Zinwell ZIN2100T User Manual

Safety Instructions

This product has been engineered and manufactured to assure your
personal safety. However, improper use can result in potential electric
shock or fire hazards. In order not to defeat the safe-guards incorporated
in this instrument and its accessories, please adhere to the following
instructions when installing, operating and servicing.

Power Source Warning

 A marking label attached on the rear side of the adapter (supplied)

indicates the correct power source for this equipment. Operate this
product only from an electrical outlet with the voltage and frequency
indicated on the product label. Incorrect power source may result in a
risk of electric shock or fire. If you are uncertain of the type of power
supplied to your home, consult your local power company or appliance
dealer.

 Only use the power cord and adapter provided by the manufacturer.

Internal component may be damaged if you use a different adapter to
power this product. To avoid electric shock and fire hazard, match the
plug and outlet connections carefully, then fully insert. If the plug fails to
fit the outlet, please contact an electrician to update your power outlets.

 Do not overload electrical outlets, extension cords, or integral convenience

receptacles as this can result in a risk of fire or electric shock. And to
prevent power cord damage, arrange all power cords so that people
cannot walk on the cords. Do not place objects on the cords.

 Place this product in a location that is close enough to an electrical outlet

and where the power cord is easily accessible to be disconnected from the
wall outlet.

Usage Warning

 T o reduce the risk of electric shock, do not remove the cover or attempt to

disassemble this product. There are no user-serviceable parts inside.
Please refer all servicing to qualified service personnel.

 Protect this product from foreign objects. Never push object of any kind

into this product through openings as they may touch dangerous voltage
points or short-out parts that could result in a fire or electric shock.

 Do not expose this product to liquids, rain or moisture.

 This product has ventilation openings that protect it from overheating.

Never block or cover these openings. And do not place this product near
heat sources such as radiators, heat registers, stoves or other products
producing heat.

 Before cleaning or wiping this product, make sure your power cord is

already unplugged from the electrical outlet. Only use damp cloth to
clean this product, and never use a liquid cleaner or an aerosol cleaner.

 During a thunderstorm, or when this product is unused for long periods of

time, unplug power cord from the wall outlet. This will prevent damage
to the product due to lightning and power-line surges.

Service Warning

 Refer all servicing to qualified service personnel. For damage that

requires service, please unplug your power cord from the AC outlet first,
and contact your dealer or servicing personnel to obtain service for the
following conditions.

 If there is damage to the adapter, power cord or plug.
 If liquid enters this product.
 If you drop this product, a heavy object falls on this product, or

damage occurs to the cover of this product.

 If you expose this product to rain or water.
 If this product does not operate normally by following the oper atin g

instructions.

 If this product exhibits a distinct change in performance.

Caution
Risk of explosion if battery is replaced by an incorrect type. Dispose of used
batteries according to the instructions.

For ZIN-2100R
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE
STATEMENT

This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.

CAUTION:

Any changes or modific ations not expressly approved by the par ty
responsible for compliance could void the user's authority to operate the
equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received, including
interference that may cause undesired operation.

RF exposure warning ·

This equipment must be installed and operated in accordance with provided
instructions and the antenna(s) used for this transmitter must be installed

to provide a separation distance of at least 20 cm fr om all persons and must
not be co-located or operating in conjunction with any other antenna or
transmitter. End-users and installers must be provided with antenna
installation instructions and transmitter operating conditions for satisfying
RF exposure compliance.

Canada, Industry Canada (IC) Notices

This Class B digital apparatus complies with Canadian ICES-003 and
RSS-210.
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.

Radio Frequency (RF) Exposure Information

The radiated output power of the Wireless Device is below the Industry
Canada (IC) radio frequency exposure limits. The Wireless Device should be
used in such a manner such that the potential for human contact during
normal operation is minimized.

This device has also been evaluated and shown compliant with the IC RF
Exposure limits under mobile exposure conditions. (antennas are greater
than 20cm from a person's body).

This device has been certified for use in Canada. Status of the listing in the
Industry
Canada’s REL (Radio Equipment List) can be found at the following web
address: http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.do?lang=eng
Additional Canadian information on RF exposure also can be found at the
following web address:
http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html

Canada, avis d'Industry Canada (IC)

Cet appareil numérique de classe B est conforme aux normes canadiennes
ICES-003 et RSS-210.
Son fonctionnement est soumis aux deux conditions suivantes : (1) cet
appareil ne doit pas causer d'interférence et (2) cet appareil doit accepter
toute interférence, notamment les interférences qui peuvent affecter son

fonctionnement.

Informations concernant l'exposition aux fréquences radio (RF)

La puissance de sortie émise par l’appareil de sans fil Dell est inférieure à la
limite d'exposition aux fréquences radio d'Industry Canada (IC). Utilisez
l’appareil de sans fil Dell de façon à minimiser les contacts humains lors du
fonctionnement normal.

Ce périphérique a également été évalué et démontré conforme aux limites
d'exposition aux RF d'IC dans des conditions d'exposition à des appareils
mobiles (les antennes se situent à moins de 20 cm du corps d'une
personne).
Ce périphérique est homologué pour l'utilisation au Canada. Pour
consulter l'entrée correspondant à l’appareil dans la liste d'équipement
radio (REL - Radio Equipment List) d'Industry Canada rendez-vous sur:
http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.do?lang=eng
Pour des informations supplémentaires concernant l'exposition aux RF au
Canada rendez-vous sur :
http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html

For ZIN-2100T
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE
STATEMENT

This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.

CAUTION:

Any changes or modific ations not expressly approved by the par ty
responsible for compliance could void the user's authority to operate the
equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received, including
interference that may cause undesired operation.

RF exposure warning ·

This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment.
SAR compliance of this product has only been verified for use with typical laptop
computers.
To comply with RF exposure limits, user must not simultaneously operate

wireless products in adjacent USB-ports or cardbus slots.

SAR Value: 0.624W/kg.

Canada, Industry Canada (IC) Notices

This Class B digital apparatus complies with Canadian ICES-003 and
RSS-210.
Operation is subject to the following two condi tions: (1) this device may not
cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.

Radio Frequency (RF) Exposure Information

The radiated output power of the Wireless Device is below the Industry
Canada (IC) radio frequency exposure limits. The Wireless Device should be
used in such a manner such that the potential for human contact during
normal operation is minimized.

This device has been evaluated for and shown compliant with the IC Specific
Absorption Rate (“SAR”) limits when installed in specific host products
operated in portable exposure conditions.

Canada’s REL (Radio Equipment List) can be found at the following web
address: http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.do?lang=eng
Additional Canadian information on RF exposure also can be found at the
following web address:

http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html

Canada, avis d'Industry Canada (IC)

Cet appareil numérique de classe B est conforme aux normes canadiennes
ICES-003 et RSS-210.
Son fonctionnement est soumis aux deux conditions suivantes : (1) cet
appareil ne doit pas causer d'interférence et (2) cet appareil doit accepter
toute interférence, notamment les interférences qui peuvent affecter son
fonctionnement.

Informations concernant l'exposition aux fréquences radio (RF)

La puissance de sortie émise par l’appareil de sans fil Dell est inférieure à la
limite d'exposition aux fréquences radio d'Industry Canada (IC). Utilisez

l’appareil de sans fil Dell de façon à minimiser les contacts humains lors du
fonctionnement normal.

Ce périphérique a été évalué et démontré conforme aux limites SAR
(Specific Absorption Rate – Taux d'absorption spécifique) d'IC lorsqu'il est
installé dans des produits hôtes particuliers qui fonctionnent dans des
conditions d'exposition à des appareils portables.

Ce périphérique est homologué pour l'utilisation au Canada. Pour
consulter l'entrée correspondant à l’appareil dans la liste d'équipement
radio (REL - Radio Equipment List) d'Industry Canada rendez-vous sur:
http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.do?lang=eng
Pour des informations supplémentaires concernant l'exposition aux RF au
Canada rendez-vous sur :
http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html

Table of Contents

1 Introduction ..................................................................... 1

1.1 Package Content ............................................................. 1

1.2 Specification ................................................................... 2

1.3 Front View ....................................................................... 3

1.4 Back View ....................................................................... 3

2 Installation ....................................................................... 4

2.1 Device Connections ......................................................... 4

2.2 Software Installation....................................................... 6

2.2.1 Standard Installation ......................................................................... 6

2.2.2 Benchmarking Your PC ...................................................................... 8

2.2.2.1 PC to TV Benchmark Tool ............................................................... 8

2.2.2.2 Star Level in PC to TV Benchmark T ool ..................................... 9

3 Usage of PC to TV Utility ................................................. 10

3.1 Basic Usage of PC to TV Utility ........................................ 10

3.2 Extend Screen Playing .................................................... 12

3.3 Advanced “Play” Management of PC to TV Utility ............ 14

3.3.1 Advanced Selections ........................................................................ 14

3.3.2 “Optimum Mode” Settings ............................................................. 17

4 Un-installation of PC to TV Utility ................................... 19

5 Device Configuration....................................................... 20

5.1 Go to “Device Configuration” .......................................... 20

5.2 Device Setting ................................................................ 21

5.2.1 Device Name Change ...................................................................... 21

5.2.2 Firmware Upgrade ............................................................................ 21

5.3 Overscan Setting ............................................................ 23

5.4 Network Settings ........................................................... 24

5.4.1 Access Point Mode Setting ............................................................. 24

6 Firmware Upgrade .......................................................... 26

6.1 Upgrade the PC to TV Utility ........................................... 26

6.2 Upgrade the PC to TV Device .......................................... 26

6.2.1 Upgrade Firmware by Network .................................................... 26

6.2.2 Upgrade Firmware by USB ............................................................ 28

7 Troubleshooting .............................................................. 30

7.1 Run as Administrator in Windows 7 / Vista .................... 30

7.2 Network Discovery and Firewall Checking ...................... 31

7.2.1 Turn on Network Discovery and File Sharing ......................... 31

7.2.2 Unblock PC to TV Application from Windows Firewall ......... 32

7.2.3 Enable SSDP and UPnP from Windows Firewall .................... 33

7.3 Audio Playback Issue ..................................................... 36

7.3.1 “Play” Mode Issue ............................................................................. 36

7.3.2 After “Stop” Issue ............................................................................. 37

7.4 Display Overscan Issue .................................................. 38

7.5 Movie and Video Playback Issue in Windows XP ............. 39

7.6 Poor Display Fluency of PC to TV Application .................. 41

7.6.1 Switch Desktop Themes of Windows 7 / Vista ...................... 41

7.6.2 Check the “Optimum Mode” setting .......................................... 41

7.6.3 Check PC’s Desktop Resolution ................................................... 42

7.6.4 Check CPU Usage .............................................................................. 43

7.6.5 Check Wi-Fi Link Speed .................................................................. 44

7.6.6 Change the Wi-Fi Channel ............................................................. 45

7.7 Common Solutions to Many Issues ................................. 46

7.8 Known Issues and Limitations ........................................ 47

7.8.1 PC to TV Limitations ......................................................................... 47

8 Appendix......................................................................... 48

8.1 Display Resolutions ........................................................ 48

8.1.1 Principals of Resolution Implementation .................................. 48

8.1.2 Resolution Implementation Table ............................................... 48

8.1.3 Media Players Compatibility of PC to TV Application ........... 51

1 Introduction

The product is designed as a pair of PC to TV Transmission Kits with
transmitter and receiver, which capture PC’s screen into TV via WiFi
technology . It also features up to 1080p resolution with specific environment.

1.1 Package Content

Please make sure the following items are included within your new product
package. The product might not be compatible with some accessories made
by other manufacturers. We highly recommend that you use only the specific
accessories we suggest.

1

1.2 Specification

General Specifications
Protocol WiFi IEEE 802.11n
Supported

Resolution

1920x1080(up to 1080p), 1280x720 、 1024x768 、
1025x576、800x600、720x480

A/V Output HDMI
Data Control

(USB Port)

USB HID: Mouse / Keyboard
USB Flash disk for firmware upgrade

Power Supply 100~240V ±10% input voltage/ 5V @ 1.5A
System

Desktop/Workstation PC Notebook/Laptop PC

Requirements
CPU Grade Intel Core 2 Duo 2.0G or better

Chipset Intel 965 series chipset or better

Memory DDR2-800, 2GB or better
Graphic

NVIDIA GeForce 8400GS /
ATI Radeon X300 or better

Chipset integrated (Intel X3100
Graphic) or better or NVIDIA

Operating
System

GeForce Go 8200M / ATI Radeon
Mobility X300 standalong graphic
chip or better

Windows 7, x86 and x64 version (Recommendation)
Windows Vista (Service Pack 1 or later), x86 and x64 version
Windows XP (Service Pack 3 or later)

2

1.3 Front View

①

Power LED Blue: Turn on the product

1.4 Back View

Dark: Power Off

①
②
③

④

Power Switch Switch power On/ Off
DC IN Connects to the DC output of the power adapter.
HDMI OUT Connects to the HDMI jack on the display; a

single cable transmits both audio and video data.

USB Port Connects to the USB Mouse/ USB Keyboard

Connects to USB disk for firmware upgrade

3

2 Installation

2.1 Device Connections

Plug power adapter into AC power outlet, then connect adapter plug into DC IN

port.

Switch power key to turn it on.
Connect a HDMI cable between the receiver’s HDMI output and HDMI input of

your display.

Connect USB Mouse or USB Keyboard to control remote PC.

Plug the USB fresh disk into USB ports for firmware upgrade.
Connect Transmitter into PC/Laptop.

4

5

2.2 Software Installation

2.2.1 Standard Installation
In order to install the PC to TV utility more stably, please close all of other
programs before installation.

 Doub le click the icon

of PC to TV utility.

 Please choose a folder

to unpack files for
installation.

 Then click “Continue”

to unpack them.

 Click “Install” for the

following several
notifications to install
drivers, or tick Always
trust software from
“VIA Technologies
Inc.”.

6

 Click “Next” to install

the PC to TV utility.

 After drivers and

utility installed, the PC
to TV benchmark tool
would be prompted to
evaluate your PC.

 Please refer to Section

2.1.1 to get more

information.

 After the

benchmarking is
done, please choose
“Yes” and then click
“Finish” to restart your
PC.

7

2.2.2 Benchmarking Your PC
The PC to TV Benchmark tool is a useful program to evaluate your PC capability to
run the PC to TV application.

2.2.2.1 PC to TV Benchmark Tool
Y ou can see the PC to TV benchmark tool when installation or manually start-up it
from PC to TV folder under “All Programs”.

 After starting-up it,

your can see the left
dialog window. Please
click “Analysis”.

 The evaluating

process will run
around 10 seconds.

8
