Zebra MC55A0, MC55N0 and MC55A0-HC Mobile Computer WorkForce Connect PTT Express Installation and Configuration Guide (en)
WorkForce Connect
PTT Express
Installation and
Configuration Guide
MN000074A04EN Rev. A
ZEBRA and the stylized Zebra head are trademarks of Zebra Technologies Corporation, registered in
many jurisdictions worldwide. All other trademarks are the property of their respective owners.
© 2020 Zebra Technologies Corporation and/or its affiliates. All rights reserved.
Information in this document is subject to change without notice. The software described in this document
is furnished under a license agreement or nondisclosure agreement. The software may be used or copied
only in accordance with the terms of those agreements.
For further information regarding legal and proprietary statements, please go to:
SOFTWARE:www.zebra.com/linkoslegal
COPYRIGHTS:www.zebra.com/copyright
WARRANTY:www.zebra.com/warranty
END USER LICENSE AGREEMENT: www.zebra.com/eula
Terms of Use
Proprietary Statement
This manual contains proprietary information of Zebra Technologies Corporation and its subsidiaries
(“Zebra Technologies”). It is intended solely for the information and use of parties operating and
maintaining the equipment described herein. Such proprietary information may not be used, reproduced,
or disclosed to any other parties for any other purpose without the express, written permission of Zebra
Technologies.
Product Improvements
Continuous improvement of products is a policy of Zebra Technologies. All specifications and designs are
subject to change without notice.
Liability Disclaimer
Zebra Technologies takes steps to ensure that its published Engineering specifications and manuals are
correct; however, errors do occur. Zebra Technologies reserves the right to correct any such errors and
disclaims liability resulting therefrom.
Limitation of Liability
In no event shall Zebra Technologies or anyone else involved in the creation, production, or delivery of the
accompanying product (including hardware and software) be liable for any damages whatsoever
(including, without limitation, consequential damages including loss of business profits, business
interruption, or loss of business information) arising out of the use of, the results of use of, or inability to
use such product, even if Zebra Technologies has been advised of the possibility of such damages. Some
jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you.
Publication Date
August 20, 2020
2
Contents
About This Document ........................................................................................................................ 5
Introduction ...................................................................................................................... 5
Chapter Descriptions........................................................................................................ 5
Notational Conventions.................................................................................................... 5
Icon Conventions ............................................................................................................. 6
Related Documents and Software ................................................................................... 6
Service Information .......................................................................................................... 6
Introduction......................................................................................................................................... 8
Introduction ...................................................................................................................... 8
PTT Express Solution Portfolio ........................................................................................ 8
Devices Supported by PTT Express ................................................................................ 8
PTT Communication Using the PTT Express Client ........................................................ 8
Network............................................................................................................................ 9
Network Recommendations.......................................................................................... 10
Recommended WLAN Access Point (AP) Configuration for PTT Express ............ 10
Multicast Rate Selection................................................................................... 10
Other Settings .................................................................................................. 11
Installation......................................................................................................................................... 12
Introduction .................................................................................................................... 12
Installing the PTT Express Client................................................................................... 12
Windows Devices Using ActiveSync ...................................................................... 12
Windows Devices Using an SD Card............................................................... 12
Android Devices ............................................................................................... 13
Uninstalling the PTT Express Client............................................................................... 13
Windows Devices ................................................................................................... 13
Updating PTT Express from a Prior Version.................................................................. 13
Windows Devices ................................................................................................... 13
Installation/Operation Verification .................................................................................. 13
3
Contents
Installation Using Mobile Device Managers ................................................................... 14
Device Configurations...................................................................................................................... 15
Introduction .................................................................................................................... 15
Microsoft Windows Registry Settings............................................................................. 15
Call Timer Registry Settings ................................................................................... 16
Private Response Registry Settings ....................................................................... 16
Group Broadcast Multicast Registry Settings ......................................................... 17
User Configurable Device Key for Private Response and Group Broadcast.......... 17
Private Key Configurations ..................................................................................... 18
Do Not Disturb ........................................................................................................ 19
Android Configuration File Settings................................................................................ 19
Talk Group Configuration............................................................................................... 19
Verification and Troubleshooting ................................................................................................... 21
Introduction .................................................................................................................... 21
Verification ..................................................................................................................... 21
Troubleshooting ............................................................................................................. 22
License Installation .......................................................................................................................... 23
Prerequisites .................................................................................................................. 23
Installation...................................................................................................................... 23
Validating the Above Profile........................................................................................... 24
Index .................................................................................................................................................. 25
4
About This Document
Introduction
The PTT Express solution is part of Zebra‘s comprehensive portfolio of high performance, feature rich,
converged voice and data solutions that provide communication solutions to meet the needs of many
different types of enterprises and enterprise users.
The purpose of this document is to describe the installation and configuration procedures necessary in
order to prepare a site to take advantage of the PTT Express voice client.
NOTE: This document contains Windows installation instructions for client versions 1.1.x. For Windows
installation instructions for client versions 1.2.x, refer to the appropriate section of the Release Notes for
your specific device.
Since wireless network infrastructure equipment varies from site to site, detailed network configuration is
not included. However, this document provides guidelines to aid in selecting parameters of the wireless
infrastructure that should ensure that the PTT Express client performs optimally.
This book provides an overview of the PTT Express solution and procedures for deployment.
Chapter Descriptions
Topics covered in this guide are as follows:
• Introduction provides an overview of the PTT Express solution, including the PTT Express Portfolio, the
supported enterprise devices, and specific requirements for the solution.
• Installation provides instructions for installing the PTT Express client on supported devices.
• Device Configurations describes the process for modifying required settings that must be assigned
particular values.
• Verification and Troubleshooting lists the steps in the validation process and presents a troubleshooting
FAQ.
• License Installation provides steps to install the PTT Express license for Android devices.
For the latest version of this guide and all guides, go to: http://www.zebra.com/support.
Notational Conventions
The following conventions are used in this document:
• Bold text is used to highlight the following:
• Dialog box, window and screen names
5
• Drop-down list and list box names
• Check box and radio button names
• Icons on a screen
• Key names on a keypad
• Button names on a screen.
• Bullets (•) indicate:
• Action items
• Lists of alternatives
• Lists of required steps that are not necessarily sequential.
• Sequential lists (such as those that describe step-by-step procedures) appear as numbered lists.
Icon Conventions
The documentation set is designed to give the reader more visual clues. The following graphic icons are
used throughout the documentation set. These icons and their associated meanings are described below.
About This Document
NOTE: The text here indicates information that is supplemental for the user to know and that is not
required to complete a task.
IMPORTANT: The text here indicates information that is important for the user to know.
CAUTION: If the precaution is not heeded, the user could receive minor or moderate injury.
WARNING: If danger is not avoided, the user CAN be seriously injured or killed.
Related Documents and Software
Refer to the following documents for associated information about the system.
The following documents provide more information about the PPT Express software.
• PTT Express User Guide, p/n MN000935Axx.
• TC52, TC57, TC72, TC77, PS20, EC30, MC93 Voice Deployment Best Practices Guide, p/n
MN-003430-xx
• TC51, TC56, TC70X, TC75X, MC33 Voice Deployment Best Practices Guide, p/n MN-003167-xx
• TC5X/TC7X Mobile Computers Best Practices Guide Voice Deployment Optimization with Aruba
Infrastructure, p/n MN-003538-xx
For the latest version of this guide and all guides, go to www.zebra.com/support
Service Information
If you have a problem with your equipment, contact Zebra Global Customer Support for your region.
Contact information is available at www.zebra.com/support
When contacting support, please have the following information available:
.
.
6
About This Document
• Serial number of the unit
• Model number or product name
• Software/firmware type or version number
Zebra responds to calls by email, telephone or fax within the time limits set forth in support agreements.
If your problem cannot be solved by Zebra Customer Support, you may need to return your equipment for
servicing and will be given specific directions. Zebra is not responsible for any damages incurred during
shipment if the approved shipping container is not used. Shipping the units improperly can possibly void
the warranty.
If you purchased your Zebra business product from a Zebra business partner, contact that business
partner for support.
7
Introduction
Introduction
The PTT Express solution is one of Zebra’s converged voice and data solutions which provide
communication solutions for many different types of enterprises and enterprise users.
PTT Express Solution Portfolio
PTT Express solutions include:
• PTT VoWLAN is a single mode solution designed to provide service to mobile users inside the
enterprise without regard to their location inside the facility or throughout a campus environment. The
solution provides mobile access over the enterprise Wireless Local Area Network (WLAN) to
comprehensive voice and data services. This includes services such as telephony, Push-To-Talk
(PTT), email, and text messaging that are typically tethered to the desk.
• PTT Express client creates Push-To-Talk communication capability between different types of devices
including PTT Smartphones, and mobile computers. Leveraging existing WLAN infrastructure, this
solution delivers simple communications across devices without the need for a voice communication
server.
• For most Zebra devices, a license is required to use PTT Express. For some value-tier devices, an
MDNA and PTT license is required. Refer to the License Manager User Guide for information on adding
a license to the device.
Devices Supported by PTT Express
Refer to the PTT Express User Guide for a list of supported devices.
The PTT Express client allows these devices to create Push-To-Talk communication capability between
different types of devices. Some of the devices listed may require a software download/install to add PTT
express to the device, but for many of the devices PTT Express comes pre-installed. The solution
leverages existing WLAN infrastructure and does not require a server.
PTT Communication Using the PTT Express Client
To establish PTT communication:
1. A user with a PTT Express enabled device presses the Group Broadcast button to initiate
communication.
2. The initial message is broadcast to all users in the form of a Group Broadcast.
3. After the initial broadcast message, the users have two options:
8
Network
Introduction
• Any user can continue the Group Broadcast by pressing the Group Broadcast button.
• The intended recipient can turn the conversation into a Private Response with the originator of the
broadcast, using the Private Response key.
NOTE: While a PTT communication key is pressed the user will not be able to use other device keys to
perform separate tasks. In general pressing multiple keys simultaneously will lead to inconsistent client
behavior.
Many characteristics of a wireless local-area network (WLAN) impact its ability to be used for deployment
of a Voice over Wireless LAN (VoWLAN) solution such as PTT Express. This section describes some of
the parameters of the wireless network that should be considered to ensure the network‘s ability to
successfully deliver voice traffic between devices running the PTT Express client.
PTT Express allows 63 users to communicate across a single sub-net. The Group Broadcast feature only
permits a single user to transmit to the other members of the Talkgroup at a given moment in time.
Additionally, it is assumed that at most half of the Talkgroup members (that is, approximately 32 users) are
served by a single access point. As members in the Talkgroup reply via the Private Call feature, they may
communicate privately to one another and Group Broadcasts may continue.
PTT Express Communication has been designed to minimize end-to-end audio delay. However, audio
delay may be up to two seconds or more depending on conditions of the network.
The PTT Express client Group Broadcast communication is made possible by transmitting audio packets
to a multicast address. Each device is configured to transmit to and receive from this address. The default
value for this address on Windows devices is provided in Table 1, along with the IP_PORT_BASE (Group
Broadcast port) that is required to be available on each device. These values may be modified from their
default values as described in Microsoft Windows Registry Settings on page 15, but each device in the
group must be configured with the same values for the parameters.
The PTT Express client Private Response communication utilizes SIP (Session Initiation Protocol) for call
signaling and sends audio packets via unicast transmissions between the devices in the Private
Response. The PvtLocalPort (SIP Private Response port) listed in Table 1 must be the same value on all
devices.
Table 1 Configurable System Parameters
Parameter Description Default Range
IP_ADDRESS_BASE IP Multicast address used for
Group Broadcast
communication
IP_PORT_BASE Port used for receiving Group
Broadcasts
PvtLocalPort Port used for receiving SIP
signaling
239.192.2.2 239.0.0.0 - 239.255.255.255
5000 1024 - 49151 <65535>
4080 1024 - 49151 <65535>
9
Network Recommendations
NOTE: In addition to the network's application-specific information below, refer to the following for
additional network settings in the Additional Configuration for Voice Multicast Applications sections in the
following guides:
• TC51, TC56, TC70x, TC75x, MC33 Voice Deployment Best Practice Guide
• TC52, TC57, TC72, TC77, PS20, EC30, MC93 Voice Deployment Best Practices Guide.
If possible, preference should be given to running PTT Express in an 802.11a network because of
common interference sources in the frequency bands used by 802.11b/g. However, many 802.11b/g
environments exist and PTT Express can be installed on devices that operate in those frequency bands
used by 802.11b/g. When PTT Express is deployed in those 802.11b/g environments, preference should
be given to using 802.11g to avoid any 802.11b devices that would force the network to operate at slower
speeds.
When using 802.11b/g/n/ac, configure the network to operate on channels 1, 6, and 11 to minimize the
frequencies in use that interfere with one another. These channels are recommended when using
802.11b/g/n/ac equipment. Also, some devices which support 802.11b/g/n/ac may be pre-configured to
only scan for 802.11 beacons on these channels.
NOTE: The use of DFS Channels is not recommended.
Introduction
The country code associated with network Access Points (APs) and the enterprise devices must be in
agreement. It is necessary that you assign the country code of the AP based on the country of operation
and that the same country code be assigned on the enterprise device.
It is not recommended to use 5.5 or 11 as the lowest basic rates with MPA2.0 and later devices.
Recommended WLAN Access Point (AP) Configuration for PTT Express
PTT Express communicates half-duplex voice traffic at a QoS of VOICE with sample rates of 200 ms for
Group and 100 ms for Private calls. It is recommended that the network support a DTIM of 2 based on a
Beacon Interval of 100 ms. To ensure timely delivery against lower priority traffic a QoS of VOICE should
be honored across the network by supporting WMM.
Multicast rates on the AP configuration should be optimized. There is some variation between
manufacturers (Cisco, Extreme, etc.). Customers should use the following guidelines to set the multicast
rates on their APs to optimize performance.
Multicast Rate Selection
1. Choosing a Multicast Rate
PTT Express uses multicast distribution to implement Group Call. In contrast to unicast mode, each AP
in the ESS transmits the multicast packet once (no retries), at a fixed rate.
Choice of MC rate is similar to picking a Beacon rate, and should strike a balance between:
a. Lower rates propagate further. Multicast Tx rate should be low enough for a reception rate of at least
90% anywhere within a cell, by all of the target mobile devices.
b. However, an MC rate lower than necessary wastes airtime, and contributes to co-channel
interference.
2. Setting the Multicast Rate
The MC rate policy varies with AP vendor, but usually cues on the Basic Rate settings. Two examples:
a. Extreme WLAN infrastructure: The MC rate is the lowest basic rate.
10
Cisco: MC rate is different for the Wireless Controllers and standalone APs:
b.
• Access points running recent Cisco IOS versions are transmitting multicast and management
frames at the highest configured basic rate, and is a situation that could cause reliability problems.
• Access points running LWAPP or autonomous IOS should transmit multicast and management
frames at the lowest configured basic rate. If reliable reception is a goal, then multicasts should be
transmitted at a low data rate.
3. Summary
Determine how the MC rate is derived, typically from the Basic Rate settings, for the specific vendor,
model, and firmware Rev in play. Then, apply section 1 above.
a. Quick Start
Use just one basic rate. Start with 24 Mb/s basic, and adjust downwards for good performance. As a
safety margin, drop the rate one more step.
Other Settings
IGMP Snooping
IGMP Snooping can be enabled to avoid forwarding multicast packets to all associated APs. When
IGMP Snooping is enabled, IGMP queries are sent to the device and IGMP report is expected. Doze
mode in device to be disabled to process the IGMP queries when device is in idle state. If Doze mode is
not disabled, then the device entries might be removed from IGMP Multicast Group and multicast
packets might not be delivered to the device.
Introduction
NOTE: When multicast packets are not forward to APs after device roamed, consult with WLAN/APs
vendor. IGMP Snooping can be disabled as a mitigation.
11
Installation
Introduction
It is recommended (but not required) that the enterprise device is associated on the network before
installing the PTT Express client on the device. Since at the end of the installation procedure, the device
reboots and a start up tone is played to indicate that the PTT Express application is functional.
Installing the PTT Express Client
NOTE: Zebra does not support installations performed using 3rd party Device Manager solutions.
The default keys used for triggering PTT Express calls need to be remapped when installing PTT Express
on the devices listed in Device Configurations on page 15.
For Windows devices, the use of ActiveSync is recommended for installation on the Mobile Computing
devices. This method is straightforward in that the files are copied to the target device and then run from
the target device.
In order to obtain application software or any available update files please go to the Zebra website
www.zebra.com/support. Once purchased, the requestor is assigned a username and password to access
and download the client.
Windows Devices Using ActiveSync
To install the client software on a Windows Mobile Computing device:
1. Establish ActiveSync connection by connecting your device to a computer with ActiveSync installed.
2. From the ActiveSync window click on the Explore icon.
3. Click on the My Windows Mobile-Based Device icon for full folder list.
4. Open the Temp folder and copy the installer_VC_FB_XXXX.cab file to the device.
5. From the device, use the File Explorer to select and run the installer_VC_FB_XXXX.cab file.
6. After execution of the installer cab file, the device reboots. After reboot, if the device is connected to a
Wi-Fi network a tone is heard, indicating that the PTT Express services are available on the device.
Windows Devices Using an SD Card
To Install the PTT Express client using SD cards:
1. Remove the SD card from the device and connect to a host computer. For information on removing the
SD card refer to device’s user guide.
12
Installation
Copy the
2.
3. Reinsert the SD card into the device.
4. From the device, use the File Explorer to select and run the installer_VC_FB_XXXX.cab file.
5. After the execution of the installer cab file, the device reboots. After reboot, if the device is connected to
a Wi-Fi network a tone is heard, indicating that the PTT Express services are available on the device.
installer_VC_FB_XXXX.cab
Android Devices
The PTT Express client comes pre-installed on all Android devices that support PTT.
Uninstalling the PTT Express Client
Windows Devices
You can only uninstall a client that was previously installed on the mobile computer. Clients that are part of
the factory image cannot be uninstalled.
1. Go to Start > Settings > System > Remove Program.
2. Select the PTT Express application and touch Remove. The Remove Program window appears. “Are
you sure you want to remove it?”
3. Select Yes.
file to the SD card.
NOTE: For some versions of PTT Express the following message may appear. The application is
currently being used... Re run after reboot. Press OK to restart the device. After restart, follow steps 1
through 3 again to uninstall the application.
4. After successful removal, the device restarts.
Updating PTT Express from a Prior Version
Windows Devices
To update PTT Express from a prior version on a Windows device:
1. Uninstall the old version of PTT Express. See Uninstalling the PTT Express Client on page 13.
2. After Uninstallation completes, install the new version of PTT Express. See Installing the PTT Express
Client on page 12.
Installation/Operation Verification
Ensure the device is connected to the network, with at least one other PTT Express enabled device and
perform the following tests to confirm successful operation:
1. Confirm that a Group Broadcast, or page communication can be initiated and that other devices receive
the spoken voice from the originating device.
2. Once a Group Broadcast communication has been successfully established, confirm that a
page-to-private, or Private Response, can be established.
3. While in a WAN call, ensure that page communication cannot be heard.
13
Installation
Installation Using Mobile Device Managers
The PTT Client installation file automatically reboots the device after installation. When installing the PTT
Express client application using a Mobile Device Management (MDM) tool, it might be desired not to
reboot the device after the PTT Express Client application installation. Especially when installing other
applications after the PTT Express Client.
To disable the reboot, the client must be set to a Silent Install mode. Silent Install disables the automatic
reboot after the PTT Express Client installation.
Using a text editor, create a text file with the following:
[installation]
reboot=false
Save the text file with the filename: pttexpress.ini.
Using the MDM push the file to the Application folder before installing the PTT Express Client application.
NOTE: After all applications are installed using the MDM, the MDM must reboot the device.
14
Device Configurations
Introduction
This chapter provides information for configuring PTT Express on Microsoft Windows devices and Android
devices.
Microsoft Windows Registry Settings
A registry editor is required to view and modify the registry settings on a device. Note that after modifying
registry settings, a warm boot or cold boot of the device is required in order to have the changes take
effect.
NOTE: Altering any registry items other than those described in this manual are not supported and could
result in the impaired operation of the device.
If installing PTT Express on the MC3190, the buttons for initiating PTT Express group calls and private
calls must be remapped.
There are two types of mobile computer devices for PTT; those with side grey buttons used for PTT Group
Calls and those without.
The devices with the side buttons are the MC55 and MC75; for these devices, after installation the side
gray button is used for PTT group and the green key for PTT private call. For the rest of the devices, after
installation, the user needs to define which keys to use, normally users use the =5‘ key (Group) and the =9‘
(Private) keys. They define the keys by modifying values in the registry; the values are hex codes obtained
from a key check application which displays the hex code upon pressing a key. The application is obtained
from the www.zebra.com/support web site as part of the EMDK sample applications.
15
Call Timer Registry Settings
Use a registry key to modify the parameters indicated in Table 2. The registry path is:
HKEY_LOCAL_MACHINE\Software\Motorola\CVC
Table 2 Call Timer Registry Settings
Key Type Range/Default Description
PrivateTalkTimeOut DWORD 10000 - 90000 ms
Device Configurations
default = 60000 ms
The amount of time that has to elapse
after which the Private Response
terminates and the unit switches to PTT
mode. Decimal Value in milliseconds.
disable = 0
TalkTimeOut DWORD 10000 - 90000 ms
END_SESSION DWORD 1000 - 10000 ms
NOTE: Note that the hang time represents a minimum value and may vary by up to 1 second due to
possible network and protocol delays. For example, if a value of 5 is entered, the hang time is actually
between 5 and 6 seconds.
Private Response Registry Settings
Use a registry key to modify the parameters indicated in Table 3. The registry path is:
HKEY_LOCAL_MACHINE\Software\Motorola\CVC\DCMe
Table 3 Private Response Registry Settings
Key Type Default Description
PvtHangTimerDuration DWORD 1000 - 10000 ms
default = 60000 ms
default = 10000 ms
default = 10000 ms
The amount of time the user is allowed to
hold the floor (talk without interruption).
Decimal Value in milliseconds. disable = 0
The amount of time that has to elapse
after which a Private Response cannot be
made to the last known talker in the
session. Decimal Value in milliseconds.
The amount of time that has to
elapse after which the Private
Response will terminate and the
device will switch to Group
Broadcast mode. Decimal Value in
milliseconds.
PvtLocalPort DWORD 4080 IP Port to be used for Private
Response communications. Decimal
value.
16
Device Configurations
Group Broadcast Multicast Registry Settings
Use a registry key to modify the indicated parameters in Table 4. The registry path is:
HKEY_LOCAL_MACHINE\Software\Motorola\CVC\WTM.
Table 4 Group Broadcast Multicast Registry Settings
Key Type Default Description
IP_ADDRESS_BASE 239.192.2.2 Multicast address to be used for Group
Broadcast communications.
IP_PORT_BASE DWORD 5000 IP Port number of the multicast address being
used for Group Broadcast communications.
Decimal value
User Configurable Device Key for Private Response and Group Broadcast
A registry editor is required to view and modify the user configurable device keys. Note that after modifying
the configurable device key, a soft-reset of the device is required in order to have the changes take effect.
The registry path is:
NOTE: The following key settings apply to Zebra Mobile Computing devices only. Only one button can be
assigned as the pttPrivateCall (Private Response) key and one button can be assigned as the
pttGroupCall (Group Broadcast) key.
Table 5 User Configurable Device key to be used for Private Response on a Mobile Computer
KEY Type Range/Default Description
pttPrivateCall DWORD 7E (hex)
pttGroupCall DWORD 7E (hex)
HKEY_LOCAL_MACHINE\Software\Motorola\CVC\Keys\
Hex/decimal value of physical key to be pressed for
126 (decimal)
20 (hex)
32 (decimal)
D (hex)
13 (decimal)
126 (decimal)
20 (hex)
32 (decimal)
D (hex)
13 (decimal)
usage in Private Call. Green Key (most MCs)
Space Bar
Enter/Return Key
Hex/decimal value of physical key to be pressed for
usage in Group Call.
Space Bar
Enter/Return Key
17
NOTE: Registry key values need to be updated after installing PTT Express on the MC3190 as it lacks
dedicated keys for PTT Express group calls and private calls:
To determine key codes, the KeyCheck.exe application is run on the device, key to be used is pressed and
keycode in hex is displayed. For example, the =5‘ key will show 0x35 and the =9‘ will show =0x39‘ in the
WM_KEYUP and WM_KEYDOWN events, it is the 0x35, 0x39 values that will be set in the registry key(s).
The KeyCheck.exe application is obtained from the zebra.com/support web site as part of the
EMDK/SMDK sample applications.
Private Key Configurations
A registry editor is required to view and modify the user configurable device keys. Note that after modifying
the configurable device key, a soft-reset of the device is required in order to have the changes take effect.
Device Configurations
The registry path is:
Table 6 User Configurable Device key to be used for Private Response on a Mobile Computer
KEY Type Range/Default Description
PrivateKeyConfig DWORD 0
PrivatecallOffset1
PrivatecallOffset2
NP = Not present.
Valid when Private Call is made using 1.5 key press of Group Call button. (i.e. when PrivateKeyConfig = 1).
Key press timings in milliseconds:
HKEY_LOCAL_MACHINE\Software\Motorola\CVC\Keys.
Disable private calls.
1
NP or any other
value
DWORD NP, NP
0, 0
t1, t2
0, t2
Private Call is made using 1.5 Key press of Group
Call button. 1.5 Key press implies Group Call button
pattern: Press + Release + Press back within
durations specified by PrivatecallOffset1 and
PrivatecallOffset2.
Dedicated keys for Group Call and Private Call.
300ms and 500 ms respectively (default)
300ms and 500 ms respectively (default)
(T2-T1) ms, (T3-T2) ms
The total window (T3 – T1) will be t2 ms.
• T1 - 1st Group Call button press
• T2 - Group Call button release
• T3 - 2nd Group Call button press.
1. By default, PrivatecallOffset1 and PrivatecallOffset2 shall not be present in the registry. In this case and
when PrivatecallOffset1 and PrivatecallOffset2 are set to zero, default values of 300 ms and 500 ms
are assigned respectively.
2. If PrivatecallOffset1 = 0, then the total window (T3 - T1) will be PrivatecallOffset2 ms.
3. If PrivatecallOffset1 and PrivatecallOffset2 are non-zero, then T2 - T1 should be PrivatecallOffset1ms
and T3 - T2 should be PrivatecallOffset2 ms.
4. T3 - T1 should always be less than 1000 ms., if it's more, then we will set to default : T2-T1 = 300 ms
and T3-T2 = 500 ms.
18
On the VC70, by default, PrivateKeyConfig = 1 and PrivatecallOffset1 = NP and PrivateCallOffset2 =
5.
NP.
6. All other devices, by default, PrivateKeyConfig = NP and PrivatecallOffset1 = NP and
PrivateCallOffset2 = NP.
7. On the VC70, the microphone button is used for Group Call and the 1.5 key press of the microphone
button for Private Calls.
Do Not Disturb
A registry editor is required to view and modify the user configurable device keys. Note that after modifying
the configurable device key, a soft-reset of the device is required in order to have the changes take effect.
Device Configurations
The registry path is:
Table 7 Do Not Disturb
KEY Type Range/Default Description
DNDSupport DWORD 0, NP
NP = Not present.
HKEY_LOCAL_MACHINE\Software\Motorola\CVC\.
1
Android Configuration File Settings
Configuration of the PTT Express voice client is controlled by a configuration XML file. The configuration
file is divided into:
• Application settings
• Profile List settings
• Channel settings.
Refer to Client Configuration in the PTT Express User Guide for information on the Android configuration
file settings.
Disabled (default)
Enabled
Talk Group Configuration
Up to 32 talk groups can be created by PTT Express users. However, only one talk group may be enabled
at a time. To toggle between desired talk groups:
1. From the enterprise device Start button, select Programs > PTT Express Configuration.
The PTT Express Configuration window opens showing the default values of:
• Voice Client Enable: selected
• Current Talk Group: 1
2. To determine the PTT Express version at any time, select the About button at the bottom of the screen.
3. To disable the PTT Express voice client PTT communication, select or deselect the Voice Client
Enable field. This toggles the service between active and inactive.
4. To select a different talk group, click the drop down menu of the Current Talk Group field.
Talk groups 1 through 32 are displayed.
19
Device Configurations
Select the desired talk group.
5.
The newly selected talk group is the one that is enabled.
6. Press Save to activate changes.
An audible service tone indicates the Voice Client status.
20
Verification and Troubleshooting
Introduction
It is important to verify the operation of the PTT Express after installing the PTT Express client on the
enterprise devices. Verify that on a Group Broadcast, the target devices are able to receive/playback audio
from the originator and that the user is able to respond to Group Broadcast requests. Then verify that a
Private Response request and response can be established.
The following sections list the verification procedures used to validate the successful installation and
configuration of the PTT Express client and a Frequently Asked Questions (FAQ) related to installation and
configuration.
Verification
The following list indicates the tests recommended to validate the installation and configuration of the PTT
Express Client.
• Download client software from a pre-defined web site.
• Install PTT Express Client software.
• Hold Multicast/ Group Broadcast Conversation. Refer to the PTT Express Users Guide for instructions.
The guide can be downloaded from: www.zebra.com/support.
• Hold a Private Conversation. See the PTT Express Users Guide for instructions. The guide can be
downloaded from: www.zebra.com/support.
• Provision Mobility Services Platform Server with PTT Express client package (for subsequent
download)
• Enable/ disable PTT Express client.
• Dual Mode (Cellular/Express) call interactions.
• Roaming
• Set Group/Private Response Key.
• Configure handset device parameters.
• Configure WLAN parameters.
• Configure Multicast Traffic Processing router/device parameters.
• PTT Express interaction with Line of Business application.
21
Troubleshooting
Table 8 provides solutions to frequently encountered problems.
Table 8 Frequently Asked Questions
Question Answer
What should the WLAN
Adapter be set to?
Verification and Troubleshooting
WLAN Adapter should be set to Fast PowerSafe.
What if you hear a “bonk”
tone when pressing Group
Broadcast key?
What if you hear
non-intelligible audio?
What if there are
association issues?
What happens if I perform
a clean boot?
Check following items on the device”
Check that the Wi-Fi is enabled.
MCxx devices: check the Wi-Fi icon on bottom right hand corner of the
screen. If there is a red “X” it means that Wi-Fi is disabled.
If disabled click the Wi-Fi icon and click on enable option.
Check that the device is associated to Wi-Fi network and has acquired an
IP address.
For MCxx devices, click on Wi-Fi icon on bottom right hand corner of the
screen.
Click Wireless status.
Click Current Profile [This will show ESSID: Channel Number: & Signal
Strength].
Click on back arrow on top right hand corner.
Click on IPv4 Status (This shows the Device IP address: Dynamic Host
Configuration Protocol IP address: DNS IP address etc.).
Check signal strength, packet loss, and speaker/microphone position.
Check country code settings on both the device and the access point.
The PTT Express client is stored in persistent storage on supported
devices. The client remain loaded and in operation after a device warm or
cold boot. A user must re-install the client after a clean boot.
What happens if I press
multiple keys
simultaneously?
While a PTT communication key is pressed the user will not be able to use
other device keys to perform separate tasks. In general pressing multiple
keys simultaneously will lead to inconsistent client behavior.
22
License Installation
Installation procedures are for customers that:
• have purchased a PTT Express version 3.1.46 or higher for Android which is managed by the Zebra
Software License Manager.
• use StageNow for staging or a similar EMM profile.
• Activate their license and associate it with their devices.
Prerequisites
• Clock and network on the devices are configured properly.
• PTT Express license is purchased, and you have the Activation ID from the entitlement notification
email. This is typically sent out to the partner and the end-user on the Purchase Order. Please contact
your partner or your administrator for this email.
Installation
1. To install the license:
2. Launch the StageNow utility.
3. Select Create new Profile.
4. Select the MX version compatible to device.
5. Select Xpert Mode.
6. Select Create.
7. Enter a profile name and select Start.
8. Under LicenseMgr, select Perform Zebra license action and proceed to set the various parameters
to activate the license required. For example:
a> For the licensing cloud option: Activate AID > Use Zebra Licensing cloud option > Zebra
Production Cloud > Enter your AID and Quantity.
9. Select Continue.
This is the recommended option since the device will be synced with the cloud for visibility from the
licensing portal.
23
b.For the local licensing (on-prem) option: Activate AID -> Use a local license server option -> Enter the
URL, friendly name, AID and Quantity. Select Continue. If you choose this option [to cater to a fire-walled
network or don't have access to the cloud]. More details on installing and configuring the Local License
Server can be found on Zebra.com's Licensing Page. Once you set up the LLS, please use the URL of that
LLS in your staging profile.
5. Complete profile creation and scan the staging barcode.
Validating the Above Profile
1. Launch the License Manager application on the device. Ensure the license activated shows up there.
2. PTT Express client on your device should be fully activated. You do not need to configure anything in
the PTT Express client for the license.
3. The quantity is typically 1 since the device is activating only one license for itself. Based on the number
of devices activated, the Available quantity visible on the portal will decrease. The list of device ids will
also show up there.
License Installation
24
