ZTE X175
CDMA 1X Digital Mobile Phone
User Manual
Copyright © 2007 by ZTE Corporation
All rights reserved.
No part of this publication may be excerpted, reproduced,
translated or utilized in any form or by any means, electronic or
mechanical, including photocopying and microfilm, without the prior
written permission of ZTE Corporation.
The manual is published by ZTE Corporation. We reserve the right
to make modifications on print errors or update specifications without
prior notice.
Version No.: Release 1.0*
Edition Time: Oct. 2007
Manual No.: 056584500xxx
ZTE
Content
1 General Information....................................................... 2
1.1 W elcom e....................................................................................2
1.2 Security.....................................................................................2
1.3 Safety Warnings ..............................................................3
1.4 Limit Warranty..........................................................................8
1.5 Limitation of Liability...............................................................9
1.6 Declaration................................................................................9
2 Know Your Phone.......................................................... 10
2.1 Keypad....................................................................................10
2.2 Instruction of Interface Icon....................................................12
2.3 Technic al Parameters...............................................................13
2.4 Battery.....................................................................................13
2.4.1 Remove and Installation of Battery.................................14
2.4.2 Charging the Battery........................................................15
2.5 Connecting to the Network.....................................................16
2.5.1 UIM Card ........................................................................16
2.5.2 Insertion and Extraction of UIM Card.............................17
2.5.3 Power on/off Phone.........................................................18
2.5.4 PIN Code......................................................................... 18
i
ZTE
2.5.5 Connecting the Network..................................................18
3 Basic Operations............................................................ 20
3.1 Making a Call..........................................................................20
3.2 Answering a Call.....................................................................21
3.2.1 Headset Ringing..............................................................22
3.2.2 Headset Autoanwer..........................................................22
3.2.3 Setting any Key Answer..................................................22
3.2.4 Incoming Call Silence.....................................................23
3.3 In Conversation.......................................................................23
3.3.1 Silence in Conversation...................................................23
3.3.2 Adjusting V olum e in Conversation..................................23
3.3.3 Selecting Options in Conversation..................................23
3.4 Menu Functions ......................................................................24
4 Contacts.......................................................................... 26
4.1 Finding Records......................................................................26
4.2 Adding New Record................................................................28
4.3 Viewing Records.....................................................................30
4.4 Erasing Records......................................................................30
4.4.1 Erasing a Record..............................................................30
4.4.2 Erasing all Contacts.........................................................31
4.5 Editing Name of the Contacts.................................................31
4.6 Editing Phone Number............................................................31
ii
ZTE
4.7 Selecting Group ......................................................................32
4.8 Setting Number Type ..............................................................32
4.9 Setting Speed Dial...................................................................32
4.10 Viewing and Making Speed Dial...........................................33
4.11 Memory Status ......................................................................33
4.12 Copying all Contacts ............................................................. 34
5 Messages......................................................................... 35
5.1 Sending a New Message.........................................................35
5.2 Sending Messages...................................................................36
5.3 Receiving Incoming Call while Editing Message...................37
5.4 Reading Message....................................................................37
5.5 Viewing OutBox .....................................................................38
5.6 Erasing Messages....................................................................38
5.6.1 Erasing a Message...........................................................39
5.6.2 Erasing all Messages.......................................................39
5.7 R-UIM.....................................................................................40
5.8 Sending Preformatted Messages.............................................40
5.9 Reading Voice Mail.................................................................41
5.10 Message Settings...................................................................41
5.10.1 Changing Voice Mail Box Number................................41
5.10.2 Message Alert................................................................42
5.10.3 Automatically Erasing InBox ........................................42
6 Recent Calls................................................................... 44
iii
ZTE
6.1 Viewing Recent Calls..............................................................44
6.2 Erasing Recent Calls List........................................................ 45
7 Settings........................................................................... 46
7.1 Auto Key Guard......................................................................46
7.2 Supp.Services..........................................................................47
7.2.1 Call Waiting.....................................................................47
7.2.2 Call Forwarding...............................................................48
7.3 Sound......................................................................................49
7.3.1 Volume............................................................................. 49
7.3.2 Alert T ype........................................................................49
7.3.3 Ringer of Incoming Call..................................................50
7.3.4 Key Beep.........................................................................50
7.3.5 Key Tone Length.............................................................50
7.3.6 SMS Ringer.....................................................................50
7.3.7 ClockRinger Type............................................................51
7.4 Display....................................................................................51
7.4.1 Set Backlighting..............................................................51
7.4.2 Changing Banner.............................................................51
7.4.3 Selecting Language .........................................................52
7.4.4 Adjusting Contrast...........................................................52
7.4.5 Setting Menu Format.......................................................52
7.4.6 Setting Time Format........................................................52
7.4.7 Screensaver......................................................................53
iv
ZTE
7.5 Alert ........................................................................................53
7.6 Call Timers..............................................................................54
7.7 Security Settings .....................................................................54
7.7.1 Setting PIN Lock.............................................................55
7.7.2 Modifying PIN Code.......................................................55
7.7.3 Erasing All Recent Calls..................................................55
7.7.4 Erasing all Contacts.........................................................55
7.7.5 Restoring Factory Default...............................................56
7.8 Accessories..............................................................................56
7.8.1 Setting Headset Ring.......................................................56
7.8.2 Setting Headset Autoanswer............................................57
7.8.3 Any Key Answer..............................................................57
8 Extra............................................................................... 58
8.1 Games.....................................................................................58
8.1.1 BlackJack ........................................................................ 58
8.1.2 Video Poker.....................................................................58
8.2 Stopwatch................................................................................59
8.3 Alarm ......................................................................................59
8.4 Calendar.................................................................................. 60
8.5 Calculator................................................................................60
8.6 Voice Memo............................................................................61
8.6.1 Recording in Normal.......................................................61
8.6.2 Recording in Conversation..............................................62
v
ZTE
8.6.3 Recording with Incoming Call/Message..........................62
9 Text Input....................................................................... 64
9.1 Multitap Input.........................................................................65
9.2 Numbers Input ........................................................................ 65
9.3 eZiText Input...........................................................................66
9.4 Symbols Input.........................................................................66
10 Troubleshooting.............................................................67
vi
ZTE
Explanation for
Mobile Phone with/without RUIM Card
There are two types of ZTE CDMA Mobile phone, one need RUIM
card inserted and another does not need. Sections or functions in this
manual are for the phone with RUIM card. If your phone could be used
without RUIM card, please pay attention to the following items:
1. The phone can be used without the RUIM card.
2. Some functions are only available concerning with RUIM and
won't display, such as,
z The new contact can be saved only in Phone, not in RUIM.
z The new message can be saved only in Phone, not in RUIM.
z The message in Inbox can not be moved to RUIM.
z There is no PIN Lock function in Security Setting.
1
ZTE
1 General Information
1.1 Welcome
Thank you for choosing ZTE X175 CDMA 1X Digital Mobile Phone.
To guarantee the mobile phone always in its best condition, please
read this manual carefully and keep it for future use.
The pictures, symbols and contents in this manual are just for your
reference. They might not be completely identical with your phone.
Please subject to the real object. ZTE operates a policy of continuous
development and reserves the right to update and modify the technical
specifications in this document at any time without prior notice.
1.2 Security
If your mobile phone is lost or stolen, please report to your service
provider or agencies of banning the use of your lost UIM card and
phone, which will protect you from economic losses resulted from
unauthorized use.
You need to provide the phone’s ESN number labeled. You can
see ESN number after removing the battery. Please keep ESN
number for future use.
To prevent your mobile phone from illegal use, please take the
security measures as follows:
¾ Set PIN code of the UIM card.
2
ZTE
¾ Take it with you as you can.
1.3 Safety Warnings
To t he Ow ne r
Some electronic devices are susceptible to electromagnetic
interference sent by mobile phone if inadequately shielded, such
as electronic system of vehicles. Please consult the manufacturer
on the device before using the phone if necessary.
Operating of mobile phone may interfere with medical devices like
hearing aides and pacemakers. Please always keep the mobile
phone more than 20 centimeters away from such medical devices
when the phone is powered on.
The phone with internal antenna has been tested for compliance
with FCC RF Exposure (SAR) limits and is complied with FCC RF
exposure compliance requirements.
Do not carry the mobile phone in the breast pocket. Power the
mobile phone off if necessary. Consult a physician or the
manufacturer on the medical device before using the phone.
Be aware of the usage limitation when using a mobile phone at
places such as oil warehouses or chemical factories, where there
are explosive gases or explosive products being processed,
because even if your phone is in standby mode, it still transmits
radio frequency (RF) energy. Therefore, power off your phone if
required.
3
ZTE
Pay attention to traffic safety. Do not use your mobile phone while
driving. Park before making or answering a call.
Store the phone out of the reach of little children. The phone may
cause injury if used as a toy.
The phone complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) The phone may not cause harmful interference, and (2) the
phone must accept any interference received, including
interference that may cause undesired operation.
Mobile Phone
Please use original accessories or accessories that are
authorized by the manufacturer. Using any unauthorized
accessories may affect your mobile phone’s performance, and
violate related national regulations about telecom terminals, or
even endanger your body
If you want to clean your phone, please use clean fabric that is a
bit wet or anti-static. Do not use harsh chemical cleaning solvents
or strong detergents to clean it. Turn off your phone before you
clean it.
As your mobile phone can produce electromagnetic field, do not
place it near magnetic items such as computer disks.
Using the phone near electrical appliances such as TV, telephone,
radio and personal computer can cause interference, which
4
ZTE
affects the function of the phone.
Do not expose your mobile phone to direct sunlight or store it in
hot areas. High temperatures can shorten the life of electronic
devices.
Prevent liquid from leaking into your phone.
Do not drop, knock or harshly treat your phone. Rough handling
can break internal circuit boards.
Do not connect the phone with other unauthorized peripheral
equipments.
Do not attempt to disassemble the mobile phone and battery by
yourself. Non-expert handling of the devices may damage them.
Do not attempt to disassemble the mobile phone and battery by
yourself. Changes and modifications made to the phone without
the approval of manufacturer could void your authority to operate
this phone.
Do not charge the mobile phone without battery.
On occasion of emergent calling, keep your phone in status of
power on and in area of service. On the condition of standby,
press the key to enter emergency phone number, and then press
Send key
Battery Using
The battery and the phone are separately deposited in the
package and packed in well condition. Please make use of the battery
to make a phone call.
5
ZTE
carefully following the instructions.
Do not short-circuit the battery, as this can cause excessive heat
and fire.
Do not store battery in hot areas or dispose of it in a fire to avoid
explosion.
Never use any charger or battery damaged or worn out.
Return the wear-out battery to the provider or put it in the
appointed recycle place. Do not put it in familial rubbish.
Warning: If the battery is broken, keep away from content. If it
taints your skin, wash your skin with abundant fresh water and
ask doctor for help if necessary.
Safety and General Using in Vehicles
Before making or answering a call, you should pay attention to
the local laws about using wireless mobile phones and take them
into account in practical use.
Safety airbag, brake, speed control system and oil eject system
shouldn’t be affected by wireless transmitting. If you do meet
problems above, please contact your automobile provider.
Please power off your mobile phone when refueling your
automobile, and so do the place where duplex wireless
equipments are banned. Don’t put your phone together with
flammable or explosive items, as inner spark may cause fire.
Exposure to radio frequency energy
Radio wave exposure and Specific Absorption Rate (SAR) information
6
ZTE
The handset is designed to comply with safely,
requirements for exposure to radio waves. This
requirement is based on scientific guidelines that include
safety margins designed to assure the safety of all persons,
regardless of age and health.
The radio wave exposure guidelines employ a unit of
measurement known as the Specific Absorption Rate, or
SAR. Tests for SAR are conducted using a standardized
method with the phone transmitting at its highest certified
power level in all used frequency bands.
While there may be differences between the SAR levels of
various ZTE phone models, they are all designed to meet
the relevant guidelines for exposure to radio waves.
The SAR limit recommended is 1.6W/kg averaged over
one(1) gramme of tissue.
The highest SAR value for this model phone tested by
MORLAB for use at the head is 1.569 W/kg(1g)
The highest SAR value for this model phone tested by
MORLAB for use at the body is 0.255W/kg(1g)
SAR compliance f or body-worn operations is restricted to
belt-clips, holsters, or similar accessories that have no
metallic component in the assembly and which provide at
least 1.5 cm separation between the device, including its
antenna, and the users body
In Aircraft
Follow the restrictions in aircraft. Wireless devices can cause
interference in aircraft.
Please power off your mobile phone before taking off till landing. In
order to protect airplane’s communication system from
interference, it is never allowed to use mobile phone when it is in
7
ZTE
flight. Using mobile phone before the plane taking off should get
aircrew’s permission according to safety regulations.
1.4 Limit Warranty
The warranty does not apply to defects or errors in the product
caused by:
(a) Reasonable abrasion.
(b) Misuse including mishandling, physical damage, improper
installation, unauthorized disassembly of the product.
(c) Water or any other liquid damage.
(d) Any unauthorized repair or modification.
(e) Power surges, lightning damage, fire, flood or other events
outside ZTE’s reasonable control.
(f) Use of the product with any unauthorized third party
products such as generic chargers.
(g) Any other cause beyond the range of normal usage for
products.
End User shall have no right to reject, return, or receive a
refund for any product from ZTE under the above-mentioned
situations.
This warranty is end user’s sole remedy and ZTE’s sole liability
for defective or nonconforming items, and is in lieu of all other
warranties, expressed, implied or statutory, including but not
limited to the implied warranties of merchantability and fitness for a
8
ZTE
particular purpose, unless otherwise required under the mandatory
provisions of the law.
1.5 Limitation of Liability
ZTE shall not be liable for any loss of profits or indirect, special,
incidental or consequential damages resulting from or arising out of or
in connection with using this product, whether or not ZTE had been
advised, knew or should have known the possibility of such damages.
1.6 Declaration
We, ZTE Corporation, declared that the product is installed with
battery separately in the box.The FCC ID label is placed on the mobile
phone clearly visible to all persons at the time of purchase.
9
ZTE
2 Know Your Phone
2.1 Keypad
Earpiece
LCD screen
4-way scroll key
OK key
Send key
0~9 Number key
* key
Microphone
Key Tip Function Description
Make or answer a call.
Press Send key in standby mode to
Send key
enter All Recent Calls list.
Press Send key two times directly
to redial the last number.
10
Earphone
Clear key
End key
# key
Charger connector
ZTE
End an active call or reject a call.
End key
Clear key
OK key
Up/Down key
(Scroll key)
Power on/power off.
Exit from any interface to standby
mode.
Erase character(s) while editing.
Cancel operation, eixt to previous
pop-up window.
In standby mode, hold Clear key to
lock keypad.
Enter main menu in standby mode,
as shown on the screen.
Switch to options of submenu.
Confirm the character chosen while
character inputting.
Scroll the cursor up and down.
Used as selection key up and
down for keying in commands
and selecting options shown on
the display.
In standby mode, hold Up key to
set Silence All; Press Down key
to enter Messages menu.
Adjust volume in conversation.
Used as direction key in games.
11
ZTE
Scroll the cursor left and right.
Used as selection key to scroll
cursor left and right for keying in
Left/Right key
(Scroll key)
~
Note: To “press” the key in this manual means to press the key
and release it. To “hold” the key means to keep pressing the key for two
seconds or more.
0~9 Number
key
*key，#key Differs in different mode, option or
commands and selecting options
shown on the display.
In standby mode, press Left key
to enter Extra menu, press Right
key to view All Contacts.
Used as direction key in games.
Key in numbers or characters.
Make a speed Dial call.
function menu.
2.2 Instruction of Interface Icon
Icon Indication
Signal strength
Incoming call or calling
Keypad locked
Roaming
12
ZTE
New message
Vibration
Silence All
Alarm
Power indicator
2.3 Technical Parameters
Handset
Type ZTEX175
Dimensions (Width×Height×Thickness)
44 mm×101mm×13.4mm
Weight About 73g(Battery Included)
Battery
Continuous standby
time
Continuous talk time
Note: Please refer to the real phone for other relative parameters
of the battery and charger.
850mAh / Li-Ion
About 80h～160h (Subject to Network)
About 2h～4h (Subject to Network)
2.4 Battery
The attached Li-ion battery along with the phone can be used after
unpacking. For the first three times, please use up the power and
charge it fully for a new battery to perform well.
13
ZTE
2.4.1 Remove and Installation of Battery
Remove：(1) Press and push the back-cover of the phone down to
release and remove it off the phone. (2) Put finger on the top
finger grip, and then lift up the battery from the finger grip to
remove the battery.
Installation：(1) Replace the battery into the battery slot, to be
noted that the lower end of the battery firstly inserted. (2) Put
the back-cover of the phone flatly upon the body of phone. Direct
the back cover towards the locking catches on the both sides of
the phone and push the back-cover of the phone upward to lock
the cover into its place.
14
ZTE
2.4.2 Charging the Battery
Plug out rubber away (turn 180° as shown in the picture)from
the jack on the bottom of the handset and connect the lead from
the charger to the socket on the bottom of the phone. (Note:
The side with arrow should be upright while connecting).
Connect the charger to a standard AC socket.
Meanwhile, the charging indicator in up-right corner of the
display flops cyclically, indicating the charging is going. In
power-off mode while charging, the display only shows the
charge indicator. If the battery is completely flat in storage or
used up, it may take for a while before the charging indicator
appears on the display or any calls can be made.
When the charging indicator on the screen stops flopping, the
charging is completed. The charging takes usually up to 2～3
hours. In the process of charging, it is a normal phenomenon
that the battery, phone and charger get into hot accordingly.
After the completion of charging, disconnect the charger from
the phone and AC socket.
15
Loading...
