ZTE S213 User Guide

ZTE-G S213
Mobile Phone
User Manual
2
LEGAL INFORMATION
Copyright © 2012 ZTE CORPORATION.
All rights reserved.
The manual is published by ZTE Corporation. We reserve the right to make modifications on print errors or update specifications without prior notice.
Version No. : R1.0
Edition Time : 2012.02.07
Manual No. :
079584504183
3
Table of Contents
SECURITY .......................................................................................................5
LIMITATION OF LIABILITY .............................................................................14
KEY FUNCTIONS ............................................................................................15
LOCKING AND UNLOCKING THE KEYPAD ..................................................17
INTERFACE ICONS......................................................................................... 18
BATTERY.........................................................................................................18
INSERTING THE SIM CARD ...........................................................................20
INSERTING THE MEMORY CARD..................................................................22
CHARGING THE BATTERY ............................................................................23
POWERING YOUR PHONE ON/OFF ..............................................................25
WRITING TEXT................................................................................................25
HOW TO ADD PEOPLE TO THE PHONEBOOK.............................................27
HOW TO MAKE AND RECEIVE CALLS .........................................................28
HOW TO SEND MESSAGES...........................................................................29
HOW TO RECEIVE A MESSAGE ....................................................................30
4
HOW TO SET USER PROFILES .....................................................................31
HOW TO VIEW CALL HISTORY......................................................................31
HOW TO CONFIGURE CALL SETTINGS .......................................................32
HOW TO SET YOUR PHONE..........................................................................32
ORGANIZER....................................................................................................34
FILE MANAGER..............................................................................................35
HOW TO PLAY MUSIC ....................................................................................36
HOW TO LISTEN TO FM................................................................................. 36
HOW TO USE SERVICES ...............................................................................37
QUESTIONS & ANSWERS..............................................................................39
5
Security
To protect your mobile phone from illegal use, take the security measures as follows:
¾ Set PIN codes of the SIM card.
¾ Set handset password.
¾ Set call restrictions.
Safety Precautions
This section includes some important information on safe and efficient operation. Please read this information before using the phone.
Operational Precautions
Please use your phone properly. When making or receiving a call, please hold your phone as holding a wireline telephone. Make sure that the phone is at least one inch (about two point five centimeters) from your body when transmitting.
Do not touch the antenna when the phone is in use. Touching the
6
antenna area affects call quality and may cause the phone to operate at a higher power level than needed.
Some people may be susceptible to epileptic seizures or blackouts when exposed to flashing lights, such as when watching television or playing video games. If you have experienced seizures or blackouts, or if you have a family history of such occurrences, please consult your doctor before playing video games on your phone or enabling a flashing-light feature on your phone. (The flashing-light feature is not available on all products.)
Keep the phone out of the reach of small children. The phone may cause injury if used as a toy.
Precautions While Driving
Please pay attention to the traffic safety. Check the laws and regulations on the use of your phone in the area where you drive. Always obey them.
Use hands-free function of the phone, if available.
Pull off the road and park before making or answering a call if
7
conditions require.
Precautions for Medical Devices and Facilities
When using your phone near pacemakers, please always keep the phone more than eight inches (about twenty centimeters) from the pacemaker when the phone is switched on. Do not carry the phone in the breast pocket. Use the ear opposite the pacemaker to minimize the potential for interference. Switch off the phone immediately if necessary.
Some phones may interfere with some hearing aids. In the event of such interference, you may consult your hearing aids manufacturer to discuss alternatives.
If you use any other personal medical device, please consult the manufacturer of your device to determine if it is adequately shielded from RF(radio frequency) energy.
In those facilities with special demand, such as hospital or health care facilities, please pay attention to the restriction on the use of mobile phone. Switch off your phone if required.
8
Mobile Phone
Please use original accessories or accessories approved by the phone manufacturer. Using any unauthorized accessories may affect your mobile phone’s performance, damage your phone or even cause danger to your body and violate related local regulations about telecom terminals.
Turn off your phone before you clean it. Use a damp or anti-static cloth to clean the phone. Do not use a dry cloth or electrostatically charged cloth. Do not use chemical or abrasive cleaners as these could damage the phone.
As your mobile phone can produce electromagnetic field, do not place it near magnetic items such as computer disks.
Using the phone near electrical appliances such as TV, telephone, radio and personal computer can cause interference.
Do not expose your mobile phone to direct sunlight or store it in hot areas. High temperatures can shorten the life of electronic devices.
Keep your phone dry. Any liquid may damage your phone.
9
Do not drop, knock or harshly treat the phone. Rough handling can break internal circuit boards.
Do not connect the phone with any incompatible enhancement.
Do not attempt to disassemble the mobile phone or battery.
Do not store the phone with flammable or explosive articles.
Do not charge the mobile phone without battery.
Precautions for Potentially Explosive Atmospheres
Switch off your phone prior to entering any area with potentially explosive atmospheres, such as fueling areas, fuel or chemical transfer or storage facilities.
Do not remove, install, or charge batteries in such areas. Spark in a potentially explosive atmosphere can cause an explosion or fire resulting in bodily injury or even death.
To avoid possible interference with blasting operations, switch off your phone when you are near electrical blasting caps, in a blasting area, or in areas posted “Turn off electronic devices.” Obey
10
all signs and instructions.
Precautions for Electronic Devices
Some electronic devices are susceptible to electromagnetic interference sent by mobile phone if inadequately shielded, such as electronic system of vehicles. Please consult the manufacturer of the device before using the phone if necessary.
Safety and General Use in Vehicles
Safety airbag, brake, speed control system and oil eject system shouldn’t be affected by wireless transmission. If you do meet problems above, please contact your automobile provider. Do not place your phone in the area over an airbag or in the airbag deployment area. Airbags inflate with great force. If a phone is placed in the ai rbag deployment area and the airbag inflates, the phone may be propelled with great force and cause serious injury to occupants of the vehicle.
Please turn off your mobile phone at a refueling point, and the
11
same to the place where the use of two-way radio is prohibited.
Aircraft Safety
Please turn off your mobile phone before the airplane takes off. In order to protect airplane’s communication system from interference, it is forbidden to use mobile phone in flight. Safety regulations require you to have permission from a crew member to use your phone while the plane is on the ground.
If the mobile phone has the function of automatic timing power-on, please check your alarm setting to make sure that your phone will not be automatically turned on during flight.
12
Battery Use
Do not short-circuit the battery, as this can cause the unit to overheat or ignite.
Do not store battery in hot areas or throw it into fire. Otherwise, it will cause explosion.
Do not disassemble or refit the battery. Otherwise, it will cause liquid leakage, overheating, explosion and ignition of the battery.
Please store the battery in a cool dry place if you don’t use it for a long period.
The battery can be recharged for hundreds of times, but it will eventually wear out. When the operating time (talk time and standby time) is noticeably shorter than normal, it is time to replace it with a new one.
Please stop using the charger and battery when they are damaged or show evidence of aging.
Return the worn-out battery to the provider or dispose of it in
13
accordance with environment regulations. Do not dispose of it in household rubbish.
Please use original batteries or batteries approved by the phone manufacturer. Using any unauthorized battery may affect your handset performance or may cause danger of explosion, etc.
Warning: If the battery is damaged, do not discharge it. If the leakage does come into contact with the eyes or skin, wash thoroughly in clean water and consult a doctor.
14
Limitation of Liability
ZTE shall not be liable for any loss of profits or indirect, special, incidental or consequential damages resulting from or arising out of or in connection with using this product, whether or not ZTE had been advised, knew or should have known the possibility of such damages. The user should refer to the enclosed warranty card for full warranty and service information.
Note: The pictures and icons shown in the manual are just schematic drawings for function demonstration. If they are inconsistent with your handset, please take your handset as the standard. If the inconsistency exits in the manual because of the handset function updating, please refer to the follow-up public information from ZTE CORPORATION.
Key Functions
Earpiece
15
Torch
Left/Right soft ke y
Send key
* key
Charger /headset interface
4-Way Navigation keys and Center key
End/Power key
Alpha numeric keys
# key
16
Function Description
Left soft key
Right soft key
Center key
4-Way
Navigation
keys
Send key
End/Power key
* key and # key
Performs the function indicated at the left bottom of the screen.
Performs the function indicated at the right bottom of the screen.
Press to confirm actions and make selections.
These keys (UP, DOWN, LEFT and RIGHT) allow for navigation through menu options and quick accessing to some function menus.
Press to dial a phone number or answer a call, or view the call history in the standby mode.
Press to exit to the standby mode. Hold to switch on/off the phone.
They have different functions in different modes or function menus.
17
Alpha numeric
keys
Torch
Note: In this User Manual, “press a key” means to press the key and
release it immediately, while “hold a key” means to press the key for at least two seconds and then release it.
Press to enter characters 0-9 and the alphabets from a-z.
In the standby mode, hold the * key to turn on or off the torch.
Locking and Unlocking the Keypad
In the standby mode, press the Left soft key and then press the * key within two seconds to lock the keypad. The unlock method is the same.
Locking the keypad can prevent unintentional operations on it. You can answer an incoming call with the regular operation when the keypad is locked.
18
Interface Icons
Signal strength Battery status
New SMS, message full when
GPRS Alarm clock set
Call diverting Silent
Missed call General
Outdoor Headset
blinking
Keypad locked
Battery
The lithium ion battery of the mobile phone can be immediately used after unpacking.
Installing the battery
1. Pull the battery cover from the notch on the top edge and remove the
19
cover.
2. Insert the battery by aligning the gold-coloured contacts with the contacts in the battery slot.
3. Push down the upper section of the battery until it clicks into place.
4. Fix the battery cover till you hear the click sound.
Remove the battery cover Push down the battery Fix the battery cover till you hear the click sound
Removing the battery
1. Make sure that your mobile phone is switched off.
2. Remove the battery cover.
20
3. Pull the battery up and remove it from the mobile phone.
Remove the battery cover Pull up the battery from here
Inserting the SIM Card
Insert the SIM card as follows:
1. Make sure that the phone is switched off and the charger is disconnected from the phone.
2. Turn the phone over and remove the battery cover.
3. Remove the battery if it is already installed.
4. Hold your SIM card with the cut corner oriented as shown and then
21
slide it into the card holder with the gold-coloured contacts facing downward.
5. Install your battery.
6. Fix the battery cover till you hear the click sound.
Insert the SIM card
SIM (Subscriber Identity Module) card is a micro chip from a network
22
provider that keeps the carrier details and customers information such as names and phone numbers. Your phone won’t work without it. If you already have contacts on your SIM card, they can be transferred in most cases.
Inserting the Memory Card
You can use a memory card to expand the storage of the phone. You can store or copy files such as pictures, music and so on.
Do not take out the card or switch off the phone while transmitting or storing data, which may cause data loss or damage to the phone or the card.
Insert the memory card as follows:
The memory card slot is in the middle of the SIM card holders. Open the battery cover and remove the battery. Insert the card with the metal contacts facing downwards until it clicks to the right position.
23
Insert the Memory card
Charging the Battery
Your phone is powered by a rechargeable battery. For maximum battery performance, it is recommended that you first use up the battery power and then charge it completely. A new battery’s full performance is achieved only after three complete charge and discharge cycles.
24
1. Connect your travel adapter to the bottom of your mobile phone as shown in the diagram.
2. Connect the other end of the travel adapter to the mains socket.
3. When you charge the battery, the battery charging indicator appears.
4. When the battery is fully charged, disconnect the charger.
Insert
25
Powering your Phone On/Off
Make sure that your SIM card is in your mobile phone and that the battery is charged.
Hold the End/Power key to power on/off the phone. The phone will automatically search for the network.
Writing Text
Change input mode: Press the # key to change the input mode (input
modes: ABC, abc, eZi ABC, eZi abc,123).
Input letters: In ABC/abc mode, constantly press the corresponding letter key till the letter appears. In eZi ABC/eZi abc mode, press the corresponding letter key, then use Left/Right Navigation keys to select the letter.
Input words: In eZi ABC/eZi abc mode, input any letter with a single key press. Press each key only once for every letter. The word changes after each key stroke. Predictive text input is based on a
26
built-in dictionary. When you have finished writing the word and it is correct, confirm it by pressing the Left soft key, Center key or the 0 key. If the word is incorrect, press the Left/Right Navigation keys to view other matching words found in the dictionary.
Input digits: In 123 mode, press digit key once to input a digit. In eZi ABC/eZi abc mode, press the digit key, and select the number by pressing the Navigation keys. You cannot input 0 in eZi ABC/eZi abc mode. In ABC/abc mode, constantly press the digit key until the number appears.
Input symbol: Press the * key to enter the symbol mode, select the required symbol (common symbols) by pressing the Navigation keys and then press the Left soft key or Center key to confirm it. In eZi ABC/eZi abc mode, press the 1 key, and select the required symbol (common symbols) by pressing the Navigation keys. In ABC/abc mode, constantly press the 1 key until the required symbol (common symbols) appears.
Input space: Press the 0 key to input space. It does not work in 123 mode.
27
Delete character: Press the Right soft key to clear a character. Hold the Right soft key to delete all characters and clear the display.
Move cursor to left or right: Among the text, press the Left/Right Navigation keys to move the cursor to left or right.
How to Add People to the Phonebook
There are some numbers that you may want to call again and again, so it makes sense to add these numbers to your phonebook. You can then access these numbers quickly and easily.
Go to Menu > Phonebook > Options > Add new contact.
Select to save the number to SIM or phone.
Edit the information and save it.
You can also save a number right after you’ve made or received a
phone call or a message from someone who is not yet in your Phonebook list.
To delete someone from your Phonebook list, first select the name,
28
then select Options > Delete.
To view the memory status and so on, select Options > Phonebook settings.
How to Make and Receive Calls
The most basic way to make a call is to input the number in the standby mode and press the Send key. You can also make a call from the Phonebook list.
To call someone: Go to Menu > Phonebook. Use the Up/Down Navigation keys to find the name of the person you want to call. You
can also type in the first letter of the name of the person you want to call to find the right name, and press the Send key.
To receive a call, press the Left soft key or the Send key.
To end a call, press the End/Power key.
To reject a call, press the End/Power key.
Make sure that you are in an area with sufficient coverage to make
29
calls. The strength of the network signal is indicated on the Status Bar of the screen.
How to Send Messages
You can use your mobile phone to send and receive messages.
1. Go to Menu > Messages > SMS/MMS > Write message.
2. Write your message. For more information on input method, see
section ‘Writing Text’. When you write an SMS, press Options > Send to, and edit the recipient. When you write an MMS, you can edit To, Cc, Bcc, Subject and content. In content field, you can select Options and then select to add picture, audio, bookmark text, attachment and slide.
3. When you finish writing an SMS, select Options and then select to
send or save the message. When you finish writing an MMS, in the MMS editing screen, press Done, and select to send or save the message.
30
How to Receive a Message
Upon receiving a message, the mobile phone will alert you with a ringtone, prompt, or a new message icon.
1. Press View to open the new message. You can also go to Inbox to
read the message.
2. Use the Up/Down Navigation keys to view the message.
3. While the message is open, use Options to reply, delete, or
forward the message. You can also call back the sender.
If you want to save the sender’s number, you can highlight the new number in the Inbox interface, then select Options > Save to Phonebook.
You can also receive broadcast messages by using this mobile phone.
Go to Menu > Messages > Voicemail server, choose SIM1/SIM2 voicemail server, you can call the voicemail or edit the voicemail’s name and number.
31
How to Set User Profiles
Go to Menu > User profiles. You can select Options > Activate to activate a profile. Or you can select Options > Customize to edit a profile.
Note: The Silent mode can be only selected On or Off. And the Headset mode can only be activated with the headset connected.
How to View Call History
Go to Menu > Call center > Call history > SIM1/SIM2 call history.
Dialed calls, Received calls and Missed calls are saved in call history. If the records are full, the earliest saved records will be deleted automatically.
Also, you can view call timers, call cost, SMS counter, and GPRS counter in call history.(Call cost need network support.)
32
How to Configure Call Settings
Go to Menu > Call center > Call settings > SIM1/SIM2 call settings.
You can set call waiting, call divert and call barring.
In Advanced settings, you can set blacklist, auto redial, call time display, call time reminder, auto quick end.
How to Set Your Phone
You can adjust various settings of your phone. Go to Menu > Settings.
Dual SIM settings: Select dual SIM open, only SIM1/SIM2 open or flight mode.
Note: In Flight mode ,you can only use local program in your phone and all the wireless functions will be turned off.
Phone settings: Set time and date and schedule power on/off, set prefered input method, display, greeting text and LCD backlight, etc.
Network settings: Set to automatically or manually select network, and set the preferred networks.
33
Security settings: Set security features to protect you from unauthorized use of your phone and SIM card. You will be required to input PIN code. If SIM lock is currently set Off, select On, then input a PIN code to turn it on. You need to input the correct PIN code to unlock your SIM card when you turn on your mobile phone next time.
Note: The PUK code is required to unlock the SIM card if you have incorrectly input the PIN code for three consecutive times. The PIN code and the PUK code may be supplied along with the SIM card. If not, contact the network provider.
Connectivity: View connection activities and set data account.
Restore factory settings: Enter the phone password to restore to the
factory settings. Some personal information might be lost if you use this function, so be careful.
Note: You may be required to input the phone password in some of the security setting interfaces. The default phone password is 1234. Go to Security settings > Change password > Phone password to change the phone password.
34
Organizer
Go to Menu > Organizer.
Calendar
Enter Calendar, the calendar of the current month will be displayed on the screen and the current date will be marked by a background box in a special colour.
You can go to Options > Add event to set event to some day and the phone will remind of you doing this event on that day.
Tasks
You can add tasks such as: Set Date, Call and Anniversary tasks.
Alarm
You can view, and edit the alarm clock settings. You can also enable or disable the alarms. By pressing Edit, you can set the corresponding features of the alarm according to the instructions.
World clock
35
You can view the time in different cities.
Calculator
You can perform simple calculations. Press digit key to enter the number. Press Navigation keys to select the operational character. Press OK or
Center key to get the result. Press Clear to delete the number.
Note: This calculator has limited accuracy and rounding errors may
occur especially in long division.
Stopwatch
Use it to record the time.
File Manager
Go to Menu > File manager. You can check all the folders in the phone or memory card, create new ones or rename, delete, or sort, etc. The files you download from the internet will be stored in these folders.
Note: When you select Options > Format, the data will be lost, so please be careful with this function.
36
How to Play Music
Go to Menu > Multimedia > Audio player. You can play the audio in your phone or the memory card.
In List > Options, you can refresh your playlist and make personal settings.
Audio player supports: AMR-NB, WAV, MP3, iMelody, MIDI.
How to Listen to FM
Go to Menu > Multimedia > FM radio.
With the radio, you can search for radio channels, listen to them. Note that the quality of the radio broadcast depends on the coverage of the radio station in that particular area. In the FM radio interface, you can press the Up/Down
Left/Right Center key to pause. Select Options to enter the submenu:
Channel list: Edit up to 9 channels.
Manual input: Manually input a channel.
Navigation keys to tune the frequency, and press the
Navigation keys to adjust volume, press the
37
Auto search: Automatically searches for channels.
Settings: You can turn on/off Background play, and you can turn on
Loudspeaker when headset is inserted.
How to Use Services
Go to Menu>Services. Services allows you to view internet content. In Services you can use the STK and WAP.
STK
SIM card Toolkit (STK) services are value-added services provided by your network provider.
Your mobile phone supports STK service, but if your SIM card and network provider do not support the service, these functions can’t be used.
WAP
In WAP
¾ Select Homepage to go into your homepage.
38
¾ Select Bookmarks to view the list of saved website addresses.
¾ Select Recent pages to view the list of pages you recently visited.
¾ Select Input address to go to a page by directly inputting the
address.
Go to Service inbox to view the service messages.
Go to Settings > Select SIM to select a SIM card which you wish to
use to connect.
Go to Settings > Profiles to select a profile or add a new one.
Go to Settings > Browser options. Select Timeout to set timeout. If
the timeout period elapsed prior to completion of the operation or the server is not responding, it will show “Connection Failed”. During the timeout period, it will keep trying to connect until expired. Select Show images to set whether or not to show the images. Select whether or not to enable Cache and Cookies.
Go to Settings > Service message settings to set the service
message receiving.
Go to Settings > Clear cache to clear cache.
39
Go to Settings > Clear cookies to clear cookies.
Questions & Answers
If you encounter problems while using the phone, or if it performs abnormally, you can refer to the chart below. If your particular problem cannot be resolved using the information in the chart, contact the dealer where you purchased the phone.
Problem Possible causes Possible solution
The network signal is too weak
Poor reception
at your current location, for example, in a basement or near a tall building, because wireless transmissions can not effectively reach it.
Move to a location where the network signal can be properly received.
The network is busy at the current time (for example, during peak times, there may be
Avoid using the phone at such times, or try again after waiting a
40
Problem Possible causes Possible solution
too much network traffic to handle additional calls).
You are too far away from a base station for your service provider.
Poor network trunk quality on the part of your service provider.
Echo or noise
Poor local telephone line quality.
short time.
You can request a service area map from your service provider.
Press End key and dial again. You may be switched to a better­quality network trunk or phone line.
Press End key and dial again. You may be switched to a better­quality network trunk or phone line.
41
Problem Possible causes Possible solution
Unable to select certain features
Battery not charge
Shortened
Your service provider does not support these features, or you have not applied for services that provide these features.
The battery or battery charger is damaged.
The phone’s temperature is below 0°C or higher than 45 °C.
Poor contact between the battery and charger.
The standby time is related to If you are located in an
Contact your service provider.
Contact the dealer.
Adjust the battery charging environment to avoid extremes of temperature.
Check all connectors to make sure all connections have been properly made.
42
Problem Possible causes Possible solution
standby time
your service provider system configuration. The same phone used with different service providers’ systems will not provide exactly the same length of standby time.
The battery is depleted. In high­temperature environments, battery life will be shortened.
If you are not able to connect to the network, the phone will continue to send out signals as it attempts to locate a base station. Doing so consumes battery power and will consequently shorten standby
area where signaling is weak, temporarily power off the phone.
Use a new battery.
Change your location to one where the network is accessible, or temporarily turn off your phone.
43
Problem Possible causes Possible solution
time.
Cannot switch your phone on
SIM card error
Unable to connect to the network
Battery power has been depleted.
SIM card malfunction or damage.
SIM card inserted improperly.
Debris on the SIM card contacts.
SIM card invalid.
You are not within the network’s Check the service
Recharge the phone’s battery.
Take the SIM card to your service provider for testing.
Insert the SIM card properly.
Use a soft, dry cloth to clean the SIM card contacts.
Contact your service provider.
44
Problem Possible causes Possible solution
service area. area with your service
provider.
Move to an open space, or if you are inside a building, move closer to a window.
Go to Call center >
Call settings > SIM1/SIM2 call settings >Call barring, and then
select Cancel all.
Go to Call center >
Call settings > SIM1/SIM2 call
Cannot answer incoming calls
You cannot make outgoing calls
Poor signal.
You have activated the Call barring feature.
You have activated the Call barring feature.
45
Problem Possible causes Possible solution
settings > Call barring, and then
select Cancel all.
Go to Settings >
You have activated the Fixed dial feature.
PIN Code blocked
Unable to The Phonebook’s memory is Delete unnecessary
You have entered an incorrect PIN code three consecutive times.
Security settings > SIM1/SIM2 security settings > Fixed dial
and select Off.
Contact your service provider. If the service provider provides the SIM card’s PUK code, use the PUK code to unlock the SIM card.
46
Problem Possible causes Possible solution
enter information into the Phonebook
already full. data from the contacts.
Loading...
