ZTE Avid Trio User Guide

Z833

Start Guide

Content

Content ............................................... 2

Getting to Know Your Phone .............. 5

Starting Up .......................................... 7

Charging the Battery .........................11

Powering On/Off Your Phone ........... 12

Getting to Know the Home Screen ... 12

Opening Applications ..............................13

Adding Shortcuts .............................. 14

Adding Widgets .......................................14

Removing Shortcuts or Widgets .............14

Organizing Shortcuts With Folders .........14

Applying New Wallpapers ................. 15

Setting Ringtone and Sound ............ 15

Setting Ringtone or Notification Sound ..15

Setting System Tones .............................15

Adjusting Volume ............................. 16

Setting a Screen Lock ...................... 16

Checking Voicemail .......................... 17

Making a Call .................................... 17

Wi-Fi Calling ............................................18

Adding Contacts ................................18

Creating a New Contact ......................... 18

Importing Contacts in Batches ............... 19

Sending a Message ...........................19

Connecting With a Bluetooth Headset

...........................................................20

Installing Apps From the Google

Play™ Store .......................................21

Taking a Photo ...................................22

Recording a Video .............................23

Playing Music ................................ ....24

Connecting to the Internet ................25

Connecting via Wi-Fi .............................. 25

Connecting via Mobile Network.............. 26

Information About Safeguarding

Handsets ................................ ............27

Approved Firmware Versions ................. 27

Emergency Dialing ................................. 28

Additional Information ............................. 29

LEGAL INFORMATION ...................... 31

Product Safety Information .............. 32

General Safety.........................................32

Radio Frequency (RF) Energy ................35

FCC Regulations .....................................37

Hearing Aid Compatibility (HAC)

Regulations for Mobile Phones ...............38

CTIA Requirements .................................40

Distraction ................................................42

Product Handling .....................................42

Electrical Safety .......................................47

Radio Frequency Interference ................48

Explosive Environments Gas Stations

and Explosive Atmospheres....................50

Indicator light

Proximity & light

sensor

Touch screen

Recent apps key

Earpiece

Home key

Back key

Front camera

Getting to Know Your Phone

Power key

Flash

Volume key

Charging/

micro-USB

Headset jack

Back cover

Back camera

Speaker

Power key

 Press and hold to power on, turn on/off

airplane mode, restart the phone, or power off.

 Press to turn off or on the screen display.

Home key

Touch to return to the home screen from any application or screen.

Back key

Touch to go to the previous screen.

Recent apps key Touch to see recently used applications. Volume key Press or hold to turn the volume up or down.

Starting Up

Switch off your phone before installing or replacing the battery or the nano-SIM card. The microSDHC™ card (not included) is optional and can be installed and removed while the phone is turned on. Unmount the microSDHC card before removing it.

1. Place your finger in the slot at the bottom of the back cover to lift and remove the cover.

2. Hold the nano-SIM card with the cut corner oriented as shown and slide it into the card holder.

WARNINGS!

 To avoid damage to the phone, do not use

any other kind of SIM card, or any non-standard nano-SIM card cut from a SIM card. You can get a standard nano-SIM card from your service provider.

 This device uses a nano-SIM card only.

3. Hold the microSDHC card (not included) with the cut corner oriented as shown and slide it into the card slot.

NOTE:

Some applications may require a microSDHC card to work normally or may store certain data on it. Therefore, it is recommended that you keep a microSDHC card (sold separately) installed and not remove or replace it randomly.

4. Insert the battery by aligning the metal contacts on the battery with the metal contacts in the battery compartment. Gently push down on the battery until it locks into place.

5. Align the back cover with the back of the phone and press the cover back into place. Ensure that all the tabs are secure and there are no gaps around the cover.

Charging the Battery

1. Connect the adapter to the charging jack. Ensure that the adapter is inserted with the correct orientation. Do not force the connector into the charging jack.

2. Connect the charger to a standard AC power outlet.

3. Disconnect the charger when the battery is fully charged.

NOTE:

If the battery is extremely low, you may be unable to power on the phone even when it is being charged. In this case, try again after charging the phone for at least 10 minutes.

Powering On/Off Your Phone

Ensure that the battery is charged before powering on.

 Press and hold the Power key to turn on

your phone.

 To turn it off, press and hold the Power key

to open the options menu. Touch Power off.

Getting to Know the Home Screen

The home screen is the starting point for your

phone‟s applications, functions, and menus. You

can customize your home screen by adding application shortcuts, folders, widgets, and more.

Status &

Favorite Tray Shortcuts

Widget

Folder

NOTE:

Your home screen extends beyond the initial screen, providing more space for shortcuts, widgets, and folders. Simply swipe left or right to see the extended home screens.

Opening Applications

1. Touch the Home key if the current screen is not the home screen.

2. Touch .

3. Slide left or right on the screen and touch an app to open it.

Adding Shortcuts

1. Touch the Home key > .

2. Touch and hold an app icon and drag it to the home screen.

Adding Widgets

1. Touch and hold a blank part of the home screen.

2. Touch WIDGETS.

3. Touch and hold a widget and drag it to the home screen.

Removing Shortcuts or Widgets

1. Touch and hold a widget or shortcut on the home screen.

2. Drag it to to remove it.

Organizing Shortcuts With Folders

1. Touch and hold a shortcut on the home screen.

2. Drag the shortcut icon over another and release your finger. A new folder is created and both shortcuts are added into the folder.

3. If needed, drag more shortcuts and drop them into the folder.

Applying New Wallpapers

1. Touch and hold a blank part of the home screen.

2. Touch WALLPAPERS.

3. Choose the image or animation you want to use as the wallpaper and touch Set

wallpaper.

Setting Ringtone and Sound

Setting Ringtone or Notification Sound

1. Touch the Home key > > Settings > Sound & notification.

2. Touch Phone ringtone or Default notification ringtone.

3. Select the ringtone you want to use.

4. Touch OK.

Setting System Tones

1. Touch the Home key > > Settings > Sound & notification > other sounds.

2. Turn on the types of sound you want to hear or turn off those you do not need.
