About This Addendum
Introduction
This addendum describes the differences between the Windows CE .NET 4.1 and
CE .NET 4.2 operating system as it pertains to the PPT 8800 with Windows Embedded
CE .NET terminal. The PPT 8800 Series includes the following variations of the terminal:
PPT 8800 Performs 1-dimensional scanning and batch communication. Memory configuration:
32 MB ROM/32 MB RAM, optional 128 MB additional CF memory.
®
PPT 8846 Performs 1-dimensional scanning and uses the Symbol Spectrum24
11 MB local area network (LAN) wireless communication. Memory configuration: 32 MB
ROM/32 MB RAM.
Chapter Descriptions
Topics covered in this guide are as follows:
• Chapter 1, CE. NET 4.2 explains the changes between CE .NET 4.1 and CE .NET
4.2.
• Chapter 2, Spectrum24 Network Configuration details specific operation when
using PEAP authentication.
• Appendix A, Technical Specifications includes a table listing the technical
specifications for the terminal.
