Zte cymbal Z-320 User Manual
User Manual
1
About This Manual
Thank you for choosing this ZTE mobile device. In order to keep
your device in its best condition, please read this manual and
keep it for future reference.
Copyright
Copyright © 2016 ZTE CORPORATION
All rights reserved.
No part of this publication may be quoted, reproduced, translated
or used in any form or by any means, electronic or mechanical,
including photocopying and microfilm, without the prior written
permission of ZTE Corporation.
Notice
ZTE Corporation reserves the right to make modifications on print
errors or update specifications in this guide without prior notice.
This manual has been designed with the utmost care to ensure
the accuracy of its content. However, all statements, information
and recommendations contained therein do not constitute a
warranty of any kind, either expressed or implied. Please refer to
For Your Safety to be sure to use your phone properly and safely.
We offer self-service for our smart terminal device users. Please
visit the ZTE official website (at www.ztedevice.com) for more
information on self-service and supported product models.
Information on the website takes precedence.
Disclaimer
ZTE Corporation expressly disclaims any liability for faults and
2
damages caused by unauthorized modifications of the software.
Images and screenshots used in this manual may differ from the
actual product. Content in this manual may differ from the actual
product or software.
Trademarks
ZTE and the ZTE logos are trademarks of the ZTE Corporation.
Google and Android are trademarks of Google, Inc.
The Bluetooth® trademark and logos are owned by the Bluetooth
SIG, Inc. and any use of such trademarks by ZTE Corporation is
under license.
microSDHC logo is a trademark of the SD-3C, LLC.
Other trademarks and trade names are the property of their
respective owners.
Version No.: R1.0
Edition Time : September 13, 2016
3
Contents
Getting Started ......................................................... 9
Getting to Know Your Phone .............................................. 9
Knowing the Keys ............................................................ 11
Installing the micro-SIM Card and the microSDHC™ card 12
Charging the Battery ........................................................ 15
Extending the Battery Life ................................................ 17
Powering On/Off .............................................................. 17
Setting Up for the First Time ............................................ 17
Getting to Know Standby Mode ........................................ 18
Personalizing.......................................................... 19
Changing the System Language ...................................... 19
Setting the Date and Time................................................ 19
Changing Ringtone and Notification Sound ...................... 19
Turning On/Off Key Tone.................................................. 20
Adjusting Volumes ........................................................... 20
Switching to Silent Mode .................................................. 21
Applying New Wallpapers ................................................ 21
Changing Screen Brightness ........................................... 22
Enabling Anti-Theft .......................................................... 22
Protecting Your Phone With Screen Locks ....................... 23
Knowing the Basics ............................................... 24
Monitoring the Phone Status ............................................ 24
Managing Notifications ..................................................... 25
Entering Text ................................................................... 25
4
Opening and Switching Apps ............................................ 27
Connecting to Networks and Devices .................. 28
Connecting to Mobile Networks ........................................ 28
Connecting to Bluetooth® Devices .................................... 30
Connecting to Your Computer via USB ............................. 32
Phone Calls ............................................................ 34
Placing and Ending Calls ................................................. 34
Answering or Rejecting Calls ............................................ 35
Working With the Call Log ................................................ 36
Calling Your Contacts ....................................................... 37
Checking Voicemail .......................................................... 37
Using Options During a Call ............................................. 38
Managing Multi-party Calls ............................................... 38
Adjusting Your Call Settings ............................................. 40
Contacts ................................................................. 45
Checking Contact Details ................................................. 45
Adding a New Contact...................................................... 45
Setting Up Your Own Profile ............................................. 46
Importing, Exporting, and Sharing Contacts ...................... 46
Working With Groups ....................................................... 48
Searching for a Contact .................................................... 49
Editing Contacts ............................................................... 50
Messages ............................................................... 52
Opening the Messaging Screen ....................................... 52
Sending a Message ......................................................... 52
5
Replying to a Message .................................................... 53
Forwarding a Message .................................................... 54
Changing Message Settings ............................................ 54
Calendar ................................................................. 55
Viewing Your Calendars and Events................................. 55
Creating an Event ............................................................ 55
Editing or Deleting an Event ............................................. 56
Changing Calendar Settings ............................................ 56
MetroWEB ............................................................... 57
Opening the Browser ....................................................... 57
Changing Browser Settings .............................................. 58
Camera .................................................................... 59
Capturing a Photo ............................................................ 59
Customizing Camera Settings .......................................... 60
Recording a Video ........................................................... 61
Gallery ..................................................................... 63
Opening Gallery ............................................................... 63
Working With Albums ....................................................... 63
Working With Pictures ...................................................... 64
Playing Videos ................................................................. 64
Music ....................................................................... 65
Copying Music Files to Your Phone .................................. 65
Viewing Your Music Library .............................................. 65
Playing Music ................................................................ .. 66
6
Managing Playlists ........................................................... 66
Video Player ........................................................... 67
Opening the Video Library ................................................ 67
Playing and Controlling Videos ......................................... 67
Managing Video Files ................................ ....................... 67
FM Radio ................................................................ 68
Scanning and Saving Channels ........................................ 68
Listening to FM Radio ...................................................... 68
To turn off FM radio immediately....................................... 69
Sound Recorder ..................................................... 70
Recording a Voice Memo ................................................. 70
Playing a Voice Memo ...................................................... 70
More Apps .............................................................. 71
Clock ............................................................................... 71
Calculator ........................................................................ 72
File Manager .................................................................... 73
Settings .................................................................. 74
Profiles............................................................................. 74
General Settings .............................................................. 74
Personal .......................................................................... 78
Troubleshooting ..................................................... 79
For Your Safety ...................................................... 85
General Safety ................................................................. 85
Radio Frequency (RF) Energy .......................................... 86
7
Hearing Aid Compatibility (HAC) regulations for Mobile
phones ............................................................................ 88
Distraction ....................................................................... 90
Product Handling ............................................................. 90
Electrical Safety ............................................................... 94
CTIA Requirements ......................................................... 95
Radio Frequency Interference .......................................... 96
Explosive Environments ................................................... 98
8
External screen
Headset jack
Auxiliary
microphone
Speaker
Back cover
Camera
Volume key
(up/down)
Getting Started
Getting to Know Your Phone
9
Internal screen
4-way navigation
and OK (center) key
Camera key
Send key
Delete key
Earpiece
Charging/
micro-USB jack
Left soft key
Recent apps key
Right soft key
Power/end key
Main microphone
10
Key
Function
Left soft
key/Right soft
key
Press to select the options that show on the
bottom line of the screen. The options change
depending on the application/function being
used.
Send key
Press to open the Recent Calls app or place a
call.
Recent apps
key
Press to see recently used applications.
Camera key
Press to launch the Camera app.
Delete key
Delete text before the cursor while editing text.
Power/end key
Press and hold to turn on or off airplane
mode, power off or restart the phone.
Press to end a call or cancel a call attempt.
Press to return to the home screen.
4-way
navigation and
OK key
From standby mode, press up/down/left/right
to activate pre-set functions.
Press up/down/left/right to move the
highlight or cursor on the screen.
Press the center to make selections.
Knowing the Keys
11
Key
Function
Volume key
Press or hold either end of the key to turn the
volume up or down.
Installing the micro-SIM Card and the
microSDHC™ card
Switch off your phone before installing or replacing the battery or
the micro-SIM card.
1. Insert your fingernail into the slot at the bottom left of the back
cover and lift it up gently.
2. Hold the micro-SIM card with the cut corner oriented as
shown and slip it into the card holder.
12
WARNING!
To avoid damage to the phone, do not use any other kind of
SIM card, or any non-standard micro-SIM card cut from a SIM
card. You can get a standard micro-SIM card from your
service provider.
This device uses a micro-SIM card only.
13
3. Hold the microSDHC card (not included) with the cut corner
oriented as shown and slip it into the card slot.
NOTE:
Some applications may require a microSDHC card to work
normally or may store certain data on it. Therefore, it is
recommended that you keep a microSDHC card installed and
not remove or replace it randomly.
4. Insert the battery by aligning the metal contacts on the
battery with the metal contacts in the battery compartment.
Gently push down on the battery until it clicks into place.
14
5. Align the back cover with the back of the phone and press the
cover back into place. Ensure that all the tabs are secure and
there are no gaps around the cover.
Charging the Battery
Your phone‟s battery should have enough power for the phone to
turn on, find a signal, and make a few calls. You should fully
charge the battery as soon as possible.
If the battery is low, there will be a pop-up message on the
screen. As you charge your phone, the screen will tell you the
exact battery level each time you wake up your phone.
WARNING!
Use only ZTE-approved chargers and cables. The use of
unapproved accessories could damage your phone or cause the
battery to explode.
15
1. Connect the adapter to the charging jack. Ensure that the
adapter is inserted with the correct orientation. Do not force
the connector into the charging jack.
2. Connect the charger to a standard AC wall outlet. If the phone
is on, you‟ll see a charging icon, such as or , appear
on the status bar.
3. Disconnect the charger when the battery is fully charged.
NOTE:
If the battery is extremely low, you may be unable to power on
the phone even when it is being charged. In this case, try again
after charging the phone for at least 10 minutes. Contact
customer service if you still cannot power on the phone after
prolonged charging.
16
Extending the Battery Life
Active applications, screen brightness levels and Bluetooth can
drain your battery. You can follow the helpful tips below to
conserve your battery power:
Reduce the screen backlight time.
Lower the screen brightness.
Turn Bluetooth off when not in use.
Powering On/Off
Press and hold the Power/end key to turn on your phone.
To turn it off, press and hold the Power/end key to open the
options menu and then select Power off.
Setting Up for the First Time
When you first power on your phone after you purchase it or
reset it to factory settings, you need to do some settings before
using it.
Select the language you want to use and then press the Right
soft key for Next. Then follow the on-screen prompts to set up
your phone.
17
Status &
Notifications
The function for
the Right soft key
The function for
the Left soft key
The function for
the OK key
Getting to Know Standby Mode
After power on your phone, the phone is in standby mode, the
standby mode is the starting point for your phone‟s applications,
functions, and menus.
18
Personalizing
Changing the System Language
1. From standby mode, press the OK key.
2. Press the 4-way navigation key and the OK key to select
Settings.
3. Select General settings > Language & input > Language.
4. Select the language you need.
Setting the Date and Time
1. From standby mode, press the OK key and choose
Settings.
2. Select General settings > Date & time.
3. Uncheck Automatic date & time and Automatic time zone
if you want to set the date, time and time zone by yourself.
4. Set the date, time, time zone, and date/time format.
Changing Ringtone and Notification
Sound
You can customize the default ringtone for incoming calls and the
default notification sound quickly.
19
1. From standby mode, press the OK key and choose Settings.
2. Select Profiles > General.
3. Press the Left soft key for Edit.
4. Select Phone ringtone or Default Notification ringtone.
5. Scroll through the ringtone list and select the ringtone you
want to use.
6. Press the Left soft key for Save.
NOTE:
See the chapter Contacts – Editing Contacts – Set a Ringtone for
a Contact for how to assign a special ringtone to an individual
contact.
Turning On/Off Key Tone
1. From standby mode, press the OK key.
2. Select Settings > Profiles > General.
3. Press the Left soft key for Edit.
4. Press the OK key to turn on or off the switch next to Key
tone.
Adjusting Volumes
1. From standby mode, press the OK key.
2. Select Settings > Profiles > General.
3. Press the Left soft key for Edit.
20
4. Select the type of audio.
5. Press the Left/Right navigation key to adjust the volumes.
NOTE:
You can adjust the media volume when a media application is in
use by pressing the Volume Up/Down key. If no media
application is active, press the Volume Up/Down key to adjust
ringtone volume (or the earpiece volume during a call).
Switching to Silent Mode
You can set the phone to silent mode by using one of the
following methods.
Keep pressing the Volume Down key when no media
application is active. When the icon appears on the
status bar, the phone is set to silent mode with vibration.
When the icon appears on the status bar, the phone is in
silent mode.
From standby mode, press the OK key. Select Settings >
Profiles > Silent only/Vibrate only.
Applying New Wallpapers
1. From standby mode, press the OK key and choose Settings.
2. Select General settings > Display.
3. Select Wallpaper and choose Gallery or Wallpapers.
4. Choose the image you want to use as the wallpaper, and then
press the OK key to finish.
21
Changing Screen Brightness
1. From standby mode, press the OK key and choose Settings.
2. Select General settings > Display > Brightness level.
3. Press the Left/Right navigation key to adjust the brightness
manually.
Enabling Anti-Theft
Anti-theft renders this phone inoperable when the device is lost
or stolen and the antitheft feature is initiated by an authorized
user. You can remotely ring or lock your device, erase everything
on it.
1. From standby mode, press the OK key and choose Settings.
2. Select Personal > Security > Anti-Theft.
3. Turn the Anti-Theft switch on, and follow the on-screen
prompts to finish the setup.
If you lose your phone, you can use the trusted email to send the
command (Lock, Alarm, or Factory data reset) to
phonenumber@mymetropcs.com.
NOTE:
The command must be listed in the email subject.
22
Protecting Your Phone With Screen
Locks
You can protect your phone by creating a screen lock. When it is
enabled, you need to enter a numeric PIN to unlock the phone.
1. From standby mode, press the OK key and choose Settings.
2. Select Personal > Security > Screen lock.
3. Select None or PIN.
Select None to disable the screen lock.
Select PIN to set a numeric PIN that you must enter to
unlock your screen.
23
4G LTE connected
Signal strength
4G connected
Mobile data in use
3G connected
Airplane mode
2G connected
Bluetooth on
No signal
Speaker on
Vibration on
Phone microphone off
Silent mode/no
interruptions
Alarm set
Battery low
/
Battery charging
Battery partially drained
Battery full
Knowing the Basics
Monitoring the Phone Status
The status bar at the top of the screen provides phone and
service status icons on the right side. Below are some of the
icons you may see.
24
New SMS
Song playing
New MMS
Downloading data
Missed call
USB connected
Call in progress
Wired headset connected
Managing Notifications
Notification Icons
The status bar at the top of the home screen provides notification
icons on the left. Below are some of the icons you may see.
Entering Text
You can enter text using the following input methods: T12 abc,
T12 Abc, T12 ABC, abc, Abc, ABC, and number input.
Current Text Mode
When you are in a field that allows characters to be entered, the
text input mode indicator is shown in the upper of the display.
Changing the Input Mode
Press and hold the # key and select an input method.
T12 abc/T12 Abc/T12 ABC Mode
The predictive text method is based on a built-in dictionary and
generates words from the combination of letters pressed.
25
Press each key once that corresponds to the letter you want
to enter. The letters are shown on the display as they are
entered. The list of candidate words changes as each key is
pressed.
Press the Up/Down navigation key to highlight a candidate
word and then press the OK key for select.
Press the 0 Key to insert a space, or press the * key to select
symbols.
Press the Delete key to delete the letter to the left of the
cursor. Press and hold the Delete key to delete all entered
text to the left of the cursor.
abc/Abc/ABC Mode
Press a number key (2 to 9) repeatedly until the required
character is shown on the screen. Press once to input the first
letter on the keypad, press twice quickly to input the second letter,
etc.
Press the 0 key to add a space.
123 Mode
When the input method icon is shown as 123, you can input
numbers directly using the number keys.
NOTE:
When using number input, you need to switch to other text input
methods if you want to insert a space by pressing the 0 key.
26
Special Symbols
1. Press the * key.
2. Use the 4-way navigation key to select a symbol.
3. Press the OK key for Select.
Input Settings
Choose input settings by pressing the OK key and choose
Settings > General settings > Language & input from standby
mode.
In the Keyboard & input methods section, you can set the
default input method and choose the settings for input methods.
Opening and Switching Apps
Open an App
1. From standby mode, press the OK key.
2. Press the 4-way navigation key and the OK key to select
and open the app.
Switch Between Recently Opened Apps
1. Press the Recent apps key.
A list of the names and thumbnails of apps you‟ve used
recently opens. If you‟ve been using more apps recently than
can fit on the screen, press the Up/Down navigation key
scroll the list up and down.
2. Press the OK key to open that app.
27
NOTE:
You can press the Left soft key for Clear all to remove all of
thumbnails from the list.
Connecting to Networks and
Devices
Connecting to Mobile Networks
Select Network Operator
1. From standby mode, press the OK key.
2. Select Settings > General settings > Mobile networks >
Network operators.
3. Select Search networks to search for all available networks.
4. Select a network in the network list to register manually.
You can also select Choose automatically to select
preferred network automatically.
Control Mobile Data Use
To enable or disable data access:
1. From standby mode, press the OK key.
2. Select Settings > General settings > Mobile networks.
3. Select Mobile Data to enable data access over the mobile
network. Select again to disable data access.
28
To get data services when roaming:
1. From standby mode, press the OK key.
2. Select Settings > General settings > Mobile networks.
3. Select Data roaming.
NOTE:
Data roaming may incur significant roaming charges.
Select Network Type
1. From standby mode, press the OK key.
2. Select Settings > General settings > Mobile networks >
Preferred network type.
3. Choose the type of network you prefer to connect to.
Set Access Point Names
To connect to the Internet you can use the default Access Point
Names (APN). And if you want to add a new APN, please contact
the service provider to get the necessary information.
1. From standby mode, press the OK key.
2. Select Settings > General settings > Mobile networks >
Access Point Names.
3. Press the Left soft key and choose New APN.
4. Select each item to enter the information you get from your
service provider.
5. Press the Left soft key and choose Save to complete.
29
NOTE:
To set the APN to default settings, Press the Left soft key and
choose Reset to default.
Connecting to Bluetooth® Devices
Bluetooth® is a short-range wireless communication technology.
Phones or other devices with Bluetooth capabilities can exchange
information wirelessly within a distance of about 10 meters. The
Bluetooth devices must be paired before the communication is
performed.
Turn Bluetooth On/Off
1. From standby mode, press the OK key.
2. Select Settings > General settings > Bluetooth.
3. Press the OK key.
When Bluetooth is on, the icon will appear in the status bar.
Change the Device Name
1. From standby mode, press the OK key.
2. Select Settings > General settings > Bluetooth.
3. Turn on the Bluetooth if Bluetooth is off.
4. Press the Left soft key and choose Rename this device.
5. Edit the name and press the OK key for Rename.
30
Loading...
