ZTE Lisbon (Orange), X670 (Orange) User Guide

Lisbon from Orange

the user guide

No part of this publication may be quoted, reproduced, translated or used in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation.

The Bluetooth

trademark and logos are owned by the Bluetooth SIG, Inc. and any use of such trademarks by ZTE Corporation is under license. Other trademarks and trade names are the property of their respective owners.

ZTE Corporation reserves the right to make modifications on print errors or update specifications in this manual without prior notice.

Version 1.0/April 2010

Contents

let’s get started................................................................................................................................1

lost or stolen?...............................................................................................................................1

using your phone safely.......................................................................................................2

battery care and safety........................................................................................................5

charger care and safety.......................................................................................................6

getting to know your phone ..........................................................................................................8

inserting and removing the SIM ..................................................................................................11

inserting and removing a memory card ......................................................................................12

using the battery ........................................................................................................................13

inserting the battery ..........................................................................................................13

removing the battery .........................................................................................................13

charging the battery ..........................................................................................................14

power on/off...............................................................................................................................14

using your phone ...........................................................................................................................16

descriptions of common functions ...............................................................................................17

making and receiving calls .........................................................................................................17

making a call ....................................................................................................................17

receiving a call..................................................................................................................18

adjusting the volume.........................................................................................................18

hands-free........................................................................................................................ 18

call options .......................................................................................................................18

sending messages............................................................................................................18

viewing messages .....................................................................................................................19

adding a new contact................................................................................................................. 20

using your phone as memory .....................................................................................................20

main function list ..........................................................................................................................21

input what you want, how you want… ........................................................................................27

appendix ........................................................................................................................................28

care and maintenance................................................................................................................28

health and safety .......................................................................................................................29

declaration of RoHS compliance................................................................................................. 31

disposal of your old phone .........................................................................................................32

EC Declaration of Conformity...................................................................................................... 33

limited warranty statement ........................................................................................................35

problems and their solutions ......................................................................................................39

let’s get started

Thanks for choosing the Lisbon from Orange. It’s a GSM dual band GPRS digital mobile phone, which we’ll simply call ‘phone’ from now on.

If you’d like your phone to live a long and fruitful life, please read this guide carefully and keep it for future reference. You never know when you might need it.

And don’t worry if the pictures we use to demonstrate your phone’s functions look a little different from what you see on its screen. It’s the functions they show that matter.

lost or stolen?

If your phone goes missing, please tell Orange as soon as you know. That way other people can be barred from using it.

Obviously, it’s best to keep your phone with you at all times, and we’d strongly advise you to set a PIN, and change it from time to time.

using your phone safely

on the road

z Using a phone while driving is illegal in many countries. Please follow local laws and

drive safely at all times.

near sensitive electronics

z Don’t use your phone near sensitive electronic equipment – particularly medical

devices such as pacemakers – as it could cause them to malfunction. It can also interfere with the operation of fire detectors and other automatic-control equipment.

z For more information about how your phone affects pacemakers or other electronic

equipment, please contact the manufacturer or your local distributor.

z Your phone may cause interference when used near TVs, radios or automated office

equipment.

while flying

z Your phone can cause interference with aircraft equipment. So it’s essential you

follow airline regulations. And if airline personnel ask you to switch off your phone, or disable its wireless functions, please do as they say.

in hospital

z Your phone may interfere with the normal operation of medical equipment. Follow all

hospital regulations and turn it off when you’re asked to by posted warnings or medical staff.

at a petrol station

z Don’t use your phone at petrol stations. In fact, it’s always best to switch off

whenever you’re near fuels, chemicals or explosives.

around water

z Keep your phone away from water (or any other liquid). It’s not a waterproof model.

making repairs

z Never take your phone apart. Please leave that to the professionals. Unauthorised

repairs could break the terms of your warranty.

broken antenna

z Don’t use your phone if the antenna is damaged, as it could cause injury.

around children

z Keep your mobile out of children’s reach. It should never be used as a toy and it

might not be good for their health.

original accessories

z Only use the original accessories supplied with your phone or those approved by the

manufacturer. Using unapproved accessories may affect performance, make the warranty void, break national regulations on the use of mobile phones, or even cause injury.

near explosives

z Turn off your phone in or near areas where explosive materials are used. Always

obey local laws and turn off your phone when requested.

emergency calls

z To make an emergency call your phone must be turned on and in an area where

there’s network coverage. Dial the national emergency number (in the UK: 999) and press ‘send’. Explain exactly where you are and don’t hang up until help has arrived.

battery care and safety

z Keep the battery in a cool, ventilated place and out of direct sunlight.

z Although the battery is rechargeable, it’ll eventually start to lose its ability to recharge.

If you find that the battery won’t recharge, it’s time to replace it.

z Please don’t throw old batteries into your household rubbish. You’ll find there are

special bins for batteries at refuse collection points. And some high street electrical stores provide a battery recycling service too.

z Never throw the battery into a fire – it’s highly inflammable and could explode,

hurting you or somebody else.

z When you put the battery into your phone, there’s no need to use force. Exerting too

much pressure could make it leak, overheat, explode or burst into flame.

z Never take the battery apart. This may result in leakage, overheating, explosion or

fire.

z If the battery becomes hot, changes colour or shape at any time (when in use,

charging or even while in storage) please stop using it immediately and replace.

z Keep the battery dry. Damp or wet conditions can cause it to overheat or corrode.

z Don’t leave the battery in direct sunlight or anywhere really hot, like in a car on a

summer’s day. That could make it leak or overheat, while lowering its performance and shortening its life.

z Don’t charge the battery continuously for 24 hours. Overcharging is not good for it.

Note:

Please avoid contact with the materials inside a damaged or leaking battery. If they get on your skin, wash with lots of water and seek medical assistance if required.

charger care and safety

z Only plug into voltages between 110VAC and 220VAC. Using a voltage outside that

range can damage the phone/charger – and cause the battery to leak or catch fire.

z Never short-circuit the charger – this may cause electrocution, overheating or

damage.

z Don’t charge the phone in direct sunlight or in an area where it’s damp, dusty, or on a

vibrating surface. And charging your phone near – or on – a TV or radio could interfere with transmission.

z Don’t use the charger if the power cable is damaged. It may cause a fire or give

someone an electric shock.

z Keep water well away from the charger. If the charger does get splashed by water, or

any other kind of liquid, immediately unplug it to avoid overheating, fire or electrocution.

z Don’t take the charger apart. It could cause injury, give you an electric shock or catch

fire.

z Never touch any charger, electric cable or socket with wet hands.

z Don’t place heavy objects on the electric cable.

z If the cable is damaged, don’t try to mend it yourself – it could cause a fire or

electrocute you.

z Always unplug the charger before you clean it.

z When unplugging the charger, hold the plug itself, rather than pulling on the cable. A

damaged cable can cause electrocution or fire.

getting to know your phone

Press to make or receive a call. In idle mode, press to view all recent calls.

Receiver

Display

Microphone

Send key

USB port

Navigation key /OK key

In idle mode: Up/down to scroll through shortcuts. Go left for Write message. Go right for Contacts. Press straight down to choose/OK shortcut.

Power Key

Press to hang up or reject an incoming call. Hold to power on/off. In idle mode, press to turn off background music. In other modes, press to return to idle mode.

Speaker

note:

In this user guide, ‘press’ means pressing the key and then releasing. ‘Hold’ means pressing and holding the key for two seconds or more.

Camera

Side keys

Adjust the volume
