ZTE Engage

User Manual

license from SRS Labs, Inc. WOW HDTM significantly improves the playback quality of audio, delivering a dynamic 3D

entertainment experience with deep, rich bass and high frequency clarity for crisp detail.

No part of this publication may be quoted, reproduced, translated or used in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation.

The Bluetooth such trademarks by ZTE Corporation is under license. Other trademarks and trade names are the property of their respective owners.

ZTE Corporation reserves the right to make modifications on print errors or update specifications in this manual without prior notice.

is a trademark of SRS Labs, Inc. WOW HD technology is incorporated under

trademark and logos are owned by the Bluetooth® SIG, Inc. and any use of

Version 1.0 June 2012

Contents

Safety............................................................ 1

About your device ...................................... 2

Let’s get started......................................... 3

Inserting a memory card........................... 4

Using the battery......................................... 4

Power on/off ................................................. 6

Getting to know your phone ................... 7

Key Definitions............................................. 8

Onscreen icons ...........................................9

Screen control............................................ 10

Open and close the All Apps ................ 10

Home screen................................................11

Switch to a recently used application..13

Display the dialing keypad......................15

Switch to sleep mode ...............................15

Wake up your phone................................ 15

Make and answer calls........................... 16

Make a call .................................................. 16

Answer a call ...............................................17

Reject a call..................................................17

End a call ..................................................... 18

Adjust the volume ..................................... 18

Turn the speakerphone on or off.......... 18

Add one call................................................ 18

Open the dialing keypad ........................ 18

Contacts..................................................... 19

Add new contact .......................................19

Delete contacts......................................... 20

Edit contact details...................................20

Search contacts ........................................20

Accounts..................................................... 20

Messaging.................................................22

Send messages........................................ 22

Receive messages...................................22

Message thread.........................................23

Settings ........................................................23

Email...........................................................24

Set up Email account ...............................24

Send Emails ............................................... 25

Check Emails............................................. 26

Gmail ..........................................................26

Set up a Gmail account for the first time

....................................................................... 26

Send Gmails................................................27

Replying to or forwarding email

messages in Gmail....................................27

Network Applications .............................28

Network connection................................ 28

Wi-Fi ............................................................. 28

Browser....................................................... 29

Bluetooth

Settings......................................................32

Airplane mode........................................... 32

Device.......................................................... 32

Accounts and sync................................... 34

Language.................................................... 35

Date & time ................................................35

About phone.............................................. 35

Experiencing Multimedia........................36

Camera........................................................ 36

Camcorder...................................................37

Music Player............................................... 39

Video Player ................................................41

Gallery............................................................41

Sound Recorder..........................................41

More Applications....................................42

File manager.............................................. 42

Clock............................................................ 42

................................................... 30

Calculator ....................................................43

Calendar ......................................................43

Documents To Go..................................... 44

Time Manager............................................45

Downloads..................................................45

Task Manager.............................................46

Manage applications...............................46

Install new applications ...........................46

Uninstall applications...............................47

Text Input...................................................48

Android Keyboard.....................................48

Google voice typing.................................49

Swype.......................................................... 50

Appendix....................................................51

Battery saving tips......................................51

Care and maintenance.............................51

Consumer limited warranty ....................53

Additional safety information................ 55

Problems and their solutions.................63

Safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

Power on safely

Do not power on the device when and where prohibited or when it may cause interference or danger.

Road safety comes first

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

Interference

All wireless devices may be susceptible to interference, which could affect performance.

Turn device off in restricted areas

Follow all warnings. Turn device off in aircraft, near medical equipment, fuel, chemicals or blasting areas.

Qualified service

Only qualified personnel should install or repair this product.

Accessories and batteries

Use only approved accessories. Do not connect incompatible products.

Water resistance

Your device is not water resistant. Keep it dry.

About your device

The wireless device described in this guide is approved for use on the CDMA2000 1X EVDO networks. Contact your service provider for more information about networks.

When using the features of this device, obey all laws and respect local customs, privacy and legitimate rights of others, including copyrights.

Warning: To use any features of this device, you must turn on the device. Do not turn on the device when using the wireless device may cause interference or danger.

Remember to make backup copies or keep a written record of all important information stored in your device.

When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.

Let’s get started

Thanks for choosing the EngageTM. It’s a CDMA2000 1X EVDO digital mobile phone, which we will refer to as ‘phone’ from now on. Under the Android operating system, the phone supports 3G high-speed internet access, which brings you brand new experiences.

Don’t worry if the pictures we use to demonstrate your phone’s functions look a little different from what you see on the screen. It’s the functions that matter.

Inserting a memory card

1. Open the battery cover and insert a memory card.

2. Push tightly until the card is installed in the correct position and replace the back cover.

Note:

This mobile phone supports memory cards. For details on compatibility information of memory, please consult your manufacturer or supplier.

Using the battery

Inserting the battery

1. Open the battery cover on the back of your phone.

2. Align the battery's contact points with those of the phone and gently press the battery

down into place.

3. Replace the battery cover, clicking it back into position.

Removing the battery

1. Switch off your phone.

2. Open the battery cover.

3. Lift the battery up and out of your phone.

Charging the battery

The rechargeable Li-ion battery that comes with your phone is ready to use but is not charged. That’s easy to do. We’ll show you how below.

Recharge it fully on the first, initial charge. Then it's best to recharge Li-ion batteries when they are at 15-25%.

1. Connect the charger to your phone and plug it into a 110V/220V socket.

2. The battery indicator in the corner of the screen will scroll up and down

to show you it’s charging. Please don’t worry if the phone and charger become warm while charging. That’s completely normal.

3. When fully charged, the battery indicator will stop scrolling.

4. Disconnect the charger from your mobile and unplug.

Power on/off

Powering on Long press the Power key until the power-on animation appears.

Powering off Long press the Power key to display the menu and select Power off.

Getting to know your phone

Home key

Earpiece

Menu key

Power key

Front camera

Volume ke ys

Touch screen

Search Key

Microphone

Back key

USB port

Headsetjack

Back camera

Flash

Speaker

Key Definitions

Menu key

Home key

Back key

Search key Touch it to open Google Search for searching the web.

Power key Press it to turn on/off the display.

Volume keys Adjust the volume.

Touch it to open a menu with items that affect the current screen or application. Touch it to open the home screen. If you’re viewing the left or right extended home screen, touch it to open the central home screen. Touch & hold the Home key to open the most recently used applications screen. Touch it to open the previous screen you were working in. If the onscreen keyboard is open, touch it to close the keyboard.

Touch and hold it to open Google Search by voice.

Long press it to open a menu with options for Airplane mode, for Silent mode, and for powering off the phone

Long press to quickly adjust the ringtone volume to maximum or minimum.

Onscreen icons

Icons Descriptions Icons Descriptions

Signal strength

Charging

In a call

You have an unread message.

You have an unread G-mail.

Vibration mode

Connected to a PC

Alarm clock on

Wi-Fi function is on

Full battery

Low battery

Missed calls

You have an unread E-mail.

Airplane mode

Silent mode

Music playing

New calendar reminder

Bluetooth® function is on

Screen control

You can control your phone through a series of operations on the screen.

- Touch: You can touch the items on the screen to select, to open the applications or to use the keyboard to input characters.

- Swipe or slide: Quickly move your finger across the surface of the screen, without pausing when you first touch (so you don't drag something instead).

- Touch & hold: You can touch & hold some items to get the item’s available menu.

- Drag: You can drag some items on the screen to realize some operations.

- Switch between landscape mode and portrait mode: You can switch to the landscape mode by rotating your phone. The landscape mode is only valid under some interfaces, such as the text input interface, the message viewing interface, etc.

- Pinch: In some apps (such as Maps, Browser, and Gallery), you can zoom in and out by placing two fingers on the screen at once and pinching them together (to zoom out) or spreading them apart (to zoom in).

Open and close the All Apps

On the home screen, touch the icon to open the All Apps.

After opening the All Apps, press an icon to enter the corresponding application. Touch the Back key to return to the previous screen. Touch the Home key to return to the home screen.

Home screen

Drag the notification bar down from the top of the screen to open the notifications panel.

Just below the status and notification bars, it lets you search your phone or the internet. Touch Google to type your search terms, or to speak them.

Arrange & work with apps

From All Apps, you can:

- Explore your widgets: Touch the widgets tab at the top of any All Apps screen.

- Get more apps.: Touch the Play Store icon.

Notification bar

Google Search

Phone

People

Messaging

All Apps

Status bar Shows the signal strength,

battery status, etc.

Icons Touch to open the relevant application.

Browser

Use folders

You can combine several app icons in a folder. Drop one app icon over another on a Home screen and the two icons will be combined.

From any Home screen, you can

- Open a folder: Touch it. The folder opens.

- Rename a fo lder : Touch its name.

- Move icons around your Home screens: Touch, hold, and drag.

Favorites tray

The app icons you keep in the tray remain visible on every Home screen.

The All Apps icon touch

to view Contacts, touch to see Messaging, and touch to use the Browser

to view the internet.

in the center is permanent. Touch the icon to see the Phone,

The middle of your Home screen can hold app and widget icons, plus folders.

-To open an app, folder or widget, touch its icon.

-To see additional Home screens, swipe your finger quickly left or right.

Manage notifications

- See your notifications: Swipe your finger down from the top of the screen.

- Respond to a notification: Touch it.

- Dismiss a notification: Swipe it sideways.

- Dismiss all notifications: Touch the X in the top right corner.

Switch to a recently used application

Long touch the Home key. A window opens with icons of applications that you’ve used recently. Touch an icon to open its application.

Change the wallpaper

Wallpapers are images from Gallery (pictures you shot with Camera, synced from Picasa, and so on), still images included with the system, and live images (such as an animation or a map that centers on your location). They take the place of the default background for your Home screens.

1. Long touch anywhere that’s not occupied on a Home screen. A list of options appears.

2. Touch a wallpaper source: z Gallery. Choose from pictures that you've taken with Camera or downloaded

to your device.

z Live Wallpapers. Choose from a scrollable list of animated wallpapers. z Wallpapers. Choose from thumbnails of default images. You can download

additional wallpapers from Play Store.

3. To set a wallpaper, touch Set wallpaper or for Gallery images, choose the image you desire and touch it, use the cropping tool to prepare it and then touch CROP.

Set ringtone & other sounds Your phone uses sounds and vibrations to communicate with you, including ringtones,

notifications, alarms, and navigation feedback. You can customize any of these sounds, as well as controlling their volume and the volume for music, videos, games, and other media.

Change default ringtone To change the default ringtone for incoming calls:

1. From a Home or All Apps screen, touch the Settings icon.

2. To u ch Sound > Phone ringtone.

Touch a ringtone to select and hear it. Touch OK to confirm your final selection. To set a ringtone for an individual caller, go to that person's contact card in the People app, touch Menu for that card, and then Set ringtone.

Set ringtone to Vibrate

You have several options for controlling when your phone vibrates. To turn Vibrate on or off easily for incoming calls, follow these steps:

To activate Vibrate, press the Volume key (on the right side of your phone) down until you feel the phone vibrate. To resume normal ringing, press the Volume key up.

Change other Sound settings

To change other sounds and vibrations, go to Settings > Sound and touch the one you want: z Volumes sets the master volume separately for music, ringtones & notifications, and

alarms. You can still use the physical volume control on the phone to raise or lower the volume of whatever sound is currently playing.

z Silent mode turns off all sounds. z Default notification announces the arrival of notifications unless you specify a

different sound in an individual app.

Display the dialing keypad

On the home screen, press the button to display the dialing keypad.

Switch to sleep mode

Sleep mode is a kind of power-saving mode, which also helps to prevent inadvertent operations.

If your phone has been in idle mode for a while, it will automatically switch to sleep mode. You can also press the Power key to turn off the screen and enable sleep mode.

Wake up your phone

After the phone switches to sleep mode, the screen will be turned off and locked. In this case please awake your phone and unlock the screen if you want to use your phone.

1. Press the Power key to turn on the screen.

2. Long touch the

you’ve set an unlock pattern, you need to draw the unlock pattern to unlock the screen. (For details, please see Settings

icon and drag it right to the unlocked padlock to unlock the screen. If

Security Screen lock Pattern. )

Make and answer calls

Make a call

Directly make a call

On the home screen, touch the

buttons to input the telephone number and touch the Make the call from Contacts

On the home screen, touch the contacts, touch the desired contact and touch the phone number to dial it.

Make the call from Call log

On the home screen, touch the

The call log tab Make an international call

On the home screen, touch the “0” key until “+” appears on the screen, then dial the country code or region code, city code and phone number.

shows recent calls. Touch the phone icon in a call log to return it.

button to display the dialing keypad. Touch the numeric

button to make the call.

icon, and then touch the icon to display the list of

button. Notice the three tabs at the top of the screen.

button to display the dialing keypad. Touch & hold the

+ 47 hidden pages
