Zebra CR0078-S, CR0008-S Quick Reference Manual

CR0078-S Series/CR0008-S Series Cradles

Quick Reference Guide

2 CR0078-S Series/CR0008-S Series Cradles

©2015 ZIH Corp and/or its affiliates. All rights reserved.

Zebra reserves the right to make changes to any product to improve reliability,
function, or design.

Zebra does not assume any product liability arising out of, or in connection with,
the application or use of any product, circuit, or application described herein.

No license is granted, either expressly or by implication, estoppel, or otherwise
under any patent right or patent, covering or relating to any combination, system,
apparatus, machine, material, method, or process in which Zebra products might
be used. An implied license exists only for equipment, circuits, and subsystems
contained in Zebra products.

This Zebra product may include Zebra Software, Commercial Third Party
Software, and Publicly Available Software. Refer to the Product Reference Guide
for complete copyright, conditions and disclaimer information.

Warranty

For the complete Zebra hardware product warranty statement, go to:
http://www.zebra.com/warranty.

Quick Reference Guide 3

Introduction

The CR0008-S Series cradle acts as a stand and charger for the LS4278 and
DS6878 cordless scanners.

The CR0078-S Series cordless scanner cradle acts as a stand, charger and host
communication interface for LS4278 and DS6878 cordless scanners. The
CR0078-S Series cradle receives data from the scanner via a Bluetooth radio,
and sends that data to the host through an attached cable. The cradle also
charges the scanner’s internal battery pack when the scanner is inserted. The
scanner can be charged through the cradle from an external power supply or
using a powered host cable.

The cradles can sit on a desktop or mount on a wall, computer work station or
medical cart.

This document provides basic instructions on setting up and using the cradle.
Unless otherwise noted, “cradle” refers to all configurations of the cradle. Any
discussion of transmission of information refers specifically to the CR0078-S
Series cradle.

Accessories

The following equipment may be needed:

• Power supply (see Power Supply on page 11).

• Mounting bracket for vertical cradle mounting (p/n 21-135001-01).

Save the shipping container for storing or shipping. Inspect all equipment for
damage. If anything is damaged or missing, call an authorized Customer Support
Representative immediately.

4 CR0078-S Series/CR0008-S Series Cradles

Rubber

Foot

Rubber
Foot

Rubber

Foot

Rubber
Foot

Host

Cable

Groove

Mounting
Hole

Cable
Support
Hooks

Power

Port

Host
Port

Power
Cable
Groove

Desk/Wall Mount

Converter Knob

Mounting
Hole

Latches

Charging/Communication

Contacts

Pairing Bar

Code

Convertible

Front

Back

Cradle Parts

Cradle Connections

Important: Connect the interface cable and power supply (if necessary) in the
following order to ensure proper operation of the scanner and cradle:

1. Insert the interface cable into the cradle’s host port.

2. Connect the other end of the interface cable to the host, if needed.

3. If necessary, connect the power supply to the cradle’s power port (if required

by the interface, or to allow fast charging of the scanner).

4. Connect the appropriate cable to the power supply and an AC power source, if

necessary.

Quick Reference Guide 5

Host Port

Power Port

Power Port

Host Port

Connect to

appropriate host

Power

If the scanner does not recognize the host, disconnect the power supply, then reconnect after connecting the host cable.

5. If applicable, thread the interface cable over the cable support hook and run

the host and power cables into their respective cable grooves.

6. If necessary, scan the appropriate host bar code (for non-autodetected

interfaces). Refer to the LS4278 Product Reference Guide, p/n 72-69834-xx
orDS6878 Product Reference Guide, p/n 72-131700-xx.

IMPORTANT For healthcare environments, use cradle p/n

CR0078-SC1009BWR and place the ferrite core (included in
box with cradle) on the power supply (see Power Supply
Ferrite Installation instructions included in the box).

Changing the Host Interface

To connect to a different host, or to the same host through a different cable:

1. Unplug the power supply from the cradle.

2. Unplug the interface cable from the host.

3. Connect the interface cable to the new host, or the new interface cable to the

existing host.

4. Reconnect the power supply, if required.

5. If necessary, scan the appropriate host bar code (for non-autodetected

interfaces). Refer to the LS4278 Product Reference Guide, p/n 72-69834-xx or

DS6878 Product Reference Guide, p/n 72-131700-xx.
