Yokogawa AXFA14GC User Manual

User’s
AXFA14G/C
Manual
Magnetic Flowmeter Remote Converter [
Hardware Edition/Software Edition
]
AXF Magnetic Flowmeter Integral Flowmeter [
Software Edition
]
IM 01E20C02-01E
Yokogawa Electric Corporation
IM 01E20C02-01E
10th Edition

CONTENTS

Contents
1. INTRODUCTION ................................................................................................... 1-1
1.1 Using the Magnetic Flowmeter Safely ........................................................... 1-2
1.2 Warranty .......................................................................................................... 1-3
1.3 Combination Remote Flowtubes ..................................................................... 1-3
1.4 ATEX Documentation .................................................................................... 1-4
2. HANDLING PRECAUTIONS ............................................................................... 2-1
2.1 Checking Model and Specifications ............................................................... 2-1
2.2 Accessories ...................................................................................................... 2-1
2.3 Storage Precautions ......................................................................................... 2-1
2.4 Installation Location Precautions .................................................................... 2-2
3. INSTALLATION .................................................................................................... 3-1
3.1 Installation Location ........................................................................................ 3-1
3.2 Mounting ......................................................................................................... 3-1
4. WIRING ................................................................................................................... 4-1
4.1 Wiring Precautions .......................................................................................... 4-1
4.2 Cables .............................................................................................................. 4-1
4.3 Wiring Ports .................................................................................................... 4-3
4.4 Wiring Connections ........................................................................................ 4-4
4.4.1 Removing Cover ...................................................................................... 4-4
4.4.2 Terminal Configuration............................................................................ 4-4
4.4.3 Precautions for Wiring of Power Supply Cables ..................................... 4-5
4.4.4 DC Power Connection ............................................................................. 4-5
4.4.5 Grounding ................................................................................................ 4-6
4.4.6 Wiring the Remote Flowtube with the AXFA14 Converter ..................... 4-6
4.4.7 Connecting to External Instruments ........................................................ 4-7
4.4.8 Installing the Cover.................................................................................. 4-8
5. BASIC OPERATING PROCEDURES (USING THE DISPLAY UNIT) ........ 5-1
5.1 Operating Panel Configuration and Functions ............................................... 5-2
5.2 Display Unit Setting Methods......................................................................... 5-3
5.2.1 Display Mode Æ Setting Mode ............................................................... 5-3
5.2.2 Setting Mode ............................................................................................ 5-5
5.3 Parameter Setting Procedure ........................................................................... 5-5
5.3.1 Setting Example for Selection-Type Data: Flow rate units ..................... 5-5
5.3.2 Setting Example for Numeric-Type Data: Flow rate span ....................... 5-7
5.3.3 Setting Example for Alphanumeric-Type Data: Tag number .................. 5-8
10th Edition: June 2012 All Rights Reserved, Copyright © 2003, Yokogawa Electric Corporation
i
IM 01E20C02-01E
CONTENTS
6. PARAMETER DESCRIPTION ............................................................................ 6-1
6.1 Parameters ....................................................................................................... 6-1
6.2 Parameter Lists ................................................................................................ 6-1
6.3 Parameter List Overview ................................................................................ 6-2
6.4 Parameter Description ................................................................................... 6-12
(1) Menu B: Easy Setup items ............................................................................ 6-12
(2) Menu C: Basic Setting items ......................................................................... 6-15
(3) Menu D: Total Setting items ......................................................................... 6-17
(4) Menu E: Pulse Setting items ......................................................................... 6-19
(5) Menu F: Status Functions Setting items ....................................................... 6-20
(6) Menu G: Alarm Setting items ....................................................................... 6-26
(7) Menu H: Display Setting items ..................................................................... 6-30
(8) Menu J: Auxiliary Function Setting items .................................................... 6-30
(9) Menu K: Diagnostic Function Setting items ................................................. 6-33
(10) Menu M: Automatic Zero Adjustment Function Setting items ................... 6-33
(11) Menu N: Loop Test Setting items ............................................................... 6-34
(12) Menu P: Parameter Protection items ........................................................... 6-34
6.5 Alarm Functions ............................................................................................ 6-35
6.5.1 Alarm Levels.......................................................................................... 6-35
6.5.2 Alarm Selection ..................................................................................... 6-36
6.5.3 Alarms & Warning Messages ................................................................ 6-38
6.6 Precautions for the AXF Integral Flowmeter ............................................... 6-40
7. OPERATION VIA BRAIN TERMINAL (BT200) .............................................. 7-1
7.1 BT200 Basic Operations ................................................................................. 7-1
7.1.1 Key Layout and Display .......................................................................... 7-1
7.1.2 Key Descriptions...................................................................................... 7-1
7.2 AXFA14 Operation Using a BT200 ............................................................... 7-3
7.2.1 BT200 Connection ................................................................................... 7-3
7.2.2 The data update and upload/download function of BT200...................... 7-3
7.2.3 BT200 Screens & Flow Rate Data Display ............................................. 7-4
7.3 Parameter Setting Using a BT200 .................................................................. 7-4
7.3.1 BT200 Setting of Selection-Type Data: Flow rate units .......................... 7-5
7.3.2 BT200 Setting of Numeric-Type Data: Flow rate span ........................... 7-6
7.3.3 BT200 Setting of Alphanumeric-Type Data: Tag number ....................... 7-7
8. OPERATION VIA HART COMMUNICATOR ................................................. 8-1
8.1 Matching of instrument (AXFA14) DD and
HART Configuration Tool’s DD .................................................................... 8-1
8.2 Interconnection between AXFA14 and HART Configuration Tool .............. 8-2
8.3 Basic Setup ...................................................................................................... 8-3
8.4 Parameters ....................................................................................................... 8-3
8.4.1 Parameter configuration........................................................................... 8-3
8.4.2 Data Renewing......................................................................................... 8-3
8.4.3 Self-diagnostic ......................................................................................... 8-4
8.4.4 HART Specific Functions ........................................................................ 8-4
8.4.5 Other operations for the HART configuration tool .................................. 8-6
8.4.6 Menu Tree for DD (HART 5) .................................................................. 8-7
8.4.7 Menu Tree for DTM (HART 5) ............................................................. 8-12
ii
IM 01E20C02-01E
CONTENTS
9. ACTUAL OPERATION ......................................................................................... 9-1
9.1 Pre-operation Zero Adjustment ....................................................................... 9-1
9.1.1 Zero Adjustment Using Display Unit Switches....................................... 9-2
9.1.2 Zero Adjustment via External Status Input.............................................. 9-3
10. MAINTENANCE .................................................................................................. 10-1
10.1 Maintenance .................................................................................................. 10-1
10.1.1 Fuse Replacement .................................................................................. 10-1
10.1.2 Changing the Direction of the Display Unit .......................................... 10-1
10.2 Setting of Switches ....................................................................................... 10-3
10.2.1 Setting of Burnout Switch ..................................................................... 10-3
10.2.2 Setting of Write Protect Switch ............................................................. 10-3
10.3 Troubleshooting ............................................................................................. 10-4
10.3.1 No Indication ......................................................................................... 10-4
10.3.2 Unstable Zero......................................................................................... 10-5
10.3.3 Disagreement Between Indication and Actual Flow.............................. 10-6
11. OUTLINE............................................................................................................... 11-1
12. EXPLOSION PROTECTED TYPE INSTRUMENT ....................................... 12-1
12.1 ATEX ............................................................................................................ 12-1
12.2 FM ................................................................................................................. 12-2
12.3 CSA ............................................................................................................... 12-3
12.4 IECEx ............................................................................................................ 12-4
12.5 TIIS ................................................................................................................ 12-5
INSTALLATION AND OPERATING PRECAUTIONS FOR TIIS FLAMEPROOF
EQUIPMENT .......................................................................................................................1
1. General ................................................................................................................ 1
2. Electrical Apparatus of Flameproof Type of
Explosion-Protected Construction .......................................................................1
3. Terminology ........................................................................................................ 1
4. Installation of Flameproof Apparatus ................................................................. 2
5. External Wiring for Flameproof Apparatus......................................................... 2
6. Maintenance of Flameproof Apparatus ............................................................... 3
7. Selection of Cable Entry Devices for Flameproof Type ..................................... 3
REVISION RECORD ......................................................................................................... 1
iii
IM 01E20C02-01E
1. INTRODUCTION
NOTE

1. INTRODUCTION

This instrument has been adjusted at the factory before shipment.
To ensure correct use of the instrument, please read this manual thoroughly and fully understand how to operate the instrument before operating it.
NOTE
This manual describes the hardware and soft­ware configurations of the AXFA14 converter and the software configuration of the AXF integral flowmeter.
The contents of “basic operating procedures”, “parameter description”, “operation via BRAIN terminal (BT200)”, “operation via HART commu­nicator”, and “actual operation” for the AXF integral flowmeter are the same as the AXFA14, see Chapter 5 to 9 in this manual. For the hardware configuration of the AXF integral flowmeter, see the user’s manual of the AXF Integral Flowmeter/Remote Flowtube [Hardware Edition] (IM 01E20D01-01E). For FOUNDATION Fieldbus protocol (Output Signal and Communication suffix code; -F), please refer to IM 01E20F02-01E. For PROFIBUS PA protocol (Output Signal and Communication suffix code; -G), please refer to IM01E20F12-01E.
Regarding This User's Manual
• This manual should be provided to the end user.
• Before use, read this manual thoroughly to compre­hend its contents.
• The contents of this manual may be changed without prior notice.
• All rights are reserved. No part of this manual may be reproduced in any form without Yokogawa's written permission.
• Yokogawa makes no warranty of any kind with regard to this material, including, but not limited to, implied warranties of merchantability and suitability for a particular purpose.
• All reasonable effort has been made to ensure the accuracy of the contents of this manual. However, if any errors or omissions are found, please inform Yokogawa.
• Yokogawa assumes no responsibilities for this product except as stated in the warranty.
• Please note that this user's manual may not be revised for any specification changes, construction changes or operating part changes that are not considered to affect function or performance.
• If the customer or any third party is harmed by the use of this product, Yokogawa assumes no responsi­bility for any such harm owing to any defects in the product which were not predictable, or for any indirect damages.
Please refer to manual IM 01E20D01-01E for information of the AXF Remote Flowtube.
Safety and Modification Precautions
• The following general safety precautions must be observed during all phases of operation, service, and repair of this instrument. Failure to comply with these precautions or with specific WARNINGS given elsewhere in this manual violates safety standards of design, manufacture, and intended use of the instrument. Yokogawa assumes no liability for the customer's failure to comply with these require­ments. If this instrument is used in a manner not specified in this manual, the protection provided by this instrument may be impaired.
• Yokogawa will not be liable for malfunctions or damage resulting from any modification made to this instrument by the customer.
• The following safety symbol marks are used in this user's manual and instrument.
WARNING
A WARNING sign denotes a hazard. It calls attention to procedure, practice, condition or the like, which, if not correctly performed or adhered to, could result in injury or death of personnel.
CAUTION
A CAUTION sign denotes a hazard. It calls attention to procedure, practice, condition or the like, which, if not correctly performed or adhered to, could result in damage to or destruction of part or all of the product.
1-1
IM 01E20C02-01E
1. INTRODUCTION
IMPORTANT
An IMPORTANT sign denotes that attention is required to avoid damage to the instrument or system failure.
NOTE
A NOTE sign denotes information necessary for essential understanding of operation and fea­tures.
Protective grounding terminal
Functional grounding terminal (This terminal should not be used as a protective grounding terminal.)
Alternating current
Direct current

1.1 Using the Magnetic Flowmeter Safely

WARNING
(1) Installation
• Installation of the magnetic flowmeter must be performed by expert engineer or skilled person­nel. No operator shall be permitted to perform procedures relating to installation.
• The magnetic flowmeter is a heavy instrument. Be careful that no damage is caused to person­nel through accidentally dropping it, or by exerting excessive force on the magnetic flowmeter. When moving the magnetic flowme­ter, always use a trolley and have at least two people carry it.
• When the magnetic flowmeter is processing hot fluids, the instrument itself may become ex­tremely hot. Take sufficient care not to get burnt.
• Where the fluid being processed is a toxic substance, avoid contact with the fluid and avoid inhaling any residual gas, even after the instrument has been taken off the piping line for maintenance and so forth.
• Do not apply excessive weight, for example, a person stepping on the magnetic flowmeter.
• All procedures relating to installation must comply with the electrical code of the country where it is used.
(2) Wiring
• The wiring of the magnetic flowmeter must be performed by expert engineer or skilled person­nel. No operator shall be permitted to perform procedures relating to wiring.
• When connecting the wiring, check that the supply voltage is within the range of the voltage specified for this instrument before connecting the power cable. In addition, check that no voltage is applied to the power cable before connecting the wiring.
• The protective grounding must be connected securely at the terminal with the mark to avoid danger to personnel.
(3) Operation
• When opening the cover, wait for more than 10 minutes after turning off the power. Only expert engineer or skilled personnel are permitted to open the cover.
• Be sure to set parameters as “Protect” on the write protect function after finish of parameter setting work. Under extremely rare case, the infra-red switches may respond unexpectedly in such conditions as sticking ball of water or extrane­ous substances on the surface of display panel glass according to the principle of infra-red switch operation. Its probability rises in such cases as sticking rain water by storm or other similar situation and washing up work near flowmeter installa­tion place. Either to illuminate or stop illuminating the infra­red switches by the flashlight may cause the mis-reaction. Refer to Chapter 6 “Menu P: Parameter Protec­tion Items” and section “10.2.2” how to use the write protect function in detail.
(4) Maintenance
• Maintenance of the magnetic flowmeter should be performed by the trained personnel having knowledge of safety standard. No operator shall be permitted to perform any operations relating to maintenance.
• When opening the cover, wait for more than 10 minutes after turning off the power.
• Always conform to maintenance procedures outlined in this manual. If necessary, contact Yokogawa.
1-2
IM 01E20C02-01E
1. INTRODUCTION
• Care should be taken to prevent the build up of dirt, dust or other substances on the display panel glass or data plate. If these surfaces do get dirty, wipe them clean with a soft dry cloth.
(5) Explosion Protected Type Instrument
• Magnetic flowmeters with the model name AXFA14C are products which have been certified as explosion proof type instruments. Strict limitations are applied to the structures, installation locations, external wiring work, maintenance and repairs, etc. of these instru­ments. Sufficient care must be taken, as any violation of the limitations may cause danger­ous situations. Be sure to read Chapter 12 “EXPLOSION PROTECTED TYPE INSTRUMENT” before handling the instruments. The description in Chapter 12 is prior to the other description in this user’s manual. For TIIS flameproof type instruments, be sure to read “INSTALLATION AND OPERATING PRECAUTIONS FOR TIIS FLAMEPROOF EQUIPMENT” at the end of this manual.
• Only trained persons use this instrument in the industrial location.
• The protective grounding to a suitable IS grounding system.
• Take care not to generate mechanical spark when access to the instrument and peripheral devices in hazardous locations.
must be connected
The guarantee will not apply in the following
cases:
• Damage due to negligence or insufficient mainte­nance on the part of the customer.
• Problems or damage resulting from handling, operation or storage that violates the intended use and specifications.
• Problems that result from using or performing maintenance on the instrument in a location that does not comply with the installation location specified by Yokogawa.
• Problems or damage resulting from repairs or modifications not performed by Yokogawa or someone authorized by Yokogawa.
• Problems or damage resulting from inappropriate reinstallation after delivery.
• Problems or damage resulting from disasters such as fires, earthquakes, storms, floods, or lightning strikes and external causes.
Trademarks:
ADMAG, AXF and ADMAG AXF are registered
trademarks of Yokogawa Electric Corporation.
Company names and product names used in this material are registered trademarks or trademarks of their respective owners.

1.3 Combination Remote Flowtubes

1.2 Warranty

• The terms of this instrument that are guaranteed are described in the quotation. We will make any repairs that may become necessary during the guaranteed term free of charge.
• Please contact our sales office if this instrument requires repair.
• If the instrument is faulty, contact us with concrete details about the problem and the length of time it has been faulty, and state the model and serial number. We would appreciate the inclusion of drawings or additional information.
• The results of our examination will determine whether the meter will be repaired free of charge or on an at-cost basis.
IMPORTANT
• The AXFA14 Magnetic Flowmeter Converter should be used in combination with the follow­ing remote flowtubes: AXFA14AXF002-P to AXF400-P Other flowtubes (size 500 to 2600 mm) cannot be combined with the AXFA14 converter.
• If the converter combined with the AXF mag­netic flowmeter remote flowtube is changed from the AXFA11 to AXFA14 or vice versa, the meter factor of the remote flowtube must be readjusted according to its flow calibration.
CAUTION
In case of combination with the explosion proof type remote flowtube (AXFC-P) for ATEX, FM, CSA, IECEx, and TIIS certification, please see the manual IM 01E20D01-01E. The construc­tion of the instrument, installation, external wiring, maintenance, and repair are strictly restricted, and non-observance or negligence of these restriction would result dangerous condition.
1-3
IM 01E20C02-01E
1. INTRODUCTION

1.4 ATEX Documentation

This procedure is only applicable to the countries in European Union.
GB
All instruction manuals for ATEX Ex related products are available in English, German and French. Should you require Ex related instructions in your local language, you are to contact your nearest Yokogawa office or representative.
DK
Alle brugervejledninger for produkter relateret til ATEX Ex er tilgængelige på engelsk, tysk og fransk. Skulle De ønske yderligere oplysninger om håndtering af Ex produkter på eget sprog, kan De rette henvendelse herom til den nærmeste Yokogawa afdeling eller forhandler.
I
Tutti i manuali operativi di prodotti ATEX contrassegnati con Ex sono disponibili in inglese, tedesco e francese. Se si desidera ricevere i manuali operativi di prodotti Ex in lingua locale, mettersi in contatto con l’ufficio Yokogawa più vicino o con un rappresentante.
E
Todos los manuales de instrucciones para los productos antiexplosivos de ATEX están disponibles en inglés, alemán y francés. Si desea solicitar las instrucciones de estos artículos antiexplosivos en su idioma local, deberá ponerse en contacto con la oficina o el representante de Yokogawa más cercano.
NL
SF
Kaikkien ATEX Ex -tyyppisten tuotteiden käyttöhjeet ovat saatavilla englannin-, saksan- ja ranskankielisinä. Mikäli tarvitsette Ex -tyyppisten tuotteiden ohjeita omalla paikallisella kielellännne, ottakaa yhteyttä lähimpään Yokogawa-toimistoon tai -edustajaan.
P
Todos os manuais de instruções referentes aos produtos Ex da ATEX estão disponíveis em Inglês, Alemão e Francês. Se necessitar de instruções na sua língua relacionadas com produtos Ex, deverá entrar em contacto com a delegação mais próxima ou com um representante da Yokogawa.
F
Tous les manuels d’instruction des produits ATEX Ex sont disponibles en langue anglaise, allemande et française. Si vous nécessitez des instructions relatives aux produits Ex dans votre langue, veuillez bien contacter votre représentant Yokogawa le plus proche.
D
Alle Betriebsanleitungen für ATEX Ex bezogene Produkte stehen in den Sprachen Englisch, Deutsch und Französisch zur Verfügung. Sollten Sie die Betriebsanleitungen für Ex-Produkte in Ihrer Landessprache benötigen, setzen Sie sich bitte mit Ihrem örtlichen Yokogawa-Vertreter in Verbindung.
S
Alla instruktionsböcker för ATEX Ex (explosionssäkra) produkter är tillgängliga på engelska, tyska och franska. Om Ni behöver instruktioner för dessa explosionssäkra produkter på annat språk, skall Ni kontakta närmaste Yokogawakontor eller representant.
Alle handleidingen voor producten die te maken hebben met ATEX explosiebeveiliging (Ex) zijn verkrijgbaar in het Engels, Duits en Frans. Neem, indien u aanwijzingen op het gebied van explosiebeveiliging nodig hebt in uw eigen taal, contact op met de dichtstbijzijnde vestiging van Yokogawa of met een vertegenwoordiger.
GR
       AT E X Ex   ,   .        Ex           Yo ko g awa   .
1-4
IM 01E20C02-01E
1. INTRODUCTION
SK
CZ
LT
PL
SLO
H
LV
EST
BG
RO
M
1-5
IM 01E20C02-01E
2. HANDLING PRECAUTIONS

2. HANDLING PRECAUTIONS

This instrument has been inspected carefully at the factory before shipment. When the instrument is delivered, visually check that no damage has occurred during transportation.
Read this section carefully as it contains important information on handling this instrument. Refer to the relevant sections for information not contained in this section. If you have any problems or questions, please contact Yokogawa sales office.

2.1 Checking Model and Specifications

The model code and specifications are found on the data plate located on the outside of the case. Check that the model code and specifications match what you have ordered.
Be sure you have your model number and serial number available when contacting Yokogawa.

2.2 Accessories

Check that the parts shown below are included in the package:
Mounting hardware: 1 setHexagonal wrench: 1 piece (nominal size 3 mm)

2.3 Storage Precautions

If the instrument is to be stored for a long period of time after delivery, observe the following points.
The instrument should be stored in its original
packing condition in the storage location.
Select a storage location that fulfils the following
conditions:
• A place where it will not be exposed to rain or water
• A place subject to minimal vibrations or shocks
• Temperature and humidity levels should be as follows:
Temperature: -30 to 70°C Humidity: 5 to 80% RH (no condensation)
The preferred ambient temperature and humidity levels are 25°C and approximately 65% RH.
If the AXFA14 converter is transferred to the
installation site and stored without being installed, its performance may be impaired due to the infiltra­tion of rainwater and so forth. Be sure to install and wire the AXFA14 as soon as possible after transfer­ring it to the installation location.
Figure 2.1.1 Data Plate
F0201.EPS
2-1
IM 01E20C02-01E

2.4 Installation Location Precautions

Select the installation location with consideration to the following items to ensure long-term stable operation of the instrument.
Ambient Temperature:
Avoid installing the instrument in locations with constantly fluctuating temperatures. If the location is subject to radiant heat from the plant, provide heat insulation or improve ventilation.
Atmospheric Condition:
Avoid installing the instrument in a corrosive atmosphere. In situations where this is unavoidable, consider ways to improve ventilation and to prevent rainwater from entering and being retained in the conduit pipes.
Vibrations or Shocks:
Avoid installing the instrument in a place subject to shocks or vibrations.
Explosion protected type:
Explosion protect types can be installed in hazard­ous areas according to the types of gases for which they are certified. See the description in Chapter 12 “EXPLOSION PROTECTED TYPE INSTRU­MENT” and “INSTALLATION AND OPERATING PRECAUTION FOR TIIS FLAMEPROOF EQUIP­MENT” in this user's manual.
2. HANDLING PRECAUTIONS
2-2
IM 01E20C02-01E
3. INSTALLATION

3. INSTALLATION

WARNING
Installation of the magnetic flowmeter must be performed by expert engineer or skilled person­nel. No operator shall be permitted to perform procedures relating to installation.

3.1 Installation Location

IMPORTANT
Install the instrument in a location where it is not exposed to direct sunlight. For ambient tempera­ture, refer to Chapter 11 “OUTLINE”. The instrument may be used in an ambient humidity where the RH ranges from 0 to 100%. However, avoid long-term continuous operation at relative humidity above 95%.

3.2 Mounting

This instrument can be mounted on a 2-inch pipe in a vertical or horizontal position depending on the installation site.
Vertical Mounting
1. Fix the instrument on the mounting fixture using four screws.
2. Fix the mounting fixture with the instrument installed on a 2-inch pipe using a U-bolt.
Horizontal Mounting
2-inch pipe
Nut
Mounting fixture
Washer
Screw
U-bolt
F0302.EPS
1. Fix the instrument casing on the mounting fixture using four screws.
U-bolt
2-inch pipe
Mounting fixture
Washer Screw
F0301.EPS
Nut
2. Fix the mounting fixture with the instrument installed on a 2-inch pipe using a U-bolt.
Figure 3.2.1 2-inch Pipe Mounting
3-1
IM 01E20C02-01E
4. WIRING

4. WIRING

This chapter describes the wiring on the converter side only. For information relating to wiring on the flowtube side, refer to the user’s manual of the AXF Remote Flowtube (IM 01E20D01-01E).
WARNING
The wiring of the magnetic flowmeter must be performed by expert engineer or skilled person­nel. No operator shall be permitted to perform procedures relating to wiring.
CAUTION
Once all wiring is complete, check the connec­tions before applying power to the instrument. Improper arrangements or wiring may cause a unit malfunction or damage.

4.1 Wiring Precautions

Be sure to observe the following precautions when wiring:
CAUTION
• In cases where the ambient temperature exceeds 50°C (122°F), use external heat­resistant wiring with a maximum allowable temperature of 70°C (158°F) or above.
• Do not connect cables outdoors in wet weather in order to prevent damage from condensation and to protect the insulation.
• Do not splice the cable between the flowtube terminal and the converter if it is too short. Replace the short cable with a cable that is the appropriate length.
• All the cable ends must be provided with round crimp-on terminals and be securely wired.
• The signal cables must be routed in separate steel conduit tubes 16 (JIS C 8305) or flexible conduit tubes 15 (JIS C 8309).
• Always route the power and output signal cables in separate steel conduit tubes, except when the power supply voltage is 24 V and four-core cables are used for wiring. Keep conduits or flexible tubes watertight using sealing tape.
• Ground the remote flowtube and the converter separately.
• Cover each shield of the signal cable with vinyl tube or vinyl tape to avoid contact between two shields or between a shield and a case.
• When waterproof glands or union equipped waterproof glands are used, avoid tightening the glands with an excessive torque.
• In case of 24V power supply version, it comes with a plug. Use this plug to cover the unused wiring port when wiring the instrument with only one, four-core cable.
• Be sure to turn power off before opening the cover.
• Before turning the power on, tighten the cover securely.
• The terminal box cover is locked by the special screw. In case of opening the terminal box cover, use the hexagonal wrench attached. For handling the locking screw, refer to Figure
4.4.1.
• Be sure to lock the cover by the special screw using the hexagonal wrench attached after installing the cover. For handling the locking screw, refer to Figure 4.4.12.
• Explosion protected types must be wired in accordance with specific requirement (and, in certain countries, legal regulations) in order to preserve the effectiveness of their explosion protected features.

4.2 Cables

(1) Dedicated Signal Cable (AXFC)
Conductors (A and B)
Shields (SA and SB)
Tape
Outer jacket
Shield (C)
Insulation
Insulation
Figure 4.2.1 Dedicated Signal Cable AXFC
The flow signal is transmitted via this dedicated cable. The cable is constructed with double shielding over the two conductors, and heat-resistant vinyl is used for the outer jacket material.
10.5 (0.413")
F0401.EPS
4-1
IM 01E20C02-01E
Finished diameter: 10.5 mm (0.413")
NOTE
Maximum length: 100 m (330 ft) Maximum temperature: 80°C (176°F)
IMPORTANT
If the cable is longer than required, cut off any extra length rather than coiling it up, and termi­nate the conductors as shown in Figure 4.2.2. Avoid using junction terminal boards to extend the cable length, as this will interrupt the shield­ing.
Unit : mm
(approx. inch)
ACB
SA
White Black
On the converter side
25 (0.98)
±5
150
8(0.3) max.
(5.9)
20 (0.8)
SB
50 (1.97)
Red
60 (2.36)
70 (2.76)
L (Specified Dimensions)
AXFC
ACB
55 (2.17)
90 (3.54)
White Black Red
8 (0.3) max.
±5
On the
(5.9)
150
flowtube side
10.5 (0.4)
F0402.EPS
Figure 4.2.2 Treatment of Dedicated Signal Cables
CAUTION
• As crimp terminals A, B, SA, SB and C have their own electrical potentials, securely insulate them so as not to come in contact with one another.
• To prevent a shield from coming in contact with another shield or the case, cover each shield with a vinyl tube or wrap it in vinyl tape.
90 (3.54)
4. WIRING
Conductors A and B carry the signal from the electrodes, and C is at the potential of the liquid (signal common). Shields SA and SB are kept at the same potentials as the individual elec­trodes (these are actively driven shields.) This is done to reduce the effect of the distributed capacitance of the cable at long cable length. Note that, since the signals from the individual electrodes are impedance converted inside the converter, errors will result if they come in contact with any other component. Great care must be taken in the cable end treatment.
(2) Excitation Cable/Power Cable/Output
Cable
JIS C3401 control cable equivalent JIS C3312 power cable equivalent 14 AWG Belden 8720 equivalent
Outer Diameter:
With no gland option;
6.5 to 12 mm (0.26 to 0.47 in.)
With gland options EG, EU and EW;
10.5 or 11.5 mm (0.41 or 0.45 in.)
With gland options EP;
6 to 12 mm (0.24 to 0.47 in.)
Nominal Cross Section:
Single wire; 0.5 to 2.5 mm Stranded wire; 0.5 to 1.5 mm
2
2
In case of power cable, Green/Yellow covered conduc­tor shall be used only for connection to PROTECTIVE CONDUCTOR TERMINALS. Conform to IEC227, IEC245 or equivalent national authorization.
Unit : mm
(approx. inch)
Crimp Terminal
EX2
EX1
85 (3.35)
85 (3.35)
EX1
EX2
On the converter side
On the flowtube side
Figure 4.2.3 End Treatment of Excitation Cable
4-2
F0403.EPS
IM 01E20C02-01E
NOTE
• For excitation and power cables, always use a crimp terminal with an insulation cover.
• Use crimp tools from the manufacturer of the crimp terminal you want to use to connect the crimp terminal and cable.
• Use crimp tools that are appropriate for the diameter of the cable to be connected.

4.3 Wiring Ports

This instrument is of watertight construction as stipulated in JIS C0920. It is shipped with a wiring bracket (waterproof gland or waterproof gland with union) or a plastic gland attached, only in cases where an optional specification is selected for the wiring port. In case of the explosion proof type, refer to chapter 12.
IMPORTANT
4. WIRING
Washer
Gasket
Waterproof gland
Cable
Figure 4.3.1 Waterproof Gland (Optional code EG)
F0404.EPS
For working on the electric wire tubes or the flexible tubes (PF1/2), remove the waterproof gland and attach them directly to the wiring port.
The wiring port is sealed with a cap (not water­proof). Do not remove the cap from the unused wiring port. If waterproof property is necessary, please use waterproof glands.
(1) When waterproof property is unnecessary
(When there are no particular optional specifications)
The wiring port is sealed with a cap (not water-proof) that must be removed before wiring. At this time, handle the wiring port in accordance with the JIS C0920 mentioned above. Do not remove the cap from the unused wiring port.
(2) When waterproof property is necessary
(Wiring using waterproof glands)
IMPORTANT
To prevent water or condensation from entering the converter housing, waterproof glands are recommended. Do not over-tighten the glands or damage to the cables may result. Tightness of the gland can be checked by confirming that the cable is held firmly in place.
Gasket
PF1/2
Washer
Tightening gland
Cable
When working on conduit pipes or flexible pipes (PF1/2 only)
Figure 4.3.2 Waterproof Gland with Union Joint
(Optional code EU)
Gasket
Plastic gland
Figure 4.3.3 Plastic Gland (Optional code EP)
F0406.EPS
F0405.EPS
4-3
IM 01E20C02-01E
4. WIRING
(3) Conduit Wiring
When wiring the conduits, pass the conduit through the wiring connection port, and utilize the waterproof gland to prevent water from flowing in. Place the conduit pipe on an angle as shown in Figure 4.3.4. Install a drain valve at the low end of the vertical pipe, and open the valve regularly.
Drain valve
F0407.EPS
Figure 4.3.4 Conduit Wiring

4.4.2 Terminal Configuration

When the cover is removed, the connection terminals will be visible. The terminal configuration labels are attached in the locations shown in Figure 4.4.2.
F0409.EPS

4.4 Wiring Connections

4.4.1 Removing Cover

Loosen cover locking screw 2 clockwise using a hexagonal wrench (nominal size 3 mm) to unlock the cover. (Upon shipment from the manufacturing plant, the cover is unlocked.) Hold the flowmeter with your hand and remove the cover by turning it in the direc­tion of the arrow as shown below.
Cover locking screws
Figure 4.4.2 Terminal Layout Labels Position
The description of the terminal symbols is shown in Table 4.1.1.
For FOUNDATION Fieldbus protocol, please refer to IM 01E20F02-01E.
For PROFIBUS PA protocol, please refer to IM 01E20F12-01E.
Table 4.1.1 Terminal Symbols
Te r minal Symbols
EX1 EX2
C
SA
A B
SB
Description
Excitation current output
Flow singal input
Te r minal Symbols
N/– L/+
I+ I–
DO+ DO–
DIO+ DIO–
Description
Functional grounding
Power supply
Current output 4 to 20mA DC
Pulse output/ Alarm output/ Status output
Alarm output/ Status output/ Status input
Protective grounding (Outside of the terminal)
T0401.EPS
Figure 4.4.1 Removing the Terminal Box Cover
F0408.EPS
4-4
IM 01E20C02-01E
4. WIRING

4.4.3 Precautions for Wiring of Power Supply Cables

When connecting to the power supply, observe the points below. Failure to comply with these warnings may result in an electric shock or damage to the instrument.
WARNING
• Ensure that the power supply is OFF in order to prevent electric shocks.
• Ensure the protective grounding terminal is grounded before turning the power on.
• Use insulating sleeve crimp terminals (for 4-mm screws) for the power supply wiring and protec­tive grounding wiring.
• Install an external switch or circuit breaker as a means to turn the powe off (capacitance; 15A, conforming to IEC947-1 and IEC947-3). Locate this switch either near the instrument or in other places facilitating easy operation. Affix a “Power Off Equipment” label to this external switch or circuit breaker.

4.4.4 DC Power Connection

When using DC power as the power supply for the converter, give attention to the following points.
(1) Connecting Power Supply
IMPORTANT
Do not connect power supply with reversed polarities.
L/+ terminal: connect + N/– terminal: connect
IMPORTANT
Do not connect power supply with 100 to 240 V AC or 100 to 120 V DC in the case of a 24 V power supply version (power supply code 2). It will give a damage to the converter.
(2) Required Power Supply Voltages
IMPORTANT
Wiring Procedure
1. Turn the instrument's power off.
2. Wire the power supply cable and the functional grounding cable to the power supply terminals.
Functional grounding cable
Power supply cable
F0410.EPS
Figure 4.4.3 Electric Cable Wiring
When using a 24 V power supply, the specifica­tion for the supply voltage is 24 V (–15% to +20%), but the input voltage of the converter drops due to cable resistance therefore it must be used within the following ranges.
Supply Voltage and Cable Length
796 (2610)
600 (1970)
446 (1460)
200 ( 660)
Allowable cable length m(ft)
0
20.4 22 24 26 28.8 Usable range E (V)
Cable cross section area: 1.25 mm Cable cross section area: 2 mm
F0411.EPS
(3) Setting Power Supply Frequency
IMPORTANT
2
2
Set the local Commercial power frequency in order to eliminate the effect of induction noise from the Commercial power supply. Refer to “Chapter 6: Parameter Description” in this manual. Parameter No.: J30 and J31
4-5
IM 01E20C02-01E

4.4.5 Grounding

4. WIRING

4.4.6 Wiring the Remote Flowtube with the AXFA14 Converter

CAUTION
Be sure to connect the protective grounding of the AXFA14 with a cable of 2mm2 or larger cross section in oder to avoid electrical shock to the operators and maintenance engineers and to prevent the influence of external noise. Connect the grounding wire to the mark. The grounding should satisfy Class D require­ments (ground resistance, 100 or less). In case of TIIS Flameproof type, the grounding should satisfy Class C requirements (ground resistance, 10 or less) or class A requirements (ground resistance, 10 or less). For explosion proof type except TIIS, follow the domestic electrical requirements as regulated in each country.
IMPORTANT
When optional code A (lighting protector) is selected, the ground should satisfy Class C requirements (grounding resistance, 10 or less).
• The protective grounding terminals are located on the inside and outside of the terminal area. Either terminal may be used.
• Use 600V vinyl insulation wires as the grounding wires.
WARNING
Before wiring, be sure that the power supply for AXFA14 converter has been turned off to prevent an electrical shock.
(1) Connection with the Remote Flowtube
(General-Purpose Use, Submersible Type, Sanitary Type, Size 2.5 to 400 mm (0.1 to 16 in.))
Connect wiring as shown in the figure below.
AXFA14 Converter
Excitation cable
AXFC dedicated signal cable
Remote flowtube
Taping*
A
B
Taping*
C
EX1
EX2
F0413.EPS
A
B
C
Figure 4.4.5 Wiring Diagram
EX2
EX1
Remote flowtube
Converter
SA
A B
SB
C EX1 EX2
* Individually tape and insulate the
shields corresponding to SA and SB on the remote flowtube side.
EX1
EX2
C
SA
A
B
SB
Protective grounding terminals
Figure 4.4.4 Protective Grounding Terminal Location
F0412.EPS
4-6
IM 01E20C02-01E
4. WIRING
NOTE
(2) Connection with the Remote Flowtube
(Explosion proof Type, Size 2.5 to 400 mm (0.1 to 16 in.))
In case of explosion proof type for ATEX, FM, CSA, IECEx and TIIS certification, connect wiring as shown in the figure below.
In case of the explosion proof type, the protective grounding
of remote flowtube must be connected to a suitable IS grounding system. In that case, (functional grounding terminal) need not be connected.
AXFA14 Converter
Excitation cable
AXFC dedicated signal cable
A
B
C
Figure 4.4.6 Wiring Diagram
EX2
EX1
Remote flowtube
Converter
SA
A B
SB
C EX1 EX2
* Individually tape and insulate the
shields corresponding to SA and SB on the remote flowtube side.
Remote flowtube
Taping*
A
B
Taping*
C
EX1
EX2
F0414.EPS
EX1
EX2
C
SA
A
B
SB
4.4.7 Connecting to External Instru­ments
WARNING
Before wiring with external instruments, be sure to turn off the power supply for AXFA14 converter and any external instruments.
Pulse Output
IMPORTANT
• As this is a transistor contact (insulated type), give attention to proper voltage and polarity when wiring.
• Do not apply a voltage larger than 30V DC or a current larger than 0.2A in order to prevent damage to the instrument.
• When input filter constant of the electronic counter is large in relation to the pulse width, the signal will decrease and the count will not be accurate.
• If the input impedance of the electronic counter is large, an induction noise from the power supply may result in inaccurate counts. Use a shield cable or sufficiently reduce the input impedance of the electronic counter within the electromagnetic flowmeter pulse output specifi­cation range.
• The active pulse output (Optional code EM) cannot be used in conjunction with the standard pulse output.
• When the active pulse output (Optional code EM) is selected, do not be short-circuit between the DO+ and DO– terminals to avoid damaging the instrument.
• When the active pulse output (Optional code EM) is selected, the range of pulse rate must be set to 2 pps maximum.
• To avoid communication (BRAIN/ HART) failure, it is recommended to use the shield cable.
Connect the AXFA14 terminal to external instruments, giving attention to the following points.
For FOUNDATION Fieldbus protocol, please refer to IM 01E20F02-01E.
For PROFIBUS PA protocol, please refer to IM 01E20F12-01E.
4 to 20 mA DC Current Output
AXFA14
Figure 4.4.7 4 to 20 mA DC Output Connection
l+
Receiver
l-
Resistive load max. 750 . (When using BRAIN/ HART communication, more than 250 , less than 600 ).
Instrument
F0415.EPS
For pulse output from the DO terminals, param­eters must be set. Refer to “Chapter 6: Param­eter Description” in this manual.
AXFA14
PULSE OUT
AXFA14
PULSE OUT
Figure 4.4.8 Pulse Output Connection
DO+
DO-
DO+
DO-
Load
4-7
Protective diode
Mechanical Counter
Electronic Counter
30V DC, 0.2A. max
F0416.EPS
IM 01E20C02-01E
4. WIRING
NOTE
AXFA14
PULSE OUT
AXFA14
PULSE OUT
Output voltage: 24 V DC 20%
• Current: 150 mA or less Pulse rate: 0.0001 to 2 pps Pulse width: 20, 33, 50, 100 ms
Figure 4.4.9 Active Pulse Output Connection (Optional
DO+
DO-
DO+
DO-
code EM)
Load
Protective diode
Mechanical Counter
Electronic Counter
F0417.EPS
Status Input
IMPORTANT
Status inputs are designed for use with no­voltage (dry) contacts. Be careful not to connect the status to any signal source carrying voltage. Applying voltage may damage the input circuit.
This output cannot switch an AC load. To switch an AC load, an intermediate relay must be inserted as shown in Figure 4.4.11. *The alarm output operates from open (normal) to closed (alarm occurrence) in the default value (as setup upon plant shipment). Changes can be made via the parameter settings.
AXFA14
AXFA14
Figure 4.4.11 Status Output/Alarm Output Connection
DO+ (or DIO+)
Load
-
(or DIO-)
DO
DO+ (or DIO+)
DO
-
(or DIO-)
External power supply 30V DC, 0.2A. max
Protective diode
This connection is not possible.
Relay
Electromagnetic
valve
AC power supply
F0419.EPS
Closed: Less than 200 Open: More than 100 k
DIO+
-
DIO
No-voltage status input
Figure 4.4.10 Status Input Connection
AXFA14
F0418.EPS
NOTE
For status input to the DIO terminals, parameters must be set. Refer to “Chapter 6: Parameter Description” in this manual.
Status Output / Alarm Output
IMPORTANT
Since this is an isolated transistor output, be careful of voltage and polarity when wiring. Do not apply a voltage larger than 30V DC or a current larger than 0.2A in order to prevent damage to the instrument.
For status and alarm outputs from the DO or DIO terminals, parameters must be set. Refer to “Chapter 6: Parameter Description” in this manual.

4.4.8 Installing the Cover

Install the cover to the flowmeter by turning it in the direction of the arrow as shown below. Tighten cover locking screw 2 counterclockwise using a hexagonal wrench (nominal size 3 mm) to lock the cover.
Cover locking screws
F0420.EPS
Figure 4.4.12 Installing the Terminal Box Cover
4-8
IM 01E20C02-01E
5. BASIC OPERATING PROCEDURES
5.
BASIC OPERATING PROCEDURES
The modification of data settings from the display unit can be carried out using the three setting switches (infra-red switches) - namely, the The infra-red switches enable the user to set parameters without opening the cover.
This chapter will provide a description of basic data configuration and the methods to be used with the three setting switches. The AXFA14 or the AXF integral flowmeter can also be operated using a handheld Brain Terminal (BT200) or a HART Communicator. (Please refer to Chapter 7 for operation via Brain Terminal and Chapter 8 for operation via HART Communicator.)
For FOUNDATION Fieldbus protocol, please refer to IM 01E20F02-01E.
For PROFIBUS PA protocol, please refer to IM 01E20F12-01E.
WARNING
Be sure to set parameters as “Protect” on the write protect function after finish of parameter setting work. Under extremely rare case, the infra-red switches may respond unexpectedly in such conditions as sticking ball of water or extraneous substances on the surface of display panel glass according to the principle of infra-red switch operation. Its probability rises in such cases as sticking rain water by storm or other similar situation and washing up work near flowmeter installation place. Either to illuminate or stop illuminating the infra-red switches by the flashlight may cause the mis-reaction. Refer to Chapter 6 “Menu P: Parameter Protection Items” and section “10.2.2” how to use the write protect function in detail.
(USING THE DISPLAY UNIT)
, , and switches.
IMPORTANT
Operate the display unit under the condition where direct sunlight, etc... do not shine to the setting switches directly when the parameter setting operation is carried out.
NOTE
(1) Always use the setting switches with the cover of the AXFA14 or the AXF
integral flowmeter closed. (2) Use these switches with them covered by the glass window. (3) If dirt, dust or other substances surfaces on the display panel glass, wipe
them clean with a soft dry cloth. (4) The operation with dirty gloves may cause a switch response error.
5-1
IM 01E20C02-01E
(3) Display items
(4)
Reversed character display
(1) Data display area
100.000
0
3274m
(2) Setting switches
(Infra-red switches)
m
3
FTL
FR
3
/h
100
F0501.EPS
5. BASIC OPERATING PROCEDURES

5.1 Operating Panel Configuration and Functions

(1) Data display area
1st line (Display Select1), 2nd line (Display Select2), and 3rd line (Display Select3) can be displayed using parameter settings. The content corresponding to selected item is shown with the reversed-character on the right of the line.
(2) Setting switch operations
: Move the layer down, select, and confirm
+ : Move the layer up
(Press the switch while
holding down the switch)
: Move the cursor down (for selection-type
parameters) or increase values (for numeric­type parameters)
: Move the cursor to the right (for numeric-type parameters)
+ : Move the cursor up (for selection-type parameters)
(3) Display items
Displayed items and
reversed-character indication
Instantaneous flow rate: %
Actual instantaneous flow rate
Instantaneous flow rate: mA
Bar graph indicating instantaneous flow rate
Totalized forward-direction flow rate
Totalized reverse-direction flow rate
Totalized differential flow rate
Tag number
Diagnosis of electrode adhesion
Communication type
Displays the instantaneous flow rate for the span as a percentage.
FR
Displays the actual reading for instantaneous flow rate.
FR
Displays the instantaneous flow rate for the span as a current output value.
FR
Displays the instantaneous flow rate for the span as a percentage
None
using bar graph.
Displays the totalized value for flow rate in the forward direction.
FTL
Displays the totalized value for flow rate in the reverse direction.
RTL
Displays the differential totalized value for flow rate between
DTL
forward totalization and reverse totalization.
Display the tag number (using up to 16 characters).
TA G
Displays the adhesion condition in the form of a bar graph.
ADH
(See the description for parameters K10 through K15 from Chapter 6: Parameter Description for more details.)
Displays the communication type.
COM
(4)
Content
Disp Select1
Disp Select2 Disp Select3
T0501.EPS
5-2
IM 01E20C02-01E

5.2 Display Unit Setting Methods

NOTE
Before changing any settings, be sure to check the corresponding setting details in Chapter 6: Parameter Description.
5. BASIC OPERATING PROCEDURES
5.2.1 Display Mode
Display Mode will be adopted when the power is turned on, and the Setting Mode can be activated using the following procedure.
Display Mode
Sample Display: Procedure for moving from Display Mode to Setting Mode
Start:
Display Mode
Setting Mode
(2 seconds or more)
Entry Mode
Select “No”
+
100.000
0
3274m
3
Parameter Search Mode
Select “Yes”
Major Item Parameter
Search Mode
* The term "mode" is used to refer to a situation where display and setting are possible.
Press the SET switch while holding down the SHIFT switch.
Sub-item Parameter
+ +
1st line: Actual instantaneous flow rate [FR]
2nd line: Bar graph indicating instantaneous flow
m3/h
100
FTL
FR
rate
3rd line: Totalized forward flow rate [FTL]
Search Mode
Setting modes
Parameter
Replacement Mode
F0502.EPS
Entry Mode
(*1)
Touch SHIFT + key
F0503-1.EPS
Setting switches
Hold the switch for 2 seconds.
Touch and switches simultaneously.
NOTE
When other operations are carried out, the system will automatically return to the Display Mode. When no operations in this display are carried out for 20 seconds, the system will automati­cally return to the Display Mode.
(*1)
NOTE
The Major Item Parameter which is set just before will be shown when entrying the Setting Mode again within 1 minute after returning from Setting Mode to Display Mode.
5-3
IM 01E20C02-01E
Setting Mode
No
Yes
Setting Mode
No
Ye s
5. BASIC OPERATING PROCEDURES
A screen is displayed to confirm whether or not the system is to enter Setting Mode.
Press the
The reversed-character (i.e. the cursor position) indicates the item that is currently selected.
switch and select [Yes].
When [Yes] has been selected, touch the
switch.
NOTE
When the operations except and switches are carried out, the system will
automatically return to the Display Mode. When no operations in this display are carried out for 20 seconds, the system will automati­cally return to the Display Mode.
Setting Mode
Setting Mode
Yes
Setting Mode
P:Protect
B:Easy Setup
C:Basic Setup
In order to request confirmation, the entire display flashes on and off.
Touch the switch once again at this time to
fix your selection.
NOTE
When no operations in the flashed display are carried out for 20 seconds, the system will automatically return to the Display Mode.
When the operations except are carried out, the system will automatically return to the
Display Mode.
The system enters Setting Mode.
Parameters to be set can be selected.
To Parameter
Search Mode
F0503-2.EPS
5-4
This completes the procedure for changing from the Display Mode to the Parameter Search Mode.
IM 01E20C02-01E

5.2.2 Setting Mode

When the Setting Mode has been activated using the procedure from Section 5.2.1, param­eters can be selected for setting.
Format for Parameter Data
Depending on the type of parameter, data is formatted in one of the following three ways.
5. BASIC OPERATING PROCEDURES
NOTE
If no operations are carried out for a period of 10 minutes in Setting Mode, the system will automatically return to the Display Mode.
Format Typical display Content
(i) Selection-type
B21:Base Flow Unit
3
m
3
m
kl(Kiloliter)
The desired data item is selected from a predefined list.
(ii) Numeric-type
(iii) Alphanumeric-type
Regarding the alphanumeric-type format (iii), the following alphanumerics are displayed in the following sequence:
#%&*+-./0123456789:<>ABCDEFGHIJKLMNOPQRSTUVWXYZabcdefghij klmnopqrstuvwxyz[space]
B23:Flow Span 100 l/min 000100 l/min Rng:0.00001 32000
C10:Tag No FI-1101 FI-1201
Data is set using the values in each digit and using the decimal point.
Data is composed using alphanumeric characters (in the case of tag numbers, special units, and the like). With this format, setting can be carried out using up to 16 of the characters shown below.

5.3 Parameter Setting Procedure

Once the system is in Setting Mode, the parameters for setting can be selected. Parameters that are frequently used have been grouped together in Easy Setup in Menu B. This section provides a description of the parameter setting procedure using B: Easy Setup and C: Basic Setup.
For more details regarding parameter content, please refer to Section 6: Parameter Descrip­tion.

5.3.1 Setting Example for Selection-Type Data: Flow rate units

This example describes the setting of the flow rate units for the selection-type parameter B21: Base Flow Unit from m3 to l (Liter).
Start:
Major Item Parameter
Search Mode
Setting Mode
Major item parameter
Setting Mode
P:Protect
B:Easy Setup
C:Basic Setup
Major Item Parameter Search Mode has been accessed in this screen.
T0502.EPS
F0504-1.EPS
Touch the switch to access B: Easy Setup.
NOTE
The and symbols to the left of the param­eters indicate that additional setting items to those being currently displayed may also be selected. Use the switch to cycle through these items.
5-5
IM 01E20C02-01E
5. BASIC OPERATING PROCEDURES
Sub-item
Parameter
Search Mode
Parameter
Replacement Mode
Current unit setting Available selections
Current unit setting
Available selections
Major item
Sub-item
parameter
Major item
Sub-item
selection (A)
Sub-item
Sub-item
B:Easy Setup
50:Auto Zero Exe
10:Language
20:Flow Damping
X
B:Easy Setup
20:Flow Damping
21:Base Flow Unit
22:Base Time Unit
B21:Base Flow Unit
3
m
3
m
kl(Kiloliter)
B21:Base Flow Unit
3
m
l(Liter)
3
cm
X
Sub-item Parameter Search Mode has been accessed in this screen.
Touch the
2
B21: Base Flow Unit.
switch to move the cursor to
The cursor has been moved to B21: Base Flow Unit in this screen. (Sub-item selection screen (A))
In this screen, Parameter Replacement Mode has
been called up using the switch.
Touch the switch to move the cursor to the
unit item for selection. In this example, the
switch is touched twice to select l (Liter)
2
Sub-item
Parameter
Search Mode
Major item
Sub-item
selection (A)
B21:Base Flow Unit l(Liter)
B:Easy Setup
20:Flow Damping
21:Base Flow Unit
22:Base Time Unit
F0504-2.EPS
When l (Liter) has been selected, touch the
switch.
In order to request confirmation, the entire display
flashes on and off. Touch the switch once
again at this time to fix your selection.
NOTE
When no operations are carried out for 20 seconds in the flashing state, the system will automatically return to the Sub-item Parameter Search Mode.
When the operations except are carried out, the parameter cannot be set.
The system automatically returns to sub-item selection screen (A).
5-6
IM 01E20C02-01E
5. BASIC OPERATING PROCEDURES

5.3.2 Setting Example for Numeric-Type Data: Flow rate span

This example describes the setting of the flow rate span for the numeric-type parameter B23: Flow Span from 100 l/min to 120 l/min.
Start:
Major Item Parameter
Search Mode
Sub-item
Parameter
Search Mode
Setting mode
Major item
parameter
Major item
Sub-item
parameter
Major item
Sub-item
selection (B)
Setting Mode
P:Protect
B:Easy Setup
C:Basic Setup
B:Easy Setup
50:Auto Zero Exe
10:Language
20:Flow Damping
X
4
B:Easy Setup
22:Base Time Unit
23:Flow Span
24:Flow Decimal Pnt
Selection of the appropriate parameter
Setting Mode Condition
Touch the switch to access B: Easy Setup.
NOTE
The and symbols to the left of the param­eters indicate that additional setting items to those being currently displayed may also be selected. Use the switch to cycle through these items.
Sub-Item Parameter Search Mode has been accessed in this screen.
Touch the switch to move the cursor to
B23: Flow Span.
The cursor has been moved to B23: Flow Span in this screen. (Sub-item selection screen (B))
Touch the switch to access Parameter
Replacement Mode.
Parameter
Replacement Mode
B23:Flow Span 100 l/min
000100. l/min Rng:0.00001 32000
B23:Flow Span 100 l/min
0000100. l/min Rng:0.00001
32000
X
X
F0505-1.EPS
4
2
Once Parameter Replacement Mode has been selected, the digit that can be replaced will be flashed on and off. When in this condition, confirm the relevant setting range as displayed at the bottom of the screen and then set the parameter as required.
In this example, the parameter will be set to “120 l/min”.
NOTE
When setting a new value, use the switch to move from digit to digit, and use the
switch to cycle through values for each individual digit. In addition to digit, it is also possible to select a decimal point, and this allows the position of the decimal point to be changed.
Modify the value to “120 l/min” as follows:
Touch the switch to move the cursor to the
position for multiples of 10. Then, touch the
switch to change the value at this position from “0” to “2”.
When the value of “120” has been setup, touch the
switch.
5-7
IM 01E20C02-01E
5. BASIC OPERATING PROCEDURES
Sub-item
Parameter
Search Mode
Major item
Sub-item
selection (B)
Incorrect setting:
B23:Flow Span 120 l/min
B:Easy Setup
22:Base Time Unit
23:Flow Span
24:Flow Decimal Pnt
B23:Flow Span 100 l/min 1200000 l/min Rng:0.00001 32000
Out of range. Touch any key.
When the switch is touched, the entire
display flashes on and off. Confirm that the setting has been correctly changed to “120”, and then fix
this value by touching the switch once again.
NOTE
When no operations are carried out for 20 seconds in the flashing state, the system will automatically return to the Sub-item Parameter Search Mode.
When the operations except are carried out, the parameter cannot be set.
The system automatically returns to sub-item selection screen (B).
NOTE
If the input value is outside the valid selection range, the message “Out of range. Touch any key.” will be displayed. In such a case, touch any switch to return to Parameter Replacement Mode and redo the setting.
Incorrect setting:
B23:Flow Span 100 l/min
0001.0. l/min Rng:0.00001
Invalid value. Touch any key.
32000
NOTE
If more than one decimal point has been input, the message “Invalid value. Touch any key.” will be displayed. In such a case, touch any switch to return to Parameter Replacement
F0505-2.EPS
Mode and redo the setting.

5.3.3 Setting Example for Alphanumeric-Type Data: Tag number

This example describes the setting of the tag number for the alphanumeric-type parameter
C10: Tag No. from “FI-1101” to “FI-1201.”
Setting Mode Condition
Touch the switch to access C: Basic Setup.
NOTE
The and symbols to the left of the param­eters indicate that additional setting items to those being currently displayed may also be selected. Use the switch to cycle through these items.
The cursor has been moved to C: Basic Setup in this screen.
Start:
Major Item Parameter
Search Mode
Setting mode
Major item
parameter
Setting mode
Major item
parameter
Setting Mode
P:Protect
B:Easy Setup
C:Basic Setup
Setting Mode
B:Easy Setup
C:Basic Setup
D:Total Set
F0506-1.EPS
Touch the switch to enter C: Basic Setup.
5-8
IM 01E20C02-01E
5. BASIC OPERATING PROCEDURES
Sub-item
Parameter
Search Mode
Parameter
Replacement Mode
Current setting value
Modified value
Current setting value
Major item
Sub-item
selection (C)
Selection of the appropriate parameter
C:Basic Setup
49:Flow User Span
10:Tag No
11:Flow Damping
C10:Tag No Fl-1101 l-1101
C10:Tag No Fl-1101 Fl-1 01
Upon selection of C: Basic Setup, the cursor will be positioned at C10: Tag No. (Sub-item selection screen (C))
Touch the
switch to access Parameter
Replacement Mode.
The cursor will flash on and off on the left of the tag number. As “FI-1201” is to be setup in this example,
touch the switch to move the cursor to the
X
4
position for multiples of 100.
At the position for multiples of 100, touch the
switch to change the “1” to “2”. When the
setting has been changed to “FI-1201”, touch the
switch.
Sub-item
Parameter
Search Mode
Major item
Sub-item
selection (C)
C10:Tag No Fl-1201
C:Basic Setup
49:Flow User Span
10:Tag No
11:Flow Damping
When the switch is touched, the entire
display flashes on and off. Confirm that the setting has been correctly changed to “FI-1201”, and then
fix this setting by touching the switch once
again.
NOTE
When no operations are carried out for 20 seconds in the flashing state, the system will automatically return to the Sub-item Parameter Search Mode.
When the operations except are carried out, the parameter cannot be set.
The system automatically returns to sub-item selection screen (C).
108.0
: : :
0
Fl-1201 TAG
FR
l/min
100
F0506-2.EPS
After returning to Display Mode by touching using
the ( and ) twice as escape switches,
it will be possible to confirm the modified content (if Display Select has been setup to display the tag number.)
Indicates selection of Tag No display for B42: Display Select3.
5-9
IM 01E20C02-01E

6. PARAMETER DESCRIPTION

NOTE
6. PARAMETER DESCRIPTION

6.1 Parameters

With the exception of parameters that were specified by the customer upon ordering, all of the internal parameters will initially be set to default values. Actions such as the modification of display details can then be carried out whenever necessary.
For FOUNDATION Fieldbus protocol, please refer to IM 01E20F02-01E.
For PROFIBUS PA protocol, please refer to IM 01E20F12-01E.
IMPORTANT
Make sure to keep the instrument’s power on at least for 30 seconds after you set the param­eters. If you turn the power off immediately after the parameters are set, the settings will be canceled.

6.2 Parameter Lists

Parameter lists are comprised of the following items.
In order to ensure that correct flow rate data can be acquired, it is crucial that the nominal size, flow rate span, and meter factor of the combined remote flowtube are set. In cases where a remote flowtube is ordered at the same time as the AXFA14, or where the AXF integral flowme­ter is ordered, the nominal size and meter factor will be set upon shipment from the manufactur­ing plant, and these will not require additional setting. If the AXFA14 is ordered separately, the default value will be set for the meter factor; accordingly, it will be necessary to change this setting to the meter factor indicated on your remote flowtube data plate. If a flow rate span was specified upon ordering, this will be set before shipment. If this is not the case, however, it will be necessary for the appropriate value to be set by the user.
Item Name
R/W
Data
range
Units
Position of
decimal point
Default
value
Description
Describes the parameter content.
The default value (as setup upon plant shipment). If marked “(*)”, it indicates that the appropriate setting has been made in accordance with ordering information and data for a remote flowtube to be combined.
The position of the decimal point within the data range and also the allowed relocation range in terms of places of decimals.
The units corresponding to the data range.
This item defines the range of data to be set for numeric parameters and also defines selection of data for selection-type parameters.
R: Read only W: Writable
The name of the parameter. Entries in parentheses indicate the parameter name displayed on the handheld BRAIN Terminal (BT200).
Parameter number.
T0601.EPS
6-1
IM 01E20C02-01E
6. PARAMETER DESCRIPTION

6.3 Parameter List Overview

(1) Item A (Menu A): Display items
Menu A contains the instantaneous flow rate, totalization values, and other items relevant to display.
Item
Display unit
A00
Display (DISPLAY)
A10
FR (FLOW RATE (%))
A20
FR (FLOW RATE)
A21
FR (FLW RATE (mA))
A30
FTL (TOTAL)
RTL (REV TOTAL)
A32
DTL (DIF TOTAL)
A60
(SELF CHECK)
Name
R/W
(BRAIN)
R%
R
R
R
R
R
R
Data range
Display unit
/BRAIN
-110.0 to 110.0
-999999 to 999999
2.400 to 21.600
0 to 99999999
0 to 99999999
-99999999 to 99999999
Good Error
Units
B21/B22
(C40/C41)
mA
B30
(D10)
B30
(D10)
B30
(D10)
Position
of decimal
point
1
0 to 3
3
0 to 7
0 to 7
0 to 7
Default value
(*): Indicated item
Description
For Display Mode only
For Display Mode only
For Display Mode only
For Display Mode only
For Display Mode onlyA31
For Display Mode only
See “6.5 Alarm Functions”.
T0602.EPS
(2) Item B (Menu B): Easy Setup items
Those parameters with a high frequency of use have been grouped together in Menu B. All basic functions can be controlled using only the parameters from this block.
Name
Item
Display unit
(BRAIN)
Easy Setup
B00
(EASY SETUP)
B10
Language (LANGUAGE)
B20 Sets damping time. Linked with
Flow Damping (FLOW DAMPING)
B21
(FLOW UNIT)
R/W
W
WBase Flow Unit
Data range
Display unit
/BRAIN
English Japanese French German Italian Spanish
0.1 to 200.0
Ml(Megaliter)
3
m kl (Kiloliter) l (Liter)
3
cm m t kg g kcf cf mcf Mgal (US) kgal (US) gal (US) mgal (US) kbbl (US Oil) bbl (US Oil) mbbl (US Oil) ubbl (US Oil) kbbl (US Beer) bbl (US Beer) mbbl (US Beer) ubbl (US Beer) ft klb (US) lb (US)
Units
sW
Position
of decimal
point
6-2
Default value
(*): Indicated item
English
3.0 s 1
m (*)
Description
Selects the language used for the display unit. Linked with H30.
C11.
Selects flow units for the flow rate span. Linked with C40.
T0603-1.EPS
IM 01E20C02-01E
6. PARAMETER DESCRIPTION
Item
Display unit
(BRAIN)
B22
Base Time Unit (TIME UNIT)
B23
(FLOW SPAN)
B24
Flow Decimal Pnt (FLOW DECIMAL)
B30
Total Unit (TOTAL UNIT)
B31
Total Scale (TOTAL SCALE)
B32
Pulse Unit (PULSE UNIT)
B33
Pulse Scale (PULSE SCALE)
B40
Display Select1 (DISP SELECT1)
B41
Display Select2 (DISP SELECT2)
B42
Display Select3 (DISP SELECT3)
B50
Auto Zero Exe (AUTOZERO EXE)
B60
(SELF CHECK)
Name
R/W
W
Data range
Display unit
/BRAIN
/h
Units
Position
of decimal
point
Default value
(*): Indicated item
/s (*)/d
Description
Selects time units for the flow
rate span. Linked with C41. /min /s
W
B21/B22
(C40
/C41)
W
Auto 0 1 2
0 to 40.0001 to 32000
1 m/s (*)Flow Span
Sets flow rate span (with units
from B21 and B22). Linked with
C42.
Auto (*)
Selects decimal point position
for the display unit's
instantaneous flow rate. Linked
with C43.
3
W
n Unit/P
Pulse/s (*) u Unit/P m Unit/P
Selects the flow rate unit per one pulse as used for totalization
display. Linked with D10. Unit/P k Unit/P M Unit/P Pulse/s
0 to 32000
W B30
(D10)
0 to 4
0 (*)
Sets the flow rate per one pulse
as used for the totalization
display. Linked with D11.
W
n Unit/P
Pulse/s (*) u Unit/P m Unit/P
Selects the flow rate unit per one pulse as used for pulse output.
Linked with E10. Unit/P k Unit/P M Unit/ Pulse/s
W
0 to 32000
B32
(E10)
0 to 4
0 (*)
Sets the flow rate per one pulse
as used for pulse output. Linked
with E11.
W
Flow Rate(%) Flow Rate Flow Rate(mA)
Flow Rate
Selects content of the first line
for Display Mode. Linked with
H10. Forward Total Reverse Total Dif Total
W
Off Flow Rate(%) Flow Rate
Off
Selects content of the second line
for Display Mode. Linked with
H11. Flow Rate(mA) Flow Rate(Bar) Forward Total Reverse Total Dif Total Tag No Adhesion Check Communication
Same as B41
W
(Display Select2)
Off
Selects content of the third line
for Display Mode. Linked with
H12.
W No Execution
Execution
No Execution
Selects whether or not automatic
zero adjustment is carried out.
Linked with M10.
Good
R See “6.5 Alarm Functions”.
Error
T0603-2.EPS
6-3
IM 01E20C02-01E
(3) Item C (Menu C): Basic Setting items
Menu C principally contains the basic setting items for the flowtube.
6. PARAMETER DESCRIPTION
Item
Display unit
(BRAIN)
C00
Basic Setup (BASIC SETUP)
C10
Tag No (TAG NO)
C11
Flow Damping (FLOW DAMPING)
C20
Measure Mode (MEASURE MODE)
C21
Low MF (LOW MF)
C22
High MF (HIGH MF)
C23
Low MF(EDF) (LOW MF(EDF))
C24
High MF(EDF) (HIGH MF(EDF))
Nominal Size Unit
C31
(SIZE UNIT)
Nominal Size
C32
(NOMINAL SIZE)
Base Flow Unit
C40
(FLOW UNIT)
Base Time Unit
C41
(TIME UNIT)
Flow Span
C42
(FLOW SPAN)
C43
Flow Decimal Pnt (FLOW DECIMAL)
Name
Data range
R/W
W
Display unit
ASCII 16 characters
W
Standard DF
W
Enhanced DF
0.0100 to 3.0000W
0.0100 to 3.0000
W
0.0000 to 3.0000
W
0.0000 to 3.0000
W
mm
W
inch
0.99 to 3000.1
W
0.01 to 120.1
W
Ml(Megaliter)
3
m kl(Kiloliter) l(Liter)
3
cm m t kg g kcf cf mcf Mgal (US) kgal (US) gal (US) mgal (US) kbbl (US Oil) bbl (US Oil) mbbl (US Oil) ubbl (US Oil) kbbl (US Beer) bbl (US Beer) mbbl (US Beer) ubbl (US Beer) ft klb (US) lb (US)
W
/d /h /min /s
W 0.0001 to 32000
W
Auto 0 1 2 3
/BRAIN
Units
s0.1 to 200.0
mm inch
C40/C41
(B21 /B22)
Position
of decimal
point
1 3.0 s
4
4
4
4
0 to 2
0 to 4
Default value
(*): Indicated item
Standard DF
1.0000 (*)
1.0000 (*)
1.0000 (*)
1.0000 (*)
mm
inch
100 (*)
m (*)
/s (*)
1 m/s (*)
Auto (*)
Description
Sets Tag number up to 16 characters.
Sets damping time. Linked with B20.
Selects measurement mode for dual frequency excitation
Sets low-frequency meter factor for standard dual frequency excitation
Sets high-frequency meter factor for standard dual frequency excitation
Sets low-frequency meter factor for enhanced dual frequency excitation
Sets high-frequency meter factor for enhanced dual frequency excitation
Selects the nominal size units for the flowtube.
Sets flowtube nominal size in selected unit at C31.
Selects flow units for the flow rate span. Linked with B21.
Selects time units for the flow rate span. Linked with B22.
Sets flow rate span (with units from C40 and C41). Linked with B23.
Selects decimal point position for the display unit's instantaneous flow rate. Linked with B24.
T0604-1.EPS
6-4
IM 01E20C02-01E
6. PARAMETER DESCRIPTION
Item
Display unit
(BRAIN)
C44
(VELOCITY CHK)
Density Unit
C45
(DENSITY UNIT)
Name
R/W
R m/s0.000 to 99.999
W
Data range
Display unit
/BRAIN
3
kg/m lb/gal
Units
Position
of decimal
point
3Velocity Check
Default value
(*): Indicated item
3
kg/m
Description
Display of the span setting using flow velocity (m/s).
Sets units for density when mass flow rate is selected.
lb/cf
C46
Mass Flow Density
0 to 32000W
(MASS DENSITY)
User Span Select
C47
(USER SPN SEL)
C48
Flow User Unit (FL USER UNIT)
C49
Flow User Span
W
W
No Yes
8 alphanumeric characters
(FL USER SPAN)
C60 Good
(SELF CHECK)
R
Error
C45
C480.0001 to 32000 1000 to 4W
0 to 4
0
No
Sets density when mass flow rate is selected (with units from C45).
Selects whether or not special units are used for flow rate units.
Sets the special flow rate units.
Sets span when using special flow rate units.
See “6.5 Alarm Functions”.
T0604-2.EPS
(4) Item D (Menu D): Total Setting items
Menu D contains setting items such as the totalization scale and the forward/reverse totalized values.
Item
Display unit
(BRAIN)
D00
Total Set (TOTAL SET)
D10
Total Unit (TOTAL UNIT)
D11
Total Scale (TOTAL SCALE)
D12
Total Decimal Pnt (TL DECIMAL)
D13
Total Low Cut (TOTAL LOWCUT)
D20
Total Execution (TOTAL EXEC)
D21
Ttl Set Val Lower (TL SET VAL L)
D22
Ttl Set Val Upper (TL SET VAL U)
D23
Ttl Switch Lower (TL SWITCH LO)
D24
Ttl Switch Upper (TL SWITCH UP)
D30
(TL USER SEL)
Ttl User Unit
D31
(TL USER UNIT)
(SELF CHECK)
Name
R/W
W
W
W
W
W
W
W
W
W
W
RD60
Data range
Display unit
/BRAIN
n Unit/P u Unit/P m Unit/P Unit/P k Unit/P M Unit/P Pulse/s
0 to 32000
0 1 2 3 4 5 6 7
0 to 100
Start Stop Preset Total Preset Rev Total
0 to 999999
0 to 99
0 to 999999
0 to 99
No Yes
8 alphanumeric characters
Good Error
Units
D10
(B30)
%
Position
of decimal
point
0 to 4
0
0
0
0
0
Default value
(*): Indicated item
Pulse/s (*)
0 (*)
0
3 %
Start
0
0
0
0
NoTtl User Select
Description
Selects the flow rate unit per one pulse as used for totalization display. Linked with B30.
Sets the flow rate per one pulse as used for totalization display. Linked with B31.
Selects position of decimal point for totalization display
Sets the range in vicinity of 0% within which the totalization display will be halted.
Executes “Start” or “Stop” of the totalization function, or executes “Preset Total” or “Preset Rev Total”.
Sets the totalization preset value in the lower 6 digits of the 8-digit totalized value.
Sets the totalization preset value in the upper 2 digits of the 8-digit totalized value.
Sets the totalization switch value in the lower 6 digits of the 8-digit totalized value.
Sets the totalization switch value in the upper 2 digits of the 8­digits totalized value.
Selects whether or not special units are used as totalized units.
Sets the special totalized units.W
See “6.5 Alarm Functions”.
6-5
T0605.EPS
IM 01E20C02-01E
6. PARAMETER DESCRIPTION
(5) Item E (Menu E): Pulse Setting items
Menu E contains items relevant to pulse output. This is used to set parameters such as the pulse scale and width.
Item
Display unit
(BRAIN)
E00
Pulse Set (PULSE SET)
E10
Pulse Unit (PULSE UNIT)
E11
Pulse Scale (PULSE SCALE)
E12
Pulse Width (PULSE WIDTH)
E13
(PULSE LOWCUT)
E60
(SELF CHECK)
Name
Data range
R/W
W n Unit/P
W 50% Duty
R Good
Display unit
/BRAIN
u Unit/P m Unit/P Unit/P k Unit/P M Unit/P Pulse/s
0 to 32000W 0 to 4
0.05 ms
0.1ms
0.5 ms 1 ms 20 ms 33 ms 50 ms 100 ms
0 to 100
Error
Units
E10
(B32)
Position
of decimal
point
03 %%WPulse Low Cut
Default value
(*): Indicated item
Pulse/s (*)
0 (*)
50% Duty
Description
Selects the flow rate unit per one pulse as used for pulse output. Linked with B32.
Sets the flow rate per one pulse as used for pulse output. Linked with B33.
Selects the pulse width for pulse output.
Sets the range in vicinity of 0% within which pulse output will be halted.
See “6.5 Alarm Function”.
T0606.EPS
(6) Item F (Menu F): Status Functions Setting items
Menu F contains items relevant to multiplex range output and other status Input/Output.
Item
Display unit
Status Function
F00
(STATUS FUNC)
F20
(DO FUNCTION)
(DIO FUNCTION)
Name
R/W
(BRAIN)
WF21
Data range
Display unit
/BRAIN
No Function Pulse Output Alarm Output Warning Output Total Switch (O) H/L Alarm (O) HH/LL Alarm (O) Fwd/Rev Rngs (O) Auto 2
Rngs Rngs Rngs
Rngs Rngs Rngs
(O) (O)
(O)
(O) (O) (O)
Auto 3 Auto 4 Ext 2 Answer (O)
No Function Alarm Output Warning Output Total Switch (O) H/L Alarm (O) HH/LL Alarm (O) Fwd/Rev Rngs (O) Auto 2 Auto 3 Auto 4 Ext 2 Answer (O) 0% Singal Lock (I) Ext Auto Zero (I) Ext Ttl Set (I) Ext R Ttl Set (I) Ext 2 Ttl Set (I)
Units
Position
of decimal
point
Default value
(*): Indicated item
Pulse OutputWDO Function
No FunctionDIO Function
Selects function for the DO terminal
Selects function for the DIO terminal
Description
T0607-1.EPS
6-6
IM 01E20C02-01E
6. PARAMETER DESCRIPTION
Item
Display unit
F22
DO Active Mode (DO ACT MODE)
F23
DIO Active Mode (DIO ACT MODE)
F30
Forward Span2 (FWD SPAN2)
F31
Forward Span3 (FWD SPAN3)
F32
Forward Span4 (FWD SPAN4)
F33
Reverse Span1 (REV SPAN1)
F34
Reverse Span2 (REV SPAN2)
F40
(AUTO RNG HYS)
F41
Bi Direction Hys (BI DIREC HYS)
— (SELF CHECK)
Name
(BRAIN)
Data range
R/W
Display unit
/BRAIN
W Closed(On) Act
Open(Off) Act
Closed/Short Act
W
Open/Open Act
0.0001 to 32000
W
0.0001 to 32000 C40
W
0.0001 to 32000
W
0.0001 to 32000
W
0.0001 to 32000
W
W
0 to 8 0W %
RF60 Good
Error
Units
C40
/C41
/C41
C40
/C41
C40
/C41
C40
/C41
Position
of decimal
point
0 to 4
0 to 4
0 to 4
0 to 4
0 to 4
00 to 15 %Auto Range Hys
Default value
(*): Indicated item
Closed(On) Act
Closed/Short Act
1
1
1
1
1
10 %
2 %
Description
Selects whether DO terminal will be set to “On Active” or “Off Active”.
Selects whether DIO terminal will be set to “Closed/Short Active” or“Open/Open Active”.
Sets flow rate span for forward No. 2 range
Sets flow rate span for forward No. 3 range
Sets flow rate span for forward No. 4 range
Sets flow rate span for reverse No. 1 range
Sets flow rate span for reverse No. 2 range
Sets hysteresis width for automatic range switching
Sets hysteresis width for forward/reverse switching
See “6.5 Alarm Function”.
T0607-2.EPS
(7) Item G (Menu G): Alarm Setting items
Menu G contains setting items relevant to alarm output, burnout, alarm record, etc.
Name
Item
Display unit
R/W
(BRAIN)
Alarm
G00
(ALARM)
Low Alarm
G10
W
(LOW ALARM) High Alarm
G11
W
(HIGH ALARM)
Low Low Alarm
G12
W
(LO LO ALARM)
High High Alarm
G13
W
(HI HI ALARM)
H/L Alarm Hys
G14
W
(H/L ALM HYS) 4-20mA Alarm Out
G21
W
(4-20 ALM OUT)
4-20mA Burn Out
G22
R
(4-20 BURNOUT)
G30 Yes
Alm-Setting
W
(ALM-SETTING)
G31
Alm-Sig Over
W
(ALM-SIG OVER)
Alm-Emp Pipe
G32
W
(ALM-EMP PIPE)
G33
Alm-HH/LL
W
(ALM-HH/LL)
G34
Alm-Adhesion
W
(ALM-ADHESION)
Data range
Display unit
/BRAIN
-110 to 110
-110 to 110
-110 to 110
-110 to 110
0 to 10
2.4mA or Less
4.0mA Hold
21.6mA or More High
Low
No Yes
No Yes
No Yes
Yes
No Yes
Units
%
%
%
%
%
Position
of decimal
point
0
0
0
0
0
Default value
(*): Indicated item
-110
110
-110
110
5 %
21.6mA or More
Yes
Yes
NoNo
No
Sets level setting value for low
flow rate limit (L)
Sets level setting value for high
flow rate limit (H)
Sets level setting value for low-
low flow rate limit (LL)
Sets level setting value for high-
high flow rate limit (HH)
Sets hysteresis width for high-
low flow rate limit alarm
Selects the current output during
alarm occurrence.
Displays the current output
during a CPU failure.
Selects whether a setting alarm is
to be specified as an alarm.
Selects whether a signal overflow
alarm is to be specified as an alarm.
Selects whether an empty pipe
alarm is to be specified as an alarm.
Selects whether a flow rate high-
high or low-low alarm is to be
specified as an alarm.
Selects whether an electrode
adhesion alarm
as an alarm.
Description
is to be specified
T0608-1.EPS
6-7
IM 01E20C02-01E
6. PARAMETER DESCRIPTION
Name
Item
Display unit
R/W
(BRAIN)
G40 Operation time
ROperation Time
(OPERATE TIME)
G41
Alm Record1
R 10:uP Fault
(ALM RECORD1)
Data range Display unit
/BRAIN
0D 00:00 to 99999D 23:59
11:EEPROM Fault
Units
Position
of decimal
point
Default value
(*): Indicated item
Description
Displays the content of the most
recent alarm. 12:A/D(H) Fault 13:A/D(L) Fault 14:A/D(Z) Fault 15:Coil Open 16:
EEPROM Dflt 18:Power Off 19:
Inst Pwr Fail 28:
WDT 30:Sig Overflow 31:Empty Pipe 33:
Adhesion Alm
G42
Alm Record Time1 (ALM TIME 1)
G43
Alm Record2 (ALM RECORD2)
G44
Alm Record Time2 (ALM TIME 2)
Alm Record3
G45
(ALM RECORD3)
Alm Record Time3
G46
(ALM TIME 3)
Alm Record4
G47
(ALM RECORD4)
Alm Record Time4
G48
(ALM TIME 4)
G60
(SELF CHECK)
0D 00:00 to
R
99999D 23:59
R
Same as G41 (Alm Record Time1)
0D 00:00 to
R
99999D 23:59
R
Same as G41 (Alm Record Time1)
R
0D 00:00 to 99999D 23:59
Same as G41
R
(Alm Record Time1)
R 0D 00:00 to
99999D 23:59
R Good
Error
Displays the operation time at the occurrence of the most recent alarm.
Displays the content of the second most recent alarm.
Displays the operation time at occurrence of the second most recent alarm.
Displays the content of the third most recent alarm.
Displays the operation time at the occurrence of the third most recent alarm.
Displays the content of the fourth most recent alarm.
Displays the operation time at the occurrence of the fourth most recent
See “6.5 Alarm Functions”.
alarm.
T0608-2.EPS
6-8
IM 01E20C02-01E
(8) Item H (Menu H): Display Setting items
Menu H contains setting items that are relevant to display on the display unit.
6. PARAMETER DESCRIPTION
Name
Item
Display unit
(BRAIN)
Display Set
H00
(DISP SET)
Display Select1
H10 Flow Rate(%)
(DISP SELECT1)
Display Select2
H11
(DISP SELECT2)
Display Select3
H12
(DISP SELECT3)
Display Cycle
H20
(DISP CYCLE)
Language
H30
(LANGUAGE)
H60
(SELF CHECK)
R/W
W
W
W
W
W
Flow Rate(%) Flow Rate Flow Rate(mA) Forward Total Reverse Total Dif Total
Off Flow Rate(%) Flow Rate Flow Rate(mA) Flow Rate(Bar) Forward Total Reverse Total Dif Total Tag No Adhesion Check Communication
Same as H11 (Display Select2)
200ms 400ms 1s 2s 4s 8s
English Japanese French German Italian Spanish
R Good
Error
Data range
Display unit
/BRAIN
Units
Position
of decimal
point
Default value
(*): Indicated item
Off
Off
400ms
English
Selects content of the first line for Display Mode. Linked with B40.
Selects content of the second line for Display Mode. Linked with B41.
Selects content of the third line for Display Mode. Linked with B42.
Selects the display cycle.
Selects the language used by the display unit. Linked with B10.
See “6.5 Alarm Functions”.
(9) Item J (Menu J): Auxiliary Function Setting items
Menu J contains setting items such as the flow direction, rate limits, and low cut.
Description
T0609.EPS
Name
Item
Display unit
(BRAIN)
Aux
J00
(AUX)
4-20mA Low Cut (4-20 LOW CUT)
4-20mA Low Lmt
J11 -20.0%
(4-20 LOW LMT) 4-20mA High Lmt
J12
(4-20 HI LMT)
J20
Flow Direction (FLOW DIRECT)
Rate Limit
J21
(RATE LIMIT) Dead Time
J22
(DEAD TIME)
Pulsing Flow
J23
(PULSING FLOW)
J24
T/P Damp Select (T/P DAMP SEL)
R/W
W
W
W
W
W
W No
W
Data range
Display unit
/BRAIN
0 to 10 %W
-20.0 to 100.0
0.0 to 120.0
Forward Reverse
0 to 15
Yes
Damping No Damping
Position
Units
of decimal
point
0
%
%
%0 to10
s0
1
1
0
Default value
(*): Indicated item
0%J10
120.0%
Forward
5%
0s
No
Damping
6-9
Description
Sets the range in vicinity of 0% within which the current output will be 4 mA.
Sets the low limit for current output
Sets the high limit for current output
Selects the flow direction.
Sets the level to reduce output fluctuation.
Sets the dead time to reduce output fluctuation. When “0” is set, rate limit function is not available.
Selects whether pulsing flow is to be supported.
Selects whether the flow rate value obtained through damping calculation for total/pulse or the instantaneous flow rate value (no damping) for total/ pulse is to be used.
T0610-1.EPS
IM 01E20C02-01E
6. PARAMETER DESCRIPTION
Item
Display unit
(BRAIN)
Power Synch
J30
(POWER SYNCH)
Power Frequency
J31
(POWER FREQ)
J40
Memo 1 (MEMO 1)
Memo 2
J41
(MEMO 2)
J42
Memo 3 (MEMO 3)
J50
Software Rev No (SOFTWARE REV)
J60 —
(SELF CHECK)
Name
R/W
W
R/W
W
W
W
R
R
Data range Display unit
/BRAIN
No Yes
47.00 to 63.00
ASCII 16 characters
ASCII 16 characters
ASCII 16 characters
Good Error
Units
Hz
Position
of decimal
point
2
Default value
(*): Indicated item
Yes
50.00
Description
Selects whether or not the internal frequency is to be synchronized with the power supply frequency.
Displays the power-supply frequency (for Power Synch = “Yes”), or sets the power-supply frequency (for Power Synch=“No”).
Memo field
Memo field
Memo field
Software revision number
See “6.5 Alarm Functions”.
(10) Item K (Menu K): Diagnostic Function Setting items
Menu K contains items that are relevant to the diagnosis of insulation adhesion to the electrode.
Item
Display unit
(BRAIN)
Diagnosis
K00
(DIAGNOSIS)
Adhesion Check
K10
(ADHESION CHK)
K11
Adhesion Level1 (ADH LEVEL1)
K12
Adhesion Level2 (ADH LEVEL2)
K13
Adhesion Level3 (ADH LEVEL3)
K14
(ADH LEVEL4)
K15
Adh Measure Value (ADH MEAS VAL)
K60
(SELF CHECK)
Name
R/W
W
W
W
W
W 0.00 to 100.00
R
R
Data range Display unit
Units
/BRAIN
No Yes
0.00 to 100.00 M ohm
0.00 to 100.00
M ohm
0.00 to 100.00 M ohm
M ohmAdhesion Level4
Good Error
Position
of decimal
point
2
2
2
2
2—M ohm
Default value
(*): Indicated item
No
0.10
0.50
1.00
3.00
Description
Selects whether or not to perform diagnosis of adhesion to the electrode.
Sets the resistance value for adhesion Level 1 to the electorode.
Sets the resistance value for adhesion Level 2 to the electorode.
Sets the resistance value for adhesion Level 3 to the electorode.
Sets the resistance value for adhesion Level 4 to the electorode.
Displays the resistance value for adhesion to the electrode.
See “6.5 Alarm Functions”.
(11) Item M (Menu M): Automatic Zero-Adjustment Function Setting items
Menu M contains items that are relevant to automatic zero adjustment.
T0610-2.EPS
T0611.EPS
Item
Display unit
(BRAIN)
Adjustment
M00
(ADJUSTMENT)
Auto Zero Exe
M10
(AUTOZERO EXE)
M11
(MAGFLOW
M60
(SELF CHECK)
Name
R/W
W
R/WMagflow Zero
R
Data range Display unit
/BRAIN
No Execution Execution
Good Error
Units
Position
of decimal
point
3-99.999 to 99.999
6-10
Default value
(*): Indicated item
No Execution Selects whether or not automatic
0.000
zero adjustment is carried out. Linked with B50.
Displays the result of the automatic zero adjustment, or sets the zero point.
See “6.5 Alarm Functions”.
Description
T0612.EPS
IM 01E20C02-01E
(12) Item N (Menu N): Loop Test Setting items
Menu N contains items that are relevant to the execution of loop testing.
6. PARAMETER DESCRIPTION
Item
Display unit
Test
N00
(TEST)
Test Mode
N10
(TEST MODE)
Test Output Value
N11
(TEST OUT VAL)
Test DO
N30
(TEST DO)
Test DIO (O)
N31
(TEST DIO (O))
Test DIO (I)
N32
(TEST DIO (I))
— (SELF CHECK)
Name
R/W
(BRAIN)
W
W
W Selects the test condition for DO
W
R Open
RN60
Data range
Display unit
/BRAIN
Normal Test
Open(Off) Closed(On) Pulse
Input Mode Open(Off) Closed(On)
Short
Good Error
Units
%-10 to 110
Position
of decimal
point
0
Default value
(*): Indicated item
Normal Selects whether mode will be set
0%
Open(Off)
Input Mode
(13) Item P (Menu P): Parameter Protection items
Menu P contains items that are relevant to write protection and passwords.
Item
Display unit
(BRAIN)
Protect
P00
(PROTECT)
Key Code
P10
(KEY CODE) Write Protect
P20
(W PROTECT)
P21
Enable Wrt Passwd (ENABLE WRITE)
New Password
P22
(NEW PASSWORD)
P23
Software Seal (SOFT SEAL)
P60
(SELF CHECK)
Name
R/W
W
R
W
W
R
R Good
Data range Display unit
/BRAIN
0 to 9999
No Yes
ASCII 8 characters
ASCII 8 characters
Break Keep
Error
Units
Position
of decimal
point
Default value
(*): Indicated item
0
No
Keep
Description
to “Normal” or “Test”.
Sets the test output value.
terminal.
Selects the test condition for DIO terminal used for output.
Displays the test condition for DIO terminal used for input.
See “6.5 Alarm Functions”.
T0613.EPS
Description
Parameter of the display restriction
Displays whether or not overwriting of parameter data is prohibited.
Sets the correct password so that write protection function will be released.
Sets the password for write protection funcion
Displays whether or not a Joker password was used (Break).
See “6.5 Alarm Functions”.
T0613-1.EPS
6-11
IM 01E20C02-01E
6. PARAMETER DESCRIPTION
NOTE
NOTE

6.4 Parameter Description

(1) Menu B: Easy Setup items

Those parameters with a high frequency of use have been grouped together in Easy Setup. All basic functions can be controlled using only the parameters from this block. Parameters from Menu B share identical names with those from other menus; however, modification of one such parameter will result in the other being automatically modified.
[B10: Language] Selection of language used for the display unit This setting is linked with that of parameter H30. One of the following languages can be selected for the display unit.
Data Range
Setting item Description
English
Japanese
French
German
Italian
Spanish
[B20: Flow Damping] Setting of the damping time constant This setting is linked with that of parameter C11. The damping time constant should be modified to suppress an output fluctuation or to change the re­sponse time. This time constant has an effect on analog output and on the flow rate display (i.e., actual instan­taneous flow rate, %, current value), and in addition, it also affects pulse output and totalization. However, when “No Damping” has been set for J24: T/P Damp Select, there will be no effect on pulse output or totalization. * Time constant: The time required for the output to
reach 63.2% from 0%.
[B21: Base Flow Unit] Selection of flow units for the flow rate span This setting is linked with that of parameter C40. This parameter selects the flow units for the flow rate span. (In case of mass flow, the setting of density is also required. Refer to C46: Mass Flow Density for more details.)
All parameters, alarm messages, etc. displayed in English.
All parameters, alarm messages, etc. displayed in Japanese katakana.
All parameters, alarm messages, etc. displayed in French.
All parameters, alarm messages, etc. displayed in German.
All parameters, alarm messages, etc. displayed in Italian.
All parameters, alarm messages, etc. displayed in Spanish.
T0614.EPS
[B22: Base Time Unit] Selection of time units for the flow rate span This setting is linked with that of parameter C41. This parameter selects the time units for the flow rate span; however, if “m” has been selected for the flow rate units, “/s” is automatically set for this parameter.
[B23: Flow Span] Setting of the flow rate span This setting is linked with that of parameter C42. The span can be set for the forward flow rate in the range 0 to 32,000 (although this does not include 0). The units set using B21/C40: Base Flow Unit and B22/ C41: Base Time Unit will be displayed at this time.
If the flow rate units, time units, and flow rate span are specified upon ordering, these param­eters will be setup before shipment; however, if this is not the case, it will be necessary for the appropriate values to be set up by the user.
Flow rate span is the value for instantaneous flow rate that corresponds to a current output of 20 mA. The following factors should be taken into consideration when deciding on the flow rate span.
• In the case of applications with large variations in flow rate, the maximum flow rate should be set. If a flow rate in excess of the flow rate span was to occur, output would be possible up to an upper limit of 108%, and beyond this, error would occur. Note that the same applies to pulse output and totalization.
• In the case of applications that have a rela­tively stable flow rate, a flow rate span of 1.5 to
2.0 times larger than the normal flow rate may be considered suitable.
• The flow rate to be adopted should - upon conversion to flow velocity - correspond to a value within the range of 0.1 to 10 m/s. The flow velocity can be confirmed using sizing data or with parameter C44: Velocity Check, and in the latter case, the value obtained when span is converted to flow velocity will be displayed.
• Regardless of the position of the decimal point, the largest value that can be set on the display unit is 32,000. Furthermore, it is not possible to set a number of 4 or greater for the highest­order digit. Similarly, if 3 is set for this highest­order digit, it will not be possible to set a
6-12
IM 01E20C02-01E
6. PARAMETER DESCRIPTION
NOTE
NOTE
number of 2 or greater for the next digit to the right, regardless of the position of the decimal point. Example: A value of 333.33 is represented by
the character string 33333, and since this exceeds 32000, it cannot be set. In such a case, the value 333.3 should be set instead.
[B24: Flow Decimal Pnt] Setting of the decimal point position for the instantaneous flow rate This setting is linked with that of parameter C43. This parameter sets the position of the decimal point for instantaneous flow rate values in terms of the number of digits. When set using “Auto”, the decimal point position will be automatically determined in accordance with the setting value for B23/C42: Flow Span as shown below.
Flow Span  9 Decimal point position: 3 digits 9 < Flow Span  90 Decimal point position: 2 digits 90 < Flow Span  900 Decimal point position: 1 digit 900 < Flow Span Decimal point position: no
digits (i.e., no decimal point)
Item Description
-
n Unit/P
u Unit/P
m Unit/P
Unit/P
k Unit/P
M Unit/P
Pulse/s
FU: Flow rate unit selected in B21/C40: Base Flow Unit.
9
10
FU
-
6
10
FU
-
3
10
FU
FU
3
10
FU
6
10
FU
Number of pulses to be counted for one second at 100% output.
T0616.EPS
[B31: Total Scale] Setting of the totalization scale
This setting is linked with that of parameter D11. The flow rate is totalized in individual counts in accordance with this parameter’s setting. If 0 is selected, it indicates that the totalization function is not to be used.
If a totalization scale is specified upon ordering, this parameter is set up before shipment; how­ever, if this is not the case, it will be necessary for the appropriate value to be set up by the user.
When an item other than “Auto” is set, the selected number of digits for the decimal point position is used.
With the decimal point removed, 6 digits are available for the instantaneous flow rate value, and display is possible up to 999,999. If an overflow occurs as a result of the setting adopted for decimal point position, the warning 84: Disp Over Wng will be displayed to provide notification of this condition.
Example: When 1000 m3/h is set for B23/C42:
Flow Span
Item
Auto
0
1
2
3
Display content for instantaneous flow rate value
1000 m3/h
3
1000 m
/h
3
1000.0 m
1000.00 m With the decimal point removed, 7 digits are not
available for the instantaneous flow rate value; therefore, a warning is displayed.
/h
3
/h
T0615.EPS
[B30: Total Unit] Setting of units for totalization scale This setting is linked with that of parameter D10. This parameter selects the flow rate units for use in totalization.
• By setting the totalization scale, the totalized value is displayed on the display unit. The totalization scale is determined in accordance with the settings of B30/D10: Total Unit and B31/D11: Total Scale.
• The maximum value that can be displayed is 99999999, and if this is exceeded, the value 0 is counted once again. However, counting stops at 99999999 when the totalization switch function is used.
• If multiple ranges are being used, the flow rate span for the smallest range becomes the standard for the D13: Total Low Cut setting value.
• Totalization for the reverse flow rate and for the differential flow rate is carried out only when “Fwd/Rev Ranges” is selected for F20: DO Function or F21: DIO Function.
• The totalized units are indicated on the display unit when B31/D11 is 0.001, 0.01, 0.1, 1, 10, 100, or 1000. In the case of other setting values, the totalized units are not indicated.
6-13
IM 01E20C02-01E
6. PARAMETER DESCRIPTION
NOTE
NOTE
Example 1: To count in 1 Ml (mega-liter) steps
with flow rate span = 100 m
3
/h Since 1 Ml = 103 x m3, k Unit/P is set for B30/D10, and 1 is set for B31/D11. “x103 m3” is indicated for the totalized units in the Display Mode.
Example 2: To count in 10 l (liter) steps with
flow rate span = 100 m3/h Since 1 l = 10-3 x m3, m Unit/P is set for B30/D10, and 10 is set for B31/D11. “x10-2 m3” is indicated for the totalized units in the Display Mode.
Example 3: To count in 5 l (liter) steps with
flow rate span = 100 m3/h Since 1 l = 10-3 x m3, m Unit/P is set for B30/D10, and 5 is set for B31/D11. Since B31/D11 is not
0.001, 0.01, 0.1, 1, 10, 100, or 1000, there is no indication of totalized units in the Display Mode.
• Setting of totalization scale is not possible when specific selections have been made for B30/D10: Total Unit, B31/D11: Total Scale, and B23/C42: Flow Span. In such a case, a setting alarm will be displayed, and parameters should be changed in accordance with the instructions given.
[B32: Pulse Unit] Setting of the pulse units
This setting is linked with that of parameter E10. This parameter selects the flow rate units to be used for pulse output.
Item Description
-
n Unit/P
u Unit/P
m Unit/P
Unit/P
k Unit/P
M Unit/P
Pulse/s
FU: Flow rate unit selected in B21/C40: Base Flow Unit.
9
10
FU
-
6
10
FU
-
3
10
FU
FU
3
10
FU
6
10
FU
Number of pulses to be output for one second at 100% output.
T0617.EPS
If a pulse scale is specified upon ordering, this parameter is setup before shipment; however, if this is not the case, it will be necessary for the appropriate value to be setup by the user.
• By setting the pulse scale, pulse output per­forms. The pulse scale is determined in accor­dance with the settings of B32/E10: Pulse Unit and B33/E11: Pulse Scale.
• If multiple ranges are being used, the flow rate span for the smallest range becomes the standard for the E13: Pulse Low Cut setting value.
• Pulse output for the reverse flow rate is carried out only when “Fwd/Rev Ranges” is selected for F20: DO Function or F21: DIO Function.
• Setting of pulse scale is not possible when specific selections have been made for B32/
E10: Pulse Unit, B33/E11: Pulse Scale, E12: Pulse Width and B23/C42: Flow Span. In
such a case, a setting alarm will be displayed, and parameters should be changed in accor­dance with the instructions given.
Example 1: To perform pulse output in 1 Ml
(mega-liter) steps with flow rate span = 100 m3/h Since 1 Ml = 103 x m3, k Unit/P is set for B32/E10, and 1 is set for B33/E11.
Example 2: To perform pulse output in 10 l
(liter) steps with flow rate span = 100 m3/h Since 1 l = 10-3 x m3, m Unit/P is set for B32/E10, and 10 is set for B33/E11.
Example 3: To perform pulse output in 5 l
(liter) steps with flow rate span = 100 m3/h Since 1 l = 10-3 x m3, m Unit/P is set for B32/E10, and 5 is set for
B33/E11.
[B33: Pulse Scale] Setting of pulse scale
This setting is linked with that of parameter E11. Pulse output is performed in individual counts in accordance with this parameter’s setting. If 0 is selected, it indicates that the pulse output function is not to be used.
[B40: Display Select1] Setting of the first line for display unit This setting is linked with that of parameter H10. This parameter selects the display content of the first line for display unit. The size of the characters which are displayed will depend on the selections made for
6-14
IM 01E20C02-01E
6. PARAMETER DESCRIPTION
NOTE
B41/H11: Display Select2 and B42/H12: Display Select3 as described below. (For more details, refer to
Chapter 5: Basic Operating Procedures.)
CAUTION
It is not possible to set Display Select1 to “Off”.
[B41: Display Select2] Setting of the second line for display unit This setting is linked with that of parameter H11. This parameter selects the display content of the second line for display unit. When “Off” is selected, one-line display will be adopted regardless of the setting made for B42/H12: Display Select 3.
[B42: Display Select3] Setting of the third line for display unit This setting is linked with that of parameter H12. This parameter selects the display content of the third line for display unit. When “Off” is selected for this parameter, two-line display is adopted.
remote flowtube is ordered at the same time as the AXFA14, or where the AXF integral flowme­ter is ordered, the nominal size and meter factor will be set upon shipment from the manufactur­ing plant, and these will not require additional setting. If the AXFA14 is ordered separately, the default value will be set for the meter factor; accordingly, it will be necessary to set the meter factor indicated on your remote flowtube data plate. If a flow rate span was specified upon ordering, this will be set before shipment. If this is not the case, however, it will be necessary for the appropriate value to be set by the user.
[C10: Tag No] Setting of the tag number
The setting for this parameter corresponds to one of the ordered items. Up to a maximum of 16 characters can be entered for the display unit. For more details regarding the actual characters that can be used, refer to Section 5.2.2: Setting Mode.
[B50: Auto Zero Exe] Execution of the automatic zero adjustment function This setting is linked with that of parameter M10. This parameter executes the automatic zero adjustment function: If “Execution” is selected, this function will be started. “Now Auto Zero Executing...” is indicated while the Auto Zero function is being carried out. The result of the automatic zero adjustment is confirmed using M11: Magflow Zero, and if the result exceeds the rated value, the warning 82: Auto Zero Wng will be displayed. (For more details, refer to Chapter 9: Operation.)
Setting Function
No Execution
Execution
No execution
Automatic zero adjustment is started.
T0643-1.EPS

(2) Menu C: Basic Setting items

Menu C principally contains the basic setting items for the flowtube.
NOTE
In order to ensure that correct flow rate data can be acquired, it is crucial that the nominal size, flow rate span, and meter factor of the combined remote flowtube are set. In cases where a
If a tag number is specified upon ordering, this parameter is set up before shipment; however, if this is not the case, it will be necessary for the appropriate value to be set up by the user.
[C11: Flow Damping] Setting of the damping time Refer to the description of parameter B20.
[C20: Measure Mode] Selection of dual frequency
excitation mode
Item Description
Standard DF Standard dual frequency excitation
Enhanced dual frequency excitationEnhanced DF
T0618.EPS
Enhanced DF (i.e., enhanced dual frequency excitation) is set to stabilize measurement for difficult applica­tions, such as for high concentration slurries or low conductivity fluid. Note that this parameter is only valid when this product is used in combination with an AXF flowtube, as only supports enhanced dual frequency excitation. (Optional code HF1 or HF2)
6-15
IM 01E20C02-01E
6. PARAMETER DESCRIPTION
NOTE
NOTE
· When this product is used in combination with any flowtube that does not support enhanced dual frequency excitation and “Enhanced DF” is selected, a setting alarm will be displayed. The setting should be returned to “Standard DF” in such a case.
· When dual frequency excitation mode is changed, perform zero adjustment. For details on zero adjustment, refer to chapter 9.
[C21: Low MF] Setting of the low-frequency meter factor This parameter sets the low-frequency meter factor for standard dual frequency excitation.
[C22: High MF] Setting of the high-frequency meter factor This parameter sets the high-frequency meter factor for standard dual frequency excitation.
[C23: Low MF (EDF)] Setting of the low-frequency meter factor for EDF This parameter sets the low-frequency meter factor as required when Enhanced DF (i.e., enhanced dual frequency excitation) is selected. If “Standard DF” has been selected for C20: Measure Mode, neither C23: Low MF (EDF) nor C24: High MF (EDF) is displayed, and if “Enhanced DF” is selected, the four parameters from C21 to C24 will be displayed.
For the AXF integral flowmeter, refer to “Section
6.6: Precautions for the AXF integral flowmeter.”
[C24: High MF (EDF)] Setting of the high-frequency meter factor for EDF This parameter sets the high-frequency meter factor as required when Enhanced DF (i.e., enhanced dual frequency excitation) is selected.
NOTE
Meter Factor Settings
Meter factors of flowtube
Flowtube data plate
Converter data plate
F0601.EPS
(1) Confirm that the serial number indicated by
COMB. NO. on the AXFA14 converter’s data plate corresponds with the AXF remote flowtube’s serial number.
(2) Set the values that are marked in the
METER FACTOR fields on the data plate for the Remote Flowtube.
(3) The meter factors are crucial in ensuring that
the electromotive force is correctly in propor­tion to the flow velocity and are determined at the manufacturing plant by actual-flow calibration.
[C31: Nominal Size Unit] Setting of the nominal size units This parameter selects the units used for setting of the nominal size.
[C32: Nominal Size] Setting of the nominal size This parameter sets the nominal size of flowtube.
[C40: Base Flow Unit] Selection of flow units for the flow rate span
Refer to the description of parameter B21.
[C41: Base Time Unit] Selection of time units for
the flow rate span
Refer to the description of parameter B22.
[C42: Flow Span] Setting of the flow rate span Refer to the description of parameter B23.
[C43: Flow Decimal Pnt] Setting of the decimal
point position for the instantaneous flow rate
Refer to the description of parameter B24.
[C44: Velocity Check] Display of the flow rate span
velocity This parameter displays the flow rate span for the maximum range in m/s units.
6-16
IM 01E20C02-01E
6. PARAMETER DESCRIPTION
[C45: Density Unit] Setting of the density units for
mass flow rate This parameter selects the units for density as required when making settings using C46: Mass Density.
[C46: Mass Density] Setting of the density for mass flow rate This parameter is necessary in situations where t, kg, g, klb or lb has been selected as the mass unit in B21/
C40: Base Flow Unit. If a mass unit is selected in B21/C40: Base Flow Unit and a value of 0 is set for
this parameter, the setting alarm “57: Dens Set Err” will be displayed. In such a case, ensure that the density is set correctly.
[C47: User Span Select] Selection of the use of special flow rate units This parameter selects whether or not special units are used for instantaneous flow rate. Actual setting of these units is carried out using C48: Flow User Unit and
C49: Flow User Span.
[C48: Flow User Unit] Setting of the special flow
rate units This parameter is used to select the special units (up to maximum 8 characters in length). These units are displayed when instantaneous flow rate is selected in the Display Mode, and they are displayed for A20: FLOW RATE when BRAIN communication is being carried out.
[C49: Flow User Span] Setting of the special flow rate span This parameter sets the special span to be displayed for 100% output in the maximum range.
NOTE
Example : To set the special flow rate span to
100 dl/s Since 100 dl (deci-liter)=10 l (liter), “l (Liter)” is set for B21/C40: Base Flow Unit, “/s” is set for B22/C41: Base Time Unit, “10” is set for B23/C42: Flow Span, “Yes” is set for C47: User Span Select, “dl/s” is set for C48: Flow User Unit, “100” is set for C49: Flow User Span. “100 dl/s” is indicated for 100% output in the Display Mode.

(3) Menu D: Total Setting items

Menu D contains parameters that are relevant to totalization function settings.
[D10: Total Unit] Setting of units for totalization scale
Refer to the description of parameter B30.
[D11: Total Scale] Setting of the totalization scale Refer to the description of parameter B31.
[D12: Total Decimal Pnt] Setting of the decimal
point position for the totalization display This parameter sets the position of the decimal point for totalization display in terms of the number of digits. Except in cases where 0 is selected, the totalized units are not displayed.
Example: When totalized value is 12345678 m
Item
0
1
2
3
4
5
6
7 1.2345678
Totalization display
12345678 m
1234567.8
123456.78
12345.678
1234.5678
123.45678
12.345678
3
[D13: Total Low Cut] Setting of the totalization stop range This parameter allows the settings to be made that prevent totalization when the flow rate is at or below the low-cut setting value. In cases where there are multiple ranges or forward/reverse ranges, low cut is carried out at the setting value for the smallest span (i.e., an integer between 0 and 10%). Example: When the first range = 10 m3/h, the second
range = 100 m3/h, and the Total Low Cut = 3%, no totalization is carried out at flow rates of 0.3 m3/h or lower.
6-17
IM 01E20C02-01E
3
T0619.EPS
6. PARAMETER DESCRIPTION
NOTE
[D20: Total Execution] Operation setting for the
totalization function This parameter sets “Start” and “Stop” of the totaliza­tion function, in addition to performing the preset function for the forward totalized value and the reverse totalized value. *: The preset function starts the count for totalization
from the set value.
Item Description
Start (initial value)
Stop
Preset Total
Preset Rev Total
NOTE
Starts totalization
Stops totalization
Sets the preset value for totalization display that has
been specified as the forward totalized value. Preset
value are determined using D21: Ttl Set Val Lower
and D22: Ttl Set Val Upper.
In case that “Start” is sellected, the count for
totalization starts from the preset value. Setting of zero
as the preset value allows the zero-reset function to be
implemented.
Sets the preset value for totalization display that has
been specified as the reverse totalized value. Preset
value are determined using D21: Ttl Set Val Lower
and D22: Ttl Set Val Upper.
In case that “Start” is sellected, the count for
totalization starts from the preset value. Setting of zero
as the preset value allows the zero-reset function to be
implemented.
T0620.EPS
Totalization presets can also be set up by using status input. For details regarding the setting method, refer to the descriptions of F21.
[D23: Ttl Switch Lower] Setting of the totalization switch value (lower 6 digits) The totalization switch function operates to set the status output terminal (i.e., DO or DIO) to “Closed (On)” when the forward internal totalized value reaches or exceeds the totalization switch value. (For details regarding the setting method for the status output, refer to the descriptions of parameters F20 and F21.)
If this function is set up, the totalization count will stop at 99999999. D23 sets the lower 6 digits of the 8-digit totalization switch value.
[D24: Ttl Switch Upper] Setting of the totalization switch value (upper 2 digits) This parameter sets the upper 2 digits of the 8-digit totalization switch value.
[D30: Ttl User Select] Selection of the use of special totalization unit This parameter specifies whether or not special units are used for totalization unit. Actual setting of these units is carried out using D31: Ttl User Unit.
[D31: Ttl User Unit] Setting of special totalization units Units of up to maximum 8 characters in length can be specified using this parameter. The units set with this parameter are displayed whenever totalization (i.e., FTL, RTL, DTL) is selected in the Display Mode, and they are displayed for A30: TOTAL, A31: REV TOTAL, and A32: DIF TOTAL when BRAIN communication is being carried out.
[D21: Ttl Set Val Lower] Setting of the totalization preset value (lower 6 digits) This parameter sets a totalization preset value in the lower 6 digits of the 8-digit totalized value. If zero is to be set as the preset value, “000000” should be set here.
[D22: Ttl Set Val Upper] Setting of the totalization preset value (upper 2 digits) This parameter sets a totalization preset value in the upper 2 digits of the 8-digit totalized value. If zero is to be set as the preset value, “00” should be set here.
Upper 2 digits
Lower 6 digits
F0602.EPS
Example: To count in 1 dl (deci-liter) steps
with flow rate span=10 l/s. Since 1 dl (deci-liter) = 0.1 l (liter), “l (Liter)” is set for B21/C40: Base Flow Unit, “/s” is set for B22/C41: Base Time Unit, “10” is set for B23/C42: Flow Span, “Unit/P” is set for B30/D10: Total Unit, “0.1” is set for B31/D11: Total Scale, “Yes” is set for D30: Ttl User Select, “dl” is set for D31: Ttl User Unit. “dl” is indicated for the totalized units in the Display Mode and is counted in 1 dl steps.
6-18
IM 01E20C02-01E
6. PARAMETER DESCRIPTION

(4) Menu E: Pulse Setting items

Menu E contains items relevant to pulse output.
NOTE
For pulse output from the DO terminal, set F20: DO Function to “Pulse Output.”
[E10: Pulse Unit] Setting of the pulse units Refer to the description of parameter B32: Pulse Unit
[E11: Pulse Scale] Setting of the pulse scale Refer to the description of parameter B33: Pulse Scale
[E12: Pulse Width] Setting of the pulse width
This parameter selects the pulse width (i.e., m/s : millisecond) that is output.
Data Range
Setting
(0) 50% Duty
(1) 0.05ms
(2) 0.1ms
(3) 0.5ms
(4) 1ms
(5) 20ms
(6) 33ms
(7) 50ms
(8) 100ms
Maximum Value
11000
10000
5000
1000
500
25
15
10
5
Pulse Rate (pps)
Minimum Value
0.0001
(pps: pulses per second)
T0621.EPS
[E13: Pulse Low Cut] Setting of the pulse output stop range This parameter allows the settings to be made which prevent pulse output when the flow rate is at or below the low-cut setting value. In cases where there are multiple ranges or forward/reverse ranges, low cut is carried out at the setting value for the smallest span (i.e., an integer between 0 and 10%). Example: When the first range = 10 m3/h, the second
range = 100 m3/h, and the Pulse Low Cut = 3%, no pulse output is carried out at flow rates of 0.3 m3/h or lower.
NOTE
*:The pulse width with the exception of “50%
Duty” is the “Closed (On)” time for each pulse in case that “Closed (On) Act” is selected for
F22: DO Active Mode
Closed (On)
Open (Off)
Pulse width
F0603.EPS
A limit applies to the maximum pulse scale that can be set with respect to the pulse width. If a value in excess of this limit is set, a setting alarm will be displayed.
6-19
IM 01E20C02-01E

(5) Menu F: Status Functions Setting items

Menu F contains setting items relevant to status Input/Output functions.
[F20: DO Function] Setting of the function for the DO status output terminal This parameter sets the function for the DO (status output) terminal.
Setting
No Function Stops output
Pulse Output Pulse output
Alarm Output Output upon alarm
Warning Output Output upon warning
Total Switch(O) Totalization switch output
H/L Alarm(O) H/L alarm output
HH/LL Alarm(O)
Fwd/Rev Rngs(O) Forward/reverse flow rate measurement
Auto 2 Rngs(O)
Auto 3 Rngs(O)
Auto 4 Rngs(O)
Ext 2 Answer(O)
Note 1: When these functions are selected, two terminals become necessary for status output, the DO and DIO
terminals which cannot be used for other functions. Accordingly, the setting for F20: DO Function is
automatically adopted as the setting for F21: DIO Function. (Setting of these two functions is not possible using F21: DIO Function.)
HH/LL alarm output
Automatic 2 ranges switching
Automatic 3 ranges switching (Note 1)
Automatic 4 ranges switching (Note 1)
Answerback: 2 ranges switching via external status input
(i.e., inactive condition)
6. PARAMETER DESCRIPTION
DescriptionFunction
As no function is set, there is no output.
Pulse output is carried out.
Refer to Alarms (Section 6.5).
Status output is carried out when the forward internal totalized value reaches or exceeds the totalization switch value. The totalization switch value is determined using D23: Ttl Switch Lower and D24: Ttl Switch Upper.
Status output is carried out when the instantaneous flow rate equals or falls below the low flow rate limit (L), or when it equals or exceeds the high flow rate limit (H). These limit values are determined using G10: Low Alarm and G11: High Alarm.
Status output is carried out when the instantaneous flow rate equals or falls below the low-low flow rate limit (LL), or when it equals or exceeds the high-high flow rate limit (HH). These limit values are determined using G12: Low Low Alarm and G13: High High
Alarm.To output “HH/LL Alarm” as an alarm, set G33: Alm­HH/LL to “Yes.”
When flow is in the reverse direction, switching to the reverse range is carried out automatically, measurement is performed, and status output is carried out.
This function ensures that when the instantaneous flow rate exceeds 100% of the range, transition to the next range is carried out automatically. Status output is carried out upon range switching.
When range switching is carried out in response to external status input, status output is performed in the form of an answerback to indicate the range currently being used.
T0622.EPS
6-20
IM 01E20C02-01E
6. PARAMETER DESCRIPTION
[F21: DIO Function] Setting of the function for the DIO status input/output terminal
This parameter sets the function for the DIO (status input/output) terminal.
Setting
No Function No function As no function is set, there is no input and output.
Alarm Output Output upon alarm
Warning Output Output upon warning
Total Switch(O) Totalization switch output
H/L Alarm(O) H/L alarm output
HH/LL Alarm(O)
Fwd/Rev Rngs(O)
Auto 2
Rngs
Auto 3
Rngs
Auto 4
Rngs
Ext 2 Answer(O)
0% Signal Lock(I)
Ext Auto Zero(I)
Ext Ttl Set(I)
Ext R Ttl Set(I)
Ext 2 Ranges(I)
Note 1: When these functions are selected, two terminals become necessary for status output, the DO and DIO
terminals which cannot be used for other functions.
HH/LL alarm output
Forward/reverse flow rate measurement
(O)
Automatic 2 ranges switching
(O)
Automatic 3 ranges switchings (Note 1)
(O)
Automatic 4 ranges switchings (Note 1)
Answerback: 2 ranges switching via external status input
0% signal lock via external status input
Automatic zero adjustment via external status input
Forward totalization preset via external status input
Reverse totalization preset via external status input
2 ranges switching via external status input
Refer to Alarms (Section 6.5).
Status output is carried out when the forward internal totalized value reaches or exceeds the totalization switch value. The totalization switch value is determined using D23: Ttl Switch Lower and D24: Ttl Switch Upper.
Status output is carried out when the instantaneous flow rate equals or falls below the low flow rate limit (L), or when it equals or exceeds the high flow rate limit (H). These limit values are determined using G10: Low Alarm and G11: High Alarm.
Status output is carried out when the instantaneous flow rate equals or falls below the low-low flow rate limit (LL), or when it equals or exceeds the high-high flow rate limit (HH). These limit values are determined using G12: Low Low Alarm and G13: High High
Alarm. To output “HH/LL Alarm” as an alarm, set G33: Alm­HH/LL to “Yes.”
When flow is in the reverse direction, switching to the reverse range is carried out automatically, measurement is performed, and status output is carried out.
This function ensures that when the instantaneous flow rate exceeds 100% of the range, transition to the next range is carried out automatically. Status output is carried out upon range switching.
When range switching is carried out in response to external status input, status output is performed in the form of an answerback to indicate the range currently being used.
Based on the external status input, the instantaneous flow rate indication is forcibly set to 0% (i.e., 4 mA), and both totalization and pulse outputs are halted. This setting has precedence over the output signal whenever an alarm occurs. When the 0% signal lock is canceled, the instantaneous flow rate is restored in accordance with the time constant originally set using B20/C11: Flow Damping.
Automatic zero adjustment is carried out in response to external status input. For more details regarding automatic zero adjustment, refer to Chapter 9: Operation.
The totalization display value is preset or reset to zero in accordance with the external status input. The preset value is determined using D21: Ttl Set Val Lower and D22: Ttl Set Val Upper. In case that “Start” is selected for D20: Total Execution, the count for totalization starts from the preset value.
This function allows the switching of 2 ranges in response to status input for a single direction only.
DescriptionFunction
T0623.EPS
6-21
IM 01E20C02-01E
6. PARAMETER DESCRIPTION
[F22: DO Active Mode] Setting of the active mode
for DO terminal
Operations are performed in accordance with the following table when the active mode has been set to “Closed (On) Act” using this parameter. Operating patterns are reversed when the active mode has been set to “Open (Off) Act.”
Selected function
Pulse Output (see Example 1)
Alarm Output (see Example 2)
Warning Output
Total Switch(O) (see Example 3)
H/L Alarm(O)
HH/LL Alarm(O)
Fwd/Rev Rngs(O)
Note: For “Auto 2 Rngs(O),” “Auto 3 Rngs(O)”, “Auto 4 Rngs(O)”, and “Ext
2 Answer(O)”, see the Multiple ranges setting section.
Condition of DO terminal
Open (Off) when pulses are output.
Good (normal)
Good (normal)
Below setting value
Normal
Normal
Forward direction
Closed (On)Open (Off)
Closed (On) when pulses are output.
Alarm status
Warning status
Equal or above setting value
H/L alarm status
HH/LL alarm status
Reverse direction
T0624.EPS
Example 1: When the “Pulse Output” function is
selected for the DO terminal and the E12: Pulse Width is “1 ms”, the following signals are output from the terminal.
Closed (On)
Open (Off)
1 ms 1 ms
Closed (On) Active Open (Off) Active
Example 2: When the “Alarm Output” function is
selected for the DO or DIO (O) terminal, the following signals are output from the terminal.
Closed (On)
Open (Off)
Alarm occurs
Closed (On) Active
Alarm occurs
Open (Off) Active
F0604-1.EPS
F0604-2.EPS
[F23: DIO Active Mode] Setting of the active mode for DIO terminal
Operations are performed in accordance with the following table when the active mode has been set to “Closed/Short Act” using this parameter. Operating patterns are reversed when the active mode has been set to “Open/Open Act.”
Selected function
Alarm Output (see Example 2)
Warning Output
Total Switch(O) (see Example 3)
H/L Alarm(O)
HH/LL Alarm(O)
Fwd/Rev Rngs(O)
Note: For “Auto 2 Rngs(O),” “Auto 3 Rngs(O)”, “Auto 4 Rngs(O)”, and “Ext
2 Answer(O)”, see the Multiple ranges setting section.
Selected function
0% Signal Lock (I) (see Example 4)
Ext Auto Zero (I)
Ext Ttl Set (I)
Ext R Ttl Set (I)
Note: For “Ext 2 Ranges(I),” see the Multiple ranges setting section.
*: “DIO (O)” indicates DIO function is used for output. “DIO (I)”
indicates DIO function is used for input.
Condition of DIO (O) terminal
Good (normal)
Good (normal)
Below setting value
Normal
Normal
Forward direction
Condition of DIO (I) terminal
Normal
Normal
Normal
Normal
Signal locked status
Start of automatic zero adjustment
Alarm status
Warning status
Equal or above setting value
H/L alarm status
HH/LL alarm status
Reverse direction
Forward totalization preset
Reverse totalization preset
Closed (On)Open (Off)
T0625.EPS
ShortOpen
T0626.EPS
Example 3: When the “Total Switch (O)” function is
selected for the DO or DIO (O) terminal, the following signals are output from the terminal.
Closed (On)
Open (Off)
Equal or above setting value
Closed (On) Active
Equal or above setting value
Open (Off) Active
F0604-3.EPS
Example 4: When the “0% Signal Lock (I)” function is
selected for the DIO (I) terminal, the following signals are input to the terminal.
Short
Open
Signal lock status
Short Active
Signal lock status
Open Active
F0604-4.EPS
6-22
IM 01E20C02-01E
6. PARAMETER DESCRIPTION
NOTE
Multiple ranges setting
Parameters from F30 to F41 are used with the automatic multiple ranges and the multiple ranges switching via an external status input. The followings will describe the setting method for each range.
The multiple ranges use the following parameters: [B23: Flow Span] Setting of the flow rate span (Setting of the forward No.1 range)
[F30: Forward Span 2] Setting of the forward No.2 range
[F31: Forward Span 3] Setting of the forward No.3 range
[F32: Forward Span 4] Setting of the forward No.4 range
[F33: Reverse Span 1] Setting of the reverse No.1 range
[F34: Reverse Span 2] Setting of the reverse No.2 range
[F40: Auto Range Hys] Setting of the automatic multiple ranges hysteresis width.
[F41: Bi Direction Hys] Setting of the forward/ reverse flow measurement hysteresis width
Multiple Ranges Setting 1:
Automatic multiple ranges switching
When the instantaneous flow rate exceeds 100% of
the range, transition to the next range (up to four ranges) is carried out automatically. Furthermore, when the flow is in reverse, the reverse range is automatically selected.
Range switching can be confirmed according to the
status of the DO and DIO status output terminals. Refer to Table 6.4.1: Status Output for Automatic Multiple Ranges Switching for details of status output conditions for each range.
Status Output for Automatic Multiple Ranges Switching
Operations are performed in accordance with the following table when the active mode has been set to “Closed (On) Act” using F22: DO Active Mode or “Closed/Short Act” using F23: DIO Active Mode. Operating patterns are reversed when the active mode has been set to “Open (Off) Act” using F22: DO
Active Mode or “Open/Open Act” using F23: DIO Active Mode.
Table 6.4.1 Status Output for Automatic Multiple Ranges
Switching
Parameter setting
F20
No Function
Fwd/Rev Rngs (O)
No Function
Auto 2 Rngs (O)
No Function
Auto 3 Rngs (O)
Auto 4 Rngs (O)
Fwd/Rev Rngs (O)
Auto 2 Rngs (O)
*: “No Function” is the default value. Only DO or DIO terminals are
used for single or dual ranges; accordingly, the unused terminal remains at the default value (i.e., No Function) and can therefore be used for other functions.
*: “DIO (O)” indicates DIO function is used for output.
F21
No Function
No Function
Fwd/Rev Rngs (O)
No Function
Auto 2 Rngs (O)
Auto 3 Rngs (O)
Auto 4 Rngs (O)
Auto 2 Rngs (O)
Fwd/Rev Rngs (O)
Function
Forward single range
Auto forward/ reverse 1 range
Auto forward 2 ranges
Auto forward 3 ranges
Auto forward 4 ranges
Auto forward/ reverse 2 ranges
Forward
Reverse
Forward
Reverse
Forward 1 range Forward 2 range
Forward 1 range Forward 2 range
Forward 1 range Forward 2 range Forward 3 range
Forward 1 range Forward 2 range Forward 3 range Forward 4 range
Forward 1 range Forward 2 range Reverse 1 range Reverse 2 range
Forward 1 range Forward 2 range Reverse 1 range Reverse 2 range
Status output
DIO
DO
DIO (O) DIO (I)
Open
Closed
Open
Closed
Open
Closed
Open
Closed
Open
Open
Open
Closed
Closed
Open
Open
Open
Open
Closed
Closed
Open
Closed
Closed
Open
Open
Closed
Open
Open
Closed
Closed
Closed
Open
Open
Open
Closed
Closed
Open
Closed
Closed
– –
– –
– –
– –
– – –
– – – –
– – – –
– – – –
T0627.EPS
6-23
IM 01E20C02-01E
6. PARAMETER DESCRIPTION
NOTE
Parameter setting sequence
(for automatic multiple ranges switching)
F20: DO Function
Select a function.
F22: DO Active Mode
Select whether DO output is to be “Closed (On) Act” or “Open (Off) Act”.
Select a function (Note 1) No Function: Output is stopped (other functions
Fwd/Rev Rngs(O): Forward/reverse flow rate
Auto 2 Rngs(O): Automatic 2-ranges switching Auto 3 Rngs(O): Automatic 3-ranges switching Auto 4 Rngs(O): Automatic 4-ranges switching
B23: Flow
Span
Forward No.1 range
F32:Forward
Span 4
Forward No.4 range
may be selected)
measurement
Refer to Table 6.4.1 and set F20 or F21. Note 1: "DIO (O)" indicates
DIO function is used for output.
F30: Forward
Span 2
Forward No.2 range
F33:Reverse
Span 1
Reverse No.1 range
F21: DIO Function
Select a function.
F23: DIO Active Mode
Select whether DIO output is to be “Closed/Short Act” or “Open/Open Act”.
F31:Forward
Span 3
Forward No.3 range
F34:Reverse
Span 2
Reverse No.2 range
Output
Reverse
Figure 6.4.1 Multiple Ranges and Hysteresis Widths
No. 1 range
Minimum span % within multiple and forward/reverse (set using F41)
No. 2 range
10% of No. 1 range (set using F40)
No. 3 range
10% of No. 3 range
10% of No. 2 range (set using F40)
(set using F40)
Forward
No. 4 range
100%
Input
F0606.EPS
Set the spans for the ranges to be used. No.1 range No.4 range
If “instantaneous flow rate % (FR)” is selected for Display Mode and A10: FLOW RATE (%) is selected for BRAIN communication, the instantaneous flow rate % and following symbols will be displayed only for multiple ranges and forward/reverse flow measurement. Forward No.1 range: [F1] Reverse No.1 range: [R1] Forward Forward Forward
No.2
range: [F2] Reverse No.2 range: [R2]
No.3
range: [F3]
No.4
range: [F4]
No.2 rangeNo.3 range
F0605.EPS
For more details regarding the setting of hyster­esis width, refer to the description of setting parameter for F40: Auto Range Hys and F41: Bi Direction Hys.
6-24
IM 01E20C02-01E
6. PARAMETER DESCRIPTION
F20: DO Function
Select a function.
F21: DIO Function
Select a function.
F23: DIO Active Mode
Select whether DIO input is to be “Closed/Short Act” or “Open/Open Act”.
Select a function (Note 1) No Function: Function is stopped (other functions may be selected) Fwd/Rev Rngs(O): Forward/reverse flow rate measurement Ext 2 Answer(O): Answerback; 2-ranges switching via external
status input
Ext 2 Ranges(I): 2-ranges switching via external status input
Refer to Table 6.4.2 and set
F20
or
F21
.
Note 1: "DIO (O)" indicates DIO function
is used for output and "DIO (I)" for input.
F0607.EPS
F22: DO Active Mode
Select whether DO output is to be “Closed (On) Act” or “Open (Off) Act”.
F34: Reverse
Span 2
Reverse No.2 range
F33: Reverse
Span 1
Reverse No.1 range
F30: Forward
Span 2
Forward No.2 range
B23: Flow
Span
Forward No.1 range
If “instantaneous flow rate % (FR)” is selected for Display Mode and A10: FLOW RATE (%) is selected for BRAIN communication, the instantaneous flow rate % and following symbols will be displayed only for multiple ranges and forward/reverse flow measurement. Forward No.1 range: [F1] Reverse No.1 range: [R1] Forward No.2 range: [F2] Reverse No.2 range: [R2]
Set the spans for the ranges to be used. No.1 range
No.2 range
Multiple Ranges Setting 2:
Multiple ranges switching via external status input
For both the forward and reverse directions, switch-
ing of up to two ranges can be carried out based on a status input; however, switching between direc­tions is not possible. Switching between forward and reverse ranges is carried out automatically only when the flow direction reverses.
DIO terminal is used for multiple ranges switching.
For more details, refer to Table 6.4.2: Multiple Ranges Switching via External Status Input.
Multiple Ranges Switching via External Status Input
Operations are performed in accordance with the following table when the active mode has been set to “Closed (On) Act” using F22: DO Active Mode or “Closed/Short Act” using F23: DIO Active Mode. Operating patterns are reversed when the active mode has been set to “Open (Off) Act” using F22: DO
Active Mode or “Open/Open Act” using F23: DIO Active Mode.
Parameter setting sequence
(for multiple ranges switching via external status input)
Table 6.4.2 Multiple Ranges Switching via External Status
Input
Parameter setting
F20
No Function
Fwd/Rev Rngs(O)
Ext 2 Answer(O)
*: “No Function” is the default value. Only DIO terminal is used for
dual ranges; accordingly, the unused DO terminal remains at the default value (i.e., No Function) and can therefore be used for other functions.
*: “DIO (I)” indicates DIO function is used for input.
F21
Ext 2 Ranges(I)
Ext 2 Ranges(I)
Ext 2 Ranges(I)
Function
External forward 2 ranges
External forward/ reverse 2 ranges
External forward 2 ranges, with answerback
Forward 1 range Forward 2 range
Forward 1 range Forward 2 range Reverse 1 range Reverse 2 range
Forward 1 range Forward 2 range
Status output
DO
– –
Open
Open Closed Closed
Open Closed
DIO
DIO (O) DIO (I)
Open
Short
Open
Short
Open
Short
Open
Short
T0628.EPS
[F40: Auto Range Hys] Setting of automatic range­switching hysteresis width Automatic switching takes place for multiple range switching when 100% of the range is exceeded, and this parameter allows a hysteresis width to be set for this switching. Refer to Figure 6.4.1: Multiple Ranges and Hysteresis Widths.
[F41: Bi Direction Hys] Setting of forward/reverse flow measurement hysteresis width This parameter sets the hysteresis for forward/reverse flow rate measurement as a % value of the minimum flow span. Refer to Figure 6.4.1: Multiple Ranges and Hysteresis Widths.
6-25
IM 01E20C02-01E
6. PARAMETER DESCRIPTION

(6) Menu G: Alarm Setting items

(Refer to Section 6.5: Alarm Functions for more
details.) Menu G principally contains setting items relevant to alarms.
[G10: Low Alarm] Low alarm setting This parameter sets the low limit (L) alarm value, and this is done using a % value of the maximum span. A setting value of -110% indicates that the alarm is
disabled.
[G11: High Alarm] High alarm setting This parameter sets the high limit (H) alarm value, and this is done using a % value of the maximum span. A setting value of 110% indicates that the alarm is
disabled.
[G12: Low Low Alarm] Low-low alarm setting This parameter sets the low-low limit (LL) alarm value, and this is done using a % value of the maxi­mum span. A setting value of -110% indicates that the alarm is
disabled.
[G13: High High Alarm] High-high alarm setting This parameter sets the high-high limit (HH) alarm value, and this is done using a % value of the maxi­mum span. A setting value of 110% indicates that the alarm is
disabled.
NOTE
Setting of -110% or 110% results in the corre­sponding function being disabled; accordingly, settings can be combined to implement only high alarms or low alarms, etc.
Output Example 1
The high-high alarm (HH) is set to 90% or more of the flow rate span; the low-low alarm (LL), to 20% or less; the high alarm (H), to 80% or more; and the low alarm (L), to 30% or less.
Settings are:
G10: Low Alarm = 30%
G11: High Alarm = 80%
G12: Low Low Alarm = 20%
G13: High High Alarm = 90%
[%]
100
90 80
50
30 20
0 Time (t)
DO
DIO
Select “H/L Alarm(O)” for F20: DO Function Select “HH/LL Alarm(O)” for F21: DIO Function Select “Closed (On) Act” for F22: DO Active Mode Select “Closed/Short Act” for F23: DIO Active Mode
HL
HH
High High Alarm
High Alarm
Instantaneous flow rate
Low Alarm
Low Low Alarm
LL
F0608.EPS
6-26
IM 01E20C02-01E
6. PARAMETER DESCRIPTION
NOTE
Output Example 2
The high alarm (H) is set to 80% or more of the flow rate span; the low-low alarm (LL), to 20% or less.
Settings are:
G10: Low Alarm = -110%
G11: High Alarm = 80%
G12: Low Low Alarm = 20%
G13: High High Alarm = 110%
[%] 100
80
High Alarm
Instantaneous flow rate
50
20
Low Low Alarm
0 Time (t)
DO
DIO
Select “H/L Alarm(O)” for F20: DO Function Select “HH/LL Alarm(O)” for F21: DIO Function Select “Closed (On) Act” for F22: DO Active Mode Select “Closed/Short Act” for F23: DIO Active Mode
H
LL
HH Alarm set to 110% indicates that the alarm is disabled.
L Alarm set to
-110% indicates that the alarm is disabled.
F0609.EPS
Output Example 3
The high alarm (H) is set to 80% or more of the flow rate span; the high-high alarm (HH), to 90% or more.
Settings are:
G10: Low Alarm = -110%
G11: High Alarm = 80%
G12: Low Low Alarm = -110%
G13: High High Alarm = 90%
[%] 100
90 80
50
0 Time (t)
DO
DIO
Select “H/L Alarm(O)” for F20: DO Function Select “HH/LL Alarm(O)” for F21: DIO Function Select “Closed (On) Act” for F22: DO Active Mode Select “Closed/Short Act” for F23: DIO Active Mode
H
HH
High High Alarm
High Alarm
Instantaneous flow rate
L Alarm set to
-110% indicates that the alarm is disabled.
LL Alarm set to -110% indicates that the alarm is disabled.
F0610.EPS
• Although the same items can be selected using the DO terminal (selected for F20) and the DIO terminal (selected for F21), output is identical for both.
• Setting values of -110% and 110% are used to disable corresponding functions; and accord­ingly, status output can be customized for specific purposes.
6-27
IM 01E20C02-01E
6. PARAMETER DESCRIPTION
NOTE
[G14: H/L Alarm Hys] Setting of upper/lower alarm
value hysteresis width This parameter sets the hysteresis width for upper and lower alarm value, using a % value of the maximum span.
Output Example
The hysteresis width is set to 5%.
Settings are:
G10: Low Alarm = 30%
G11: High Alarm = 80%
G12: Low Low Alarm = 20%
G13: High High Alarm = 90%
G14: H/L Alarm Hys = 5%
[%]
100
90 80
50
30 20
0 Time (t)
DO
DIO
Select “H/L Alarm(O)” for F20: DO Function Select “HH/LL Alarm(O)” for F21: DIO Function Select “Closed (On) Act” for F22: DO Active Mode Select “Closed/Short Act” for F23: DIO Active Mode
85%
75%
75%
HL
85%
HH
High High Alarm
High Alarm
Instantaneous flow rate
Low Alarm
35%
25%
Low Low Alarm
35%
25%
LL
F0611.EPS
[G21: 4-20mA Alarm Out] Setting of the current output during an alarm occurrence This parameter can be used to set up the current output during alarm occurrence in advance.
Setting Function
2.4mA or Less
4.0mA
Hold
21.6mA or More
Fixed at 2.4 mA or less
Fixed at 4 mA
Fixed current value when an alarm occured.
Fixed at 21.6 mA or more
T0629.EPS
[G22: 4-20mA Burn Out] Display of the current output during a CPU failure This parameter displays the current output direction for a CPU failure (i.e., burnout). Note that communication will not be possible if such a failure occurs. With the standard specification, this is set to High and 25mA is output when a failure occurs. Low is setup for optional code C1, and in such a case, 0mA is output when a failure occurs.
The current output direction for a CPU failure (i.e., burnout) can be changed. Refer to selection
10.2.1: Setting of Burnout Switch.
[G30: Alm-Setting] Alarm recognition of “Setting Alarm” This parameter specifies whether the setting alarm will be recognized as an alarm.
Setting Function
No
Ye s
Not recognized as an alarm
Recognized as an alarm
T0630.EPS
[G31: Alm-Sig Over] Alarm recognition of “Signal Overflow Alarm” This parameter specifies whether the signal overflow in process alarms will be recognized as an alarm. A signal overflow occurs when there is an error in the input signal.
Setting Function
No
Ye s
Not recognized as an alarm
Recognized as an alarm
T0631.EPS
[G32: Alm-Emp Pipe] Alarm recognition of “Empty Pipe Alarm” This parameter specifies whether the empty pipe (flowtube is not filled with fluid) in process alarms will be recognized as an alarm.
Setting Function
No
Ye s
Not recognized as an alarm
Recognized as an alarm
T0632.EPS
6-28
IM 01E20C02-01E
6. PARAMETER DESCRIPTION
NOTE
[G33: Alm-HH/LL] Alarm recognition of “HH/LL Alarm”
(Refer to the descriptions of G12 and G13 for more details regarding HH and LL alarms.) This parameter specifies whether HH/LL alarm in process alarms will be recognized as an alarm.
Setting Function
No
Ye s
Not recognized as an alarm
Recognized as an alarm
T0633.EPS
NOTE
To set “HH/LL Alarm” as an alarm, it is necessary to set “HH/LL Alarm(O)” according to F20: DO Func-
tion or F21: DIO Function, and set G12: Low Low Alarm or G13: High High Alarm as well.
[G34: Alm-Adhesion] Alarm recognition of “Adhe-
sion Alarm” This parameter specifies whether the electrode adhe­sion alarm in process alarms will be recognized as an alarm.
Setting Function
No
Ye s
Not recognized as an alarm
Recognized as an alarm
T0634.EPS
NOTE
The AXFA14 or the AXF integral flowmeter has three different type of alarm (i.e., system alarms, process alarms, and setting alarms). For setting alarms and process alarms, settings are made with G30, G31, G32, G33 and G34 to specify whether these will be recognized as an alarm. Refer to Section 6.5: Alarm Functions for more details regarding the content of each alarm and the effect of alarm recognition on output.
[G40: Operation Time] Display of operation time This parameter is used to display the operation time. The operation time is the total time that is counted while the device works actually. When the power supply is off, the operation time is not counted. For example, “1D23:45” indicates an operation time of 1 day, 23 hours, and 45 minutes.
IMPORTANT
Use this value as a rough guideline because the operation time has an error.
[G41: Alm Record1] Alarm record1 This parameter is used to display the most-recent alarm, and the alarms that can be displayed are as follows.
Alarm Items
Item
: 16 space characters
(i.e., no display)
10 : uP Fault 11 : EEPROM Fault 12 : A/D(H) Fault 13 : A/D(L) Fault 14 : A/D(Z) Fault 15 : Coil Open 16 : EEPROM Dflt 18 : Power off
19 : Inst Pwr Fail
28 : WDT
30 : Sig Overflow 31 : Empty Pipe 33 : Adhesion Alm
No issuing of alarms
Microprocessor (CPU) failure EEPROM failure A/D converter A/D converter A/D converter Flowtube coil is open-circuit EEPROM returns to default values
Power supply is off. Instantaneous power fail for tens of
milliseconds. After this fail is released, outputs reach the previous value immediately.
The return from excessive instantaneous noise. After the noise is released, output return the normal condition.
Input signal error Flowtube is not filled with fluid Insulation adhered to electrode
Description
failure
(at high frequency
failure
(at low frequency side)
failure
(detection of adhesion)
Records for “30: Sig Overflow” are kept only when G31 specifies that this condition is to be recognized as an alarm (i.e., “Yes” is selected). Records for “31: Empty Pipe” are kept only when G32 specifies that this condition is to be recog­nized as an alarm (i.e., “Yes” is selected). Records for “33: Adhesion Alm” are kept only when G34 specifies that this condition is to be recognized as an alarm (i.e., “Yes” is selected).
[G42: Alm Record Time1] Display the operation time of alarm record1 This parameter is used to display the operation time at which the alarm indicated by G41: Alm Record1 was occurred. For example, “1D23:45” indicates that an alarm was occured at the operation time of 1 day, 23 hours, and 45 minutes.
IMPORTANT
Use these values as a reference because the time of alarm records (1 to 4) have an error.
[G43: Alm Record2] Alarm record2 This parameter is used to display the second most­recent alarm, and the alarms that can be displayed are the same as those for G41: Alm Record1.
[G44: Alm Record Time2] Display the operation time of alarm record2 This parameter is used to display the operation time at which the alarm indicated by G43: Alm Record2 was occurred. For example, “1D23:45” indicates that an alarm was occured at the operation time of 1 day, 23 hours, and 45 minutes.
6-29
IM 01E20C02-01E
T0635.EPS
6. PARAMETER DESCRIPTION
[G45: Alm Record3] Alarm record3
This parameter is used to display the third most-recent alarm, and the alarms that can be displayed are the same as those for G41: Alm Record1.
[G46: Alm Record Time3] Display the operation time of alarm record3 This parameter is used to display the operation time at which the alarm indicated by G45: Alm Record3 was occurred. For example, “1D23:45” indicates that an alarm was occured at the operation time of 1 day, 23 hours, and 45 minutes.
[G47: Alm Record4] Alarm record4 This parameter is used to display the fourth most­recent alarm, and the alarms that can be displayed are the same as those for G41: Alm Record1.
[G48: Alm Record Time4] Display the operation time of alarm record4 This parameter is used to display the operation time at which the alarm indicated by G47: Alm Record4 was occurred. For example, “1D23:45” indicates that an alarm was occured at the operation time of 1 day, 23 hours, and 45 minutes.
[H30: Language] Selection of language used for the display unit Refer to the description for parameter B10 This parameter can be used to select the language for the display unit.

(8) Menu J: Auxiliary Function Setting items

Menu J contains setting items such as the flow direc­tion, rate limits, and current output limits.
[J10: 4-20mA Low Cut] Setting of the low-cut range for current output This parameter is used to force current output to 0% (i.e., 4mA) in the vicinity of 0% output, and setting for the current (4 to 20 mA) output low cut is made using a percentage of the smallest flow rate span. However, the low cut function will be terminated if this param­eter is set to 0%. The indications of the instantaneous flow rates (%, Actual instantaneous flow rate, mA, Bar graph) on the display unit are the same action.
Example: Situation where low cut is set to 10%
Output Setting value

(7) Menu H: Display Setting items

Menu H contains setting items relevant to the display unit.
[H10: Display Select1] Setting of the first line for display unit Refer to the description for parameter B40 This parameter selects the display content of the first line for display unit.
[H11: Display Select2] Setting of the second line for display unit Refer to the description for parameter B41 This parameter selects the display content of the second line for display unit.
[H12: Display Select3] Setting of the third line for display unit Refer to the description for parameter B42 This parameter selects the display content of the third line for display unit.
[H20: Display Cycle] Setting of the display cycle This parameter sets the cycle for the display-response speed of display unit. Settings should be made in accordance with the measurement environment by, for example, setting a longer display cycle when using the equipment in low temperatures.
5.6mA(10%)
4mA
Setting range: 0 to 10%
Input
0.5% 0.5%
[J11: 4-20mA Low Lmt] Setting of the low limit for current output This parameter is used to restrict low current portions of current (4 to 20mA) output, and it is initially set to
-20%. Setting should be performed when a higher value is required for the lower limit. The indications of the instantaneous flow rates (%, Actual instantaneous flow rate, mA, Bar graph) on the display unit are the same action.
Example: Situation where low limit is set to 10%
Output
5.6mA(10%)
4mA
6-30
Input
F0655.EPS
IM 01E20C02-01E
Hysteresis fixed at 1%
F0612.EPS
6. PARAMETER DESCRIPTION
NOTE
F0613.EPS
T
0
T
0
2% 2%
Rate limit value:
Determines the level for output fluctuation cutoff. For example, if this is set to 2%, noise above 2% will be eliminated as shown in the diagram.
Dead time (T
0
):
This is to be determined using the output fluctuation width. If noise exceeds the dead time as shown in the diagram below, the dead time should be made longer.
NOTE
If “2.4mA or less” has been set for G21:4-20mA Alarm Out, 2.4mA or less will be output upon an
alarm occurrence, regardless of the low limit setting.
NOTE
• If the setting value for the low limit is not less than the high limit value (as set using J12: 4- 20mA High Lmt), the setting alarm “54: 4-20 Lmt Err” will be displayed.
• This parameter has no effect on pulse output or the totalization function.
[J12: 4-20mA High Lmt] Setting of the high limit for current output This parameter is used to restrict high current portions of current (4 to 20mA) output, and it is initially set to 120%. Setting should be performed when a lower value is required for the higher limit. The indications of the instantaneous flow rates (%, Actual instantaneous flow rate, mA, Bar graph) on the display unit are the same action.
Example: Situation where high limit is set to 90%
Output
Note: This function does not apply to measurement in
both the forward and reverse directions, al­though this can be setup using by selecting “Fwd/Rev Rngs(O)” from either F20: DO Function or F21: DIO Function.
Setting Function
Forward
Reverse
Forward direction corresponds with arrow mark.
Forward direction is opposite to arrow mark.
T0638.EPS
[J21: Rate Limit] Setting of the rate limit value
This parameter is used in situations where sudden
noise cannot be eliminated by increasing the damping time constant.
In situations where step signals or sudden noise
signals caused by slurries or the like are entered, this parameter is used to set the standard for determining whether an input corresponds to a flow measurement or noise. Specifically, this determination is made using upper and lower rate limits and using the dead time.
Rate limit values are set using a percentage of the
smallest range. The range of deviation per one calculation cycle should be input.
[J22: Dead Time] Setting of dead time This parameter sets the time for application of the rate limit, and if a value of 0 is set, the rate limit function will be terminated.
18.4mA(90%)
NOTE
If “21.6mA or more” has been set for G21:4-20 mA Alarm Out, 21.6mA or more will be output
upon an alarm occurrence, regardless of the high limit setting.
[J20: Flow Direction] Setting of the flow direction Upon shipment from the manufacturing plant, the system is setup such that flow in the same direction, as shown by the direction of the arrow mark on the flowtube, will be measured as forward flow; however, this parameter can be used to set “Reverse” so that flow in the opposite direction to the arrow mark will be treated as forward.
4mA
F0656.EPS
Input
Determining rate limit value and dead time
Signal processing method:
A fixed upper and lower limit value is setup with respect to the primary delay response value for the flow rate value obtained during the previous sam­pling, and if the currently sampled flow rate is outside these limits, then the corresponding limit is adopted as the current flow rate value. In addition, if signals which breach the limits in the same direction occur over multiple samples (i.e., within the dead time), it is concluded that the corresponding signal is a flow rate signal.
6-31
IM 01E20C02-01E
6. PARAMETER DESCRIPTION
Example 1: Step input
Input: 0 to 10% Damping time constant: 3 s Dead time: 3 s
10
1
Step signal
%
Flow rate value after rate limit processing
(a)
%
(b)
100 225
Dead time: 3 s
(c)
Rate limit value: 1%
(d)
Flow rate value after damping
Number of signal samples
F0614.EPS
63.2
(1) In comparison with the previous value at (a), it is
determined that the signal is in excess of the rate limit value and the response becomes 1%. How­ever, the actual output applies damping, and therefore the output turns out to be as indicated by the solid line.
(2) Subsequent flow values within the dead time zone
correspond to signals of post-damping flow value + rate limit value (1%).
(3) Since input signals do not return to within the rate
limit value during the dead time, it is determined at (c) that this signal is a flow rate signal.
(4) The output signal becomes a damped curve and
compliance with the step signal begins.
[J24: T/P Damp Select] Setting of damping opera­tion This parameter is used to select that the flow rate value obtained through damping calculation for totalization and pulse output or the instantaneous flow rate value (no damping) for totalization and pulse output.
%
Setting Function
Damp
No Damp
Damping
No damping
T0653.EPS
[J30: Power Synch] Setting of power synchroniza- tion This parameter sellects whether or not the internal frequency is to be synchronized with that of the power supply.
Setting Function
No
Ye s
Not synchronized
Synchronized
T0639.EPS
[J31: Power Frequency] Setting of power fre­quency When “Yes” (i.e., in synchrony) has been selected for J30: Power Synch, this parameter is used to display the power supply frequency. If “No” (i.e., not synchro­nized) has been selected, the power supply frequency is to be specified.
Three seconds after determination of a flow rate signal in the above figure, a level of 63.2% is reached.
Example 2: Slurry noise
Input: 0 to 10%
Slurry noise
Flow rate value after rate limit
+1
%
-1
%
Flow rate value after damping
Dead time: 1 s
processing
Damping time constant: 1 s Dead time: 1 s Rate limit value: 1%
In the figure on the left, it is determined that the slurries noise signal is not a flow rate signal.
Time
F0615.EPS
[J23: Pulsing Flow] Selection of pulsing flow support In a situation where pulsating flow causes error in the average flow value, due to the application of a plunger pump, this parameter provides functionality whereby calculation is controlled and variations in flow rate are followed.
Setting Function
No
Ye s
Normal
Support for pulsing flow
T0637.EPS
IMPORTANT
In situations where a DC power supply is used for converters, set the local commercial power frequency in area where the converter is in­stalled. Set “No” for J30: Power Synch and the local commercial power frequency for J31: Power Frequency.
Following settings are necessary by power supply and by flow tube size.
Power Supply Code 1
(100 to 240 V AC or 100 to 120 V DC)
Size 2.5 mm (0.1 in.) to 400 mm (16 in.)
AC power supply
DC power supply
Power Supply Code 2 (24 V AC/DC)
AC power supply
DC power supply
6-32
Power synchronous (Yes)
J30 J31
No setting Power asynchronous (No)
J30 J31
Local commercial power frequency
Size 2.5 mm (0.1 in.) to 400 mm (16 in.)
Power asynchronous (No)
J30 J31
Local commercial power frequency
Power asynchronous (No)
J30 J31
Local commercial power frequency
IM 01E20C02-01E
T0642-1.EPS
T0642-2.EPS
6. PARAMETER DESCRIPTION
[J40: Memo 1] Setting of memo 1
[J41: Memo 2] Setting of memo 2
[J42: Memo 3] Setting of memo 3
These parameters are used with the memo function, and up to 16 characters can be set for each.
[J50: Software Rev No] Display of software revision This parameter is used to display the software’s revision number.

(9) Menu K: Diagnostic Function Setting items

Menu K contains items that are relevant to the diagno­sis of insulation adhesion to the electrode.
[K10: Adhesion Check] Setting of adhesion diagnostic function This parameter selects whether or not the adhesion diagnostic function will be carried out.
Setting Function
Halt the adhesion diagnostic functionNo
Ye s
NOTE
Carry out the adhesion diagnostic function
T0640.EPS
Adhesion Diagnostic Function
This function diagnose adhesion using elec-
trode resistance values.
When “Adhesion check” has been set for B41/
H11: Display Select 2 or B42/H12: Display Select 3, the diagnose adhesion is indicated
on the display unit using four different levels.
If the judgment value for Level 3 is exceeded,
a warning is displayed; and if the value for Level 4 is exceeded, an alarm is displayed.
Available conductivity for this function is
limited to: Nominal size 10 mm or smaller: 30 S/cm
Nominal size 15 mm or larger: 10 S/cm Make sure to use the adhesion diagnostic function with the greater conductivity than the above mentioned value.
[K11: Adhesion Level1] Setting the resistance value for adhesion diagnostic level1 This parameter sets the resistance value (in M ohm) for judgment of Level 1.
[K12: Adhesion Level2] Setting the resistance value for adhesion diagnostic level2 This parameter sets the resistance value (in M ohm) for judgment of Level 2.
[K13: Adhesion Level3] Setting the resistance value for adhesion diagnostic level3 This parameter sets the resistance value (in M ohm) for judgment of Level 3. *: The warning 80: Adhesion Wng is displayed
when the adhension level reaches Level 3.
*: If “Warning Output” has been selected for F20: DO
Function or F21: DIO Function, then status output will be performed when the adhesion level reaches Level 3.
[K14: Adhesion Level4] Setting the resistance value for adhesion diagnostic level4 This parameter sets the resistance value (in M ohm) for judgment of Level 4. *: The process alarm 33: Adhesion Alm is displayed
when the adhension level reaches Level 4.
*: Alarm output will be preformed if “Alarm Output”
has been selected for F20: DO Function or F21:
DIO Function, and “Yes” for G34: Alm-Adhe­sion.
[K15: Adh Measure Value] Displays the resistance
value for adhesion diagnose This parameter displays the value measured using the adhesion diagnostic function (in M ohm). When “No” is selected for K10: Adhesion Check, this parameter displays the indetermination value.
(10) Menu M: Automatic Zero Adjustment
Function Setting items
Menu M contains items that are relevant to automatic adjustment of the zero point.
[M10: Auto Zero Exe] Execution of automatic zero adjustment function
Refer to the description of parameter B50.
[M11: Magflow Zero] Results of automatic zero
Warning
Alarm
adjustment This parameter is used to display the results obtained from B50/M10: Auto Zero Exe. Specifically, the
Level: 2Level: 1
Level: 3
Level: 4
F0616.EPS
correction value displayed, and it is also possible to directly enter correction value.
6-33
IM 01E20C02-01E
6. PARAMETER DESCRIPTION
NOTE

(11) Menu N: Loop Test Setting items

Menu N contains items that are relevant to loop testing.
[N10: Test Mode] Setting for loop test execution
Setting Function
Normal
Test
IMPORTANT
No execution of loop testing.
Loop testing is started
T0641.EPS
(1) Test output has priority over flow rate mea-
surement signals. When carrying out flow rate measurements, be sure to always return to “Normal”.
(2) Upon entry to the Test Mode, all output
terminals will simultaneously adopt test condition.
(3) “Normal” will be restored when the power is
turned off or when 30 minutes have elapsed since entry to Test Mode.
(4) In Test Mode, the warning 83: Fix Cur Wng
will be displayed as a warning message. (For more details, refer to Section 6.5 Alarm Functions.)
[N31: Test DIO (O)] Setting for the DIO terminal condition during testing This parameter sets the condition of the DIO terminal during loop testing. Setting is possible when “Test” has been selected for N10: Test Mode.
Setting Function
Input mode
Open (Off)
Closed (On)
Must be set when N32: Test DIO (I) is used to display the condition of the DIO terminal.
DIO terminal in Open (Off) condition
DIO terminal in Closed (On) condition
T0643.EPS
[N32: Test DIO (I)] Display for DIO terminal condition during testing This parameter is used to display the condition of the DIO terminal. Setting is possible when “Test” has been selected for N10: Test Mode.
Setting Function
Open
Short
DIO terminal in Open condition
DIO terminal in Short condition
T0644.EPS

(12) Menu P: Parameter Protection items

Menu P contains items that are relevant to write protection and passwords.
[N11: Test Output Value] Setting for test output values During loop testing, current output (4 to 20mA), totalization, and pulse will be output in accordance with this parameter’s setting, and values can be set when “Test” has been selected for N10: Test Mode. With multiple ranges or when performing forward/ reverse flow measurements, setting should be done using a percentage of the maximum range.
[N30: Test DO] Setting for DO terminal condition during testing This parameter sets the condition of the DO terminal during loop testing. Setting is possible when “Test” has been selected for N10: Test Mode.
Setting Function
Open (Off)
Closed (On)
Pulse
DO terminal in Open (Off) condition
DO terminal in Closed (On) condition
Outputs pulses as were specified with Menu E.*
T0642.EPS
*: If the pulse scale is 0 pps or there is a pulse setting
error, the DO terminal is “Open (Off).”
[P10: Key Code] Parameter of the display restriction This parameter restricts access to the Service Mode.
Write Protect function
The parameters P20 through P23 are set
when using the write protect function. Specifi­cally, this function responds to a hardware switch or the setting of a software password, and it protects parameters from being over­written.
If the hardware switch is set to “Protect”, it will
not be possible to overwrite parameters; furthermore, this condition will be maintained until the switch is set to “Enable”.
For more details regarding hardware switch
settings, refer to Section 10.2.2: Setting of Write Protect Switch.
[P20: Write Protect] Setting of password to release the write protection function This parameter is used to indicate whether or not write protection is currently on.
6-34
IM 01E20C02-01E
6. PARAMETER DESCRIPTION
NOTE
Default setting (Enable)
P20:Write Protect No
F0617.EPS
Write protection (Protect)
P20:Write Protect Yes
F0618.EPS
[P21: Enable Wrt Passwd] Setting of password to release the write protection function When the correct password is input, write protection will be released for a period of 10 minutes; further­more, this period will be extended by a further 10 minutes each time a parameter is overwritten.
P21:Enable Wrt Passwd ********
F0619.EPS
The cursor will flash when entering Parameter Re­placement Mode, and the password set with P22: New
Password should be input at this time.
[P22: New Password] Setting of a new password
This parameter sets the password required for the release of write protection. When set, it will be possible to make write protect settings on the software side.
Default setting
P22:New Password
F0620.EPS
The default setting for this parameter is a string of 8 spaces (i.e., Enable), and thus, the password field will be empty. When the cursor is flashing, the password should be input. Press the SET key twice to confirm the password. The display will then change to “********”.
After password setting
P22:New Password ********
F0621.EPS
To change a password, first of all use the password originally set with P21: Enable Wrt Passwd to release the write protect function, and then set the new password. Alternatively, if it is desired to return to the condition where no password is set, enter a string of 8 spaces.
[P23: Software Seal] Display the software seal When the joker password has been used to release write protection, this parameter displays “Break”, and when protection is cancelled using the password set using P22: New Password, it returns to “Keep”.
If you should forget your password, the joker password can be used to temporarily release write protection function. To obtain the joker password, please contact your nearest YOKOGAWA sales office.

6.5 Alarm Functions

6.5.1 Alarm Levels

Alarms are classified into the following four different types based on level.
Alarm DescriptionLevel
Major
System
breakdown
alarm
Intermediate
Process
level break
alarm
down
Minor
Setting
breakdown
alarm
Warning
Warning
When an alarm has been occurred, the corresponding alarm name, description, and suitable countermeasure will be displayed on the display unit. The normal Display Mode and Alarm Mode may be displayed alternatively. When a warning has been issued, the corresponding content will be shown in the third line in the Display Mode.
Upon occurrence of an alarm
(example: a System alarm)
Upon issuance of a warning
(a description appears in the 3rd line only
when a warning is occurred)
Device breakdown or inability to obtain correct measurements. Replacement will be required.
Device is normal but process-related errors make correct measurement impossible. Maintenance or the like will be required.
Device is normal but errors have been made in the setting of parameters. Functions not related to the incorrect settings are operating normally. The incorrect settings must be corrected.
Device and measurements are normal but a warning is occurred.
T0645.EPS
Alarm name Description
Countermeasure message
Description of warning
F0622.EPS
6-35
IM 01E20C02-01E
6. PARAMETER DESCRIPTION

6.5.2 Alarm Selection

The display and output differs depending on the alarm levels. Certain types of alarm may or may not be recognized as alarms, according to the settings of certain parameters. The parameters that are relevant to this function as follows.
[F20: DO Function] Setting of the function for the DO status output terminal
[F21: DIO Function] Setting of the function for the DIO status input/output terminal
[F22: DO Active Mode] Setting of the active mode for DO terminal
[F23: DIO Active Mode] Setting of the active mode for DIO terminal
[G21: 4-20mA Alarm Out] Setting of the current output during an alarm occurring.
(1) Display and output condition for system alarms
Alarm description
Normal Normal
P Fault
10
EEPROM Fault
11
A/D(H) Fault
12
A/D(L) Fault
13
A/D(Z) Fault
14
Coil Open
15
EEPROM Dflt
16
Note: • Alarm is output only when F20: DO Function or F21: DIO Function is set to “Alarm Output.”
• The operation when “Open (Off) Act” is set for F22: DO Active Mode, or “Open/Open Act“ is set for F23: DIO Active Mode is shown in above table.
• 4-20mA output upon the occurrence of an alarm will be fixed at the value selected with G21: 4-20mA Alarm Out.
*The output value is performed in accordance with the setting of the burnout switch. For information about
this switch, see Section 10.2.1.
Microprocessor(CPU)failure EEPROM failure
A/D converter failure
Flowtube coil is open-circuit EEPROM default values
[G30: Alm-Setting] Alarm recognition of “Setting Alarm”
[G31: Alm-Sig Over] Alarm recognition of “Signal Overflow Alarm”
[G32: Alm-Emp Pipe] Alarm recognition of “Empty Pipe alarm”
[G33: Alm-HH/LL] Alarm recognition of “HH/LL Alarm” (Refer to the descriptions of G12 and G13 for more details regarding HH and LL alarms.)
[G34: Alm-Adhesion] Alarm recognition of “Adhe­sion Alarm”
[G41: Alm Record1] Alarm record1
[G43: Alm Record2] Alarm record2
[G45: Alm Record3] Alarm record3
[G47: Alm Record4] Alarm record4
Alarm
output
Closed
(On)
Open
(Off)
Open
(Off)
4-20 mA
output
0mA or
(*)
25mA
Fixed
(G21 selection)
Totali-
Pulse Display unit
zation
Normal Normal
Indeter­mination
Stopped Stopped Recorded
Display Mode No
Stopped Indetermination
Alarm Mode
(display of system
alarm message)
Alarm
record
Indeter­mination
T0646.EPS
(2) Display and output condition for process alarms
Alarm
description
30
Sig Overflow
31
Empty Pipe
32
HH/LL Alm
33
Adhesion Alm
Note: • Alarm is output only when F20: DO Function or F21: DIO Function is set to “Alarm Output.”
• The operation when “Open (Off) Act” is set for F22: DO Active Mode or “Open/Open Act“ is set for F23: DIO Active Mode is shown in above table.
• 4-20mA output upon the occurrence of an alarm will be fixed at the value selected with G21: 4-20mA Alarm Out.
*: Although outputs are continuous, output values are not guaranteed.
Input signal error
Flowtube is not filled with fluid
HH/LL Alarm
Electrode adhesion alarm
Selection
(parameter
number)
YES
(G31)
NO
(G31)
YES
(G32)
NO
(G32)
YES
(G33)
NO
(G33)
YES
(G34)
NO
(G34)
Alarm
output
Open
(Off)
Closed
(On)
Open
(Off)
Closed
(On)
Open
(Off)
Closed
(On)
Open
(Off)
Closed
(On)
4-20 mA
output
Fixed
Continu-
ous (*)
Fixed
Continu-
ous (*)
Normal
operation
Fixed
Continu-
ous (*)
6-36
Totali­zation
Stopped
Continu-
ous (*)
Stopped
Continu-
ous (*)
Normal
operation
Stopped
Continu-
ous (*)
Pulse
output
Stopped
Continu-
ous (*)
Stopped
Continu-
ous (*)
Normal
operation
Stopped
Continu-
ous (*)
Display
unit
Alarm Mode
(Message)
Display Mode
Alarm Mode
(Message)
Display Mode
Alarm Mode
(Message)
Display Mode
Alarm Mode
(Message)
Display Mode
IM 01E20C02-01E
Alarm
record
Recorded
No
Recorded
No
No
Recorded
No
T0647.EPS
6. PARAMETER DESCRIPTION
(3) Display and output condition for setting alarm occurrences
Selection
Alarm description
(parameter
number)
50
Span > 10m/s
51
Span < 0.1m/s
52
TTL>10000p/s
53
TTL<0.0001p/s
54
4-20 Lmt Err
55
Multi Rng Err
56
H/L HH/LL Set
57
Dens Set Err
60
PLS >10000p/s
61
PLS > 5000p/s
62
PLS > 1000p/s
63
PLS > 500p/s
64
PLS > 25p/s
65
PLS > 15p/s
66
PLS > 10p/s
67
PLS > 5p/s
70
PLS<0.0001p/s
71
Meas Mod Set
72
Size Set Err
73
Adh Set Err
Occurring of any alarm from 50 through 73
Span flow velocity setting is 11 m/s or more
Span flow velocity setting is 0.05 m/s or less
Totalization rate is 11000 pps or more
Totalization rate is
0.00005 pps or less
The condition [4-20 low limit (J11) < 4-20 high limit (J12)] is not satisfied.
The condition [No. 1 range < No. 2 range < No. 3 range < No. 4 range] is not satisfied for multiple ranges.
The condition [High Alarm (G11) – Low Alarm (G10) > H/L Alarm Hys (G14)] or the condition [High High Alarm (G13) – Low Low Alarm (G12) > H/L Alarm Hys (G14)] is not satisfied.
Mass units have been selected for Base Flow Unit (C40) but density is set to 0.
Pulse rate is 11000 pps or more with 50% duty selection.
Pulse rate is 10000 pps or more with 0.05 ms selection.
Pulse
rate
is 5000 pps or
more with 0.1 ms selection.
Pulse
rate
is 1000 pps or
more with 0.5 ms selection.
Pulse rate is 500 pps or more with 1 ms selection.
Pulse
rate
is 25 pps or
more with 20 ms selection.
Pulse
rate
is 15 pps or
more with 33 ms selection.
Pulse
rate
is 10 pps or
more with 50 ms selection.
Pulse
rate
is 5 pps or
more with 100 ms selection.
Pulse rate is 0.00005 pps or less.
Measure Mode (C20) is set to Enhanced DF without selecting an optional code HF1 or HF2.
A value of 3000.1 mm or more is set for Nominal Size (C32).
The condition [Level:1< Level:2<Level:3<Level:4] is not satisfied for adhesion diagnostic level.
(G30)
(G30)
Note: • Alarm is output only when F20: DO Function or F21: DIO Function is set to “Alarm Output.”
• The operation when “Open (Off) Act” is set for F22: DO Active Mode or “Open/Open Act“ is set for F23: DIO Active Mode is shown in above table.
• 4-20mA output upon the occurrence of an alarm will be fixed at the value selected with G21: 4-20mA Alarm Out.
NO
YES
Alarm
4-20 mA
output
output
Closed
Fixed Stopped Stopped
(On)
Normal
Closed
operation
(On)
Closed
Fixed
(On)
Closed
Fixed Stopped Stopped
(On)
Closed
Normal
(On)
operation
Closed
Fixed Stopped Stopped
(On)
Closed
Normal
(On)
operation
Closed
Fixed Stopped Stopped
(On)
Closed
Fixed Stopped Stopped
(On)
Normal
Closed
operation
(On)
Open
Fixed Stopped Stopped
(Off)
Totali­zation
Stopped
Normal
operation
Normal
operation
Normal
operation
Normal
operation
Pulse
output
Normal
operation
Normal
operation
Normal
operation
Stopped
Normal
operation
Display
unit
Alarm Mode
(message)
Alarm Mode
(message)
Alarm Mode
(message)
Alarm Mode
(message)
Alarm Mode
(message)
Alarm Mode
(message)
Alarm Mode
(message)
Alarm Mode
(message)
Alarm Mode
(message)
Alarm Mode
(message)
Alarm Mode
(message)
Alarm record
No
No
No
No
No
No
No
No
No
No
No
T0648.EPS
6-37
IM 01E20C02-01E

6.5.3 Alarms & Warning Messages

System Alarms (Device breakdown or inability to obtain correct measurements.)
Display unit/BRAIN (60) content
10:uP Fault
11:EEPROM Fault
12:A/D(H) Fault
13:A/D(L) Fault
14:A/D(Z) Fault
15:Coil Open
16:EEPROM Dflt
Process Alarms (Device is normal but process-related errors make correct measurement impossible.)
Display unit/BRAIN (60) content
30:Sig Overflow
31:Empty Pipe
32:HH/LL Alm
33:Adhesion Alm
Alarm countermeasure message on display unit
Contact nearest office or service center
Contact nearest office or service center
Contact nearest office or service center
Contact nearest office or service center
Contact nearest office or service center
Cut the power and check coil & EX cable
Contact nearest office or service center
Alarm countermeasure message on display unit
Check signal cable and grounding
Fill flow tube with fluid
Check the flow rate and setting value
Clean electrodes
6. PARAMETER DESCRIPTION
Alarm description Countermeasure
Microprocessor (CPU) failure
EEPROM failure
Contact your nearest Yokogawa office or service center.
A/D converter failure
Turn off the AXFA14 power supply and examine the excitation cable for breakage. If there is no breakage, contact your
Flowtube coil is open-circuit
EEPROM default values
Alarm description Countermeasure
Input signal error
Flowtube is not filled with fluid
Flow rate alarm for greater than High-High limit value or less than Low-Low limit value.
Electrode adhesion alarm Clean the electrodes.
nearest Yokogawa office or service center. In case of the AXF integral flowmeter, the excitation cable cannot be examined. Contact your nearest Yokogawa office or service center.
Contact your nearest Yokogawa office or service center.
Carry out an investigation as follows:
Check the signal cable for breakage.
Check for contact between signal cable,
power cable, and excitation cable.
Check for stray currents in the fluid.
Check the grounding.
Fill the flowtube with fluid.
Check the flow rate and setting value of High High limit and Low Low limit.
T0649.EPS
T0650.EPS
6-38
IM 01E20C02-01E
6. PARAMETER DESCRIPTION
Setting Alarms (Device is normal but errors have been made in the setting of parameters.)
Display unit/BRAIN (60) content
50:Span > 10m/s
51:Span < 0.1m/s
52:TTL>10000p/s
53:TTL<0.0001p/s
54:4-20 Lmt Err
55:Multi Rng Err
56:H/L HH/LL Set
57:Dens Set Err
60:PLS > 10000p/s
61:PLS > 5000p/s
62:PLS > 1000p/s
63:PLS > 500p/s
64:PLS > 25p/s
65:PLS > 15p/s
66:PLS > 10p/s
67:PLS > 5p/s
70:PLS<0.0001p/s
71:Meas Mod Set Check parameter C20
72: Size Set Err Check parameter C32
73: Adh Set Err Check parameter K11 to K14
Alarm countermeasure message on display unit
Check parameter C40, C41, and C42
Check parameter C40, C41, and C42
Check parameter D10 and D11
Check parameter D10 and D11
Check parameter J11and J12
Check parameter F30 to F34
Check parameter G10 to G14
Check parameter C40, C45, and C46
Check parameter E10, E11, and E12
Check parameter E10, E11, and E12
Check parameter E10, E11, and E12
Check parameter E10, E11, and E12
Check parameter E10, E11, and E12
Check parameter E10, E11, and E12
Check parameter E10, E11, and E12
Check parameter E10, E11, and E12
Check parameter E10, E11, and E12
Alarm description Countermeasure
Span flow velocity setting is 11 m/s or more
Span flow velocity setting is 0.05 m/s or less
Totalization rate is 11000 pps or more
Totalization rate is 0.00005 pps or less
The condition [4-20 low limit (J11) < 4-20 high limit (J12)] is not satisfied.
The condition [No. 1 range < No. 2 range < No. 3 range < No. 4 range] is not satisfied for multiple ranges.
The condition [High Alarm (G11) – Low Alarm (G10) > H/L Alarm Hys (G14)] or the condition [High High Alarm (G13) – Low Low Alarm (G12) > H/L Alarm Hys (G14)] is not satisfied.
Mass units have been selected for Base Flow Unit (C40) but density is set to 0.
Pulse rate is 11000 pps or more with 50% duty selection. Pulse rate is 10000 pps or more with
0.05 ms selection.
Pulse rate is 5000 pps or more with
0.1 ms selection.
Pulse rate is 1000 pps or more with
0.5 ms selection.
Pulse rate is 500 pps or more with 1 ms selection.
Pulse rate is 25 pps or more with 20 ms selection.
Pulse rate is 15 pps or more with 33 ms selection.
Pulse rate is 10 pps or more with 50 ms selection.
Pulse rate is 5 pps or more with 100 ms selection.
Pulse rate is 0.00005 pps or less.
Measure Mode (C20) is set to Enhanced DF without selecting an optional code HF1 or HF2.
A value of 3000.1 mm or more is set for Nominal Size (C32).
The condition in Adhesion detection level, Level:1<Level:2<Level:3<Level:4 is not satisfied.
Check whether parameters C40, C41, and C42 are correct. In case that multiple range or forward and reverse flow measurement functions is used, check whether parameters F30 through F34 are correct.
Check whether parameters D10 and D11 are correct.
Check whether parameters J11 and J12 are correct.
Check whether parameters F30 through F34 are correct.
Check whether parameters G10 through G14 are correct.
Check whether parameters C40, C45, and C46 are correct.
Check whether parameters E10, E11, and E12 are correct.
Check whether parameter C20 is correct.
Check whether parameter C32 is correct.
Check whether parameters K11, K12, K13 and K14 are correct.
T0651.EPS
Setting Alarms (Device and measurements are normal but a warning is issued.)
Display unit/BRAIN (60) content
80:Adhesion Wng
82:Auto Zero Wng
83:Fix Cur Wng The current value is fixed.
84:Disp Over Wng (only for display unit)
90:Disp SW Wng (only for display unit)
Alarm countermeasure message on display unit
Alarm description Countermeasure
Slight adhesion to electrodes.
Results of automatic zero adjustment are higher than the rated values.
Overflow in the display digits during instantaneous flow rate display.
Display unit switches are not operating.
Clean and check the electrodes. Refer to parameter K13.
Carry out adjustment as follows:
Check if the flowtube is filled with
fluid.
Check if the flow velocity is
completely zero.
Check the condition of grounding.
Confirm whether the flow rate is in excess of the upper limit (108%) or below the lower limit (-8%), or whether upon entry to the Test Mode or not.
Check whether parameter C43 is correct.
Investigate whether the display unit cover is fitted or whether the cover’s glass surface is dirty.
6-39
T0652.EPS
IM 01E20C02-01E
6.6 Precautions for the
NOTE
NOTE
6. PARAMETER DESCRIPTION
AXF Integral Flow­meter
Although the AXF integral flowmeter’s software configurations are the same as the AXFA14, care must be taken in setting the following parameters:
[C31: Nominal Size Unit] Setting of the nominal size units
[C32: Nominal Size] Setting of the nominal size
NOTE
The nominal size unit, nominal size and meter factor have been properly set upon shipment from the manufacturing plant. Do not change these parameters.
[C21: Low MF] Setting of the low-frequency meter factor [C22: High MF] Setting of the high-frequency meter factor [C23: Low MF (EDF)] Setting of the low-frequency meter factor for enhanced DF (i.e., enhanced dual frequency excitation) [C24: High MF (EDF)] Setting of the high-frequency meter factor for enhanced DF (i.e., enhanced dual frequency excitation)
Setting the meter factor
Meter factors for the AXF integral flowmeter
0038
F0623.EPS
(1) Confirm that the meter factors indicated on
your AXF integral flowmeter’s data plate has been set to the parameters.
(2) The meter factors are crucial in ensuring that
the electromotive force is correctly in propor­tion to the flow velocity and are determined at the manufacturing plant by actual-flow calibration.
For the hardware configuration of the AXF integral flowmeter, see the user’s manual of the AXF Integral Flowmeter [Hardware Edition] (IM 01E20D01-01E).
6-40
IM 01E20C02-01E

7. OPERATION VIA BRAIN TERMINAL (BT200)

7.
OPERATION VIA BRAIN TERMINAL (BT200)
NOTE
This chapter describes the AXFA14 converter as an example. The same attention must be paid to the AXF integral flowmeter.
7.1 BT200 Basic Opera­tions

7.1.1 Key Layout and Display

LCD (21 characters 8 lines)

7.1.2 Key Descriptions

(1) Alphanumeric keys and shift keys
You can use the alphanumeric keys in conjunction with the shift keys to enter letters, digits, and symbols.
Alphanumeric keys
Shift keys
a) Entering digits, symbols, and spaces [i.e., 0-
9, period (.), hyphen (-), underscore (_)]
Simply press the required alphanumeric key.
Entry
–4
Key-in sequence
F0703.EPS
Movement keys
Select items
Move the cursor
Change pages
Power ON/OFF key
Alphanumeric keys
Enter digits
Enter letters in
combination with the shift keys.
Figure 7.1 Key Layout
Menu Screen
MENU A:DISPLAY B:EASY SETUP C:BASIC SETUP D:TOTAL SET
Screen titles
E:PULSE SET F:STATUS FUNC
HOME SET ADJ ESC
Parameter Screen
PARAMETER A10:FLOW RATE(
80.0 A20:FLOW RATE 100m3/h A21:FLW RATE(mA) 1417
DATA DIAG PRNT ESC
Function keys
Used to execute commands displayed at the bottom of the screen. (See Table 7.1.)
ENT key
Enters selected
items
Sets up input data
on the connected instrument.
Runs BT200
functions.
Shift keys
If BATTERY is displayed on the screen, it indicates that the battery voltage has dropped.
BATTERY
%
)
%
Messages
Menu choices (up to six are displayed)
Function commands
Parameters (up to three are displayed)
Function commands
F0701.EPS
0.3
1 –9
b) Entering letters (i.e., A through Z)
Press an alphanumeric key following a shift key to enter the letter shown on the same side as the shift key. The shift key must be pressed for each letter being input.
Left-side letter on an alphanumeric key
Entry Key-in sequence
W
IC
J. B
Right-side letter on an alphanumeric key
T0701.EPS
F0704.EPS
T0702.EPS
F0702.EPS
7-1
IM 01E20C02-01E
7. OPERATION VIA BRAIN TERMINAL (BT200)
Use the function key [F2]
CAPS
to select between uppercase and lowercase (for letters only). The case toggles between uppercase and lowercase each time you press [F2] CAPS.
Entering uppercase
CODE CAPS CLR ESC
Entry
Boy
( B ) ( y )( o )
Use the function key [F1]
Entering lowercase
CODE caps CLR ESC
Key-in Sequence
to lower case
CODE
to enter symbols. The
F0807.EPS
following symbols will appear in sequence, one at a time, at the cursor each time you press [F1] CODE:
/ . – , + * ) ( ’ & % $ # ” ! To enter characters next to these symbols, press [ > ] to move the cursor.
Entry
symbol command
l/m
Key-in Sequence
( / )
( m )( I )
T0803.EPS
Function Command List
Command Function
ADJ Displays the ADJ menu
CAPS/caps
CODE
CLR
DATA
DEL
DIAG
ESC
HOME
NO OK
PARM
SET
SLOT
UTIL *COPY *FEED
*LIST
*PON/POFF
*PRNT
*GO
*STOP
* Available on BT200-P00 (with printer).
Selects uppercase or lowercase Selects symbols Erases input data or deletes all data Updates parameter data Deletes one character Calls the self-check panel Returns to the most recent display Displays the menu panel Quits setup and returns to the previous display Proceeds to the next panel Enters the parameter number setup mode Displays the SET menu Returns to the slot selection panel Calls the utility panel Prints out parameters on display Paper feed Lists all parameters in the menu Automatic printout mode on or off Changes to the print mode Starts printing Cancels printing
T0804.EPS
(2) Function Keys
The functions of the function keys depend on the function commands on display.
MENU A:DISPLAY B:EASY SETUP C:BASIC SETUP D:TOTAL SET E:PULSE SET F:STATUS FUNC
HOME SET ADJ ESC
Function commands
Function keys
F0808.EPS
7-2
IM 01E20C02-01E
7. OPERATION VIA BRAIN TERMINAL (BT200)
t
NOTE

7.2 AXFA14 Operation Using a BT200

This section describes procedures for setting parameters using a BRAIN Terminal (BT200). For more details regarding AXFA14 functions, refer to Chapter 6: Parameter Description; and for more details regarding BT200 operation methods, refer to the BT200 User’s Manual (IM 01C00A11-01E).

7.2.1 BT200 Connection

Connection to a 4 to 20 mA DC signal line
The communication signal is superimposed onto the 4 to 20 mA DC analog signals to be transmitted.
AXFA14 terminals
G
EXCITATION
SIGNAL
1 N/
EX
2
C
SA
A
B
SB
L/
+ + – + – + –
I
I
POWER SUPPLY
CURRENT OUTPUT
I
DO
DIO
Relaying terminals
4 to 20 mA DC signal transmission line
Control room
Te r minal board
Receiving instrumen
Refer to Chapter 6 “Menu P: Parameter Protec­tion Items” and section “10.2.2” how to use the write protect function in detail.
IMPORTANT
Restrictions exist with regard to the distance over which communication is possible. (See Chapter 11: Outline.)
IMPORTANT
If the power of flowmeter is turned off within 30 seconds after parameters have been set, these settings will be canceled. Accordingly, please keep the power on for at least 30 seconds after setting parameters.
IMPORTANT
After approximately 5 minutes of inactivity, the Auto Power-Off function will operate to turn your BT200 off.
Receiving resistance: 250 to 450
BT200
Figure 7.2 Connecting the BT200
BT200
BT200
F0705.EPS
WARNING
Be sure to set parameters as “Protect” on the write protect function after finish of parameter setting work. Under extremely rare case, the infra-red switches may respond unexpectedly in such conditions as sticking ball of water or extraneous substances on the surface of display panel glass according to the principle of infra-red switch operation. Its probability rises in such cases as sticking rain water by storm or other similar situation and washing up work near flowmeter installation place. Either to illuminate or stop illuminating the infra­red switches by the flashlight may cause the mis-reaction.
In case of BT200, the parameters are displayed in English only. Even if the language with the exception of English is selected at B10/H30: Language, the param­eters are displayed in English upon BT200.

7.2.2 The data update and upload/ download function of BT200

(1) The data update of BT200
When the following parameters are displayed, the measured data is updated automatically every seven seconds.
7-3
Item
A10 A20 A21 A30 A31
A32 C44 G22 G40 G41
Name (BRAIN)
FLOW RATE (%) FLOW RATE FLW RATE (mA) TOTAL REV TOTAL DIF TOTAL VELOCITY CHK 4-20 BURNOUT OPERATE TIME ALM RECORD1
Item
G42 G43 G44 G45 G46 G47 G48 N32 P20 P23
Name (BRAIN)
ALM TIME 1 ALM RECORD2 ALM TIME 2 ALM RECORD3 ALM TIME 3 ALM RECORD4 ALM TIME 4 TEST DIO (I) W PROTECT SOFT SEAL
IM 01E20C02-01E
T0704.EPS
(2) Upload/download function of BT200
NOTE
Upload function is used when the parameters of one AXFA14 are copied to the BT200. And download function is used when the parameters copied to the BT200 are set to another AXFA14. For details, refer to BT200 User’s Manual (IM 01C00A11-01E). The targeted parameters for upload and download are following.
Item
C11/B20
C31
C32 C40/B21 C41/B22 C42/B23 C43/B24
Name (BRAIN)
FLOW DAMPING SIZE UNIT NOMINAL SIZE FLOW UNIT TIME UNIT FLOW SPAN FLOW DECIMAL
Item
D10/B30 D11/B31 E10/B32 E11/B33 H10/B40 H11/B41 H12/B42
Name (BRAIN)
TOTAL UNIT TOTAL SCALE PULSE UNIT PULSE SCALE DISP SELECT1 DISP SELECT2 DISP SELECT3
T0705.EPS

7.2.3 BT200 Screens & Flow Rate Data Display

Use the following procedure to display flow rate data on the BT200.
• The display of flow rate data is updated every 5 seconds.
–––WELCOME––– BRAIN Terminal ID:BT200
Check cable connection and press the Ent key.
UNTIL FEED
When the BT200 is turned on, the message “Please wait ...” is displayed for several seconds, and then the screen on the left is shown.
Press the key.
7. OPERATION VIA BRAIN TERMINAL (BT200)
MENU A:DISPLAY B:EASY SETUP C:BASIC SETUP D:TOTAL SET E:PULSE SET F:STATUS FUNC
HOME SET ADJ ESC
PARAMETER A10:FLOW RATE(
80.0 A20:FLOW RATE 100m3/h A21:FLW RATE(mA)
16.800mA
DATA DIAG PRNT ESC
%
)
%
The Menu Screen (Major Item Parameter Search Mode) will be displayed.
If the key is pressed while A: DISPLAY
is selected by the highlight bar, the Parameter Screen (Sub-Item Parameter Search Mode) will be displayed.
( )
ESC
The Flow Rate Screen will be displayed. A maximum of three items of data can be displayed.
The or key can be used to move
the cursor up and down. (Note that the key can be used to move the
cursor to the top of the next screen.
Press the to return to Menu Screen
(Major Item Parameter Search Mode).
( ) key
ESC
F0706-02.EPS

7.3 Parameter Setting Using a BT200

This section describes the procedure for setting of parametes using a BT200.
PARAMETER 01:MODEL AXFA11-A00 02:TAG NO FI-1101 03:SELF CHECK GOOD
OK
Press the key to display initial data as shown on the left.
The tag number specified upon ordering is found here.
Press the ( )or key.
or
OK
F0706-01.EPS
IMPORTANT
If the power of flowmeter is turned off within 30 seconds after parameters have been set, these settings will be canceled. Accordingly, please keep the power on for at least 30 seconds after setting parameters.
Before updating any setting, remember to always check the data content you want to change as described in Chapter 6: Parameter Description.
7-4
IM 01E20C02-01E
7. OPERATION VIA BRAIN TERMINAL (BT200)

7.3.1 BT200 Setting of Selection-Type Data: Flow rate units

In this example, the flow rate units specified by the selection-type parameter B21: Flow Unit are changed from m to l (Liter).
3
MENU A:DISPLAY B:EASY SETUP C:BASIC SETUP D:TOTAL SET E:PULSE SET F:STATUS FUNC
HOME SET ADJ ESC
MENU A:DISPLAY B:EASY SETUP C:BASIC SETUP D:TOTAL SET E:PULSE SET F:STATUS FUNC
HOME SET ADJ ESC
PARAMETER B10:LANGUAGE English B20:FLOW DAMPING
3.0s B21:FLOW UNIT m3
DATA DIAG PRNT ESC
PARAMETER B10:LANGUAGE English B20:FLOW DAMPING
3.0s B21:FLOW UNIT m3
DATA DIAG PRNT ESC
When Menu Screen (Major Item Parameter Search Mode) has been entered as shown here, press the
key to move to B: EASY SETUP.
When the cursor has been moved to B: EASY SETUP,
press the key to access Parameter Screen
(Sub-Item Parameter Search Mode).
Press the key twice to move the cursor to
B21: FLOW UNIT.
X 2
After moving the cursor to B21: FLOW UNIT, press
the key to access Setting Screen (Parameter
Replacement Mode).
SETTING B21:FLOW UNIT m3 < m3 > < kl(Kiloliter)> < l(Liter) > < cm3 >
ESC
SETTING B21:FLOW UNIT m3 l(Liter)
PRINTER OFF F2:PRINTER ON
FEED POFF NO
SETTING B21:FLOW UNIT l(Liter)
FEED NO OK
With the cursor aligned with “l (Liter)”, press the
key.
When selected, “l (Liter)” will begin to flash on and
off: Press the key once again to confirm
your selection. In case of cancel, press the
NO
( ) key.
The units for flow rate have been changed to l (Liter).
Press ( ) key to
OK
exit Setting Screen (Parameter Replacement
Mode), and then the display returns to Parameter Screen (Sub-Item Parameter Search Mode) of Menu B items. In case of redo of setting,
press the ( ) key
NO
to return the Setting Screen (Parameter Replacement Mode).
OK
( )
SETTING B21:FLOW UNIT m3 < m3 > < kl(Kiloliter)> < l(Liter) > < cm3 >
ESC
Press the key twice to move the cursor to
“l (Liter)”.
X 2
7-5
PARAMETER B10:LANGUAGE English B20:FLOW DAMPING
3.0s B21:FLOW UNIT l(Liter)
DATA DIAG PRNT ESC
The changed setting for units can now be confirmed.
Press the ( ) key
ESC
to return to Menu Screen (Major Item Parameter Search Mode).
F0707.EPS
IM 01E20C02-01E
7. OPERATION VIA BRAIN TERMINAL (BT200)

7.3.2 BT200 Setting of Numeric-Type Data: Flow rate span

In this example, the flow rate span specified by the numeric-type parameter B23: Flow Span is changed from
100.000 l/min. to 120.000 l/m.
MENU A:DISPLAY B:EASY SETUP C:BASIC SETUP D:TOTAL SET E:PULSE SET F:STATUS FUNC
HOME SET ADJ ESC
MENU A:DISPLAY B:EASY SETUP C:BASIC SETUP D:TOTAL SET E:PULSE SET F:STATUS FUNC
HOME SET ADJ ESC
PARAMETER B10:LANGUAGE English B20:FLOW DAMPING
3.0s B21:FLOW UNIT l(Liter)
DATA DIAG PRNT ESC
PARAMETER B22:TIME UNIT /min B23:FLOW SPAN
100.000l/min B24:FLOW DECIMAL l
DATA DIAG PRNT ESC
SETTING B23:FLOW SPAN
100.000l/min + 0
When Menu Screen (Major Item Parameter Search Mode) has been entered as shown here, press the
key to move to B: EASY SETUP.
When the cursor has been moved to B: EASY SETUP.
Press the key to access Parameter Screen
(Sub-Item Parameter Search Mode).
In the parameter list, the parameter for setting of flow rate span is B23: FLOW
SPAN. Press the key four times to move the
cousor to B23. (Note that the key can be used to move the
cursor to the top of the next screen.
or
After moving the cursor to B23: FLOW SPAN, press
the key to access Setting Screen (Parameter
Replacement Mode).
In this mode, new values can be entered into the highlighted field using the alphanumeric keys.
SETTING B23:FLOW SPAN
100.000l/min + 120
DEL CLR ESC
SETTING B23:FLOW SPAN
100.000l/min + 120
PRINTER OFF F2:PRINTER ON
FEED POFF NO
SETTING B23:FLOW SPAN
120.000l/min
FEED NO OK
PARAMETER B22:TIME UNIT /min B23:FLOW SPAN
120.000l/min B24:FLOW DECIMAL l
DATA DIAG PRNT ESC
In this example, the value “120” is entered, press the
key.
The data will begin to flash on and off: Press the
key once again to confirm your entry.
In case of cancel, press the ( ) key.
NO
The value for flow span has been changed to “120.000 l/min.”
Press ( ) key to
OK
exit Setting Screen (Parameter Replacement
Mode), and then the display returns to Parameter Screen (Sub-Item Parameter Search Mode) of Menu B items. In case of redo of setting,
press the ( ) key to return the Setting Screen
(Parameter Replacement Mode).
OK
( )
The changed setting for flow rate span can now be confirmed.
Press the ( ) key
ESC
to return to Menu Screen (Major Item Parameter Search Mode).
NO
F0708.EPS
DEL CLR ESC
7-6
IM 01E20C02-01E
7. OPERATION VIA BRAIN TERMINAL (BT200)

7.3.3 BT200 Setting of Alphanumeric-Type Data: Tag number

In this example, the tag number specified by the alphanumeric-type parameter C10: TAG NO is changed from “FI-1101” to “FI-1201”.
MENU A:DISPLAY B:EASY SETUP C:BASIC SETUP D:TOTAL SET E:PULSE SET F:STATUS FUNC
HOME SET ADJ ESC
MENU A:DISPLAY B:EASY SETUP C:BASIC SETUP D:TOTAL SET E:PULSE SET F:STATUS FUNC
HOME SET ADJ ESC
PARAMETER C10:TAG NO FI-1101 C11:FLOW DAMPING
3.0s C20:MEASURE MODE Standard DF
DATA DIAG PRNT ESC
When Menu Screen (Major Item Parameter Search Mode) has been entered as shown here, press the
key twice to move to C: BASIC SETUP.
When the cursor has been moved to C: BASIC SETUP,
press the key to access Parameter Screen
(Sub-Item Parameter Search Mode).
The cursor will already be aligned with C10: TAG NO.
Press the key to access Setting Screen
(Parameter Replacement Mode).
SETTING C10:TAG NO FI-1101 FI-1201
FEED POFF NO
SETTING C10:TAG NO FI-1201
FEED NO OK
The highlighted data will begin to flash on and off:
Press the key once again to confirm your
entry. In case of cancel, press the
( ) key.
NO
The tag number has been changed to “FI-1201”.
Press ( ) key to
OK
exit Setting Screen (Parameter Replacement
Mode), and then the display returns to Parameter Screen (Sub-Item Parameter Search Mode) of Menu C items. In case of redo of setting,
press the ( ) key
NO
to return the Setting Screen (Parameter Replacement Mode).
( )
OK
SETTING C10:TAG NO FI-1101 FI-1101
CODE CAPS CLR ESC
SETTING C10:TAG NO FI-1101 FI-1201
CODE CAPS CLR ESC
An underscore (small cursor) will start to flash on and off at the furthest left character in the tag number as displayed in the data­overwrite section.
Press the key four times to move the flashing
underscore (small cursor) to the position for multiples of
100.
X 4
When the flashing under­score (small cursor) has been moved to the position for multiples of 100, use the alphanumeric keys to enter the value “2”. (When this value has been entered, the underscore will move to the position for multiples of 10.) When the tag number has been corrected to “FI-1201” in this way, press the
key.
PARAMETER C10:TAG NO FI-1201 C11:FLOW DAMPING
3.0s C20:MEASURE MODE Standard DF
DATA DIAG PRNT ESC
The changed setting for tag number can now be confirmed.
Press the ( ) key
ESC
to return to Menu Screen (Major Item Rarameter Search Mode).
F0709.EPS
7-7
IM 01E20C02-01E

8. OPERATION VIA HART COMMUNICATOR

8.
This chapter describes the AXFA14 as an example.
Note: HART is a registered trademark of the HART
OPERATION VIA HART COMMUNICATOR
NOTE
Communication Foundation.
8.1 Matching of instru­ment (AXFA14) DD and HART Configura­tion Tool’s DD
Before using the HART Configuration Tool (such as FieldMate), confirm that the DD (Device Description) of the AXFA14 is installed in the Configuration Tool before using. About the DD, use the device type, device revision and DD Revision shown in follows.
2. Confirmation of the device revision for the HART Configuration Tool
(1) Turn on the power of the Configuration Tool
under the standalone condition. (2) Confirm the installed DD revision in accor-
dance with the procedure of the Configuration Tool. Refer to its manual how to confirm it in detail. The first 2 digits of the DD file are expressed the device revision, and its last 2 digits are expressed the DD revision.
01 03.XXX
DD revision Device revision
F0801.EPS
Model Name DTM Name Device Type Device
AXFA14 AXFA14
V1.1
The DD revisions for AXFA14 and Configuration Tool’s can confirm in accordance with the following steps. If the correct DD is not installed in the HART Con­figuration Tool, download them from the official HART programming sites, otherwise, contact the respective vendors of the Configuration Tool for its upgrade information.
1. Confirmation of the device revision for AXFA14
(1) Connect the Configuration Tool to the
AXFA14. The device revision can be checked as follows.
DD Device Setup Review → Review4
Fld dev rev
DTM Confi guration HART Fld dev rev
AXFA14 (0x0052)
Revision
2
T0801.EPS
T0802.EPS
8-1
IM 01E20C02-01E
8. OPERATION VIA HART COMMUNICATOR
NOTE
NOTE

8.2 Interconnection between AXFA14 and HART Configuration Tool

The HART Configuration Tool can interface with the AXFA14 from the control room, the AXFA14 site, or any other wiring termination point in the loop, provided there is a minimum load resistance of 250 V between the connection and the receiving instrument. To communicate, it must be connected in parallel with the AXFA14, and the connections must be non-polarized. Figure 8.2.1 illustrates the wiring connections for a direct interface at the AXFA14 site. The HART Configuration Tool can be used for remote access from any terminal strip as well.
G
EXCITATION
SIGNAL
1 N/
EX
2
C
SA
A
B
SB
POWER SUPPLY
L/
+
CURRENT OUTPUT
+
I
– +
DO
– +
DIO
I + I -
AXFA14
4 to 20 mA DC signal line
+
Relaying
terminals
FieldMate
Figure 8.2.1 Interconnection Diagram
WARNING
Be sure to set parameters as “Protect” on the write protect function after finish of parameter setting work. Under extremely rare case, the infra-red switches may respond unexpectedly in such conditions as sticking ball of water or extraneous substances on the surface of display panel glass according to the principle of infra-red switch operation. Its probability rises in such cases as sticking rain water by storm or other similar situation and washing up work near flowmeter installation place. Either to illuminate or stop illuminating the infra­red switches by the flashlight may cause the mis-reaction. Refer to Chapter 6 “Menu P: Parameter Protec­tion Items” and section “10.2.2” how to use the write protect function in detail. This menu in the 275 is located at [Hot key] → [2 Wrt Protect Menu].
USB
modem
USB
PC/FieldMate
Control room
Te r minal board
Receiving instrument load resistance:
250 to 600 (including cable resistance)
F0802.EPS
IMPORTANT
If the power of flowmeter is turned off within 30 seconds after parameters have been set, these settings will be canceled. Accordingly, please keep the power on for at least 30 seconds after setting parameters.
Before updating any setting, remember to always check the data content you want to change as described in Chapter 6: Parameter Description.
In case of HART Configuration, the parameters are displayed in English only. Even if the language with the exception of English is selected at “Language” setting display, the parameters are displayed in English upon HART Configuration Tool.
8-2
IM 01E20C02-01E
8. OPERATION VIA HART COMMUNICATOR
NOTE

8.3 Basic Setup

Tag and Device Information
The tag number and device information can be checked as follows:
• The location for the tag number and device
information
(DD)
Tag Device Setup Detailed Setup
Basic setup Ta g
Descriptor Device Setup Detailed Setup
→ Device info → Field device info → Descriptor
Message Device Setup Detailed Setup
→ Device info → Field device info → Message
Date Device Setup Detailed Setup
→ Device info → Field device info → Date
T0803.EPS
(DTM)
Tag Easy Setup Ta g
or Confi guration HART Tag
Descriptor Confi guration → Device infomation
Descriptor
Message Confi guration → Device infomation
Message
Date Confi guration → Device infomation
Date
T0804.EPS
When changing the tag number or device information, enter the information directly within the following limitations.

8.4 Parameters

8.4.1 Parameter configuration

The parameter structure of the HART configuration tool is hierarchical.
Refer to 8.4.6, Menu Tree Example for the correspond­ing parameters. The menu tree shows a cross-reference of the parameters for HART and BRAIN.
See “Chapter 6 Parameter Description” for the func­tions of parameters.
Note that some display parameters of AXFA14 are different from those of HART configuration tools.

8.4.2 Data Renewing

There are two methods to load the AXFA14 data from/to HART Configuration Tool --- periodic data renewing and discretionary data renewing. Refer to the
8.4.6 menu tree for each corresponding parameter.
(1) Periodic Data Renewing
The data is updated 0.5 to 2 second cycles. The parameter of this type is marked as “P” in the 8.4.6 menu tree.
(2) Discretionary Data Renewing
The data can be loaded from/to the AXFA14 when the data save is finished to the Configuration Tool. The parameter of this type is marked as “u/d” in the 8.4.6 menu tree.
Item Number and characters
Tag 8
Descriptor 16
Message 32
Date 2/2/2 (mm/dd/yy)
• mm : month
• dd : day
• yy : year
T0805.EPS
The AXFA14 is not able to set parameters via its display unit during a communication of the HART Configuration Tool.
8-3
IM 01E20C02-01E
8. OPERATION VIA HART COMMUNICATOR

8.4.3 Self-diagnostic

The self-diagnostic function of the AXFA14 is ex­plained in Section 6.5 “Alarm Functions.” The HART configuration tool can be used to run self-diagnostics on a device and check for incorrect data settings.
(1) Using DD
The Self test and Status commands are available for self-diagnostics. When Self test is run, the display unit shows an error code and alarm message if the device detects any illegal parameter settings or functional faults.
• Procedure to call up the Self test display
Device Setup → Diag/Service Test → Self test
If no error is detected, “Self test OK” is displayed on the configuration tool. If the specific diagnostic item is known for the check, you can directly call up the item by using the Status command. The status is categorized from 1 to 7. Show an example below to confirm the status of Status group 1.
• Procedure to call up the Status display
Device Setup → Diag/Service → Status → Status group 1
If no error is detected, “Off” is displayed on the configuration tool. If there is an error, “On” is displayed on the configura­tion tool, and a countermeasure for that error is necessary.
Example of display: Span > 10 m/s On Span < 0.3 m/s Off TTL > 10000 p/s Off TTL < 0.0001 p/s Off 4-20 Lmt Err Off
The HART configuration tool diagnoses at each communication. When an improper operation is performed, the error message is displayed.
(2) Using DTM
The Device Status commands are used for self-diagnostics. When Device Status is run, the display unit shows an error code and alarm message if the AXFA14 detects any illegal parameter settings or functional faults.
If no error is detected, “Status: Normal” is displayed on the configuration tool. If the specific diagnostic item is known for the check, you can directly call up the item by using the Diagnos­tic List in the Device Status display. The Diagnostic List is categorized to Device Status, Hardware Failure, Transducer Status, Diag Status, and Configuration. If no error is detected, color symbol which shows Normal State is displayed on top of the error message. If color symbol which shows Error State is displayed, there is an error and a countermeasure for that error is necessary.
The HART configuration tool diagnoses at each communication. When an improper operation is performed, the error message is displayed.

8.4.4 HART Specific Functions

Trim Analog Output
This function is used to adjust the analog output at 4 mA and 20 mA with the D/A trim or Scaled D/A trim.
(1) D/A trim
Connect a calibration digital ammeter, and then enter the read value of the ammeter for each output of AXFA14.
• Procedure to call up the D/A trim display
DD Device Setup → Diagnosis/Service
Adjustment → D/A trim
DTM Calibration D/A trim
T0808.EPS
(2) Scaled D/A trim
The output is adjusted by using a voltmeter or other types of meters with 0 to 100% scale. Example using a voltmeter:
4 mA DC 1 V 20 mA DC 5 V
Connect this meter, and enter the read value of the meter for each output of AXFA14.
• Procedure to call up the Scaled D/A trim display
DD Device Setup Diagnosis/Service
Calibration Analog output trim Scaled D/A trim
DTM Calibration Scaled D/A trim
T0809.EPS
• Procedure to call up the Device Status display
Device Status
8-4
IM 01E20C02-01E
8. OPERATION VIA HART COMMUNICATOR
IMPORTANT
The D/A trim should be executed only at single range mode. If the D/A trim is executed at Bi direction mode, it is possible that the current output becomes 108%.
IMPORTANT
When “D/A trim” or “Scaled D/A trim” is carried out, the warning message “83: Fix Cur Wng” is displayed on the display unit.
CAUTION
The output adjustment function can match the 4mA and 20mA output to the reference meter such as a voltmeter. In the output adjustment, it is necessary to use the calibrated voltmeter and resistance.
Fixed Current Output
This feature can be used to output a fixed current for loop checks.
In the case of using DD
Call up the test output parameter (Loop test) and select the output signal.
• Procedure to call up the display
DD Device Setup Diagnosis/Service
Test → Loop test →
4mA Output a 4mA DC signal 20mA Output a 20mA DC signal Other Set a desired output signal value End Exit
T0806.EPS
In the case of using DTM
Call up the test output parameter (Loop test) and select either manual test or auto test, and set the current value.
• Procedure to call up the display
DTM Diag and Service → Output Test
Loop test
Manual Test Set the current value or % value at
Test output value, then click the Start button.
Auto Test Set the interval and rate of change of
current output at Auto Test Setting, then click the Start button.
T0807.EPS
Burst Mode
AXFA14 continuously sends the data via HART communication when the burst mode is set on (any one of PV, % range/current, or process vars/crnt). The data is sent intermittently as a digital signal at 3 times a second. The burst mode is set as follows.
(1) Setting the data to be sent
• Procedure to call up the display
DD Device Setup Detailed setup
HART output → Burst option
DTM Confi guration HART Burst option
T0810.EPS
Select the type of data to be sent from the following
options:
- Instantaneous flow rate (PV)
- Output in % and current output (% range/current)
- Instantaneous flow rate, totalization value* and
current output (Process vars/crnt)
* “Totl,” “Reverse Totl” or “Dif Totl”
(2) Setting the burst mode
• Procedure to call up the display
DD Device Setup Detailed setup
HART output → Burst mode
DTM Confi guration HART Burst mode
T0811.EPS
Then, select “On” at the menu to start the burst
mode.
To release from the burst mode, call up the burst
mode display, and set to “Off.”
The default setting is “Off.”
Multidrop Mode
When set in the multidrop mode, up to 15 field devices in a single communications line can be connected. To activate multidrop communication, the address of the field devices must be set to a number from 1 to 15. This deactivates the 4 to 20 mA analog output, fixing it to 4 mA. Burn out is also disabled. Note that the accuracy for multidrop mode is different from that for other modes. Refer to Chapter 11: Outline. The multidrop mode is set as follows.
(1) Setting the polling address
• Procedure to call up the display
DD (HART 5) Device Setup → Detailed setup
Output condition → HART output
DTM (HART 5) Confi guration → HART Poll addr Enter the number from 1 to 15
T0812.EPS
8-5
IM 01E20C02-01E
(2) Activating the multidrop mode
About the procedure to call up the Polling display, please refer to the User’s Manual of each configu­ration tool.
NOTE
When the same polling address is assigned for two or more field devices in multidrop mode, communication with these field devices is disabled.
(3) Communication when set in the multidrop mode
1. The HART configuration tool searches a field device that is set in the multidrop mode when the HART configuration tool is turned on. When the HART configuration tool is connected to the field device, the polling address and the tag will be displayed.
2. Select the field device, and then communication with it is possible. The communication speed is slow in this case.
3. To communicate with another field device, turn off the power once and then turn it back on, or call up “Online” menu, and select “Online.” The polling address and the tag will appear. Select the field device.
(4) Release of the multidrop mode
Call up the “Poll addr” display, and set the address to “0.”
8. OPERATION VIA HART COMMUNICATOR

8.4.5 Other operations for the HART configuration tool

Regarding other operations for the HART configura­tion tool, refer to the HART configuration tool opera­tions manual.
8-6
IM 01E20C02-01E

8.4.6 Menu Tree for DD (HART 5)

8. OPERATION VIA HART COMMUNICATOR
Offline
Online Frequency Utility
1 Device setup
New Configuration Saved Configuration
1. Device setup
2. PV
3. PV AO
4. PV Span
1 Process Variables PV % rnge
2 Diag/Service
PV PV AO Totl Reverse Totl Dif Totl
1 Test/Status
2 Adjustment
1 Status
2 Self test
1 Auto Zero Exe 2 Magflow Zero 3 D/A trim 4 Scaled D/A trim
Status group 1(System alarms) Status group 3(Process alarms) Status group 5(Setting alarms) Status group 6(Setting alarms) Status group 7(Setting alarms) Status group 8(Warnings)
Read/Write
R R R R R R
R R R R R R
W
W
R/W
W W
Parameter
of BRAIN
protocol
A10 A20 A21 A30 A31 A32
See Section 6.5 “Alarm Functions”
M10/B50
Data(*1)
––
M11
– –
P P P P P P
– – – – – –
– – – –
3 Easy Setup
3 Output Test
4 Diagnosis
1 Language 2 PV Damping 3 Base Flow Unit 4 Base Time Unit 5 PV Span 6 Flow Decimal Pnt 7 Total Unit 8 Total Scale 9 Pulse Unit Pulse Scale Display Select1 Display Select2 Display Select3 Auto Zero Exe
1 Loop test 4mA
2 Test Mode 3 Test DO 4 Test DIO (O) 5 Test DIO (I)
1 Adhesion Check 2 Adhesion Level1 3 Adhesion Level2 4 Adhesion Level3 5 Adhesion Level4 6
Adh Measure Value
20mA Other End
W W W
R
W W W W W
R
W W W W W W W W W W W W W W
W
N10 N30 N31 N32
K10 K11 K12 K13 K14 K15
B10/H30 B20/C11 B21/C40 B22/C41 B23/C42 B24/C43 B30/D10 B31/D11 B32/E10 B33/E11 B40/H10 B41/H11 B42/H12
B50/M10
– – –
P
– – – – – –
u/d u/d u/d u/d u/d u/d u/d u/d u/d u/d u/d u/d u/d
(continued on next page)
8-7
F0803.EPS
IM 01E20C02-01E
8. OPERATION VIA HART COMMUNICATOR
Parameter
Read/Write
of BRAIN
protocol
Data(*1)
4 Detailed Setup 1 Basic Setup
2 Total
1 Tag 2 PV Damping
3 MF Set
4 Nominal Size unit 5 Nominal Size 6 Base Flow Unit 7 Base Time Unit 8 PV Span 9 Flow Decimal Pnt Velocity Check Density Unit Mass Flow Density User Span Select Flow User Unit Flow User Span
1 Total Unit 2 Total Scale 3 Total Decimal Pnt 4 Total Low Cut 5 Total Execution 6 Ttl Set Val Lower 7 Ttl Set Val Upper 8 Ttl Switch Lower 9 Ttl Switch Upper Ttl User Select Ttl User Unit
Standard DF
Enhanced DF
Low MF High MF
Low MF (EDF) High MF (EDF)
W W
W
W W
W W W
W W W W W W W W W W W
W W W W W W
W W W W W
R
C10
C11/B20
C20 C21
C22
C20 C23 C24
C31
C32 C40/B21 C41/B22 C42/B23 C43/B24
C44
C45
C46
C47
C48
C49
D10/B30 D11/B31
D12
D13
D20
D21
D22
D23
D24
D30
D31
u/d u/d
– –
– – –
u/d u/d u/d u/d u/d u/d
P u/d u/d u/d u/d u/d
u/d u/d u/d u/d u/d u/d u/d u/d u/d u/d u/d
3 Pulse 1 Pulse Unit
4 Function Set 1 Status Function 1 DO Function
(continued on next page)
2 Pulse Scale 3 Pulse Width 4 Pulse Low Cut
2 DIO Function 3 DO Active Mode 4 DIO Active Mode 5 Forward Span2 6 Forward Span3 7 Forward Span4 8 Reverse Span1 9 Reverse Span2 Auto Range Hys Bi Direction Hys
2 Alarm 1 Low Alarm
2 High Alarm 3 Low Low Alarm 4 High High Alarm 5 H/L Alarm Hys 6 4-20 Alarm Out 7 4-20 Burn Out 8 Alm-Setting 9 Alm-Sig Over Alm-Emp Pipe Alm-HH/LL Alm-Adhesion
W
E10/B32
W
E11/B33
W
E12
W
E13
W W W W W W W W W W W
W W W W W W
W W W W W
F20 F21 F22 F23 F30 F31 F32 F33 F34 F40 F41
G10 G11 G12 G13 G14 G21
R
G22 G30 G31 G32 G33 G34
u/d u/d u/d u/d
u/d u/d u/d u/d u/d u/d u/d u/d u/d u/d u/d
u/d u/d u/d u/d u/d u/d
u/d u/d u/d u/d u/d
F0804.EPS
8-8
IM 01E20C02-01E
8. OPERATION VIA HART COMMUNICATOR
Parameter
of BRAIN
protocol
Data(*1)
Read/Write
4 Detailed setup
4 Function Set
3 Alm Record 1 Operation Time
4 Display Set 1 Display Select1
5 Aux
2 Alm Record1 3 Alm Record Time1 4 Alm Record2 5 Alm Record Time2 6 Alm Record3 7 Alm Record Time3 8 Alm Record4 9 Alm Record Time4
2 Display Select2 3 Display Select3 4 Display Cycle 5 Language
1 4-20mA Low Cut 2 4-20mA Low Lmt 3 4-20mA High Lmt 4 Flow Direction 5 Rate Limit 6 Dead Time 7 Pulsing Flow 8 T/P Damp Select 9 Power Synch Power Frequency Memo 1 Memo 2 Memo 3 Software Rev No
R R R R R R R R R
W W W W W
W W W W W W W W W
R/W
W W W
R
G40 G41 G42 G43 G44 G45 G46 G47 G48
H10/B40 H11/B41 H12/B42
H20
H30/B10
J10 J11 J12 J20 J21 J22 J23 J24 J30 J31 J40 J41 J42 J50
P P P P P P P P P
u/d u/d u/d u/d u/d
u/d u/d u/d u/d
P
5 HART output
6 Device info 1 Field device info
(continued on next page)
1 Poll addr 2 Num req preams 3 Burst mode 4 Burst option
2 Model specific
1 PV 2 % range/current 3 Process vars/crnt
1 Manufacturer 2 Tag 3 Descriptor 4 Message 5 Date 6 Dev id 7 Write protect 8 Revision #'s
1 Use 2 Lining 3 Electrode Material 4 Electrode Struct 5 Grounding Ring 6 Process Connect 7 Lay Length 8 Electrical Conn 9 Sensor Serial No
1 Universal rev 2 Fld dev rev 3 Software rev
W
R W W W W
R W W W W
R
R
R
R
R
W W W W W W W W W
– – – – – –
– – – – – – – – – –
– – – – – – – – –
– – – – – –
– u/d u/d u/d u/d
P
F0805.EPS
8-9
IM 01E20C02-01E
8. OPERATION VIA HART COMMUNICATOR
Parameter
Read/Write
of BRAIN
protocol
Data(*1)
5 Review
1 Review1
2 Review2
3 Review3
4 Review4
Hot key 1 PV Span
*1 : Data Renewing
P : Periodic Date Renewing
u/d : Discretionary Renewing
– : Other (Method etc...)
2 Wrt Protect Menu
1 Write protect 2 Enable Wrt 10min 3 New Password 4 Software Seal
R R R R
W
R W W
R
– – – –
B23/C42
P20 P21 P22 P23
– – – –
u/d
P – – –
F0806.EPS
8-10
IM 01E20C02-01E
8. OPERATION VIA HART COMMUNICATOR
Review 1
Ta g
PV Damping
Measure Mode
Low MF
High MF
Low MF(EDF)
High MF(EDF)
Nominal Size unit
Nominal Size
Base Flow Unit
Base Time Unit
PV Span
Flow Decimal Pnt
Velocity Check
Density Unit
Mass Flow Density
User Span Select
Flow User Unit
Flow User Span
Total Unit
Total Scale
Total Decimal Pnt
Total Low Cut
Total Execution
Ttl Set Val Lower
Ttl Set Val Upper
Ttl Switch Lower
Ttl Switch Upper
Ttl User Select
Ttl User Unit
Pulse Unit
Pulse Scale
Pulse Width
Pulse Low Cut
Review 2
DO Function
DIO Function
DO Active Mode
DIO Active Mode
Forward Span2
Forward Span3
Forward Span4
Reverse Span1
Reverse Span2
Auto Range Hys
Bi Direction Hys
Low Alarm
High Alarm
Low Low Alarm
High High Alarm
H/L Alarm Hys
4-20 Alarm Out
4-20 Burn Out
Alm-Setting
Alm-Sig Over
Alm-Emp Pipe
Alm-HH/LL
Alm-Adhesion
Operation Time
Alm Record1
Alm Record Time1
Alm Record2
Alm Record Time2
Alm Record3
Alm Record Time3
Alm Record4
Alm Record Time4
Review 3
Display Select1
Display Select2
Display Select3
Display Cycle
Language
4-20mA Low Cut
4-20mA Low Lmt
4-20mA High Lmt
Flow Direction
Rate Limit
Dead Time
Pulsing Flow
T/P Damp Select
Power Synch
Power Frequency
Memo1
Memo2
Memo3
Software Rev No
Use
Lining
Electrode Material
Electrode Struct
Grounding Ring
Process Connect
Lay Length
Electrical Conn
Sensor Serial No
Adhesion Check
Adhesion Level1
Adhesion Level2
Adhesion Level3
Adhesion Level4
Adh Measure Value
Review 4
Poll addr
Num req preams
Burst mode
Burst option
Manufacturer
Ta g
Descriptor
Message
Date
Dev id
Write protect
Universal rev
Fld dev rev
Software rev
Status 1
uP Fault
EEPROM Fault
A/D(H) Fault
A/D(L) Fault
A/D(Z) Fault
Coil Open
EEPROM Dflt
Status 6
PLS>10000p/s
PLS > 5000p/s
PLS > 1000p/s
PLS > 500p/s
PLS > 25p/s
PLS > 15p/s
PLS > 10p/s
PLS > 5p/s
Status 3
Sig Overflow
Empty Pipe
HH/LL Alm
Adhesion Alm
Status 7
PLS<0.0001p/s
Meas Mod Set
Size Set Err
Adh Set Err
Status 5
Span > 10m/s
Span < 0.1m/s
TTL>10000p/s
TTL<0.0001p/s
4-20 Lmt Err
Multi Rng Err
H/L HH/LL Set
Dens Set Err
Status 8
Adhesion Wng
Auto Zero Wng
Fix Cur Wng
8-11
F0807.EPS
IM 01E20C02-01E

8.4.7 Menu Tree for DTM (HART 5)

Root Menu
Process Variables Device Status Diag and Service Easy Setup Configuration Calibration Write Protect
A
Process Variables
PV PV % rnge PV AO PV Span PV Damping Totl Reverse Totl Dif Totl
A B C D E F G
8. OPERATION VIA HART COMMUNICATOR
Read/Write
R R R R R R R R
Parameter
of BRAIN
protocol
A20 A10 A21 B23
C11/B20
A30 A31 A32
Data
Renewing
(*1)
P P P P P P P P
B
Device Status Process Variable
Diagnostic List
PV PV % rnge Totl Reverse Totl Dif Totl
Device Status Hardware Failure Tr ansducer Status Configuration Warning
F0808.EPS
8-12
IM 01E20C02-01E
8. OPERATION VIA HART COMMUNICATOR
C
Diag and Service
Output Test
Loop test Test Mode Test DO Test DIO (I) Test DIO (O)
Alarm Set Low Alarm
High Alarm Low Low
Alarm High High Alarm H/L Alarm Hys 4-20mA Alarm Out 4-20mA Burn Out Alm-Setting Alm-Sig Over Alm-Emp Pipe Alm-HH/LL Alm-Adhesion
Alarm Record Operation Time
Alm Record1 Alm Record Time1 Alm Record2 Alm Record Time2 Alm Record3 Alm Record Time3 Alm Record4 Alm Record Time4
Read/Write
– W W
R
W
W W W W W W R W W W W
R
R
R
R
R
R
R
R
R
Parameter
of BRAIN
protocol
– N10 N30 N32 N31
G10 G11 G12 G13 G14 G21 G22 G30 G31 G32 G33 G34W u/d
G40 G41 G42 G43 G44 G45 G46 G47 G48
Data
Renewing
(*1)
– – – P –
u/d u/d u/d u/d u/d u/d
– u/d u/d u/d u/d
P
P
P
P
P
P
P
P
P
D
Easy Setup
Adhesion
Ta g Language PV Damping Base Flow Unit Base Time Unit PV Span Flow Decimal Pnt Total Unit Total Scale Pulse Unit Pulse Scale Display Select1 Display Select2 Display Select3 Auto Zero Exe
Adhesion Check Adhesion Level1 Adhesion Level2 Adhesion Level3 Adhesion Level4 Adh Measure Value
K10
W
K11
W
K12
W
K13
W
K14
W
K15
R
W
C10
W
B10/H30
W
B20/C11
W
B21/C40
W
B22/C41
W
B23/C42
W
B24/C43
W
B30/D10
W
B31/D11
W
B32/E10
W
B33/E11
W
B40/H10
W
B41/H11
W
B42/H12
u/d u/d u/d u/d u/d u/d u/d u/d u/d u/d u/d u/d u/d u/d
F0809.EPS
8-13
IM 01E20C02-01E
8. OPERATION VIA HART COMMUNICATOR
E
Configuration
Characterize Meter
Flow Condition
Total Set
Nominal Size Unit Nominal Size Measure Mode Low MF High MF Low MF (EDF) High MF (EDF) MF Set
PV Damping Base Flow Unit Base Time Unit PV Span Flow Decimal Pnt User Span Select Flow User Unit Flow User Span Velocity Check Density Unit Mass Flow Density
Total Unit Total Scale Total Decimal Pnt Total Low Cut Total Execution Ttl Set Val Lower Ttl Set Val Upper Ttl Switch Lower Ttl Switch Upper Ttl User Select Ttl User Unit
Read/Write
W W
R R R R R
W W W W W W W W
R W W
W
W
W
W
W
W
W
W
W
W
W
Parameter
of BRAIN
protocol
C31 C32 C20 C21 C22 C23 C24
C11/B20 C40/B21 C41/B22 C42/B23 C43/B24
C44 C45 C46 C47 C48 C49
D10/B30 D11/B31
D12 D13 D20 D21 D22 D23 D24 D30 D31
Data
Renewing
(*1)
u/d u/d
– – – – – –
u/d u/d u/d u/d u/d
P u/d u/d u/d u/d u/d
u/d u/d u/d u/d u/d u/d u/d u/d u/d u/d u/d
Pulse Set
Status Function DO Function
(continued on next page)
Pulse Unit Pulse Scale Pulse Low Cut Pulse Width
DIO Function DO Active Mode DIO Active Mode Auto Range Hys Bi Direction Hys Forward Span2 Forward Span3 Forward Span4 Reverse Span1 Reverse Span2
W W W W
W W W W W W W W W W W
E10/B32 E11/B33
E13 E12
F20 F21 F22 F23 F40 F41 F30 F31 F32 F33 F34
u/d u/d u/d u/d
u/d u/d u/d u/d u/d u/d u/d u/d u/d u/d u/d
F0810.EPS
8-14
IM 01E20C02-01E
8. OPERATION VIA HART COMMUNICATOR
Configuration
Display Set Display Select1
Display Select2 Display Select3 Display Cycle Language
Aux
4-20mA Low Cut 4-20mA Low Lmt 4-20mA High Lmt Flow Direction Rate Limit Dead Time Pulsing Flow T/P Damp Select Power Synch Power Frequency Memo 1 Memo 2 Memo 3 Software Rev No
Model Specification
Use Lining Electrode Material Electrode Struct Grounding Ring Process Connect Lay Length Electrical Conn Sensor Serial No
Read/Write
W W W W W
W W W W W W W W W
R/W
W W W
R
W W W W W W W W W
Parameter
of BRAIN
protocol
H10/B40 H11/B41 H12/B42
H20
H30/B10
J10 J11 J12 J20 J21 J22 J23 J24 J30 J31 J40 J41 J42 J50
– – – – – – – – –
Data
Renewing
(*1)
u/d u/d u/d u/d u/d
u/d u/d u/d u/d
P
Device Information
HART
Model Manufacturer Hardware rev Software rev Descriptor Message Date Final asmbly num
Ta g Poll addr Dev id Universal rev Fld dev rev Num req preams Physical signl code Burst mode Burst option
R R R
R W W W W
W W
R
R
R
R
R W W
– – – – – – – –
– – – – – – – – –
– – – – – – – –
u/d
– – – – – – – –
F0811.EPS
8-15
IM 01E20C02-01E
8. OPERATION VIA HART COMMUNICATOR
F
Calibration
G
Write Protect
Auto Zero Exe Magflow Zero D/A trim Scaled D/A trim
Write protect Enable Wrt Password New Password Software Seal
*1: Data Renewing
P : Periodic Data Renewing
u/d
: Discretionary Data Renewing
– : Others (Method, etc...)
Read/Write
R/W
R
W W
R
Parameter
of BRAIN
protocol
M10/B50
M11
– –
P20 P21 P22
P23
Data
Renewing
(*1)
– – – –
P
– – –
F0812.EPS
8-16
IM 01E20C02-01E
9. ACTUAL OPERATION
After you have installed the flowtube into the process piping, wired the input/output terminals, set up the required parameters, and performed a pre-operation zero adjustment, the magnetic flowmeter should output an accurate flow signal from its terminals as soon as flow of the fluid to be measured begins. This section describes zero adjustment and the corresponding procedures.
For F
OUNDATION Fieldbus protocol, please refer to IM
01E20F02-01E.
For PROFIBUS PA protocol, please refer to IM 01E20F12-01E.
9.1 Pre-operation Zero

9. ACTUAL OPERATION

Adjustment
Zero adjustment is carried out to ensure that the output for zero flow is 0% (i.e., 4 mA). Although adjustment to zero is performed at the manufacturing plant prior to shipment, this procedure must be carried out once again following the installation of piping in order to match the magnetic flowmeter to its operating condi­tions.
This section describes the zero adjustment procedure using display unit switches from the converter and using the external status input; accordingly, one of these methods should be selected and implemented.
IMPORTANT
• Zero adjustment should be carried out before actual operation. Note that setting and update functions cannot be carried out during this procedure (i.e., for approximately 30 seconds).
• Zero adjustment should only be carried out when the flowtube has been filled with measurement fluid and the fluid velocity is completely zero by closing the valve.
• Each time that the fluid being measured is changed, it will be necessary for zero adjust­ment to be carried out for the new fluid.
9-1
IM 01E20C02-01E

9.1.1 Zero Adjustment Using Display Unit Switches

This section describes the procedure for zero adjustment using the display unit switches. (For more details regarding setting methods using these switches, refer to Chapter 5: Basic Operating Procedures.)
The parameters for zero adjustment are B50/M10: Auto Zero Exe (and either of these can be used to carry out this procedure). For more details regarding these parameters, refer to Chapter 6: Parameter Description.
The parameter M10: Auto Zero Exe will be used in the following description.
Start:
Major Item Parameter
Search Mode
Once in Setting Mode, use the switch to move the cursor to M: Adjustment.
9. ACTUAL OPERATION
Sub-item
Parameter
Search Mode
Parameter
Replacement
(execute) Mode
Setting Mode
Major item
parameter
Major item
Sub-item
selection (D)
Setting Mode
K:Diagnosis
M:Adjustment
N:Test
M:Adjustment
10:Auto Zero Exe
11:Magflow Zero
M10:Auto Zero Exe No Execution
No Execution
Execution
M10:Auto Zero Exe No Execution
Execution
No Execution
Touch the switch to access Sub-item
Parameter Search Mode.
Upon selection of M: Adjustment, the cursor will be positioned at M10: Auto Zero Exe. (Sub-item selection (D))
Touch the switch to access Parameter
Replacement Mode.
Touch the switch to move the cursor to
“Execution”.
Touch the switch to select the “Execution”.
M10:Auto Zero Exe
Execution
In order to request confirmation, the entire display
flashes on and off. Touch the switch once
again at this time to fix selection of the automatic zero adjustment function.
NOTE
When no operations are carried out for 20 seconds in the flashing state, the system will automatically return to the Sub-item Parameter Search Mode.
When the operations except are carried out, the parameter cannot be set.
9-2
IM 01E20C02-01E
9. ACTUAL OPERATION
Auto zero adjustment function is being executed
Sub-item
Parameter
Search Mode
Major item
Sub-item
selection (D)
Now Auto Zero
Executing...
M:Adjustment
10:Auto Zero Exe
11:Magflow Zero
F0901.EPS
(about 30 seconds).
When zero adjustment function has been completed, the system automatically returns to the sub-item selection screen (D).
The results of M10: Auto Zero Exe can be displayed using M11: Magflow Zero. Alterna­tively, if the results of the automatic zero adjustment exceed the rated value, the warn­ing 82: Auto Zero Wng will be displayed.

9.1.2 Zero Adjustment via External Status Input

This section describes the procedure for zero adjustment via external status input. (For more details regarding external status input, refer to Chapter 6: Parameter Description.)
NOTE
Start:
Major Item Parameter
Search Mode
Sub-item
Parameter
Search Mode
CAUTION
In certain cases where the multiple range function is being used with other status inputs, it may not be possible to perform settings for automatic zero adjustment. For more details, refer to the description of multiple ranges from Chapter 6: Parameter Description.
In order to carry out zero adjustment via external status input, it will be necessary to set “Ext Auto Zero (I)” using F21: DIO Function. The following describes the setting procedure:
Once in Setting Mode, use the switch to move the cursor to F: Status Function.
Setting Mode
Major item
parameter
Major item
Sub-item
parameter
Setting Mode
E:Pulse Set
F:Status Function
G:Alarm
F:Status Function
41:Bi Direction Hys
20:DO Function
21:DIO Function
Touch the switch to access Sub-item
Parameter Search Mode.
Touch the switch once to move the cursor to F21: DIO Function.
Major item
Sub-item
selection (E)
F:Status Function
20:DO Function
21:DIO Function
22:DO Active Mode
The cursor has been moved to F21: DIO Function in this screen. (Sub-item selection screen (E))
Touch the switch to access Parameter
Replacement Mode.
9-3
IM 01E20C02-01E
9. ACTUAL OPERATION
Parameter
Replacement
(execute) Mode
F21:DIO Function No Function
No Function
Alarm Output
F21:DIO Function No Function
Ext Auto Zero (I)
Ext Ttl Preset (I)
F21:DIO Function
Ext Auto Zero (I)
X1
Touch the switch twelve times to move the
cursor to “Ext Auto Zero (I)”.
2
Touch the
switch to select “Ext Auto Zero
(Zero adjustment via external status input)”.
In order to request confirmation, the entire display
flashes on and off. Touch the
switch once
again at this time to fix selection of the automatic zero adjustment function.
NOTE
When no operations are carried out for 20 seconds in the flashing state, the system will automatically return to the Sub-item Parameter Search Mode.
When the operations except are carried out, the parameter cannot be set.
Sub-item
Parameter
Search Mode
Major item
Sub-item
selection (E)
F:Status Function
20:DO Function
21:DIO Function
22:DO Active Mode
F0902-2.EPS
The system automatically returns to sub-item selection screen (E).
Zero adjustment will be started if the DIO terminals are shorted (when the active mode has been set to “Closed/Short Act” using F23: DIO Active Mode).
This process will end after approximately 30 seconds.
Now Auto Zero
Executing...
F0902-3.EPS
NOTE
Auto zero adjustment function is being executed. (about 30 seconds.)
When the DIO terminals continue to be shorted, this zero adjustment is automati­cally repeated.
9-4
IM 01E20C02-01E
10. MAINTENANCE

10. MAINTENANCE

10.1 Maintenance

WARNING
• Maintenance work must be carried out by the trained personnel having knowledge of safety standard and not by operators.
• When opening the cover, wait for more than 10 minutes after turning off the power. Further­more, opening of the cover must also be carried out by the trained personnel having knowledge of safety standard.
CAUTION
• Explosion protected type must be, as a rule, removed to a non-hazardous area for mainte­nance and be disassembled and reassembled to the original state.
• The display cover is locked by the special screw. In case of opening the display cover, use the hexagonal wrench attached.
• Be sure to lock the cover by the special screw using the hexagonal wrench attached after installing the cover.

10.1.1 Fuse Replacement

CAUTION
Please contact Yokogawa's service office for fuse replacement. Also be sure to use the fuse that was supplied by Yokogawa’s sales or service offices.

10.1.2 Changing the Direction of the Display Unit

10.1.2.1 Removing the Cover
(1) Turn off the power.
(2) Loosen cover locking screw 1 clockwise using a
hexagonal wrench (nominal size 3) to unlock the cover. (Upon shipment from the manufacturing plant, the cover is locked.) Hold the flowmeter with your hand and remove the cover by turning it in the direction of the arrow as shown below.
IMPORTANT
• As a rule, maintenance of this flowmeter should be implemented in a maintenance service shop where the necessary tools are provided.
• The amplifier assembly contains sensitive parts that may be damaged by static electricity. Excercise care so as not to directly touch the electronic parts or circuit patterns on the board, for example, by preventing static electrification by using grounded wrist straps when handing the assembly.
Cover locking screws
Figure 10.1.1 Removing the Display Cover
10-1
F1002.EPS
IM 01E20C02-01E
10. MAINTENANCE
10.1.2.2 Changing the Display Unit Direction 90 Degrees
(1) Hold the display unit with your hand and remove
the two mounting screws.
(2) Turn the display unit 90 degrees clockwise and
confirm the assembling position, taking care of the connector and wire of the display unit. At this time, do not remove the connector.
(3) Secure the display unit using its two mounting
screws.
*1
Display unit mounting screws (two screws)
10.1.2.3 Installing the Cover
(1) Taking care not to entangle the cables, install the
cover to the flowmeter by turning it in the direc­tion of the arrow as shown below.
(2) Tighten cover locking screw 1 counterclockwise
using a hexagonal wrench (nominal size 3) to lock the cover.
Cover locking screws
F1005.EPS
Figure 10.1.3 Installing the Display Cover
Clockwise 90°
Figure 10.1.2 Changing the Display Unit Direction 90
Degrees
F1004.EPS
IMPORTANT
*1: To preserve the safety, do not touch the electrical circuit and cable of shaded area.
10-2
IM 01E20C02-01E
10. MAINTENANCE
NOTE

10.2 Setting of Switches

IMPORTANT
•Removing and installing cover are necessary for setting switches. Perform removing and installing of the cover as described in section
10.1.2.1 and 10.1.2.3.
• To preserve the safety, do not touch the electrical circuit and the cables except the setting switches.

10.2.1 Setting of Burnout Switch

The burnout function sets the direction of current output in situations where the CPU has become damaged. Upon shipment from the manufacturing plant, the burnout direction is set to High (i.e., 25 mA); however, in cases where the optional code C1 has been specified, the output direction will be set to Low (i.e., 0 mA).
Modification of the burnout direction must be carried out using the setting switch from the amplifier’s CPU board (i.e., Switch 1) (See Figure 10.2.1).
Low High
Switch 1 Switch 2
Enable Protect
Figure 10.2.1 Switch Configuration
2 Burnout setting switch 1 Write protect setting switch
F1007.EPS

10.2.2 Setting of Write Protect Switch

By setting the write protect function to “Protect” it is possible to prevent the overwriting of parameters. Write protection can be carried out using either the hardware switch on the CPU board (i.e., Switch 2) or software parameter settings. If either of these items is set to “Protect,” the overwriting of parameters will be prohibited.
Table 10.2.1 Output Setting Pins for Burnout
Position of
Pin
Low High
Low High
NOTE
Burnout Direction
High
Low
Burnout
Output
25 mA
0 mA
Remarks
Set to High before shipment
Set to Low for optional code C1
• On the amplifier’s CPU board, the burnout
setting switch (i.e., Switch 1) and the write protect switch (i.e., Switch 2) are located adjacent to each other. Accordingly, special care should be taken when making switch settings.
• In the case of Fieldbus communication type,
burnout setting swich is not applied.
T1001.EPS
• If the hardware switch is set to “Protect,” it will not be possible to overwrite parameters; furthermore, this condition will be maintained until the switch is set to “Enable.”
• In the case of Fieldbus communication type, write protect setting switch is always be set as “Enable”.
For more details regarding usage of the write protect function and the software’s parameter switches, refer to “Chapter 6: Parameter Description” in this user’s manual.
10-3
IM 01E20C02-01E

10.3 Troubleshooting

Although magnetic flowmeters rarely require maintenance, failures may occur when the instrument is not operated correctly. This section describes troubleshooting procedures where the cause of the breakdown is identified through receiver indication.

10.3.1 No Indication

START
Is an error being displayed? Check the converter display.
10. MAINTENANCE
Is an error being
displayed?
NO
Is anything else
being displayed?
YES
Does the
arrow on the tube match the
flow direction?
YES
Check whether the flowtube is filled with fluid.
Is the flowtube
full of fluid?
YES
Check the resistance between the flowtube’s A, B, and C terminals using a multimeter.
YES
NO
NO
NO
Examine in accordance with Section 6.5: Alarms.
Perform either of the following: a. Reinstall the flowtube in
order to make the arrow and flow direction match.
b. Reverse the setting for the
flow direction.
Change the piping or the mounting condition so that the tube fills with the fluid.
resistance 100 M or more
Remove the tube and inspect the inside of the pipe.
Remove the foreign matter.
Is the
in each case?
YES
Is foreign
matter adhering to
the walls?
YES
NO
NO
10-4
Contact a service center.
F1008.EPS
IM 01E20C02-01E
Loading...
