Zenoah G3000 User Manual

OWNER/OPERATOR MANUAL

CHAINSAWS

2631-93111(205)

The engine exhaust from this product
contains chemicals known to the State
of California to cause cancer, birth
defects or other reproductive harm.

WARNING

Before using our products, please
read this manual carefully to
understand the proper use of your
unit.

WARNING

APPLICABLE SERIAL NUMBERS : 200101 and up

G3000

SAFETY FIRST

Instructions contained in warnings within this
manual marked with a symbol concern
critical points which must be taken into
consideration to prevent possible serious
bodily injury, and for this reason you are
requested to read all such instructions
carefully and follow them without fail.

■ WARNINGS IN THE MANUAL

This mark indicates instructions which must be
followed in order to prevent accidents which could
lead to serious bodily injury or death.

This mark indicates instructions which must be
followed, or it leads to mechanical failure,
breakdown, or damage.

This mark indicates hints or directions useful in the
use of the product.

NOTE

CONTENTS

1. Parts location …………………………………4

2. Specifications …………………………………4

3. Symbols on the machine ……………………5

4. For safe operation ……………………………6

5. Installing guide bar and saw chain …………8

6. Fuel and chain oil ……………………………9

7. Operation ……………………………………10

8. Sawing ………………………………………13

9. Maintenance …………………………………16

10. Storage ………………………………………19

WARNING

IMPORTANT

2. Specifications

■ G3000

Power unit :

Dis placement ········································································································ 28.5cm

3

Fuel ············································································· Mixture(Gasoline 25 : 2-cycle oil 1)
Fuel tank capacity ···································································································· 0.22
Chain oil ························································································ Motor oil SAE #10W-30
Oil tank capacity ······································································································· 0.13
Carburetor ································································································· Diaphragm type
lgnition system ··································································································· Solid-state
Spark plug ······························································································· Champion CJ-8Y
Oil feeding system ····································································· Mechanical plunger pump
Sprocket : Pitch – No. of teeth ·························································· 3/8in(9.38 mm) – 6T
Dimensions : LxWxH ·············································································· 260x230x240mm
Dry weight ·················································································································· 3.2kg

Cutting attachment :

Guide bar : Type – Size ························································ Sprocket nose – 12in (30cm)
Saw chain : Type – Pitch – Gauge ···············

Oregon 91SG – 3/8(9.375) – 0.050(1.25) in(mm)

Specifications are subject to change without notice.

1. Parts location

 4 

1. Guide Bar

2. Saw Chain

3. Front Guard

4. Front Handle

5. Rear Handle

6. Chain Cover

7. Fuel Tank Cap

8. Oil Tank Cap

9. Air Cleaner

3. Symbols on the machine

 5 

For safe operation and maintenance, symbols are
on the machine. According to these indications,
please be careful not to take a mistake.

(a). The port to refuel the “MIX GASOLINE”
Position: fuel tank cap

(b). The port to refuel the “CHAIN OIL”
Position: oil cap

(c). The indication regarding the switch.

Flipping the engine switch to the “O” (STOP)
direction, the engine stops.

Position: upper part of the unit

(d). The indication regarding the choke.

Pulling out the choke knob, the choke closes.

Position: front of the chain cover

(e). The position of H-needle

The position of L-needle
The position of idle adjusting screw

Position: Front of the chain cover

 6 

4. For safe operation

1. Never operate a chain saw when you are
fatigued, ill, or upset, or under the
influence of medication that may make
you drowsy, or if you are under the
influence of alcohol or drugs.

2. Use safety footwear, snug fitting clothing
and eye, hearing and head protection
devices.

3. Always use caution when handling fuel.
Wipe up all spills and then move the
chain saw at least 3m from the fueling
point before starting the engine.

3a) Eliminate all sources of sparks or

flame (ie. smoking, open flames, or
work that can cause sparks) in the
areas where fuel is mixed, poured, or
stored.

3b) Do not smoke while handling fuel or

while operating the chain saw.

4. Do not allow other persons to be near
the chain saw when starting the engine
or cutting a wood. Keep bystanders and
animals out of the work area. Children,
pets, and bystanders should be a
minimum of 10m away when you start or
operate the chain saw.

5. Never start cutting until you have a clear
work area, secure footing, and planned
retreat path from the falling tree.

6. Always hold the chain saw firmly with
both hands when the engine is running.
Use a firm grip with thumb and fingers
encircling the chain saw handles.

7. Keep all parts of your body away from
the saw chain when the engine is
running.

8. Before you start the engine, make sure
the saw chain is not contacting anything.

9. Always carry the chain saw with the
engine stopped, the guide bar and saw
chain to the rear, and the muffler away
from your body.

10. Always inspect the chain saw before
each use for worn, Ioose, or changed
parts. Never operate a chain saw that is
damaged, improperly adjusted, or is not
completely and securely assembled. Be
sure that the saw chain stops moving
when the throttle control trigger is
released.

11. All chain saw service, other than the
items listed in the Operator’s Manual,
should be performed by competent chain
saw service personnel. (e.g., if improper
tools are used to remove the flywheel, or
if an improper tool is used to hold the
flywheel in order to remove the clutch,
structural damage to the flywheel could
occur which could subsequently cause
the flywheel to disintegrate).

12. Always shut off the engine before setting
it down.

13. Use extreme caution when cutting small
size brush and saplings because slender
material may catch the saw chain and be
whipped toward you or pull you off
balance.

14. When cutting a limb that is under
tension, be alert for spring back so that
you will not be struck when the tension in
the wood fibers is released.

15. Keep the handles dry, clean and free of
oil or fuel mixture.
