Yamaha CRW4001t-NB User Manual

CRW4001t

SERIES

User Guide

Guide de I’utilisateur

Bedienungsanleitung

COMPLIANCE INFORMATION STATEMENT

(DECLARATION OF CONFORMITY PROCEDURE)

Responsible Party: Yamaha Systems Technology, Inc.

Address: 100 Century Center Court

San Jose, California 95112

Telephone: [phone]

FAX: [phone]

Type of Equipment: CD Recorder

Model Name: CRW4001t

CRW4001t-NB

This device complies with Part 15 of the FCC Rules.
Operation is subject to the following conditions:

1) this device may not cause harmful interference, and

2) this device must accept any interference received including interference that
may cause undesired operation.
See user manual instructions if interference to radio reception is suspected.

FCC INFORMATION (U.S.A.)

1. IMPORTANT NOTICE: DO NOT MODIFY THIS UNIT!
This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements. Modifications not
expressly approved by Yamaha may void your authority, granted by the FCC, to use the product.

2. IMPORTANT: When connecting this product to accessories and/or another product use only high quality shielded cables. Cable/
s supplied with this product MUST be used. Follow all installation instructions. Failure to follow instructions could void your FCC
authorization to use this product in the USA.

3. NOTE: This product has been tested and found to comply with the requirements listed in FCC Regulations, Part 15 for Class “B”
digital devices. Compliance with these requirements provides a reasonable level of assurance that your use of this product in a
residential environment will not result in harmful interference with other electronic devices. This equipment generates/uses radio
frequencies and, if not installed and used according to the instructions found in the users manual, may cause interference harmful
to the operation of other electronic devices. Compliance with FCC regulations does not guarantee that interference will not occur
in all installations. If this product is found to be the source of interference, which can be determined by turning the product “OFF”
and “ON”, please try to eliminate the problem by using one of the following measures:
Relocate either this product or the device that is being affected by the interference.
Utilize power outlets that are on different branch (circuit breaker or fuse) circuits or install AC line filter/s.
In the case of radio or TV interference, relocate/reorient the antenna. If the antenna lead-in is 300 ohm ribbon lead, change the lead­in to coaxial type cable.
If these corrective measures do not produce satisfactory results, please contact the local retailer authorized to distribute this type
of product. If you can not locate the appropriate retailer, please contact Yamaha Systems Technology, Inc. 100 Century Center
Court, San Jose, CA95112, U.S.A.

• This manual applies to the CRW4001t and CRW4001t-NB.
The CRW4001t front panel displays the YAMAHA brand name.
The CRW4001t-NB front panel does not display a brand name.

Laser Diode Properties

Material : GaAlAs
Wavelength : 780-790 nm
Emission Duration : Continuous
Laser Output Power : Less than 44.6 µW*

*

This output is value measured at a

distance 200mm from the objective lens
surface on the optical pick-up block.
ANSI Class : Class 1

CLASS 1 LASER PRODUCT

LASER KLASSE 1 PRODUKT

VORSICHT : UNSICHTBARE LASERSTRAHLUNG WENN ABDECKUNG
GEOFFNET. NICHT DEM STRAHL AUSSETZEN.

VARNING : OSYNIIG LASERSTRÅLNING NÄR DENNA DEL ÄR ÖPPAND OCH
SPÄRREN ÄR URKOPPLAD. BETRAKTA EJ STRÅRLEN. STRALEN ÄR FARLING.

VARO! : AVATAESSA JA SUOJALUKITUS OHITETTAESSA OLET
ALTTINA NÄKYMÄTTÖMÄLLE LASERS TEILYLLE. ÄLÄ KATSO SÄTESSEN.

ADVARSEL : USYNLIG LASERSTRALNING VED ÅBNING NÄR SIKKERHETSAF­ BYDERE ER UDE AF FUNKTION. UNDGÅ UDSETTELS FOR STRÅLING.

CAUTION

Use of controls or adjustments or performance of
procedures other than those specified herein may
result in hazardous radiation exposure.

This compact disc player is
classified as a CLASS 1
LASER product.
The CLASS 1 LASER
PRODUCT label must be
located on the exterior.

Varningsanvisning för
laserstrålning.

❢

WARNING

W ARNING ❢

• The temperature where CRW4001t is located
should be between 5ºC and 40ºC (41ºF – 104ºF),
when used in a fan-cooled system.

• Do not disassemble the CRW4001t cover to
reduce the risk of electric shock.

• Always remove the disc before transporting
CRW4001t.

i

Important Precautions

Important Precautions

Please read the following precautions before attempt­ing to operate the CRW4001t.

• Before recording a disc, be sure to clean the disc
and tray using an air aerosol-type dust remover.
A dust particle on the disc may cause recording
to fail, producing an unusable disc.

• Always record in a dust-free environment. If the
disc must be removed from the CRW4001t before
recording is finished, store the disc in a clean,
dust-free environment.

• The CRW4001t contains no user serviceable parts.
Refer all servicing to qualified personnel.

• If any of the following should occur , the CRW4001t
should be serviced by qualified personnel:

Metal objects or liquids get inside the CRW4001t.
The CRW4001t does not operate normally or a

marked change in performance is noticed.

• Do not place heavy objects on the CD-RW discs.

• Do not subject the CRW4001t and computer to
impact or shock when in use, as this may impair
recording or playback.

• Yamaha is not responsible for any data or infor­mation losses resulting from the operation of the
CRW4001t.

ii

©199

All Righ

Table of Contents

Table of Contents

Introduction ............................................................................. 1

CRW4001t Features ...................................................... 1

Orange Book Compatible Recording ............................ 2

Chapter 1 - System Configuration ..................................... 3

Computer....................................................................... 3

Software......................................................................... 3

Tools.............................................................................. 3

Discs .............................................................................. 4

Chapter 2 - Installing the Yamaha CRW4001t Drive .......5

MASTER/SLAVE settings............................................ 5

Installing the CRW4001t drive...................................... 7

Chapter 3 - Operation .......................................................... 12

Front Panel................................................................... 12

Loading a Disc............................................................. 13

Ejecting the Disc.......................................................... 14

Troubleshooting ................................................................... 15

Appendix ................................................................................. 16

Specifications............................................................... 16

Front Panel Indicator Key............................................ 17

7 Yamaha Corporation.
This document may not, in whole or in part, be copied, photocopied, reproduced,
translated, transmitted or reduced to any electronic medium of machine readable
form without prior consent in writing from Yamaha.
MS-DOS and Windows are registered trademarks of Microsoft, Inc.
Unix is a registered trademark of UNIX System Laboratories.
All other trademarks are the property of their respective companies.

iii

ts Reserved.

■

Introduction

Thank you for purchasing a Y amaha CRW4001t drive. Please read this
manual before using the drive in order to make the best use of the supe­rior CRW4001t functions.
After reading, please retain this manual for future reference.

CRW4001t Features

2xS Recording (Rewritable) - 4xS Recording (Recor dable) ­6xS Reading

The CRW4001t is able to write (ov erwrite) CD-RW discs at double speed,
and is able to write CD-R discs at quad speed, double speed, or normal
speed.
For both types of media, this drive is able to read at 6X speed, quad speed,
double speed, or normal speed, and any of these modes can be selected
as desired.

■

Compatible with Seven Different Formats

The CRW4001t can both record and read seven different formats:
CD-ROM, CD-R OM XA, CD-I, CD-D A, CD-Bridge (multisession), CD­Extra, and Video CD. The CRW4001t is also equipped with an analog
audio output terminal (headphones) for CD-DA.

Introduction

■

ATAPI for High-Volume, High-Speed Data Transfer

The CRW4001t features AT API/IDE interf ace for connecting computers
and peripheral devices. ATAPI provides high-speed transmission of large
quantities of data, which is especially important when working with image
data.

■

Orange Book Part 2, Part 3 Compatible 5-Mode Recording

The CRW4001t conforms to the five recording modes outlined in the
Orange Book Part 2 and Part 3: T rack at Once, Multisession, Disc at
Once, Session at Once and Packet Writing.

1

Introduction

Orange Book Compatible Recording

Track at Once

In this mode, data can be recorded to disc one track at a time. Discs
recorded in this mode cannot be played in CD players or CD-R OM dri ves
other than a CD-RW or CD-R drive until the session is closed.

Multisession

In this mode, data can be recorded to disc in stages (one session at a time).
Additional data can be written later.

Disc at Once

In this mode, data can be recorded to an entire disc in one pass.
It is not possible to write additional data later.

Session at Once

In this mode, data can be recorded to disc one session at a time. To use
this mode, your software must support Session at Once recording.
New sessions can be written later.

Packet Writing

This is useful for data back-up. Smaller units of data can be added to
tracks. To use this mode, your software must support Packet Writing.

2
