MC9500-NI
FOR UL CLASS I,
II, III / DIVISION 2, ATEX
ZONE 2 AND ZONE 22

USER GUIDE

2 MC9500-NI

Zebra reserves the right to make changes to any product to improve reliability, function, or design.

Zebra does not assume any product liability arising out of, or in connection with, the application or use of any
product, circuit, or application described herein.

No license is granted, either expressly or by implication, estoppel, or otherwise under any patent right or patent,
covering or relating to any combination, system, apparatus, machine, material, method, or process in which
Zebra products might be used. An implied license exists only for equipment, circuits, and subsystems contained
in Zebra products.

Warranty

For the complete Zebra hardware product warranty statement, go to: http://www.zebra.com/warranty.

Service Information

If you have a problem using the equipment, contact your facility’s Technical or Systems Support. If there is a
problem with the equipment, they will contact the Zebra Support at: http://www.zebra.com/support.

For the latest version of this guide go to: http://www.zebra.com/support.

Software Support

Zebra wants to ensure that customers have the latest release of entitled software at the time of product
purchase.

To confirm that your Zebra device shipped with the latest release of entitled software, visit:
www.zebra.com/support. Check for the latest software from Software Downloads > Product Line/Product > Go.

If your device does not have the latest entitled software release as of your product purchase date, please e-mail
a request to Zebra at: [e-mail].

You must include the following essential device information with your request:

• Model number

• Serial number

• Proof of purchase

• Title of the software download you are requesting.

If it is determined by Zebra that your device is entitled to the latest software release, you will receive an e-mail
containing a link directing you to a Zebra Web site to download the appropriate software.

User Guide 3

Notes on This Guide

IMPORTANT Read carefully before putting the devices into operation.

The user guide is a constituent part of the product and must be kept in the direct vicinity of the device and
accessible at all times to installation, operating and maintenance personnel.

It contains important notes, safety instructions and test certificates which are necessary for perfect functioning
when the devices are being operated and handled. It is written for technically qualified personnel.

Familiarity with and the technically perfect implementation of the safety instructions and warnings described in
this guide are preconditions for safe installation and commissioning. The safety notes and warnings given in this
guide are given in a general way and only qualified personnel will have the necessary specialized know-how to
interpret and implement them correctly in specific cases.

Qualifications of the Personnel Working with the Devices

The user guide is written for all people who carry out assembly, installation, commissioning and service work on
the product, whereby the directives and standards 99/92/EC, EN 60079-17, EN 60079-19 for the gas area and
EN 61241-17 and EN 61241-19 for the dust area must be observed.

Handling the Product

The product described in this guide has been tested and left the factory in perfect condition in regard to meeting
safety requirements.

To maintain this condition and ensure that this product operates perfectly and safely, it may be used only in the
manner described by the manufacturer. Appropriate transportation, suitable storage and careful operation are
also essential for the perfect and safe operation of this product.

Use for the Intended Purpose

NOTE The versions, components, screens and windows illustrated in this guide are examples only and

can deviate from the actual display.
The information in this guide relates to the explosion protected version of the MC9500-NI Series.
This guide contains all important information concerning explosion protection. In addition, the

original user guides are also available and these contain information about handling and
commissioning. In the event of information overlap, the information in this guide supersedes other
guides.

4 MC9500-NI

Documentation Set

The documentation set for the MC9500 provides information corresponding with the respective user
requirements and comprises:

• MC9500 Quick Start Guide - This user guide describes the operation of the mobile computer MC9500.

• MC9500 User Guide - This user guide describes the use of the MC9500 mobile computer series.

• MC9500 Integrator Guide - This user guide describes the setup of the MC9500 mobile computer,
including accessories.

• Microsoft® Applications for Windows Mobile® 6 User Guide for Enterprise Mobility Devices - This
user guide describes the use of Microsoft applications.

• Enterprise Mobility Application Guide - This user guide describes the use of example applications
developed with Enterprise Mobility.

• EMDK Help file (Enterprise Mobility Developer Kit) - This Help file comprises API information about
writing applications.

Safety Instructions

IMPORTANT Safety instructions and warnings are specially highlighted in this manual and marked by

symbols.

The safety instructions and warnings are assigned to the individual work steps. Careful
handling and consistent observation of the instructions will prevent accidents, personal
injuries and damage to property.

The adherence to all directions and safety instructions in this manual is a precondition for
safe working and the correct handling of the device.

The graphic representations in these instructions serve to show the information being
described and are not necessarily true to scale and they may deviate slightly from the actual
construction of the device.

Marking

Particularly important points in these instructions are marked with a symbol:

WARNING

CAUTION Warning of damage to property and financial and penal disadvantages (e.g. loss of guarantee

! Non-observance leads to death or serious physical injury.

The necessary safety measures must be taken.

rights, liability etc.).

User Guide 5

ATTENTION Important instructions and information on preventing disadvantageous behavior.

NOTE Important instructions and information on effective, economical and environmentally compatible

handling.

Product Description

Definition

The MC9500-NI is a 3.5G Worldwide device and has been specifically modified for use in hazardous areas:

• ATEX Zone 2 and Zone 22 or

• Class I, II, III Division 2.

This means that even in the hazardous area the user can avail of the extensive communication options that are
already standard in other areas.

6 MC9500-NI

Its ergonomic design and easy operation make it an ideal support for fast data availability in enterprise
processes. A keyboard is available in different versions for manual data capture.

The integrated 1D or 1D/2D scan engine for capturing bar codes and optionally a 3-megapixels camera is
available as another data capture option. The ergonomically mounted scan triggers on the MC9500-NI allow data
to be captured easily in one-hand operation.

Several technologies are available for data communication with other systems:

• Wireless 3.5G WAN (WWAN)

• Wireless LAN (WLAN)

• Wireless PAN (WPAN) (Bluetooth)

• IrDA connection.

These modules, which are integrated in the device, allow seamless transmission of voice and data with easy
integration into the company's network.

Other advantages in its use are the rugged construction, easy-to-read 3.7" VGA color display with touch
technology and high-performance lithium-ion battery.

Fast process execution is ensured by the Intel PXA320@ processor with 806 MHz, which is integrated in the
MC9500-NI, and an easy development of applications is facilitated by the Microsoft® Windows Mobile® 6.5
operating system in conjunction with the Enterprise Mobility Developer Kits (EMDK) from Zebra.

256 MB RAM and 1 GB flash drive integrated in the device are available for storing user defined applications and
data. For larger applications and volumes of data, Zebra offers SD memory cards.

Use

The MC9500-NI is a hand-guided piece of electric equipment. It serves the mobile capture, processing and
wireless transmission of data in hazardous areas.

It is used exclusively in combination with operating devices which satisfy the requirements for overvoltage
category I.

The MC9500-NI, series has been modified for use in the hazardous area of:

• ATEX Zone 2 and Zone 22

• UL Class I Division 2 Groups A, B, C and D

• UL Class II Division 2 Groups F and G

• UL Class III

• Non hazardous area.

The MC9500-NI may not be used in locations of:

• ATEX Zone 0

• ATEX Zone 1 and Zone 21

User Guide 7

• UL Class I, II Division 1

• UL Class I, II Division 1

• UL Class II Division 2, Groups E.

Technical Data

Table 1

Explosion Protection ATEX Zone 2 and Zone 22

Ex protection II 3G Ex ic IIC T6

Ambient temperature -20 °C ≤ Ta ≤ +50 °C

Temperature Code T6

Standards EN 60079-0:2009 EN 60079-11:2007

Explosion Protection UL Division 2

Ex protection type Class I Division 2 Groups A, B, C and D

Ambient temperature -20 °C ≤ Ta ≤ +50 °C

Temperature Code T6

Standards ISA12.12.01 1st Edition

Characteristics

Dimensions (height x width x depth) approx. 23.36 cm x 8.89 cm x 5.08 cm (9.2 inch x 3.5 inch x 2.0

Weight including battery approx. 623 g (22 oz) depending on the version and

Display Transflective 3.7 inch color TFT-LCD display

Touchscreen Glass analog resistive touchscreen

Technical Data

Type Description

II 3D tD A22 IP64 T90°C

EN 61241-0:2006 EN 61241-11:2007

Class II Division 2 Groups F and G
Class III

UL 60950-1 1st Edition
C22.2 No. 213-M1987
C22.2 No. 60950-1-03 1st Edition

inch)

configuration

LED backlight, 65K colors, 640 x 480 pixels

8 MC9500-NI

Table 1

Keyboard variants Alpha Primary, Alpha Numeric, Calculator Numeric, Telephony

Audio VoWWAN, VoWLAN, Team Express compliant, rugged audio

Network connections High-speed USB client, full-speed USB host, Ethernet (via

Interfaces RS232

Performance Features

Processor Marvel PXA320@ processor with 806 MHz

Operating system Windows Mobile 6.5

Memory 256 MB RAM/1 GB Flash

Expansion slot Micro SD slot / supports up to 16 GB

User Environment

Ambient temperature -20 °C to +50 °C (-4 °F to 122 °F)

Ambient temperature when charging 0 °C to +40 °C (32 °F to 104 °F)

Storage temperature (without battery) -40 °C to +70 °C (-40 °F to 158 °F)

Air humidity 5% to 95% (non-condensing)

Protection class (EN 60529) IP 64

Application Development

EMDK (Enterprise Mobility Developer Kit) Available for: C, Java and .Net

More tools are available from Zebra for the
devices.

Technical Data (continued)

Type Description

Numeric

connector, high quality speakerphone, headset (wired or
Bluetooth) and handset and speaker phone modes

cradle), Bluetooth

USB 2.0 Client / USB 1.1 host

outside the hazardous area

Rem Capture for processing registry files.
Application Launcher for dividing applications into categories and

access regulation to the individual applications or operating
system.

Data Wedge allows data reading by applications that do not
support any scanner.

App Center is an end-user application access control engine that
restricts activity to a set of authorized applications on mobile
devices.

User Guide 9

Table 1

Voice and Data Transmission Wireless WAN

GSM GPRS/HSDPA (850, 900, 1800, 1900 and 2100 MHz)

CDMA EVDO Rev. A (850 and 1900 MHz) (Verizon or Spirit)

Antenna Integrated in the device

Voice and Data Transmission Wireless LAN

Wireless standard Tri Mode IEEE 802.11a/b/g

Data rate IEEE802.11a: up to 54 Mbit/sec.

Frequency range (country-dependent) IEEE802.11a: 5 GHz

Radio channels Channel 1 - 13 (2412 MHz - 2472 MHz)

Safety TKIP, AES, WPA (Personal Enterprise), WPA2 (Personal or

Spreading procedure Direct Sequence Spread Spectrum (DSSS) and Orthogonal

Voice communication Voice-over-IP ready (with P2P, PBX, PTT clients), WI-FiTM

Antenna integrated in the device

Voice and Data Transmission Wireless PAN

Bluetooth Class 2. Version 2.1 with EDR

Maximum data rate Up to 2.1 Mbit/s

Antenna Integrated in the device

Options for Data Capture

Technical Data (continued)

Type Description

IEEE802.11b: up to 11 Mbit/sec.
IEEE802.11g: up to 54 Mbit/sec.

IEEE802.11b: 2.4 GHz
IEEE802.11g: 2.4 GHz

Channel 14 (2484 MHz) Japan only

Enterprise), 802.1x, EAP-TLS, TTLS (CHAP, MS-CHAP,
MS-CHAPv2, PAP or MD5), PEAP (TLS,
MSCHAPv2,EAP-GTC), LEAP, EAP-Fast (TLS, MS-CHAPv2,
EAPGTC), CCXv4 certified, support for IPv6, FIPS140-2 certified

Frequency Multiplexing Process (OFDM)

certified, IEEE 802.11 a/b/g Direct Sequence Wireless LAN,
WI-FI Multimedia (WMM), Zebra Voice Quality manager (VQM)

10 MC9500-NI

Table 1

Four possible configurations SE950 1D Standard Range Scan Engine

Color Camera

Resolution 3.0 megapixels

Exposure user controllable flash

Objective Auto focus

SE950 1D Standard Range Scan Engine

Reading range approx. 10 cm to 120 cm (3.9 in. to 47 in.)

Resolution 4 mil minimum element width

Roll ± 35° from the vertical

Pitch angle ± 65° from normal

Skew tolerance ± 50° from normal

Ambient light immunity 107,640 lux

Scan rate 104 (± 12) scans/sec. (bi-directional)

Scan angle 47° ± 3 ° standard

SE4500 1D/2D Imager Engine

Reading range approx. 6 cm to 50 cm (2.3 inc. to 19 in.)

Resolution 752 x 480 pixels HxV (grey tone)

Roll 360°

Pitch angle ± 60° from normal

Skew tolerance ± 60° from normal

Ambient light Absolute darkness to 96,000 lux

Aiming element (VLD) 655 Nm ± 10 Nm

Illumination element (LED) 625 Nm ± 5 Nm

Field of view Horizontal 40°

Technical Data (continued)

Type Description

SE4500 1D/2D Imager Engine
SE950 1D Standard Range Scan Engine and camera
SE4500 1D/2D Imager Engine and camera

35° ± 3° reduces

Vertical 25°

User Guide 11

Table 1

Decodable Bar Code Types

Laser Decode Capability MC9500-NI with
SE950 1D-Standard Range Scan Engine

Imaging Decode Capability MC9500-NI with
SE4500 1D/2D Imager Engine

Camera Decode Capability Code 39 Code 128 Code 93, Codabar, Code 11, Discrete 2 of 5,

Technical Data Battery

Battery
82-111636-05 for UL Full NI

82-111636-04 for UL Full NI

Operating temperature
During charging
During discharging

Storage temperature -20 °C to +50 °C (-4 °F to 122 °F)

Technical Data (continued)

Type Description

Code 39, Code 128, Code 93, Codabar, Code 11, Discrete 2 of 5,
Interleaved 2 of 5, EAN-8, EAN-13, MSI, UPCA, UPCE,
UPC/EAN supplementals, Coupon code, Trioptic 39, Web code,
Chinese 2 of 5, GS1 DataBar, GS1 DataBar Truncated, GS1
DataBar Limited, GS1 DataBar Stacked, GS1 DataBar
Expanded, GS1 DataBar Expanded Stacked, GS1 DataBar
Expanded Stacked Omni

Code 39, Code 128, Code 93, Codabar, Code 11, Discrete 2 of 5,
Interleaved 2 of 5, EAN-8, EAN-13, MSI, UPCA, UPCE,
UPC/EAN supplementals, Coupon code, Trioptic 39, Web code,
Chinese 2 of 5, GS1 DataBar, GS1 DataBar Truncated, GS1
DataBar Limited, GS1 DataBar Stacked, TLC39, Composite AB,
Composite C, Micro PDF-417, Macro PDF-417, (Macro) Micro
PDF-417, QR Code, Data Matrix, microQR, Maxi Code,
PDF-417, US Postnet, US Planet, UK 4-state, Australian 4-state,
Canadian 4-state, Japanese 4-state, USPS 4-state (US4CB),
Aztec

Interleaved 2 of 5, EAN-8, EAN-13, MSI, UPCA, UPCE,
UPC/EAN supplementals, Coupon code, Trioptic 39, Web code,
Chinese 2 of 5, GS1 DataBar, GS1 DataBar Truncated, GS1
DataBar Limited, GS1 DataBar Stacked, TLC39, Composite AB,
Composite C, Micro PDF-417, Macro PDF-417, (Macro) Micro
PDF-417, QR Code, Data Matrix, microQR, Maxi Code,
PDF-417, US Postnet, US Planet, UK 4-state, Australian 4-state,
Canadian 4-state, Japanese 4-state, USPS 4-state (US4CB),
Aztec

(rechargeable only in the safe area)
Lithium ions 3.7 V/4800 mAh

Lithium ions 3.7 V/7020 mAh

0 °C to +40 °C (32 °F to 104 °F)

-20 °C to +50 °C (-4 °F to 122 °F)

12 MC9500-NI

Table 1

Relative air humidity 20% - 95% (non-condensing)

Backup battery Ni-MH battery (rechargeable) 2.4 V/15 mAh, rechargeable

Technical Data (continued)

Type Description

Integrated in the device and replaceable only in the factory.

Technical Data External Interface

CAUTION Operating of the 10-pin data interface is only permissible outside the hazardous area and only

with devices specified by the manufacturer!
Operating of the headset port is only permissible outside the hazardous area and only with

devices specified by the manufacturer!

Safety Instructions

Warnings for the MC9500-NI

CAUTION The device may not be opened by the user outside the hazardous area. The user may not

make any alterations to the device.
Do not exchange or replace components and do not retrofit any components on internal plug

connectors or slots.

NOTE Exception: microSD card, SIM card, battery and screen protector.

User Guide 13

CAUTION If components other than those specified are used, the protection against explosions can no

longer be assured.
Substitution of any components may impair suitability for Class I, II, III Division 2 as well as for

ATEX Zone 2 and Zone 22.
To prevent ignition of flammable or combustible atmospheres disconnect power before

servicing.
Do not open or charge the device in the hazardous area.
Operating of the 10-pin data interface (see Technical Data External Interface on page 12) is

only permissible outside the hazardous area and only with devices specified by the
manufacturer.

Operating of the headset port is only permissible outside the hazardous area and only with
devices specified by the manufacturer.

Protect the device from impact effects. Do not expose the operating equipment to any
caustic/aggressive liquids, vapors or mist! In the event of malfunctioning or damage to the
enclosure, take the equipment out of the potentially explosive atmosphere immediately, bring it
into a safe area and decommission it by removing the battery.

CAUTION If on account of adverse effects or conditions (e.g. penetration of water, fluids, exposure to

temperatures outside the specified range etc.) there is a danger of not being able to operate the
equipment safely, switch off the equipment instantly and remove the battery.

Avoid the influence of heat that is higher or lower than the specified temperature range (see

Technical Data on page 7). Do not place the devices anywhere near sources of heat, such as

for example heaters, air exit openings in air conditioners, or near cookers or other devices
(including amplifiers) that radiate heat.

Avoid the effects of moisture.
Do not put any objects into the device, into the enclosure or other openings in the Mobile

Computer. Openings in the device may not be blocked, obstructed or covered.
Use of controls or adjustments or performance of procedures other than those specified herein

may result in hazardous radiation exposure.

14 MC9500-NI

ATTENTION Equipment that is damaged in any way or that does not function properly must instantly be

removed from the hazardous area and sent in for inspection/repair.

Take the device out of the hazardous areas before wiping it with a dry cloth or cleaning it.

General statutory regulations or directives on safety at work; accident prevention regulations
and environmental protection legislation must be complied with, e.g.

Ordinance on industrial health and safety (BetrSichV) or the national ordinances.

Ensure safe handling of the equipment during operation by making sure the device in a
steady position and the user has sufficient space to move.

When transporting the equipment in vehicles, it must be placed in appropriate compartments
or fittings so that it cans neither fall off during the drive nor be exposed to extreme vibrations.

The rules for hazardous areas (see NEC Article NFPA 70) must be observed. In particular,
appropriate clothing and footwear should be worn in view of the risk of dangerous
electrostatic charges. Do not wear rubber gloves or suchlike during operation.

Warnings for Battery

CAUTION The battery may only be charged and changed outside the hazardous area.

It must be ensured that only original batteries of the following type/s are used in safety-oriented
operation. 82-111636-05 with 3.7 V/4800 mAh. 82-111636-04 with 3.7V/7020 mAh.

The use of imitation batteries or batteries from other manufacturers will render the type of
ignition protection ineffective and there will then be a risk of fire or explosion.

Keep away from children.
The battery may explode if disposed of in fire.
DO NOT short circuit or disassemble battery.
The battery may only be used for the purposes stated in the user manual and is only suitable

for use in the MC9500-NI.
If used incorrectly, there is a risk of burning. The battery should not be disassembled over a

temperature higher than +50 °C (122 °F). If the battery is damaged, battery acid can escape
from the cells and cause corrosion. For that reason, extreme care must be taken in handling
and disposing of a damaged or leaking Li-ion battery.

Defective batteries must be disposed of immediately, whereby the battery disposal regulations
that apply to the respective region must be observed.

User Guide 15

Laser Devices Warnings

CAUTION Laser-equipped devices from Zebra conform to Directive 21CFR1040.10 and 1040.11. (with the

exception of the deviations listed in Laser Notice no. 50 of 24 June 2007) as well as EN
60825-1:2007 and IEC 60825-1 (Ed. 2).

The classification of the laser apparatus is specified on a sign affixed to the device.
Class 2 laser devices operate with a visible low-voltage light emitting diode. As with any bright

source of light, for example the sun, the user should avoid looking directly into the light beam.
However, there is no evidence of risks in momentary or brief exposure to a Class 2 laser.

The use of control elements, adaptations or the application of procedures which do not agree
with the instructions described here can lead to a hazardous exposure to radiation.

Laser Devices

Complies with 21CFR1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated June
24, 2007 and EN60825-1:2007 and IEC 60825-1 (Ed.2). The laser classification is marked on one of the labels
on the device.

CAUTION Use of controls, adjustments or performance of procedures other than those specified herein

may result in hazardous laser light exposure.

Class 2 laser scanners use a low power, visible light diode. As with any very bright light source, such as the sun,
the user should avoid staring directly into the light beam. Momentary exposure to a Class 2 laser is not known to
be harmful.

Health and Safety Recommendations

CAUTION Use only the accessories, batteries and battery chargers approved by Zebra. Do not attempt to

charge damp/wet MC9500-NI or batteries. All components must be dry before they are
connected to an external power supply.

Ergonomic Recommendations

CAUTION The following recommendations should be observed to avoid or minimise potential health

problems at the workplace. Contact your health and safety officer on site to ensure that you are
familiar with your company’s safety regulations, which serve to protect employees in the
workplace.

• Avoid unilateral repetitive movements.

• Posture should be as neutral as possible.

• Avoid using excessive force.

16 MC9500-NI

• Keep objects that are used frequently within easy functional reach.

• Perform tasks at heights that suit the person and the type of work

• Place the objects in positions that will eliminate vibrations

• Avoid exerting direct pressure

• Provide adjustable tables and chairs.

• Ensure sufficient clearance for easy movement

• Provide a suitable working environment

• Optimize work procedures

• Alternate hands as often as possible when doing repetitive tasks.

Installation in Vehicles

RF signals can have a negative impact on electronic systems in vehicles (including safety systems) if they have
not been installed correctly or shielded adequately. If you have any questions about your vehicle, please get in
touch with the manufacturer or with a sales representative. You can find out from the manufacturer if any
additional equipment has been installed in the vehicle. An airbag inflates with great force. DO NOT PLACE ANY
objects, such as mounted or mobile wireless equipment in the area above the airbag or in the airbag deployment
area. If the wireless equipment in the vehicle was not installed properly, serious injuries can occur when the
airbag is deployed. Position the device within reach. Make sure you have access to the device without having to
take your eyes off the road.

NOTE Connection to an alert device that will cause a horn to sound or a light to flash on receipt of an

incoming call on public roads is not permissible.

Safety in Traffic

Do not make any notes or use the device while driving. Creating a “to do” list or flipping through the address book
while driving interferes with safe driving.

In road traffic you must first and foremost concentrate on your own safety and that of the other road users. Give
your full attention to the road. Check the legal regulations on the use of wireless devices in road traffic in the
respective region. Always observe them. If you use a wireless device while driving, rely on your common sense
and adhere to the following:

1. Familiarise yourself with the wireless device and its functions, such as speed dial and redial. These functions

may prove to be useful if you wish to make a call without taking your eyes off the road.

2. Use a hands-free telephone, if possible.

3. Inform the person you are speaking with that you are driving. If necessary, end the call if there is heavy traffic

or bad weather. Rain, sleet, snow, ice and even heavy traffic can be dangerous.

4. Dial numbers carefully and keep an eye on the traffic. Make your calls when you have stopped the car or

before you set off. Plan your calls so that you can make them when parked. If it is essential to make a call

User Guide 17

when driving, dial only part of the number, check the road again and look in the rear mirror and then dial the
rest of the number.

5. Do not engage in stressful and emotional telephone calls which might take your attention away from the road.

Let the other person know that you are driving a car and do not get involved in any discussions that might
divert your attention from the road.

6. Use your mobile device to call for help if necessary. Dial emergency services (9-1-1 in the USA and 1-1-2 in

Europe) or other local emergency service numbers if there is a fire, an accident or a medical emergency.
These calls are free of charge on the wireless device! The call can be made independently of security codes
or networks and with or without a SIM card.

7. Use your mobile device to call for help for other people in emergency situations. If you witness a serious

accident, crime or other emergency, call the emergency service (9-1-1 in the USA and 1-1-2 in Europe) or
another local emergency service number. Remember you yourself might need help the next time.

8. Call the breakdown service or a special mobile radio number for support when problems occur on the road. If

you drive past a car with a breakdown which does not present any serious risk to traffic, a traffic light that is
not functioning, a traffic accident with minor damage and without injured people, or a possibly stolen car,
report it to the road patrol or another special mobile radio number for assistance.

“The wireless industry reminds you to use your device/phone safely when driving.”

Electromagnetic Fields

International

The device complies with internationally recognized standards relating to human exposure to electromagnetic
fields from radio devices.

Reducing RF Exposure - Use Properly

Only operate the device in accordance with the supplied instructions.

Portable Devices

This device was tested for typical body-worn operation. Use only Zebra tested and approved belt clips, holsters,
and similar accessories to ensure FCC Compliance. The use of third-party belt-clips, holsters, and similar
accessories may not comply with FCC RF exposure compliance requirements, and should be avoided.

NOTE The MC9500-NI must be switched off before it may be carried on the body.

Handheld Devices

To comply with FCC RF exposure requirements, this device must be operated in the hand with a minimum
separation distance of 20 cm or more from a person's body. Other operating configurations should be avoided.
