Yamaha Audio DPX-1000 User Manual

DPX–1000

Digital Cinema Projector

UCAK

OWNER’S MANUAL

• Explanation of Graphical Symbols

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert you to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert you to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.

1 Read these instructions.

2 Keep these instructions.

3 Heed all warnings.

4 Follow all instructions.

5 Do not use this apparatus near water.

6 Clean only with dry cloth.

7 Do not block any ventilation openings. Install in accordance

with the manufacturer’s instructions.

8 Do not install near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including amplifiers) that produce heat.

9 Do not defeat the safety purpose of the polarized or grounding-

type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10 Protect the power cord from being walked on or pinched

particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11 Only use attachments/accessories specified by the

manufacturer.

12 Use only with the cart, stand, tripod, bracket,

or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13 Unplug this apparatus during lightning storms

or when unused for long periods of time.

14 Refer all servicing to qualified service personnel. Servicing is

required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15 Be sure to allow spaces of at least 30cm above, behind and on

both sides the unit.

16 Do not place the following objects on this unit:

A vessel with water in it. If the vessel falls by vibrations and water spills, it may cause damage to the unit, and/or you may get an electric shock.

IMPORTANT!

Please record the serial number of this unit in the space below.

Model: Serial No.:

The serial number is located on the bottom of the unit. Retain this Owner’s Manual in a safe place for future reference.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF

ELECTRIC SHOCK, DO NOT REMOVE

COVER (OR BACK). NO USER-SERVICEABLE

PARTS INSIDE. REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

IMPORTANT SAFETY INSTRUCTIONS

FCC INFORMATION (for US customers only)

1. IMPORTANT NOTICE: DO NOT MODIFY THIS UNIT!

This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements. Modifications not expressly approved by Yamaha may void your authority, granted by the FCC, to use the product.

2. IMPORTANT: When connecting this product to accessories and/or another product use only high quality shielded cables. Cable/s supplied with this product MUST be used. Follow all installation instructions. Failure to follow instructions could void your FCC authorization to use this product in the USA.

3. NOTE: This product has been tested and found to comply with the requirements listed in FCC Regulations, Part 15 for Class “B” digital devices. Compliance with these requirements provides a reasonable level of assurance that your use of this product in a residential environment will not result in harmful interference with other electronic devices.

This equipment generates/uses radio frequencies and, if not installed and used according to the instructions found in the users manual, may cause interference harmful to the operation of other electronic devices.

Compliance with FCC regulations does not guarantee that interference will not occur in all installations. If this product is found to be the source of interference, which can be determined by turning the unit “OFF” and “ON”, please try to eliminate the problem by using one of the following measures:

Relocate either this product or the device that is being affected by the interference.

Utilize power outlets that are on different branch (circuit breaker or fuse) circuits or install AC line filter/s.

In the case of radio or TV interference, relocate/reorient the antenna. If the antenna lead-in is 300 ohm ribbon lead, change the lead-in to coaxial type cable.

If these corrective measures do not produce satisfactory results, please contact the local retailer authorized to distribute this type of product. If you can not locate the appropriate retailer, please contact Yamaha Electronics Corp., U.S.A. 6660 Orangethorpe Ave, Buena Park, CA 90620.

The above statements apply ONLY to those products distributed by Yamaha Corporation of America or its subsidiaries.

We Want You Listening For A Lifetime

YAMAHA and the Electronic Industries Association’s Consumer Electronics Group want you to get the most out of your equipment by playing it at a safe level. One that lets the sound come through loud and clear without annoying blaring or distortion – and, most importantly, without affecting your sensitive hearing. Since hearing damage from loud sounds is often undetectable until it is too late, YAMAHA and the Electronic Industries Association’s Consumer Electronics Group recommend you to avoid prolonged exposure from excessive volume levels.

COMPLIANCE INFORMATION STATEMENT

(DECLARATION OF CONFORMITY PROCEDURE)

Responsible Party: Yamaha Electronics Corporation

Address: 6660 Orangethorpe Avenue

Buena Park, CA90620

Telephone: 714-522-9105

Fax: 714-670-0108

Type of Equipment: Projector

Model Name: DPX-1000

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following conditions:

1) this device may not cause harmful interference, and

2) this device must accept any interference received including interference that may cause undesired operation.

See the user manual instructions if interference to radio reception is suspected.

Caution: Read this before operating this unit.

• To assure the finest performance, please read this manual carefully. Keep it in a safe place for future reference.

Installation

• Install this unit in a well-ventilated, cool, dry, clean place with at least 30 cm (1 feet) clearance on the top, right and left, and at the back of this unit — away from direct sunlight, heat sources, vibration, dust, moisture, and/or cold.

• Locate this unit away from other electrical appliances, motors, or transformers to avoid humming sounds. To prevent fire or electrical shock, do not place this unit where it may get exposed to rain, water, and/or any type of liquid.

• Do not expose this unit to sudden temperature changes from cold to hot, and do not locate this unit in an environment with high humidity (i.e. a room with a humidifier) to prevent condensation inside this unit, which may cause an electrical shock, fire, damage to this unit, and/or personal injury.

• On the top of this unit, do not place:

– Other components, as they may cause damage and/or

discoloration on the surface of this unit.

– Burning objects (i.e. candles), as they may cause fire,

damage to this unit, and/or personal injury.

– Containers with liquid in them, as they may cause electrical

shock to the user and/or damage to this unit.

• Do not cover this unit with a newspaper, tablecloth, curtain, etc. in order not to restrict heat dissipation. If the temperature inside this unit rises too much, it may cause fire, damage to this unit, and/or personal injury.

• When installing this unit on the ceiling, make sure the ceiling has sufficient strength to support this unit and the ceiling mounts for an extended period of time. Installation must be performed only by qualified service personnel.

Operation

• Remove the lens cover before starting any operation of this unit to prevent the heat from staying around the lens. Operation with the cap on may cause damage to this unit.

• Do not plug in this unit to a wall outlet until all connections are complete.

• Only the voltage specified on this unit must be used. Using this unit with a higher voltage than specified is dangerous and may cause fire, damage to this unit, and/or personal injury. YAMAHA will not be held responsible for any damage resulting from use of this unit with a voltage other than that specified.

• Do not use force on switches, knobs and/or cords.

• Do not operate this unit upside-down. It may overheat, possibly causing damage.

• Take care of this unit so that no foreign objects and/or liquid drop inside this unit.

• To prevent damage by lightning, disconnect the power cord from the wall outlet during an electrical storm.

• Do not look into the lens while this unit is turned on. It may cause serious damage to your eyesight.

• Before moving this unit, press STANDBY/ON to set this unit in the standby mode, and disconnect the AC power plug from the wall outlet.

• Do not attempt to modify or fix this unit. Contact qualified YAMAHA service personnel when any service is needed. The cabinet should never be opened for any reason.

• When not planning to use this unit for a long period of time (i.e. vacation), disconnect the AC power plug from the wall outlet.

• When disconnecting the power cord from the wall outlet, grasp the plug; do not pull the cord.

• Be sure to read the “TROUBLESHOOTING” section on common operating errors before concluding that this unit is faulty.

Others

• Clean the lens carefully so as not to create any scratches by using a blower or lens paper.

• Replace the lamp when the LAMP warning indicator blinks in red after the lamp usage has exceeded 2000 hours. Follow the lamp replacement procedure described in this manual.

For U.K. customers

IMPORTANT

THE WIRES IN THIS MAINS LEAD ARE COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE:

GREEN-AND-YELLOW: EARTH BLUE: NEUTRAL BROWN: LIVE

As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The wire which is coloured GREEN-AND-YELLOW must be connected to the terminal in the plug which is marked by the letter E or by the safety earth symbol or coloured GREEN or GREENand-YELLOW. The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured BLACK. The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or coloured RED.

If the socket outlets in the home are not suitable for the plug supplied with this appliance, it should be cut off and an appropriate 3 pin plug fitted. For details, refer to the instructions described below.

Note

• The plug severed from the mains lead must be destroyed, as a plug with bared flexible cord is hazardous if engaged in a live socket outlet.

For Canadian customers

To prevent electric shock, match wide blade of plug to wide slot and fully insert. This Class B digital apparatus complies with Canadian ICES-

003.

English

If this unit is not correctly installed in an appropriate place, it may cause fire or failure, or damage the unit itself. Carefully choose the place to install this unit by avoiding the places listed below.

1. Places where the temperature and humidity vary greatly

• Do not install this unit in a place where the temperature and humidity become extremely high or the temperature becomes extremely low.

• This unit must be used within a temperature range of 5—35°C.

2. Places without adequate ventilation

• Install this unit with at least 30 cm (1 feet) of ventilation space on the top, right and left, and back.

• Do not cover the ventilation slots of this unit not to obstruct the heat dissipation.

• Install this unit on the firm surface.

• Do not cover this unit with a tablecloth, etc.

• Make sure there is nothing to get sucked into the ventilation slots so that the temperature of this unit does not become too high.

• If you are going to install the unit in a rack, be sure to leave space for ventilation to prevent exhaust overheating the unit.

3. Places where it gets dusty

• If the filter is blocked with dust, the temperature of this unit may become too high.

4. Places with too much vibration or impact

• Vibration and impact can damage parts of this unit.

5. Places where this unit gets exposed to water or high humidity

• If this unit is exposed to water or high humidity, it may cause a fire or electrical shock.

6. Unstable places

• If this unit is installed on an unstable or an inclined tabletop, it may fall and cause damage to the unit or personal injury.

7. In close proximity to a Radio or Stereo

• The unit may interfere with reception if placed in close proximity to a radio or television receiver.

Important

• To ensure vivid, high contrast images, make sure that no light other than the projector light falls directly on the screen.

Accessory check

Please check that all accessories listed here are included in your package.

Inappropriate places for installation

RESET

123

VIDEO

STILL HIDE

INPUT

PATTIRIS

AUTO

SETTING

ASPECT

ZOOM FOCUSV. POS

ESCAPE

LIGHT

BD4

S VIDEO

INPUT

MEMORY

DVI

• Remote control • Batteries (AA, UM-3 or R6)

• Pin/BNC adapters

• Power cable

• Lens cover

E-1

INTRODUCTION

INSTALLATION

CONNECTIONS

BASIC OPERATION

ADDITIONAL

INFORMATION

English

ENGLISH

Features

Contents

• Bright, high contrast images achieved through DLP™ technology

• HDTV capable 1280 x 720 pixel wide DMD™ element

• A bright, high resolution large diameter lens

• Electronic lens adjustment — Zoom, Focus, Vertical Position, Optical Iris Diaphragm —

(DLP™ and DMD™ are trademarks of Texas Instruments.)

• Low operating noise made possible by Yamaha sound technology

• High quality progressive reproduction of film sources thanks to 3-2 pulldown detection

• 6 memory settings and an abundance of image adjustment functions

• Digital Visual Interface (DVI) HDCP Compatible

INTRODUCTION

Features ............................................. 1

Part Names and Functions

Front panel and controls ....................................................... 2

Connections .......................................................................... 3

Remote control ..................................................................... 4

Using the remote control ...................................................... 5

Loading the batteries into the remote control ....................... 5

Using the remote as a wired remote control ......................... 5

INSTALLATION

Installation

Installation methods ............................................................. 6

Screen and projection distance ............................................. 7

Projection image position ..................................................... 8

Keystone ............................................................................... 8

CONNECTIONS

Connecting the unit

Connecting A/V components ................................................ 9

Connecting to a computer ................................................... 10

BASIC OPERATION

Basic Operations

Turning on the power ......................................................... 11

Turning off the power ......................................................... 11

Preparations for projection ................................................. 12

Select an input .................................................................... 13

Select a display aspect ........................................................ 14

Other functions ................................................................... 15

Indicators ............................................................................ 15

Menu structure ................................... 16

1 <IMAGE> ...................................................................... 17

2 <SIGNAL> .................................................................... 19

3 <INITIAL> .................................................................... 20

4 <SETUP> ...................................................................... 21

Menu operation

Menu screen and operating buttons .................................... 22

Basic menu operation ......................................................... 23

Submenus ........................................................................... 24

Basic submenu operation .................................................... 25

One-touch image menu ...................................................... 28

Changing the menu location ............................................... 28

Memory function

Selecting the memory setting number ................................ 29

Resetting to the factory default settings ............................. 30

ADDITIONAL INFORMATION

Additional information

Glossary .............................................................................. 31

Projectable signals .............................................................. 33

Message display ................................................................. 34

Maintenance

Regular care ........................................................................ 35

Filter replacement ............................................................... 35

Replacing the lamp cartridge .............................................. 36

Troubleshooting .................................. 37

Specifications

Specifications ..................................................................... 38

Dimensional drawing ......................................................... 39

E-2

Part Names and Functions

1 STANDBY/ON indicator

2 STANDBY/ON button

Switches the unit between Standby and On (operational) modes.

3 ESCAPE button

Use this button to exit from submenu mode.

4 PATTERN button

Switches the built-in test pattern display on and off.

5 ASPECT button

Selects the display aspect of the projection image. Press the button to display the aspect presently being used. Pressing the button again within 2 seconds will switch the unit to the next aspect mode.

6 LAMP warning indicator

7 COVER warning indicator

■ Front panel and controls

STANDBY/ON

SETTING

LAMP COVER TEMP FAN

PATTERN

ESCAPE MENU

INPUT

DIGITAL CINEMA PROJECTOR DPX-1000

ASPECT

1 2

3 4

6 7

8 9 0

q w

e r

Front remote control sensor

STANDBY/ON indicator

Ventilation (Exhaust) vent

Lens cover

Lens

Adjuster

Use this to make fine adjustments to the projection angle.

(Enter) button

Press this button to set values and enter into submenus.

9 MENU button

Press this button to display the general settings and adjustments menu.

0 SETTING button

Selects the various lens adjustment modes.

q INPUT button

Press this button to display the input source and input signal selection menu.

w Cursor button

Use the h, g, –, + buttons for functions such as system operations, menu item selection, and changing system values.

e FAN warning indicator

r TEMP warning indicator

Ventilation inlet

Lamp cover

E-3

INTRODUCTION

English

DVI

INPUT B

RGB/YP

BPR

/YCBC

D4 VIDEO G/Y B/PB/CBR/PR/C

INPUT A

HD/SYNC VD

OUT IN

REMOTE

RS-232C

S-VIDEO VIDEO

TRIGGER OUT

1234567 809

wer

DVI

INPUT B

RGB/YPBPR/YCBCR

D4 VIDEO G/Y B/PB/CB R/PR/CR

INPUT A

HD/SYNC VD

OUT IN

REMOTE

RS-232C

S-VIDEO VIDEO

TRIGGER OUT

1 INPUT B (D-Sub 15 pin)

This is the input connector for signals (RGB/YPBPR/YCBCR) from a component video or RGB source. Use a D-Sub monitor cable when connecting another component to the DPX-1000 through this connector.

2 D4 VIDEO (D connector)

This connector receives video signals from the D connector of other A/V components. It is compatible with the D1—D4 formats. (This connector is designed for the Japanese D format only.)

3—7 INPUT A (BNC jacks)

These are input jacks for signals from component video or RGB sources. Component signals from A/V equipment should be connected to ports 3—5, and RGB signals from Computer equipment to ports 3—7. Use a BNC cable when connecting other components to the DPX-1000 through these jacks.

3 G/Y (G, or luminance signal) 4 B/P

B/CB (B, or color difference signal)

5 R/PR/CR (R, or color difference signal) 6 HD/SYNC (horizontal sync signal, composite sync signal) 7 VD (vertical sync signal)

8 S-VIDEO (Mini DIN jack)

This jack receives S VIDEO signals from the S-VIDEO output jack of other A/V components. Use an S VIDEO cable when connecting other components to the DPX-1000 through this jack.

■ Connections

Part Names and Functions

Rear remote control sensor

9 VIDEO (Pin jack)

This jack receives composite signals from jacks of other A/V components. Use a video pin cable when connecting other components to the DPX-1000 through this jack.

0 AC inlet

q DVI (DVI jack)

This jack receives DVI signals from computer equipment or DVI signals from A/V equipments.

w REMOTE IN/OUT jack

Connect the remote control to the IN jack when using it through a cable. Codes input through the IN jack will be output directly through the OUT jack.

e RS-232C (D-sub 9 pin)

This jack is used for factory testing.

r TRIGGER OUT

This jack outputs control signals to external components. A potential of 12V/Maximum 200 mA is provided when the DPX-1000 is projecting.

AC inlet

Plug in the supplied power cord here.

E-4

Part Names and Functions

■ Remote control

Buttons with identical names to those on the main unit perform identical functions. To use the remote, point it at the remote control sensor on the front or back of the unit from a distance of no more than 7 m (23 feet).

1 Transmit indicator

This indicator will light up when the unit is sending infra-red signals to the main unit.

2 AUTO button

Pressing this button will automatically adjust the unit to the best settings for projection by retuning the frequency of the projection to that of the source component.

3 V. POS button

Switches on and off the adjustment mode for the vertical positioning of the entire image.

4 ZOOM button

Switches on and off the size adjustment mode for the image being projected.

5 IRIS button

Switches on and off the lens iris diaphragm change mode.

6 ESCAPE button

Press this button to exit from a sub-menu.

7 Cursor buttons

Use the h, g, –, + buttons to move the cursor within the interface.

8 ASPECT button

9 STILL button

Stops a moving image to display a still of the desired image. Press STILL again to cancel this function.

RESET

123

VIDEO

STILL HIDE

INPUT

PATTIRIS

AUTO

SETTING

ASPECT

ZOOM FOCUSV. POS

ESCAPE

LIGHT

BD4

S VIDEO

INPUT

MEMORY

DVI

2 3

4 5 6

9 0

RESET

S VIDEO

DVI

STI

SPE

ESC

HID

INPUT

IRIS

PATT

V. POS

FOCUS

AUTO

ID-2

ID-1

0 INPUT area

Directly selects the input jack.

q MEMORY area

Calls up stored video memory directly.

w RESET button

Press this button to reset all parameters altered in the menu to their default factory settings.

button

Switches the unit between Standby and On (operational) modes.

r FOCUS button

Switches on and off the focus adjustment mode for the image being projected.

t PATT (PATTERN) button

Switches the built-in test pattern display on and off.

y MENU button

Press this button to display the general settings and adjustments menu.

(Enter) button

Use this button to set values and enter into submenus when the menu is being displayed. Pressing the button when the menu is not being displayed will call up the in-line menu. (see page 28.)

i INPUT button

Press this button to display the input source and input signal selection menu.

o LIGHT switch

Pressing this switch will light up the often used 2, 6, 8, e, y, i buttons. The lights will switch off if no operation is

performed within 10 seconds.

p HIDE button

Press this button to temporarily halt projection of the image being displayed. Press the HIDE button once more to cancel this function.

a Remote control code switch

This remote control will work when it has the same code as that set on the menu. The default setting on the menu is ID-1.

s Remote control cable jack

Use this jack to connect the remote control to the main unit with a cable.

E-5

INTRODUCTION

English

Part Names and Functions

Important

• Bright light, fluorescent light etc. on the remote sensor on the main unit may inhibit the normal functioning of the remote control.

• The remote may not function normally if there is an obstacle blocking the signal between the remote and the remote control sensor on the main unit.

• The above are approximate figures.

■ Using the remote control

Use the remote control under the following conditions. The remote control will not function if it is used outside the angles and/or range detailed here.

■ Loading the batteries into the remote

control

1. Remove the battery compartment cover from the

back of the remote control.

2. Insert two batteries (AA, UM3, or R6 type), matching

the polarity markings (+, –) on the batteries with those in the battery compartment.

3. After inserting the batteries, close the cover until it

snaps into place.

Important

• If the remote must be used closer to the main unit than normal, or does not always operate correctly, exchange the batteries for new ones.

• Do not mix old and new, or different types of battery.

• Remove the batteries if you do not plan to use the unit for a long time.

• If the batteries leak, dispose of them immediately, taking care not to touch the battery fluid. If the battery fluid comes into contact with your eyes, mouth, or skin, rinse it off with water immediately and consult a doctor. Clean the battery compartment thoroughly before installing new batteries.

■ Using the remote as a wired remote control

To use the remote control as a wired remote control, use a 2P monaural miniplug to connect the remote control cable jack on the underside of the remote control to the REMOTE IN jack on the main unit.

Usable angle

30 degrees

Usable distance

7 m (23 feet)

A left/right arc of 30 degrees A vertical arc of 30 degrees

DVI

INPUT B

RGB/YP

BPR

/YCBC

D4 VIDEO G/Y B/PB/CBR/PR/C

INPUT A

HD/SYNC VD

OUT IN

REMOTE

RS-232C

S-VIDEO VIDEO

TRIGGER OUT

RESET

123

VIDEO

STILL HIDE

INPUT

PATTIRIS

AUTO

SETTING

ASPECT

ZOOM FOCUSV. POS

ESCAPE

LIGHT

BD4

S VIDEO

INPUT

MEMORY

DVI

RESET

123

VIDEO

STILL HIDE

INPUT

PATTIRIS

AUTO

SETTING

ASPECT

ZOOM FOCUSV. POS

ESCAPE

LIGHT

BD4

S VIDEO

INPUT

MEMORY

DVI

7 m

(23 feet)

7 m (23 feet)

RESET

VIDEO

S VIDEO

DVI

STILL

ASPECT

ESC

P E

HIDE

INPUT

IRIS

PATT

V. P

ZOOM

FOCUS

AUTO

ID-1

ID-2

DVI

INPUT B

RGB/YP

BPR

/YCBC

D4 VIDEO G/Y B/PB/CBR/PR/C

INPUT A

HD/SYNC VD

OUT IN

REMOTE

RS-232C

S-VIDEO VIDEO

TRIGGER OUT

E-6

Installation

■ Installation methods

There are four ways to install this unit:

on a table in front of the screen. mounted on the ceiling in front of the screen. on a table behind a semi translucent screen. mounted on the ceiling behind a semi translucent screen.

Set the method you use on the 4 <SETUP> section of the MENU described later. (see page 21.)

Place the unit on a standard height table to project and view the image from in front of the screen. The height from the bottom of the unit to the center of the lens is 12.4 cm (4”-7/8).

There are two kinds of brackets (low ceiling and high ceiling, sold separately) available which can be used to mount the unit on the ceiling. Consult your dealer for details on their use, and have installation done by either your dealer or a reputable contractor. The image on the screen is vertically reversed compared to that of a table mounted installation. In this case, please set the installation type to FRONT/CEILING in the 4 <SETUP> section of the menu. (see page

21.)

In this case, images are projected onto a semi translucent screen, and the viewer watches it from the reverse side. The relationship with the screen and projection distance corresponds to that for front projection. For rear projection, set the installation type to REAR/CEILING or REAR/TABLE in the 4 <SETUP> section of the menu. (see page 21.)

E-7

English

INSTALLATION

■ Screen and projection distance

The ideal position for mounting the main unit (Projection distance [a]) depends on the size of the screen to be used (the length of a diagonal line across the screen). It is possible to adjust the projection distance within a preset range from Wide to Tele using the zoom function. Additionally, it is possible to adjust the V. POS (Vertical positioning) of the image to better suit the screen. Use the information illustrated in the figure below to determine the best position for installation.

Installation

Screen size

60 70 80

90 100 110 120 150 200

Wide (m) — Tele (m)

1.8 — 2.88

2.1 — 3.36

2.4 — 3.84

2.7 — 4.32

3.0 — 4.8

3.3 — 5.28

3.6 — 5.76

4.5 — 7.2

6.0 — 9.6

Since the DPX-1000 is equipped with a 16:9 element, the ideal installation position for viewing images with a 4:3 screen depends on the size of the desired image projection.

1 When a standard 16:9 image completely fills the width of the

screen (leaving black line at the top and bottom of the screen)

2 When the standard 4:3 image completely fills the screen

Screen size

100

120

200

Wide — Tele

(m), (feet, inches)

1.65 m — 2.64 m 5’5” — 8’8”

2.2 m — 3.52 m 7’2” — 11’7”

2.75 m — 4.4 m 9’ — 14’5”

3.3 m — 5.28 m 10’10” — 17’4”

5.5 m — 8.8 m 18’ — 28’10”

Projection distance

Wide — Tele

(m), (feet, inches)

2.2 m — 3.52 m 7’3” — 11’7”

2.9 m — 4.64 m 9’6” — 15’3”

3.65 m — 5.84 m 12’ — 19’2”

4.4 m — 7.04 m 14’5” — 23’1”

7.3 m — 11.68 m 23’11” — 38’4”

3 Projecting both 16:9 and 4:3 images

It is possible to use the zoom function to make use of the screen efficiently for both 1 and 2 above. The projection distance in this case will be between Wide in 2 and Tele in 1. Adjust the size of the projected image using the zoom so that all images fill the screen completely. However, please be aware that adjustments to V. POS can cause the position of the image to slip.

60'' 80'' 100'' 150'' 200''

6.0 – 9.6 m

(19'8" – 31'6")

4.5 – 7.2 m

(14'9" – 23'7")

3.0 – 4.8 m

(9'10" – 15'9")

2.4 – 3.84 m

(7'10" – 12'7")

1.8 – 2.88 m

(5'11" – 9'5")

For a 16:9 screen

*These are theoretical numerical values. Please be aware that there may be some discrepancy in comparison to actual values.

Lens center line

Screen size

Projection distance [a]

(feet, inches)

5’11” — 9’5” 6’10” — 11’ 7’10” — 12’7” 8’10” — 14’2” 9’10” — 15’9” 10’10” — 17’4” 11’10” — 18’11” 14’9” — 23’7” 19’8” — 31’6”

Projection distance [a]

E-8

Installation

■ Projection image position

Follow the instructions below to adjust the position of the projected image on the screen.

This figure shows the limits within which the zoom function can alter projection distance in relation to the screen size. Within these limits, it is possible to adjust the image so that it fills the screen completely. (See page 12.)

It is possible to adjust the vertical position of the projected image on the screen up or down by half the height of the screen. For example, shifting V. POS fully up will bring the lower limit of the image above the centerline of the lens. (See page 12.)

When this unit is mounted on a tabletop, the position of the image can be adjusted by using the adjusters located on the underside of the unit. Adjust the height by rotating the movable part of the two screw-type adjusters at the front bottom of the case. The adjustment range of these adjusters is 3 cm (1-1/4 inch). Adjust with care as loosening them further may cause them to separate from the main unit.

■ Keystone

When the unit is mounted at an angle to the screen, the image will be projected in a trapezoid manner. Use the keystone function in the keystone section of 4 <SETUP> in the menu to rectify this. (See page 21.)

Tele

Lens center line

Shifted fully down

Shifted fully up

Lens center line

Projected image

Wide

E-9

CONNECTIONS

English

DVI

INPUT B

RGB/YPBPR/YCBC

D4 VIDEO G/Y B/PB/CBR/PR/C

INPUT A

HD/SYNC VD

OUT IN

REMOTE

RS-232C

S-VIDEO VIDEO

TRIGGER OUT

G/YR

PR/

B/PB/

◆ Note ◆

• Make sure to match the Y/PB/PR or Y/CB/CR of the A/V component and this unit when connecting a component to INPUT A component jacks. Also, refer to the operation instructions for the A/V component. HD/SYNC and VD need to be connected for RGB video signals in some cases.

Connecting the unit

• Make sure that the power of this unit and all other components is turned off before making any connections.

• Some components have different connection methods and connector names. Refer to the operating instructions for each component that you wish to connect.

• Plug the unit in correctly to prevent it from creating noise or other problems.

■ Connecting A/V components

As shown in the illustration below, there are 6 types of connections provided on this unit for connection to A/V components. Follow the instructions on the figure below to connect A/V video outputs from other components to this unit using the correct cables and adapters.

D connector cable

D-sub monitor cable

BNC cable for component connection

Pin/BNC adapters

Pin cable

Video pin cable

S video cable

D1—4 output

connectors

Pin jacksD-sub

Component/RGB video output connectors

Image output from A/ V components

BNC jacks S video output

jack

Video output

jack

Input

VIDEO S-VIDEO INPUT A INPUT B D4 VIDEO DVI

Signal type

Composite video S video Component video/RGB video Component video/RGB video Component video Component video/RGB video (digital)

Connector type

Pin jack Mini DIN connector BNC connector x 3—5 D-sub 15 pin D connector DVI connector

DVI cable (digital)

DVI output connector
