Quick Reference
Introduction
The FL-370-1000CC RF Forkl ift base is a commu nication cond uit
between the Phaser RF scanner and forklift moun ted term in al. It
is a sealed device designed to be mounted on a forklift. The RF
Forklift base receives data from the scanner via radio frequency
(RF) transmissions through its antenna, then transmits that d ata to
the forklift vehicle mounted terminal through an attache d cab le.
Quick Reference Guide
This
up and use of the RF Forklift base.
Unpacking the Radio Base
The shipping box includes the following:
• Fully sealed RF Forklift base
• Four screws (see page 3 for mounting)
• This Quick Reference Gui de (p/n 72-52373-xx)
• Radio Base mounting template (page 13)
Note: The Interface cable m ust be purchased separately.
Save the shipp ing container for s toring or shippi ng. Inspect all your
equipment for damage. If any th ing is damaged or missing, call
your authorized Customer Support Representative immediately.
provides basic instruct ion on the se t
1
FL370-I000CC
RF Forklift Base
About This Guide
This guide provides instructions for the foll ow ing:
• “Mounting the Radio Base” on page 3
• “Connecting to the Host” on page 3
• “Connector Pinout” on page 5
• “Pairing” on page 6
• “Spectrum 24 Environment” page 6
• “LED Indicator” on page 8
• “Cleaning the Base” on page 8
• “Troubleshooting” on page 8
• “Service Information” o n page 14
• “Warranty” on page 12
• “Mounting Template” on page 13 .
LED Light
Mounting Holes
Interface Cable
Connector
2
Quick Reference
r
Mounting the Base
1. Mount the RF Forklift base on a flat
surface free of dirt and oi l and three
feet or more from an RF terminal’s
radio antenna.
2. Fasten the four screws provided
through the RF Forklift base and
into the mounting area. A mounting
template is provided for you on page
13.
3. Install the cable by aligning the alignment tab and firmly
pushing the cable into the connector.
Mounting Holes
Connecting to the Host
Note: The RF Forklift base power con-
sumption is 200mA maximum.
Interface Cable Connecto
3
