Yamato Scientific RT200 User Manual

p

Organic Solvent Recovery Unit

Model

RT200

Instruction Manual

- First Edition -

 Thank you for purchasing "Organic Solvent

Recovery Unit, RT200" of Yamato Scientific Co.,
Ltd.

 To use this unit properly, read this "Instruction

Manual" thoroughly before using this unit.
Keep this instruction manual around this unit for
referring at anytime.

WARNING!:

Carefully read and thoroughly understand the

ortant warning items described in this

im

Yamato Scientific Co. LTD.

Contents

 Cautions in Using with Safety................................................................1

Explanation.................................................................................................................... 1

•

•

Table of Illustrated Symbols .......................................................................................... 2

Fundamental Matters of "WARNING!" and "CAUTION!"............................................... 3

•

 Before Using This Unit ...........................................................................4

Requirements for Installation......................................................................................... 4

•

 Description and Function of Each Part.................................................5

Main Unit .......................................................................................................................5

•

 Installation ...............................................................................................6

 Handling Precautions .............................................................................7

 Maintenance Method...............................................................................7

Daily Inspection and Maintenance ................................................................................ 7

•

 Long storage and disposal.....................................................................8

When not using this unit for long term / When disposing .............................................. 8

•

 Trouble Shooting .....................................................................................8

 After Service and Warranty ....................................................................9

 Specification..........................................................................................10

 Piping Diagram......................................................................................10

 Replacement Parts Table......................................................................11

 Reference...............................................................................................12

List of Dangerous Substances .................................................................................... 12

•

Explanation

Illustrated Symbols

Various symbols are used in this safety manual in order to use the unit without
danger of injury and damage of the unit. A list of problems caused by ignoring
the warnings and improper handling is divided as shown below.Be sure that you
understand the warnings and cautions in this manual before operating the unit.

Cautions in Using with Safety

MEANING OF ILLUSTRATED SYMBOLS

WARNING!
CAUTION!

If the warning is ignored, there is the danger of a problem that
may cause a serious accident or even fatality.

If the caution is ignored, there is the danger of a problem that may
cause injury/damage to property or the unit itself.

Meaning of Symbols

This symbol indicates items that urge the warning (including the caution).
A detailed warning message is shown adjacent to the symbol.

This symbol indicates items that are strictly prohibited.
A detailed message is shown adjacent to the symbol with specific actions not to
perform.

This symbol indicates items that should be always performed.
A detailed message with instructions is shown adjacent to the symbol.

1

Table of Illustrated Symbols

Warning

Cautions in Using with Safety

Warning,
generally

Caution

Caution,

generally

Caution,

water only

Warning,

high voltage

Caution,

electrical shock

Caution,

deadly poison

Warning,

high temperature

Caution,

Warning,

drive train

Caution,

scald

no road heating

Warning,

explosive

Caution,

not to drench

Prohibit

Prohibit,

generally

Compulsion

Compulsion,

generally

inflammable

Compulsion,

connect to the

Prohibit,

grounding

terminal

to disassemble

Compulsion,

install on a flat

Prohibit,

surface

Prohibit,

to touch

Compulsion,

disconnect the

power plug

Compulsion,

periodical

inspection

2

Cautions in Using with Safety

Fundamental Matters of "WARNING!" and "CAUTION!"

WARNING!

Do not use this unit in an area where there is flammable or explosive gas

Never use this unit in an area where there is flammable or explosive gas. This unit is not explosion-proof.
An arc may be generated when the power switch is turned on or off, and fire/explosion may result. (Refer to
page 12 "List of Dangerous Substances".)

Substances that can not be used

Never use explosive substances, flammable substances and substances that include explosive or flammable
ingredients in this unit. Explosion or fire may occur. (Refer to page 12 "List of Dangerous Substances".)

Do not disassemble or modify this unit

Do not disassemble or modify this unit. Fire or electrical shock or failure may be caused.

CAUTION!

Choose a proper place for installation

• Do not install this unit in a place where:

♦ Rough or dirty surface.
♦ Flammable gas or corrosive gas is generated.
♦ Ambient temperature above 35°C.
♦ Ambient temperature fluctuates violently.
♦ There is direct sunlight.
♦ There is excessive humidity and dust.
♦ There is a constant vibration.
♦ Without a ventilation system.
