•Feature-rich devices with wirespeed, non-blocking performance
•Advanced features, such as support for traffic prioritization are ideal for larger networks, running real-time applications
•Easy installation, with plug-and-play design
3Com® Baseline Switches
DATA SHEET
Key Benefits
Wide-Ranging Unmanaged Family
Small to mid-sized businesses looking for a switched LAN with or without high-speed uplinks, or a low cost, high-performance Gigabit network, will find an affordable solution with the family of 3Com® Baseline switches, designed for plug-and-play network operation.
10/100 Switching with Legacy Support
3Com Baseline Switch 2016 and 2024 are ideal for businesses with legacy Ethernet desktops that want to start a network. Fast Ethernet (100 Mbps) support easily handles higher speed desktop and office server connections.
High-Performance 10/100/1000 Switching
For top performance, the 3Com Baseline Switch 2808, 2816 and 2824 deliver wirespeed Gigabit throughput and a switching capacity of up to 48 Gbps to handle the most bandwidth-hungry applications.
Plug-and-Play Unmanaged Operation
3Com Baseline switches operate straight out of the box, with no configuration required. Auto MDI/MDIX ports identify and adapt to the Ethernet cable type, eliminating the most common cabling errors and simplifying installation. Autosensing ports detect and adjust to the speed of the connected device to optimize network performance.
Rack-Mounted or Free-Standing Configuration
Small-business configurations can vary, so the switches are designed to operate as a free-standing or rack-mounted switch with included mounting kit. The standard 19-inch, one rack-unit-high (1 RU) enclosure optimizes valuable office space.
Warranty
Limited Lifetime Hardware Replacement. See www.3com.com/warranty for more detail.
1
3COM® BASELINE SWITCHES DATA SHEET
3Com Baseline Switches at a Glance
|
3COM BASELINE |
3COM BASELINE |
3COM BASELINE |
3COM BASELINE |
3COM BASELINE |
3COM BASELINE |
|
SWITCH 2016 |
SWITCH 2024 |
SWITCH 2126-G |
SWITCH 2808 |
SWITCH 2816 |
SWITCH 2824 |
|
3C16470 |
3C16471 |
3C16472 |
3C16477A |
3C16478 |
3C16479 |
|
|
|
|
|
|
|
Ports - Autosensing |
16 10/100 |
24 10/100 |
24 10/100 and |
8 10/100/1000 |
16 10/100/1000 |
24 10/100/1000 |
|
Ethernet |
Ethernet |
2 10/100/1000 |
Ethernet |
Ethernet |
Ethernet |
|
|
|
Ethernet |
|
|
|
|
|
|
|
|
|
|
LED Indicators |
Power, Network |
Power, Network |
Power, Network |
Power, Network |
Power, Network |
Power, Network |
|
traffic/Duplex |
traffic/Duplex |
traffic/Duplex |
traffic/Duplex |
traffic/Duplex |
traffic/Duplex |
|
mode, Link |
mode, Link |
mode, Link |
mode, Link |
mode, Link |
mode, Link |
|
status/Speed |
status/Speed |
status/Speed |
status/Speed |
status/Speed |
status/Speed |
|
|
|
|
|
|
|
802.1p Traffic |
N/A |
N/A |
N/A |
4 queues on |
4 queues on |
4 queues on |
Prioritization |
|
|
|
every port |
every port |
every port |
(Priority Queuing) |
|
|
|
|
|
|
|
|
|
|
|
|
|
MAC Addresses |
4,000 |
4,000 |
4,000 |
8,000 |
32,000 |
32,000 |
|
|
|
|
|
|
|
MDI/MDIX - |
|
|
|
|
|
|
Automatic |
|
|
|
|
|
|
configuration |
|
|
|
|
|
|
on all ports |
|
|
|
|
|
|
|
|
|
|
|
|
|
Forwarding |
Store & Forward |
Store & Forward |
Store & Forward |
Store & Forward |
Store & Forward |
Store & Forward |
Method |
|
|
|
|
|
|
|
|
|
|
|
|
|
Features and Benefits
|
Description |
|
|
POWERFUL, ADVANCED SWITCHING |
|
Gigabit performance (3C16472, 3C16477A, |
Connect to servers and desktops running at 10, 100, or 1000 Mbps. 48 Gbps switching capacity supports |
3C16478, 3C16479) |
highest speed servers and desktops without additional network investment. |
Non-blocking performance |
Baseline switches operate at full wirespeed on all ports, delivering unimpeded access to |
|
networked resources. |
Cost-effective 10/100/1000 connections |
Range of port densities provides expansion for growing small businesses at a very affordable price per port. |
SIMPLE INSTALLATION AND USE |
|
Auto MDI/MDIX ports |
Simplify installation by eliminating common cabling errors, automatically detecting the type of Ethernet |
|
cable used—straight-through or crossover. |
Pre-configured setup |
Makes sure that switches work "right out of the box" with no configuration or management |
|
software needed. |
Easy-to-read front panel LEDs |
Give at-a-glance status and network information to simplify diagnostics and troubleshooting. |
Consistent form factor |
Clean design, standard 1RU enclosure optimizes rack space. |
RELIABLE |
|
Sturdy, dependable design |
3Com delivers premium-quality, reliable networking products that stay up and running year after year. |
Complete support package |
Limited Lifetime Hardware Replacement provides peace of mind. |
|
|
