ZyXEL Communications P660HNUT1V2 User Manual
P-660HN(U)-Tx v2
802.11n2x2 WirelessADSL2+4-port
QuickStart
Guide
Gateway
Version3.10
7/2012
Edition2
1
P-660HN(U)-Tx
Overview
TheP-660HN(U)-Tx v2isawirelessADSLrouterwithafour-portbuilt-inswitch.
T
hisQuickStartGuideshowsyouhowtousetheP-660HN(U)-Tx v2to
connecttotheInternetandhowto configurethedevice
settingstoconnectwirelesslyy.
SeeyourUser’sGuideforbackgroundinformationonallfeatures.
Quick Login Information
LANIPaddress http://192.168.1.254
defaultadministratorpassword Check back label for the info
2
P-660HN(U)-Tx
If you want to mount this product onto the wall, please follow below
step.
Step 1: use screws (Dimension:4.0mm) fix bracket into the wall
Step 2: put equipment mount on bracket
3
P-660HN(U)-Tx
Note: The device is designed to allow both vertical and wall
mounted usage.
Hardware
Connections
1DSL:UsethegraytelephonewiretoconnectyourP-660HN(U)-Tx
v2DSLporttoatelephonejack(or to
themodemportonasplitterifyouareusingone).
2ETHERNET:UsetheyellowEthernetcabletoconnectacomputertoanETHERN
ETportfor initialconfigurationand/orInternetaccess.
3POWER:Usetheincludedpoweradaptortoconnectanappropriatepowersourc
etothePOWERsocket. Makesurethepowersourceison.
4Pushin thePOWERbutton.
5Look atthe lightsonthe frontpanel.
• ThePOWERlightblinkswhileyourP-660HN(U)-Tx v2startsupandstays
ononceitisready.
• EachETHERNETlightstaysonifthe
correspondingETHERNETportisproperlyconnectedandblinks
whenthereistraffic.
• TheDSLlightisonwhenthe P-660HN(U)-Tx v2hasaDSLconnection.
•
TheINTERNETlightisonwhenyouareabletoaccesstheInternetandblinkswhe
ntheP-660HN(U)-Tx v2
Issendingorreceivingdata.
W
aita couple
4
P-660HN(U)-Tx
ofminuteswhileyourdevicecheckstheconnection.
Ifanyoftheselightsarenoton,checkyourconnectionsandinspectyourcablesfo
rdamage.Ifthe lights are stilloff,contactyourlocalvendor.
2
InternetConnection
Setup:Automatic
Usethissectionto haveyourP-660HN(U)-Tx
v2automaticallydetectandsetupyourInternetconnection.
1Openyourwebbrowserto awebsite.WaitwhileyourP-660HN(U)-Tx
v2triestodetectyourDSLconnectiontoyourISP.Thismaytakea fewminutes.
2Afteritdetectstheconnection,theDSLlightshowsgreenonyourdeviceandthe
Internetlightcomeson when theInternetisreadyforyouto use.If
youhaveaPPPoEconnection,youwillhavetoenteryourusernameandpasswo
rd.
3Gotosection3ifyouwishtoconfigureyourwirelesssettings.
4 If you do not see the connection test screen, or the connection test is not
successful, follow the
instructionsinthescreenbelow,orcheckyourconnectionsandrestarttheP-
660HN(U)-Tx v2.Ifyoustillcannot accessthe
Internet,followthestepsinsection3.
ConfiguringyourWireless
3
Settings
5
P-660HN(U)-Tx
Tocreateawirelessnetwork,theP-660HN(U)-Tx
v2andyourwirelesscomputermustalluse thesameSSID
(networkname),channelandsecuritysettings.
IfyoudonotsetwirelesssecuritythenanyonewithinrangecoulduseyourP-
660HN(U)-Tx v2to accessyour networkandtheInternet.
ChooseWPA-PSKwirelesssecurity ifyourwirelessdevicesupportsitasitis
strongerthanWEP.Otherwise chooseWEP.
1SelectActiveandclickNexttocontinue.It is
stronglyrecommendedthatEnableOTISTisNOTselected.
Seesection7formoreinformation.
2 C o n f i gu r e yourwirelesssettingsinthescreen.ClickNext.
3Ifyou selecteitherWEPorWPA-PSKsecurity(recommended),thenfollowthe
directionstoenter theappropriatekey.ClickNexttocontinueandApplyto
saveyourwirelessLANsettings.
4CheckyourconfigurationandwritedownyourwirelessLANsettingsforlateruse.
ClickFinishtocompleteand savethe wizardsetup.
5YourInternetisreadyforyouto
use.Openyourbrowserandnavigatetoyourfavoritewebsite.
6
