ZTE Render
User Manual
LEGAL INFORMATION
Copyright © 2012 ZTE CORPORATION.
All rights reserved.
No part of this publication may be quoted,
reproduced, translated or used in any form or by
any means, electronic or mechanical, including
photocopying and microfilm, without the prior
written permission of ZTE Corporation.
The manual is published by ZTE Corporation. We
reserve the right to make modifications on
print errors or update specifications without prior
notice. Every effort has been made in the
preparation of this manual to ensure accuracy of
the contents, but all statements, information, and
recommendations in this manual do not
constitute a warranty of any kind, expressed or
implied.
The Bluetooth® trademark and logos are owned
by the Bluetooth SIG, Inc. and any use of such
trademarks by ZTE Corporation is under license.
Other trademarks and trade names are the
property of their respective owners.
Version No. : R1.0
Edition Time : 201205
Contents
Getting Started ........................................ 11
Overview ........................................................ 11
Keys Explained ............................................. 13
Starting Up ..................................................... 14
Installing the Battery .................................. 14
Charging the battery .................................. 16
Switching Your Phone On/Off ....................... 17
Setting Up Your Phone for the First Time 17
Switching to Sleep Mode ........................... 19
Waking up Your Phone .............................. 19
Getting Around ............................................... 20
Touch Control ............................................ 20
Start Screen .............................................. 21
Status Icons ............................................... 23
Accessing the applications and Settings . 25
Hubs .......................................................... 25
Adjusting the Volume ................................ 25
Page 4
Searching .................................................. 26
Voice Interaction ........................................ 27
Switching between Running Applications . 27
Setting up an Account ............................... 28
Phone Calls ............................................. 29
How to make calls .......................................... 29
Calling with the Keypad ............................. 29
Calling from your Contacts ........................ 30
Calling from your Call History ................... 30
How to receive calls ....................................... 30
Answering or rejecting a call ..................... 30
Muting a Call ............................................. 31
Putting a call on Hold ................................ 31
Turning the Speakerphone On/Off ............ 32
Ending a Call ............................................. 32
Adjusting your Call Settings ........................... 32
People ...................................................... 34
Contact Information ....................................... 35
Creating a Contact ......................................... 36
Page 5
Searching for a Contact ................................. 36
Linking Contact Information ........................... 37
Unlinking Contact Information ....................... 38
Creating a New Group ................................... 38
The Me Tile .................................................... 39
Using the Keyboard ................................ 40
Entering Text .................................................. 40
Moving the Cursor ......................................... 42
Copying and Pasting ...................................... 42
Changing Keyboard Settings ......................... 43
Messaging ............................................... 44
The Message Box .......................................... 44
Sending a Message ....................................... 44
Managing Message Threads ......................... 45
Deleting a Message Thread ...................... 45
Deleting a Message .................................. 46
Changing Message Settings .......................... 46
Online Messaging .......................................... 46
Email ........................................................ 49
Page 6
Creating an Email account ............................ 49
Receiving Emails ........................................... 50
Composing and Sending an Email ................ 50
Replying to or Forwarding an Email .............. 51
Deleting an Account ....................................... 51
Email Settings ................................................ 52
Getting Connected to the Internet ........ 53
Turning on Wi-Fi ........................................... 53
Connecting to a Wi-Fi Network ...................... 54
Sharing Internet ............................................. 54
Browsing the Internet ............................. 56
Navigating on a Web Page ............................ 57
Browsing Options ........................................... 57
Managing Bookmarks .................................... 58
Editing a Bookmark ................................... 58
Deleting a Bookmark ................................. 58
Changing Browser Settings ........................... 59
Bluetooth® ............................................... 60
Calendar ................................................... 62
Page 7
Creating an Appointment ............................... 62
Calendar Views .............................................. 63
Viewing an Appointment ................................ 64
Editing an Appointment .................................. 64
Deleting an Appointment ............................... 64
Handling Appointment Reminders ................. 65
Hiding or Showing Appointments ................... 65
Making the Most of Multimedia ............. 67
Syncing your Phone and your Computer ...... 67
Stereo Headset adapter ................................ 68
Taking Pictures with your Camera ................. 68
Adjusting Camera Settings ....................... 69
Shooting Video with your Camcorder ............ 70
Adjusting your Video Settings ................... 71
Listening to your FM Radio ............................ 71
Playing your Music ......................................... 73
Playing your Videos ....................................... 73
Listening to or Watching Podcasts ................ 73
Opening your Picture and Video Gallery ....... 74
Page 8
Pictures Hub .............................................. 74
Viewing Pictures and Videos ..................... 74
Using Maps .............................................. 75
Enabling Location Services ........................... 75
Bing Maps ...................................................... 75
Finding your Current Location ................... 76
Viewing the Map ........................................ 76
Getting Directions ...................................... 78
Searching for Places ................................. 79
Exploring Nearby Places ........................... 79
Clearing the Map ....................................... 80
Sorting out your Phone Settings ........... 80
Setting Time and Date ................................... 80
Changing Display Settings ............................ 81
Changing the Lock Screen Wallpaper ...... 81
Adjusting Screen Timeout ......................... 82
Adjusting Screen Brightness ..................... 82
Sound Settings .............................................. 82
Language and Region Settings ..................... 83
Page 9
Mobile Network Services ............................... 84
Turning On/Off Airplane Mode .................. 84
Setting up Mobile Services ....................... 84
Security Settings ............................................ 85
Protecting your phone with a password .... 85
Protecting your phone when you lose it .... 86
Privacy: Reset to Factory Settings ................ 86
Managing Application Settings ...................... 87
Managing Other Settings ............................... 87
Other Applications .................................. 89
Alarms ............................................................ 89
Calculator ....................................................... 89
Games ........................................................... 89
Marketplace ................................................... 89
Office .............................................................. 90
Specifications .......................................... 91
Page 10
Getting Started
Please read the Product Safety and Warranty
Information in the box before proceeding.
For additional information about your phone go to
windowsphone.com
Overview
Charger/
USB Jack
Page 11
Volume
Keys
CAMERA
Key
Camera with
LED flash
Battery Cover
Page 12
Loudspeaker
Keys Explained
Key Function
POWER Key • Press and hold to turn on or
CAMERA Key • Press fully to start the
off the phone.
•
Press to switch your phone
to Sleep mode.
•
Press to wake up your
phone.
camera.
•
When the camera is started,
press halfway to adjust the
focus; press fully to take a
photo.
Page 13
Key Function
BACK Key • Touch to go one screen back.
•
Touch and hold to see and
switch running apps.
START Key • Touch to go back to Start.
•
Touch and hold to use voice
recognition.
SEARCH Key • Touch to use Bing search.
Volume Keys • Press or hold to turn the
volume up or down.
Starting Up
Installing the Battery
Switch off your phone before installing or
replacing the battery.
1. Remove the back cover.
Page 14
2. Insert the battery by aligning the gold
contacts on the battery with the gold contacts
in the battery compartment. Gently push down
on the battery until it clicks into place.
Page 15
3. Press the cover gently back into place until
you hear a click.
Charging the battery
When you first get your new phone you’ll need to
charge the battery.
1. Connect the adapter to the charger jack.
Ensure that the adapter is inserted with the
correct orientation. Do not force the connector
into the charger jack.
2. Connect the charger to a standard AC wall
outlet.
Page 16
3. Disconnect the charger when the battery is fully
charged.
Switching Your Phone On/Off
Make sure the battery is charged.
•
Press and hold POWER Key to switch on
your phone.
•
To switch it off, press and hold POWER Key.
Then slide down the picture on the screen.
Setting Up Your Phone for the First
Time
When you first power on your phone after you
purchase it or reset it to factory settings (see
Sorting out Your Phone Settings – Privacy: Reset
to Factory Settings in the manual), you need to
do some settings before using it.
1. In the welcome screen, touch get started and
select the language you want to use.
Page 17
2. Touch next. If you have changed the
language, touch ok for the phone to reboot
and then touch next.
3. Read the WINDOWS PHONE TERMS OF
USE and Privacy Statement. Touch accept
to continue.
4. Touch recommended to enable mobile data
and send information to Microsoft for product
improvement. Or touch custom to select the
options you want to enable and touch next.
5. Choose the time zone you are in and touch
next.
6. Sign in or create a Windows Live ID. You
need it to get apps, games, and music from
Marketplace, find a lost phone, and more.
Touch not now to sign in or create an account
later.
7. Touch done. The phone will show the Start
screen.
Page 18
Switching to Sleep Mode
To save battery power, Sleep Mode suspends
your device to a low-power-consumption state
while the display is off. Your device also goes into
Sleep Mode by itself when the display is
automatically turned off after a certain period of
time, which you can set in Settings > lock +
wallpaper > Screen times out after.
Press POWER Key to switch to Sleep Mode.
Waking up Your Phone
1. Press POWER Key. The phone displays the
lock screen.
2. Press the bottom of the screen and slide your
finger up.
Page 19
NOTE: If you have set a phone password (see
Sorting out Your Phone Settings – Security
Settings in the manual) you’ll need to enter the
password to unlock your screen.
Getting Around
Touch Control
You can use finger gestures to control your
phone. The controls on your touch screen change
dynamically depending on the tasks you’re
performing.
•
Touch the buttons, icons, or applications to
Page 20
select items or to open applications.
•
Touch and hold an item by keeping your finger
on it to see the available options.
•
Flick the screen to scroll up, down, left or
right.
•
Point, drag and drop to move particular items
across the screen.
•
Pinch or double-tap the screen, to zoom in/out
on a web page or an image.
NOTE: You can view the phone screen in portrait
or landscape orientation simply by holding the
phone upright or turning it on its side.
Start Screen
On your Windows Phone, the Start Screen (or
Start) is like a home screen: you can keep what
really matters to you at easy reach. The start
screen contains Windows Phone live tiles, which
are shortcuts to functional features and apps.
Page 21
Pin all sorts of things to Start, including apps,
websites, map locations, and even contacts.
When you pin a contact to Start, you’ll see
missed calls, SMS, IM, email, and feed updates
from that person, right from that Tile. You can
also customize your start screen layout.
Rearranging the Start Screen Tiles
1. Touch and hold the tile you want to move until
other tiles recede.
2. Drag the tile to a new position in the Start
Page 22
screen.
3. Touch the tile or a blank space to dock the tile.
Pinning New Items to the Start Screen
Lots of stuff can be pinned to the Start screen,
such as apps, contacts, and office documents.
To pin something to the Start screen, touch and
hold it until a menu pops up. Then touch pin to
start.
Removing a Tile from the Start Screen
1. Touch and hold the tile you want to remove
until other tiles recede.
2. Touch on the upper-right corner of the tile.
Status Icons
Your phone will tell you exactly what’s going on
by showing you different icons. Simply touch the
top of the screen to see the icons. After a few
seconds, they will disappear again.
Page 23
Here’s some of the icons you may see and what
they mean.
3G connection No signal
Signal strength WiFi on but not
Battery very low Connected to a WiFi
Battery medium Bluetooth connected
Battery high Silent mode
Battery full Vibrate mode
Battery charging Flight mode
Call forwarding Roaming
connected
network
(vibrate and no
ringtone)
Internet sharing on
TIP: When the phone notifies you of something
on top of the screen, for instance, a new
message or a new found WiFi network, touch the
notification area to open the related screen, such
as the new message or WiFi settings.
Page 24
Accessing the applications and
Settings
From the Start screen, touch or flick your
finger left to see all your apps and settings.
Hubs
Your Windows Phone simplifies related
experiences by combining them into one hub.
You can see all your contacts and check out their
status updates on social networks from the
People Hub; check all your music, video, podcast
and listen to FM radio from the Music+Videos
Hub; explore Office documents on your phone or
online from the Office Hub, and more.
Flick left or right in a hub to view different
categories of information.
Adjusting the Volume
Press the Volume Up or Volume Down key to
adjust the volume to your desired level. At the
Page 25
same time, numbers will appear on top of the
screen to show the current volume level.
Touch icon on the right to turn off ringtone and
make the phone only vibrate or silent.
Touch or icon to turn ringtone back on.
Searching
1. From Start, press SEARCH Key to open the
BingTM search screen.
2. Touch the search box and enter the key words
with the onscreen keyboard. Then touch
on the keyboard to see the search results.
3. Touch the categories below the search box or
flick left or right to check out other results in
other categories.
TIP: Touch , , or to search for local
Page 26
businesses, scan barcodes or texts, use audio
search to find songs, or use your voice to do a
search.
Voice Interaction
From any screen on your phone, touch and hold
the START Key to bring up the Microsoft Tellme
screen. Now you can use your voice to call your
contacts, open applications, text a friend, search
the web, and more.
Touch to learn what you can do and how to use
this feature.
Switching between Running
Applications
You can have multiple applications running on
your phone.
When you want to open another application
without exiting the current one, touch START Key
and touch then touch the new application you
Page 27
want to open.
To switch back to the previous application, first
touch and hold BACK Key to see all running
applications. Then flick left or right to find the
application you want and touch to restore it.
Setting up an Account
Set up an email, Windows Live, Google, and
social network account to synchronize emails,
contacts, or receive updates on your phone.
1. From Start, touch
2. Touch Settings > email + accounts > add an
account.
3. Touch the account you want to set up and
enter the email address and password.
4. Touch sign in.
Page 28
