Zebra TC21, TC26 Product Reference Guide

Download

TC21/TC26/ TC21HC/TC26-HC

Touch Computer

Product Reference Guide

for Android 11™

MN-004301-04EN Rev A

ZEBRA and the stylized Zebra head are trademarks of Zebra Technologies Corporation, registered in many jurisdictions worldwide. Google, Android, Google Play and other marks are trademarks of Google LLC. All other trademarks are the property of their respective owners. ©2021 Zebra Technologies Corporation and/ or its affiliates. All rights reserved.

Information in this document is subject to change without notice. The software described in this document is furnished under a license agreement or nondisclosure agreement. The software may be used or copied only in accordance with the terms of those agreements.

For further information regarding legal and proprietary statements, please go to:

SOFTWARE: zebra.com/linkoslegal. COPYRIGHTS: zebra.com/copyright. WARRANTY: zebra.com/warranty. END USER LICENSE AGREEMENT: zebra.com/eula.

Proprietary Statement

This manual contains proprietary information of Zebra Technologies Corporation and its subsidiaries (“Zebra Technologies”). It is intended solely for the information and use of parties operating and maintaining the equipment described herein. Such proprietary information may not be used, reproduced, or disclosed to any other parties for any other purpose without the express, written permission of Zebra Technologies.

Product Improvements

Continuous improvement of products is a policy of Zebra Technologies. All specifications and designs are subject to change without notice.

Liability Disclaimer

Zebra Technologies takes steps to ensure that its published Engineering specifications and manuals are correct; however, errors do occur. Zebra Technologies reserves the right to correct any such errors and disclaims liability resulting therefrom.

Limitation of Liability

In no event shall Zebra Technologies or anyone else involved in the creation, production, or delivery of the accompanying product (including hardware and software) be liable for any damages whatsoever (including, without limitation, consequential damages including loss of business profits, business interruption, or loss of business information) arising out of the use of, the results of use of, or inability to use such product, even if Zebra Technologies has been advised of the possibility of such damages. Some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.

About This Guide............................................................................................................................................14

Configurations......................................................................................................................................... 14

Mobility DNA Enterprise License.......................................................................................................18

Licensed Features..........................................................................................................................19

Request Licenses..........................................................................................................................20

Notational Conventions........................................................................................................................21

Icon Conventions................................................................................................................................... 21

Service Information................................................................................................................................21

Determining Software Versions........................................................................................................22

Determining the Serial Number........................................................................................................22

Getting Started...............................................................................................................................................23

Unpacking the Device.........................................................................................................................23

Device Features.................................................................................................................................... 24

Setting Up the Device.........................................................................................................................25

Installing a microSD Card...........................................................................................................26

Installing the SIM Card................................................................................................................ 27

Installing the Battery.................................................................................................................... 29

Replacing the Battery.......................................................................................................................... 30

Replacing the microSD Card.............................................................................................................. 31

Replacing the SIM Card......................................................................................................................32

Using the Device............................................................................................................................................35

Home Screen......................................................................................................................................... 35

Setting Home Screen Rotation................................................................................................. 36

Contents

Status Bar........................................................................................................................................ 37

Managing Notifications................................................................................................................40

Opening the Quick Access Panel............................................................................................. 41

Editing Icons on the Quick Settings Bar................................................................................ 43

Battery Management............................................................................................................................43

Checking Battery Status..............................................................................................................44

Monitoring Battery Usage...........................................................................................................44

Low Battery Notification..............................................................................................................44

Interactive Sensor Technology......................................................................................................... 44

Waking the Device............................................................................................................................... 45

USB Communication............................................................................................................................ 45

Transferring Files...........................................................................................................................45

Transferring Photos...................................................................................................................... 46

Disconnecting from the Host Computer.................................................................................46

Settings............................................................................................................................................................ 47

Accessing Settings................................................................................................................................47

Display Settings..................................................................................................................................... 47

Setting the Screen Brightness Manually.................................................................................47

Setting the Screen Brightness Automatically........................................................................ 47

Setting Night Light........................................................................................................................48

Setting Screen Timeout...............................................................................................................48

Setting Screen Rotation.............................................................................................................. 48

Setting Lock Screen Notifications............................................................................................ 49

Setting Font Size...........................................................................................................................49

Notification LED Brightness Level............................................................................................49

Setting Touch Panel Mode.........................................................................................................49

Setting the Date and Time................................................................................................................ 50

General Sound Setting........................................................................................................................50

Sound Options...............................................................................................................................50

Setting Wake-Up Sources................................................................................................................... 51

Remapping a Button............................................................................................................................. 51

Remappable Keys.................................................................................................................................52

Alert Button.............................................................................................................................................53

Contents

Configure the Alert Button......................................................................................................... 53

Alert Accessibility Service.......................................................................................................... 53

Using an Alert Button.................................................................................................................. 53

Keyboards............................................................................................................................................... 53

Enabling Keyboards......................................................................................................................54

Switching Between Keyboards................................................................................................. 54

Using the Android and Gboard Keyboards...................................................................................54

Edit Text...........................................................................................................................................54

Entering Numbers, Symbols, and Special Characters........................................................ 54

Enterprise Keyboard............................................................................................................................ 55

Numeric Tab................................................................................................................................... 55

Alpha Tab........................................................................................................................................ 55

Additional Character Tab............................................................................................................55

Scan Tab..........................................................................................................................................55

Language Usage...................................................................................................................................55

Changing the Language Setting...............................................................................................55

Adding Words to the Dictionary...............................................................................................56

Notifications............................................................................................................................................ 56

Enabling Blink Light......................................................................................................................56

Applications.....................................................................................................................................................57

Installed Applications........................................................................................................................... 57

Accessing Apps.....................................................................................................................................58

Switching Between Recent Apps............................................................................................. 58

Battery Manager....................................................................................................................................59

Opening Battery Manager..........................................................................................................59

Battery Manager Information.....................................................................................................59

Camera.....................................................................................................................................................60

Taking Photos................................................................................................................................. 61

Recording Videos..........................................................................................................................62

Camera Settings............................................................................................................................ 63

DataWedge Demonstration................................................................................................................65

DataWedge Demonstration Icons............................................................................................ 65

Selecting a Scanner..................................................................................................................... 65

Contents

RxLogger................................................................................................................................................. 66

RxLogger Configuration.............................................................................................................. 66

Configuration File..........................................................................................................................66

Enabling Logging.......................................................................................................................... 66

Disabling Logging......................................................................................................................... 66

Extracting Log Files......................................................................................................................66

Backing Up Data...........................................................................................................................66

RxLogger Utility..............................................................................................................................67

Data Capture.................................................................................................................................................. 68

Imaging.....................................................................................................................................................68

Digital Camera....................................................................................................................................... 68

Linear Imager......................................................................................................................................... 69

Operational Modes...............................................................................................................................69

Scanning Considerations.................................................................................................................... 70

Scanning with the Internal Imager...................................................................................................70

Scanning with Internal Camera......................................................................................................... 72

Scanning with the RS507/RS507X Hands-Free Imager............................................................. 73

Scanning with the RS5100 Ring Scanner.......................................................................................75

Scanning with the RS6000 Bluetooth Ring Scanner..................................................................76

Scanning with the DS3578 Bluetooth Scanner............................................................................79

Scanning with the DS3678 Bluetooth Scanner.............................................................................81

Scanning with the DS8178 Digital Scanner................................................................................... 83

Pairing the Bluetooth Ring Scanner................................................................................................ 84

Pairing in SSI Mode Using Near Field Communication......................................................84

Pairing in HID Mode Using Near Field Communication.....................................................85

Pairing a Bluetooth Scanner.............................................................................................................. 87

Pairing Using Simple Serial Interface......................................................................................87

Pairing Using Bluetooth Human Interface Device............................................................... 88

DataWedge............................................................................................................................................. 88

Enabling DataWedge................................................................................................................... 88

Disabling DataWedge.................................................................................................................. 89

Supported Devices...............................................................................................................................89

Camera Supported Decoders................................................................................................... 89

Contents

SE4100 Internal Imager Supported Decoders...................................................................... 90

SE4710 Internal Imager Supported Decoders...................................................................... 90

RS507/RS507x Supported Decoders.......................................................................................91

RS5100 Supported Decoders....................................................................................................92

RS6000 Supported Decoders...................................................................................................93

DS3578 Supported Decoders...................................................................................................94

DS3678 Supported Decoders...................................................................................................94

DS8178 Supported Decoders....................................................................................................95

Wireless............................................................................................................................................................97

Wireless Wide Area Networks.......................................................................................................... 97

Sharing the Mobile Data Connection......................................................................................97

Data Usage..................................................................................................................................... 99

Cellular Network Settings......................................................................................................... 100

Wireless Local Area Networks........................................................................................................ 102

Connecting to a Wi-Fi Network...............................................................................................102

Wi-Fi Version.................................................................................................................................103

Removing a Wi-Fi Network....................................................................................................... 103

WLAN Configuration...........................................................................................................................103

Configuring a Secure Wi-Fi Network.....................................................................................103

Manually Adding a Wi-Fi Network..........................................................................................104

Configuring for a Proxy Server................................................................................................105

Configuring the Device to Use a Static IP Address...........................................................106

Wi-Fi Preferences.........................................................................................................................107

Additional Wi-Fi Settings........................................................................................................... 107

Wi-Fi Direct....................................................................................................................................108

Bluetooth................................................................................................................................................108

Adaptive Frequency Hopping..................................................................................................108

Security...........................................................................................................................................109

Bluetooth Profiles......................................................................................................................... 110

Bluetooth Power States...............................................................................................................111

Bluetooth Radio Power................................................................................................................111

Discovering Bluetooth Device(s)............................................................................................... 111

Changing the Bluetooth Name.................................................................................................112

Contents

Connecting to a Bluetooth Device..........................................................................................112

Selecting Profiles on the Bluetooth Device..........................................................................112

Unpairing a Bluetooth Device...................................................................................................112

Cast...........................................................................................................................................................112

Near Field Communications..............................................................................................................113

Reading NFC Cards..................................................................................................................... 114

Sharing Information Using NFC................................................................................................114

Enterprise NFC Settings............................................................................................................. 115

Calls.................................................................................................................................................................116

Emergency Calling............................................................................................................................... 116

Audio Modes..........................................................................................................................................116

Bluetooth Headset............................................................................................................................... 116

Wired Headset.......................................................................................................................................117

Adjusting Audio Volume.....................................................................................................................117

Making a Call Using the Dialer.........................................................................................................117

Accessing Dialing Options.........................................................................................................118

Make a Call Using Contacts..............................................................................................................118

Using the Dialer............................................................................................................................ 118

Using the Contacts App.............................................................................................................119

Make a Call Using Call History........................................................................................................ 119

Using the Call History List......................................................................................................... 119

Making a Conference Call on GSM................................................................................................ 119

Making a Call Using a Bluetooth Headset...................................................................................120

Answering Calls................................................................................................................................... 120

Call Settings........................................................................................................................................... 121

Accessories....................................................................................................................................................124

Battery Charging..................................................................................................................................127

Main Battery Charging............................................................................................................... 127

Spare Battery Charging............................................................................................................. 128

Charging Temperature...............................................................................................................128

1-Slot Charge Only Cradle................................................................................................................ 128

Contents

1-Slot Charge Only Cradle Setup............................................................................................129

Charging with the 1-Slot Charge Only Cradle...................................................................... 131

1-Slot USB/Ethernet Cradle................................................................................................................131

1-Slot USB/Ethernet Cradle Setup...........................................................................................132

USB/Ethernet Module................................................................................................................. 133

Charging with the 1-Slot USB/Ethernet Cradle.................................................................... 137

4-Slot Charge Only Cradle with Battery Charger....................................................................... 137

4-Slot Charge Only Cradle with Battery Charger Setup...................................................139

Charging with the 4-Slot Charge Only Cradle with Battery Charger.............................140

5-Slot Charge Only Cradle................................................................................................................ 141

5-Slot Charge Only Cradle Setup...........................................................................................142

Charging with the 5-Slot Charge Only Cradle.................................................................... 142

5-Slot Ethernet Cradle........................................................................................................................143

5-Slot Ethernet Cradle Setup................................................................................................... 144

Daisy-chaining Ethernet Cradles............................................................................................. 144

Ethernet Communication........................................................................................................... 145

Charging with the 5-Slot Ethernet Cradle.............................................................................147

4-Slot Battery Charger........................................................................................................................147

4-Slot Battery Charger Setup................................................................................................... 148

Charging Spare Batteries..........................................................................................................149

Hand Strap............................................................................................................................................ 150

Healthcare Belt Clip.............................................................................................................................151

Removing the Healthcare Belt Clip........................................................................................153

Healthcare Handstrap........................................................................................................................ 153

Soft Holster............................................................................................................................................154

Adjusting the Holster..................................................................................................................154

Wrist/Arm Mount.................................................................................................................................. 154

Wrist/Arm Mount Installation.................................................................................................... 155

Installing the Device into the Wrist Mount........................................................................... 156

Removing the Device from the Wrist Mount....................................................................... 156

Installing Wrist Mount Straps....................................................................................................157

3.5 mm Audio Adapter......................................................................................................................158

Accessing the USB-C Connector....................................................................................................160

USB Cable............................................................................................................................................. 160

Contents

USB Communication...................................................................................................................160

Charging the Device....................................................................................................................161

Trigger Handle..................................................................................................................................... 162

Installing the Optional Lanyard................................................................................................163

Inserting the Device into the Trigger Handle......................................................................163

Removing the Device from the Trigger Handle..................................................................164

Vehicle Cradle......................................................................................................................................165

Assembling the Mount...............................................................................................................165

Installing on the Windshield..................................................................................................... 166

Installing the Dash Mount......................................................................................................... 167

Installing the Device into the Vehicle Cradle...................................................................... 167

Connecting Power.......................................................................................................................169

Removing the Device from the Vehicle Cradle.................................................................. 170

USB Power Supply............................................................................................................................... 171

Setting Up the USB Power Supply..........................................................................................171

5-Slot Cradle Rack Installation..........................................................................................................171

Installing the 5-Slot Cradle on a Rack.................................................................................... 171

4-Slot Battery Chargers Rack Installation..................................................................................... 174

Installing 4-Slot Battery Chargers on a Rack....................................................................... 174

Installing the Rack Mount..................................................................................................................177

Wall Installation.................................................................................................................................... 180

Bottom Tray Assembly................................................................................................................181

Mounting the Bracket..................................................................................................................181

Application Deployment..............................................................................................................................183

Android Security.................................................................................................................................. 183

Secure Certificates...................................................................................................................... 183

Installing a Secure Certificate.................................................................................................. 183

Configuring Credential Storage Settings..............................................................................184

Android Development Tools............................................................................................................184

Android Development Workstation........................................................................................ 184

Enabling Developer Options.................................................................................................... 184

EMDK for Android....................................................................................................................... 185

StageNow for Android............................................................................................................... 185

Contents

GMS Restricted.................................................................................................................................... 185

ADB USB Setup...................................................................................................................................186

Enabling USB Debugging......................................................................................................... 186

Entering Android Recovery Manually.................................................................................... 186

Application Installation Methods.....................................................................................................187

Installing Applications Using the USB Connection.............................................................187

Installing Applications Using the Android Debug Bridge.................................................188

Installing Applications Using Wireless ADB......................................................................... 188

Installing Applications Using a microSD Card.....................................................................190

Uninstalling an Application.......................................................................................................190

Android System Update..................................................................................................................... 191

Performing a System Update Using microSD Card............................................................191

Performing a System Update Using ADB..............................................................................191

Performing a System Update using Wireless ADB............................................................192

Verifying System Update Installation.....................................................................................194

Android Enterprise Reset..................................................................................................................194

Performing an Enterprise Reset From Device Settings.................................................... 194

Performing an Enterprise Reset Using microSD Card...................................................... 195

Performing an Enterprise Reset Using Wireless ADB.......................................................195

Performing an Enterprise Reset Using ADB........................................................................ 197

Android Factory Reset.......................................................................................................................198

Performing a Factory Reset Using microSD Card..............................................................198

Performing a Factory Reset Using ADB................................................................................199

Performing a Factory Rest Using Wireless ADB............................................................... 200

Android Storage.................................................................................................................................. 201

Random Access Memory......................................................................................................... 202

Viewing Memory.........................................................................................................................202

Internal Storage.......................................................................................................................... 202

External Storage......................................................................................................................... 203

Managing Apps...................................................................................................................................204

App Details...................................................................................................................................204

Managing Downloads....................................................................................................................... 204

Maintenance and Troubleshooting...........................................................................................................205

Contents

Maintaining the Device.....................................................................................................................205

Battery Safety Guidelines................................................................................................................ 205

Best Practices for Enterprise Mobile Computing Devices Operating in Hot

Environments and Direct Sunlight............................................................................................206

Cleaning Instructions.........................................................................................................................206

Approved Cleanser Active Ingredients................................................................................ 207

Approved Cleanser Active Ingredients for Healthcare Devices....................................207

Harmful Ingredients....................................................................................................................207

Device Cleaning Instructions...................................................................................................207

Special Cleaning Notes............................................................................................................208

Cleaning Materials Required...................................................................................................208

Cleaning Frequency...................................................................................................................208

Cleaning the Device..........................................................................................................................208

Housing......................................................................................................................................... 208

Display........................................................................................................................................... 208

Camera and Exit Window........................................................................................................ 209

Cleaning Battery Connectors..................................................................................................209

Cleaning Cradle Connectors...................................................................................................209

Troubleshooting..................................................................................................................................209

Resetting the Device..................................................................................................................210

Troubleshooting the Device.....................................................................................................210

1-Slot Charge Only Cradle Troubleshooting........................................................................ 212

1-Slot USB/Ethernet Cradle Troubleshooting.......................................................................213

4-Slot Charge Only Cradle with Battery Charger Troubleshooting............................... 214

5-Slot Charge Only Cradle Troubleshooting....................................................................... 214

5-Slot Ethernet Cradle Troubleshooting...............................................................................215

4-Slot Battery Charger Troubleshooting...............................................................................216

USB-C Audio Adapter................................................................................................................ 216

Technical Specifications..............................................................................................................................217

Decode Distances............................................................................................................................... 217

Back Housing....................................................................................................................................... 218

I/O Connector Pin-Outs..................................................................................................................... 218

1-Slot Charge Only Cradle Technical Specifications................................................................. 219

Contents

1-Slot USB/Ethernet Cradle Technical Specifications...............................................................220

4-Slot Charge Only Cradle with Battery Charger Technical Specifications........................220

5-Slot Charge Only Cradle Technical Specifications................................................................ 221

5-Slot Ethernet Cradle Technical Specifications........................................................................ 221

4-Slot Battery Charger Technical Specifications....................................................................... 222

Trigger Handle Technical Specifications.....................................................................................223

USB-C Audio Adapter Technical Specifications........................................................................ 223

Vehicle Cradle Technical Specifications......................................................................................224

About This Guide

This guide provides information about setting up and using TC21/TC26 touch computers with the AndroidTM 10 operating system. Some screens shown in this guide may differ from the actual screens

shown on the device.

Configurations

The following table covers all configurations of the device. Models available in your area may vary.

Table 1WLAN Configurations

Part

Number

TC210K01A222

TC210K01A242

TC210K01A422

TC210K01A442

Radios Battery Camera Memory Connector/

WLAN: 802.11 a/b/ g/n/ac/d/h/i/r/k/v/ wWPAN: Bluetooth v5.0 Low Energy

Basic Battery

Extended Battery

Basic Battery

Extended Battery

13 MP rear/5 MP front

3 GB RAM/32 GB Flash

4 GB RAM/64 GB Flash

Data

Alert

Button

2-pin Connector2Dimager

Capture Options

(SE4710) and integrated NFC

Operating

System

Google Mobile Services (GMS) 11.

About This Guide

Table 1WLAN Configurations (Continued)

Part

Number

TC210K01A423

TC210K01B212

TC210K01B232

TC210K01D221

TC210K01D241

Radios Battery Camera Memory Connector/

WLAN: 802.11 a/b/ g/n/ac/d/h/i/r/k/v/ wWPAN: Bluetooth v5.0 Low Energy

Basic Battery

Extended Battery

Basic Battery

Extended Battery

13 MP rear/5 MP front

13 MP rear/ no front camera

13 MP rear/5 MP front

4 GB RAM/64 GB Flash

3 GB RAM/32 GB Flash

Data

Alert

Button

8-pin Connector2Dimager

2-pin Connector2Dimage

No ConnectorNoScanner

Capture Options

(SE4710) and integrated NFC

(SE4100) and integrated NFC

Operating

System

Google Mobile Services (GMS) 11.

TC210K02A222

TC210K02B212

TC210K02B412

TC210K0HD224 (Healthcare)

WLAN: 802.11 a/b/ g/n/ac/d/h/i/r/k/v/ wWPAN: Bluetooth v5.0 Low Energy

WLAN: 802.11 a/b/ g/n/ac/d/h/i/r/k/v3/ wWPAN: Bluetooth v5.0 Low Energy

Basic Battery

13 MP rear/5 MP front

13 MP rear/ no front camera

13 MP rear/5 MP front

3 GB RAM/32 GB Flash

4 GB RAM/64 GB Flash

3 GB RAM/32 GB Flash

2-pin Connector2Dimager

(SE4710) and integrated NFC

2-pin Connector2Dimager

(SE4100) and integrated NFC

2-pin Connector2Dimager

(SE4100) and integrated NFC

Back Alert Button

No Scanner

Android Open Source Project (AOSP) 11 (China only).

Google Mobile Services (GMS) 11.

About This Guide

Table 1WLAN Configurations (Continued)

Part

Number

TC210K0HB224 (Healthcare)

TC210K06B224 (Healthcare)

Table 2WWAN Configurations

Part

Number

TC26AK11A222 TC26BK11A222

Radios Battery Camera Memory Connector/

WLAN: 802.11 a/b/ g/n/ac/d/h/i/r/k/v3/ wWPAN: Bluetooth v5.0 Low Energy

Radios Battery Camera Memory Connector/

WLAN: 802.11 a/b/g/n/ac/d/h/ i/r/k/v/wWPAN: Bluetooth v5.0 Low EnergyWWAN: HSPA+/LTE/CDMA

Basic Battery

13 MP rear/5 MP front

3 GB RAM/32 GB Flash

Data

Alert

Button

Back Alert Button

Alert

Button

2-pin Connector2Dimager

Capture Options

2D imager (SE4100) and integrated NFC

Data Capture Options

(SE-4710) and integrated NFC

Operating

System

Google Mobile Services (GMS) 11.

Android Open Source Project (AOSP) 11 (China only).

Operating

System

Google Mobile Services (GMS) 11.

TC26AK11A242 TC26BK11A242

TC26AK11A422 TC26BK11A422

TC26AK11A423 TC26BK11A423

WLAN: 802.11 a/b/g/n/ac/d/h/ i/r/k/v/wWPAN: Bluetooth v5.0 Low EnergyWWAN: HSPA+/LTE/CDMA

Extended Battery

Basic Battery

13 MP rear/5 MP front

3 GB RAM/32 GB Flash

4 GB RAM/64 GB Flash

2-pin Connector2Dimager

(SE-4710) and integrated NFC

2-pin Connector2Dimager

(SE-4710) and integrated NFC

8-pin Connector2Dimager

(SE-4710) and integrated NFC

Google Mobile Services (GMS) 11.

About This Guide

Table 2WWAN Configurations (Continued)

Part

Number

TC26AK11A442 TC26BK11A442

TC26AK11B212 TC26BK11B212

TC26AK11B232 TC26BK11B232

TC26AK11D221 TC26BK11D221

Radios Battery Camera Memory Connector/

WLAN: 802.11 a/b/g/n/ac/d/h/ i/r/k/v/wWPAN: Bluetooth v5.0 Low EnergyWWAN: HSPA+/LTE/CDMA

Extended Battery

Basic Battery

Extended Battery

Basic Battery

13 MP rear/5 MP front

13 MP rear/ no front camera

13 MP rear/5 MP front

4 GB RAM/64 GB Flash

3 GB RAM/32 GB Flash

Data

Alert

Button

2-pin Connector2Dimager

No ConnectorNoScanner

Capture Options

(SE-4710) and integrated NFC

(SE-4100) and integrated NFC

Operating

System

Google Mobile Services (GMS) 11.

TC26AK21D221 TC26BK21D221

TC26AK11D241 TC26BK11D241

TC26AK21A222 TC26BK21A222

WLAN: 802.11 a/b/g/n/ac/d/h/ i/r/k/v/wWPAN: Bluetooth v5.0 Low EnergyWWAN: HSPA+/LTE/eSIM

WLAN: 802.11 a/b/g/n/ac/d/h/ i/r/k/v/wWPAN: Bluetooth v5.0 Low EnergyWWAN: HSPA+/LTE/CDMA

WLAN: 802.11 a/b/g/n/ac/d/h/ i/r/k/v/wWPAN: Bluetooth v5.0 Low EnergyWWAN: HSPA+/LTE/eSIM

Basic Battery

Extended Battery

Basic Battery

13 MP rear/5 MP front

3 GB RAM/32 GB Flash

No ConnectorNoScanner

2-pin Connector2Dimager

(SE-4710) and integrated NFC

Google Mobile Services (GMS) 11.

About This Guide

Table 2WWAN Configurations (Continued)

Part

Number

TC26CK12A222

TC26CK12B212

TC26BK1HB224 (Healthcare)

TC26BK1HD224 (Healthcare)

Radios Battery Camera Memory Connector/

WLAN: 802.11 a/b/g/n/ac/d/h/ i/r/k/v/wWPAN: Bluetooth v5.0 Low EnergyWWAN: HSPA+/LTE

WLAN: 802.11 a/b/g/n/ac/d/h/ i/r/k/v/wWPAN: Bluetooth v5.0 Low EnergyWWAN: HSPA+/LTE/CDMA

Basic Battery

13 MP rear/5 MP front

13 MP rear/ no front camera

13 MP rear / 5 MP front

3 GB RAM/32 GB Flash

3 GB RAM / 32 GB Flash

Data

Alert

Button

2-pin Connector2Dimager

Back Alert Button

Capture Options

(SE-4710) and integrated NFC

(SE-4100) and integrated NFC

2D imager (SE-4100) and integrated NFC

No scanner

Operating

System

Android Open Source Project (AOSP) 11 (China only).

Google Mobile Services (GMS) 11.

TC26BK16B224 (Healthcare)

TC26EK21A222NA

WLAN: 802.11 a/b/g/n/ac/d/h/ i/r/k/v/wWPAN: Bluetooth v5.0 Low EnergyWWAN: HSPA+/LTE

WLAN: 802.11 a/b/g/n/ac/d/h/ i/r/k/v/wWPAN: Bluetooth v5.0 Low EnergyWWAN: HSPA+/LTE/CBRS

Mobility DNA Enterprise License

Powerful complimentary Mobility DNA tools are made available and ready to use, making it easier to stage, secure and troubleshoot devices; capture and send data to your applications right out of the box; restrict access to features and applications; and more. The Mobility DNA Enterprise License delivers premium voice capabilities over Wi-Fi and unlocks powerful tools and utilities that takes workforce productivity and device management simplicity to a new level.

Basic Battery

13 MP rear / 5 MP front

3 GB RAM / 32 GB Flash

Back Alert Button

2-pin Connector2Dimager

2D imager (SE-4100) and integrated NFC

(SE-4710) and integrated NFC

Android Open Source Project (AOSP) 11 (China only).

Google Mobile Services (GMS) 11.

VoLTE delivers superior voice quality over cellular networks, while Zebra’s advanced VoWiFi technology, included with the Mobility DNA Enterprise License, delivers superior voice quality over all of your WiFi voice applications. For example, Push-to-Talk Express for basic walkie-talkie style communications, the

Workforce Connect PTT Pro1 subscription service for walkie talkie-style communications over cellular and WiFi networks, and Workforce Connect Voice1 to turn TC21 and TC26 devices into fully-featured PBX

handsets.

Licensed Features

Licensed features are only available on this device with the purchase of a Mobility DNA Enterprise License. A single license unlocks all premium features on the device. Some apps may require a download from

zebra.com/support. Please contact your administrator or go to zebra.com for more information.

NOTE: Android Multi-User Mode is not supported by the Mobility DNA Enterprise License. Entering Multi-User Mode on a device with an active Mobility DNA Enterprise License may cause undefined behavior.

Core OS, Apps, and mDNA

Core OS, apps, and mDNA features that require the purchase of a Mobility DNA Enterprise License.

About This Guide

Fusion

• PowerPrecisionConsole

• Zebra Volume Control

• Secure NFC through EMDK

• Firmware Over the Air (FOTA)

• Device Tracker

• Enterprise Keyboard

• Device Central

• NG SimulScan through EMDK and DataWedge

• WFC Voice

Fusion features that require the purchase of a Mobility DNA Enterprise License.

• Power Management (WMM U-APSD)

• EAP Methods (LEAP)

• PEAP Phase 2: GTC Dynamic Password

• Fast Roam (CCKM)

• CCXv4 (compliant, but not certified)

• Band Preference (5 GHz Only)

• Subnet Roam

Optional Zebra voice solutions available for purchase. Push-to-Talk Express and Workforce Connect PTT Pro do not require the MDNA Enterprise license. Workforce Connect Voice and other third party full duplex voice solutions require the MDNA Enterprise license for performance and support.

About This Guide

• 802.11v

• Fusion Logger

• Fusion Status

• WorryFree WiFi

• WorryFree WiFi Manager (WorryFree WiFi)

• Wi-Fi Manager (Wi-Fi)

• Channel mask

• AutoTimeConfig

• CCKM

• WLANPowerSave (WMM-PS)

• EnableRestrictedSettingsUI

• BandPreference

• SubNetRoam

• PasswordProtectEncryption

• 802.11v

• CallAdmissionControl

• Gratuitous ARP

• Profile configuration (Dynamic GTC)

• Profile configuration (LEAP)

Connectivity

Connectivity features that require the purchase of a Mobility DNA Enterprise License.

• Bluetooth Silent Pairing, Trusted and Single Pairing

• Bluetooth NFC Tap and Pair

• Bluetooth CSPs

• Disable future pairing with remote Bluetooth devices.

• Do not allow the device to be visible to other devices over Bluetooth.

• Allow Silent Pairing

• SmartLeash (Quality monitoring feature)

• Clear All PDL (Paired Device List)

Request Licenses

Customers, partners, and distributors require a Mobility DNA Enterprise License. Please request an evaluation or trial license through your account manager.

An account manager or sales engineer can request a trial or evaluation of the Mobility DNA Enterprise License for customers, partners, or distributors using SFDC forms.

Zebra engineering can submit a request for a trial or evaluation of the Mobility DNA Enterprise License using Service NOW.

Notational Conventions

The following conventions are used in this document:

• Bold text is used to highlight the following:

• Dialog box, window, and screen names

• Drop-down list and list box names

• Checkbox and radio button names

• Icons on a screen

• Key names on a keypad

• Button names on a screen

• Bullets (•) indicate:

• Action items

About This Guide

• List of alternatives

• Lists of required steps that are not necessarily sequential.

• Sequential lists (for example, those that describe step-by-step procedures) appear as numbered lists.

Icon Conventions

The documentation set is designed to give the reader more visual clues. The following graphic icons are used throughout the documentation set.

NOTE: The text here indicates information that is supplemental for the user to know and that is not required to complete a task.The text here indicates information that is important for the user to know.

IMPORTANT: The text here indicates information that is important for the user to know.

CAUTION: If the precaution is not heeded, the user could receive a minor or moderate injury.

WARNING: If danger is not avoided, the user CAN be seriously injured or killed.

DANGER: If danger is not avoided, the user WILL be seriously injured or killed.

Service Information

If you have a problem with your equipment, contact Zebra Global Customer Support for your region. Contact information is available at: zebra.com/support.

When contacting support, please have the following information available:

• Serial number of the unit

• Model number or product name

• Software type and version number

Zebra responds to calls by email, telephone, or fax within the time limits set forth in support agreements.

If your problem cannot be solved by Zebra Customer Support, you may need to return your equipment for servicing and will be given specific directions. Zebra is not responsible for any damages incurred during shipment if the approved shipping container is not used. Shipping the units improperly can possibly void the warranty.

If you purchased your Zebra business product from a Zebra business partner, contact that business partner for support.

Determining Software Versions

Before contacting Customer Support, determine the current software version on your device.

Swipe down from the Status bar with two fingers to open the Quick Access panel, and then touch .

2. Touch About phone.

3. Scroll to view the following information:

About This Guide

• Battery information

• Emergency information

• SW components

• Legal information

• Model & hardware

• Android version

• Android Security Update

• Google Play system update

• Baseband version

• Kernel version

• Build number

To determine the deviceInternational Mobile Equipment Identity (IMEI) information (WWAN only), touch About phone > IMEI.

• IMEI - Displays the IMEI number for the device.

• IMEI SV - Displays the IMEI software version (SV) number for the device.

Determining the Serial Number

Before contacting Customer Support, determine the serial number of your device.

Swipe down from the Status bar with two fingers to open the Quick Access panel, and then touch .

2. Touch About phone.

3. Touch Model & hardware.

Getting Started

This section provides information to get the device up and running for the first time.

Unpacking the Device

1. Carefully remove all protective material from the device and save the shipping container for later

storage and shipping.

2. Verify that the following items were received:

• Touch computer

• USB-C cover (TC2X-HC only).

• PowerPrecision Lithium-ion battery

• Regulatory Guide.

3. Inspect the equipment for damage. If any equipment is missing or damaged, contact Customer Support center immediately. See About This Guide on page 14.

4. Prior to using the device for the first time, remove the protective shipping film that covers the exit window, touch screen, and rear camera.

Device Features

Figure 1Front View

Getting Started

1 Front Camera Takes photos and videos (available on some models).

2 Receiver Use for audio playback in Handset mode.

3 Proximity/Light Sensor Determines proximity for turning off display when in Handset

mode.Determines ambient light for controlling display backlight intensity.

4 Data Capture LED Indicates data capture status.

5 Charging/Notification

LED

6 Touch Screen Displays all information needed to operate the device.

7 Speaker Provides audio output for video and music playback. Provides audio

8 Cradle Charging

Contacts

9 USB-C Connector Provides USB host and client communications, and device charging

10 Microphone Use for communications in Handset mode.

11 PTT Button Typically used for Push-to-Talk communications. Where regulatory

Indicates battery charging status while charging and application generated notifications.

in speakerphone mode.

Provides device charging via cradles and accessories.

via cables and accessories.NOTE: For healthcare devices, it is not recommended to remove the USB-C cover to ensure proper device sealing.

restrictions exista for Push-to-Talk VoIP communication, this button is configurable for use with other applications.

12 Scan Button Initiates data capture (programmable).

Pakistan, Egypt, Jordan, Qatar

Figure 2Rear View

Getting Started

13 NFC Antenna Provides communication with other NFC-enabled devices.

14 Basic Hand Strap

Mount

15 Battery Release

Latches

16 Alert Button Red alert button (available on healthcare devices only).

17 Battery Standard - 3,400 mAh (typical) / 3,300 mAh (minimum),

18 Volume Up/Down

Button

19 Scan Button Initiates data capture (programmable).

20 Camera Flash Provides illumination for the camera.

21 Rear Camera Takes photos and videos.

22 Power Button Turns the display on and off. Press and hold to reset the device or

23 Exit Window Provides data capture using the imager.

24 Microphone Use for communications in Speakerphone mode.

25 cbrs logo Citizens Broadband Radio Service (cbrs) available on TC26EK

Provides mounting point for Basic Hand Strap accessory.

Press to remove the battery.

PowerPrecision Lithium-ion BatteryExtended - 5,260 mAh (typical) / 5,000 mAh (minimum), PowerPrecision Lithium-ion Battery.

Increase and decrease audio volume (programmable).

power off.

configuration.

Setting Up the Device

Follow these steps before using the device for the first time.

1. Install a micro secure digital (SD) card (optional).

2. Installing a nano SIM card (optional)

3. Install hand strap (optional).

4. Install the battery.

5. Charge the device.

6. Power on the device.

Installing a microSD Card

The microSD card slot provides secondary non-volatile storage. The slot is located under the battery pack. For more information, refer to the documentation provided with the card and follow the manufacturer’s recommendations for use.

CAUTION: Follow proper electrostatic discharge (ESD) precautions to avoid damaging the microSD card. Proper ESD precautions include, but are not limited to, working on an ESD mat and ensuring that the operator is properly grounded.

1. Lift and remove the access door.

Getting Started

2. Slide the microSD card holder to the unlock position.

3. Lift the microSD card holder.

Getting Started

4. Insert the microSD card into the card holder door, and ensure that the card slides into the holding tabs on each side of the door.

5. Close the microSD card holder and slide into the lock position.

CAUTION: Access door must be replaced and securely seated to ensure proper device

sealing.

6. Replace the access door.

Installing the SIM Card

NOTE: Only use a nano SIM card. Not applicable to TC21.

CAUTION: For proper electrostatic discharge (ESD) precautions to avoid damaging the SIM card.

Proper ESD precautions include, but not limited to, working on an ESD mat and ensuring that the user is properly grounded.

Getting Started

1. Lift the access door.

2. Slide the SIM card holder to the unlock position.

3. Lift the SIM card holder door.

4. Place the nano SIM card into the card holder with contacts facing down.

Getting Started

5. Close the SIM card holder door and slide into the lock position.

CAUTION: Access door must be replaced and securely seated to ensure proper device

sealing.

6. Replace the access door.

Installing the Battery

NOTE: User modification of the device, particularly in the battery well, such as labels, asset tags,

engravings, stickers may compromise the intended performance of the device or accessories. Performance levels such as sealing (Ingress Protection (IP)), impact performance (drop and tumble), functionality, temperature resistance could be effected. DO NOT put any labels, asset tags, engravings, stickers in the battery well.

1. Insert the battery, bottom first, into the battery compartment in the back of the device.

2. Press the battery down into the battery compartment until the battery release latches snap into place.

For information on battery charging, see Battery Charging on page 127.

Replacing the Battery

CAUTION: Do not add or remove SIM or microSD card during battery replacement.

1. Press the Power button until the menu appears.

2. Touch Power Off.

3. Wait for the device to completely turn off.

4. If the hand strap is attached, slide the hand strap clip away from the bottom of the device, and then lift.

Getting Started

5. Press the two battery latches in.

6. Lift the battery from the device.

7. Insert the replacement battery, bottom first, into the battery compartment in the back of the device.

8. Press the battery down until the battery release latches snap into place.

9. Replace the hand strap, if required.

10. Press the Power button to turn on the device.

Replacing the microSD Card

1. Press the Power button until the menu appears.

2. Touch Power off.

3. Touch OK.

4. If the hand strap is attached, slide the hand strap clip away from the bottom of the device, and then lift.

Getting Started

5. Press the two battery latches in.

6. Lift the battery from the device.

7. Lift the access door.

8. Remove microSD card from holder.

9. Insert the replacement microSD card.

CAUTION: Access door must be replaced and securely seated to ensure proper device

sealing.

Getting Started

10. Replace the access door.

11. Insert the battery, bottom first, into the battery compartment in the back of the device.

12. Press the battery down until the battery release latches snap into place.

13. Replace the hand strap, if required.

14. Press and hold the Power button to turn on the device.

Replacing the SIM Card

NOTE: Only use a nano SIM card. Not applicable to TC21.

1. Press the Power button until the menu appears.

2. Touch Power off.

3. Touch OK.

4. If the hand strap is attached, slide the hand strap clip away from the bottom of the device, and then lift.

5. Press the two battery latches in.

6. Lift the battery from the device.

Getting Started

7. Lift the access door.

8. Slide the SIM card door to the unlock position.

9. Lift the SIM card holder door.

10. Remove the SIM card.

11. Place the new SIM card into the card holder with contacts facing down.

Getting Started

12. Close the SIM card holder and slide into the lock position.

CAUTION: Access door must be replaced and securely seated to ensure proper device

sealing.

13. Replace the access door.

14. Insert the battery, bottom first, into the battery compartment in the back of the device.

15. Press the battery down until the battery release latch snaps into place.

16. Replace the hand strap, if required.

17. Press and hold the Power button to turn on the device.

Using the Device

This section explains how to use the device.

Home Screen

Turn on the device to display the Home screen. Depending on how your system administrator configured your device, your Home screen may appear differently than the graphics in this section.

After the device goes into Sleep mode, the Home screen displays with the lock slider. Touch the screen and slide up to unlock. The Home screen provides four additional screens to place widgets and shortcuts. Swipe the screen left or right to view the additional screens.

NOTE: By default, AOSP devices do not have the same icons on the Home screen as GMS devices. Icons are shown below for example only.

Home screen icons can be configured by the user and may look different than shown.

Figure 3Home Screen

Using the Device

1 Status bar Displays the time, status icons (right side), and notification icons

2 Widgets Launches stand-alone apps that run on the Home screen.

3 Shortcut icons Opens apps installed on the device.

4 Folder Contains apps.

5 Back Displays the previous screen.

6 Home Displays the home screen.

7 Recent Displays recently used applications.

Setting Home Screen Rotation

By default, the Home screen rotation is disabled.

1. Touch and hold anywhere on the Home screen until the options appear.

2. Touch Home settings.

3. Touch the Allow Home screen rotation switch.

4. Touch Home.

5. Rotate the device.

(left side).

Status Bar

The Status bar displays the time, notification icons (left side), and status icons (right side).

If there are more notifications than can fit in the Status bar, a dot displays indicating that more notifications exist. Swipe down from the Status bar to open the Notification panel and view all notifications and status.

Figure 4Notifications and Status Icons

1 Notification icons

2 Status icons

Notification Icons

Notification icons indicate app events and messages.

Using the Device

Table 3Notification Icons

Icon Description

Mainbattery is low.

More notifications are available for viewing.

Data is synching.

Indicates an upcoming event. AOSP devices only.

Indicates an upcoming event. GMS devices only.

Open Wi-Fi network is available.

Audio is playing.

Problem with sign-in or sync has occurred.

Device is uploading data.

Animated: the device is downloading data. Static: the download is complete.

Using the Device

Table 3Notification Icons (Continued)

Icon Description

Device is connected to or disconnected from a virtual private network (VPN).

Preparing internal storage by checking it for errors.

USB debugging is enabled on the device.

Call is in progress (WWAN only).

The mailbox contains one or more voice message (WWAN only).

Call is on hold (WWAN only).

Call was missed (WWAN only).

Status Icons

Status icons display system information for the device.

Table 4Status Icons

Wired headset with a boom module is connected to the device.

Wired headset without a boom module is connected to the device.

Indicates the RxLogger app is running.

Indicates the Bluetooth scanner is connected to the device.

Indicates the ring scanner is connected to the device in HID mode.

Icon Description

Alarm is active.

Mainbattery is fully charged.

Mainbattery is partially drained.

Table 4Status Icons (Continued)

Icon Description

Main battery charge is low.

Mainbattery charge is very low.

Mainbattery is charging.

All sounds, except media and alarms, are muted. Vibrate mode is active.

Indicates that all sounds except media and alarms are muted.

Do Not Disturb mode active.

Using the Device

Airplane Mode is active. All radios are turned off.

Bluetooth is on.

The device is connected to a Bluetooth device.

Connected to a Wi-Fi network. Indicates the Wi-Fi version number.

Not connected to a Wi-Fi network or no Wi-Fi signal.

Connected to an Ethernet network.

Speakerphone enabled.

Portable Wi-Fi hotspot is active (WWAN only).

Connected to a 4G LTE/LTE-CA network (WWAN only).

Connected to a 1x-RTT (Sprint), EGDGE, EVDO, EVDV or WCDMA network (WWAN

only).

Connected to a GPRS network (WWAN only).

Table 4Status Icons (Continued)

Icon Description

Connected to a DC - HSPA, HSDPA, HSPA+ or HSUPA network (WWAN only).

Using the Device

Managing Notifications

Notification icons report the arrival of new messages, calendar events, alarms, and ongoing events. When a notification occurs, an icon appears in the Status bar with a brief description.

Figure 5Notification Panel

Connected to an EDGE network (WWAN only).

Connected to a GPRS network (WWAN only).

Roaming from a network (WWAN only).

No SIM card installed (WWAN only).

1 Quick settings bar

• To view a list of all notifications, open the Notification panel by dragging the Status bar down from the top of the screen.

• To respond to a notification, open the Notification panel and then touch a notification. The Notification panel closes and the corresponding app opens.

• To manage recent or frequently used notifications, open the Notification panel and then touch Manage notifications. Touch the toggle switch next to an app to turn off all notifications, or touch an app for more notification options.

• To clear all notifications, open the Notification panel and then touch CLEAR ALL. All event-based notifications are removed. Ongoing notifications remain in the list.

• To close the Notification panel, swipe the Notification panel up.

Opening the Quick Access Panel

Use the Quick Access panel to access frequently used settings (for example, Airplane mode).

NOTE: Not all icons are pictured. Icons may vary.

Using the Device

Figure 6Quick Access Panel

• If the device is locked, swipe down once.

• If the device is unlocked, swipe down once with two fingers, or twice with one finger.

• If the Notification panel is open, swipe down from the Quick Settings bar.

Quick Access Panel Icons

Quick Access panel icons indicate frequently used settings (for example, Airplane mode).

Table 5Quick Access Panel Icons

Icon Description

Display brightness - Use the slider to decrease or increase the brightness of the screen.

Wi-Fi network - Turn Wi-Fi on or off. To open Wi-Fi settings, touch the Wi-Fi network name.

Bluetooth settings - Turn Bluetooth on or off. To open Bluetooth settings, touch Bluetooth.

Battery saver - Turn Battery saver mode on or off. When Battery saver mode is on the performance of the device is reduced to preserve battery power (not applicable).

Invert colors - Invert the display colors.

Using the Device

Do not disturb - Control how and when to receive notifications.

Mobile data - Turns cellular radio on or off. To open Mobile data settings, touch and hold (WWAN only).

Airplane mode - Turn Airplane mode on or off. When Airplane mode is on the device does not connect to Wi-Fi or Bluetooth.

Auto-rotate - Lock the device’s orientation in portrait or landscape mode or set to automatically rotate.

Flashlight - Turn flashlight on or off. Turn camera flash on or off. On camera-only devices without an internal scan engine, the flashlight turns off when an app is opened. This ensures the camera is available for scanning.

Location - Enable or disable locationing feature.

Hotspot - Turn on to share the device’s mobile data connection with other devices.

Data Saver - Turn on to prevent some apps from sending or receiving data in the background.

Night Light - Tint the screen amber to make it easier to look at the screen in dim light. Set Night Light to turn on automatically from sunset to sunrise, or at other times.

Using the Device

Table 5Quick Access Panel Icons (Continued)

Icon Description

Screen Cast - Share phone content on Chromecast or a television with Chromecast built-in. Touch cast screen to display a list of devices, then touch a device to begin casting.

Dark Theme - Toggles dark theme on and off. Dark themes reduce the luminance emitted by the screen, while meeting minimum color contrast ratios. It helps improve visual ergonomics by reducing eye strain, adjusting brightness to current lighting conditions, and facilitating screen use in dark environments, while conserving battery power.

Focus mode - Turn on to pause distracting apps. To open Focus mode settings, touch and hold.

Bedtime mode - Turn grayscale on and off. Grayscale turns the screen black and white, reducing phone distractions and improving battery life.

Nearby Share - Helps find and interact with services and devices close to the device.

Screen Record - Makes a video recording of everything that happens on the screen, with options to include audio and screen touches.

NFC - Enable or disable NFC communication.

Editing Icons on the Quick Settings Bar

The first several setting tiles from the Quick Access panel become the Quick Settings bar.

•

Open the Quick Access panel and touch to edit, add, or remove settings tiles.

Battery Management

Observe the recommended battery optimization tips for the device.

• Set the screen to turn off after a short period of inactivity.

• Reduce screen brightness.

• Turn off all wireless radios when not in use.

• Turn off automatic syncing for Email, Calendar, Contacts, and other apps.

• Minimize the use of apps that keep the device from sleeping, for example, music and video apps.

NOTE: Before checking the battery charge level, remove the device from any AC power source (cradle or cable).

Checking Battery Status

• Open Settings and touch About phone > Battery Information.Or, swipe up from the bottom of the screen and touch to open the Battery Manager app.

Battery present status indicates if the battery is present.

Battery level lists the battery charge (as a percentage of fully charged).

• Swipe down with two fingers from the status bar to open the quick access panel.

Batterypercentage is displayed next to the battery icon.

Monitoring Battery Usage

The Battery screen provides battery charge details and power management options to extend battery life.Different apps display different information. Some apps include buttons that open screens with settings to adjust power use. Use the DISABLE or FORCE CLOSE buttons to turn off apps that consume too much power.

• Go to Settings.

• Touch Battery.

Using the Device

Todisplay battery information and power management options for a specific app:

• Go to Settings.

• Touch Apps & notifications.

• Touch an app.

• Touch Advanced > Battery.

Low Battery Notification

When the battery charge level drops below 18%, the device displays a notice to connect the device to power. The user should charge the battery using one of the charging accessories.

When the battery charge drops below 10%, the device displays a notice to connect the device to power. The user must charge the battery using one of the charging accessories.

When the battery charge drops below 4%, the device turns off. The user must charge the battery using one of the charging accessories.

Interactive Sensor Technology

To take advantage of these sensors, applications use API commands. Refer to the Google Android Sensor APIs for more information. For information on the Zebra Android EMDK, go to: techdocs.zebra.com.The device contains sensors that monitor movement and orientation.

The device contains sensors that monitor movement, orientation, and ambient light.

• Gyroscope- Measures angular rotational velocity to detect rotation of the device.

• Accelerometer- Measures the linear acceleration of movement to detect the orientation of the device.

• Light Sensor- Detects ambient light and adjusts the screen brightness.

• Proximity Sensor- Detects the presence of nearby objects without physical contact. The sensor detects when the device close to your face during a call and turns off the screen, preventing unintentional screen touches.

Waking the Device

The device goes into Sleep mode when you press Power or after a period of inactivity (set in the Display settings window).

1. To wake the device from Sleep mode, press Power or the configured wake-up sources.

The Lock screen displays.

2. Swipe the screen up to unlock.

• If the Pattern screen unlock feature is enabled, the Pattern screen appears instead of the Lock

screen.

• If the PIN or Password screen unlock feature is enabled, enter the PIN or password after unlocking

the screen.

NOTE: If you enter the PIN, password, or pattern incorrectly five times, you must wait 30 seconds before trying again.

Using the Device

• If you forget the PIN, password, or pattern, contact your system administrator.

USB Communication

Connect the device to a host computer to transfer files between the device and the host computer.

When connecting the device to a host computer, follow the host computer’s instructions for connecting and disconnecting USB devices, to avoid damaging or corrupting files.

Transferring Files

Use Transfer files to copy files between the device and the host computer.

NOTE: It is recommended to install a microSD card in the device for storing files due to limited internal storage.

1. Connect the device to a host computer using a USB accessory.

2. On the device, pull down the Notification panel and touch Charging this device via USB.

By default, No data transfer is selected.

3. Touch File Transfer.

NOTE: After changing the setting to File Transfer, and then disconnecting the USB cable, the

setting reverts back to No data transfer. If the USB cable is reconnected, select File Transfer again.

4. On the host computer, open File Explorer.

5. Locate the device as a portable device.

6. Open the Internal storage folder.

7. Copy files to and from the device or delete files as required.

Using the Device

Transferring Photos

Use PTP to copy photos from the device to the host computer.

1. Connect the device to a host computer using a USB accessory.

2. On the device, pull down the Notification panel and touch Charging this device via USB.

3. Touch Transfer photos PTP.

4. On the host computer, open a file explorer application.

5. Open the SD card or the Internal storage folder.

6. Copy or delete photos as required.

Disconnecting from the Host Computer

NOTE: Carefully follow the host computer’s instructions to unmount the microSD card and

disconnect USB devices correctly to avoid losing information.

1. On the host computer, unmount the device.

2. Remove the device from the USB accessory.

Settings

This section describes the settings on the device.

Accessing Settings

There are multiple ways to access settings on a device.

• Swipe down with two fingers from the top of the Home screen to open the Quick Access panel and touch .

•

Double-swipe down from the top of the Home screen to open the Quick Access panel and touch .

•

Swipe up from the bottom of the Home screen to open APPS and touch Settings.

Display Settings

Use Display settings to change the screen brightness, enable night light, change the background image, enable screen rotation, set screen timeout, and change font size.

Setting the Screen Brightness Manually

Manually set the screen brightness using the touchscreen.

1. Swipe down with two fingers from the Status bar to open the Quick Access panel.

2. Slide the icon to adjust the screen brightness level.

Setting the Screen Brightness Automatically

Automatically adjust the screen brightness using the built-in light sensor.

1. Go to Settings.

2. Touch Display.

3. If disabled, touch Adaptive brightness to automatically adjust the brightness.

By default, Adaptive brightness is enabled. Toggle the switch to disable.

Setting Night Light

The Night Light setting tints the screen amber, making the screen easier to look at in low light.

1. Go to Settings.

2. Touch Display.

3. Touch Night Light.

4. Touch Schedule.

5. Select one of the schedule values:

• None (default)

• Turns on at custom time

• Turns on from sunset to sunrise.

6. By default, Night Light is disabled. Touch TURN ON NOW to enable.

7. Adjust the tint using the Intensity slider.

Setting Screen Timeout

Settings

The screen turns off and goes into Sleep mode after the selected period of inactivity.

1. Go to Settings.

2. Touch Display > Advanced > Screen timeout.

3. Select one of the screen timeout values.

• 15 seconds (default)

• 30 seconds

• 1 minute

• 2 minutes

• 5 minutes

• 10 minutes

• 30 minutes

Setting Screen Rotation

By default, screen rotation is enabled.

NOTE: To change the Home screen rotation, see Setting Home Screen Rotation.

1. Go to Settings.

2. Touch Display > Advanced.

3. Touch Auto-rotate screen.

Setting Lock Screen Notifications

The lock screen display setting wakes the screen when notifications are received.

1. Go to Settings.

2. Touch Display > Advanced.

3. Touch Lock screen.

4. In the When to show section, enable or disable an option using the switch.

Setting Font Size

Set the size of the font in system apps.

1. Go to Settings.

2. Touch Display > Advanced.

3. Touch Font size.

4. Select an option to choose how long the touch key light stays on:

• Small

Settings

• Default

• Large

• Largest.

Notification LED Brightness Level

1. Go to Settings.

2. Touch Display > Advanced.

3. Touch Notification LED Brightness Level.

4. Use the slider to set the brightness value (default: 15).

Setting Touch Panel Mode

The device display is able to detect touches using a finger or gloved finger.

NOTE: A glove can be made of medical latex, leather, cotton, or wool. The device supports light to medium weight gloves, and may not detect touches from heavy outdoor gloves.

1. Go to Settings.

2. Touch Display > Advanced.

3. Touch Touch Panel Mode.

• Finger Only to use a finger on the screen.

• Finger and Glove to use a finger or a gloved finger on the screen.

Setting the Date and Time

The date and time are automatically synchronized using a NITZ server when the device is connected to a cellular network.You are only required to set the time zone or set the date and time if the wireless LAN does not support Network Time Protocol (NTP) or when not connected to a cellular network.

1. Go to Settings.

2. Touch System > Date & time.

3. Touch Use network-provided time to disable automatic date and time synchronization.

4. Touch Use network-provided time zone to disable automatic time zone synchronization.

5. Touch Update Interval to select an interval to synchronize the system time from the network.

6. Touch Date to select the date in the calendar.

7. Touch OK.

8. Touch Time.

a) Touch the green circle, drag to the current hour, and then release.

b) Touch the green circle, drag to the current minute, and then release.

Settings

c) Touch AM or PM.

9. Touch OK.

10. Touch Time zone to select the current time zone from the list.

11. In TIME FORMAT, choose either Use local default or Use 24-hourformat.

General Sound Setting

Press the volume buttons on the device to display on-screen volume controls.

Use the Sound settings to configure media and alarm volumes.

1. Go to Settings.

2. Touch Sound.

3. Touch an option to set sounds.

Sound Options

• Media volume - Controls the music, games, and media volume.

• Call volume - Controls the volume during a call.

• Alarm volume - Controls the alarm clock volume.

• Notifications volume - Controls the notification volume.

• Do Not Disturb - Mutes some or all sounds and vibrations.

• Media - Shows the media player in Quick Settings while sound is playing, allowing quick access.

• Shortcut to prevent ringing - Turn on the switch to make the device vibrate when a call is received (default – disabled).

• Phone ringtone - Select a sound to play when the phone rings.

• Default notification sound - Select a sound to play for all system notifications.

• Default alarm sound - Select a sound to play for alarms.

• Other sounds and vibrations

• Dial pad tones - Play a sound when pressing keys on dial pad (default - disabled).

• Screen locking sounds - Play a sound when locking and unlocking the screen (default – enabled).

• Charging sounds and vibration - Plays a sound and vibrates when power is applied to the device

(default - enabled).

• Touch sounds - Play a sound when making screen selections (default – enabled).

• Touch vibration - Vibrate the device when making screen selections (default – enabled).

Setting Wake-Up Sources

By default, the device wakes from Sleep mode when the user presses Power. The device can be configured to wake when the user presses PTT or Scan on the left side of the device handle.

1. Go to Settings.

2. Touch Wake-Up Sources.

Settings

• GUN_TRIGGER - Programmable button on the Trigger Handle accessory.

• LEFT_TRIGGER_2 - PTT button.

• REAR_BUTTON - Programmable button on the back of healthcare devices.

• RIGHT_TRIGGER_1 - Right scan button.

• SCAN - Left scan button.

3. Touch a checkbox. A check appears in the checkbox.

Remapping a Button

Buttons on the device can be programmed to perform different functions or as shortcuts to installed apps. For a list of key names and descriptions, refer to: techdocs.zebra.com.

NOTE: It is not recommended to remap the scan button.

1. Go to Settings.

2. Touch Key Programmer. A list of programmable buttons displays.

3. Select the button to remap.

4. Touch the SHORTCUT, the KEYS and BUTTONS, or the TRIGGERS tabs that lists the available

functions, applications, and triggers.

5. Touch a function or application shortcut to map to the button.

NOTE: If you select an application shortcut, the application icon appears next to the button on

the Key Programmer screen.

Remappable Keys

Figure 7Remappable Keys

Settings

Table 6Key Positions

1 SCAN Left scan button.

2 LEFT_TRIGGER_2 Typically used for Push-to-Talk communications.

Where regulatory restrictions exista for Pushto-Talk VoIP communication, this button is configurable for use with other applications.

3 GUN_TRIGGER Optional trigger handle scan button.

4 VOLUMEDOWN Volume down button.

VOLUMEUP Volume up button.

6 RIGHT_TRIGGER_1 Right scan button.

7 REAR_BUTTON Programmable button on back of device that is a

scan button by default (healthcare devices only).

Pakistan, Egypt, Jordan, Qatar

Alert Button

Configure any remappable key on the device as an alert button using StageNow.

Use an Alert button to launch an app and a command, or call a specified phone number. Healthcare devices provide a red button on the back of the device for this purpose.

Configure the Alert Button

This section provides basic configuration. For detailed information on configuring the Alert button, refer to

zebra.techdocs.com/stagenow.

Configure the Alert button through StageNow, using the following Configuration Service Providers (CSPs).

• PowerMgr - Set All Wake-Up Sources to Turn on. This wakes the device if it is in Sleep mode.

• Intent - Create a new setting:

• Mode - Set to Schedule sending of Intent on key presses.

• Keep Device Awake - Enable this option to keep the device awake after the short key press.

• Key Identifier - Select a remappable key. For example, Rear Button.

Settings

• Android Action Name - Enter the action name. For example, to initiate a call, enter

android.intent.action.CALL.

• URI - Enter the URI. For example, to place a call to a phone number, enter tel:123456789.

• KeyMappingMgr - Modify the default behavior of the button.It is recommended to set this to None. Otherwise, the button performs its default behavior in addition to sending an alert.

Alert Accessibility Service

After the Alert button is configured using StageNow, the Alert Accessibility Service is available on the device.

Go to Settings > Accessibility > Alert Accessibility service to enable or disable the alert button. When the device reboots, Alert Accessibility Service is automatically enabled.

Using an Alert Button

Activate the Alert button using a long-press of at least one second to prevent accidental alerts.

• If the device is in Sleep mode, perform a short-press on the Alert button, followed by a long-press.

• If the device is awake, perform a long-press on the Alert button.

Keyboards

The device provides multiple keyboard options.

• Android Keyboard - AOSP devices only

• Gboard - GMS devices only

• Enterprise Keyboard - Only available with Mobility DNA Enterprise License.

NOTE: By default, the Enterprise and Virtual Keyboards are disabled.TheEnterpriseKeyboard is available for download from the Zebra Support Site.

Enabling Keyboards

1. Go to Settings.

2. Touch System > Languages & input > Virtual keyboard > Manage keyboards.

3. Touch a keyboard to enable.

Switching Between Keyboards

To switch between keyboards, touch in a text box to display the current keyboard.

NOTE: By default, the Gboard is enabled. All other virtual keyboards are disabled.

•

On the Gboard keyboard, touch and hold (GMS devices only).

•

On the Android keyboard, touch, and hold (AOSP devices only).

•

On the Enterprise keyboard, touch . Only available with Mobility DNA Enterprise License. Not preinstalled on the device. Contact Zebra Support for more information.

Settings

Using the Android and Gboard Keyboards

Use the Android or Gboard keyboards to enter text in a text field.

• To configure the keyboard settings, touch and hold "," (comma) and then select Android keyboard

settings.

Edit Text

Edit entered text and use menu commands to cut, copy, and paste text within or across apps. Some apps do not support editing some or all of the text they display; others may offer their own way to select text.

Entering Numbers, Symbols, and Special Characters

1. Enter numbers and symbols.

• Touch and hold one of the top-row keys until a menu appears then select a number or special

character.

• Touch the Shift key once for a single capital letter. Touch the Shift key twice to lock in uppercase.

Touch the Shift key a third time to unlock Capslock.

• Touch ?123 to switch to the numbers and symbols keyboard.

• Touch the =\< key on the numbers and symbols keyboard to view additional symbols.

2. Enter special characters.

• Touch and hold a number or symbol key to open a menu of additional symbols. A larger version of

the key displays briefly over the keyboard.

Enterprise Keyboard

The Enterprise Keyboard contains multiple keyboard types.

NOTE: Only available with Mobility DNA Enterprise License.

• Numeric

• Alpha

• Special characters

• Data capture.

Numeric Tab

The numeric keyboard is labeled 123. The keys displayed vary on the app being used. For example, an arrow displays in Contacts, however Done displays in Email account setup.

Alpha Tab

Settings

The alpha keyboard is labeled using the language code. For English, the alpha keyboard is labeled EN.

Additional Character Tab

The additional characters keyboard is labeled #*/.

•

Touch to enter emoji icons in a text message.

• Touch ABC to return to the Symbols keyboard.

Scan Tab

The Scan tab provides an easy data capture feature for scanning barcodes.

Language Usage

Use the Language & input settings to change the device’s language, including words added to the dictionary.

Changing the Language Setting

1. Go to Settings.

2. Touch System > Languages & input.

3. Touch Languages. A list of available languages displays.

4. If the desired language is not listed, touch Add a language and select a language from the list.

Touch and hold to the right of the desired language, then drag it to the top of the list.

6. The operating system text changes to the selected language.

Adding Words to the Dictionary

1. Go to Settings.

2. Touch System > Languages & input > Advanced > Personal dictionary .

3. If prompted, select the language where this word or phase is stored.

4. Touch + to add a new word or phrase to the dictionary.

5. Enter the word or phrase.

6. In the Shortcut text box, enter a shortcut for the word or phrase.

Notifications

The user can configure notifications for the device and for specific apps. Device notifications settings allow the user to configure how notifications occur on the device. App notification settings allow the user to configure how notifications for a specific app occur.

To view device notification settings, touch Settings > Apps & notifications > Notifications. To view app notifications, Settings > Apps & notifications > App info, and then select an app.

Settings

Enabling Blink Light

The Notification LED lights blue when an app, such as email and VoIP, generates a programmable notification or to indicate when the device is connected to a Bluetooth device. By default, LED notifications are enabled.

1. Go to Settings.

2. Touch Apps & notifications > Notifications > Advanced .

3. Touch Blink light to toggle the notification on or off.

Applications

Apart from the standard pre-installed Android applications, the following table lists Zebra-specific applications installed on the device.

Installed Applications

Aside from the common Google apps, the Zebra-specific apps that are installed on the device are described in this section.

Table 7Apps

Icon Description

Battery Manager - Displays battery information, including charge level, status,

health and wear level.

Bluetooth Pairing Utility - Use to pair peripherals with the device by scanning a barcode.

Camera - Take photos or record videos.

DataWedge - Enables data capture using the imager.

DisplayLink Presenter - Use to present the device screen onto a connected

monitor.

DWDemo - Provides a way to demonstrate the data capture features using the imager.

License Manager - Use to manage software licenses on the device.

Table 7Apps (Continued)

Icon Description

Music - Play music stored on the microSD card. Play music stored on the internal

storage.Play music stored on the microSD card or internal storage. Non-GMS devices only.AOSP only.

Phone - Use to dial a phone number when used with some Voice over IP (VoIP) clients (VoIP telephony ready only). WAN devices only.

RxLogger - Use to diagnose device and app issues.

Settings - Use to configure the device.

StageNow - Allows the device to stage a device for initial use by initiating the

deployment of settings, firmware, and software.

Applications

Accessing Apps

Accessall apps installed on the device using the APPS window.

1. On the Home screen, swipe up from the bottom of the screen.

2. Slide the APPS window up or down to view more app icons.

3. Touch an icon to open the app.

VoD - The Video on Device basic app provides a how-to video for proper device

cleaning. For Video on Device licensing information, go to learning.zebra.com.

Worry Free Wifi Analyzer - A diagnostic intelligent app. Use to diagnose surrounding area and display network stats, such as coverage hole detection, or AP in the vicinity. Refer to the Worry Free Wi-Fi Analyzer Administrator Guide for Android.

Zebra Bluetooth Settings - Use to configure Bluetooth logging.

Zebra Data Services - Use to enable or disable Zebra Data Services. Some

options are set by the system administrator.

Switching Between Recent Apps

1. Touch Recent.

A window appears on the screen with icons of recently used apps.

2. Slide the apps displayed up and down to view all recently used apps.

3. Swipe left or right to remove the app from the list and force close the app.

4. Touch an icon to open an app or touch Back to return to the current screen.

Battery Manager

The Battery Manager provides detailed information about the battery.

Opening Battery Manager

•

To open the Battery Manager app, swipe up from the bottom of the Home screen, and then touch .

Battery Manager Information

The Battery Manager displays detailed information about battery charging, health, and status.

Table 8Battery Icons

Applications

Battery Icon Description

Battery charge level is between 85% and 100%.

Battery charge level is between 19% and 84%.

Battery charge level is between 0% and 18%.

• Level - The current battery charge level as a percentage. Displays -% when the level is unknown.

• Wear - The health of the battery in graphical form. When the wear level exceeds 80%, the bar color changes to red.

•

Health - The health of the battery. If a critical error occurs, appears. Touch to view the error description.

• Decommission - The battery is past its useful life and should be replaced. See system administrator.

• Good - The battery is good.

• Charge error - An error occurred while charging. See system administrator.

• Over Current - An over-current condition occurred. See system administrator.

• Dead - The battery has no charge. Replace the battery.

• Over Voltage - An over-voltage condition occurred. See system administrator.

• Below Temperature - The battery temperature is below the operating temperature. See system

administrator.

• Failure Detected - A failure has been detected in the battery. See system administrator.

• Unknown - See system administrator.

Applications

• Charge Status

• Not charging - The device is not connected to AC power.

• Charging-AC - The device is connected to AC power and charging or is fast charging via USB.

• Charging-USB - The device is connected to a host computer with a USB cable and charging.

• Discharging - The battery is discharging.

• Full - The battery is fully charged.

• Unknown - The battery status is unknown.

• Time until Full - The amount of time until the battery is fully charged.

• Time since charging - The amount of time since the device began charging.

• Advanced info - Touch to view additional battery information.

• Battery present status - Indicates that the battery is present.

• Battery level - The battery charge level as a percentage of scale.

• Battery scale - The battery scale level used to determine battery level (100).

• Battery voltage - The current battery voltage in millivolts.

Camera

• Battery temperature - The current battery temperature in degrees Centigrade.

• Battery technology - The type of battery.

• Battery current - The average current into or out of the battery over the last second in mAh.

• Battery manufacture date - The date of manufacture.

• Battery serial number - The battery serial number. The number matches the serial number printed

on the battery label.

• Battery part number - The battery part number.

• Battery decommission status - Indicates if the battery is past its life span.

• Battery Good - The battery is in good health.

• Decommissioned Battery - The battery is past its useful life and should be replaced.

• Base cumulative charge - Cumulative charge using Zebra charging equipment only.

• Battery error status - The error status of the battery.

• App version - The application version number.

This section provides information for taking photos and recording videos using the integrated digital cameras.

NOTE: The device saves photos and videos on the microSD card, if installed and the storage path is changed manually. By default, or if a microSD card is not installed, the device saves photos and videos on internal storage.

On camera only devices without an internal scan engine, the back camera is used for barcode scanning.

When the front camera is used by an app, such as for indoor locationing, the back camera becomes disabled and cannot be used for barcode scanning.

Taking Photos

1. Swipe up from the bottom of the Home screen and touch Camera.

Applications

1 Scene mode and settings

2 Filters

3 Camera switch (available on devices with a rear camera and front camera)

4 Flash

5 Video recording button

6 Camera shutter button

7 Gallery

To switch between the rear camera and front camera (if available), touch .

3. Frame the subject on the screen.

4. To zoom in or out, press two fingers on the display and pinch or expand your fingers. The zoom controls

appear on the screen.

5. Touch an area on the screen to focus. The focus circle appears. The two bars turn green when in focus.

Touch .

The camera takes a photo and a shutter sound plays.

The photo momentarily displays as a thumbnail in the lower-left corner.

Recording Videos

1. Swipe up from the bottom of the Home screen and touch Camera.

Touch the camera mode menu and touch .

Applications

1 Audio

2 Flash

3 Pause recording

4 Shutter button (stop recording)

5 Take photo

6 Gallery

3. Point the camera and frame the scene.

4. To zoom in or out, press two fingers on the display and pinch or expand fingers. The zoom controls appear on the screen.

Touch to start recording.

The video time remaining appears in the top left of the screen.

Touch to end the recording.

The video momentarily displays as a thumbnail in the lower left corner.

Camera Settings

In Photo mode, camera settings appear on the screen. Touch ••• > to display the camera settings options.

• General - These settings apply to both the still camera and video camera.

• GPS location - Turn On(default)or Off.

• Face Detection - Select to turn face detection Off (default) or On.

• Storage – Set the location to store the photo to: Phone or SD Card.

Applications

• Still Camera - These settings apply only to the still camera.

• Countdown timer - Select Off (default), 2 seconds, 5 seconds or 10 seconds.

• Continuous Shot - Select to take a series of photos quickly while holding the capture button. Off

(default) or On.

• SelfieMirror -Select to save a mirror image of the photo. Available for the front camera only.

Options:Off (default) or On.

• Picture size - The size (in pixels) of the photo to: 13M pixels (rear camera default), 8M pixels, 5M

pixels (front camera default), 3M pixels, HD1080, 2M pixels, HD720, 1M pixels, or WVGA.

• Picture quality - Set the picture quality setting to: Low, Standard, or High (default).

• Redeye reduction - Helps eliminate the redeye effect. Available for the rear camera only. Options:

Disabled (default), or Enable.

• Exposure - Set the exposure settings to: -2, -1.5, -1, -0.5, 0 (default), +0.5, +1, +1.5, +2.

• White balance - Select how the camera adjusts colors in different kinds of light, to achieve the most

natural-looking colors:

• Incandescent - Adjust the white balance for incandescent lighting.

• Fluorescent - Adjust the white balance for fluorescent lighting.

• Auto - Adjust the white balance automatically (default).

• Daylight - Adjust the white balance for daylight.

• Cloudy - Adjust the white balance for a cloudy environment.

• Shutter Sound - Select to play a shutter sound when taking a photo. Options: Disable or Enable

(default).

• Selfie Flash - Turns the screen white to help produce a little extra light in dimmer settings.

Availablefor the front camera only. Options: Off (default), or On.

• AF Animation -Select to enable or disable the camera focus ring in the camera preview. Options:

Disable (default) or Enable.

• Picture Format - All still images are saved in JPEG format.

• Video Camera - These settings apply only to the video camera.

• Video quality - Set video quality to: 4k UHD (supported on 4GB RAM devices only), HD 1080p

(default), HD 720p, SD 480p, VGA, CIF, or QVGA.

• Video duration - Set to: 30 seconds (MMS), 10 minutes, 30 minutes (default), or no limit.

• Image Stabilization - Set to reduce blurry videos due to device movement. Options: On or Off

(default).

• Noise Reduction - Off (default), Fast, or High Quality.

• Video Encoder - Set the video encoder to: MPEG4, H264 (default), or H265.

• Audio Encoder - Set the audio encoder to: AMRNB, or AAC (default).

• Video Rotation - Set the rotation of the video to: 0 (default), 90, 180, or 270.

• Time Lapse - Set the time lapse interval to: Off (default), or a time between 0.5 seconds and 24

hours.

• System

• Restore default - Select to restore all settings to the default values.

• Version Info - Displays the software version of the camera app.

DataWedge Demonstration

Use DataWedge Demonstration (DWDemo) to demonstrate data capture functionality. To configure DataWedge, refer to techdocs.zebra.com/datawedge/.

NOTE: DataWedge is enabled on the Home screen. To disable this feature, go to the DataWedge settings and disable the Launcher profile.

DataWedge Demonstration Icons

Table 9DataWedge Demonstration Icons

Category Icon Description

Illumination Imager illumination is on. Touch to turn illumination

Illumination Imager illumination is off. Touch to turn illumination

Applications

off.

on.

Data Capture The data capture function is through the internal

Data Capture A Bluetooth scanner is connected.

Data Capture A Bluetooth scanner is not connected.

Scan Mode Imager is in picklist mode. Touch to change to normal

Scan Mode Imager is in normal scan mode. Touch to change to

Menu Opens a menu to view the application information or

Selecting a Scanner

See the Data Capture section for more information.

•

To select a scanner, touch > Settings > Scanner Selection.

• Press the programmable button or touch the yellow scan button to capture data. The data appears in the text field below the yellow button.

imager.

scan mode.

picklist mode.

to set the application DataWedge profile.

RxLogger

RxLogger is a comprehensive diagnostic tool that provides application and system metrics, and diagnoses device and application issues.

RxLogger logs the following information: CPU load, memory load, memory snapshots, battery consumption, power states, wireless logging, cellular logging, TCP dumps, Bluetooth logging, GPS logging, logcat, FTP push/pull, ANR dumps, etc. All generated logs and files are saved onto flash storage on the device (internal or external).

RxLogger Configuration

RxLogger is built with an extensible plug-in architecture and comes packaged with a number of plug-ins already built-in. For information on configuring RxLogger, refer to techdocs.zebra.com/rxlogger/.

To open the configuration screen, from the RxLogger home screen touch Settings.

Configuration File

RxLogger configuration can be set using an XML file.

The config.xml configuration file is located on the microSD card in the RxLogger\config folder. Copy the file from the device to a host computer using a USB connection. Edit the configuration file and then replace the XML file on the device. There is no need to stop and restart the RxLogger service since the file change is automatically detected.

Applications

Enabling Logging

Swipe the screen up and select .

2. Touch Start.

Disabling Logging

Swipe the screen up and select .

2. Touch Stop.

Extracting Log Files

1. Connect the device to a host computer using an USB connection.

2. Using a file explorer, navigate to the RxLogger folder.

3. Copy the file from the device to the host computer.

4. Disconnect the device from the host computer.

Backing Up Data

RxLogger Utility allows the user to make a zip file of the RxLogger folder in the device, which by default contains all the RxLogger logs stored in the device.

•

To save the backup data, touch > BackupNow.

RxLogger Utility

RxLogger Utility is a data monitoring application for viewing logs in the device while RxLogger is running. Logs and RxLogger Utility features are accessed using Main Chat Head.

Initiating the Main Chat Head

1. Open RxLogger.

Touch > Toggle Chat Head.

The Main Chat Head icon appears on the screen.

3. Touch and drag the Main Chat head icon to move it around the screen.

Removing the Main Chat Head

1. Touch and drag the icon.

A circle with an X appears.

2. Move the icon over the circle and then release.

Applications

Viewing Logs

1. Touch the Main Chat Head icon.

The RxLogger Utility screen appears.

2. Touch a log to open it.

The user can open many logs with each displaying a new Sub Chat Head.

3. If necessary, scroll left or right to view additional Sub Chat Head icons.

4. Touch a Sub Chat Head to display the log contents.

Removing a Sub Chat Head Icon

• To remove a Sub Chat Head icon, press and hold the icon until it disappears.

Backing Up In Overlay View

RxLogger Utility allows the user to make a zip file of the RxLogger folder in the device, which by default contains all the RxLogger logs stored in the device.

The Backup icon is always available in Overlay View.

Touch .

The Backup dialog box appears.

2. Touch Yes to create the backup.

Data Capture

This section provides information for capturing barcode data using various scanning options.

The device supports data capture using:

• Internal Linear Imager

• Integrated Camera

• RS507/RS507X Hands-free Imager

• RS5100 Bluetooth Ring Scanner

• RS6000 Hands-free Imager

• DS3578 Bluetooth scanner

• DS3678 Digital Scanner

• DS8178 Digital Scanner

Imaging

The device with an integrated 2D imager has the following features:

• Omnidirectional reading of a variety of barcode symbologies, including the most popular linear, postal, PDF417, Digimarc, and 2D matrix code types.

• The ability to capture and download images to a host for a variety of imaging applications.

• Advanced intuitive laser aiming cross-hair and dot aiming for easy point-and-shoot operation.

The imager uses imaging technology to take a picture of a barcode, stores the resulting image in memory, and executes state-of-the-art software decoding algorithms to extract the barcode data from the image.

Digital Camera

The device with an integrated camera based barcode scanning solution has the following features:

NOTE: The integrated camera is intended for light-duty barcode scanning. For heavy-duty scanning, 100 or more scans per day, use the 2D imager.

• Omnidirectional reading of a variety of barcode symbologies, including the most popular linear, postal, QR, PDF417, and 2D matrix code types.

• Cross-hair reticle for easy point-and-shoot operation.

• Picklist mode to decode a particular barcode from many in the field of view.

The solution uses the advanced camera technology to take a digital picture of a barcode, and executes state-of-the-art software decoding algorithms to extract the data from the image.

On camera only devices without an internal scan engine, the back camera is used for barcode scanning.When the front camera is used by an app, such as for indoor locationing, the back camera becomes disabled and cannot be used for barcode scanning.

Linear Imager

The device with an integrated linear imager has the following features:

• Reading a variety of bar code symbologies, including the most popular 1-D code types.

• Intuitive aiming for easy point-and-shoot operation.

The imager uses imaging technology to take a picture of a bar code, stores the resulting image in its memory, and executes state-of-the-art software decoding algorithms to extract the bar code data from the image.

Operational Modes

The device with an integrated imager supports three modes of operation.

Data Capture

Activate each mode by pressing Scan.

• Decode mode — The device attempts to locate and decode enabled barcodes within its field of view. The imager remains in this mode as long as you hold the scan button, or until it decodes a barcode.

NOTE: To enable Pick List Mode, configure in DataWedge or set in an application using a API command.

• Pick List mode—Selectively decode a barcode when more than one barcode is in the device’s field of view by moving the aiming crosshair or dot over the required barcode. Use this feature for pick lists containing multiple barcodes and manufacturing or transport labels containing more than one barcode type (either 1D or 2D).

NOTE: To enable Basic MultiBarcode Mode, configure in DataWedge or set in an application using a API command.

• Basic MultiBarcode Mode — In this mode, the device attempts to locate and decode a specific number of unique barcodes within its field of view. The device remains in this mode as long as the user holds the scan button, or until it decodes all the barcodes.

• The device attempts to scan the programmed number of unique barcodes (from 2 through 100).

• If there are duplicate barcodes (same symbology type and data), only one of the duplicate barcodes

is decoded and the remainder are ignored. If the label has two duplicate barcodes plus another two different barcodes, a maximum of three barcodes will be decoded from that label; one will be ignored as a duplicate.

• Barcodes can be of multiple symbology types and still be acquired together. For example, if the

specified quantity for a Basic MultiBarcode scan is four, two barcodes can be symbology type Code 128 and the other two can be symbology type Code 39.

• If the specified number of unique barcodes is not initially in view of the device, the device will not

decode any data until the device is moved to capture the additional barcode(s) or time out occurs. If the device field of view contains a number of barcodes greater than the specified quantity, the device randomly decodes barcode(s) until the specified number of unique barcodes is reached. For

example, if the count is set to two and eight barcodes are in the field of view, the device decodes the first two unique barcodes it sees, returning the data in random order.

• Basic MultiBarcode Mode does not support concatenated barcodes.

Scanning Considerations

Typically, scanning is a simple matter of aim, scan, and decode, with a few quick trial efforts to master it.

However, consider the following to optimize scanning performance:

• Range— Scanners decode best over a particular working range — minimum and maximum distances from the barcode. This range varies according to barcode density and scanning device optics. Scan within range for quick and constant decodes; scanning too close or too far away prevents decodes. Move the scanner closer and further away to find the right working range for the barcodes being scanned.

• Angle—Scanning angle is important for quick decodes. When the illumination/flash reflects directly back into the imager, the specular reflection can blind/saturate the imager. To avoid this, scan the barcode so that the beam does not bounce directly back. Do not scan at too sharp an angle; the scanner needs to collect scattered reflections from the scan to make a successful decode. Practice quickly shows what tolerances to work within.

Data Capture

• Hold the device farther away for larger symbols.

• Move the device closer for symbols with bars that are close together.

NOTE: Scanning procedures depend on the app and device configuration. An app may use different scanning procedures from the one listed above.

Scanning with the Internal Imager

Use the internal imagerto capture barcode data.

1. Ensure that an application is open on the device and a text field is in focus (text cursor in text field).

Data Capture

2. Point the exit window of the device at a barcode.

3. Press and hold thescan button.

The red laser aiming pattern turns on to assist in aiming.

NOTE: When the device is in Pick List Mode, the device does not decode the barcode until the center of the crosshair touches the barcode.

4. Ensure the barcode is within the area formed by the aiming pattern.The aiming dot is used for increased visibility in bright lighting conditions.

The Data Capture LED lights green and a beep sounds, by default, to indicate the barcode was decoded successfully.

5. Release the scan button.

NOTE: Imager decoding usually occurs instantaneously. The device repeats the steps

required to take a digital picture (image) of a poor or difficult barcode as long as the scan button remains pressed.

The barcode content data displays in the text field.

Scanning with Internal Camera

Use theinternal camera to capture barcode data.

NOTE: To read a barcode, a scan-enabled app is required.The device contains the DataWedge app that allows the user to enable the scanner to decode barcode data and display the barcode content.

NOTE: The integrated camera is intended for light-duty barcode scanning. For heavy-duty scanning, 100 or more scans per day, use the 2D imager.

When capturing barcode data in poor lighting, turn on Illumination mode in the DataWedge application.

To scan with the internal camera:

Data Capture

1. Launch a scanning application.

2. Point the camera window at a barcode.

3. Press and hold thescan button. By default, a preview window appears on the screen.

4. Move the device until the barcode is visible on the screen.

Data Capture

5. If Picklist mode is enabled, move the device until the barcode is centered under the aiming dot on the screen.

6. The Decode LED lights green, a beep sounds and the device vibrates, by default, to indicate the barcode is decoded successfully.

The captured data appears in the text field.

Scanning with the RS507/RS507X Hands-Free Imager

Use theRS507/RS507X Hands-Free Imagerto capture barcode data.

Figure 8RS507/RS507X Hands-Free Imager

Refer to the RS507/RS507X Hands-free Imager Product Reference Guide for more information.

NOTE: To read a barcode, a scan-enabled app is required.The device contains the DataWedge app that allows the user to enable the scanner to decode barcode data and display the barcode content.

To scan with the RS507/RS507x:

1. Pair the RS507/RS507X with the device.

2. Ensure that an app is open on the device and a text field is in focus (text cursor in text field).

3. Point the RS507/RS507X at a barcode.

Data Capture

4. Press and hold the trigger.

The red laser aiming pattern turns on to assist in aiming. Ensure the barcode is within the area formed by the cross-hairs in the aiming pattern. The aiming dot increases visibility in bright lighting conditions.

Figure 9RS507/RS507X Aiming Pattern

When the RS507/RS507X is in Pick List mode, the RS507/RS507X does not decode the barcode until the center of the crosshair touches the barcode.

Figure 10RS507/RS507X Pick List Mode with Multiple Barcodes in Aiming Pattern

The RS507/RS507X LEDs light green and a beep sounds to indicate the barcode was decoded successfully.

The captured data appears in the text field.

Data Capture

Scanning with the RS5100 Ring Scanner

Use the RS5100 Ring Scanner to capture barcode data.

Figure 11RS5100 Ring Scanner

Refer to the RS5100 Ring Scanner Product Reference Guide for more information.

NOTE: To read a barcode, a scan-enabled app is required.The device contains the DataWedge app that allows the user to enable the scanner to decode barcode data and display the barcode content.

To scan with the RS5100:

1. Pair the RS5100 with the device.

2. Ensure that an app is open on the device and a text field is in focus (text cursor in text field).

3. Point the RS5100 at a barcode.

Data Capture

4. Press and hold the trigger.

Figure 12RS5100 Aiming Pattern

When the RS5100 is in Pick List mode, the RS5100 does not decode the barcode until the center of the crosshair touches the barcode.

Figure 13RS5100 Pick List Mode with Multiple Barcodes in Aiming Pattern

The RS5100 LEDs light green and a beep sounds to indicate the barcode was decoded successfully.

The captured data appears in the text field.

Scanning with the RS6000 Bluetooth Ring Scanner

Use the RS6000 Bluetooth Ring Scanner to capture barcode data.

Figure 14RS6000 Bluetooth Ring Scanner

Data Capture

Refer to the RS6000 Bluetooth Ring Scanner Product Reference Guide for more information.

NOTE: To read a barcode, a scan-enabled app is required.The device contains the DataWedge app that allows the user to enable the scanner to decode barcode data and display the barcode content.

To scan with the RS6000:

1. Pair the RS6000 with the device.

2. Ensure that an app is open on the device and a text field is in focus (text cursor in text field).

3. Point the RS6000 at a barcode.

Data Capture

4. Press and hold the trigger.

Figure 15RS6000 Aiming Pattern

When the RS6000 is in Pick List mode, the RS6000 does not decode the barcode until the center of the crosshair touches the barcode.

Figure 16RS6000 Pick List Mode with Multiple Barcodes in Aiming Pattern

The RS6000 LEDs light green and a beep sounds to indicate the barcode was decoded successfully.

The captured data appears in the text field.

Data Capture

Scanning with the DS3578 Bluetooth Scanner

Use the DS3678 Bluetooth Scanner to capture barcode data.

Figure 17DS3678 Digital Scanner

Refer to the DS3678 Product ReferenceGuide for more information.

NOTE: To read a barcode, a scan-enabled app is required.The device contains the DataWedge app that allows the user to enable the scanner to decode barcode data and display the barcode content.

To scan with the DS3578 scanner:

1. Pair the scanner with the device. See Pairing Bluetooth Scanners for more information.

2. Ensure that an app is open on the device and a text field is in focus (text cursor in text field).

Data Capture

3. Point the scanner at a barcode.

4. Press and hold the trigger.

Ensure the barcode is within the area formed by the aiming pattern. The aiming dot increases visibility in bright lighting conditions.

The captured data appears in the text field.

Data Capture

Scanning with the DS3678 Bluetooth Scanner

Use the DS3678 Bluetooth Scanner to capture barcode data.

Figure 18DS3678 Digital Scanner

Refer to the DS3678 Product ReferenceGuide for more information.

NOTE: To read a barcode, a scan-enabled app is required.The device contains the DataWedge app that allows the user to enable the scanner to decode barcode data and display the barcode content.

To scan with the DS3678 scanner:

1. Pair the scanner with the device. See Pairing Bluetooth Scanners for more information.

2. Ensure that an app is open on the device and a text field is in focus (text cursor in text field).

3. Point the scanner at a barcode.

4. Press and hold the trigger.

Data Capture

Ensure the barcode is within the area formed by the aiming pattern. The aiming dot increases visibility in bright lighting conditions.

The captured data appears in the text field.

Data Capture

Scanning with the DS8178 Digital Scanner

Use the DS8178 Bluetooth Scanner to capture barcode data.

Figure 19DS8178 Digital Scanner

Refer to the DS8178 Digital Scanner Product Reference Guide for more information.

NOTE: To read a barcode, a scan-enabled app is required.The device contains the DataWedge app that allows the user to enable the scanner to decode barcode data and display the barcode content.

To scan with the DS8178 scanner:

1. Pair the scanner with the device.See Pairing Bluetooth Scanners for more information.

2. Ensure that an app is open on the device and a text field is in focus (text cursor in text field).

3. Point the scanner at a barcode.

4. Press and hold the trigger.

Data Capture

5. Ensure the barcode is within the area formed by the aiming pattern. The aiming dot increases visibility in bright lighting conditions.

6. Upon successful decode, the scanner beeps and the LED flashes, and the scan line turns off.The captured data appears in the text field.

Pairing the Bluetooth Ring Scanner

Before using a Bluetooth Ring Scanner with the device, connect the device to the Ring Scanner.

To connect the Ring Scanner to the device, use one of the following methods:

• Near Field Communication (NFC) (RS5100 and RS6000 only)

• Simple Serial Interface (SSI)

• Bluetooth Human Interface Device (HID) Mode.

NOTE: When establishing a connection, a pairing confirmation prompt may appear on devices without a Mobility DNA Enterprise License.

Pairing in SSI Mode Using Near Field Communication

The device provides the ability to pair theRS5100 orRS6000 Ring Scanner in SSI Mode using NFC.

1. Ensure that NFC is enabled on the device.

Data Capture

2. Align the NFC icon on the Ring Scanner with the NFC icon on the back of the device.

1 NFC logo

The Status LED blinks blue indicating that the Ring Scanner is attempting to establish a connection with the device. When a connection is established, the Status LED turns off and the Ring Scanner emits a single string of low/high beeps.

A notification appears on the device screen.

The icon appears in the Status bar.

Pairing in HID Mode Using Near Field Communication

The device provides the ability to pair theRS5100 orRS6000 Ring Scanner in HID Mode using NFC.

1. Ensure that NFC is enabled on the device.

2. Ensure that Bluetooth is enabled on both devices.

3. Ensure that the Bluetooth device to discover is in discoverable mode.

4. Ensure that the two devices are within 10 meters (32.8 feet) of one another.

Data Capture

5. Place the Ring Scanner in Human Interface Device (HID) mode. If theRing Scanneris already in HID mode, skip to step 6.

a) Remove the battery from theRing Scanner.

b) Press and hold the Restore key.

c) Install the battery onto theRing Scanner.

d) Keep holding the Restore key for about five seconds until a chirp is heard and the Scan LEDs flash

green.

e) Scan the barcode below to place theRing Scannerin HID mode.

Figure 20Bluetooth HID Barcode

6. Remove the battery from theRing Scanner.

7. Re-install the battery into theRing Scanner.

8. Align the NFC icon on theRing Scannerwith the NFC icon on thedevice.

1 NFC logo

A notification appears on the device screen.

The icon appears in the Status bar.

Pairing a Bluetooth Scanner

Before using a Bluetooth scanner with the device, connect the device to the Bluetooth scanner.

Connect the scanner to the device using one of the following methods:

• Simple Serial Interface (SSI) mode

• Bluetooth Human Interface Device (HID) mode

Pairing Using Simple Serial Interface

Pair the Ring Scanner to the device using Simple Serial Interface.

1. Ensure that the two devices are within 10 meters (32.8 feet) of one another.

2. Install the battery into the scanner.

Swipe up from the bottom of the Home screen and touch .

Data Capture

4. Using the Ring Scanner, scan the barcode on the screen.

TheRing Scanneremits a string of high/low/high/low beeps. The Scan LED flashes green indicating that theRing Scanneris attempting to establish a connection with the device. When a connection is established, the Scan LED turns off and theRing Scanneremits one string of low/high beeps.

A notification appears on the Notification panel and the icon appears in the Status bar.

Data Capture

Pairing Using Bluetooth Human Interface Device

Pair the Bluetooth scanner to the device usingHID.

To pair the scanner with the device using HID:

1. Remove the battery from the scanner.

2. Replace the battery.

3. After the scanner reboots, scan the barcode below to place the scanner in HID mode.

On the device, swipe down from the Status bar to open the Quick Access panel and then touch .

5. Touch Bluetooth.

6. Touch Pair new device. The device begins searching for discoverable Bluetooth devices in the area and displays them under Available devices.

7. Scroll through the list and select XXXXX xxxxxx, where XXXXX is the scanner and xxxxxx is the serial

number.

The device connects to the scanner, the scanner beeps once and Connected appears below the device name. The Bluetooth device is added to the Paired devices list and a trusted (“paired”) connection is established.

DataWedge

DataWedge is a utility that adds advanced barcode scanning capability to any application without writing code. It runs in the background and handles the interface to built-in barcode scanners. The captured barcode data is converted to keystrokes and sent to the target application as if it was typed on the keypad.

DataWedge allows any app on the device to get data from input sources such as a barcode scanner, MSR, RFID, voice, or serial port and manipulate the data based on options or rules.

Configure DataWedge to:

• Provide data capture services from any app.

• Use a particular scanner, reader, or other peripheral devices.

• Properly format and transmit data to a specific app.

To configure DataWedge, refer to techdocs.zebra.com/datawedge/.

Enabling DataWedge

This procedure provides information on how to enable DataWedge on the device.

Swipe up from the bottom of the Home screen and touch .

Touch > Settings.

3. Touch the DataWedge enabled checkbox.

A blue checkmark appears in the checkbox indicating that DataWedge is enabled.

Disabling DataWedge

This procedure provides information on how to disable DataWedge on the device.

Swipe up from the bottom of the Home screen and touch .

Touch .

3. Touch Settings.

4. Touch DataWedge enabled.

Supported Devices

This sections provides the supported decoders for each data capture option.

Camera Supported Decoders

Lists the supported decoders for the internal camera.

Table 10Camera Supported Decoders

Data Capture

Decoder Default State Decoder Default State Decoder Default State

Australian Postal

Aztec X Grid Matrix O PDF417 X

Canadian Postal

Chinese 2 of 5 O GS1 DataBar

Codabar X GS1 DataBar

Code 11 O GS1 Datamatrix O Trioptic 39 O

Code 128 X GS1 QRCode O UK Postal O

Code 39 X HAN XIN O UPCA X

Code 93 O Interleaved 2

Composite AB O Japanese

Composite C O Korean 3 of 5 O US4state O

Discrete 2 of 5 O MAIL MARK X US4state FICS O

Datamatrix X Matrix 2 of 5 O US Planet O

O EAN8 X MSI O

O GS1 DataBar X QR Code X

X Decoder

Expanded

O TLC 39 O

Limited

O UPCE0 X

of 5

O UPCE1 O

Postal

Signature

Dutch Postal O Maxicode X US Postnet O

DotCode X MicroPDF O

EAN13 X MicroQR O

Key: X = Enabled, O = Disabled, - = Not Supported

Data Capture

SE4100 Internal Imager Supported Decoders

Lists the supported decoders for the internal SE4100 imager.

Table 11Internal SE4100 Imager Supported Decoders

Decoder Default State Decoder Default State Decoder Default State

Australian Postal

Aztec X Grid Matrix O PDF417 X

Canadian Postal

Chinese 2 of 5 O GS1 DataBar

Codabar X GS1 DataBar

Code 11 O GS1 Datamatrix O Trioptic 39 O

Code 128 X GS1 QRCode — UK Postal O

Code 39 X HAN XIN O UPCA X

Code 93 O Interleaved 2

Composite AB O Japanese

Composite C O Korean 3 of 5 O US4state —

Discrete 2 of 5 O MAIL MARK O US4state FICS —

Datamatrix X Matrix 2 of 5 O US Planet O

Dutch Postal — Maxicode O US Postnet O

O EAN8 X MSI O

— GS1 DataBar X QR Code X

X Decoder

Expanded

X TLC 39 O

Limited

X UPCE0 X

of 5

O UPCE1 O

Postal

Signature

—

DotCode O MicroPDF O

EAN13 X MicroQR X

Key: X = Enabled, O = Disabled, - = Not Supported

SE4710 Internal Imager Supported Decoders

Lists the supported decoders for the SE4710 internal imager.

Table 12Internal Imager SE4710 Supported Decoders

Decoder Default State Decoder Default State Decoder Default State

Australian Postal

Aztec X Grid Matrix O PDF417 X

Canadian Postal

O EAN8 X MSI O

O GS1 DataBar X QR Code X

Data Capture

Table 12Internal Imager SE4710 Supported Decoders (Continued)

Decoder Default State Decoder Default State Decoder Default State

Chinese 2 of 5 O GS1 DataBar

Expanded

Codabar X GS1 DataBar

Limited

Code 11 O GS1 Datamatrix O Trioptic 39 O

Code 128 X GS1 QRCode O UK Postal O

Code 39 X HAN XIN O UPCA X

Code 93 O Interleaved 2

of 5

Composite AB O Japanese

Postal

Composite C O Korean 3 of 5 O US4state O

Discrete 2 of 5 O MAIL MARK X US4state FICS O

Datamatrix X Matrix 2 of 5 O US Planet O

Dutch Postal O Maxicode X US Postnet O

DotCode O MicroPDF O

EAN13 X MicroQR O

Key: X = Enabled, O = Disabled, - = Not Supported

X Decoder

Signature

O TLC 39 O

O UPCE0 X

O UPCE1 O

RS507/RS507x Supported Decoders

Lists the supported decoders for the RS507/RS507x Ring Scanner.

Table 13RS507/RS507x Supported Decoders

Decoder Default State Decoder Default State Decoder Default State

Australian Postal

Aztec X Grid Matrix O PDF417 X

Canadian Postal

Chinese 2 of 5 O GS1 DataBar

Codabar X GS1 DataBar

Code 11 O GS1 Datamatrix - Trioptic 39 O

Code 128 X GS1 QRCode - UK Postal O

Code 39 O HAN XIN - UPCA X

O EAN8 X MSI O

- GS1 DataBar X QR Code X

Expanded

Limited

X Decoder

Signature

O TLC 39 O

Data Capture

Table 13RS507/RS507x Supported Decoders (Continued)

Decoder Default State Decoder Default State Decoder Default State

Code 93 O Interleaved 2

Composite AB O Japanese

Composite C O Korean 3 of 5 O US4state O

Discrete 2 of 5 O MAIL MARK - US4state FICS O

Datamatrix X Matrix 2 of 5 O US Planet O

Dutch Postal O Maxicode X US Postnet O

DotCode O MicroPDF O

EAN13 X MicroQR O

Key: X = Enabled, O = Disabled, - = Not Supported

RS5100 Supported Decoders

Lists the supported decoders for the RS5100 Ring Scanner.

Table 14RS5100 Supported Decoders

Decoder Default State Decoder Default State Decoder Default State

Australian Postal

O EAN8 X MSI O

O UPCE0 X

of 5

O UPCE1 O

Postal

Aztec X Grid Matrix O PDF417 X

Canadian Postal

Chinese 2 of 5 O GS1 DataBar

Codabar X GS1 DataBar

Code 11 O GS1 Datamatrix O Trioptic 39 O

Code 128 X GS1 QRCode O UK Postal O

Code 39 X HAN XIN O UPCA X

Code 93 O Interleaved 2

Composite AB O Japanese

Composite C O Korean 3 of 5 O US4state O

Discrete 2 of 5 O MAIL MARK X US4state FICS O

Datamatrix X Matrix 2 of 5 O US Planet O

Dutch Postal O Maxicode X US Postnet O

O GS1 DataBar X QR Code X

X Decoder

Expanded

O TLC 39 O

Limited

O UPCE0 X

of 5

O UPCE1 O

Postal

Signature

Table 14RS5100 Supported Decoders (Continued)

Decoder Default State Decoder Default State Decoder Default State

DotCode O MicroPDF O

EAN13 X MicroQR O

Key: X = Enabled, O = Disabled, - = Not Supported

RS6000 Supported Decoders

Lists thesupported decoders for the RS6000 Ring Scanner.

Table 15RS6000 Supported Decoders

Decoder Default State Decoder Default State Decoder Default State

Data Capture

Australian Postal

Aztec X Grid Matrix O PDF417 X

Canadian Postal

Chinese 2 of 5 O GS1 DataBar

Codabar X GS1 DataBar

Code 11 O GS1 Datamatrix O Trioptic 39 O

Code 128 X GS1 QRCode O UK Postal O

Code 39 X HAN XIN O UPCA X

Code 93 O Interleaved 2

Composite AB O Japanese

Composite C O Korean 3 of 5 O US4state O

Discrete 2 of 5 O MAIL MARK X US4state FICS O

Datamatrix X Matrix 2 of 5 O US Planet O

Dutch Postal O Maxicode X US Postnet O

O EAN8 X MSI O

O GS1 DataBar X QR Code X

X Decoder

Expanded

O TLC 39 O

Limited

O UPCE0 X

of 5

O UPCE1 O

Postal

Signature

DotCode O MicroPDF O

EAN13 X MicroQR O

Key: X = Enabled, O = Disabled, - = Not Supported

DS3578 Supported Decoders

Lists the supported decoders for theDS3578 Digital Scanner.

Table 16DS3578 Digital ScannerSupported Decoders

Decoder Default State Decoder Default State Decoder Default State

Data Capture

Australian Postal

Aztec X Grid Matrix O PDF417 X

Canadian Postal

Chinese 2 of 5 O GS1 DataBar

Codabar X GS1 DataBar

Code 11 O GS1 Datamatrix O Trioptic 39 O

Code 128 X GS1 QRCode O UK Postal O

Code 39 X HAN XIN — UPCA X

Code 93 O Interleaved 2

Composite AB O Japanese

Composite C O Korean 3 of 5 O US4state O

Discrete 2 of 5 O MAIL MARK X US4state FICS O

Datamatrix X Matrix 2 of 5 O US Planet O

Dutch Postal O Maxicode X US Postnet O

O EAN8 X MSI O

— GS1 DataBar X QR Code X

X Decoder

Expanded

O TLC 39 O

Limited

O UPCE0 X

of 5

O UPCE1 O

Postal

Signature

—

DotCode O MicroPDF O

EAN13 X MicroQR O

Key: X = Enabled, O = Disabled, — = Not Supported

DS3678 Supported Decoders

Lists the supported decoders for the DS3678 scanner.

Table 17DS3678 Supported Decoders

Decoder Default State Decoder Default State Decoder Default State

Australian Postal

Aztec X Grid Matrix O PDF417 X

Canadian Postal

O EAN8 X MSI O

— GS1 DataBar X QR Code X

Data Capture

Table 17DS3678 Supported Decoders (Continued)

Decoder Default State Decoder Default State Decoder Default State

Chinese 2 of 5 O GS1 DataBar

Expanded

Codabar X GS1 DataBar

Limited

Code 11 O GS1 Datamatrix O Trioptic 39 O

Code 128 X GS1 QRCode O UK Postal O

Code 39 X HAN XIN O UPCA X

Code 93 O Interleaved 2

of 5

Composite AB O Japanese

Postal

Composite C O Korean 3 of 5 O US4state O

Discrete 2 of 5 O MAIL MARK X US4state FICS O

Datamatrix X Matrix 2 of 5 O US Planet O

Dutch Postal O Maxicode X US Postnet O

DotCode O MicroPDF O

EAN13 X MicroQR O

Key: X = Enabled, O = Disabled, — = Not Supported

X Decoder

Signature

O TLC 39 O

O UPCE0 X

O UPCE1 O

—

DS8178 Supported Decoders

Lists the supported decoders for the DS8178 Digital scanner.

Table 18DS8178 Digital Scanner Supported Decoders

Decoder Default State Decoder Default State Decoder Default State

Australian Postal

Aztec X Grid Matrix O PDF417 X

Canadian Postal

Chinese 2 of 5 O GS1 DataBar

Codabar X GS1 DataBar

Code 11 O GS1 Datamatrix O Trioptic 39 O

Code 128 X GS1 QRCode O UK Postal O

Code 39 X HAN XIN — UPCA X

O EAN8 X MSI O

— GS1 DataBar X QR Code X

Expanded

Limited

X Decoder

Signature

O TLC 39 O

—

Data Capture

Table 18DS8178 Digital Scanner Supported Decoders (Continued)

Decoder Default State Decoder Default State Decoder Default State

Code 93 O Interleaved 2

of 5

Composite AB O Japanese

Postal

Composite C O Korean 3 of 5 O US4state O

Discrete 2 of 5 O MAIL MARK X US4state FICS O

Datamatrix X Matrix 2 of 5 O US Planet O

Dutch Postal O Maxicode X US Postnet O

DotCode O MicroPDF O

EAN13 X MicroQR O

Key: X = Enabled, O = Disabled, — = Not Supported

O UPCE0 X

O UPCE1 O

Wireless

This section provides information on the wireless features of the device.

Thefollowing wireless features are available on the device:

• Wireless Wide Area Network (WWAN)

• Wireless Local Area Network (WLAN)

• Bluetooth

• Cast

• Near Field Communications (NFC)

Wireless Wide Area Networks

Use Wireless wide area networks (WWANs) to access data over a cellular network.

NOTE: TC26 only.

This section provides information on:

• Sharing a data connection

• Monitoring data usage

• Changing Cellular Network settings

Sharing the Mobile Data Connection

The Tethering & Portable Hotspot settings allow sharing the mobile data connection with a single computer via USB tethering or Bluetooth tethering.

Share the data connection with up to eight devices at once, by turning it into a portable Wi-Fi hotspot. While the device is sharing its data connection, an icon displays at the top of the screen and a corresponding message appears in the notification list.

Enabling USB Tethering

NOTE: USB tethering is not supported on computers running Mac OS. If the computer is running

Windows or a recent version of Linux (such as Ubuntu), follow these instructions without any special preparation. If running a version of Windows that precedes Windows 7, or some other

operating system, you may need to prepare the computer to establish a network connection via USB.

1. Connect the device to a host computer with a USB cable.

The notification Charging this device via USB appears in the Notifications panel.

2. Go to Settings.

3. Touch Network & Internet.

4. Touch Hotspot & tethering.

5. Touch the USB tethering switch to enable.

The host computer is now sharing the device’s data connection.

To stop sharing the data connection, touch the USB tethering switch again or disconnect the USB cable.

Enabling Bluetooth Tethering

Use Bluetooth tethering to share the data connection with a host computer.

Configure the host computer to obtain its network connection using Bluetooth. For more information, see the host computer’s documentation.

Wireless

1. Pair the device with the host computer.

2. Go to Settings.

3. Touch Networking & Internet.

4. Touch Hotspot & tethering.

5. Touch the Bluetooth tethering switch to enable.

The host computer is now sharing the device’s data connection.

To stop sharing the data connection, touch the Bluetooth tethering switch again.

Enabling Wi-Fi Hotspot

1. Go to Settings.

2. Touch Networking & Internet.

3. Touch Hotspot & tethering.

4. Touch Wi-Fi hotspot.

5. Toggle the switch to enable.

After a moment, the device starts broadcasting its Wi-Fi network name (SSID). Connect to it with up to eight computers or other devices. The Hotspot icon appears in the Status bar.

To stop sharing the data connection, touch the toggle switch again.

Configuring the Wi-Fi Hotspot

1. Go to Settings.

2. Touch Networking & Internet.

3. Touch Hotspot & tethering.

4. Touch Wi-Fi hotspot.

5. In the Hotspot name text field, edit the name for the hotspot.

6. Touch Security and select a security method from the drop-down list.

7. Touch Advanced.

8. If desired, touch Turn off hotspot automatically to turn off Wi-Fi Hotspot when no devices are

9. In the AP Band drop-down list, select 2.4 GHz Band or 5.0 GHz Band.

Data Usage

Data usage refers to the amount of data uploaded or downloaded by the device during a given period. Depending on the wireless plan, you may be charged additional fees when your data usage exceeds your plan's limit.

Wireless

• WPA2-Personal

a. Touch Hotspot password.

b. Enter a password.

c. Touch OK.

• None - If None is selected in the Security option, a password is not required.

connected.

Data usage settings allow:

• Enable Data Saver.

• Set the data usage warning level.

• Set a data usage limit.

• View or restrict data usage by app.

• Identify mobile hotspots and restrict background downloads that may result in extra charges.

Monitoring Data Usage

1. Go to Settings.

2. Touch Network & internet > Mobile network > Data usage.

CAUTION: The usage displayed on the data usage settings screen is measured by your

device. Your carrier's data usage accounting may differ. Usage in excess of your carrier plan's data limits can result in steep overage charges. The feature described here can help you track your usage, but is not guaranteed to prevent additional charges.

By default, the data usage settings screen displays the mobile data settings. That is, the data network or networks provided by your carrier.

Setting Data Usage Warning

Set a warning alert when the device has used a certain amount of mobile data.

1. Go to Settings.

Touch Network & internet > Mobile network > Data usage > .

3. If necessary, touch Set data warning to enable it.

4. Touch Data warning.

5. Enter a number.

To switch between megabytes (MB) and gigabytes (GB), touch the down arrow.

6. Touch SET.

When the data usage reaches the set level, a notification appears.

Setting Data Limit

1. Go to Settings.

Touch Network & internet > Mobile network > Data usage > .

3. Touch Set data limit.

4. Touch OK.

5. Touch Data limit.

6. Enter a number.

Wireless

To switch between megabytes (MB) and gigabytes (GB), touch the down arrow.

7. Touch Set.

When the limit is reached, data automatically turns off and a notification appears.

Cellular Network Settings

Cellular network settings applies to WWAN devices only.

Data When Roaming
