Zinwell ZW-2000-22 Users Manual

Configure DEV4:

1. Access the web server ( http://192.168.2.254) of device from the Ethernet port.

Caution

If you configure multiple devices in the same PC, since the devices have the
same default IP address but different MAC addresses, it may cause you
unable to access the web server of device. If the situation happens, please
try to clean the ARP table of your PC by DOS command “arp –d” then you
can access the web server of device using the default IP address.

2. Use Wizard page to setup device.

3. Press “Next>>” button then set the “Operation Mode” to “Wireless ISP”
mode.

4. Press “Next>>” button then disable “Time Zone” function.

21

5. Press “Next>>” button then set the IP address of LAN interface.

6. Press “Next>>” button then select the “DHCP Client” for “WAN Access
Type”.

7. Press “Next>>” button then select the “Client” for “mode” and change the
SSID to “DEV4”.

8. Press “Next>>” button then select “None” for “Encryption” then press
“Finished” button.

22

9. Wait for refreshing web page.

10. Change the IP address of your PC to 192.168.3.x then access the web server
by the new IP address “192.168.3.1” and use “Status” page check the setting.

11. If the “State” of “Wireless Configuration” is not “Connected” or you want to
refresh the “RSSI “, please use “Site Survey” page to re-connect a AP.

23

Configure DEV5:

1. Access the web server ( http://192.168.2.254) of device fro m the Ethernet port.

Caution

If you configure multiple devices in the same PC, since the devices have the
same default IP address but different MAC addresses, it may cause you
unable to access the web server of device. If the situation happens, please
try to clean the ARP table of your PC by DOS command “arp –d” then you
can access the web server of device using the default IP address.

2. Use Wizard page to setup device.

3. Press “Next>>” button then set the “Operation Mode” to “Wireless ISP”
mode.

4. Press “Next>>” button then disable “Time Zone” function.

24
