SECTION 4

MODEL PARTS

GA-1 MODELS

A19A02D

Part# Description

009-01869-01 MODULE, MAIN, 19, 20V MONAURAL, GA1 CHASSIS 014-12290-14 CABINET FRONT, TV, MOLDED PLASTIC, 19V

MONAURAL CTV

014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-01989 CONNECTOR AND, CABLE ASSEMBLY 095-03705-12 DEFLECTION YOKE A48ACB32X VACUUM TUBE, CRT, COLOR, 19 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00338 WEDGE, YOKE SPACER 192-00916 LENS, IR 206-03369 INSTR BOOK, OPERATION GUIDE A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

A19A02D4

Part# Description

009-01869-01 MODULE, MAIN, 19, 20V MONAURAL, GA1 CHASSIS 014-12290-16 CABINET FRONT, TV, MOLDED PLASTIC, 19V

MONAURAL CTV 014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-01989 CONNECTOR AND, CABLE ASSEMBLY 095-03705-12 DEFLECTION YOKE A48ACB32X VACUUM TUBE, CRT, COLOR, 19 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00338 WEDGE, YOKE SPACER 192-00916 LENS, IR 206-03369 INSTR BOOK, OPERATION GUIDE A-18681 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

A19A02D7

Part# Description

009-01990-01 MODULE, MAIN, 19, 20V MONAURAL, GA1 CHASSIS 014-12290-14 CABINET FRONT, TV, MOLDED PLASTIC, 19V

MONAURAL CTV 014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-01989 CONNECTOR AND, CABLE ASSEMBLY 095-04557 DEFLECTION YOKE 19V HIBI A48KRD89X VACUUM TUBE, CRT, COLOR, 19 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER, POSITIONER 192-00916 LENS, IR 206-03369 INSTR BOOK, OPERATION GUIDE A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

A19A02D74

Part# Description

009-01990-01 MODULE, MAIN, 19, 20V MONAURAL, GA1 CHASSIS 014-12290-16 CABINET FRONT, TV, MOLDED PLASTIC, 19V

MONAURAL CTV

014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-01989 CONNECTOR AND, CABLE ASSEMBLY 095-04557 DEFLECTION YOKE 19V HIBI A48KRD89X VACUUM TUBE, CRT, COLOR, 19 INCH DIAGONAL, 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER, POSITIONER 192-00916 LENS, IR 206-03369 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18681 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

A19A02D8

Part# Description

009-01990-01 MODULE, MAIN, 19, 20V MONAURAL, GA1 CHASSIS 014-12290-14 CABINET FRONT, TV, MOLDED PLASTIC, 19V

MONAURAL CTV 014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER, 046-10578

KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-01989 CONNECTOR AND, CABLE ASSEMBLY 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER, POSITIONER 192-00916 LENS, IR 206-03369 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18671 CRT AND YOKE, ASSEMBLY A-18695-11 GND STRAP ASSY , CRT

A19A02D8

Part# Description

009-01990-01 MODULE, MAIN, 19, 20V MONAURAL, GA1 CHASSIS 014-12290-16 CABINET FRONT, TV, MOLDED PLASTIC, 19V

MONAURAL CTV 014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-01989 CONNECTOR AND, CABLE ASSEMBLY 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER, POSITIONER 192-00916 LENS, IR 206-03369 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18671 CRT AND YOKE, ASSEMBLY

CM150 4-1 GA - MODEL PARTS

MODEL PARTS

A-18681 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

A19A11D

Part# Description

009-01870-01 MODULE, MAIN, 19, 20V STEREO, GA1 CHASSIS 014-12289-09 CABINET FRONT, TV, MOLDED PLASTIC, 19V STEREO

CTV

014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER 046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-03705-12 DEFLECTION YOKE A48ACB32X VACUUM TUBE, CRT, COLOR, 19 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00338 WEDGE, YOKE SPACER 192-00917 LENS, IR 206-03370 INSTR BOOK, OPERATION GUIDE A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

A19A11D4

Part# Description

009-01870-01 MODULE, MAIN, 19, 20V STEREO, GA1 CHASSIS 014-12289-10 CABINET FRONT, TV, MOLDED PLASTIC, 19V STEREO

CTV 014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER 046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-03705-12 DEFLECTION YOKE A48ACB32X VACUUM TUBE, CRT, COLOR, 19 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00338 WEDGE, YOKE SPACER 192-00917 LENS, IR 206-03370 INSTR BOOK, OPERATION GUIDE A-18681 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

A19A11D7

Part# Description

009-01991-01 MODULE, MAIN, 19, 20V STEREO, GA1 CHASSIS 014-12289-09 CABINET FRONT, TV, MOLDED PLASTIC, 19V STEREO

CTV 014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER 046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04557 DEFLECTION YOKE 19V HIBI A48KRD89X VACUUM TUBE, CRT, COLOR, 19 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER, POSITIONER 192-00917 LENS, IR 206-03370 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY

A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

A19A11D74

Part# Description

009-01991-01 MODULE, MAIN, 19, 20V STEREO, GA1 CHASSIS 014-12289-10 CABINET FRONT, TV, MOLDED PLASTIC, 19V STEREO

CTV

014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER 046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04557 DEFLECTION YOKE 19V HIBI A48KRD89X VACUUM TUBE, CRT, COLOR, 19 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER, POSITIONER 192-00917 LENS, IR 206-03370 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18681 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

A19A11D8

Part# Description

009-01991-01 MODULE, MAIN, 19, 20V STEREO, GA1 CHASSIS 014-12289-09 CABINET FRONT, TV, MOLDED PLASTIC, 19V STEREO

CTV 014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER 046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER, POSITIONER 192-00917 LENS, IR, 206-03370 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18671 CRT AND YOKE, ASSEMBLY A-18695-11 GND STRAP ASSY , CRT

A19A11D84

Part# Description

009-01991-01 MODULE, MAIN, 19, 20V STEREO, GA1 CHASSIS 014-12289-10 CABINET FRONT, TV, MOLDED PLASTIC, 19V STEREO

CTV 014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER 046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONL 152-00335 WEDGE, YOKE SPACER, POSITIONER 192-00917 LENS, IR 206-03370 INSTR BOOK, OPERATION GUIDE

CM150 4-2 GA - MODEL PARTS

MODEL PARTS

A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18671 CRT AND YOKE, ASSEMBLY A-18681 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

A20A22D

Part# Description

009-01871-01 MODULE, MAIN, 19, 20V MTS, GA CHASSIS 014-12292-04 CABINET FRONT, TV, MOLDED PLASTIC, 20V STEREO 014-12294-03 CABINET REAR, TV, MOLDED PLASTIC, 20V

MONAURAL, STEREO 020-04330-31 COIL, DEGAUSSER 046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04023-09 DEFLECTION YOKE A51AGD33X VACUUM TUBE, CRT, COLOR, 20 INCH DIAGONAL 124-00212-62 SPACE COMMAND, TRANSMITTER, MBR3446 152-00338 WEDGE, YOKE SPACER 192-00917 LENS, IR 206-03371 INSTR BOOK, OPERATION GUIDE A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-09 GND STRAP ASSY , CRT

A20A22D4

Part# Description

009-01871-01 MODULE, MAIN, 19, 20V MTS, GA CHASSIS 014-12292-04 CABINET FRONT, TV, MOLDED PLASTIC, 20V STEREO 014-12294-03 CABINET REAR, TV, MOLDED PLASTIC, 20V

MONAURAL, STEREO 020-04330-31 COIL, DEGAUSSER 046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04023-09 DEFLECTION YOKE A51AGD33X VACUUM TUBE, CRT, COLOR, 20 INCH DIAGONAL 124-00212-62 SPACE COMMAND, TRANSMITTER, MBR3446 152-00338 WEDGE, YOKE SPACER 192-00917 LENS, IR 206-03371 INSTR BOOK, OPERATION GUIDE A-18681 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-09 GND STRAP ASSY , CRT

A20A22D8

Part# Description

009-01992-01 MODULE, MAIN, 19, 20V WITH MTS, GA1 CHASSIS 014-12292-04 CABINET FRONT, TV, MOLDED PLASTIC, 20V STEREO 014-12294-03 CABINET REAR, TV, MOLDED PLASTIC, 20V

MONAURAL, STEREO 020-04330-31 COIL, DEGAUSSER 046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 124-00212-62 SPACE COMMAND, TRANSMITTER, MBR3446 152-00335 WEDGE, YOKE SPACER, POSITIONER 192-00917 LENS, IR 206-03371 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR

A-18693 CRT ASSEMBLY, WITH DEFLECTION YOKE A-18695-09 GND STRAP ASSY , CRT

A20A22D84

Part# Description

009-01992-01 MODULE, MAIN, 19, 20V WITH MTS, GA1 CHASSIS 014-12292-04 CABINET FRONT, TV, MOLDED PLASTIC, 20V STEREO 014-12294-03 CABINET REAR, TV, MOLDED PLASTIC, 20V

MONAURAL, STEREO 020-04330-31 COIL, DEGAUSSER 046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 124-00212-62 SPACE COMMAND, TRANSMITTER, MBR3446 152-00335 WEDGE, YOKE SPACER, POSITIONER 192-00917 LENS, IR 206-03371 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18681 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18693 CRT ASSEMBLY, WITH DEFLECTION YOKE A-18695-09 GND STRAP ASSY , CRT

LGA20A02DM

Part# Description

009-01869-01 MODULE, MAIN, 19, 20V MONAURAL, GA1 CHASSIS 001-00224-06 ANTENNA, DIPOLE 014-12290-14 CABINET FRONT, TV, MOLDED PLASTIC, 19V

MONAURAL CTV 014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-01989 CONNECTOR AND, CABLE ASSEMBLY 095-03705-12 DEFLECTION YOKE A48ACB32X VACUUM TUBE, CRT, COLOR, 19 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00338 WEDGE, YOKE SPACER 192-00916 LENS, IR 206-03320 WARRANTY SHEET , SPANISH, LGE 206-03379 INSTR BOOK, OPERATION GUIDE, DAEWOO, SPANISH A-14323 BALUN ASSEMBLY A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

LGA20A02DM4

Part# Description

009-01869-01 MODULE, MAIN, 19, 20V MONAURAL, GA1 CHASSIS 001-00224-06 ANTENNA, DIPOLE 014-12290-16 CABINET FRONT, TV, MOLDED PLASTIC, 19V

MONAURAL CTV 014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V

CM150 4-3 GA - MODEL PARTS

MODEL PARTS

152-00338 WEDGE, YOKE SPACER 192-00916 LENS, IR 206-03379 INSTR BOOK, OPERATION GUIDE, DAEWOO,

SPANISH A-14323 BALUN ASSEMBLY A-18681 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

LGA20A02DM7

Part# Description

009-01990-01 MODULE, MAIN, 19, 20V MONAURAL, GA1 CHASSIS 001-00224-06 ANTENNA, DIPOLE 014-12290-14 CABINET FRONT, TV, MOLDED PLASTIC, 19V

MONAURAL CTV 014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V

SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

LGA20A02DM74

Part# Description

009-01990-01 MODULE, MAIN, 19, 20V MONAURAL, GA1 CHASSIS 001-00224-06 ANTENNA, DIPOLE 014-12290-16 CABINET FRONT, TV, MOLDED PLASTIC, 19V

MONAURAL CTV 014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V

SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18681 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

LGA20A02DM8

Part# Description

009-01990-01 MODULE, MAIN, 19, 20V MONAURAL, GA1 CHASSIS

001-00224-06 ANTENNA, DIPOLE 014-12290-14 CABINET FRONT, TV, MOLDED PLASTIC, 19V

MONAURAL CTV

014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V

SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18671 CRT AND YOKE, ASSEMBLY A-18695-11 GND STRAP ASSY , CRT

LGA20A02DM84

Part# Description

009-01990-01 MODULE, MAIN, 19, 20V MONAURAL, GA1 CHASSIS 001-00224-06 ANTENNA, DIPOLE 014-12290-16 CABINET FRONT, TV, MOLDED PLASTIC, 19V

MONAURAL CTV 014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V

SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18671 CRT AND YOKE, ASSEMBLY A-18681 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

LGA20A02GM

Part# Description

009-01869-01 MODULE, MAIN, 19, 20V MONAURAL, GA1 CHASSIS 001-00224-06 ANTENNA, DIPOLE 014-12290-13 CABINET FRONT, TV, MOLDED PLASTIC, 19V

MONAURAL CTV 014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V

CM150 4-4 GA - MODEL PARTS

MODEL PARTS

192-00916 LENS, IR 206-03379 INSTR BOOK, OPERATION GUIDE, DAEWOO,

SPANISH A-14323 BALUN ASSEMBLY A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

LGA20A02GM8

Part# Description

009-01990-01 MODULE, MAIN, 19, 20V MONAURAL, GA1 CHASSIS 001-00224-06 ANTENNA, DIPOLE 014-12290-13 CABINET FRONT, TV, MOLDED PLASTIC, 19V

MONAURAL CTV 014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V

SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18671 CRT AND YOKE, ASSEMBLY A-18695-11 GND STRAP ASSY , CRT

LGA20A04DM

Part# Description

009-01950-01 MODULE, MAIN, MONAURAL, JACKPACK, GA1

CHASSIS 001-00224-06 ANTENNA, DIPOLE 014-12290-14 CABINET FRONT, TV, MOLDED PLASTIC, 19V

MONAURAL CTV 014-12291-05 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-04 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-03705-12 DEFLECTION YOKE A48ACB32X VACUUM TUBE, CRT, COLOR, 19 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00338 WEDGE, YOKE SPACER 192-00916 LENS, IR 206-03330-01 INSTR BOOK, OPERATION GUIDE, ADDENDUM

GA,MONO,SC,SPAN 206-03379 INSTR BOOK, OPERATION GUIDE, DAEWOO,

SPANISH A-14323 BALUN ASSEMBLY A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

LGA20A04DM7

Part# Description

009-01993-01 MODULE, MAIN, MONAURAL WITH 2 JACKS, GA1

CHASSIS 001-00224-06 ANTENNA, DIPOLE

014-12290-14 CABINET FRONT, TV, MOLDED PLASTIC, 19V

MONAURAL CTV

014-12291-05 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-04 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04557 DEFLECTION YOKE 19V HIBI A48KRD89X VACUUM TUBE, CRT, COLOR, 19 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER, POSITIONER 192-00916 LENS, IR 206-03330-01 INSTR BOOK, OPERATION GUIDE, ADDENDUM

GA,MONO,SC,SPAN 206-03379 INSTR BOOK, OPERATION GUIDE, DAEWOO,

SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

LGA20A04DM74

Part# Description

009-01993-01 MODULE, MAIN, MONAURAL WITH 2 JACKS, GA1

CHASSIS 001-00224-06 ANTENNA, DIPOLE 014-12290-16 CABINET FRONT, TV, MOLDED PLASTIC, 19V

MONAURAL CTV 014-12291-05 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-04 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04557 DEFLECTION YOKE 19V HIBI A48KRD89X VACUUM TUBE, CRT, COLOR, 19 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER, POSITIONER 192-00916 LENS, IR 206-03330-01 INSTR BOOK, OPERATION GUIDE, ADDENDUM,

GA,MONO,SC,SPAN 206-03379 INSTR BOOK, OPERATION GUIDE, DAEWOO,

SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18681 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

LGA20A04DM8

Part# Description

009-01993-01 MODULE, MAIN, MONAURAL WITH 2 JACKS, GA1

CHASSIS 001-00224-06 ANTENNA, DIPOLE 014-12290-14 CABINET FRONT, TV, MOLDED PLASTIC, 19V

MONAURAL CTV 014-12291-05 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION

CM150 4-5 GA - MODEL PARTS

MODEL PARTS

049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-04 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER, POSITIONER 192-00916 LENS, IR 206-03330-01 INSTR BOOK, OPERATION GUIDE, ADDENDUM

GA,MONO,SC,SPAN

206-03379 INSTR BOOK, OPERATION GUIDE, DAEWOO,

SPANISH

A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18671 CRT AND YOKE, ASSEMBLY A-18695-11 GND STRAP ASSY , CRT

LGA20A04DM84

Part# Description

009-01993-01 MODULE, MAIN, MONAURAL WITH 2 JACKS, GA1

CHASSIS 001-00224-06 ANTENNA, DIPOLE 014-12290-16 CABINET FRONT, TV, MOLDED PLASTIC, 19V

MONAURAL CTV 014-12291-05 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-04 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER, POSITIONER 192-00916 LENS, IR 206-03330-01 INSTR BOOK, OPERATION GUIDE, ADDENDUM,

GA,MONO,SC,SPAN 206-03379 INSTR BOOK, OPERATION GUIDE, DAEWOO,

SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18671 CRT AND YOKE, ASSEMBLY A-18681 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

LGA20A05DM

Part# Description

009-01950-01 MODULE, MAIN, MONAURAL, JACKPACK, GA1

CHASSIS 001-00224-06 ANTENNA, DIPOLE 014-12289-09 CABINET FRONT, TV, MOLDED PLASTIC, 19V STEREO

CTV 014-12291-05 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER 024-03346 COVER, UNUSED SPEAKER OPENINGS 046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-04 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-03705-12 DEFLECTION YOKE A48ACB32X VACUUM TUBE, CRT, COLOR, 19 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00338 WEDGE, YOKE SPACER

192-00917 LENS, IR 206-03330-01 INSTR BOOK, OPERATION GUIDE, ADDENDUM

GA,MONO,SC,SPAN

206-03379 INSTR BOOK, OPERATION GUIDE, DAEWOO,

SPANISH A-14323 BALUN ASSEMBLY A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

LGA20A05DM7

Part# Description

009-01993-01 MODULE, MAIN, MONAURAL WITH 2 JACKS, GA1

CHASSIS 001-00224-06 ANTENNA, DIPOLE 014-12289-09 CABINET FRONT, TV, MOLDED PLASTIC, 19V STEREO

CTV 014-12291-05 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER 024-03346 COVER, UNUSED SPEAKER OPENINGS 046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-04 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04557 DEFLECTION YOKE 19V HIBI A48KRD89X VACUUM TUBE, CRT, COLOR, 19 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER, POSITIONER 192-00917 LENS, IR 206-03330-01 INSTR BOOK, OPERATION GUIDE, ADDENDUM

GA,MONO,SC,SPAN 206-03379 INSTR BOOK, OPERATION GUIDE, DAEWOO,

SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

LGA20A05DM74

Part# Description

009-01993-01 MODULE, MAIN, MONAURAL WITH 2 JACKS, GA1

CHASSIS 001-00224-06 ANTENNA, DIPOLE 014-12289-10 CABINET FRONT, TV, MOLDED PLASTIC, 19V STEREO

CTV 014-12291-05 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER 024-03346 COVER, UNUSED SPEAKER OPENINGS 046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-04 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04557 DEFLECTION YOKE 19V HIBI A48KRD89X VACUUM TUBE, CRT, COLOR, 19 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER, POSITIONER 192-00917 LENS, IR 206-03330-01 INSTR BOOK, OPERATION GUIDE, ADDENDUM,

GA,MONO,SC,SPAN 206-03379 INSTR BOOK, OPERATION GUIDE, DAEWOO,

SPANISH

CM150 4-6 GA - MODEL PARTS

MODEL PARTS

A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18681 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

LGA20A05DM8

Part# Description

009-01993-01 MODULE, MAIN, MONAURAL WITH 2 JACKS, GA1

CHASSIS 001-00224-06 ANTENNA, DIPOLE 014-12289-09 CABINET FRONT, TV, MOLDED PLASTIC, 19V STEREO

CTV 014-12291-05 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER 024-03346 COVER, UNUSED SPEAKER OPENINGS 046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-04 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER, POSITIONER 192-00917 LENS, IR 206-03330-01 INSTR BOOK, OPERATION GUIDE, ADDENDUM,

GA,MONO,SC,SPAN 206-03379 INSTR BOOK, OPERATION GUIDE, DAEWOO,

SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18671 CRT AND YOKE, ASSEMBLY A-18695-11 GND STRAP ASSY , CRT

LGA20A05DM84

Part# Description

009-01993-01 MODULE, MAIN, MONAURAL WITH 2 JACKS, GA1

CHASSIS 001-00224-06 ANTENNA, DIPOLE 014-12289-10 CABINET FRONT, TV, MOLDED PLASTIC, 19V STEREO

CTV 014-12291-05 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER 024-03346 COVER, UNUSED SPEAKER OPENINGS 046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-04 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER, POSITIONER 192-00917 LENS, IR 206-03330-01 INSTR BOOK, OPERATION GUIDE, ADDENDUM,

GA,MONO,SC,SPAN 206-03379 INSTR BOOK, OPERATION GUIDE, DAEWOO,

SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18671 CRT AND YOKE, ASSEMBLY A-18681 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

LGA20A11DM

Part# Description

009-01870-01 MODULE, MAIN, 19, 20V STEREO, GA1 CHASSIS 001-00224-06 ANTENNA, DIPOLE 014-12289-09 CABINET FRONT, TV, MOLDED PLASTIC, 19V STEREO

CTV

014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER 046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-03705-12 DEFLECTION YOKE A48ACB32X VACUUM TUBE, CRT, COLOR, 19 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00338 WEDGE, YOKE SPACER 192-00917 LENS, IR 206-03380 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-14323 BALUN ASSEMBLY A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

LGA20A11DM7

Part# Description

009-01991-01 MODULE, MAIN, 19, 20V STEREO, GA1 CHASSIS 001-00224-06 ANTENNA, DIPOLE 014-12289-09 CABINET FRONT, TV, MOLDED PLASTIC, 19V STEREO

CTV 014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER 046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04557 DEFLECTION YOKE 19V HIBI A48KRD89X VACUUM TUBE, CRT, COLOR, 19 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER, POSITIONER 192-00917 LENS, IR 206-03380 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

LGA20A11DM74

Part# Description

009-01991-01 MODULE, MAIN, 19, 20V STEREO, GA1 CHASSIS 001-00224-06 ANTENNA, DIPOLE 014-12289-10 CABINET FRONT, TV, MOLDED PLASTIC, 19V STEREO

CTV 014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V

CM150 4-7 GA - MODEL PARTS

MODEL PARTS

152-00335 WEDGE, YOKE SPACER, POSITIONER 192-00917 LENS, IR 206-03380 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18681 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

LGA20A11DM8

Part# Description

009-01991-01 MODULE, MAIN, 19, 20V STEREO, GA1 CHASSIS 001-00224-06 ANTENNA, DIPOLE 014-12289-09 CABINET FRONT, TV, MOLDED PLASTIC, 19V STEREO

CTV 014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER 046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER, POSITIONER 192-00917 LENS, IR 206-03380 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18671 CRT AND YOKE, ASSEMBLY A-18695-11 GND STRAP ASSY , CRT

LGA20A11DM84

Part# Description

009-01991-01 MODULE, MAIN, 19, 20V STEREO, GA1 CHASSIS 001-00224-06 ANTENNA, DIPOLE 014-12289-10 CABINET FRONT, TV, MOLDED PLASTIC, 19V STEREO

CTV 014-12291-04 CABINET REAR, TV, MOLDED PLASTIC, 19V

MONAURAL, STEREO 020-04330-32 COIL, DEGAUSSER 046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER, POSITIONER 192-00917 LENS, IR 206-03380 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18671 CRT AND YOKE, ASSEMBLY A-18681 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-11 GND STRAP ASSY , CRT

LGA21A22DM

Part# Description

009-01871-01 MODULE, MAIN, 19, 20V MTS, GA CHASSIS 001-00224-06 ANTENNA, DIPOLE 014-12292-04 CABINET FRONT, TV, MOLDED PLASTIC, 20V STEREO

014-12294-03 CABINET REAR, TV, MOLDED PLASTIC, 20V

MONAURAL, STEREO 020-04330-31 COIL, DEGAUSSER 046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04023-09 DEFLECTION YOKE A51AGD33X VACUUM TUBE, CRT, COLOR, 20 INCH DIAGONAL 124-00212-62 SPACE COMMAND, TRANSMITTER, MBR3446 152-00338 WEDGE, YOKE SPACER 192-00917 LENS, IR 206-03381 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-14323 BALUN ASSEMBLY A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-09 GND STRAP ASSY , CRT

LGA21A22DM4

Part# Description

009-01871-01 MODULE, MAIN, 19, 20V MTS, GA CHASSIS 001-00224-06 ANTENNA, DIPOLE 014-12292-04 CABINET FRONT, TV, MOLDED PLASTIC, 20V STEREO 014-12294-03 CABINET REAR, TV, MOLDED PLASTIC, 20V

MONAURAL, STEREO 020-04330-31 COIL, DEGAUSSER 046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04023-09 DEFLECTION YOKE A51AGD33X VACUUM TUBE, CRT, COLOR, 20 INCH DIAGONAL 124-00212-62 SPACE COMMAND, TRANSMITTER, MBR3446 152-00338 WEDGE, YOKE SPACER 192-00917 LENS, IR 206-03320 WARRANTY SHEET , SPANISH, LGE 206-03381 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-14323 BALUN ASSEMBLY A-18681 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-09 GND STRAP ASSY , CRT

LGA21A22DM8

Part# Description

009-01992-01 MODULE, MAIN, 19, 20V WITH MTS, GA1 CHASSIS 001-00224-06 ANTENNA, DIPOLE 014-12292-04 CABINET FRONT, TV, MOLDED PLASTIC, 20V STEREO 014-12294-03 CABINET REAR, TV, MOLDED PLASTIC, 20V

MONAURAL, STEREO 020-04330-31 COIL, DEGAUSSER 046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 124-00212-62 SPACE COMMAND, TRANSMITTER, MBR3446 152-00335 WEDGE, YOKE SPACER, POSITIONER 192-00917 LENS, IR 206-03381 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18588 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18693 CRT ASSEMBLY, WITH DEFLECTION YOKE A-18695-09 GND STRAP ASSY , CRT

CM150 4-8 GA - MODEL PARTS

MODEL PARTS

LGA21A22DM84

Part# Description

009-01992-01 MODULE, MAIN, 19, 20V WITH MTS, GA1 CHASSIS 001-00224-06 ANTENNA, DIPOLE 014-12292-04 CABINET FRONT, TV, MOLDED PLASTIC, 20V STEREO 014-12294-03 CABINET REAR, TV, MOLDED PLASTIC, 20V

MONAURAL, STEREO 020-04330-31 COIL, DEGAUSSER 046-10577 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01369 SPEAKER, OVAL, 6 X 9 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 124-00212-62 SPACE COMMAND, TRANSMITTER, MBR3446 152-00335 WEDGE, YOKE SPACER, POSITIONER 192-00917 LENS, IR 206-03381 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18681 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18693 CRT ASSEMBLY, WITH DEFLECTION YOKE A-18695-09 GND STRAP ASSY , CRT

GA-2 MODELS

A25A02D

Part# Description

009-01789-01 MODULE, MAIN, 25V MONAURAL, GA2 CHASSIS 014-12296-09 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-02 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 024-03372 COVER, BLANK, 2 X 5 SPEAKER OPENING 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01989 CONNECTOR AND, CABLE ASSEMBLY 095-04456-03 DEFLECTION YOKE A63AGD01X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03369 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-10 GND STRAP ASSY , CRT

A25A02D4

Part# Description

009-01789-01 MODULE, MAIN, 25V MONAURAL, GA2 CHASSIS 014-12296-15 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-06 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 024-03372 COVER, BLANK, 2 X 5 SPEAKER OPENING 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01989 CONNECTOR AND, CABLE ASSEMBLY 095-04456-03 DEFLECTION YOKE A63AGD01X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR

206-03369 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-10 GND STRAP ASSY , CRT

A25A02D64

Part# Description

009-01789-01 MODULE, MAIN, 25V MONAURAL, GA2 CHASSIS 014-12296-15 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-06 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 024-03372 COVER, BLANK, 2 X 5 SPEAKER OPENING 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01989 CONNECTOR AND, CABLE ASSEMBLY 095-04456-03 DEFLECTION YOKE A63AHC26X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03369 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-10 GND STRAP ASSY , CRT

A25A02D7

Part# Description

009-01977-01 MODULE, MAIN, 25V MONAURAL, GA CHASSIS 014-12296-09 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-02 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 024-03372 COVER, BLANK, 2 X 5 SPEAKER OPENING 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01989 CONNECTOR AND, CABLE ASSEMBLY 095-04456-05 DEFLECTION YOKE 25V HIBI COMERCIAL A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03369 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT

A25A02D74

Part# Description

009-01977-01 MODULE, MAIN, 25V MONAURAL, GA CHASSIS 014-12296-15 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-06 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 024-03372 COVER, BLANK, 2 X 5 SPEAKER OPENING 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01989 CONNECTOR AND, CABLE ASSEMBLY 095-04456-05 DEFLECTION YOKE 25V HIBI COMERCIAL A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY

CM150 4-9 GA - MODEL PARTS

MODEL PARTS

152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03369 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT

A25A02D8

Part# Description

009-01977-01 MODULE, MAIN, 25V MONAURAL, GA CHASSIS 014-12296-09 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-02 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 024-03372 COVER, BLANK, 2 X 5 SPEAKER OPENING 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01989 CONNECTOR AND, CABLE ASSEMBLY 095-04531 DEFLECTION YOKE A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03369 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT

A25A02D84

Part# Description

009-01977-01 MODULE, MAIN, 25V MONAURAL, GA CHASSIS 014-12296-15 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-06 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 024-03372 COVER, BLANK, 2 X 5 SPEAKER OPENING 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01989 CONNECTOR AND, CABLE ASSEMBLY 095-04531 DEFLECTION YOKE A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03369 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT

A63AGD01X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03370 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-10 GND STRAP ASSY , CRT

A25A11D4

Part# Description

009-01790-01 MODULE, MAIN, 25V STEREO, GA2 CHASSIS 014-12296-15 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-05 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04456-03 DEFLECTION YOKE A63AGD01X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03370 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-10 GND STRAP ASSY , CRT

A25A11D64

Part# Description

009-01790-01 MODULE, MAIN, 25V STEREO, GA2 CHASSIS 014-12296-15 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-05 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04456-03 DEFLECTION YOKE A63AHC26X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03370 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-10 GND STRAP ASSY , CRT

A25A11D

Part# Description

009-01790-01 MODULE, MAIN, 25V STEREO, GA2 CHASSIS 014-12296-09 CABINET FRONT, TV, MOLDED PLASTIC 014-12296-10 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-01 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04456-03 DEFLECTION YOKE

CM150 4-10 GA - MODEL PARTS

A25A11D7

Part# Description

MODEL PARTS

124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03370 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT

A25A11D74

Part# Description

009-01976-01 MODULE, MAIN, 25V STEREO, GA2 CHASSIS 014-12296-15 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-05 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04456-05 DEFLECTION YOKE 25V HIBI COMERCIAL A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03370 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT

152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03370 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT

A25A12D

Part# Description

009-01790-01 MODULE, MAIN, 25V STEREO, GA2 CHASSIS 014-12296-09 CABINET FRONT, TV, MOLDED PLASTIC 014-12296-11 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-01 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04456-03 DEFLECTION YOKE A63AGD01X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00212-58 SPACE COMMAND, TRANSMITTER, MBR3447A 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03416 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-10 GND STRAP ASSY , CRT

A25A11D8

Part# Description

009-01976-01 MODULE, MAIN, 25V STEREO, GA2 CHASSIS 014-12296-09 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-01 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04531 DEFLECTION YOKE A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03370 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT

A25A11D84

Part# Description

009-01976-01 MODULE, MAIN, 25V STEREO, GA2 CHASSIS 014-12296-15 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-05 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04531 DEFLECTION YOKE A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY

A25A12D4

Part# Description

009-01790-01 MODULE, MAIN, 25V STEREO, GA2 CHASSIS 014-12296-15 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-05 CABINET REAR, TV, MOLDED PLASTIC 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04456-03 DEFLECTION YOKE A63AGD01X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00212-58 SPACE COMMAND, TRANSMITTER, MBR3447A 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03416 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-10 GND STRAP ASSY , CRT

A25A74R

Part# Description

009-01831-01 MODULE, MAIN, 25V MTS, GA2 CHASSIS 002-04084-11 CABINET BACK, PRESSED WOOD 012-10810 MOLDED PLASTIC , PANEL, JACK PACK, GA CHASSIS 014-12191-03 CABINET MAIN, TV, WOOD 019-01248 CLIP, DEGAUSSER COIL RETENTION 020-04330-35 COIL, DEGAUSSER 030-01455-14 DECORATIVE ITEM, CABINET HARDWARE 049-01302-03 SPEAKER, OVAL, 3X5 INCH 050-01699-06 CONNECTOR&CABLE, ASSY, 2.5MM, 5 CONTACT, 2 UP 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 057-09067-07 ESCUTCHEON, TV, MOLDED PLASTIC

CM150 4-11 GA - MODEL PARTS

MODEL PARTS

095-04456-03 DEFLECTION YOKE A63AGD01X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00876 CRYSTAL WINDOW , IR 197-00180-01 CUP, CABINET BACK 206-03450 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-10 GND STRAP ASSY , CRT A-19122 ESCUTCHEON ASSY 046-10555 KNOB ARRAY, PUSH BUTTON, 10 POSITION, STR 194-02535 PAD, BUTTONS A-18225 KEYBOARD ASSEMBLY, WITH IR, AGUA CHASSIS

A25A74R7

Part# Description

009-01831-02 MODULE, MAIN, 25V MTS, GA2 CHASSIS 002-04084-11 CABINET BACK, PRESSED WOOD 012-10810 MOLDED PLASTIC , PANEL, JACK PACK, GA CHASSIS 014-12191-03 CABINET MAIN, TV, WOOD 019-01248 CLIP, DEGAUSSER COIL RETENTION 020-04330-35 COIL, DEGAUSSER 030-01455-14 DECORATIVE ITEM, CABINET HARDWARE 049-01302-03 SPEAKER, OVAL, 3X5 INCH 050-01699-06 CONNECTOR&CABLE, ASSY, 2.5MM, 5 CONTACT, 2 UP 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 057-09067-07 ESCUTCHEON, TV, MOLDED PLASTIC 095-04456-05 DEFLECTION YOKE 25V HIBI COMERCIAL A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00876 CRYSTAL WINDOW , IR 197-00180-01 CUP, CABINET BACK 206-03450 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT A-19122 ESCUTCHEON ASSY 046-10555 KNOB ARRAY, PUSH BUTTON, 10 POSITION, STR 194-02535 PAD, BUTTONS A-18225 KEYBOARD ASSEMBLY, WITH IR, AGUA CHASSIS

124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00876 CRYSTAL WINDOW , IR 197-00180-01 CUP, CABINET BACK 206-03450 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR, A-18695-02 GND STRAP ASSY , CRT A-19122 ESCUTCHEON ASSY 046-10555 KNOB ARRAY, PUSH BUTTON, 10 POSITION, STR 194-02535 PAD, BUTTONS A-18225 KEYBOARD ASSEMBLY, WITH IR, AGUA CHASSIS

A25A76R

Part# Description

009-01831-01 MODULE, MAIN, 25V MTS, GA2 CHASSIS 002-04103-01 CABINET BACK 012-10751 METAL STAMPING , STRIKER PLATE 014-11639-19 CABINET REAR, TV, MOLDED PLASTIC 014-12333 CABINET MAIN, TV, WOOD 019-01248 CLIP, DEGAUSSER COIL RETENTION 020-04330-35 COIL, DEGAUSSER 040-00567 HINGE 049-01302-03 SPEAKER, OVAL, 3X5 INCH 050-01699-06 CONNECTOR&CABLE, ASSY, 2.5MM, 5 CONTACT, 2 UP 050-02576-03 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 057-09067-07 ESCUTCHEON, TV, MOLDED PLASTIC 095-04456-03 DEFLECTION YOKE A63AGD01X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 157-00024 CABINET BACK, FASTENER 192-00876 CRYSTAL WINDOW , IR 192-00892 GLASS DOOR 206-03450 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-10 GND STRAP ASSY , CRT A-19127 ESCUTCHEON ASSY 046-10555 KNOB ARRAY, PUSH BUTTON, 10 POSITION, STR 194-02535 PAD, BUTTONS A-18225 KEYBOARD ASSEMBLY, WITH IR, AGUA CHASSIS

A25A74R8

Part# Description

CM150 4-12 GA - MODEL PARTS

A25A76R7

Part# Description

MODEL PARTS

A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 110-00687-59 GRILLE CLOTH, RECTANGULAR 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00876 CRYSTAL WINDOW , IR 192-00892 GLASS DOOR 206-03450 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT A-19127 ESCUTCHEON ASSY 046-10555 KNOB ARRAY, PUSH BUTTON, 10 POSITION, STR 194-02535 PAD, BUTTONS A-18225 KEYBOARD ASSEMBLY, WITH IR, AGUA CHASSIS

A25A76R8

Part# Description

009-01831-02 MODULE, MAIN, 25V MTS, GA2 CHASSIS 002-04103-01 CABINET BACK 012-10751 METAL STAMPING , STRIKER PLATE 014-11639-19 CABINET REAR, TV, MOLDED PLASTIC 014-12333 CABINET MAIN, TV, WOOD 019-01248 CLIP, DEGAUSSER COIL RETENTION 020-04330-35 COIL, DEGAUSSER 040-00567 HINGE 049-01302-03 SPEAKER, OVAL, 3X5 INCH 050-01699-06 CONNECTOR&CABLE, ASSY, 2.5MM, 5 CONTACT, 2 UP 050-02576-03 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 057-09067-07 ESCUTCHEON, TV, MOLDED PLASTIC 095-04531 DEFLECTION YOKE A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 110-00687-59 GRILLE CLOTH, RECTANGULAR 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00876 CRYSTAL WINDOW , IR 192-00892 GLASS DOOR 206-03450 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

A27A11D

Part# Description

009-01791-01 MODULE, MAIN, 27V STEREO, GA2 CHASSIS 014-12304-01 CABINET REAR, TV, MOLDED PLASTIC 014-12305-06 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-30 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-03797-05 DEFLECTION YOKE A68AGD02X VACUUM TUBE, CRT, COLOR, 27 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR

206-03370 INSTR BOOK, OPERATION GUIDE A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT

A27A11D4

Part# Description

A27A11D8

Part# Description

009-01791-02 MODULE, MAIN, 27V STEREO, GA2 CHASSIS 014-12304-01 CABINET REAR, TV, MOLDED PLASTIC 014-12305-06 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-30 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02361 CONNECTOR AND, CABLE ASSEMBLY, 35V CTV YOKE 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 192-00916 LENS, IR 206-03370 INSTR BOOK, OPERATION GUIDE A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT A-19058-01 CRT AND YOKE, ASSEMBLY

A27A11D84

Part# Description

009-01791-02 MODULE, MAIN, 27V STEREO, GA2 CHASSIS 014-12304-01 CABINET REAR, TV, MOLDED PLASTIC 014-12305-06 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-30 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02361 CONNECTOR AND, CABLE ASSEMBLY, 35V CTV YOKE 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 192-00916 LENS, IR 206-03370 INSTR BOOK, OPERATION GUIDE A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT A-19058-01 CRT AND YOKE, ASSEMBLY

A27A12D

Part# Description

009-01791-01 MODULE, MAIN, 27V STEREO, GA2 CHASSIS 014-12304-01 CABINET REAR, TV, MOLDED PLASTIC 014-12305-06 CABINET FRONT, TV, MOLDED PLASTIC

CM150 4-13 GA - MODEL PARTS

MODEL PARTS

020-04330-30 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-03797-05 DEFLECTION YOKE A68AGD02X VACUUM TUBE, CRT, COLOR, 27 INCH DIAGONAL 124-00212-58 SPACE COMMAND, TRANSMITTER, MBR3447A 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03416 INSTR BOOK, OPERATION GUIDE A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT

A27A12D4

Part# Description

009-01791-01 MODULE, MAIN, 27V STEREO, GA2 CHASSIS 014-12304-01 CABINET REAR, TV, MOLDED PLASTIC 014-12305-06 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-30 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-03797-05 DEFLECTION YOKE A68AGD02X VACUUM TUBE, CRT, COLOR, 27 INCH DIAGONAL 124-00212-58 SPACE COMMAND, TRANSMITTER, MBR3447A 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03416 INSTR BOOK, OPERATION GUIDE A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT

A27A12D8

Part# Description

009-01791-02 MODULE, MAIN, 27V STEREO, GA2 CHASSIS 014-12304-01 CABINET REAR, TV, MOLDED PLASTIC 014-12305-06 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-30 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02361 CONNECTOR AND, CABLE ASSEMBLY, 35V CTV YOKE 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 124-00212-58 SPACE COMMAND, TRANSMITTER, MBR3447A 192-00916 LENS, IR 206-03416 INSTR BOOK, OPERATION GUIDE A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT A-19058-01 CRT AND YOKE, ASSEMBLY

LGA26A02DM

Part# Description

124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03379 INSTR BOOK, OPERATION GUIDE, DAEWOO, SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-10 GND STRAP ASSY , CRT

LGA26A02DM4

Part# Description

PURITY A-14323 BALUN ASSEMBLY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-10 GND STRAP ASSY , CRT

LGA26A02DM64

Part# Description

009-01789-01 MODULE, MAIN, 25V MONAURAL, GA2 CHASSIS 014-12296-15 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-06 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 024-03372 COVER, BLANK, 2 X 5 SPEAKER OPENING 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01989 CONNECTOR AND, CABLE ASSEMBLY 095-04456-03 DEFLECTION YOKE A63AHC26X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03379 INSTR BOOK, OPERATION GUIDE, DAEWOO, SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-10 GND STRAP ASSY , CRT

LGA26A02DM7

Part# Description

CM150 4-14 GA - MODEL PARTS

MODEL PARTS

046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01989 CONNECTOR AND, CABLE ASSEMBLY 095-04456-05 DEFLECTION YOKE 25V HIBI COMERCIAL A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03379 INSTR BOOK, OPERATION GUIDE, DAEWOO, SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT

LGA26A02DM74

Part# Description

PURITY, A-14323 BALUN ASSEMBLY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT

LGA26A02DM8

Part# Description

009-01977-01 MODULE, MAIN, 25V MONAURAL, GA CHASSIS 014-12296-09 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-02 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 024-03372 COVER, BLANK, 2 X 5 SPEAKER OPENING 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01989 CONNECTOR AND, CABLE ASSEMBLY 095-04531 DEFLECTION YOKE A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03379 INSTR BOOK, OPERATION GUIDE, DAEWOO, SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT

LGA26A11DM

Part# Description

009-01790-01 MODULE, MAIN, 25V STEREO, GA2 CHASSIS 014-12296-09 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-01 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04456-03 DEFLECTION YOKE A63AGD01X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03380 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-10 GND STRAP ASSY , CRT

LGA26A11DM4

Part# Description

009-01790-01 MODULE, MAIN, 25V STEREO, GA2 CHASSIS 014-12296-15 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-05 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04456-03 DEFLECTION YOKE A63AGD01X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03380 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-10 GND STRAP ASSY , CRT

LGA26A11DM64

Part# Description

009-01790-01 MODULE, MAIN, 25V STEREO, GA2 CHASSIS 014-12296-15 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-05 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04456-03 DEFLECTION YOKE A63AHC26X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR, 206-03380 INSTR BOOK OPERATION GUIDE, ZENITH, SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY

CM150 4-15 GA - MODEL PARTS

MODEL PARTS

A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-10 GND STRAP ASSY , CRT

LGA26A11DM7

Part# Description

009-01976-01 MODULE, MAIN, 25V STEREO, GA2 CHASSIS 014-12296-09 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-01 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04456-05 DEFLECTION YOKE 25V HIBI COMERCIAL A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03380 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT

LGA26A11DM74

Part# Description

009-01976-01 MODULE, MAIN, 25V STEREO, GA2 CHASSIS 014-12296-15 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-05 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04456-05 DEFLECTION YOKE 25V HIBI COMERCIAL A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03380 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT

LGA26A11DM8

Part# Description

A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT

LGA26A12DM

Part# Description

009-01790-01 MODULE, MAIN, 25V STEREO, GA2 CHASSIS 014-12296-09 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-01 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04456-03 DEFLECTION YOKE A63AGD01X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00212-58 SPACE COMMAND, TRANSMITTER, MBR3447A 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03383 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-10 GND STRAP ASSY , CRT

LGA26A02GM

Part# Description

009-01789-01 MODULE, MAIN, 25V MONAURAL, GA2 CHASSIS 014-12296-12 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-02 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 024-03372 COVER, BLANK, 2 X 5 SPEAKER OPENING 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01989 CONNECTOR AND, CABLE ASSEMBLY 095-04456-03 DEFLECTION YOKE A63AGD01X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03379 INSTR BOOK, OPERATION GUIDE, DAEWOO, SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-10 GND STRAP ASSY , CRT

LGA26A02GM7

Part# Description

CM150 4-16 GA - MODEL PARTS

MODEL PARTS

PURITY A-14323 BALUN ASSEMBLY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT

LGA26A02GM8

Part# Description

009-01977-01 MODULE, MAIN, 25V MONAURAL, GA CHASSIS 014-12296-12 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-02 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 024-03372 COVER, BLANK, 2 X 5 SPEAKER OPENING 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01989 CONNECTOR AND, CABLE ASSEMBLY 095-04531 DEFLECTION YOKE A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03379 INSTR BOOK, OPERATION GUIDE, DAEWOO, SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT

LGA29A11DM

Part# Description

LGA29A11DM4

Part# Description

A68AGD02X VACUUM TUBE, CRT, COLOR, 27 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03380 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-14323 BALUN ASSEMBLY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT

LGA29A11DM8

Part# Description

009-01791-02 MODULE, MAIN, 27V STEREO, GA2 CHASSIS 014-12304-01 CABINET REAR, TV, MOLDED PLASTIC 014-12305-06 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-30 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02361 CONNECTOR AND, CABLE ASSEMBLY, 35V CTV YOKE 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 192-00916 LENS, IR 206-03380 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-14323 BALUN ASSEMBLY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT A-19058-01 CRT AND YOKE, ASSEMBLY

LGA29A11DM84

Part# Description

009-01791-02 MODULE, MAIN, 27V STEREO, GA2 CHASSIS 014-12304-01 CABINET REAR, TV, MOLDED PLASTIC 014-12305-06 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-30 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02361 CONNECTOR AND, CABLE ASSEMBLY, 35V CTV YOKE 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 192-00916 LENS, IR 206-03380 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-14323 BALUN ASSEMBLY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT A-19058-01 CRT AND YOKE, ASSEMBLY

LGA29A12DM

Part# Description

009-01791-01 MODULE, MAIN, 27V STEREO, GA2 CHASSIS 014-12304-01 CABINET REAR, TV, MOLDED PLASTIC 014-12305-06 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-30 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-03797-05 DEFLECTION YOKE A68AGD02X VACUUM TUBE, CRT, COLOR, 27 INCH DIAGONAL 124-00212-58 SPACE COMMAND, TRANSMITTER, MBR3447A 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03383 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-14323 BALUN ASSEMBLY

CM150 4-17 GA - MODEL PARTS

MODEL PARTS

A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT

LGA29A12DM4

Part# Description

009-01791-01 MODULE, MAIN, 27V STEREO, GA2 CHASSIS 014-12304-01 CABINET REAR, TV, MOLDED PLASTIC 014-12305-06 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-30 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-03797-05 DEFLECTION YOKE A68AGD02X VACUUM TUBE, CRT, COLOR, 27 INCH DIAGONAL 124-00212-58 SPACE COMMAND, TRANSMITTER, MBR3447A 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03383 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-14323 BALUN ASSEMBLY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT

LGA29A12DM84

Part# Description

009-01791-02 MODULE, MAIN, 27V STEREO, GA2 CHASSIS 014-12304-01 CABINET REAR, TV, MOLDED PLASTIC 014-12305-06 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-30 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02361 CONNECTOR AND, CABLE ASSEMBLY, 35V CTV YOKE 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 124-00212-58 SPACE COMMAND, TRANSMITTER, MBR3447A 192-00916 LENS, IR 206-03383 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-14323 BALUN ASSEMBLY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR, A-18695-02 GND STRAP ASSY , CRT A-19058-01 CRT AND YOKE, ASSEMBLY

LGA29A11GM

Part# Description

009-01791-01 MODULE, MAIN, 27V STEREO, GA2 CHASSIS 014-12304-01 CABINET REAR, TV, MOLDED PLASTIC 014-12305-07 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-30 COIL, DEGAUSSER 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02576-02 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-03797-05 DEFLECTION YOKE A68AGD02X VACUUM TUBE, CRT, COLOR, 27 INCH DIAGONAL 124-00213-16 SPACE COMMAND, TRANSMITTER, TV ONLY 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00916 LENS, IR 206-03380 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-14323 BALUN ASSEMBLY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT

GA-3 MODELS

A25A22BT

Part# Description

009-01996 MODULE, MAIN, 25V MTS, GA3 CHASSIS 012-10571 METAL STAMPING , BRACKET, CRT MOUNTING 012-10694 METAL STAMPING , BRACKET, CRT SUPPORT 012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS 014-12038-02 CABINET TRAY, TV, MOLDED PLASTIC 014-12229-16 CABINET FRONT, TV, MOLDED PLASTIC 014-12230-03 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04456-03 DEFLECTION YOKE A63AGD01X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00887 LENS, INFRARED 206-03436 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-10 GND STRAP ASSY , CRT 046-10561 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS 194-02535-01 PAD, BUTTONS A-18295 KEYBOARD ASSEMBLY, WITH IR RECEIVER, AGUA

CHASSIS

A25A22BT4

Part# Description

PURITY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-10 GND STRAP ASSY , CRT 046-10561 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS 194-02535-01 PAD, BUTTONS A-18295 KEYBOARD ASSEMBLY, WITH IR RECEIVER, AGUA

CHASSIS

CM150 4-18 GA - MODEL PARTS

MODEL PARTS

A25A22BT64

Part# Description

009-01996 MODULE, MAIN, 25V MTS, GA3 CHASSIS 012-10571 METAL STAMPING , BRACKET, CRT MOUNTING 012-10694 METAL STAMPING , BRACKET, CRT SUPPORT 012-10858-01 MOLDED PLASTIC , PANEL, JACK PACK, GA3 CHASSIS 014-12038-02 CABINET TRAY, TV, MOLDED PLASTIC 014-12229-16 CABINET FRONT, TV, MOLDED PLASTIC 014-12230-03 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04456-03 DEFLECTION YOKE A63AHC26X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00887 LENS, INFRARED 206-03436 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

CHASSIS

A25A22BT7

Part# Description

009-02041 MODULE, MAIN, 25V MTS, GA3 CHASSIS 012-10694 METAL STAMPING , BRACKET, CRT SUPPORT 012-10832 METAL STAMPING , BRACKET, CRT MOUNTING 012-10832-01 METAL STAMPING , BRACKET, CRT MOUNTING 012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS 014-12038-02 CABINET TRAY, TV, MOLDED PLASTIC 014-12229-16 CABINET FRONT, TV, MOLDED PLASTIC 014-12230-03 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04456-05 DEFLECTION YOKE, 25V HIBI COMERCIAL A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00887 LENS, INFRARED 206-03436 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT 046-10561 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS 194-02535-01 PAD, BUTTONS A-18295 KEYBOARD ASSEMBLY, WITH IR RECEIVER, AGUA

CHASSIS

A25A22BT74

Part# Description

009-02041 MODULE, MAIN, 25V MTS, GA3 CHASSIS

012-10694 METAL STAMPING , BRACKET, CRT SUPPORT 012-10832 METAL STAMPING , BRACKET, CRT MOUNTING 012-10832-01 METAL STAMPING , BRACKET, CRT MOUNTING 012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS 014-12038-02 CABINET TRAY, TV, MOLDED PLASTIC 014-12229-16 CABINET FRONT, TV, MOLDED PLASTIC 014-12230-03 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04456-05 DEFLECTION YOKE, 25V HIBI COMERCIAL A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00887 LENS, INFRARED 206-03436 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT 046-10561 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS 194-02535-01 PAD, BUTTONS A-18295 KEYBOARD ASSEMBLY, WITH IR RECEIVER, AGUA

CHASSIS

A25A22BT8

Part# Description

009-02041 MODULE, MAIN, 25V MTS, GA3 CHASSIS 012-10694 METAL STAMPING , BRACKET, CRT SUPPORT 012-10832 METAL STAMPING , BRACKET, CRT MOUNTING 012-10832-01 METAL STAMPING , BRACKET, CRT MOUNTING 012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS 014-12038-02 CABINET TRAY, TV, MOLDED PLASTIC 014-12229-16 CABINET FRONT, TV, MOLDED PLASTIC 014-12230-03 CABINET REAR, TV, MOLDED PLASTIC, 020-04330-35 COIL, DEGAUSSER 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04531 DEFLECTION YOKE A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00887 LENS, INFRARED 206-03436 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

CHASSIS

A25A22BT84

Part# Description

009-02041 MODULE, MAIN, 25V MTS, GA3 CHASSIS 012-10694 METAL STAMPING , BRACKET, CRT SUPPORT 012-10832 METAL STAMPING , BRACKET, CRT MOUNTING 012-10832-01 METAL STAMPING , BRACKET, CRT MOUNTING

CM150 4-19 GA - MODEL PARTS

MODEL PARTS

012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS 014-12038-02 CABINET TRAY, TV, MOLDED PLASTIC 014-12229-16 CABINET FRONT, TV, MOLDED PLASTIC 014-12230-03 CABINET REAR, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04531 DEFLECTION YOKE A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00887 LENS, INFRARED 206-03436 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

CHASSIS

A25A23W

Part# Description

009-01996 MODULE, MAIN, 25V MTS, GA3 CHASSIS 012-10571 METAL STAMPING , BRACKET, CRT MOUNTING 012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS 014-12143-02 CABINET TRAY, MOLDED PLASTIC 014-12181-09 CABINET REAR, TV, MOLDED PLASTIC 014-12187-13 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04456-03 DEFLECTION YOKE A63AGD01X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00858-01 LENS, PRIMARY CONTROLS AND IR 206-03373 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-10 GND STRAP ASSY , CRT 046-10554 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS 194-02535 PAD, BUTTONS A-18232 KEYBOARD ASSEMBLY, WITH IR RECEIVER

A25A23W4

Part# Description

050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04456-03 DEFLECTION YOKE A63AGD01X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00858-01 LENS, PRIMARY CONTROLS AND IR 206-03373 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-10 GND STRAP ASSY , CRT 046-10554 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS 194-02535 PAD, BUTTONS A-18232 KEYBOARD ASSEMBLY, WITH IR RECEIVER

A25A23W6

Part# Description

009-01996 MODULE, MAIN, 25V MTS, GA3 CHASSIS 012-10571 METAL STAMPING , BRACKET, CRT MOUNTING 012-10858-01 MOLDED PLASTIC , PANEL, JACK PACK, GA3 CHASSIS 014-12143-02 CABINET TRAY, MOLDED PLASTIC 014-12181-09 CABINET REAR, TV, MOLDED PLASTIC 014-12187-13 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04571 DEFLECTION YOKE A63AHC26X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00858-01 LENS, PRIMARY CONTROLS AND IR 206-03373 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

A25A23W64

Part# Description

CM150 4-20 GA - MODEL PARTS

MODEL PARTS

A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

A25A23W7

Part# Description

009-02041 MODULE, MAIN, 25V MTS, GA3 CHASSIS 012-10832 METAL STAMPING , BRACKET, CRT MOUNTING 012-10832-01 METAL STAMPING , BRACKET, CRT MOUNTING 012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS 014-12143-02 CABINET TRAY, MOLDED PLASTIC 014-12181-09 CABINET REAR, TV, MOLDED PLASTIC 014-12187-13 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04456-05 DEFLECTION YOKE, 25V HIBI COMERCIAL A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00858-01 LENS, PRIMARY CONTROLS AND IR 206-03373 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT 046-10554 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS 194-02535 PAD, BUTTONS A-18232 KEYBOARD ASSEMBLY, WITH IR RECEIVER

A25A23W74

Part# Description

PURITY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT, 046-10554 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS 194-02535 PAD, BUTTONS

A-18232 KEYBOARD ASSEMBLY, WITH IR RECEIVER

A25A23W8

Part# Description

009-02041 MODULE, MAIN, 25V MTS, GA3 CHASSIS 012-10832 METAL STAMPING , BRACKET, CRT MOUNTING 012-10832-01 METAL STAMPING , BRACKET, CRT MOUNTING 012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS 014-12143-02 CABINET TRAY, MOLDED PLASTIC 014-12181-09 CABINET REAR, TV, MOLDED PLASTIC 014-12187-13 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER, 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04531 DEFLECTION YOKE A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00858-01 LENS, PRIMARY CONTROLS AND IR 206-03373 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

A25A23W84

Part# Description

009-02041 MODULE, MAIN, 25V MTS, GA3 CHASSIS 012-10832 METAL STAMPING , BRACKET, CRT MOUNTING 012-10832-01 METAL STAMPING , BRACKET, CRT MOUNTING 012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS 014-12143-02 CABINET TRAY, MOLDED PLASTIC 014-12181-09 CABINET REAR, TV, MOLDED PLASTIC 014-12187-13 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER, 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04531 DEFLECTION YOKE A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00858-01 LENS, PRIMARY CONTROLS AND IR 206-03373 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT 046-10554 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS 194-02535 PAD, BUTTONS A-18232 KEYBOARD ASSEMBLY, WITH IR RECEIVER

A25A23W9

Part# Description

009-01996 MODULE, MAIN, 25V MTS, GA3 CHASSIS 012-10571 METAL STAMPING , BRACKET, CRT MOUNTING

CM150 4-21 GA - MODEL PARTS

MODEL PARTS

012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS 014-12143-02 CABINET TRAY, MOLDED PLASTIC 014-12181-09 CABINET REAR, TV, MOLDED PLASTIC 014-12187-13 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04456-03 DEFLECTION YOKE A63AGD01X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00858-01 LENS, PRIMARY CONTROLS AND IR 206-03373 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

A27A22BT

Part# Description

009-01997 MODULE, MAIN, WITH MTS, 27V GA3 CHASSIS 012-10568 METAL STAMPING , BRACKET, CRT SUPPORT 012-10569 METAL STAMPING , BRACKET, CRT MOUNTING 012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS 014-12038-02 CABINET TRAY, TV, MOLDED PLASTIC 014-12185-10 CABINET REAR, TV, MOLDED PLASTIC 014-12186-29 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-30 COIL, DEGAUSSER 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-03797-05 DEFLECTION YOKE A68AGD01X VACUUM TUBE, CRT, COLOR, 27 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00858-01 LENS, PRIMARY CONTROLS AND IR 206-03436 INSTR BOOK, OPERATION GUIDE A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT 046-10554 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS 194-02535 PAD, BUTTONS A-18232 KEYBOARD ASSEMBLY, WITH IR RECEIVER

A27A22BT4

Part# Description

095-03797-05 DEFLECTION YOKE A68AGD01X VACUUM TUBE, CRT, COLOR, 27 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00858-01 LENS, PRIMARY CONTROLS AND IR 206-03436 INSTR BOOK, OPERATION GUIDE A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT 046-10554 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS 194-02535 PAD, BUTTONS A-18232 KEYBOARD ASSEMBLY, WITH IR RECEIVER

A27A22BT8

Part# Description

009-01997-01 MODULE, MAIN, WITH MTS, 27V GA3 CHASSIS 012-10568 METAL STAMPING , BRACKET, CRT SUPPORT 012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS 012-10900 METAL STAMPING , BRACKET, CRT MOUNTING 014-12038-02 CABINET TRAY, TV, MOLDED PLASTIC 014-12185-10 CABINET REAR, TV, MOLDED PLASTIC 014-12186-29 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-30 COIL, DEGAUSSER 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02361 CONNECTOR AND, CABLE ASSEMBLY, 35V CTV YOKE 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 192-00858-01 LENS, PRIMARY CONTROLS AND IR 206-03436 INSTR BOOK, OPERATION GUIDE A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT A-19058 CRT AND YOKE, ASSEMBLY 046-10554 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS 194-02535 PAD, BUTTONS A-18232 KEYBOARD ASSEMBLY, WITH IR RECEIVER

A27A22BT84

Part# Description

009-01997-01 MODULE, MAIN, WITH MTS, 27V GA3 CHASSIS 012-10568 METAL STAMPING , BRACKET, CRT SUPPORT 012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS 012-10900 METAL STAMPING , BRACKET, CRT MOUNTING 014-12038-02 CABINET TRAY, TV, MOLDED PLASTIC 014-12185-10 CABINET REAR, TV, MOLDED PLASTIC 014-12186-29 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-30 COIL, DEGAUSSER 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02361 CONNECTOR AND, CABLE ASSEMBLY, 35V CTV YOKE 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 192-00858-01 LENS, PRIMARY CONTROLS AND IR 206-03436 INSTR BOOK, OPERATION GUIDE A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT A-19058 CRT AND YOKE, ASSEMBLY 046-10554 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS 194-02535 PAD, BUTTONS A-18232 KEYBOARD ASSEMBLY, WITH IR RECEIVER

CM150 4-22 GA - MODEL PARTS

MODEL PARTS

A27A23W

Part# Description

009-01997 MODULE, MAIN, WITH MTS, 27V GA3 CHASSIS 012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS 014-12281-04 CABINET FRONT, TV, MOLDED PLASTIC 014-12282-04 CABINET REAR, TV, MOLDED PLASTIC 020-04330-30 COIL, DEGAUSSER 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-03797-05 DEFLECTION YOKE A68AGD02X VACUUM TUBE, CRT, COLOR, 27 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03373 INSTR BOOK, OPERATION GUIDE A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT 046-10588 KNOB ARRAY, PUSH BUTTON, 6 POSITION 194-02663 PAD, BUTTONS A-18769 KEYBOARD ASSEMBLY, 6 BUTTON

A27A23W4

Part# Description

009-01997 MODULE, MAIN, WITH MTS, 27V GA3 CHASSIS 012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS 014-12281-06 CABINET FRONT, TV, MOLDED PLASTIC 014-12282-06 CABINET REAR, TV, MOLDED PLASTIC 020-04330-30 COIL, DEGAUSSER 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-03797-05 DEFLECTION YOKE A68AGD02X VACUUM TUBE, CRT, COLOR, 27 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03373 INSTR BOOK, OPERATION GUIDE A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR 046-10588 KNOB ARRAY, PUSH BUTTON, 6 POSITION 194-02663 PAD, BUTTONS A-18769 KEYBOARD ASSEMBLY, 6 BUTTON

A27A23W8

Part# Description

009-01997-01 MODULE, MAIN, WITH MTS, 27V GA3 CHASSIS 012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS 014-12281-04 CABINET FRONT, TV, MOLDED PLASTIC 014-12282-04 CABINET REAR, TV, MOLDED PLASTIC 020-04330-30 COIL, DEGAUSSER 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02361 CONNECTOR AND, CABLE ASSEMBLY, 35V CTV YOKE 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03373 INSTR BOOK, OPERATION GUIDE A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT A-19058-01 CRT AND YOKE, ASSEMBLY

046-10588 KNOB ARRAY, PUSH BUTTON, 6 POSITION 194-02663 PAD, BUTTONS A-18769 KEYBOARD ASSEMBLY, 6 BUTTON

A27A23W84

Part# Description

009-01997-01 MODULE, MAIN, WITH MTS, 27V GA3 CHASSIS 012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS 014-12281-06 CABINET FRONT, TV, MOLDED PLASTIC 014-12282-06 CABINET REAR, TV, MOLDED PLASTIC 020-04330-30 COIL, DEGAUSSER 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02361 CONNECTOR AND, CABLE ASSEMBLY, 35V CTV YOKE 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03373 INSTR BOOK, OPERATION GUIDE A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT A-19058-01 CRT AND YOKE, ASSEMBLY 046-10588 KNOB ARRAY, PUSH BUTTON, 6 POSITION 194-02663 PAD, BUTTONS A-18769 KEYBOARD ASSEMBLY, 6 BUTTON

A27A74R

Part# Description

009-01998 MODULE, MAIN, 27V MTS, GA3 CHASSIS 002-04084-13 CABINET BACK, PRESSED WOOD 012-10810-01 MOLDED PLASTIC , PANEL, JACK PACK, GA CHASSIS 014-12326 CABINET MAIN, TV, WOOD 019-00961 CABLE TIE, DOUBLE LOOP 020-04330-30 COIL, DEGAUSSER 030-01455-09 DECORATIVE ITEM, CABINET HARDWARE 049-01334-02 SPEAKER, OVAL, 3X6.500 050-01699-06 CONNECTOR&CABLE, ASSY, 2.5MM, 5 CONTACT, 2 UP 050-02576-01 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 057-09055-39 ESCUTCHEON, CRT 080-02456-04 SPRING, COMPRESSION 095-03797-05 DEFLECTION YOKE A68AGD01X VACUUM TUBE, CRT, COLOR, 27 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00872 CRYSTAL WINDOW , IR, STEREO, AND COLOR SENTRY 197-00180-01 CUP, CABINET BACK 206-03372 INSTR BOOK, OPERATION GUIDE A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT A-19122 ESCUTCHEON ASSY 046-10555 KNOB ARRAY, PUSH BUTTON, 10 POSITION, STR 194-02535 PAD, BUTTONS A-18225 KEYBOARD ASSEMBLY, WITH IR, AGUA CHASSIS

A27A74R8

Part# Description

CM150 4-23 GA - MODEL PARTS

MODEL PARTS

030-01455-09 DECORATIVE ITEM, CABINET HARDWARE 049-01334-02 SPEAKER, OVAL, 3X6.500 050-01699-06 CONNECTOR&CABLE, ASSY, 2.5MM, 5 CONTACT, 2 UP 050-02576-01 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 057-09055-39 ESCUTCHEON, CRT 080-02456-04 SPRING, COMPRESSION 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 192-00872 CRYSTAL WINDOW , IR, STEREO, AND COLOR SENTRY 197-00180-01 CUP, CABINET BACK 206-03372 INSTR BOOK, OPERATION GUIDE A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT A-19058 CRT AND YOKE, ASSEMBLY A-19122 ESCUTCHEON ASSY 046-10555 KNOB ARRAY, PUSH BUTTON, 10 POSITION, STR 194-02535 PAD, BUTTONS A-18225 KEYBOARD ASSEMBLY, WITH IR, AGUA CHASSIS

A27A76R

Part# Description

009-01998 MODULE, MAIN, 27V MTS, GA3 CHASSIS 002-04103-02 CABINET BACK 012-10751 METAL STAMPING , STRIKER PLATE 014-11639-20 CABINET REAR, TV, MOLDED PLASTIC 014-12327 CABINET MAIN, TV, WOOD 020-04330-30 COIL, DEGAUSSER 040-00567 HINGE 049-01302-03 SPEAKER, OVAL, 3X5 INCH 049-01334-02 SPEAKER, OVAL, 3X6.500 050-01699-06 CONNECTOR&CABLE, ASSY, 2.5MM, 5 CONTACT, 2 UP 050-02576-01 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 057-09055-39 ESCUTCHEON, CRT 095-03797-05 DEFLECTION YOKE A68AGD01X VACUUM TUBE, CRT, COLOR, 27 INCH DIAGONAL 110-00687-59 GRILLE CLOTH, RECTANGULAR 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00872 CRYSTAL WINDOW , IR, STEREO, AND COLOR SENTRY 192-00892 GLASS DOOR 206-03372 INSTR BOOK, OPERATION GUIDE A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT A-19128 ESCUTCHEON ASSY 046-10555 KNOB ARRAY, PUSH BUTTON, 10 POSITION, STR 194-02535 PAD, BUTTONS A-18225 KEYBOARD ASSEMBLY, WITH IR, AGUA CHASSIS

A27A76R8

Part# Description

110-00687-59 GRILLE CLOTH, RECTANGULAR 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 192-00872 CRYSTAL WINDOW , IR, STEREO, AND COLOR SENTRY 192-00892 GLASS DOOR 206-03372 INSTR BOOK, OPERATION GUIDE A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT A-19058 CRT AND YOKE, ASSEMBLY A-19128 ESCUTCHEON ASSY 046-10555 KNOB ARRAY, PUSH BUTTON, 10 POSITION, STR 194-02535 PAD, BUTTONS A-18225 KEYBOARD ASSEMBLY, WITH IR, AGUA CHASSIS

LGA26A23WM

Part# Description

009-01996 MODULE, MAIN, 25V MTS, GA3 CHASSIS 012-10571 METAL STAMPING , BRACKET, CRT MOUNTING 012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS 014-12143-02 CABINET TRAY, MOLDED PLASTIC 014-12181-09 CABINET REAR, TV, MOLDED PLASTIC 014-12187-13 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04456-03 DEFLECTION YOKE A63AGD01X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00858-01 LENS, PRIMARY CONTROLS AND IR 206-03414 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-10 GND STRAP ASSY , CRT 046-10554 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS 194-02535 PAD, BUTTONS A-18232 KEYBOARD ASSEMBLY, WITH IR RECEIVER

LGA26A23WM6

Part# Description

009-01996 MODULE, MAIN, 25V MTS, GA3 CHASSIS 012-10571 METAL STAMPING , BRACKET, CRT MOUNTING 012-10858-01 MOLDED PLASTIC , PANEL, JACK PACK, GA3 CHASSIS 014-12143-02 CABINET TRAY, MOLDED PLASTIC 014-12181-09 CABINET REAR, TV, MOLDED PLASTIC 014-12187-13 CABINET FRONT, TV, MOLDED PLASTIC 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04571 DEFLECTION YOKE A63AHC26X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 192-00858-01 LENS, PRIMARY CONTROLS AND IR 206-03414 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-14323 BALUN ASSEMBLY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-10 GND STRAP ASSY , CRT 046-10554 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS 194-02535 PAD, BUTTONS

CM150 4-24 GA - MODEL PARTS

MODEL PARTS

A-18232 KEYBOARD ASSEMBLY, WITH IR RECEIVER

LGA26A23WM7

Part# Description

009-02041 MODULE, MAIN, 25V MTS, GA3 CHASSIS 012-10832 METAL STAMPING , BRACKET, CRT MOUNTING 012-10832-01 METAL STAMPING , BRACKET, CRT MOUNTING 012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS 014-12143-02 CABINET TRAY, MOLDED PLASTIC 014-12181-09 CABINET REAR, TV, MOLDED PLASTIC 014-12187-13 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04456-05 DEFLECTION YOKE, 25V HIBI COMERCIAL A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00858-01 LENS, PRIMARY CONTROLS AND IR 206-03414 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT 046-10554 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS 194-02535 PAD, BUTTONS A-18232 KEYBOARD ASSEMBLY, WITH IR RECEIVER

LGA26A23WM74

Part# Description

009-02041 MODULE, MAIN, 25V MTS, GA3 CHASSIS 012-10832 METAL STAMPING , BRACKET, CRT MOUNTING 012-10832-01 METAL STAMPING , BRACKET, CRT MOUNTING 012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS 014-12143-02 CABINET TRAY, MOLDED PLASTIC 014-12181-09 CABINET REAR, TV, MOLDED PLASTIC 014-12187-13 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04456-05 DEFLECTION YOKE, 25V HIBI COMERCIAL A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00858-01 LENS, PRIMARY CONTROLS AND IR 206-03414 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT 046-10554 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS 194-02535 PAD, BUTTONS A-18232 KEYBOARD ASSEMBLY, WITH IR RECEIVER

LGA26A23WM8

Part# Description

009-02041 MODULE, MAIN, 25V MTS, GA3 CHASSIS 012-10832 METAL STAMPING , BRACKET, CRT MOUNTING 012-10832-01 METAL STAMPING , BRACKET, CRT MOUNTING 012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS 014-12143-02 CABINET TRAY, MOLDED PLASTIC 014-12181-09 CABINET REAR, TV, MOLDED PLASTIC 014-12187-13 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04531 DEFLECTION YOKE A63AFW36X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00858-01 LENS, PRIMARY CONTROLS AND IR 206-03414 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

LGA26A23WM9

Part# Description

009-01996 MODULE, MAIN, 25V MTS, GA3 CHASSIS 012-10571 METAL STAMPING , BRACKET, CRT MOUNTING 012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS 014-12143-02 CABINET TRAY, MOLDED PLASTIC 014-12181-09 CABINET REAR, TV, MOLDED PLASTIC 014-12187-13 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-35 COIL, DEGAUSSER 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-04456-03 DEFLECTION YOKE A63AGD01X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00858-01 LENS, PRIMARY CONTROLS AND IR 206-03414 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

LGA29A23WM

Part# Description

CM150 4-25 GA - MODEL PARTS

MODEL PARTS

049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-03797-05 DEFLECTION YOKE A68AGD02X VACUUM TUBE, CRT, COLOR, 27 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03414 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-14323 BALUN ASSEMBLY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT 046-10588 KNOB ARRAY, PUSH BUTTON, 6 POSITION 194-02663 PAD, BUTTONS A-18769 KEYBOARD ASSEMBLY, 6 BUTTON

LGA29A23WM4

Part# Description

009-01997 MODULE, MAIN, WITH MTS, 27V GA3 CHASSIS 012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS 014-12281-06 CABINET FRONT, TV, MOLDED PLASTIC 014-12282-06 CABINET REAR, TV, MOLDED PLASTIC 020-04330-30 COIL, DEGAUSSER 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 095-03797-05 DEFLECTION YOKE A68AGD02X VACUUM TUBE, CRT, COLOR, 27 INCH DIAGONAL 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 152-00335 WEDGE, YOKE SPACER,POSITIONER 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03414 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-14323 BALUN ASSEMBLY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT 046-10588 KNOB ARRAY, PUSH BUTTON, 6 POSITION 194-02663 PAD, BUTTONS A-18769 KEYBOARD ASSEMBLY, 6 BUTTON

LGA29A23WM84

Part# Description

009-01997-01 MODULE, MAIN, WITH MTS, 27V GA3 CHASSIS 012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS 014-12281-06 CABINET FRONT, TV, MOLDED PLASTIC 014-12282-06 CABINET REAR, TV, MOLDED PLASTIC 020-04330-30 COIL, DEGAUSSER 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02361 CONNECTOR AND, CABLE ASSEMBLY, 35V CTV YOKE 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03414 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-14323 BALUN ASSEMBLY A-18681-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT A-19058-01 CRT AND YOKE, ASSEMBLY 046-10588 KNOB ARRAY, PUSH BUTTON, 6 POSITION 194-02663 PAD, BUTTONS A-18769 KEYBOARD ASSEMBLY, 6 BUTTON

LGA29A23WM8

Part# Description

009-01997-01 MODULE, MAIN, WITH MTS, 27V GA3 CHASSIS 012-10858-04 MOLDED PLASTIC , PANEL, JACK PACK, CA CHASSIS 014-12281-04 CABINET FRONT, TV, MOLDED PLASTIC 014-12282-04 CABINET REAR, TV, MOLDED PLASTIC 020-04330-30 COIL, DEGAUSSER 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-01699-03 CONNECTOR&CABLE, ASSY, 2.5 MM, 5 CONTACT, 2 UP 050-02361 CONNECTOR AND, CABLE ASSEMBLY, 35V CTV YOKE 050-02576 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT, 1 UP 124-00212-35 SPACE COMMAND, TRANSMITTER, MBR3447 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03414 INSTR BOOK, OPERATION GUIDE, ZENITH, SPANISH A-14323 BALUN ASSEMBLY A-18588-01 LINE CORD ASSY , WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY , CRT A-19058-01 CRT AND YOKE, ASSEMBLY 046-10588 KNOB ARRAY, PUSH BUTTON, 6 POSITION 194-02663 PAD, BUTTONS A-18769 KEYBOARD ASSEMBLY, 6 BUTTON

CM150 4-26 GA - MODEL PARTS

GA1 MODULE PARTS

A 9-1869 B 9-1869-01 C 9-1870 D 9-1870-01 E 9-1871 F 9-1871-01 G 9-1950 H 9-1950-01 I 9-1990 J 9-1990-01 K 9-1991 L 9-1991-01 M 9-1992 N 9-1992-01 O 9-1993 P 9-1993-01

NOTE: This list will enable you to determine the parts used on each Model, Chassis, or Assembly.

RC REF PART# DESCRIPTION

ABCDEFGHIJKLMNOP 3T8 058-00643-02 PLUG, MULTIPRONG, 2 POSITION ABCDEFGHIJKLMNOP 3Y3 058-00643-04 PLUG, MULTIPRONG, 4 POSITION OP 4G9 058-00526-05 PLUG, 0.098P 5 CONTACT/ OP 9S4 058-00526-04 PLUG, 0.098P 4 CONTACT/ ABCDEFGHIJKLMNOP ANT0001 A-18578 ISOLATOR ASSY, SHIELDED BOX/ ABIJ C0801 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO ABIJ C0802 022-08309-15A CAP, 470 MFD 20% 16V, ELECTRO ABIJ C0803 022-08049-24A CAP, 0.10 MFD 10% 50V, POLYESTER ABIJ C0806M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC

ABIJ C0820 022-08310-16 CAP, 1000 MFD 20% 25V, ELECTRO CDEFGHKLMNOP C0820 022-08310-17 CAP, 2200 MFD 20% 25V, ELECTRO ABCDEFGHIJKLMNOP C0821M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP CDEFGHKLMNOP C0830 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO CDEFGHKLMNOP C0831 022-08310-11A CAP, 47 MFD 20% 25V, ELECTRO CDEFGHKLMNOP C0832 022-08049-24A CAP, 0.10 MFD 10% 50V, POLYESTER CDEFGHKLMNOP C0833 022-08309-14A CAP, 330 MFD 20% 16V, ELECTRO CDEFKLMN C0850 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO CDEFKLMN C0851 022-08310-11A CAP, 47 MFD 20% 25V, ELECTRO CDEFKLMN C0852 022-08049-24A CAP, 0.10 MFD 10% 50V, POLYESTER CDEFKLMN C0853 022-08309-14A CAP, 330 MFD 20% 16V, ELECTRO ABIJ C1202M 022-08366-16A CAP, 4,700 PFD 10% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C1206M 022-08352-24A CAP, 33 PFD 5% 50V, CERAMIC CHIP ABCDEFIJKLMN C1208 022-08492-01A CAP, 1 MFD 20% 50V, NONPLZD ELECTRO ABCDEFIJKLMN C1211 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO GHOP C1211 022-08492-01A CAP, 1 MFD 20% 50V, NONPLZD ELECTRO ABCDEFGHIJKLMNOP C1212M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C1213M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C1215M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKLMNOP C1216M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKLMNOP C1217 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO ABCDEFGHIJKLMNOP C1218M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKLMNOP C1219M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKLMNOP C1220 022-08309-13A CAP, 220 MFD 20% 16V, ELECTRO ABCDEFGHIJKLMNOP C1221M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C1222 022-08049-24A CAP, 0.10 MFD 10% 50V, POLYESTER ABCDEFGHIJKLMNOP C1223M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKLMNOP C1224M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C1225M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKLMNOP C1226M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKLMNOP C1227M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C1228M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C1229 022-08312-03A CAP, 0.47 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP C1231M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C1232 022-08312-03A CAP, 0.47 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP C1233 022-08308-15A CAP, 470 MFD 20% 10V, ELECTRO ABCDEFGHIJKLMNOP C1234M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C1235 022-08312-03A CAP, 0.47 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP C1236M 022-08371-24A CAP, 22,000 PFD 20% 16V, CERAMIC CHIP CDKL C1401M 022-08366-16A CAP, 4,700 PFD 10% 50V, CERAMIC CHIP CDKL C1403 022-08227-15A CAP, 0.22 MFD 5% 50V, POLYESTER CDKL C1404 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO CDKL C1409 022-08310-11A CAP, 47 MFD 20% 25V, ELECTRO CDKL C1410 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO CDKL C1411 022-08049-24A CAP, 0.10 MFD 10% 50V, POLYESTER CDKL C1412M 022-08371-24A CAP, 22,000 PFD 20% 16V, CERAMIC CHIP CDKL C1415 022-08312-05A CAP, 2.2 MFD 20% 50V, ELECTRO CDKL C1416 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO CDKL C1417 022-08049-24A CAP, 0.10 MFD 10% 50V, POLYESTER CDKL C1418M 022-08366-13A CAP, 2,700 PFD 10% 50V, CERAMIC CHIP CDKL C1420M 022-08371-24A CAP, 22,000 PFD 20% 16V, CERAMIC CHIP CDKL C1423 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO CDEFKLMN C1432 022-08049-08A CAP, 0.0047 MFD 10% 50V, POLYESTER CDEFGHKLMNOP C1433 022-08049-08A CAP, 0.0047 MFD 10% 50V, POLYESTER

CHIP

GA1 MODULE PARTS LIST

RC REF PART# DESCRIPTION

CDEFKLMN C1450 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO CDEFGHKLMNOP C1451 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO CDEFKLMN C1490 022-08312-09A CAP, 22 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP C2102 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP C2103M 022-08352-48A CAP, 330 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C2104 022-08049-24A CAP, 0.10 MFD 10% 50V, POLYESTER ABCDEFGHIJKLMNOP C2105 022-08312-06A CAP, 3.3 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP C2107M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C2202M 022-08352-14A CAP, 12 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C2203 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP C2204 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP C2205 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP C2206 022-08227-23A CAP, 1 MFD 5% 50V, POLYESTER ABCDEFGHIJKLMNOP C2207M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKLMNOP C2208 022-08308-15A CAP, 470 MFD 20% 10V, ELECTRO ABCDEFGHIJKLMNOP C2209M 022-08371-24A CAP, 22,000 PFD 20% 16V, CERAMIC CHIP ABCDEFGHIJKLMNOP C2211 022-08312-05A CAP, 2.2 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP C2212 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP C2215 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP C2216 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO ABCDGHIJKLOP C2217 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO EFMN C2217 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO ABCDGHIJKLOP C2218 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO EFMN C2218 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP C2219 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP C2220M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKLMNOP C2225M 022-08352-42A CAP, 180 PFD 5% 50V, CERAMIC CHIP EFGHMNOP C2226 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP C2227 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDIJKL C2230M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKLMNOP C2234M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C2237M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C2240M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C2241M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C2250M 022-08352-31A CAP, 62 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C3202 022-07786-11C CAP, 560 PFD 10% 500V, CERAMIC DISC ABCDEFGHIJKLMNOP C3203 022-08315-05A CAP, 2.2 MFD 20% 160V, ELECTRO ABCDEFGHIJKLMNOP C3205 022-08229-21 CAP, 0.0075 MFD 3% 1600VDC, POLYPROP IJKLMNOP C3206 022-08386-01 CAP, 270 PFD 10% 2000V, CERAMIC DISC ABCDEFGHIJKLMNOP C3207 022-08317-08 CAP, 10 MFD 20% 250V, ELECTRO ABCDEFGHIJKLMNOP C3208 022-07786-11C CAP, 560 PFD 10% 500V, CERAMIC DISC ABCDEFGHIJKLMNOP C3209 022-07786-11C CAP, 560 PFD 10% 500V, CERAMIC DISC ABCDEFGHIJKLMNOP C3210 022-07811A CAP, 1000 PFD 10% 1000V, CERAMIC DISC ABCDEFGHIJKLMNOP C3211 022-07811A CAP, 1000 PFD 10% 1000V, CERAMIC DISC ABCDEFGHIJKLMNOP C3214 022-07774-16 CAP, 0.022MFD 10% 100V, POLYESTER ABCDEFGHIJKLMNOP C3216 022-08315-05A CAP, 2.2 MFD 20% 160V, ELECTRO ABCDEFGHIJKLMNOP C3217 022-07876-19 CAP, 0.39 MFD 5% 250V, POLYESTER ABCDEFGHIJKLMNOP C3218 022-08312-03A CAP, 0.47 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP C3219 022-08049-24A CAP, 0.10 MFD 10% 50V, POLYESTER ABCDEFGHIJKLMNOP C3220 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP C3221 022-07811A CAP, 1000 PFD 10% 1000V, CERAMIC DISC ABCDEFGHIJKLMNOP C3222 022-08312-05A CAP, 2.2 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP C5100 022-08318-04A CAP, 1 MFD 20% 350V, ELECTRO ABCDEFGHIJKLMNOP C5101M 022-08352-48A CAP, 330 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C5102M 022-08352-48A CAP, 330 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C5103M 022-08352-48A CAP, 330 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C5104 022-07523-01B CAP, 0.01 MFD +80 % & -20 % 2000V,

ABCDEFGHIJKLMNOP C5105 022-07773-08 CAP, 0.0047 MFD 5% 100V, POLYESTER ABCDEFGHIJKLMNOP C6001M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6002M 022-08364-52A CAP, 470 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6003M 022-08364-52A CAP, 470 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6004 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP C6005M 022-08366A CAP, 220 PFD 10% 50V, CERAMIC CHIP

CERAMIC DISC

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

CM150 4-1 GA - MODULE PARTS

GA1 MODULE PARTS LIST

A 9-1869 B 9-1869-01 C 9-1870 D 9-1870-01 E 9-1871 F 9-1871-01 G 9-1950 H 9-1950-01 I 9-1990 J 9-1990-01 K 9-1991 L 9-1991-01 M 9-1992 N 9-1992-01 O 9-1993 P 9-1993-01

NOTE: This list will enable you to determine the parts used on each Model, Chassis, or Assembly.

RC REF PART# DESCRIPTION

ABCDEFGHIJKLMNOP C6006 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP C6007M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6008M 022-08366A CAP, 220 PFD 10% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6009 022-08049-24A CAP, 0.10 MFD 10% 50V, POLYESTER ABCDEFGHIJKLMNOP C6010M 022-08352-19A CAP, 20 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6011M 022-08352-19A CAP, 20 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6012M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6014M 022-08352-22A CAP, 27 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6015M 022-08352-22A CAP, 27 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6016 022-08312-05A CAP, 2.2 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP C6017 022-08049-24A CAP, 0.10 MFD 10% 50V, POLYESTER ABCDEFGHIJKLMNOP C6018M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6019M 022-08352-42A CAP, 180 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6020 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP C6021M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP CDEFGHKLMNOP C6022 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP C6023M 022-08352-36A CAP, 100 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6024M 022-08352-36A CAP, 100 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6025M 022-08352-36A CAP, 100 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6026M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6028 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP C6029M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6030 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO ABCDEFGHIJKLMNOP C6031M 022-08366-16A CAP, 4,700 PFD 10% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6032 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP C6033M 022-08352-36A CAP, 100 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6035M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6036 022-08257-04A CAP, 220 PFD 10% 50V, CERAMIC DISC ABCDEFGHIJKLMNOP C6040M 022-08364-52A CAP, 470 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6041M 022-08364-52A CAP, 470 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6042M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6043M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6044M 022-08364-52A CAP, 470 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6045M 022-08364-52A CAP, 470 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6046M 022-08364-52A CAP, 470 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6047M 022-08352-36A CAP, 100 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6048M 022-08352-36A CAP, 100 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6049M 022-08352-36A CAP, 100 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6050M 022-08352-36A CAP, 100 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6051M 022-08364-52A CAP, 470 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6052M 022-08366A CAP, 220 PFD 10% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6053M 022-08366A CAP, 220 PFD 10% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6054M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6055M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP C6056M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP EFGHMNOP C9701 022-08309-15A CAP, 470 MFD 20% 16V, ELECTRO EFMN C9703 022-08312-03A CAP, 0.47 MFD 20% 50V, ELECTRO EFGHMNOP C9704 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO EFMN C9705 022-08492-01A CAP, 1 MFD 20% 50V, NONPLZD ELECTRO EFGHMNOP C9707 022-08312-03A CAP, 0.47 MFD 20% 50V, ELECTRO EFGHMNOP C9708 022-08309-15A CAP, 470 MFD 20% 16V, ELECTRO EFGHMNOP C9709 022-08492-01A CAP, 1 MFD 20% 50V, NONPLZD ELECTRO EFGHMNOP C9711 022-08309-15A CAP, 470 MFD 20% 16V, ELECTRO EFGHMNOP C9712 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO EFGHMNOP C9713 022-08241-34A CAP, 100 PFD 5% 50V, CERAMIC DISC EFGHMNOP C9714 022-08309-15A CAP, 470 MFD 20% 16V, ELECTRO EFGHMNOP C9716 022-08241-04A CAP, 4 PFD +&- 0.25 PFD 50V, CERAMIC DISC EFGHMNOP C9720 022-08049-24A CAP, 0.10 MFD 10% 50V, POLYESTER CDKL CR1401 224-00179 RESONATOR, CERAMIC, 378 KHZ ABCDEFGHIJKLMNOP CR2200 224-00027A CRYSTAL, QUARTZ, 3.579 MHZ ABCDEFGHIJKLMNOP CR2205 224-00178 RESONATOR, CERAMIC, 503 KHZ IJKLMN CRT0001 078-03394-09 SOCKET, CRT ABCDEFGHIJKLMNOP CRY6001 224-00074-02A CRYSTAL, QUARTZ, 8 MHZ ABCDEFGHIJKLMNOP CX2101 022-08311-13 CAP, 220 MFD 20% 35V, ELECTRO

RC REF PART# DESCRIPTION

ABCDEFGHIJKLMNOP CX2106 022-08310-17 CAP, 2200 MFD 20% 25V, ELECTRO ABCDEFGHIJKLMNOP CX2108 022-08311-13 CAP, 220 MFD 20% 35V, ELECTRO ABCDEFGHIJKLMNOP CX3001 022-08310-10A CAP, 33 MFD 20% 25V, ELECTRO ABCDEFGHIJKLMNOP CX3002 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP CX3213 022-08309-15A CAP, 470 MFD 20% 16V, ELECTRO ABCDEFGHIJKLMNOP CX3215 022-08315-11 CAP, 47 MFD 20% 160V, ELECTRO ABCDEFGHIJKLMNOP CX3403 022-07786-17C CAP, 2200 PFD 10% 500V, CERAMIC DISC ABCDEFGHIJKLMNOP CX3404 022-07811A CAP, 1000 PFD 10% 1000V, CERAMIC DISC ABCDEFGHIJKLMNOP CX3405 022-07811A CAP, 1000 PFD 10% 1000V, CERAMIC DISC ABCDEFGHIJKLMNOP CX3406 022-08444-11 CAP, 470 MFD 20% 200V, ELECTRO ABCDEFGHIJKLMNOP CX3407 022-08315-07A CAP, 4.7 MFD 20% 160V, ELECTRO ABCDEFGHIJKLMNOP CX3408 022-08315-11 CAP, 47 MFD 20% 160V, ELECTRO ABCDEFGHIJKLMNOP CX3410 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOP CX3411 022-08153-24 CAP, 1000 MFD 20% 16V, ELECTRO ABCDEFGHIJKLMNOP CX3413 022-08309-13A CAP, 220 MFD 20% 16V, ELECTRO ABCDEFGHIJKLMNOP CX6027 022-08309-16 CAP, 1000 MFD 20% 16V, ELECTRO ABCDEFGHIJKLMNOP CX9702 022-07431-06B CAP, 0.0047 MFD 20%, CERAMIC DISC ABCDEFGHIJKLMNOP D2102 103-00254-01 DIODE, LOW VOLTAGE GENERAL, SILICON ABCDEFGHIJKLMNOP D2202 103-00461A DIODE, FAST SWITCHING, HIGH

ABCDEFGHIJKLMNOP D2203 103-00461A DIODE, FAST SWITCHING, HIGH

ABCDEFGHIJKLMNOP D2204 091-02053 WIRE, SOLID, BARE, 22 GA COPPER ABCDEFGHIJKLMNOP D2206 103-00461A DIODE, FAST SWITCHING, HIGH

ABCDEFGHIJKLMNOP D3201 103-00326A DIODE, LOW VOLTAGE GENERAL, SILICON ABCDEFGHIJKLMNOP D3202 103-00284A DIODE, LOW VOLTAGE GENERAL, SILICON ABCDEFGHIJKLMNOP D3203 103-00344-04A DIODE, LOW VOLTAGE GENERAL ABCDEFGHIJKLMNOP D3203 149-00583-01 CORE, FERRITE BEAD ABCDEFGHIJKLMNOP D3204 103-00344-04A DIODE, LOW VOLTAGE GENERAL ABCDEFGHIJKLMNOP D3204 149-00583-01 CORE, FERRITE BEAD ABCDEFGHIJKLMNOP D3205 103-00461A DIODE, FAST SWITCHING, HIGH

ABCDEFGHIJKLMNOP D3208 103-00461A DIODE, FAST SWITCHING, HIGH

ABCDEFGHIJKLMNOP D3209 103-00284A DIODE, LOW VOLTAGE GENERAL, SILICON ABCDEFGHIJKLMNOP D6001 103-00461A DIODE, FAST SWITCHING, HIGH

EFGHMNOP D9701 103-00344-01A DIODE, LOW VOLTAGE GENERAL/ ABCDEFGHIJKLMNOP DX3001 103-00461A DIODE, FAST SWITCHING, HIGH

ABCDEFGHIJKLMNOP DX3002 103-00461A DIODE, FAST SWITCHING, HIGH

ABCDEFGHIJKLMNOP DX3003 103-00336-18A DIODE, ZENER, 9.1V 0.5W ABCDEFGHIJKLMNOP DX3401 103-00467A DIODE, LOW VOLTAGE GENERAL, SILICON ABCDEFGHIJKLMNOP DX3402 103-00467A DIODE, LOW VOLTAGE GENERAL, SILICON ABCDEFGHIJKLMNOP DX3403 103-00467A DIODE, LOW VOLTAGE GENERAL, SILICON ABCDEFGHIJKLMNOP DX3404 103-00467A DIODE, LOW VOLTAGE GENERAL, SILICON ABCDEFGHIJKLMNOP DX3405 103-00347-03A DIODE, LOW VOLTAGE GENERAL, SILICON ABCDEFGHIJKLMNOP DX3406 103-00347-03A DIODE, LOW VOLTAGE GENERAL, SILICON ABCDEFGHIJKLMNOP DX3409 103-00347-03A DIODE, LOW VOLTAGE GENERAL, SILICON ABCDEFGHIJKLMNOP DX3410 103-00326A DIODE, LOW VOLTAGE GENERAL, SILICON ABCDEFGHIJKLMNOP DX3411 103-00347-03A DIODE, LOW VOLTAGE GENERAL, SILICON ABCDEFGHIJKLMNOP EX3401 038-00102 SPARK GAP, HIGH VOLTAGE, 4KV DC ABCDEFGHIJKLMNOP EX3401 079-00317-04 SLEEVING, HEAT SHRINKABLE, 0.020 INCH

ABCDEFGHIJKLMNOP FB6001 149-00549 CORE, FERRITE, WITH CAPTIVATED THRU-

ABCDEFGHIJKLMNOP FB6002 149-00583-01 CORE, FERRITE BEAD ABCDEFGHIJKLMNOP FX3401 136-00114-23A FUSE, NORMAL LAG, 4 AMP 250V ABCDEFGHIJKLMNOP FX3402 136-00148-02 FUSE, NORMAL LAG, 1A 250V ABCDEFGHIJKLMNOP GND0001 301-99001P150D WIRE, STRANDED, SINGLE CONDUCTOR, 18

ABIJ IC0801 221-00981 IC , 1 WATT AUDIO AMPLIFIER CDEFGHKLMNOP IC0830 221-01163 INTEGRATED CKT, AUDIO PWR AMP, W/ VOL

CONDUCTANCE

WALL, 0.187 I

LEAD

GA, WHITE

CTRL

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

CM150 4-2 GA - MODULE PARTS

GA1 MODULE PARTS LIST

A 9-1869 B 9-1869-01 C 9-1870 D 9-1870-01 E 9-1871 F 9-1871-01 G 9-1950 H 9-1950-01 I 9-1990 J 9-1990-01 K 9-1991 L 9-1991-01 M 9-1992 N 9-1992-01 O 9-1993 P 9-1993-01

NOTE: This list will enable you to determine the parts used on each Model, Chassis, or Assembly.

RC REF PART# DESCRIPTION

CDEFKLMN IC0850 221-01163 INTEGRATED CKT, AUDIO PWR AMP, W/ VOL

CDKL IC1400 221-00907 IC , STEREO DECODER ABCDEFGHIJKLMNOP IC2101 083-09299-02 STRIP, EDGE PROTECTOR, NYLON ABCDEFGHIJKLMNOP IC2101 221-00903 INTEGRATED CKT, VERTICAL DEFLECTION ABCDEFGHIJKLMNOP IC3201 221-00166-09 INTEGRATED CKT, 9 VOLT, 500MA, LINEAR

ABCDEFGHIJKLMNOP IC6000 126-03446-02 SHIELD, EMI, MICROPROCESSOR ACEFGIKMO IC6000 221-01164-01 IC , 8-BIT MICROCOMPUTER, WITH CAPTION BDHJLNP IC6000 221-01164-02 IC , 8-BIT MICROCOMPUTER, WITH LIGHT DE ABCDEFGHIJKLMNOP IC6001 221-00745-04 IC , 4K BIT SERIAL EEPROM ABCDEFGHIJKLMNOP IC6002 221-01177A IC , SYSTEM RESET EFMN IC9700 162-00018 PHOTO-OPTIC, COUPLER , INTERRUPTER EFGHMNOP IC9701 162-00018 PHOTO-OPTIC, COUPLER , INTERRUPTER EFGHMNOP IC9702 162-00040-01 PHOTOCOUPLER ABCDEFGHIJKLMNOP ICX2200 221-01165 IC , I2C BUS CONTROL NTSC ABCDEFGHIJKLMNOP ICX3401 019-00838-05 CLIP, STAND-OFF ABCDEFGHIJKLMNOP ICX3401 223-00040-01 INT CKT, THICK FILM, HYBRID, VOLTAGE

ABCDEFGHIJKLMNOP ICX3402 221-00167-01A IC , VOLTAGE REGULATOR, 5V 100MA ABCDEFGHIJKLMNOP IR6000 162-00046 IR DETECTOR EFMN J0001 A-18577 JACK ASSEMBLY, 3 JACK GHOP J0001 A-18577-01 JACK ASSEMBLY, 2 JACK ABCDEFGHIJKLMNOP J0001M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W ABCDEFGHIJKLMNOP J0002M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W ABCDEFGHIJKLMNOP KX3401 195-00161 RELAY, SPST, 12 VDC COIL ABCDEFGHIJKLMNOP L1200 020-04506 COIL, RCF, FIXED, SHIELDED ABCDEFGHIJKLMNOP L1201 020-04277-39A COIL, 10 MICROHENRY, RCF, FIXED ABCDEFGHIJKLMNOP L1202 020-03907-12A COIL, 10 MICROHENRY, RCF, FIXED ABCDEFGHIJKLMNOP L1203 020-04277-23A COIL, 12 MICROHENRY, RCF, FIXED ABCDEFGHIJKLMNOP L1204 091-02053 WIRE, SOLID, BARE, 22 GA COPPER ABCDEFGHIJKLMNOP L1205 020-04278B COIL, RCF, TUNABLE, 7.0 MM ABCDEFGHIJKLMNOP L1206 020-04277-09A COIL, 0.82 MICROHENRY, RCF, FIXED ABCDEFGHIJKLMNOP L1208 020-03907-25A COIL, 120 MICROHENRY, RCF, FIXED ABCDEFGHIJKLMNOP L2202 020-04277-20A COIL, 6.8 MICROHENRY, RCF, FIXED ABCDEFGHIJKLMNOP L3201 020-04458 COIL, LINEARITY/ ABCDEFGHIJKLMNOP L3202 149-00576-01 CORE, FERRITE BEAD ABCDEFGHIJKLMNOP L5100 020-03907-28A COIL, 220 MICROHENRY, RCF, FIXED ABCDEFGHIJKLMNOP L5102 149-00583-01 CORE, FERRITE BEAD ABCDEFGHIJKLMNOP L6000 020-03907-24A COIL, 100 MICROHENRY, RCF, FIXED ABCDEFGHIJKLMNOP L6001 020-04129-21 COIL, 12 MICROHENRY, RCF, FIXED ABCDEFGHIJKLMNOP L6002 091-02053 WIRE, SOLID, BARE, 22 GA COPPER ABCDEFGHIJKLMNOP L6003 020-04129-08 COIL, 1 MICROHENRY, RCF, FIXED ABCDEFGHIJKLMNOP L6004 020-04277-20A COIL, 6.8 MICROHENRY, RCF, FIXED ABCDEFGHIJKLMNOP L6005 020-04129-16 COIL, 4.7 MICROHENRY, RCF, FIXED ABCDEFGHIJKLMNOP LX3401 095-03868-04 TRANSFORMER, LINE CHOKE, COMMON MODE ABCDEFGHIJKLMNOP LX3402 020-04129-08 COIL, 1 MICROHENRY, RCF, FIXED EFMN MTS0001 009-01867 MODULE, SOUND MULTIPLEXING DECODER,

ABCDEFGHIJKLMN P0025C 050-01666-11 CONNECTOR&CABLE, ASSY, 2.5MM, 5

ABCDEFGHIJKLMN P0025F 050-01665-11 CONNECTOR&CABLE, ASSY, 2.5MM, 4

ABCDEFGHIJKLMN P0049G 058-00526-05 PLUG, 0.098P 5 CONTACT ABIJ P0094M 058-00526-02 PLUG, 0.098P 2 CONTACT CDEFGHKLMN P0094S 058-00526-04 PLUG, 0.098P 4 CONTACT ABCDEFGHIJKLMNOP Q1203 121-01310A TRANSISTOR, NPN, SILICON ABCDEFGHIJKLMNOP Q1204 121-01310A TRANSISTOR, NPN, SILICON ABCDEFGHIJKLMNOP Q1205 121-01261A TRANSISTOR, NPN, SILICON CDKL Q1400 121-01311A TRANSISTOR, PNP, SILICON EFGHMNOP Q1402 121-01310A TRANSISTOR, NPN, SILICON ABCDEFGHIJKLMNOP Q2201 121-01311A TRANSISTOR, PNP, SILICON ABCDEFGHIJKLMNOP Q2202 121-01311A TRANSISTOR, PNP, SILICON ABCDEFGHIJKLMNOP Q2203 121-01311A TRANSISTOR, PNP, SILICON ABCDEFGHIJKLMNOP Q2204 121-01311A TRANSISTOR, PNP, SILICON

CTRL

REGULATOR

USA

CONTACT, 2 UP

RC REF PART# DESCRIPTION

ABCDEFGHIJKLMNOP Q2205 121-01311A TRANSISTOR, PNP, SILICON ABCDEFGHIJKLMNOP Q3201 121-01290 TRANSISTOR, NPN, SILICON EF Q3202 121-01148 TRANSISTOR, NPN, SILICON, H.O.T., 5A ABCDGHIJKLMNOP Q3202 121-01383 TRANSISTOR, NPN, SILICON ABCDEFGHIJKLMNOP Q3203 121-01311A TRANSISTOR, PNP, SILICON ABCDEFGHIJKLMNOP Q5101 121-01334 TRANSISTOR, NPN, SILICON ABCDEFGHIJKLMNOP Q5102 121-01334 TRANSISTOR, NPN, SILICON ABCDEFGHIJKLMNOP Q5103 121-01334 TRANSISTOR, NPN, SILICON ABCDEFGHIJKLMNOP Q6001 121-01310A TRANSISTOR, NPN, SILICON ABCDEFGHIJKLMNOP Q6002 121-01310A TRANSISTOR, NPN, SILICON CDEFGHKLMNOP Q6003 121-01310A TRANSISTOR, NPN, SILICON EFMN Q9700 121-01310A TRANSISTOR, NPN, SILICON EFMN Q9701 121-01310A TRANSISTOR, NPN, SILICON EFGHMNOP Q9702 121-01310A TRANSISTOR, NPN, SILICON EFGHMNOP Q9703 121-01310A TRANSISTOR, NPN, SILICON EFGHMNOP Q9704 121-01310A TRANSISTOR, NPN, SILICON EFGHMNOP Q9705 121-01310A TRANSISTOR, NPN, SILICON EFGHMNOP Q9706 121-01310A TRANSISTOR, NPN, SILICON ABCDEFGHIJKLMNOP QX3402 121-01310A TRANSISTOR, NPN, SILICON ABIJ R0801M 063-11059-45A RESISTOR, CHIP, 680 OHM 5% 1/10W ABIJ R0802M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABIJ R0803 063-10235-16 RESISTOR, FILM, 4.7 OHM 5% 1/4W ABIJ R0820 063-10832-24B RESISTOR, FILM, 10 OHM 5% 1W CDEFGHKLMNOP R0820 063-11156-07B RESISTOR, FILM, 2 OHM 5% 1W CDEFGHKLMNOP R0831 063-10235 RESISTOR, FILM, 1 OHM 5% 1/4W CDEFGHKLMNOP R0832M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W CDEFKLMN R0851 063-10235 RESISTOR, FILM, 1 OHM 5% 1/4W CDEFKLMN R0852 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W ABCDEFIJKLMN R1209 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W GHOP R1210M 022-08366-16A CAP, 4,700 PFD 10% 50V, CERAMIC CHIP ABCDEFGHIJKLMNOP R1211M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDEFGHIJKLMNOP R1212M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDEFGHIJKLMNOP R1213M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDEFGHIJKLMNOP R1214M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDEFGHIJKLMNOP R1216M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W ABCDEFGHIJKLMNOP R1217M 063-11059-31A RESISTOR, CHIP, 180 OHM 5% 1/10W ABCDEFGHIJKLMNOP R1218M 063-11059-31A RESISTOR, CHIP, 180 OHM 5% 1/10W ABCDEFGHIJKLMNOP R1219 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W ABCDEFGHIJKLMNOP R1220M 063-11059-95A RESISTOR, CHIP, 82K OHM 5% 1/10W ABCDEFGHIJKLMNOP R1221 063-10235-96 RESISTOR, FILM, 10K OHM 5% 1/4W ABCDEFGHIJKLMNOP R1222M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGHIJKLMNOP R1223 063-10235-48 RESISTOR, FILM, 100 OHM 5% 1/4W ABCDEFGHIJKLMNOP R1224M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W ABCDEFGHIJKLMNOP R1225M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W ABCDEFGHIJKLMNOP R1226M 063-11059-09A RESISTOR, CHIP, 22 OHM 5% 1/10W ABCDEFGHIJKLMNOP R1227M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W ABCDEFGHIJKLMNOP R1228 063-10235-76 RESISTOR, FILM, 1.5K OHM 5% 1/4W ABCDEFGHIJKLMNOP R1229M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W ABCDEFGHIJKLMNOP R1230M 063-11059-13A RESISTOR, CHIP, 33 OHM 5% 1/10W ABCDEFGHIJKLMNOP R1232M 063-11059-46A RESISTOR, CHIP, 750 OHM 5% 1/10W ABCDEFGHIJKLMNOP R1233M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGHIJKLMNOP R1234M 063-11059-87A RESISTOR, CHIP, 39K OHM 5% 1/10W ABCDEFGHIJKLMNOP R1235M 063-11059-97A RESISTOR, CHIP, 100K OHM 5% 1/10W CDKL R1404M 063-11059-67A RESISTOR, CHIP, 5.6K OHM 5% 1/10W CDKL R1407M 063-11059-61A RESISTOR, CHIP, 3.3K OHM 5% 1/10W CDKL R1409M 063-11059-53A RESISTOR, CHIP, 1.5K OHM 5% 1/10W CDKL R1410M 063-11059-77A RESISTOR, CHIP, 15K OHM 5% 1/10W CDKL R1411M 063-11059-76A RESISTOR, CHIP, 13K OHM 5% 1/10W CDKL R1412 063-10235-96 RESISTOR, FILM, 10K OHM 5% 1/4W EFGHMNOP R1420M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W EFGHMNOP R1421 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W EFMN R1423 063-11087-46 RESISTOR, FILM, 82 OHM 5% 1/2W CDKL R1423 063-11087-48 RESISTOR, FILM, 100 OHM 5% 1/2W CDEFKLMN R1450M 063-11059-75A RESISTOR, CHIP, 12K OHM 5% 1/10W

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

CM150 4-3 GA - MODULE PARTS

GA1 MODULE PARTS LIST

A 9-1869 B 9-1869-01 C 9-1870 D 9-1870-01 E 9-1871 F 9-1871-01 G 9-1950 H 9-1950-01 I 9-1990 J 9-1990-01 K 9-1991 L 9-1991-01 M 9-1992 N 9-1992-01 O 9-1993 P 9-1993-01

NOTE: This list will enable you to determine the parts used on each Model, Chassis, or Assembly.

RC REF PART# DESCRIPTION

CDEFKLMN R1451M 063-11059-61A RESISTOR, CHIP, 3.3K OHM 5% 1/10W CDEFKLMN R1452M 063-11059-75A RESISTOR, CHIP, 12K OHM 5% 1/10W CDEFKLMN R1453M 063-11059-61A RESISTOR, CHIP, 3.3K OHM 5% 1/10W GHOP R1453M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGHIJKLMNOP R2102 063-10235-62 RESISTOR, FILM, 390 OHM 5% 1/4W ABCDEFGHIJKLMNOP R2103M 063-11059-71A RESISTOR, CHIP, 8.2K OHM 5% 1/10W ABCDEFGHIJKLMNOP R2104M 063-11059-21A RESISTOR, CHIP, 68 OHM 5% 1/10W ABCDEFGHIJKLMNOP R2105 063-10235-94 RESISTOR, FILM, 8.2K OHM 5% 1/4W ABCDEFGHIJKLMNOP R2106M 063-11059-21A RESISTOR, CHIP, 68 OHM 5% 1/10W ABCDEFGHIJKLMNOP R2107 063-10235-12 RESISTOR, FILM, 3.3 OHM 5% 1/4W ABCDEFGHIJKLMNOP R2108 063-10235-84 RESISTOR, FILM, 3.3K OHM 5% 1/4 W ABCDEFGHIJKLMNOP R2109 063-10243-20 RESISTOR, FILM, 6.8 OHM 5% 1/2W ABCDEFGHIJKLMNOP R2110 063-10243-20 RESISTOR, FILM, 6.8 OHM 5% 1/2W ABCDEFGHIJKLMNOP R2111 063-11087-74 RESISTOR, FILM, 1.2K OHM 5% 1/2W ABCDEFGHIJKLMNOP R2112 063-11087-64 RESISTOR, FILM, 470 OHM 5% 1/2W ABCDEFGHIJKLMNOP R2200M 063-11059-61A RESISTOR, CHIP, 3.3K OHM 5% 1/10W ABCDEFGHIJKLMNOP R2202 063-10235-24 RESISTOR, FILM, 10 OHM 5% 1/4W ABCDEFGHIJKLMNOP R2204M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDEFGHIJKLMNOP R2206M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDEFGHIJKLMNOP R2207M 063-11059-45A RESISTOR, CHIP, 680 OHM 5% 1/10W ABCDEFGHIJKLMNOP R2208M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDEFGHIJKLMNOP R2209M 063-11059-45A RESISTOR, CHIP, 680 OHM 5% 1/10W ABCDEFGHIJKLMNOP R2210M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDEFGHIJKLMNOP R2211M 063-11059-45A RESISTOR, CHIP, 680 OHM 5% 1/10W ABCDEFGHIJKLMNOP R2213M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDEFGHIJKLMNOP R2214M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDEFGHIJKLMNOP R2215M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDEFGHIJKLMNOP R2218M 063-11059-89A RESISTOR, CHIP, 47K OHM 5% 1/10W ABCDEFGHIJKLMNOP R2219 063-10235-48 RESISTOR, FILM, 100 OHM 5% 1/4W ABCDEFGHIJKLMNOP R2220 063-10235-48 RESISTOR, FILM, 100 OHM 5% 1/4W ABCDEFGHIJKLMNOP R2221M 063-11059-97A RESISTOR, CHIP, 100K OHM 5% 1/10W ABCDEFGHIJKLMNOP R2222M 063-11059-39A RESISTOR, CHIP, 390 OHM 5% 1/10W ABCDEFGHIJKLMNOP R2224M 063-11060-13A RESISTOR, CHIP, 470K OHM 5% 1/10W ABCDEFGHIJKLMNOP R2226M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDEFGHIJKLMNOP R2227M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDEFGHIJKLMNOP R2228M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W ABCDEFGHIJKLMNOP R2229M 063-11059-39A RESISTOR, CHIP, 390 OHM 5% 1/10W ABCDEFGHIJKLMNOP R2230M 063-11059-57A RESISTOR, CHIP, 2.2K OHM 5% 1/10W ABCDEFGHIJKLMNOP R2231 063-10235-64 RESISTOR, FILM, 470 OHM 5% 1/4W ABCDEFGHIJKLMNOP R2232M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W ABCDEFGHIJKLMNOP R2233 063-10235-80 RESISTOR, FILM, 2.2K OHM 5% 1/4W ABCDEFGHIJKLMNOP R2234M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGHIJKLMNOP R2238 063-10235-66 RESISTOR, FILM, 560 OHM 5% 1/4W ABCDEFGHIJKLMNOP R2239M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGHIJKLMNOP R2240M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDEFGHIJKLMNOP R2241M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W ABCDEFGHIJKLMNOP R2242M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W ABCDEFGHIJKLMNOP R2243M 063-11059-87A RESISTOR, CHIP, 39K OHM 5% 1/10W ABCDEFGHIJKLMNOP R2250M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGHIJKLMNOP R2252 063-10235-40 RESISTOR, FILM, 47 OHM 5% 1/4W ABCDEFGHIJKLMNOP R2257M 063-11059-71A RESISTOR, CHIP, 8.2K OHM 5% 1/10W ABCDEFGHIJKLMNOP R2259M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDEFGHIJKLMNOP R2260M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W ABCDEFGHIJKLMNOP R2261M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W ABCDEFGHIJKLMNOP R2262M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W ABCDEFGHIJKLMNOP R2266 063-10235-40 RESISTOR, FILM, 47 OHM 5% 1/4W ABCDEFGHIJKLMNOP R2282 063-10235-64 RESISTOR, FILM, 470 OHM 5% 1/4W ABCDEFGHIJKLMNOP R2283M 063-11059-45A RESISTOR, CHIP, 680 OHM 5% 1/10W ABCDEFGHIJKLMNOP R2284M 063-11059-45A RESISTOR, CHIP, 680 OHM 5% 1/10W ABCDEFGHIJKLMNOP R2285M 063-11059-45A RESISTOR, CHIP, 680 OHM 5% 1/10W ABCDEFGHIJKLMNOP R3201M 063-11059-31A RESISTOR, CHIP, 180 OHM 5% 1/10W IJKLMNOP R3202 063-10832-96B RESISTOR, FILM, 10K OHM 5% 1W ABCDEFGH R3202 063-10832-98B RESISTOR, FILM, 12K OHM 5% 1W ABCDEFGHIJKLMNOP R3203 063-10565-10 RESISTOR, FILM, 2.7 OHM 5% 1/2W

RC REF PART# DESCRIPTION

ABCDEFGHIJKLMNOP R3204 063-11214-16 RESISTOR, FILM, 0.51 OHM 5% 1/2W ABCDEFGHIJKLMNOP R3205 063-11156B RESISTOR, FILM, 1 OHM 5% 1W ABIJ R3206 063-10565-12 RESISTOR, FILM, 3.3 OHM 5% 1/2W CDEFGHKLMNOP R3206 063-11156-07B RESISTOR, FILM, 2 OHM 5% 1W ABCDEFGHIJKLMNOP R3208 063-10235-96 RESISTOR, FILM, 10K OHM 5% 1/4W ABCDGHIJKLOP R3209 063-10236-03 RESISTOR, FILM, 20K OHM 5% 1/4W EFMN R3209 063-10236-05 RESISTOR, FILM, 24K OHM 5% 1/4W EFMN R3210 063-10829-22A RESISTOR, FILM, 0.47 OHM 5% 1/2W ABCDGHIJKLOP R3210 063-10829-22A RESISTOR, FILM, 0.47 OHM 5% 1/2W ABCDEFGHIJKLMNOP R3211 063-10832-98B RESISTOR, FILM, 12K OHM 5% 1W ABCDEFGHIJKLMNOP R3212 063-10428-34 RESISTOR, WIREWOUND, 2.7 OHM 5% 3W ABCDEFGHIJKLMNOP R3213 063-10235-57 RESISTOR, FILM, 240 OHM 5% 1/4W ABCDEFGHIJKLMNOP R3214 063-10235-88 RESISTOR, FILM, 4.7K OHM 5% 1/4W ABCDEFGHIJKLMNOP R3215 063-10243-96 RESISTOR, FILM, 10K OHM 5% 1/2W ABCDEFGHIJKLMNOP R3216 063-10235-48 RESISTOR, FILM, 100 OHM 5% 1/4W ABCDEFGHIJKLMNOP R3217 063-10235-96 RESISTOR, FILM, 10K OHM 5% 1/4W ABCDEFGHIJKLMNOP R3218M 063-11059-46A RESISTOR, CHIP, 750 OHM 5% 1/10W ABCDEFGHIJKLMNOP R3219M 063-11059-71A RESISTOR, CHIP, 8.2K OHM 5% 1/10W ABCDEFGHIJKLMNOP R3220 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W ABCDEFGHIJKLMNOP R5101M 063-11059-17A RESISTOR, CHIP, 47 OHM 5% 1/10W ABCDEFGHIJKLMNOP R5102M 063-11059-17A RESISTOR, CHIP, 47 OHM 5% 1/10W ABCDEFGHIJKLMNOP R5103M 063-11059-17A RESISTOR, CHIP, 47 OHM 5% 1/10W ABCDEFGHIJKLMNOP R5104M 063-11059-32A RESISTOR, CHIP, 200 OHM 5% 1/10W ABCDEFGHIJKLMNOP R5105M 063-11059-32A RESISTOR, CHIP, 200 OHM 5% 1/10W ABCDEFGHIJKLMNOP R5106M 063-11059-32A RESISTOR, CHIP, 200 OHM 5% 1/10W ABCDEFGHIJKLMNOP R5107M 063-11059-47A RESISTOR, CHIP, 820 OHM 5% 1/10W ABCDEFGHIJKLMNOP R5108M 063-11059-47A RESISTOR, CHIP, 820 OHM 5% 1/10W ABCDEFGHIJKLMNOP R5109M 063-11059-47A RESISTOR, CHIP, 820 OHM 5% 1/10W ABCDEFGHIJKLMNOP R5113M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W ABCDEFGHIJKLMNOP R5114M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W ABCDEFGHIJKLMNOP R5115M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W ABCDEFGHIJKLMNOP R5116 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W ABCDEFGHIJKLMNOP R5117 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W ABCDEFGHIJKLMNOP R5118 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W ABCDEFGHIJKLMNOP R5119 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W ABCDEFGHIJKLMNOP R6001M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDEFGHIJKLMNOP R6002M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDEFGHIJKLMNOP R6003M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGHIJKLMNOP R6004 063-10236-12 RESISTOR, FILM, 47K OHM 5% 1/4W ABCDEFGHIJKLMNOP R6005M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDEFGHIJKLMNOP R6006M 063-11059-39A RESISTOR, CHIP, 390 OHM 5% 1/10W ABCDEFGHIJKLMNOP R6007M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGHIJKLMNOP R6008 063-10235-96 RESISTOR, FILM, 10K OHM 5% 1/4W ABCDEFGHIJKLMNOP R6009 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W ABCDEFGHIJKLMNOP R6012M 063-11059-87A RESISTOR, CHIP, 39K OHM 5% 1/10W ABCDEFGHIJKLMNOP R6013M 063-11059-57A RESISTOR, CHIP, 2.2K OHM 5% 1/10W ABCDEFGHIJKLMNOP R6015 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W ABCDEFGHIJKLMNOP R6016 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W ABCDEFGHIJKLMNOP R6017M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGHIJKLMNOP R6018M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGHIJKLMNOP R6019M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDEFGHIJKLMNOP R6020M 063-11059-56A RESISTOR, CHIP, 2K OHM 5% 1/10W ABCDEFGHIJKLMNOP R6021M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDEFGHIJKLMNOP R6022M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDEFGHIJKLMNOP R6023M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDEFGHIJKLMNOP R6024M 063-11059-56A RESISTOR, CHIP, 2K OHM 5% 1/10W ABCDEFGHIJKLMNOP R6025M 063-11059-56A RESISTOR, CHIP, 2K OHM 5% 1/10W ABCDEFGHIJKLMNOP R6027 063-10235-88 RESISTOR, FILM, 4.7K OHM 5% 1/4W ABCDEFGHIJKLMNOP R6028 063-10235-60 RESISTOR, FILM, 330 OHM 5% 1/4W ABCDEFGHIJKLMNOP R6029 063-10235-96 RESISTOR, FILM, 10K OHM 5% 1/4W ABCDEFGHIJKLMNOP R6031M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDEFGHIJKLMNOP R6032M 063-11059-77A RESISTOR, CHIP, 15K OHM 5% 1/10W ABCDEFGHIJKLMNOP R6033M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W ABCDEFGHIJKLMNOP R6034M 063-11060-21A RESISTOR, CHIP, 1 MEG OHM 5% 1/10W

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

CM150 4-4 GA - MODULE PARTS

GA1 MODULE PARTS LIST

A 9-1869 B 9-1869-01 C 9-1870 D 9-1870-01 E 9-1871 F 9-1871-01 G 9-1950 H 9-1950-01 I 9-1990 J 9-1990-01 K 9-1991 L 9-1991-01 M 9-1992 N 9-1992-01 O 9-1993 P 9-1993-01

NOTE: This list will enable you to determine the parts used on each Model, Chassis, or Assembly.

RC REF PART# DESCRIPTION

ABCDEFGHIJKLMNOP R6035M 063-11060-21A RESISTOR, CHIP, 1 MEG OHM 5% 1/10W ABCDEFGHIJKLMNOP R6037M 063-11059-83A RESISTOR, CHIP, 27K OHM 5% 1/10W ABCDEFGHIJKLMNOP R6038 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W ABCDEFGHIJKLMNOP R6039 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W ABCDEFGHIJKLMNOP R6040M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W ABCDEFGHIJKLMNOP R6041 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W ABCDEFGHIJKLMNOP R6042M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDEFGHIJKLMNOP R6043 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W ABCDEFGHIJKLMNOP R6044M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDEFGHIJKLMNOP R6045M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDEFGHIJKLMNOP R6046M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDEFGHIJKLMNOP R6047M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDEFGHIJKLMNOP R6048M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDEFGHIJKLMNOP R6049M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDEFGHIJKLMNOP R6050M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDEFIJKLMN R6051 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W EFMN R6052 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W ABCDIJKL R6052 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W ABCDEFIJKLMN R6053M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFIJKLMN R6054M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W EFMN R6055 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W EFMN R6056 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W CDEFGHKLMNOP R6058 063-10235-76 RESISTOR, FILM, 1.5K OHM 5% 1/4W ABCDEFGHIJKLMNOP R6059M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGHIJKLMNOP R6060M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W EFMN R6061M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W CDKL R6061M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W GHOP R6061M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W EFMN R6062M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W EFMN R6063M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGHIJKLMNOP R6072M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGHIJKLMNOP R6080M 063-11060-14A RESISTOR, CHIP, 510K OHM 5% 1/10W EFGHMNOP R9701 091-02053 WIRE, SOLID, BARE, 22 GA COPPER EFGHMNOP R9703 063-10235-12 RESISTOR, FILM, 3.3 OHM 5% 1/4W EFGHMNOP R9704 063-10235-64 RESISTOR, FILM, 470 OHM 5% 1/4W EFMN R9705 063-10236-14 RESISTOR, FILM, 56K OHM 5% 1/4W EFMN R9706 063-10235-68 RESISTOR, FILM, 680 OHM 5% 1/4W EFMN R9707M 063-11059-83A RESISTOR, CHIP, 27K OHM 5% 1/10W EFGHMNOP R9708 063-10235-40 RESISTOR, FILM, 47 OHM 5% 1/4W EFMN R9709M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W EFMN R9710 063-10235-96 RESISTOR, FILM, 10K OHM 5% 1/4W EFMN R9711M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W EFGHMNOP R9712 063-10235-48 RESISTOR, FILM, 100 OHM 5% 1/4W EFMN R9714M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W EFMN R9715M 063-11059-29A RESISTOR, CHIP, 150 OHM 5% 1/10W EFGHMNOP R9717 063-10236-14 RESISTOR, FILM, 56K OHM 5% 1/4W EFGHMNOP R9718 063-10235-68 RESISTOR, FILM, 680 OHM 5% 1/4W EFGHMNOP R9720M 063-11059-83A RESISTOR, CHIP, 27K OHM 5% 1/10W EFGHMNOP R9721M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W EFGHMNOP R9724M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W EFGHMNOP R9725M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W EFGHMNOP R9726M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W EFGHMNOP R9727M 063-11059-29A RESISTOR, CHIP, 150 OHM 5% 1/10W EFGHMNOP R9728 063-10235-45 RESISTOR, FILM, 75 OHM 5% 1/4W EFGHMNOP R9729M 063-11059-89A RESISTOR, CHIP, 47K OHM 5% 1/10W EFGHMNOP R9730 063-10235-64 RESISTOR, FILM, 470 OHM 5% 1/4W EFGHMNOP R9731M 063-11059-31A RESISTOR, CHIP, 180 OHM 5% 1/10W EFGHMNOP R9732M 063-11059-97A RESISTOR, CHIP, 100K OHM 5% 1/10W EFGHMNOP R9734M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W EFGHMNOP R9735M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W EFGHMNOP R9736M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W EFGHMNOP R9737M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W EFGHMNOP R9738 063-11007-06 CONTROL, ROTARY, TRIMMER

RC REF PART# DESCRIPTION

EFGHMNOP R9739M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W EFGHMNOP R9740 063-10235-40 RESISTOR, FILM, 47 OHM 5% 1/4W GHOP R9745 063-10235-65 RESISTOR, FILM, 510 OHM 5% 1/4W EFMN R9745 063-11007-29 CONTROL, ROTARY, TRIMMER ABCDEFGHIJKLMNOP RX3002M 063-11059-57A RESISTOR, CHIP, 2.2K OHM 5% 1/10W ABCDEFGHIJKLMNOP RX3003 063-10233-86 RESISTOR, FILM, 3.9K OHM 2% 1/4W ABCDEFGHIJKLMNOP RX3004M 063-11059-97A RESISTOR, CHIP, 100K OHM 5% 1/10W ABCDEFGHIJKLMNOP RX3401 063-11264-01 RESISTOR, CARBON COMPOSITION, 5.6M

ABCDEFGH RX3402 063-10710A RESISTOR, THERMISTOR IJKLMNOP RX3402 063-11119 RESISTOR, THERMISTOR, DEGAUSSER ABCDEFGHIJKLMNOP RX3403 063-10449-24B RESISTOR, WIREWOUND, 1 OHM 5% 7W ABCDEFGHIJKLMNOP RX3404 063-10458-92A RESISTOR, WIREWOUND, 680 OHM 5% 10W ABCDEFGHIJKLMNOP RX3405 063-10458-92A RESISTOR, WIREWOUND, 680 OHM 5% 10W ABCDEFGHIJKLMNOP RX3406 063-11164-93B RESISTOR, FILM, 7.5K OHM 5% 3W ABCDEFGHIJKLMNOP RX3407 063-10235-80 RESISTOR, FILM, 2.2K OHM 5% 1/4W ABCDEFGHIJKLMNOP RX3408 063-10244-20 RESISTOR, FILM, 100K OHM 5% 1/2W ABCDEFGHIJKLMNOP RX3409 063-11087-96 RESISTOR, FILM, 10K OHM 5% 1/2W ABCDEFGHIJKLMNOP RX3410 063-10236-38 RESISTOR, FILM, 560K OHM 5% 1/4W ABCDEFGHIJKLMNOP RX3411 063-10559-40 RESISTOR, FILM, 47 OHM 5% 1/4W ABCDEFGHIJKLMNOP RX3412 063-10442-32A RESISTOR, WIREWOUND, 2.2 OHM 5% 5W ABCDEFGHIJKLMNOP RX3413 063-10476-78A RESISTOR, WIREWOUND, 180 OHM 5% 20W ABCDEFGHIJKLMNOP RX3414 063-10244-06 RESISTOR, FILM, 27K OHM 5% 1/2W ABCDEFGHIJKLMNOP RX3415 063-11164-93B RESISTOR, FILM, 7.5K OHM 5% 3W ABCDEFGHIJKLMNOP RX3416 063-10836-82B RESISTOR, FILM, 2.7K OHM 5% 2W ABCDEFGHIJKLMNOP RX3417 063-11164-93B RESISTOR, FILM, 7.5K OHM 5% 3W ABCDEFGHIJKLMNOP RX3418 063-11164-88B RESISTOR, FILM, 4.7K OHM 5% 3W ABCDEFGHIJKLMNOP RX3419 063-11164-88B RESISTOR, FILM, 4.7K OHM 5% 3W ABCDEFGHIJKLMNOP RX3420 063-10235-24 RESISTOR, FILM, 10 OHM 5% 1/4W ABCDEFGHIJKLMNOP RX5126 063-10833B RESISTOR, FILM, 15K OHM 5% 1W ABCDEFGHIJKLMNOP RX5127 063-10833B RESISTOR, FILM, 15K OHM 5% 1W ABCDEFGHIJKLMNOP RX5128 063-10833B RESISTOR, FILM, 15K OHM 5% 1W EFGHMNOP RX9702 063-11264-01 RESISTOR, CARBON COMPOSITION, 5.6M

ABCDEFGHIJKLMNOP SW0001 085-01832 SWITCH, PUSH-BUTTON, NON LOCKING,

ABCDEFGHIJKLMNOP SW0002 085-01832 SWITCH, PUSH-BUTTON, NON LOCKING,

ABCDEFGHIJKLMNOP SW0003 085-01832 SWITCH, PUSH-BUTTON, NON LOCKING,

ABCDEFGHIJKLMNOP SW0004 085-01832 SWITCH, PUSH-BUTTON, NON LOCKING,

ABCDEFGHIJKLMNOP SW0005 085-01832 SWITCH, PUSH-BUTTON, NON LOCKING,

ABCDEFGHIJKLMNOP SW0006 085-01832 SWITCH, PUSH-BUTTON, NON LOCKING,

ABCDEFGHIJKLMNOP T3201 095-04525 TRANSFORMER, HORIZONTAL DRIVER/ EFGHIJKLMNOP TU6000 175-02720 TUNER, VARACTOR, 181 CHANNEL, SINGLE

ABCDEFGHIJKLMNOP TX3202 095-04376-02 SWEEP XFMR, COLOR, FINAL EFGHMNOP TX9701 095-04526 TRANSFORMER, ISOLATION ABCDEFGHIJKLMNOP U1200 224-00139-01A FILTER, 4.5 MHZ CERAMIC BANDPASS ABCDEFGHIJKLMNOP U1201 224-00160 FILTER, SURFACE ACOUSTIC WAVE ABCDEFGHIJKLMNOP U1202 224-00023A CERAMIC FILTER , 4.5 MHZ TRAP GHOP W0075 301-99282P020D WIRE, STRANDED, SINGLE CONDUCTOR, 22

CDKL ZD1400 103-00279-15A DIODE, ZENER, 7.5V 0.5W EFMN ZD1400 103-00279-18A DIODE, ZENER, 9.1V 0.5W ABCDEFGHIJKLMNOP ZD3206 103-00336-10A DIODE, ZENER, 5.1V 0.5W ABCDEFGHIJKLMNOP ZD6001 103-00279-36A DIODE, ZENER, 33V 0.5W EFGHMNOP ZD9701 103-00279-18A DIODE, ZENER, 9.1V 0.5W EFMN ZD9702 103-00279-18A DIODE, ZENER, 9.1V 0.5W ABCDEFGHIJKLMNOP ZDX3408 103-00301-16A DIODE, ZENER, 12V 1W ABCDEFGHIJKLMNOP ZDX3412 103-00336-18A DIODE, ZENER, 9.1V 0.5W

OHM 20% 1/2W

SPST

IC, WORLD STAN

GA WHITE

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

CM150 4-5 GA - MODULE PARTS

-4-6-

GA2 MODULE PARTS

NOTE: This list will enable you to determine the parts used on each Model, Chassis, or Assembly.

RC REF PART# DESCRIPTION

IJ 2K6 058-00526-05 PLUG, 0.098P 5 CONTACT ABCDEFGHIJKL 3T8 058-00643-02 PLUG, MULTIPRONG, 2 POSITION DHIJKL 3Y3 058-00546-04 PLUG, MULTIPRONG, 4 POSITION IJ 4G9 058-00526-05 PLUG, 0.098P 5 CONTACT IJ 9S4 058-00526-04 PLUG, 0.098P 4 CONTACT ABL C0801 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO ABL C0802 022-08309-15A CAP, 470 MFD 20% 16V, ELECTRO ABL C0803 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY ABL C0804M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABL C0805 022-08310-16 CAP, 1000 MFD 20% 25V, ELECTRO ABL C0806M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP CDEFGHIJK C0820 022-08310-17 CAP, 2200 MFD 20% 25V, ELECTRO CDEFGHIJK C0821M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP CDEFGHIJK C0830 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO CDEFGHIJK C0831 022-08310-11A CAP, 47 MFD 20% 25V, ELECTRO CDEFGHIJK C0832 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY CDEFGHIJK C0833 022-08309-15A CAP, 470 MFD 20% 16V, ELECTRO CDEFGHIJK C0850 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO CDEFGHIJK C0851 022-08310-11A CAP, 47 MFD 20% 25V, ELECTRO CDEFGHIJK C0852 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY CDEFGHIJK C0853 022-08309-15A CAP, 470 MFD 20% 16V, ELECTRO ABL C1202M 022-08366-16A CAP, 4,700 PFD 10% 50V, CERAMIC CHIP ABCDEFGHIJKL C1206M 022-08352-24A CAP, 33 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C1208 022-08492-01A CAP, 1 MFD 20% 50V, NONPLZD ELECTRO ABCDEFGHIJKL C1211 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C1212M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C1213M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C1215M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKL C1216M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKL C1217 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO ABCDEFGHIJKL C1218M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKL C1219M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKL C1220 022-08309-13A CAP, 220 MFD 20% 16V, ELECTRO ABCDEFGHIJKL C1221M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP ABCDEFGHIJKL C1222 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY ABCDEFGHIJKL C1223M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKL C1224M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP ABCDEFGHIJKL C1225M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKL C1226M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKL C1227M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP ABCDEFGHIJKL C1228M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP ABCDEFGHIJKL C1229 022-08312-03A CAP, 0.47 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C1231M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP ABCDEFGHIJKL C1232 022-08312-03A CAP, 0.47 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C1233 022-08308-15A CAP, 470 MFD 20% 10V, ELECTRO ABCDEFGHIJKL C1234M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP ABCDEFGHIJKL C1235 022-08312-03A CAP, 0.47 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C1236M 022-08371-24A CAP, 22,000 PFD 20% 16V, CERAMIC CHIP CDEFGK C1401M 022-08366-16A CAP, 4,700 PFD 10% 50V, CERAMIC CHIP CDEFGK C1403 022-08227-15A CAP, 0.22 MFD 5% 50V, POLY CDEFGK C1404 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO CDEFGK C1409 022-08310-11A CAP, 47 MFD 20% 25V, ELECTRO CDEFGK C1410 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO CDEFGK C1411 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY CDEFGK C1412M 022-08371-24A CAP, 22,000 PFD 20% 16V, CERAMIC CHIP CDEFGK C1415 022-08312-05A CAP, 2.2 MFD 20% 50V, ELECTRO CDEFGK C1416 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO CDEFGK C1417 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY CDEFGK C1418M 022-08366-13A CAP, 2,700 PFD 10% 50V, CERAMIC CHIP CDEFGK C1420M 022-08371-24A CAP, 22,000 PFD 20% 16V, CERAMIC CHIP CDEFGK C1423 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO CDEFGHIJK C1432 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO CDEFGHIJK C1433 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO CDEFGHIJK C1435M 022-08366-16A CAP, 4,700 PFD 10% 50V, CERAMIC CHIP

GA2 MODULE PARTS LIST

A 9-1789 B 9-1789-01 C 9-1790 D 9-1790-01 E 9-1791 F 9-1791-01 G 9-1791-02 H 9-1831 I 9-1831-01 J 9-1831-02 K 9-1976-01 L 9-1977-01

RC REF PART# DESCRIPTION

CDEFGHIJK C1437M 022-08366-16A CAP, 4,700 PFD 10% 50V, CERAMIC CHIP CDEFGHIJK C1440 022-08049-08A CAP, 0.0047 MFD 10% 50V, POLY CDEFGHIJK C1441 022-08049-08A CAP, 0.0047 MFD 10% 50V, POLY CDEFGHIJK C1450 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO CDEFGHIJK C1451 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO CDEFGHIJK C1490 022-08312-09A CAP, 22 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C2102 022-08312-06A CAP, 3.3 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C2103M 022-08366A CAP, 220 PFD 10% 50V, CERAMIC CHIP ABCDEFGHIJKL C2104 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY ABCDEFGHIJKL C2105 022-08312-05A CAP, 2.2 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C2107M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP ABCDEFGHIJKL C2202M 022-08352-14A CAP, 12 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C2203 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C2204 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C2205 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C2206 022-08227-23A CAP, 1 MFD 5% 50V, POLY ABCDEFGHIJKL C2207M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKL C2208 022-08308-15A CAP, 470 MFD 20% 10V, ELECTRO ABCDEFGHIJKL C2209M 022-08371-24A CAP, 22,000 PFD 20% 16V, CERAMIC CHIP ABCDEFGHIJKL C2211 022-08312-05A CAP, 2.2 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C2212 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C2215 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C2216 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C2217 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C2218 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C2219 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C2220M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKL C2221M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C2225M 022-08352-42A CAP, 180 PFD 5% 50V, CERAMIC CHIP CDEFGHIJK C2226 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C2227 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C2230 022-08310-12A CAP, 100 MFD 20% 25V, ELECTRO ABCDEFGHIJKL C2231 022-08310-12A CAP, 100 MFD 20% 25V, ELECTRO ABL C2232M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKL C2234M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C2237M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP ABCDEFGHIJKL C2240M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C2241M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C2250M 022-08352-31A CAP, 62 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C2257M 022-08364-52A CAP, 470 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C2601 022-08049-16A CAP, 0.022 MFD 10% 50V, POLY ABCDEFGHIJKL C2602 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY ABCDEFGHIJKL C2603 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C2604 022-08309-16 CAP, 1000 MFD 20% 16V, ELECTRO ABCDEFGHIJKL C3209 022-07786-17C CAP, 2200 PFD 10% 500V, CERAMIC DISC ABCDEFGHIJKL C3211 022-07774-16 CAP, 0.022MFD 10% 100V, POLY ABCDEFGHIJKL C3214M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C3215 022-08257-08A CAP, 470 PFD 10% 50V, CERAMIC DISC ABCDEFGHIJKL C3232 022-07811A CAP, 1000 PFD 10% 1000V, CERAMIC DISC ABCDEFGHIJKL C3237 022-07786-10C CAP, 470 PFD 10% 500V, CERAMIC DISC EF C3248 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C3269 022-07786-10C CAP, 470 PFD 10% 500V, CERAMIC DISC ABCDEFGHIJKL C3271 022-07786-10C CAP, 470 PFD 10% 500V, CERAMIC DISC ABCDEFGHIJKL C3419 022-07786C CAP, 1000 PFD 10% 500V, CERAMIC DISC ABCDEFGHIJKL C3421 022-07786C CAP, 1000 PFD 10% 500V, CERAMIC DISC ABCDEFGHIJKL C3428 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO ABCDEFHIJKL C5101M 022-08352-48A CAP, 330 PFD 5% 50V, CERAMIC CHIP G C5101M 022-08366-04A CAP, 470 PFD 10% 50V, CERAMIC CHIP ABCDEFHIJKL C5102M 022-08352-48A CAP, 330 PFD 5% 50V, CERAMIC CHIP G C5102M 022-08366-04A CAP, 470 PFD 10% 50V, CERAMIC CHIP ABCDEFHIJKL C5103M 022-08352-48A CAP, 330 PFD 5% 50V, CERAMIC CHIP G C5103M 022-08366-04A CAP, 470 PFD 10% 50V, CERAMIC CHIP ABCDEFGHIJKL C5104 022-07523-01B CAP, 0.01 MFD +80% & -20% 2000V, CERAMIC DI ABCDEFGHIJKL C5109 022-07786-10C CAP, 470 PFD 10% 500V, CERAMIC DISC

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

CM150 4-7 GA - MODULE PARTS

GA2 MODULE PARTS LIST

A 9-1789 B 9-1789-01 C 9-1790 D 9-1790-01 E 9-1791 F 9-1791-01 G 9-1791-02 H 9-1831 I 9-1831-01 J 9-1831-02 K 9-1976-01 L 9-1977-01

NOTE: This list will enable you to determine the parts used on each Model, Chassis, or Assembly.

RC REF PART# DESCRIPTION

ABCDEFGHIJKL C6001M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C6002M 022-08364-52A CAP, 470 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C6003M 022-08364-52A CAP, 470 PFD 5% 50V, CERAMIC CHIP ABCDEFGKL C6004 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C6005M 022-08366A CAP, 220 PFD 10% 50V, CERAMIC CHIP ABCDEFGHIJKL C6006 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C6007M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP ABCDEFGHIJKL C6008M 022-08366A CAP, 220 PFD 10% 50V, CERAMIC CHIP ABCDEFGHIJKL C6009 022-07774-24 CAP, 0.1 MFD 10% 100V, POLY ABCDEFGHIJKL C6010M 022-08352-19A CAP, 20 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C6011M 022-08352-19A CAP, 20 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C6012M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKL C6013 022-08309-13A CAP, 220 MFD 20% 16V, ELECTRO ABCDEFGHIJKL C6014M 022-08352-22A CAP, 27 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C6015M 022-08352-22A CAP, 27 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C6016 022-08312-05A CAP, 2.2 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C6017 022-07774-24 CAP, 0.1 MFD 10% 100V, POLY ABCDEFGHIJKL C6018M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP ABCDEFGHIJKL C6019M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C6020 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C6021M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP CDEFGHIJK C6022 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C6023M 022-08352-36A CAP, 100 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C6024M 022-08352-36A CAP, 100 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C6025M 022-08352-36A CAP, 100 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C6026M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKL C6028 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C6029M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKL C6030 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO ABCDEFGHIJKL C6031M 022-08366-16A CAP, 4,700 PFD 10% 50V, CERAMIC CHIP ABCDEFGHIJKL C6032 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO ABCDEFGHIJKL C6033M 022-08352-36A CAP, 100 PFD 5% 50V, CERAMIC CHIP HIJ C6036M 022-08367-08A CAP, 1,000 PFD 20% 50V, CERAMIC CHIP ABCDEFGHIJKL C6037 022-08257-04A CAP, 220 PFD 10% 50V, CERAMIC DISC ABCDEFGHIJKL C6038M 022-08366A CAP, 220 PFD 10% 50V, CERAMIC CHIP ABCDEFGHIJKL C6040M 022-08366A CAP, 220 PFD 10% 50V, CERAMIC CHIP ABCDEFGHIJKL C6041M 022-08364-52A CAP, 470 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C6042M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKL C6043M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKL C6044M 022-08364-52A CAP, 470 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C6045M 022-08364-52A CAP, 470 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C6046M 022-08364-52A CAP, 470 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C6047M 022-08352-36A CAP, 100 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C6048M 022-08352-36A CAP, 100 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C6049M 022-08352-36A CAP, 100 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C6050M 022-08352-36A CAP, 100 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C6051M 022-08364-52A CAP, 470 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C6052M 022-08366A CAP, 220 PFD 10% 50V, CERAMIC CHIP ABCDEFGHIJKL C6053M 022-08366A CAP, 220 PFD 10% 50V, CERAMIC CHIP ABCDEFGHIJKL C6054M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C6055M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C6056M 022-08369-20A CAP, 10,000 PFD 20% 25V, CERAMIC CHIP ABCDEFGHIJKL C6058M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C6059M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C6060M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDEFGHIJKL C6061M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP CDEFGK CR1401 224-00179 RESONATOR, CERAMIC, 378 KHZ ABCDEFGHIJKL CR2200 224-00027A CRYSTAL, QUARTZ, 3.579 MHZ ABCDEFGHIJKL CR2205 224-00178 RESONATOR, CERAMIC, 503 KHZ IJL CRT0001 078-03394-09 SOCKET, CRT ABCDEFGHIJKL CRY6001 224-00074-02A CRYSTAL, QUARTZ, 8 MHZ ABCDEFGHIJKL CX2101 022-08311-13 CAP, 220 MFD 20% 35V, ELECTRO ABCDEFGHIJKL CX2106 022-08310-17 CAP, 2200 MFD 20% 25V, ELECTRO ABCDEFGHIJKL CX2108 022-08311-13 CAP, 220 MFD 20% 35V, ELECTRO

RC REF PART# DESCRIPTION

ABCDEFGHIJKL CX3003 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO ABCDEFGHIJKL CX3004 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO ABCDEFGHIJKL CX3007 022-07786-10C CAP, 470 PFD 10% 500V, CERAMIC DISC EF CX3201 022-08116-07 CAP, .039 MFD 5% 630V, POLYPROP EF CX3208 022-08057-01 CAP, 4.7 MFD 20% 50V, NONPLZD ELECTRO KL CX3220 022-08386-01 CAP, 270 PFD 10% 2000V, CERAMIC DISC G CX3220 022-08386-08 CAP, 1000 PFD 10% 2000V, CERAMIC DISC G CX3222 022-08386-08 CAP, 1000 PFD 10% 2000V, CERAMIC DISC ABCDGHIJKL CX3229 022-08229-27 CAP, 0.013 MFD 3% 1600VDC, POLYPROP EF CX3229 022-08229-29 CAP, 0.016 MFD 3% 1600VDC, POLYPROP J CX3231 022-08386-01 CAP, 270 PFD 10% 2000V, CERAMIC DISC ABCDEFGHI CX3231 022-08386-05 CAP, 560 PFD 10% 2000V, CERAMIC DISC ABCDEFGHIJKL CX3233 022-08514-11 CAP, 47 MFD 20% 160V, ELECTRO ABCDEFGHIJKL CX3260 022-08315-05A CAP, 2.2 MFD 20% 160V, ELECTRO G CX3261 022-08231-11 CAP, 0.39 MFD 5% 200V, POLYPROP ABCDEFHIJKL CX3261 022-08231-13 CAP, 0.56 MFD 5% 200V, POLYPROP ABCDEFGHIJKL CX3264 022-07786-10C CAP, 470 PFD 10% 500V, CERAMIC DISC EF CX3272 022-08312-11A CAP, 47 MFD 20% 50V, ELECTRO EF CX3273 022-07786-10C CAP, 470 PFD 10% 500V, CERAMIC DISC ABCDEFGHIJKL CX3274 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO ABCDEFGHIJKL CX3296 022-08317-08 CAP, 10 MFD 20% 250V, ELECTRO ABCDEFGHIJKL CX3400 022-07431-06B CAP, 0.0047 MFD 20%, CERAMIC DISC ABCDEFGHIJKL CX3402 022-07431-06B CAP, 0.0047 MFD 20%, CERAMIC DISC ABCDEFGHIJKL CX3403 022-07811A CAP, 1000 PFD 10% 1000V, CERAMIC DISC ABCDEFGHIJKL CX3404 022-07811A CAP, 1000 PFD 10% 1000V, CERAMIC DISC ABCDEFGHIJKL CX3405 022-07811A CAP, 1000 PFD 10% 1000V, CERAMIC DISC ABCDEFGHIJKL CX3406 022-07811A CAP, 1000 PFD 10% 1000V, CERAMIC DISC ABCDEFGHIJKL CX3407 022-08444-09 CAP, 330 MFD 20% 200V, ELECTRO ABCDEFGHIJKL CX3408 022-08310-16 CAP, 1000 MFD 20% 25V, ELECTRO ABCDEFGHIJKL CX3409 022-08160-01 CAP, 1000 PFD 10% 1000V, CERAMIC DISC ABCDEFGHIJKL CX3410 022-07786C CAP, 1000 PFD 10% 500V, CERAMIC DISC ABCDEFGHIJKL CX3411 022-07774-18 CAP, 0.033 MFD 10% 100V, POLY ABCDEFGHIJKL CX3412 022-07786C CAP, 1000 PFD 10% 500V, CERAMIC DISC ABCDEFGHIJKL CX3413 022-08313-09A CAP, 22 MFD 20% 63V, ELECTRO ABCDEFGHIJKL CX3414 022-07786-10C CAP, 470 PFD 10% 500V, CERAMIC DISC ABCDEFGHIJKL CX3415 022-08008-12 CAP, .01 MFD 5% 1250V, POLYPROP ABCDEFGHIJKL CX3416 022-08310-12A CAP, 100 MFD 20% 25V, ELECTRO ABCDEFGHIJKL CX3418 022-07786-01C CAP, 220 PFD 10% 500V, CERAMIC DISC ABCDEFGHIJKL CX3420 022-08444-07 CAP, 220 MFD 20% 200V, ELECTRO ABCDEFGHIJKL CX3424 022-08310-17 CAP, 2200 MFD 20% 25V, ELECTRO ABCDEFGHIJKL CX3431 022-08310-16 CAP, 1000 MFD 20% 25V, ELECTRO ABCDEFGHIJKL CX6027 022-08309-16 CAP, 1000 MFD 20% 16V, ELECTRO ABCDEFGHIJKL D2102 103-00254-01 DIODE, LOW VOLTAGE GENERAL, SILICON ABCDEFGHIJKL D2202 103-00461A DIODE, FAST SWITCHING, HIGH CONDUCTANCE ABCDEFGHIJKL D2203 103-00461A DIODE, FAST SWITCHING, HIGH CONDUCTANCE ABCDEFGHIJKL D2204 091-02053 WIRE, SOLID, BARE, 22 GA COPPER ABCDEFGHIJKL D2206 103-00461A DIODE, FAST SWITCHING, HIGH CONDUCTANCE ABCDEFGHIJKL D2601 103-00461A DIODE, FAST SWITCHING, HIGH CONDUCTANCE ABCDEFGHIJKL D3409 103-00339-04A DIODE, LOW VOLTAGE GENERAL, SILICON ABCDEFGHIJKL D3409 149-00576-01 CORE, FERRITE BEAD ABCDEFGHIJKL D3410 103-00417-03A DIODE, LOW VOLTAGE GENERAL, SILICON ABCDEFGHIJKL D3410 149-00576-01 CORE, FERRITE BEAD ABCDEFGHIJKL D6001 103-00461A DIODE, FAST SWITCHING, HIGH CONDUCTANCE ABCDEFGHIJKL DX3005 103-00461A DIODE, FAST SWITCHING, HIGH CONDUCTANCE ABCDEFGHIJKL DX3006 103-00344-04A DIODE, LOW VOLTAGE GENERAL EF DX3201 103-00344-06A DIODE, LOW VOLTAGE GENERAL ABCDEFGHIJKL DX3204 103-00461A DIODE, FAST SWITCHING, HIGH CONDUCTANCE EF DX3207 103-00305-01A DIODE, HIGH VOLTAGE GENERAL, SILICON ABCDEFGHIJKL DX3260 103-00284A DIODE, LOW VOLTAGE GENERAL, SILICON ABCDEFGHIJKL DX3273 103-00339-04A DIODE, LOW VOLTAGE GENERAL, SILICON ABCDEFGHIJKL DX3287 103-00326A DIODE, LOW VOLTAGE GENERAL, SILICON EF DX3288 103-00344-04A DIODE, LOW VOLTAGE GENERAL ABCDEFGHIJKL DX3401 103-00467A DIODE, LOW VOLTAGE GENERAL, SILICON ABCDEFGHIJKL DX3402 103-00467A DIODE, LOW VOLTAGE GENERAL, SILICON

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

CM150 4-8 GA - MODULE PARTS

GA2 MODULE PARTS LIST

A 9-1789 B 9-1789-01 C 9-1790 D 9-1790-01 E 9-1791 F 9-1791-01 G 9-1791-02 H 9-1831 I 9-1831-01 J 9-1831-02 K 9-1976-01 L 9-1977-01

NOTE: This list will enable you to determine the parts used on each Model, Chassis, or Assembly.

RC REF PART# DESCRIPTION

ABCDEFGHIJKL DX3403 103-00467A DIODE, LOW VOLTAGE GENERAL, SILICON ABCDEFGHIJKL DX3404 103-00467A DIODE, LOW VOLTAGE GENERAL, SILICON ABCDEFGHIJKL DX3405 103-00254-01 DIODE, LOW VOLTAGE GENERAL, SILICON ABCDEFGHIJKL DX3406 103-00344-02A DIODE, LOW VOLTAGE GENERAL ABCDEFGHIJKL DX3407 103-00344-02A DIODE, LOW VOLTAGE GENERAL ABCDEFGHIJKL DX3408 103-00344-02A DIODE, LOW VOLTAGE GENERAL ABCDEFGHIJKL EX3401 038-00102 SPARK GAP, HIGH VOLTAGE, 4KV DC ABCDEFGHIJKL FB6001 149-00576 CORE, FERRITE BEAD ABCDEFGHIJKL FB6002 149-00583-01 CORE, FERRITE, BEAD ABCDEFGHIJKL FX3401 136-00114-23A FUSE, NORMAL LAG, 4 AMP 250V ABCDEFGHIJKL FX3402 136-00148-23 FUSE, NORMAL LAG, 3 AMP 250V ABCDEFGHIJKL GND0001 301-99001P150DHWIRE, STRANDED, SINGLE CONDUCTOR, 18 GA,

ABL IC0801 221-00981 IC, 1 WATT AUDIO AMPLIFIER CDEFGHIJK IC0830 221-01163 IC, AUDIO POWER AMPLIFIER, WITH VOLUME

CDEFGHIJK IC0850 221-01163 IC, AUDIO POWER AMPLIFIER, WITH VOLUME

CDEFGK IC1400 221-00907 IC, STEREO DECODER ABCDEFGHIJKL IC2100 221-00903 IC, VERTICAL DEFLECTION ABCDEFGHIJKL IC3441 221-00213-09 IC, 9 VOLT, 1 AMP, LINEAR, REGULATOR ABCDEFGHIJKL IC6000 126-03446-02 SHIELD, EMI, MICROPROCESSOR ACEH IC6000 221-01164-01 IC, 8-BIT MICROCOMPUTER, WITH CAPTION BDFGIJKL IC6000 221-01164-02 IC, 8-BIT MICROCOMPUTER, WITH LIGHT DE ABCDEFGHIJKL IC6001 221-00745-04 IC, 4K BIT SERIAL EEPROM ABCDEFGHIJKL IC6002 221-01177A IC, SYSTEM RESET ABCDEFGHIJKL ICX2200 221-01165 IC, I2C BUS CONTROL NTSC ABCDEFGHIJKL ICX3431 223-00028 IC PKG, HYBRID, VOLTAGE REGULATOR ABCDEFGKL IR6000 162-00046 IR DETECTOR CDEFGHIJK J0001 A-18577 JACK ASSEMBLY, 3 JACK ABCDEFGHIJKL J0001M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W ABCDEFGHIJKL J0002M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W CDEFGHIJK J0003M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W ABCDEFGKL J0004M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W ABCDEFGHIJKL KX3401 195-00161 RELAY, SPST, 12 VDC COIL ABCDEFGHIJKL L1200 020-04506 COIL, RCF, FIXED, SHIELDED ABCDEFGHIJKL L1201 020-04277-39A COIL, 10 MICROHENRY, RCF, FIXED ABCDEFGHIJKL L1202 020-03907-12A COIL, 10 MICROHENRY, RCF, FIXED ABCDEFGHIJKL L1203 020-04277-23A COIL, 12 MICROHENRY, RCF, FIXED ABCDEFGHIJKL L1204 091-02053 WIRE, SOLID, BARE, 22 GA COPPER ABCDEFGHIJKL L1205 020-04278B COIL, RCF, TUNABLE, 7.0 MM ABCDEFGHIJKL L1206 020-04277-09A COIL, 0.82 MICROHENRY, RCF, FIXED ABCDEFGHIJKL L1208 020-03907-25A COIL, 120 MICROHENRY, RCF, FIXED ABCDEFGHIJKL L2202 020-04277-20A COIL, 6.8 MICROHENRY, RCF, FIXED ABCDEFGHIJKL L3404 020-04462-18A COIL, 33 MICROHENRY, RCF, FIXED ABCDEFGHIJKL L5100 020-03907-28A COIL, 220 MICROHENRY, RCF, FIXED ABCDEFGHIJKL L5102 149-00583-01 CORE, FERRITE, BEAD ABCDEFGHIJKL L6000 020-03907-24A COIL, 100 MICROHENRY, RCF, FIXED ABCDEFGHIJKL L6001 020-04129-08 COIL, 1 MICROHENRY, RCF, FIXED ABCDEFGHIJKL L6002 091-02053 WIRE, SOLID, BARE, 22 GA COPPER ABCDEFGHIJKL L6003 020-04129-08 COIL, 1 MICROHENRY, RCF, FIXED HIJ L6004 020-04129-08 COIL, 1 MICROHENRY, RCF, FIXED HIJ L6005 020-04129-08 COIL, 1 MICROHENRY, RCF, FIXED ABCDEFGHIJKL L6007 020-04129-16 COIL, 4.7 MICROHENRY, RCF, FIXED ABCDGHIJKL L6008 020-04277-20A COIL, 6.8 MICROHENRY, RCF, FIXED EF L6008 020-04277-21A COIL, 8.2 MICROHENRY, RCF, FIXED EF LX3201 020-04530 COIL, CHOKE ABCDEFGHIJKL LX3210 149-00540-01 CORE, FERRITE EF LX3262 020-04073-01 COIL, RCF, LINEARITY ABCDGHIJKL LX3262 020-04073-03 COIL, RCF ABCDEFGHIJKL LX3401 095-04285 TRANSFORMER, LINE CHOKE ABCDEFGHIJKL LX3403 149-00576-01 CORE, FERRITE BEAD IJ MTS 009-01867 MODULE, SOUND MULTIPLEXING DECODER, USA H P0000MTS 009-01867 MODULE, SOUND MULTIPLEXING DECODER, USA

WHITE

CONTROL

RC REF PART# DESCRIPTION

H P0026K 058-00526-05 PLUG, 0.098P 5 CONTACT ABCDEFGHKL P0049G 058-00526-05 PLUG, 0.098P 5 CONTACT ABCDEFGHKL P0052C 050-01666-07 CONNECTOR&CABLE, ASSY, 2.5MM, 5 CONTACT,

ABCDEFGHKL P0052F 050-01665-12 CONNECTOR&CABLE, ASSY, 2.5MM, 4 CONTACT,

ABL P0094M 058-00526-02 PLUG, 0.098P 2 CONTACT CDEFGHK P0094S 058-00526-04 PLUG, 0.098P 4 CONTACT ABCDEFGHIJKL Q1203 121-01310A TRANSISTOR, NPN, SILICON ABCDEFGHIJKL Q1204 121-01310A TRANSISTOR, NPN, SILICON ABCDEFGHIJKL Q1205 121-01261A TRANSISTOR, NPN, SILICON CDEFGK Q1400 121-01311A TRANSISTOR, PNP, SILICON CDEFGHIJK Q1402 121-01310A TRANSISTOR, NPN, SILICON ABCDEFGHIJKL Q2101 121-01310A TRANSISTOR, NPN, SILICON ABCDEFGHIJKL Q2201 121-01311A TRANSISTOR, PNP, SILICON ABCDEFGHIJKL Q2202 121-01311A TRANSISTOR, PNP, SILICON ABCDEFGHIJKL Q2203 121-01311A TRANSISTOR, PNP, SILICON ABCDEFGHIJKL Q2204 121-01311A TRANSISTOR, PNP, SILICON ABCDEFGHIJKL Q2205 121-01311A TRANSISTOR, PNP, SILICON ABCDEFGHIJKL Q2206 121-01310A TRANSISTOR, NPN, SILICON ABCDEFGHIJKL Q2601 121-01311A TRANSISTOR, PNP, SILICON ABCDEFGHIJKL Q2602 121-01311A TRANSISTOR, PNP, SILICON ABCDEFGHIJKL Q3202 121-01310A TRANSISTOR, NPN, SILICON EF Q3203 121-01264-01A TRANSISTOR, NPN SILICON ABCDEFGHIJKL Q3206 121-01264-01A TRANSISTOR, NPN SILICON ABCDEFGHIJKL Q3402 121-01340A TRANSISTOR, NPN, SILICON ABCDEFGHIJKL Q3403 121-01102A TRANSISTOR, PNP, SILICON ABCDEFGHIJKL Q3404 121-01102A TRANSISTOR, PNP, SILICON ABCDEFGHIJKL Q5101 121-01291-01 TRANSISTOR, NPN, SILICON ABCDEFGHIJKL Q5102 121-01291-01 TRANSISTOR, NPN, SILICON ABCDEFGHIJKL Q5103 121-01291-01 TRANSISTOR, NPN, SILICON ABCDEFGHIJKL Q6001 121-01310A TRANSISTOR, NPN, SILICON ABCDEFGHIJKL Q6002 121-01310A TRANSISTOR, NPN, SILICON ABCDEFGHIJKL Q6003 121-01310A TRANSISTOR, NPN, SILICON EF QX3201 121-01237 TRANSISTOR, PNP, SILICON 5A 80V ABCDEFGHIJKL QX3208 121-01383 TRANSISTOR, NPN, SILICON ABCDEFGHIJKL QX3401 121-01348 TRANSISTOR, NPN, SILICON 80V/1A ABL R0801M 063-11059-45A RESISTOR, CHIP, 680 OHM 5% 1/10W ABL R0802M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABL R0803 063-10235-16 RESISTOR, FILM, 4.7 OHM 5% 1/4W ABL R0805 063-10832-24B RESISTOR, FILM, 10 OHM 5% 1W CDEFGHIJK R0820 063-11214-16 RESISTOR, FILM, 0.51 OHM 5% 1/2W CDEFGHIJK R0831 063 -10235 RESISTOR, FILM, 1 OHM 5% 1/4W CDEFGHIJK R0832 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W CDEFGHIJK R0833M 063-11059-61A RESISTOR, CHIP, 3.3K OHM 5% 1/10W CDEFGHIJK R0851 063-10235 RESISTOR, FILM, 1 OHM 5% 1/4W CDEFGHIJK R0852 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W CDEFGHIJK R0853M 063-11059-61A RESISTOR, CHIP, 3.3K OHM 5% 1/10W CDEFGHIJK R1209 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W ABL R1209 063-10236-06 RESISTOR, FILM, 27K OHM 5% 1/4W ABCDEFGHIJKL R1211M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDEFGHIJKL R1212M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDEFGHIJKL R1213M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDEFGHIJKL R1214M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDEFGHIJKL R1216M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W ABCDEFGHIJKL R1217M 063-11059-31A RESISTOR, CHIP, 180 OHM 5% 1/10W ABCDEFGHIJKL R1218M 063-11059-31A RESISTOR, CHIP, 180 OHM 5% 1/10W ABCDEFGHIJKL R1219 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W ABCDEFGHIJKL R1220M 063-11059-95A RESISTOR, CHIP, 82K OHM 5% 1/10W ABCDEFGHIJKL R1221 063-10235-96 RESISTOR, FILM, 10K OHM 5% 1/4W ABCDEFGHIJKL R1222M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGHIJKL R1223 063-10235-48 RESISTOR, FILM, 100 OHM 5% 1/4W ABCDEFGHIJKL R1224M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W ABCDEFGHIJKL R1225M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W

2 UP

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

CM150 4-9 GA - MODULE PARTS

GA2 MODULE PARTS LIST

A 9-1789 B 9-1789-01 C 9-1790 D 9-1790-01 E 9-1791 F 9-1791-01 G 9-1791-02 H 9-1831 I 9-1831-01 J 9-1831-02 K 9-1976-01 L 9-1977-01

NOTE: This list will enable you to determine the parts used on each Model, Chassis, or Assembly.

RC REF PART# DESCRIPTION

ABCDEFGHIJKL R1226M 063-11059-09A RESISTOR, CHIP, 22 OHM 5% 1/10W ABCDEFGHIJKL R1227M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W ABCDEFGHIJKL R1228 063-10235-76 RESISTOR, FILM, 1.5K OHM 5% 1/4W ABCDEFGHIJKL R1229M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W ABCDEFGHIJKL R1230M 063-11059-13A RESISTOR, CHIP, 33 OHM 5% 1/10W ABCDEFGHIJKL R1232M 063-11059-46A RESISTOR, CHIP, 750 OHM 5% 1/10W ABCDEFGHIJKL R1233M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGHIJKL R1234M 063-11059-87A RESISTOR, CHIP, 39K OHM 5% 1/10W ABCDEFGHIJKL R1235M 063-11059-97A RESISTOR, CHIP, 100K OHM 5% 1/10W CDEFGK R1404M 063-11059-67A RESISTOR, CHIP, 5.6K OHM 5% 1/10W CDEFGK R1407M 063-11059-61A RESISTOR, CHIP, 3.3K OHM 5% 1/10W CDEFGK R1409M 063-11059-53A RESISTOR, CHIP, 1.5K OHM 5% 1/10W CDEFGK R1410M 063-11059-77A RESISTOR, CHIP, 15K OHM 5% 1/10W CDEFGK R1411M 063-11059-76A RESISTOR, CHIP, 13K OHM 5% 1/10W CDEFGK R1412 063-10235-96 RESISTOR, FILM, 10K OHM 5% 1/4W CDEFGHIJK R1420 063-10235-96 RESISTOR, FILM, 10K OHM 5% 1/4W CDEFGHIJK R1421 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W HIJ R1423 063-10243-52 RESISTOR, FILM, 150 OHM 5% 1/2W CDEFGK R1423 063-10243-56 RESISTOR, FILM, 220 OHM 5% 1/2W CDEFGK R1435 063-10236-04 RESISTOR, FILM, 22K OHM 5% 1/4W CDEFGHIJK R1437 063-10236-04 RESISTOR, FILM, 22K OHM 5% 1/4W CDEFGHIJK R1446 063-10235-45 RESISTOR, FILM, 75 OHM 5% 1/4W CDEFGHIJK R1447 063-10235-40 RESISTOR, FILM, 47 OHM 5% 1/4W CDEFGHIJK R1450M 063-11059-83A RESISTOR, CHIP, 27K OHM 5% 1/10W CDEFGHIJK R1452M 063-11059-83A RESISTOR, CHIP, 27K OHM 5% 1/10W ABCDEFGHIJKL R2102M 063-11059-39A RESISTOR, CHIP, 390 OHM 5% 1/10W ABCDEFGHIJKL R2103 063-10235-94 RESISTOR, FILM, 8.2K OHM 5% 1/4W ABCDEFGHIJKL R2104 063-10235-44 RESISTOR, FILM, 68 OHM 5% 1/4W EF R2105 063-10235-96 RESISTOR, FILM, 10K OHM 5% 1/4W ABCDGHIJKL R2105 063-10235-97 RESISTOR, FILM, 11K OHM 5% 1/4W ABCDEFGHIJKL R2106 063-10235-42 RESISTOR, FILM, 56 OHM 5% 1/4W ABCDEFGHIJKL R2107 063-10235-12 RESISTOR, FILM, 3.3 OHM 5% 1/4W ABCDGHIJKL R2108 063-10235-81 RESISTOR, FILM, 2.4K OHM 5% 1/4W EF R2108 063-10235-84 RESISTOR, FILM, 3.3K OHM 5% 1/4 W ABCDGHIJKL R2109 063-10243-11 RESISTOR, FILM, 3 OHM 5% 1/2W EF R2109 063-10243-16 RESISTOR, FILM, 4.7 OHM 5% 1/2W ABCDGHIJKL R2110 063-10243-11 RESISTOR, FILM, 3 OHM 5% 1/2W EF R2110 063-10243-16 RESISTOR, FILM, 4.7 OHM 5% 1/2W ABCDGHIJKL R2111 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W EF R2111 063-11087-74 RESISTOR, FILM, 1.2K OHM 5% 1/2W ABCDEFGHIJKL R2112 063-11087-64 RESISTOR, FILM, 470 OHM 5% 1/2W ABCDEFGHIJKL R2114 063-10236-52 RESISTOR, FILM, 2.2M OHM 5% 1/4W ABCDEFGHIJKL R2116 063-10236-12 RESISTOR, FILM, 47K OHM 5% 1/4W ABCDGHIJKL R2117 063-10236-30 RESISTOR, FILM, 270K OHM 5% 1/4W EF R2117 063-10236-34 RESISTOR, FILM, 390K OHM 5% 1/4W ABCDEFGHIJKL R2200M 063-11059-61A RESISTOR, CHIP, 3.3K OHM 5% 1/10W ABCDEFGHIJKL R2202 063-10235-24 RESISTOR, FILM, 10 OHM 5% 1/4W ABCDEFGHIJKL R2204M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDEFGHIJKL R2206M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDHI R2207M 063-11059-43A RESISTOR, CHIP, 560 OHM 5% 1/10W G R2207M 063-11059-44A RESISTOR, CHIP, 620 OHM 5% 1/10W EF R2207M 063-11059-45A RESISTOR, CHIP, 680 OHM 5% 1/10W JKL R2207M 063-11059-47A RESISTOR, CHIP, 820 OHM 5% 1/10W ABCDEFGHIJKL R2208M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDHI R2209M 063-11059-43A RESISTOR, CHIP, 560 OHM 5% 1/10W G R2209M 063-11059-44A RESISTOR, CHIP, 620 OHM 5% 1/10W EF R2209M 063-11059-45A RESISTOR, CHIP, 680 OHM 5% 1/10W JKL R2209M 063-11059-47A RESISTOR, CHIP, 820 OHM 5% 1/10W ABCDEFGHIJKL R2210M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDHI R2211M 063-11059-43A RESISTOR, CHIP, 560 OHM 5% 1/10W G R2211M 063-11059-44A RESISTOR, CHIP, 620 OHM 5% 1/10W EF R2211M 063-11059-45A RESISTOR, CHIP, 680 OHM 5% 1/10W JKL R2211M 063-11059-47A RESISTOR, CHIP, 820 OHM 5% 1/10W ABCDEFGHIJKL R2213M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W

RC REF PART# DESCRIPTION

ABCDEFGHIJKL R2214M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDEFGHIJKL R2215M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDEFGHIJKL R2215M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDEFGHIJKL R2218M 063-11059-89A RESISTOR, CHIP, 47K OHM 5% 1/10W ABCDEFGHIJKL R2219 063-10235-48 RESISTOR, FILM, 100 OHM 5% 1/4W ABCDEFGHIJKL R2220 063-10235-48 RESISTOR, FILM, 100 OHM 5% 1/4W ABCDEFGHIJKL R2221M 063-11059-97A RESISTOR, CHIP, 100K OHM 5% 1/10W ABCDEFGHIJKL R2223M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDEFGHIJKL R2224M 063-11060-13A RESISTOR, CHIP, 470K OHM 5% 1/10W ABCDEFGHIJKL R2225M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDEFGHIJKL R2226M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDEFGHIJKL R2227M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDEFGHIJKL R2228M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W ABCDEFGHIJKL R2229M 063-11059-39A RESISTOR, CHIP, 390 OHM 5% 1/10W ABCDEFGHIJKL R2230M 063-11059-57A RESISTOR, CHIP, 2.2K OHM 5% 1/10W ABCDEFGHIJKL R2231 063-10235-64 RESISTOR, FILM, 470 OHM 5% 1/4W ABCDEFGHIJKL R2232M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W ABCDEFGHIJKL R2233 063-10235-88 RESISTOR, FILM, 4.7K OHM 5% 1/4W ABCDEFGHIJKL R2234M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGHIJKL R2235M 063-11059-77A RESISTOR, CHIP, 15K OHM 5% 1/10W ABCDEFGHIJKL R2238 063-10235-66 RESISTOR, FILM, 560 OHM 5% 1/4W ABCDEFGHIJKL R2239M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGHIJKL R2240M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDEFGHIJKL R2241M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W ABCDEFGHIJKL R2242M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W ABCDEFGHIJKL R2243M 063-11059-87A RESISTOR, CHIP, 39K OHM 5% 1/10W ABCDEFGHIJKL R2250M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGHIJKL R2252 063-10235-40 RESISTOR, FILM, 47 OHM 5% 1/4W ABCDEFGHIJKL R2257M 063-11059-57A RESISTOR, CHIP, 2.2K OHM 5% 1/10W ABCDEFGHIJKL R2259M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDEFGHIJKL R2260M 063-11059-51A RESISTOR, CHIP, 1.2K OHM 5% 1/10W ABCDEFGHIJKL R2261M 063-11059-51A RESISTOR, CHIP, 1.2K OHM 5% 1/10W ABCDEFGHIJKL R2262M 063-11059-51A RESISTOR, CHIP, 1.2K OHM 5% 1/10W ABCDEFGHIJKL R2266 063-10235-40 RESISTOR, FILM, 47 OHM 5% 1/4W ABCDEFGHIJKL R2282 063-10235-64 RESISTOR, FILM, 470 OHM 5% 1/4W ABCDEFGHIJKL R2283M 063-11059-53A RESISTOR, CHIP, 1.5K OHM 5% 1/10W ABCDEFGHIJKL R2284M 063-11059-53A RESISTOR, CHIP, 1.5K OHM 5% 1/10W ABCDEFGHIJKL R2285M 063-11059-53A RESISTOR, CHIP, 1.5K OHM 5% 1/10W ABCDEFGHIJKL R2602 063-10235-96 RESISTOR, FILM, 10K OHM 5% 1/4W EF R2603 063-10236-02 RESISTOR, FILM, 18K OHM 5% 1/4W ABCDGHIJKL R2603 063-10236-03 RESISTOR, FILM, 20K OHM 5% 1/4W ABCDEFGHIJKL R2604 063-10235-48 RESISTOR, FILM, 100 OHM 5% 1/4W ABCDEFGHIJKL R2605 063-10235-96 RESISTOR, FILM, 10K OHM 5% 1/4W ABCDEFGHIJKL R2606M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGHIJKL R2607M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDEFGHIJKL R2608 063-10243-74 RESISTOR, FILM, 1.2K OHM 5% 1/2W ABCDEFGHIJKL R2610 063-10236-12 RESISTOR, FILM, 47K OHM 5% 1/4W ABCDEFGHIJKL R2611 063-10235-48 RESISTOR, FILM, 100 OHM 5% 1/4W ABCDEFGHIJKL R2612 063-10236 RESISTOR, FILM, 15K OHM 5% 1/4W EF R3201 063-10235-82 RESISTOR, FILM, 2.7K OHM 5% 1/4W EF R3203 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W EF R3212M 063-11060-05A RESISTOR, CHIP, 220K OHM 5% 1/10W EF R3223 063-10236-04 RESISTOR, FILM, 22K OHM 5% 1/4W ABCDEFGHIJKL R3225 063-11087-66 RESISTOR, FILM, 560 OHM 5% 1/2W ABCDEFGHIJKL R3226 063-11087-66 RESISTOR, FILM, 560 OHM 5% 1/2W EF R3243 063-10235-58 RESISTOR, FILM, 270 OHM 5% 1/4W EF R3247 063-10235-96 RESISTOR, FILM, 10K OHM 5% 1/4W EF R3248 063-10235-84 RESISTOR, FILM, 3.3K OHM 5% 1/4 W EF R3249 063-11007-56 CONTROL, ROTARY, TRIMMER ABCDEFGHIJKL R3254 063-11087-64 RESISTOR, FILM, 470 OHM 5% 1/2W ABCDEFGHIJKL R3255M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDEFGHIJKL R3256M 063-11059-29A RESISTOR, CHIP, 150 OHM 5% 1/10W ABCDEFGHIJKL R3414M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGHIJKL R3418 063-10235-82 RESISTOR, FILM, 2.7K OHM 5% 1/4W

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

CM150 4-10 GA - MODULE PARTS

GA2 MODULE PARTS LIST

A 9-1789 B 9-1789-01 C 9-1790 D 9-1790-01 E 9-1791 F 9-1791-01 G 9-1791-02 H 9-1831 I 9-1831-01 J 9-1831-02 K 9-1976-01 L 9-1977-01

NOTE: This list will enable you to determine the parts used on each Model, Chassis, or Assembly.

RC REF PART# DESCRIPTION

ABCDEFGHIJKL R3421 063-10235-82 RESISTOR, FILM, 2.7K OHM 5% 1/4W ABCDEFGHIJKL R3422M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGHIJKL R3423 063-10235-88 RESISTOR, FILM, 4.7K OHM 5% 1/4W ABCDEFGHIJKL R5101M 063-11059-17A RESISTOR, CHIP, 47 OHM 5% 1/10W ABCDEFGHIJKL R5102M 063-11059-17A RESISTOR, CHIP, 47 OHM 5% 1/10W ABCDEFGHIJKL R5103M 063-11059-17A RESISTOR, CHIP, 47 OHM 5% 1/10W ABCDEFGHI R5104M 063-11059-27A RESISTOR, CHIP, 120 OHM 5% 1/10W JKL R5104M 063-11059-29A RESISTOR, CHIP, 150 OHM 5% 1/10W ABCDEFGHI R5105M 063-11059-27A RESISTOR, CHIP, 120 OHM 5% 1/10W JKL R5105M 063-11059-29A RESISTOR, CHIP, 150 OHM 5% 1/10W ABCDEFGHI R5106M 063-11059-27A RESISTOR, CHIP, 120 OHM 5% 1/10W JKL R5106M 063-11059-29A RESISTOR, CHIP, 150 OHM 5% 1/10W ABCDEFGHI R5107M 063-11059-43A RESISTOR, CHIP, 560 OHM 5% 1/10W JKL R5107M 063-11059-46A RESISTOR, CHIP, 750 OHM 5% 1/10W ABCDEFGHI R5108M 063-11059-43A RESISTOR, CHIP, 560 OHM 5% 1/10W JKL R5108M 063-11059-46A RESISTOR, CHIP, 750 OHM 5% 1/10W ABCDEFGHI R5109M 063-11059-43A RESISTOR, CHIP, 560 OHM 5% 1/10W JKL R5109M 063-11059-46A RESISTOR, CHIP, 750 OHM 5% 1/10W G R5113M 063-11059-17A RESISTOR, CHIP, 47 OHM 5% 1/10W ABCDEFHIJKL R5113M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W G R5114M 063-11059-17A RESISTOR, CHIP, 47 OHM 5% 1/10W ABCDEFHIJKL R5114M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W G R5115M 063-11059-17A RESISTOR, CHIP, 47 OHM 5% 1/10W ABCDEFHIJKL R5115M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W ABCDEFGHIJKL R5116 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W ABCDEFGHIJKL R5117 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W ABCDEFGHIJKL R5118 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W ABCDEFGHIJKL R5119 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W ABCDEFGHIJKL R5120 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W ABCDEFGHIJKL R5121 063-10244-28 RESISTOR, FILM, 220K OHM 5% 1/2W ABCDEFHIJKL R5122 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W G R5122 063-11087-72 RESISTOR, FILM, 1.0K OHM 5% 1/2W ABCDEFGHIJKL R6001M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDEFGHIJKL R6002M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDEFGHIJKL R6003M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGHIJKL R6004M 063-11059-89A RESISTOR, CHIP, 47K OHM 5% 1/10W ABCDEFGHIJKL R6005 063-10235-88 RESISTOR, FILM, 4.7K OHM 5% 1/4W ABCDEFGHIJKL R6006M 063-11059-31A RESISTOR, CHIP, 180 OHM 5% 1/10W ABCDEFGHIJKL R6007M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGHIJKL R6008M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGHIJKL R6009M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDEFGHIJKL R6012M 063-11059-87A RESISTOR, CHIP, 39K OHM 5% 1/10W ABCDEFGHIJKL R6013M 063-11059-57A RESISTOR, CHIP, 2.2K OHM 5% 1/10W ABCDEFGHIJKL R6015M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDEFGHIJKL R6016M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDEFGKL R6017M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGKL R6018M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGKL R6020M 063-11059-56A RESISTOR, CHIP, 2K OHM 5% 1/10W ABCDEFGKL R6021M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDEFGKL R6022M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDEFGKL R6023M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDEFGKL R6024M 063-11059-56A RESISTOR, CHIP, 2K OHM 5% 1/10W ABCDEFGKL R6025M 063-11059-56A RESISTOR, CHIP, 2K OHM 5% 1/10W ABCDEFGHIJKL R6027 063-10235-88 RESISTOR, FILM, 4.7K OHM 5% 1/4W ABCDEFGKL R6028 063-10235-60 RESISTOR, FILM, 330 OHM 5% 1/4W ABCDEFGKL R6029 063-10235-96 RESISTOR, FILM, 10K OHM 5% 1/4W ABCDEFGHIJKL R6030 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W ABCDEFGHIJKL R6031M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDEFGHIJKL R6032M 063-11059-77A RESISTOR, CHIP, 15K OHM 5% 1/10W ABCDEFGHIJKL R6033M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W ABCDEFGHIJKL R6034M 063-11060-21A RESISTOR, CHIP, 1 MEG OHM 5% 1/10W ABCDEFGHIJKL R6035M 063-11060-21A RESISTOR, CHIP, 1 MEG OHM 5% 1/10W ABCDEFGHIJKL R6037M 063-11059-81A RESISTOR, CHIP, 22K OHM 5% 1/10W CDEFGHIJK R6038 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W

RC REF PART# DESCRIPTION

ABCDEFGHIJKL R6039 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W ABCDEFGHIJKL R6040M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W ABCDEFGHIJKL R6041 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W ABCDEFGHIJKL R6042M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDEFGHIJKL R6043 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W ABCDEFGHIJKL R6044M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDEFGHIJKL R6045M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDEFGHIJKL R6046M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDEFGHIJKL R6047M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDEFGHIJKL R6048M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDEFGHIJKL R6049M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDEFGHIJKL R6050M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W CDEFGHIJK R6051 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W HIJ R6052 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W CDEFGHIJK R6053M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W HIJ R6054M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W HIJ R6055 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W HIJ R6056 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W CDEFGHIJK R6058M 063-11059-41A RESISTOR, CHIP, 470 OHM 5% 1/10W CDEFGHIJK R6059M 063-11059-76A RESISTOR, CHIP, 13K OHM 5% 1/10W CDEFGHIJK R6060M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W CDEFGHIJK R6061M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W HIJ R6062M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W HIJ R6063M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W HIJ R6069M 063-11060-13A RESISTOR, CHIP, 470K OHM 5% 1/10W HIJ R6070M 063-11060-13A RESISTOR, CHIP, 470K OHM 5% 1/10W ABCDEFGHIJKL R6072M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDEFGHIJKL R6080M 063-11060-21A RESISTOR, CHIP, 1 MEG OHM 5% 1/10W ABCDEFGHIJKL RX2601 063-10243-96 RESISTOR, FILM, 10K OHM 5% 1/2W ABCDEFGHIJKL RX3008 063-10936-37 RESISTOR, FILM, 2.21K OHM 1% 1/4W ABCDEFGHIJKL RX3009 063-10236-20 RESISTOR, FILM, 100K OHM 5% 1/4W ABCDEFGHIJKL RX3010 063-10235-48 RESISTOR, FILM, 100 OHM 5% 1/4W ABCDGHIJKL RX3015 063-10236-12 RESISTOR, FILM, 47K OHM 5% 1/4W EF RX3015 063-10236-16 RESISTOR, FILM, 68K OHM 5% 1/4W ABCDEFGHIJKL RX3016 063-10936-72 RESISTOR, FILM, 4.32K OHM 1% 1/4W ABCDEFGHIJKL RX3022 063-10936-72 RESISTOR, FILM, 4.32K OHM 1% 1/4W EF RX3202 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W ABCDEFGHIJKL RX3204 063-10235-88 RESISTOR, FILM, 4.7K OHM 5% 1/4W ABCDEFGHIJKL RX3205 063-10565 RESISTOR, FILM, 1 OHM 5% 1/2W ABCDEFGHI RX3237 063-10420-28 RESISTOR, WIREWOUND, 1.5 OHM 5% 2W JKL RX3237 063-10420-37 RESISTOR, WIREWOUND, 3.6 OHM 5% 2W ABCDEFGHIJKL RX3242 063-11214-16 RESISTOR, FILM, 0.51 OHM 5% 1/2W ABCDEFGHI RX3261 063-10460-38A RESISTOR, WIREWOUND, 3.9 OHMS 10% 10W JKL RX3261 063-10460-44A RESISTOR, WIREWOUND, 6.8 OHM 10% 10W ABCDEFGHIJKL RX3263 063-10244-04 RESISTOR, FILM, 22K OHM 5% 1/2W ABCDEFGHIJKL RX3264 063-10832-69B RESISTOR, FILM, 750 OHM 5% 1W ABCDEFGHIJKL RX3277 063-10565-10 RESISTOR, FILM, 2.7 OHM 5% 1/2W ABCDEFGHIKL RX3299 063-10565-28C RESISTOR, FILM, 15 OHM 5% 1/2W ABCDEFGHIJKL RX3400 063-11182 RESISTOR, CARBON COMPOSITION, 5.6M OHM

ABCDEFGHIJKL RX3401 063-10444-20A RESISTOR, WIREWOUND, 0.68 OHM 10% 5W ABCDEFGHIJKL RX3403 063-10428-06 RESISTOR, WIREWOUND, 0.18 OHM 5% 3W ABCDEFGHIJKL RX3404 063-10244-26 RESISTOR, FILM, 180K OHM 5% 1/2W ABCDEFGHIJKL RX3406 063-10235-40 RESISTOR, FILM, 47 OHM 5% 1/4W ABCDEFGHIJKL RX3407 063-11156-40B RESISTOR, FILM, 47 OHM 5% 1W ABCDEFGHIJKL RX3408 063-10243-32 RESISTOR, FILM, 22 OHM 5% 1/2W ABCDEFGHIJKL RX3409 063-11110-16 RESISTOR, FILM, 4.7 OHM 5% 1/2W ABCDEFGHIJKL RX3411 063-10837B RESISTOR, FILM, 15K OHM 5% 2W ABCDEFGHIJKL RX3415 063-10710A RESISTOR, THERMISTOR ABCDEFGHIJKL RX3416 063-11160-60B RESISTOR, FILM, 330 OHM 5% 2W ABCDEFGHIJKL RX3417 063-10243-68 RESISTOR, FILM, 680 OHM 5% 1/2W ABCDEFGHIJKL RX3420 063-11164-20B RESISTOR, FILM, 6.8 OHM 5% 3W ABCDEFGHIJKL RX3424 063-11164-08B RESISTOR, FILM, 2.2 OHM 5% 3W ABCDEFGHIJKL RX5126 063-10836-98B RESISTOR, FILM, 12K OHM 5% 2W

20% 1/2W

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

CM150 4-11 GA - MODULE PARTS

GA2 MODULE PARTS LIST

A 9-1789 B 9-1789-01 C 9-1790 D 9-1790-01 E 9-1791 F 9-1791-01 G 9-1791-02 H 9-1831 I 9-1831-01 J 9-1831-02 K 9-1976-01 L 9-1977-01

NOTE: This list will enable you to determine the parts used on each Model, Chassis, or Assembly.

RC REF PART# DESCRIPTION

ABCDEFGHIJKL RX5127 063-10836-98B RESISTOR, FILM, 12K OHM 5% 2W ABCDEFGHIJKL RX5128 063-10836-98B RESISTOR, FILM, 12K OHM 5% 2W ABCDEFGKL SW0001 085-01832 SWITCH, PUSH-BUTTON, NON LOCKING, SPST ABCDEFGKL SW0002 085-01832 SWITCH, PUSH-BUTTON, NON LOCKING, SPST ABCDEFGKL SW0003 085-01832 SWITCH, PUSH-BUTTON, NON LOCKING, SPST ABCDEFGKL SW0004 085-01832 SWITCH, PUSH-BUTTON, NON LOCKING, SPST ABCDEFGKL SW0005 085-01832 SWITCH, PUSH-BUTTON, NON LOCKING, SPST ABCDEFGKL SW0006 085-01832 SWITCH, PUSH-BUTTON, NON LOCKING, SPST ABCDEFGHIJKL T3205 095-04477 TRANSFORMER, HORIZONTAL DRIVER IJKL TU6000 175-02721 TUNER, VARACTOR, 181 CHANNEL, SINGLE IC,

ABCDEFGHIJKL TX3204 095-04372-01 SWEEP XFMR, COLOR FINAL, MINI ABCDEFGHIJKL TX3401 095-04473 TRANSFORMER, CHOPPER ABCDEFGHIJKL U1200 224-00139-01A FILTER, 4.5 MHZ CERAMIC BANDPASS ABCDEFGHIJKL U1201 224-00160 FILTER, SURFACE ACOUSTIC WAVE ABCDEFGHIJKL U1202 224-00023A CERAMIC FILTER , 4.5 MHZ TRAP CDEFGK ZD1400 103-00279-15A DIODE, ZENER, 7.5V 0.5W HIJ ZD1400 103-00279-18A DIODE, ZENER, 9.1V 0.5W CDEFGHIJK ZD1402 103-00279-18A DIODE, ZENER, 9.1V 0.5W CDEFGHIJK ZD1403 103-00279-18A DIODE, ZENER, 9.1V 0.5W CDEFGHIJK ZD1404 103-00279-18A DIODE, ZENER, 9.1V 0.5W ABCDEFGHIJKL ZD3401 103-00279-10A DIODE, ZENER, 5.1V 0.5W ABCDEFGHIJKL ZD3402 103-00336-10A DIODE, ZENER, 5.1V 0.5W ABCDEFGHIJKL ZD6001 103-00279-36A DIODE, ZENER, 33V 0.5W ABCDEFGHIJKL ZDX3004 103-00472A DIODE, ZENER, 12V 0.5W

WORLD STAN

RC REF PART# DESCRIPTION

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

CM150 4-12 GA - MODULE PARTS

GA3 MODULE PARTS

GA3 MODULE PARTS LIST

A 9-1996 B 9-1997 C 9-1997-01 D 9-1998 E 9-2041

NOTE: This list will enable you to determine the parts used on each Model, Chassis, or Assembly.

RC REF PART# DESCRIPTION

ABCDE 2K6 058-00526-05 PLUG, 0.098P 5 CONTACT ABCDE 3T8 058-00643-02 PLUG, MULTIPRONG, 2 POSITION ABCDE 3Y3 058-00643-04 PLUG, MULTIPRONG, 4 POSITION ABCDE 4G9 058-00526-05 PLUG, 0.098P 5 CONTACT ABCDE 9S4 058-00526-04 PLUG, 0.098P 4 CONTACT ABCDE C0841 022-08310-16 CAP, 1000 MFD 20% 25V, ELECTRO ABCDE C0842 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY ABCDE C0843 022-08310-12A CAP, 100 MFD 20% 25V, ELECTRO ABCDE C0851 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO ABCDE C0852 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO ABCDE C0853 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY ABCDE C0854 022-08310-16 CAP, 1000 MFD 20% 25V, ELECTRO ABCDE C0855M 022-08366-18A CAP, 6,800 PFD 10% 50V, CERAMIC CHIP ABCDE C0861 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO ABCDE C0862 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO ABCDE C0863 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY ABCDE C0864 022-08310-16 CAP, 1000 MFD 20% 25V, ELECTRO ABCDE C0865M 022-08366-18A CAP, 6,800 PFD 10% 50V, CERAMIC CHIP ABCDE C1206M 022-08352-24A CAP, 33 PFD 5% 50V, CERAMIC CHIP ABCDE C1211 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDE C1212M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDE C1213M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP ABCDE C1215M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP ABCDE C1216M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP ABCDE C1217 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO ABCDE C1218M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP ABCDE C1219M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP ABCDE C1220 022-08309-13A CAP, 220 MFD 20% 16V, ELECTRO ABCDE C1221M 022-08366-08A CAP, 1,000 PFD 10% 50V, CERAMIC CHIP ABCDE C1222 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY ABCDE C1223M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP ABCDE C1224M 022-08366-08A CAP, 1,000 PFD 10% 50V, CERAMIC CHIP ABCDE C1225M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP ABCDE C1226M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP ABCDE C1227M 022-08366-08A CAP, 1,000 PFD 10% 50V, CERAMIC CHIP ABCDE C1228M 022-08366-08A CAP, 1,000 PFD 10% 50V, CERAMIC CHIP ABCDE C1229 022-08312-03A CAP, 0.47 MFD 20% 50V, ELECTRO ABCDE C1231M 022-08366-08A CAP, 1,000 PFD 10% 50V, CERAMIC CHIP ABCDE C1232 022-08312-03A CAP, 0.47 MFD 20% 50V, ELECTRO ABCDE C1233 022-08308-15A CAP, 470 MFD 20% 10V, ELECTRO ABCDE C1234M 022-08366-18A CAP, 6,800 PFD 10% 50V, CERAMIC CHIP ABCDE C1235 022-08312-03A CAP, 0.47 MFD 20% 50V, ELECTRO ABCDE C1236M 022-08370-24A CAP, 22,000 PFD 10% 16V, CERAMIC CHIP ABCDE C1401M 022-08370-22A CAP, 15,000 PFD 10% 16V, CERAMIC CHIP ABCDE C1402M 022-08366-18A CAP, 6,800 PFD 10% 50V, CERAMIC CHIP ABCDE C1403M 022-08370-22A CAP, 15,000 PFD 10% 16V, CERAMIC CHIP ABCDE C1404M 022-08366-18A CAP, 6,800 PFD 10% 50V, CERAMIC CHIP ABCDE C1406M 022-08370-24A CAP, 22,000 PFD 10% 16V, CERAMIC CHIP ABCDE C1408 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCD C1410 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDE C1413 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO ABCDE C1414 022-07669-15A CAP, 10 MFD 10% 50V, ELECTRO ABCDE C1415 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDE C1416 022-08188-05A CAP, 10 MFD 20% 25V, NONPLZD ELECTRO ABCDE C1417 022-08188-05A CAP, 10 MFD 20% 25V, NONPLZD ELECTRO ABCDE C1418 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDE C1419 022-07669-14A CAP, 3.3 MFD 10% 50V, ELECTRO ABCDE C1420 022-08049-13A CAP, 0.012 MFD 10% 50V, POLY ABCDE C1421 022-08257-21A CAP, 5600 PFD 10% 50V, CERAMIC DISC ABCDE C1422 022-08049-20A CAP, 0.047 MFD 10% 50V, POLY ABCDE C1424 022-08257-17A CAP, 2700 PFD 10% 50V, CERAMIC DISC ABCDE C1425 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDE C1426 022-08188-05A CAP, 10 MFD 20% 25V, NONPLZD ELECTRO ABCDE C1427 022-08188-05A CAP, 10 MFD 20% 25V, NONPLZD ELECTRO

RC REF PART# DESCRIPTION

ABCDE C1428 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDE C1430 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO ABCDE C1431M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP ABCDE C1432 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDE C1433M 022-08370-24A CAP, 22,000 PFD 10% 16V, CERAMIC CHIP ABCDE C1436 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDE C1440 022-08227A CAP, 0.01 MFD 5% 50V, POLY ABCDE C1442 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDE C1443 022-08312-05A CAP, 2.2 MFD 20% 50V, ELECTRO ABCDE C1444 022-08227A CAP, 0.01 MFD 5% 50V, POLY ABCDE C1445 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDE C1446 022-08312-05A CAP, 2.2 MFD 20% 50V, ELECTRO ABCDE C1447 022-08309-14A CAP, 330 MFD 20% 16V, ELECTRO ABCDE C1448 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDE C1449 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDE C2106 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY ABCDE C2107 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO ABCDE C2108 022-08310-11A CAP, 47 MFD 20% 25V, ELECTRO ABCDE C2114 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY ABCDE C2115 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY ABCDE C2116 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDE C2119 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO ABCDE C2202M 022-08352-14A CAP, 12 PFD 5% 50V, CERAMIC CHIP ABCDE C2203 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO ABCDE C2204 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO ABCDE C2205 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO ABCDE C2207M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP ABCDE C2208 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO ABCDE C2209M 022-08370-24A CAP, 22,000 PFD 10% 16V, CERAMIC CHIP ABCDE C2210M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP ABCDE C2211 022-08312-05A CAP, 2.2 MFD 20% 50V, ELECTRO ABCDE C2212 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY ABCDE C2215 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDE C2216 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO ABCDE C2217 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO ABCDE C2218 022-08312A CAP, 0.1 MFD 20% 50V, ELECTRO ABCDE C2219 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDE C2220M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP ABCDE C2221M 022-08352-24A CAP, 33 PFD 5% 50V, CERAMIC CHIP ABCDE C2225M 022-08366A CAP, 220 PFD 10% 50V, CERAMIC CHIP ABCDE C2226 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDE C2227 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDE C2237M 022-08366-08A CAP, 1,000 PFD 10% 50V, CERAMIC CHIP ABCDE C2245 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDE C2257M 022-08366-04A CAP, 470 PFD 10% 50V, CERAMIC CHIP ABCDE C2260 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO ABCDE C2261 022-08310-11A CAP, 47 MFD 20% 25V, ELECTRO ABCDE C2270 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY ABCDE C2271 022-08312-09A CAP, 22 MFD 20% 50V, ELECTRO ABCDE C2272 022-08049-16A CAP, 0.022 MFD 10% 50V, POLY ABCDE C2290 022-08309-16 CAP, 1000 MFD 20% 16V, ELECTRO ABCDE C2294M 022-08366A CAP, 220 PFD 10% 50V, CERAMIC CHIP ABCDE C2299M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP ABCDE C2901M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP ABCDE C2902M 022-08352-22A CAP, 27 PFD 5% 50V, CERAMIC CHIP ABCDE C2903M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP ABCDE C2904M 022-08366A CAP, 220 PFD 10% 50V, CERAMIC CHIP ABCDE C2905 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO ABCDE C2908 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO ABCDE C2951 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO ABCDE C3209 022-07786-17C CAP, 2200 PFD 10% 500V, CERAMIC DISC ABCDE C3211 022-08049-16A CAP, 0.022 MFD 10% 50V, POLY ABCDE C3214M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDE C3215 022-08257-08A CAP, 470 PFD 10% 50V, CERAMIC DISC

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

CM150 4-13 GA - MODULE PARTS

GA3 MODULE PARTS LIST

A 9-1996 B 9-1997 C 9-1997-01 D 9-1998 E 9-2041

NOTE: This list will enable you to determine the parts used on each Model, Chassis, or Assembly.

RC REF PART# DESCRIPTION

BD C3248 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDE C3269 022-07786-10C CAP, 470 PFD 10% 500V, CERAMIC DISC BD C3270 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDE C3271 022-07786-10C CAP, 470 PFD 10% 500V, CERAMIC DISC ABCDE C3419 022-07786C CAP, 1000 PFD 10% 500V, CERAMIC DISC ABCDE C3421 022-07786C CAP, 1000 PFD 10% 500V, CERAMIC DISC ABCDE C3422 022-08310-13A CAP, 220 MFD 20% 25V, ELECTRO ABCDE C3423 022-07786C CAP, 1000 PFD 10% 500V, CERAMIC DISC ABCDE C3428 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO ABCDE C5101M 022-08366-04A CAP, 470 PFD 10% 50V, CERAMIC CHIP ABCDE C5102M 022-08366-04A CAP, 470 PFD 10% 50V, CERAMIC CHIP ABCDE C5103M 022-08366-04A CAP, 470 PFD 10% 50V, CERAMIC CHIP ABCDE C5104 022-07523-01B CAP, 0.01 MFD +80 % & -20 % 2000V, CERAMIC DI ABCDE C5109 022-07786-10C CAP, 470 PFD 10% 500V, CERAMIC DISC ABCDE C6001M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC CHIP ABCDE C6003M 022-08366-04A CAP, 470 PFD 10% 50V, CERAMIC CHIP ABCDE C6005M 022-08366A CAP, 220 PFD 10% 50V, CERAMIC CHIP ABCDE C6006 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDE C6007M 022-08366-08A CAP, 1,000 PFD 10% 50V, CERAMIC CHIP ABCDE C6009 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY ABCDE C6010M 022-08352-19A CAP, 20 PFD 5% 50V, CERAMIC CHIP ABCDE C6011M 022-08352-19A CAP, 20 PFD 5% 50V, CERAMIC CHIP ABCDE C6012M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP ABCDE C6013 022-08309-13A CAP, 220 MFD 20% 16V, ELECTRO ABCDE C6014M 022-08352-22A CAP, 27 PFD 5% 50V, CERAMIC CHIP ABCDE C6015M 022-08352-22A CAP, 27 PFD 5% 50V, CERAMIC CHIP ABCDE C6016 022-08312-05A CAP, 2.2 MFD 20% 50V, ELECTRO ABCDE C6017 022-08049-24A CAP, 0.10 MFD 10% 50V, POLY ABCDE C6018M 022-08366-08A CAP, 1,000 PFD 10% 50V, CERAMIC CHIP ABCDE C6019M 022-08352-42A CAP, 180 PFD 5% 50V, CERAMIC CHIP ABCDE C6020 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDE C6021M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP ABCDE C6023M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDE C6024M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDE C6025M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDE C6026M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP ABCDE C6028 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDE C6029M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP ABCDE C6030 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO ABCDE C6031M 022-08366-18A CAP, 6,800 PFD 10% 50V, CERAMIC CHIP ABCDE C6032 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDE C6033M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDE C6036M 022-08366-08A CAP, 1,000 PFD 10% 50V, CERAMIC CHIP ABCDE C6037 022-08257-04A CAP, 220 PFD 10% 50V, CERAMIC DISC ABCDE C6038M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDE C6040M 022-08352-42A CAP, 180 PFD 5% 50V, CERAMIC CHIP ABCDE C6041M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDE C6042M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP ABCDE C6043M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP ABCDE C6045M 022-08366-04A CAP, 470 PFD 10% 50V, CERAMIC CHIP ABCDE C6046M 022-08366-04A CAP, 470 PFD 10% 50V, CERAMIC CHIP ABCDE C6047M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDE C6048M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDE C6049M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDE C6050M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDE C6051M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDE C6052M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDE C6053M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDE C6054M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDE C6055M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDE C6056M 022-08368-20A CAP, 10,000 PFD 10% 25V, CERAMIC CHIP ABCDE C6058M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDE C6059M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP

RC REF PART# DESCRIPTION

ABCDE C6060M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP BCDE C6061M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDE C6079M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDE C6090M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDE C6091M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDE C6092M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDE C6093M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDE C6094M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDE C6095M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC CHIP ABCDE C6096 022-08241-26A CAP, 47 PFD 5% 50V, CERAMIC DISC ABCDE C6098 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDE CR2200 224-00027A CRYSTAL, QUARTZ, 3.579 MHZ ABCDE CR2205 224-00178 RESONATOR, CERAMIC, 503 KHZ ABCDE CRT0001 078-03394-09 SOCKET, CRT ABCDE CRY6001 224-00074-02A CRYSTAL, QUARTZ, 8 MHZ ABCDE CX2105 022-08311-13 CAP, 220 MFD 20% 35V, ELECTRO ABCDE CX2109 022-08310-16 CAP, 1000 MFD 20% 25V, ELECTRO ABCDE CX2110 022-08310-13A CAP, 220 MFD 20% 25V, ELECTRO ABCDE CX3003 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO ABCDE CX3004 022-08312-08A CAP, 10 MFD 20% 50V, ELECTRO ABCDE CX3007 022-07786-10C CAP, 470 PFD 10% 500V, CERAMIC DISC BD CX3201 022-08116-07 CAP, .039 MFD 5% 630V, POLYPROP BD CX3208 022-08057-01 CAP, 4.7 MFD 20% 50V, NONPLZD ELECTRO C CX3222 022-08386-05 CAP, 560 PFD 10% 2000V, CERAMIC DISC ACE CX3229 022-08229-27 CAP, 0.013 MFD 3% 1600VDC, POLYPROP BD CX3229 022-08229-29 CAP, 0.016 MFD 3% 1600VDC, POLYPROP E CX3231 022-08386-01 CAP, 270 PFD 10% 2000V, CERAMIC DISC BD CX3231 022-08386-05 CAP, 560 PFD 10% 2000V, CERAMIC DISC C CX3231 022-08386-12 CAP, 2200 PFD 10% 2000V, CERAMIC DISC ABCDE CX3233 022-08514-11 CAP, 47 MFD 20% 160V, ELECTRO ABCDE CX3260 022-08315-05A CAP, 2.2 MFD 20% 160V, ELECTRO C CX3261 022-08231-11 CAP, 0.39 MFD 5% 200V, POLYPROP A CX3261 022-08231-12 CAP, 0.47 MFD 5% 200V, POLYPROP BDE CX3261 022-08231-13 CAP, 0.56 MFD 5% 200V, POLYPROP ABCDE CX3264 022-07786-10C CAP, 470 PFD 10% 500V, CERAMIC DISC BD CX3272 022-08312-11A CAP, 47 MFD 20% 50V, ELECTRO BD CX3273 022-07786-10C CAP, 470 PFD 10% 500V, CERAMIC DISC ABCDE CX3274 022-08309-12A CAP, 100 MFD 20% 16V, ELECTRO ABCDE CX3296 022-08317-08 CAP, 10 MFD 20% 250V, ELECTRO ABCDE CX3400 022-07431-06B CAP, 0.0047 MFD 20%, CERAMIC DISC ABCDE CX3402 022-07431-06B CAP, 0.0047 MFD 20%, CERAMIC DISC ABCDE CX3403 022-07811A CAP, 1000 PFD 10% 1000V, CERAMIC DISC ABCDE CX3404 022-07811A CAP, 1000 PFD 10% 1000V, CERAMIC DISC ABCDE CX3405 022-08444-09 CAP, 330 MFD 20% 200V, ELECTRO ABCDE CX3406 022-07811A CAP, 1000 PFD 10% 1000V, CERAMIC DISC ABCDE CX3407 022-08310-16 CAP, 1000 MFD 20% 25V, ELECTRO ABCDE CX3408 022-07786-10C CAP, 470 PFD 10% 500V, CERAMIC DISC ABCDE CX3409 022-08386-08 CAP, 1000 PFD 10% 2000V, CERAMIC DISC ABCDE CX3410 022-07786C CAP, 1000 PFD 10% 500V, CERAMIC DISC ABCDE CX3411 022-08049-18A CAP, 0.033 MFD 10% 50V, POLY ABCDE CX3412 022-07786C CAP, 1000 PFD 10% 500V, CERAMIC DISC ABCDE CX3413 022-08312-09A CAP, 22 MFD 20% 50V, ELECTRO ABCDE CX3415 022-08008-12 CAP, .01 MFD 5% 1250V, POLYPROP ABCDE CX3416 022-08310-12A CAP, 100 MFD 20% 25V, ELECTRO ABCDE CX3418 022-07786-01C CAP, 220 PFD 10% 500V, CERAMIC DISC ABCDE CX3420 022-08444-09 CAP, 330 MFD 20% 200V, ELECTRO ABCDE CX3424 022-08310-16 CAP, 1000 MFD 20% 25V, ELECTRO ABCDE CX3429 022-08309-13A CAP, 220 MFD 20% 16V, ELECTRO ABCDE CX3431 022-08310-15 CAP, 470 MFD 20% 25V, ELECTRO ABCDE CX3440 022-08312-07A CAP, 4.7 MFD 20% 50V, ELECTRO ABCDE CX3441 022-08309-13A CAP, 220 MFD 20% 16V, ELECTRO ABCDE CX6027 022-08309-15A CAP, 470 MFD 20% 16V, ELECTRO ABCDE D2202 103-00461A DIODE, FAST SWITCHING, HIGH CONDUCTANCE

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

CM150 4-14 GA - MODULE PARTS

GA3 MODULE PARTS LIST

A 9-1996 B 9-1997 C 9-1997-01 D 9-1998 E 9-2041

NOTE: This list will enable you to determine the parts used on each Model, Chassis, or Assembly.

RC REF PART# DESCRIPTION

ABCDE D2203 103-00461A DIODE, FAST SWITCHING, HIGH CONDUCTANCE ABCDE D2206 103-00461A DIODE, FAST SWITCHING, HIGH CONDUCTANCE ABCDE D2215 103-00471A DIODE, LOW VOLTAGE GENERAL, SILICON ABCDE D3410 103-00339-04A DIODE, LOW VOLTAGE GENERAL, SILICON ABCDE D3410 149-00576-01 CORE, FERRITE BEAD ABCDE D3411 103-00417-03A DIODE, LOW VOLTAGE GENERAL, SILICON ABCDE D3411 149-00576-01 CORE, FERRITE BEAD ABCDE D3412 103-00417-03A DIODE, LOW VOLTAGE GENERAL, SILICON ABCDE D6001 103-00461A DIODE, FAST SWITCHING, HIGH CONDUCTANCE ABCDE D6002 103-00461A DIODE, FAST SWITCHING, HIGH CONDUCTANCE ABCDE DL2200 223-00045 INTD CKT PKG, NTSC COMB FILTER, HYBRID ABCDE DX2101 103-00254-01 DIODE, LOW VOLTAGE GENERAL, SILICON ABCDE DX2102 103-00461A DIODE, FAST SWITCHING, HIGH CONDUCTANCE ABCDE DX2103 103-00461A DIODE, FAST SWITCHING, HIGH CONDUCTANCE ABCDE DX3005 103-00461A DIODE, FAST SWITCHING, HIGH CONDUCTANCE ABCDE DX3006 103-00344-04A DIODE, LOW VOLTAGE GENERAL BD DX3201 103-00344-06A DIODE, LOW VOLTAGE GENERAL ABCDE DX3204 103-00471A DIODE, LOW VOLTAGE GENERAL, SILICON BD DX3207 103-00305-01A DIODE, HIGH VOLTAGE GENERAL, SILICON BD DX3207 149-00454 CORE, FERRITE BEAD ABCDE DX3260 103-00284A DIODE, LOW VOLTAGE GENERAL, SILICON ABCDE DX3273 103-00339-04A DIODE, LOW VOLTAGE GENERAL, SILICON ABCDE DX3287 103-00326A DIODE, LOW VOLTAGE GENERAL, SILICON BD DX3288 103-00344-04A DIODE, LOW VOLTAGE GENERAL ABCDE DX3401 212-00172-04 RECTIFIER NTWK , BRIDGE, 600V/4A ABCDE DX3405 103-00254-01 DIODE, LOW VOLTAGE GENERAL, SILICON ABCDE DX3406 103-00344-02A DIODE, LOW VOLTAGE GENERAL ABCDE DX3407 103-00344-02A DIODE, LOW VOLTAGE GENERAL ABCDE DX3409 103-00344-02A DIODE, LOW VOLTAGE GENERAL ABCDE EX3401 038-00102 SPARK GAP, HIGH VOLTAGE, 4KV DC ABCDE FX3401 136-00114-23A FUSE, NORMAL LAG, 4 AMP 250V ABCDE FX3402 136-00148-23 FUSE, NORMAL LAG, 3 AMP 250V ABCDE FX3403 136-00148-03 FUSE, NORMAL LAG, 2 AMP 250V ABCDE IC0804 221-00598-01 IC, AUDIO POWER AMPLIFIER, 3.5W, 2 CHANNEL ABCDE IC1400 221-01127 IC, MTS STEREO DECODER/VOL.LIMITER AND ABCDE IC2001 221-01171 IC, AUDIO/VIDEO SWITCH, 2 CHAN/2 POSIT ABCDE IC2100 221-00992-01 IC, VERTICAL DEFLECTION ABCDE IC6000 126-03446-02 SHIELD, EMI, MICROPROCESSOR/ ABCDE IC6000 221-01305-01 IC, 8-BIT MICROCOMPUTER ABCDE IC6001 221-00745-04 IC, 4K BIT SERIAL EEPROM ABCDE IC6002 221-01177A IC, SYSTEM RESET ABCDE ICX2200 221-01165 IC, I2C BUS CONTROL NTSC ABCDE ICX3431 223-00028 IC PKG, HYBRID, VOLTAGE REGULATOR ABCDE ICX3441 221-00213-09 IC, 9 VOLT, 1 AMP, LINEAR, REGULATOR ABCDE ICX3442 221-00167-01A IC, VOLTAGE REGULATOR, 5V 100MA ABCDE J0002M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W ABCDE J0004M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W ABCDE J0005M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W ABCDE J0006M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W ABCDE JM0008 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W ABCDE KX3401 195-00161 RELAY, SPST, 12 VDC COIL ABCDE L1200 020-04506 COIL, RCF, FIXED, SHIELDED ABCDE L1201 020-04277-39A COIL, 10 MICROHENRY, RCF, FIXED ABCDE L1202 020-03907-12A COIL, 10 MICROHENRY, RCF, FIXED ABCDE L1203 020-04277-23A COIL, 12 MICROHENRY, RCF, FIXED ABCDE L1204 091-02053 WIRE, SOLID, BARE, 22 GA COPPER ABCDE L1205 020-04278B COIL, RCF, TUNABLE, 7.0 MM ABCDE L1206 020-04277-09A COIL, 0.82 MICROHENRY, RCF, FIXED ABCDE L1208 020-03907-25A COIL, 120 MICROHENRY, RCF, FIXED ABCDE L2203 020-04129-22 COIL, 15 MICROHENRY, RCF, FIXED ABCDE L2901 020-04129-16 COIL, 4.7 MICROHENRY, RCF, FIXED ABCDE L3407 020-04462-18A COIL, 33 MICROHENRY, RCF, FIXED ABCDE L5100 020-03907-28A COIL, 220 MICROHENRY, RCF, FIXED ABCDE L5102 149-00583-01 CORE, FERRITE BEAD

RC REF PART# DESCRIPTION

ABCDE L6000 020-03907-24A COIL, 100 MICROHENRY, RCF, FIXED ABCDE L6001 020-04129-16 COIL, 4.7 MICROHENRY, RCF, FIXED ABCDE L6002 020-04277-70A COIL, 1.8 MICROHENRY, RCF, FIXED ABCDE L6003 020-04129-08 COIL, 1 MICROHENRY, RCF, FIXED ABCDE L6004 020-04129-08 COIL, 1 MICROHENRY, RCF, FIXED ABCDE L6005 020-04129-08 COIL, 1 MICROHENRY, RCF, FIXED ABCDE L6007 020-04129-16 COIL, 4.7 MICROHENRY, RCF, FIXED BD LX3201 020-04530 COIL, CHOKE ABCDE LX3210 149-00540-01 CORE, FERRITE BD LX3262 020-04073-01 COIL, RCF, LINEARITY ACE LX3262 020-04073-03 COIL, RCF ABCDE LX3401 095-04285 TRANSFORMER, LINE CHOKE ABCDE LX3405 020-04405-48 COIL, 100 MICROHENRY, RCF, FIXED ABCDE LX3410 149-00576-01 CORE, FERRITE BEAD ABCDE Q0800 121-01310A TRANSISTOR, NPN, SILICON ABCDE Q1203 121-01310A TRANSISTOR, NPN, SILICON ABCDE Q1204 121-01310A TRANSISTOR, NPN, SILICON ABCDE Q1205 121-01261A TRANSISTOR, NPN, SILICON ABCDE Q1401 121-01310A TRANSISTOR, NPN, SILICON ABCDE Q1402 121-01311A TRANSISTOR, PNP, SILICON ABCDE Q1403 121-01310A TRANSISTOR, NPN, SILICON ABCDE Q1404 121-01311A TRANSISTOR, PNP, SILICON ABCDE Q1405 121-01310A TRANSISTOR, NPN, SILICON ABCDE Q2202 121-01311A TRANSISTOR, PNP, SILICON ABCDE Q2203 121-01311A TRANSISTOR, PNP, SILICON ABCDE Q2204 121-01311A TRANSISTOR, PNP, SILICON ABCDE Q2205 121-01311A TRANSISTOR, PNP, SILICON ABCDE Q2206 121-01310A TRANSISTOR, NPN, SILICON ABCDE Q2209 121-01311A TRANSISTOR, PNP, SILICON ABCDE Q2210 121-01311A TRANSISTOR, PNP, SILICON ABCDE Q3202 121-01310A TRANSISTOR, NPN, SILICON BD Q3203 121-01264-01A TRANSISTOR, NPN SILICON ABCDE Q3206 121-01264-01A TRANSISTOR, NPN SILICON ABCDE Q3402 121-01340A TRANSISTOR, NPN, SILICON ABCDE Q3404 121-01102A TRANSISTOR, PNP, SILICON ABCDE Q5101 121-01291-01 TRANSISTOR, NPN, SILICON ABCDE Q5102 121-01291-01 TRANSISTOR, NPN, SILICON ABCDE Q5103 121-01291-01 TRANSISTOR, NPN, SILICON ABCDE Q6001 121-01310A TRANSISTOR, NPN, SILICON ABCDE Q6002 121-01310A TRANSISTOR, NPN, SILICON BD QX3201 121-01237 TRANSISTOR, PNP, SILICON, 5A 80V ABCD QX3208 121-01383 TRANSISTOR, NPN, SILICON ABCDE QX3401 121-01348 TRANSISTOR, NPN, SILICON, 80V/1A ABCDE R0843 063-10235-60 RESISTOR, FILM, 330 OHM 5% 1/4W ABCDE R0851M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDE R0852M 063-11059-57A RESISTOR, CHIP, 2.2K OHM 5% 1/10W ABCDE R0853 063-10235-12 RESISTOR, FILM, 3.3 OHM 5% 1/4W ABCDE R0854M 063-11059-29A RESISTOR, CHIP, 150 OHM 5% 1/10W ABCDE R0861M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDE R0862M 063-11059-57A RESISTOR, CHIP, 2.2K OHM 5% 1/10W ABCDE R0863 063-10235-12 RESISTOR, FILM, 3.3 OHM 5% 1/4W ABCDE R0864M 063-11059-29A RESISTOR, CHIP, 150 OHM 5% 1/10W ABCDE R1209M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDE R1210M 063-11059-61A RESISTOR, CHIP, 3.3K OHM 5% 1/10W ABCDE R1211M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDE R1212M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDE R1213M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDE R1214M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDE R1216M 063-11059-29A RESISTOR, CHIP, 150 OHM 5% 1/10W ABCDE R1217M 063-11059-29A RESISTOR, CHIP, 150 OHM 5% 1/10W ABCDE R1218M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDE R1219M 063-11059-47A RESISTOR, CHIP, 820 OHM 5% 1/10W ABCDE R1220 063-10236-20 RESISTOR, FILM, 100K OHM 5% 1/4W ABCDE R1221M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

CM150 4-15 GA - MODULE PARTS

GA3 MODULE PARTS LIST

A 9-1996 B 9-1997 C 9-1997-01 D 9-1998 E 9-2041

NOTE: This list will enable you to determine the parts used on each Model, Chassis, or Assembly.

RC REF PART# DESCRIPTION

ABCDE R1222M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDE R1223M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W ABCDE R1224M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W ABCDE R1225M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W ABCDE R1226M 063-11059-09A RESISTOR, CHIP, 22 OHM 5% 1/10W ABCDE R1227M 063-11059-39A RESISTOR, CHIP, 390 OHM 5% 1/10W ABCDE R1228 063-10235-76 RESISTOR, FILM, 1.5K OHM 5% 1/4W ABCDE R1229M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W ABCDE R1230M 063-11059-13A RESISTOR, CHIP, 33 OHM 5% 1/10W ABCDE R1232M 063-11059-46A RESISTOR, CHIP, 750 OHM 5% 1/10W ABCDE R1233M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDE R1234M 063-11059-87A RESISTOR, CHIP, 39K OHM 5% 1/10W ABCDE R1235M 063-11059-97A RESISTOR, CHIP, 100K OHM 5% 1/10W ABCDE R1401 063-10235-48 RESISTOR, FILM, 100 OHM 5% 1/4W ABCDE R1402 063-10235-48 RESISTOR, FILM, 100 OHM 5% 1/4W ABCDE R1404M 063-11244-76A RESISTOR, CHIP, 61.9K OHM 1% 1/10W ABCDE R1405M 063-11059-63A RESISTOR, CHIP, 3.9K OHM 5% 1/10W ABCDE R1406M 063-11059-97A RESISTOR, CHIP, 100K OHM 5% 1/10W ABCDE R1407 063-10235-83 RESISTOR, FILM, 3K OHM 5% 1/4W ABCDE R1408M 063-11059-61A RESISTOR, CHIP, 3.3K OHM 5% 1/10W ABCDE R1409M 063-11060-21A RESISTOR, CHIP, 1 MEG OHM 5% 1/10W ABCDE R1421M 063-11059-71A RESISTOR, CHIP, 8.2K OHM 5% 1/10W ABCDE R1422M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDE R1423 063-10235-80 RESISTOR, FILM, 2.2K OHM 5% 1/4W ABCDE R1424 063-10235-80 RESISTOR, FILM, 2.2K OHM 5% 1/4W ABCDE R1425M 063-11060-21A RESISTOR, CHIP, 1 MEG OHM 5% 1/10W ABCDE R1440M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDE R1441M 063-11059-53A RESISTOR, CHIP, 1.5K OHM 5% 1/10W ABCDE R1442M 063-11059-46A RESISTOR, CHIP, 750 OHM 5% 1/10W ABCDE R1443M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDE R1444M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDE R1445M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDE R1446M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W ABCDE R1447M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDE R1448M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDE R1449M 063-11059-53A RESISTOR, CHIP, 1.5K OHM 5% 1/10W ABCDE R1450M 063-11059-46A RESISTOR, CHIP, 750 OHM 5% 1/10W ABCDE R1451M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDE R1452M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDE R1453M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDE R1454M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W ABCDE R1455M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDE R1456M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDE R1457M 063-11059-97A RESISTOR, CHIP, 100K OHM 5% 1/10W ABCDE R1490M 063-11059-57A RESISTOR, CHIP, 2.2K OHM 5% 1/10W ABCDE R1491M 063-11059-57A RESISTOR, CHIP, 2.2K OHM 5% 1/10W ABCDE R2107M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDE R2108M 063-11059-57A RESISTOR, CHIP, 2.2K OHM 5% 1/10W ABCDE R2109 063-10235-84 RESISTOR, FILM, 3.3K OHM 5% 1/4 W ABCDE R2111 063-10565-61 RESISTOR, FILM, 360 OHM 5% 1/2W ABCDE R2113 063-10565-61 RESISTOR, FILM, 360 OHM 5% 1/2W ABCDE R2122 063-10235-80 RESISTOR, FILM, 2.2K OHM 5% 1/4W ABCDE R2131M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDE R2133M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDE R2141M 063-11060-18A RESISTOR, CHIP, 750K OHM 5% 1/10W ABCDE R2142 063-10236-10 RESISTOR, FILM, 39K OHM 5% 1/4W ABCDE R2143M 063-11059-77A RESISTOR, CHIP, 15K OHM 5% 1/10W ABCDE R2144M 063-11059-89A RESISTOR, CHIP, 47K OHM 5% 1/10W ABCDE R2145M 063-11059-77A RESISTOR, CHIP, 15K OHM 5% 1/10W ABCDE R2146 063-10236-24 RESISTOR, FILM, 150K OHM 5% 1/4W ABCDE R2147M 063-11059-89A RESISTOR, CHIP, 47K OHM 5% 1/10W E R2150M 063-11059-37A RESISTOR, CHIP, 330 OHM 5% 1/10W ABCD R2150M 063-11059-39A RESISTOR, CHIP, 390 OHM 5% 1/10W ABCDE R2151M 063-11059-71A RESISTOR, CHIP, 8.2K OHM 5% 1/10W

RC REF PART# DESCRIPTION

ABCDE R2152M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDE R2153M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDE R2202 063-10235-24 RESISTOR, FILM, 10 OHM 5% 1/4W ABCDE R2212M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W ABCDE R2213M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDE R2214M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDE R2215M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDE R2218M 063-11059-83A RESISTOR, CHIP, 27K OHM 5% 1/10W ABCDE R2219 063-10235-48 RESISTOR, FILM, 100 OHM 5% 1/4W ABCDE R2220 063-10235-48 RESISTOR, FILM, 100 OHM 5% 1/4W ABCDE R2221M 063-11059-97A RESISTOR, CHIP, 100K OHM 5% 1/10W ABCDE R2222M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDE R2223M 063-11059-17A RESISTOR, CHIP, 47 OHM 5% 1/10W ABCDE R2224M 063-11060-13A RESISTOR, CHIP, 470K OHM 5% 1/10W ABCDE R2225M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDE R2226M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDE R2227M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W ABCDE R2228M 063-11059-39A RESISTOR, CHIP, 390 OHM 5% 1/10W ABCDE R2229M 063-11059-39A RESISTOR, CHIP, 390 OHM 5% 1/10W ABCDE R2230M 063-11059-57A RESISTOR, CHIP, 2.2K OHM 5% 1/10W ABCDE R2231 063-10235-64 RESISTOR, FILM, 470 OHM 5% 1/4W ABCDE R2233 063-10235-88 RESISTOR, FILM, 4.7K OHM 5% 1/4W ABCDE R2234M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDE R2235M 063-11059-77A RESISTOR, CHIP, 15K OHM 5% 1/10W ABCDE R2238 063-10235-66 RESISTOR, FILM, 560 OHM 5% 1/4W ABCDE R2240M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W ABCDE R2241M 063-11059-29A RESISTOR, CHIP, 150 OHM 5% 1/10W ABCDE R2242M 063-11059-29A RESISTOR, CHIP, 150 OHM 5% 1/10W ABCDE R2243M 063-11059-87A RESISTOR, CHIP, 39K OHM 5% 1/10W ABCDE R2257M 063-11059-63A RESISTOR, CHIP, 3.9K OHM 5% 1/10W ABCDE R2259M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDE R2260M 063-11059-47A RESISTOR, CHIP, 820 OHM 5% 1/10W ABCDE R2261M 063-11059-47A RESISTOR, CHIP, 820 OHM 5% 1/10W ABCDE R2262M 063-11059-47A RESISTOR, CHIP, 820 OHM 5% 1/10W ABCDE R2266 063-10235-54 RESISTOR, FILM, 180 OHM 5% 1/4W ABCDE R2270M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDE R2271M 063-11059-83A RESISTOR, CHIP, 27K OHM 5% 1/10W ABCDE R2272 063-10235-96 RESISTOR, FILM, 10K OHM 5% 1/4W BCD R2273 063-10236-01 RESISTOR, FILM, 16K OHM 5% 1/4W AE R2273 063-10236-02 RESISTOR, FILM, 18K OHM 5% 1/4W ABCDE R2274 063-10235-48 RESISTOR, FILM, 100 OHM 5% 1/4W ABCDE R2275M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDE R2276 063-10235-64 RESISTOR, FILM, 470 OHM 5% 1/4W ABCDE R2277 063-10243-74 RESISTOR, FILM, 1.2K OHM 5% 1/2W ABCDE R2279M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDE R2282M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W C R2283M 063-11059-47A RESISTOR, CHIP, 820 OHM 5% 1/10W ABDE R2283M 063-11059-53A RESISTOR, CHIP, 1.5K OHM 5% 1/10W C R2284M 063-11059-47A RESISTOR, CHIP, 820 OHM 5% 1/10W ABDE R2284M 063-11059-53A RESISTOR, CHIP, 1.5K OHM 5% 1/10W C R2285M 063-11059-47A RESISTOR, CHIP, 820 OHM 5% 1/10W ABDE R2285M 063-11059-53A RESISTOR, CHIP, 1.5K OHM 5% 1/10W ABCDE R2290 063-10236 RESISTOR, FILM, 15K OHM 5% 1/4W ABCDE R2291M 063-11059-89A RESISTOR, CHIP, 47K OHM 5% 1/10W ABCDE R2292M 063-11059-25A RESISTOR, CHIP, 100 OHM 5% 1/10W ABCDE R2901 063-10235-45 RESISTOR, FILM, 75 OHM 5% 1/4W ABCDE R2902 063-10235-40 RESISTOR, FILM, 47 OHM 5% 1/4W ABCDE R2903 063-10235-45 RESISTOR, FILM, 75 OHM 5% 1/4W ABCDE R2904 063-10235-45 RESISTOR, FILM, 75 OHM 5% 1/4W ABCDE R2905 063-10235-83 RESISTOR, FILM, 3K OHM 5% 1/4W ABCDE R2906 063-10235-40 RESISTOR, FILM, 47 OHM 5% 1/4W ABCDE R2907M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W ABCDE R2909M 063-11059-57A RESISTOR, CHIP, 2.2K OHM 5% 1/10W ABCDE R2910 091-02053 WIRE, SOLID, BARE, 22 GA COPPER

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

CM150 4-16 GA - MODULE PARTS

GA3 MODULE PARTS LIST

A 9-1996 B 9-1997 C 9-1997-01 D 9-1998 E 9-2041

NOTE: This list will enable you to determine the parts used on each Model, Chassis, or Assembly.

RC REF PART# DESCRIPTION

ABCDE R2914 063-10235-48 RESISTOR, FILM, 100 OHM 5% 1/4W ABCDE R2916 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W ABCDE R2920 063-10235-96 RESISTOR, FILM, 10K OHM 5% 1/4W BD R3201 063-10235-82 RESISTOR, FILM, 2.7K OHM 5% 1/4W BD R3203 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W BD R3212 063-10236-28 RESISTOR, FILM, 220K OHM 5% 1/4W BD R3223M 063-11059-71A RESISTOR, CHIP, 8.2K OHM 5% 1/10W ABCDE R3225 063-11087-66 RESISTOR, FILM, 560 OHM 5% 1/2W ABCDE R3226 063-11087-66 RESISTOR, FILM, 560 OHM 5% 1/2W BD R3243 063-10235-58 RESISTOR, FILM, 270 OHM 5% 1/4W BD R3247 063-10235-96 RESISTOR, FILM, 10K OHM 5% 1/4W BD R3248 063-10235-84 RESISTOR, FILM, 3.3K OHM 5% 1/4 W BD R3249M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDE R3254 063-10235-64 RESISTOR, FILM, 470 OHM 5% 1/4W ABCDE R3255M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDE R3256M 063-11059-29A RESISTOR, CHIP, 150 OHM 5% 1/10W ABCDE R3421 063-10235-80 RESISTOR, FILM, 2.2K OHM 5% 1/4W ABCDE R3422M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDE R5101M 063-11059-17A RESISTOR, CHIP, 47 OHM 5% 1/10W ABCDE R5102M 063-11059-17A RESISTOR, CHIP, 47 OHM 5% 1/10W ABCDE R5103M 063-11059-17A RESISTOR, CHIP, 47 OHM 5% 1/10W ABCDE R5104M 063-11059-31A RESISTOR, CHIP, 180 OHM 5% 1/10W ABCDE R5105M 063-11059-31A RESISTOR, CHIP, 180 OHM 5% 1/10W ABCDE R5106M 063-11059-31A RESISTOR, CHIP, 180 OHM 5% 1/10W ABCDE R5107M 063-11059-46A RESISTOR, CHIP, 750 OHM 5% 1/10W ABCDE R5108M 063-11059-46A RESISTOR, CHIP, 750 OHM 5% 1/10W ABCDE R5109M 063-11059-46A RESISTOR, CHIP, 750 OHM 5% 1/10W ABCDE R5113M 063-11059-09A RESISTOR, CHIP, 22 OHM 5% 1/10W ABCDE R5114M 063-11059-09A RESISTOR, CHIP, 22 OHM 5% 1/10W ABCDE R5115M 063-11059-09A RESISTOR, CHIP, 22 OHM 5% 1/10W ABCDE R5116 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W ABCDE R5117 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W ABCDE R5118 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W ABCDE R5119 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W ABCDE R5120 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W ABCDE R5121 063-10244-28 RESISTOR, FILM, 220K OHM 5% 1/2W ABCDE R5122 063-10243-72 RESISTOR, FILM, 1K OHM 5% 1/2W ABCDE R5123 063-10243-80 RESISTOR, FILM, 2.2K OHM 5% 1/2W ABCDE R6001M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDE R6002M 063-11059-31A RESISTOR, CHIP, 180 OHM 5% 1/10W ABCDE R6003M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDE R6004M 063-11059-89A RESISTOR, CHIP, 47K OHM 5% 1/10W ABCDE R6005M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDE R6006M 063-11059-29A RESISTOR, CHIP, 150 OHM 5% 1/10W ABCDE R6008M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDE R6012M 063-11059-89A RESISTOR, CHIP, 47K OHM 5% 1/10W ABCDE R6013 063-10235-88 RESISTOR, FILM, 4.7K OHM 5% 1/4W ABCDE R6015 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W ABCDE R6016 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W ABCDE R6026 063-10235-96 RESISTOR, FILM, 10K OHM 5% 1/4W ABCDE R6027 063-10235-80 RESISTOR, FILM, 2.2K OHM 5% 1/4W ABCDE R6030 091-02053 WIRE, SOLID, BARE, 22 GA COPPER ABCDE R6031M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDE R6032M 063-11059-77A RESISTOR, CHIP, 15K OHM 5% 1/10W ABCDE R6033M 063-11059A RESISTOR, CHIP, 0 OHM 5% 1/10W ABCDE R6034M 063-11060-21A RESISTOR, CHIP, 1 MEG OHM 5% 1/10W ABCDE R6035M 063-11060-21A RESISTOR, CHIP, 1 MEG OHM 5% 1/10W ABCDE R6037M 063-11059-83A RESISTOR, CHIP, 27K OHM 5% 1/10W ABCDE R6039M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDE R6041M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDE R6042M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDE R6043M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDE R6044M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDE R6045M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W

RC REF PART# DESCRIPTION

ABCDE R6046M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDE R6047M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDE R6048M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDE R6049M 063-11059-33A RESISTOR, CHIP, 220 OHM 5% 1/10W ABCDE R6050 063-10235-56 RESISTOR, FILM, 220 OHM 5% 1/4W ABCDE R6053M 063-11059-53A RESISTOR, CHIP, 1.5K OHM 5% 1/10W ABCDE R6058M 063-11059-87A RESISTOR, CHIP, 39K OHM 5% 1/10W ABCDE R6059M 063-11059-71A RESISTOR, CHIP, 8.2K OHM 5% 1/10W ABCDE R6061M 063-11059-56A RESISTOR, CHIP, 2K OHM 5% 1/10W ABCDE R6069M 063-11060-13A RESISTOR, CHIP, 470K OHM 5% 1/10W ABCDE R6070M 063-11060-13A RESISTOR, CHIP, 470K OHM 5% 1/10W ABCDE R6072M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDE R6080M 063-11060-18A RESISTOR, CHIP, 750K OHM 5% 1/10W ABCDE R6090M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDE R6091M 063-11059-65A RESISTOR, CHIP, 4.7K OHM 5% 1/10W ABCDE R6092M 063-11059-73A RESISTOR, CHIP, 10K OHM 5% 1/10W ABCDE R6093 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W ABCDE R6094M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDE R6095 063-10235-88 RESISTOR, FILM, 4.7K OHM 5% 1/4W ABCDE R6096 063-10235-88 RESISTOR, FILM, 4.7K OHM 5% 1/4W ABCDE R6097 063-10235-88 RESISTOR, FILM, 4.7K OHM 5% 1/4W ABCDE R6098M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDE R6099M 063-11059-49A RESISTOR, CHIP, 1K OHM 5% 1/10W ABCDE RX2110 063-10235-10 RESISTOR, FILM, 2.7 OHM 5% 1/4W E RX2115 063-10565-04 RESISTOR, FILM, 1.5 OHM 5% 1/2W BD RX2115 063-10565-06 RESISTOR, FILM, 1.8 OHM 5% 1/2W AC RX2115 063-11110-04 RESISTOR, FILM, 1.5 OHM 5% 1/2W E RX2126 063-10565-04 RESISTOR, FILM, 1.5 OHM 5% 1/2W BD RX2126 063-10565-06 RESISTOR, FILM, 1.8 OHM 5% 1/2W AC RX2126 063-11110-04 RESISTOR, FILM, 1.5 OHM 5% 1/2W ABCDE RX2278 063-10243-96 RESISTOR, FILM, 10K OHM 5% 1/2W ABCDE RX3008 063-10936-37 RESISTOR, FILM, 2.21K OHM 1% 1/4W ABCDE RX3009 063-10236-20 RESISTOR, FILM, 100K OHM 5% 1/4W ABCDE RX3010 063-10235-48 RESISTOR, FILM, 100 OHM 5% 1/4W ABCDE RX3015 063-10236-16 RESISTOR, FILM, 68K OHM 5% 1/4W ABCDE RX3016 063-10936-72 RESISTOR, FILM, 4.32K OHM 1% 1/4W ABCDE RX3022 063-10936-72 RESISTOR, FILM, 4.32K OHM 1% 1/4W BD RX3202 063-10235-72 RESISTOR, FILM, 1K OHM 5% 1/4W ABCDE RX3204 063-10235-88 RESISTOR, FILM, 4.7K OHM 5% 1/4W ABCDE RX3205 063-10565 RESISTOR, FILM, 1 OHM 5% 1/2W C RX3237 063-10442-26A RESISTOR, WIREWOUND, 1.2 OHM 5% 5W ABD RX3237 063-10442-28A RESISTOR, WIREWOUND, 1.5 OHM 5% 5W E RX3237 063-10442-35A RESISTOR, WIREWOUND, 3 OHM 5% 5W ABCDE RX3242 063-11214-16 RESISTOR, FILM, 0.51 OHM 5% 1/2W ABCD RX3261 063-10460-38A RESISTOR, WIREWOUND, 3.9 OHMS 10% 10W E RX3261 063-10460-44A RESISTOR, WIREWOUND, 6.8 OHM 10% 10W ABCDE RX3263 063-10244-04 RESISTOR, FILM, 22K OHM 5% 1/2W ABCDE RX3264 063-10832-69B RESISTOR, FILM, 750 OHM 5% 1W ABCDE RX3277 063-10565-10 RESISTOR, FILM, 2.7 OHM 5% 1/2W ABD RX3299 063-10565-28C RESISTOR, FILM, 15 OHM 5% 1/2W B RX3299 063-10565-38C RESISTOR, FILM, 39 OHM 5% 1/2 W ABCDE RX3400 063-11264-01 RESISTOR, CARBON COMPOSITION, 5.6M OHM 20%

ABCDE RX3401 063-10444-20A RESISTOR, WIREWOUND, 0.68 OHM 10% 5W ABCDE RX3403 063-10442-04A RESISTOR, WIREWOUND, 0.15 OHM 5% 5 WATT ABCDE RX3404 063-11088-26 RESISTOR, FILM, 180K OHM 5% 1/2W ABCDE RX3406 063-10235-40 RESISTOR, FILM, 47 OHM 5% 1/4W ABCDE RX3407 063-11156-40B RESISTOR, FILM, 47 OHM 5% 1W ABCDE RX3408 063-11156-32B RESISTOR, FILM, 22 OHM 5% 1W ABCDE RX3409 063-11110-16 RESISTOR, FILM, 4.7 OHM 5% 1/2W ABCDE RX3411 063-10837B RESISTOR, FILM, 15K OHM 5% 2W ABCDE RX3416 063-11160-56B RESISTOR, FILM, 220 OHM 5% 2W ABCDE RX3420 063-10442-40A RESISTOR, WIREWOUND, 4.7 OHM 5% 5W ABCDE RX3424 063-11164-08B RESISTOR, FILM, 2.2 OHM 5% 3W

1/2W

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

CM150 4-17 GA - MODULE PARTS

GA3 MODULE PARTS LIST

A 9-1996 B 9-1997 C 9-1997-01 D 9-1998 E 9-2041

NOTE: This list will enable you to determine the parts used on each Model, Chassis, or Assembly.

RC REF PART# DESCRIPTION

ABCDE RX3428 063-10559-24 RESISTOR, FILM, 10 OHM 5% 1/4W ABCDE RX3431 063-10244-26 RESISTOR, FILM, 180K OHM 5% 1/2W ABCDE RX5126 063-10836-98B RESISTOR, FILM, 12K OHM 5% 2W ABCDE RX5127 063-10836-98B RESISTOR, FILM, 12K OHM 5% 2W ABCDE RX5128 063-10836-98B RESISTOR, FILM, 12K OHM 5% 2W ABCDE THX3415 063-10710A RESISTOR, THERMISTOR ABCDE TU6000 175-02721 TUNER, VARACTOR, 181 CHANNEL, SINGLE IC, WORLD

ABCDE TX3204 095-04372-01 SWEEP XFMR, COLOR FINAL, MINI ABCDE TX3205 095-04477 TRANSFORMER, HORIZONTAL DRIVER ABCDE TX3401 095-04549 TRANSFORMER, CHOPPER ABCDE U1200 224-00139-01A FILTER, 4.5 MHZ CERAMIC BANDPASS ABCDE U1201 224-00160 FILTER, SURFACE ACOUSTIC WAVE ABCDE U1202 224-00023A CERAMIC FILTER , 4.5 MHZ TRAP BD W3200 091-02053 WIRE, SOLID, BARE, 22GA COPPER ACE W3201 091-02053 WIRE, SOLID, BARE, 22GA COPPER ACE W3202 091-02053 WIRE, SOLID, BARE, 22GA COPPER ACE W3203 091-02053 WIRE, SOLID, BARE, 22GA COPPER ABCDE ZD1401 103-00279-18A DIODE, ZENER, 9.1V 0.5W ABCDE ZD1402 103-00279-18A DIODE, ZENER, 9.1V 0.5W ABCDE ZD1403 103-00279-18A DIODE, ZENER, 9.1V 0.5W ABCDE ZD1404 103-00279-18A DIODE, ZENER, 9.1V 0.5W ABCDE ZD2901 103-00279-18A DIODE, ZENER, 9.1V 0.5W ABCDE ZD2902 103-00279-10A DIODE, ZENER, 5.1V 0.5W ABCDE ZD2903 103-00279-18A DIODE, ZENER, 9.1V 0.5W ABCDE ZD6001 103-00279-36A DIODE, ZENER, 33V 0.5W ABCDE ZDX3004 103-00472A DIODE, ZENER, 12V 0.5W ABCDE ZDX3401 103-00279-10A DIODE, ZENER, 5.1V 0.5W

STAN

RC REF PART# DESCRIPTION

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

CM150 4-18 GA - MODULE PARTS

Zenith A19A02D, A19A02D74, A19A02D4, A19A02D8, A19A02D7 Parts list

Specifications and Main Features

Frequently Asked Questions

User Manual

MODEL PARTS

GA-1 MODELS

GA-2 MODELS

GA-3 MODELS

GA1 MODULE PARTS

GA2 MODULE PARTS

GA3 MODULE PARTS
