME#

D49

PLOCK#

D41

STOP#

C48

TRDY#

M7

PME#

D5

PLTRST#

N52

CLKOUT_PCI0

P53

CLKOUT_PCI1

P46

CLKOUT_PCI2

P51

CLKOUT_PCI3

P48

CLKOUT_PCI4

IBEXPEAK-M-GP-NF

IBEXPEAK-M-GP-NF

PLT_RST# 5,30,36,37,40,41,59,62

PCI

PCI

5 OF 10

AY9

NV_CE#0

BD1

NV_CE#1

AP15

NV_CE#2

BD8

NV_CE#3

AV9

NV_DQS0

BG8

NV_DQS1

NV_DQ0/NV_IO0
NV_DQ1/NV_IO1
NV_DQ2/NV_IO2
NV_DQ3/NV_IO3
NV_DQ4/NV_IO4
NV_DQ5/NV_IO5
NV_DQ6/NV_IO6
NV_DQ7/NV_IO7
NV_DQ8/NV_IO8

NV_DQ9/NV_IO9
NV_DQ10/NV_IO10
NV_DQ11/NV_IO11

NVRAM

NVRAM

NV_DQ12/NV_IO12
NV_DQ13/NV_IO13
NV_DQ14/NV_IO14
NV_DQ15/NV_IO15

NV_RCOMP

NV_WR#0_RE#
NV_WR#1_RE#

NV_WE#_CK0
NV_WE#_CK1

USB

USB

USBRBIAS#

OC0#/GPIO59
OC1#/GPIO40
OC2#/GPIO41
OC3#/GPIO42
OC4#/GPIO43

OC5#/GPIO9
OC6#/GPIO10
OC7#/GPIO14

PCI_GNT3#

A16 swap override Strap/Top-Block
Swap Override jumper

PCI_GNT#3 Low = A16 swap

3

AP7
AP6
AT6
AT9
BB1
AV6
BB3
BA4
BE4
BB6
BD6
BB7
BC8
BJ8
BJ6
BG6

BD3

NV_ALE

AY6

NV_CLE

AU2
AV7

NV_RB#

AY8
AY5

AV11
BF5

H18

USBP0N

J18

USBP0P

A18

USBP1N

C18

USBP1P

N20

USBP2N

P20

USBP2P

J20

USBP3N

L20

USBP3P

F20

USBP4N

G20

USBP4P

A20

USBP5N

C20

USBP5P

M22

USBP6N

N22

USBP6P

B21

USBP7N

D21

USBP7P

H22

USBP8N

J22

USBP8P

E22

USBP9N

F22

USBP9P

A22

USBP10N

C22

USBP10P

G24

USBP11N

H24

USBP11P

L24

USBP12N

M24

USBP12P

A24

USBP13N

C24

USBP13P

B25
D25

USBRBIAS

N16
J16
F16
L16
E14
G16
F12
T15

1 2

DY

DY

R491 Do Not Stuff

R491 Do Not Stuff

override/Top-Block
Swap Override enabled
High = Default

NV_ALE
NV_CLE

NV_RCOMP

USB_RBIAS_PN

USB_OC#3

These pins are left as NC,
because the function is disable.

1 2

R564

R564
Do Not Stuff

Do Not Stuff

DY

DY

USBPN0 29
USBPP0 29
USBPN1 29
USBPP1 29
USBPN2 29
USBPP2 29
USBPN3 37
USBPP3 37

USBPN4 23
USBPP4 23
USBPN5 23
USBPP5 23

USBPN9 29
USBPP9 29
USBPN10 43
USBPP10 43
USBPN11 28
USBPP11 28
USBPN12 37
USBPP12 37
USBPN13 36
USBPP13 36

1 2

R186

R186
22D6R2F-L1-GP

22D6R2F-L1-GP

USB_OC#0 29
USB_OC#1 29

USB_OC#4 29

2

DMI Termination Voltage

NV_CLE Set to Vss when low.

Set to Vcc when high.

Danbury Technology:
Disabled when Low.
Enable when High.

NV_CLE

NV_ALE

USB

Pair

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
A3

A3

A3
Date: Sheet of

Date: Sheet of

Date: Sheet of

Device

0

USB3
USB2

1

USB4

2
3

MINICARD1

4 WECAM

Touch Panel

5

NC

6
7

NC

89NC

USB1(HS)

10

Finger Print

11

Blue Tooth

1213MINIC2

Cardreader

USB_OC#4
USB_OC#3
USB_OC#1
USB_OC#0

8
7
6

PCH (5/9)

PCH (5/9)

PCH (5/9)

JV50-CP

JV50-CP

JV50-CP

3D3V_S5

RN30

RN30

1
2
3
45

SRN10KJ-6-GP

SRN10KJ-6-GP

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

1

PSW_CLR#

21

G77

G77

3D3V_S0

5

PCH_GPIO28
PCH_GPIO60
EC_SWI#
PCH_GPIO11

PCH_GPIO45

PCH_GPIO15

1 2

R261 1KR2J-1-GPR261 1KR2J-1-GP

RP1

RP1

1
2
3
4
5 6

SRN10KJ-L3-GP

SRN10KJ-L3-GP

RN31

RN31

6
7
8

SRN10KJ-7GP

SRN10KJ-7GP

1 2

R370 8K2R2J-3-GPR370 8K2R2J-3-GP

RN36

RN36

6
7
8

SRN10KJ-7GP

SRN10KJ-7GP

45
3
2
1

10
9
8
7

45
3
2
1

3D3V_S0

EC_SCI#40
EC_SWI#40

PCH_GPIO1212

DGPU_HOLD_RST#62

DGPU_PW ROK55,61,62

3D3V_S5

DGPU_PW R_EN#61

dGPU_EDID22,24

SB 0814

SB 0722

3D3V_S0

STP_PCI#

GPIO8 has a weak[20K] internal pull up.
No need to have external pull down/up.
GPIO8 pin set to high at reset.

GPIO15 has a weak[20K] internal pull down.
No need to have external pull up/down.
GPIO 15 pin is set to low at reset.
Low : ME Crypto TLS with no confidentiality
High : ME Crypto TLS with confidentiality

D D

C C

B B

GPIO27 has a weak[20K] internal pull up.
To enable on-die PLL Voltage regurator,
should not place external pull down.

PCH_GPIO6012
PCH_GPIO1112

SB 0819

Do Not Stuff

Do Not Stuff

PCH_GPIO39
PCH_GPIO48
PSW_CLR#

PCH_GPIO0
EC_SMI# PCH_GPIO22
dGPU_EDID
EC_SCI# PX_HDMI#

4

PCH1F

PCH1F

PCH_GPIO0
EC_SMI#
PX_HDMI#

TP51Do Not Stuff TP51Do Not Stuff

TP61Do Not Stuff TP61Do Not Stuff
TP59Do Not Stuff TP59Do Not Stuff

1

EC_SCI#
EC_SWI#
PCH_GPIO12
PCH_GPIO15
DGPU_HOLD_RST#
DGPU_PW ROK
PCH_GPIO22
PCH_GPIO24

1

PCH_GPIO27

1

PCH_GPIO28
STP_PCI#
PCH_GPIO35
DGPU_PW R_EN#
dGPU_PRSNT#
dGPU_EDID
PCH_GPIO39
PCH_GPIO45
RST_GATE
PCH_GPIO48
PSW_CLR#
PCH_GPIO57

1
1

1

1

PCH_TP95
PCH_TP96

PCH_TP97

PCH_TP98

TP95Do Not Stuff TP95Do Not Stuff
TP96Do Not Stuff TP96Do Not Stuff

TP97Do Not Stuff TP97Do Not Stuff

TP98Do Not Stuff TP98Do Not Stuff

Y3

BMBUSY#/GPIO0

C38

TACH1/GPIO1

D37

TACH2/GPIO6

J32

TACH3/GPIO7

F10

GPIO8

K9

LAN_PHY_PWR_CTRL/GPIO12

T7

GPIO15

AA2

SATA4GP/GPIO16

F38

TACH0/GPIO17

Y7

SCLOCK/GPIO22

H10

GPIO24

AB12

GPIO27

V13

GPIO28

M11

STP_PCI#/GPIO34

V6

SATACLKREQ#/GPIO35

AB7

SATA2GP/GPIO36

AB13

SATA3GP/GPIO37

V3

SLOAD/GPIO38

P3

SDATAOUT0/GPIO39

H3

PCIECLKRQ6#/GPIO45

F1

PCIECLKRQ7#/GPIO46

AB6

SDATAOUT1/GPIO48

AA4

SATA5GP/GPIO49

F8

GPIO57

B4

VSS_NCTF_8

B52

VSS_NCTF_9

BH2

VSS_NCTF_16

BH52

VSS_NCTF_17

D2

VSS_NCTF_28

A4

VSS_NCTF#A4

A49

VSS_NCTF#A49

A5

VSS_NCTF#A5

A50

VSS_NCTF#A50

A52

VSS_NCTF#A52

A53

VSS_NCTF#A53

B2

VSS_NCTF#B2

B53

VSS_NCTF#B53

BE1

VSS_NCTF#BE1

BE53

VSS_NCTF#BE53

BF1

VSS_NCTF#BF1

BF53

VSS_NCTF#BF53

BH1

VSS_NCTF#BH1

BH53

VSS_NCTF#BH53

BJ1

VSS_NCTF#BJ1

BJ2

VSS_NCTF#BJ2

BJ4

VSS_NCTF#BJ4

BJ49

VSS_NCTF#BJ49

BJ5

VSS_NCTF#BJ5

BJ50

VSS_NCTF#BJ50

BJ52

VSS_NCTF#BJ52

BJ53

VSS_NCTF#BJ53

D1

VSS_NCTF#D1

D53

VSS_NCTF#D53

E1

VSS_NCTF#E1

E53

VSS_NCTF#E53

IBEXPEAK-M-GP-NF

IBEXPEAK-M-GP-NF

NCTF TEST PIN:

NCTF TEST PIN:

3

MISC

MISC

CLKOUT_BCLK0_N/CLKOUT_PCIE8N

CLKOUT_BCLK0_P/CLKOUT_PCIE8P

GPIO

GPIO

CPU

CPU

NCTF

NCTF

RSVD

RSVD

A4,A49,A5,A50,A52,A53,B2,B53,BE1,

BE53,BF1,BF53,BH1,BH53,BJ1,BJ2,BJ4,

BJ49,BJ5,BJ50,BJ52,BJ53,D1,D53,E1,E53

A4,A49,A5,A50,A52,A53,B2,B53,BE1,

BE53,BF1,BF53,BH1,BH53,BJ1,BJ2,BJ4,

BJ49,BJ5,BJ50,BJ52,BJ53,D1,D53,E1,E53

6 OF 10

6 OF 10

CLKOUT_PCIE6N
CLKOUT_PCIE6P

CLKOUT_PCIE7N
CLKOUT_PCIE7P

A20GATE

PECI

RCIN#

PROCPWRGD

THRMTRIP#

TP10
TP11
TP12
TP13
TP14
TP15
TP16
TP17
TP18

TP19
NC_1
NC_2
NC_3
NC_4
NC_5

INIT3_3V#

TP24

TP1
TP2
TP3
TP4
TP5
TP6
TP7
TP8
TP9

AH45
AH46

AF48
AF47

U2

AM3
AM1
BG10
T1
BE10
BD10

BA22
AW22
BB22
AY45
AY46
AV43
AV45
AF13
M18
N18
AJ24
AK41
AK42
M32
N32
M30
N30
H12
AA23
AB45
AB38
AB42
AB41
T39

P6
C10

BCLK_CPU_N_R
BCLK_CPU_P_R

PCH_THERMTRIP_R

INIT3_3V#

2

KA20GATE 40

2 3
1

KBRCIN# 40
H_PWRGD 5,45,59

1

4

H_PECI 5

RST_GATE

TP65 Do Not StuffTP65 Do Not Stuff

1 2

R217

R217
56R2J-4-GP

56R2J-4-GP

BCLK_CPU_N 5
BCLK_CPU_P 5

SRN0J-10-GP-U

SRN0J-10-GP-U
RN62

RN62

1 2

DY

DY

R226

R226
Do Not Stuff

Do Not Stuff

Placed Within 2" from PCH

1D5V_S3

S3

S3

3D3V_S5

12

R789

R789

Do Not Stuff

Do Not Stuff

S3

S3

12

S3

S3

B

S3

S3

C1006

C1006
Do Not Stuff

Do Not Stuff

S3

S3

1D05V_VTT

PM_THRMTRIP-A# 5,45

12

R64

R64
Do Not Stuff

Do Not Stuff

Q54

Q54

C

Do Not Stuff

Do Not Stuff

Do Not Stuff

Do Not Stuff

E

2ND = 84.03904.L06

2ND = 84.03904.L06

12

R63

R63
Do Not Stuff

Do Not Stuff

1

DDR3_DRAMRST# 20,21

NON-S3

NON-S3

12

R788

R788
0R2J-2-GP

0R2J-2-GP

SM_DRAMRST# 5

SB 0814

SB 0811 SB 0812

PCH_GPIO35

A A

DGPU_HOLD_RST#

DGPU_PW R_EN#

1 2

R256 10KR2J-3-GPR256 10KR2J-3-GP

1 2

5

R22510KR2J-3-GP R22510KR2J-3-GP

12

R17310KR2J-3-GP R17310KR2J-3-GP

3D3V_S0 3D3V_S5

UMA_DIS_ONLY

UMA_DIS_ONLY

R234

R234
10KR2J-3-GP

10KR2J-3-GP

1 2

dGPU_PRSNT#

R233

R233
Do Not Stuff

Do Not Stuff

PX

PX

1 2

4

1 2

1 2

UMA_PX

UMA_PX

R608

R608
Do Not Stuff

Do Not Stuff

PCH_GPIO57

R382

R382
10KR2J-3-GP

10KR2J-3-GP

DIS_ONLY

DIS_ONLY

UMA_DISCRETE#
SG: HIGH
UMA: HIGH
DIS ONLY: LOW

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
A3

A3

A3
Date: Sheet of

Date: Sheet of

3

2

Date: Sheet of

PCH (6/9)

PCH (6/9)

PCH (6/9)

JV50-CP

JV50-CP

JV50-CP

Taipei Hsien 221, Taiwan, R.O.C.

16 57Thursday, September 03, 2009

16 57Thursday, September 03, 2009

16 57Thursday, September 03, 2009

1

SA

SA

SA

5

4

3

2

1

1D05V_S0

1.432A

D D

1D05V_S0

1D05V_S0

42mA

1D05V_S0

C C

1D05V_S0

B B

TC18

TC18

Do Not Stuff

Do Not Stuff

3.062A

12

DY

DY

1D05V_S0

12

C327

C327

1 2

L22

L22
Do Not Stuff

Do Not Stuff

DY

DY

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

1 2

L21

L21
Do Not Stuff

Do Not Stuff

12

C311

C311

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

DY

DY

12

DY

DY

C341

C341

12

C318

C318

12

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

12

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

3D3V_S0

C626

C626
Do Not Stuff

Do Not Stuff

12

C330

C330

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

C331

C331

12

12

C312

C312

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

+1.05VS_VCCAPLL_EXP

DY

DY

12

C333

C333

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

12

C307

C307

SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

12

C342

C342

C332

C332

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

12

C322

C322

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

12

C624

C624

Do Not Stuff

Do Not Stuff

12

C321

C321

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

357mA

VCCAFDI_VRM

+1.05VS_VCCAPLL_FDI

12

C343

C343

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

PCH1G

PCH1G

AB24
AB26

AB28
AD26
AD28

AF26

AF28

AF30

AF31
AH26
AH28
AH30
AH31

AJ30

AJ31

AK24

BJ24

AN20
AN22
AN23
AN24
AN26
AN28

BJ26

BJ28

AT26

AT28
AU26
AU28

AV26

AV28

AW26
AW28

BA26

BA28

BB26

BB28
BC26
BC28
BD26
BD28

BE26

BE28
BG26
BG28
BH27

AN30
AN31

AN35

AT22

BJ18
AM23

IBEXPEAK-M-GP-NF

IBEXPEAK-M-GP-NF

VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE
VCCCORE

VCCIO

VCCAPLLEXP

VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO

VCCIO
VCCIO

VCC3_3

VCCVRM[1]
VCCFDIPLL
VCCIO

POWER

POWER

VCC CORE

VCC CORE

DMI

DMI

PCI E*

PCI E*

NAND / SPI

NAND / SPI

FDI

FDI

CRTLVDS

CRTLVDS

HVCMOS

HVCMOS

7 OF 10

7 OF 10

VCCADAC

VCCADAC
VSSA_DAC
VSSA_DAC

VCCALVDS

VSSA_LVDS

VCCTX_LVDS
VCCTX_LVDS
VCCTX_LVDS
VCCTX_LVDS

VCC3_3
VCC3_3
VCC3_3

VCCVRM

VCCDMI
VCCDMI

VCCPNAND
VCCPNAND
VCCPNAND
VCCPNAND
VCCPNAND
VCCPNAND
VCCPNAND
VCCPNAND
VCCPNAND

VCCME3_3
VCCME3_3
VCCME3_3
VCCME3_3

AE50
AE52
AF53
AF51

AH38
AH39

AP43
AP45
AT46
AT45

AB34
AB35
AD35

AT24

AT16
AU16

AM16
AK16
AK20
AK19
AK15
AK13
AM12
AM13
AM15

AM8
AM9
AP11
AP9

+VCCA_DAC_1_2

12

R148

R148
Do Not Stuff

Do Not Stuff

DY

DY

+3VS_VCCA_LVD

Do Not Stuff

Do Not Stuff

12

C289

C289

UMA_PX

UMA_PX

357mA

12

C298

C298

SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

SB 0811

196mA

12

C360

C360

12

C356

C356
SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

85mA

12

C365

C365
SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

12

1 2

R169

R169
Do Not Stuff

Do Not Stuff

+1.8VS_VCCTX_LVDS

Do Not Stuff

Do Not Stuff

12

C274

C274

UMA_PX

UMA_PX

3D3V_S0

+1.1VS_VCC_DMI

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

156mA

VCCME3_3

12

C271

C271

C268

C268

SCD01U50V2KX-1GP

SCD01U50V2KX-1GP

300mA

UMA_PX

UMA_PX

C275

C275

12

Do Not Stuff

Do Not Stuff

DY

DY

1D5V_S0_1D8V_S0

1 2

R214 0R3J-0-U-GPR214 0R3J-0-U-GP

1 2

R218 Do Not Stuff

R218 Do Not Stuff

+V_NVRAM_VCCQ

1 2

R221

R221
0R3J-0-U-GP

0R3J-0-U-GP

R131

R131

1 2

0R2J-2-GP

SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

DY

DY

12

C238

C238

3D3V_S0

1 2

R150

R150
Do Not Stuff

Do Not Stuff

UMA_PX

UMA_PX

0R2J-2-GP

Do Not Stuff

Do Not Stuff

59mA

61mA

DY

DY

VCCPNAND which power the DC NAND interface must be powered even if dual channel
NAND interface is not connected since it also supplies power to other functions inside
PCH.

3D3V_S0

1D8V_S0

1D05V_VTT

1D05V_S0

69mA

5V_S0

SB 0811

3D3V_S0_DAC

SC1U16V3ZY-GP

SC1U16V3ZY-GP

12

C301

C301

+3VS_VCCA_LVD

+1.8VS_VCCTX_LVDS

0R3J-0-U-GP

0R3J-0-U-GP

R223

R223

Imax = 300 mA

U14

U14

1

VIN

2

GND
EN3NC#4

RT9198-33GBR-GP

RT9198-33GBR-GP

74.09198.Q7F

74.09198.Q7F

3D3V_S01D8V_S0

12

VOUT

DIS_ONLY

DIS_ONLY

R665

R665

1 2

0R3J-0-U-GP

0R3J-0-U-GP
R666

R666

1 2

0R3J-0-U-GP

0R3J-0-U-GP

DIS_ONLY

DIS_ONLY

12

DY

DY

Do Not Stuff

Do Not Stuff
R245

R245

3D3V_S0_DAC

5
4

C300

C300

SC1U16V3ZY-GP

SC1U16V3ZY-GP

12

C290

C290

SC22U6D3V5MX-2GP

SC22U6D3V5MX-2GP

12

1D5V_S0_1D8V_S0

VCCAFDI_VRM

A A

5

1D8V_S0

1D5V_S0

4

1 2

R200

R200
0R3J-0-U-GP

0R3J-0-U-GP

1 2

R195

R195
0R3J-0-U-GP

0R3J-0-U-GP

1 2

R190

R190
Do Not Stuff

Do Not Stuff

DY

DY

1D5V_S0_1D8V_S0

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
A3

A3

A3
Date: Sheet of

Date: Sheet of

3

2

Date: Sheet of

PCH (7/9)

PCH (7/9)

PCH (7/9)

JV50-CP

JV50-CP

JV50-CP

Taipei Hsien 221, Taiwan, R.O.C.

17 57W ednesday, August 26, 2009

17 57W ednesday, August 26, 2009

17 57W ednesday, August 26, 2009

1

SA

SA

SA

5

1D05V_S0 +1.05VS_VCCA_CLK

52mA

1D05V_S0

R187 Do Not Stuff

D D

VccLAN may be
grounded if Intel LAN is
disabled

1D05V_S0

C C

L17

L17

1 2

IND-10UH-30-GP

IND-10UH-30-GP

Do Not Stuff

Do Not Stuff

L18

L18

1 2

IND-10UH-30-GP

IND-10UH-30-GP

Do Not Stuff

Do Not Stuff

R187 Do Not Stuff

1D05V_S0

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

+1.05VS_VCCA_A_DPL

C591

C591

12

DY

DY

+1.05VS_VCCA_B_DPL

C592

C592

12

DY

DY

1 2

Do Not Stuff

Do Not Stuff

1 2

DY

DY

0R2J-2-GP

0R2J-2-GP

12

C596

C596

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

12

C597

C597

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

L19

L19

DY

DY

R191

R191

12

C338

C338

1.849A

C293

C293

C284

C284

12

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

68mA
69mA

1D05V_S0

12

C319

C319

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

B B

C358

SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

3D3V_S5

12

C349

C349

SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

1D05V_VTT

0R3J-0-U-GP

0R3J-0-U-GP

A A

RTC_AUX_S5

5

C358

3D3V_S0

R209

R209

1 2

SC4D7U6D3V3KX-GP

SC4D7U6D3V3KX-GP

R546

R546

1 2

0R3J-0-U-GP

0R3J-0-U-GP

SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

C302

C302

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

12

163mA

12

C355

C355

12

C634

C634

DY

DY

+1.05VS_VCCLAN

12

Do Not Stuff

Do Not Stuff

DY

DY

Do Not Stuff

Do Not Stuff

12

C364

C364

+1.05VS_VCCA_A_DPL

+1.05VS_VCCA_B_DPL

12

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

+VCCSST

12

C352

C352
SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

1mA

SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

12

C350

C350

2mA

12

C633

C633
SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

4

Do Not Stuff

Do Not Stuff

12

12

C265

C265

C288

C288

12

4

C269

C269

Do Not Stuff

Do Not Stuff

DY

DY

DCPSUSBYP

12

C339

C339

SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

12

C286

C286

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

12

DY

DY

+VCCRTCEXT

1D5V_S0_1D8V_S0

12

C310

C310

+1.1VALW _INT_VCCSUS

C336

C336
SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

+1.1VS_PCH_CPU_IO

12

C348

C348

SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

+1.1VS_PCH_VCCRTC

PCH1J

PCH1J

AP51

VCCACLK

AP53

VCCACLK

AF23

VCCLAN

AF24

VCCLAN

Y20

DCPSUSBYP

AD38

VCCME

AD39

VCCME

AD41

VCCME

AF43

VCCME

AF41

VCCME

AF42

VCCME

V39

VCCME

V41

VCCME

V42

VCCME

Y39

VCCME

Y41

VCCME

Y42

VCCME

V9

DCPRTC

AU24

VCCVRM

BB51

VCCADPLLA

BB53

VCCADPLLA

BD51

VCCADPLLB

BD53

VCCADPLLB

AH23

VCCIO

AJ35

VCCIO

AH35

VCCIO

AF34

VCCIO

AH34

VCCIO

AF32

VCCIO

V12

DCPSST

Y22

DCPSUS

P18

VCCSUS3_3

U19

VCCSUS3_3

U20

VCCSUS3_3

U22

VCCSUS3_3

V15

VCC3_3

V16

VCC3_3

Y16

VCC3_3

AT18

V_CPU_IO

AU18

V_CPU_IO

A12

VCCRTC

IBEXPEAK-M-GP-NF

IBEXPEAK-M-GP-NF

POWER

POWER

USB

USB

Clock and Miscellaneous

Clock and Miscellaneous

PCI/GPIO/LPC

PCI/GPIO/LPC

SATA

SATA

CPU

CPU

RTC PCI/GPIO/LPC

RTC PCI/GPIO/LPC

3

10 OF 10

10 OF 10

V24

VCCIO

V26

VCCIO

Y24

VCCIO

Y26

VCCIO

VCCIO

V5REF

VCC3_3
VCC3_3
VCC3_3
VCC3_3
VCC3_3
VCC3_3

VCC3_3

VCCIO

VCCVRM

VCCIO
VCCIO
VCCIO
VCCIO

VCCIO
VCCIO
VCCIO

VCCIO
VCCIO
VCCIO
VCCIO

VCCME

VCCME

VCCME

VCCME

V28
U28
U26
U24
P28
P26
N28
N26
M28
M26
L28
L26
J28
J26
H28
H26
G28
G26
F28
F26
E28
E26
C28
C26
B27
A28
A26

U23
V23
F24

K49

J38
L38
M36
N36
P36
U35

AD13

AK3
AK1

AH22

AT20

AH19
AD20
AF22
AD19

AF20
AF19
AH20

AB19
AB20
AB22
AD22

AA34
Y34
Y35
AA35

L30

VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3
VCCSUS3_3

VCCSUS3_3

V5REF_SUS

VCCSATAPLL
VCCSATAPLL

VCCSUSHDA

HDA

HDA

3

12

C324

C324

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

12

C323

C325

C325

+5VALW _PCH_VCC5REFSUS

+5VS_PCH_VCC5REF

Do Not Stuff

Do Not Stuff

PCH_VCC_1_1_20
PCH_VCC_1_1_21
PCH_VCC_1_1_22
PCH_VCC_1_1_23

C323

SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

12

C299

C299

SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

+1.05VS_VCCAPLL

C638

C638

DY

DY

1D5V_S0_1D8V_S0

R177 0R2J-2-GPR177 0R2J-2-GP
R178 0R2J-2-GPR178 0R2J-2-GP
R164 0R2J-2-GPR164 0R2J-2-GP
R176 0R2J-2-GPR176 0R2J-2-GP

12

C313

C313

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

12

12

12

12

DY

DY

1 2
1 2
1 2
1 2

6mA

C335

C335
SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

C354

C354

C639

C639
Do Not Stuff

Do Not Stuff

12

C329

C329

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

1D05V_S0

1 2

2

1D05V_S0

3D3V_S5

3D3V_S5

3D3V_S5

1mA

12

C622

C622
SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

3D3V_S0

SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

L23

L23

1 2

DY

DY

Do Not Stuff

Do Not Stuff

12

C353

C353

1D05V_S0

+3VS_+1.5VS_HDA_IO

2

21

D21

D21
RB751V-40-3-GP

RB751V-40-3-GP

83.R2004.C8F

83.R2004.C8F

1 2

R527 10R2J-2-GPR527 10R2J-2-GP

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

+3VS_+1.5VS_HDA_IO

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
A3

A3

A3
Date: Sheet of

Date: Sheet of

Date: Sheet of

5V_S5

1mA

3D3V_S0

1D05V_S0

32mA

1D05V_S0

1 2

R182 0R3J-0-U-GPR182 0R3J-0-U-GP

1 2

DY

DY

R175 Do Not Stuff

R175 Do Not Stuff

PCH ( 8/9 )

PCH ( 8/9 )

PCH ( 8/9 )

JV50-CP

JV50-CP

JV50-CP

1

3D3V_S0

21

D2

D2
RB751V-40-3-GP

RB751V-40-3-GP

83.R2004.C8F

83.R2004.C8F

1 2

12

R133 10R2J-2-GPR133 10R2J-2-GP

C270

C270
SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

18 57W ednesday, August 26, 2009

18 57W ednesday, August 26, 2009

18 57W ednesday, August 26, 2009

1

5V_S0

3D3V_S5

1D5V_S5

SA

SA

SA

5

D D

C C

B B

A A

5

PCH1H

PCH1H

AB16

VSS

AA19

VSS

AA20

VSS

AA22

VSS

AM19

VSS

AA24

VSS

AA26

VSS

AA28

VSS

AA30

VSS

AA31

VSS

AA32

VSS

AB11

VSS

AB15

VSS

AB23

VSS

AB30

VSS

AB31

VSS

AB32

VSS

AB39

VSS

AB43

VSS

AB47

VSS

AB5

VSS

AB8

VSS

AC2

VSS

AC52

VSS

AD11

VSS

AD12

VSS

AD16

VSS

AD23

VSS

AD30

VSS

AD31

VSS

AD32

VSS

AD34

VSS

AU22

VSS

AD42

VSS

AD46

VSS

AD49

VSS

AD7

VSS

AE2

VSS

AE4

VSS

AF12

VSS

Y13

VSS

AH49

VSS

AU4

VSS

AF35

VSS

AP13

VSS

AN34

VSS

AF45

VSS

AF46

VSS

AF49

VSS

AF5

VSS

AF8

VSS

AG2

VSS

AG52

VSS

AH11

VSS

AH15

VSS

AH16

VSS

AH24

VSS

AH32

VSS

AV18

VSS

AH43

VSS

AH47

VSS

AH7

VSS

AJ19

VSS

AJ2

VSS

AJ20

VSS

AJ22

VSS

AJ23

VSS

AJ26

VSS

AJ28

VSS

AJ32

VSS

AJ34

VSS

AT5

VSS

AJ4

VSS

AK12

VSS

AM41

VSS

AN19

VSS

AK26

VSS

AK22

VSS

AK23

VSS

AK28

VSS

IBEXPEAK-M-GP-NF

IBEXPEAK-M-GP-NF

4

4

8 OF 10

8 OF 10

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

AK30
AK31
AK32
AK34
AK35
AK38
AK43
AK46
AK49
AK5
AK8
AL2
AL52
AM11
BB44
AD24
AM20
AM22
AM24
AM26
AM28
BA42
AM30
AM31
AM32
AM34
AM35
AM38
AM39
AM42
AU20
AM46
AV22
AM49
AM7
AA50
BB10
AN32
AN50
AN52
AP12
AP42
AP46
AP49
AP5
AP8
AR2
AR52
AT11
BA12
AH48
AT32
AT36
AT41
AT47
AT7
AV12
AV16
AV20
AV24
AV30
AV34
AV38
AV42
AV46
AV49
AV5
AV8
AW14
AW18
AW2
BF9
AW32
AW36
AW40
AW52
AY11
AY43
AY47

PCH1I

PCH1I

AY7

VSS

B11

VSS

B15

VSS

B19

VSS

B23

VSS

B31

VSS

B35

VSS

B39

VSS

B43

VSS

B47

VSS

B7

VSS

BG12

VSS

BB12

VSS

BB16

VSS

BB20

VSS

BB24

VSS

BB30

VSS

BB34

VSS

BB38

VSS

BB42

VSS

BB49

VSS

BB5

VSS

BC10

VSS

BC14

VSS

BC18

VSS

BC2

VSS

BC22

VSS

BC32

VSS

BC36

VSS

BC40

VSS

BC44

VSS

BC52

VSS

BH9

VSS

BD48

VSS

BD49

VSS

BD5

VSS

BE12

VSS

BE16

VSS

BE20

VSS

BE24

VSS

BE30

VSS

BE34

VSS

BE38

VSS

BE42

VSS

BE46

VSS

BE48

VSS

BE50

VSS

BE6

VSS

BE8

VSS

BF3

VSS

BF49

VSS

BF51

VSS

BG18

VSS

BG24

VSS

BG4

VSS

BG50

VSS

BH11

VSS

BH15

VSS

BH19

VSS

BH23

VSS

BH31

VSS

BH35

VSS

BH39

VSS

BH43

VSS

BH47

VSS

BH7

VSS

C12

VSS

C50

VSS

D51

VSS

E12

VSS

E16

VSS

E20

VSS

E24

VSS

E30

VSS

E34

VSS

E38

VSS

E42

VSS

E46

VSS

E48

VSS

E6

VSS

E8

VSS

F49

VSS

F5

VSS

G10

VSS

G14

VSS

G18

VSS

G2

VSS

G22

VSS

G32

VSS

G36

VSS

G40

VSS

G44

VSS

G52

VSS

AF39

VSS

H16

VSS

H20

VSS

H30

VSS

H34

VSS

H38

VSS

H42

VSS

IBEXPEAK-M-GP-NF

IBEXPEAK-M-GP-NF

3

9 OF 10

9 OF 10

H49

VSS

H5

VSS

J24

VSS

K11

VSS

K43

VSS

K47

VSS

K7

VSS

L14

VSS

L18

VSS

L2

VSS

L22

VSS

L32

VSS

L36

VSS

L40

VSS

L52

VSS

M12

VSS

M16

VSS

M20

VSS

N38

VSS

M34

VSS

M38

VSS

M42

VSS

M46

VSS

M49

VSS

M5

VSS

M8

VSS

N24

VSS

P11

VSS

AD15

VSS

P22

VSS

P30

VSS

P32

VSS

P34

VSS

P42

VSS

P45

VSS

P47

VSS

R2

VSS

R52

VSS

T12

VSS

T41

VSS

T46

VSS

T49

VSS

T5

VSS

T8

VSS

U30

VSS

U31

VSS

U32

VSS

U34

VSS

P38

VSS

V11

VSS

P16

VSS

V19

VSS

V20

VSS

V22

VSS

V30

VSS

V31

VSS

V32

VSS

V34

VSS

V35

VSS

V38

VSS

V43

VSS

V45

VSS

V46

VSS

V47

VSS

V49

VSS

V5

VSS

V7

VSS

V8

VSS

W2

VSS

W52

VSS

Y11

VSS

Y12

VSS

Y15

VSS

Y19

VSS

Y23

VSS

Y28

VSS

Y30

VSS

Y31

VSS

Y32

VSS

Y38

VSS

Y43

VSS

Y46

VSS

P49

VSS

Y5

VSS

Y6

VSS

Y8

VSS

P24

VSS

T43

VSS

AD51

VSS

AT8

VSS

AD47

VSS

Y47

VSS

AT12

VSS

AM6

VSS

AT13

VSS

AM5

VSS

AK45

VSS

AK39

VSS

AV14

VSS

3

2

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
A3

A3

A3
Date: Sheet of

Date: Sheet of

2

Date: Sheet of

PCH ( 9/9 )

PCH ( 9/9 )

PCH ( 9/9 )

JV50-CP

JV50-CP

JV50-CP

1

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

19 57Tuesday, August 18, 2009

19 57Tuesday, August 18, 2009

19 57Tuesday, August 18, 2009

1

SA

SA

SA

5

M_A_A[15..0]6

0D75_S0

12

R860

R860
Do Not Stuff

D D

PM_SLP_S3_CTL8,13

S3

S3

S3

S3

G

S D

Do Not Stuff

PM_SLP_S3_CTL_D1

Q55

Q55

Do Not Stuff

Do Not Stuff

Do Not Stuff

Do Not Stuff

2nd = 84.27002.N31

2nd = 84.27002.N31

M_A_BS26
M_A_BS06

M_A_BS16

M_A_DQ[63..0]6

SB 0818

C C

SB 0817

DDR_VREF_S3

R286

R286

1 2

0R3J-0-U-GP

0R3J-0-U-GP

B B

A A

DDR_VREF_S3

R289

R289

0R3J-0-U-GP

0R3J-0-U-GP

Place these caps
close to VTT1 and
VTT2.

SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

1 2

SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

0D75_S0

R573

R573
0R3J-0-U-GP

0R3J-0-U-GP

1 2

12

C385

C385

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

5

C389

C389

C403

C403

12

C386

C386

MA_VTT

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

M_VREF_CA_DIMM0

12

M_VREF_DQ_DIMM0

12

12

C649

C649

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

C394

C394
SC2D2U10V3KX-1GP

SC2D2U10V3KX-1GP

1 2

C402

C402
SC2D2U10V3KX-1GP

SC2D2U10V3KX-1GP

1 2

SB 0817

12

C650

C650

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

M_A_DQS#[7..0]6

M_A_DQS[7..0]6

M_ODT06
M_ODT16

M_VREF_DQ_DIMM010
DDR3_DRAMRST#16,21

4

M_VREF_CA_DIMM0
M_VREF_DQ_DIMM0

MA_VTT

4

M_A_A0
M_A_A1
M_A_A2
M_A_A3
M_A_A4
M_A_A5
M_A_A6
M_A_A7
M_A_A8
M_A_A9
M_A_A10
M_A_A11
M_A_A12
M_A_A13
M_A_A14
M_A_A15

M_A_DQ0
M_A_DQ1
M_A_DQ2
M_A_DQ3
M_A_DQ4
M_A_DQ5
M_A_DQ6
M_A_DQ7
M_A_DQ8
M_A_DQ9
M_A_DQ10
M_A_DQ11
M_A_DQ12
M_A_DQ13
M_A_DQ14
M_A_DQ15
M_A_DQ16
M_A_DQ17
M_A_DQ18
M_A_DQ19
M_A_DQ20
M_A_DQ21
M_A_DQ22
M_A_DQ23
M_A_DQ24
M_A_DQ25
M_A_DQ26
M_A_DQ27
M_A_DQ28
M_A_DQ29
M_A_DQ30
M_A_DQ31
M_A_DQ32
M_A_DQ33
M_A_DQ34
M_A_DQ35
M_A_DQ36
M_A_DQ37
M_A_DQ38
M_A_DQ39
M_A_DQ40
M_A_DQ41
M_A_DQ42
M_A_DQ43
M_A_DQ44
M_A_DQ45
M_A_DQ46
M_A_DQ47
M_A_DQ48
M_A_DQ49
M_A_DQ50
M_A_DQ51
M_A_DQ52
M_A_DQ53
M_A_DQ54
M_A_DQ55
M_A_DQ56
M_A_DQ57
M_A_DQ58
M_A_DQ59
M_A_DQ60
M_A_DQ61
M_A_DQ62
M_A_DQ63

M_A_DQS#0
M_A_DQS#1
M_A_DQS#2
M_A_DQS#3
M_A_DQS#4
M_A_DQS#5
M_A_DQS#6
M_A_DQS#7

M_A_DQS0
M_A_DQS1
M_A_DQS2
M_A_DQS3
M_A_DQS4
M_A_DQS5
M_A_DQS6
M_A_DQS7

DM1

DM1

98

A0

97

A1

96

A2

95

A3

92

A4

91

A5

90

A6

86

A7

89

A8

85

A9

107

A10/AP

84

A11

83

A12

119

A13

80

A14

78

A15

79

A16/BA2

109

BA0

108

BA1

5

DQ0

7

DQ1

15

DQ2

17

DQ3

4

DQ4

6

DQ5

16

DQ6

18

DQ7

21

DQ8

23

DQ9

33

DQ10

35

DQ11

22

DQ12

24

DQ13

34

DQ14

36

DQ15

39

DQ16

41

DQ17

51

DQ18

53

DQ19

40

DQ20

42

DQ21

50

DQ22

52

DQ23

57

DQ24

59

DQ25

67

DQ26

69

DQ27

56

DQ28

58

DQ29

68

DQ30

70

DQ31

129

DQ32

131

DQ33

141

DQ34

143

DQ35

130

DQ36

132

DQ37

140

DQ38

142

DQ39

147

DQ40

149

DQ41

157

DQ42

159

DQ43

146

DQ44

148

DQ45

158

DQ46

160

DQ47

163

DQ48

165

DQ49

175

DQ50

177

DQ51

164

DQ52

166

DQ53

174

DQ54

176

DQ55

181

DQ56

183

DQ57

191

DQ58

193

DQ59

180

DQ60

182

DQ61

192

DQ62

194

DQ63

10

DQS0#

27

DQS1#

45

DQS2#

62

DQS3#

135

DQS4#

152

DQS5#

169

DQS6#

186

DQS7#

12

DQS0

29

DQS1

47

DQS2

64

DQS3

137

DQS4

154

DQS5

171

DQS6

188

DQS7

116

ODT0

120

ODT1

126

VREF_CA

1

VREF_DQ

30

RESET#

203

VTT1

204

VTT2

H =9.2mm

DDR3-204P-57-GP

DDR3-204P-57-GP

NP1

NP1

NP2

NP2

110

RAS#

113

WE#

115

CAS#

114

CS0#

121

CS1#

73

CKE0

74

CKE1

101

CK0

103

CK0#

102

CK1

104

CK1#

11

DM0

28

DM1

46

DM2

63

DM3

136

DM4

153

DM5

170

DM6

187

DM7

200

SDA

202

SCL

198

EVENT#

199

VDDSPD

197

SA0

201

SA1

77

NC#1

122

NC#2

125

NC#/TEST

75

VDD1

76

VDD2

81

VDD3

82

VDD4

87

VDD5

88

VDD6

93

VDD7

94

VDD8

99

VDD9

100

VDD10

105

VDD11

106

VDD12

111

VDD13

112

VDD14

117

VDD15

118

VDD16

123

VDD17

124

VDD18

2

VSS

3

VSS

8

VSS

9

VSS

13

VSS

14

VSS

19

VSS

20

VSS

25

VSS

26

VSS

31

VSS

32

VSS

37

VSS

38

VSS

43

VSS

44

VSS

48

VSS

49

VSS

54

VSS

55

VSS

60

VSS

61

VSS

65

VSS

66

VSS

71

VSS

72

VSS

127

VSS

128

VSS

133

VSS

134

VSS

138

VSS

139

VSS

144

VSS

145

VSS

150

VSS

151

VSS

155

VSS

156

VSS

161

REVERSE TYPE

VSS

162

VSS

167

VSS

168

VSS

172

VSS

173

VSS

178

VSS

179

VSS

184

VSS

185

VSS

189

VSS

190

VSS

195

VSS

196

VSS

205

VSS

206

VSS

62.10017.Q41

62.10017.Q41

2ND = 62.10017.N61

2ND = 62.10017.N61

3

M_A_DM0
M_A_DM1
M_A_DM2
M_A_DM3
M_A_DM4
M_A_DM5
M_A_DM6
M_A_DM7

SODIMM0_1_SMB_DATA_R
SODIMM0_1_SMB_CLK_R

R272

R272

TS#_DIMM0

SA0_DIM0
SA1_DIM0

3

0R2J-2-GP

0R2J-2-GP

1D5V_S3

1 2

M_A_RAS# 6
M_A_WE# 6
M_A_CAS# 6

M_CS#0 6
M_CS#1 6

M_CKE0 6
M_CKE1 6

M_CLK_DDR0 6
M_CLK_DDR#0 6

M_CLK_DDR1 6
M_CLK_DDR#1 6

M_A_DM[7..0] 6

12

C405

C405

C404

C404

SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

SC2D2U10V3KX-1GP

SC2D2U10V3KX-1GP

1 2

Layout Note:
Place these Caps near
SO-DIMMA.

PM_EXTTS#0_R 5

2

SA0_DIM0
SA1_DIM0

12

R570

R570
10KR2J-3-GP

10KR2J-3-GP

R271 0R2J-2-GPR271 0R2J-2-GP

1 2

R270 0R2J-2-GPR270 0R2J-2-GP

1 2

3D3V_S0

1D5V_S3

2

3D3V_S0

12

R287

R287
Do Not Stuff

Do Not Stuff

DY

DY

12

R288

R288
10KR2J-3-GP

10KR2J-3-GP

SODIMM A DECOUPLING

C411

C411

C410

C410

SC1U10V2KX-1GP

SC1U10V2KX-1GP

SC1U10V2KX-1GP

SC1U10V2KX-1GP

12

Note:
If SA0 DIM0 = 0, SA1_DIM0 = 0
SO-DIMMA SPD Address is 0xA0
SO-DIMMA TS Address is 0x30

If SA0 DIM0 = 1, SA1_DIM0 = 0
SO-DIMMA SPD Address is 0xA2
SO-DIMMA TS Address is 0x32

PCH_SMBDATA 3,12,21
PCH_SMBCLK 3,12,21

12

12

C641

C641

C646

C646

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

12

12

C408

C408

C643

C643

SC1U10V2KX-1GP

SC1U10V2KX-1GP

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

C645

C645

C647

C647

SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

12

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom
Date: Sheet of

Date: Sheet of

Date: Sheet of

1

12

12

C407

C407

C642

C642

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

C644

C644

SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

12

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

DDRIII Socket DM1

DDRIII Socket DM1

DDRIII Socket DM1

JV50-CP

JV50-CP

JV50-CP

1

SA

SA

20 57Thursday, September 03, 2009

20 57Thursday, September 03, 2009

20 57Thursday, September 03, 2009

SA

5

M_B_A[15..0]6

D D

M_B_BS26
M_B_BS06

M_B_BS16

M_B_DQ[63..0]6

C C

DDR_VREF_S3

R293

R293

1 2

0R3J-0-U-GP

0R3J-0-U-GP

DDR_VREF_S3

B B

R302

R302

0R3J-0-U-GP

0R3J-0-U-GP

1 2

C416

C416

SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

C426

C426

SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

M_VREF_CA_DIMM1

12

M_VREF_DQ_DIMM1

12

C415

C415
SC2D2U10V3KX-1GP

SC2D2U10V3KX-1GP

1 2

C425

C425
SC2D2U10V3KX-1GP

SC2D2U10V3KX-1GP

1 2

SB 0817

M_B_DQS#[7..0]6

M_B_DQS[7..0]6

0D75_S0

R602

R602

0R3J-0-U-GP

A A

Place these caps
close to VTT1 and
VTT2.

5

0R3J-0-U-GP

12

12

C668

C668

12

C666

C666

C659

C659

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

M_VREF_DQ_DIMM110
DDR3_DRAMRST#16,20

1 2

12

C658

C658

SC1U6D3V2KX-GP

SC1U6D3V2KX-GP

4

SB 0817

M_ODT26
M_ODT36

M_VREF_CA_DIMM1
M_VREF_DQ_DIMM1

MB_VTT
MB_VTT

Note:
SO-DIMMB SPD Address is 0xA4
SO-DIMMB TS Address is 0x34

4

M_B_A0
M_B_A1
M_B_A2
M_B_A3
M_B_A4
M_B_A5
M_B_A6
M_B_A7
M_B_A8
M_B_A9
M_B_A10
M_B_A11
M_B_A12
M_B_A13
M_B_A14
M_B_A15

M_B_DQ0
M_B_DQ1
M_B_DQ2
M_B_DQ3
M_B_DQ4
M_B_DQ5
M_B_DQ6
M_B_DQ7
M_B_DQ8
M_B_DQ9
M_B_DQ10
M_B_DQ11
M_B_DQ12
M_B_DQ13
M_B_DQ14
M_B_DQ15
M_B_DQ16
M_B_DQ17
M_B_DQ18
M_B_DQ19
M_B_DQ20
M_B_DQ21
M_B_DQ22
M_B_DQ23
M_B_DQ24
M_B_DQ25
M_B_DQ26
M_B_DQ27
M_B_DQ28
M_B_DQ29
M_B_DQ30
M_B_DQ31
M_B_DQ32
M_B_DQ33
M_B_DQ34
M_B_DQ35
M_B_DQ36
M_B_DQ37
M_B_DQ38
M_B_DQ39
M_B_DQ40
M_B_DQ41
M_B_DQ42
M_B_DQ43
M_B_DQ44
M_B_DQ45
M_B_DQ46
M_B_DQ47
M_B_DQ48
M_B_DQ49
M_B_DQ50
M_B_DQ51
M_B_DQ52
M_B_DQ53
M_B_DQ54
M_B_DQ55
M_B_DQ56
M_B_DQ57
M_B_DQ58
M_B_DQ59
M_B_DQ60
M_B_DQ61
M_B_DQ62
M_B_DQ63

M_B_DQS#0
M_B_DQS#1
M_B_DQS#2
M_B_DQS#3
M_B_DQS#4
M_B_DQS#5
M_B_DQS#6
M_B_DQS#7

M_B_DQS0
M_B_DQS1
M_B_DQS2
M_B_DQS3
M_B_DQS4
M_B_DQS5
M_B_DQS6
M_B_DQS7

H = 5.2mm

98
97
96
95
92
91
90
86
89
85

107

84
83

119

80
78
79

109
108

5

7
15
17

4

6
16
18
21
23
33
35
22
24
34
36
39
41
51
53
40
42
50
52
57
59
67
69
56
58
68
70

129
131
141
143
130
132
140
142
147
149
157
159
146
148
158
160
163
165
175
177
164
166
174
176
181
183
191
193
180
182
192
194

10
27
45
62

135
152
169
186

12
29
47
64

137
154
171
188

116
120

126

1
30

203
204

DM2

DM2

A0
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10/AP
A11
A12
A13
A14
A15
A16/BA2

BA0
BA1

DQ0
DQ1
DQ2
DQ3
DQ4
DQ5
DQ6
DQ7
DQ8
DQ9
DQ10
DQ11
DQ12
DQ13
DQ14
DQ15
DQ16
DQ17
DQ18
DQ19
DQ20
DQ21
DQ22
DQ23
DQ24
DQ25
DQ26
DQ27
DQ28
DQ29
DQ30
DQ31
DQ32
DQ33
DQ34
DQ35
DQ36
DQ37
DQ38
DQ39
DQ40
DQ41
DQ42
DQ43
DQ44
DQ45
DQ46
DQ47
DQ48
DQ49
DQ50
DQ51
DQ52
DQ53
DQ54
DQ55
DQ56
DQ57
DQ58
DQ59
DQ60
DQ61
DQ62
DQ63

DQS0#
DQS1#
DQS2#
DQS3#
DQS4#
DQS5#
DQS6#
DQS7#

DQS0
DQS1
DQS2
DQS3
DQS4
DQS5
DQS6
DQS7

ODT0
ODT1

VREF_CA
VREF_DQ

RESET#

VTT1
VTT2

DDR3-204P-52-GP

DDR3-204P-52-GP

3

NP1

NP1

NP2

NP2

110

RAS#

113

WE#

115

CAS#

114

CS0#

121

CS1#

73

CKE0

74

CKE1

101

CK0

103

CK0#

102

CK1

104

CK1#

DM0
DM1
DM2
DM3
DM4
DM5
DM6
DM7

SDA
SCL

EVENT#

VDDSPD

SA0
SA1

NC#1
NC#2

NC#/TEST

VDD1
VDD2
VDD3
VDD4
VDD5
VDD6
VDD7
VDD8

VDD9
VDD10
VDD11
VDD12
VDD13
VDD14
VDD15
VDD16
VDD17
VDD18

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

REVERSE TYPE

VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS
VSS

62.10017.P61 2ND = 62.10017.N41

62.10017.P61 2ND = 62.10017.N41

SO-DIMMB is placed farther from
the Processor than SO-DIMMA

M_B_DM0

11

M_B_DM1

28

M_B_DM2

46

M_B_DM3

63

M_B_DM4

136

M_B_DM5

153

M_B_DM6

170

M_B_DM7

187

SODIMM1_1_SMB_DATA_R

200

SODIMM1_1_SMB_CLK_R

202

TS#_DIMM1

198
199

SA0_DIM1

197

SA1_DIM1

201
77

122
125

75
76
81
82
87
88
93
94
99
100
105
106
111
112
117
118
123
124

2
3
8
9
13
14
19
20
25
26
31
32
37
38
43
44
48
49
54
55
60
61
65
66
71
72
127
128
133
134
138
139
144
145
150
151
155
156
161
162
167
168
172
173
178
179
184
185
189
190
195
196
205
206

3

1D5V_S3

R584

R584
0R2J-2-GP

0R2J-2-GP

M_B_RAS# 6
M_B_WE# 6
M_B_CAS# 6

M_CS#2 6
M_CS#3 6

M_CKE2 6
M_CKE3 6

M_CLK_DDR2 6
M_CLK_DDR#2 6

M_CLK_DDR3 6
M_CLK_DDR#3 6

M_B_DM[7..0] 6

1 2

12

C427

C427

SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

1 2

PM_EXTTS#1_R 5

C430

C430
SC2D2U10V3KX-1GP

SC2D2U10V3KX-1GP

2

R586 0R2J-2-GPR586 0R2J-2-GP

1 2

R588 0R2J-2-GPR588 0R2J-2-GP

1 2

3D3V_S0

1D5V_S3

2

C678

C678

1

3D3V_S0

12

R593

R593
10KR2J-3-GP

10KR2J-3-GP

SA1_DIM1
SA0_DIM1

DY

DY

12

R592

R592
Do Not Stuff

Do Not Stuff

PCH_SMBDATA 3,12,20
PCH_SMBCLK 3,12,20

12

R303

R303
10KR2J-3-GP

10KR2J-3-GP

SODIMM B DECOUPLING

12

12

C434

C434

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

C677

C677

C676

C676

SC1U10V2KX-1GP

SC1U10V2KX-1GP

SC1U10V2KX-1GP

SC1U10V2KX-1GP

12

12

12

C432

C432

C433

C433

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

C413

C413

C412

C412

SC1U10V2KX-1GP

SC1U10V2KX-1GP

SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

12

12

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

ENG DIS MADSION SAMSUNG

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom
Date: Sheet of

Date: Sheet of

Date: Sheet of

12

12

C406

C406

C409

C409

SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

12

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

SC10U6D3V3MX-GP

C675

C675

SCD1U10V2KX-5GP

SCD1U10V2KX-5GP

12

Wistron Corporation

Wistron Corporation

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

DDRIII Socket DM2

DDRIII Socket DM2

DDRIII Socket DM2

JV50-CP

JV50-CP

JV50-CP

SA

SA

21 57Thursday, September 03, 2009

21 57Thursday, September 03, 2009

21 57Thursday, September 03, 2009

1

SA
