Page 1
TRULY
TIMELESS
Z353VL
USER
MANUAL
Z079584508048
ZTEUSA.COM
Page 2
About This Manual
Thank you for choosing this ZTE mobile device. In order to keep your device in its best condition,
please read this manual and keep it for future reference.
Copyright © 2016 ZTE CORPORATION
All rights reserved.
No part of this publication may be quoted, reproduced, translated or used in any form or by any
means, electronic or mechanical, including photocopying and microlm, without the prior written
permission of ZTE Corporation.
Notice
ZTE Corporation reserves the right to make modications on print errors or update specications in
this manual without prior notice. This manual has been designed with the utmost care to ensure the
accuracy of its content. However, all statements, information and recommendations contained therein
do not constitute a warranty of any kind, either expressed or implied. Please refer to chapter For Your
Safety to be sure to use your phone properly and safely.
We oer self-service for our smart terminal device users. Please visit the ZTE ocial website
(at www.ztedevice.com) for more information on self-service and supported product models.
Information on the website takes precedence.
Disclaimer
ZTE Corporation expressly disclaims any liability for faults and damages caused by unauthorized
modications of the software.
Images and screenshots used in this manual may dier from the actual product. Content in this
manual may dier from the actual product or software.
Trademarks
ZTE, Cymbal, and the ZTE logos are trademarks of ZTE Corporation. LTE is a trademark of ETSI.
Google and Android are trademarks of Google, Inc.
The Bluetooth® trademark and logos are owned by the Bluetooth SIG, Inc. and any use of such
trademarks by ZTE Corporation is under license.
The microSDHC™ logo is a trademark of SD-3C, LLC.
Qualcomm and Snapdragon are trademarks of Qualcomm Incorporated, registered in the United
States and other countries. Used with permission.
Other trademarks and trade names are the property of their respective owners.
Edition Time: July 2016
Table of Contents
Getting Started .................................. 5
Installing a microSDHC™ Card ................. 5
Charging the Battery ................................... 6
Extending the Battery Life......................... 6
Powering Your Phone On/O ................... 7
Setting Up Your Phone for the
First Time ......................................................... 7
Using the Touch Screen .............................. 7
Getting to Know Your Phone.................... 8
Getting to Know the Home Screen ........ 11
Personalizing ...................................... 13
Changing the System Language ............ 13
Setting the Date and Time ........................ 13
Changing the Ringtone and
Notication Sound ....................................... 13
Turning System Sounds On/O .............. 14
Adjusting Volumes ....................................... 14
Switching to Silent or
Vibration Mode ............................................. 14
Limiting Interruptions ................................ 15
Applying New Wallpapers ......................... 15
Changing the Screen Brightness ............ 16
Setting the Theme........................................ 16
Setting the Home Screen
Transition Eect ............................................ 16
Protecting Your Phone With
Screen Locks ................................................... 16
Protecting Your Phone With
Encryption....................................................... 17
Protecting Your Phone With
Screen Pinning .............................................. 18
Knowing the Basics .......................... 20
Monitoring the Phone Status ................... 20
Managing Notications .............................. 21
Managing Shortcuts and Widgets .......... 23
Organizing With Folders ............................ 24
Rearranging the Primary Shortcuts ....... 25
Opening and Switching Apps .................. 25
Entering Text .................................................. 26
Changing Input Methods .......................... 26
TouchPal Keyboard ...................................... 27
Google Keyboard.......................................... 30
Editing Text ..................................................... 32
Connecting to Networks
and Devices .......................................... 33
Connecting to Mobile Networks............. 33
Connecting to Wi-Fi® ................................... 33
Connecting to Bluetooth® Devices ......... 36
Connecting to Your Computer
via USB .............................................................. 38
Connecting to Virtual Private
Networks ......................................................... 40
1
Page 3
Table of ContentsTable of Contents
Phone Calls ........................................... 42
Placing and Ending Calls ........................... 42
Answering or Rejecting Calls ................... 42
Working With the Call History .................. 43
Calling Your Contacts .................................. 44
Checking Voicemail ..................................... 44
Using Options During a Call ..................... 45
Managing Multiparty Calls ........................ 45
Adjusting Your Call Settings ..................... 46
Contacts ................................................. 51
Checking Contact Details .......................... 51
Adding a New Contact ............................... 51
Setting Up Your Own Prole ..................... 51
Importing, Exporting, and
Sharing Contacts .......................................... 52
Working With Favorite Contacts ............. 53
Working With Groups .................................. 53
Searching for a Contact .............................. 54
Editing Contacts ........................................... 54
Accounts ................................................ 57
Adding or Removing Accounts ............... 57
Conguring Account Sync ........................ 57
Email ........................................................ 59
Setting Up the First Email Account ........ 59
Checking Your Emails .................................. 59
2
Responding to an Email ............................. 59
Writing and Sending an Email ................. 60
Adding a Signature to Your Emails ......... 61
Adding and Editing Email Accounts ...... 61
Changing General Email Settings ........... 62
Messaging ............................................ 63
Opening the Messaging Screen .............. 63
Sending a Text Message ............................. 63
Replying to a Message ................................ 64
Forwarding a Message ............................... 64
Deleting Messages or Threads ................. 64
Changing Message Settings ..................... 65
Calendar ................................................ 67
Viewing Your Calendars and Events ...... 67
Creating an Event ......................................... 67
Editing, Deleting, or Sharing
an Event ........................................................... 68
Changing Calendar Settings .................... 68
Searching an Event ...................................... 68
Browser .................................................. 69
Opening the Browser .................................. 69
Setting the Home Page .............................. 69
Changing Browser Settings ...................... 69
Camera ................................................... 70
Capturing a Photo ........................................ 70
Using Manual Camera Mode .................... 71
Using Other Camera Modes ..................... 71
Recording a Video ........................................ 72
Customizing Camera and
Video Settings................................................ 72
Gallery .................................................... 74
Opening the Gallery .................................... 74
Working With Albums ................................. 74
Working With Pictures ................................ 75
Playing Videos ............................................... 75
Music ....................................................... 76
Copying Music Files to Your Phone ........ 76
Viewing Your Music Library....................... 76
Playing Music ................................................. 77
Managing Playlists ....................................... 79
Video Player ......................................... 80
Opening the Video Library ........................ 80
Playing and Controlling Videos ............... 80
Managing Video Files .................................. 81
Sound Recorder ................................. 82
Recording a Voice Memo ........................... 82
Playing a Voice Memo ................................. 82
More Apps ............................................ 83
Calculator ........................................................ 83
Clock.................................................................. 83
Downloads ...................................................... 84
File Manager ................................................... 84
Task Manager ................................................. 85
Voice Dialer ..................................................... 85
Wi-Fi Utility ..................................................... 85
Google™ Apps ..................................... 86
Chrome™ ......................................................... 86
Drive™ ............................................................... 86
Gmail™ .............................................................. 86
Google .............................................................. 86
Hangouts™ ...................................................... 86
Maps™ ............................................................... 86
Photos............................................................... 86
Play Movies & TV ........................................... 86
Play Music........................................................ 87
Play Store ......................................................... 87
Voice Search™ ................................................ 87
YouTube™ ........................................................ 87
3
Page 4
Table of Contents
Getting Started
Settings .................................................. 88
General Settings ........................................... 88
Wireless and Networks ............................... 90
Device ............................................................... 90
Personal ........................................................... 92
System .............................................................. 94
Upgrading the Phone
Software ................................................ 95
Troubleshooting ................................ 96
For Your Safety ................................... 99
General Safety ............................................... 99
Radio Frequency (RF) Energy .................. 100
FCC Regulations ...........................................101
Hearing Aid Compatibility (HAC)
Regulations for Mobile Phones .............. 102
Distraction......................................................103
Product Handling ........................................ 103
Electrical Safety ............................................ 106
Radio Frequency Interference ................ 108
Explosive Environments ............................109
Specications .................................... 110
4
Installing a microSDHC Card (not included)
The microSDHC card can be installed and removed while
the phone is turned on. Unmount the microSDHC card
before removing it.
1. Place your nger in the slot at the bottom of the back
cover to lift and remove the cover. If the battery is
installed, remove it.
2. Hold your microSDHC card with the metal contacts facing
down and slide it into the microSDHC card slot. If the
battery is installed, remove it.
NOTE: Some applications may require a microSDHC card
to store certain data on it and to work properly. Therefore,
it isrecommended that you keep a microSDHC card installed
and not remove or replace it unnecessarily.
3. Insert the battery by aligning the metal contacts on the
battery with the metal contacts in the battery compartment.
Gently push down on the battery until it clicks into place.
4. Gently press the cover back into place following the
sequence shown here.
5
Page 5
Getting Started
Getting Started
Charging the Battery
Your phone’s battery should have enough power for the phone to turn on, nd a signal,
and make a few calls. You should fully charge the battery as soon as possible.
WARNING! Use only ZTE-approved chargers and cables.
The use of unapproved accessories could damage your
phone or cause the battery to explode.
1.
Connect the adapter to the charging port.
2. Connect the charger to a standard AC wall outlet. If the
phone is on, you’ll see a charging icon, such as or ,
appear in the Status Bar.
3. Disconnect the charger when the battery is fully charged.
NOTE: If the battery is extremely low, you may be unable to power on the phone even
when it is being charged. In this case, try again after charging the phone for at least
20 minutes. Contact customer service if you still cannot power on the phone after
prolonged charging.
Extending the Battery Life
Active applications, screen brightness levels, Bluetooth and Wi-Fi usage, and GPS
functionality can drain your battery. You can follow the helpful tips below to conserve
your battery power:
• Use the Battery saver feature in Settings.
• Reduce the screen backlight time.
• Lower the screen brightness.
• Turn auto-sync, Wi-Fi, and Bluetooth o when not in use.
• Disable the GPS function when not in use. Most applications using this function
will periodically query the GPS satellites for your current location; each query drains
your battery.
6
Powering Your Phone On/O
• Press and hold the Power/End Key to turn on your phone.
• To turn it o, press and hold the Power/End Key to open the options menu.
Tap Power o > OK.
NOTE: If the phone freezes or takes too long to respond, press and hold the Power/End
Key for about 10 seconds to power the phone o. Press and hold the Power/End Key to
turn the phone on again.
Setting Up Your Phone for the First Time
When you rst power on your phone after you purchase it or reset it to factory settings
(see Settings – Personal – Backup and Reset), you may need to set it up before using it.
1. Tap the language eld to select the language you want, and tap .
2. Follow the prompts to set up your Wi-Fi connection, Google account, Google services,
and other options.
Using the Touch Screen
Your phone’s touch screen lets you control actions through a variety of touch gestures.
• Tap – When you want to type using the on-screen keyboard, select on-screen items
(such as application and settings icons), or press on-screen buttons, simply tap them
with your nger.
• Press and Hold – To open the available options for an item (for example, a message or
link in a web page), press and hold the item.
• Swipe or Slide – To swipe or slide means to quickly drag your nger vertically or
horizontally across the screen.
• Drag – To drag, press and hold your nger with some pressure before you start to
move your nger. While dragging, do not release your nger until you have reached
the target position.
• Pinch – In some apps (such as Maps, Browser, and Gallery), you can zoom in and out by
placing two ngers on the screen at once and pinching them together (to zoom out)
or spreading them apart (to zoom in).
7
Page 6
Getting Started Getting Started
Getting to Know Your Phone
3.5 mm
Headset
Jack
Volume
Up/Down
Key
External
Screen
8 9
Auxiliary
Microphone
Speaker
Back
Camera
Battery
Cover
Proximity &
Light Sensor
Touch
Screen
4-way Navigation/
OK (center) Key
Back Key
Speaker Key
Camera Key
Send Key
Delete Key
Charging/
micro-USB Jack
Earpiece
Front Camera
Home Key
Recent Apps Key
Customizable Key
Messaging Key
Power/End Key
Main Microphone
Page 7
Getting Started Getting Started
Key Functions
Key Description
• Press and hold to turn Airplane mode on or o, restart,
Power/End Key
Home Key
Recent Apps Key Press to see recently used applications.
Back Key Press to go to the previous screen.
Volume Up/Down Key Press or hold to turn the volume up or down.
Speaker Key Press to turn speakerphone on/o during a call.
Camera Key
Customizable Key
Messaging Key Press to launch Messaging.
Send Key Press to launch the phone app or place a call.
Delete Key Press to delete text before the cursor.
4-Way Navigation Key
OK Key Press to select a highlighted item on the screen.
10 11
or to power o.
• Press to end or cancel a call.
• Press to return to the home screen.
• Press to return to the home screen from any application
or screen.
• Press and hold to access Google Now™.
Press to launch the camera or take a picture when the
Camera app is already launched.
Press to launch the assigned application (Music by default).
Press and hold to change the assigned application.
Press up/down/left/right to highlight items on the touch
screen or move the cursor.
Getting to Know the Home Screen
The home screen is the starting point for your phone’s applications, functions, and menus.
You can customize your home screen by adding application icons, shortcuts, folders,
widgets, and more.
Status &
Notications
Widget
Wallpaper
Shortcut
Primary
Shortcuts
Extended Home Screen Panels
Your home screen is extendable, providing more space for shortcuts, widgets, and more.
Simply swipe left or right on the home screen to see the extended panels. You can add or
remove home screen panels, or adjust their order.
Folder
Page 8
Getting Started
Personalizing
To add a new home screen panel:
1. Press the Home Key > , or press and hold an empty area of the home screen and
select Widgets.
2. Press and hold an application icon or a widget and drag it to the right edge of the
screen to create a new home screen panel and put the icon or widget on it.
To delete a home screen panel:
1. Press and hold an empty area of the home screen and slide left or right to view the
home screen thumbnails.
2. Tap on the top right corner of a thumbnail.
3. Tap OK. The items on the panel will also be removed.
NOTES:
• A home screen panel cannot be left empty. If the icon, widget, or folder is the only
item on the current home screen panel, the panel will be deleted as you remove
the item.
• When there are only three home screen panels, you cannot delete any of them.
To adjust the order of a home screen panel:
1. Press and hold an empty area of the home screen and slide left or right to view
the home screen thumbnails.
2. Press and hold a thumbnail and drag it left or right to the place you need.
NOTE: Tap at the bottom of a home screen thumbnail to set it as the main
home screen.
12 13
Changing the System Language
1. Press the Home Key > > Settings > Language & input > Language.
2. Select the language you need.
Setting the Date and Time
1. Press the Home Key > > Settings > Date & time.
2. Set the date, time, time zone, and date/time format.
• To adjust the date and time automatically, check Automatic date & time.
• To adjust the date and time manually, uncheck Automatic date & time and
tap Set date / Set time to change the date and time.
• To adjust the time zone automatically, check Automatic time zone.
• To adjust the time zone manually, uncheck Automatic time zone and tap
Select time zone to set the correct time zone.
•
To adjust the format of time and date, tap Use 24-hour format or Choose
date format.
Changing the Ringtone and Notication Sound
You can customize the default ringtone for incoming calls and the default notication
sound quickly.
1. Press the Home Key > > Settings > Sound & notications.
2. Tap Phone ringtone or Default notication ringtone.
3. Scroll through the list and select the ringtone you’d like to use.
4. Tap OK.
NOTE: See Contacts – Editing Contacts – Setting a Ringtone for a Contact for how to assign
a special ringtone to an individual contact.
Page 9
PersonalizingPersonalizing
Turning System Sounds On/O
1. Press the Home Key > > Settings > Sound & notications > Other sounds.
2. Tap Dialpad touch sounds, Key and touch sound, Screen lock sounds, or Vibrate
on touch to turn each option on or o.
3. Tap Emergency tone and select Alert, Vibrate, or Silent.
Adjusting Volumes
1. Press the Home Key > > Settings > Sound & notications.
2. Drag the sliders below Media volume, Alarm volume, Ring volume, and
Notication volume to adjust the volume for each type of audio.
NOTE: You can adjust the media volume when a media application is in use by pressing
the Volume Up/Down Key. If no media application is active, press the Volume Up/Down
Key to adjust ringtone volume (or the earpiece volume during a call).
Switching to Silent or Vibration Mode
You can set the phone to silent or vibration mode by using one of the following methods.
• Press the Volume Up/Down Key when no media application is active to show the
volume management window. Drag the slider to the left or keep pressing the Volume
Down Key to switch the phone to vibration mode. Press the key again in vibration
mode to switch the phone to silent mode.
• Swipe down from the top of the screen to open the Notication Panel and drag
the panel downward. Tap Vibrate or Mute to switch the phone to vibration or
silent mode.
• Press the Home Key > > Settings > Sound & notications > Interruptions >
When calls and notications arrive, and tap Don’t interrupt to switch the phone
to silent mode.
• Press the Home Key > > Settings > Sound & notications > Notication mode
and select Vibrate or Mute to switch to vibration or silent mode.
NOTES:
• In addition to silent mode and vibration, you can also allow priority apps to send out
notications when you switch the phone to priority interruption mode.
• To quickly switch to Vibrate Only Mode, press and hold the # Key on the keypad.
• To instantly turn o an incoming call ringtone or audio from a media application such
as Music, press the Mute Key.
Limiting Interruptions
You can limit ringtones and vibration caused by incoming calls, messages, and other
notications.
1. Press the Home Key > > Settings > Sound & notications > Interruptions >
When calls and notications arrive.
• Tap Always interrupt to allow all notications.
• Tap Allow only priority interruptions to select a time frame for priority interruptions.
Only allowed notications will disturb you with a ringtone or vibration. You can also
congure the Downtime section to allow priority interruptions to automatically turn
on or o.
• Tap Don’t interrupt to switch to silent mode.
NOTE: To stop limiting interruptions, you can press the Volume Up/Down Key to turn up
the ringtone volume.
Applying New Wallpapers
You can set the wallpaper for the home screen.
1. Press and hold an empty place on the home screen.
2. Tap Wallpapers.
3. Swipe left or right on the wallpaper panel to select a wallpaper, or tap GALLERY or
LIVE WALLPAPER to choose the image or animation you want to use as the wallpaper.
1514
Page 10
PersonalizingPersonalizing
NOTES:
• In addition, you can press the Home Key > > Settings > Display > Wallpaper
to pick an image from Gallery, Photos, Wallpapers, or an animation from
Live Wallpapers.
• Some cropping may be needed for Gallery and Photos images.
Changing the Screen Brightness
1. Press the Home Key > > Settings > Display > Brightness level.
2. Drag the slider to manually adjust the screen brightness.
NOTE: With the proximity and light sensor, your phone can automatically adjust the
screen brightness for available light. Tap Adaptive brightness in the Display settings
screen to turn the feature on or o.
Setting the Theme
1. Press and hold an empty place on the home screen.
2. Tap Themes.
3. Tap a theme to select it.
Setting the Home Screen Transition Eect
1. Press and hold an empty place on the home screen.
2. Tap Eects.
3. Tap an eect to select it.
Protecting Your Phone With Screen Locks
You can protect your phone by creating a screen lock. When enabled, you can press and
hold a blank area on the home screen, and then draw a pattern or enter a numeric PIN or
password to unlock the phone’s screen and keys.
16 17
1. Press the Home Key > > Settings > Security.
2. Tap Screen lock.
3. Tap None, PIN, or Password.
• Tap None to disable screen lock protection.
• Tap PIN or Password to set a numeric PIN or a password that you must enter to
unlock the screen.
NOTE: Remember the PIN or password you set. Otherwise, you will have to upgrade the
phone software to use the phone (see Upgrading the Phone Software).
Protecting Your Phone With Encryption
You can encrypt all the data on your phone: Google accounts, application data, music
and other media, downloaded information, and more. If you do, you must enter a
numeric PIN or password each time you power on your phone.
WARNING! Encryption is irreversible. The only way to revert to an unencrypted phone is
to perform a factory data reset, which erases all your data.
Encryption provides additional protection in case your phone is stolen, and may be
required or recommended in some organizations. Consult your system administrator
before turning it on. In many cases the PIN or password you set for encryption is
controlled by the system administrator.
Before turning on encryption, prepare as follows:
• Set a lock screen PIN or password.
• Charge the battery.
• Keep the phone connected to the charger.
• Schedule an hour or more for the encryption process. You must not interrupt it or you
will lose some or all of your data.
Page 11
Personalizing Personalizing
When you’re ready to turn on encryption:
1. Press the Home Key > > Settings > Security > Encrypt phone.
2. Read the information about encryption carefully.
The ENCRYPT PHONE button is dimmed if your battery is not charged or your phone
is not plugged in. If you change your mind about encrypting your phone, press the
Back Key.
WARNING! If you interrupt the encryption process, you will lose data.
3. Tap ENCRYPT PHONE.
4.
Enter your lock screen PIN or password and tap NEXT.
5. Tap ENCRYPT PHONE again.
The encryption process starts and displays its progress. Encryption can take
an hour or more, during which time your phone may restart several times.
When encryption is complete, you’ll be prompted to enter your PIN or password.
Subsequently, you must enter your PIN or password each time you power on your phone
to decrypt it.
Pinning a Screen
1. Ensure that screen pinning is turned on.
2. Open the app you want to keep in view.
3. Press the Recent Apps Key.
4. If there are many app tabs, swipe up to nd on the front-most tab.
5. Tap .
Unpinning the Screen
1. To unpin the screen and return to normal use, press and hold the Recent Apps Key.
2. If you have checked Ask for PIN / password before unpinning when pinning the
screen, swipe up on the lock screen and enter the PIN/password.
Protecting Your Phone With Screen Pinning
You can use the screen pinning feature to keep an app in view, so others cannot switch to
other apps or access your personal information.
Turning on Screen Pinning
1. Press the Home Key > > Settings > Security > Screen pinning.
2. Tap the On/O switch.
3. If you have set a screen lock, you can tap Ask for PIN / password before unpinning.
You will need to enter the PIN/password to unpin the screen.
18 19
Page 12
Knowing the Basics
Knowing the Basics
Monitoring the Phone Status
The Status Bar at the top of the home screen provides phone and service status icons on
the right side. Below are some of the icons you may see.
Indicators and Icons
Indicator What it means
2G connected
1x
3G connected
4G LTE connected
Ringer o
Vibration mode
Priority mode
Battery low
Battery partially drained
Battery full
Battery charging
/
Indicator What it means
Alarm set
No signal
Signal strength
Airplane mode
Bluetooth on
Connected to a Wi-Fi
network
Wi-Fi in use
Speaker on
Phone microphone o
GPS on
Managing Notications
The Status Bar at the top of the home screen provides notication icons on the left side.
Below are some of the icons you may see.
Indicators and Icons
Indicator What it means
New SMS
New MMS
New email
/
New Gmail message(s)
/
Missed call
Call in progress
Song playing
/
Indicator What it means
Upcoming event
New Wi-Fi network
detected
Downloading data
Sending data
USB connected
Updates available
Wired headset connected
2120
Page 13
Knowing the Basics
Knowing the Basics
Opening/Closing the Notication Panel
Notications report the arrival of new messages, calendar events, and alarms, as well as
ongoing events. You can open the Notication Panel to view the details of notications.
• To open the Notication Panel, swipe your nger down from the top of the screen.
• To close the Notication Panel, swipe your nger up
press the Back Key.
NOTE: You can also press and hold the 0 Key to open the Notication Panel.
from the bottom of the screen or
Responding to or Removing a Notication
In the Notication Panel, you can respond to a notication or remove the notications.
The Notication Panel also supports expandable notications that let you perform
additional actions right from the notication itself.
• To respond to a notication, tap it.
• Slide down with one nger to expand certain notications. You can also swipe two
ngers vertically or pinch-zoom to expand or collapse certain notications.
• To remove a notication, swipe it left or right.
• To remove all notications, tap .
• To manage notications you have received, press and hold a notication to identify
the application that created it. Depending on the notication, you can then tap and
select Block to hide future notications from this app, or tap Priority to show them in
priority mode.
• Most apps that send notications, such as Gmail, have notication settings that you
can adjust.
NOTE: If you turn o notications for an app, you may miss its important alerts and
updates. The notications of some apps cannot be turned o.
Using Quick Settings
The Quick Settings in the Notication Panel make it convenient to view or change the
most common settings for your phone.
22
Swipe down with two ngers from the top of the screen, or open the Notication Panel
and drag the panel downward to view the following Quick Settings.
• Sync: Tap to turn auto-sync of accounts data on or o. Press and hold to open the
Accounts menu in Settings.
• Sound: Tap to switch between Normal, Vibrate, and Mute.
• Battery Saver: Tap to turn on or o Battery saver.
• Location: Tap to turn on or o the location access function.
• Airplane: Tap to turn on or o airplane mode.
• Wi-Fi: Tap to turn on or o Wi-Fi.
• Data: Tap to enable or disable data access over the mobile network.
• Bluetooth: Tap to turn on or o Bluetooth.
• Brightness: Uncheck Auto and drag the brightness slider to adjust the
screen brightness.
NOTE: In the Quick Settings screen, tap at the top to access the Power manager
settings; tap to get to the Settings menu; tap to view your prole in Contacts;
tap EDIT at the bottom to change control switch position.
Managing Shortcuts and Widgets
Adding Shortcuts and Widgets
1. Press the Home Key > to add apps.
Or, to add widgets, press and hold an empty area of the home screen and
select Widgets.
2. Slide left or right to browse the available applications or widgets.
3. Press and hold a widget or an application icon and drag it to a home screen panel.
NOTE: While holding the item, you can drag it to the right edge of the screen to create a
new home screen panel and put the item on it.
23
Page 14
Knowing the Basics
Knowing the Basics
Moving Shortcuts or Widgets
1. Press and hold a widget or shortcut on the home screen.
2. Drag it to the place you need.
Removing Shortcuts or Widgets
1. Press and hold a widget or shortcut on the home screen.
2. Drag it to to remove it.
Adjusting Widget Size
1. Press and hold a widget on the home screen and then release it.
2. An outline appears around the widget. Drag the outline to resize the widget.
NOTE: Not all widgets can be resized.
Organizing With Folders
You can create folders on the home screen and add several shortcuts to a folder.
You can move or remove folders the same way as moving or removing shortcuts.
1. On the home screen, press and hold the shortcut you want to add into a folder.
2. Drag the shortcut to . A new folder will be created, and the shortcut is added into
the folder.
3. To add more shortcuts into the folder, press and hold each shortcut and drag it over
the folder before releasing it.
4. To remove a shortcut from a folder, tap the folder to open it. Press and hold the
shortcut and drag it to the home screen.
NOTES:
• Tap the folder and then tap the name eld to rename the folder.
• Drag the folder to to delete the folder and replace its shortcuts on the last
home screen.
24
Uninstalling or Disabling an Application
1. Press the Home Key > to open the application list screen.
2. Press and hold an application icon and drag the icon to or at the top of the
screen.
3. Tap OK to uninstall or disable the app.
NOTE: To nd the disabled applications, press the Home Key > > Settings > Apps >
DISABLED. You can then tap an application and tap ENABLE to enable it. Not all
applications can be uninstalled or disabled.
Rearranging the Primary Shortcuts
The home screen includes a customizable primary shortcuts area at the bottom of all home
screens. You can keep up to four items in the primary shortcuts area. Drag shortcuts or
folders in or out of the area to rearrange the area.
Opening and Switching Apps
Opening an App
1. Press the Home Key > .
2. Slide left or right on the screen and tap an app to open it.
Switching Between Recently Opened Apps
1. Press the Recent Apps Key. A list of the names and thumbnails of apps you’ve recently
used opens. If you’ve been using more apps recently than can t on the screen, you
can scroll the list up and down.
2. Tap a thumbnail to open that app.
25
Page 15
Knowing the Basics Knowing the Basics
NOTE: You can swipe a thumbnail left or right or tap on the thumbnail to remove it
from the list. Tap Clear all to remove all thumbnails.
Entering Text
You can enter text using the on-screen keyboard. Some apps open it automatically. In
others, you open it by tapping where you want to type. You can press the Back Key to
hide the on-screen keyboard. You can also enter text by speaking with the Google voice
typing feature.
TouchPal Keyboard
The TouchPal keyboard oers an input experience similar to a computer keyboard. To
change the language, swipe horizontally on the space bar key.
You can also use Curve® and Wave™ to speed up text input by replacing the key tapping
operation with a tracing gesture where you move your nger from letter to letter without
lifting the nger until you reach the end of the word.
Enabling or Disabling Input Methods
1. Press the Home Key > > Settings > Language & input.
2. Tap an item under Keyboard & input methods. You can set the current input method
and choose the settings for input methods.
NOTE: Some default input methods may not be disabled.
Changing Input Methods
1. When you use the on-screen keyboard to enter text, the icon appears in the
Status Bar.
NOTE: The icon appears only when more than one input methods is installed and
enabled for use.
2. Open the Notication Panel and tap Change keyboard.
3. Select the input method you need.
26 27
• The alphabetic keys: Tap the keys to enter letters. Tap a key and slide up to enter the
number or symbol on the key. You can also press and hold a key and slide to choose
more characters.
• The capital key: Tap to use uppercase. Double tap to lock uppercase. This
key also changes to indicate the current case you are using: for lowercase, for
uppercase, and when locked in uppercase.
• Word prediction: Press and hold and tap the Prediction switch to turn o or on
prediction.
• Pre-dened texts: Tap to enter digits and symbols. You can tap to go back
to the alphabetic keys. Tap to enter emoji or emoticons.
• The delete key: Tap to delete text before the cursor. You can also press and hold
the key to quickly delete multiple characters.
• Voice input: Press and hold the space bar and speak into the microphone.
• More options: Tap to access the quick settings of TouchPal keyboard, use voice
input, edit text, resize or split the keyboard, and more.
Page 16
Knowing the Basics Knowing the Basics
Curve - Word Gesture
Curve - Word gesture allows you to enter text by sliding your nger on the screen from
letter to letter to enter each word.
To enable and use Curve - Word gesture:
1. On the TouchPal keyboard screen, tap > Settings > Smart input and check
Curve® - Word gesture.
2. Tap > and tap inside a text eld to open the keyboard.
3. Move your nger from letter to letter on the keyboard to trace a word without lifting
the nger until you reach the end of the word.
End of the word
Start of the word
NOTES:
• Tap to type when you want to. If you want to enter a single letter, simply tap the
key once.
• Lift your nger at the end of the word. A space is added automatically when you begin
to trace the next word.
28 29
Wave - Sentence Gesture
Wave - Sentence gesture allows you to enter words by dragging candidate words to the
space key.
To enable and use Wave - Sentence gesture:
1. On the TouchPal keyboard screen, tap > Settings > Smart input and check Wave™
- Sentence gesture.
2. Tap > and tap inside a text eld to open the keyboard.
3. Tap or use Curve to enter the rst word. As the rst word appears on the text eld,
candidate words appear on the keyboard for you to choose from as the following word.
4. Drag the correct candidate word to the space key to add the word to the text eld.
NOTE: If none of the suggested words are correct, type the word as you normally would.
Page 17
Knowing the Basics Knowing the Basics
Google Keyboard
The Google keyboard provides a layout similar to a desktop computer keyboard.
• Tap the alphabetic keys to enter letters. Press and hold some specic keys to enter
associated accented letters or numbers. For example, to enter È, press and hold and
the available accented letters and number 3 appear. Then slide to choose È.
• Tap to use uppercase. Double-tap to lock uppercase. This key also changes color
to indicate the current case you are using.
• Tap to delete the text before the cursor.
• Tap to select numbers and symbols. You can then tap to nd more.
• Tap to enter miniature icons.
• Tap to use Google’s networked voice input.
• Press and hold > to change the input language or set up the Google keyboard.
Gesture Typing
The Google keyboard supports the gesture typing feature. You use this feature to input a
word by sliding through the letters.
To enable and use gesture typing:
1. On the Google keyboard, press and hold > > Google Keyboard Settings.
Or, tap Home Key > > Settings > Language & input > Google Keyboard.
30 31
2. Tap Gesture Typing > Enable gesture typing if the feature is turned o.
3. Move your nger from letter to letter on the keyboard to trace a word without lifting
the nger until you reach the end of the word.
End of the word
Start of the word
NOTES:
• Tap when you want to. If you want to enter a single letter, go ahead and tap.
• Lift your nger at the end of the word. A space is added automatically when you begin
to input the next word.
Google Voice Typing
Google voice typing uses the Google voice recognition service to convert speech to text.
You must have a data connection on a mobile or Wi-Fi network to use it.
1. Tap or > to access the voice typing feature.
2. When you see the microphone image, speak what you want to type.
3. You can continue entering text to keep it or to delete it.
NOTE: Say “comma,” “period,” “question mark,” “exclamation mark,” or “exclamation point ”
to enter punctuation.
Page 18
Knowing the Basics
Connecting to Networks and Devices
Input Method Settings
Choose the input method settings by pressing the Home Key > > Settings >
Language & input.
In the Keyboard & input methods section, you can set the current input method and
choose the settings for input methods.
Editing Text
• Move the insertion point: Tap where you want to type. The cursor blinks in the new
position, and a tab appears below it. Drag the tab to move the cursor.
• Select text: Press and hold or double tap within the text. The nearest word highlights,
with a tab at each end of the selection. Drag the tabs to change the selection. Tap
to select all the text.
• Cut or copy: Select the text you want to manipulate. Then tap or to cut or
copy the text to the clipboard.
• Replace text with the clipboard text: Select the text you want to replace.
Then tap or PASTE.
Connecting to Mobile Networks
Controlling Mobile Data Use
To enable or disable data access:
1. Press the Home Key > > Settings > Mobile networks.
2. Slide the Mobile Data switch to enable or disable mobile data use.
To get data services when roaming:
1. Press the Home Key > > Settings > Mobile networks.
2. Slide the Data roaming switch to enable or disable roaming.
NOTE: Data roaming may incur signicant roaming charges.
Setting Access Point Names
You can use the default Access Point Names (APNs) to connect to the Internet. To add a
new APN, you may need to contact your service provider for the required information.
1. Press the Home Key > > Settings > Mobile networks > Access Point Names.
2. Tap > New APN.
3. Tap each item to enter the required information.
4. Tap > Save.
NOTE: To set the APN to default settings, tap > Reset to default > CONTINUE.
Connecting to Wi-Fi
Wi-Fi is a wireless networking technology that can provide Internet access at distances of
up to 300 feet, depending on the Wi-Fi router and your surroundings.
Turning Wi-Fi On and Connecting to a Wi-Fi Network
1. Press the Home Key > > Settings > Wi-Fi.
2. Slide the Wi-Fi switch to the On position to turn on Wi-Fi.
32 33
Page 19
Connecting to Networks and DevicesConnecting to Networks and Devices
3. Tap a network name to connect to it.
4. If the network is secured, enter the password and tap CONNECT.
NOTE: Your phone automatically connects to previously used Wi-Fi networks when they
are in range.
Getting Notied of Open Networks
1. Press the Home Key > > Settings > Wi-Fi.
2. Slide the Wi-Fi switch to the On position.
3. Tap > Advanced.
4. Slide the Network notication switch to the On position.
When Wi-Fi is on, you receive notications in the Status Bar when your phone detects an
open Wi-Fi network. Slide the Network notication switch to the O position to turn
o notications.
Adding a Wi-Fi Network
You can add a Wi-Fi network if the network does not broadcast its name (SSID) or add a
Wi-Fi network when you are out of range.
To connect to a secured network, you rst need to get the security details from the
network’s administrator.
1. Press the Home Key > > Settings > Wi-Fi.
2. Slide the Wi-Fi switch to the On position.
3. Tap > Add network.
4. Enter the network SSID (name). If necessary, enter security or other network
conguration details.
5. Tap SAVE.
Forgetting a Wi-Fi Network
You can make your phone forget the details of a Wi-Fi network that you added—for
example, if you don’t want the phone to connect to it automatically or if it is a network
that you no longer use.
1. Press the Home Key > > Settings > Wi-Fi.
2. Slide the Wi-Fi switch to the On position.
3. Tap the Wi-Fi network name and then tap FORGET.
Connecting to a WPS Network
Wi-Fi Protected Setup (WPS) is a feature that makes it easy to add your phone to the
access points which supply WPS.
You can use one of the following methods to connect your phone to a wireless network
using WPS.
Method one: WPS button (Recommended)
1. Press the Home Key > > Settings > Wi-Fi.
2. Slide the Wi-Fi switch to the On position.
3. Tap > Advanced > WPS Push Button.
4. Press the WPS button on the wireless router and the access point will recognize your
phone and add it to the network.
Method two: PIN
1. Press the Home Key > > Settings > Wi-Fi.
2. Slide the Wi-Fi switch to the On position.
3. Tap > Advanced > WPS Pin Entry.
4. The WPS PIN displays on the screen. Enter the PIN into the access point’s setup page.
After entering the PIN, your phone automatically
the connection.
nds the access point and congures
3534
Page 20
Connecting to Networks and DevicesConnecting to Networks and Devices
NOTE: For detailed information about the WPS feature of the access point, please refer to
its documentation.
Adjusting Advanced Wi-Fi Settings
1. Press the Home Key > > Settings > Wi-Fi.
2. Tap > Advanced to adjust the following settings.
• Network notication: Enable to be notied whenever a public network is available.
• Scanning always available: Let Google’s location service and other apps scan for
networks, even when Wi-Fi is o.
• Keep Wi-Fi on during sleep: Choose whether or not to keep Wi-Fi on in Sleep mode.
• Install certicates: Check the installed certicates.
• WPS Push Button: Connect to a WPS network via the push button method.
• WPS Pin Entry: Connect to a WPS network via the phone PIN method.
• MAC address: Check the MAC address.
• IP address: Check the phone’s IP address.
Connecting to Bluetooth Devices
Bluetooth is a short-range wireless communication technology. Phones or other
devices with Bluetooth capabilities can exchange information wirelessly within a
distance of about 30 feet (10 meters). The Bluetooth devices must be paired before
the communication is performed.
Turning Bluetooth On/O
1. Press the Home Key > > Settings > Bluetooth.
2. Slide the Bluetooth switch to the On or O position.
When Bluetooth is on, the icon will appear in the Status Bar.
36 37
Changing the Device Name
1. Press the Home Key > > Settings > Bluetooth.
2. Slide the Bluetooth switch to the On position if Bluetooth is o.
3. Tap > Rename this device.
4. Edit the name and tap RENAME.
Pairing With Another Bluetooth Device
1. Press the Home Key > > Settings > Bluetooth.
2. Slide the Bluetooth switch to the On position if Bluetooth is o.
Your phone automatically scans for and displays the IDs of all available Bluetooth
devices in range. Tap > Refresh if you want to scan again.
3. Tap the device you want to pair with.
4. If necessary, conrm that the Bluetooth passkeys are the same between the two
devices and tap PAIR. Alternately, enter a Bluetooth passkey and tap PAIR.
Pairing is successfully completed when the other device accepts the connection or
the same passkey is entered.
NOTE: The Bluetooth passkey may be xed for certain devices, such as headsets and
hands-free car kits. You can try entering 0000 or 1234 (the most common passkeys) or
refer to the documents for that device.
Forgetting a Bluetooth Device
You can make your phone forget its pairing connection with another Bluetooth device.
To connect to the device again, you need to search for it and enter or conrm a
passkey again.
1. Press the Home Key > > Settings > Bluetooth and ensure that Bluetooth is
turned on.
2. In the list of paired devices, tap beside the Bluetooth device you want to forget.
3. Tap FORGET.
Page 21
Connecting to Networks and DevicesConnecting to Networks and Devices
•
Sending Data via Bluetooth
1. Open the appropriate application and select the le or item you want to share.
2. Select the option for sharing via Bluetooth. The method may vary by application and
data type.
3. Tap a Bluetooth device the phone has paired with or wait for it to search for new
devices and tap one of them.
Receiving Data via Bluetooth
1. Turn Bluetooth on before trying to receive data via Bluetooth.
2. Swipe down on the Status Bar and tap .
3. Tap ACCEPT to start receiving the data.
Depending on your storage setting and whether a microSDHC card is installed, received
les are stored automatically in a dedicated folder (Bluetooth, for instance). You can
access them with the File Manager app. Received contacts (vCard les) are automatically
imported to your contact list.
Connecting to Your Computer via USB
You can connect your phone to a computer with a USB cable and transfer music, pictures,
and other les in both directions. Your phone stores these les in internal storage or on a
removable microSDHC card.
Connecting Your Phone to a Computer via USB
1. Connect your phone to the PC with a USB cable.
2. Choose one of the following options:
• Charge only: Charge your phone via USB.
• Install driver: Select this option when features (Connect to PC software, Media
device) are enabled for the rst time, or when they’re unavailable.
NOTE: You can also install the driver on the PC by running the executable le in the
new CD-ROM drive.
38 39
Media device (MTP): Transfer media les on Windows, or using Android™ File Transfer
on Mac®.
NOTE: For Windows® XP, install the drivers and Windows Media® Player 11 (or later
version) when you use Media device (MTP) for the rst time.
• Camera (PTP): Transfer photos using camera software.
NOTE: To make your phone connect to the computer automatically using the selected
connection type, check Don’t ask me again.
Connecting with Windows Media Player
You can sync music, picture, and video les from the computer to your phone via
Windows Media Player on the computer.
1. Connect the phone with your computer via USB and choose Media device (MTP).
2. Open Windows Media Player and synchronize music, picture, and video les.
Disconnecting Your Phone From the Computer
To disconnect the phone from the computer, simply unplug the USB cable when
you’re nished.
Removing the microSDHC Card From Your Phone
If you need to remove the microSDHC card while the phone is on, you should unmount
it rst.
1. Press the Home Key > > Settings > Storage.
2. Scroll down and tap Unmount SD card > OK.
3. The icon appears in the Status Bar and you can now safely remove the microSDHC
card from the phone.
NOTE: If you unmount the microSDHC card, some apps that you are using will stop and
may be unavailable until you remount the microSDHC card.
Page 22
Connecting to Networks and Devices
Connecting to Networks and Devices
Erasing the microSDHC Card
1. Press the Home Key > > Settings > Storage.
2. Scroll down the screen and tap Erase SD card > ERASE SD CARD > ERASE
EVERYTHING.
CAUTION: The formatting procedure erases all the data on the microSDHC card, after
which the les CANNOT be retrieved.
Connecting to Virtual Private Networks
Virtual private networks (VPNs) allow you to connect to the resources inside a secured
local network. VPNs are commonly deployed by corporations, schools, and other
institutions to let people access local network resources when not on campus, or when
connected to a wireless network.
Depending on the type of VPN you are using, you may be required to enter your login
credentials or install security certicates before you can connect to your VPN. You can get
this information from your network administrator.
NOTE: You need to set a lock screen pattern, PIN, or password before you can use
credential storage (VPN).
Connecting to a VPN
1. Press the Home Key > > Settings > More > VPN.
2. Tap the VPN that you want to connect to.
3. When prompted, enter any requested credentials and then tap CONNECT.
When you are connected, the VPN connected icon appears in the Status Bar.
Modifying a VPN
1. Press the Home Key > > Settings > More > VPN.
2. Press and hold the VPN that you want to modify.
3. Tap Edit prole.
4. Edit the VPN settings and tap SAVE.
Adding a VPN
1. Press the Home Key > > Settings > More > VPN.
2. Tap and enter the VPN name and server address.
3. Tap the check box beside Show advanced options.
4. Enter the server address and other information provided by your network
administrator.
5. Tap SAVE.
The VPN is added to the list on the VPN screen.
40 41
Page 23
Phone Calls
Phone Calls
You can place calls from the Phone app, the Contacts app, or other apps or widgets that
display contact information. Wherever you see a phone number, you can usually tap it
to dial.
Placing and Ending Calls
Placing a Call by Dialing
1. Press the Home Key, then enter the phone number with the keypad. Press the
Delete Key to delete incorrect digits.
NOTE: As you enter digits, your phone searches for contacts that match. If you see the
number you want to dial, tap it to place the call immediately without entering the rest
of the number.
2. Press the Send Key to dial.
NOTES:
• To make an international call, press and hold the * Key to enter the plus (+) symbol.
Next, enter the country code followed by the city/area code and then the phone
number.
•
To redial the last call you made, press the Home Key > then press the Send Key twice.
Ending a Call
During a call, tap on the screen or press the Power/End Key.
Answering or Rejecting Calls
When you receive a phone call, the Incoming Call screen opens, displaying the Caller
ID or the information about the caller that you’ve entered in the Contacts app. You can
answer or reject the call, or reject it with a text message.
42 43
Answering a Call
When you receive a phone call, slide (Slide down to answer) down to
answer the call.
NOTE: To silence the ringer before answering the call, press the Volume Up/Down Key.
Rejecting a Call
When you receive a phone call, slide
the call.
You can also slide up to reject the call and send a preset text message to the caller.
NOTE: To edit the text response from within the Phone app, tap > Call Setting >
Quick responses.
(Slide up to decline) up to reject
Working With the Call History
The call history is a list of all the calls you’ve placed, received, or missed. It provides a
convenient way to redial a number, return a call, or add a number to your Contacts.
To open the call history, press the Home Key > > Call History.
Placing a Call from the Call History
1. Open the call history.
2. Press up or down on the 4-Way Navigation Key to select a listing and then press the
Send Key.
NOTE: You can tap MISSED, OUTGOING, or INCOMING to lter the records by call type.
Adding a Call History Number as a Contact
1. Open the call history.
2. Tap the circle in front of a number.
3. Tap on the contact information tab.
4. To add the number to an existing contact, tap a contact in the list. To add a new
contact, tap in the top right corner.
Page 24
Phone Calls
Phone Calls
Taking Other Actions on a Call History Entry
1. Open the call history.
2. Tap a number to view more call information. While viewing the call details, you can:
• Tap > Edit number before call to edit the number in the dialer before calling it.
• Tap the circle in front of an entry to open the contact information tab from the
bottom of the screen. You can send a message, call back, edit the contact, add the
contact to favorites, or add the number to contacts.
• Tap to delete the entry.
NOTE: You can tap > Clear call log in the call history screen to delete all history records.
Calling Your Contacts
Calling a Contact
1. Press the Home Key > Contacts.
2. Press up or down on the 4-Way Navigation Key to select a listing and then press
the Send Key.
Checking Voicemail
If you have set the phone to divert certain calls to voicemail, callers can leave voicemail
messages when they cannot reach you. Here’s how to check the messages they left.
1. From the home screen, press and hold the 1 Key on the keypad. If prompted, enter
your voicemail password.
2. Follow the voice prompts to listen to and manage your voicemail messages.
NOTE: See Phone Calls – Adjusting Your Call Settings – Setting Voicemail for how to set your
voicemail service. For detailed information, please contact your service provider.
44 45
Using Options During a Call
During a call, you will see a number of on-screen options. Tap an option to select it.
• Tap to view all call options.
• Tap to turn the speaker on or o.
• Tap to mute or unmute the microphone.
• Tap
• Tap
• Tap to go to contacts.
• Tap to merge the separate calls into a single conference call.
• Tap to put the caller you are speaking to on hold, and switch to the other call that
• Tap to end the current call.
WARNING! Because of higher volume levels, do not place the phone near your ear during
speakerphone use.
to make another call separately from the rst call, which is put on hold.
to go to your messaging inbox.
has been put on hold.
Managing Multiparty Calls
When the call waiting and three-way call features are available, you can switch between
two calls or set up a conference call.
NOTE: The call waiting and three-way call features need network support and may result
in additional charges. Please contact your service provider for more information.
Switching Between Current Calls
When you’re on a call, your phone screen informs you that another call is coming in and
displays the caller ID.
To respond to an incoming call while you’re on a call:
• Tap (Answer) to answer the call. This puts the rst caller on hold and
answers the second call.
Page 25
Phone Calls
Phone Calls
• Tap to reject the second call.
• Tap to reject the second call and select a preset text message or edit one to send
to the caller.
To switch between two calls:
Tap > .
Setting Up a Conference Call
With this feature, you can talk to two people at the same time.
1. Place the rst call.
2. Once you have established the connection, tap > and dial the second number.
This puts the rst caller on hold.
3. When you’re connected to the second party, tap .
If one of the people you called hangs up during your call, you and the remaining
caller stay connected. If you initiated the call and are the rst to hang up, all callers are
disconnected.
To end the conference call, tap .
Adjusting Your Call Settings
Setting Contact Display Options
You can set the order of the contacts displayed in the Contacts app.
1. Press the Home Key > > Contacts > > Settings.
2. Tap Sort list by or View contact names to set the order of the contacts and the format
of the contact names.
46 47
Setting Sound and Vibration
Set the sound and vibration for incoming calls as well as dial pad sounds.
Press the Home Key > > Settings > Sound & notications.
• Tap Other sounds, then tap the on/o switch next to Dialpad touch sounds to hear a
sound when you press the dial pad keys or turn o dial pad sound.
• Tap Notication mode and select Vibrate when ringing to enable vibration for
incoming calls.
NOTE: You can set the vibration pattern for incoming call notications. Press the
Home Key > > > Call Setting > Vibrate pattern and select one.
Editing Quick Response to Rejected Callers
1. Press the Home Key > > > Call Setting > Quick responses.
2. Tap a text message to edit it.
3. Tap OK to save the message.
Setting Voicemail
1. Press the Home Key > > > Call Setting.
2. Tap Voicemail to congure voicemail settings.
• Tap Service to select the voicemail service provider. Your carrier is the default.
• Tap Setup > Voicemail number to view or edit the voicemail number.
• Tap Sound to select the notication sound for new voicemails.
• Check Vibrate to enable vibration for notication.
Setting the Flip Phone Action
You can answer a call by simply opening the ip phone.
1. Press the Home Key > > > Call Setting.
2. Check Open to answer.
Page 26
Phone Calls
Phone Calls
Setting TTY Mode
Your phone is a TTY compatible device. A TTY device can allow people who have hearing
or speech disabilities to communicate by telephone. Simply connect the TTY device to
the phone’s headset jack.
Select a TTY mode for your phone to work with a TTY device, or turn TTY o.
1. Press the Home Key > > > Call Setting > TTY mode.
2. Select one of the following options. Consult your teletypewriter manufacturer’s
manual if necessary.
• TTY O: Users who can hear and talk can disable TTY support.
• TTY Full: Users who cannot talk or hear may use this mode to send and receive text
messages through TTY device.
• TTY HCO: Users who can hear, but cannot talk, may use this mode to listen to
conversation of the other party, and respond via text messages.
• TTY VCO: Users who can talk, but cannot hear, may use this mode to talk through
the phone and receive responses via text messages.
Setting Hearing Aids
Your phone supports HAC (Hearing Aid Compatibility) function. When you turn on the
hearing aid compatibility and use a hearing aid with a Telecoil to answer the phone, it will
help you hear more clearly during the phone call.
1. Press the Home Key > > > Call Setting.
2. Check Hearing aids to turn on hearing aid compatibility.
CAUTION: Do not turn on the Hearing aids option unless you use a hearing aid with a
telecoil. Using this setting without a hearing aid or with a hearing aid without a telecoil
may be harmful to your hearing.
48
Setting Speed Dials
You can press and hold the 1-9 Keys from the dialer to call the corresponding speed
dial number.
The number 1 Key is reserved to speed dial your voicemail.
To assign a speed dial key:
1. Press the Home Key > > > Call Setting > Speed dial.
2. Tap a speed dial entry.
3. Enter a phone number or tap to select one from the contact list.
4. Tap OK.
Setting DTMF Tones
You can set the length of dual-tone multi-frequency (DTMF) signal tones.
1. Press the Home Key > > > Call Setting > DTMF tones.
2. Tap Normal or Long.
Call Ended Operation Tips
When this feature is enabled, the phone will prompt you to call back, send a message to
the contact, or add the new number to your contacts after you nish a call.
1. Press the Home Key > > > Call Setting.
2. Check Call ended operation tips to enable this feature.
Answering Calls Automatically
You can set the phone to answer calls automatically.
Press the Home Key > > > Call Setting > Auto answer.
• Tap Call duration to set how long the phone should wait before answering the call.
•
Tap Auto answer conditions and select an option for when auto answer should function.
49
Page 27
Phone Calls
Contacts
Forwarding Incoming Calls
The call forwarding feature allows you to forward your incoming calls to another
phone number.
1. Press the Home Key > > > Call Setting > Call forwarding.
2. Tap an available option (Always forward, Forward when busy, Forward when
unanswered, or Cancel All Forwarding) to enable it.
Voice Privacy
1. Press the Home Key > > > Call Setting > Additional settings.
2. Check Voice privacy to enable this feature.
Plus Code Dialing Setting
Plus Code Dialing allows the phone to automatically dial the international access code for
your location when you press and hold the * Key on the keypad.
To activate Plus Code Dialing:
1. Press the Home Key > > > Call Setting > Additional settings > Plus code
dialing setting.
2. Check Setup Plus Code Replacement to replace + with the international dialing code.
To change the international dialing code:
1. Press the Home Key > > > Call Setting > Additional settings > Plus code
dialing setting > Replace Code of Plus Code.
2. Enter a new code and tap OK.
50 51
You can add contacts on your phone and synchronize them with the contacts in your
Google account or other accounts that support contact syncing.
To see your contacts, press the Home Key > > Contacts > CONTACTS. From there, you
can tap the tabs to quickly switch to your contact groups or favorite contacts.
Checking Contact Details
1. Press the Home Key > > Contacts > CONTACTS.
2. Scroll through the list to view all your contacts.
3. Tap a contact to view its details.
NOTE: If you have a lot of contacts stored, you’ll see a slider on the right side of the
screen. To go directly to a letter, press and hold the slider and drag it to a letter.
Adding a New Contact
1. Press the Home Key > > Contacts > CONTACTS.
2. Tap to add a new contact.
NOTE: If you have no contacts added yet, tap CREATE A NEW CONTACT.
3. Tap the account eld to choose where to save the contact. If a sync account is selected,
the contacts will be synced automatically with your account online.
4. Enter the contact name, phone numbers, email addresses, and other information.
5. Tap to save the contact.
Setting Up Your Own Prole
You can create your own name card in your phone.
1. Press the Home Key > > Contacts > CONTACTS.
2. Tap Set up my prole. If a prole has been set up, tap the listing below ME and tap .
3. Edit your prole information. Tap ADD ANOTHER FIELD to add more information if
you want.
4. Tap to save.
Page 28
Contacts
Contacts
Importing, Exporting, and Sharing Contacts
You can import/export contacts to/from the phone storage or a microSDHC card. This is
especially useful when you need to transfer contacts between dierent devices. You can
also quickly share your contacts using Bluetooth, Email, Messaging, Google Drive,
or Gmail.
Importing Contacts From the microSDHC Card or Phone Storage
1. Press the Home Key > > Contacts.
2. Tap
> Import/Export > Import from storage.
3. If you have added contact accounts other than the phone, select an account in which
to save the contacts.
4. Select the vCard le(s) in the microSDHC card or the phone storage.
Exporting Contacts to the microSDHC Card or Phone Storage
1. Press the Home Key > > Contacts.
2. Tap
> Import/Export > Export to storage.
3. The phone will prompt you with the name of the vCard le. Tap OK to create the le.
NOTE: If the microSDHC card is not installed in the phone, you can export vCard le(s) to
the phone storage.
Sharing Contacts
1. Press the Home Key > > Contacts > CONTACTS.
2. Tap
> Multi-Select.
3. Tap the contacts you want to share to select them and then tap .
4. Choose to share the contacts via Messaging, Bluetooth, Drive, Email, or Gmail.
Working With Favorite Contacts
You can add the contacts you use frequently to FAVORITES so that you can nd
them quickly.
Adding a Contact to Favorites
1. Press the Home Key > > Contacts > CONTACTS.
2. Tap a contact and then tap at the top of the screen.
Removing a Contact from Favorites
1. Press the Home Key > > Contacts > FAVORITES.
2. Tap a favorite contact and then tap .
Working With Groups
Viewing Your Contact Groups
1. Press the Home Key > > Contacts > GROUPS.
2. Scroll through the list to view the preset groups and any groups you have created.
3. Tap a group to view its members.
NOTE: To send a message or an email to the group members, tap a group > >
Send Group message/Send Group email after you open the group.
Setting Up a New Group
1. Press the Home Key > > Contacts > GROUPS.
2. Tap to create a new group.
3. If you have added contact accounts other than the phone, tap to choose an account
for the new group.
4. Tap Group’s name and enter a name.
5. Tap Add member and select the contacts you wish to be the group members.
6. Tap .
5352
Page 29
Contacts
Contacts
7. If necessary, tap Default below RingTone to set a special ringtone for incoming calls
from the group members, and then tap OK.
8. Tap to save the group.
Deleting a Group
1. Press the Home Key > > Contacts > GROUPS.
2. Tap a group and then tap > Delete Group.
3. Tap OK.
Editing a Group
1. Press the Home Key > > Contacts > GROUPS.
2. Tap a group >
3. Tap the group name to edit it, or tap the eld below MEMBER or RingTone to add
more members or change the ringtone.
NOTE: To remove group members, tap a group and then tap > Multi-Select and select
the members you would like to remove. Tap > OK.
> Edit.
Searching for a Contact
1. Press the Home Key > > Contacts and then tap to search.
2. Input the contact name you want to search for. The contacts matched will be listed.
Editing Contacts
Editing Contact Details
1. Press the Home Key > > Contacts > CONTACTS.
2. Tap a contact and then tap .
3. Edit the contact and tap .
54
Setting a Ringtone for a Contact
Assign a special ringtone to a contact, so you know who is calling when you hear
the ringtone.
1. Press the Home Key > > Contacts > CONTACTS.
2. Tap a contact you want to set a ringtone for and then tap
3. Select a ringtone you like and tap OK.
> Set ringtone.
Deleting a Contact
1. Press the Home Key > > Contacts > CONTACTS.
2. Tap a contact you want to delete and then tap > Delete.
3. Tap OK to conrm.
Deleting Several Contacts
1. Press the Home Key > > Contacts > CONTACTS.
2. Tap > Multi-Select.
3. Tap to select the contacts you want to remove and then tap .
4. Tap OK to conrm.
Joining Contacts
As your phone synchronizes with multiple online accounts, you may see duplicate entries
for the same contact. You can merge all the separate information of a contact into one
entry in the Contacts list.
1. Press the Home Key > > Contacts > CONTACTS.
2. Tap a contact to display the contact’s details.
3. Tap > > Join.
4. Tap the contact whose information you want to join with the rst entry.
55
Page 30
Contacts
Accounts
NOTES:
• The information from the second contact is added to the rst, and the second
contact is no longer displayed in the contacts list.
• You can repeat these steps to join another contact to the main contact.
5. Tap to save the joined contact.
Separating Contact Information
If contact information from dierent sources was joined in error, you can separate the
information back into individual contacts on your phone.
1. Press the Home Key > > Contacts > CONTACTS.
2. Tap a contact you want to separate.
3. Tap > > Separate.
4. Tap OK to conrm.
Adding or Removing Accounts
You can add multiple Google accounts and Microsoft Exchange ActiveSync® accounts.
You may also add other kinds of accounts, depending on the apps installed on your phone.
Adding an Account
1. Press the Home Key > > Settings > Accounts > Add account.
2. Tap the type of account you want to add.
3. Follow the on-screen steps to enter the information about the account. Most accounts
require a username and password, but the details may vary. You may also need to
obtain some information from IT support or your system administrator.
When the account is successfully added, it is displayed in the Accounts menu in Settings.
Removing an Account
Removing an account will delete it and all information associated with it from your
phone, such as emails and contacts.
1. Press the Home Key > > Settings > Accounts.
2. Tap the account category and then tap the account you'd like to remove.
3. Tap > Remove account > REMOVE ACCOUNT.
Conguring Account Sync
Conguring Auto Sync Setting
1. Press the Home Key > > Settings > Accounts.
2. Tap and check or uncheck Auto-sync data to enable or disable automatic sync.
• When automatic sync is turned on, changes you make to information on your phone
or on the web are automatically synced with each other.
• When automatic sync is turned o, you need to sync manually to collect emails,
updates, or other recent information.
56 57
Page 31
Accounts
Email
Syncing Manually
1. Press the Home Key > > Settings > Accounts.
2. Tap the account category and then the account you want to sync.
3. Tap > Sync now.
Changing an Account’s Sync Settings
1. Press the Home Key > > Settings > Accounts.
2. Tap the account category and then the account. The Sync settings screen appears,
showing a list of information the account can sync.
3. Check or uncheck items as you need. Checked types of information on the phone and
the web will be kept in sync when auto-sync is turned on. When auto-sync is disabled,
tap a listing to sync that type of information between the phone and the web.
Press the Home Key > . Use it to read and send emails from Microsoft Exchange
ActiveSync, Gmail, Hotmail, Yahoo!®, and more.
Setting Up the First Email Account
1. Press the Home Key > .
2. Tap an email type, and then enter your email address and password.
3. Tap Next to let the phone retrieve the network parameters automatically.
NOTE: You can also enter these details manually by tapping Manual setup or if
automatic setup fails.
4. Follow the on-screen instructions to nish setup.
Your phone will show the inbox of the email account and start to download email
messages.
Checking Your Emails
Your phone can automatically check for new emails at the interval you set when setting
up the account.
You can also check new emails manually by swiping down on the message list. Tap Load
more messages at the bottom of the email list to download earlier messages.
Responding to an Email
You can reply to or forward a message that you receive. You can also delete messages and
manage them in other ways.
Replying to or Forwarding an Email
1. Open the email you want to reply to or forward from the Inbox.
2. Choose one of the following:
• To reply to the sender, tap .
• To reply to the sender and all recipients of the original message, tap .
5958
Page 32
Email
Email
• To forward the message, tap .
3. Edit your message and tap .
Marking an Email as Unread
You can return a read email to the unread state— for example, to remind yourself to read
it again later. You can also mark a batch of emails as unread.
• While reading a message, tap > Mark as unread.
• While in a message list (for instance, the inbox), tap the checkboxes before the
messages and then tap .
Deleting an Email
You can delete an email from its folder. You can also delete a batch of emails.
• While reading a message, tap > OK.
• While in a message list (for instance, the inbox), tap the checkboxes in front of the
messages and then tap > OK.
Writing and Sending an Email
1. Open your email Inbox and tap .
NOTE: If you have more than one email account added on the phone, tap the sender
line to select the account you want to use for sending the message.
2. Enter a contact name or email address in the To eld. Separate each recipient with a
comma. You can also tap to select recipients from your contacts.
NOTE: Tap > Add Cc/Bcc to send a carbon copy or blind carbon copy to other
recipients.
3. Enter the email subject and compose the email text.
4. Tap > Attach le to add audio les, images, videos, and other types of les as
attachments.
5. Tap at the top of the screen to send the message.
Adding a Signature to Your Emails
You can set a few lines of plain text as a signature for every outgoing email message from
an account, such as your name and contact information.
1. Open the Email app.
2. Tap > Settings and select the account you want to add a signature to.
3. Tap Signature and enter the text.
4. Tap OK.
Adding and Editing Email Accounts
Adding an Email Account
After setting up your rst email account (see Email – Setting Up the First Email Account),
you can add more email accounts and manage them separately.
1. Open the Email app.
2. Tap > Settings and tap at the top right of the screen.
3. Set up the account as you did with the rst one.
Editing an Email Account
You can change a number of settings for an account, including how often you check for
email, how you’re notied of new emails, and details about the servers the account uses
to send and receive emails.
1. Open the Email app.
2. Tap > Settings and tap the account whose settings you want to change.
3. Make the changes you want and press the Back Key when you’re nished.
6160
Page 33
Email
Messaging
Removing an Email Account
1. Open the Email app.
2. Tap > Settings and tap the account you want to remove.
3. Tap Remove account > OK.
Changing General Email Settings
General settings apply to all email accounts you add.
1. Open the Email app.
2. Tap > Settings > General.
3. Make the changes you want and press the Back Key when you’re nished.
You can use Messaging to exchange text messages (SMS) and multimedia messages (MMS).
Opening the Messaging Screen
Press the Home Key > .
NOTE: You can also press the Messaging Key to launch Messaging.
The Messaging screen opens where you can create a new message, search for messages,
or open an ongoing message thread.
• Tap to write a new text or multimedia message.
• Tap > Search to search for a message using keywords.
• Tap an existing message thread to open the conversation.
Sending a Text Message
1. On the Messaging screen, tap .
2. Add recipients in one of the following ways:
• Tap the To eld and manually enter the recipient’s number or the contact name. If
the phone presents a few suggestions, tap the one you want to add.
• Select recipients from your contacts by tapping .
3. Tap the Type message eld and enter the content of your text message.
4. If you want to send a multimedia message, tap to add a picture, video, or other le
to the message.
5. Tap SEND.
NOTES:
• You can also include email addresses as recipients for multimedia messages.
• Do not add any attachment if you want to send a text message. Otherwise you may be
charged for a multimedia message.
6362
Page 34
Messaging
Messaging
Replying to a Message
Messages you receive are appended to existing threads of the same number. If the new
message comes from a new number, a new thread is created.
1. On the Messaging screen, tap the thread that has the message you want to reply to.
2. Type your reply in the text box at the bottom. You can tap if you want to reply with
an MMS.
3. Tap SEND.
Forwarding a Message
1. On the Messaging screen, tap the thread that has the message you want to forward.
2. Tap the message.
3. Tap Forward in the menu that opens.
4. Enter a recipient for the message and edit the content if needed.
5. Tap SEND.
Deleting Messages or Threads
Deleting Messages in a Thread
1. On the Messaging screen, tap a thread.
2. Tap
> Multi-Select.
3. Tap the checkboxes beside the messages you want to delete.
4. Tap > OK.
Delete Message Threads
1. On the Messaging screen, press and hold one thread you want to delete.
2. If there are more threads you want to delete, tap them one by one.
3. Tap > OK.
Changing Message Settings
Tap
> Settings in the Messaging screen to change Message settings.
• SMS Enabled: Tap to change your default SMS app.
Storage:
• Delete old messages: Delete old messages as limits are reached.
• Text message limit: Set the number of text messages to save.
• Multimedia message limit: Set the number of multimedia messages to save.
Text (SMS) messages:
• Delivery reports: Request a delivery report for each message you send.
• Manage SIM card messages: Manage the messages stored on your micro-SIM card.
• SMS priority: Set the SMS priority setting to Normal or High.
Multimedia (MMS) messages:
• Auto-retrieve: Automatically download multimedia messages.
• Group messaging: Set to use MMS to send a single message when there are
multiple recipients.
• Delivery reports: Request a delivery report for each message sent.
• Roaming auto-retrieve: Automatically retrieve messages while roaming.
• MMS validity: Set the MMS validity setting.
• MMS creation mode: Set the MMS creation mode to Free, Warning, or Restricted.
Display Settings:
• Bubble and background: Select a dialog bubble and background.
• Preview messages: Select to preview messages on the lock screen and status bar.
Notications:
• Notications: Show message notications in the Status Bar.
• Select ringtone: Choose a ringtone for your incoming messages.
• Vibrate: Make your phone vibrate when a new message arrives.
6564
Page 35
Messaging
Calendar
Signature settings:
• Edit signature: Edit your signature, which can be added automatically to outgoing
messages.
• Add signature: Add the signature to all outgoing messages.
WAP push switch:
• Enable wap push receiving: Allow your phone to receive WAP push.
Emergency alerts:
• Vibrate alert: Enable vibration alerts when emergency alerts and messages arrive.
• Receive emergency alerts: Choose the types of alerts you’d like to receive.
• Notication for unread alerts: Set a notication reminder for every 10 minutes.
• Alerts notication preview: Preview settings for alert tones and vibration cadence.
• Speak alert message: Use text-to-speech to read emergency alert messages.
66
Calendar on the phone works with the web-based Google Calendar™ service for creating
and managing events, meetings, and appointments. It also works with the Microsoft
Exchange ActiveSync calendar once you sign into your Exchange account on the phone.
To open Calendar, press the Home Key > > Calendar.
Viewing Your Calendars and Events
Selecting Visible Calendars
1. Open the Calendar app.
2. Tap
> Calendars to display.
3. In the new screen, tap to check the calendars you want to see or uncheck the
calendars you’d like to hide.
Events from hidden calendars are not shown in the Calendar app.
Changing Calendar Views
You can view your calendar by month or agenda. To change a calendar view, tap and
choose Month or Agenda.
• In Month view, swipe vertically to see earlier months and later months.
• When you are viewing earlier months, tap > To day to switch to the current month.
Viewing Event Details
In Agenda view, tap an event to view its details.
In Month view, double-tap a day and then tap an event to view its details.
Creating an Event
1.
In any Calendar view, tap > New event to open an event details screen for a new event.
NOTE: If you have more than one calendar, you can choose the calendar to which to
add the event by tapping the current calendar above the Event name box.
2. Add details about the event.
3. Tap SAVE to save the new event.
67
Page 36
Calendar
Browser
NOTE: You can also create a new event by copying the details of an existing event. Just
open the event details screen and tap
tap SAVE.
> Copy. Then edit the new event information and
Editing, Deleting, or Sharing an Event
1. Find the event you want to edit, delete, or share.
2. Open its details screen (see Calendar – Viewing Your Calendars and Events – Viewing
Event Details).
3. Choose one of the following options:
• To edit the event, tap . Tap SAVE to save your changes.
• To delete the event, tap > OK.
• To share the event, tap
> Share and choose how to share.
Changing Calendar Settings
To change Calendar settings, open a Calendar view (Month or Agenda) and then tap
Settings.
You can change General settings, which apply to all accounts, or other settings that only
apply to specic accounts.
• To create an email account, tap
Google account.
• For General settings, choose options for Calendar view setting and Notications &
reminders settings. You can choose to show the week number, set the day of the week
the calendar starts on, and use home time zone when you travelling. Also you can
choose event reminder settings such as notication sound, vibrate, default reminder
time, and more.
> Settings > ADD ACCOUNT to create a corporate or
Searching an Event
Tap
> Search event, and then type the event in the Search eld.
68
Use Browser to view web pages and search for information.
Opening the Browser
Press the Home Key > to launch the web browser. The Browser also opens when you
tap a web link—for example, in an email or a text message.
1. Open the Browser app.
2. Tap the address box at the top of the web page.
3. Enter the address (URL) of a web page, or enter terms you want to search for.
4. Tap a URL or search suggestion or tap Go on the keyboard to open the web page or
search results.
Setting the Home Page
Your home page opens when you open a new browser tab, and when you open Browser
after restarting your phone.
>
1. Open the Browser app.
2. Tap > Settings > Set homepage.
3. Enter the URL and tap OK to set it as the homepage.
Changing Browser Settings
You can congure a number of settings to customize the way you browse the web,
including several that you can use to control your privacy.
To open the Browser settings screen, tap > Settings in the browser screen.
69
Page 37
Camera
You can take photos and record videos. Photos and
videos are stored to the phone’s memory card or to
the phone’s internal storage. You can copy them to
your computer or access them in the Gallery app.
Capturing a Photo
1. Press the Home Key > .
NOTE: You can also press the Camera Key from the
home or apps screen to launch the Camera app.
2. Aim the camera at the subject and make any necessary
adjustments. AUTO camera mode is used by default.
3. Tap the area on the screen where you want the
camera to focus, or let the camera autofocus on
the center of the image.
4. Lightly tap . The Volume Keys can be used to zoom
in and out in the Camera app.
Number Function
1 Change the camera settings.
2
View photos and videos you have taken.
3
Capture a photo.
4
Capture a video.
5 Select a camera mode for the back camera.
6 Switch between the front and back cameras.
Set a time delay before the camera automatically takes a picture after you
7
tap the shutter icon.
70
Camera
➐
➊
➋
➌
➍
➏
➎
NOTE: You can pinch or spread your ngers on the screen to zoom in or out before taking
a picture.
Using Manual Camera Mode
You can use the Manual camera mode to adjust more camera options for your photo,
such as ISO, white balance, exposure, etc.
1. Press the Home Key > > > MANUAL.
2. Aim the camera at the subject and you can make the following adjustments.
• Drag to any area on the screen that you want to focus on.
• Drag to any area on the screen where you want the camera to meter exposure so
as to adjust the photo brightness.
• Tap to show the grid or the golden spiral, or hide it.
• Tap to enable or disable the gradienter.
• Tap to adjust white balance.
• Tap to adjust ISO.
• Tap to adjust overall exposure.
3. Tap to take the photo.
Using Other Camera Modes
Besides capturing photos in the traditional way, your Camera app oers other powerful
and interesting camera modes. Tap in the viewnder screen to nd them all.
• PANORAMA: Capture panorama photos.
• HDR: Capture high-dynamic range photos, which combine three images taken at
dierent exposures to create one image with greater contrast.
• SPECIAL EFFECT: Select a color eect or other special eects.
• INTERVAL: Set a time delay before the camera automatically takes a picture after you
tap the shutter icon.
• SMILE: Activate the shutter to take a photo when the subject smiles.
71
Page 38
Camera
Recording a Video
1. Press the Home Key > .
NOTE: You can also press the Camera Key from the home or apps screen to launch the
Camera app.
2. Aim the camera at the subject and make any necessary adjustments. You can tap
any area on the screen that you want the camcorder to focus on before and during
recording.
NOTE:
You can pinch or spread your ngers on the screen to zoom in or zoom out
before and during recording.
3. Tap to start recording. You can also tap / to pause and resume recording.
NOTE: While recording is in progress, you can tap to save the frame as a photo.
4. Tap to stop recording.
VIDEO
• Video quality: Set the quality for your video.
• Focus lock when recording: Select whether to lock the focus point on the center of
the screen when recording videos using the back camera.
• Geo-tagging: Select whether to store the GPS location in your captured videos.
• Storage location: Tap Save location to change the storage location for
captured videos.
• Restore defaults: Restore default camera and camcorder settings.
NOTE: Some camera and video options will change in dierent camera modes.
Camera
Customizing Camera and Video Settings
Before capturing a photo or video, you can tap to open the following camera setting
options:
CAMERA
• Picture size: Set the image size for your photo.
• Full screen: Set the viewnder screen as full screen when the back camera is in use.
• Point-and-shoot: Available for the front camera. When this feature is enabled, you can
touch the viewnder screen to take a photo using the front camera.
• Shutter tone: Turn the shutter tone on or o.
• Geo-tagging: Select whether to store the GPS location in your captured photos.
• Storage location: Tap Save location to change the storage location for
captured photos and videos.
• Restore defaults: Restore default camera and camcorder settings.
72 73
Page 39
Gallery
Gallery
Opening the Gallery
Press the Home Key > > Gallery to view albums of your pictures and videos.
Working With Albums
When you open the Gallery, all pictures and videos on your phone are displayed in a
number of albums. Swipe up and down to see them all.
Viewing Album Contents
Tap an album to view the pictures and videos it contains.
Sharing Albums, Pictures, or Videos
1. Press and hold an item in the Albums view to select an album or after you open an
album to select a picture or a video.
2. Tap more items that you want to share.
3. Tap and select how you want to share the items.
Deleting Albums, Pictures, or Videos
1. Press and hold an item in the Albums view to select an album or after you open an
album to select a picture or a video.
2. Tap more items that you want to delete.
3. Tap > OK.
Hiding Albums
1. Press and hold an album to select it.
2. Tap more albums that you want to hide.
3. Tap > OK.
NOTE: To show the hidden albums again, tap > Settings > Manage hidden albums.
Tap the albums you want to restore and then tap Show.
74 75
Working With Pictures
Tap a picture in an album to view the picture in full screen. Double-tap the picture, or
pinch two ngers together or spread them apart to zoom out or in. Slide left or right to
view other pictures in the album.
Number Function
Tap to return to the album, where all
1
its contents are displayed in a grid.
2 Share the picture.
3 Delete the picture.
View more options, such as set as
4
wallpaper, rotate, and rename.
NOTES:
• Swipe horizontally to see more pictures and videos.
• Double-tap the picture or pinch/spread two ngers
on the screen to zoom in or out.
• Not all options may be available for certain albums or pictures.
➊
➌
➋
Playing Videos
1. Tap an album in Gallery and then tap the thumbnail of a video.
2. Tap at the center and select a player to start playing.
3. Tap the video to view the playback controls.
➍
Page 40
Music
Music
Press the Home Key > > Music to play audio les stored on your phone. Music
supports a wide variety of audio formats, so it can play music you purchase from online
stores, music you copy from your CD collection, and more.
NOTE: You can also press the Customizable Key to launch Music from any screen.
Playing Music
Tap a song in the music library to listen to it. The following playback screen will appear.
Copying Music Files to Your Phone
Before using Music, you need to copy audio les from your computer to your phone or
memory card.
Copying From a Computer
1. Connect your phone and the computer with a USB cable.
2. Tap Media device (MTP) as the connection mode (see Connecting to Networks and
Devices – Connecting to Your Computer via USB – Connecting Your Phone to a Computer
via USB).
3. Copy the music le from the PC to the phone storage or microSDHC card.
Receiving via Bluetooth
You can receive music les from other devices via Bluetooth (see Connecting to Networks
and Devices – Connecting to Bluetooth Devices – Receiving Data via Bluetooth).
Viewing Your Music Library
Press the Home Key > > Music and your music library is displayed. All your audio les
are cataloged according to the information stored in the les.
Your music is organized by All Songs, Playlists, Artists, Albums, Favorites, and Folders.
You can also tap a song under RECENT PLAY to play it again.
NOTE: If an audio le is being played, its name and player controls are displayed at the
bottom of the screen. Tap the area to open the playback screen.
76 77
➊
➋
➌
➍
➓
➒
➑
➐
➏
➎
Page 41
Music Music
Number Function
1 Return to the music library.
2 Album artwork (if available).
3 Check the track information.
Toggle repeat mode: no repeat, repeat the current track, or repeat the
4
current playlist.
Playback control: Skip songs or pause and resume playback. Drag the
5
progress bar to jump to any part of the track.
6 Turn shue on or o.
7 Add the track to the Favorites playlist.
8 Track name, artist, and album information.
9 View playlist.
10 Access additional options.
You can still control the music when you are not in the playback screen.
• In other apps, swipe down the Notication Panel. Tap the song title to restore the
playback screen, or you can pause/resume playback or skip songs.
78 79
Setting a Song as the Default Ringtone
The song will be used as the ringtone for all incoming calls, except those from contacts
you have assigned special ringtones to (See Contacts – Editing Contacts – Setting a
Ringtone for a Contact).
1. Press the Home Key > > Music > All Songs and then choose a song.
2. In the playback screen, tap > Set as ringtone.
3.
Tap Phone Ringtone or Notication Ringtone.
Managing Playlists
Create playlists to organize your music les into sets of songs, so that you can play the
songs you like in the order you prefer.
1. Tap All Songs > > Multi-Select and then choose songs for your playlist.
2. Tap to add the songs to a playlist or create a new one.
• Tap > Rename or Delete in a playlist screen to rename or delete it.
• Tap a playlist to view its content. To remove a song, press and hold the song. Tap
additional songs to select multiple songs for removal. Tap to remove the songs
from the playlist.
Page 42
Video Player
Video Player
Use the Video Player to manage your video library and to watch videos.
Opening the Video Library
Press the Home Key > > Video Player to view your video library. Swipe up or down to
nd the video you want. You can also tap to search for video les, or tap > View by
or Sort by to change the display mode or sort the list.
Playing and Controlling Videos
Tap a video in the video library to play it. Tap the screen to show the playback controls.
You can control the video and audio or carry out other operations.
➍
➊
➌
➋
80
Number
Function
1 Rotate the video.
Playback control: Skip videos or pause and resume playback. Drag the
2
slider to jump to any part of the video.
3 Adjust the brightness.
Share, rename, or delete the video, check its details, or congure
4
player settings.
Managing Video Files
Deleting Videos
1. In the video library, tap > Multi-Select, or press and hold a video.
2. Tap other videos you want to delete.
3. Tap > OK.
Sharing Videos
1. In the video library, tap > Multi-Select, or press and hold a video.
2. Tap other videos you want to share.
3. Tap and select how you want to share them.
81
Page 43
Sound Recorder
More Apps
Sound Recorder enables you to record voice memos and listen to them whenever
you like.
Recording a Voice Memo
1. Press the Home Key > > Sound Recorder.
2. Slide the HQ switch to turn on or o high-quality recording.
3. Tap to start recording. Tap > OK to cancel recording. Tap to pause and to
continue recording.
4. Tap to stop recording. The memo is automatically saved.
If you don’t want to save the memo after recording it, tap > OK to delete it.
Playing a Voice Memo
Playing a Memo You Just Recorded
Tap at the bottom of the screen.
Playing Any Saved Memo
1. Tap at the top right of the screen to see all recordings.
2. Tap the title of a memo and select Play to play it.
NOTE: In addition to playing the memo, you can also tap a memo to delete, share,
rename, tag, check its le information, or set it as your phone or notication ringtone.
Calculator
Press the Home Key > > Calculator to use the phone’s convenient built-in calculator
for some basic as well as advanced mathematical equations.
NOTE: To see more calculator options, swipe left on the screen.
Clock
Press the Home Key > > Clock. The Clock app allows you to check local time in places
around the world, set alarms, and use timers.
Setting a New Alarm
1. Open the Clock app and tap .
2. Tap a default alarm to congure it, or tap at the bottom of the screen to create a
new alarm.
3. Set up the alarm options, such as time, alarm days, snooze, and alarm ringtone.
4. Tap SAVE to save and exit.
NOTES:
• To enable or disable existing alarms directly, tap On or O on the right side
of each alarm.
• Tap to congure alarm settings, including ringtone volume, vibration, alarm
duration, volume crescendo, and alarm in silent mode.
Using World Time
1. Open the Clock app and tap .
2. World time lets you check local times for cities around the world. Tap to add a
new city.
8382
Page 44
More Apps
More Apps
Using Stopwatch and Countdown
1. Open the Clock app and tap or .
2. Stopwatch allows you to record lap times while countdown allows you to set a time
and count down to zero.
Downloads
The Downloads app keeps a record of the les you have downloaded using apps such
as Chrome or Email.
Press the Home Key > > Downloads.
• Tap a le to open it with the appropriate application.
• Press and hold a le to delete or share it.
File Manager
Quickly access all of your images, videos, audio clips, and other types of les on your
phone and on the memory card.
1. Press the Home Key > > File Manager. Tap to nd the le you need by category,
or tap or to browse folders and les on the phone storage or the microSDHC card.
• Tap folders and les to access stored items.
• Press and hold an item to access option icons such as Copy, Move, Share, or Delete.
• To copy or move an item, navigate to a new location and tap PASTE.
• Tap to create a new folder in the current directory.
84 85
Task Manager
Press the Home Key > > Task Manager to view or stop applications.
• Tap a task in the Tasks tab to check the details of the application or force it to stop.
• Tap the Apps tab to manage all the apps on your phone.
• Tap the Resources tab to view the real-time system resources information (CPU, RAM,
and storage).
Voice Dialer
Voice Dialer is speech recognition software. You can use it to dial a phone number in your
contacts, open menus, or launch phone functions.
1. Press the Home Key > > Voice Dialer.
2. When you see “Listening”, follow the on-screen examples to speak “Call...”, “Dial...”, or
“Open...” to make phone calls or open phone menus and applications.
Wi-Fi Utility
Wi-Fi Utility can manage your Wi-Fi settings to provide free and high-speed data by
automatically connecting your phone to reputable Wi-Fi hotspots.
Press the Home Key > > Wi-Fi Utility, and select a Wi-Fi settings option.
Page 45
Google Apps
Google Apps
Open the Google apps to use Google services.
NOTE: Some contents or Google services may not be available in your region.
Chrome
Use the Chrome app to browse the Internet and get your bookmarks, browsing history,
and more synced with your Google account.
Drive
Store les on Google servers for free after you sign in to your Google account. You
can access them on your computers, your phones and other devices, share them, or
collaborate with others.
Play Music
Play music on the phone and on your Google account.
Play Store
Purchase and download apps, games, and more from the Google Play store.
Voice Search
Search for information with your voice.
YouTube
Watch video clips from YouTube.com, or upload your own and share with the world.
Gmail
Send and receive emails via your Gmail account or other personal email accounts.
Google
Use Google search or get information when you need it with Google Now.
Hangouts
Chat with Google+ friends or send text or multimedia messages.
Maps
Find your place and nd your way in the world.
Photos
Manage photos on the phone and your Google account.
Play Movies & TV
Stream and download movies and TV shows.
86 87
Page 46
Settings
Settings
Press the Home Key > > Settings. Settings contains most of the tools for customizing
and conguring your device.
General Settings
Wi-Fi
Turn Wi-Fi on or o and congure your Wi-Fi connections (see Connecting to Networks and
Devices – Connecting to Wi-Fi).
Bluetooth
Turn Bluetooth on or o and congure your Bluetooth connections (see Connecting to
Networks and Devices – Connecting to Bluetooth Devices).
Mobile Networks
Control mobile data use, data roaming, preferred network type, and access point names
(see Connecting to Networks and Devices – Connecting to Mobile Networks).
Sound and Notications
Adjust dierent types of volume (see Personalizing – Adjusting Volumes), set up ringtone
and notication sound (see Personalizing – Changing the Ringtone and Notication Sound),
select system sounds (see Personalizing – Turning System Sounds On/O), or control
notication display.
Display
• Brightness level: Set the brightness of the display.
• Adaptive brightness: Automatically adjust screen brightness.
• Wallpaper: Select a background image or animation for the home screen and
lock screen.
• Sleep: Set the length of time of inactivity before the screen turns o automatically.
• Daydream: Manage the Daydream function. When Daydream is enabled, photos
or animations will be displayed as a screensaver.
88
• Font size: Set the font size of the text on the screen.
• Keypad light: Set the keypad light to be always o, always on, or have it turn o
in 5, 10, or 20 seconds.
Date and Time
Set date, time, time zone, and how date and time are displayed. You can also use
network-provided data (see Personalizing – Setting the Date and Time).
Language and Input
• Language: Select a language for your system.
• Spell checker: Use Google Spell Checker to check for spelling errors when entering
text and change its settings.
• Personal dictionary: Add new words to the phone’s dictionary or remove words from
the dictionary. The words you add are used for spelling check and word suggestion.
• Keyboard & input methods: Congure text input settings (see Knowing the
Basics – Entering Text).
• Voice input: Select and congure voice input services.
• Text-to-speech output
– Preferred engine: Select the speech synthesis engine you want to use or change
its settings.
– Speech rate: Select how quickly you want the synthesizer to speak.
– Pitch: Adjust the tone of spoken text.
– Listen to an example: Play a brief sample of the speech synthesizer, using your
current settings.
– Default language status: Check whether the text-to-speech output feature
supports the current system language.
• Pointer speed: Select how fast the pointer/mouse should scroll when you connect the
phone to a trackpad or mouse accessory.
89
Page 47
Settings
Settings
Wireless and Networks
Data Usage
Tap the Mobile data or Set mobile data limit switches to turn on or o mobile data or
mobile data limit.
You can check how much data has been used during the time cycle you set, set a
mobile data limit and warning, see what apps have been using mobile data, or restrict
background data for individual apps.
NOTE: The data usage is measured by your phone, and your carrier’s data usage
accounting may dier.
Airplane Mode
In the Settings app, tap More under Wireless & networks, then tap the switch next to
Airplane mode to turn voice and data transmission on or o.
VPN
In the Settings app, tap More under Wireless & networks and select VPN to set up and
connect to virtual private networks (see Connecting to Networks and Devices – Connecting
to Virtual Private Networks).
Default SMS App
In the Settings app, tap More under Wireless & networks and select Default SMS app to
choose the preferred application for sending and receiving SMS.
Device
Storage
Check memory information for your external memory card and internal storage. You can
choose the default location for new data, such as downloaded les and captured photos.
• Save location: Select Phone or SD card to store items in the phone storage or the
installed microSDHC card.
90
• Internal storage: View available storage space and more. Tap Used space to see
details on memory use, clear cached data, and delete certain les.
• SD card
– Unmount SD card: Unmount the memory card from your phone so that you can
safely remove the card while the phone is on.
– Erase SD card: Erase all data on your memory card and prepare it for use with
your phone.
Battery
Check the battery status and what has been using the battery.
NOTE: You can tap an app or service to adjust its settings in order to save battery
life. For example, tap Screen > DISPLAY to change screen brightness and display
sleep time.
Apps
See apps installed on your phone and manage them.
Tap an app in the DOWNLOADED, RUNNING, or ALL tab to see its information. You can
stop the app, uninstall or disable the app, clear data and cache, or move the app between
the internal storage and the memory card.
NOTE: Not all applications can be moved or uninstalled.
Connect to PC
Select the USB connection mode between your phone and PC (see Connecting to
Networks and Devices – Connecting to Your Computer via USB – Connecting Your Phone to a
Computer via USB).
Call Settings
Congure the call options (see Phone Calls – Adjusting Your Call Settings).
91
Page 48
Settings
Settings
Personal
Location
Activate location services to determine your location. To use location-related
applications, such as nding your location on Google Maps, you must have location
services turned on on your phone.
1. Press the Home Key > > Settings > Location.
2. Slide the Location switch to the On position to turn on location access.
3. When location access is enabled, tap Mode to select location modes you want to use.
• High accuracy: Get accurate location using both GPS and Wi-Fi as well as
mobile networks.
• Battery saving: Use only Wi-Fi and mobile networks to get your approximate
location. This will drain less power from your battery than using GPS.
• Device only: Use GPS to pinpoint your location.
• Accelerated location: Slide the switch to turn on/o the Qualcomm® IZat™
hardware accelerated location feature.
Security
• Screen lock: Lock the screen with a PIN or password (see Personalizing – Protecting
Your Phone With Screen Locks).
• Automatically lock: Set the time needed for the lock protection to be activated
after the screen turns o. This option is available when PIN or password is set.
• Owner info: Set the text that you may display on the lock screen.
• Smart Lock: Keep the phone unlocked when connected to trusted devices, in trusted
places, when it recognizes your face or voice, or when your phone is being carried on
the body.
NOTE: You need to sign in to your Google account on the phone to use the Smart
Lock feature.
92 93
• Encrypt phone: Encrypt your data on the phone to protect your privacy (see
Personalizing – Protecting Your Phone With Encryption).
• Set up SIM card lock: Lock the SIM card and change the SIM PIN.
– Lock SIM card: Activate or deactivate the PIN lock to require PIN before accessing
the micro-SIM card.
– Change SIM PIN: Change the PIN used to access the micro-SIM card.
NOTE: Put all your condential passwords in a safe place for future use. If you enter the
wrong SIM PIN more times than allowed, your micro-SIM card will be locked and you
cannot access the mobile phone network. Contact your operator for a PIN Unlock Key
(PUK) to restore the micro-SIM card.
• Make passwords visible: Display passwords as you enter them.
• Device administrators: View or deactivate apps you have authorized to be
device administrators.
• Unknown sources: Permit installation of apps from sources other than the Play Store.
• Storage type: Check the credential storage type.
• Trusted credentials: Display trusted CA certicates.
• Install from SD card: Install certicates from the phone storage or the memory card.
• Clear credentials: Delete all certicates.
• Trust agents: View or deactivate trust agents.
• Screen pinning: Turn the screen pinning feature on/o (see Personalizing –
Protecting Your Phone With Screen Pinning).
• Apps with usage access: Turn on or o some apps’ access to your phone
usage information.
Page 49
Settings
Upgrading the Phone Software
Backup and Reset
• Back up my data: Back up app data, Wi-Fi passwords, and other settings to Google
servers after you sign in to your Google account.
•
Backup account: Back up data to a Gmail address.
• Automatic restore: Restore previously backed up settings and data when you reinstall
an app.
• Factory data reset: Reset your phone to factory default settings. All your personal
data from the phone’s internal storage will be erased. You can also erase the data on
the memory card during the process.
There are several ways to upgrade your phone software:
1. Use the online upgrade tool for mobile terminal products.
2. Use the one-press upgrade package oered by your mobile service provider.
3. Use your PC to download an upgrade package to your microSDHC card and install it to
your phone from the card.
NOTE: Visit the ZTE ocial handset service support website (http://www.ztedevice.
com/support) and click your country or region to learn more about the above upgrade
methods, as well as which phones and methods are supported.
Accounts
Manage your accounts and synchronization. Tap Add account to sign in to or create
accounts on your phone.
Tap an account type to see that type of accounts you have added and adjust the
accounts’ settings.
System
Accessibility
Congure the system accessibility options and accessibility plug-ins on your phone, such
as using Color inversion, Large text, and TalkBack for low-vision users.
Printing
Congure Cloud printing service options, manage print jobs, and more.
Software Update
Check your current software version and update your software.
About Phone
View phone status, legal information, and other information.
94 95
Page 50
Troubleshooting
Troubleshooting
If you encounter problems while using the phone, or if it performs abnormally, you
can refer to the chart below. If your particular problem cannot be resolved using the
information in the chart, contact the dealer where you purchased the phone.
Problem Possible Causes Possible Solution
The network signal is too weak
at your current location, for
example, in a basement or near
a tall building, because wireless
transmissions can not eectively
reach it.
Poor reception
Echo or noise
Unable to
select certain
features
96 97
The network is busy at the
current time (for example,
during peak times, there may
be too much network trac to
handle additional calls).
You are too far away from a base
station for your service provider.
Poor network link quality on the
part of your service provider.
Poor local telephone line quality.
Your service provider does not
support these features, or you
have not applied for services
that provide these features.
Move to a location where the
network signal can be properly
received.
Avoid using the phone at such
times, or try again after waiting a
short time.
You can request a service area
map from your service provider.
End the call and dial again. You
may be switched to a betterquality network link or phone line.
End the call and dial again. You
may be switched to a betterquality network link or phone line.
Contact your service provider.
Problem Possible Causes Possible Solution
Battery not
charging
Shortened
standby time
The battery or battery charger is
damaged.
The phone’s temperature is
below 32°F (0°C) or higher than
113°F (45°C).
Poor contact between the
battery and charger.
The standby time is related to
your service provider system
conguration. The same phone
used with dierent service
providers’ systems will not
provide exactly the same length
of standby time.
The battery is depleted. In
high-temperature environments,
battery life will be shortened.
If you are not able to connect
to the network, the phone will
continue to send out signals as it
attempts to locate a base station.
Doing so consumes battery
power and will consequently
shorten standby time.
Contact the dealer.
Adjust the battery charging
environment to avoid extremes of
temperature.
Check all connectors to make
sure all connections have been
properly made.
If you are located in an area where
signaling is weak, temporarily
power o the phone.
Use a new battery.
Change your location to one
where the network is accessible,
or temporarily turn o your
phone.
Page 51
Troubleshooting
For Your Safety
Problem Possible Causes Possible Solution
Cannot turn
your phone on
micro-SIM
card error
Unable to
connect to the
network
PIN Code
blocked
Phone crashes,
reboots, freeze,
or cannot be
powered on
98 99
Battery power has been
depleted.
The micro-SIM card has
malfunctioned or is damaged.
The micro-SIM card is inserted
improperly.
Debris is on the micro-SIM card
contacts.
The micro-SIM card is invalid. Contact your service provider.
You are not within the network’s
service area.
Poor signal.
You have entered an incorrect
PIN code three consecutive
times.
Some third-party software is not
compatible with your phone.
Recharge the phone’s battery.
Take the micro-SIM card to your
service provider for testing.
Insert the micro-SIM card
properly.
Use a soft, dry cloth to clean the
micro-SIM card contacts.
Check the service area with your
service provider.
Move to an open space, or if you
are inside a building, move closer
to a window.
Contact your service provider.
Uninstall the software that may be
causing the problem.
Upgrade the phone software.
Reset the phone to factory status.
General Safety
Don’t make or receive
handheld calls while driving.
Never text while driving.
Keep your phone at least
15 mm away from your ear or
body while making calls.
Small parts may cause
choking.
Your phone can produce a
loud sound.
Avoid contact with anything
magnetic.
Keep away from pacemakers
and other electronic medical
devices.
Power o when asked to in
hospitals and medical facilities.
Power o when told to in
aircrafts and airports.
Power o when near explosive
materials or liquids.
Don’t use at gas stations.
Your phone may produce a
bright or ashing light.
Don’t dispose of your phone
in re.
To prevent possible hearing
damage, do not listen at high
volume levels for long periods.
Avoid extreme temperatures.
Avoid contact with liquids.
Keep your phone dry.
Don’t take your phone apart.
Only use approved
accessories.
Don’t rely on your phone for
emergency communications.
Page 52
For Your SafetyFor Your Safety
Radio Frequency (RF) Energy
This phone is designed and manufactured not to exceed the emission limits for exposure
to radio frequency (RF) energy set by the Federal Communications Commission of the
United States.
During SAR testing, this device was set to transmit at its highest certied power level in
all tested frequency bands, and placed in positions that simulate RF exposure in usage
against the head with no separation, and near the body with the separation of 0.4 inches
(10 mm). Although the SAR is determined at the highest certied power level, the actual
SAR level of the device while operating can be well below the maximum value. This is
because the phone is designed to operate at multiple power levels so as to use only the
power required to reach the network. In general, the closer you are to a wireless base
station antenna, the lower the power output.
The exposure standard for wireless devices employs a unit of measurement known as the
Specic Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg.
This device complies with SAR for general population/uncontrolled exposure limits
in ANSI/IEEE C95.1-1992 and has been tested in accordance with the measurement
methods and procedures specied in IEEE1528.
The FCC has granted an Equipment Authorization for this model phone with all
reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines.
SAR information on this model phone is on le with the FCC and can be found under
the Display Grant section of www.fcc.gov/oet/ea/fccid after searching on FCC ID:
SRQ-Z353VL.
For this device, the highest reported SAR value for usage against the head is 0.49 W/kg,
for usage near the body is 0.96 W/kg.
While there may be dierences between the SAR levels of various phones and at various
positions, they all meet the government requirements.
SAR compliance for body-worn operation is based on a separation distance of 0.6 inches
(15 mm) between the unit and the human body. Carry this device at least 0.6 inches
(15 mm) away from your body to ensure RF exposure level compliant or lower to the
100
reported level. To support body-worn operation, choose the belt clips or holsters, which
do not contain metallic components, to maintain a separation of 0.6 inches (15 mm)
between this device and your body.
RF exposure compliance with any body-worn accessory, which contains metal, was not
tested and certied, and use such body-worn accessory should be avoided.
FCC Regulations
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on,
the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modications not expressly approved by the manufacturer could
void the user’s authority to operate the equipment.
101
Page 53
For Your Safety For Your Safety
Hearing Aid Compatibility (HAC) Regulations for Mobile Phones
In 2003, the FCC adopted rules to make digital wireless telephones compatible with
hearing aids and cochlear implants. Although analog wireless phones do not usually
cause interference with hearing aids or cochlear implants, digital wireless phones
sometimes do because of electromagnetic energy emitted by the phone’s antenna,
backlight, or other components. Your phone is compliant with FCC HAC regulations
(ANSI C63.19-2011).
While some wireless phones are used near some hearing devices (hearing aids and
cochlear implants), users may detect a buzzing, humming, or whining noise. Some
hearing devices are more immune than others to this interference noise, and phones
also vary in the amount of interference they generate. The wireless telephone industry
has developed ratings for some of their mobile phones to assist hearing device users in
nding phones that may be compatible with their hearing devices. Not all phones have
been rated. Phones that have been rated have a label on the box. These ratings are not
guaranteed. Results will vary, depending on the level of immunity of your hearing device
and the degree of your hearing loss. If your hearing device happens to be vulnerable to
interference, you may not be able to use a rated phone successfully. Trying out the phone
with your hearing device is the best way to evaluate it for your personal needs.
This phone has been tested and rated for use with hearing aids for some of the wireless
technologies that it uses. However, there may be some newer wireless technologies used
in this phone that have not been tested yet for use with hearing aids. It is important to
try the dierent features of this phone thoroughly and in dierent locations, using your
hearing aid or cochlear implant, to determine if you hear any interfering noise. Consult
your service provider or the manufacturer of this phone for information on hearing aid
compatibility. If you have questions about return or exchange policies, consult your
service provider or phone retailer.
M-Ratings: Phones rated M3 or M4 meet FCC requirements and are likely to generate
less interference with hearing devices than phones that are not labeled. M4 is the better/
higher of the two ratings.
102
T-Ratings: Phones rated T3 or T4 meet FCC requirements and are likely to be more
usable with a hearing device’s telecoil (“T Switch” or “Telephone Switch”) than unrated
phones. T4 is the better/higher of the two ratings. (Note that not all hearing devices
contain telecoils.)
Your Z353VL has been tested for hearing aid device compatibility and has an M4/T4 rating.
Hearing devices may also be measured for immunity to this type of interference. Your
hearing device manufacturer or hearing health professional may help you nd results for
your hearing device.
For additional information about the FCC’s actions with regard to hearing aid compatible
wireless devices and other steps the FCC has taken to ensure that individuals with
disabilities have access to telecommunications services, please go to www.fcc.gov/cgb/dro.
Distraction
Driving
Full attention must be given to driving at all times in order to reduce the risk of an
accident. Using a phone while driving (even with a hands free kit) can cause distraction
and lead to an accident. You must comply with local laws and regulations restricting the
use of wireless devices while driving.
Operating Machinery
Full attention must be given to operating machinery in order to reduce the risk of
an accident.
Product Handling
General Statement on Handling and Use
You alone are responsible for how you use your phone and any consequences of its use.
You must always turn o your phone wherever the use of a phone is prohibited. Use of your
phone is subject to safety measures designed to protect users and their environment.
103
Page 54
For Your Safety For Your Safety
• Always treat your phone and its accessories with care and keep it in a clean and dustfree place.
• Keep the screen and camera lens clean. Unclean screen or camera lens may slow down
the phone’s reaction to your operations or lower image quality.
• Clean the device and its accessories with a soft material such as cleaning cloth for
eyeglass lenses. Do not use alcohol or other corrosive substances for cleaning or allow
them to get inside.
• Do not expose your phone or its accessories to open ames or lit tobacco products.
• Do not expose your phone or its accessories to liquid, moisture or high humidity.
• Do not drop, throw or try to bend your phone or its accessories.
• Do not use harsh chemicals, cleaning solvents, or aerosols to clean the device or its
accessories.
• Do not paint your phone or its accessories.
• Do not attempt to disassemble your phone or its accessories. Only authorized
personnel can do so.
• Do not expose or use your phone or its accessories in an environment with or that can
reach extreme temperatures, minimum - [5] and maximum + [50] degrees Celsius.
• Do not place your phone inside or near heating equipment or high-pressure
containers, such as water heaters, microwave ovens, or hot cooking utensils.
Otherwise, your phone may be damaged.
• Please check local regulations for disposal of electronic products.
• Do not carry your phone in your back pocket as it could break when you sit down.
Small Children
Do not leave your phone and its accessories within the reach of small children or allow
them to play with it. They could hurt themselves or others, or could accidentally damage
the phone. Your phone contains small parts with sharp edges that may cause an injury or
may become detached and create a choking hazard.
104
Demagnetization
To avoid the risk of demagnetization, do not allow electronic devices or magnetic media
to be close to your phone for a long time.
Electrostatic Discharge (ESD)
Do not touch the micro-SIM/SD card’s metal connectors.
Antenna
Do not touch the antenna unnecessarily.
Normal Use Position
When placing or receiving a phone call, hold your phone to your ear, with the bottom
towards your mouth.
Air Bags
Do not place a phone in the area over an air bag or in the air bag deployment area as
an airbag inates with great force and serious injury could result. Store the phone safely
before driving your vehicle.
Seizures/Blackouts
The phone can produce a bright or ashing light. A small percentage of people may
be susceptible to blackouts or seizures (even if they have never had one before) when
exposed to ashing lights or light patterns such as when playing games or watching
video. If you have experienced seizures or blackouts or have a family history of such
occurrences, please consult a physician. To reduce the risk of blackouts or seizures, you
can use your phone in a well-lit room and take frequent breaks.
Repetitive Strain Injuries
To minimize the risk of Repetitive Strain Injury (RSI) when texting or playing games with
your phone:
105
Page 55
For Your Safety For Your Safety
• Do not grip the phone too tightly.
• Press the buttons lightly.
• Use the special features that are designed to minimize the times of pressing buttons,
such as Message Templates and Predictive Text.
• Take many breaks to stretch and relax.
Emergency Calls
This phone, like any wireless phone, operates using radio signals, which cannot
guarantee connection in all conditions. Therefore, you must never rely solely on any
wireless phone for emergency communications.
Loud Noise
This phone is capable of producing loud noises, which may damage your hearing.
Turn down the volume before using headphones, Bluetooth stereo headsets or other
audio devices.
Phone Heating
Your phone may become warm during charging and during normal use.
Electrical Safety
Accessories
Use only approved accessories. Do not connect with incompatible products or
accessories. Take care not to touch or allow metal objects, such as coins or key rings, to
contact or short-circuit the charging jack terminals. Never puncture the surface of the
phone with sharp objects.
Connection to Vehicles
Seek professional advice when connecting a phone interface to the vehicle electrical
system.
106
Faulty and Damaged Products
Do not attempt to disassemble the phone or its accessories. Only qualied personnel can
service or repair the phone or its accessories. If your phone (or its accessories) has been
submerged in water, punctured, or subjected to a severe fall, do not use it until you have
taken it to be checked at an authorized service center.
CTIA Requirements
• Do not disassemble or open, crush, bend or deform, puncture, or shred the battery.
• Do not modify or remanufacture, attempt to insert foreign objects into the battery,
immerse or expose to water or other liquids, expose to re, explosion or other hazard.
• Only use the battery for the system for which it is specied.
• Only use the battery with a charging system that has been qualied with the system
per CTIA Certication Requirements for Battery System Compliance to IEEE 1725. Use
of an unqualied battery or charger may present a risk of re, explosion, leakage, or
other hazard.
• Do not short-circuit a battery or allow metallic conductive objects to contact battery
terminals.
• Replace the battery only with another battery that has been qualied with the system
per this standard, IEEEStd-1725. Use of an unqualied battery may present a risk of re,
explosion, leakage or other hazard.
• Promptly dispose of used batteries in accordance with local regulations.
• Battery usage by children should be supervised.
• Avoid dropping the phone or battery. If the phone or battery is dropped, especially on
a hard surface, and the user suspects damage, take it to a service center for inspection.
• Improper battery use may result in a re, explosion, or other hazard.
• The phone shall only be connected to CTIA certied adapters, products that bear the
USB-IF logo or products that have completed the USB-IF compliance program.
107
Page 56
For Your Safety
For Your Safety
Radio Frequency Interference
General Statement on Interference
Care must be taken when using the phone in close proximity to personal medical
devices, such as pacemakers and hearing aids. Please consult your doctor and the device
manufacturers to determine if the operation of your phone may interfere with the
operation of your medical devices.
Pacemakers
Pacemaker manufacturers recommend that a minimum separation of 15 cm be
maintained between a mobile phone and a pacemaker to avoid potential interference
with the pacemaker. To achieve this, use the phone on the opposite ear to your
pacemaker and do not carry it in a breast pocket.
Hearing Aids
People with hearing aids or other cochlear implants may experience interfering noises
when using wireless devices or when one is nearby. The level of interference will depend
on the type of hearing device and the distance from the interference source. Increasing
the separation between them may reduce the interference. You may also consult your
hearing aid manufacturer to discuss alternatives.
Medical Equipment
Turn o your wireless device when requested to do so in hospitals, clinics or healthcare
facilities. These requests are designed to prevent possible interference with sensitive
medical equipment.
Aircraft
Turn o your wireless device whenever you are instructed to do so by airport or airline
sta. Consult the airline sta about the use of wireless devices onboard the aircraft. If
your device oers airplane mode, this must be enabled prior to boarding an aircraft.
108
Interference in Vehicles
Please note that because of possible interference with electronic equipment, some
vehicle manufacturers forbid the use of mobile phones in their vehicles unless a handsfree kit with an external antenna is included in the installation.
Explosive Environments
Gas Stations and Explosive Atmospheres
In locations with potentially explosive atmospheres, obey all posted signs to turn o
wireless devices such as your phone or other radio equipment. Areas with potentially
explosive atmospheres include fueling areas, below decks on boats, fuel or chemical
transfer or storage facilities, areas where the air contains chemicals or particles, such as
grain, dust, or metal powders.
Blasting Caps and Areas
Power o your mobile phone or wireless device when in a blasting area or in areas posted
power o “two-way radios” or “electronic devices” to avoid interfering with blasting
operations.
WARNING: This product contains a chemical known to the State of California to cause
cancer, birth defects or other reproductive harm.
109
Page 57
Specications
Handset specications are shown in the following table.
Operating system Android 5.1.1 (Lollipop)
Handset standards LTE/CDMA
Dimensions (H × W × D) 4.72" (H) x 2.40" (W) x 0.72" (D)
Weight 5.82 oz. (with battery)
Internal Display
External Display
Camera Rear 5 MP AF; Front 2 MP
Internal memory ROM: 8GB, RAM: 1 GB
Removable memory card Supports microSDHC card up to 32 GB
Battery 1,800 mAh (removable)
Continuous idle time Up to 6 days
Continuous talk time Up to 10 hours
WAP browser version WAP 2.0
Bluetooth BT 4.1
HAC M4/T4
NOTE: The phone’s talk time and idle time are based on ideal working environments.
The use of extended backlighting, browser, and network conditions can reduce battery
life and talk/idle time.
3.5" 480 x 320
0.96" 128 x 64
Notes
110 111
Page 58
Notes
112
Loading...
