3M X70, X80 Operator Guide

Digital Projector X70/X80

Operator's Guide

Thank you for purchasing this projector.

CAUTION Before using, read the "Product Safety Guide" and this "Operator's guide" to ensure correct usage through understanding. After

reading, store them in a safe place for future reference.

NOTE

• The manufacturer assumes no responsibility for any errors that may appear in this manual.

• The reproduction, transmission or use of this document or contents is not permitted without express written authority.

TRADEMARK ACKNOWLEDGMENT :

• VGA and XGA are registered trademarks of the International Business Machines Corporation.

• Apple and Mac are registered trademarks of Apple Computer, Inc.

• VESA and SVGA are trademarks of the Video Electronics Standard Association.

• Windows is a registered trademark of Microsoft Corporation.

• Internet Explorer is a trademark of Microsoft Corporation. All other trademarks are the property of their respective owners.

• The information in this manual is subject to change without notice.

Projector Features

This multimedia projector is used to project various computer signals as well as NTSC/PAL/SECAM video signals onto a screen. Little space is required for installation and large images can easily be realized.

Ultra High Brightness

●

Crisp, ultra-bright presentations is achieved by using a UHB (ultra high brightness) lamp and a highly efficient optical system.

Whisper Mode Equipped

●

Special mode is available for reducing projector noise to achieve quieter operation.

User Memory Function

●

This projector can memorize 4 settings by MY MEMORY function.

Partial Magnification Function

●

Interesting parts of images can be magnified for closer viewing.

Keystone Distortion Correction

●

Quick correction of distorted images electrically.

Optical Lens Shift (X80 only)

●

The lens of this projector can be shifted vertically. When you want to finely adjust the picture position, use the LENS SHIFT buttons.

Preparation

Please see the “Quick Start Guide”. Your projector should come with the items shown there. Contact your dealer anything is missing.

NOTE

sure to use the original packing material. Use special caution for the lens part.

• Keep the original packing material for future reshipment. For moving the projector, be

Contents

Projector Features Preparation Part Names

Projector ……………………………4 Control Buttons ……………………5 Remote control ……………………5

Setting Up

Arrangement ………………………6 Adjusting The Projector’s Elevator ……………………………7 Using The Lens shift Buttons (X80 only) Connecting Your Devices…………8 Connecting The Power Supply …11

Remote Control

About The Laser Pointer ………12 Putting Batteries …………………12 Operating The Remote Control …………………13 Using The Remote ID Feature…………………………13 Using The Mouse/Keyboard Control Function …………………14

Power ON/OFF

Turning On The Power …………15 Turning Off The Power …………15

Operating

Selecting An Input Signal ………16 Selecting The Aspect Ratio ……17 Using The Automatic Adjustment Feature………………17 Adjusting The Picture Position …18 Correcting The Keystone Distortion …………………………18 Adjusting The Volume …………19 Muting The Sound ………………19 Temporarily Blanking The Screen ………………………19 Freezing The Screen ……………20 Using The Magnify Feature ……20 Displaying The Child Window …21 Selecting An Audio Input ………21

………………………… …………………………

……………………………

…………………………

…………………

……………………

…7

2 2 4

Multifunctional Settings

Using The Menu Functions ……22 MAIN Menu ………………………23 PICTURE-1 Menu ………………24 PICTURE-2 Menu ………………26 INPUT Menu ……………………27 AUTO Menu ………………………29 SCREEN Menu …………………31 OPTION Menu ……………………33 NETWORK Menu ………………35

Network Setting Up Lamp

Replacing The Lamp ……………38

Air Filter

Caring For The Air Filter…………39

Other Care

Caring For The Inside Of The Projector ……………………40 Caring For The Lens ……………40 Caring For The Cabinet And Remote Control …………………40

Troubleshooting

Related Messages Regarding The Indicator Lamps ……………………………43 Phenomena That May Easily Be Mistaken For Machine Defects …45

Specifications Accessories

TECHNICAL

………………………………

……………………………

…………………………

…………………

……………………

………………………

………

………………

………………41

…

36 37

47 48

Setting Up

Arrangement

WARNING • Before installation, make sure that the projector is turned off and the

power cord is disconnected.

• Do not set up and move the projector, while it is hot.

• Install the projector in a suitable environment according to instructions of the “Product

Safety Guide” and this manual.

• The power outlet should be close to the projector and easily accessible.

Refer to the illustrations and tables below to determine the screen size and projection distance. The values shown in the table are calculated for a full size screen. (±10%)

Reference for the 4:3 aspect ratio

Screen

Lens center

Reference for the 16:9 aspect ratio

Screen

Lens center

Side View

Screen Size

[inch (m)]

40 (1.0) 46(1.2) 71(1.8) 12(30) 24(61) 24(61) 60 (1.5) 71(1.8) 107(2.7) 18(46) 36(91) 36(91) 70 (1.8) 83(2.1) 126(3.2) 21(53) 42(107) 42(107)

80 (2.0) 95(2.4) 144(3.7) 24(61) 48(122) 48(122) 100 (2.5) 120(3.0) 181(4.6) 30(76) 60(152) 60(152) 120 (3.0) 144(3.7) 217(5.5) 36(91) 72(183) 72(183) 150 (3.8) 181(4.6) 272(6.9) 45(114) 90(229) 90(229) 200 (5.1) 243(6.2) 364(9.2) 60(152) 120(305) 120(305) 250 (6.4) 304(7.7) 300 (7.6) 366(9.3) 350 (8.9)

400 (10.2) 500 (12.7)

Screen Size

[inch (m)]

40 (1.0) 50(1.3) 77(2.0) 10(25) 23(58) 20(50)

60 (1.5) 77(2.0) 117(3.0) 15(37) 34(87) 29(75)

70 (1.8) 91(2.3) 137(3.5) 17(44) 40(102) 34(87)

80 (2.0) 104(2.6) 157(4.0) 20(50) 46(116) 39(100) 100 (2.5) 131(3.3) 197(5.0) 25(62) 57(145) 49(125) 120 (3.0) 158(4.0) 237(6.0) 29(75) 69(174) 59(149) 150 (3.8) 198(5.0) 297(7.5) 37(93) 86(218) 74(187) 200 (5.1) 265(6.7) 250 (6.4) 332(8.4) 300 (7.6) 350 (8.9)

400 (10.2) 450 (11.4)

a [inch (m)] b [inch (cm)]

Min. Max.

455(11.6)

547(13.9) 427(10.9) 638(16.2) 489(12.4) 730(18.5) 612(15.5) 913(23.2)

a [inch (m)] b [inch (cm)]

Min. Max.

396(10.1)

496(12.6) 399(10.1) 596(15.1) 466(11.8) 696(17.7) 533(13.5) 795(20.2) 600(15.2) 895(22.7)

min

X80

75(191) 150(381) 150(381)

90(229) 180(457) 180(457) 105(267)210(533) 210(533) 120(305)240(610) 240(610) 150(381)300(762) 300(762)

X80

min

49(125) 114(291) 98(249)

61(156) 143(363) 123(311)

74(187) 172(436) 147(374)

86(218) 200(508) 172(436)

98(249) 229(581) 196(498) 110(280)257(654) 221(560)

X80

X70

max

[inch (cm)]

max

[inch (cm)]

Setting Up (continued)

Connecting Your Devices

WARNING • Whenever attempting to connect other devices to the projector, read thoroughly the "Product Safety Guide", this manual and the manual of each device

to be connected. Incorrect connecting could result in fire or electrical shock.

CAUTION

Attempting to connect a live device to the projector may generate extremely loud noises or other abnormalities that may result in malfunction and/or damage to the device and/or projector.

ATTENTION

connection may result in malfunction and/or damage to the device and/or projector. Refer to the section “Technical” of this manual for the pin assignment of connectors and RS-232C communication data.

• Some cables have to be used with core set. Use the accessory cable or a

designated-type cable for the connection. For cables that have a core only at one end, connect the core to the projector.

• Secure the screws on the connectors and tighten.

• Whenever attempting to connect a laptop computer to the projector, be sure to

activate the laptop’s RGB external image output (set the laptop to CRT display or to simultaneous LCD and CRT display). For details on how this is done, please refer to the instruction manual of the corresponding laptop computer.

• TURN OFF ALL DEVICES prior to connecting them to the projector.

• Make sure that you connect devices to the correct port. Incorrect

NOTE

these modes may not be compatible with this projector.

• For some RGB input modes, the optional Mac adapter is necessary.

• When the image resolution is changed on a computer, depending on an input,

automatic adjust function may take some time and may not be completed. In this case, you may not be able to see a check box to select “Yes/No” for the new resolution on Windows. Then the resolution will go back to the original. It might be recommended to use other CRT or TFT monitors to change the resolution.

NOTE

• Plug-and-Play is a system incorporated in the computer, its operating system and peripheral equipment (i.e. display devices).

• This projector is compatible with VESA DDC 1/2B. Plug-and-Play can be achieved by connecting this projector to computers that are VESA DDC (display data channel) compatible.

• Please take advantage of this function by connecting the accessory RGB cable to the RGB port (DDC 1/2B compatible). Plug-and-Play may not work properly if any other type of connection is attempted.

• Please use the standard drivers in your computer as this projector is a Plug-and-Play monitor.

• Some computers may have multiple display screen modes. Use of some of

Plug-and-Play Capability

Setting Up (continued)

Examples of connection with a VCR/DVD Player

VCR/DVD Player Projector

Audio out (R)

Audio out (L)

Video out

R-audio in-L video in

R-audio in audio in-L video in

■ If using a s-video signal

S-video out S-video cable S -video in

R-audio in-L video in

Audio out (R)

Audio out (L)

R-audio in audio in-L

■ If using a component signal

component

R/PR out

C C

B/PB out

Y out

Audio out (R)

Audio out (L)

CR/PR CB/PB Y

R-audio in-L video in

R-audio in audio in-L

H I

audio in1

audio in2

rgb

R/C

R/PR G/Y B/CB/PB HV

BNC

audio in1

audio in2

rgb

R/C

R/PR G/Y B/CB/PB HV

BNC

audio in1

audio in2

rgb

R/C

R/PR G/Y B/CB/PB HV

BNC

rgb out

remote control

audio out

remote control

audio out

remote control

audio out

control network

CR/PR

Ca/Pa

H I

video inR-audio in-L

S-video in

control network

CR/PR

Ca/Pa

H J

video inR-audio in-L

S-video in

control network

CR/PR

Ca/Pa

video inR-audio in-L

S-video in

■ If using a SCART RGB input

SCART RGB out

SCART adapter

component

R-audio in-L video in

R (CR/PR) B (C

B/PB)

G (Y) R-audio in audio in-L video in

audio in1

audio in2

rgb

R/C

R/PR G/Y B/CB/PB HV

BNC

rgb out

remote control

audio out

CR/PR

Ca/Pa

video inR-audio in-L

control network

S-video in

H I

Remote Control

STANDBY/ON

VIDEO

LASER INDICATOR

ESC MENU

POSITION

RESET

AUTO

KEYSTONE

1 2 3

ID CHANGE

OFF

FREEZE

MUTE

MAGNFY

PinP

VOL

UME

RGB

BLANK

ASPECT

MOUSE

LASER

LENSSHIFT

–––

FOCUS

ZOOM

Remote Control

About The Laser Pointer

WARNING • The laser pointer of the remote control is used in place of a finger or rod. Never look directly into the laser beam outlet or point the laser beam at other

people. The laser beam can cause vision problems.

CAUTION

than those specified herein may result in hazardous radiation exposure.

AVOID EXPOSURE-LASER

CAUTION

Comples with 21 CFR, 1040.10 AND 1040.11 IEO60825-1:1993+A1:1997+A2:2001

LASER-STRAHLING NICHT IN DEN STRAHL BLICKEN LASER KLASSE 2 WAVE LENGTH:640-660nm MAX OUTPUT:1mW

レーザー光ビームをのぞきこまないことクラス2レーザー製品 JISC6802（1998）最大出力：1.0mW 波長：640−660nm

MODEL:H-IRC4

INTERLINK K.K. 1-10-7 HIGASHIKANDA CHIYODA-KU,TOKYO,JAPAN 101-0031

• Use of controls or adjustments or performance of procedures other

RADIATION IS EMITTED FROM THIS APERTURE

LASER RADIATION

DO NOT STARE INTO BEAM

WAVE LENGTH: 640-660nm MAX OUTPUT: 1mW CLASS 2 LASER PRODUCT

レーザー光をのぞき込まないこと。

MANUFACTURER: B MANUFACTURED

JANUARY,2003

MADE IN CHINA

レーザー光を人に向けないこと。子供に使わせないこと。製造者：INTERLINK ELECTRONICS

P S

This remote control has a laser pointer in place of a finger or rod. The laser beam works and the LASER INDICATOR lights while the LASER button is pressed.

Putting Batteries

CAUTION • About the battery

• Keep a battery away from children and pets.

• Use only the battery specified: two AA batteries.

• Do not mix new battery with used one.

• Make sure the plus and minus terminals are correctly aligned when loading the

battery (as indicated in the remote control).

• Dispose of batteries in accord with environmental laws.

Remove the battery

cover. Slide back and remove the battery cover in the direction of the arrow.

Insert the batteries.

Align and insert the two AA batteries according to their plus minus terminals (as indicated in the remote control).

Close the battery cover. Replace the battery cover in the direction of the arrow and snap it back into place.

Remote Control (continued)

Using The Mouse/Keyboard Control Function

CAUTION • Before connecting, read the manuals of the device you will connect.

Mistaken use of the mouse/keyboard control could damage your equipment.

• Only connect to a PC or an USB Hub connected PC.

• Do not unplug the connector cables while the computer is operating.

Using the USB control feature, you can use the remote control as a simplified mouse or keyboard of the computer.

Connect the M1-D port of the projector to the computer via the M1-D cable. Then functions illustrated below will be enabled.

memo

Windows 95 OSR 2.1 or higher. It may not be possible to use the remote control, depending

The USB control can be used with

STANDBY/ON

LENS SHIFT

on the computer’s configurations and mouse drivers.

memo

The function can be used only for the

functions illustrated on the right.

memo

The projector would be enumerated as a mouse and a keyboard of HID (Human Interface Device) class devices, after connecting cable.

LASER INDICATOR

VIDEO

FOCUS ZOOM

–––

ASPECT

LASER

BLANK

MOUSE

ESC MENU

POSITION

RESET AUTO

MAGNFY

PinP

VOLUME

FREEZE MUTE

OFF

KEYSTONE

1 2 3

ID CHANGE

(Front)

RGB

Mouse left button

Mouse move pointer

Keyboard

Arrow keys / / /

Mouse right button

Keyboard ESC key

(Rear)

Operating

Selecting An Input Signal

Select an input signal.

■ Using the INPUT dial

SEARCH button

Turn the INPUT dial of the projector. Turning the dial cycles through the input ports as shown below. Select the signal you wish to project.

M1-D rgb BNC

S-video componen

t video

■ Using SEARCH button

Press the SEARCH button of the projector or the remote control. Pressing the button automatically cycles through input ports and displays the picture of retrieved signal.

memo

If no signal is found or the projector is unstable to find an input signal at any of its ports, it will turn to the state it was in prior to the search.

STANDBY/ON

M1-D rgb BNC

S-video componen

t video

LENS SHIFT

BLANK

■ Using RGB button

rgb

BNC

component

S-video

video

INPUT dial

LASER INDICATOR

VIDEO

RGB

FOCUS ZOOM

–––

ASPECT

LASER

MOUSE

M1-D

input

ENTER

VIDEO button

RGB button

reset

Press the RGB button of the remote control. Pressing the button toggles between the RGB ports as shown below Select the signal you wish to project.

M1-D rgb BNC

■ Using VIDEO button

Press the VIDEO button of the remote control. Pressing the button toggles between the VIDEO ports as shown below Select the signal you wish to project.

S-video videocomponent

Use the ZOOM buttons to adjust the screen size.

Use the FOCUS buttons to adjust the focus.

ESC MENU

POSITION

MAGNFY

OFF

RESET AUTO

PinP

FREEZE MUTE

KEYSTONE

1 2 3

ID CHANGE

buttons

VOLUME

zoom

ZOOM

SEARCH button

focus

FOCUS buttons

Operating (continued)

Selecting The Aspect Ratio

Press the Aspect button to toggle between the

modes for aspect ratio.

■ At a M1-D signal

NORMAL

memo

NORMAL keeps the original aspect ratio of the

4:3

16:9

LASER INDICATOR

STANDBY/ON

VIDEO

LENS SHIFT

FOCUS ZOOM

–––

ASPECT

BLANK

MOUSE

input signal.

■ At a RGB signal (not M1-D)

16:

4:3

■ At a video signal

4:3

memo

16:9

SMALL

At a HDTV signal of 1125i or 750p, only 16:9 can

ESC MENU

POSITION

MAGNFY

OFF

ID CHANGE

RESET AUTO

PinP

VOLUME

FREEZE MUTE

KEYSTONE

1 2 3

be selected.

Using The Automatic Adjustment Feature

RGB

LASER

ASPECT button

memo The automatic adjustment operation requires approximately 10 seconds. Also,

please note that it may not function correctly with some input.

Press the AUTO button.

■ At a RGB signal

The Vertical position (V POSITION), the horizontal position (H POSITION), the clock phase (H PHASE) and horizontal size (H SIZE) will be automatically adjusted.

memo

Make sure that the application window is set to its maximum size prior to attempting to use this feature. Dark pictures may still be incorrectly adjusted. Use a bright screen when adjusting.

■ At a video signal

The signal type mode best suited for the respective input signal will be selected automatically.

memo

This function is available only when the AUTO is selected to the item VIDEO of the INPUT menu. For a component video signal, the signal type is identified automatically independently of this function.

LASER INDICATOR

STANDBY/ON

VIDEO

LENS SHIFT

FOCUS ZOOM

–––

ASPECT

LASER

BLANK

MOUSE

ESC MENU

POSITION

RESET AUTO

MAGNFY

PinP

VOLUME

FREEZE MUTE

OFF

KEYSTONE

1 2 3

ID CHANGE

RGB

AUTO button

Operating (continued)

Adjusting The Picture Position

memo This function is available only for RGB signals.

Press the POSITION button.

As illustrated on the right, a dialog will appear on the screen to aid you in adjusting

POSITION

the position.

Use the cursor buttons / / / to adjust the

position.

memo

When you want to initialize the position, press

the RESET button during adjustment.

Press the POSITION button again to close the

dialog and complete this operation.

memo

Even if you don't do anything, the dialog will

automatically disappear after a few seconds.

Correcting The Keystone Distortion

Press the KEYSTONE button.

As illustrated on the right, a dialog will appear on the screen to aid you in correcting the keystone distortion.

Use the cursor buttons / to

select the direction of distortion to correct ( or ).

Use the cursor buttons / to correct the

distortion.

Press the KEYSTONE button again to close the

dialog and complete this operation.

KEYSTONE

LASER INDICATOR

STANDBY/ON

VIDEO

LENS SHIFT

FOCUS ZOOM

–––

ASPECT

BLANK

MOUSE

ESC MENU

POSITION

RESET AUTO

MAGNFY

PinP

FREEZE MUTE

OFF

KEYSTONE

1 2 3

ID CHANGE

LASER INDICATOR

STANDBY/ON

VIDEO

LENS SHIFT

FOCUS ZOOM

–––

ASPECT

BLANK

MOUSE

ESC MENU

POSITION

RESET AUTO

MAGNFY

PinP

FREEZE MUTE

OFF

KEYSTONE

1 2 3

ID CHANGE

RGB

LASER

VOLUME

RGB

LASER

VOLUME

Cursor buttons

POSITION button

RESET button

Cursor buttons

KEYSTONE button

memo

Even if you don't do anything, the dialog will

automatically disappear after a few seconds.

memo When this adjustment is excessive, certain

degradation may appear on the picture. Also, please note that it may not function correctly with some input.

Operating (continued)

Adjusting The Volume

Press the VOLUME button.

As illustrated on the right, a dialog will appear on the screen to aid you in adjusting the volume.

Use the cursor buttons / to

adjust the volume.

Press the VOLUME button again to close the

dialog and complete this operation.

memo

Even if you don't do anything, the dialog will

automatically disappear after a few seconds.

Muting The Sound

Press the MUTE button.

As illustrated on the right, a dialog will appear on the screen indicating that you have muted the sound.

VOLUME

LASER INDICATOR

STANDBY/ON

VIDEO

LENS SHIFT

FOCUS ZOOM

–––

ASPECT

LASER

BLANK

MOUSE

ESC MENU

POSITION

RESET AUTO

MAGNFY

PinP

VOLUME

FREEZE MUTE

OFF

KEYSTONE

1 2 3

ID CHANGE

LASER INDICATOR

STANDBY/ON

VIDEO

LENS SHIFT

FOCUS ZOOM

–––

ASPECT

LASER

BLANK

MOUSE

RGB

Cursor buttons

VOLUME button

RGB

Press the MUTE or VOLUME

button to restore the sound.

memo

Even if you don't do anything,

the dialog will automatically disappear after a few seconds.

Temporarily Blanking The Screen

Press the BLANK button.

The input signal screen will shut off, and a BLANK screen will appear.

memo You can set the BLANK screen using the

menu. Please refer to the item “BLANK” of the table of the section “SCREEN Menu”.

Press the BLANK button again to remove the

blank screen, and return to the input signal screen.

ESC MENU

POSITION

RESET AUTO

MAGNFY

PinP

FREEZE MUTE

OFF

KEYSTONE

1 2 3

ID CHANGE

LASER INDICATOR

STANDBY/ON

VIDEO

LENS SHIFT

FOCUS ZOOM

–––

ASPECT

BLANK

MOUSE

ESC MENU

POSITION

RESET AUTO

MAGNFY

PinP

VOLUME

FREEZE MUTE

OFF

KEYSTONE

1 2 3

ID CHANGE

RGB

LASER

VOLUME

MUTE button

BLANK button

Operating (continued)

Freezing The Screen

Press the FREEZE button.

As illustrated on the right, a dialog will appear on the screen, and the screen will

FREEZE

LASER INDICATOR

STANDBY/ON

VIDEO

LENS SHIFT

FOCUS ZOOM

–––

ASPECT

BLANK

RGB

LASER

freeze at the current image.

ESC MENU

POSITION

MAGNFY

OFF

MOUSE

RESET AUTO

PinP

FREEZE MUTE

KEYSTONE

1 2 3

ID CHANGE

VOLUME

FREEZE button

Press the FREEZE button again to restore the

screen to normal. The icon “||” will change to the icon “ ”. And after a couple of seconds, the dialog will be closed and the screen will be restored to normal.

memo

The freezing feature will automatically finish if a remote control’s button that changes some display state (ex. blanking the screen, displaying a dialog or a menu, adjusting the picture, changing the input signal) is pressed, or a button of projector is pressed.

NOTE

•

If the projector continues projecting the same image for a long time (i.e. you forget to exit FREEZE mode),

the image might possibly remain as an afterimage. Do not leave the projector in FREEZE mode for too long.

Using The Magnify Feature

Press the MAGNIFY

button. As illustrated on the right, a dialog will appear on the screen to aid you in magnifying the picture.

Press the POSITION button, then use the cursor

buttons / / / to select the area to zoom.

Press the POSITION button again to finalize the

zoom area.

Use the cursor buttons / to adjust the zoom

level.

Press the MAGNIFY button again to close the

dialog and complete this operation.

OFF

MAGNIFY

LASER INDICATOR

STANDBY/ON

VIDEO

LENS SHIFT

FOCUS ZOOM

–––

ASPECT

BLANK

MOUSE

ESC MENU

POSITION

RESET AUTO

MAGNFY

PinP

FREEZE MUTE

OFF

KEYSTONE

1 2 3

ID CHANGE

RGB

LASER

VOLUME

Cursor buttons

POSITION button

MAGNIFY buttons

memo

The magnify feature will automatically finish if the automatic adjustment is execute, or the aspect, the signal type mode of video or the signal input state is changed.

Operating (continued)

Displaying The Child Window

memo

This feature called "PinP (Picture in Picture)" is available only when a RGB signal is selected to main screen.

Press the PinP button.

The child window with a picture of a video signal will appear.

Press the PinP button again to change the size of

the child window or close the window.

Small child window Large child window

No child window

memo

You can select the video signal to display in the

child window, and the position of the child window. Please refer to the items “P.INP. INPUT” and “P.INP. POSIT.” of the table of the section “INPUT Menu”.

Selecting An Audio Input

LASER INDICATOR

STANDBY/ON

VIDEO

LENS SHIFT

FOCUS ZOOM

–––

ASPECT

LASER

BLANK

MOUSE

ESC MENU

POSITION

RESET AUTO

MAGNFY

PinP

VOLUME

FREEZE MUTE

OFF

KEYSTONE

1 2 3

ID CHANGE

RGB

PinP button

memo

This feature is available only when the child window is on the screen.

When the child window is on the

screen, press the VOLUME button. As illustrated on the right, a dialog will appear on the screen.

Use the cursor buttons / to

select an audio input.

RGB (Audio input for the main screen)

Video (Audio input for the child window)

memo

buttons

You also can adjust the volume using the cursor

. Please refer to the section “Adjusting

The Volume”.

Press the VOLUME button again to close the

dialog and complete this operation.

memo

Even if you don’t do anything, the dialog will

automatically disappear after a few seconds.

VOLUME

RGB Video

LASER INDICATOR

STANDBY/ON

VIDEO

LENS SHIFT

FOCUS ZOOM

–––

ASPECT

LASER

BLANK

MOUSE

ESC MENU

POSITION

RESET AUTO

MAGNFY

PinP

VOLUME

FREEZE MUTE

OFF

KEYSTONE

1 2 3

ID CHANGE

RGB

Cursor buttons

VOLUME button

Multifunctional Settings

Using The Menu Functions

This projector has the following menus: MAIN, PICTURE-1, PICTURE-2, INPUT, AUTO, SCREEN, OPTION and NETWORK. Each of these menus is operated using the same methods. The basic operations of these menus are as follows.

Press the MENU button.

The menu will appear on the screen.

Use the cursor buttons

/ to select a menu, then press the (or the ENTER) button to

LASER INDICATOR

STANDBY/ON

VIDEO

LENS SHIFT

FOCUS ZOOM

–––

ASPECT

BLANK

MOUSE

ESC MENU

POSITION

RESET AUTO

MAGNFY

PinP

FREEZE MUTE

OFF

KEYSTONE

1 2 3

ID CHANGE

RGB

LASER

VOLUME

progress. The display of the selected menu will appear.

Use the cursor buttons

/ to select an item, then press the (or the ENTER) button to progress. The operation display of the selected item will appear.

Use the cursor buttons / to operate the item.

memo

press the RESET button during the operation. Note that the items whose functions are performed simultaneously with operating (ex. LANGUAGE, WHISPER, H PHASE etc.) are not reset.

memo

display, press the or ESC button.

When you want to reset the adjustment,

When you want to return to the previous

Cursor buttons

MENU button

RESET button

ESC button

ENTER button

ex. Turning off the built-in speaker

1) Press the MENU button.

MENU MAIN

BRIGHT

PICTURE-1

CONTRAST

PICTURE-2

ASPECT

INPUT

WHISPER

AUTO

MIRROR

SCREEN

LANGUAGE

OPTION

[Language]

NETWORK

RESET

: SELECT

2) Select the “OPTION” using the button, then press the button.

MENU MAIN PICTURE-1 PICTURE-2 INPUT AUTO SCREEN OPTION NETWORK

: SELECT

VOLUME SPEAKER IR REMOTE IR REMOTE ID LAMP TIME FILTER TIME SERVICE RESET

16 TURN ON

ALL 1234 h 4321 h

3) Select the “SPEAKER” using the button, then press the button.

MENU MAIN

VOLUME

PICTURE-1

SPEAKER

PICTURE-2

IR REMOTE

INPUT

IR REMOTE ID

AUTO

LAMP TIME

SCREEN

FILTER TIME

OPTION

SERVICE

NETWORK

RESET

: SELECT

4) Use the cursor button to select the “TURN OFF”.

OPTION SPEAKER TURN ON TURN OFF

MENU MAIN PICTURE-1 PICTURE-2 INPUT AUTO SCREEN OPTION NETWORK

: SELECT

16 TURN ON

ALL 1234 h 4321 h

+0 +0 4:3 NORMAL NORMAL ENGLISH

VOLUME SPEAKER IR REMOTE IR REMOTE ID LAMP TIME FILTER TIME SERVICE RESET

OPTION SPEAKER TURN ON TURN OFF

16 TURN ON

ALL 1234 h 4321 h

Press the MENU button again to close the menu

display and complete this operation.

memo

Even if you don’t do anything, the menu will

automatically disappear after a few seconds

5) Press the MENU button.

Multifunctional Settings (continued)

ENGLISH FRANÇAIS DEUTSCH  ESPAÑOL ITALIANO

SVENSKA

SUOMI  POLSKI

Multifunctional Settings (continued)

MAIN Menu

With the MAIN menu, the items shown in the table below can be performed. Perform each operation in accordance with the instructions in the table below.

Item Description

MENU MAIN PICTURE-1 PICTURE-2 INPUT AUTO SCREEN OPTION NETWORK

: SELECT

BRIGHT CONTRAST ASPECT WHISPER MIRROR LANGUAGE [Language] RESET

+0 +0 4:3 NORMAL NORMAL ENGLISH

BRIGHT

CONTRAST

ASPECT

WHISPER

MIRROR

Adjust the brightness using the / buttons. : Light  Dark Adjust the contrast using the / buttons. : Strong  Weak Select an aspect ratio using the / buttons. :

■ At a M1-D signal NORMAL  4:3  16:9

The NORMAL keeps the original aspect ratio of the input signal.

■ At a RGB signal (not M1-D) 4:3  16:9

■ At a video signal 4:3  16:9  SMALL

memo At a HDTV signal of 1125i or 750p, only the 16:9 can be selected.

Select the NORMAL or the WHISPER using the / buttons. :

NORMAL  WHISPER

When the WHISPER is selected, acoustic noise and screen brightness are reduced.

Select a mirror status using the / buttons. :

NORMAL  H:INVERT  V:INVERT  H&V:INVERT

ex.

Select a menu language using the / buttons. :

LANGUAGE

NORSK  NEDERLANDS  日本語  PORTUGUÊS  中文





Select the EXECUTE using the button to reset the MAIN menu items. :

RESET

EXECUTE  CANCEL

The items of the MAIN menu are collectively returned to the initial setting. Note that the items “WHISPER” and “LANGUAGE” are not reset.

Multifunctional Settings (continued)

PICTURE-1 Menu

With the PICTURE-1 menu, the items shown in the table below can be performed. Perform each operation in accordance with the instructions in the table below.

Item Description

Select a gamma mode using the / buttons. :

NORMAL  CINEMA  DYNAMIC  CUSTOM

Selecting the CUSTOM and then pressing the (or the ENTER) button calls the CUSTOM menu.

CUSTOM Menu

Select an item using the / buttons, and press the

(or the ENTER) button to perform each function.

GAMMA  COLOR TEMP  R  G  B

memo The R, G and B can be selected only when the

USER is selected under the COLOR TEMP.

MAIN PICTURE-1 PICTURE-2 INPUT AUTO SCREEN OPTION NETWORK

: SELECT

GAMMA NORMAL CINEMA DYNAMIC CUSTOM

: SELECT

GAMMA COLOR BAL R COLOR BAL G COLOR BAL B SHARPNESS COLOR TINT MY MEMORY

GAMMA COLOR TEMP R G B

NORMAL +0 +0 +0 +0 +0 +0 LOAD1

2.2 HIGH 100 100 100

GAMMA

COLOR BAL R

COLOR BAL G

COLOR BAL B

SHARPNESS

GAMMA

COLOR TEMP

Adjust the gamma data using the / buttons. :

Up  Down

Select a color temperature using the / buttons. :

HIGH  MIDDLE  LOW  USER

Adjust the red color level for the USER mode of the COLOR TEMP using the / buttons. : Strong  Weak

Adjust the green color level for the USER mode of the COLOR TEMP using the / buttons. : Strong  Weak

Adjust the blue color level for the USER mode of the COLOR TEMP using the / buttons. : Strong  Weak

Adjust the red color balance using the / buttons. :

Strong  Weak

Adjust the green color balance using the / buttons. :

Strong  Weak

Adjust the blue color balance using the / buttons. :

Strong  Weak

Adjust the sharpness using the / buttons. :

Clear  Soft

memo This item can be selected only at a video signal.

COLOR

TINT

Adjust the whole color using the / buttons. :

Strong  Weak

memo This item can be selected only at a video signal.

Adjust the tint using the / buttons. :

Green  Red

memo This item can be selected only at a video signal.

(This table is continued to the following page.)

Multifunctional Settings (continued)

PICTURE-1 Menu (continued)

Item Description

Select a command to load or save using the / buttons, and then press the (or the ENTER) button to perform the function.:

LOAD1  LOAD2  LOAD3  LOAD4

SAVE1  SAVE2  SAVE3  SAVE4

MY MEMORY

RESET

This projector has 4 numbered memories for adjustment data. Performing the SAVE1, SAVE2, SAVE3 or SAVE4 puts the current adjustment data on the memory whose number corresponds with the command’s number. Performing the LOAD1, LOAD2, LOAD3 or LOAD4 loads the data on the memory whose number corresponds with the command’s number, and adjusts the picture automatically depending on the data.

Select the EXECUTE using the button to reset the PICTURE-1 menu items. :

EXECUTE  CANCEL

The items of the PICTURE-1 menu are collectively returned to the initial setting. Note that the items “MY MEMORY” and “GAMMA” of the CUSTOM menu under the item “GAMMA” are not reset.

Multifunctional Settings (continued)

PICTURE-2 Menu

With the PICTURE-2 menu, the items shown in the table below can be performed. Perform each operation in accordance with the instructions in the table below.

memo This menu cannot be selected at a M1-D signal.

Item Description

Adjust the vertical position using the / buttons. :

V POSITION

H POSITION

H.PHASE

Up  Down

memo This item can be selected only at a RGB signal.

Adjust the horizontal position using the / buttons. :

Left  Right

memo This item can be selected only at a RGB signal.

Adjust the horizontal phase to eliminate flicker using the / buttons. :

Right  Left

memo This item can be selected only at a RGB signal or a component video

signal other than a COMPONENT port input of 525i/625i/SCART RGB.

MENU MAIN PICTURE-1 PICTURE-2 INPUT AUTO SCREEN OPTION NETWORK

: SELECT

V POSITION H POSITION H PHASE H SIZE OVER SCAN RESET

20 142 31 1344 95

H SIZE

OVER SCAN

RESET

Adjust the horizontal size using the / buttons. :

Large  Small

memo This item can be selected only at a RGB signal. memo When this adjustment is excessive, the picture may not be displayed

correctly. In such a case, please reset the adjustment pressing the RESET button during this operation.

Adjust the over-scan ratio using the / buttons. :

Small  Large

memo This item can be selected only at a video signal. memo When this adjustment is too large, certain degradation may appear at

the frame area of the picture. In such a case, please adjust small. Select the EXECUTE using the button to reset the PICTURE-2 menu items. :

EXECUTE  CANCEL The items of the PICTURE-2 menu are collectively returned to the initial setting. Note that the item “H PHASE” is not reset.

Multifunctional Settings (continued)

INPUT Menu

With the INPUT menu, the items shown in the table below can be performed. Perform each operation in accordance with the instructions in the table below.

Item Description

Select a color space mode using the / buttons. :

AUTO  RGB  SMPTE240  REC709  REC601 Selecting the AUTO automatically selects the optimum mode.

COLOR SPACE

COMPONENT

memo This item can be selected only at a RGB signal or a component video

signal other than a COMPONENT port input of 525i/625i/SCART RGB.

memo The AUTO operation may not work well at some signals. In such a case,

select the SMPTE240 or the REC709 for a HDTV signal. Select a function of COMPONENT port using the / buttons. :

COMPONENT  SCART RGB When the SCART RGB is selected, the COMPONENT port function as a port for a SCART RGB signal input. Please refer to the section “Connecting Your Devices”.

MENU MAIN PICTURE-1 PICTURE-2 INPUT AUTO SCREEN OPTION NETWORK

: SELECT

COLOR SPACE COMPONENT VIDEO 3D-YCS VIDEO NR P. INP. INPUT P. INP. POSIT. POWERUP INPUT

AUTO COMPONENT AUTO TURN OFF LOW VIDEO

RGB

VIDEO

3D-YCS

VIDEO NR

Select a signal type mode using the / buttons. :

AUTO  NTSC  PAL  SECAM  NTSC4.43  M-PAL  N-PAL Selecting the AUTO automatically selects the optimum mode.

memo This item is performs only at a video signal from the VIDEO port or the S-

VIDEO port. For a component video signal, the signal type is identified automatically independently of this function.

memo The AUTO operation may not work well at some signals. If the picture

becomes unstable (ex. a irregular picture, a color lack), please select the mode depending on the input signal.

Select the TURN ON or the TURN OFF using the / buttons. :

TURN ON  TURN OFF When the TURN ON is selected, the 3D-YCS mode works for a completely still image, or images with few motions.

memo This item performs only at a video signal of NTSC3.58. memo When this function performs, the setting of the item “VIDEO NR” of this

INPUT menu is not effective. Select a noise reduction level using the / buttons. :

HIGH  MIDDLE  LOW The noise on screen is reduced according to the selected level.

memo This item performs only at a video signal from the VIDEO port or the S-

VIDEO port. At a video signal of NTSC3.58, this function performs only when the TURN OFF is selected to the item “3D-YSC” of this INPUT menu.

memo When this adjustment is excessive, certain degradation may appear on

the picture.

(This table is continued to the following page.)

Multifunctional Settings (continued)

INPUT Menu (continued)

Item Description

Select a signal input port for the child window using the / buttons. :

P.IN P. INPUT

P.IN P. POSIT.

POWERUP

INPUT

video  S-video

memo About the child window, please refer to the section “Displaying the Child

Window”. Select the display position of the child window using the / buttons. :



memo About the child window, please refer to the section “Displaying the Child

Window”. Select a signal input port to display just when the projector is turned on, using

the / buttons. :

LAST INPUT  M1-D  rgb  BNC  component  S-video  video

Selecting the LAST INPUT selects the port that was used at the last time. Pressing the (or the ENTER) button displays the INPUT INFORMATION

menu. The INPUT INFORMATION menu shows the information about the current signal input as illustrated below.

INFORMATION

S2-ASPECT

RESET

INPUT-INFORMATION

RGB

1024x768 @60.0

FRAME LOCK

INPUT-INFORMATION

S-VIDEO

SECAM

AUTO

INPUT-INFORMATION

COMPONENT

575i @50

SCART RGB

memo The “FRAME LOCK” message means the frame lock function is working.

This function automatically works when a RGB signal with vertical frequency of 50 to 60 is input, and it displays a moving picture more smoothly.

memo The “SCART RGB” message means the COMPONENT port is working

as a SCART RGB port. Please refer to the item “COMPONENT” in this table. Select the TURN ON or the TURN OFF using the / buttons. :

TURN ON  TURN OFF When the TURN ON is selected, an S2-video signal can be identified and the optimum aspect ratio is automatically selected.

memo This item is performs only at a S-VIDEO signal. memo When the ASPECT button is used or the item “ASPECT” of the MAIN

menu is operated, the TURN OFF will be automatically selected to this item. Select the EXECUTE using the button to reset the INPUT menu items. :

EXECUTE  CANCEL The items of the INPUT menu are collectively returned to the initial setting. Note that the item “INFORMATION” is not reset.

Multifunctional Settings (continued)

AUTO Menu

With the AUTO menu, the items shown in the table below can be performed. Perform each operation in accordance with the instructions in the table below.

Item Description

Pressing the (or the ENTER) button performs the automatic adjustment.

■ At a RGB signal

The vertical position (V POSITION), the horizontal position (H POSITION), the

clock phase (H PHASE) and the horizontal size (H SIZE) will be automatically

adjusted.

memo Make sure that the application window is set to its maximum size prior to

attempting to use this feature. Dark pictures may still be incorrectly adjusted. Use a bright screen when adjusting.

■ At a video signal

ADJUST

The signal type mode best suited for the respective input signal will be

selected automatically.

memo This function is available only when the AUTO is selected to the item

“VIDEO” of the INPUT menu. For a component video signal, the signal type is identified automatically independently of this function.

memo This operation requires approximately 10 seconds, and the message

“AUTO IN PROGRESS” is displayed during the operation.

memo This operation may not work well at some signals. If the picture

becomes unstable (ex. a irregular picture, a color lack), please select the suitable mode to the item “VIDEO” of the INPUT menu.

MENU MAIN PICTURE-1 PICTURE-2 INPUT AUTO SCREEN OPTION NETWORK

: SELECT

ADJUST POWER OFF POWER ON SEARCH RESET

0 min TURN ON TURN ON

POWER OFF

POWER ON

Set the time using the / buttons. :

Long (max. 99 minutes)  Short (min. 0 minute = DISABLE)

ex.

AUTO

POWER OFF

ENABLE

1min

AUTO

POWER OFF

DISABLE

0min

When the time is set to 1 to 99, the projector lamp will go off and the STANDBY/ON indicator begins blinking when the passed time with a proper signal (without no-signal and an unsuitable signal) reaches at the set time. Please refer to the section “Turning Off The Power”.

Select the TURN ON or the TURN OFF using the / buttons.:

TURN ON  TURN OFF When the TURN ON is selected, you can turn the projector on without pressing the STANDBY/ON button. Please refer to the section “Turning Off The Power”.

(This table is continued to the following page.)

Multifunctional Settings (continued)

AUTO Menu (continued)

Item Description

Select the TURN ON or the TURN OFF using the / buttons. :

TURN ON  TURN OFF When the TURN ON is selected, detecting no signal cycles through input ports and displays the picture of retrieved signal.

RESET

M1-D rgb

video S-video com

memo When the TURN ON is selected, pressing the RGB button selects the

M1-D ports, and pressing the VIDEO button selects the component port.

memo If no signal is found or the projector is unstable to find an input signal at

any of its ports, it will return to the state it was in prior to the search. Select the EXECUTE using the button to reset the AUTO menu items. :

EXECUTE  CANCEL The items of the AUTO menu are collectively returned to the initial setting. Note that the item “ADJUST” is not reset.

BNC

onent

Multifunctional Settings (continued)

SCREEN Menu

With the SCREEN menu, the items shown in the table below can be performed. Perform each operation in accordance with the instructions in the table below.

Item Description

Select a type of the BLANK screen using the / buttons. :

MyScreen  ORIGINAL  BLUE  WHITE  BLACK The BLANK screen is the screen, which is displayed by pressing the BLANK button. The MyScreen is the screen you can register a desired screen, and the

BLANK

START UP

ORIGINAL is the existing standard screen. The BLUE, the WHITE and the BLACK are the non-pattered (plain) screens in each color.

memo To avoid remaining as an afterimage, the MyScreen and the ORIGINAL

screens will change to the BLACK screen after several minutes.

memo For the MyScreen, please refer to the item “MyScreen” in this table.

Select a type of the START UP screen using the / buttons. :

MyScreen  ORIGINAL  TURN OFF The START UP screen is the screen, which is displayed by detecting no signal or an unsuitable signal. The MyScreen is the screen you can register a desired screen, and the ORIGINAL is the existing standard screen. When the TURN OFF is selected, the BLUE is used.

memo To avoid remaining as an afterimage, the MyScreen and the ORIGINAL

screens will change to the BLANK after several minutes. If also the BLANK screen is the MyScreen or the ORIGINAL, it will change to the BLACK screen.

memo About the MyScreen, please refer to the item “MyScreen” in this table.

About the BLUE, BLACK and BLANK screens, please refer to the item “BLANK” in this table.

MENU MAIN PICTURE-1 PICTURE-2 INPUT AUTO SCREEN OPTION NETWORK

: SELECT

BLANK START UP MyScreen MyScreen SIZE MyScreen LOCK MENU POSITION MESSAGE RESET

BLACK ORIGINAL

x1 TURN OFF

TURN ON

MyScreen

MyScreen SIZE

Pressing the (or the ENTER) button starts the MyScreen registration. Please see the flow chart on the following page.

Select the size of the MyScreen using the / buttons. :

x1  FULL Select the TURN ON or the TURN OFF using the / buttons.:

MyScreen LOCK

TURN ON  TURN OFF The TURN ON disables the operation of the item “MyScreen” of this SCREEN menu.

Adjust the menu position using the / / / buttons. :



MENU POSITION

Left  +  Right



Down

memo To finish this operation, press the ESC button but not the button.

(This table is continued to the following page.)

Multifunctional Settings (continued)

SCREEN Menu (continued)

Item Description

Select the TURN ON or the TURN OFF using the / buttons. :

TURN ON  TURN OFF When the TURN ON is selected, the following message function works.

The message of the “AUTO IN PROGRESS” for the auto adjustment.

The message of the ”NO INPUT IS DETECTED”

MESSAGE

RESET

The message of the ”SYNC IS OUT OF RANGE”

The message of the ”Searching …”

The message of the “Detecting …” The indication of the input signal by input change. The indication of the aspect ratio by changing the aspect ratio. The indication of “FOCUS” by adjusting the focus.

Select the EXECUTE using the button to reset the SCREEN menu items. :

EXECUTE  CANCEL The items of the SCREEN menu are collectively returned to the initial setting.

How to register your picture as the MyScreen

MyScreen is pointed on the SCREEN menu.

Press the button

The MyScreen

menu appears.

Do you capture the picture from

the current screen?

If the ESC/RESET button is pressed ...

YES: Press the ENTER button

The picture freeze and the frame for capturing appears.

Move the frame to the position of the picture

which you want to use, using / / / buttons,

and press the ENTER button to register.

Registering.

It takes about 1 minute to register.

MyScreen

Do you start capturing this picture?

ESC ENT

:NO

:YES

NO: Press the ESC/RESET button

MyScreen Move the capture area

as you want.

ESC

My Screen

:RETURN

ENT

:NEXT

45%

Just when the picture registration is completed

the registered screen and

the message of the right is displayed for a few seconds.

If the picture registration failed,

the message of the right is displayed for a few seconds.

MyScreen registration is finished.

A capturing error has occurred.

Please try again.

Multifunctional Settings (continued)

OPTION Menu

With the OPTION menu, the items shown in the table below can be performed. Perform each operation in accordance with the instructions in the table below.

Item Description

MENU MAIN PICTURE-1 PICTURE-2 INPUT AUTO SCREEN OPTION NETWORK

: SELECT

VOLUME SPEAKER IR REMOTE IR REMOTE ID LAMP TIME FILTER TIME SERVICE PIN LOCK

16 TURN ON

ALL 1234 h 4321 h

TURN ON

VOLUME

SPEAKER

IR REMOTE

IR REMOTE ID

LAMP TIME

Adjust the volume using the / buttons. :

High  Low Select the TURN ON or the TURN OFF using the / buttons. :

TURN ON  TURN OFF When the TURN ON is selected, the built-in speaker works.

Select a remote sensor using the / button (1), then switch it using the ENTER button (2). :

(1) 1:FRONT  2:TOP  3:REAR (2)  (Off) (On)

memo A sensor cannot be turned off when the other two are off.

OPTION IR REMOTE 1:FRONT 2:TOP 3:REAR ENT

Always at least one sensor is on. Select a number as an ID number for remote control using the / buttons. :

ALL  1  2  3 The projector is controlled by the remote control whose ID CHANGE switch is set into the position of the same number as this number. When the ALL is selected, the projector is controlled by a remote control irrespective of the position of the ID CHANGE switch.

memo Please refer to the section “Using The Remote ID Feature”.

Pressing the RESET button for about 3 seconds displays the LAMP TIME menu. Select the RESET using button to reset the timer. :

RESET  CANCEL Selecting the RESET resets the count of the lamp timer to 0.

memo Perform this function only when you have replaced the lamp. The lamp

timer counts the used time of the current lamp, to display the messages about the lamp. Incorrect performing causes incorrect operation of the messages.

memo About replacing the lamp, please refer to the section” Lamp”.

Pressing the RESET button for about 3 seconds displays the FILTER TIME menu. Select the RESET using button to reset the timer. :

RESET  CANCEL

FILTER TIME

Selecting the RESET resets the count of the lamp timer to 0.

memo Perform this function only when you have cleaned or replaced the air

filter. The filter timer counts the used time of the air filter after cleaning or replacement, to display the messages about the air filter. Incorrect performing causes incorrect operation of the messages.

memo About caring for the air filter, please refer to the section “Air Filter”.

(This table is continued to the following page.)

Multifunctional Settings (continued)

OPTION Menu (continued)

Item Description

SERVICE

Pressing the (or the ENTER) button calls the SERVICE menu.

SERVICE Menu

Select an item using the / buttons, and press the (or the ENTER) button to per form each function. :

FANSPEED  AUTO ADJUST  LENS TYPE  LENS LOCK

Select the fan speed level using the / buttons. :

HIGH  NORMAL

FANSPEED

The HIGH ups rotation speeds of fans, though. Please use this function in using a projector at highlands etc.

memo Note that the projector is noisier when the HIGH is

selected. Select the ENABLE or the DISABLE using the /

buttons. :

ENABLE  DISABLE

AUTO

ADJUST

When you want to keep the current adjustment state, select the DISABLE. When the ENABLE is selected, detecting a signal change to a RGB signal performs the automatic adjustment of the vertical position (V POSITION), the horizontal position (H POSITION), the clock phase (H PHASE) and the horizontal size (H SIZE).

SERVICE FANSPEED AUTO ADJUST LENS TYPE LENS LOCK

: SELECT

NORMAL ENABLE AUTO TURN OFF

RESET

Select the lens type currently used using the / buttons. :

AUTO  1  2  3  4  5 Please select depending on the following. AUTO: automatically selects optimum mode.

1: for a standard lens (Type NL-500 etc.)

LENS TYPE

2: for a fixed short throw lens (Type FL-501 etc.)

3: for a short throw lens (Type SL-502 etc.)

4: for a long throw lens (Type LL-503 etc.)

5: for a super long throw lens (Type LL-504 etc.)

memo This setting has an influence on the keystone distortion

etc.

memo About the optional lens, ask your dealer.

Select the TURN ON or the TURN OFF using the

buttons. :

LENS LOCK

TURN ON  TURN OFF Selecting the TURN ON locks the adjustment of the lens shift (X80 only), the zoom and the focus.

Select the EXECUTE using the button to reset the OPTION menu items. :

EXECUTE  CANCEL The items of the OPTION menu are collectively returned to the initial setting. Note that the items “VOLUME”, “LAMP TIME” , “FILTER TIME” and “SERVICE” are not reset.

Multifunctional Settings (continued)

NETWORK Menu

This projector provides the NETWORK function. If you use this function, please set up the projector according to the Network environment in which you use it.

memo The following settings is not required If your network can assign an IP

address through its DHCP server. The projector is set to DHCP by default. Please see the section “Network Setting Up”.

Item Description

MENU MAIN PICTURE-1 PICTURE-2 INPUT AUTO SCREEN OPTION NETWORK

: SELECT

SETUP DHCP INFORMATION RESET

TURN OFF

SETUP

DHCP

Pressing the (or the ENTER) button, displays the IP ADDRESS menu to the right.

memo This menu will be shown only when the DHCP

NETWORK - SETUP

IP ADRRESS

192 . 168 . 1 . 24

ESC ENT

:RETURN

is disabled at the NETWORK menu. The IP Address is identification number of the projector on the Network.

1. Set the IP Address using the / buttons.

memo The same IP Address cannot be used for two devices.

Pressing the (or the ENTER) button at the IP ADDRESS menu, displays the SUBNET MASK menu. The SUBNET MASK is an address of the Network.

NETWORK - SETUP

SUBNET MASK

255 . 255 . 255 . 1

ESC ENT

:RETURN

2. Set the address of the Network to be used. Pressing the (or the ENTER) button at the SUBNET MASK, shows the DEFAULT GATEWAY menu. The DEFAULT GATEWAY is the main device

NETWORK - SETUP DEFAULT GATEWAY

255 . 255 . 255 . 0

ESC ENT

:RETURN

to access outside of the Network.

3. Set the address of the device as gateway to an outer Network.

Select the TURN ON or the TURN OFF using the / buttons. :

TURN ON  TURN OFF If your Network doesn’t support the DHCP function, select the TURN OFF.

:NEXT

NETWORK

DHCP

TURN ON

TURN OFF

Pressing the (or the ENTER) button displays the

INFORMATION

INFORMATION menu. The menu shows the information about the current Network setting as illustrated right.

Select the EXECUTE using the button to reset the NETWORK menu items. :

RESET

EXECUTE  CANCEL All items on the NETWORK menu are returned to the initial setting.

NETWORK-INFORMATION IP ADRRESS 192. 168. 1. 24 SUBNETMASK 255. 255. 255. 0 DEFAULT GATEWAY 255. 255. 255. 0 MAC ADRRESS 00. E0. 47. 03. 0C. D8

Network Setting Up

This projector provides the NETWORK function. When you start to use this function, please consult your dealer for further information.

To start, connect the network port to a gateway device via a CAT-5 cable, then set up the projector according to the Network environment in which you use it.

When your Network enables the DHCP function

The IP Address can be set automatically if the DHCP is "TURN ON" using the NETWORK menu. Please refer to the section "NETWORK Menu".

When your Network doesn’t support the DHCP function or When you use a fixed address even if your Network can support the DHCP function

Please set the IP Address, the Subnet Mask, the Default Gateway and the DHCP using the NETWORK menu.(Page 35) At first, set the DHCP function to “TURN OFF”. You can set them using a Web Browser (Internet Explore 4.0 or higher) on the computer connected to the Network.

Input the same IP address as set to the projector onto the Web Browser on the computer connected to LAN.

ex. Case of IP Address = 192.168.1.11

1) Input “http://192.168.1.11”.

2) Click “ENTER”.

3) Input the required data according to the screen.

Make sure the input data is correct, then click "Write".

memo These setting will be active after reboot. These

setting will be stored, and used when DHCP is OFF.

5) Click “Return to top page”.

6) Click “REBOOT” to complete this operation.

Lamp

WARNING

The projector uses a high-pressure mercury glass lamp. The lamp can break with a loud bang, or burn out, if jolted or scratched, handled while hot, or worn over time.

Note that each lamp has a different lifetime, and some may burst or burn out soon after you start using them. In addition, when the bulb bursts, it is possible for shards of glass to fly into the lamp housing, and for gas containing mercury to escape from the projector’s vent holes.

About disposal of a lamp • This product contains a mercury lamp; do not put in trash. Dispose of in accord with environmental laws. For lamp recycling, go to www.lamprecycle.org. (in USA) For product disposal, contact your local government agency or www.eiae.org (in the US) or www.epsc.ca (in Canada). For more information, call your dealer.

• If the lamp should break (it will make a loud bang when it does), unplug the power cord from the outlet, and make sure to request a replacement lamp from your local dealer. Note that shards of glass could damage the projector’s internals, or cause injury during handling, so please do not try to clean the projector or replace the lamp yourself.

• If the lamp should break (it will make a loud bang when it does), ventilate

Disconnect the

plug from the

power outlet

the room well, and make sure not to breathe the gas that comes out of the projector vents, or get it in your eyes or mouth.

• Before replacing the lamp, make sure the power switch is off and the power cable is not plugged in, then wait at least 45 minutes for the lamp to cool sufficiently. Handling the lamp while hot can cause burns, as well as damaging the lamp.

HIGH VOLTAGE HIGH TEMPERATURE HIGH PRESSURE

• Do not open the lamp door while the projector is suspended from above. This is dangerous, since if the lamp’s bulb has broken, the shards will fall out when the door is opened. In addition, working in high places is dangerous, so ask your local dealer to have the lamp replaced even if the bulb is not broken.

• Use only the lamp of the specified type 78-6969-9718-4 6969-9719-2 for X80.

• If the lamp breaks soon after the first time it is used, it is possible that there are electrical problems elsewhere besides the lamp. If this happens, contact your local dealer or a service representative.

• Handle with care: jolting or scratching could cause the lamp bulb to burst during use.

• If the indicators or a message prompts you to replace the lamp (see the section “Related Messages” and “Regarding the indicator Lamps”), replace the lamp as soon as possible. Using the lamp for long periods of time, or past the replacement date, could cause it to burst. Do not use old (used) lamps; this is a cause of breakage.

for X70 / 78-

Lamp (continued)

Replacing The Lamp

If the indicators or a message prompts you to replace the lamp, replace the lamp as soon as possible.

Turn off the projector, and unplug the power cord. Allow the lamp bulb to cool for at

least 45 minutes.

Contact your dealer to prepare a new lamp. Tell the dealer your lamp type number.

If the projector is mounted on the ceiling, or if the lamp has broken, also ask the dealer to replace the lamp.

In the case of replacement by yourself,

After making sure that the projector has cooled

adequately, slide the knob of a lamp door lock as shown in the Figure. Then, one side of the lamp door is raised. Pull up the lamp door and remove it, as shown in the Figure.

Lamp door knob

Lamp door

Unscrew the 3 screws, and slowly pull out the lamp

by the handle. Be careful not to touch the inside of the lamp case.

Insert the new lamp, and tighten the 3 screws firmly

to lock it in place.

Interlocking the 2 tabs of the lamp door to the

projector, put the lamp door on the projector. Then push the point of the lamp door to fix it, as shown in the Figure. Make sure that the lamp door doesn’t come up.

NOTE

sure that the screws are screwed in firmly. Loose screws could result in damage or injury.

•

Do not use the projector with the lamp door removed. At the lamp replacing, make

Turn on the projector, and reset the lamp timer. (1) While the projector running, press the MENU button to open the menu. (2) Choose the “OPTION” on the menu using the

button or ENTER button.

(3) Choose the “LAMP TIME” using the

RESET button for 3 seconds.

(4) Choose the “RESET” using the button.

Screws

CO LAMP

Tabs

button, then press the

button, then press and hold the

memo When the lamp has been replaced after the message of "THE POWER WILL

TURN OFF AFTER 0hr." is displayed, complete this operation within 10 minutes of switching power on.

memo Incorrectly resetting of the lamp timer (resetting without replacement, or

neglect of resetting after replacement) will result in incorrect message functions.

Air Filter

WARNING • Please carefully read the “Product Safety Guide.

• Before caring, make sure the power switch is off and the power cable is not

plugged in, then wait at least 45 minutes for the lamp to cool sufficiently.

• Use only the air filter of the specified type 78-8118-9187-4.

• Do not use the projector with the air filter and filter cover removed. The use without

the air filter could result in damage.

CAUTION

temperature rises and could cause malfunction. The power is automatically turned

off in order to prevent the projector from overheating internally.

• If the air filter becomes clogged by dust or the like, internal

Caring For The Air Filter

The air filter should be cleaned about every 100 hours. If the indicators or a message prompts you to clean the air filter, clean the air filter as soon as possible. If the soiling will not come off the air filter, or it becomes damaged, then it needs to be replaced. Please replace the air filter as soon as possible.

memo When you replace the lamp, please replace also the air filter.

Turn off the projector, and unplug the power cord. Allow the lamp bulb to cool for at

least 45 minutes.

After making sure that the projector has cooled adequately, remove the filter cover

and air filter.

Apply a vacuum cleaner to the top of the filter cover and

the air filter to clean. If the soiling will not come off the air filter, or it becomes damaged, it needs to be replaced. If the air filter needs to be replaced, contact your dealer to prepare a new air filter. Tell the dealer your air filter type.

Insert the cleaned air filter or a new air filter, and replace

the filter cover.

Turn on the projector power, and reset the filter timer.

(1) While the projector running, press the MENU button to

open the menu.

(2) Choose the “OPTION” on the menu using the

button, then press the button or ENTER button.

(3) Choose the “FILTER TIME” using the

press and hold the RESET button for 3 seconds.

(4) Choose the “RESET” using the button.

button, then

Hold the release button

Hold the release buttons of the filter cover while pulling

of the air filter while

pulling out it.

down it.

memo Incorrectly resetting of the filter timer (resetting

without replacement, or neglect of resetting after replacement) will result in incorrect message functions.

Other Care

WARNING • Please carefully read the “Product Safety Guide”.

• Before caring, make sure the power switch is off and the power cable is not

plugged in.

• Be cautious of high temperature. Do not touch about the lens and ventilation openings during use or immediately after use prevent a burn.

• Never try to care for the inside of the unit yourself. Doing so is dangerous.

• Do not use cleaner or chemicals other than those listed below, including benzene and

paint thinner.

• Do not use aerosols or sprays.

CAUTION

peeling paint, etc.

• Incorrect care could have adverse influence such as discoloration,

NOTE

• Do not polish or wipe with hard objects.

Caring For The Inside Of The Projector

In order to ensure the safe use of your projector, please have it cleaned and inspected by your local dealer about once every 2 years.

Caring For The Lens

Turn off the projector, and unplug the power cord.

Lightly wipe the lens with a commercially available lens-cleaning wipe. Do not touch

the lens directly with your hand.

Caring For The Cabinet And Remote Control

Turn off the projector, and unplug the power cord.

Wipe lightly with gauze or a soft cloth.

memo If soiling is severe, dip soft cloth in water or a neutral cleaner dilute in water,

and wipe lightly after wringing well. Then, wipe lightly with a soft, dry cloth.

roubleshooting

TTroubleshooting

Related Messages

When the unit's power is on, messages such as those shown below may be displayed. When any such message is displayed on the screen, please respond as described below. If the same message is displayed after the treatment, or if a message other than the following appears, please contact your dealer or service company.

memo Although these messages will be automatically disappeared around several

minutes, it will be reappeared every time the power is turned on.

Message Description

CHANGE THE LAMP

AFTER REPLACING LAMP,

RESET THE LAMP TIMER.

CHANGE THE LAMP

AFTER REPLACING LAMP,

RESET THE LAMP TIMER.

THE POWER WILL TURN OFF

AFTER ** hr.

CHANGE THE LAMP

AFTER REPLACING LAMP,

RESET THE LAMP TIMER.

THE POWER WILL TURN OFF

AFTER 0 hr.

The time the lamp timer has counted is approaching 2000 hours.

Preparation of a new lamp, and an early lamp change is recommended. After you have change the lamp, please be sure to reset the lamp timer.

The time the lamp timer has counted is approaching 2000 hours, so a lamp change within ** hours is recommended.

When lamp usage reaches 2000 hours, the power will automatically be turned off. Please change the lamp by referring to the section “Lamp”. After you have changed the lamp, please be sure to reset the lamp timer.

As the time the lamp timer has counted has reached 2000 hours, the power will soon be automatically turned off.

Please immediately turn the power off, and change the lamp by referring to the section “Lamp”. After changing the lamp, please be sure to reset the lamp timer.

(This table is continued to the following page.)

NOTE

• A lamp has a finite product life. Lamps are characterized by the fact that, after long hours of usage, a lamp will no longer light up, or the lamp will break or burst, etc. This projector is equipped with an automatic shut-down function, such that the power will automatically be turned off when lamp usage time has reached 2000 hours. Please be aware, however, that among lamp types, there are major differences in product lifetimes; a lamp may thus fail to light even prior to the functioning of the automatic shut-down function of this projector.

roubleshooting (continued)

TTroubleshooting (continued)

Related Messages

Message Description

CLEAN THE AIR FILTER

POWER OFF FIRST,

THEN CLEAN THE AIR FILTER.

AFTER CLEANING THE AIR

FILTER,

RESET THE FILTER TIMER.

CHECK THE AIR FLOW

NO INPUT IS DETECTED

ON ***

(continued)

The time the filter timer has counted has reached 100 hours.

Please clean or change the air filter by referring to the section “Air Filter”. After caring for the air filter, please be sure to reset the filter timer.

The internal portion temperature is rising.

Please turn the power OFF, and allow the unit to cool down at least 20 minutes. After the projector has sufficiently cooled down, please make confirmation of the following items, and then turn the power on again.

• Is there blockage of the air passage aperture?

• Is the air filter dirty?

• Does the peripheral temperature exceed 35°C?

There is no input signal.

Please confirm the signal input connection, and the status of the signal source.

SYNC IS OUT OF RANGE

ON *** fH *****kHz fV *****Hz

The horizontal or vertical wavelength of the inputted signal is outside of the response parameters of this unit.

Please confirm the specs for this unit or the signal source specs.

roubleshooting (continued)

TTroubleshooting (continued)

Regarding The Indicator Lamps

Lighting and flashing of the standby/on indicator, the lamp indicator, and the temp indicator have the meanings as described in the table below. Please respond in accordance with the instructions within the table. If the same indication is displayed after the treatment, or if an indication other than the following is displayed, please contact your dealer or service company.

NOTE

•

When the interior portion has become overheated, for safety purposes, the power source is automatically turned off, and the indicator lamps may also be turned off. In such a case, press the “○” (OFF) side of the main power switch, and wait at least 45 minutes. After the projector has sufficiently cooled down, please make confirmation of the attachment state of the lamp and lamp door, and then turn the power on again.

standby/on

indicator

Lighting

in Orange

Blinking

in Green

Lighting

in Green

Blinking

in Orange

lamp

indicator

Turned

off

Turned

off

Turned

off

Turned

off

temp

indicator

Turned

off

Turned

off

Turned

off

Turned

off

Description

The projector is in a standby state.

Please refer to the section “Power On/Off”.

The projector is warming up.

Please wait.

The projector is in an on state.

Ordinary operations may be performed.

The projector is cooling down.

Please wait.

The projector is cooling down. A certain error has

Blinking

in Red

(discre-

tionary)

(discre-

tionary)

been detected.

Please wait until the STANDBY/ON indicator finishes blink, and then perform the proper response measure using the item descriptions below as reference.

The lamp does not light, and there is a possibility that interior portion has become heated.

Please turn the power off, and allow the unit to cool down at least 20 minutes. After the projector has sufficiently cooled

Lighting

in Red

Lighting

in Red

Turned

off

down, please make confirmation of the following items, and then turn the power on again.

• Is there blockage of the air passage aperture?

• Is the air filter dirty?

• Does the peripheral temperature exceed 35°C?

If the same indication is displayed after the treatment, please change the lamp by referring to the section “Lamp”.

(This table is continued to the following page.)

roubleshooting (continued)

TTroubleshooting (continued)

Regarding The Indicator Lamps

standby/on

indicator

Lighting

in Red

Lighting

in Red

lamp

indicator

Blinking

in Red

Turned

off

temp

indicator

Turned

off

Blinking

in Red

Either there is no lamp and/or lamp door, or either of these has not been properly fixed.

Please turn the power off, and allow the unit to cool down at least 45 minutes. After the projector has sufficiently cooled down, please make confirmation of the attachment state of the lamp and lamp door, and then turn the power on again. If the same indication is displayed after the treatment, please contact your dealer or service company.

The cooling fan is not operating.

Please turn the power off, and allow the unit to cool down at least 20 minutes. After the projector has sufficiently cooled down, please make confirmation that no foreign matter has become caught in the fan, etc., and then turn the power on again. If the same indication is displayed after the treatment, please contact your dealer or service company.

(continued)

Description

Lighting

in Red

Lighting

in Green

Lighting

in Green

Turned

off

Alternative

Blinking in Red

Simultaneous

Blinking in Red

Lighting

in Red

There is a possibility that the interior portion has become heated.

Please turn the power off, and allow the unit to cool down at least 20 minutes. After the projector has sufficiently cooled down, please make confirmation of the following items, and then turn the power on again.

• Is there blockage of the air passage aperture?

• Is the air filter dirty?

• Does the peripheral temperature exceed 35°C?

If the same indication is displayed after the treatment, please contact your dealer or service company.

There is a possibility that the interior portion has become overcooled.

Please use the unit within the usage temperature parameters (0°C to 35°C). After the treatment, resent the power to ON.

It is time to clean the air filter, or there is no air filter.

Please immediately turn the power OFF, and clean or change the air filter by referring to the section “Air Filter”. After cleaning or changed the lamp, please be sure to reset the filter timer. After the treatment, resent the power to ON.

roubleshooting (continued)

TTroubleshooting (continued)

Phenomena That May Easily Be Mistaken For Machine Defects

WARNING • Never use the projector if abnormal operations such as smoke,

strange odor, excessive sound, damaged casing or elements or cables, penetration of liquids or foreign matter, etc. should occur. In such cases, immediately turn off the power switch and then disconnect the power plug from the power outlet After making sure that the smoke or odor has stopped, contact your dealer or service company.

Before requesting repair, please check in accordance with the following chart. If the situation cannot be corrected, please contact your dealer or service company.

NOTE

• Although bright spots or dark spots may appear on the screen, this is a unique characteristic of liquid crystal displays, and do not constitute or imply a machine defect.

Phenomenon Cases not involving a machine defect

The electrical power cord is not plugged in.

Correctly connect the power cord.

The power switch is not set to the on position.

Set the power switch to [ | ] (On).

The main power source has been interrupted during operation such as by a power outage (blackout), etc.

Power does not come on.

Please turn the power off, and allow the unit to cool down at least 20 minutes. After the projector has sufficiently cooled down, please turn the power on again.

Either there is no lamp and/or lamp door, or either of these has not been properly fixed.

Reference

pages

35, 36

The signal cables are not correctly connected.

Correctly connect the connection cables.

Neither sounds nor pictures are outputted.

Signal source does not correctly work.

Correctly set up the signal source device by referring to the manual of the source device.

The input changeover settings are mismatched.

Select the input signal, and correct the settings.

8, 9

(This table is continued to the following page.)

roubleshooting (continued)

TTroubleshooting (continued)

Phenomena That May Easily Be Mistaken For Machine Defects

Phenomenon Cases not involving a machine defect

The signal cables are not correctly connected.

Correctly connect the connection cables.

Pictures are displayed, but no sounds are heard.

Sounds are heard, but no pictures are displayed.

The volume is adjusted to an extremely low level.

Adjust the VOLUME to a higher level.

The sound is muted.

Press the MUTE button to restore the sound.

The audio input is not correctly selected when the child window is displayed.

Correctly select the audio input.

The lens cap is attached.

Remove the lens cap.

The signal cables are not correctly connected.

Correctly connect the connection cables.

The brightness is adjusted to an extremely low level.

Adjust the BRIGHT to a higher level using the menu function.

The screen is blanked.

Press the BLANK button to return to the input signal screen.

(continued)

Reference

19, 32

pages

8, 9

4, 15

8, 9

Colors have a faded- out appearance, or Color tone is poor.

Pictures appear dark.

Pictures appear blurry.

Input signal changes with no operation.

Color settings are not correctly adjusted.

Perform picture adjustments by changing the COLOR BAL R, COLOR BAL G, COLOR BAL B, COLOR and/or TINT settings, using the menu functions.

The brightness and/or contrast are adjusted to an extremely low level.

Adjust the BRIGHT and/or CONTRAST settings to a higher level using the menu function.

The WHISPER function is working.

Select the NORMAL to the item WHISPER in the MAIN menu.

The lamp is approaching the end of its product lifetime.

Replace the lamp.

Either the focus and/or horizontal phase settings are not properly.

Adjust the focus using the focus buttons, and/or H PHASE using the menu function.

The lens is dirty or misty.

Clean the lens by referring to the section “Caring For The Lens”.

The INPUT dial is set between the click points.

Turn the INPUT dial and set it at a click point.

35, 36

Specifications

NOTE

• This specifications are subject to change without notice.

Item Specification

Product name Liquid crystal projector Liquid

crystal panel

Lens Zoom lens F=1.7 ~ 2.4 f=30.5 ~ 45.8 mm Lamp Speaker 1.0W + 1.0W (Stereo) Power supply

Power consumption Temperature range 0 ~ 35°C (Operating)

Size

Panel size 2.5 cm (0.99 type) Drive system TFT active matrix Pixels 786,432 pixels (1024 horizontal x 768 vertical)

X70:275W UHB X80:310W UHB

X70:AC100 ~ 120V, 4.7A / AC220 ~ 240V, 2.0A X80:AC100 ~ 120V, 5.2A / AC220 ~ 240V, 2.2A

X70:430W X80:470W

420 (W) x 150 (H) x 336 (D) mm (Not including protruding parts)

• Please refer to the figure of the section “TECHNICAL” of the end of this manual.

Weight (mass) 7.7 kg

RGB input ports

rgb M1-D BNC (R, G, B, H, V)

Video input ports

video in

Ports

S-video in component (C

R/PR, CB/PB, Y)

Audio input ports

audio in 1 audio in 2 audio in R/L

RGB output port

rgb out

Audio output port

audio out

Control port

control

Other ports

network remote control dc out

Accessories

Accessories ............................................................... Part Number

UHB Lamp, 275W (X70) ............................................................................. 78-6969-9718-4

UHB Lamp, 310W (X80) ............................................................................. 78-6969-9719-2

Air Filter ...................................................................................................... 78-8118-9187-4

Power Cord (US) ......................................................................................... 78-8118-8102-4

Power Cord (UK) ......................................................................................... 78-8118-8101-6

Power Cord (Europe) .................................................................................. 78-8118-8103-2

VGA Cable .................................................................................................. 78-8118-8708-8

RCA Video/Audio Cable .............................................................................. 78-8118-3234-0

M1-D Cable ................................................................................................. 78-8118-9276-5

Remote Control (X70)................................................................................... 78-8118-9274-0

Remote Control (X80)................................................................................... 78-8118-9275-7

Not Included with Basic Packet................................ Part Number

Ceiling Mount .............................................................................................. 78-6969-9697-0

Adjustable Height Suspension .................................................................... 78-6969-9699-6

Shipping Case ............................................................................................. 78-6969-8925-6

Soft rolling case ........................................................................................... 78-6969-8926-4

RCA Component Cable ............................................................................... 78-8118-8843-3

S-Video Cable ....................................................................................... ...... 78-8118-3238-1

Stereo Mini-Cable................................................................................. ....... 78-8118-8846-6

RS-232C Cable ..................................................................................... ...... 78-8118-9192-4

Ultra value warranty X70 (US only) ........................................................ ..... 78-6969-9708-5

Ultra value warranty X80 (US only) ............................................................ . 78-6969-9709-3

Mac Adapter ................................................................................................ 78-8118-3308-2

How to Order

Please order these parts through your dealer, or contact 3M Customer Service at the following number:

In U.S. or Canada : 1-800-328-1371 In other locations, contact your local 3M sales office.

Intended Use

Before operating this machine, please read this entire manual thoroughly. The 3M using 3M lamps, 3M ceiling mount hardware, and nominal local voltages. The use of other replacement lamps, outdoor operation, or different voltages has not been tested and could damage the projector peripheral equipment and/or create a potentially unsafe operating condition. 3M Multimedia projectors and Wall Display Systems are designed to operate in a normal office environment.

• 16˚ to 29˚C (60˚ to 85˚ F)

• 10- 80 %RH (without condensation)

• 0- 1828 m (0-6000 feet) above sea level The ambient operating environment should be free of airborne smoke, grease, oil and other contaminates that can affect the operation or performance of the projector. Use of this product in adverse conditions will void the product warranty.

Let us help you make the most of your next presentation. We offer everything from presentation supplies to tips for better meetings. And we're the only transparency manufacturer that offers a recycling program for your used transparencies. For late-breaking news, handy reference and free product samples, call us toll-free in the continental United States and Canada, 24 hours a day, or visit our Internet Website.

TM Multimedia Projectors are designed, built, and tested for use indoors,

3M Austin Center

Building A145-5N-01 6801 River Place Blvd. Austin, TX 78726-9000

3M Canada

P.O. Box 5757 London, Ontario N6A 4T1

DN00591 (X70/X80_OG_ENG)

3M Mexico, S.A. de C.V.

Apartado Postal 14-139 Mexico, D.F. 07000 Mexico

3M Europe

Boulevard de l'Oise 95006 Cerge Pontoise Cedex France

Litho in Japan

78-6970-9368-6 Rev. A

3M X70, X80 Operator Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Operator's Guide

Projector Features

Setting Up

Arrangement

Remote Control

Selecting An Input Signal

Selecting The Aspect Ratio

Adjusting The Picture Position

Adjusting The Volume

Freezing The Screen

Selecting An Audio Input

MAIN Menu

PICTURE-1 Menu

PICTURE-2 Menu

INPUT Menu

AUTO Menu

SCREEN Menu

OPTION Menu

NETWORK Menu

Lamp

Air Filter

Specifications

Accessories

Intended Use
