TECHNICAL GUIDE

80% AFUE MODULATING ECM
RESIDENTIAL GAS FURNACES

MULTI-POSITION LOW NOx
MODELS: YPLC

NATURAL GAS
60 - 120 MBH INPUT

Due to continuous product improvement, specifications
are subject to change without notice.

Visit us on the web at:

www.york.com

Additional rating information can be found at:

www.ahridirectory.org

WARRANTY SUMMARY

A 20-year limited warranty on heat exchangers in residential
applications.

A 10-year warranty on the heat exchanger in commercial
applications.

Standard 5-year limited Parts warranty.

Extended lifetime heat exchanger and 10-year limited
parts warranty when product is registered online within
90 days of purchase for replacement or closing for new
home construction.

See Limited Warranty certificate in Users Information Manual for details.

FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE

539163-YTG-E-0715

DESCRIPTION

These compact units employ induced combustion, reliable hot
surface ignition and high heat transfer aluminized tubular heat
exchangers. The units are factory shipped for installation in
upflow or horizontal applications and may be converted for
downflow applications.

These furnaces are designed for residential installation in a
basement, closet, alcove, attic, recreation room or garage and
are also ideal for commercial applications. All units are factory
assembled, wired and tested to assure safe dependable and
economical installation and operation.

These units are Category I listed and may be common vented
with another gas appliance as allowed by the National Fuel Gas
Code.

FEATURES

• Modulating heating operation includes:

- Modulating gas valve, inducer and circulating blower

- Modulating operation from 100% input to 50% input in
100% increments or from 100% to 65 % in pu t w it h ch im­ney kit S1-1CK0605

• Easily applied in upflow, horizontal left or right, or downflow
installation with minimal conversion necessary.

• Compact, easy to install, ideal height 33" tall cabinet.

• ECM variable speed motor for cooling SEER
enhancement, blower delay options for comfort, and
continuous fan options for IAQ performance.

• Easy access to controls to connect power/control wiring.

• Built-in, high level self diagnostics with fault code display.

• Low unit amp requirement for easy replacement
application.

• All models are convertable to use propane (LP) gas.

• Electronic Hot Surface Ignition saves fuel cost with
increased dependability and reliability.

• 100% shut off main gas valve for extra safety.

• 24V, 40 VA control transformer and blower relay supplied
for add-on cooling.

• Hi-tech tubular aluminized steel primary heat exchanger.

• Blower door safety switch.

• Solid removable bottom panel allows easy conversion.

• Low NOx models have been designed to meet specific
code requirements.

• Airflow leakage less than 1% of nominal airflow for
ductblaster conditions.

• No knockouts to deal with, making installation easier.

• Movable duct connector flanges for application flexibility.

• Quiet inducer, burner and blower operation.

• Inducer rotates for easy conversion of venting options.

• Fully supported blower assembly for easy access and
removal of blower.

• External air filters used for maximum flexibility in meeting
customers IAQ needs.

• Venting applications - may be installed as a common vent
with other gas-fired appliances.

• Insulated blower compartment for thermal and acoustic
performance.

• 1/4 turn knobs provided for easy door removal.

539163-YTG-E-0715

LEFT SIDE

RIGHT SIDE

.5”

.5”

RETURN END

B

24.25”

30.25”

28.5”

Gas Pipe
Entry

Thermostat
Wiring

FRONT

14”

1”

1.5”

23”

SUPPLY END

C

24.38”

20”

.5”

B

Gas Pipe
Entry

Thermostat
Wiring

33”

A

.5”

Electrical
Entry

Electrical
Entry

Vent Connection
Outlet

Vent
Connection
Outlet

4” Diameter

Outlet

Vent Connection

•

Cabinet and Duct Dimensions

Models

Nominal

CFM (m

3

/min)

Cabinet

Size

YPLC060A12MP12C 1200 A 14 1/2 13 1/4 10.3
YPLC080B12MP12C 1200 B 17 1/2 16 1/4 11.8
YPLC080C16MP12C 1600 C 21 19 3/4 13.6
YPLC100C16MP12C 1600 C 21 19 3/4 13.6
YPLC100C20MP12C 2000 C 21 19 3/4 13.6
YPLC120C20MP12C 2000 C 21 19 3/4 15.8

Cabinet Dimensions (Inches)

ABC

Ratings & Physical / Electrical Data

Input

Models

Max/Min

MBH MBH CFM °F °F
YPLC060A12MP12C 60/30 47/24 80.0 1200 7.0 30-60 20-50
YPLC080B12MP12C 80/40 62/32 80.0 1200 7.5 40-70 20-50
YPLC080C16MP12C 80/40 62/32 80.0 1600 10.0 35-65 20-50
YPLC100C16MP12C 100/50 78/40 80.0 1600 10.0 35-65 20-50
YPLC100C20MP12C 100/50 78/40 80.0 2000 12.0 35-65 20-50
YPLC120C20MP12C 120/60 95/48 80.0 2000 12.0 45-75 25-55

Max. Outlet

Models

Air Temp

°F HP Amps Lbs
YPLC060A12MP12C 160 1/2 4.8 11 x 8 15 14 94
YPLC080B12MP12C 170 1/2 4.8 11 x 8 15 14 103
YPLC080C16MP12C 165 3/4 7.5 11 x 10 15 14 114
YPLC100C16MP12C 165 3/4 7.5 11 x 10 15 14 118
YPLC100C20MP12C 165 1 14.5 11 x 11 20 12 122
YPLC120C20MP12C 175 1 14.5 11 x 11 20 12 129

NOTES:

Annual Fuel Utilization Efficiency (AFUE) numbers are determined in accordance with DOE Test procedures.
Wire size and over current protection must comply with the National Electrical Code (NFPA-70-latest edition) and all local codes.

2 Johnson Controls Unitary Products

Output

Max/Min

Blower

AFUE

Nominal

Airflow

Blower

Wheel Size

Total

Unit

Amps

Max

Over-Current

Protect

Air Temp. Rise

Max Input

Min. wire Size

(awg) @ 75 ft

one way

Operating Weights

Air Temp.

Rise Min Input

Approximate

539163-YTG-E-0715

FILTER PERFORMANCE

The airflow capacity data published in the “Blower Perfor­mance” table represents blower performance WITHOUT filters.

All applications of these furnaces require the use of field
installed air filters. All filter media and mounting hardware or
provisions must be field installed external to the furnace cabi­net. DO NOT attempt to install any filters inside the furnace.

NOTE: Single side return above 1800 CFM is approved as long
as the filter velocity does not exceed filter manufacturer ’s rec­ommendation and a transition is used to allow use of a 20 x 25
filter.

Recommended Filter Sizes

CFM

1200 A 16 x 25 14 x 25
1200 B 16 x 25 16 x 25
1600 C 16 x 25 20 x 25
2000 C (2) 16 x 25 20 x 25

NOTES:

1.Air velocity through throwaway type filters may not exceed 300 feet per min­ute (91.4 m/min). All velocities over this require the use of high velocity fil­ters.

2.Do not exceed 1800 CFM using a single side return and a 16x25 filter. For
CFM greater than 1800, you may use two side returns or one side and the
bottom or one return with a transition to allow use of a 20x25 filter.

Cabinet

Size

Side

(in)

Bottom

(in)

Unit Clearances to Combustibles

Application Top Front Rear

Upflow B-Vent 130001CombustibleYesYesYes No
Downflow B-Vent130001

Horizontal B-Vent130001CombustibleNoYesYes

NOTES:

1. Special floor base or air conditioning coil required for use on combusti ble floor.

2. Line contact only permitted between lines formed by the intersection of the rear panel and side panel (top in horizontal position) of the fur nace jacket and building
joists, studs or framing.

Left

Side

Right

Side

Flue

Floor/

Bottom

1

1

Closet Alcove Attic

Yes Yes Yes No

Line

Contact

2

Yes

ACCESSORIES

PROPANE (LP) CONVERSION KIT -

1NP0681 - All Models
This accessory conversion kit may be used to convert natural

gas (N) units for propane (LP) operation.
Do not use Conversion Kit S1-1NP0680 with these models, as

the control/gas valve combination have been updated, and that
kit S1-1NP0680 will not function correctly with these models.

SIDE RETURN FILTER RACKS -

1SR0200 - All Models
1SR0302 - All Models
1SF0101 - All Models

BOTTOM RETURN FILTER RACKS -

1BR0514 or 1BR0614 - For 14-1/2” cabinets
1BR0517 or 1BR0617 - For 17-1/2” cabinets
1BR0521 or 1BR0621 - For 21” cabinets
1BR05xx series are galvanized steel filter racks. 1BR06xx are

pre-painted steel filter racks to match the appearance of the fur­nace cabinet.

MASONRY CHIMNEY KIT -

S1-1CK0605 - All Models
This accessory kit allows the modulating 80% models to be

vented into a tile-lined masonry chimney. The kit modifies the
control board software to restrict the lowest input rate to 65% of
the maximum input.

COMBUSTIBLE FLOOR BASE KIT -

1CB0514 - For 14-1/2” cabinets
1CB0517 - For 17-1/2” cabinets
1CB0521 - For 21” cabinets
For installation of these furnaces in downflow applications

directly onto combustible flooring material, These kits are
required to prevent potential overheating situations. These kits
are also required in any applications where the furnace in
installed in a downflow configuration without an evaporator coil,
where the combustible floor base kit provides access for com­bustible airflow.

HIGH ALTITUDE -

No high altitude kits are required.

ROOM THERMOSTATS -

A wide selection of compatible thermosets are available to pro­vide optimum performance and features for any installation.

1H/1C, manual change-over electronic non-programmable ther­mostat.

1H/1C, auto/manual changeover, electronic programmable,
deluxe 7-day, thermostat.

1H/1C, auto/manual changeover, electronic programmable.
* For the most current accessory information, refer to the price

book or consult factory.

Johnson Controls Unitary Products 3

Blower Performance CFM - Any Position

High / Low Speed Cooling CFM

060A12*C 080B12*C Jumper Settings

Hi Cool Lo Cool Hi Cool Lo Cool COOL Jumper ADJ Jumper

1340 900 1290 790 H B
1125 750 1065 660 MH B
1225 820 1165 720 H A
1050 680 960 600 MH A
1100 740 1050 590 H C

890 600 855 525 ML B
920 615 875 540 MH C
675 450 640 395 L B
815 545 775 495 ML A
600 440 580 380 L A
720 499 700 430 ML C
540 440 525 380 L C

High / Low Speed Cooling CFM

080C16*C 100C16*C Jumper Settings

Hi Cool Lo Cool Hi Cool Lo Cool COOL Jumper ADJ Jumper

1715 1165 1600 1120 H B
1520 1020 1450 980 MH B
1575 1060 1500 1020 H A
1395 930 1345 900 MH A
1430 950 1315 930 H C
1320 875 1265 845 ML B
1260 840 1210 805 MH C
1100 730 1080 700 L B
1200 795 1165 765 ML A
1000 665 980 635 L A
1080 715 1050 695 ML C

900 600 885 585 L C

High / Low Speed Cooling CFM

100C20*C 120C20*C Jumper Settings

Hi Cool Lo Cool Hi Cool Lo Cool COOL Jumper ADJ Jumper

2110 1360 1990 1290 H B
1670 1085 1760 1030 MH B
1900 1235 1900 1210 H A
1515 990 1510 935 MH A
1710 1130 1800 1095 H C
1465 950 1540 900 ML B
1370 890 1440 845 MH C
1255 815 1320 790 L B
1330 865 1400 835 ML A
1140 740 1200 725 L A
1195 780 1260 750 ML C
1025 665 1080 650 L C

NOTES:

All CFM’s are shown at 0.5” w.c. external static pressure.These units have variable speed motors that automatically adjust to provide constant CFM from 0.0”
to 0.6” w.c. static pressure. From 0.6” to 1.0” static pressure, CFM is reduced by 2% per 0.1” increase in static. Operation on duct systems with greater than

1.0” w.c. external static pressure is not recommended.
At some settings, LOW COOL airflow may be lower that what is required to operate an airflow swi tch on cert ain models of elect ronic air cle aners. Consult the

instructions for the electronic air cleaner for further details.

Subject to change without notice. Published in U.S.A. 539163-YTG-E-0715
