Page 1
2010 WaveRunner
SuperJet
OWNER’S/OPERATOR’S MANUAL
Read this manual carefully
before operating this watercraft.
U.S.A. Edition
LIT-18626-08-63
F2F-28199-12
Page 2
Read this manual carefully before operating this watercraft. This manual
should stay with the WaveRunner if it is sold.
Page 3
Important manual information
EJU30182
To the owner/operator
Thank you for choosing a Yamaha watercraft.
This owner’s/operator’s manual contains information you will need for proper operation,
maintenance, and care. A thorough understanding of these simple instructions will help
you to obtain maximum enjoyment from your
new Yamaha. If you have any questions
about the operation or maintenance of your
watercraft, please consult a Yamaha dealer.
In this manual, information of particular importance is distinguished in the following ways:
This is the safety alert symbol. It is used
to alert you to potential personal injury hazards. Obey all safety messages that follow
this symbol to avoid possible injury or death.
EWJ00071
WARNING
A WARNING indicates a hazardous situation which, if not avoided, could result in
death or serious injury.
ECJ00091
NOTICE
A NOTICE indicates special precautions
that must be taken to avoid damage to the
watercraft or other property.
EJU40400
Because Yamaha has a policy of continuing
product improvement, this product may not be
exactly as described in this owner’s/operator’s manual. Specifications are subject to
change without notice.
This manual should be considered a permanent part of this watercraft and should remain
with it even if the watercraft is subsequently
sold.
EJU30203
WaveRunner SuperJet
OWNER’S/OPERATOR’S MANUAL
©2009 by Yamaha Motor Corporation,
U.S.A.
1st Edition, June 2009
All rights reserved.
Any reprinting or unauthorized use
without the written permission of
Yamaha Motor Corporation, U.S.A.
is expressly prohibited.
Printed in Japan
P/N LIT-18626-08-63
TIP:
A TIP provides key information to make procedures easier or clearer.
Page 4
Table of contents
General and important labels........... 1
Identification numbers .................... 1
Primary Identification (PRI-ID)
number ........................................... 1
Hull Identification Number (HIN) ........ 1
Engine serial number ........................ 1
Emission control information .......... 2
Approval label of emission control
certificate ........................................ 2
Manufactured date label .................... 2
Important labels .............................. 3
Warning labels ................................... 4
Other labels ....................................... 6
Safety information............................. 7
Limitations on who may operate
the watercraft .............................. 7
Cruising limitations ......................... 8
Operation requirements ................. 9
Recommended equipment ........... 11
Hazard information ....................... 12
Watercraft characteristics ............. 12
Rules of the Road ........................ 13
To get more boating safety
information ................................ 17
Enjoy your watercraft
responsibly ................................ 18
Description....................................... 20
Watercraft glossary ...................... 20
Location of main components ...... 21
Control function operation .............23
Watercraft control functions ......... 23
Engine stop switch .......................... 23
Engine shut-off switch ..................... 23
Start switch ...................................... 23
Throttle lever ................................... 24
Steering system ............................... 24
Steering pole ................................... 24
Fuel cock knob ................................ 24
Choke knob ..................................... 25
Cooling water pilot outlet ................. 25
Water separator ............................... 26
Engine overheat warning system .... 26
Equipment operation ...................... 27
Equipment .................................... 27
Hood ................................................ 27
Bow rope hole ................................. 28
Stern rope hole ................................ 28
Storage pouch ................................. 28
Fire extinguisher container .............. 29
Operation and handling
requirements ................................... 31
Fuel and engine oil
requirements ............................. 31
Fuel ................................................. 31
2-stroke engine oil ........................... 31
Mixing fuel and oil ............................ 31
Filling the fuel tank .......................... 32
Draining the bilge water ............... 33
Draining the bilge water on water .... 33
Transporting ................................. 33
First-time operation ........................ 35
Engine break-in ............................ 35
Pre-operation checks ..................... 36
Pre-operation checklist .................... 36
Pre-operation check points .......... 38
Pre-launch checks ........................... 38
Post-launch checks ......................... 42
Operation ......................................... 44
Operating your watercraft ............ 44
Getting to know your watercraft ....... 44
Learning to operate
your watercraft ............................. 44
Operating positions ......................... 44
Launching the watercraft ................. 45
Starting the engine on water ........... 45
Stopping the engine ........................ 47
Leaving the watercraft ..................... 47
Operating the watercraft .................. 47
Page 5
Table of contents
Turning the watercraft ..................... 47
Stopping the watercraft ................... 49
Starting off ....................................... 49
Capsized watercraft ......................... 52
Beaching the watercraft ................... 53
Operating in weeded areas ............. 53
After removing the watercraft
from the water .............................. 53
Care and storage ............................. 54
Post-operation care ...................... 54
Flushing the cooling water
passages ...................................... 54
Cleaning the watercraft ................... 55
Battery care ..................................... 55
Long-term storage ........................ 58
Cleaning .......................................... 58
Lubrication ....................................... 58
Rustproofing .................................... 59
Maintenance..................................... 60
Maintenance ................................. 60
Tool kit ............................................. 60
Adjusting the steering friction .......... 60
Adjusting the jet thrust nozzle
angle ............................................ 61
Periodic maintenance chart ............. 63
Lubrication points ............................ 64
Checking the fuel filter ..................... 64
Checking the spark plugs ................ 64
Adjusting the choke cable ............... 65
Adjusting the carburetor .................. 66
Towing the watercraft ...................... 72
Submerged watercraft ..................... 72
Consumer information ................... 74
Limited warranty ........................... 74
YAMAHA EXTENDED SERVICE
(Y.E.S.) ..................................... 76
Specifications .................................. 67
Specifications ................................ 67
Trouble recovery ............................. 68
Troubleshooting ........................... 68
Troubleshooting chart ...................... 68
Emergency procedures ................ 70
Cleaning the jet intake and
impeller ........................................ 70
Jumping the battery ......................... 71
Replacing the fuse ........................... 71
Page 6
General and important labels
EJU30261
Identification numbers
Record the Primary Identification (PRI-ID)
number, Hull Identification Number (HIN), and
engine serial number in the spaces provided
for assistance when ordering genuine parts
from a Yamaha dealer. Also record and keep
these ID numbers in a separate place in case
your watercraft is stolen.
EJU30271
Primary Identification (PRI-ID) number
The PRI-ID number is stamped on a plate attached inside the engine compartment. (See
page 27 for hood removal and installation procedures.)
MODEL:
SJ700B-J (SuperJet)
EJU30290
Hull Identification Number (HIN)
The HIN is stamped on a plate attached to the
hull on the aft, starboard (right) side.
1 Hull Identification Number (HIN) location
EJU40640
Engine serial number
The engine serial number is stamped on a
plate attached to the engine unit. (See page
27 for hood removal and installation procedures.)
1 Primary Identification (PRI-ID) number loca-
tion
1
1 Engine serial number location
Page 7
General and important labels
EJU30342
Emission control information
This engine conforms to U.S. Environmental
Protection Agency (EPA) regulations for marine SI engines applicable at the time of manufacture.
EJU30371
Approval label of emission control
certificate
This label is attached to the electrical box and
muffler. (See page 27 for Hood removal and
installation procedures.)
1 Emission control information label location
EJU30411
Manufactured date label
This label is attached to the electrical box and
muffler. (See page 27 for hood removal and
installation procedures.)
1 Manufactured date label location
1 Emission control information label location
1 Manufactured date label location
2
Page 8
General and important labels
EJU30452
Important labels
Read the following labels before using this watercraft. If have any questions, consult a Yamaha
dealer.
3
Page 9
General and important labels
EJU35912
Warning labels
If any of these labels are damaged or missing, contact a Yamaha dealer for replacements.
4
Page 10
General and important labels
5
Page 11
EJU35924
Other labels
General and important labels
The following label indicates the correct direction to upright a capsized watercraft.
6
Page 12
Safety information
EJU30671
The safe use and operation of this watercraft is dependent upon the use of proper
riding techniques, as well as upon the
common sense, good judgment, and expertise of the operator. Every operator
should know the following requirements
before riding the watercraft.
● Before operating the watercraft, read this
owner’s/operator’s manual, the Riding
Practice Guide, the Riding Instruction card,
and all labels on the watercraft. Also, watch
the Basic Orientation Video provided with
your watercraft. These materials should
give you an understanding of the watercraft
and its operation.
● Never allow anyone to operate this water-
craft until they too have read this owner’s/operator’s manual, the Riding Practice
Guide, the Riding Instruction card, and all
labels, and, if possible, watched the Basic
Orientation Video.
Showing them the video may help reinforce
the information contained in these materials.
EJU30690
Limitations on who may
operate the watercraft
● Yamaha recommends a minimum operator
age of 16 years old.
Adults must supervise use by minors.
Know the operator age and training requirements for your state. A boating safety
course is recommended and may be required in your state. You can find local rules
by contacting the United States Coast
Guard (USCG), the National Association of
State Boating Law Administrators, or your
local Power Squadron.
● This watercraft is designed to carry the op-
erator only. Never have more than one person on the watercraft at any time.
7
Page 13
Safety information
EJU30761
Cruising limitations
● Scan constantly for people, objects, and
other watercraft. Be alert for conditions that
limit your visibility or block your vision of
others.
● Operate defensively at safe speeds and
keep a safe distance away from people, objects, and other watercraft.
● Do not follow directly behind watercraft or
other boats.
● Do not go near others to spray or splash
them with water.
● Avoid sharp turns or other maneuvers that
make it hard for others to avoid you or understand where you are going.
● Avoid areas with submerged objects or
shallow water.
● Take early action to avoid collisions. Re-
member, watercraft and other boats do not
have brakes.
● Do not release the throttle lever when trying
to steer away from objects—you need throttle to steer. Always check throttle and steering controls before starting the watercraft.
● Ride within your limits and avoid aggressive
maneuvers to reduce the risk of loss of control, ejection, and collision.
● This is a high performance boat—not a toy.
Sharp turns or jumping wakes or waves can
increase the risk of back/spinal injury (paralysis), facial injuries, and broken legs, an-
kles, and other bones. Do not jump wakes
or waves.
● Do not operate the watercraft in rough wa-
ter, bad weather, or when visibility is poor;
this may lead to an accident causing injury
or death. Be alert to the possibility of adverse weather. Take note of weather forecasts and the prevailing weather conditions
before setting out on your watercraft.
● As with any water sport, you should not op-
erate your watercraft without someone else
nearby. If you operate further than swimming distance from shore, you should be
accompanied by another boat or watercraft,
but make sure you stay a safe distance
away. It’s good, common sense.
● Never operate in water that is less than 60
cm (2 ft) deep from the bottom of the watercraft, otherwise you increase your chance
of hitting a submerged object, which could
result in injury.
● This watercraft is not equipped with lighting
required for night operation. Do not operate
the watercraft after sunset or before dawn,
otherwise you increase the risk of colliding
8
Page 14
Safety information
with another boat, which could result in severe injury or death.
● Follow navigation rules, and state/provin-
cial and local laws that apply to watercraft.
EJU30771
Operation requirements
● All riders must wear a U.S. Coast Guard
(USCG) approved personal flotation device
(PFD) that is suitable for personal watercraft use.
● Wear protective clothing. Severe internal
injuries can occur if water is forced into
body cavities as a result of falling into the
water or being near the jet thrust nozzle.
Normal swimwear does not adequately protect against forceful water entry into the rectum or vagina. All riders must wear a
wetsuit bottom or clothing that provides
equivalent protection. Such clothing includes thick, tightly woven, sturdy and
snug-fitting apparel such as denim, but
does not include spandex or similar fabrics,
like those used in bicycle shorts.
1 USCG approved PFD
2 Wetsuit bottom
● Eye protection is recommended to keep
wind, water, and glare from the sun out of
your eyes while you operate your watercraft. Restraining straps for eyewear are
made which are designed to float should
your eyewear fall in the water.
Footwear and gloves are recommended.
● Helmets meeting Snell or DOT standards
are required for IJSBA-sanctioned races.
You must decide whether to wear a helmet
while you ride for recreation. You should
9
Page 15
Safety information
know that a helmet could help protect you in
certain kinds of accidents and that it could
injure you in others.
A helmet is designed to provide some head
protection. Although helmets cannot protect
against all foreseeable impacts, a helmet
might reduce your injuries in a collision with
a boat or other obstacle.
A helmet may have potential safety hazards, as well. Falling into the water could
risk the chance of the helmet catching water, commonly known as “bucketing”, and
the resulting strain on your neck could
cause choking, severe and permanent neck
injuries, or death. A helmet could also increase the risk of an accident if it reduces
your vision or hearing, or if it distracts you or
increases your fatigue.
How should you decide if a helmet’s potential safety benefits outweigh its potential
risks for you? Consider your particular
riding conditions. Consider factors such as
your riding environment and your riding
style and ability. Also consider the likelihood of traffic congestion, and the water
surface conditions. If you decide to wear a
helmet based upon your riding circumstances, choose one carefully. Look for a
helmet designed for personal watercraft
use, if possible. Consider a helmet meeting
Snell or DOT standards. If you will be engaging in closed-course competition, follow
the helmet requirements of the sanctioning
organization.
● Never operate the watercraft after consum-
ing alcohol or taking other drugs.
● For reasons of safety and proper care of the
watercraft, always perform the pre-operation checks listed on page 36 before operating the watercraft.
● The operator should always keep both feet
or knees on the riding tray when the watercraft is in motion. Lifting your feet increases
the chances of losing your balance or hitting
objects outside the watercraft with your
feet.
● Always consult your doctor on whether it is
safe for you to operate this watercraft if you
are pregnant or in poor health.
● Do not attempt to modify this watercraft.
Modifications to your watercraft may reduce
safety and reliability, and render the watercraft unsafe or illegal for use.
● Attach the engine shut-off cord (lanyard) to
your left wrist and keep it free from the handlebars so that the engine stops if you, the
operator, fall off. After riding, remove the
engine shut-off cord (lanyard) from the watercraft to avoid accidental starting or unauthorized use by children or others.
10
Page 16
Safety information
● Scan carefully for swimmers, and stay
away from swimming areas. Swimmers are
hard to see and you could accidentally hit
someone in the water.
● Avoid being hit by another boat. You should
always take the responsibility to watch for
traffic; other boaters may not be watching
for you. If they do not see you, or if you maneuver more quickly than other boaters expect, you risk a collision.
● Maintain a safe distance from other boats
and watercraft, and also watch for ski ropes
or fishing lines. Obey the “Rules of the
Road” and be sure to check behind you before making a turn. (See “Rules of the
Road” on page 13.)
● According to the USCG, boats under 6.1 m
(20 ft) in length like your watercraft must
carry a fire extinguisher of a B-1 classification, with a capacity of two pounds or more
when navigating in waters under USCG jurisdiction. In addition, most state and local
boating laws also require that the fire extinguisher be approved by the USCG.
EJU30830
Recommended equipment
The following items should be carried on
board your watercraft:
● Sound-signaling device
You should carry a whistle or other soundsignaling device that can be used to signal
other boats. See “Rules of the Road” for
more information.
● Visual distress signals
It is recommended that a U.S. Coast Guard
approved pyrotechnic device be stored in a
waterproof container on your watercraft. A
mirror can also be used as an emergency
signal. Contact a Yamaha dealer or the
U.S. Coast Guard for more information.
● Watch
A watch is helpful so you will know how long
you have been operating the watercraft.
● Towline
A towline can be used to tow a disabled watercraft in an emergency.
11
Page 17
Safety information
EJU30850
Hazard information
● When transporting or storing your water-
craft, always turn the fuel cock knob to
“OFF”, otherwise gasoline may overflow
from the carburetor.
● Never start the engine or let it run for any
length of time in an enclosed area. Exhaust
fumes contain carbon monoxide, a colorless, odorless gas that may cause loss of
consciousness and death within a short
time. Always operate the watercraft in an
open area.
EJU30880
Watercraft characteristics
● Jet thrust turns the watercraft. Releasing
the throttle lever completely produces only
minimum thrust. If you are traveling at
speeds above trolling, you will have rapidly
decreasing ability to steer without throttle.
You may still have some turning ability immediately after releasing the throttle lever,
but once the engine slows down, the watercraft will no longer respond to handlebar input until you apply throttle again or you
reach trolling speed.
Practice turning in an open area without obstacles until you have a good feel for this
maneuver.
● This watercraft is water-jet propelled. The
jet pump is directly connected to the engine.
This means that jet thrust will produce some
movement whenever the engine is running.
There is no “neutral” position.
● Keep away from the intake grate while the
engine is on. Items such as long hair, loose
clothing, or PFD straps can become entangled in moving parts, resulting in severe injury or drowning.
● Never insert any object into the jet thrust
nozzle while the engine is running. Severe
injury or death could result from coming in
12
Page 18
Safety information
contact with the rotating parts of the jet
pump.
1 Intake grate
2 Jet thrust nozzle
● Stop the engine and remove the clip from
the engine shut-off switch before removing
any debris or weeds, which may have collected around the jet intake.
1 Clip
2 Engine shut-off switch
● Avoid forceful jet thrust and limited visibility
while reboarding. Get to a standing or
kneeling position quickly, but do not expose
yourself to the forceful jet thrust.
EJU30961
Rules of the Road
Your Yamaha watercraft is legally considered a powerboat. Operation of the watercraft must be in accordance with the rules
and regulations governing the waterway
on which it is used.
Just as there are rules that apply when you
are driving on streets and highways, there are
waterway rules that apply when you are operating your watercraft. These rules are used internationally, and are also enforced by the
United States Coast Guard and local agencies. You should be aware of these rules, and
follow them whenever you encounter another
vessel on the water.
Several sets of rules prevail according to geographic location, but are all basically the same
as the International Rules of the Road. The
rules presented here in this owner’s/opera-
tor’s manual are condensed, and have been
provided for your convenience only. Consult
your local U.S. Coast Guard Auxiliary or Department of Motor Vehicles for a complete set
of rules governing the waters in which you will
be operating your watercraft.
Steering and sailing rules
Whenever two vessels on the water meet one
another, one vessel has the right-of-way; it is
called the “stand-on” vessel. The vessel that
does not have the right-of-way is called the
“give-way” or “burdened” vessel. These rules
determine which vessel has the right-of-way,
and what each vessel should do.
Stand-on vessel
The vessel with the right-of-way has the duty
to continue its course and speed, except to
avoid an immediate collision. When you maintain your direction and speed, the other vessel
will be able to determine how best to avoid
you.
13
Page 19
Safety information
Give-way vessel
The vessel which does not have the right-ofway has the duty to take positive and timely
action to stay out of the way of the stand-on
vessel. Normally, you should not cross in front
of the vessel with the right-of-way. You should
slow down or change directions briefly and
pass behind the other vessel. You should always move in such a way that the operator of
the other vessel can see what you are doing.
The General Prudential Rule regarding the
right-of-way is that if a collision appears unavoidable, neither boat has the right-of-way.
Both boats must avoid the collision.
In other words, follow the standard rules except when a collision will occur unless both
vessels try to avoid each other. If that is the
case, both vessels become give-way vessels.
Rules when encountering vessels
There are three main situations that you may
encounter with other vessels which could lead
to a collision unless the Steering Rules are followed:
Meeting: you are approaching another vessel
head-on
Crossing: you are traveling across another
vessel’s path
Overtaking: you are passing or being passed
by another vessel
In the following illustration, your watercraft is
in the center. You should give the right-of-way
to any vessels shown in the white area (you
are the give-way vessel). Any vessels in the
shaded area must yield to you (they are the
give-way vessels). Both you and the meeting
vessel must alter course to avoid each other.
Meeting
If you are meeting another power-driven vessel head on, and are close enough to run the
risk of collision, neither of you has the right-ofway. Both of you should alter course to avoid
an accident. You should keep the other vessel
on your port (left) side. This rule does not apply if both of you will clear one another if you
continue on your set course and speed.
Crossing
When two power-driven vessels are crossing
each other’s path close enough to run the risk
of collision, the vessel which has the other on
the starboard (right) side must keep out of the
way of the other. If the other vessel is on your
starboard (right) side, you must keep out of its
way; you are the give-way vessel. If the other
vessel is on your port (left) side, remember
that you should maintain course and direction,
14
Page 20
Safety information
provided the other vessel gives you the rightof-way as it should.
Overtaking
If you are passing another vessel, you are the
give-way vessel. This means that the other
vessel is expected to maintain its course and
speed. You must stay out of its way until you
are clear of it. Likewise, if another vessel is
passing you, you should maintain your speed
and direction so that the other vessel can
steer itself around you.
Other special situations
There are three other rules you should be
aware of when riding your watercraft around
other vessels.
Narrow channels and bends
When navigating in narrow channels, you
should keep to the right when it is safe and
practical to do so. If the operator of a powerdriven vessel is preparing to go around a
bend that may obstruct the view of other water
vessels, the operator should sound a prolonged blast of four to six seconds on the
whistle. If another vessel is around the bend,
it too should sound the whistle. Even if no reply is heard, however, the vessel should still
proceed around the bend with caution. If you
navigate such waters with your watercraft,
you will need to carry a portable air horn,
available from local marine supply stores.
Fishing vessel right-of-way
All vessels fishing with nets, lines, or trawls
are considered to be “fishing vessels” under
the International Rules. Vessels with trolling
lines are not considered fishing vessels. Fishing vessels have the right-of-way regardless
of position. Fishing vessels cannot, however,
impede the passage of other vessels in narrow channels.
Sailing vessel right-of-way
Sailing vessels should normally be given the
right-of-way. The exceptions to this are:
(1) When the sailing vessel is overtaking the
power-driven vessel, the power-driven
vessel has the right-of-way.
(2) Sailing vessels should keep clear of any
fishing vessel.
(3) In a narrow channel, a sailing vessel
should not hamper the safe passage of a
power-driven vessel that can navigate
only in such a channel.
Reading buoys and other markers
The waters of the United States are marked
for safe navigation by the lateral system of
buoyage. Simply put, buoys and markers
have an arrangement of shapes, colors, numbers, and lights to show which side of the
buoy a boater should pass on when navigating in a particular direction. The markings on
these buoys are oriented from the perspective
of being entered from seaward (the boater is
going towards the harbor). Red buoys are
passed on your starboard (right) side when
proceeding from open water into the harbor,
and black buoys are to your port (left) side. An
easy way to remember the meaning of the
colors is the phrase “red right returning”.
When navigating out of the harbor, your position with respect to the buoys should be reversed; red buoys should be to port and black
buoys to starboard.
15
Page 21
Safety information
Many bodies of water used by boaters are entirely within the boundaries of a particular
state. The Uniform State Waterway Marking
System has been devised for these waters.
This system uses buoys and signs with distinctive shapes and colors to show regulatory
or advisory information. These markers are
white with black letters and orange borders.
They signify speed zones, restricted areas,
danger areas, and general information.
16
Page 22
Safety information
Remember, markings may vary by geographic location. Always consult local boating authorities before riding your watercraft in
unfamiliar waters.
EJU30982
To get more boating safety
information
Be informed about boating safety. Additional
publications and information can be obtained
from many organizations, including the following.
United States Coast Guard
Consumer Affairs Staff (G-BC)
Office of Boating, Public, and Consumer Affairs
U.S. Coast Guard Headquarters
Washington, D.C. 20593-0001
http://www.uscgboating.org/
Other sources
You can find local rules by contacting the National Association of State Boating Law Administrators, or your local Power Squadron.
Watercraft Education and Training
The Online Boating Safety Course, available
through the watercraft section of the yamahamotor.com website, is a free, 50 question
learning course available to the public. Upon
successful completion of 80 percent or better,
the user can request a certificate of completion by mail or can download one immediately. The Online Boating Safety Course,
provided by the Boat/US Foundation, is approved by the National Association of State
Boating Law Administrators (NASBLA) and
recognized by the United States Coast
Guard. This course meets the education requirement for those states that recognize nonproctored, NASBLA-approved courses.
Yamaha is the watercraft industry’s leading
manufacturer to build awareness and support
for boating education. In 1997, Yamaha
launched its GET W.E.T. (Watercraft Education and Training) initiative and has since
reached out to over one million Americans
promoting the benefits of boating education.
17
Page 23
Safety information
The Online Boating Safety Course:
http://www.boatus.org/
EJU30991
Enjoy your watercraft
responsibly
You share the areas you enjoy when riding
your watercraft with others and with nature.
So your enjoyment includes a responsibility to
treat these other people, and the lands, waters, and wildlife with respect and courtesy.
Whenever and wherever you ride, think of
yourself as the guest of those around you. Remember, for example, that the sound of your
watercraft may be music to you, but it could be
just noise to others. And the exciting splash of
your wake can make waves others won’t enjoy.
Avoid riding close to shoreline homes and waterfowl nesting areas or other wildlife areas,
and keep a respectful distance from fishermen, other boats, swimmers, and populated
beaches. When travel in areas like these is
unavoidable, ride slowly and obey all laws.
Proper maintenance is necessary to ensure
that the exhaust emission and sound levels of
your watercraft will continue to be within regulated limits. You have the responsibility to
make sure that the recommended maintenance in this owner’s/operator’s manual is
carried out.
Remember, pollution can be harmful to the
environment. Do not refuel or add oil where a
spill could cause damage to nature. Remove
your watercraft from the water and move it
away from the shoreline before refueling. Dispose of water and any fuel and oil residue in
the engine compartment according to local
regulations. And keep your surroundings
pleasant for the people and wildlife that share
the waterways: don’t litter.
When you ride responsibly, with respect and
courtesy for others, you help ensure that our
18
Page 24
Safety information
waterways stay open for the enjoyment of a
variety of recreational opportunities.
19
Page 25
Description
EJU40652
Watercraft glossary
Trolling speed
“Trolling” is the lowest maneuvering speed. You are applying little or no throttle. The watercraft
is down in the water, and there is no wake.
Sub-planing speed
“Sub-planing” is a medium speed. The bow of the watercraft is slightly up from the water surface, but you are still traveling through the water. There is a wake.
Planing speed
“Planing” is a faster speed. The watercraft is more level and is skimming on top of the water.
There is a wake.
Bow
The front end of the watercraft.
Stern
The rear end of the watercraft.
Starboard
The right side of the watercraft when facing forward.
Port
The left side of the watercraft when facing forward.
Bilge water
Water that has collected in the engine compartment.
20
Page 26
Description
EJU31011
Location of main components
3
1 Steering pole
2 Steering pole cover
3 Bow rope hole
4 Fuel filler cap
5 Cooling water pilot outlet
6 Hood
7 Hood latch
8 Handlebars
9 Storage pouch
10 Riding tray
11 Stern rope hole
12 Jet thrust nozzle
13 Ride plate
14 Jet intake
15 Drive shaft
16 Intake grate
1
2
7
8
9
6
5
4
10
11
12 13
15 16
21
Page 27
1 Fire extinguisher container
2 Fuel cock knob
3 Choke knob
4 Clip
5 Start switch
6 Throttle lever
7 Engine shut-off cord (lanyard)
8 Engine stop switch
9 Engine shut-off switch
10 Fuel tank
11 Battery
12 Silencer
13 Spark plugs/Spark plug caps
14 Water separator
15 Muffler
16 Fuel filter
17 Electrical box
Description
22
Page 28
Control function operation
EJU31024
Watercraft control functions
EJU31152
Engine stop switch “”
The engine stop switch (red button) stops the
engine when the switch is pushed.
1 Engine stop switch
EJU31163
Engine shut-off switch “”
The engine shut-off switch automatically
stops the engine when the clip, on the end of
the engine shut-off cord (lanyard), is removed
from the switch, such as if the operator falls off
the watercraft.
Insert the clip under the engine shut-off switch
before starting the engine.
accidental starting or unauthorized operation
by children or others.
EJU41050
Start switch “”
ECJ01360
NOTICE
Do not run the engine for more than 15
seconds on land without supplying water,
otherwise the engine could overheat.
The start switch (green button) starts the engine when the switch is pushed.
Release the start switch as soon as the engine starts to run. If the engine does not start
in 5 seconds, release the start switch, wait 15
seconds, and then try again. NOTICE: Never
push the start switch while the engine is
running. Do not operate the start switch
for more than 5 seconds, otherwise the
battery will be discharged and the engine
1 Clip
2 Engine shut-off switch
3 Engine shut-off cord (lanyard)
When the engine is not running, remove the
clip from the engine shut-off switch to prevent
23
Page 29
Control function operation
will not start. Also, the starter motor could
be damaged.
1 Start switch
[ECJ01040]
The engine will not start when the clip is removed from the engine shut-off switch.
EJU31211
Throttle lever
The throttle lever increases the engine speed
when the lever is squeezed.
is changed, and the direction of the watercraft
is changed accordingly.
1 Handlebar
2 Jet thrust nozzle
Since the strength of the jet thrust determines
the speed and degree of a turn, throttle must
always be applied when attempting a turn, except at trolling speed.
The angle of the jet thrust nozzle can be adjusted to suit operator preference. (See page
61 for adjustment procedures.)
EJU31272
Steering pole
The steering pole can be moved up or down
to change the height of the handlebars.
1 Throttle lever
The throttle lever returns automatically to its
fully closed (idle) position when released.
EJU35931
Steering system
By turning the handlebars in the direction you
wish to travel, the angle of the jet thrust nozzle
EJU31123
Fuel cock knob
The fuel supply method can be switched by
operating the fuel cock knob.
24
Page 30
Control function operation
Select the fuel cock knob position from the following three positions according to the circumstances of use.
1 Fuel cock knob
OFF:
With the fuel cock knob in this position, fuel
does not flow to the carburetors. Always turn
the fuel cock knob to this position when the
engine is not running.
ON:
With the fuel cock knob in this position, fuel
flows to the carburetors. Turn the fuel cock
knob to this position when starting the engine
and operating the watercraft.
RES:
With the fuel cock knob in this position, the
fuel reserve is made available. Turn the fuel
cock knob to this position if you run out of fuel
while operating the watercraft. When this occurs, refuel as soon as possible and be sure
to turn the fuel cock knob back to “ON”.
EJU31202
Choke knob “”
The choke knob can be operated to supply a
richer air-fuel mixture that is required to start a
cold engine.
To use the choke:
Pull the choke knob out.
Push the choke knob in to stop using the
choke after the engine starts.
1 Choke knob
EJU31222
Cooling water pilot outlet
When the engine is running, some of the cooling water that is circulated in the engine is discharged from the cooling water pilot outlet.
1 Cooling water pilot outlet
There is a cooling water pilot outlet on the port
(left) side of the watercraft. To check for proper operation of the cooling system, make sure
that water is being discharged from the cooling water pilot outlet. If water is not being discharged from the outlet, stop the engine and
25
Page 31
Control function operation
check the jet intake for clogging. (See page
70 for information on the jet intake.)
TIP:
● If the cooling water passages are dry, it will
take about 20 seconds for the water to
reach the outlet after the engine is started.
● Water discharge may not be constant when
the engine is running at idling speed. If this
occurs, apply a little throttle to make sure
that water discharges properly.
EJU40321
Water separator
The water separator prevents water from entering the fuel tank by collecting any water that
has entered the fuel tank breather hose if the
watercraft was capsized.
If water has collected in the water separator,
drain it by loosening the drain screw.
1 Water separator
To drain water from the water separator:
(1) Place a drain pan or dry cloth under the
water separator.
(2) Gradually loosen the drain screw to drain
the water. Catch the draining water in the
drain pan or soak it up with the dry cloth
so that it does not spill into the engine
compartment. If any water spills into the
watercraft, be sure to wipe it up with a dry
cloth.
(3) Tighten the drain screw securely.
EJU31664
Engine overheat warning system
If the engine temperature rises significantly,
the engine overheat warning system will activate and the engine speed will be limited to
about 3400 r/min to help prevent damage.
If the engine overheat warning system is activated, immediately reduce the engine speed,
return to shore, and then make sure that water is being discharged from the cooling water
pilot outlet while the engine is running. If there
is no discharge of water, stop the engine, and
then check the jet intake for clogging. (See
page 70 for information on the jet intake.)
NOTICE: If you cannot locate and correct
the cause of the overheating, consult a
Yamaha dealer. Continuing to operate at
higher speeds could result in severe engine damage.
[ECJ00041]
1
1 Drain screw
26
Page 32
Equipment operation
EJU40333
Equipment
EJU31056
Hood
The hood is removable.
Remove the hood to access the engine compartment.
To remove the hood:
(1) Lift the steering pole and support it with
the lock pin.
1 Steering pole
(2) Turn the latch knob to the “OPEN” posi-
tion, and then pull up on the hood latch to
unlatch the hood.
1
O
K
P
E
N
LOC
2
1 Hood latch
2 Hood latch knob
(3) Grasp the hood using the handgrips pro-
vided at the front and rear of the hood. Lift
the hood up and to the rear to remove it.
1 Lock pin
27
1 Handgrip
Page 33
Equipment operation
To install the hood:
(1) Position the hood on the deck so that the
two projections at the front of the hood fit
under the two stays on the deck.
(2) Push down on the hood latch, and then
turn the knob to the “LOCK” position to
securely lock the hood in place.
O
P
CK
E
N
LO
towing it in an emergency. (See page 72 for
towing procedures.)
1
1 Bow rope hole
EJU36011
Stern rope hole
The stern rope hole is used to attach a rope to
the watercraft when mooring it.
(3) While holding the steering pole, move the
lock pin to the stowed position, and then
lower the steering pole.
EJU36001
Bow rope hole
The bow rope hole is used to attach a rope to
the watercraft when transporting, mooring, or
1 Stern rope hole
EJU31674
Storage pouch
The storage pouch is located on the bottom of
the hood.
Use the storage pouch to store the owner’s/operator’s manual, tool kit, and other
small items. The storage pouch is not designed to be waterproof. If you carry objects
that must be kept dry, put them in a waterproof bag.
To remove the storage pouch:
(1) Remove the hood. (See page 27 for hood
removal and installation procedures.)
28
Page 34
Equipment operation
(2) Unfasten the bands, and then remove the
storage pouch.
1 Storage pouch
2 Band
To install the storage pouch:
(1) Bend the owner’s/operator’s manual
slightly to insert it into the storage pouch,
and then add the tool kit and any other
small items. Fold the pouch, and then
wrap the strap around it.
To open the fire extinguisher container:
(1) Lift the steering pole and support it with
the lock pin.
1 Steering pole
2 Lock pin
(2) Grasp the tab, pull the band to the rear,
and then pull it up.
1 Strap
(2) Install the storage pouch on the hood and
secure it with the bands.
(3) Install the hood in its original position.
EJU41002
Fire extinguisher container
The fire extinguisher container is located on
the hood.
29
1 Fire extinguisher container
2 Ta b
(3) Lift the fire extinguisher container about
30 degrees from the storage position.
NOTICE: Do not force the fire extinguisher container up more than 30 degrees from the storage position,
otherwise the container and hood
could be damaged.
[ECJ00401]
Page 35
(4) Loosen the fire extinguisher container
cap and remove it.
1 Fire extinguisher container cap
To close the fire extinguisher container:
(1) Insert the fire extinguisher into the con-
tainer, and then install the fire extinguisher container cap and tighten it securely.
(2) Lower the container on the hood to its
storage position and secure it with the
band.
(3) While holding the steering pole, move the
lock pin to the stowed position, and then
lower the steering pole.
Equipment operation
30
Page 36
Operation and handling requirements
EJU31792
Fuel and engine oil
requirements
EJU31833
Fuel
EWJ00282
WARNING
● Gasoline and gasoline vapors are ex-
tremely flammable. To avoid fires and
explosions and to reduce the risk of injury when refueling, follow these instructions.
● Gasoline is poisonous and can cause in-
jury or death. Handle gasoline with care.
Never siphon gasoline by mouth. If you
should swallow some gasoline, inhale a
lot of gasoline vapor, or get some gasoline in your eyes, see your doctor immediately. If gasoline spills on your skin,
wash with soap and water. If gasoline
spills on your clothing, change your
clothes.
ECJ00321
NOTICE
● Do not use leaded gasoline. Leaded gas-
oline can seriously damage the engine.
● Avoid getting water and contaminants in
the fuel tank. Contaminated fuel can
cause poor performance and engine
damage. Use only fresh gasoline that
has been stored in clean containers.
Recommended fuel:
Regular unleaded gasoline with a minimum octane rating of
86
(Pump octane number) = (R + M)/2
90 (Research octane number)
Gasohol containing ethanol can be used if
ethanol content does not exceed 10% and the
fuel meets the minimum octane ratings. E-85
is a fuel blend containing 85% ethanol and
therefore must not be used in this watercraft.
All ethanol blends containing more than 10%
ethanol can cause fuel system damage or engine performance problems.
Yamaha does not recommend gasohol containing methanol because it can cause fuel
system damage and engine performance
problems.
EJU31872
2-stroke engine oil
Recommended engine oil:
YAMALUBE 2-W or TC-W3 outboard
motor oil or equivalent
If YAMALUBE 2-W engine oil is not available,
another 2-stroke engine oil with an NMMAcertified TC-W3 rating may be used.
EJU31902
Mixing fuel and oil
ECJ00331
NOTICE
Make sure that the gasoline and oil are
thoroughly mixed in the correct ratio, otherwise severe engine damage could result.
To mix gasoline and engine oil:
(1) Pour 2-stroke engine oil into a clean con-
tainer, and then add gasoline.
Fuel-to-oil ratios (gasoline to oil)
Break-in period (first two tankfuls):
25:1
After break-in:
50 :1
Gasohol
There are two types of gasohol: gasohol containing ethanol and that containing methanol.
31
Page 37
Operation and handling requirements
(2) To mix them thoroughly, shake the con-
tainer from side to side.
1 2-stroke engine oil
2 Gasoline
EJU41490
Filling the fuel tank
To fill the fuel tank:
(1) Before refueling, stop the engine. Do not
stand or sit on the watercraft. Never refuel while smoking, or while in the vicinity of
sparks, open flames, or other sources of
ignition.
(2) Place the watercraft in a well-ventilated
area and in a horizontal position.
(3) Remove the hood, and then check the
fuel level. (See page 27 for hood removal
and installation procedures.)
(4) Loosen the fuel filler cap and remove it.
Fuel tank capacity:
To ta l :
18 L (4.8 US gal, 4.0 Imp.gal)
Reserve:
5.5 L (1.5 US gal, 1.2 Imp.gal)
(6) Stop filling when the fuel level just reach-
es the bottom of the filler tube. Do not fill
up the filler tube. Because fuel expands
when it heats up, heat from the engine or
the sun can cause fuel to spill out of the
fuel tank. Do not leave the watercraft with
a full tank in direct sunlight.
(7) Wipe up any spilled fuel immediately with
a dry cloth.
(8) Securely install the fuel filler cap by tight-
ening it until it clicks.
(9) Install the hood in its original position.
1
1 Fuel filler cap
(5) Slowly add fuel to the fuel tank.
32
Page 38
Operation and handling requirements
EJU40021
Draining the bilge water
ECJ01301
NOTICE
Do not run the engine at full throttle when
bilge water remains in the engine compartment. The bilge water can splash into the
engine, which can result in severe damage.
EJU40920
Draining the bilge water on water
A small quantity of bilge water will remain in
the engine compartment even after the bilge
water is drained on water. To completely remove the bilge water, remove the watercraft
from the water and wipe up any remaining
moisture in the engine compartment with a
dry cloth.
Jet vacuum bilge draining system
While the watercraft is operating, a vacuum is
generated in the jet pump that draws in the
bilge water from the engine compartment and
discharges it from the jet thrust nozzle.
To drain the bilge water on water:
Operate the watercraft as straight as possible
and above planing speed for at least 2 minutes. NOTICE: Do not run the engine at full
throttle for at least 1 minute after the engine has been restarted. Bilge water in the
engine compartment can splash into the
engine, which can result in severe damage.
[ECJ00553]
EJU33423
Transporting
EWJ00750
WARNING
Always turn the fuel cock knob to “OFF”
when transporting the watercraft, otherwise fuel could leak out into the engine or
engine compartment, which would create
a fire hazard.
When transporting the watercraft on a trailer,
secure the bow rope hole and stern of the watercraft to the trailer with ropes or tie downs.
Use a rubber shock cord to secure the steering pole to the watercraft. NOTICE: Do not
secure the steering pole with ropes or tie
downs and do not secure it to the trailer.
Also, do not transport the watercraft with
the steering pole up. Otherwise, the steering pole could be damaged. Wrap the
ropes or tie downs with towels or rags
33
Page 39
Operation and handling requirements
where they touch the body of the watercraft to avoid scratches or damage.
1 Rubber shock cord
2 Tie down
[ECJ00632]
34
Page 40
First-time operation
EJU32755
ECJ00431
NOTICE
Failure to perform the engine break-in
could result in reduced engine life or even
severe engine damage.
The engine break-in is essential to allow the
various components of the engine to wear
and polish themselves to the correct operating clearances. This ensures proper performance and promotes longer component life.
To perform the engine break-in:
(1) Fill the fuel tank with fuel in a fuel-to-oil ra-
(2) Launch the watercraft and start the en-
(3) For the first 5 minutes, operate with the
(4) For the first tankful of fuel, squeeze the
(5) Fill the fuel tank once more with fuel in a
After completing the engine break-in, fill the
fuel tank with fuel in a fuel-to-oil ratio of 50:1
and proceed with normal operation.
Engine break-in
tio of 25:1. (See page 31 “Mixing fuel and
oil” and “Filling the fuel tank” for fuel filling
procedures.)
gine. (See page 45 for engine starting
procedures.)
engine at idling speed.
throttle lever slowly and operate at 3/4
throttle or less.
fuel-to-oil ratio of 25:1, and then operate
with the engine at any speed.
35
Page 41
Pre-operation checks
EJU31981
EWJ00411
WARNING
Failure to inspect or maintain the watercraft properly increases the possibility of an accident or damage to the watercraft. Do not operate the watercraft if you find any problem. If a problem cannot be corrected by the procedures provided in this manual, have
the watercraft inspected by a Yamaha dealer.
EJU31995
Pre-operation checklist
Before using this watercraft, be sure to perform the checks in the following checklist.
ITEM ROUTINE PAGE
PRE-LAUNCH CHECKS
Engine compartment
Fuel system
Water separator Check the water separator for water. 39
Engine unit Check the exterior of the engine unit for damage. 39
Bilge water Check the engine compartment for bilge water. 39
Battery Check the battery connections and electrolyte level. 39
Steering system Check the steering system for proper operation. 39
Throttle lever
Engine shut-off cord (lanyard)
Switches
Storage pouch
Safety equipment
Fire extinguisher container Check the fire extinguisher container for damage. 42
Fire extinguisher Check the condition of the fire extinguisher. 42
Hull and deck Check the hull and deck for damage. 42
Jet intake Check the jet intake for damage and clogging. 42
Hood Check that the hood is securely closed. 42
POST-LAUNCH CHECKS
Cooling water pilot outlet
Ventilate the engine compartment.
Check inside the engine compartment for damage.
Check the fuel system for leakage.
Check the fuel level in the fuel tank.
Check the throttle lever for proper operation.
Check the throttle lever free play.
Check the engine shut-off cord (lanyard) for damage.
Check the start switch, engine stop switch, and engine shut-off switch for proper operation.
Check the storage pouch for damage and water.
Check that the storage pouch is securely installed.
Check that safety equipment meeting the applicable
regulations is on board.
Check that water is discharged from the cooling water pilot outlet while the engine is running.
38
38
40
41
41
41
42
43
36
Page 42
Pre-operation checks
TIP:
To ensure safety and reliability, pre-operation checks should be made each time the watercraft
is used.
37
Page 43
Pre-operation checks
EJU32281
Pre-operation check points
EJU40684
Pre-launch checks
Perform the pre-launch checks in the pre-operation checklist while the watercraft is on
land.
To perform the pre-launch checks:
(1) Remove the hood. (See page 27 for hood
removal and installation procedures.)
(2) Perform the checks and make sure that
there are no malfunctioning items or other problems.
(3) After completing these checks, install the
hood in its original position.
EJU32333
Engine compartment check
EWJ00461
WARNING
Failure to ventilate the engine compartment could result in a fire or explosion. Do
not start the engine if there is a fuel leak.
Ventilate the engine compartment. Leave the
engine compartment open for a few minutes
to allow any fuel vapors to escape.
Make sure that there is no damage inside the
engine compartment.
● If any fuel leakage is found, the fuel sys-
tem must be repaired by a qualified mechanic. Improper repairs can make the
watercraft unsafe to operate.
Make sure that there is no damage, leakage,
or other problem in the fuel system.
Check:
● Carburetor for leakage
● Fuel filler cap and seal for damage
● Fuel in fuel tank for water and dirt
● Fuel tank for damage and leakage
● Fuel hoses and joints for damage and leak-
age
● Fuel filter for leakage
● Fuel cock for leakage
● Fuel tank breather hose for damage and
leakage
Releasing the pressure in the fuel tank
Release the pressure in the fuel tank before
each use.
To release the pressure in the fuel tank:
(1) Loosen the fuel filler cap slowly and re-
move it to release any pressure in the fuel
tank.
EJU41500
Fuel system checks
EWJ00381
WARNING
Leaking fuel can result in fire or explosion.
● Check for fuel leakage regularly.
1
1 Fuel filler cap
(2) Securely install the fuel filler cap by tight-
ening it until it clicks.
EJU32363
Fuel level check
Check the fuel level in the fuel tank.
38
Page 44
Pre-operation checks
Add fuel if necessary. (See page 32 for filling
procedures.)
EJU32422
Water separator check
Make sure that no water has collected in the
water separator. If water has collected in the
water separator, drain it. (See page 26 for
draining procedures.)
1 Water separator
EJU40181
Engine unit check
Check the exterior of the engine unit for damage or other problem.
EJU41011
Bilge water check
Make sure that no bilge water has collected in
the engine compartment. If bilge water has
collected in the engine compartment, wipe it
up with a dry cloth. NOTICE: Excessive wa-
ter in the engine compartment can splash
into the engine, which can result in severe
damage.
EJU32484
[ECJ00341]
Battery checks
Make sure that the battery terminals and
breather hose are not damaged and that the
battery leads and breather hose are connected properly. WARNING! Fire or explosion
could result if the breather hose is dam-
aged, obstructed, or not connected properly.
[EWJ00451]
1 Positive (+) battery terminal: Red lead
2 Negative (–) battery terminal: Black lead
3 Breather hose
Make sure that the electrolyte level is between the minimum and maximum level
marks. WARNING! Never operate the wa-
tercraft if the battery does not have sufficient power to start the engine or if it
shows any other signs of decreased power. Loss of battery power may leave you
stranded.
1 Maximum level mark
2 Minimum level mark
[EWJ01240]
Make sure that the battery is securely held in
place.
EJU32613
Steering system checks
Turn the handlebars to the right and left several times to make sure that operation is
smooth and unrestricted throughout the
39
Page 45
Pre-operation checks
whole range, and that the free play is not excessive.
Turn the handlebars as far as possible to the
right and left to make sure that the jet thrust
nozzle moves as the handlebars are turned,
and that there is no difference between the
right and left fully turned positions of the jet
thrust nozzle.
EJU32622
Steering pole check
Move the steering pole up and down several
times to make sure that operation is smooth
and unrestricted throughout the whole range,
and that the free play is not excessive. Also,
make sure that the steering pole does not
have any side play.
EJU32594
Throttle lever checks
Operate the throttle lever several times to
make sure that operation is smooth throughout the whole range. Also, make sure that the
throttle lever returns automatically to its fully
closed (idle) position when released.
Difference between fully turned positions
of jet thrust nozzle (distances A and B):
Maximum 5 mm (0.20 in)
40
Page 46
Pre-operation checks
Make sure that there is the proper amount of
throttle lever free play when the throttle lever
is in the fully closed (idle) position.
1 Throttle lever free play
Throttle lever free play:
7.0–10.0 mm (0.28–0.39 in)
EJU32663
Engine shut-off cord (lanyard) check
Make sure that the engine shut-off cord (lanyard) is not damaged. If the cord is damaged,
replace it. WARNING! Never try to repair
the engine shut-off cord (lanyard) or tie it
together. The engine shut-off cord (lanyard) may not pull free when the operator
falls off, allowing the watercraft to continue to run and cause an accident.
[EWJ01220]
EJU41020
Switch checks
ECJ01360
NOTICE
Do not run the engine for more than 15
seconds on land without supplying water,
otherwise the engine could overheat.
Check the start switch, the engine stop
switch, and the engine shut-off switch for
proper operation. (See pages 23 to 23 for information on operating each switch.)
1 Clip
2 Engine shut-off switch
3 Start switch
4 Engine stop switch
5 Engine shut-off cord (lanyard)
To check the operation of the switches:
(1) Push the start switch to make sure that
the engine starts.
(2) As soon as the engine starts running,
push the engine stop switch to make sure
that the engine stops immediately.
(3) Restart the engine, and then pull the en-
gine shut-off cord (lanyard) to remove the
clip from the engine shut-off switch to
make sure that the engine stops immediately.
EJU41210
Storage pouch checks
Make sure that the storage pouch is not damaged and that water has not collected in the
pouch. Also, make sure that the storage
41
Page 47
Pre-operation checks
pouch is securely installed. (See page 28 for
information on the storage pouch.)
EJU40121
Safety equipment check
Check that safety equipment meeting the applicable regulations is on board.
EJU32352
Hull and deck check
Check the hull and deck for damage or other
problem.
EJU32655
Jet intake checks
Make sure that the jet intake is not damaged
or clogged with weeds or debris. If the jet intake is clogged, clean it. (See page 70 for jet
intake cleaning procedures.)
EJU40701
Hood check
Make sure that the hood is securely closed.
(See page 27 for more information.)
EJU32493
Fire extinguisher check
Check that there is a full fire extinguisher on
board.
To check the fire extinguisher, see the instructions supplied by the fire extinguisher manufacturer. Always keep the fire extinguisher in
the fire extinguisher container.
Always carry a fire extinguisher on board. A
fire extinguisher is not standard equipment
with this watercraft. If you do not have one,
contact a Yamaha dealer or a fire extinguisher
dealer to obtain one meeting the proper specifications.
EJU41071
Fire extinguisher container checks
Make sure that the fire extinguisher container
is not damaged and is securely held in place.
(See page 29 for information on the fire extinguisher container.)
Fire extinguisher:
Classification:
B-1
Capacity:
2 lb or more
EJU40143
Post-launch checks
Perform the post-launch checks in the pre-operation checklist while the watercraft is in the
water and the engine is running.
To perform the post-launch checks:
(1) Launch the watercraft. (See page 45 for
launch procedures.)
(2) Perform the checks and make sure that
there are no malfunctioning items or other problems.
42
Page 48
Pre-operation checks
EJU40551
Cooling water pilot outlet check
Make sure that water is discharged from the
cooling water pilot outlet while the engine is
running. (See page 25 for more information.)
43
Page 49
Operation
EJU32902
Operating your watercraft
EWJ00510
WARNING
Before operating your watercraft, become
familiar with all of the controls. Consult a
Yamaha dealer about any control or function that you do not fully understand. Failure to understand how the controls work
could cause an accident or prevent you
from avoiding an accident.
EJU32913
Getting to know your watercraft
Operating your watercraft requires skills acquired through practice over a period of time.
Take the time to learn the basic techniques
well before attempting more difficult maneuvers.
Operating your new watercraft can be a very
enjoyable activity, providing you with hours of
pleasure. However, it is essential to familiarize yourself with the operation of the watercraft to achieve the skill level necessary to
enjoy riding safely.
Before operating this watercraft, read this
owner’s/operator’s manual, the Riding Practice Guide, the Riding Instruction card, and all
labels on the watercraft. Pay particular attention to the safety information beginning on
page 7. Also, watch the Basic Orientation Video provided with your watercraft. These materials should give you an understanding of the
watercraft and its operation.
Remember: This watercraft is designed to
carry the operator only. Never have more than
one person on the watercraft at any time.
EJU32974
Learning to operate your watercraft
Before operating the watercraft, always perform the pre-operation checks listed on page
36. The short time spent checking the water-
craft will reward you with added safety and reliability.
Check state and local laws before operating
your watercraft.
Operate defensively at safe speeds and keep
a safe distance away from people, objects,
and other watercraft. Select a wide area to
practice maneuvering in, where there is good
visibility and light boat traffic.
Use the buddy system—operate with someone nearby. Scan constantly for people, objects, and other watercraft. Be alert for
conditions that limit your visibility or block your
vision of others.
You should grip the handlebars firmly and get
to a standing or kneeling position quickly.
Keep both feet or knees on the riding tray
when the watercraft is in motion.
EJU33171
Operating positions
After you are underway, you may choose to
kneel or stand, depending upon watercraft
speed, your skill level, and your preference.
Here are some guidelines.
Kneeling
It is easier to maintain your balance when
kneeling than when standing. This position is
recommended when traveling at sub-planing
speeds. (At sub-planing speeds, there is a
44
Page 50
Operation
wake, but the watercraft is moving through the
water rather than skimming on top of it.)
At very slow speeds, it may be necessary to
support your upper-body weight with your elbows resting on the gunwales, trailing your
legs in the water.
Standing
After you are comfortable handling the watercraft from a kneeling position, try standing as
the watercraft gains speed. The watercraft will
become easier to balance as the speed increases, because jet thrust provides stability
as well as directional control. When you are
moving slowly, or preparing to stop, you will
probably need to return to the kneeling position to maintain your balance.
If the watercraft is launched from a trailer,
someone should make sure that waves do not
push the watercraft into the trailer.
After the watercraft is in the water, turn it
around so that the bow faces the direction you
wish to go.
EJU32835
Starting the engine on water
EWJ01520
WARNING
Do not apply throttle when others are at
the rear of the watercraft. Turn the engine
off or keep it at idle. Water and debris exiting the jet thrust nozzle can cause severe
injury.
To start the engine:
(1) Move the watercraft to an area that is free
from weeds and debris, and has a water
depth of at least 60 cm (2 ft) from the bottom of the watercraft. NOTICE: Never
run the engine in water that is less
than 60 cm (2 ft) deep from the bottom
of the watercraft, otherwise pebbles or
sand could be sucked into the jet intake, causing impeller damage and engine overheating.
[ECJ00472]
EJU32821
Launching the watercraft
When launching the watercraft, make sure
that there are no obstacles around you.
45
Page 51
Operation
(2) Turn the fuel cock knob to “ON”.
(3) Attach the engine shut-off cord (lanyard)
to your left wrist, and then attach the clip
to the engine shut-off switch. (See page
23 for information on operating the engine shut-off switch.) WARNING! Check
that the engine shut-off cord (lanyard)
is attached correctly. If the engine
shut-off cord (lanyard) is not attached
correctly, it may not pull free when the
operator falls off, allowing the watercraft to continue to run and cause an
accident.
[EWJ00581]
(4) Pull the choke knob all the way out to
start a cold engine.
TIP:
The choke should not be used when the engine is warm.
(5) While lightly squeezing the throttle lever,
push the start switch (green button) to
start the engine. (See page 23 for information on operating the start switch.)
WARNING! Do not apply too much
throttle when starting the engine, otherwise the watercraft will accelerate
unexpectedly. This could cause a collision or cause the operator to be
thrown overboard.
[EWJ00591]
1 Clip
2 Engine shut-off switch
3 Engine shut-off cord (lanyard)
(6) After the engine has warmed up, push
the choke knob in to its original position.
TIP:
If the choke knob is left pulled out, the engine
will stall.
46
Page 52
Operation
EJU32862
Stopping the engine
Release the throttle lever, and then push the
engine stop switch (red button) to stop the engine. WARNING! You need throttle to steer.
Shutting the engine off can cause you to
hit an obstacle you are attempting to
avoid. A collision could result in severe injury or death.
EJU32872
[EWJ00601]
Leaving the watercraft
If leaving the watercraft, remove the clip from
the engine shut-off switch to prevent accidental starting or unauthorized operation by children or others.
fully closed (idle) position and the engine is at
idling speed.
EJU33243
Turning the watercraft
EWJ00761
WARNING
● Do not release the throttle lever when
trying to steer away from objects—you
need throttle to steer. A collision could
result in severe injury or death.
● When operating at higher speeds, make
gradual turns or slow down before turning. Sharp high-speed turns may cause
the watercraft to slide sideways or spin,
throwing the operator overboard, which
could cause an injury.
EJU41170
Operating the watercraft
When the engine is running, the watercraft will
move forward even if the throttle lever is in the
47
Steering control depends on the combination
of handlebar position and the amount of throttle.
Water sucked in through the intake grate is
pressurized by the impeller in the jet pump. As
the pressurized water is expelled from the
pump through the jet thrust nozzle, it creates
thrust to move and steer the watercraft. The
higher the engine speed, the more thrust produced.
The amount of jet thrust, in addition to the position of the handlebars, determines how
sharply you turn.
Page 53
Operation
A. More throttle produces higher thrust, so
the watercraft will turn more sharply.
B. Less throttle produces lower thrust, so
the watercraft will turn more gradually.
alone using just the amount of thrust
available at idle.
D. If the engine is stopped while riding, there
is no thrust. The watercraft will go straight
even though the handlebars are turned.
C. Releasing the throttle lever completely
produces only minimum thrust. If you are
traveling at speeds above trolling, you will
have rapidly decreasing ability to steer
without throttle. You may still have some
turning ability immediately after releasing
the throttle lever, but once the engine
slows down, the watercraft will no longer
respond to handlebar input until you apply throttle again or you reach trolling
speed.
At trolling speed, the watercraft can be
turned gradually by handlebar position
You need throttle to steer.
To maintain your balance, lean into a turn.
How much you lean depends on the sharpness of the turn and your traveling speed. In
48
Page 54
Operation
general, the higher the speed or the sharper
the turn, the more you lean.
EJU33272
Stopping the watercraft
The watercraft is not equipped with a separate braking system. It is stopped by water resistance when the throttle lever is released.
From full speed, the watercraft comes to a
complete stop in approximately 90 m (300 ft)
after the throttle lever is released or the engine is stopped, although this distance will
vary depending on many factors, including
gross weight, water surface conditions, and
wind direction. The watercraft slows down as
soon as the throttle lever is released, but will
coast for a distance before fully stopping. If
you are not sure you can stop in time before
hitting an obstacle, apply throttle and turn in
another direction.
EWJ00722
WARNING
● Allow adequate stopping distance.
● Take early action to avoid collisions. Re-
member, watercraft and other boats do
not have brakes.
● Operate defensively at safe speeds and
keep a safe distance away from people,
objects, and other watercraft to give you
time to stop.
● Do not shut the engine off when slowing
down in case you need engine power to
steer away from a boat or other obstacle
that comes into your path.
EJU33074
Starting off
EWJ00711
WARNING
To avoid collisions:
● Scan constantly for people, objects, and
other watercraft. Be alert for conditions
that limit your visibility or block your vision of others.
● Operate defensively at safe speeds and
keep a safe distance away from people,
objects, and other watercraft.
● Do not follow directly behind watercraft
or other boats. Do not go near others to
spray or splash them with water. Avoid
49
Page 55
Operation
sharp turns or other maneuvers that
make it hard for others to avoid you or
understand where you are going. Avoid
areas with submerged objects or shallow water.
● Take early action to avoid collisions. Re-
member, watercraft and other boats do
not have brakes. Do not release the
throttle lever when trying to steer away
from objects—you need throttle to steer.
EWJ00632
WARNING
Avoid forceful jet thrust and limited visibility while reboarding. Get to a standing or
kneeling position quickly, but do not expose yourself to the forceful jet thrust.
ECJ01340
NOTICE
Never run the engine in water that is less
than 60 cm (2 ft) deep from the bottom of
the watercraft, otherwise pebbles or sand
could be sucked into the jet intake, causing impeller damage and engine overheating.
Even though it is easier to start in shallow water, you must learn deep-water boarding first.
You will inevitably fall off, so be sure you know
how to get back on the watercraft once you
are away from shore.
EJU33104
Boarding and starting in shallow water
Be sure to learn the deep-water starting method before operating the watercraft in water
where it is too deep for you to stand. (See
page 51 for the deep-water starting method.)
(1) Launch the watercraft in water free from
weeds and debris and at least 60 cm (2 ft)
deep from the bottom of the watercraft.
NOTICE: Never run the engine in water
that is less than 60 cm (2 ft) deep from
the bottom of the watercraft, otherwise pebbles or sand could be sucked
into the jet intake, causing impeller
damage and engine overheating.
[ECJ00472]
(2) Attach the engine shut-off cord (lanyard)
to your left wrist, and then attach the clip
to the engine shut-off switch.
(3) Grip the handlebars with both hands.
Place one knee on the riding tray and balance there.
The watercraft is less stable when at a standstill or at a slow speed. It takes skill to keep the
watercraft upright when starting.
To stabilize the watercraft when accelerating
to planing speed, maintain a low center of
gravity by operating it in the kneeling position.
(4) Look in all directions, start the engine,
and then begin to accelerate.
50
Page 56
Operation
(5) Pull your other knee up onto the riding
tray as the watercraft speed increases.
(6) Move as far forward as possible without
interfering with the movement of the handlebars. Keep your body perpendicular to
the water, with your weight forward and
low.
TIP:
The watercraft will become easier to balance
as the speed increases, because jet thrust
provides stability as well as directional control.
EJU33124
Boarding and starting in deep water
EWJ01260
WARNING
Be sure the operator have practiced
boarding from the water while still close to
shore before riding. A person who has
made many unsuccessful attempts to get
back on the watercraft may become fatigued and suffer from exposure, increasing the risk of injury and drowning.
left wrist, and then attach the clip to the
engine shut-off switch.
(2) Grip the handlebars with both hands. Pull
your body up onto the riding tray and balance there, using your elbows on the
gunwales for leverage.
(3) Look in all directions, start the engine,
and then begin to accelerate.
(4) Continue to pull your body up onto the
watercraft as the watercraft speed increases.
(1) Swim to the rear of the watercraft. Attach
the engine shut-off cord (lanyard) to your
51
Page 57
Operation
(5) Bring your knees up onto the riding tray
and change to a kneeling position as
soon as you can do so.
(6) Move as far forward as possible without
interfering with the movement of the handlebars. Keep your body perpendicular to
the water, with your weight forward and
low.
(7) Once the bow drops, and the watercraft
has leveled out in the water and reached
planing speed, back off the throttle and
select your desired speed.
TIP:
● The watercraft will become easier to bal-
ance as the speed increases, because jet
thrust provides stability as well as directional control.
● It will take longer for a heavy operator to
reach planing speed than it will for a light
operator.
EJU33203
Capsized watercraft
EWJ00671
WARNING
Improper uprighting can cause injury.
● Be sure to shut the engine off by pulling
on the engine shut-off cord (lanyard) to
remove the clip from the engine shut-off
switch.
● Do not put your hands in the intake
grate.
If the watercraft capsizes, turn it over immediately.
To upright the watercraft:
(1) Remove the clip from the engine shut-off
switch.
(2) Swim to the rear of the watercraft. Turn
the watercraft over clockwise.
If the port (left) side of the capsized watercraft is tilting up, push down on the
gunwale so that the port (left) side is
down before turning the watercraft clockwise. NOTICE: Do not turn the water-
craft over counterclockwise,
otherwise water can enter the engine,
which can result in severe damage.
[ECJ00541]
(3) Start the engine and operate the water-
craft at planing speed to drain water in the
engine compartment. (See page 33 for
water draining procedures. If the engine
does not start, see “Towing the water-
52
Page 58
Operation
craft” on page 72 or “Submerged watercraft” on page 72.) NOTICE: Do not run
the engine at full throttle for at least 1
minute after the engine has been restarted. Bilge water in the engine compartment can splash into the engine,
which can result in severe damage.
[ECJ00553]
EJU33302
Beaching the watercraft
To beach the watercraft:
(1) Make sure that there are no boats, swim-
mers, or obstacles near the beach.
(2) Release the throttle lever to reduce
speed about 90 m (300 ft) before you
reach the intended beaching area.
(3) Slowly approach the beach and stop the
engine just before reaching land.
WARNING! You need throttle to steer.
Shutting the engine off can cause you
to hit an obstacle you are attempting
to avoid. A collision could result in severe injury or death.
[EWJ00601] NOTICE:
Never run the engine in water that is
less than 60 cm (2 ft) deep from the
bottom of the watercraft, otherwise
pebbles or sand could be sucked into
the jet intake, causing impeller damage and engine overheating.
[ECJ00472]
(4) Get off the watercraft and pull it up on the
beach.
EJU37192
Operating in weeded areas
Always avoid using your watercraft in areas
where weed growth is thick. If operating in
weeded areas is unavoidable, alternately
squeeze the throttle lever to the full throttle
position and relax your grip on the throttle lever to vary the engine speed. Weeds tend to
become clogged more when operating at a
steady speed and at trolling speed. If weeds
may have clogged the intake area, clean the
jet intake. (See page 70 for jet intake cleaning
procedures.)
EJU41060
After removing the watercraft from the
water
ECJ01360
NOTICE
Do not run the engine for more than 15
seconds on land without supplying water,
otherwise the engine could overheat.
After operating and removing the watercraft
from the water, promptly discharge the remaining water from the cooling water passages.
To discharge water from the cooling water
passages:
(1) Make sure that the area around the wa-
tercraft is clear, and then start the engine.
(2) Discharge the remaining water out of the
cooling water passages by alternately
squeezing and releasing the throttle lever
quickly for 10 to 15 seconds.
(3) Stop the engine.
53
Page 59
Care and storage
EJU41190
Post-operation care
EWJ00320
WARNING
Always turn the fuel cock knob to “OFF”
when storing the watercraft, otherwise
fuel could leak out into the engine or engine compartment, which would create a
fire hazard.
After using the watercraft, always take it out of
the water, clean it, and store it. Leaving the
watercraft in the water for extended periods
will accelerate the rate of normal deterioration
of the jet pump and hull. Marine organisms
and corrosion are some of the conditions that
can adversely affect the life of many watercraft components.
EJU33508
Flushing the cooling water passages
ECJ01360
NOTICE
Do not run the engine for more than 15
seconds on land without supplying water,
otherwise the engine could overheat.
(1) Place the watercraft in a horizontal posi-
tion.
(2) Remove the hood. (See page 27 for hood
removal and installation procedures.)
(3) Insert the garden hose adapter into the
flushing hose connector.
1 Garden hose adapter
2 Flushing hose connector
(4) Connect a garden hose to the garden
hose adapter.
(5) Connect the garden hose to a water tap.
(6) Make sure that the area around the wa-
tercraft is clear, and then start the engine.
Immediately after the engine starts, turn
the water supply on gradually until water
flows out continually from the cooling wa-
ter pilot outlet.
Flush the cooling water passages to prevent
them from clogging with salt, sand, or dirt.
Use the Yamaha Watercraft Flush Kit to make
flushing easier.
See the instructions included with the flush kit
for proper installation.
(7) Run the engine at idling speed for about
3 minutes watching the engine condition.
If the engine stops while flushing, turn the
water supply off immediately and perform
54
Page 60
Care and storage
the procedure again from step 6.
NOTICE: Do not supply water to the
cooling water passages when the engine is not running. The water could
flow back through the muffler into the
engine, causing severe engine damage.
[ECJ00122]
(8) Turn the water supply off.
(9) Discharge the remaining water out of the
cooling water passages by alternately
squeezing and releasing the throttle lever
quickly for 10 to 15 seconds.
(10) Stop the engine.
(11) Remove the garden hose adapter.
(12) Install the hood in its original position.
EJU40732
Cleaning the watercraft
(1) Remove the hood. (See page 27 for hood
removal and installation procedures.)
(2) Rinse the engine and engine compart-
ment with a small amount of water.
NOTICE: Do not use high-pressure
water when rinsing the engine or en-
gine compartment as severe engine
damage could result.
(3) Wipe the engine and engine compart-
ment with a dry cloth.
(4) Wash down the hull and jet pump with
fresh water.
(5) Wipe the hull and jet pump with a dry
cloth.
(6) Wipe all vinyl and rubber components,
such as the engine compartment seals,
with a vinyl protectant such as Yamaha
Protectant.
(7) To minimize corrosion, spray metallic
parts of the hull with a rust inhibitor such
as Yamaha Silicone Protectant and Lu-
bricant.
(8) Allow the engine compartment to air dry
completely before installing the hood.
(9) Install the hood in its original position.
[ECJ00571]
EJU33685
Battery care
If the watercraft will not be used for more than
a month, remove the battery from the watercraft, check it, and then store it in a cool, dry
place.
EWJ00791
WARNING
Battery electrolyte is poisonous and dangerous, causing severe burns, etc. Electrolyte contains sulfuric acid. Avoid
contact with skin, eyes, or clothing.
Antidotes
External: Flush with water.
Internal: Drink large quantities of water or
milk. Follow with milk of magnesia, beaten
egg, or vegetable oil. Call a physician immediately.
Eyes: Flush with water for 15 minutes and
get prompt medical attention.
Batteries produce explosive gases. Keep
sparks, flames, cigarettes, etc., well away.
If using or charging the battery in an enclosed space, make sure that it is well ventilated. Always shield your eyes when
working near batteries.
Keep out of the reach of children.
To remove the battery:
(1) Disconnect the negative (–) battery lead.
(2) Disconnect the positive (+) battery lead.
(3) Disconnect the breather hose.
55
Page 61
Care and storage
(4) Unhook the battery bands, and then re-
move the battery from the watercraft.
1 Positive (+) battery terminal: Red lead
2 Battery band
3 Negative (–) battery terminal: Black lead
4 Breather hose
Checking the battery
● Make sure that the battery case is not dam-
aged.
● Make sure that the battery terminals are not
corroded or damaged.
● Make sure that the breather hose is not
clogged or damaged.
Checking the electrolyte level
Make sure that the electrolyte level is between the maximum and minimum level
marks.
If the electrolyte level is low, add distilled water to raise it to the specified level. NOTICE:
Use only distilled water for replenishing
the battery, otherwise battery life could be
shortened.
1 Maximum level mark
2 Minimum level mark
[ECJ00241]
If distilled water was added, check the battery
voltage.
It is recommended to have a Yamaha dealer
check the battery voltage and charge the battery. If you charge the battery yourself, be
sure to read and follow the instructions provided with the battery tester and charger you
use. NOTICE: Do not attempt to charge a
battery hastily. Battery life could be shortened.
[ECJ00251]
Checking the battery bands
Make sure that the battery bands are not
damaged.
1 Battery band
To store the battery:
(1) Clean the battery case using fresh water.
56
Page 62
Care and storage
(2) If the battery terminals are dirty or corrod-
ed, clean them using a wire brush.
1 Battery terminal
(3) Apply Yamaha Marine Grease or
Yamaha Grease A to the battery termi-
nals.
Recommended water-resistant grease:
Yamaha Marine Grease/Yamaha
Grease A
(4) Store the battery in a cool, dry place.
NOTICE: Always keep the battery
charged. Storing a discharged battery
can cause permanent battery damage.
[ECJ00101]
To install the battery:
(1) Place the battery in the battery compart-
ment and hook the battery bands onto the
holders.
(2) Connect the positive (+) battery lead (red)
to the positive (+) battery terminal.
NOTICE: Reversal of the battery leads
will damage the electrical parts.
[ECJ00261]
(3) Connect the negative (–) battery lead
(black) to the negative (–) battery termi-
nal.
(4) Connect the breather hose to the battery.
WARNING! Fire or explosion could re-
sult if the breather hose is damaged,
obstructed, or not connected proper-
ly.
[EWJ00451]
(5) Make sure that the battery is securely
held in place.
57
Page 63
Care and storage
EJU33483
Long-term storage
EWJ00320
WARNING
Always turn the fuel cock knob to “OFF”
when storing the watercraft, otherwise
fuel could leak out into the engine or engine compartment, which would create a
fire hazard.
Storage for long periods of time, such as winter storage, requires preventive maintenance
to ensure against deterioration. It is advisable
to have the watercraft serviced by a Yamaha
dealer prior to storage.
However, the following procedures can be
performed easily by the owner.
EJU40251
Cleaning
(1) Flush the cooling water passages. (See
page 54 for flushing procedures.)
TIP:
If you will be storing the watercraft for a prolonged period, such as winter storage, top off
the fuel tank with fresh gasoline and add one
ounce of Yamaha Fuel Stabilizer and Conditioner to each gallon of fuel in the fuel tank before starting the engine.
(2) Clean the watercraft. (See page 55 for
watercraft cleaning procedures.)
Wax the hull with a non-abrasive wax
such as Yamaha Silicone Wax.
EJU40783
Lubrication
Use a Yamaha Power Cable Luber and spray
Yamaha Lube-Zall between the inner and outer cables to lubricate the cables and purge out
any dirt and moisture.
To keep moving parts sliding or rotating
smoothly, lubricate them with water-resistant
grease.
Recommended water-resistant grease:
Yamaha Marine Grease/Yamaha
Grease A
● Throttle cable (carburetor end) and choke
cable (carburetor end)
● Throttle cable (throttle lever end)
Squeeze the throttle lever and remove the
seal. Spray Yamaha Lube-Zall into the outer cable. Refit the seal securely.
1 Seal
58
Page 64
Care and storage
● Steering cable ball joint (handlebar end)
and steering cable inner wire (handlebar
end)
To access the steering cable ball joint (handlebar end) and steering cable inner wire
(handlebar end), remove the steering pole
cover. (See step 1 in “Adjusting the jet
thrust nozzle angle” on page 61 for information on removing the steering pole cover.)
● Steering cable ball joint (jet thrust nozzle
end) and steering cable inner wire (jet thrust
nozzle end)
EJU40932
Rustproofing
ECJ01360
NOTICE
Do not run the engine for more than 15
seconds on land without supplying water,
otherwise the engine could overheat.
Spray metallic parts of the hull and engine
with a rust inhibitor such as Yamaha Silicone
Protectant and Lubricant.
To rustproof the internal engine components:
(1) Remove the hood. (See page 27 for hood
removal and installation procedures.)
(2) Loosen the silencer cap and remove it.
1 Silencer cap
(3) Make sure that the area around the wa-
tercraft is clear, and then start the engine
in a well-ventilated area.
(4) Run the engine at a fast idle.
(5) Quickly spray as much rust inhibitor as
possible through the hole in the silencer
cover. Use Yamaha Stor-Rite Engine
Fogging Oil or an equivalent. Keep spray-
ing until the engine stalls (or a maximum
of 15 seconds). WARNING! Do not pour
or spray gasoline, or any substance
other than a rust inhibitor through the
hole in the silencer cover. Do not
spray flammable rust inhibitor prod-
ucts on engine surfaces while the en-
gine is hot. Otherwise, a fire or
explosion could occur.
[EWJ00301]
(6) Install the silencer cap and tighten it se-
curely. NOTICE: Be sure to install the
silencer cap securely after fogging the
engine, otherwise water could enter
the engine and cause damage.
[ECJ00152]
(7) Install the hood in its original position.
59
Page 65
Maintenance
EJU33757
Maintenance
Periodic checks and lubrication will keep your
watercraft in the safest and most efficient condition possible. Therefore, make sure to carry
out the periodic maintenance. Safety is an obligation of the watercraft owner. Proper maintenance must be carried out to keep the
exhaust emission and sound levels within the
regulated limits. The most important points of
watercraft inspection and lubrication are explained on the following pages.
See a Yamaha dealer for genuine Yamaha replacement parts and optional accessories designed for your watercraft.
Remember, failures that are the result of the
installation of parts or accessories which are
not qualitatively equivalent to genuine
Yamaha parts are not covered by the limited
warranty.
Maintenance, replacement, or repair of the
emission control devices and system may
be performed by any marine SI engine repair establishment or individual. Warranty
repair, however, must be performed at an
authorized Yamaha marine dealership.
EWJ00311
WARNING
Be sure to turn off the engine when you
perform maintenance unless otherwise
specified. If you are not familiar with machine servicing, this work should be done
by a Yamaha dealer or other qualified mechanic.
EJU33802
Tool kit
A tool kit is included with this watercraft. Place
the tool kit in a waterproof bag and always
carry it with you whenever you use the watercraft.
1 Tool bag
2 Screwdriver
3 10/12 mm box wrench
4 Spark plug (one included for each cylinder)
5 14/21 mm box wrench
6 Pliers
7 Open-end wrench
EJU34336
Adjusting the steering friction
The amount of friction in the steering can be
adjusted to suit operator preference.
To adjust the steering friction:
(1) Lift the steering pole and support it with
the lock pin.
A service manual is available for purchase
through a Yamaha dealer for owners who
have the mechanical skills, tools, and other
equipment necessary to perform maintenance not covered by this owner’s/operator’s
manual.
1 Steering pole
2 Lock pin
60
Page 66
Maintenance
(2) Remove the four screws, and then re-
move the handlebar cover.
1
1 Handlebar cover
(3) Turn the handlebars so that the left han-
dlebar grip is facing down.
(4) Loosen the locknut.
(5) Tighten or loosen the adjusting nut until
the desired amount of friction is obtained.
(8) While holding the steering pole, move the
lock pin to the stowed position, and then
lower the steering pole.
EJU31288
Adjusting the jet thrust nozzle angle
The angle of the jet thrust nozzle can be adjusted to two settings to suit operator preference.
To adjust the jet thrust nozzle angle:
(1) Remove the two bolts, and then remove
the steering pole cover.
1 Steering pole cover
(2) Pull back the outer sleeve of the steering
cable joint, and then disconnect the joint
from the steering cable pivot bolt.
1 Adjusting nut
2 Locknut
(6) While holding the adjusting nut with a
wrench, tighten the locknut to the speci-
fied torque.
Tightening torque:
Locknut:
29.0 Nm (2.96 kgf-m, 21.4 ft-lb)
(7) Securely install the handlebar cover and
four screws in their original positions.
61
1 Steering cable joint
Page 67
Maintenance
(3) Remove the steering cable pivot bolt.
1 Steering cable pivot bolt
2 Steering column
(4) Select the nozzle angle, install the steer-
ing cable pivot bolt with the lock washer in
the desired position (P1 or P2) on the
steering column, and then tighten the bolt
to the specified torque.
TIP:
The outermost hole in the steering column
cannot be used.
1 Nozzle angles
1 Nozzle angles
2 Steering cable pivot bolt positions
Standard steering cable pivot bolt position:
P2
Tightening torque:
Steering cable pivot bolt:
5.4 Nm (0.55 kgf-m, 4.0 ft-lb)
(5) Securely connect the steering cable joint
to the steering cable pivot bolt.
(6) Securely install the steering pole cover
and two bolts in their original positions.
62
Page 68
Maintenance
EJU40830
Periodic maintenance chart
The periodic maintenance chart gives general guidelines for periodic maintenance. Have a
Yamaha dealer perform the checks in the following chart. However, maintenance may need to
be performed more frequently depending on your operating conditions. If you have any questions, consult a Yamaha dealer.
This “” mark indicates maintenance that you may do yourself.
This “” mark indicates items to be checked and serviced by a Yamaha dealer.
Initial Thereafter every
Item Operation
Spark plugs Check, clean, replace 64
Lubrication points Lubricate 58
Intermediate housing
Fuel system Check —
Fuel filter
Fuel tank Check, clean —
Carburetor Check, adjust —
Engine idling
speed
Carburetor throttle shaft
Bilge strainer Clean —
Impeller Check —
Jet thrust nozzle
angle
Handlebar pivot
shaft
Steering friction Check, adjust —
Throttle cable Check, adjust —
Choke cable Check, adjust 65
Battery Check, charge —
Rubber coupling Check —
Engine mount Check —
Lubricate 64
Check 64
Check, replace —
Check, adjust 66
Check —
Check, adjust —
Check, adjust —
10
hours
50 hours
6
months
12
months
100
hours
12
months
200
hours
24
months
Page
63
Page 69
Maintenance
Initial Thereafter every
Item Operation
Nuts and bolts Check —
EJU41180
10
hours
Lubrication points
Lubricate moving parts with water-resistant
50 hours
6
months
12
months
Have a Yamaha dealer replace the fuel filter if
necessary.
grease. (See page 58 for information on the
main lubrication points.)
Recommended water-resistant grease:
Yamaha Marine Grease/Yamaha
Grease A
Intermediate housing
Fill the intermediate housing with water-resistant grease through the grease nipple using a
grease gun.
Grease quantity:
Initial 10 hours or 1 month:
20.0–22.0 cm³ (0.68–0.74 US oz,
0.71–0.78 Imp.oz)
Every 100 hours or 12 months:
3.0–5.0 cm³ (0.10–0.17 US oz,
0.11–0.18 Imp.oz)
1 Fuel filter
EJU34377
Checking the spark plugs
EWJ00350
WARNING
Be careful not to damage the insulator
when removing or installing a spark plug.
A damaged insulator could allow sparks to
escape, which could result in a fire or explosion.
100
hours
12
months
200
hours
24
months
Page
EJU34225
Checking the fuel filter
Check the fuel filter. The fuel filter should be
replaced if water or dirt is found in the filter.
Remove and check the condition of the spark
plugs.
The condition of a spark plug can indicate
something about the condition of the engine.
For example, if the center electrode portion is
very white, this could indicate an intake air
leak or carburetion problem in that cylinder.
Do not attempt to diagnose any problems
yourself. Have a Yamaha dealer service the
watercraft.
64
Page 70
Maintenance
To remove a spark plug:
(1) Remove the hood. (See page 27 for hood
removal and installation procedures.)
(2) Remove the spark plug cap.
(3) Remove the spark plug, and then check
the condition of the spark plug and the
spark plug gap. If the electrode portion is
significantly discolored, if electrode ero-
sion becomes excessive, if carbon and
other deposits are excessive, or if the
spark plug gap is not within the specified
range, replace the spark plug.
TIP:
When the engine is operating normally, the
color of the spark plug electrode portion will
be a medium-to-light tan.
1 Insulator
2 Electrode
3 Spark plug gap
Specified spark plug:
B7HS
Spark plug gap:
0.6–0.7 mm (0.024–0.028 in)
Tightening torque:
Spark plug:
25.0 Nm (2.55 kgf-m, 18.4 ft-lb)
TIP:
If a torque wrench is not available when you
are installing a spark plug, a good estimate of
the correct torque is 1/4 turn to 1/2 turn past
finger tight using the spark plug wrench included in the tool kit. Have the spark plug adjusted to the correct torque with a torque
wrench as soon as possible.
(3) Wipe off any water or dirt inside the spark
plug cap.
(4) Install the spark plug cap by pushing it
down until it is securely installed in its
original position.
(5) Install the hood in its original position.
EJU34441
Adjusting the choke cable
Check that the choke cable is properly adjusted.
To adjust the choke cable:
(1) Pull the choke knob out until it stops, and
then release the knob. The knob should
not move.
(2) If the choke knob moves back on its own,
tighten the choke knob adjusting nut
slightly. If the knob is difficult to move,
loosen the adjusting nut slightly.
To install a spark plug:
(1) Wipe off any dirt from the threads, insula-
tor, and gasket surface of the spark plug.
(2) Install the spark plug, and then tighten it
to the specified torque.
65
1 Choke knob adjusting nut
Page 71
EJU34463
Adjusting the carburetor
ECJ00172
NOTICE
If the carburetor settings are disturbed by
someone who does not have the necessary technical knowledge, poor engine
performance and damage may result.
The carburetor is a vital part of the engine and
requires very sophisticated adjustments.
Most adjustments should be left to a Yamaha
dealer who has the professional knowledge
and experience to make them.
However, the operator may adjust the engine
idling speed as part of the usual maintenance
routine.
EJU34471
Adjusting the engine idling speed
(1) Place the watercraft in the water.
(2) Start the engine and warm it up for 1 to 2
minutes.
(3) While using a diagnostic tachometer, turn
the throttle stop screw to adjust the en-
gine idling speed to specification. Turn
the throttle stop screw clockwise to in-
crease the engine idling speed or coun-
terclockwise to decrease the engine
idling speed.
Maintenance
1 Throttle stop screw
Engine idling speed:
1300 ±50 r/min
66
Page 72
Specifications
EJU34542
Specifications
Watercraft capacity:
Maximum people on board:
1 person
Dimensions:
Length:
2240 mm (88.2 in)
Width:
680 mm (26.8 in)
Height:
660 mm (26.0 in)
Dry weight:
139 kg (306 lb)
Performance:
Maximum fuel consumption:
29.0 L/h (7.7 US gal/h, 6.4 Imp.gal/h)
Cruising range at full throttle:
0.62 hour
Trolling speed:
1300 ±50 r/min
Engine:
Engine type:
2-stroke
Number of cylinders:
2
Engine displacement:
701 cm³
Bore & stroke:
81.0 × 68.0 mm (3.19 × 2.68 in)
Compression ratio:
7.2 : 1
Lubrication system:
Pre-mixed fuel and oil
Cooling system:
Water
Starting system:
Electric
Ignition system:
C.D.I.
Spark plug:
B7HS
Spark plug gap:
0.6–0.7 mm (0.024–0.028 in)
Battery capacity:
12 V, 19.0 Ah
Charging system:
Flywheel magneto
Drive unit:
Propulsion system:
Jet pump
Jet pump type:
Axial flow, single stage
Impeller rotation:
Counterclockwise
Jet thrust nozzle angle:
P1: 14.4+14.4°
P2: 17.3+17.3°
Fuel and oil:
Recommended fuel:
Regular unleaded gasoline
Minimum octane rating (PON):
86
Minimum octane rating (RON):
90
Recommended engine oil:
YAMALUBE 2-W or TC-W3 outboard motor
oil or equivalent
Fuel mixing ratio (fuel to oil):
50 :1
Fuel tank total capacity:
18 L (4.8 US gal, 4.0 Imp.gal)
Fuel tank reserve capacity:
5.5 L (1.5 US gal, 1.2 Imp.gal)
67
Page 73
Trouble recovery
EJU34561
Troubleshooting
If you have any trouble with your watercraft, use the troubleshooting chart to check for the possible cause.
If you cannot find the cause, consult a Yamaha dealer.
EJU34574
Troubleshooting chart
TROUBLE POSSIBLE CAUSE REMEDY PAGE
Engine does not
start (Starter motor
does not turn over)
Engine does not
start (Starter motor
turns over)
Engine shutoff switch
Fuse Burned out Replace fuse and
Battery Run down Recharge 55
Starter motor Faulty Have serviced by
Fuel cock Turned to “OFF” Turn fuel cock knob to
Fuel Empty Refill as soon as pos-
Fuel tank Water or dirt present Have serviced by
Spark plug Fouled or defective Replace 64
Spark plug
cap
Crankcase Filled with water Have serviced by
Fuel filter Clogged or water
Choke Knob moves back on
Clip not in place Install clip
check wiring
Poor terminal connections
Terminal corroded Clean or replace 55
Stale or contaminat-edHave serviced by
Not connected or
loose
pooled
its own
Tighten as required
Yamaha dealer
“ON”
sible
Yamaha dealer
Yamaha dealer
Connect properly
Yamaha dealer
Have serviced by
Yamaha dealer
Tighten choke knob
adjusting nut
23
71
55
—
24
32
—
—
64
72
64
65
68
Page 74
Trouble recovery
TROUBLE POSSIBLE CAUSE REMEDY PAGE
Engine runs irregularly or stalls
Watercraft slow or
loses power
Fuel Empty Refill as soon as pos-
Stale or contaminat-edHave serviced by
Too much oil in fuel
mixing ratio
Choke Knob is left pulled Push fully in 25
Fuel filter Clogged or water
Fuel tank Water or dirt present Have serviced by
Spark plug Fouled or defective Replace 64
Spark plug
cap
Electrical wiring
Carburetor Incorrect idle adjust-
Cavitation Jet intake clogged Clean 70
Engine overheated
Fuel filter Clogged Have serviced by
Spark plug Fouled or defective Replace 64
Spark plug
caps
Fuel Stale or contaminat-edHave serviced by
pooled
Incorrect heat range Replace 64
Gap incorrect Replace 64
Loose Connect properly 64
Cracked, torn or dam-
aged
Loose electrical con-
nections
ment
Clogged Have serviced by
Impeller damaged or
worn
Jet intake clogged Clean
Incorrect heat range Replace 64
Gap incorrect Replace 64
Loose Connect properly
sible
Yamaha dealer
Correct fuel-to-oil ra-
tio to 50:1
Have serviced by
Yamaha dealer
Yamaha dealer
Have serviced by
Yamaha dealer
Have serviced by
Yamaha dealer
Have serviced by
Yamaha dealer
Yamaha dealer
Have serviced by
Yamaha dealer
Yamaha dealer
Yamaha dealer
32
—
31
64
—
—
—
—
66
70
70
64
64
—
69
Page 75
Trouble recovery
EJU34622
Emergency procedures
EJU34634
Cleaning the jet intake and impeller
EWJ00782
WARNING
Before attempting to remove weeds or debris from the jet intake or impeller area,
shut the engine off and remove the clip
from the engine shut-off switch. Severe injury or death could result from coming in
contact with the rotating parts of the jet
pump.
If weeds or debris gets caught in the jet intake
or impeller, cavitation can occur, causing jet
thrust to decrease even though engine speed
rises. If this condition is allowed to continue,
the engine will overheat and may seize.
NOTICE: If weeds or debris gets caught in
the jet intake, do not operate the watercraft
above trolling speed until they have been
removed.
If there is any sign that the jet intake or impeller is clogged with weeds or debris, return to
shore and check the intake and impeller. Al-
[ECJ00653]
ways stop the engine before beaching the watercraft.
(1) Place a suitable clean cloth or carpeting
underneath the watercraft to protect it
from abrasions and scratches. Turn the
watercraft on its side as shown. NOTICE:
Always turn the watercraft over onto
its port (left) side. When turning the
watercraft on its side, support the bow
so that the handlebars are not bent or
damaged.
[ECJ00661]
70
Page 76
Trouble recovery
(2) Remove any weeds or debris from
around the jet intake, drive shaft, impeller, jet pump housing, and jet thrust nozzle.
If debris is difficult to remove, consult a
Yamaha dealer.
EJU34641
Jumping the battery
If the watercraft battery has run down, the engine can be started using a 12-volt booster
battery and jumper cables.
EJU34653
Connecting the jumper cables
EWJ01250
WARNING
To avoid battery explosion and serious
damage to the electrical system:
● Do not reverse the polarity of the jumper
cables when connecting to the batteries.
● Do not connect the negative (–) jumper
cable to the negative (–) terminal of the
watercraft battery.
● Do not touch the positive (+) jumper ca-
ble to the negative (–) jumper cable.
(1) Connect the positive (+) jumper cable to
the positive (+) battery terminals of both
batteries.
(2) Connect one end of the negative (–)
jumper cable to the negative (–) battery
terminal of the booster battery.
(3) Connect the other end of the negative (–)
jumper cable to an unpainted bolt on the
cylinder head.
1 Positive (+) jumper cable
2 Booster battery
3 Negative (–) jumper cable
(4) Start the engine, and then disconnect the
jumper cables by reversing the steps
above. (See page 23 for information on
starting the engine.)
EJU34673
Replacing the fuse
If the fuse is blown, replace it with the proper
fuse.
21
71
1 Good fuse
2 Blown fuse
To replace the fuse:
(1) Remove the hood. (See page 27 for hood
removal and installation procedures.)
(2) Loosen the cap and remove it.
(3) Pull out the red lead to pull out the fuse
holder from the electrical box.
Page 77
Trouble recovery
(4) Open the fuse holder and replace the
fuse with one of the correct amperage.
WARNING! Do not use fuses of higher
amperage than recommended. Substitution with a fuse that has an improper
rating can cause extensive electrical
system damage and possible fire.
[EWJ00801]
1 Fuse holder
2 Electrical box
3 Fuse
4 Cap
Fuse amperage:
Battery fuse:
10 A
(5) Insert the fuse holder into the electrical
box.
(6) Install the cap and tighten it securely.
(7) Install the hood in its original position.
EJU34704
Towing the watercraft
EWJ00811
WARNING
● The operator of the towing boat must
keep speed to a minimum and avoid traffic or obstacles which could be a hazard
to the operator on the watercraft.
● The towline should be long enough so
that the watercraft will not collide with
the towing boat when slowing down.
If the watercraft becomes inoperative in the
water, it can be towed to shore.
To tow the watercraft:
Use a towline that is three times the combined
length of the towing boat and the watercraft.
(1) Securely attach the towline to the bow
rope hole of the watercraft being towed.
1
1 Bow rope hole
(2) Ride the watercraft with your body weight
supported on the riding tray. Hold on to
the handlebars in order to balance the
watercraft and keep the bow up out of the
water. NOTICE: The bow must be kept
up out of the water during towing, otherwise water could flood the engine
compartment or water could flow back
into the engine, causing severe engine damage.
Tow the watercraft at 8 km/h (5 mph) or less.
NOTICE: Tow the watercraft at 8 km/h (5
mph) or less, otherwise water could flood
the engine compartment or water could
flow back into the engine, causing severe
engine damage.
EJU34733
Submerged watercraft
If the watercraft is submerged or flooded with
water, drain the water from the engine compartment. Then, have a Yamaha dealer service the watercraft as soon as possible.
(1) Remove the watercraft from the water,
and then remove the hood.
[ECJ01330]
[ECJ01321]
72
Page 78
Trouble recovery
(2) Turn the fuel cock knob to “OFF”.
(3) Turn the watercraft over far enough to
drain the water from the engine compart-
ment. NOTICE: Turning the watercraft
on its side with the hood removed
could cause damage to the steering
pole. Use two people to provide
enough support to make sure that the
steering pole is not damaged.
(4) Turn the watercraft upright again.
(5) Have the watercraft serviced by a
Yamaha dealer as soon as possible.
NOTICE: Be sure to have a Yamaha
dealer inspect the watercraft. Other-
wise, serious engine damage could re-
sult.
[ECJ00791]
[ECJ00701]
73
Page 79
Consumer information
EJU34781
Limited warranty
AMAHA MOTOR CORPORATION, U.S.A.
ATERCRAFT LIMITED WARRANTY
amaha Motor Corporation is proud of its heritage and reputation for producing products with high standards of quality and workman-
hip. Product excellence provides the cornerstone for our commitment to customer satisfaction. The Yamaha Watercraft Limited War-
anty is your assurance of this commitment.
his warranty provides you with protection against the expense of repairs for your watercraft that are required as a result of defects in
aterials or workmanship. When maintained and utilized in the prescribed manner, you can count on your Yamaha watercraft to pro-
ide reliable service.
his warranty provides you with specific coverage and notes your responsibilities in maintaining and operating your watercraft.
lease take the time to read and become familiar with this warranty.
ERIOD OF WARRANTY. Any new Yamaha watercraft purchased for pleasure use from an authorized Yamaha dealer in the United
States, will be warranted against defects in material or workmanship for a period of one (1) year from date of purchase, subject to
xclusions noted herein. Any Yamaha Watercraft purchased and utilized for commercial applications will be warranted for a period of
inety [90] days from the date of purchase, subject to exclusions noted herein. Replacement parts used in warranty repairs will be war-
anted for the balance of the applicable warranty period.
he warranty described here applies to watercrafts purchased and registered for use in the United States only. For warranty provisions
utside the United States, contact the particular country’s local Yamaha distributor.
BTAINING REPAIRS UNDER WARRANTY. During the period of warranty, any authorized Yamaha dealer will, free of charge, repair
r replace, at Yamaha’s option, any parts adjudged defective by Yamaha due to faulty workmanship or material from the factory. All
arts replaced under warranty will become the property of Yamaha Motor Corporation, U.S.A.
USTOMER’S RESPONSIBILITY. Under the terms of this warranty, the customer will be responsible for ensuring that the watercraft is
roperly operated, maintained, and stored as specified in the applicable Owner’s/Operator’s Manual.
he owner of the watercraft shall give notice to an authorized Yamaha dealer of any and all apparent defects within ten [10] days of disovery and make the watercraft available at that time for inspection and repairs at the dealer’s place of business.
ENERAL EXCLUSIONS FROM WARRANTY. This warranty will not cover the repair of damage if the damage is a result of abuse or
eglect of the product. Examples of abuse and neglect include, but are not limited to:
. Racing or competition use, modification of original parts abnormal strain.
. Lack of proper maintenance and off season storage as described in the Owner’s/Operator’s Manual, installation of parts or acces-
sories that are not equivalent in design and quality to genuine Yamaha parts.
. Use of lubricants, oils, and fuel/oil mixtures that are not suitable for watercraft motor use.
. Damage as a result of accidents, collisions, contact with foreign materials, or submersion.
. Growth of marine organisms on motor or hull surfaces.
. Normal deterioration.
. Gel coat stress cracks.
PECIFIC PARTS EXCLUDED FROM WARRANTY.
arts replaced due to normal wear or routine maintenance such as oil, spark plugs, fuel filters, impeller and liner, and anodes are not
overed by warranty. Charges for transporting the watercraft to and from an authorized Yamaha dealer are excluded from warranty covrage.
RANSFER OF WARRANTY. Transfer of the warranty from the original purchaser to any subsequent purchaser is possible by having
he watercraft inspected by an authorized Yamaha dealer and requesting the dealer to submit a change of registration to Yamaha Motor
orporation. U.S.A. within ten [10] days of the transfer.
MISSION CONTROL WARRANTY. Yamaha warrants to the ultimate purchaser and any subsequent owner, that the emission control
omponents on this engine are designed, built and equipped so as to conform at the time of sale with applicable regulations under
ection 213 of the Clean Air Act and that this engine is free from defects in materials and workmanship which cause said engine to fail
o conform with applicable regulations for thirty (30) months from the date of purchase or 175 hours of operation, whichever comes first,
and, for evaporative emission components, for twenty-four (24) months from the date of purchase. Some states have different emission
ontrol warranty provisions. As these vary from state to state, consult your Yamaha dealer or contact Yamaha Customer Relations at 100-962-7926 for more information.
AMAHA MOTOR CORPORATION, U.S.A. MAKES NO OTHER WARRANTY OF ANY KIND, EXPRESSED OR IMPLIED. ALL IMPLIED WAR-
ANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE WHICH EXCEED THE OBLIGATIONS AND TIME LIMITS
TATED IN THIS WARRANTY ARE HEREBY DISCLAIMED BY YAMAHA MOTOR CORPORATION, U.S.A. AND EXCLUDED FROM THIS
ARRANTY.
OME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT
PPLY TO YOU. ALSO EXCLUDED FROM THIS WARRANTY ARE ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES INCLUDING LOSS
F USE. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE
BOVE EXCLUSION MAY NOT APPLY TO YOU.
74
Page 80
Consumer information
O
n
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE T
STATE.
YAMAHA MOTOR CORPORATION, U.S.A.
WARRANTY QUESTIONS AND ANSWERS
Q. What costs are my responsibility during the warranty period?
A. The customer’s responsibility includes all costs of normal maintenance services, non-warranty repairs, accident and collision dam-
ages.
Q. What are some examples of “abnormal” strain, neglect, or abuse?
A. These terms are general and overlap each other in areas. Specific examples include:
Running the watercraft out of oil, operating the machine with a broken or damaged part which causes another part to fail, and so
on. If you have any specific questions on operation or maintenance, please contact your Yamaha dealer for advice.
Q. Does the warranty cover incidental costs such as transportation due to a failure?
A. No. The warranty is limited to repair of the watercraft itself.
Q. May I perform any or all of the recommended maintenance shown in the Owner’s/Operator’s Manual instead of having the dealer do
them?
A. Yes, if you are a qualified mechanic and follow the procedures specified in the Owner’s/Operator’s and Service Manual. We do rec-
ommend, however, that items requiring special or equipment be done by a Yamaha dealer.
Q. Will the warranty be void or cancelled if I do not operate or maintain my new watercraft exactly as specified in the Owner’s/Opera-
tor’s Manual?
A. No. The warranty on a new watercraft cannot be “voided” or “cancelled”.
or maintenance other than as shown in the Owner’s/Operator’s Manual, that failure may not be covered under warranty.
Q. What responsibility does my dealer have under this warranty?
A. Each Yamaha dealer is expected to:
1. Completely set up each new watercraft before sale.
2. Explain the operation, maintenance, and warranty requirements to your satisfaction at the time of sale, and upon your request at
any later date. In addition, each Yamaha dealer is held responsible for his setup, service and warranty repair work.
Q. Is the warranty transferable to second owners?
A. Yes. The remainder of the existing warranty can be transferred upon request. The unit has to be inspected and re-registered by an
authorized Yamaha dealer for the policy to remain effective.
CUSTOMER SERVICE
If your watercraft requires warranty service, you must take it to any authorized Yamaha dealer within the continental United States. Be
sure to bring your warranty registration card or other valid proof of the original date of purchase. If a question or problem arises regarding warranty, first contact the owner of the dealership. Since all warranty matters are handled at the dealer level, this person is in the
best position to help you. If you are still not satisfied and require additional assistance, please write:
YAMAHA MOTOR CORPORATION U.S.A.
CUSTOMER RELATIONS DEPARTMENT
CHANGE OF ADDRESS
The federal government requires each manufacturer to maintain a complete, up-to-date list of all first purchasers against the p ossibility
of a safety-related defect and recall. This list is complied from the purchase registrations sent to Yamaha Motor Corporation, U.S.A. by
the selling dealer at the time of your purchase.
If you should move after you have purchased your new watercraft, please advise us of your new address by sending a postcard listing
your Yamaha model name, engine number, dealer number [or dealer’s name] as it is shown on your warranty card, your name and new
mailing address.
Mail to:
YAMAHA MOTOR CORPORATION, U.S.A.
This will ensure that Yamaha Motor Corporation, U.S.A. has an up-to-date registration record in accordance with federal law.
P.O. Box 6555
Cypress, California 90630
P.O. Box 6555
Cypress, California 90630
Attention: Warranty Department
However, if a particular failure is caused by operatio
Post Office Box 6555
Cypress, California 90630
75
Page 81
Consumer information
EJU34800
YAMAHA EXTENDED SERVICE (Y.E.S.)
Keep your Yamaha protected even after your warranty expires with genuine Yamaha Extended
Service (Y.E.S.).
Y.E.S. is designed and administered by Yamaha Motor Corporation to provide maximum owner
•
satisfaction. You get uninterrupted factory-backed coverage for extra peace of mind.
Y.E.S. is flexible. You choose the plan that is right for you: 12 months, 24 months, 36 months, or
•
(on four-stroke models) 48 months beyond your warranty period.
Y.E.S. is designed and administered by the same Yamaha people who handle your warranty—
•
and it shows in the comprehensive coverage benefits. There are no mileage limitations. Coverage is not limited to “moving parts” or the “drive train” like many other plans. And Y.E.S. covers
manufacturing defects just like the warranty. See the sample contract at your Yamaha dealer to
see how comforting uninterrupted factory-backed protection can be.
You do not have to pay anything for covered repairs. There is no deductible to pay, and repairs
•
are not “pro-rated.” You do not have any “out-of-pocket” expenses for covered repairs.
In addition, Travel and Recreation Interruption Protection (TRIP) is included at no extra cost.
•
TRIP gives you up to $150 reimbursement per occurrence for any reasonable expenses you
incur because your Yamaha needs covered service: replacement vehicle rental, emergency
towing, phone calls, even food and lodging when you are away from home. This superb coverage goes into effect when you purchase Y.E.S., so it applies to any warranty repairs as well as
covered repairs during your entire Y.E.S. plan period.
Y.E.S. coverage is honored at any authorized Yamaha dealer nationwide.
•
Y.E.S. coverage is transferable to a new owner if you sell or trade-in. That can make your
•
Yamaha much more valuable!
This excellent Y.E.S. plan coverage is only available to Yamaha owners like you, and only while
your Yamaha is still within the Yamaha Limited Warranty period. So visit your authorized Yamaha
dealer to get all the facts. He can show you how easy it is to protect your investment with Yamaha
Extended Service.
We urge you to act now. You will get the excellent benefits of TRIP coverage right away, and you
will rest easy knowing you will have strong factory-backed protection even after your Yamaha
Limited Warranty expires.
A special note:
If visiting your dealer is not convenient, contact Yamaha with your Primary ID number (your Owner’s
Manual shows you where to find this number). We will be happy to help you get the Y.E.S. coverage
you need.
Yamaha Service Marketing
P.O. Box 6555
Cypress, CA 90630
1-(866)-YES-EXTD
(1-866-937-3983)
76
Page 82
Index
2-stroke engine oil.................................... 31
A
After removing the watercraft
from the water....................................... 53
Approval label of emission control
certificate ................................................ 2
B
Battery care..............................................55
Battery checks.......................................... 39
Battery, jumping .......................................71
Beaching the watercraft ...........................53
Bilge water check..................................... 39
Bilge water, draining................................. 33
Bilge water, draining on water.................. 33
Boarding and starting in deep water ........51
Boarding and starting in shallow water .... 50
Bow rope hole .......................................... 28
C
Capsized watercraft .................................52
Carburetor, adjusting................................ 66
Choke cable, adjusting.............................65
Choke knob.............................................. 25
Cleaning................................................... 58
Cleaning the watercraft ............................ 55
Cooling water pilot outlet.......................... 25
Cooling water pilot outlet check ...............43
Cruising limitations..................................... 8
E
Emergency procedures............................ 70
Emission control information ...................... 2
Engine break-in........................................ 35
Engine compartment check...................... 38
Engine idling speed, adjusting ................. 66
Engine overheat warning system ............. 26
Engine serial number ................................. 1
Engine shut-off cord (lanyard) check .......41
Engine shut-off switch.............................. 23
Engine stop switch................................... 23
Engine unit check.....................................39
Enjoy your watercraft responsibly ............ 18
Equipment................................................ 27
F
Fire extinguisher check ............................ 42
Fire extinguisher container.......................29
Fire extinguisher container checks........... 42
Flushing the cooling water passages ....... 54
Fuel .......................................................... 31
Fuel and engine oil requirements............. 31
Fuel cock knob......................................... 24
Fuel filter, checking .................................. 64
Fuel level check .......................................38
Fuel system checks.................................. 38
Fuel tank, filling ........................................ 32
Fuse, replacing......................................... 71
G
Getting to know your watercraft ............... 44
Glossary, watercraft ................................. 20
H
Hazard information................................... 12
Hood......................................................... 27
Hood check .............................................. 42
Hull and deck check.................................42
Hull Identification Number (HIN)................. 1
I
Identification numbers................................ 1
J
Jet intake and impeller, cleaning..............70
Jet intake checks...................................... 42
Jet thrust nozzle angle, adjusting.............61
Jumper cables, connecting ......................71
L
Labels, important........................................ 3
Labels, other ..............................................6
Labels, warning .......................................... 4
Launching the watercraft.......................... 45
Learning to operate your watercraft ......... 44
Leaving the watercraft.............................. 47
Limitations on who may operate
the watercraft .......................................... 7
Limited warranty....................................... 74
Long-term storage.................................... 58
Lubrication................................................ 58
Lubrication points..................................... 64
M
Main components, location of ..................21
Maintenance............................................. 60
Manufactured date label............................. 2
Mixing fuel and oil ....................................31
Page 83
Index
O
Operating in weeded areas ...................... 53
Operating positions..................................44
Operating the watercraft........................... 47
Operating your watercraft......................... 44
Operation requirements ............................. 9
P
Periodic maintenance chart...................... 63
Post-launch checks.................................. 42
Post-operation care..................................54
Pre-launch checks.................................... 38
Pre-operation check points ...................... 38
Pre-operation checklist............................. 36
Primary Identification (PRI-ID) number ...... 1
R
Recommended equipment ....................... 11
Rules of the Road ....................................13
Rustproofing.............................................59
S
Safety equipment check........................... 42
Spark plugs, checking.............................. 64
Start switch............................................... 23
Starting off................................................ 49
Starting the engine on water .................... 45
Steering friction, adjusting........................60
Steering pole............................................ 24
Steering pole check.................................. 40
Steering system .......................................24
Steering system checks ........................... 39
Stern rope hole......................................... 28
Stopping the engine ................................. 47
Stopping the watercraft ............................ 49
Storage pouch..........................................28
Storage pouch checks.............................. 41
Submerged watercraft.............................. 72
Switch checks .......................................... 41
T
Throttle lever ............................................ 24
Throttle lever checks................................ 40
To get more boating safety information.... 17
Tool kit...................................................... 60
Towing the watercraft............................... 72
Transporting............................................. 33
Troubleshooting ....................................... 68
Troubleshooting chart ..............................68
Turning the watercraft .............................. 47
W
Water separator ....................................... 26
Water separator check.............................39
Watercraft characteristics.........................12
Watercraft control functions ..................... 23
Y
YAMAHA EXTENDED SERVICE
(Y.E.S.) .................................................76
Page 84
Page 85
Page 86
YAMAHA MOTOR CORPORATION, USA
Printed in Japan
July 2009–0.3 × 1 CR
Printed on recycled paper
Loading...
