MC
919Z
Quick Start Guide
http://www.zebra.com/mc919Z
See User Guide for more information
BATTERY INSERTION
Microphone
Front View
Display
Power
Indicator LED Bar
Scan Button
Headphone
Jack
Keypad
POST IN WORK AREA
Battery Removal
1
3
Trigger
2
Strap Lanyard
1
Stylus
Stored in handle
Stylus Removal
SNAP-ON ACCESSORY INSTALLATION
Data
Power
Cable Adapter Module Magnetic Stripe Reader
Data
Power
CHARGING INSTRUCTIONS
= LED Indicator Location Slow Flash = Normal Charge Solid Amber = Full Charge Fast Flash = Charging Error= LED Indicator Location Slow Flash = Normal Charge Solid Amber = Full Charge Fast Flash = Charging Error
Four Slot Cradles
Single Slot Serial/USB CradleFour Slot Spare Battery Charger
Charge-Only Cradle and Ethernet Cradle
OPTIMUM IMAGING AND SCANNING POSITIONS
Laser Scanning
Long Range ImagingStandard Range Imaging
OPTIMUM UPRIGHT BODY POSTURE
AVOID EXTREME WRIST ANGLES
AVOID EXTREME
WRIST ANGLES
Low Scanning
Alternate left and right knees
ALTERNATE LEFT AND RIGHT HANDSALTERNATE LEFT AND RIGHT HANDS
TAKING BREAKS AND TASK ROTATION RECOMMENDEDTAKING BREAKS AND TASK ROTATION RECOMMENDED
OPTIMUM BODY POSTURE
High Scanning
Use a ladder
AVOID BENDING
Alternate left and right hands
POST IN WORK AREAPOST IN WORK AREA
Zebra Technologies Corporation, Lincolnshire, IL U.S.A.
Zebra and the Zebra head graphic are registered trademarks of ZIH Corp. The Symbol logo is a registered
trademark of Symbol Technologies, Inc., a Zebra Technologies company.
© 2015 Symbol Technologies, Inc.
72-152191-02 Rev. A – February 2015
MC919Z
AVOID REACHING
Taking breaks and
task rotation recommended
http://www.zebra.com/mc919z
Recommended Usage Guide
