Zebra ZC11-0000000EM00 Product Data Sheet

SPECIFICATION SHEET

ZC100 CARD PRINTER

ZC100 Card Printer

NEXT GENERATION SIMPLICITY AND SECURITY IN A ‘FIT EVERYWHERE’ DESIGN

Whether you need to print single-sided employee identity badges or membership and event guest cards, card printing is a crucial
aspect of your business. Deployment flexibility and the time it takes to print and manage your card printing solutions all have an
impact on your business — from your brand image to staff productivity, overall operational efficiency and operating costs. Now,
there’s a new kind of card printer designed to address it all — the ZC100. You get groundbreaking simple operation and the slimmest
fit-everywhere design, along with a toolbox of additional capabilities that make the ZC100 even easier to integrate, use and manage.
The ZC100 — when only the best single-sided card printer will do.

ELEGANTLY ENGINEERED FOR
GAMECHANGING SIMPLICITY

Painless plug-and-play deployment

The ZC100 is designed to work right
out of the box. There’s no time-consuming
complicated set-up — just plug it in and
start reaping the benefits the day your
printer arrives.

A new ingenious card feeder handles
varying card thickness on-the-fly

The card feeder instantly adjusts to the
thickness of each card — no more adjusting
for dierent card stocks.

The most intuitive LEDs

With our well-tested intuitive icons, a quick
glance is all it will take for your users to see
the status of the ZC100.

Innovative new driver with
a graphical user interface

The intuitive interface in the newly-designed
driver makes it easier than ever to print cards.
Settings are grouped logically into tabs
where they are easily accessible with a
click. A visual display of your card allows
you to instantly see how your card looks
and how setting changes impact card
design — eliminating the time and cost to
repeatedly print test cards.

Revolutionary new hopper design

The completely re-designed hopper makes
loading and unloading cards easier than ever.
With the saloon-style output doors, there’s
nothing to open — just grab one card or the
whole stack of cards. And the input and output
hoppers have the same capacity, reducing the
need to refill and empty the hoppers.

Fool-proof ribbon changing

Changing a ribbon has never been so simple
and uncomplicated — no instructions required.
Unlock and open the newly designed ribbon
door latch in one motion. The unique door­handle style grip leaves no question about how
to remove or insert the ribbon. The snug-fit
design has no play or adjacent open areas, so
there’s never a question about whether the
ribbon is installed correctly and in the proper
place. And with embedded smartchips, you
always know when to change the ribbon.

Eortless manual card feed

Manually feeding a card can be complicated
— we made it simple with a lightpipe that
guides the user through the manual feeding
process, the same way that automatic teller
machines guide users through their interaction.

We speak your language

Workers can interact with the ZC100 in their
native tongue with driver support for multiple
languages — English, Italian, Spanish,
Portuguese (Brazilian), German, Polish,
Russian, Simplified Chinese and Arabic.

GROUNDBREAKING ‘FITS
EVERYWHERE’ DESIGN

Good looks that fit in anywhere

Even though the ZC100 is built for business, it
has the consumer good looks required to fit in
customer facing areas, from the retail store to
the hospital admission desk.

Sized to fit wherever you need printing

Your printer shouldn’t dictate where you
can issue cards — it should fit wherever
card printing is needed. From the minimal
footprint and the slimmest profile to the
lowest clearance in this printer class, the
ZC100 was designed to fit in the most
possible places — including under a
counter or shelf.

All the connectivity options you need

Connect to one computer through the
onboard USB to create a standalone printing
station. Or, add optional Ethernet or Wi-Fi
to give everyone who needs card printing
instant access, maximizing printer usage.
And improve deployment flexibility with Wi-Fi
— the time and cost to run network cabling to
your printers is eliminated.

Printer cover lock

The printer cover lock prevents the thef t of
card stock, providing the security required
to install in public-facing areas.

SPECIFICATION SHEET

ZC100 CARD PRINTER

ADVANCED SECURITY

Printer and host authentication

Advanced security features enable
printer-to-host authentication to prevent
printing from unauthorized applications
or devices.

AES data encryption

Government-grade encryption protects
the most sensitive data during printing,
such as account numbers.

FAST AND FLEXIBLE PRINTING

Fast single-sided color and
monochrome printing

We took a good thing and made it better.
The ZC100 prints up to 30% faster in
monochrome and 15% faster in color than
its predecessor, Zebra’s ZXP Series 1
card printers.

Basic encoding options

Whether you are printing employee
badges, ID cards, season passes and
membership cards or credit and debit
cards, you can choose the encoding
option of your choice. Add a ‘swipe-and­go’ magnetic stripe when you print cards.
Or use the ZIP Pocket with our new
Software Development Kits (SDKs) to
easily add a third party contactless
encoder to create ‘pass through’
contactless cards.

BOOST VALUE WITH NEW CAPABILITIES
AND THE RIGHT SUPPORT

Get unmatched value with
Print DNA — only from Zebra

The printer hardware is just the star t of
what you need to maximize the value of
your printers. That’s why we created Print
DNA — because what’s inside your printer
matters. The Print DNA family of solutions
brings unmatched ease of use, ease of
integration and security to card printing,
streamlining your business processes,
improving operational eciency and
reducing development and deployment
time and cost.

Protect your investment with
Zebra’s superior support services

No matter what level of suppor t you need,
there is a Zebra suppor t service that is just
right for your business. With Zebra OneCare,
no matter what happens to your printer, it’s
covered. If you just need access to technical
support, choose Zebra’s Technical Software
and Support (TSS). And if you want help
setting up and configuring the hundreds
of settings on local and remote ZC100
printers, our Install & Configuration
Assistance (ICA) Select program provides
the support you need.

The ZC100 is ideal in
many applications,
including:

Retail/Hospitality

• Membership cards

• Events and
season passes

• Guest and
passenger cards

• Food safety labeling

Identification

• Employee badges

• Visitor badges

• K-12 identificat ion and
facility access

STEP UP TO THE NEXT GENERATION IN

CARD PRINTING WITH THE ZC100

FOR MORE INFORMATION, VISIT WWW.ZEBRA.COM/ZC100 OR ACCESS OUR

GLOBAL CONTACT DIRECTORY AT WWW.ZEBRA.COM/CONTACT

SPECIFICATION SHEET

ZC100 CARD PRINTER

ZC100 Card Printer Specifications

PRINTER NAME

ZC100

STANDARD FEATURES

• 300 dpi ( 11.8 dots/mm) print resolution

• 2 GB flash memory

• Image size: 1006 x 6 40 pixels

• Auto calibration of ribbon

• USB 2.0 connect ivity

• 100 card capacity auto-adjusting input hopper (30 mil)

• 100 card capacity output hopper (30 mil)

• Manual card feeding capability with LED bezel

• 3 Tricolor printer status indicator lights

• Kensington® secure lock slot

• Printer host authentication and data encryption

• Print Touch NFC tag and Quick Help QR code for online printer
help and documentation access

• Two-year unlimited warranty on printer and printhead

PRINTING SPECIFICATIONS

• Dye- sublimation thermal transfer direct to card print method

• Full-color or monochrome printing

• Single-sided printing

• Edge-to-edge print ing on standard CR-80 media

Printing throughput (cards per hour) based on batch printing wit h USB
connec tiv ity. Times may vary depending on the computer configuration.

Single-Sided
YMCKO: 150 cph
Monochrome: 700 cph

MEDIA SPECIFICATIONS

Supplies Specifications:

NOTE: The ZC100 printer is designed to work only with Zebra
genuine ribbons. Ribbons are included in a simple-to-load cartridge.

Ribbon Description Cartridge Image Count

YMCKO* 200
½ YMCKO* 40 0
Black Monochrome* 2000
Black Monochrome 1500
White Monochrome* 1500
Red Monochrome 1500
Blue Monochrome 1500
Gold Monochrome 150 0
Silver Monochrome 1500

Ribbon availabilit y may vary by region.

• *Zebra intelligent technology automatically detects

and authenticates ribbon

• Cleaning roller is included with each ribbon

• Two available cleaning kit options: your choice of two (2) or

five (5) isopropyl alcohol cleaning cards (1,000 images/card)

Card Compatibility:

NOTE: For optimum print quality and printer performance,
use of Genuine Zebra supplies is recommended.

• Card Thickness: 10-40 mil

• Card Size: CR80 ISO 7810 ID-1 format, C R79

• Card Material: PVC and PVC composi te

• Adhesive back and writable back cards

• Spot color or monochrome printing only on < 20 mil

thick cards and CR79 cards

OPERATING CHARACTERISTICS

Operating Temperature:
59º F to 95º F/15º C to 35º C

Storage Temperature:
23º F to 158º F/-5º C to 70 º C

Environmental

Electrical

Operating Humidity: 20% to 80% non-condensing

Storage Humidity: 20% to 90% non-condensing

Media Storage:
— Temperature: 41º F to 77º F/5º C to 25º C
— Humidity : 35% to 65% non-condensing

• Auto-swi tching single -phase AC power

• Operating range: 90 -132VAC and
190-264VAC R MS

• Frequency range: 47-63 Hz

• FCC Class A

PHYSICAL CHARACTERISTICS

Dimensions

Weight

10.2 in. H x 6.2 in. W x 15.1 in. D

258 mm H x 157 mm W x 383 mm D

8.6 lbs (3.9 kg)

COMMUNICATIONS AND INTERFACE CAPABILITIES

USB 2.0 — Standard
Built-in 10/100 Ethernet — Optional

802.11ac with MFi — Optional

ENCODING OPTIONS AND SPECIFICATIONS

• Magnetic stripe encoder — ISO 7811 (new and pre-encoded; tracks 1,
2, and 3; high and low coerciv ity; stripe down; 30 mil cards only) *

• Third party contactless encoder integration kit *

*Field upgradeable options

PRINTER DRIVERS

Windows Ser ver® 2003 (32 bit)

Windows Ser ver 2008 (32 and 64 bit),

Windows 7 (32 bi t and 64 bit)

Windows 8 and Win 8 Pro (32 bit and 64 bit
compatible)

Windows Ser ver 2012 (64 bit)

Microsoft
Windows
Certified

Linux Ubuntu

Apple iOS 10.2

Please see w ww.zebra.com for an up -to-date listing of
supported systems.

Windows 10 (32 bit and 6 4 bit)

Windows drivers include:

• Color coded printer status indicators for
the operator

• Black panel extraction and controls for
specialty ribbon panels with image prev iew

• Configuration utility to limit access by
operators to change image quality and
printer settings

• Advanced printer configuration, security
settings and diagnostics capabilities

Continued on back

  3

SPECIFICATION SHEET

ZC100 CARD PRINTER

ZC100 Card Printer Specifications (continued)

ADDITIONAL OPTIONAL FEATURES

Lockable enclosure (field upgradeable option)

PRINT DNA

Multiplatform Software Development Kit (SDK)

Windows C#/.Net and Java Printer Software Development Kit (SDK)

• One SDK download support s Android, Java and Windows
environments

• Easily build card-printing apps with complete control over print
functionality from Windows, Linux, Mac OS and Android environments

• Enable card printing from Android mobile devices

• Incorporate encryption and host authentication

• Includes documentation and source
code examples

CardStudio

Included with the printer, this simple-to-learn and feature-rich card
design soft ware that makes it easy to design loyalt y cards, gif t cards,
ID cards and more.

Print Touch

With a single tap, you can use Android- based mobile devices to access
how-to and troubleshooting information to help keep printers up,
running and available.

About Print DNA . Print DNA propels your Zebra Link-OS for Card
printers into a class of their own, providing Zebra- only soft ware tools
that make life easier for everyone who touches your printers, from
printing to printer management and application development.

Features are subject to availability. Specifications are subject to
change without notice.

NA and Corporate Headquarters

[phone]
[e-mail]

©2018 ZIH Corp an d/or it s affilia tes. All rights reserved. Zebra and the s tylized Zebra head are t rademarks of ZIH Cor p, registered i n many jurisdictions
worldwide. All other trademarks are the property of their respective owners. Part number: SS-ZC100 03/07/2018

Asia-Pacific Headquarters

[phone]
[e-mail]

EMEA Headquarters

zebra.com/locations
[e-mail]

Latin America Headquarters

[phone]
[e-mail]
