Yamaha YSP-3050 User Manual

YSP-3050

U

Digital Sound Projector

TM

OWNER’S MANUAL

IMPORTANT SAFETY INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF

ELECTRIC SHOCK, DO NOT REMOVE

COVER (OR BACK). NO USER-SERVICEABLE

PARTS INSIDE. REFER SERVICING TO

QUALIFIED SERVICE PERSONNEL.

■ Explanation of Graphical Symbols

The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert you to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to
persons.

The exclamation point within an equilateral
triangle is intended to alert you to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.

1

Read these instructions.

2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings. Install in accordance with

the manufacturer’s instructions.

8 Do not install near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including amplifiers) that
produce heat.

9 Do not defeat the safety purpose of the polarized or grounding-

type plug. A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided
for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.

10 Protect the power cord from being walked on or pinched

particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.

11 Only use attachments/accessories specified by the manufacturer.
12 Use only with the cart, stand, tripod, bracket,

or table specified by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.

13 Unplug this apparatus during lightning

storms or when unused for long periods of time.

14 Refer all servicing to qualified service personnel. Servicing is

required when the apparatus has been damaged in any way, such
as power supply cable or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has
been dropped.

i En

IMPORTANT SAFETY INSTRUCTIONS

FCC INFORMATION (for US customers)

1. IMPORTANT NOTICE: DO NOT MODIFY THIS UNIT!

This product, when installed as indicated in the instructions
contained in this manual, meets FCC requirements.
Modifications not expressly approved by Yamaha may void
your authority, granted by the FCC, to use the product.

2. IMPORTANT:

When connecting this product to accessories and/or another
product use only high quality shielded cables. Cable/s supplied
with this product MUST be used. Follow all installation
instructions. Failure to follow instructions could void your FCC
authorization to use this product in the USA.

3. NOTE:

This product has been tested and found to comply with the
requirements listed in FCC Regulations, Part 15 for Class “B”
digital devices. Compliance with these requirements provides a
reasonable level of assurance that your use of this product in a
residential environment will not result in harmful interference
with other electronic devices.

This equipment generates/uses radio frequencies and, if not
installed and used according to the instructions found in the
users manual, may cause interference harmful to the operation
of other electronic devices.

Compliance with FCC regulations does not guarantee that
interference will not occur in all installations. If this product is
found to be the source of interference, which can be determined
by turning the unit “OFF” and “ON”, please try to eliminate the
problem by using one of the following measures:

Relocate either this product or the device that is being affected
by the interference.

Utilize power outlets that are on different branch (circuit
breaker or fuse) circuits or install AC line filter/s.

In the case of radio or TV interference, relocate/reorient the
antenna. If the antenna lead-in is 300 ohm ribbon lead, change
the lead-in to coaxial type cable.

If these corrective measures do not produce satisfactory results,
please contact the local retailer authorized to distribute this type
of product. If you can not locate the appropriate retailer, please
contact Yamaha Electronics Corp., U.S.A. 6660 Orangethorpe
Ave, Buena Park, CA 90620.

The above statements apply ONLY to those products distributed
by Yamaha Corporation of America or its subsidiaries.

We Want You Listening For A Lifetime

Yamaha and the Electronic Industries Association’s Consumer Electronics Group want you to get the most out of your
equipment by playing it at a safe level. One that lets the sound come through loud and clear without annoying
blaring or distortion – and, most importantly, without affecting your sensitive hearing.
Since hearing damage from loud sounds is often undetectable until it is too late, Yamaha and the Electronic Industries
Association’s Consumer Electronics Group recommend you to avoid prolonged exposure from excessive volume levels.

ii En

CAUTION: READ THIS BEFORE OPERATING THIS UNIT.

Caution: Read this before operating this unit.

To assure the finest performance, please read this manual

1

carefully. Keep it in a safe place for future reference.

2 Install this sound system in a well ventilated, cool, dry, clean

place with at least 5 cm (2 in) of space above (or below) this unit
– away from direct sunlight, heat sources, vibration, dust,
moisture, and/or cold.

3 Locate this unit away from other electrical appliances, motors, or

transformers to avoid humming sounds.

4 Do not expose this unit to sudden temperature changes from cold

to hot, and do not locate this unit in an environment with high
humidity (i.e. a room with a humidifier) to prevent condensation
inside this unit, which may cause an electrical shock, fire,
damage to this unit, and/or personal injury.

5 Avoid installing this unit where foreign object may fall onto this

unit and/or this unit may be exposed to liquid dripping or
splashing. On the top of this unit, do not place:

– Other components, as they may cause damage and/or

discoloration on the surface of this unit.

– Burning objects (i.e. candles), as they may cause fire, damage

to this unit, and/or personal injury.

– Containers with liquid in them, as they may fall and liquid

may cause electrical shock to the user and/or damage to this
unit.

6 Do not cover this unit with a newspaper, tablecloth, curtain, etc.

in order not to obstruct heat radiation. If the temperature inside
this unit rises, it may cause fire, damage to this unit, and/or
personal injury.

7 Do not plug in this unit to a wall outlet until all connections are

complete.

8 Do not operate this unit upside-down. It may overheat, possibly

causing damage.

9 Do not use force on switches, knobs and/or cords.
10 When disconnecting the power supply cable from the wall outlet,

grasp the plug; do not pull the cable.

11 Do not clean this unit with chemical solvents; this might damage

the finish. Use a clean, dry cloth.

12 Only voltage specified on this unit must be used. Using this unit

with a higher voltage than specified is dangerous and may cause
fire, damage to this unit, and/or personal injury. Yamaha will not
be held responsible for any damage resulting from use of this unit
with a voltage other than specified.

13 To prevent damage by lightning, keep the power supply cable

disconnected from a wall outlet or this unit during a lightning
storm.

14 Do not attempt to modify or fix this unit. Contact qualified

Yamaha service personnel when any service is needed.
The cabinet should never be opened for any reasons.

15 When not planning to use this unit for long periods of time (i.e.

vacation), disconnect the power supply cable from the wall
outlet.

16 Be sure to read the “Troubleshooting” section on common

operating errors before concluding that this unit is faulty.

17 Before moving this unit, press STANDBY/ON to set this unit in

standby mode, and disconnect the power supply cable from the
wall outlet.

18 Condensation will form when the surrounding temperature

changes suddenly. Disconnect the power supply cable from the
outlet, then leave the unit alone.

19 When using the unit for a long time, the unit may become warm.

Turn the power off, then leave the unit alone for cooling.

20 Install this unit near the AC outlet and where the AC power plug

can be reached easily.

21 The batteries shall not be exposed to excessive heat such as

sunshine, fire or the like.

WAR NING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.

This unit is not disconnected from the AC power source as long as
it is connected to the AC wall outlet, even if this unit itself is
turned off by STANDBY/ON. This state is called the standby
mode. In this state, this unit is designed to consume a very small
quantity of power.

IMPORTANT

Please record the serial number of this unit in the space below.
MODEL:
Serial No.:
The serial number is located on the rear of the unit. Retain this
Owner’s Manual in a safe place for future reference.

FOR CANADIAN CUSTOMERS

To prevent electric shock, match wide blade of plug to wide slot
and fully insert.
This Class B digital apparatus complies with Canadian ICES-003.

POUR LES CONSOMMATEURS CANADIENS

Pour éviter les chocs électriques, introduire la lame la plus
large de la fiche dans la borne correspondante de la prise et
pousser jusqu’au fond.
Cet appareil numérique de la classe B est conforme à la norme
NMB-003 du Canada.

CAUTION

Danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type.

CAUTION

Use of controls or adjustments or performance of procedures other
than those specified herein may result in hazardous radiation
exposure.

iii En

Contents

INTRODUCTION

Overview.................................................................. 2

Features ................................................................... 3

Using this manual ................................................... 5

Supplied accessories ............................................... 6

Controls and functions ........................................... 7

Front panel ................................................................. 7

Front panel display .................................................... 8

Rear panel .................................................................. 9

Remote control......................................................... 10

PREPARATION

Installation............................................................. 13

Before installing this unit......................................... 13

Installing this unit .................................................... 13

Connections ........................................................... 16

Before connecting components................................ 17

Case 1: Connections using HDMI cables ................ 18

Case 2: Connecting a DVD player/recorder and tuner

(digital satellite, cable TV or digital airwave)..... 19

Case 3: Connecting other connection methods........20

Connecting a TV without an HDMI cable............... 21

Connecting a portable audio player ......................... 22

Connecting a subwoofer .......................................... 22

Connecting the FM antenna..................................... 23

About the IR IN jack................................................ 23

Connecting the AC power supply cable .................. 23

SETUP

Getting started ...................................................... 24

Installing batteries in the remote control ................. 24

Operation range of the remote control ..................... 24

Turning on this unit or

setting it to the standby mode.............................. 25

Using SET MENU................................................. 26

Displaying the OSD (on-screen display) ................. 26

The flow chart of SET MENU................................. 27

Changing OSD language ...................................... 28

AUTO SETUP (IntelliBeam) ............................... 29

The flow chart of AUTO SETUP ............................ 29

Installing the IntelliBeam microphone .................... 30

Using AUTO SETUP (IntelliBeam) ........................ 31

Using the system memory .................................... 36

Convenient usage of the system memory ................ 36

Saving settings......................................................... 36

Loading settings....................................................... 37

BASIC OPERATION

Playback ................................................................ 39

Selecting the input source ........................................ 39

Playing back sources................................................ 40

Adjusting the volume............................................... 41

FM tuning .............................................................. 42

FM controls and functions ....................................... 42

Automatic tuning ..................................................... 43

Manual tuning.......................................................... 43

Automatic preset tuning........................................... 44

Manual preset tuning ............................................... 45

Selecting a preset station ......................................... 46

XM™ Satellite Radio tuning ............................... 47

Connecting XM™ Mini-Tuner Home Dock ........... 47

Activating XM™ Satellite Radio ............................ 48

Basic XM™ Satellite Radio operations................... 48

Presetting the XM™ Satellite Radio channels ........ 51

Displaying the XM™ Satellite Radio information.... 52

Using iPod™ ..........................................................53

Connection............................................................... 53

Controlling iPod™................................................... 53

Enjoying surround sound .....................................56

5 Beam..................................................................... 56

Stereo plus 3 Beam .................................................. 57

3 Beam..................................................................... 57

My Surround............................................................ 57

Enjoying 2-channel sources

in surround sound ................................................ 59

Enjoying TV in surround sound .............................. 60

Adjusting surround mode parameters ...................... 61

Enjoying stereo sound ...........................................62

2-channel stereo playback........................................ 62

5-channel stereo playback........................................ 62

Playing back sound clearly (My Beam)...............63

Using auto-adjust function....................................... 63

Using manual-adjust function.................................. 64

Using sound field programs..................................65

CINEMA DSP programs ......................................... 66

Using the music enhancer .....................................68

Using the volume mode

(Night listening enhancer/TV volume equal

mode) ..................................................................69

Using the sleep timer .............................................70

Displaying the input source information.............72

Using the HDMI control feature ..........................73

ADVANCED OPERATION

MANUAL SETUP .................................................74

Using MANUAL SETUP ....................................... 75

BEAM MENU ......................................................... 76

SOUND MENU....................................................... 80

INPUT MENU......................................................... 82

DISPLAY MENU.................................................... 86

Adjusting the audio balance .................................87

Using the test tone ................................................... 87

Using the audio output being played back............... 88

Selecting the input mode.......................................90

Adjusting the system parameters ........................91

Using the system parameters ................................... 91

Remote control features........................................94

Setting remote control codes ................................... 94

Controlling other components ................................. 95

Using the TV macro ................................................ 98

ADDITIONAL INFORMATION

Troubleshooting...................................................100

Glossary................................................................104

Index .....................................................................106

Specifications .......................................................107

List of remote control codes .............................................i

PREPARATIONINTRODUCTION

SETUP

OPERATION

BASIC

OPERATION

ADVANCED

INFORMATION

ADDITIONAL

English

1 En

Overview

Overview

It is generally accepted that in order to fully enjoy the benefits of surround sound at home, you must endure the agony of
wiring and installing a great number of speakers in the hope that your listening room will give you the same kind of
surround sound experience as your local movie theater.
Yamaha YSP-3050 Digital Sound Projector challenges this preconception that complicated speaker setup and
troublesome wiring go hand-in-hand with the enjoyment of multi-channel surround sound.
This slimline unit does away with the need for complicated wiring and installation worries, leaving you with a unit that is
not only easy to set up, but is also capable of reproducing the kind of powerful surround sound you have been waiting for
from its built-in 2 woofers and 21 full-range small speakers.
You can fine-tune the parameters of this unit to adjust the delay time for separate sound beams, resulting in highly
directional sound that comes in on the listening position from all directions.
The YSP-3050 projects sound beams containing surround sound information for the front right (R), front left (L),
surround right (SR), and surround left (SL) speaker positions, which are reflected off the walls of your listening room
before reaching the actual listening position. With the addition of center (C) sound beams, this Digital Sound Projector
creates true-to-life 5.1-channel surround sound that makes you feel as if there are actual speakers around the room.
Sit back and enjoy the real sound experience of this simple, yet stylish Digital Sound Projector.

Imaginary
front right
speaker

Imaginary

front left

speaker

Imaginary

center

speaker

R

C

SR

L

SL

Imaginary

surround right

speaker

Listening position

Imaginary

surround left

speaker

2 En

Features

Features

Digital Sound Projector™

The Digital Sound Projector technology allows one slim
unit to control and steer multiple channels of sound to
generate multi-channel surround sound, thus eliminates
the need for satellite loudspeakers and cabling normally
associated with conventional surround sound systems.
This unit also employs the beam modes that let you enjoy
the surround sound (5 Beam, Stereo plus 3 Beam and 3
Beam), 2-channel and 5-channel stereo playback, and My
Beam.

My Surround

In addition to the above mentioned beam modes, this unit
is equipped with My Surround beam mode that allows you
to enjoy surround system even in a small listening area.
My Surround is a function integrated and optimized with
DiMAGIC's Euphony technology and Yamaha's Beam
reproduction system.

My Beam

This unit employs My Beam that ensures a clear sound in
a noisy environment. You can adjust the beam angle
manually or automatically.

Cinema DSP

This unit employs the Cinema DSP technology developed
by Yamaha Corporation that lets you experience movies at
home with all the original dramatic sound impact.

HDMI™ (High-Definition Multimedia Interface)

◆ HDMI interface for standard, enhanced, or high-definition
video (including 1080p video signal transmission) as well as
multi-channel digital audio based on HDCP

◆ Simple and easy connections with HDMI supported external
components

◆ Functional link with an HDMI control-compatible TV

◆ Analog video up-scaling from 480i (NTSC)/576i (PAL) or

480p (NTSC)/576p (PAL) to 720p or 1080i

Versatile Remote Control

The supplied remote control comes with preset remote
control codes used to control the DVD player, VCR, cable
TV tuner, and digital satellite tuner connected to this unit.
In addition, the remote control is equipped with the macro
capability that enables a series of operations with the press
of a single button.

AUTO SETUP (IntelliBeam)

This unit employs the automatic sound beam and acoustic
optimization technology with the aid of the supplied
IntelliBeam microphone. You can avoid troublesome
listening-based speaker setup and achieve highly accurate
sound beam adjustments that best match your listening
environment.

Compatibility with the Newest Technologies

This unit employs decoders compatible with Dolby
Digital, DTS, Dolby Pro Logic, Dolby Pro Logic II, DTS
Neo:6, Music Enhancer, and Neural Surround.

◆ Dolby Digital
This is the standard audio signal format used on various
digital media such as DVD, Blu-ray, and HD DVD. This
surround technology delivers high-quality digital audio for up
to 5.1 discrete channels to produce a directional and more
realistic effect.

◆ DTS
This is the standard audio signal format used on various
digital media such as DVD, Blu-ray, and HD DVD. This
surround technology delivers high-quality digital audio for up
to 5.1 discrete channels to produce a directional and more
realistic effect.

◆ Dolby Pro Logic
A surround system that takes a 4-channel signal and records it
as a 2-channel signal, then by way of some arithmetic
processing converts back to an independent 4-channel signal
for playback.

◆ Dolby Pro Logic II
Dolby Pro Logic II is an improved technique used to decode
vast numbers of existing Dolby Surround software.
This new technology enables a discrete 5-channel playback
with 2 front left and right channels, 1 center channel, and 2
surround left and right channels (instead of only 1 surround
channel for conventional Pro Logic technology).

◆ DTS Neo:6
This technology decodes the conventional 2-channel sources
for 6-channel playback, enabling playback with the full-range
channels with higher separation. Music mode and Cinema
mode are available to play back music and movie sources
respectively.

◆ Music Enhancer to restore the original depth and width of
compression artifacts such as the MP3 format.

◆ Neural Surround decoder.

Sophisticated FM tuner

◆ 40-station random and direct preset tuning

◆ Automatic preset tuning

XM™ Satellite Radio

◆ XM Satellite Radio tuning capability (using the XM Mini­Tuner Dock, and Antenna sold separately by XM Satellite
Radio)

◆ Neural Surround decoder to play back the XM HD content of
XM Satellite Radio broadcasts in multi-channels, resulting in
a full surround sound experience

◆ XM Satellite Radio information displaying capability

iPod™ Controlling Capability

◆ DOCK terminal to connect a Yamaha iPod universal dock
(such as the YDS-10, sold separately), which supports iPod
(Click and Wheel), iPod nano, and iPod mini

◆ Playback information displaying capability

◆ Battery charging capability

INTRODUCTION

English

3 En

Features

The “ ” logo and “IntelliBeam” are trademarks of
Yamaha Corporation.

The “ ” logo and “Cinema DSP” are registered
trademarks of Yamaha Corporation.

Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic”, and the double-D symbol are trademarks
of Dolby Laboratories.

Manufactured under license from 1 Ltd. Worldwide patents
applied for.

The “ ” logo and “Digital Sound Projector

™

” are trademarks

of 1 Ltd.

TruBass, SRS and the “ ” symbol are registered trademarks
of SRS Labs, Inc. TruBass technology is incorporated under
license from SRS Labs, Inc.

™

is a trademark of DiMAGIC Co., Ltd.

“DTS” and “Neo:6” are registered trademarks of DTS, Inc.

“HDMI”, the “HDMI” logo and “High-Definition Multimedia
Interface” are trademarks or registered trademarks of HDMI
Licensing LLC.

TM

iPod

“iPod” is a trademark of Apple Inc., registered in the U.S. and
other countries.

The XM name and related logos are registered trademarks of XM
Satellite Radio Inc.

Neural Surround

™

name and related logos are trademarks owned

by Neural Audio Corporation.

4 En

Using this manual

Using this manual

Notes

• This manual describes how to connect and operate this unit. For details regarding the operation of external components, refer to the
supplied owner’s manual for each component.

• Operations in this manual use keys on the supplied remote control of this unit unless otherwise specified.

• y indicates a tip for your operation.

• This manual is printed prior to production. Designs and specifications are subject to change in part as a result of improvements, etc. In
case of differences between the manual and the product, the product has priority.

1 Install this unit in your listening room.

See “Installation” on page 13.

2 Connect this unit to your TV and other external components.

See “Connections” on page 16.

3 Prepare the remote control and turn on the power of this unit.

See “Getting started” on page 24.

INTRODUCTION

4 Run AUTO SETUP.

See “AUTO SETUP (IntelliBeam)” on page 29.

5 Play back a source.

See “Playback” on page 39.

6 Change the beam modes and/or CINEMA DSP settings.

See “Enjoying surround sound” on page 56.

If you want to make additional settings
and adjustments

7 Run MANUAL SETUP to fine-tune settings and/or set remote control codes.

See “MANUAL SETUP” on page 74 and “Remote control features” on page 94.

English

5 En

Supplied accessories

Supplied accessories

Check that you have received all of the following parts.

Remote control (×1)

POWERPOWERSTANDBY/ON

AV

TV

AUX1 AUX2

INPUT1

TV

PRESET/TUNE

CATFM/XM

AUTO

SETUP

INPUTMODE

MY BEAM

5

+10

ENTRY

ENTER

CH

TV INPUT TV MUTE

DOCK

AUX3

TV

MACRO

MEMORYSEARCH

SLEEP

321

6

SPORTS

9

SUR. DECODE

RETURNDISPLAY

TV VOL

CODE SET

TV/AV

YSP

DVD

STB

VOL MODE

5BEAM ST+3BEAM 3BEAM

STEREO MY SUR.

4

MUSIC MOVIE

78

OFF

0

ENHANCER MENU

CAT/
A-E

VOLUME

MUTE

CH LEVEL TEST

Fasteners (×4)

Cable clamp (×1)

IntelliBeam microphone

(×1)

Cardboard microphone

stand (×1)

Optical cable (×1)

Digital audio pin cable (×1)

(Orange)

Audio pin cable (×1)

(White/Red)

Batteries (×2)

(AA, R6, UM-3)

Demonstration DVD

(×1)

QUICK REFERENCE

GUIDE

Indoor FM antenna (×1)

OSD* video pin cable (×1)

(Yellow)

*OSD: On-Screen Display

6 En

Front panel

Controls and functions

Controls and functions

INTRODUCTION

3 4

21

AUX 3

INTELLIBEAM MIC

1 AUX 3 input jack

Connect your portable audio player (see page 22).

2 INTELLIBEAM MIC jack

Connect the supplied IntelliBeam microphone for AUTO
SETUP (see page 30).

3 Remote control sensor

Receives infrared signals from the remote control.

4 Front panel display

Shows information about the operational status of this
unit.

5 INPUT

Press repeatedly to switch between input sources (see
page 39).

5

INPUT

6

VOLUME

+

7

STANDBY/ON

6 VOLUME +/–

Controls the volume level of all audio channels (see
page 41).

7 STANDBY/ON

Turns on the power of this unit or sets it to the standby
mode (see page 25).

Notes

• When you turn on this unit, you will hear a click sound
followed by the 4 to 5-second interval before sound
reproducing.

• In the standby mode, this unit consumes a small amount of
power in order to receive infrared signals from the remote
control or to search for HDMI signals.

7 En

English

Controls and functions

Front panel display

1

0

89

AB C D

1 HDMI indicator

Lights up when the signal of the selected input source is
input at the HDMI IN jack(s).

2 TUNER indicators

FM: Light up when this unit is receiving an FM broadcast
(see pages 43 to 45).
XM: MEMORY flashes during the XM preset operation
(see page 51).

3 CINEMA DSP indicator

Lights up when a CINEMA DSP program is selected (see
page 66).

4 PCM indicator

Lights up when this unit is reproducing PCM (Pulse Code
Modulation) digital audio signals.

5 Decoder indicators

Light up when the corresponding decoder operates
(see page 58).

6 ENHANCER indicator

Lights up when the Music Enhancer is selected (see
page 68).

7 Volume level indicator

Displays the current volume level.

8 DOCK indicator

Lights up when your iPod (Click and Wheel), iPod nano,
or iPod mini is connected to this unit via the DOCK
terminal on this unit.

9 SRS TruBass indicator

Lights up when TruBass is turned on (see page 81).

23

4

A NIGHT indicator

Lights up when one of the night listening enhancers is
selected (see page 69).

B SLEEP indicator

Lights up when the sleep timer is set (see page 70).

C XM indicator

Lights up when XM is selected as the input source.

D Multi-information display

Shows information with alphanumeric characters when
you adjust the parameters of this unit.

E Input channel indicators

Show information when you adjust the parameters of this
unit. The channel component of the current digital input
signal is displayed (see page 58).

y

You can adjust the brightness and display setting of the front
panel display using the F.DISPLAY SET parameter in MANUAL
SETUP (see page 86).

5

67

E

0 EQUAL indicator

Lights up when the TV volume equal mode is selected
(see page 69).

8 En

Rear panel

AUDIO INPUTANTENNA

AUX 1 TV/STB STB DVD TV/STB

3

4

1

2

FM75Ω
UNBAL.

DOCK

1 ANTENNA jack

Connect the FM antenna (see page 23).

2 DOCK terminal

Connect the Yamaha iPod universal dock (such as YDS­10, sold separately) (see page 53).

3 AUX 1 AUDIO INPUT jacks

Connect an external component via an analog connection
(see page 20).

4 TV/STB AUDIO INPUT jacks

Connect your TV, digital satellite tuner, or cable TV tuner
via an analog connection (see pages 21).

5 VIDEO OUT jack

Connect to the video input jack of your TV via a
composite analog video connection to display the OSD of
this unit (see page 21).

6 SUBWOOFER OUT jack

Connect your subwoofer (see page 22).

7 STB VIDEO INPUT jacks

Connect a digital satellite tuner or a cable TV tuner via a
composite analog video connection (see pages 19).

8 DVD COMPONENT VIDEO INPUT jacks

Connect a DVD player/recorder or an external component
via a component analog video connection (see pages 19
and 20).

9 AUX 2 COAXIAL DIGITAL INPUT jack

Connect an external component via a coaxial digital
connection (see page 20).

OUT

VIDEO

SUBWOOFER

5

6

COMPONENT

7

8

Controls and functions

H

AUX 2 DVD

COAXIAL

OPTICAL

AUX 1

90

IR IN

AB C D

HDMI

STB

DVD

IN

OUT

XMDIGITAL INPUTVIDEO INPUT

0 AUX 1 OPTICAL DIGITAL INPUT jack

Connect an external component via an optical digital
connection (see page 20).

A TV/STB OPTICAL DIGITAL INPUT jack

Connect your TV, digital satellite tuner, or cable TV tuner
via an optical digital connection (see pages 19 and 21).

B DVD COAXIAL DIGITAL INPUT jack

Connect your DVD player via a coaxial digital connection
(see page 19).

C XM antenna jack

Connect your XM Mini-Tuner Home Dock (sold
separately) (see page 47).

D IR IN terminal

This is a control expansion terminal for commercial use
only (see page 23).

E STB HDMI IN jack

Connect your digital satellite tuner, cable TV tuner, digital
airwave tuner, or game console via an HDMI connection
(see page 18).

F DVD HDMI IN jack

Connect your DVD player via an HDMI connection (see
page 18).

G HDMI OUT jack

Connect to the HDMI input jack on your HDMI
component such as a TV or a projector connected to this
unit (see page 18 to 20).

H AC power supply cable

Connect to the AC wall outlet (see page 23).

INTRODUCTION

E

F

G

English

9 En

Controls and functions

Remote control

This section describes the functions of the remote control
used to control this unit. Some buttons marked with an
asterisk (*) share the common functions between the YSP
and TV/AV operation modes (S).

y

You can also control other components using the remote control
once you set the appropriate remote control codes. See
“Controlling other components” on page 95 for details.

1G

POWERPOWERSTANDBY/ON

2

*

3

DVD

4

*

5
6

7

STB

VOL MODE

5BEAM ST+3BEAM

STEREO

4

MUSIC MOVIE

78

OFF

0

ENHANCER MENU

8

9

CAT/
A-E

0

VOLUME

A

*

B

*

C

*

D

MUTE

CH LEVEL TEST

AV

AUX1 AUX2

INPUT1

TV

PRESET/TUNE

CATFM/XM

AUTO

SETUP

INPUTMODE

MY BEAM

5

+10

ENTRY

ENTER

CH

TV INPUT TV MUTE

TV

DOCK

AUX3

TV

MACRO

MEMORYSEARCH

SLEEP

3BEAM

321

MY SUR.

6

SPORTS

9

SUR. DECODE

TV/AV

RETURNDISPLAY

TV VOL

CODE SET

YSP

H
I

J
K
L

M
N

O
P

Q

R

S

t

U

V
W

*
*

*

*

*
*

E
F

1 Infrared window

Outputs infrared control signals. Aim this window at the
component you want to operate.

2 STANDBY/ON

Sets this system to the standby mode (see page 25).

3 Transmission indicator

Lights up when infrared control signals are being output.

4 Input selector buttons

Use to select an input source (DVD, AUX1, AUX2,
AUX3/DOCK, STB, TV, or FM/XM).

5 VOL MODE

Turns on or off the volume modes (see page 69).

6 AUTO SETUP

Enters the AUTO SETUP menu (see page 29).

7 Sound field program buttons

Select the sound field programs (see page 65).

8 ENHANCER

Turns on or off the Music Enhancer (see page 68).

9 Cursor buttons / / / , ENTER

Select and adjust SET MENU items.

0 DISPLAY

Displays information on the selected input signal.

A VOLUME +/–

Increases or decreases the volume level of this unit (see
page 41).

B MUTE

Mutes the sound. Press again to restore the audio output to
the previous volume level (see page 41).

C TV INPUT

Toggles between the input source on your TV (see
page 95).

D CH LEVEL

Adjusts the volume level of each channel (see page 88).

E TEST

Outputs a test tone when adjusting the output level of each
channel (see page 87).

10 En

Controls and functions

F DVD player/VCR control buttons

Control your DVD player or VCR (see pages 95 and 97).

G My Beam microphone

Collects the test tones from this unit when using the My
Beam auto-adjust function (see page 63).

H TV POWER

Turns on or off the power of your TV (see page 95).

I AV POW E R

Turns on or off the power of the selected component (see
pages 95 and 97).

J INPUT1

Switches the input source on your TV (see page 95).

K MACRO

Use to set the TV macro (see page 98).

L a /5

Switches the preset station number (1 to 8) when this unit
is receiving an FM broadcast or XM channel (see
page 46).

M CAT

Switches the preset station group (A to E) when this unit is
receiving an FM broadcast or XM channel (see page 46).

N SLEEP

Sets the sleep timer (see page 70).

O INPUTMODE

Toggles between input modes (AUTO, DTS, and
ANALOG) (see page 90).

P Beam mode buttons

Change the beam mode settings (see pages 56, 62, and

63).

Q SUR. DECODE

Selects the surround mode for playback (see page 59).

R MENU

Displays the setup menu on your TV monitor (see
pages 31 and 75).

S Operation mode selector

Selects the operation mode of this unit. Select YSP when
operating this unit and select TV/AV when operating your
TV or other AV components.

T RETURN

Returns to the previous SET MENU screen.

U TV VOL +/–

Adjusts the volume level of your TV (see page 95).

V CH +/–

Changes the channels of your TV, digital satellite tuner,
cable TV tuner, or VCR (see pages 95 to 97).

W TV MUTE, CODE SET

Mutes the audio output of your TV (see page 95).
Sets up remote control codes (see page 94).

Note

The functions L and M are available only when the FM/XM
stations are preset.

INTRODUCTION

11 En

English

Controls and functions

This section describes the functions of the remote control
used to control FM, XM Satellite Radio, or iPod when the
TV/AV mode is selected with the operation mode selector
(7).

POWERPOWERSTANDBY/ON

AV

TV

1

2

3

AUX1 AUX2

DVD

TV

STB

PRESET/TUNE

CATFM/XM

AUTO

SETUP

VOL MODE

5BEAM ST+3BEAM 3BEAM

STEREO

4

MUSIC MOVIE

78

OFF

0

ENHANCER MENU

CAT/
A-E

INPUTMODE

MY BEAM

5

+10

ENTRY

ENTER

INPUT1

SUR. DECODE

DOCK

AUX3

TV

MACRO

MEMORYSEARCH

SLEEP

321

MY SUR.

6

SPORTS

9

RETURNDISPLAY

TV/AV

YSP

5

6

7

4

VOLUME

MUTE

CH LEVEL TEST

TV VOL

CH

TV INPUT TV MUTE

CODE SET

1 PRESET/TUNE

FM: Switches between the preset search mode and the
frequency search mode (see pages 43 to 46).

2 Numeric buttons

FM, XM: Enter numbers.

3 Cursor buttons / / / , ENTER

FM: Use ENTRY ( / ) to change the preset station
number (1 to 8) or frequency level (see pages 43 to 46).
Use CAT/A-E ( / ) to change the preset station group
(A to E) (see pages 45 and 46).
XM: Use ENTRY ( / ) to select XM channels in
All Channel Search mode/Category Search mode, and to
select the preset channel number (1 to 8) in Preset Search
mode. Use CAT/A-E ( / ) to select XM categories in
All Channel Search mode/Category Search mode, and to
select the preset channel group (A to E) in Preset Search
mode. Use ENTER to confirm the input above (see
pages 49 to 51).

y

For further information on controlling iPod, see page 53.

4 DISPLAY

XM and iPod: Displays information when this unit is
receiving an XM channel (see page 52) or playing back
your iPod (see page 54).

5 MEMORY

FM: Stores the preset stations (see pages 44 and 45).
XM: Use to store the preset stations (see page 51).

6 SEARCH

FM: Switches between automatic and manual tuning (see
page 43).
XM: Switches between search modes (All Channel
Search, Category Search, and Preset Search) (see page 49
and 50).

12 En

7 Operation mode selector

Selects the operation mode of this unit. Select YSP when
operating this unit and select TV/AV when operating your
TV or other AV components.

Installation

Installation

This section describes a suitable installation location to install this unit using a metal wall bracket, a rack or a stand.
Depending on your installation environment, connections with external components can be done before installing this
unit. We recommend that you temporarily place and arrange all components, including this unit, in order to decide which
procedure should come first. Especially when you make a connection over HDMI, we recommend that you make a
connection first before installation (see page 18).

Before installing this unit

This unit creates surround sound by reflecting projected
sound beams off the walls of your listening room. The
surround sound effects produced by this unit may not be
sufficient when this unit is installed in the following
locations.

• Rooms with walls inadequate for reflecting sound
beams

• Rooms with acoustically absorbent walls

• Rooms with measurements outside the following
range: W (3 to 7 m (10 to 23 ft)) x H (2 to 3.5 m (7 to

11.5 ft)) x D (3 to 7 m (10 to 23 ft))

• Rooms with less than 1.8 m (6 ft) from the listening
position to this unit

• Rooms where objects such as furniture are likely to
obstruct the path of sound beams

• Rooms where the listening position is close to the walls

• Rooms where the listening position is not in front of
this unit

y

• You can enjoy surround sound by selecting My Surround (see

page 57) as the beam mode even if your listening room may not
fulfill the above conditions (except when the listening position
is not directly facing toward the front of this unit).

• You can also enjoy surround sound by selecting 2-channel or 5-

channel stereo playback (see page 62) or My Beam (see
page 63) as the beam mode even if your listening room may not
fulfill the above conditions.

Make sure you leave an adequate amount of ventilation
space so that heat can escape. Make at least 5 cm (2 in) of
space above or below this unit.

Side view

Notes

• We do not recommend putting this unit directly on the floor of
your listening room. Please install this unit using a metal wall
bracket, a rack, or a stand.

• This unit weighs 11.5 kg (25 lbs 6 oz). Be sure to install this
unit where it will not fall subject to vibrations, such as from an
earthquake, and where it is out of the reach of children.

• When using a cathode-ray tube (CRT) TV, do not install this
unit directly above your TV.

• This unit is shielded against magnetic rays. However, if the
picture on your TV screen becomes blurred or distorted, we
recommend moving this unit away from your TV.

Installing this unit

Install this unit where there are no obstacles such as
furniture obstructing the path of sound beams. Otherwise,
the desired surround sound effects may not be achieved.
You may install this unit in parallel with the wall or in the
corner.

Parallel installation

Install this unit in the exact center of the wall when it is
measured from the left and right corners.

An object, such as furniture

PREPARATION

Front

5 cm (2 in) or more

Rear

Corner installation

Install this unit in the corner at a 40º to 50º angle from the
adjacent walls.

40° to 50°

English

An object, such as furniture

13 En

Installation

■ Installation examples

Example 1

Install this unit as close to the exact center of the wall as possible.

Example 2

Install this unit so that the sound beams can be reflected off the walls.

Example 3

Install this unit as close to the exact front of your normal listening position as possible.

14 En

Installation

■ Using a metal wall bracket

You can use the optional metal wall bracket to mount this
unit on the wall in your listening room.

Metal wall bracket

This unit

TV

YSP-3050

65

SPM-K30 (Option)

325 65325

24- 7x22

670

92

4- 7

(mm)

y

Refer to the instructions supplied with the metal bracket for
details on how to attach the metal bracket to the wall or how to
attach this unit to the metal bracket.

■ Using a stand

You can mount your TV on a stand placed on a
commercially available rack and install this unit under
your TV.

Stand

■ Using a rack

You can install this unit either above or under your TV in a
commercially available rack.

When this unit is installed above your TV

PREPARATION

112

When this unit is installed under your TV

Note

Make sure that the rack is large enough to allow adequate
ventilation space around this unit (see page 13) and that it is
strong enough to support the weight of both this unit and your TV.

■ Affixing this unit

Peel off the film from each of the four supplied fasteners
and then secure them to the bottom four corners of this
unit and the top of the rack, etc.

This unit

TV

This unit

y

Refer to the instructions supplied with the stand for details on
how to install the stand or how to mount the TV on the stand.

Fasteners

Peel off
the film

2

1

Notes

• Do not install this unit on top of a slanted surface. This unit may
fall over and cause injury.

• Make sure you wipe the surface of the rack, etc. before securing
the fasteners. Applying the tape to a dirty or wet surface will
weaken the sticking power of the tape, and this unit may fall as
a result.

15 En

English

Connections

Connections

This unit is equipped with the following types of audio/video input/output jacks/terminal:

For audio input

• 2 optical digital input jacks

• 2 coaxial digital input jacks

• 2 sets of analog input jacks

• 1 universal dock terminal

For video input

• 1 composite video input jack

• 1 set of component video input jacks

For audio/video input

• 2 HDMI input jacks

Use these jacks/terminal to connect external components such as your TV, DVD player, VCR, digital satellite tuner, cable
TV tuner, digital airwave tuner, portable audio player, game console, and iPod. Further, by connecting a subwoofer to this
unit, you can enjoy reinforced low-bass sounds. For details on how to connect various types of external components to
this unit, see pages 18 to 22.

CAUTION

• Do not connect this unit or other components to the mains power until all connections between components are
complete.

• Unplug the AC power supply cable before changing connections, moving or cleaning this unit.

For audio output

• 1 subwoofer output jack

For video output

• 1 analog output jack

For audio/video output

• 1 HDMI output jack

Audio connection Video connection

TV

This unit

16 En

portable audio

player

or cable TV tuner

VCR or game consoleDVD player Subwoofer Digital satellite tuner

Before connecting components

Connections

■ Cables used for connections

Audio/Video

HDMI cable

A

Audio

Audio pin cable (supplied)

(White)

(Red)

(White)

(Red)

Optical cable (supplied)

Digital audio pin cable (supplied)

(Orange)(Orange)

3.5 mm stereo mini plug cable

Subwoofer pin cable

5

Video

OSD video pin cable (supplied)/ Video pin cable

(Yellow)(Yellow)

Component video pin cable

(Green)

(Blue)

(Red)

(Green)

(Blue)

(Red)

■ Notes on connecting the optical cable

• Pull out the cap before connecting the optical cable.
When you are not using the optical cable, be sure to put the cap
back in place.

• When inserting the cable into the optical digital jack, make sure
the direction is correct.

■ Affixing cables

To prevent cables from becoming unplugged, place the supplied
cable clamp with the open side facing upward, attach it to the rear
panel of this unit in a suitable position, and then affix cables in
the cable clamp.

Optical cable

Attach to this unit

■ Information on HDMI™

Audio signals

Input source Audio signal type

DVD video Dolby Digital, DTS, PCM

DVD audio

Blu-ray Disc

HD DVD

2-channel stereo

(up to 96 kHz/24 bit)

Dolby Digital, DTS, PCM

Notes

•

When CPPM copy-protected DVD audio is played back, video and
audio signals may not be output depending on the type of DVD player.

• This unit is not compatible with HDCP-incompatible HDMI or
DVI components.

y

• We recommend that you use an HDMI cable shorter than 5 m
(16 ft) with the HDMI logo printed on it.

• Use a conversion cable (HDMI jack
this unit to other DVI components.

↔ DVI-D jack) to connect

■ Priority order for audio input signals

When multiple types of audio signals are simultaneously
being input from a single source component, this unit
plays back the audio signals in the following priority
order: HDMI → Digital → Analog
As default settings, the following input jacks are assigned
to the corresponding input sources:

Input

jack

Input
source

TV/STB ✔✔✔

DVD ✔✔

AUX 1 ✔✔

AUX 2 ✔

AUX 3 ✔

HDMI Digital Analog

PREPARATION

English

Cap

Note

This unit is compatible with 2-channel PCM signals, but not with
multi-channel PCM signals.

17 En

Connections

Case 1: Connections using HDMI cables

This unit is equipped with 2 HDMI input jacks and 1 HDMI output jack. If your TV and other components have HDMI
jacks, use HDMI cables for simpler and easier connections, and you can skip the connection procedures from page 19 to

21. If your TV has a built-in digital satellite tuner and an optical digital output jack, connect the optical digital output jack
on your TV to the TV/STB OPTICAL DIGITAL IN jack on this unit.

y

• We recommend that you secure the HDMI cable(s) with adhesive tape, etc. once you have connected the HDMI cable(s) to the HDMI
jack(s) of this unit.

• This unit outputs analog video signals input at the video/component video jacks at the HDMI OUT jack. Similarly, this unit outputs
analog audio signals input at the analog input jacks at the HDMI OUT jack.

Rear panel of this unit

*

If TV built-in tuner is
used, connect the optical
digital output jack on your
TV to the TV/STB
OPTICAL DIGITAL
INPUT jack on this unit
(see page 21).

HDMI

input

TV

STB

DVD

IN

OUT

HDMI

HDMI

output

DVD player/recorder

*

This connection (except
for a game console) is not
necessary if your TV has a
built-in digital satellite
tuner, cable TV tuner, or
digital airwave tuner.

Digital satellite tuner,

digital airwave tuner,

or game console

AAA

HDMI

output

cable TV tuner,

HDMI cable

A

18 En

Audio/Video

Connections

Case 2: Connecting a DVD player/recorder and tuner (digital satellite,

cable TV or digital airwave)

For audio connection, connect the coaxial digital output jack on your DVD player/recorder to the DVD COAXIAL
DIGITAL INPUT jack on this unit. When you connect this unit to your DVD/VCR combo player/recorder, connect the
analog audio output jacks on your DVD/VCR combo player/recorder to the AUX 1 AUDIO INPUT jacks on this unit in
addition to the coaxial digital audio connection. Connect the optical digital output jack on your tuner (digital satellite,
cable TV or digital airwave) to the TV/STB OPTICAL DIGITAL INPUT on this unit.
For video connection, connect the component video output jack of your DVD player/recorder to the COMPONENT
VIDEO INPUT jacks on this unit. Connect the video output jack on your tuner (digital satellite, cable TV) to the STB
VIDEO INPUT jack on this unit.
Connect the HDMI input jack on your TV to the HDMI OUT jack.

y

To prevent the optical cable from being unplugged, affix the optical cable in the supplied cable clamp (see page 17).

Notes

• Check that your DVD player/recorder is properly set to output Dolby Digital and DTS digital audio signals. If not, adjust the system
settings of your DVD player/recorder. For details, refer to the operation manual supplied with your DVD player/recorder.

• If your DVD player/recorder does not have a coaxial digital output jack, connect the analog audio output jacks on your DVD player/
recorder to the AUX 1 AUDIO INPUT jacks on this unit.

Rear panel of this unit

OUTAUDIO INPUT

VIDEO

COMPONENT

DIGITAL INPUTVIDEO INPUT

AUX 2 DVD

COAXIAL

STB

PREPARATION

AUX 1 TV/STB STB DVD TV/STB

Digital satellite tuner, cable TV tuner,

digital airwave tuner, or game console

SUBWOOFER

Video

output

Optical

digital

output

Audio/Video

HDMI cable

A

Video

OPTICAL

AUX 1

Component

video output

DVD player/recorder

DVD

IN

OUT

HDMI

32

Coaxial

digital
output

Audio

Optical cable

Digital audio pin cable

A

HDMI
input

TV

English

OSD video pin cable

Component video pin cable

19 En

Connections

Case 3: Connecting other connection methods

If your component supports optical digital connections, connect the optical digital output jack on your component
(e.g., DVD player/recorder) to the AUX 1 OPTICAL DIGITAL INPUT jack on this unit. If your component does not
support optical digital connections, connect the coaxial digital output jack on your component to the AUX 2 COAXIAL
DIGITAL INPUT jack on this unit.
If your component does not support any digital connections, connect the analog audio output jacks on your component
(e.g., VCR) to the AUX 1 AUDIO INPUT jacks on this unit.

y

To prevent the optical cable from being unplugged, affix the optical cable in the supplied cable clamp (see page 17).

Note

If you make analog and digital audio connections at the same time as shown in the illustration below, the digital audio signals input at
the AUX 1 OPTICAL DIGITAL INPUT jack take priority over the analog audio signals input at the AUX 1 AUDIO INPUT jacks.

Rear panel of this unit

OUTAUDIO INPUT

VIDEO

AUX 1 TV/STB STB DVD TV/STB

RL

Analog audio

output

DVD player/recorder, VCR,

game console, CD player, etc.

SUBWOOFER

COMPONENT

Coaxial

digital

output

DIGITAL INPUTVIDEO INPUT

AUX 2 DVD

COAXIAL

OPTICAL

AUX 1

21 3

Optical

digital

output

Video signal to the TV

Video

input

Video Audio

OSD video pin cable Audio pin cable

Optical cable

Digital audio pin cable

20 En

TV

Connections

Connecting a TV without an HDMI cable

For audio connection, connect the analog audio output jacks on your TV to the TV/STB AUDIO INPUT jacks on this
unit. If your TV has an optical digital output jack, connect the optical digital output jack on your TV to the TV/STB
OPTICAL DIGITAL INPUT jack on this unit.
For video connection, connect the video input jack on your TV to the VIDEO OUT jack on this unit to display the OSD
for easy viewing when you adjust the system parameters in SET MENU.

y

To prevent the optical cable from being unplugged, affix the optical cable in the supplied cable clamp (see page 17).

Notes

If you make analog and optical digital audio connections at the same time as shown in the illustration below, the digital audio signals
input at the TV/STB OPTICAL DIGITAL INPUT jack take priority over the analog audio signals input at the TV/STB AUDIO INPUT
jacks.

Rear panel of this unit

PREPARATION

OUTAUDIO INPUT

VIDEO

AUX 1 TV/STB STB DVD TV/STB

RL

Analog audio

SUBWOOFER

output

Video

input

COMPONENT

DIGITAL INPUTVIDEO INPUT

AUX 2 DVD

AUX 1

Optical

digital
output

COAXIAL

OPTICAL

TV

Video Audio

OSD video pin cable Audio pin cable

Optical cable

English

21 En

Connections

Connecting a portable audio player

Connect the analog audio output jack on your portable
audio player to the AUX 3 input jack on the front panel of
this unit.

Front panel of this unit

AUX 3

Connecting a subwoofer

Connect the monaural input jack on your subwoofer to the
SUBWOOFER OUT jack on this unit.
This connection alone does not output sound from the
connected subwoofer. To output sound from the connected
subwoofer, turn on the power of your subwoofer and then
run AUTO SETUP (see page 29) or select SUBWOOFER
for BASS OUT in SUBWOOFER SET (see page 80).

Rear panel of this unit

OUTAUDIO INPUT

VIDEO INPUT

VIDEO

AUX 1 TV/STB STB DVD

SUBWOOFER

COMPONENT

5

Portable audio player

Audio

3.5 mm stereo mini plug cable

22 En

Analog

audio

output

Subwoofer pin cable

5

Monaural

Subwoofer

Audio

input

Connecting the FM antenna

Connect the supplied FM antenna to the FM ANTENNA jack on this unit.

FM indoor antenna (supplied)

Rear panel of this unit

Connections

FM75Ω
UNBAL.

DOCK

AUDIO INPUTANTENNA

AUX 1 TV/STB STB DVD

OUT

VIDEO

SUBWOOFER

VIDEO INPUT

COMPONENT

About the IR IN jack

The IR IN jack does not support normal external component connection. This is a control expansion terminal for
commercial use only.

IR IN

AUX 2 DVD

COAXIAL

OPTICAL

AUX 1

TV/STB

Rear panel of this unit

XMDIGITAL INPUT

IR IN

PREPARATION

Connecting the AC power supply cable

Once all other connections are complete, plug the AC power supply cable into the AC wall outlet.

To the AC wall outlet

English

23 En

GETTING STARTED

Getting started

Installing batteries in the remote control

Press

1 Press and hold the mark on the battery

cover and then open the cover.

y

Remove the transparent sheet before using the remote control.

Operation range of the remote control

The remote control transmits a directional infrared beam.
Use the remote control within 6 m (20 ft) of this unit and
point it toward the remote control sensor of this unit
during operation.

2 Insert the two supplied batteries (AA, R6,

UM-3) into the battery compartment.

Make sure you insert the batteries according to the
polarity markings (+/–).

3 Close the battery cover.

Notes

• Change all of the batteries if you notice the following
conditions: the operation range of the remote control decreases
or the transmission indicator does not light up or becomes dim.

• Do not use old batteries together with new ones.

• Do not use different types of batteries (such as alkaline and
manganese batteries) together. Read the packaging carefully as
these different types of batteries may have the same shape and
color.

• Exhausted batteries may leak. If the batteries have leaked,
dispose of them immediately. Avoid touching the leaked
material or letting it come into contact with clothing, etc. Clean
the battery compartment thoroughly before installing new
batteries.

• Do not throw away batteries with general house waste. Dispose
of them correctly in accordance with your local regulations.

• The memory stored in the remote control may be erased in the
following cases:
– The remote control is left without batteries for more than two

minutes.
– Exhausted batteries remain in the remote control.
– The buttons on the remote control are accidentally pressed

when you change batteries.

• If the memory stored in the remote control is unwantedly
erased, insert new batteries and set the remote control codes
again.

Approximately
6 m (20 ft)

45 45

Notes

• Do not spill water or other liquids on the remote control.

• Do not drop the remote control.

• Do not leave or store the remote control in the following places:
– places of high humidity, such as near a bath
– places of high temperatures, such as near a heater or a stove
– places of extremely low temperatures
– dusty places

• Do not expose the remote control sensor of this unit to direct
sunlight or lighting such as inverted fluorescent lamps.

• If the batteries grow old, the effective operation range of the
remote control decreases considerably. If this happens, replace
the batteries with two new ones as soon as possible.

24 En

Getting started

Turning on this unit or setting it to the standby mode

INPUT

+

STANDBY/ON

VOLUME

POWERPOWERSTANDBY/ON

AV

TV

DVD

STB

AUX1 AUX2

TV

PRESET/TUNE

CATFM/XM

INPUT1

TV

DOCK

AUX3

MACRO

MEMORYSEARCH

2 Press STANDBY/ON again to set this unit to

the standby mode.

Note

When this unit is in the standby mode, only STANDBY/ON on
the front panel or on the remote control is operational, and the
other control buttons on the front panel or on the remote control
are not operational until the power of this unit is turned on.

SETUP

1 Press STANDBY/ON to turn on the power of

this unit.

The volume level appears in the front panel display,
and the current input source and beam mode are
displayed.

STANDBY/ON

STANDBY/ON

Front panel

or

Remote control

VOLUME 30

Current volume level

TV/STB MY SUR

Current input

source

Current beam
mode

English

25 En

USING SET MENU

Using SET MENU

Displaying the OSD (on-screen display)

This section describes how to display the OSD (on-screen display) of this unit on your TV screen and to set the
parameters for your listening room. Once this is complete, you can enjoy real surround sound while watching TV in the
comfort of your own home.

1 Check that the video input jack on your TV is

connected to the VIDEO OUT jack on this unit
to display the OSD of this unit.

2 Press STANDBY/ON to turn on the power of

this unit.

STANDBY/ON

STANDBY/ON

Front panel

or

Remote control

3 Turn on the power of your TV.

4 Set the operation mode selector to YSP.

TV/AV

YSP

5 Press MENU.

The SET MENU screen appears on your TV.

SET MENU

;MEMORY

MENU

.

;AUTO SETUP
;MANUAL SETUP
;LANGUAGE SETUP

p

[ ]/[ ]:Up/Down

p

[ENTER]:Enter

26 En
