U
CD RECEIVER
AMPLI-TUNER CD
OWNER’S MANUAL
MODE D’EMPLOI
IMPORTANT SAFETY INSTRUCTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
• Explanation of Graphical Symbols
The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert you to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle
is intended to alert you to the presence of important
operating and maintenance (servicing) instructions
in the literature accompanying the appliance.
IMPORTANT
Please record the serial number of this unit in the space
below.
MODEL:
Serial No.:
The serial number is located on the rear of the unit. Retain
this Owner’s Manual in a safe place for future reference.
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8 Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9 Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has
two blades and a third grounding prong. The wide blade
or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10 Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11 Only use attachments/accessories specified by the
manufacturer.
12 Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
13 Unplug this apparatus during lightning storms or when
unused for long periods of time.
14 Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug
is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to rain
or moisture, does not operate normally, or has been
dropped.
We Want You Listening For A Lifetime
Yamaha and the Electronic Industries Association’s Consumer Electronics Group want you to get the most out of your
equipment by playing it at a safe level. One that lets the sound come through loud and clear without annoying blaring or
distortion – and, most importantly, without affecting your sensitive hearing. Since hearing damage from loud sounds is
often undetectable until it is too late, Yamaha and the Electronic Industries Association’s Consumer Electronics Group
recommend you to avoid prolonged exposure from excessive volume levels.
i En
FCC INFORMATION (for US customers)
1 IMPORTANT NOTICE: DO NOT MODIFY THIS
UNIT!
This product, when installed as indicated in the
instructions contained in this manual, meets FCC
requirements. Modifications not expressly approved by
Yamaha may void your authority, granted by the FCC,
to use the product.
2 IMPORTANT:
accessories and/or another product use only high quality
shielded cables. Cable/s supplied with this product MUST
be used. Follow all installation instructions. Failure to
follow instructions could void your FCC authorization to
use this product in the USA.
When connecting this product to
3 NOTE: This product has been tested and found to comply
with the requirements listed in FCC Regulations, Part 15
for Class “B” digital devices. Compliance with these
requirements provides a reasonable level of assurance that
your use of this product in a residential environment will
not result in harmful interference with other electronic
devices.
This equipment generates/uses radio frequencies and,
if not installed and used according to the instructions
found in the users manual, may cause interference
harmful to the operation of other electronic devices.
Compliance with FCC regulations does not guarantee
that interference will not occur in all installations. If
this product is found to be the source of interference,
which can be determined by turning the unit “OFF”
and “ON”, please try to eliminate the problem by using
one of the following measures:
Relocate either this product or the device that is being
affected by the interference.
Utilize power outlets that are on different branch
(circuit breaker or fuse) circuits or install AC line
filter/s.
In the case of radio or TV interference, relocate/
reorient the antenna. If the antenna lead-in is 300 ohm
ribbon lead, change the lead-in to coaxial type cable.
If these corrective measures do not produce
satisfactory results, please contact the local retailer
authorized to distribute this type of product. If you can
not locate the appropriate retailer, please contact
Yamaha Electronics Corp., U.S.A. 6660 Orangethorpe
Ave, Buena Park, CA 90620.
The above statements apply ONLY to those products
distributed by Yamaha Corporation of America or its
subsidiaries.
ii En
CAUTION: READ THIS BEFORE OPERATING YOUR UNIT.
1 To assure the finest performance, please read this manual
carefully. Keep it in a safe place for future reference.
2 Install this sound system in a well ventilated, cool, dry,
clean place - away from direct sunlight, heat sources,
vibration, dust, moisture, and/or cold. For proper
ventilation, allow the following minimum clearances
around CRX-332.
Top: 20 cm (8 in)
Rear: 10 cm (4 in)
Sides: 10 cm (4 in)
3 Locate this unit away from other electrical appliances,
motors, or transformers to avoid humming sounds.
4 Do not expose this unit to sudden temperature changes
from cold to hot, and do not locate this unit in an
environment with high humidity (i.e. a room with a
humidifier) to prevent condensation inside this unit,
which may cause an electrical shock, fire, damage to this
unit, and/or personal injury.
5 Avoid installing this unit where foreign object may fall
onto this unit and/or this unit may be exposed to liquid
dripping or splashing. On the top of this unit, do not
place:
– Other components, as they may cause damage and/or
discoloration on the surface of this unit.
– Burning objects (i.e. candles), as they may cause fire,
damage to this unit, and/or personal injury.
– Containers with liquid in them, as they may fall and
liquid may cause electrical shock to the user and/or
damage to this unit.
6 Do not cover this unit with a newspaper, tablecloth,
curtain, etc. in order not to obstruct heat radiation. If the
temperature inside this unit rises, it may cause fire,
damage to this unit, and/or personal injury.
7 Do not plug in this unit to a wall outlet until all
connections are complete.
8 Do not operate this unit upside-down. It may overheat,
possibly causing damage.
9 Do not use force on switches, knobs and/or cords.
10 When disconnecting the power cable from the wall outlet,
grasp the plug; do not pull the cable.
11 Do not clean this unit with chemical solvents; this might
damage the finish. Use a clean, dry cloth.
12 Only voltage specified on this unit must be used. Using
this unit with a higher voltage than specified is dangerous
and may cause fire, damage to this unit, and/or personal
injury. Yamaha will not be held responsible for any
damage resulting from use of this unit with a voltage
other than specified.
13 To prevent damage by lightning, keep the power cable
and outdoor antennas disconnected from a wall outlet or
this unit during a lightning storm.
14 Do not attempt to modify or fix this unit. Contact
qualified Yamaha service personnel when any service is
needed. The cabinet should never be opened for any
reasons.
15 When not planning to use this unit for long periods of
time (i.e. vacation), disconnect the AC power plug from
the wall outlet.
16 Be sure to read the “TROUBLESHOOTING” section on
common operating errors before concluding that this unit
is faulty.
17 Before moving this unit, press to set this unit to the
standby mode, and disconnect the AC power plug from
the wall outlet.
18 Condensation will form when the surrounding
temperature changes suddenly. Disconnect the power
cable from the outlet, then leave this unit alone.
19 When using this unit for a long time, this unit may
become warm. Turn the power off, then leave this unit
alone for cooling.
20 Install this unit near the AC outlet and where the AC
power plug can be reached easily.
21 The batteries shall not be exposed to excessive heat such
as sunshine, fire or the like.
22 Excessive sound pressure from earphones and
headphones can cause hearing loss.
This unit is not disconnected from the AC power source as long as
it is connected to the wall outlet, even if this unit itself is turned off
by . This state is called the standby mode. In this state, this unit is
designed to consume a very small quantity of power.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
LASER SAFETY
This unit employs a laser. Due to possible eye injury, only a
qualified service person should remove the cover or attempt to
service this device.
DANGER
This unit emits visible laser radiation when open. Avoid direct
eye exposure to beam. When this unit is plugged into the wall
outlet, do not place your eyes close to the opening of the disc tray
and other openings to look into inside.
LASER
Type Semiconductor laser GaAs/GaAlAs
Wave length 790 nm
Output Power 7 mW
WARNING
DO NOT TOUCH THIS UNIT WHEN IT IS USED
CONTINUOUSLY AT HIGH VOLUME BECAUSE THE
BOTTOM OF THIS UNIT MAY BECOME HOT. IT MAY LEAD
TO INJURIES SUCH AS BURNS, ETC.
FOR CANADIAN CUSTOMERS
To prevent electric shock, match wide blade of plug to wide slot
and fully insert.
This Class B digital apparatus complies with Canadian ICES-003.
iii En
CONTENTS
PREPARATION
SUPPLIED ACCESSORIES ................................. 2
PLAYABLE DISCS AND FILE FORMAT......... 3
CONNECTION....................................................... 4
Connecting speakers/antennas/subwoofer ................. 4
Connecting the power cable....................................... 5
Other connection........................................................ 5
REMOTE CONTROL ........................................... 6
FRONT PANEL DISPLAY ................................... 7
OPERATION
FRONT PANEL AND BASIC OPERATION ..... 8
LISTENING TO MUSIC ....................................... 9
Playback operation..................................................... 9
Other operation ........................................................ 10
LISTENING TO RADIO STATIONS................ 11
Tuning to radio stations ........................................... 11
Presetting radio stations........................................... 11
Selecting preset radio stations (Preset tuning)......... 11
USING USEFUL FUNCTIONS .......................... 12
Using option menu................................................... 12
Using sleep timer ..................................................... 12
ADDITIONAL INFORMATION
TROUBLESHOOTING .......................................13
General..................................................................... 13
iPod/iPad.................................................................. 14
USB/iPad ................................................................. 15
Radio reception........................................................ 15
Disc playback .......................................................... 16
Remote control ........................................................ 16
HANDLING COMPACT DISCS ........................17
SPECIFICATIONS...............................................17
PREPARATION OPERATION
INFORMATION
ADDITIONAL
■ About this manual
• “iPod” described in this manual may also refer to “iPhone”.
• This manual describes how to operate this unit using a remote control except when it is not available. Some of these
operations are also available using the front panel buttons.
• The symbol “
• Notes contain important information about safety and operating instructions. y indicates a tip for your operation.
• This manual is printed prior to production. Design and specifications are subject to change in part as a result of
improvements, etc. In case of differences between the manual and the product, the product has priority.
☞” with page number(s) indicates the corresponding reference page(s).
English
1 En
PREPARATION
SUPPLIED ACCESSORIES
Make sure you have all of the following items.
Remote control FM antenna
SLEEP
CD
iPod AUX
TUNER
USB
FOLDER
MENU
ENTER
OPTION
DISPLAY
VOLUME
MUTE
TUNING
MEMORY
PRESET
(With CR2032 battery)
■ Using the remote control
Dock cover USB cap
AM antenna
CAUTION
Keep the USB cap out of the reach
of children, so that it is not
mistakenly swallowed.
Use the remote control within 6 m (20’) of this unit and
point it toward the remote control sensor.
PHONES
PRESET
VOLUME
INPUT
Within 6 m (20’)
SLEEP
CD
iPod AUX
USB
TUNER
FOLDER
MENU
ENTER
OPTION
DISPLAY
VOLUME
MUTE
TUNING
MEMORY
PRESET
Battery insulation sheet:
Remove before using.
■ Replacing the battery in the remote control
1
CR2032 battery
3
Notes
• Do not spill liquid on the remote control.
• Do not drop the remote control.
• Do not leave the remote control in the following places:
– hot or humid places such as a bathroom or near a heater
– extremely cold places
– dusty places
While pushing the release tab in direction , slide out
the battery holder in direction .
Change the battery when the operation range of the
remote control decreases.
Notes
• If the battery grows old, the effective operation range of the
2
remote control decreases considerably. If this happens,
replace the battery with new one as soon as possible.
• Exhausted battery may leak. If the battery have leaked,
dispose of it immediately. Avoid touching the leaked
material or letting it come into contact with clothing, etc.
Clean the battery compartment thoroughly before installing
a new battery.
• Keep the battery away from children. If the battery is
accidentally swallowed, contact your doctor immediately.
• When not planning to use the remote control for long
periods of time, remove the battery from the remote control.
• Do not charge or disassemble the supplied battery.
2 En
PLAYABLE DISCS AND FILE FORMAT
■ Playable discs
Use compact discs bearing the marks below.
....
Compact discs (digital audio)
....
CD-R,CD-RW digital audio discs
• CD-R or CD-RW discs bearing one of
the following phrases.
FOR CONSUMER
FOR CONSUMER USE
FOR MUSIC USE ONLY
• Finalized CD-R or CD-RW discs
Note
This compact disc player may not be able to
play some CD-R/CD-RW discs or discs on
which recording was not made correctly.
....
CD-TEXT discs
To play back an 8-cm (3 in) CD
Place it in the inner recessed area of the disc tray. Do not
put a normal (12-cm) CD on top of an 8-cm (3 in) CD.
To prevent a malfunction of this unit:
• Do not use any nonstandard shaped
disc (heart, etc.) available on the
market because it might damage the
unit.
• Do not use a disc with tape, stickers, or paste on it. If
you use such a disc, the disc may get stuck in the
unit, or damage to the unit may result.
Note: Do not use any lens cleaners as they may be a
cause of malfunction.
■ Playable MP3 and WMA files
MP3
Format
MPEG 1 Audio Layer-3
MPEG 2 Audio Layer-3, 2
*1Variable bitrate is supported.
Bitrate
(kbps)
32-320
8-160
WMA
• Version 8
• Version 9 (Standard and variable bitrates are supported.
Professional and Lossless are not supported.)
Profile
High Profile
Mid Profile
*2Both constant and variable bitrates are supported.
Bitrate
(kbps)
32-320
16-32 22.05
Notes
• Playback for Data Disc starts in alphanumeric order of files.
• Playback for USB starts in order by date and time of creation.
• Copyright-protected WMA (DRM) files cannot be played back
by this unit.
• The disc must be ISO 9660 compatible.
• The maximum file and folder numbers are as follows.
Data Disc USB
Maximum total number of file
and folder
Maximum folder number
Maximum file number per
folder
3
*
The root is counted as one of the folders.
*3
*3
Sampling
frequency
(kHz)
*1
32/44.1/48
*1
16/22.05/24
Sampling
frequency
(kHz)
*2
32/44.1/48
512 9,999
255 999
511 255
PREPARATION
3 En
English
CONNECTION
Connecting speakers/antennas/subwoofer
Follow the procedure below to connect the speakers and FM/AM antennas to this unit. For information on your speakers,
refer to the owner’s manual supplied for the speakers.
If a subwoofer is connected, low-frequency audio signals are output through SUBWOOFER OUT.
CAUTION
Do not connect the power cable of this unit until all cable connections are completed.
AM antenna
Notes
• Place the antenna in a location with good signal
reception.
• Digital devices located near the antenna may
affect signal reception.
FM antenna
Notes
• The antenna should be stretched out.
• If you use an outdoor antenna instead of the
supplied FM antenna, reception will be better.
• If radio reception is poor, change the height,
direction, or placement of the antenna.
• If you use an FM antenna that is not supplied
with the unit, make sure that the base of the
antenna is not threaded.
Subwoofer (sold
separately)
Subwoofer cable
(sold separately)
Be sure to remove insulation
from the end of each speaker
cable.
Notes
• If you connect a subwoofer, use a subwoofer that has a built-in amplifier.
• Be sure to connect the left channel (L), right channel (R), “+”(red) “–”(black) properly. If the connections are faulty, no sound will be
heard from the speakers, and if the polarity of the speaker connections is incorrect, the sound will be unnatural and lacks bass.
• Do not let the bare speaker wires touch each other or do not let them touch any metal part of this unit. This could damage this unit and/
or the speakers.
• Use speakers having more than 6 Ω impedance.
• There is a chance that placing speakers too close to a CRT-based (Braun tube) TV set might impair picture color. Should this happen,
move the speakers away from the TV set.
4 En
Connecting the power cable
CONNECTION
■ Connecting iPad
Connect or remove your iPad whenever you want.
After you made all connections, connect the power cables
of this unit
To the wall
outlet
Other connection
■ Stationing iPod
Station or remove your iPod whenever you want.
y
An iPod is charged when set in the iPod dock.
When the unit is turned on and the input source is set to USB, the
iPod is not charged.
Note
This unit is compatible with iPod classic, iPod nano (2nd
generation and later), iPod touch and iPhone.
USB
IPod
y
When the unit is turned on and the input source is set to USB, the
connected iPad is charged.
Note
• Make sure to use a Dock Connector to USB Cable that is
supplied with your iPad.
• When an iPad or USB device is not in use, set the USB cover to
protect USB port.
■ Connecting a USB device
Connect or remove your USB device whenever you want.
USB
IPod
PREPARATION
Dock Adapter
USB
IPod
iPod dock
Notes
• To secure the connection, attach a compatible Dock Adapter
supplied with the iPod or an iPod Universal Dock Adapter (sold
separately), and remove the protective case covering from your
iPod.
• If you do not use an adapter or if the adapter is not compatible,
the connection could be loose or poor, which could cause
damage or malfunctions. For details on dock adaptor
information, please visit official Apple’s website.
• If an iPod in protective case is connected by force, the
connector may be damaged. Remove the protective case before
connection.
• Attach the dock cover to the iPod dock whenever you are not
using it.
y
When the unit is turned on and the input source is set to USB, the
connected USB device is charged.
Notes
• This unit supports USB mass storage class devices (e.g., flash
memories or portable audio players) using FAT16 or FAT32
format.
• Do not connect devices other than USB mass storage class
devices (such as USB chargers or USB hubs), PCs, card
readers, an external HDD, etc.
• USB devices that use encryption cannot be used.
• When an iPad or USB device is not in use, set the USB cover to
protect USB port.
■ Connecting an external device
Connect your portable audio device using a commercially
available 3.5 mm (1/8 in) mini plug cable.
English
5 En
REMOTE CONTROL
1
2
3
4
5
6
7
8
9
CD
TUNER
OPTION
SLEEP
MEMORY
iPod AUX
FOLDER
MENU
ENTER
VOLU ME
TUNING
PRESET
USB
DISPLAY
MUTE
0
A
B
C
D
E
F
1 Infrared signal transmitter
2 SLEEP: Sleep setting (☞ P. 12)
3 Source buttons: Change sources. When listening to the
radio, press TUNER to switch between the FM and AM
bands.
4 FOLDER (during data CD/USB playback): Change folder.
5 , : Scrolls through items on the iPod’s screen.
6 OPTION: Displays the option menu. (☞ P. 12)
7 (Shuffle), (Repeat) (☞ P. 10)
8 TUNING (during receiving radio): Tuning radio (☞ P. 11)
9 PRESET (during receiving radio): Select the preset radio
station (☞ P. 11)
0 : Standby/on
A , (during playback): Skip backward and forward/
press and hold to rewind and fast-forward
MENU: Returns to the upper level in the iPod menu.
: Play/pause
S/T/W/X (During using the option menu): Changes the
setting
ENTER
(During using the iPod): Select group/start playback
(During using the option menu): Confirms the setting
B : Stop playback.
C DISPLAY: Switches the information shown on the front
panel. (☞ P. 10)
D MUTE: Mute/resume the sound.
E VOLUME: Volume control
F MEMORY: Memories preset radio stations. (☞ P. 11)
6 En
FRONT PANEL DISPLAY
90 A
8
PREPARATION
12 34 756
SLEEP
PRESET
VOLUME
INPUT
PHONES
PRESET
TUNED
STEREO
MEMORY
AUTO
SHUFFLE
ARTISTS
REPEAT
ALBUMS
SONGS
MUTE
B
1 SLEEP indicator: Lights up when the sleep timer is on
(☞ P. 12).
2 PRESET indicator: Lights up when you preset radio
stations (☞ P. 11).
3 STEREO indicator: Lights up when this unit is receiving a
strong signal from an FM stereo broadcast.
4 AUTO indicator: Lights up when this unit is in the
Automatic Tuning mode (☞ P. 11).
5 SHUFFLE indicator: Lights up when you set your
iPod/iPad/CD/USB to shuffle play (☞ P. 10).
6 REPEAT indicator: Lights up when you set your
iPod/iPad/CD/USB to repeat play (☞ P. 10).
7 MUTE indicator: Lights up when the sound is muted.
8 Multi information display: Shows the various
information.
9 TUNED indicator: Lights up when this unit is tuned into a
station (☞ P. 11).
0 MEMORY indicator: Flashes when searching for a radio
station by automatic preset tuning. Lights up when you preset
radio stations automatically or manually (☞ P. 11).
A Multi information indicators: Indicate the music
information currently displayed on Multi information display
(☞ P. 10).
B Operation indicators: Show the available menu buttons
for the currently selected OPTION menu item.
English
7 En
OPERATION
FRONT PANEL AND BASIC OPERATION
y
• Press to set the unit to standby mode. All the information on the front panel display is not displayed in standby mode. This can
reduce power consumption. To turn on the unit, press , , or on the front panel. If you press , the input source
is set to CD, iPod or USB depending on which input source is used last. Playback begins if the input source is set to CD or USB.
USB port:
☞ P. 5, 9
:
Unit standby/on
3.5 mm (1/8 in) mini plug cable
Remote control sensor:
Receives signals from the remote
control.
USB
IPod
iPod dock
Disc tray
PHONES
INPUT
VOLUME
PRESET
:
Disc tray open/close
:
Play/pause playback
:
Stop playback
(During playback):
Skip and search backward/forward.
PRESET (During receiving radio):
Select the preset radio station.
VOLUME
VOLUME
Down Up
PHONES:
Connecting headphones
No sound is output from the speakers
when headphones are connected.
8 En
INPUT button:
Press repeatedly to choose the input source.
CD iPod AUX USB FM AM
y
To listen to an external device, select AUX
and use the external device to begin
playback.
LISTENING TO MUSIC
Playback operation
Follow the procedures below to play back music.
1
Set the source
2
Switch the
input
3
Select music and start playback
OPERATION
iPod
iPad
USB
Dock Adapter
*1
USB
IPod
iPod
Scroll the list
☞ P. 5
MENU
ENTER
*1
USB
IPod
USB
Control menu
☞ P. 5
Skip to the first file in the previous/next
*2
USB
IPod
folder for MP3 or WMA
☞ P. 5
*3
FOLDER
MENU
CD
VOLUME
INPUT
PHONES
PRESET
CD
OPTION
*1Some features may not be available depending on the model or the software version of your iPod/iPad.
2
*
· Some devices may not work properly even if they meet the requirements.
· Playability of and power supply to all kind of USB devices are not guaranteed.
· The reading time may exceed 30 seconds depending on the number of files/folders.
· Yamaha and suppliers accept no liability for the loss of data saved on the USB devices connected to this unit.
As a precaution, it is recommended that the files are made backup copies.
3
· If you press these buttons, the folder name is displayed on the front panel display for a certain period.
*
· ROOT is displayed for the root folder when the directory contains playable files.
ENTER
English
9 En
LISTENING TO MUSIC
Other operation
■ Control playback
1 2
MENU
ENTER
During playback
OPTION
: Skip forward/Press and hold to Fast forward
: Skip backward/Press and hold to Rewind
: Play/Pause
: Stop
Notes
• Playback for Data Disc starts in alphanumeric order of files.
• Playback for USB starts in order by date and time of creation.
• If is pressed during playback, next time playback starts
from the beginning of the track you listened to last time. If
is pressed again while playback is stopped, next time playback
starts from the first track of the CD/USB device.
• This unit automatically switch the unit to standby mode if the
unit is left turned on for 1 hour without playback or any other
operation being performed (Automatic standby function).
■ Shuffle play
You can play back in random sequence.
Press repeatedly.
For iPod/iPad
*1You cannot set SHUFFLE ALBUMS when you use an iPod
touch, iPhone or iPad.
For CD/USB
*2If the audio format of the selected music source is MP3/
WMA, you can also select SHUFFLE FOLDER.
■ Repeat play
You can play back repeatedly.
Press repeatedly.
For iPod/iPad
For CD/USB
*3If the audio format of the selected music source is MP3/
WMA, you can also select REPEAT FOLDER.
■ Switching the display
You can switch the playback information shown on the
front panel display. Some special characters may not be
shown properly.
1 2
DISPLAY
During playback
For iPod/iPad
Song number and elapsed time (default setting)
↓
Song number and remaining time
↓
Song name
↓
Artist name
↓
Album name
↓
Back to the default setting
Note
This function is available for iPod classic, iPod nano (2nd
generation and later), iPod touch, iPhone and iPad. However,
even with these models, this function may not be available
depending on the software version of your iPod/iPad.
For CD/USB
Track/file number and elapsed time of the current
song (default setting)
↓
Track number and remaining time of the current
*4
song
↓
Total time of the disc
↓
Remaining time of the disc
↓
File name
↓
Track name
↓
Artist name
↓
Album name
↓
Back to the default setting
4
Only for Audio CDs
*
5
*
Only for MP3/WMA files
6
*
Only when the selected track has information
*5
*6
*6
*6
*4
Press repeatedly.
*4
10 En
LISTENING TO RADIO STATIONS
Tuning to radio stations
1 2
TUNER
Press repeatedly to
select FM/AM mode.
Press and hold.
Automatic tuning starts.
y
If the signal received from the station you want to select is weak,
you can also tune into radio stations manually by pressing
TUNING repeatedly.
Note
If you tune to a station manually, the sound is monaural.
TUNING
Presetting radio stations
You can store your favorite FM/AM stations with the
preset function.
■ Automatic preset tuning
1 2
MEMORY
Press and hold MEMORY
for more than 2 seconds
in FM/AM mode.
Start the automatic preset.
y
To cancel automatic presetting, press MEMORY again without
pressing ENTER in step 2.
ENTER
Selecting preset radio stations (Preset tuning)
Select the preset radio station
in FM/AM mode.
PRESET
OPERATION
Note
When you perform the automatic preset, all stored stations are
cleared and the new stations are stored.
■ Manual preset tuning
1 2
3 4
TUNING
Tune into a favorite
radio station.
MENU
ENTER
Select the preset
number you want to
store to.
y
• You can preset up to 30 FM and 30 AM stations.
• To cancel the manual preset while choosing a preset number,
press MEMORY again.
• You can delete a preset station by pressing OPTION →
Cursor S/T → ENTER to select PRESET DELETE.
MEMORY
Press MEMORY.
ENTER
Complete the
manual preset.
English
11 En
USING USEFUL FUNCTIONS
Using option menu
The option menu appears on the front panel display by pressing OPTION. You can set various useful functions with
option menu.
Option menu Parameter or control range Reference page
PRESET DELETE (Displays only when the input source is set to FM/AM.) 11
DIMMER DIMMER OFF (brightest)/DIMMER 1/DIMMER 2 (darkest) This page
TREBLE –10 to +10 This page
BASS –10 to +10 This page
BALANCE L+5 - CENTER - R+5 This page
TIME OFF/ TIME 8H/ TIME 4H
AUTO POWER OFF
AUTO POWER OFF sets the system to standby mode whenever no
operation is performed for a preset amount of time.
This page
1 2 3 4 5
MENU
OPTION
Press OPTION. Select desired
option menu.
ENTER
*1To set additional items, repeat steps 2 to 5.
ENTER
Confirm with
ENTER.
Change the settings.
MENU
ENTER
y
To cancel the setting during the operation, press OPTION.
■ Setting dimmer, tone/balance
DIMMER: Changes the brightness of the front panel display.
TREBLE*2: Adjusts the high frequency response.
BASS*2: Adjusts the low frequency response.
BALANCE: Adjusts the volume level of each left and right speaker channel.
*2Also effective when you are using headphones.
Using sleep timer
The sleep timer sets the unit to the standby mode after the specified time elapses.
SLEEP
Press repeatedly.
30min 60min 90min 120min OFF
ENTER
Complete the
1
setting.*
6
OPTION
Exit option
menu.
The SLEEP indicator lights up on the front panel display (☞ P. 7).
12 En
ADDITIONAL INFORMATION
TROUBLESHOOTING
Refer to the table below when this unit does not function properly. If the problem you are experiencing is not listed below
or if the instruction below does not help, turn off this unit, disconnect the power cable, and contact the nearest authorized
Yamaha dealer or service center.
General
Problem Cause Remedy Page
This unit fails to turn
on or enters the
standby mode soon
after the power is
turned on.
The unit does not
operate properly.
No sound. No appropriate input source has been
The power is
suddenly turned off.
Sound is heard from
the speaker on one
side only.
There is noise
interference from
digital or radio
frequency
equipment.
The power cable is not connected or the
plug is not completely inserted.
This unit has been exposed to a strong
external electric shock (such as lightning
or strong static electricity).
selected.
Speaker connections are not secure. Secure the connections.
The mute function may be on. Cancel the mute function.
The volume is turned down. Turn up the volume.
Signals this unit cannot reproduce are
being input from a source component,
such as a CD-ROM.
The sleep timer may be set. This is not malfunction. Turn on the unit and play the
The unit is left turned on for 1 hour
without playback or any other operation
being performed.
AUTO POWER OFF is triggered. Setting AUTO POWER OFF to TIME OFF enables
Incorrect cable connections. Connect the cables properly. If the problem persists,
This unit is too close to the digital or
high-frequency equipment.
Connect the power cable firmly.
Press and hold for more than 5 seconds to reset
the system. If this does not solve the problem, set this
unit to the standby mode, disconnect the power
cable, plug it back in after 30 seconds and then use it
normally.
Select an appropriate input source with INPUT on
the front panel (or the source buttons on the remote
control).
Play a source whose signals can be reproduced by
this unit.
source again.
to play continuously.
the cables may be defective.
Move this unit farther away from such equipment.
5
—
—
4
6
8
3
—
12
4
—
INFORMATION
ADDITIONAL
13 En
English
TROUBLESHOOTING
iPod/iPad
Note
In case of a transmission error without a status message appearing in the front panel of this unit, check the connection to your iPod/iPad
(see page 5).
Status message Cause Remedy Page
iPod Connecting
iPod Charging
Unknown iPod
iPod
iPod Unplugged
Over Current
This unit is in the middle of recognizing
the connection with your iPod.
There is a problem with the signal path
from your iPod to this unit.
The iPod being used is not supported by
this unit.
This unit has recognized your iPod;
however, it cannot obtain information
such as elapsed time.
Your iPod was removed. Connect the iPod again.
The iPod being used is not supported by
this unit.
The iPod is connected at an angle.
* Messages shown above appear only when a device is connected to the iPod dock.
If the message continues to appear in the front panel
display, disconnect and connect the iPod again.
Connect the iPod again.
Only iPod classic, iPod nano (2nd generation and
later), iPod touch and iPhone are supported.
Disconnect the iPod and then turn the unit off and on
again. Then connect supported iPod again.
5
5
—
5
5
Problem Cause Remedy Page
No sound. The power of the unit is off. Connect the power cable correctly.
The iPod/iPad
sounds, but you
cannot operate it with
the unit or the remote
control.
You cannot operate
from the iPod/iPad.
The playback
information is not
displayed on the
front panel display.
The iPod/iPad does
not charge up.
Suddenly the music
being played back is
canceled and another
track starts playing
without performing
any operation.
The iPod/iPad software version has not
been updated.
The iPod/iPad is in the process of
connecting with the unit.
The iPod/iPad is not connected correctly. Remove the iPod/iPad from the unit, then connect it
The iPod/iPad is not connected correctly. Remove the iPod/iPad from the unit, then connect it
The iPod/iPad is not connected correctly. Remove the iPod/iPad from the unit, then connect it
The iPod/iPad you set is not compatible
with the playback information display.
The iPod/iPad is not connected correctly. Remove the iPod/iPad from the unit, then connect it
The iPod’s Shake to Shuffle function is
turned on.
Download the latest iTunes software to update the
iPod/iPad software version to the latest.
Please wait for a while.
again.
again.
again.
Only iPod classic, iPod nano (2nd generation and
later), iPod touch, iPhone and iPad are supported.
again.
Turn off the Shake to Shuffle function in the iPod’s
settings.
—
—
—
5
5
5
5
5
—
14 En
TROUBLESHOOTING
USB/iPad
Note
In case of a transmission error without a status message appearing in the front panel of this unit, check the connection to the USB device
(see page 5).
Status message Cause Remedy Page
USB Unplugged
Unknown USB
Over Current
No Files
USB Time Out
The USB device is not connected
firmly.
The connected USB device is not
playable on this unit.
The file name is too long. The file name should be no more than 250
The USB device is connected at an
angle.
The USB device does not contain
playable files.
An incompatible USB device is
connected to the unit.
The number of files/folders exceeds the
limit.
Connect the USB device again.
Connect playable USB device.
characters.
Disconnect the USB device and then turn the unit off
and on again. Then connect playable USB device
again.
Use a USB device contains playable files.
Turn off the system and reconnect the USB device to
the unit. If it does not resolve the problem, the USB
device is not playable on the unit.
Reduce the number of files/folders; refer to the
limitations noted in this manual.
5
5
—
5
3
—
3
INFORMATION
ADDITIONAL
Problem Cause Remedy Page
MP3/WMA file in the
USB device does not
play.
The USB device is not recognized. Connect the USB device again.
Connect an AC adapter if supplied with the device.
Format the USB device and copy the files again.
Improper USB device connections. Connect the USB device again.
The MP3 or WMA formats are not
compatible with this unit.
If the solutions above do not resolve the
problem, the USB device is not playable
on the unit.
Replace the file with a correctly recorded file
playable with this unit.
Try another USB device.
Radio reception
Problem Cause Remedy Page
FM stereo reception is
noisy.
The desired station
cannot be tuned into
with the automatic
tuning method.
The preset selecting
function does not work.
There is distortion,
and clear reception
cannot be obtained
even with a good
antenna or an outdoor
antenna.
The antenna is connected improperly. Check the antenna connections.
The characteristics of FM stereo
broadcasts may cause this problem
when the transmitter is too far away or
the antenna input is poor.
The signal is too weak. Use a high-quality antenna.
The preset (memory) may have been
erased.
Multipath reflection or other radio
interference may have occurred.
Try using a high-quality antenna.
Use the manual tuning method.
Use the manual tuning method.
Preset radio stations again.
Change the height, direction, or placement of the
antenna.
—
—
—
—
11
—
11
11
—
5
5
3
4
English
15 En
TROUBLESHOOTING
Disc playback
Problem Cause Remedy Page
No sound or
distorted sound
Disc playback does
not start.
Some button
operations do not
work.
Playback does not
start immediately
after pressing
on the unit or on
the remote control.
“No Disc” appears in
the display even
though a disc is in
the disc tray.
The sampling rate of an MP3 or WMA
file may not be compatible with this unit.
You may be using a CD-R/RW that is not
finalized.
The disc label may be upside down. Check that the disc label is facing up.
The disc may be defective. Try playing back another disc. If this cures the
MP3/WMA disc may not contain
sufficient music files to be played back.
The sampling rate of an MP3 or WMA
file may not be compatible with this unit.
The disc loaded into the unit may not be
compatible.
The disc may be dirty. Wipe the disc clean.
The disc loaded into the unit may not be
compatible.
If the unit was moved from a cold to
warm place, condensation may have
formed on the disc reading lens.
The disc loaded into the unit may not be
compatible.
The disc may be dirty. Remove the disc and then wipe the disc clean.
Disc is loaded upside-down. Remove the disc and then load the disc with the
Check the sampling rate and bit rate of an MP3 or
WMA file are compatible with this unit.
Finalize the CD-R/RW.
problem, the disc you want to play back is defective.
Check that your MP3/WMA disc contains at least
5 MP3/WMA music files. If the number of files is
small, the disc may not be recognized.
Check the sampling rate and bit rate of an MP3 or
WMA file are compatible with this unit.
Remove the disc and then check whether the unit
supports the disc or not.
Use a disc supported by the unit.
Wait for an hour or two until the unit adjusts to the
room temperature, and try again.
Use a disc supported by the unit.
labeled side facing up.
3
—
—
—
—
3
3
—
3
—
3
—
—
Remote control
Problem Cause Remedy Page
The remote control
does not work nor
function properly.
16 En
The remote control may be operated
outside its operation range.
The remote control sensor on this unit
may be exposed to direct sunlight or
lighting.
The battery may be worn out. Replace the battery with new one.
There are obstacles between the sensor of
this unit and the remote control.
For information on the remote control operation
range, refer to “Using the remote control”.
Change the lighting or orientation of this unit.
Remove the obstacles.
2
—
2
—
HANDLING COMPACT DISCS
• Always handle with care so that the playing surface is
not scratched. Do not bend discs.
• To keep the playing surface clean, wipe with a clean,
dry cloth. Do not use any type of disc cleaner, spray, or
any other chemical-based liquid.
• Do not expose discs to direct sunlight, high temperature
or high humidity for a long time.
SPECIFICATIONS
PLAYER SECTION
iPod
• Supported iPod.............................................................iPod classic,
iPod nano (2nd generation and later), iPod touch, iPhone, iPad
CD
• Media ...................................................................... CD, CD-R/RW
• Audio format............................................. Audio CD, MP3, WMA
LASER
• Type ........................................Semiconductor laser GaAs/GaAlAs
• Wave length .........................................................................780 nm
• Output Power .......................................................................10 mW
USB
• Audio format................................................................MP3, WMA
AUX
• Input connector .......... STEREO L/R: 3.5 mm STEREO mini Jack
AMPLIFIER SECTION
• Maximum output power ............................................20 W + 20 W
(6 Ω 1 kHz, 10% THD)
• Input impedance (AUX) ........................................................73 kΩ
• Maximum input signal (AUX)................................................2.2 V
• Total harmonic distortion
CD etc. 1 kHz/8 W............................................................... 0.04 %
TUNER SECTION
• Tuning range
FM
[U.S.A. and Canada models] ......................... 87.5 to 107.9 MHz
[Other models]........................................... 87.50 to 108.00 MHz
AM.................................................................... 530 to 1710 KHz
GENERAL
• Power Supply
[Europe model] .................................................AC 230 V, 50 Hz
[U.S.A. and Canada models] ............................AC 120 V, 60 Hz
[Asia model] ........................................ AC 220-240 V, 50/60 Hz
[Taiwan model]......................................... AC 110-120 V, 60 Hz
[Australia model]..............................................AC 240 V, 50 Hz
[U.K. model].....................................................AC 230 V, 50 Hz
[China model] ...................................................AC 220 V, 50 Hz
[Korea model]...................................................AC 220 V, 60 Hz
• Power consumption ................................................................ 32 W
• Do not wipe with a circular motion; wipe straight
outward from the center.
• Use a soft-tipped pen when writing on the label side of a
disc.
• Standby Power consumption...................................... 0.3 W or less
• Dimensions (W × H × D) ........................... 180 × 118 × 318.2 mm
(7 1/8 × 4 5/8 × 12 1/2 in)
• Weight .................................................................. 2.95 kg (6.5 lbs.)
Specifications are subject to change without notice.
iPod, iPhone, iPad
“Made for iPod,” “Made for iPhone,” and “Made for iPad” mean
that an electronic accessory has been designed to connect
specifically to iPod, iPhone, or iPad, respectively, and has been
certified by the developer to meet Apple performance standards.
Apple is not responsible for the operation of this device or its
compliance with safety and regulatory standards.
Please note that the use of this accessory with iPod, iPhone, or
iPad may affect wireless performance.
iPad, iPhone, iPod, iPod classic, iPod nano, iPod shuffle, and
iPod touch are trademarks of Apple Inc., registered in the U.S.
and other countries.
INFORMATION
ADDITIONAL
English
17 En
CAUTION
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous
radiation exposure.
AVERTISSEMENT
L’utilisation de commandes et l’emploi de réglages ou de
méthodes autres que ceux décrits ci-dessous, peuvent
entraîner une exposition à un rayonnement dangereux.
The laser component in this product is capable of emitting radiation
exceeding the limit for Class 1.
Le laser de cet appareil peut émettre un rayonnement dépassant les
limites de la classe 1.
DANGER:
CAUTION:
AVOID DIRECT EXPOSURE TO THE BEAM
INVISIBLE LASER RADIATION WHEN OPEN
DO NOT STARE INTO BEAM
INVISIBLE LASER RADIATION WHEN OPEN
(Traduction française)
DANGER : ÉVITER UNE EXPOSITION DIRECTE AU
RAYON
RADIATION LASER INVISIBLE QUAND
L’APPAREIL EST OUVERT
ATTENTION : NE PAS REGARDER FIXEMENT LE
FAISCEAU
RADIATION LASER INVISIBLE QUAND
L’APPAREIL EST OUVERT
● The label is located on the bottom of the unit. (U.S.A and
Canada models only)
● L’étiquette est situé sur la base de l’unité (États-Unis et le
Canada modèles seulement).
Printed in Malaysia WY88840© 2011 Yamaha Corporation
Loading...
