MOTOROLA SOLUTIONS™
TC55 ACCESSORIES
TC55 SPEC
2
What comes in the Box?
TC55 Device
(Electronic User Guide loaded onto device)
TC55
TC55 Regulatory Guide
Note: Power Supply Sold
Separately
3
TC55
TC55
TC55
CBL-TC55-CHG1-01
Works with or without protective boot.
Rugged
Rugged
Rugged
Charge Cable
Charge Cable
Charge Cable
Requires Power Supply Wall Adapter;
(PWRS-124306-01R) sold separately.
Power Supply
PWRS-124306-01R
Power Supply-100-240 VAC,
5 V, 1.2 A Power Supply:
100-240 VAC, 5V, 1.2A w/plugs.
Includes four international plugs for US, UK, EU & AU.
Provides a full 1.2 amps of power for rapid battery charging.
For Brazil Order: PWRS-124306-01BR: PS 90-264VAC, 5V,1.2A w/Brazil & U.S. plug
For China Order: PWRS-124306-01CN: PS: 90-264VAC, 5V,1.2A w/China plug
For South Korea Order: PWRS-124306-01S : PS 90-264VAC, 5V,1.2A w/S. Korean plug
4
TC55 Lithium-Ion Batteries
Features:
User replaceable battery
Smart battery with:
Fuel gauging
Manufacturing date
Cycle count
TC55 Batteries
& Battery Doors
Lithium Ion
P/N:
For Brazil Order:
Battery Door SKU
mAh
TC55Dimensions:
TC55 Weight:
Talk Time:
Test Profile: WAN on 100% ; GPS on 100%; BT off, WIFI on ( not associated to AP: worst case); 350 scans/hour; Send 500k bytes every 2 hours (ATT 4G); Back­light 50%; Display on 75%, off 25%;> Standard Battery: 13 hours; > Extended Battery 18.5 hours
1X 1.5X
BTRY-TC55-29MA1-01 BTRY-TC55-44MA1-01
BTRY-TC55-29BR1-01 BTRY-TC55-44BR1-01
KT-TC55-29BTYD1-01 KT-TC55-44BTYD1-01
2940 4410
137.2 X 69 X1 5.9 mm 137.2 X 69 X 22.8 mm
220 grams 250 grams
16 Hours 24 Hours
5
1.5X
1X
TC55 Holster
SG-TC55-HLSTR1-01
Stylus can be stored in upper flap
Holster accommodates:
1X or 1.5X battery
Optional Protective Boot
Stylus in upper flap
Magnetic Flap allows
for quick closure
Rugged Belt Clip
6
TC55 Protective Boots
Provides additional protection
Battery, SIM, and micro SD are accessible when boot is in place
Stylus (sold separately) can be snapped into side of Boot
Can be used with all other accessories including:
1X & 1.5X Batteries
Charging Accessories
Vehicle Cradle Holster
Available in 2 Color Options:
Blue & Black: SG-TC55-BOOT1-01
Grey & Black: SG-TC55-BOOT2-01
TC55 Stylus
Stylus ships with tether;
Can be snapped into Boot or stored in upper flap of Holster
Available in 1 & 3 Packs:
Single Pack: KT-TC55-STYLUS1-01
3-Pack: KT-TC55-STYLUS1-03
7
TC55
Vehicle Cradle
CRD-TC55-VCD1-01
Auto Charge Cable
VCA400-01R
12/24 VOLT MICRO USB AUTO CHARGER (CIG ADPTR)
Designed to withstand the demanding requirements of
commercial use where up-time is prime consideration.
Input: 12-24VDC 1.3A
Output: 5.0V- 1.2A
NOTE: The VCA400-01R auto charge cable is designed to con-
nect directly to the micros USB port on the TC55 vehicle cra-
dle. It should NOT be used to connect directly to TC55.
TC55 Vehicle Cradle includes Suction Cup
Installation Kit.
Accommodates Device with or without
Protective Boot.
Vehicle cradle enables charging through the
rugged connector on the bottom of the TC55
by passing power through the micro USB con-
necter located at the rear of the cradle. An Auto
Charge Cable is required and sold separately.
8
TC55 5-SlOT CHARGE ONLY CRADLE
CRDUNIV-55-5000R
Accommodates up to 5 TC55s Can Support 1X or 1.5X Batteries
Can Charge Terminal with or without Protective Boot
( remove shim from terminal cup to accommodate terminal w/protective boot)
Desk top ready
Rack mountable
Mounting Bracket Kit sold separately (KT-UNIVLBRKT-01R)
NOTE: Power supply (PWRS-14000-148C) & Country Specific AC Line Cord Sold Separately
PWRS-14000-148C
PWR SPLY:100-240 VAC,12VDC,4.16A MOD.
Order country specific three wire grounded AC
Line Cord (sold separately)
Also compatible with ET1, MC40, MC45, & TC55.
KT-UNIVLBRKT-01R
Cradle mounting bracket for the 5– Slot Charge
Only Cradle. Accommodates Power Supplies on
lower shelf.
9
TC55 5-SLOT CRADLE:
AC LINE CORDS for use with PWRS-14000-148C
COUNTRY SKU DESCRIPTION
Bolivia Iran Abu Dhabi Australia China China Dubai Egypt Europe Hong Kong India Iraq Israel Italy Japan Korea Korea
50-16000-220R 50-16000-220R 50-16000-220R 50-16000-217R 50-16000-217R 50-16000-257R 50-16000-220R 50-16000-220R 50-16000-220R 50-16000-219R 50-16000-669R 50-16000-219R 50-16000-672R 50-16000-671R 50-16000-218R 50-16000-220R 50-16000-256R
AC Line Cord, 1.8M, grounded, three wire CEE 7/7plug. AC Line Cord, 1.8M, grounded, three wire CEE 7/7plug. AC Line Cord, 1.8M, grounded, three wire CEE 7/7plug. AC Line Cord, 1.9M, grounded, three wire AS 3112 plug. AC Line Cord, 1.9M, grounded, three wire AS 3112 plug. AC Line Cord, 1.8M, grounded, three wire, IEC 60320 C13 plug. AC Line Cord, 1.8M, grounded, three wire CEE 7/7plug. AC Line Cord, 1.8M, grounded, three wire CEE 7/7plug. AC Line Cord, 1.8M, grounded, three wire CEE 7/7plug. AC Line Cord, 1.8M, grounded, three wire BS1363 plug. AC Lind Cord, 1.9M, grounded, three wire BS 546 plug AC Line Cord, 1.8M, grounded, three wire BS1363 plug. AC Line Cord, 1.9M grounded, three wire, S132 plug. AC Line Cord, 1.8M grounded, three wire, CIE 23-16 plug. AC Line Cord, 1.8M, grounded, three wire , NEMA 1-15P plug. AC Line Cord, 1.8M, grounded, three wire CEE 7/7plug.
AC Line Cord, 1.8M, grounded, three-wire, CEE7/7 plug. Malaysia New Guinea Russia Singapore United Kingdom United States United States Vietnam
50-16000-219R 50-16000-217R 50-16000-220R 50-16000-219R 50-16000-219R
23844-00-00R 50-16000-678R 50-16000-220R
AC Line Cord, 1.8M, grounded, three wire BS1363 plug. AC Line cord, 1.9M, grounded, three wire AS 3112 plug AC Line Cord, 1.8M, grounded, three wire CEE 7/7plug. AC Line Cord, 1.8M, grounded, three wire BS1363 plug. AC Line Cord, 1.8M, grounded, three wireBS1363 plug. AC Line cord 7.5 ft long, grounded, three wire. AC Line Cord, 36" long, grounded, three wire. AC Line Cord, 1.8M, grounded, three wire CEE 7/7plug.
10
TC55 Miscellaneous SKUS
USB Cable
25-MCXUSB-01R
TC55 CRADLE REPLACEMENT PART SKUS
Replacement Part Numbers
Base for 5-Slot
Charge Only
Cradle
TC55 Cradle
Adapter Cup
Blank Slot cover CUPUNICVR-5000R
CRDUNIV-XX-5000R
CUPTC55XX-1000R
5-Slot Charge Only Cradle Base; requires Terminal specific Cups
(CUPTC55XX-1000R, PWRS-14000-148C, and country specific AC
Line Cord (all sold separately)
TC55 Single Charging Cup for use with Charging Cradle
(CRDUNIV-XX-5000R sold separately)
Blank Slot Covers for use with the 5-Slot Charge Only Cradle
(CRDUNIV-XX-5000R). Plastic lid to cover and protect cradle
charge slots when device specific charge cups are not in use. Con-
tains 5 Pieces
11
Accessory
Category
TC55 ACCESSORY LIST
SKU Description
Holster
Protective Boot
Single Terminal
Charging
Multiple Terminal
Charging
SG-TC55-HLSTR1-01
SG-TC55-BOOT1-01
SG-TC55-BOOT2-01
CBL-TC55-CHG1-01
PWRS-124306-01R
CRDUNIV-55-5000R
PWRS-14000-148C
TC55 HOLSTER with Magnetic flap; can use with 1X/1.5X Battery, with or without optional boot.
Compartment for stylus in upper flap.
TC55 BOOT: BLUE/BLACK; Protective Boot; accommodates stylus (KT-TC55-STYLUS1-01; sold separately)
TC55 BOOT: GREY/BLACK; Protective Boot; accommodates stylus (KT-TC55-STYLUS1-01; sold separately)
TC55 RUGGED CHARGING CABLE; Snap-On Rugged Charging Cable requires Power Supply (PWRS-124306-01R sold separately)
Power Supply-100-240 VAC, 5 V, 1.2 A for rapid battery charging. Includes four international plugs for US, UK, EU and AU. For use with ES400 /MC40/MC45/TC55.
TC55 5-SLOT CHARGING CRADLE. Requires PWRS-14000-148C & Country Specific AC Line Cord (sold separately).
Power Supply: 100-240 VAC,12VDC,4.16A MOD . Order country specific three wire grounded AC Line Cord (sold separately)
Vehicle Solutions
KT-UNIVLBRKT-01R
CRD-TC55-VCD1-01
VCA400-01R
Cradle mounting bracket for the 5– Slot Charge Only Cradle. Accommodates Power Supplies on
lower shelf.
TC55 VEHICLE CRADLE with suction cup mounting kit. Purchase auto charge cable (VCA400-01R) separately for vehicle charging.
Auto Charge Cable: 12/24 Volt Micro USB Auto Charger (Cig Adapter)
12
Accessory
Category
TC55 ACCESSORY LIST
SKU Description
USB Cable
Batteries
Battery Doors
Stylus
Screen Protectors KT-TC55-SCRNP1-03
25-MCXUSB-01R
BTRY-TC55-29MA1-01
BTRY-TC55-44MA1-01
BTRY-TC55-29BR1-01
BTRY-TC55-44BR1-01
KT-TC55-29BTYD1-01
KT-TC55-44BTYD1-01
KT-TC55-STYLUS1-01
KT-TC55-STYLUS1-03
Micro USB Cable - for MC40 & TC55
TC55 1X BATTERY; 2,940 mAh Lithium-Ion, QTY-1
TC55 1.5X BATTERY; 4,410 mAh Lithium-Ion, QTY-1
TC55 1X BRAZIL BATTERY; 2,940 mAh Lithium-Ion, QTY-1
TC55 1.5X BRAZIL BATTERY; 4,410 mAh Lithium-Ion, QTY-1
TC55 1X BATTERY DOOR for TC55 when using a 1X Battery
(BTRY-TC55-29MA1-01; sold separately)
TC55 1.5X BATTERY DOOR or TC55 when using a 1.5X Battery (BTRY-TC55-44MA1-01; sold separately)
TC55 SPARE STYLUS with Tether (QTY-1)
TC55 STYLUS with Tether (3-Pack)
TC55 SCREEN PROTECTORS (3-Pack)
CUPTC55XX-1000R
Replacement
5-Slot Cradle Parts
CRDUNIV-XX-5000R
TC55 Single Charging Cup for use with 5-Slot Charging (CRDUNIV-XX-5000R (sold separately)
BASE ONLY FOR 5-SLOT CHARGE ONLY CRADLE - works with MC40, MC45, and TC55. Must order device specific charging cups, power supply (PWRS-14000-148C) and country specific AC line cord separately.
13
