The TC25 Rugged Smartphone

THE RUGGED SMARTPHONE DESIGNED FOR YOUR SMALL BUSINESS

You spend your days making deliveries, repairing equipment or providing services — from plumbing and electrical to parcel delivery,
yard maintenance and more. Every day, there’s so much to do, so little time to get it done — and so many competitors for your
customers to call if you can’t get the job done fast enough. You need a tool that can help you work faster and smarter. You need the
TC25. You get all the features you need to get more done and satisfy more customers every day:

• ‘Just right’ durable design — you can drop it on the floor and use it in the cold, heat, rain and snow — and it still works.

• The right features — get the information you need faster than ever to slash the time it takes to perform all those everyday tasks.

• The right service program for the right price — so you can easily keep your devices up, running and in your hands.

• All day power, guaranteed — with the unique PowerPack snap-on extended battery.

• The fastest cellular speeds — delivering fast application access and great voice quality.

Get more done in less time with the TC25 —
the rugged smartphone designed for your small business.

For work, we win.

For more information, visit www.zebra.com/tc25

Save time and money, increase sales and boost
profitability with the TC25 — the rugged smartphone
for small business.

Built for work

Rain. Heat. Sub -zero cold. Drops. Spills. The TC25 can handle it all.

All day power — always

No need for a charger — just snap on the unique PowerPack and keep on working.

A real scanner for real time-savings

Smartphone cameras aren’t built for barcode scanning — that’s why the TC25 delivers
the same scanning technology that drives many of the world’s field service teams. You
get instant and eortless point-and-shoot capture of any electronic or printed barcode in
virtually any condition — no aiming and no waiting. So no matter what your workers are
doing, with a real Zebra scanner inside, they’ll get it done faster, more accurately and
more eciently — boosting workforce productivity, customer service and profitability.

Instantly document everything

From proof of delivery to a damaged package or a completed repair, you can
document it all with the 8 MP autofocus color camera.

The right service plan for the right price

With Zebra OneCare™ SV, you get two years of coverage for normal wear and tear and
device failure, unmatched from-the-manufacturer technical support, a Device Diagnostics
Tool for onsite troubleshooting, priority repair turnaround time, free return shipping and
more — all for a fraction of the cost of a single, uncovered repair. And when you add
LifeGuardTM for AndroidTM to your ser vice plan, you get true peace of mind — guaranteed
security updates throughout the lifecycle of your TC25 mobile computer.

Easy to use — no learning curve

The TC25 makes it so easy to do business. With Android, you get pinch and zoom and
all the same familiar gestures you already use on your personal smartphone. The screen
is just as easy to see outside as it is indoors. The large touchscreen displays all the
information you need to see — without scrolling. And three programmable buttons
provide instant access your most used features and applications.

Doubles as a walkie-talkie

With an instant voice connection and secure text messaging, you can reach a specific
worker, a specific group of workers, or all of your workers at the press of a button.
And with secure text messaging, you can still reach workers, even when a phone
call isn’t appropriate.*

Fast cellular connections for crystal clear voice calls
and great application performance

With support for 4G and VoLTE, you get HD calling for exceptional voice clarity and
fast connections. And with three to six times the data bandwidth over 3G or 2G,
you can count on fast app performance and rapid screen draws.

Fast Bluetooth and Wi-Fi

The fastest Bluetooth connections mean great performance for Bluetooth headsets
and printers. And with 802.11ac, you can switch to fast Wi-Fi connections when you’re
in the oce, at home or in a public hot spot, without sacrificing connection quality.

It’s a snap to enter barcodes into your apps

Send barcodes captured with the scanner right into your existing apps with Zebra’s
DataWedge — no programming or modification of your existing apps required.
The result? A big time-savings — without any cost.

GET BIG BUSINESS TECHNOLOGY FOR YOUR SMALL BUSINESS.

For 45 years, Zebra’s innovative mobile devices have increased eciency, sales and profitability in many of the world’s largest

field service and delivery operations. Now, you can put that same innovation to work in your small business with the TC25.

PRODUCT SPEC SHEET

TC25 RUGGED SMARTPHONE

TC25 Specifications

PHYSICAL CHARACTERISTICS

Dimensions

Weight 6.88 oz./195 g

Display

Imager Window Corning Gorilla Glass

Touch Panel Capacitive Touch Panel; multi-touch

Power

Expansion Slot One 128G B micro SD slot

SIM 1 Nano SI M slot

Network
Connections

Notifications Audible tone, multi-colored LEDs, vibration

Keypad On-screen keypad

Audio

Buttons

PERFORMANCE CHARACTERISTICS

CPU

Operating System Android Nougat 7.X

Memory 2GB RAM/16GB Flash memory

Security Verified Boot

USER ENVIRONMENT

Operating
Temperature

Storage
Temperature

Drop
Specifications

Tum ble
Specifications

Sealing IP65

Vibration 4G peak , 5Hz to 2kHz, 1 hour duration per axis

Thermal Shock

Electrostatic
Discharge (ESD)

INTERACTIVE SENSOR TECHNOLOGY IST

Accelerometer (3-axis), ambient light sensor, proximity sensor

DATA CAPTURE

Scanning

Rear Camera 8MP autofocus color camera with flash

5.27 in. L x 2.82 in. W x .63 in. D
134 mm L x 73.1 mm W x 16 mm D

4.3 in. color W VGA (8 00x480); LED backlight ;
Corning Gorilla Glass

Non-removable / serviceable
Rechargeable Li-Ion: standard capacity,

3000mAh
Charge in under 4 hours (10 hours = 1 shift)
RTC backup

1 USB OTG - host /client
(Type C connector)

Speaker - 1 Watt (9 4dBA)
Voice support (Internal speaker/microphone)
Two (2) microphones

Scan on each side, Volume Up/Dow n, Power,
push-to-talk ( PTT ) keys

QCOM MS M8937® 64 -bit 8- Core, A RM®
Cortex A53 1.4GHz, 512KB L2 cache,
power-optimization

14° F to 122 ° F / -10° C to 50° C

-40 ° F to 158 ° F / -40° C to 70 ° C

Multiple 4 f t./1. 2 m drop to tile over concrete
per MIL-STD 810G at room temperature

300 tumbles, 1.6 ft./0.5 m

-40 °C to 70°C rapid transition
10 cycles: (1 c ycle = 1 .25 hours at - 40°C
and 1.25 hours at 70°C )

+/-15k v Air, +/- 8k v contact
+/-8kv charge body

SE2100 1D/2D imager
SE4710 1D/2D imager

WIRELESS WAN DATA & VOICE COMMUNICATIONS

TC25 A meric as:

• LTE: B2, B4, B5, B12, B17

• WCDMA: B2, B4, B5

• GSM: 850,900,1800,1900

TC25 Rest Of World:

• LTE: B1, B3, B7, B8, B20, B28

Radio Frequency
Band

Voice
Communications

GPS GPS wi th A- GPS (Glonass, BeiDou)

• WCDMA: B1, B5, B8

• GSM: 850,900,1800,1900

TC25 China:

• LTE FDD: B1, B3

• LTE TDD: B39, B 40, B41

• WCDMA: B1, B8

• TDSCDMA B34, B39
(Diversit y not suppor ted)

• GSM: 900,1800

Workforce Connect Push-to-Talk (PTT) Express
(Integrated complimentary software application
for instant PTT walkie-talkie style calls inside
the four walls).

Workforce Connect Push-to-Talk (PTT) Pro
(Optional easy-to-deploy subscriptions service
that provides instant PTT walkie-talkie style
calls inside and outside the four walls).

WIRELESS LAN

WLAN Radio 802.11a/b/g/n/ac/d/r/h/i IPv4, IP v6

Data Rates

Operating
Channels

Security and
Encryption

Certifications 802.11a/b/g/n; WPA; WPA2

Fast Roam 802.11r

2.4 GHz: 20 M Hz, 40 MHz
5 GHz: 20 MHz, 40 MHz, 80 MHz

2.4 GHz (channels 1-13; 1-11(US))
5 GHz (channels 36- 48, 52-64, 100 -144,

149-165)
Actual operating channels/ frequencies and

bandwidths depend on regulatory rules and
certification agency.

WPA/ WPA2 ( PSK & Enterpr ise 802.1x);
EAP-TTLS; PEAPv0-MSCHAPv2; EAP-TLS

WIRELESS PAN

Bluetooth Bluetooth 4. 2 BLE

MOBILITY DNA SOLUTIONS

Mobility Extensions (Mx) Smar tDEX

Lifeguard™ for Android™ DataWedge

StageNow EMM Tool Kit

Enterprise Home Screen

Mobility DNA is available on Android only. Features may vary by model
and a Support Contract may be required. To learn what solutions are
supported, please visit: https://developer.zebra.com/mobilitydna

WARRANTY

Subject to the terms of Zebra’s hardware warranty statement, the
TC25 is warranted agains t defec ts in workmanship and materials
for a period of 1 (one) year from the date of shipment. For complete
warranty statement, please visit: www.zebra.com/warranty

RECOMMENDED SERVICES

Zebra OneCareTM SV

Where can you put
the TC25 to work?

• Field Service

• Direct Store Delivery
(DSD)

• Route accounting

• Postal

• Courier

  3

PRODUCT SPEC SHEET

TC25 RUGGED ANDROID SMARTPHONE

* Workforce Connect PTT Express provides basic push-to-talk services between TC25 and other

compatible Zebra mobile devices inside the four walls for no cost. Workforce Connect PTT Pro is
a cost-effective subscription service that provides comprehensive push-to -talk and secure text
messaging services between TC25 and other compatible Zebra mobile devices outside the four walls.
