XR Series, C API

Programmer Reference Guide

XR Series RFID Readers C API Programmer Reference Guide

72E-73028-02

Revision A

July 2006

No part of this publication may be reproduced or used in any form, or by any electrical or mechanical means, without permission in writing from Symbol. This includes electronic or mechanical means, such as photocopying, recording, or information storage and retrieval systems. The material in this manual is subject to change without notice.

The software is provided strictly on an “as is” basis. All software, including firmware, furnished to the user is on a licensed basis. Symbol grants to the user a non-transferable and non-exclusive license to use each software or firmware program delivered hereunder (licensed program). Except as noted below, such license may not be assigned, sublicensed, or otherwise transferred by the user without prior written consent of Symbol. No right to copy a licensed program in whole or in part is granted, except as permitted under copyright law. The user shall not modify, merge, or incorporate any form or portion of a licensed program with other program material, create a derivative work from a licensed program, or use a licensed program in a network without written permission from Symbol. The user agrees to maintain Symbol’s copyright notice on the licensed programs delivered hereunder, and to include the same on any authorized copies it makes, in whole or in part. The user agrees not to decompile, disassemble, decode, or reverse engineer any licensed program delivered to the user or any portion thereof.

Symbol reserves the right to make changes to any software or product to improve reliability, function, or design.

Symbol does not assume any product liability arising out of, or in connection with, the application or use of any product, circuit, or application described herein.

No license is granted, either expressly or by implication, estoppel, or otherwise under any Symbol Technologies, Inc., intellectual property rights. An implied license only exists for equipment, circuits, and subsystems contained in Symbol products.

Symbol, Spectrum One, and Spectrum24 are registered trademarks of Symbol Technologies, Inc. Bluetooth is a registered trademark of Bluetooth SIG. Microsoft, Windows and ActiveSync are either registered trademarks or trademarks of Microsoft Corporation. Other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies and are hereby acknowledged.

Symbol Technologies, Inc. One Symbol Plaza Holtsville, New York 11742-1300

http://www.symbol.com

Patents

This product is covered by one or more of the patents listed on the webbiest: www.symbol.com/patents

Revision History

Changes to the original manual are listed below:

Change Date Description

-01 Rev A June 2005 Initial Release

-02 Rev A July 2006 Added Gen 2 update

Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii

About This Guide

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi

Chapter Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi

Notational Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi

Related Documents and Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii

Service Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii

Chapter 1. Getting Started

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Chapter 2. Structures and Definitions

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Chapter 3. Initialization

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

RFID_Open . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-5

RFID_Close . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-8

XR400 Reader C API Programmer Reference Guidevi

Chapter 4. Device Capabilities Discovery

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3

RFID_GetCapList. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-4

RFID_GetCapInfo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5

RFID_GetCapCurrValue . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-7

RFID_GetCapDfltValue . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-10

RFID_SetCapCurrValue. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-11

RFID_SetCapDflts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-12

RFID_SetCapDfltValue . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-13

Chapter 5. Reading and Writing Tags

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

RFID_GetTagID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-4

RFID_GetTagMask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-5

RFID_SetTagMask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-6

RFID_KillTag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7

RFID_LockTag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-9

RFID_ProgramTags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-11

RFID_EraseTag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-13

RFID_ReadTagInventory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-14

GPIO Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-15

Extended Version of Data Structures and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-16

Error in Tag Reading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-18

Chapter 6. General Helper Functions

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

RFID_GetCommandStatusText. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-4

RFID_GetStats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-5

Appendix A. RFID API Capabilities

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3

RFID_INFCAP_SUPPORTEDCAPS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-4

RFID_DEVCAP_IP_NAME. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-5

RFID_DEVCAP_IP_PORT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-6

RFID_DEVCAP_ANTENNA_SEQUENCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-8

RFID_READCAP_RF_ATTENUATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-10

RFID_READCAP_EVENTTAGPTR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-11

RFID_READCAP_EVENTNAME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-12

RFID_READCAP_EVENT_ALLTAGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-16

RFID_READCAP_METHOD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-17

RFID_READCAP_OUTLOOP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-18

RFID_READCAP_INLOOP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-20

RFID_READCAP_READMODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-21

RFID_WRITECAP_RF_ATTENUATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-22

RFID_WRITECAP_TAGTYPE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-23

RFID_TAGCAP_LOCKCODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-24

RFID_TAGCAP_SUPPORTED_TYPES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-25

RFID_TAGCAP_ENABLED_TYPES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-26

RFID_TAGCAP_C0_SINGULATION_FIELD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-26

RFID_WRITECAP_ANTENNA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-27

RFID_TAGCAP_G2_KILL_PASSWORD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-27

RFID_TAGCAP_G2_ACCESS_PASSWORD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-28

RFID_DEVCAP_VALID_ANTENNA_LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-28

RFID_DEVCAP_ANTENNA_GROUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-29

RFID_TAGCAP_MASK_BITS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-30

RFID_TAGCAP_MASK_NUMBITS_TOMATCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-30

RFID_TAGCAP_MASK_STARTPOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-31

Contents vii

Appendix B. Return Values

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3

Appendix C. Sample Application

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-3

Index

Tell Us What You Think

XR400 Reader C API Programmer Reference Guideviii

About This Guide

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi

Chapter Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi

Notational Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi

Related Documents and Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii

Service Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii

XR400 Reader C API Programmer Reference Guidex

Introduction

This guide provides information on using C API to develop applications to read and write tags on an XR Series RFID reader. The C API provides an interface with the XR Series readers using the parameters defined in the XR Series Interface Control Guide, p/n 72E-71803-xx.

Chapter Descriptions

Topics covered in this guide are as follows:

• Chapter 1, Getting Started provides an overview of the RFID C API.

• Chapter 3, Initialization describes commands associated with device initialization and discovery.

• Chapter 4, Device Capabilities Discovery describes how to discover and change the RFID API capabilities.

• Chapter 5, Reading and Writing Tags describes tag reading and writing functions.

• Chapter 6, General Helper Functions includes commands for retrieving API status codes and module statistics.

• Appendix A, RFID API Capabilities provides capabilities information to use for reference when calling functions.

• Appendix B, Return Values describes the return values that the C API uses when responding to function calls.

• Appendix C, Sample Application provides a sample application for finding and opening a reader, and reading and displaying tags.

Notational Conventions

The following conventions are used in this document:

• Italics are used to highlight the following:

• Chapters and sections in this and related documents

• Dialog box, window and screen names

• Drop-down list and list box names

• Check box and radio button names

• Icons on a screen.

• Bold text is used to highlight the following:

• Key names on a keypad

• Button names on a screen.

• Bullets (•) indicate:

• Action items

• Lists of alternatives

• Lists of required steps that are not necessarily sequential.

• Sequential lists (e.g., those that describe step-by-step procedures) appear as numbered lists.

XR400 Reader C API Programmer Reference Guidexii

Service Information

For service information, warranty information or technical assistance contact or call the Symbol Support Center. Contact information is provided on the Symbol contact web site go to:

If the problem cannot be solved over the phone, the equipment may need to be returned for servicing. If that is necessary, specific directions will be provided.

Symbol Technologies is not responsible for any damages incurred during shipment if the approved shipping container is not used. Shipping the units improperly can possibly void the warranty.

http://www.symbol.com/contactsupport

If the Symbol product was purchased from a Symbol Business Partner, contact that Business Partner for service.

Getting Started

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

XR400 Reader C API Programmer Reference Guide1-2

Getting Started 1-3

Introduction

The C API enables programmers to write applications which run either directly on an XR Series RFID reader or on a Windows XP SP2 PC host.

This API provides access to the reader features, by utilizing the byte stream protocol as defined in the XR Series Interface Control Guide, p/n 72E-71803-xx. The API exposes these features as a set of predefined capabilities, and carries out operations through function calls.

The API does not save any configuration information. All of the capabilities are initialized to their default values when an instance is created and any changes made by the user(s) is not persisted by the API. The users must manage and adjusting the parameters at runtime. This is true for both the PC and the XR reader platforms.

XR400 Reader C API Programmer Reference Guide1-4

Structures and Definitions

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

XR400 Reader C API Programmer Reference Guide2-2

Introduction

This section describes the code structures and definitions.

Definitions

Capability Data Type

// Definitions for capability data types

#define TWTY_INT8 0x0000 /* Means Item is a TW_INT8 */

#define TWTY_INT16 0x0001 /* Means Item is a TW_INT16 */

#define TWTY_INT32 0x0002 /* Means Item is a TW_INT32 */

#define TWTY_UINT8 0x0003 /* Means Item is a TW_UINT8 */

#define TWTY_UINT16 0x0004 /* Means Item is a TW_UINT16 */

#define TWTY_UINT32 0x0005 /* Means Item is a TW_UINT32 */

Structures and Definitions 2-3

Capability Container Type

// Definitions for capability container types

#define TWON_UNKNOWN 0

#define TWON_ARRAY 3

#define TWON_ENUMERATION 4

#defineTWON_ONEVALUE 5

#define TWON_RANGE 6

Maximum Tag Type Array Size

#define RFID_TAG_TYPE_MAX20 // Reserve for 20 types of tag in stats block

XR400 Reader C API Programmer Reference Guide2-4

Tag Type Definition

enum RFID_TAG_TYPE_INDEX {

RFID_TAG_TYPE_OTHER = 0, //

RFID_TAG_TYPE_EPC_CLASS0 = 1, //

RFID_TAG_TYPE_EPC_CLASS0PLUS = 2, //

RFID_TAG_TYPE_EPC_CLASS1 = 3, //

RFID_TAG_TYPE_EPC_CLASSG2 = 4, //

RFID_TAG_TYPE_EPC_CLASS0ZUMA = 5, //

RFID_TAG_TYPE_MAXINDEX = 5, // Max used

RFID_TAG_TYPE_ERROR = 0xFFFFFFFF, // Unassigned type

};

Maximum Tag Type ID Length

#define RFID_MAX_TAG_ID_LENGTH_EX64 // max tag id length

Tag Filter Option

#define RFID_FILTER_OPTION_PASS 0 // pass tags that match the supplied filter

#define RFID_FILTER_OPTION_DROP 1 // drop tags that match the supplied filter

#define RFID_FILTER_OPTION_NOMATCH_PASS 2 // pass tags that do not match the supplied filter

#define RFID_FILTER_OPTION_NOMATCH_DROP 3 // drop tags that do not match the supplied filter

Antenna Structure Size

// RFID_CAPS defines

#define RFID_ANTENNA_SEQUENCE_LENGTH 16

#define MAX_NUMBER_ANTENNA 8

Generic Structure Information

typedef struct tagSTRUCT_INFO

{

DWORD dwAllocated; // Size of allocated structure in bytes

DWORD dwUsed; // Amount of structure actually used

} STRUCT_INFO;

CAPINFO Structure

// Capability information structure

typedef struct tagCAPINFO {

STRUCT_INFO StructInfo; // Information about this structure

DWORD dwCapId; // The capability ID

BOOLEAN bSupported; // non zero: supported

DWORD dwDataTypeId; // data type for this capability

DWORD dwDataSize; // size (# of bytes) of this data type

DWORD dwContainerId; // container type for this capability

DWORD dwContainerSize; // container size for this capability

DWORD dwNumItems; // Maximum Number of Item in this capability

TCHAR tszName[MAX_CAP_NAME]; // name of this capability

} CAPINFO, *LPCAPINFO;

Structures and Definitions 2-5

TYPE_TAG Structure

/* type storing tag data for a Tag List **************/

typedef struct

{

unsigned char status; //Status of entry - discovered, ... 1

unsigned char antennaNum; //Last antenna this tag has been read 2

unsigned char dataLength; //Tag length in bytes 3

unsigned char tagID[RFID_MAX_TAG_ID_LENGTH]; //ID code of tag 4-20

SYSTEMTIME lastSeen; //Timestamp of last time tag was seen 21-36

unsigned long readCount; //Number of reads of this tag 37-40

DWORD dwType; //Type of Tag 41-44

DWORD dwFormat; //Tag Data Format 45-48

DWORD dwOperationStatus; //RFIDAPI status code 49-52

WORD wStatusDetail; //extended status information 53-54

WORD wReserved1; // 55-56

DWORD dwReserved4; // 57-60

DWORD dwReserved5; // Reserve 5 DWORDS for future 61-64

}TYPE_TAG;

XR400 Reader C API Programmer Reference Guide2-6

TYPE_TAG_EX structure

typedef struct

{

int nInit; // This will be initialized by macro

int nTypeTagStructureFormat;

int nTypeTagStructureSize;

} TYPE_TAG_STRUCTURE_HEADER;

typedef struct

{

TYPE_TAG_STRUCTURE_HEADER Header;

unsigned char status; //Status of entry - discovered, ...

unsigned char antennaNum; //Last antenna this tag has been read

DWORD dataLength; //number of bytes in the tagID field. SYSTEMTIME firstSeen;

//Timestamp of first time tag was seen

SYSTEMTIME lastSeen; //Timestamp of last time tag was seen

unsigned long readCount; //Number of reads of this tag

DWORD dwType; //Type of Tag

DWORD dwFormat; //Tag Data Format

int nMemoryPageNumber; //For class 0 tags, memory page 2 is EPC.

// Memory page 2 information is not stored in this

// and the following memory page variables

DWORD dwMemoryPageOffset; //starting bit Offset into tag's memory page where data was read.

DWORD dwMemoryPageLength; //length of memory page in bytes.

DWORD dwOperationStatus; //status code for the read operation

WORD wStatusDetail; //other hardware related detail

WORD wCRC; // reserved

WORD wPC; // reserved

WORD wRSSI; // reserved

DWORD dwMillisecond; // reserved

DWORD dwReserved5; // Reserve DWORDS

unsigned char tagID[RFID_MAX_TAG_ID_LENGTH_EX];//ID code of tag

}TYPE_TAG_EX;

TYPE_MASK Structure

typedef struct

{

unsigned char cBitLen;

unsigned char cBitStartOffset;

unsigned char cTagMask[RFID_MAX_TAG_ID_LENGTH];

DWORD dwReserved[20]; // Reserve 20 DWORDS for future

}TAG_MASK;

TYPE_MASK_EX structure

typedef struct

{

int nInit; // This will be initialized by macro

Structures and Definitions 2-7

int nTagMaskStructureFormat;

int nTagMaskStructureSize;

} TAG_MASK_STRUCTURE_HEADER;

typedef struct

{

TAG_MASK_STRUCTURE_HEADER Header;

unsigned int nBitLen;

unsigned int nBitStartOffset;

unsigned char cTagMask[RFID_MAX_TAG_ID_LENGTH_EX];

DWORD dwReserved[20]; // Reserve 20 DWORDS for future

}TAG_MASK_EX;

XR400 Reader C API Programmer Reference Guide2-8

RFID_CAPS structure

typedef struct

{

TCHAR szAPIVersionString[RFID_API_VERSION_STRING_LENGTH];

TCHAR szFirmwareVersion[RFID_FIRMWARE_VERSION_STRING_LENGTH];

TCHAR szMfgDateCode[RFID_FIRMWARE_MFGDATECODE_LENGTH];

TCHAR szSerialInfo[RFID_FIRMWARE_SERIALINFO_LENGTH];

unsigned char ReaderNumber;

unsigned char Antenna;

unsigned char AntennaSequence[RFID_ANTENNA_SEQUENCE_LENGTH];

BOOL bPowerState;

BOOL bPortOpen;

DWORD dwReaderType;

DWORD dwCurrentPort;

DWORD dwCurrentBaud;

DWORD dwRFIDDeviceTable[10];

DWORD dwRFIDDeviceCount;

DWORD dwRFAttenuation; // 1

DWORD dwRFChannel; // 2

DWORD dwLastReaderCmdSeqNum; // 3

DWORD dwLastReaderCmd; // 4

DWORD dwLastReaderRsp; // 5

DWORD dwTagListSeqNum; // 6

BYTE bSupportedTagTypes[RFID_TAG_TYPE_MAX]; // 7 - 11

BYTE bEnabledTagTypes[RFID_TAG_TYPE_MAX]; // 12 - 16

DWORD dwMonitorStatus; // 17

BYTE bRFIDModuleType; // 18

DWORD dwReserved[100-18]; // Reserve 100 DWORDS for future

}RFID_CAPS;

TAG_LIST structure

typedef struct

{

DWORD dwTotalTags; // 1

DWORD dwTotalReads; // 2

DWORD dwNewTags; // 3

DWORD dwReadTimeMS; // 4

DWORD dwSeqNum; // 5

DWORD dwMaxTags; // Max tags supported. 0 means 200

DWORD dwErrorTags; // total of error tag packets appended to end of valid tags.

DWORD dwReserved[25-7]; // Use a total of 25 DWORDS

TYPE_TAG Tags[RFID_MAX_TAGS];

} TAG_LIST;

Structures and Definitions 2-9

TAG_LIST_EX structure

typedef struct

{

int nInit; // This will be initialized by macro

int nTagListStructureFormat;

int nTagListStructureSize;

} TAG_LIST_STRUCTURE_HEADER;

typedef struct

{

TAG_LIST_STRUCTURE_HEADER Header;

DWORD dwTotalTags; //

DWORD dwTotalReads; //

DWORD dwNewTags; //

DWORD dwReadTimeMS; //

DWORD dwSeqNum; //

DWORD dwMaxTags; // Max tags supported. 0 means 200

DWORD dwErrorTags; //total of error tag packets appended to end of valid tags

DWORD dwReserved[19]; // Reserve a total of 19 DWORDS

TYPE_TAG_EX Tags[RFID_MAX_TAGS];

} TAG_LIST_EX;

XR400 Reader C API Programmer Reference Guide2-10

RFID_STATS structure

typedef struct {

DWORD dwVersion; // 1 DWORD dwTotalTX; // 2 DWORD dwTotalRX; // 3 DWORD dwPacketsTX; // 4 DWORD dwPacketsRX; // 5 DWORD dwIncompleteTX; // 6 DWORD dwPacketsFragmented; // 7 DWORD dwPacketsCRCError; // 8 DWORD dwSessionIDError; // 9 DWORD dwTotalReads; // 10 DWORD dwTotalTagCRCError; // 11 DWORD dwTotalTagCollisions; // 12 DWORD dwTimeouts; // 13 DWORD dwTotal_10MSOnTime; // 14 DWORD dwTotalMSRFOnTime; // 15 DWORD dwNoTagErr; // 16 DWORD dwEraseFailErr; // 17 DWORD dwProgFailErr; // 18 DWORD dwTagLockErr; // 19 DWORD dwKillFailErr; // 20 DWORD dwHardwareErr; // 21 DWORD dwDataSizeErr; // 22 DWORD dwReadTime_10MS; // 23 DWORD dwReadAttempts; // 24 DWORD dwReadSuccess; // 25 DWORD dwProgramAttempts; // 26 DWORD dwProgramSuccess; // 27 DWORD dwEraseAttempts; // 28 DWORD dwEraseSuccess; // 29 DWORD dwLockAttempts; // 30 DWORD dwLockSuccess; // 31 DWORD dwKillAttempts; // 32 DWORD dwKillSuccess; // 33 DWORD dwLockFailErr; // 34 DWORD dwTagTypeReadTotal[RFID_TAG_TYPE_MAX]; // 35-54 (35+(RFID_TAG_TYPE_MAX - 1) DWORD dwTagUnderrunErrors; // 55 DWORD dwDroppedTagEvents; //56

DWORD dwReserved[256-56]; // Total of 256 DWORDS for stats(Fixed size total of 1K) } RFID_STATS;

Macro Used to Initialize TYPE_TAG_EX Structure

A TYPE_TAG_EX variable must be initialized by this macro before it is used.

The macro syntax is: TYPE_TAG_EX1_INIT(TypeTag)

Parameter TypeTag is a TYPE_TAG_EX variable.

Macro used to initialize TYPE_MASK_EX structure

A TYPE_MASK_EX variable must be initialized by this macro before it is used.

The macro syntax is: TAG_MASK_EX1_INIT(TagMask)

Parameter TagMask is a TYPE_MASK_EX variable.

Macro used to initialize TAG_LIST_EX structure

A TAG_LIST_EX variable must be initialized by this macro before it is used.

The macro syntax is: TAG_LIST_EX1_INIT(TagList, MaxTags)

Structures and Definitions 2-11

Parameter TagList is a TAG_LIST_EX variable.

Parameter MaxTags is either 0 or 200.

XR400 Reader C API Programmer Reference Guide2-12

Initialization

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

RFID_Open . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-5

RFID_Close . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-8

XR400 Reader C API Programmer Reference Guide3-2

Initialization 3-3

Introduction

Clients must initialize the RFID C API and obtain a reader handle before interacting with the devices. All subsequent

interactions with the RFID device are based on this handle. For the PC host version of this C-API the client can manage

multiple readers by opening a different handle for each reader. Each reader maintains a copy of the capability engine

version and tag list. Each of the capability engine version can be operated independently.

The C API library needs to be initialized before any other functions can be called. This is required because the capabilities

and functions need to be associated with a reader object instance to be functional. Every reader object instance is

uniquely identified by a handle, which the API uses to interact with the corresponding RFID device.

For Windows XP PC version, the library supports multiple concurrent reader instances. The user can interact with all the

readers simultaneously by referring to their handles. For the XR device version, only one instance is supported (the local

reader).

The reader handle is initialized by RFID_Open(HANDLE *hReader) function. Upon success, the hReader holds a valid

handle for the reader object instance. Any further reader operations require the handle as reference. The handle and the

reader object instance must be released by calling the RFID_Close(HANDLE *hReader) function.

The standard procedure for using a reader is as following:

1. Initialize a handle

2. Configure the IP address and TCP port for the reader

3. Open connection to the reader

4. Carry out other operations

5. Close the reader connection

6. Release the handle by closing the reader

XR400 Reader C API Programmer Reference Guide3-4

The following code segment demonstrates this procedure:

/// Opens and establishs connection to a reader

/// @param[in] tszNewIPAddressThe IP address of the teader

/// @param[in] wPortThe TCP port of the reader

HANDLE OpenReader(TCHAR tszNewIPAddress[32], WORD wPort)

{

HANDLE hReader = 0;

// open the API object for the reader

if(RFID_Open(&hReader) == RFID_SUCCESS)

{

// configure TCP/IP parameter for the reader

if(ConfigureTCPIP(hReader, tszNewIPAddress, wPort))

{

// connect to the reader

if(RFID_OpenReader(hReader, 0) == RFID_SUCCESS)

{

printf("Found reader\n");

// configure other parameters of the reader

ConfigureReader(hReader);

}

RFID_CAPS Caps;

if(RFID_GetCaps(hReader, &Caps) == RFID_SUCCESS)

{

printf("RFIDAPI Version %S Firmware Version %S\n\n",

Caps.szAPIVersionString, Caps.szFirmwareVersion);

printf(" Serial # Info: %S\n", Caps.szSerialInfo);

}

else

{

printf("Failed to open RFIDAPI\n");

}

return hReader;

}

Initialization 3-5

RFID_Open

Description

Call this function first to initialize the RFID API and obtain the reader handle. It returns RFID_SUCCESS on successful opening.

This function opens the RFID communications port.

To open an RFID device over a TCP socket, first configure the capabilities RFID_DEVCAP_IP_PORT and RFID_DEVCAP_IP_NAME. See

RFID_DEVCAP_IP_PORT on page A-6 and RFID_DEVCAP_IP_NAME on page A-5.

Function Prototype

DWORD RFID_Open(*phReader);

DWORD RFID_OpenReader(HANDLE hReader, int port);

Parameters

*phReader Pointer to the handle that receives the RFID device handle on RFID_SUCCESS.

HReader Handle to open the RFID device.

Port Desired port. Any valid port number, if the port number is 0, the value forRFID_DEVCAP_IP_PORT will be used.

Return Values

If successful:

RFID_SUCCESS

Upon failure, it returns one of the following values:

RFID_INVALID_HANDLE

RFID_CANNOT_ALLOC_MEM

RFID_ENGINE_BUSY

RFID_PORT_OPEN_ERROR

Example 1

HANDLE hRFIDReader;

RFID_Open(&hRFIDReader);

XR400 Reader C API Programmer Reference Guide3-6

Example 2

ConfigureTCPIP (HANDLE hReader, TCHAR *pszIPAddress, DWORD dwPort)

BOOL FindAndOpenReader(void)

DWORD dwItems;

DWORD dwStatus;

dwItems = 1;

dwIStatus = RFID_SetCapCurrValue (hReader, RFID_DEVCAP_IP_PORT, &dwITems, sizeof (dwPort), &dwPort);

if(dwStatus == RFID_SUCCESS)

{

bSuccess = TRUE;

}

else

{

printf (“RFID_DEVCAP_IP_NAME Set Cap Error %S\n”, RFID_GetCommandStatusText (hReader, dwStatus));

};

}

else

{

printf (“RFID_DEVCAP_IP_NAME Set Cap Error %S\n”, RFID_GetCommandStatusText (hReader, dwStatus));

};

return (bSuccess) ;

};

BOOL FindAndOpenReader(void)

{

BOOL bSuccess = FALSE;

// Open, and Initialize API

if(RFID_Open(&hReader)== RFID_SUCCESS)

{

// Now try to find the first RFID reader.

// It will look for a device on the local com ports...

if(ConfigureTCPIP (hReader,TEXTC ”192.168.0.101”), 3000))

{// A reader was found, now try and open using the port number returned.

if(RFID_OpenReader(hReader, RFIDFindInfo.nPortNumber) == RFID_SUCCESS)

{

bSuccess = TRUE;

};

Initialization 3-7

RFID_FindClose(hReader, hFind);

};

return(bSuccess);

};

XR400 Reader C API Programmer Reference Guide3-8

RFID_Close

Description

The RFID_Close function releases handle. It returns RFID_SUCCESS on successful closing.

This function closes the communication port.

Function Prototype

DWORD RFID_Close(HANDLE *phReader);

DWORD WINAPI RFID_CloseReader(HANDLE hReader);

Parameters

*phReader Pointer to the handle that receives the RFID device handle on RFID_SUCCESS.

hReader Handle for the open RFID device.

Return Values

If successful:

RFID_SUCCESS

Upon failure:

RFID_ENGINE_BUSY

RFID_INVALID_HANDLE

RFID_PORT_NOT_OPEN

Example

HANDLE hRFIDReader;

If ( RFID_Open( &HRFIDReader ) == RFID_SUCCESS )

{

RFID_Close(&hRFIDReader);

}

Initialization 3-9

XR400 Reader C API Programmer Reference Guide3-10

Device Capabilities Discovery

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3

RFID_GetCapList . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-4

RFID_GetCapInfo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5

RFID_GetCapCurrValue . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-7

RFID_GetCapDfltValue. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-10

RFID_SetCapCurrValue . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-11

RFID_SetCapDflts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-12

RFID_SetCapDfltValue . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-13

XR400 Reader C API Programmer Reference Guide4-2

Device Capabilities Discovery 4-3

Introduction

This chapter describes how to discover and change the API capabilities. These capabilities allow configuring the API and retrieving

the current API settings.

The API supports a limited set of capabilities, including attenuation settings, supported tag types, and reading modes. To get the set

a current or default values, query the API for a list of supported capabilities.

The following functions allow performing operations on the API capabilities.

XR400 Reader C API Programmer Reference Guide4-4

RFID_GetCapList

Description

This function returns a list of capability IDs. Each ID represents a unique capability provided by the API.

Function Prototype

DWORD RFID_GetCapList(HANDLE hReader, DWORD *pdwCapId, DWORD *pNumCaps);

Parameters

pdwCapId Pointer to an array of DWORDs for placing the CapIDs.

pNumCaps Pointer to DWORD that contains the number of CapIDs in the list.

Note

If pdwCapId or *pNumCaps is 0, the function sets *pNumCaps to the number of DWORDs required to hold the entire list. The user can then allocate sufficient storage for retrieving the capability list on the next call to RFID_GetCapList.

Return Values

If successful:

RFID_SUCCESS

Upon failure, it returns one of the following values:

RFID_PARAM_ERROR

RFID_INVALID_HANDLE

RFID_BUFFER_TO_SMALL

Device Capabilities Discovery 4-5

RFID_GetCapInfo

Description

This function returns information regarding the capability with ID dwCapId. Information includes unique name, data type, and

contained type.

Function Prototype

DWORD RFID_GetCapInfo(HANDLEhReader, DWORD dwCapId, LPCAPINFO lpCapInfo);

Parameters

dwCapId Cap Id on which to return information.

lpCapInfo Pointer to CapInfo structure to be filled with information.

See CAPINFO structure.

Return Values

If successful:

RFID_SUCCESS

Upon failure, it returns one of the following values:

RFID_INVALID_HANDLE

RFID_PARAM_ERROR

RFID_CAPNOTSUPPORTED

XR400 Reader C API Programmer Reference Guide4-6

Example

Get the List of Capabilities and Display the Human Readable Names of Each

void DisplayCapabilities(void)

{

DWORD *pCaps;

DWORD dwNumCaps;

CAPINFO CapInfo;

// ask for the number of capabilities supported

if(RFID_GetCapList(hReader, 0, &dwNumCaps) == RFID_SUCCESS)

{

// allocate a buffer for them

pCaps = malloc(dwNumCaps * sizeof(DWORD));

if(pCaps)

{

// now we know how many there are, and we have a valid buffer to hold them

// Ask for the cap list

if(RFID_GetCapList(hReader, pCaps, &dwNumCaps) == RFID_SUCCESS)

{

DWORD dwCount;

// now go through the list, and print the human readable name

for(dwCount = 0; dwCount < dwNumCaps; dwCount++)

{

if(RFID_GetCapInfo(hReader, *(pCaps + dwCount), &CapInfo) == RFID_SUCCESS)

{

printf("Cap Name: %S", CapInfo.tszName);

};

free(pCaps);

};

Device Capabilities Discovery 4-7

RFID_GetCapCurrValue

Description

This function returns the current value of the desired capability.

Function Prototype

DWORD RFID_GetCapCurrValue(HANDLE hReader, DWORD dwCapId, DWORD *pdwNumItems, DWORD dwValueBufSize, LPVOID pvValueBuf);

Parameters

dwCapId ID of capability to get.

pdwNumItems Pointer to DWORD indicating the maximum number of items to get.

dwValueBufSize Size in bytes pointed to by pvValueBuf.

pvValueBuf Block of memory receiving the capability value(s).

Notes

A capability can be a single entry, or multiple entries long. Each entry must be 8, 16, or 32 bits (1, 2, or 4 bytes) long. The parameters

imply the size of each entry, which the API calculates as follows:

EntrySize = dwValueBufSize / *pdwNumItems

The API converts smaller entries into larger entries, but not vice-versa. For example, the tag lock code is an array of bytes. The caller

can provide this function with an array of DWORDs. The API places each lock code byte into a single DWORD.

Return Values

If successful:

RFID_SUCCESS

Upon failure, it returns one of the following values:

RFID_INVALID_HANDLE

RFID_PARAM_ERROR

RFID_CAPNOTSUPPORTED

RFID_BUFFER_TO_SMALL

XR400 Reader C API Programmer Reference Guide4-8

Example

Get the List of Supported Tag Types, Enable One, and Disable the Rest

This example uses RFID_GetCapCurrValue() and RFID_SetCapCurrValue().

BOOL ConfigureTagTypes(void)

{

BOOL bSuccess = FALSE;

BYTE bSupportedTypes[5];

BYTE bEnabledTypes[5];

DWORD dwNumItems;

DWORD dwSize;

// init enabled type list to 0's. Indicates no types are yet enabled.

ZeroMemory(bEnabledTypes, sizeof(bEnabledTypes));

// Set the number of items in our buffer for API to use.

// The number of items in the array is the same as the size of the array

// if each item is a byte. This calculation ensures that dwNumItems is

// correct regardless of the size of each item

dwNumItems= sizeof(bSupportedTypes) / sizeof(bSupportedTypes[0]);

// Buffer size is in bytes

dwSize= sizeof(bSupportedTypes);

// Now ask for the list of supported tag types

if(RFID_GetCapCurrValue(hReader, RFID_TAGCAP_SUPPORTED_TYPES, &dwNumItems, dwSize, bSupportedTypes) ==

RFID_SUCCESS)

{

// The API updates dwNumItems to reflect number of items returned.

// One byte is returned for each possible Tag type

// The defines for tag type are indexes into the tag type list

// If a tag type's byte is 0, the type is not supported

// Now we can see what tag types are supported, and turn some off, and some on

// If class 0 is supported

if(bSupportedTypes[RFID_TAG_TYPE_EPC_CLASS0])

{

bEnabledTypes[RFID_TAG_TYPE_EPC_CLASS0] = 1;// Enable Class 0

};

// If class 1 is supported

if(bSupportedTypes[RFID_TAG_TYPE_EPC_CLASS1])

{

bEnabledTypes[RFID_TAG_TYPE_EPC_CLASS1] = 0;// Disable Class 1

};

// If class 1 Gen 2 is supported

if(bSupportedTypes[RFID_TAG_TYPE_EPC_CLASSG2])

{

bEnabledTypes[RFID_TAG_TYPE_EPC_CLASSG2] = 0;// Disable Class 1 Gen 2

};

Device Capabilities Discovery 4-9

// dwNumItems has been updated by GetCapCurrValue to be equal to the number of tag

// type entries. Use the same number for this call.

// Make sure the buffer size is based on the number of items returned when

// getting the supported tag type list.

dwSize = dwNumItems * sizeof(bEnabledTypes[0]);

// Now set the enabled types

if(RFID_SetCapCurrValue(hReader, RFID_TAGCAP_ENABLED_TYPES, &dwNumItems, dwSize, bEnabledTypes) == RFID_SUCCESS)

{

};

return(bSuccess);

};

bSuccess = TRUE;

XR400 Reader C API Programmer Reference Guide4-10

RFID_GetCapDfltValue

Description

This function returns the default value for the specified capability ID.

Function Prototypes

DWORD RFID_GetCapDfltValue(HANDLE hReader, DWORD dwCapId, DWORD *pdwNumItems, DWORD dwValueBufSize,

LPVOID pvValueBuf);

Notes

This function is similar to RFID_GetCapCurrValue except it applies to the default values. See RFID_GetCapCurrValue on page 4-7 for a function description.

Parameters

dwCapId ID of capability to get.

pdwNumItems Pointer to DWORD indicating the maximum number of items to get.

dwValueBufSize Size in bytes pointed to by pvValueBuf.

pvValueBuf Block of memory receiving the capability value(s).

Return Values

If successful:

RFID_SUCCESS

Upon failure, it returns one of the following values:

RFID_INVALID_HANDLE

RFID_PARAM_ERROR

RFID_CAPNOTSUPPORTED

RFID_BUFFER_TO_SMALL

Device Capabilities Discovery 4-11

RFID_SetCapCurrValue

Description

This function sets the current value of the specified capability ID.

Function Prototypes

DWORD RFID_SetCapCurrValue(HANDLE hReader, DWORD dwCapId, DWORD *pdwNumItems, DWORD dwValueBufSize, LPVOID pvValueBuf);

Notes

This function is similar to RFID_SetCapCurrValue except it sets caps. See RFID_GetCapCurrValue on page 4-7 for a function

description.

Parameters

dwCapId ID of the capability to get.

pdwNumItems Pointer to DWORD indicating the maximum number of items to get.

dwValueBufSize Size in bytes pointed to by pvValueBuf.

pvValueBuf Block of memory receiving the capability value(s).

Return Values

If successful:

RFID_SUCCESS

Upon failure, it returns one of the following values:

RFID_INVALID_HANDLE

RFID_PARAM_ERROR

RFID_CAPNOTSUPPORTED

RFID_CAPREADONLY

RFID_BUFFER_TO_SMALL

XR400 Reader C API Programmer Reference Guide4-12

RFID_SetCapDflts

Description

This function sets the capabilities values to their default values. The default values for some capabilities differ based on device type.

Function Prototypes

DWORD RFID_SetCapDflts(HANDLE hReader);

Return Values

If successful:

RFID_SUCCESS

Device Capabilities Discovery 4-13

RFID_SetCapDfltValue

Description

This function sets the current capability value to the default values. The default values for some capabilities differ based on device

type.

Function Prototypes

DWORD RFID_SetCapDfltValue(HANDLE hReader, DWORD dwCapId);

Parameters

dwCapId ID of capability to get.

Return Values

If successful:

RFID_SUCCESS

Upon failure:

RFID_INVALID_HANDLE

XR400 Reader C API Programmer Reference Guide4-14

Reading and Writing Tags

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

RFID_GetTagID. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-4

RFID_GetTagMask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-5

RFID_SetTagMask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-6

RFID_KillTag. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7

RFID_LockTag. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-9

RFID_ProgramTags. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-11

RFID_EraseTag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-13

RFID_ReadTagInventory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-14

GPIO support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-15

Extended version of data structures and functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-16

Error in tag reading. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-18

XR400 Reader C API Programmer Reference Guide5-2

Introduction

This chapter describes tag reading and writing functions.

Reading and Writing Tags 5-3

XR400 Reader C API Programmer Reference Guide5-4

RFID_GetTagID

Description

This function attempts to read a single RFID tag into pTag.

Function Prototype

DWORD RFID_GetTagID(HANDLE hReader, TYPE_TAG *pTag);

Parameters

HReader Open RFID device handle.

*pTag Pointer to a TYPE_TAG structure which is filled with the tag if the function returns RFID_SUCCESS.

Return Values

If successful:

RFID_SUCCESS (GetTagID returned a TAG)

Upon failure, it returns one of the following values:

RFID_ENGINE_BUSY

RFID_INVALID_HANDLE

RFID_PORT_NOT_OPEN

RFID_PARAM_ERROR

RFID_CMD_NOTAG

Notes

The API currently supports two reading modes, On Demand and Autonomous. The Autonomous reading mode is implemented in the API software, however it may not be available using the reader capabilities.

• In On Demand mode (the default mode), this function initiates tag reading and blocks until the reading process completes. If any tags are read, a single tag returns.

• In Autonomous mode, the RFID API is always reading tags. The API saves all tag reads in an internal queue. Calling this function removes a single tag from the queue. If no tags are available, the function returns immediately. If desired, configure the API to generate an event if any tags are queued. By doing so, the application can wait for the event, then use this function to get the tag. For details, see the capability RFID_READCAP_EVENTNAME on page A-12.

To change modes, see the capability RFID_READCAP_READMODE on page A-21.

Example

HANDLE hReader;

TYPE_TAG Tag;

if(RFID_GetTagID(hReader, &Tag) == RFID_SUCCESS)

{

// Display tag ID bytes

// Tag. TagID[0] is first byte

// Tag.dataLength is number of bytes in tag

};

Reading and Writing Tags 5-5

RFID_GetTagMask

Description

This function gets the current TagMask used during RFID tag reading functions. The mask limits the list of tags to read based on the current mask. The tag mask is limited to 64 bits; future releases will support 96-bit and higher masks.

The TagMask is reset whenever the RFID module is reset or powered off.

Function Prototype

DWORD RFID_GetTagMask(HANDLE hReader, TAG_MASK *pTagMask);

Parameters

hReader Handle to open the RFID device.

*pTagMask Pointer to a tag mask structure for getting the tag mask. Tag Mask contains the following:

nBitLength Number of bits to match. nStartBit The bit on which to start matching. The first 16 bits of the tag (0-15) are reserved. pMaskBits Array of bytes (bits) representing the bits to match.

Return Values

If successful:

RFID_SUCCESS

Upon failure, it returns one of the following values:

RFID_ENGINE_BUSY

RFID_INVALID_HANDLE

RFID_PORT_NOT_OPEN

RFID_PARAM_ERROR

Example

HANDLE hReader;

TAG_MASK TagMask;

BYTE *pTagBitMask = "\x10\x20\x30\x40\x50\x60\x70\x80";

TagMask.cBitLen = 8*8; // Match all 64 bits of the TAG ID

TagMask.cBitStartOffset = 16; // Start matching after the first 16 bits.

// These bits are reserved by the tag.

// set the tag mask bits

memcpy(TagMask.cTagMask, pTagBitMask, 8);

RFID_SetTagMask(hReader, &TagMask);

XR400 Reader C API Programmer Reference Guide5-6

RFID_SetTagMask

Description

The RFID_SetTagMask SetTagMask function sets the current TagMask used during RFID tag reading functions. The mask limits the list of tags to read based on the current mask.

Function Prototype

DWORD RFID_SetTagMask(HANDLE hReader, TAG_MASK *pTagMask);

Parameters

hReader Handle to open RFID device.

*pTagMask Pointer to a tag mask structure for setting the tag mask. Tag Mask contains the following:

cBitLen Number of bits to match.

cBitStartOffset The starting bit offset is not currently supported. cTagMask Array of bytes (bits) representing bits to match.

Return Values

If successful:

RFID_SUCCESS

Upon failure:

RFID_XXXX error code

Example

HANDLE hReader;

TAG_MASK TagMask;

BYTE *pTagBitMask = "\x10\x20\x30\x40\x50\x60\x70\x80";

TagMask.cBitLen = 8*8; // Match all 64 bits of the TAG ID

TagMask.cBitStartOffset = 0;

// set the tag mask bits

memcpy(TagMask.cTagMask, pTagBitMask, 8);

RFID_SetTagMask(hReader, &TagMask);

Reading and Writing Tags 5-7

RFID_KillTag

Description

This function kills a tag, making it programmable again. Use this command to reset a locked tag, similar to unlocking and erasing a tag.

Function Prototype

DWORD RFID_KillTag(HANDLE hReader, unsigned char *pTagID,

unsigned char cTagLength, unsigned char cTagVerifyCount,

unsigned char cKillAttempts, unsigned char cTagKillCode);

Parameters

HReader Handle to open the RFID reader.

*pTagID TagID of the tag to kill.

CTagLength Number of bytes in the Tag ID killed.

CTagVerifyCount Number of times to verify the tag before locking.

CKillAttempts Number of times to attempt killing the tag.

CTagKillCode Pass code used to kill the tag, set using RFID_LockTag. The cTagKillCode has an 8-bit value from 0 to 255.

Return Values

If successful:

RFID_SUCCESS

Upon failure, it returns one of the following values:

RFID_ENGINE_BUSY

RFID_INVALID_HANDLE

RFID_PORT_NOT_OPEN

RFID_PARAM_ERROR

Notes

By default, this function targets Class 1 tags. Set the type of tag on which to perform this operation by setting the capability RFID_WRITECAP_TAGTYPE on page A-23.

The cTagKillCode only supports one-byte kill codes. Class 0 tags require a three-byte code. To set a kill code with more than one byte, set the capability RFID_TAGCAP_LOCKCODE on page A-24 to the proper kill code, and pass cTagKillCode to 0.

For Gen2 tags, use RFID_TAGCAP_G2KILL_PASSWORD.

XR400 Reader C API Programmer Reference Guide5-8

Example

HANDLE hRFIDReader;

DWORD dwStatus;

unsigned char cTagLength;

unsigned char cTagVerifyCount;

unsigned char cLockAttempts;

unsigned char cTagKillCode;

unsigned char *pTagID;

pTagID = "\x01\x02\x03\x04\x05\x06\x07\x08";

cTagLength = 8;

cTagVerifyCount = 3;

cKillAttempts = 3;

cTagKillCode = 255;

dwStatus = RFID_KillTag(hReader, pTagID, cTagLength, cTagVerifyCount, cKillAttempts, cTagKillCode);

if(dwStatus == RFID_SUCCESS)

{

// Tag Killed

};

RFID_LockTag

Description

This function locks a tag to prevent changes.

Function Prototype

DWORD RFID_LockTag(HANDLE hReader, unsigned char cTagLength,

unsigned char cTagVerifyCount, unsigned char cLockAttempts,

unsigned char cTagKillCode);

Parameters

HReader Handle to open the RFID reader.

CTagLength Number of bytes in the Tag ID to lock.

CTagVerifyCount Number of times to verify the tag before locking.

CLockAttempts Number of times to try locking the tag.

CTagKillCode Pass code used to lock the tag. Use this pass code when killing the tag.

CTagKillCode has an 8-bit value from 0 to 255.

Reading and Writing Tags 5-9

Return Values

If successful:

RFID_SUCCESS

Upon failure, it returns one of the following values:

RFID_ENGINE_BUSY

RFID_INVALID_HANDLE

RFID_PORT_NOT_OPEN

RFID_PARAM_ERROR

RFID_CMD_NOTAG

RFID_CMD_TAGLOCK

RFID_CMD_LOCKFAIL

Notes

By default, this function targets Class 1 tags. Set the type of tag on which to perform this operation by setting the capability RFID_WRITECAP_TAGTYPE on page A-23.

For Gen2 tags, use RFID_TAGCAP_G2KILL_PASSWORD.

XR400 Reader C API Programmer Reference Guide5-10

Example

HANDLE hRFIDReader;

DWORD dwStatus;

unsigned char cTagLength;

unsigned char cTagVerifyCount;

unsigned char cLockAttempts;

unsigned char cTagKillCode;

cTagLength = 8;

cTagVerifyCount = 3;

cLockAttempts = 3;

cTagKillCode = 417;

dwStatus = RFID_LockTag(hReader, cTagLength, cTagVerifyCount, cLockAttempts, cTagKillCode);

if(dwStatus == RFID_SUCCESS)

{

// Tag Locked

};

RFID_ProgramTags

Description

This function programs a tag with a new TagID provided the tag is not locked.

Function Prototype

DWORD RFID_ProgramTags(HANDLE hReader, unsigned char *pTagID,

unsigned char cTagLength, unsigned char cTagVerifyCount,

unsigned char cEraseAttempts,unsigned char cProgramAttempts);

Parameters

Hreader Handle to open the RFID reader.

*pTagID Bytes representing the new tag ID.

cTagLength Number of bytes in the Tag ID.

cTagVerifyCount Number of times to verify the tag after programming (performed by the reader module).

cEraseAttempts Number of times to attempt erasing the tag before programming.

CProgramAttempts Number of times to try programming the tag.

Reading and Writing Tags 5-11

Return Values

If successful:

RFID_SUCCESS

Upon failure, it returns one of the following values:

RFID_ENGINE_BUSY

RFID_INVALID_HANDLE

RFID_PORT_NOT_OPEN

RFID_PARAM_ERROR

RFID_CMD_NOTAG

RFID_CMD_ERASEFAIL

RFID_CMD_PROGFAIL

RFID_CMD_TAGLOCK

Note

By default, this function targets Class 1 tags. Set the type of tag on which to perform this operation by setting the capability

RFID_WRITECAP_TAGTYPE on page A-23.

XR400 Reader C API Programmer Reference Guide5-12

Example

HANDLE hRFIDReader;

DWORD dwStatus;

unsigned char *pTagID;

unsigned char cTagLength;

unsigned char cTagVerifyCount;

unsigned char cEraseAttempts;

unsigned char cProgramAttempts;

pTagID = "\x01\x02\x03\x04\x05\x06\x07\x08";

cTagLength = 8;

cTagVerifyCount = 3;

cEraseAttempts = 3;

cProgramAttempts = 3;

dwStatus = RFID_ProgramTags(hRFIDReader, pTagID, cTagLength, cTagVerifyCount, cEraseAttempts, cProgramAttempts);

if(dwStatus == RFID_SUCCESS)

{

// Tag programmed

};

RFID_EraseTag

Description

This function erases a programmed tag, making it unreadable, provided the tag is not locked.

Function Prototype

DWORD RFID_EraseTag(unsigned char cTagVerifyCount, unsigned char cEraseAttempts)

Parameters

cTagVerifyCount Number of times to verify a successful.

cEraseAttempts Number of times to attempt erasing the tag.

Return Values

If successful:

RFID_SUCCESS

Upon failure, it returns one of the following values:

RFID_CMD_NOTAG

RFID_CMD_ERASEFAIL

Reading and Writing Tags 5-13

RFID_CMD_TAGLOCK

Notes

By default, this function targets Class 1 tags. Set the type of tag on which to perform this operation by setting the capability RFID_WRITECAP_TAGTYPE on page A-23.

Gen2 does not support erase

XR400 Reader C API Programmer Reference Guide5-14

RFID_ReadTagInventory

Description

This function supports reading multiple tags. This commands attempts to read a tag for a period of time based on programmerprovided parameters. This command also maintains a list of all tags read, the number of times each was read, the last time each was read, and its Tag ID. The caller provides a TAG_LIST structure that the API updates. To reset the tag list, set the clear inventory parameter. If a tag mask was set using RFID_SetTagMask, the inventory does not read tags that do not fit the mask.

Function Prototype

DWORD WINAPI RFID_ReadTagInventory(HANDLE hReader, TAG_LIST *pTagList, BOOL bClearInventory)

Parameters

HReader Handle to open the RFID device.

*pTagList TAG_LIST structure the API fills with results on the RFID_SUCCESS return value. This includes total tags read,

new tags read during this inventory request, and a list of tags. The caller can provide a valid tag list which the API updates, or initialize the tag list by setting the bClearInventory flag. This structure is limited to 200 tags. The nNewTags variable contains the number of new tags detected during the current API call. The first new tag is located at index nTotalTags-nNewTags.

BClearInventory TRUE - Clear out the current list of tags read, and reset the read count.

FALSE - Continue accumulating tags and keep track of how many times each tag was read.

Return Values

If successful:

RFID_SUCCESS

Upon failure, it returns one of the following values:

RFID_ENGINE_BUSY

RFID_INVALID_HANDLE

RFID_PORT_NOT_OPEN

RFID_PARAM_ERROR

If the tag list is full of valid tag read results but tags read after the list filled were lost:

RFID_MAX_TAGS_EXCEEDED

Notes

Provide a properly initialized taglist before calling this function. In general, zero the structure the first time used (or call this function with the bClearInventory parameter).

By default, the tag list can hold up to 200 tags. If desired, set the dwMaxTags field in the taglist. The API uses this number to override the maximum number of tags stored in the list. Allocate a TAG_LIST structure of the appropriate size when changing dwMaxTags.

This function returns RFID_MAX_TAGS_EXCEEDED if the tag list is full, and a queued tag cannot be added to the list. Clear the list, then call the function again.

The API currently supports two reading modes, On Demand and Autonomous. The Autonomous reading mode is implemented in the API software, however it may not be available using the reader capabilities.

• In On Demand mode (the default mode), this function initiates tag reading and blocks until the reading process completes. If any tags are read, they are added to the provided tag list, and returned to the caller.

Reading and Writing Tags 5-15

• In Autonomous mode, the RFID API is always reading tags. The API saves all tag reads in an internal queue. Calling this

function removes all currently queued tags from the queue, and adds these to the provided taglist. If no tags are available, the function returns immediately. If desired, configure the API to generate an event if any tags are queued. By doing so, the application can wait for the event, then use this function to get all queued tags. For details, see the capability RFID_READCAP_EVENTNAME on page A-12.

To change modes, see the capability RFID_READCAP_READMODE on page A-21.

Example

if(RFID_ReadTagInventory(hReader, &TagList, TRUE) == RFID_SUCCESS)

{

DWORD dwI = TagList.dwTotalTags;

for(dwI = 0; dwI < TagList.dwTotalTags; dwI++)

{

// print tag id TagList.Tags[dwI].tagID

};

GPIO Support

The following functions provide support for GPIO on the XR Series readers.

DWORD WINAPI RFID_GetGPIValue(HANDLE hReader, BYTE *pbValue);

This function gets the current value for the input pins. There are 6 TTL input pins on the XR reader, which will fill in the low 6 bits of the *pbValue variable.

DWORD WINAPI RFID_SetGPOValue(HANDLE hReader, BYTE GPOMask, BYTE bValue);

The readers have 6 TTL output pins. This function can set the value of particular output pins. The GPOMask has the bit mask for selecting pins. The low 6 bits match those output pins respectively. Value of 1 in the mask means that pin is selected. The Value variable tells the desired pin value for the specified pins.

DWORD WINAPI RFID_SetGPIDetection(HANDLE hReader, HANDLE hNotifyEvent, BYTE bMask, BYTE bInterval);

The readers support general purpose input detection and event notification. This function lets user enable this detection and set up the notification event.

The user needs to create a system event for notification, and pass the handle of this event in through the hNotifyEvent parameter. The parameter bMask provides a bit mask specifying which bit the user is interested in and would like the detection to listen to its change. This bit mask has the similar definition as in the previous function. The parameter bInterval specifies the detection interval the reader will use. This value is in terms of 100ms. 0 means the default value as 500ms.

XR400 Reader C API Programmer Reference Guide5-16

Extended Version of Data Structures and Functions

This version of the XR Series C-API also provides a set of enhanced version of the API function and data structures to provide richer information and functionalities. It is recommended that new applications should use this new extended version of structures and functions.

As a convention, these new structures and functions all have the similar names as their original counter parts with the "EX" extension.

Structures

Following table shows the new extended data structures and their respective original parts:

Table 5-1. Structures

New structure Original structure

TYPE_TAG_EX TYPE_TAG

TAG_LIST_EX TAG_LIST

TAG_MASK_EX TAG_MASK

For the structure of TAG_LIST_EX, it should be initialized by the macro of:

TAG_LIST_STRUCTURE_INIT(TagList, MaxTags, TagListStructureFormat)

The MaxTags parameter tells the maximum number of tags this structure should hold. 0 means the default value of 200 tags. The TagListStructureFormat parameter should always use the predefined constant value of TAG_LIST_STRUCTURE_FORMAT_EX1.

For example:

TAG_LIST_EX NewTagList;

TAG_LIST_STRUCTURE_INIT(

NewTagList, // The new tag list structure

0, // 0 means default value of 200.

TAG_LIST_STRUCTURE_FORMAT_EX1);

// Then the NewTagList variable is ready to be used in other function calls

Reading and Writing Tags 5-17

Functions

Following shows the pairs of the original functions and their extended counter parts. The only difference is that all extended version of functions use the extended version of data structures. Other than that, their usage is the same.

DWORD WINAPI RFID_GetTagID(HANDLE hReader, TYPE_TAG *pTag);

DWORD WINAPI RFID_GetTagIDEX(HANDLE hReader, TYPE_TAG_EX *pTag);

DWORD WINAPI RFID_SetTagMask(HANDLE hReader, TAG_MASK *pTagMask);

DWORD WINAPI RFID_SetTagMaskEX(HANDLE hReader, TAG_MASK_EX *pTagMask);

DWORD WINAPI RFID_GetTagMask(HANDLE hReader, TAG_MASK *pTagMask);

DWORD WINAPI RFID_GetTagMaskEX(HANDLE hReader, TAG_MASK_EX *pTagMask);

DWORD WINAPI RFID_ReadTagInventory(HANDLE hReader, TAG_LIST *pTagList, BOOL bClearInventory);

DWORD WINAPI RFID_ReadTagInventoryEX(HANDLE hReader, void *pTagList, BOOL bClearInventory);

DWORD WINAPI RFID_TagFilterAdd(HANDLE hReader, TCHAR *pFilterName, DWORD dwBitsToMatch, DWORD dwBitMatchOffset, unsigned char *pMatchBits, DWORD dwOptionMask, void (*pMatchCallBack)(TYPE_TAG *pTag, TCHAR *pFilterName, DWORD dwBitsToMatch, DWORD dwBitMatchOffset, const unsigned char *pMatchBits, DWORD dwOptionMask));

DWORD WINAPI RFID_TagFilterAddEX(HANDLE hReader, TCHAR *pFilterName, DWORD dwBitsToMatch, DWORD dwBitMatchOffset, unsigned char *pMatchBits, DWORD dwOptionMask, void (*pMatchCallBack)(TYPE_TAG_EX *pTag, TCHAR *pFilterName, DWORD dwBitsToMatch, DWORD dwBitMatchOffset, const unsigned char *pMatchBits, DWORD dwOptionMask));

XR400 Reader C API Programmer Reference Guide5-18

Error in Tag Reading

When it is reading with the functions of RFID_GetTagIDEX ()/RFID_GetTagIDEX(), RFID_ReadTagInventory()/ RFID_ReadTagInventoryEX(), the returned TAG_TYPE or TAG_TYPE_EX structure may contain errors that have occurred in the background reading.

If the value of the status field of the structure is RFID_SUCCESS, then this structure holds valid tag information in the respective fields. Otherwise, the status field tells the main error state; the wStatusDetail field holds device specific error information; and the antennaNum field holds the antenna index where this error occurred; and all other fields are reserved and should not be used.

Code sample:

/// Processes the error from reader tag reads

/// @param[in] hReader The handle of the reader

/// @param[in] Tag The tag structure which holds the status information

/// @returns true if the tag structure is an error and is processed, otherwise false

bool ProcessErrorRead(HANDLE hReader, TYPE_TAG_EX *pTag)

{

DWORD dwStatus = pTag->status;

if (dwStatus == RFID_SUCCESS)

{

return false;

}

printf("RFID_GetTagID Error %S, detail: %2x, antenna: %2u\n",

RFID_GetCommandStatusText(hReader, pTag->status),

pTag->wStatusDetail, pTag->antennaNum);

switch (dwStatus)

{

case RFID_CMD_UNKVAL:

{

switch (pTag->wStatusDetail)

{

case 0xF0: // invalid command params

// This antenna (Tag.antennaNum) may need to be removed from the

// antenna sequence, otherwise it may keep generating the same

// error

break;

default:

}

break;

case RFID_CMD_HWERR:

{

switch (pTag->wStatusDetail)

{

case 0xF3: // Antenna fault

Reading and Writing Tags 5-19

break;

// This antenna (Tag.antennaNum) may need to be removed from the

// antenna sequence, otherwise it may keep generating the same

// error

break;

case 0xF4: // DSP Timeout

case 0xF5: // DSP Error

case 0xF6: // DSP Idle

case 0xF7: // Zero Power (invalid RF power specified)

default:

break;

}

break;

case RFID_PORT_OPEN_ERROR:

case RFID_PORT_WRITE_ERROR:

case RFID_COMMAND_TIMEOUT:

case RFID_PORT_NOT_OPEN:

case RFID_UNKNOWN_COMM_TYPE:

case RFID_CMD_UNKLEN: //0xF1: // insufficient data

case RFID_CMD_UNKCMD: //0xF2: // Command not supported

case RFID_UNKNOWN_ERROR: //0xFF:

XR400 Reader C API Programmer Reference Guide5-20

default:

}

return true;

}

// enter error handling, may need to stop reading …

break;

General Helper Functions

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

RFID_GetCommandStatusText. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-4

RFID_GetStats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-5

XR400 Reader C API Programmer Reference Guide6-2

Introduction

This chapter includes commands for retrieving API status codes and module statistics.

General Helper Functions 6-3

XR400 Reader C API Programmer Reference Guide6-4

RFID_GetCommandStatusText

Description

This function returns RFID API status codes as English text strings. The hRFIDReader handle is not required, but used for consistency with the rest of this API.

Function Prototype

const TCHAR * RFID_GetCommandStatusText(int stat);

Parameters

stat Status code returned by an RFID API function call.

Return Values

Returns a human readable string representing the RFID API's integer error code.

Example

const TCHAR *szStatus;

stat = RFID_Reboot(hRFIDReader);

szStatus = RFID_GetCommandStatusText(hRFIDReader, stat);

General Helper Functions 6-5

RFID_GetStats

Description

This function fills the RFID_STATS structure with RFID module statistics. Statistics include Total Characters Transmitted, Total Characters Received, and Total Tags Read.

Function Prototype

DWORD RFID_GetStats(HANDLE hReader, RFID_STATS *pStats);

Parameters

HReader Open RFID device handle.

PStats Pointer to RFID_STATS structure that receives the latest stats.

Return Values

If successful:

RFID_SUCCESS

Upon failure, it returns one of the following values:

RFID_ENGINE_BUSY

RFID_PARAM_ERROR

RFID_INVALID_HANDLE

Example

RFID_STATS RFID_Stats;

HANDLE hReader;

RFID_GetStats(hReader, &RFID_Stats);

XR400 Reader C API Programmer Reference Guide6-6

RFID API Capabilities

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3

RFID_INFCAP_SUPPORTEDCAPS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-4

RFID_DEVCAP_IP_NAME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-5

RFID_DEVCAP_IP_PORT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-6

RFID_DEVCAP_ANTENNA_SEQUENCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-8

RFID_READCAP_RF_ATTENUATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-10

RFID_READCAP_EVENTTAGPTR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-11

RFID_READCAP_EVENTNAME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-12

RFID_READCAP_EVENT_ALLTAGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-16

RFID_READCAP_METHOD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-17

RFID_READCAP_OUTLOOP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-18

RFID_READCAP_INLOOP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-20

RFID_READCAP_READMODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-21

RFID_WRITECAP_RF_ATTENUATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-22

RFID_WRITECAP_TAGTYPE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-23

RFID_TAGCAP_LOCKCODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-24

RFID_TAGCAP_SUPPORTED_TYPES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-25

RFID_TAGCAP_ENABLED_TYPES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-26

RFID_TAGCAP_C0_SINGULATION_FIELD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-26

RFID_WRITECAP_ANTENNA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-27

RFID_TAGCAP_G2_KILL_PASSWORD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-27

RFID_TAGCAP_G2_ACCESS_PASSWORD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-28

RFID_DEVCAP_VALID_ANTENNA_LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-28

RFID_DEVCAP_ANTENNA_GROUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-29

XR400 Reader C API Programmer Reference GuideA-2

RFID_TAGCAP_MASK_BITS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-30

RFID_TAGCAP_MASK_NUMBITS_TOMATCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-30

RFID_TAGCAP_MASK_STARTPOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-31

Introduction

This appendix provides the description of the definition and usage of RFID API capabilities.

RFID API Capabilities A-3

XR400 Reader C API Programmer Reference GuideA-4

RFID_INFCAP_SUPPORTEDCAPS

Description

This capability can hold a complete list of all capability IDs.

Capability Type

CAPUINT32: Each item is a 32-bit value, 4 bytes.

Maximum Number of Items

This capability can hold 40 items

Container Type

CONT_ARRAY: This capability contains an array of value

Container Size

The size is 40 words, (160 bytes)

Default Value

This capability uses 160 bytes memory space, 40 items * 4 bytes

0x00 0x01 0x02 0x03 0x04 0x05 0x06 0x07

0x08 0x09 0x0A 0x0B 0x0C 0x0D 0x0E 0x0F

0x10 0x11 0x12 0x13 0x14 0x15 0x16 0x17

0x18 0x19 0x1A 0x1B 0x1C 0x1D 0x1E 0x1F

0x20 0x21 0x22 0x23 0x24 0x25 0x26 0x00

RFID_DEVCAP_IP_NAME

This is the IP address to use when calling RFID_FindFirst.

Description

This capability represents the IP address of the reader (Unicode string)

Capability Type

CAPUINT16: Each item is a 16-bit value, 2 bytes.

Maximum Number of Item

This capability can hold 14 items

Container Type

CONT_ARRAY: This capability's container contains an array.

Container Size

The size is 28 bytes

RFID API Capabilities A-5

Default Value

"127.0.0.1"

XR400 Reader C API Programmer Reference GuideA-6

RFID_DEVCAP_IP_PORT

This is the IP port number to use when calling RFID_FindFirst.

Description

This capability represents the TCP port of the reader

Capability Type

CAPUINT32: Each item is a 32-bit value, 4 bytes.

Maximum Number of Item

This capability can hold 1 item

Container Type

CONT_ONEVALUE: This capability's container contains one value.

Container Size

The size is 4 bytes

Default Value

0x0BB8 (3000)

Example

By setting RFID_DEVCAP_IP_NAME and RFID_DEVCAP_IP_PORT, the API searches for an RFID device on the provided TCP information when RFID_FindFirst or RFID_FindNext are called. If a device is not found at the supplied address:port, the API searches local com ports for a valid RFID device.

void ConfigureSocket(void)

{

DWORD dwNumItems;

DWORD dwSize;

szIPaddress = L"localhost";

dwPort = 3000;// default XR port number

dwNumItems = 1;

// Start by setting IP port number

if(RFID_SetCapCurrValue(hReader, RFID_DEVCAP_IP_PORT, &dwNumItems, sizeof(dwPort), &dwPort) == RFID_SUCCESS)

{

// Use local host as the host name. (try and find reader locally)

dwNumItems = wcslen(szIPaddress) + 1;// + 1 for null

dwSize = dwNumItems * sizeof(szIPaddress[0]);

if(RFID_SetCapCurrValue(hReader, RFID_DEVCAP_IP_NAME, &dwNumItems, dwSize, szIPaddress)== RFID_SUCCESS)

{

RFID API Capabilities A-7

};

XR400 Reader C API Programmer Reference GuideA-8

RFID_DEVCAP_ANTENNA_SEQUENCE

Use this to set the antenna sequence when reading tags. The ReadTag functions issue one set of read commands for each antenna specified in the sequence.

Description

Use this to set the antenna sequence when reading tags. The ReadTag functions issue one set of read commands for each antenna specified in the sequence.

Capability Type

CAPUINT8: Each item is a 8-bit value, 1 byte.

Maximum Number of Item

This capability can hold 16 items

Container Type

CONT_ARRAY: This capability's container contains an array.

Container Size

The size is 28 bytes

Default Value

0x00 0x01 0x02 0x03 0x04 0x05 0x06 0x07 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF

Note

0xFF means the end of the antenna sequence.

Example

// Create a small list of antennas to use when reading. // Read functions will cycle through the antenna sequence BOOL ConfigureAntennas(void) {

BOOL bSuccess = FALSE; DWORD dwNumItems; char cAntennaSequence[2]; cAntennaSequence[0] = 1;// First antenna cAntennaSequence[1] = 0;// Second antenna dwNumItems = 2; // antenna sequence has only 2 entries // Now tell the API to use this list of antennas if(RFID_SetCapCurrValue(hReader, RFID_DEVCAP_ANTENNA_SEQUENCE,

&dwNumItems, sizeof(cAntennaSequence), cAntennaSequence) == RFID_SUCCESS)

{

bSuccess = TRUE;

}; return(bSuccess);

};

Example

// Create a small list of antenna's to use when reading.

// Read functions will cycle through the antenna sequence

BOOL ConfigureAntennas(void)

{

BOOL bSuccess = FALSE;

DWORD dwNumItems;

char cAntennaSequence[2];

cAntennaSequence[0] = 1;// First antenna

cAntennaSequence[1] = 0;// Second antenna

dwNumItems = 2; // antenna sequence has only 2 entries

// Now tell the API to use this list of antennas

if(RFID_SetCapCurrValue(hReader, RFID_DEVCAP_ANTENNA_SEQUENCE, &dwNumItems, sizeof(cAntennaSequence), cAntennaSequence) == RFID_SUCCESS)

{

bSuccess = TRUE;

RFID API Capabilities A-9

};

return(bSuccess);

};

XR400 Reader C API Programmer Reference GuideA-10

RFID_READCAP_RF_ATTENUATION

Description

This function represents the attenuation level to use for all tag read operations.

Description

This capability represents the attenuation level to use for tag read operations.

Capability Type

CAPUINT8: Each item is a 8-bit value, 1 byte.

Maximum Number of Items

This capability can hold 1 item

Container Type

CONT_ONEVALUE: This capability's container contains one value

Container Size

The size is 1 byte

Default Value

Example

void ConfigureAttenuation(void) {

unsigned char cReadAttenuation; unsigned char cWriteAttenuation; DWORD dwNumItems;

// Attenuation of 0 is full power, 255 is no power... cReadAttenuation = 25; dwNumItems = 1; // Now tell API to set read attenuation RFID_SetCapCurrValue(hReader, RFID_READCAP_RF_ATTENUATION, &dwNumItems, sizeof(cReadAttenuation),

&cReadAttenuation);

// set to low power for tag writes... cWriteAttenuation = 220; dwNumItems = 1; // Now tell API to set read attenuation RFID_SetCapCurrValue(hReader, RFID_WRITECAP_RF_ATTENUATION, &dwNumItems, sizeof(cWriteAttenuation),

&cWriteAttenuation); };

RFID API Capabilities A-11

RFID_READCAP_EVENTTAGPTR

Description

This capability contains the address of a TYPE_TAG structure owned by the application. To use this feature, also set the RFID_READCAP_EVENTNAME capability.

This capability operates as follows:

In On Demand mode, when a tag is read, the API checks to see if the RFID_READCAP_EVENTNAME event is reset. If so, the API places tag data into the user supplied TYPE_TAG structure, and sets the event RFID_READCAP_EVENTNAME. If the event is already set, the API queues the tag for later.

When the application receives the event, it processes the tag data and resets the event. The API then re-starts this process. (The API takes the next queued tag in the TYPE_TAG structure, and resets the event.)

XR400 Reader C API Programmer Reference GuideA-12

RFID_READCAP_EVENTNAME

Description

The name of the windows event object user provided for signaling tag read

Capability Type

CAPUINT16: Each item is a 16-bit value, 2 byte (Unicode string).

Maximum Number of Items

This capability can hold 1 item

Container Type

CONT_ARRAY: This capability contains an array of Unicode characters

Container Size

The size is 64 Unicode characters, 128 bytes

Default Value

NULL string

Notes

The eventname is stored as a Unicode null terminated string. Include the terminating 16-bit NULL character. By implementing this capability, an application can efficiently wait for tags using a window event.

The API currently supports two reading modes, On Demand and Autonomous. The Autonomous reading mode is implemented in the API software, however it may not be available using the reader capabilities.

In On Demand mode, by default, this event is signaled when a new tag is added to the supplied taglist.

In Autonomous mode, this event is signaled for all tags.

Example

Autonomous Mode Tag Event Handling

DWORD WINAPI TagEventThread(LPVOID pvarg)

{

TCHAR *szReadEvent = L"MyReadTagEvent";

HANDLE hTagEvent;

DWORD dwNumItems;

DWORD dwSize;

DWORD dwReadMode = RFID_READCAP_READMODE_AUTONOMOUS;

// create a named event. Use this event for listening to tag read events from api

hTagEvent = CreateEvent(NULL, TRUE, FALSE, szReadEvent);

if(hTagEvent)

{

RFID API Capabilities A-13

// Register for tag read events using a named event

// include the null character

dwNumItems = wcslen(szReadEvent) + 1;

dwSize = dwNumItems * sizeof(szReadEvent[0]);

RFID_SetCapCurrValue(hReader, RFID_READCAP_EVENTNAME, &dwNumItems, dwSize, szReadEvent);

dwNumItems = 1;

// Tell API to configure autonomous read mode

// Once this is called, reading starts…

RFID_SetCapCurrValue(hReader, RFID_READCAP_READMODE, &dwNumItems, sizeof(dwReadMode), &dwReadMode);

// wait for api to signal that there are tags

// the API will keep event signalled as long as tags are available...

};

while(WaitForSingleObject(hTagEvent, INFINITE) == WAIT_OBJECT_0)

{

// Ask API for tag…

if(RFID_GetTagID(hReader, &Tag) == RFID_SUCCESS)

{

// process tag

};

return(0);

XR400 Reader C API Programmer Reference GuideA-14

On Demand Tag Event Handling

In On Demand mode, calls to RFID_ReadTagInventory() and RFID_GetTagID() block until the read process completes. Since the application thread is blocked, the application cannot see tags until the call completes. However, the developer can process read events while blocked by listening to events on another thread as follows:

DWORD WINAPI OnDemandModeTagEventThread(LPVOID pvarg)

{

DWORD dwTotalReads = 0;

// wait for api to signal that there are tags

// the API will keep event signalled as long as tags are available...

while(WaitForSingleObject(hTagEvent, INFINITE) == WAIT_OBJECT_0)

{

// we read another tag...

// By default, we only get these events when a new tag is added to the TagList.

// When RFID_ReadTagInventory returns, dwTotalReads will be the same as TagList.dwNewTags.

dwTotalReads++;

// We can see tag, and process it now...

// On demand mode requires we reset the event...

// this way, API knows when to overwrite the tag structure we provided.

ResetEvent(hTagEvent);

// On Demand mode does not allow us to call tag read functions on tag event.

// Main thread will get entire list when call completes

};

return(0);

};

void OnDemandEventTest(void)

{

TCHAR *szReadEvent = L"MyReadTagEvent";

DWORD dwNumItems;

DWORD dwSize;

HANDLE hThread;

TYPE_TAG *pTag;

// create a named event. Use this event for listening to tag read events from api

hTagEvent = CreateEvent(NULL, TRUE, FALSE, szReadEvent);

if(hTagEvent)

{

// Register for tag read events using a named event

// include the null character

dwNumItems = wcslen(szReadEvent) + 1;

dwSize = dwNumItems * sizeof(szReadEvent[0]);

RFID_SetCapCurrValue(hReader, RFID_READCAP_EVENTNAME, &dwNumItems, dwSize, szReadEvent);

// Give the API a place to store tag

dwNumItems = 1;

dwSize = sizeof(&Tag);// Size of pointer to a tag

// pass the address of the tag pointer. The API will use the tag pointer to store read tags

pTag = &Tag;

RFID_SetCapCurrValue(hReader, RFID_READCAP_EVENTTAGPTR, &dwNumItems, dwSize, &pTag);

// create the listening thread

hThread = CreateThread(NULL, 64*1024, OnDemandModeTagEventThread, (LPVOID)hReader, 0, NULL);

RFID API Capabilities A-15

if(hThread)

{

// start the read using OnDemand Mode.

// This call will block until the read completes it's inventory

if(RFID_ReadTagInventory(hReader, &TagList, TRUE) == RFID_SUCCESS)

{

PrintTagList();

};

XR400 Reader C API Programmer Reference GuideA-16

RFID_READCAP_EVENT_ALLTAGS

Set this to generate events (RFID_READCAP_EVENTNAME) on all tag reads while in On Demand mode. By default, the API signals only new tags (i.e., it does not signal duplicates).

RFID_READCAP_METHOD

Description

This function represents the tag reading method to use when performing the RFID_ReadTagInventory call.

Capability Type

CAPUINT8: Each item is a 8-bit value, 1 byte.

Maximum Number of Item

This capability can hold 1 item

Container Type

CONT_ONEVALUE: This capability's container contains one value.

Container Size

The size is 1 byte

Default Value

RFID API Capabilities A-17

Note

The API supports two read methods for the Class 1 Reader only:

o Method 0 performs RFID tag reading using a binary tree method.

o Method 1 performs RFID tag reading using a masked scroll technique.

XR400 Reader C API Programmer Reference GuideA-18

RFID_READCAP_OUTLOOP

Description

This function represents the outer loop value used when performing the RFID_ReadTagInventory call.

Capability Type

CAPUINT8: Each item is a 8-bit value, 1 byte.

Maximum Number of Item

This capability can hold 1 item

Container Type

CONT_ONEVALUE: This capability's container contains one value.

Container Size

The size is 1 byte

Default Value

Note

Calling RFID_ReadTagInventory() performs a tag inventory, which consists of one or more actual read attempts. The number of read attempts depends on a number of capabilities, including:

• RFID_READCAP_OUTLOOP

• RFID_READCAP_INLOOP

• RFID_TAGCAP_ENABLED_TYPES

• RFID_DEVCAP_ANTENNA_SEQUENCE

The following pseudo code illustrates the tag reading sequence for each read attempt:

While RFID_READCAP_OUTLOOP

While RFID_READCAP_INLOOP

For each antenna in RFID_DEVCAP_ANTENNA_SEQUENCE

For each RFID_TAGCAP_ENABLED_TYPES

Read Tags

Example

void ReadTagInventoryTest(void)

{

DWORD dwNumItems = 1;

BYTE bParam;

ZeroMemory(&TagList, sizeof(TagList));

// Set Outer loop to 3

bParam = 3;

dwNumItems = 1;

RFID_SetCapCurrValue(hReader, RFID_READCAP_OUTLOOP, &dwNumItems, sizeof(bParam), &bParam);

// Set inner loop to 5

bParam = 5;

dwNumItems = 1;

RFID_SetCapCurrValue(hReader, RFID_READCAP_INLOOP, &dwNumItems, sizeof(bParam), &bParam);

RFID API Capabilities A-19

// Now do a tag inventory

if(RFID_ReadTagInventory(hReader, &TagList, TRUE) == RFID_SUCCESS)

{

// print tag list

};

XR400 Reader C API Programmer Reference GuideA-20

RFID_READCAP_INLOOP

Description

This function represents the inner loop value used when performing the RFID_ReadTagInventory call.

Capability Type

CAPUINT8: Each item is a 8-bit value, 1 byte.

Maximum Number of Item

This capability can hold 1 item

Container Type

CONT_ONEVALUE: This capability's container contains one value.

Container Size

The size is 1 byte

Default Value

Note

The API uses this capability value only when calling RFID_ReadTagInventory with the innerLoop parameter set to zero.

Zebra XR480 RFID Reader Reference Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

XR Series RFID Readers C API Programmer Reference Guide

Contents

About This Guide

Introduction

Chapter Descriptions

Notational Conventions

Related Documents and Software

Service Information

Getting Started

Introduction

Structures and Definitions

Introduction

Definitions

Initialization

Introduction

RFID_Open

RFID_Close

Device Capabilities Discovery

Introduction

RFID_GetCapList

RFID_GetCapInfo

RFID_GetCapCurrValue

RFID_GetCapDfltValue

RFID_SetCapCurrValue

RFID_SetCapDflts

RFID_SetCapDfltValue

Reading and Writing Tags

Introduction

RFID_GetTagID

RFID_GetTagMask

RFID_SetTagMask

RFID_KillTag

RFID_LockTag

RFID_ProgramTags

RFID_EraseTag

RFID_ReadTagInventory

GPIO Support

Extended Version of Data Structures and Functions

Error in Tag Reading

General Helper Functions

Introduction

RFID_GetCommandStatusText

RFID_GetStats

RFID API Capabilities

Introduction

RFID_INFCAP_SUPPORTEDCAPS

RFID_DEVCAP_IP_NAME

RFID_DEVCAP_IP_PORT

RFID_DEVCAP_ANTENNA_SEQUENCE

RFID_READCAP_RF_ATTENUATION

RFID_READCAP_EVENTTAGPTR

RFID_READCAP_EVENTNAME

RFID_READCAP_EVENT_ALLTAGS

RFID_READCAP_METHOD

RFID_READCAP_OUTLOOP

RFID_READCAP_INLOOP
