Yamato Scientific IJ100 User Manual
Low Temperature Incubator
Model
IJ 100
Instruction Manual
- First Edition -
Thank you for purchasing " Low Temperature
Incubator, IJ100 " of Yamato Scientific Co.,
Ltd.
To use this unit properly, read this "Instruction
Manual" thoroughly before using this unit.
Keep this instruction manual around this unit
for referring at anytime.
WARNING!:
Carefully read and thoroughly understand the
important warning items described in this
manual before using this unit.
Yamato Scientific Co. LTD.
Contents
Cautions in Using with Safety...............................................................1
•
Explanation..................................................................................................................1
•
Table of Illustrated Symbols.........................................................................................2
Fundamental Matters of “WARNING!” and “CAUTION!”...............................................3
•
Before Using this unit............................................................................4
•
Requirements for Installation........................................................................................4
Change the Direction of Opening/Closing Door............................................................7
•
Description and Function of Each Part.................................................8
•
Main Unit......................................................................................................................8
•
Control Panel...............................................................................................................9
Operation Method.................................................................................10
•
Sequence of Operation..............................................................................................10
Independent overheating prevention device...............................................................12
•
Handling Precautions ..........................................................................13
Maintenance Method............................................................................16
•
Daily Inspection and Maintenance .............................................................................16
Setting Air Jacket (Optional accesso ry).............................................17
Long storage and disposal..................................................................18
•
When not using this unit for long term / When disposing............................................18
In the Event of Failure…......................................................................19
•
Safety Device and Error Code....................................................................................19
Trouble Shooting........................................................................................................19
•
After Service and Warranty..................................................................20
Specification.........................................................................................21
Wiring Diagram.....................................................................................22
Replacement Parts Table.....................................................................23
Reference..............................................................................................24
•
List of Dangerous Substances ...................................................................................24
Explanation
Illustrated Symbols
Various symbols are used in this safety manual in order to use the unit without
danger of injury and damage of the unit. A list of problems caused by ignoring
the warnings and improper handling is divided as shown below.Be sure that you
understand the warnings and cautions in this manual before operating the unit.
Cautions in Using with Safety
MEANING OF ILLUSTRATED SYMBOLS
WARNING!
CAUTION!
If the warning is ignored, there is the danger of a problem that
may cause a serious accident or even fatality.
If the caution is ignored, there is the danger of a problem that may
cause injury/damage to property or the unit itself.
Meaning of Symbols
This symbol indicates items that urge the warning (including the caution).
A detailed warning message is shown adjacent to the symbol.
This symbol indicates items that are strictly prohibited.
A detailed message is shown adjacent to the symbol with specific actions not to
perform.
This symbol indicates items that should be always performed.
A detailed message with instructions is shown adjacent to the symbol.
1
Table of Illustrated Symbols
Warning
Cautions in Using with Safety
Warning,
generally
Caution
Caution,
generally
Caution,
water only
Warning,
high voltage
Caution,
electrical shock
Caution,
deadly poison
Warning,
high temperature
Caution,
scald
Warning,
drive train
Caution,
no road heating
Warning,
explosive
Caution,
not to drench
Prohibit
Prohibit,
generally
Compulsion
Compulsion,
generally
inflammable
Compulsion,
connect to the
Prohibit,
grounding
terminal
to disassemble
Compulsion,
install on a flat
Prohibit,
surface
Prohibit,
to touch
Compulsion,
disconnect the
power plug
Compulsion,
periodical
inspection
2
Cautions in Using with Safety
Fundamental Matters of “WARNING!” and “CAUTION!”
WARNING!
Do not use this unit in an area where there is flammable or explosive gas
Never use this unit in an area where there is flammable or explosive gas.
This unit is not explosion-proof. An arc may be generated when the power switch is turned on or off,
and fire/explosion may result. (Refer to page24 “List of Dangerous Substances”.)
Always ground this unit
Always ground this unit on the power equipment side in order to avoid electrical shock due to a power
surge.
If a problem occurs
If smoke or strange odor should come out of this unit for some reason, turn off the power key right
away, and then turn off the circuit breaker and the main power. Immediately contact a service
technician for inspection. If this procedure is not followed, fire or electrical shock may result. Never
perform repair work yourself, since it is dangerous and not recommended.
Do not use the power cord if it is bundled or tangled
Do not use the power cord if it is bundled or tangled. If it is used in this manner, it can overheat and
fire may be caused.
Do not process, bend, wring, or stretch the power cord forcibly
Do not process, bend, wring, or stretch the power cord forcibly. Fire or electrical shock may result.
Substances that can not be used
Never use explosive substances, flammable substances and substances that include explosive or
flammable ingredients in this unit. Explosion or fire may occur.
Do not disassemble or modify this unit
Do not disassemble or modify this unit. Fire or electrical shock or failure may be caused.
CAUTION!
During a thunder storm
During a thunderstorm, turn off the power key immediately, then turn off the circuit breaker and the main
power . If this procedure is not followed, fire or electrical shock may be caused.
3
Requirements for Installation
Before Using this unit
WARNING!
1. Always ground this unit
• Connect the power plug to a receptacle with grounding connectors.
• Do not forget to ground this unit, to protect y ou and t he unit from electrical shock in case of
power surge. Choose a receptacle with grounding connectors as often as possible.
• Do not connect the grounding wire to a gas pipe, or by means of a lightning rod or telephone
line. A fire or electrical shock will occur .
2. Choose a proper place for installation
• Do not install this unit in a place where:
♦ Rough or dirty surface.
♦ Flammable gas or corrosive gas is gene rated.
♦ Ambient temperature exceeds 35°C.
♦ Ambient temperature fluctuates violently.
♦ There is direct sunlight.
♦ There is excessive humidity and dust.
♦ There is a constant vibration.
• Install this unit on a stable place with the space as shown below. Furthermore, make a space
30cm or more above this unit.
More than 15cm
More than
15cm
Main Unit
Front side
More than
15cm
3. Do not use this unit in an area where there is flammable or explosive gas
• Never use this unit in an area
where there is flammable or
explosive gas. This unit is not
explosion-proof. An arc may
be generated when the power
switch is turned ON or OFF,
and fire/explosion may result.
(To know about flammable or
explosive gas, refer to
page24 “List of Dangerous
Substances”.)
4
Requirements for Installation
4. Do not modify
• Modification of this unit is strictly prohibited.
This could cause a failure.
Before Using this unit
5. Installation on horizontal surface
• Set this unit to the flattest place. Setting this
unit on rough or slope place could cause the
vibration or noise, or cause the unexpectible
trouble or malfunction.
CAUTION!
6. Choose a correct power distribution board or receptacle
• Choose a correct power distribution board or receptacle that meets the unit’s rated electric
capacity.
Electric capacity: 100V AC 3.5A
NOTE)
There could be the case that the unit does not run even after turning ON the power. Inspect
whether the voltage of the main power is lowered than the specified value, or whether other
device(s) uses the same power lin e of thi s unit. If the phenomena might be found, change the
power line of this unit to the other power line.
5
Requirements for Installation
Before Using this unit
CAUTION!
7. Before/after installing
• It may cause injure to a person if this unit falls down or moves by the earthquake and the
impact. etc..To prevent, take measures that the unit cannot fall down , and not inst all to busy
place.
8. Handling of power code
• Do not entangle the power cord. This will cause ov er heat ing and possibly a fire.
• Do not bend or twist the power cord, or apply excessiv e tension to it. This may cause a fire
and electrical shock.
• Do not lay the power cord under a desk or chair, and do not allow it to be pinched in order to
prevent it from being damaged and to avoid a fire or electrical shock.
• Keep the power cord away from any heating equipment such as a room heater. The cord's
insulation may melt and cause a fire or electrical shock.
• If the power cord becomes damaged (wiring exposed, breakage, etc.), immediately turn off the
power at the rear of this unit and shut off the main supply power. Then contact y our nearest
dealer for replacement of the power cord. Leaving it may cause a fire or electrical shock.
• Connect the power plug to the outlet which is supplied appropriate pow er and voltage.
9. Draining of condensation
• When the cooling device is operated, condensation may occur on the cooling surface. The
condensation is led out via the drain provided at the bottom on the rear t he unit . Therefore,
be sure to set the attached drain-receiving pan.
10. Setting shelf
• Fix the two shelves (attached accessory) on the appropriat e posit ion.
6
t
Before Using this unit
Change the Direction of Opening/Closi ng Door
This unit can be changed the direction of opening/closing the door easily.
The door opened/closed to the right or left can be selected according to the place where it is
installed and the convenience of operation.
The direction of opening/closing the door is set to left at the shipping from factory. If the
door should be opened/closed to the right, the direction of opening/closing the door can be
changed by the following procedure:
1. Lay down the main body backward in a way that t he door unit may come abov e.
2. By using phillips screwdriver, remove the hinge mounting screws fixing the door in the lower
part of the main body.
3. Pull off the door downward carefully.
4. Pull off the guide pin fixing the upper part of the door, and insert it into the screw hole on the
opposite side (right side).
5. Turn t he door 180 degrees, and insert it into the upper guide pin.
6. After adjusting the door position, fix the hinge in the lower part of the door.
7. Replace the main body to complete the procedure.
1. Lay down the main body.
4. Remove the guide pin, and
move it to the right side.
2. Remove the lower hinge
and move it to the righ
side.
設定温度
Lowtemp incubator
IJ100
5. Turn around the door
3. Pull out the door.
セット
ヒータ
6. Fix the lower hinge.
7
